PAMS Technical Documentation

NSE–3 Series Transceivers

Chapter 3

System Module UP8

Original 09/98

NSE–3

PAMS

System Module UP8

AMENDMENT RECORD SHEET

Amendment Number

Issue 1 09/97 Original

Issue 2

Date Inserted By Comments

Technical Documentation

Page 3 – 2

Original 09/98

PAMS

NSE–3

Technical Documentation

CONTENTS

Transceiver NSE–3 3 – 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction 3 – 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Functional Description 3 – 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Interconnection Diagram 3 – 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

System Module 3 – 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External and Internal Connectors 3 – 7. . . . . . . . . . . . . . . . . . . . .

System Connector Contacts 3 – 8. . . . . . . . . . . . . . . . . . . . . . .

RF Connector Contacts 3 – 9. . . . . . . . . . . . . . . . . . . . . . . . . . .

Supply Voltages and Power Consumtion 3 – 9. . . . . . . . . . . .

Functional Description 3 – 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Baseband Module 3 – 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Block Diagram 3 – 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Technical Summary 3 – 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Bottom Connector External Contacts 3 – 12. . . . . . . . . . . . . . .

Bottom Connector Signals 3 – 12. . . . . . . . . . . . . . . . . . . . . . . .

Battery Connector 3 – 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SIM Card Connector 3 – 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Internal Microphone 3 – 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Infrared Module Connections 3 – 15. . . . . . . . . . . . . . . . . . . . . .

RTC Backup Battery 3 – 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Buzzer 3 – 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Functional Description 3 – 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Distribution 3 – 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Battery charging 3 – 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Startup Charging 3 – 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Battery Overvoltage Protection 3 – 19. . . . . . . . . . . . . . . . . . . .

Battery Removal During Charging 3 – 20. . . . . . . . . . . . . . . . . .

Different PWM Frequencies ( 1Hz and 32 Hz) 3 – 21. . . . . . .

Battery Identification 3 – 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Battery Temperature 3 – 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Supply Voltage Regulators 3 – 23. . . . . . . . . . . . . . . . . . . . . . . .

Switched Mode Supply VSIM 3 – 25. . . . . . . . . . . . . . . . . . . . . .

Power Up 3 – 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power up with a charger 3 – 26. . . . . . . . . . . . . . . . . . . . . . . . . .

Power Up With The Power Switch (PWRONX) 3 – 26. . . . . . .

Power Up by RTC 3 – 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Up by IBI 3 – 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Acting Dead 3 – 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Active Mode 3 – 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Sleep Mode 3 – 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Charging 3 – 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Off 3 – 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Watchdog 3 – 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

System Module UP8

Original 09/98

Page 3 – 3

NSE–3

PAMS

System Module UP8

Audio control 3 – 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Audio Connections 3 – 30. . . . . . . . . . . . . . . . . . . . . . .

Analog Audio Accessory Detection 3 – 31. . . . . . . . . . . . . . . . .

Headset Detection 3 – 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Internal Audio Connections 3 – 32. . . . . . . . . . . . . . . . . . . . . . . .

4–wire PCM Serial Interface 3 – 32. . . . . . . . . . . . . . . . . . . . . . .

Alert Signal Generation 3 – 33. . . . . . . . . . . . . . . . . . . . . . . . . . .

Digital Control 3 – 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

MAD2 3 – 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Memories 3 – 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Program Memory 3 – 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SRAM Memory 3 – 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

EEPROM Memory 3 – 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

MCU Memory Map 3 – 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Flash Programming 3 – 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

COBBA–GJ 3 – 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Infrared Transceiver Module 3 – 45. . . . . . . . . . . . . . . . . . . . . . .

Real Time Clock 3 – 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RTC backup battery charging 3 – 46. . . . . . . . . . . . . . . . . . . . . .

Vibra Alerting Device 3 – 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

IBI Accessories 3 – 47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Phone Power–on by IBI 3 – 47. . . . . . . . . . . . . . . . . . . . . . . . . . .

IBI power–on by phone 3 – 47. . . . . . . . . . . . . . . . . . . . . . . . . . .

RF Module 3 – 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Maximum Ratings 3 – 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RF Frequency Plan 3 – 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Distribution Diagram 3 – 49. . . . . . . . . . . . . . . . . . . . . . . . . .

DC Characteristics 3 – 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Regulators 3 – 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Control Signals 3 – 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Functional Description 3 – 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Frequency synthesizers 3 – 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Receiver 3 – 52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Transmitter 3 – 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

AGC strategy 3 – 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

AFC function 3 – 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Receiver blocks 3 – 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RX interstage filter 3 – 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1st mixer in CRFU_1a 3 – 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1st IF–filter 3 – 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Technical Documentation

Page 3 – 4

Original 09/98

PAMS

NSE–3

Technical Documentation

Transmitter Blocks 3 – 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX interstage filter 3 – 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power amplifier MMIC 3 – 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Synthesizer blocks 3 – 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

VHF VCO and low pass filter 3 – 57. . . . . . . . . . . . . . . . . . . . . . . .

UHF PLL 3 – 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

UHF PLL block in PLUSSA 3 – 57. . . . . . . . . . . . . . . . . . . . . . . . . .

UHF VCO module 3 – 58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

UHF local signal input in CRFU_1a 3 – 58. . . . . . . . . . . . . . . . . . .

Connections 3 – 58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RF connector and antenna switch 3 – 58. . . . . . . . . . . . . . . . . . . .

Timings 3 – 61. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Synthesizer control timing 3 – 61. . . . . . . . . . . . . . . . . . . . . . . . . . .

Transmitter power switching timing diagram 3 – 63. . . . . . . . . . .

Synthesizer clocking 3 – 63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Block Diagram of Baseband Blocks 3 – 64. . . . . . . . . . . . . . . . . . .

System Module UP8

Parts list of UP8T (EDMS Issue 11.10) 3 – 65

Schematic Diagrams:

Block Diagram of System/RF Blocks 3/A3–1. . . . . . . . . . . . . . . . . . . . . .

Circuit Diagram of Baseband (Version 12 Edit 8) 3/A3–2. . . . . . . . . .

Circuit Diagram of Power Supply (Version 14 Edit 41) 3/A3–3. . . . . .

Circuit Diagram of SIM Connectors (Version 14 Edit 9) 3/A3–4. . . . . .

Circuit Diagram of CPU Block (Version 14 Edit 23) 3/A3–5. . . . . . . . .

Circuit Diagram of Audio (Version 14 Edit 27) 3/A3–6. . . . . . . . . . . . .

Circuit Diagram of IR Module (Version 14 Edit 21) 3/A3–7. . . . . . . . . .

Circuit Diagram of RF Block (Version 14 Edit 26) 3/A3–8. . . . . . . . . . .

Layout Diagram of UPT8T (Version 14) 3/A3–9. . . . . . . . . . . . . . . . . . .

Original 09/98

Page 3 – 5

NSE–3

PAMS

System Module UP8

Transceiver NSE–3

Introduction

The NSE–3 is a radio transceiver unit designed for the GSM network. It is a

GSM phase 2 power class 4 transceiver providing 15 power levels with a

maximum output power of 2 W. The transceiver is a true 3 V transceiver.

The transceiver consists of System/RF module (UP8T), User interface

module (UE4) and assembly parts.

The transceiver has full graphic display and two soft key based user inter-

face.

The antenna is a fixed helix. External antenna connection is provided by

rear RF connector

Functional Description

Technical Documentation

There are five different operation modes:

– power off mode

– idle mode

– active mode

– charge mode

– local mode

In the power off mode only the circuits needed for power up are supplied.

In the idle mode circuits are powered down and only sleep clock is run-

ning.

In the active mode all the circuits are supplied with power although some

parts might be in the idle state part of the time.

The charge mode is effective in parallel with all previous modes. The

charge mode itself consists of two different states, i.e. the charge and the

maintenance mode.

The local mode is used for alignment and testing.

Page 3 – 6

Original 09/98

PAMS

NSE–3

Technical Documentation

Interconnection Diagram

10 9

System Module UP8

Keypad Display

User Interface

Module

UE4

Earpiece

SIM Battery

System/RF

Module

Antenna

Mic

Connector

UP8

System

Connector

Charger

3 + 36

IR Link

Original 09/98

Page 3 – 7

NSE–3

PAMS

System Module UP8

System Module

External and Internal Connectors

Technical Documentation

Rubber boot

Microphone

Contact 1

DC–jack

Contact 2

Microphone port

Contacts

3...8 Contact 9

Solderable element,

2 pcs

Cable/Cradle connector, guiding/fixing hole, 3 pcs

Page 3 – 8

Original 09/98

PAMS

NSE–3

Technical Documentation

System Connector Contacts

Con-

tact

1 VIN Charger input volt-

DC– JACK

Line

Sym-

bol

L_GND Charger ground

VIN Charger input volt-

Parameter Mini-

age Charger input cur-

rent

input

age Charger input cur-

rent

System Module UP8

Typical

mum

7.1 720

7.24 320

0 0 0 V/ Supply ground

7.1 720

7.24 320

/ Nomi-

nal

8.4 800

7.6 370

8.4 800

7.6 370

Maxi-

mum

9.3 850

16.0 420

9.3 850

16.0 420

Unit / Notes

V/ Unloaded ACP–9 Charger mA/ Supply current V/ Unloaded ACP–7 Charger mA/ Supply current

DC– JACK

2 CHRG

Mic ports

3 XMIC Input signal volt-

4 SGND Signal ground 0 0 mVrms 5 XEAR Output signal volt-

6 MBUS I/O low voltage

7 FBUS_RXInput low voltage

CHRG CTRL

CTRL

Output high voltage

PWM frequency output low voltage

Output high voltage

PWM frequency

Acoustic signal N/A N/A N/A Microphone sound ports

age

I/O high voltage

Input high voltage02.0

2.0

2.8

0.5

2.8 V/ Charger control (PWM)

60 1 Vpp mVrms

80 1 Vpp mVrms

0.8

2.8

0.8

2.8

V/ Charger control (PWM) high

Hz /PWM frequency for charger V

high Hz /PWM frequency for

charger

Serial bidirectional control bus. Baud rate 9600 Bit/s

V/ Fbus receive. V/ Serial Data, Baud rate

9.6k–230.4kBit/s

8 FBUS_TXOutput low voltage

Output high voltage

9 L_GND Charger ground

input

Original 09/98

2.0

0 0 0 V/ Supply ground

0.8

2.8

V/ Fbus transmit. V/ Serial Data, Baud rate

9.6k–230.4kBit/s

Page 3 – 9

NSE–3

Im edance

50ohm

tor

PAMS

System Module UP8

Technical Documentation

RF Connector Contacts

Con-

tact

1 EXT_ANT 2 GND

Line

Symbol

Parameter Mini-

mum

Typical / Nomi-

nal

Maxi-

mum

Unit / Notes

External antenna connec-

0 V DC

Supply Voltages and Power Consumtion

Connector Line Symbol Minimum Typical /

Nominal

Charging VIN 7.1 8.4 9.3 V/ Travel charger,

Charging VIN 7.25 7.6 16.0 V/ Travel charger.

Charging I / VIN 720 800 850 mA/ Travel char-

Charging I / VIN 320 370 420 mA/ Travel char-

Maximum/

Peak

Unit / Notes

ACP–9

ACP–7

ger, ACP–9

ger, ACP–7

Functional Description

The transceiver electronics consist of the Radio Module ie. RF + System blocks, the UI PCB, the display module and audio components. The keypad and the display module are connected to the Radio Module with a connectors. System blocks and RF blocks are interconnected with PCB wiring. The Transceiver is connected to accessories via a bottom system connector with charging and accessory control.

The System blocks provide the MCU, DSP and Logic control functions in MAD ASIC, external memories, audio processing and RF control hardware in COBBA ASIC. Power supply circuitry CCONT ASIC delivers operating voltages both for the System and the RF blocks.

The RF block is designed for a handportable phone which operates in the GSM system. The purpose of the RF block is to receive and demodulate the radio frequency signal from the base station and to transmit a modulated RF signal to the base station. The PLUSSA ASIC is used for VHF and PLL functions. The CRFU ASIC is used at the front end.

Page 3 – 10

Original 09/98

PAMS

NSE–3

Technical Documentation

Baseband Module

Block Diagram

TX/RX SIGNALS

COBBA

COBBA SUPPLY

RF SUPPLIES

CCONT

BB SUPPLY

PA SUPPLY

SIM

32kHz CLK

SLEEP CLOCK

System Module UP8

13MHz

SYSTEM CLOCK

CLK

AUDIOLINES

BASEBAND

Technical Summary

The baseband module consists of four asics, CHAPS, CCONT, COBBA– GJ and MAD2, which take care of the baseband functions of NSE–3.

The baseband is running from a 2.8V power rail, which is supplied by a power controlling asic. In the CCONT asic there are 6 individually controlled regulator outputs for RF–section and two outputs for the baseband. In addition there is one +5V power supply output (V5V) for flash programming voltage and other purposes where a higher voltage is needed. The CCONT contains also a SIM interface, which supports both 3V and 5V SIM–cards. A real time clock function is integrated into the CCONT, which utilizes the same 32kHz clock supply as the sleep clock. A backup power supply is provided for the RTC, which keeps the real time clock running when the main battery is removed. The backup power supply is a rechargable polyacene battery. The backup time with this battery is minimum of ten minutes.

MAD +

MEMORIES

VBAT

BATTERY

CHAPS

SYSCON

Original 09/98

Page 3 – 11

NSE–3

PAMS

System Module UP8

The interface between the baseband and the RF section is handled by a specific asic. The COBBA asic provides A/D and D/A conversion of the in–phase and quadrature receive and transmit signal paths and also A/D and D/A conversions of received and transmitted audio signals to and from the UI section. The COBBA supplies the analog TXC and AFC signals to rf section according to the MAD DSP digital control and converts analog AGC into digital signal for the DSP. Data transmission between the COBBA and the MAD is implemented using a parallel connection for high speed signalling and a serial connection for PCM coded audio signals. Digital speech processing is handled by the MAD asic. The COBBA asic is a dual voltage circuit, the digital parts are running from the baseband supply VBB and the analog parts are running from the analog supply VCOBBA.

The baseband supports three external microphone inputs and two external earphone outputs. The inputs can be taken from an internal microphone, a headset microphone or from an external microphone signal source. The microphone signals from different sources are connected to separate inputs at the COBBA asic.

Technical Documentation

The output for the internal earphone is a dual ended type output capable of driving a dynamic type speaker. Input and output signal source selection and gain control is performed inside the COBBA asic according to control messages from the MAD. Keypad tones, DTMF, and other audio tones are generated and encoded by the MAD and transmitted to the COBBA for decoding. A buzzer and an external vibra alert control signals are generated by the MAD with separate PWM outputs.

EMC shieding is implemented using a metallized plastic B–cover with a conductive rubber seal on the ribs. On the other side the engine is shielded with a frame having a conductive rubber on the inner walls, which makes a contact to a ground ring of the engine board and a ground plane of the UI–board. Heat generated by the circuitry will be conducted out via the PCB ground planes.

Page 3 – 12

Original 09/98

PAMS

NSE–3

Technical Documentation

System Module UP8

Bottom Connector External Contacts

Contact Line Symbol Function

1 VIN Charger input voltage DC–jack

side contact (DC–plug ring)

DC–jack center pin

DC–jack side contact (DC–plug jacket)

2 CHRG_CTRL Charger control output (from phone) Microphone

acoustic ports 3 XMIC Accessory microphone signal input (to phone) 4 SGND Accessory signal ground

L_GND Charger ground

VIN Charger input voltage

CHRG_CTRL Charger control output (from phone)

Acoustic signal (to phone)

5 XEAR Accessory earphone signal output (from phone) 6 MBUS MBUS, bidirectional serial data i/o 7 FBUS_RX FBUS, unidirectional serial data input (to phone) 8 FBUS_TX FBUS, unidirectional serial data output (from phone) 9 L_GND Charger ground

Bottom Connector Signals

Pin Name Min Typ Max Unit Notes

1,3 VIN

2 L_GND 0 0 V Supply ground

7.25

3.25 320

7.1

3.25 720

7.6

3.6

370

8.4

3.6

800

7.95

16.9

3.95 420

9.3

3.95 850

V V V

V V

Unloaded ACP–7 Charger (5kohms load)

Peak output voltage (5kohms load) Loaded output voltage (10ohms load) Supply current

Unloaded ACP–9 Charger Loaded output voltage (10ohms load) Supply current

4,5 CHRG_

TRL

6 MICP N/A see section Internal microphone 7 MICN N/A see section Internal microphone

Original 09/98

0 0.5 V Charger control PWM low

2.0 2.85 V Charger control PWM high 32 Hz PWM frequency for a fast charger

1 99 % PWM duty cycle

Page 3 – 13

NSE–3

Baud rate 9600 Bit/s

Baud rate 9.6k–230.4kBit/s

PAMS

System Module UP8

8 XMIC

HMIC 0 3.2 29.3 mV Microphone signal

9 SGND

10 XEAR

2.0 2.2 kΩ Input AC impedance

1.47 1.55 V Mute (output DC level)

2.5 2.85 V Unmute (output DC level)

100 600 µA Bias current

Technical Documentation

NotesUnitMaxTypMinNamePin

1 Vpp Maximum signal level

58 490 mV Maximum signal level

Connected to COBBA MIC3P input 47 Ω Output AC impedance (ref. GND) 10 µF Series output capacitance

380 Ω Resistance to phone ground

47 Ω Output AC impedance (ref. GND) 10 µF Series output capacitance

16 300 Ω Load AC impedance to SGND (Head-

4.7 10 kΩ Load AC impedance to SGND (Acces-

1.0 Vpp Maximum output level (no load) 22 626 mV Output signal level 10 kΩ Load DC resistance to SGND (Acces-

16 1500 Ω Load DC resistance to SGND (Head-

2.8 V DC voltage (47k pull–up to VBB)

HEAR 28 626 mV Earphone signal (HF– HFCM)

11 MBUS 0 logic low

2.0 logic high 2.85

12 FBUS_RX 0 logic low

2.0 logic high 2.85

13 FBUS_TX 0 logic low

2.0 logic high 2.85

set)

sory)

set)

Connected to COBBA HF output

0.8 V Serial bidirectional control bus. Phone has a 4k7 pullup resistor

0.8 V Fbus receive. Serial Data Phone has a 220k pulldown resistor

0.5 V Fbus transmit. Serial Data Phone has a 47k pullup resistor

14 GND 0 0.3 V Supply ground

Page 3 – 14

Original 09/98

PAMS

5.0

Maximum voltage in call state with charger

NSE–3

Technical Documentation

System Module UP8

Battery Connector

Pin Name Min Typ Max Unit Notes

1 BVOLT 3.0 3.6 4.5

5.3

2 BSI

3 BTEMP

0 2.85 V Battery size indication

2.2 18 kohm Battery indication resistor (Ni battery) 20 22 24 kohm Battery indication resistor (service battery) 27 51 kohm Battery indication resistor (4.1V Lithium

68 91 kohm Battery indication resistor (4.2V Lithium bat-

0 1.4 V Battery temperature indication

V Battery voltage

Maximum voltage in idle state with charger

Phone has 100kohm pull up resistor.

SIM Card removal detection

(Treshold is 2.4V@VBB=2.8V)

battery)

tery)

Phone has a 100k (+–5%) pullup resistor,

Battery package has a NTC pulldown resis-

tor:

47k+–5%@+25C , B=4050+–3%

2.1

5 10

1.9 90 100

0 1 kohm Local mode initialization (in production)

20 22 25 kHz PWM control to VIBRA BATTERY

4 BGND 0 0 V Battery ground

2.85 200

Phone power up by battery (input)

Power up pulse width

Battery power up by phone (output)

Power up pulse width

SIM Card Connector

Pin Name Parameter Min Typ Max Unit Notes

4 GND GND 0 0 V Ground

3, 5 VSIM 5V SIM Card

3V SIM Card

6 DATA 5V Vin/Vout

3V Vin/Vout

2 SIMRST 5V SIM Card

3V SIM Card

4.8

2.8

4.0 0

2.8 0

4.0

2.8

5.0

3.0 ”1”

”0” ”1” ”0” ”1” ”1”

5.2

3.2

VSIM

0.5

VSIM

0.5 VSIM VSIM

V Supply voltage

V SIM data

Trise/Tfall max 1us

V SIM reset

1 SIMCLK Frequency

Trise/Tfall

Original 09/98

3.25 25

MHz

SIM clock

Page 3 – 15

NSE–3

PAMS

System Module UP8

Technical Documentation

Internal Microphone

Pin Name Min Typ Max Unit Notes

6 MICP 0.55 4.1 mV Connected to COBBA MIC2N input. The

maximum value corresponds to1 kHz, 0 dBmO network level with input amplifier gain set to 32 dB. typical value is maximum value – 16 dB.

7 MICN 0.55 4.1 mV Connected to COBBA MIC2P input. The

maximum value corresponds to1 kHz, 0 dBmO network level with input amplifier gain set to 32 dB. typical value is maximum value – 16 dB.

Infrared Module Connections

An infrared transceiver module is designed to substitute an electrical cable between the phone and a PC. The infrared transceiver module is a stand alone component capable to perform infrared transmitting and receiving functions by transforming signals transmitted in infrared light from and to electrical data pulses running in two wire asyncronous databus. In DCT3 the module is placed inside the phone at the top of the phone.

Signal Parameter Min Typ Max Unit Notes

IRON IR–module on/off 2.0 2.85 V Iout@2mA FBUS_RX

FBUS_TX

IR receive pulse 0 0.8 V IR receive no pulse 2.0 2.85 V IR transmit pulse 2.0 2.85 V Iout@2mA IR transmit no pulse 0 0.5 V

RTC Backup Battery

The RTC block in CCONT needs a power backup to keep the clock running when the phone battery is disconnected. The backup power is supplied from a rechargable polyacene battery that can keep the clock running minimum of 10 minutes. The backup battery is charged from the main battery through CHAPS.

Signal Parameter Min Typ Max Unit Notes

VBACK

Backup battery charging from CHAPS

Backup battery supply to CCONT

3.02 3.15 3.28 V

100 200 500 uA Vout@VBAT–0.2V

2 3.28 V Battery capacity

65uAh

80 uA

Page 3 – 16

Original 09/98

PAMS

NSE–3

Technical Documentation

Buzzer

Signal Maximum

output cur-

rent

BuzzPWM /

BUZZER

2mA 2.5V 0.2V 0...50 (128 lin-

Input

high level

Input

low level

System Module UP8

Level (PWM)

range, %

ear steps)

Frequency

range, Hz

440...4700

Original 09/98

Page 3 – 17

NSE–3

PAMS

System Module UP8

Functional Description

Power Distribution

In normal operation the baseband is powered from the phone‘s battery. The battery consists of one Lithium–Ion cell. There is also a possibility to use batteries consisting of three Nickel Metal Hydride cells. An external charger can be used for recharging the battery and supplying power to the phone. The charger can be either a standard charger that can deliver around 400 mA or so called performance charger, which can deliver supply current up to 850 mA.

The baseband contains components that control power distribution to whole phone excluding those parts that use continuous battery supply. The battery feeds power directly to three parts of the system: CCONT, power amplifier, and UI (buzzer and display and keyboard lights). Figure 4 shows a block diagram of the power distribution.

Technical Documentation

The power management circuit CHAPS provides protection agains overvoltages, charger failures and pirate chargers etc. that would otherwise cause damage to the phone.

PA SUPPLY

VCOBBA

COBBA

VBAT

VBB

MAD

MEMORIES

RF SUPPLIES

CCONT

PWRONX

CNTVR

VBB PURX

PWM

LIM

CHAPS

VSIM

VBAT

RTC

BACKUP

SIM

BATTERY

Page 3 – 18

BASEBAND

VIN

BOTTOM CONNECTOR

Original 09/98

PAMS

NSE–3

Technical Documentation

Battery charging

The electrical specifications give the idle voltages produced by the acceptable chargers at the DC connector input. The absolute maximum input voltage is 30V due to the transient suppressor that is protecting the charger input. At phone end there is no difference between a plug–in charger or a desktop charger. The DC–jack pins and bottom connector charging pads are connected together inside the phone.

MAD

0R22

VBAT

MAD

CCONTINT

CCONT

ICHAR

PWM_OUT

VCHAR

GND

LIM VOUT

CHAPS

RSENSE

PWM

22k

VCH

GND

TRANSCEIVER

100k

10k

30V

System Module UP8

CHARGER

VIN

CHRG_CTRL

L_GND

NOT IN ACP–7

Startup Charging

When a charger is connected, the CHAPS is supplying a startup current minimum of 130mA to the phone. The startup current provides initial charging to a phone with an empty battery. Startup circuit charges the battery until the battery voltage level is reaches 3.0V (+/– 0.1V) and the CCONT releases the PURX reset signal and program execution starts. Charging mode is changed from startup charging to PWM charging that is controlled by the MCU software. If the battery voltage reaches 3.55V (3.75V maximum) before the program has taken control over the charging, the startup current is switched off. The startup current is switched on again when the battery voltage is sunken 100mV (nominal).

Parameter Symbol Min Typ Max Unit

VOUT Start– up mode cutoff limit Vstart 3.45 3.55 3.75 V

VOUT Start– up mode hysteresis

NOTE: Cout = 4.7 uF

Start–up regulator output current

VOUT = 0V ... Vstart

Vstarthys 80 100 200 mV

Istart 130 165 200 mA

Original 09/98

Page 3 – 19

NSE–3

PAMS

System Module UP8

Battery Overvoltage Protection

Output overvoltage protection is used to protect phone from damage. This function is also used to define the protection cutoff voltage for different battery types (Li or Ni). The power switch is immediately turned OFF if the voltage in VOUT rises above the selected limit VLIM1 or VLIM2.

Parameter Symbol LIM input Min Typ Max Unit

Output voltage cutoff limit

(during transmission or Li–

battery)

Output voltage cutoff limit

(no transmission or Ni–bat-

tery)

VLIM1 LOW 4.4 4.6 4.8 V

VLIM2 HIGH 4.8 5.0 5.2 V

The voltage limit (VLIM1 or VLIM2) is selected by logic LOW or logic HIGH on the CHAPS (N101) LIM– input pin. Default value is lower limit VLIM1.

Technical Documentation

VCH

VCH<VOUT

VOUT

VLIM1 or VLIM2

When the switch in output overvoltage situation has once turned OFF, it stays OFF until the the battery voltage falls below VLIM1 (or VLIM2) and PWM = LOW is detected. The switch can be turned on again by setting PWM = HIGH.

SWITCH

PWM (32Hz)

Page 3 – 20

ON OFF

Original 09/98

PAMS

NSE–3

Technical Documentation

Battery Removal During Charging

Output overvoltage protection is also needed in case the main battery is removed when charger connected or charger is connected before the battery is connected to the phone.

With a charger connected, if VOUT exceeds VLIM1 (or VLIM2), CHAPS turns switch OFF until the charger input has sunken below Vpor (nominal

3.0V, maximum 3.4V). MCU software will stop the charging (turn off PWM) when it detects that battery has been removed. The CHAPS remains in protection state as long as PWM stays HIGH after the output overvoltage situation has occured.

VCH (Standard Charger)

VOUT

Vpor

VLIM

Vstart

Droop depends on load

& C in phone

System Module UP8

Istart off due to VCH<Vpor

Vstarthys

PWM

SWITCH

1.1Battery removed, (standard) charger connected, VOUT rises (follows charger voltage)

2. VOUT exceeds limit VLIM(X), switch is turned immediately OFF

3.3VOUT falls (because no battery) , also VCH<Vpor (standard chargers full–rectified

4. Software sets PWM = LOW –> CHAPS does not enter PWM mode

5. PWM low –> Startup mode, startup current flows until Vstart limit reached

6. VOUT exceeds limit Vstart, Istart is turned off

7. VCH falls below Vpor

”1”

”0”

OFF

output). When VCH > Vpor and VOUT < VLIM(X) –> switch turned on again (also PWM is still HIGH) and VOUT again exceeds VLIM(X).

Original 09/98

Page 3 – 21

NSE–3

PAMS

System Module UP8

Different PWM Frequencies ( 1Hz and 32 Hz)

When a travel charger (2– wire charger) is used, the power switch is turned ON and OFF by the PWM input when the PWM rate is 1Hz. When PWM is HIGH, the switch is ON and the output current Iout = charger current – CHAPS supply current. When PWM is LOW, the switch is OFF and the output current Iout = 0. To prevent the switching transients inducing noise in audio circuitry of the phone soft switching is used.

The performance travel charger (3– wire charger) is controlled with PWM at a frequency of 32Hz. When the PWM rate is 32Hz CHAPS keeps the power switch continuously in the ON state.

SWITCH

ON ONON OFF OFF

Technical Documentation

PWM (1Hz)

SWITCH

PWM (32Hz)

Page 3 – 22

Original 09/98

PAMS

NSE–3

Technical Documentation

Battery Identification

Different battery types are identified by a pulldown resistor inside the battery pack. The BSI line inside transceiver has a 100k pullup to VBB. The MCU can identify the battery by reading the BSI line DC–voltage level with a CCONT (N100) A/D–converter.

BATTERY

BVOLT

BTEMP

BSI

2.8V

100k

10k

System Module UP8

TRANSCEIVER

BSI

CCONT

The battery identification line is used also for battery removal detection. The BSI line is connected to a SIMCardDetX line of MAD2 (D200). SIMCardDetX is a threshold detector with a nominal input switching level

0.85xVcc for a rising edge and 0.55xVcc for a falling edge. The battery removal detection is used as a trigger to power down the SIM card before the power is lost. The BSI contact in the battery pack is made 0.7mm shorter than the supply voltage contacts so that there is a delay between battery removal detection and supply power off,

Vcc

0.850.05 Vcc

0.550.05 Vcc

BGND

10n

SIMCardDetX

MAD

GND

Original 09/98

SIMCARDDETX

IGOUT

Page 3 – 23

NSE–3

PAMS

System Module UP8

Battery Temperature

The battery temperature is measured with a NTC inside the battery pack. The BTEMP line inside transceiver has a 100k pullup to VREF. The MCU can calculate the battery temperature by reading the BTEMP line DC– voltage level with a CCONT (N100) A/D–converter.

BATTERY

BVOLT

BSI

BTEMP

Technical Documentation

TRANSCEIVER

VREF

100k

10k

BTEMP

CCONT

NTC

Supply Voltage Regulators

The heart of the power distrubution is the CCONT. It includes all the voltage regulators and feeds the power to the whole system. The baseband digital parts are powered from the VBB regulator which provides 2.8V baseband supply. The baseband regulator is active always when the phone is powered on. The VBB baseband regulator feeds MAD and memories, COBBA digital parts and the LCD driver in the UI section. There is a separate regulator for a SIM card. The regulator is selectable between 3V and 5V and controlled by the SIMPwr line from MAD to CCONT. The COBBA analog parts are powered from a dedicated 2.8V supply VCOBBA. The CCONT supplies also 5V for RF and for flash VPP. The CCONT contains a real time clock function, which is powered from a RTC backup when the main battery is disconnected.

BGND

10n

VibraPWM

MAD

MCUGenIO4

Page 3 – 24

Original 09/98

PAMS

NSE–3

Technical Documentation

The RTC backup is rechargable polyacene battery, which has a capacity of 50uAh (@3V/2V) The battery is charged from the main battery voltage by the CHAPS when the main battery voltage is over 3.2V. The charging current is 200uA (nominal).

Operating mode Vref RF REG VCOB-

Power off Off Off Off Off Off Pull

Power on On On/Off On On On On/Off Reset On Off

VR1 On

Sleep On Off On On On On/Off

NOTE:

On On Off Pull

VBB VSIM SIMIF

System Module UP8

down

CCONT includes also five additional 2.8V regulators providing power to the RF section. These regulators can be controlled either by the direct control signals from MAD or by the RF regulator control register in CCONT which MAD can update. Below are the listed the MAD control lines and the regulators they are controlling.

– TxPwr controls VTX regulator (VR5) – RxPwr controls VRX regulator (VR2) – SynthPwr controls VSYN_1 and VSYN_2 regulators (VR4 and VR3) – VCXOPwr controls VXO regulator (VR1) CCONT generates also a 1.5 V reference voltage VREF to COBBA,

PLUSSA and CRFU. The VREF voltage is also used as a reference to some of the CCONT A/D converters.

In additon to the above mentioned signals MAD includes also TXP control signal which goes to PLUSSA power control block and to the power amplifier. The transmitter power control TXC is led from COBBA to PLUSSA.

Original 09/98

Page 3 – 25

NSE–3

PAMS

System Module UP8

Switched Mode Supply VSIM

There is a switched mode supply for SIM–interface. SIM voltage is selected via serial IO. The 5V SMR can be switched on independently of the SIM voltage selection, but can’t be switched off when VSIM voltage value is set to 5V.

NOTE: VSIM and V5V can give together a total of 30mA. In the next figure the principle of the SMR / VSIM–functions is shown.

CCONT External

VBAT

Technical Documentation

V5V_4 V5V_3

V5V_2

Power Up

VSIM

The baseband is powered up by:

1. Pressing the power key, that generates a PWRONX interrupt

2. Connecting a charger to the phone. The CCONT recognizes

3. A RTC interrupt. If the real time clock is set to alarm and the

5V reg

V5V

signal from the power key to the CCONT, which starts the power up procedure.

the charger from the VCHAR voltage and starts the power up procedure.

phone is switched off, the RTC generates an interrupt signal, when the alarm is gone off. The RTC interrupt signal is connected to the PWRONX line to give a power on signal to the CCONT just like the power key.

5/3V

Page 3 – 26

4. A battery interrupt. Intelligent battery packs have a possibility to power up the phone. When the battery gives a short (10ms) voltage pulse through the BTEMP pin, the CCONT wakes up and starts the power on procedure.

Original 09/98

PAMS

NSE–3

Technical Documentation

Power up with a charger

When the charger is connected CCONT will switch on the CCONT digital voltage as soon as the battery voltage exeeds 3.0V. The reset for CCONT’s digital parts is released when the operating voltage is stabilized ( 50 us from switching on the voltages). Operating voltage for VCXO is also switched on. The counter in CCONT digital section will keep MAD in reset for 62 ms (PURX) to make sure that the clock provided by VCXO is stable. After this delay MAD reset is relased, and VCXO –control (SLEEPX) is given to MAD. The diagram assumes empty battery, but the situation would be the same with full battery:

When the phone is powered up with an empty battery pack using the standard charger, the charger may not supply enough current for standard powerup procedure and the powerup must be delayed.

Power Up With The Power Switch (PWRONX)

System Module UP8

When the power on switch is pressed the PWRONX signal will go low. CCONT will switch on the CCONT digital section and VCXO as was the case with the charger driven power up. If PWRONX is low when the 64 ms delay expires, PURX is released and SLEEPX control goes to MAD. If PWRONX is not low when 64 ms expires, PURX will not be released, and CCONT will go to power off ( digital section will send power off signal to analog parts)

SLEEPX

PURX

CCPURX

PWRONX

12 3

1:Power switch pressed ==> Digital voltages on in CCONT (VBB) 2: CCONT digital reset released. VCXO turned on 3: 62 ms delay to see if power switch is still pressed.

Original 09/98

VR1,VR6 VBB (2.8V)

Vchar

Page 3 – 27

NSE–3

PAMS

System Module UP8

Power Up by RTC

RTC ( internal in CCONT) can power the phone up by changing RTCPwr to logical ”1”. RTCPwr is an internal signal from the CCONT digital section.

Power Up by IBI

IBI can power CCONT up by sending a short pulse to logical ”1”. RTCPwr is an internal signal from the CCONT digital section.

Acting Dead

If the phone is off when the charger is connected, the phone is powered on but enters a state called ”acting dead”. To the user the phone acts as if it was switched off. A battery charging alert is given and/or a battery charging indication on the display is shown to acknowledge the user that the battery is being charged.

Active Mode

Technical Documentation

In the active mode the phone is in normal operation, scanning for channels, listening to a base station, transmitting and processing information. All the CCONT regulators are operating. There are several substates in the active mode depending on if the phone is in burst reception, burst transmission, if DSP is working etc..

Sleep Mode

In the sleep mode, all the regulators except the baseband VBB, VCOBBA, and the SIM card VSIM regulators are off. Sleep mode is activated by the MAD after MCU and DSP clocks have been switched off. The voltage regulators for the RF section are switched off and the VCXO power control, VCXOPwr is set low. In this state only the 32 kHz sleep clock oscillator in CCONT is running. The flash memory power down input is connected to the ExtSysResetX signal, and the flash is deep powered down during the sleep mode.

The sleep mode is exited either by the expiration of a sleep clock counter in the MAD or by some external interrupt, generated by a charger connection, key press, headset connection etc. The MAD starts the wake up sequence and sets the VCXOPwr and ExtSysResetX control high. After VCXO settling time other regulators and clocks are enabled for active mode.

Charging

Page 3 – 28

If the battery pack is disconnect during the sleep mode, the CCONT pulls the SIM interface lines low as there is no time to wake up the MCU.

Charging can be performed in any operating mode. The charging algorithm is dependent on the used battery technology. The battery type is in-

Original 09/98

PAMS

NSE–3

Technical Documentation

dicated by a resistor inside the battery pack. The resistor value corresponds to a specific battery capacity. This capacity value is related to the battery technology as different capacity values are achieved by using different battery technology.

The battery voltage, temperature, size and current are measured by the CCONT controlled by the charging software running in the MAD.

The power management circuitry controls the charging current delivered from the charger to the battery. Charging is controlled with a PWM input signal, generated by the CCONT. The PWM pulse width is controlled by the MAD and sent to the CCONT through a serial data bus. The battery voltage rise is limited by turning the CHAPS switch off when the battery voltage has reached 4.2V (LiIon) or 5.2V (NiMH, 5V in call mode). Charging current is monitored by measuring the voltage drop across a 220mohm resistor.

Power Off

The baseband is powered down by:

System Module UP8

1. Pressing the power key, that is monitored by the MAD, which starts the power down procedure.

2. If the battery voltage is dropped below the operation limit, either by not charging it or by removing the battery.

3. Letting the CCONT watchdog expire, which switches off all CCONT regulators and the phone is powered down.

4. Setting the real time clock to power off the phone by a timer. The RTC generates an interrupt signal, when the alarm is gone off. The RTC interrupt signal is connected to the PWRONX line to give a power off signal to the CCONT just like the power key.

The power down is controlled by the MAD. When the power key has been pressed long enough or the battery voltage is dropped below the limit the MCU initiates a power down procedure and disconnects the SIM power. Then the MCU outputs a system reset signal and resets the DSP. If there is no charger connected the MCU writes a short delay to CCONT watchdog and resets itself. After the set delay the CCONT watchdog expires, which activates the PURX and all regulators are switched off and the phone is powered down by the CCONT.

If a charger is connected when the power key is pressed the phone enters into the acting dead mode.

Watchdog

The Watchdog block inside CCONT contains a watchdog counter and some additional logic which are used for controlling the power on and power off procedures of CCONT. Watchdog output is disabled when WDDisX pin is tied low. The WD-counter runs during that time, though. Watchdog counter is reset internally to 32s at power up. Normally it is reset by MAD writing a control word to the WDReg.

Original 09/98

Page 3 – 29

NSE–3

PAMS

System Module UP8

Audio control

The audio control and processing is taken care by the COBBA–GJ, which contains the audio and RF codecs, and the MAD2, which contains the MCU, ASIC and DSP blocks handling and processing the audio signals. A detailed audio specification can be found from document

Bias + EMC

MICP/N

EMC + Acc.

Interf.

XMIC

System

SGND

Connector

XEAR

AuxOut

EMC

MIC2 MIC1 MIC3

HFCM

HF EAR

Preamp

Amp Multipl.

Multipl.Premult.

COBBA

Pre & LP

Technical Documentation

MAD

DSP

MCU

Buzzer Driver Circuit

Buzzer

The baseband supports three microphone inputs and two earphone outputs. The inputs can be taken from an internal microphone, a headset microphone or from an external microphone signal source. The microphone signals from different sources are connected to separate inputs at the COBBA–GJ asic. Inputs for the microphone signals are differential type.

The MIC1 inputs are used for a headset microphone that can be connected directly to the system connector. The internal microphone is connected to MIC2 inputs and an external pre–amplified microphone (handset/handfree) signal is connected to the MIC3 inputs. In COBBA there are also three audio signal outputs of which dual ended EAR lines are used for internal earpiece and HF line for accessory audio output. The third audio output AUXOUT is used only for bias supply to the headset microphone. As a difference to DCT2 generation the SGND ( = HFCM at COBBA) does not supply audio signal (only common mode). Therefore there are no electrical loopback echo from downlink to uplink.

The output for the internal earphone is a dual ended type output capable of driving a dynamic type speaker. The output for the external accessory and the headset is single ended with a dedicated signal ground SGND. Input and output signal source selection and gain control is performed inside the COBBA–GJ asic according to control messages from the MAD2. Keypad tones, DTMF, and other audio tones are generated and encoded by the MAD2 and transmitted to the COBBA–GJ for decoding.

Page 3 – 30

Original 09/98

PAMS

NSE–3

Technical Documentation

External Audio Connections

The external audio connections are presented in figure 16. A headset can be connected directly to the system connector. The headset microphone bias is supplied from COBBA AUXOUT output and fed to microphone through XMIC line. The 330ohm resistor from SGND line to AGND provides a return path for the bias current.

Baseband

HookDet

MAD

HeadDet

System Module UP8

2.8 V

47k

22k

CCONT

AUXOUT

COBBA

EAD

HFC M

MIC1 N

MIC1 P

MIC3 N

MIC3 P

2.8 V

47k

47R



10

H F

10

33n

33n 33n

33n

47R

330R

2k2

XEAR

SGN D

XMI C

Original 09/98

Page 3 – 31

NSE–3

PAMS

System Module UP8

Technical Documentation

Analog Audio Accessory Detection

In XEAR signal there is a 47 kW pullup in the transceiver and 6.8 kW pull–down to SGND in accessory. The XEAR is pulled down when an accessory is connected, and pulled up when disconnected. The XEAR is connected to the HookDet line (in MAD), an interrupt is given due to both connection and disconnection. There is filtering between XEAR and HookDet to prevent audio signal giving unwanted interrupts.

External accessory notices powered–up phone by detecting voltage in XMIC line. In Table 23 there is a truth table for detection signals.

Accessory connected HookDet HeadDet Notes

No accessory connected High High Pullups in the transceiver Headset HDC–9 with a button switch

pressed Headset HDC–9 with a button switch re-

leased Handsfree (HFU–1) Low High XEAR loaded (dc)

Low Low XEAR and XMIC loaded (dc)

High Low *) XEAR unloaded (dc)

Headset Detection

The external headset device is connected to the system connector, from which the signals are routed to COBBA headset microphone inputs and earphone outputs. In the XMIC line there is a (47 + 2.2) kW pullup in the transceiver. The microphone is a low resistancepulldown compared to the transceiver pullup.

When there is no call going, the AUXOUT is in high impedance state and the XMIC is pulled up. When a headset is connected, the XMIC is pulled down. The XMIC is connected to the HeadDet line (in MAD), an interrupt is given due to both connection and disconnection. There is filtering between the XMIC and the HeadDet to prevent audio signal giving unwanted interrupts (when an accessory is connected).

In the XEAR line there is a 47 kW pullup in the transceiver. The earphone is a low resistance pulldown compared to the transceiver pullup. When a remote control switch is open, there is a capacitor in series with the earphone, so the XEAR (and HookDet) is pulled up by the phone. When the switch is closed, the XEAR (and HookDet) is pulled down via the earphone. So both press and release of the button gives an interrupt.

During a call there is a bias voltage (1.5 V) in the AUXOUT, and the HeadDet cannot be used. The headset interrupts should to be disabled during a call and the EAD line (AD converter in CCONT) should be polled to see if the headset is disconnected.

Page 3 – 32

Original 09/98

PAMS

NSE–3

Technical Documentation

Internal Audio Connections

The speech coding functions are performed by the DSP in the MAD2 and the coded speech blocks are transferred to the COBBA–GJ for digital to analog conversion, down link direction. In the up link direction the PCM coded speech blocks are read from the COBBA–GJ by the DSP.

There are two separate interfaces between MAD2 and COBBA–GJ: a parallel bus and a serial bus. The parallel bus has 12 data bits, 4 address bits, read and write strobes and a data available strobe. The parallel interface is used to transfer all the COBBA–GJ control information (both the RFI part and the audio part) and the transmit and receive samples. The serial interface between MAD2 and COBBA–GJ includes transmit and receive data, clock and frame synchronisation signals. It is used to transfer the PCM samples. The frame synchronisation frequency is 8 kHz which indicates the rate of the PCM samples and the clock frequency is 1 MHz. COBBA is generating both clocks.

4–wire PCM Serial Interface

System Module UP8

The interface consists of following signals: a PCM codec master clock (PCMDClk), a frame synchronization signal to DSP (PCMSClk), a codec transmit data line (PCMTX) and a codec receive data line (PCMRX). The COBBA–GJ generates the PCMDClk clock, which is supplied to DSP SIO. The COBBA–GJ also generates the PCMSClk signal to DSP by dividing the PCMDClk. The PCMDClk frequency is 1.000 MHz and is generated by dividing the RFIClk 13 MHz by 13. The COBBA–GJ further divides the PCMDClk by 125 to get a PCMSClk signal, 8.0 kHz.

PCMDClk

PCMSClk

PCMTxData

PCMRxData

sign extended 15 14 13 12 011 10 sign extended

MSB

LSB

Original 09/98

Page 3 – 33

NSE–3

PAMS

System Module UP8

Alert Signal Generation

A buzzer is used for giving alerting tones and/or melodies as a signal of an incoming call. Also keypress and user function response beeps are generated with the buzzer. The buzzer is controlled with a BuzzerPWM output signal from the MAD. A dynamic type of buzzer must be used since the supply voltage available can not produce the required sound pressure for a piezo type buzzer. The low impedance buzzer is connected to an output transistor that gets drive current from the PWM output. The alert volume can be adjusted either by changing the pulse width causing the level to change or by changing the frequency to utilize the resonance frequency range of the buzzer.

A vibra alerting device is used for giving silent signal to the user of an incoming call. The device is controlled with a VibraPWM output signal from the MAD2. The vibra alert can be adjusted either by changing the pulse width or by changing the pulse frequency. The vibra device is not inside the phone, but in a special vibra battery.

Technical Documentation

Digital Control

The baseband functions are controlled by the MAD asic, which consists of a MCU, a system ASIC and a DSP.

MAD2

MAD2 contains following building blocks: – ARM RISC processor with both 16–bit instruction set (THUMB mode)

and 32–bit instruction set (ARM mode)

– TI Lead DSP core with peripherials:

– BUSC (BusController for controlling accesses from ARM to API, Sys-

tem Logic and MCU external memories, both 8– and 16–bit memories)

– API (Arm Port Interface memory) for MCU–DSP commu-

nication, DSP code download, MCU interrupt handling vec-

tors (in DSP RAM) and DSP booting – Serial port (connection to PCM) – Timer – DSP memory

Page 3 – 34

– System Logic

– CTSI (Clock, Timing, Sleep and Interrupt control) – MCUIF (Interface to ARM via B

tROM – DSPIF (Interface to DSP) – MFI (Interface to COBBA AD/DA Converters)

USC). Contains MCU Boo-

Original 09/98

PAMS

NSE–3

Technical Documentation

– CODER (Block encoding/decoding and A51&A52 ciphering) – AccIF(Accessory Interface) – SCU (Synthesizer Control Unit for controlling 2 separate

– UIF (Keyboard interface, serial control interface for COBBA

– SIMI (SimCard interface with enhanched features) – PUP (Parallel IO, USART and PWM control unit for vibra

The MAD2 operates from a 13 MHz system clock, which is generated from the 13Mhz VCXO frequency. The MAD2 supplies a 6,5MHz or a 13MHz internal clock for the MCU and system logic blocks and a 13MHz clock for the DSP, where it is multiplied to 52 MHz DSP clock. The system clock can be stopped for a system sleep mode by disabling the VCXO supply power from the CCONT regulator output. The CCONT provides a 32kHz sleep clock for internal use and to the MAD2, which is used for the sleep mode timing. The sleep clock is active when there is a battery voltage available i.e. always when the battery is connected.

System Module UP8

synthesizer)

PCM Codec, LCD Driver and CCONT)

and buzzer)

N:o

1 MCUGenOut5 O Audio 2 0 MCU General

2 MCUGenOut4 O N101 2 0 MCU General

3 4 MCUGenOut3 O 2 0 MCU General

5 VCC IO VCC in

6 MCUGenOut2 O 2 0 MCU General

7 MCUGenOut1 O MCU

8 MCUGenOut0 O 2 1 LoByteSelX

9 Col4 I/O UIF 2 Input program-

Pin Name Pin

T ype

LEADGND

Connected

to/from

memory

Drive

req.

Reset

State

2 0 MCU General

Note Explanation

purpose output

Lead Ground

purpose output

Power

3325c10

purpose output

MCU General

in 16–bit

mode

mable pullup

PR0201

purpose output

I/O line for key-

board column 4

port

Original 09/98

Page 3 – 35

NSE–3

PAMS

System Module UP8

Pin NamePin

N:o

10 Col3 I/O UIF 2 Input program-

11 GND Ground 12 Col2 I/O UIF 2 Input program-

13 Col1 I/O UIF 2 Input program-

14 Col0 I/O UIF 2 Input program-

15 LCDCSX I/O UIF 2 Input external

Type

Connected

to/from

Drive

req.

State

Technical Documentation

ExplanationNoteReset

I/O line for key-

mable pullup

PR0201

mable pullup

PR0201

mable pullup

PR0201

mable pullup

PR0201

pullup/down

board column 3

I/O line for keyboard column 2

I/O line for keyboard column 1

I/O line for keyboard column 0

serial LCD driver

chip select, par-

allel LCD driver

enable

16 17 Row5LCDCD I/O UIF 2 Input,

18 VCC Core VCC in

19 Row4 I/O UIF 2 Input,

20 Row3 I/O UIF 2 Input,

21 Row2 I/O UIF 2 Input,

LEADVCC

pullup

PR0201

3325c10

pullup

PR0201

pullup

PR0201

pullup

PR0201

Lead Power

Keyboard row5

data I/O , serial

LCD driver com-

mand/data indi-

cator, parallel

LCD driver read/

write select

Power

I/O line for key-

board row 4, par-

allel LCD driver

control

I/O line for key-

board row 3, par-

allel LCD driver

data

I/O line for key-

board row 2, par-

allel LCD driver

data

22 Row1 I/O UIF 2 Input,

23 Row0 I/O UIF 2 Input,

Page 3 – 36

pullup

PR0201

pullup

PR0201

I/O line for key-

board row 1, par-

allel LCD driver

data

I/O line for key-

board row 0, par-

allel LCD driver

data

Original 09/98

PAMS

NSE–3

Technical Documentation

Pin NamePin

N:o

24 JTDO O 2 Tri–

25 GND Ground 26 JTRst I Input,

27 JTClk I Input pulldown

28 JTDI I Input,

29 JTMS I Input,

30 VCC IO VCC in

Type

Connected

to/from

Drive

req.

State

state

pull-

down

pullup

System Module UP8

ExplanationNoteReset

JTAG data out

pulldown

PD0201

pullup

PR0201

pullup

PR0201

3325c10

JTAG reset

JT AG Clock

JTAG data in

JTAG mode se-

Power

lect

31 CoEmu0 I/O 2 Input,

pullup

32 CoEmu1 I/O 2 Input,

pullup

33 MCUGenIO7 I/O 2 Input,

pull-

down

34 MCUGenIO6 I/O UI 2 Input,

pull-

down

35 36 MCUGenIO5 I/O UI 2 Input,

37 38 MCUAd0 O MCU

39 40 MCUAd1 O MCU

41 MCUAd2 O MCU

LEADGND

pull-

down

ARMGND

2 0 MCU address

MEMORY

ARMVCC

2 0 MCU address

MEMORY

2 0 MCU address

MEMORY

pullup

PR0201

pullup

PR0201

pulldown

PD1001

pulldown

PD1001

pulldown

PD1001

DSP/MCU

emulation port 0

DSP/MCU

emulation port 1

General purpose

I/O port

Lights

Lead Ground

LCD reset

ARM Ground

bus

ARM Power

bus

42 GND Ground 43 MCUAd3 O MCU

MEMORY

44 MCUAd4 O MCU

MEMORY

45 MCUAd5 O MCU

MEMORY

Original 09/98

2 0 MCU address

bus

2 0 MCU address

bus

2 0 MCU address

bus

Page 3 – 37

NSE–3

PAMS

System Module UP8

Pin NamePin

N:o

46 MCUAd6 O MCU

47 VCC IO VCC in

48 MCUAd7 O MCU

49 MCUAd8 O MCU

50 MCUAd9 O MCU

51 MCUAd10 O MCU

52 GND Ground 53 MCUAd11 O MCU

54 MCUAd12 O MCU

55 MCUAd13 O MCU

56 MCUAd14 O MCU

57 MCUAd15 O MCU

58 MCUAd16 O MCU

59 VCC Core VCC in

60 MCUAd17 O MCU

61 MCUAd18 O MCU

62 MCUAd19 O MCU

63 MCUAd20 O MCU

64 MCUAd21 O MCU

65 ExtMCUDa0 I/O MCU

66 GND Ground

Type

Connected

to/from

MEMORY

Drive

req.

State

2 0 MCU address

2 Input MCU data bus

Technical Documentation

ExplanationNoteReset

bus

Power

3325c10

bus

Power

3325c10

bus

67 ExtMCUDa1 I/O MCU

MEMORY

68 ExtMCUDa2 I/O MCU

MEMORY

Page 3 – 38

2 Output MCU data bus

Original 09/98

PAMS

NSE–3

Technical Documentation

Pin NamePin

N:o

69 ExtMCUDa3 I/O MCU

70 ExtMCUDa4 I/O MCU

71 ExtMCUDa5 I/O MCU

72 ExtMCUDa6 I/O MCU

73 VCC IO VCC in

74 ExtMCUDa7 I/O MCU

75 MCUGenIO8 I/O 2 Input MCU Data in

76 MCUGenIO9 I/O 2 Input MCU Data in

77 MCUGenIO10 I/O 2 Input MCU Data in

78 MCUGenIO11 I/O 2 Input MCU Data in

79 GND Ground

Type

Connected

to/from

MEMORY

Drive

req.

State

2 Output MCU data bus

16–bit mode

System Module UP8

ExplanationNoteReset

Power

3325c10

General purpose

I/O port

General purpose

I/O port

General purpose

I/O port

General purpose

I/O port

80 MCUGenIO12 I/O 2 Input MCU Data in

16–bit mode

81 MCUGenIO13 I/O 2 Input MCU Data in

16–bit mode

82 MCUGenIO14 I/O 2 Input MCU Data in

16–bit mode

83 MCUGenIO15 I/O 2 Input MCU Data in

16–bit mode

84 MCURdX O MCU

MEMORY

85 VCC Core VCC in

86 MCUWrX O MCU

MEMORY

87 ROM1SelX O MCU ROM 2 1 ROM chip select 88 RAMSelX O MCU RAM 2 1 RAM chip select 89 ROM2SelX O MCU ROM2 2 1 Extra chip select,

90 MCUGenIO1 I/O 2 Input,

91 DSPXF O 2 1 External flag

2 1 MCU Read

3325c10

2 1 MCU write

pullup

PR0201

General purpose

I/O port

General purpose

I/O port

General purpose

I/O port

General purpose

I/O port

strobe Power

strobe

can be used as

MCU general

output

General purpose

I/O port

Original 09/98

Page 3 – 39

NSE–3

PAMS

System Module UP8

Pin NamePin

N:o

93 RFClk I VCXO Input System clock

94 RFClkGnd Input System clock

95 SIMCardDetX I Input SIM card detec-

97 BuzzPWM O BUZZER 2 0 Buzzer PWM

98 99 V ibraPWM O VIBRA 2 0 V ibra PWM con-

100 GND Ground

SCVCC

SCGND

LEADVCC

Type

Connected

to/from

Drive

req.

State

Technical Documentation

ExplanationNoteReset

Special cell Pow-

from VCTCXO

reference ground

input

tion

Special cell

Ground

control

LEAD Power

trol

101 MCUGenIO3 I/O EEPROM 2 Input,

pullup

102 MCUGenIO2 I/O EEPROM 2 Input,

pullup

103 EEPROMSelX O MCU EE-

PROM

104 AccTxData I/O 4 Tri–

105 VCC IO VCC in

106 GenDet I Input General purpose

107 HookDet I Input Non–MBUS ac-

108 HeadDet I Input Headset detec-

109 AccRxData I Input Accessory RX

110 GND Ground

2 1 EEPROM chip

State

pullup

PR1001

pullup

PR1001

external

pullup

3325c10

General purpose

I/O port

WP SCL

select, can be

used as MCU

general output

Accessory TX

data, Flash_TX

Power

interrupt

cessory connec-

tion detector

tion interrupt

data, Flash_RX

111 MCUGenIO4 I/O 2 Input,

Page 3 – 40

pull-

down

pulldown

PD1001

General purpose

I/O port

Original 09/98

PAMS

NSE–3

Technical Documentation

Pin NamePin

N:o

112 MBUS I/O 2 Input,

113 VCXOPwr O CCONT 2 1 VCXO regulator

114 SynthPwr O CCONT 2 0 Synthesizer reg-

115 VCC Core VCC in

116 GenCCONTCSX O CCONT 2 1 Chip select to

117 118 GenSDIO I/O CCONT, UIF 2 Input,

LEADGND

Type

Connected

to/from

Drive

req.

State

exter-

nal

pullup

exter-

nal

pullup/

down

pullup/down

depending

System Module UP8

ExplanationNoteReset

external

pullup

3325c10

external

on how to

boot

MBUS, Flash

ulator control

LEAD Ground

Serial data in/out

clock

control

Power

CCONT

119 GenSClk O CCONT, UIF 2 0 Serial clock 120 SIMCardData I/O CCONT 2 0 SIM data 121 GND Ground 122 PURX I CCONT Input Power Up Reset 123 CCONTInt I CCONT Input CCONT interrupt 124 Clk32k I CCONT Input Sleep clock os-

cillator input

125 VCC IO VCC in

3325c10

126 SIMCardClk O CCONT 2 0 SIM clock 127 SIMCardRstX O CCONT 2 0 SIM reset 128 SIMCardIOC O CCONT 2 0 SIM data in/out

129 SIMCardPwr O CCONT 2 0 SIM power con-

130 131 RxPwr O CCONT 2 0 RX regulator

132 TxPwr O CCONT 2 0 TX regulator

LEADVCC

Power

control

trol

LEAD Power

control

133 TestMode I Input,

pull-

down

134 ExtSysResetX O 2 0 System Reset

Original 09/98

pulldown

PD0201

Test mode select

Page 3 – 41

NSE–3

PAMS

System Module UP8

Pin NamePin

N:o

135 PCMTxData O COBBA 2 0 Transmit data,

136 VCC IO VCC in

137 PCMRxData I COBBA Input Receive data,

138 PCMDClk I COBBA Input Transmit clock,

139 PCMSClk I COBBA Input Transmitframe

140 COBBADAX I COBBA Input Data available

141 GND Ground 142 COBBAWrX O COBBA 2 1 COBBA write

Type

Connected

to/from

Drive

req.

State

Technical Documentation

ExplanationNoteReset

Power

3325c10

CLKX

sync, FSX

acknowledge

strobe

143 COBBARdX O COBBA 2 1 COBBA read

strobe

144 COBBAClk O COBBA 4 1 COBBA clock,

13 MHz

145 COBBAAd3 O COBBA 2 0 COBBA address

bit

146 COBBAAd2 O COBBA 2 0 COBBA address

bit

147 COBBAAd1 O COBBA 2 0 COBBA address

bit

148 COBBAAd0 O COBBA 2 0 COBBA address

bit

149 COBBADa1 1 I/O COBBA 2 0 COBBA data bit 150 VCC Core VCC in

3325c10

151 COBBADa10 I/O COBBA 2 0 COBBA data bit 152 COBBADa9 I/O COBBA 2 0 COBBA data bit 153 COBBADa8 I/O COBBA 2 0 COBBA data bit 154 COBBADa7 I/O COBBA 2 0 COBBA data bit 155 COBBADa6 I/O COBBA 2 0 COBBA data bit

Power

156 GND Ground 157 COBBADa5 I/O COBBA 2 0 COBBA data bit 158 COBBADa4 I/O COBBA 2 0 COBBA data bit 159 COBBADa3 I/O COBBA 2 0 COBBA data bit 160 COBBADa2 I/O COBBA 2 0 COBBA data bit 161 COBBADa1 I/O COBBA 2 0 COBBA data bit

Page 3 – 42

Original 09/98

PAMS

NSE–3

Technical Documentation

Pin NamePin

N:o

162 COBBADa0 I/O COBBA 2 0 COBBA data bit 163 DSPGenOut5 O RF 2 0 DSP general

164 VCC IO VCC in

165 DSPGenOut4 O 2 0 DSP general

166 DSPGenOut3 O IR 2 0 IR ON 167 DSPGenOut2 O 2 0 DSP general

168 DSPGenOut1 O 2 0 DSP general

169 DSPGenOut0 O 2 0 DSP general

170 MCUGenIO0 I/O EEPROM 2 Input,

171 FrACtrl O RF 2 0 SDATX0

Type

Connected

to/from

Drive

req.

State

pullup

System Module UP8

ExplanationNoteReset

purpose output,

COBBA reset

3325c10

purpose output

pullup

PR0201

Power

SDA

172 GND Ground 173 SynthEna O PLUSSA 2 0 Synthesizer data

enable

174 SynthClk O PLUSSA 2 0 Synthesizer

clock

175 SynthData O PLUSSA 2 0 Synthesizer data 176 TxPA O PLUSSA,

power ampli-

fier

2 0 Power amplifier

control

Original 09/98

Page 3 – 43

NSE–3

PAMS

System Module UP8

Memories

The MCU program code resides in an external flash program memory, which size is 8 Mbits (512kx16bit). The MCU work (data) memory size is 512kbits (64kx8bit). A serial EEPROM is used for storing the system and tuning parameters, user settings and selections, a scratch pad and a short code memory. The EEPROM size is 64kbits (8kx8bit).

The BusController (BUSC) section in the MAD decodes the chip select signals for the external memory devices and the system logic. BUSC controls internal and external bus drivers and multiplexers connected to the MCU data bus. The MCU address space is divided into access areas with separate chip select signals. BUSC supports a programmable number of wait states for each memory range.

Program Memory

The MCU program code resides in the program memory. The program memory size is 8 Mbits (512kx16bit).

Technical Documentation

The flash memory has a power down pin that should be kept low, during the power up phase of the flash to ensure that the device is powered up in the correct state, read only. The power down pin is utilized in the system sleep mode by connecting the ExtSysResetX to the flash power down pin to minimize the flash power consumption during the sleep.

SRAM Memory

The work memory is a static ram of size 512k (64kx8) in a shrink TSOP32 package. The work memory is supplied from the common baseband VBB voltage and the memory contents are lost when the baseband voltage is switched off. All retainable data should be stored into the EEPROM (or flash) when the phone is powered down.

EEPROM Memory

An EEPROM is used for a nonvolatile data memory to store the tuning parameters and phone setup information. The short code memory for storing user defined information is also implemented in the EEPROM. The EEPROM size is 8kbytes. The memory is accessed through a serial bus and the default package is SO8.

Page 3 – 44

Original 09/98

PAMS

NSE–3

Technical Documentation

MCU Memory Map

MAD2 supports maximum of 4GB internal and 4MB external address space. External memories use address lines MCUAd0 to MCUAd21 and 16–bit databus. The BUSC bus controller supports 8– and 16–bit access for byte, double byte, word and double word data. Access wait state 2 and used databus width can be selected separately for each memory block.

Flash Programming

The phone have to be connected to the flash loading adapter FLA–5 so that supply voltage for the phone and data transmission lines can be supplied from/to FLA–5. When FLA–5 switches supply voltage to the phone, the program execution starts from the BOOT ROM and the MCU investigates in the early start–up sequence if the flash prommer is connected. This is done by checking the status of the MBUS–line. Normally this line is high but when the flash prommer is connected the line is forced low by the prommer.

System Module UP8

The flash prommer serial data receive line is in receive mode waiting for an acknowledgement from the phone. The data transmit line from the baseband to the prommer is initially high. When the baseband has recognized the flash prommer, the TX–line is pulled low. This acknowledgement is used to start to toggle MBUS (FCLK) line three times in order that MAD2 gets initialized. This must be happened within 15 ms after TX line is pulled low. After that the data transfer of the first two bytes from the flash prommer to the baseband on the RX–line must be done within 1 ms.

When MAD2 has received the secondary boot byte count information, it forces TX line high. Now, the secondary boot code must be sent to the phone within 10 ms per 16 bit word. If these timeout values are exceeded, the MCU (MAD2) starts normal code execution from flash. After this, the timing between the phone and the flash prommer is handled with dummy bites.

A 5V programming voltage is supplied inside the transceiver from the battery voltage with a switch mode regulator (5V/30mA) of the CCONT. The 5V is connected to VPP pin of the flash through the UI board.

COBBA–GJ

The COBBA–GJ provides an interface between the baseband and the RF–circuitry. COBBA–GJ performs analogue to digital conversion of the receive signal. For transmit path COBBA_GJ performs digital to analogue conversion of the transmit amplifier power control ramp and the in–phase and quadrature signals. A slow speed digital to analogue converter will provide automatic frequency control (AFC).

The COBBA asic is at any time connected to MAD asic with two interfaces, one for transferring tx and rx data between MAD and COBBA and one for transferring codec rx/tx samples.

Original 09/98

Page 3 – 45

NSE–3

PAMS

System Module UP8

Infrared Transceiver Module

The module is activated with an IRON signal by the MAD, which supplies power to the module. The IR datalines are connected to the MAD accessory interface AccIf via FBUS. The RX and TX lines are separated from FBUS by three–state buffers, when the IR–module is switched off. The AccIf in MAD performs pulse encoding and shaping for transmitted data and detection and decoding for received data pulses.

The data is transferred over the IR link using serial data at speeds 9.6,

19.2, 38.4, 57.6 or 115.2 kbits/s, which leads to maximum throughput of

92.160 kbits/s. The used IR module complies with the IrDA 1.0 specification (Infra Red Data Association), which is based on the HP SIR (Hewlett– Packard‘s Serial Infra Red) consept.

Following figure gives an example of IR transmission pulses. In IR transmission a light pulse correspondes to 0–bit and a ”dark pulse” correspondes to 1–bit.

Technical Documentation

constant pulse

IR TX

UART TX

The FBUS cannot be used for external accessory communication when the infrared mode is selected, as IR communication reserves the FBUS completely.

Real Time Clock

Requirements for a real time clock implementation are a basic clock (hours and minutes), a calender and a timer with alarm and power on/off –function and miscellaneous calls. The RTC will contain only the time base and the alarm timer but all other functions (e.g. calendar) will be implemented with the MCU software. The RTC needs a power backup to keep the clock running when the phone battery is disconnected. The backup power is supplied from a rechargable polyacene battery that can keep the clock running some ten minutes. If the backup has expired, the RTC clock restarts after the main battery is connected. The CCONT keeps MCU in reset until the 32kHz source is settled (1s max).

startbit stopbit1 0100110

Page 3 – 46

The CCONT is an ideal place for an integrated real time clock as the asic already contains the power up/down functions and a sleep control with the 32kHz sleep clock, which is running always when the phone battery is connected. This sleep clock is used for a time source to a RTC block.

Original 09/98

PAMS

NSE–3

Technical Documentation

RTC backup battery charging

CHAPS has a current limited voltage regulator for charging a backup battery. The regulator derives its power from VOUT so that charging can take place without the need to connect a charger. The backup battery is only used to provide power to a real time clock when VOUT is not present so it is important that power to the charging circuitry is derived from VOUT and that the charging circuitry does not present a load to the backup battery when VOUT is not present.

It should not be possible for charging current to flow from the backup battery into VOUT if VOUT happens to be lower than VBACK. Charging current will gradually diminish as the backup battery voltage reaches that of the regulation voltage.

Vibra Alerting Device

A vibra alerting device is used for giving silent signal to the user of an incoming call. The device is not placed in the phone but it will be added to a special battery pack. The vibra is controlled with a PWM signal by the MAD via the BTEMP battery terminal.

System Module UP8

Vibra

A 15kohm BSI resistor is needed to detect the vibra battery. It is only used to enable vibra selection in user menu. When alerting, VibraPWM signal is delivered to battery.

VBAT

TRANSCEIVER

VREF

100k

R3 1k

10k

10n

BTEMP

VIBRAPWM

CCONT

MAD

22k

100n

10n

47k NTC

BSI

BTEMP

GND

BATTERY

Original 09/98

MCUGenIO4

Page 3 – 47

NSE–3

PAMS

System Module UP8

IBI Accessories

All accessories which can be connected between the transceiver and the battery or which itself contain the battery, are called IBI accessories.

Either the phone or the IBI accessory can turn the other on, but both possibilities are not allowed in the same accessory.

Phone Power–on by IBI

IBI accessory can power the phone on by pulling the BTEMP line up to 3 V.

IBI power–on by phone

Phone can power the IBI accessory on by pulling the BTEMP line up by MCUGenIO4 of MAD2. BTEMP measurement is not possible during this time.

Technical Documentation

+1.5 V

33n

BATTERY

The accessory is commanded back to power–off by MBUS message.

VBAT

TRANSCEIVER

–

220k

10n

Accessory power on

100ms

NTC

BSI

BTEMP

GND

VREF

100k

10k

10n

BTEMP

VIBRAPWM

CCONT

MAD

Page 3 – 48

MCUGenIO4

Original 09/98

PAMS

NSE–3

Technical Documentation

RF Module

Maximum Ratings

Parameter Rating

Battery voltage, idle mode 6.0 V Battery voltage during call, highest power level 5.0 V Regulated supply voltage 2.8 +/– 3% V Voltage reference 1.5 +/– 1.5% V Operating temperature range –10...+55 deg. C

RF Frequency Plan

System Module UP8

935–960 MHz

890–915 MHz

LO– buffers

PLUSSACRFU_1

1st IF 71 MHz 2nd IF 13 MHz

2nd LO 58 MHz

232 MHz

13 MHz

VCTCXO

1006– 1031 MHz

TX IF 116 MHz

UHF PLL

f/2

f/2f/2

VHF PLL

Original 09/98

Page 3 – 49

Page 3 – 50

3.6 V

Power Distribution Diagram

NSE–3

System Module UP8

VR 1

2.3 mA

VCTCXO

BUFFER

Original 09/98

VXO

VR 2

51 mA

CRFU, PLUSSA

VRX

BATTERY

VR 3

18 mA

PLLs

VSYN_2

VR 4

19.5 mA

VCOs

BUFFERS

VSYN_1

VR 5

90 mA

CRFU, PLUSSA PA, limiter

VTX

VR 6

COBBA ANAL.

1.35 A

VR 7

NOT USED

VREF V5V

0.1 mA

PLUSSA CRFU

VREF_1 VREF_2

1 mA

CHARGE PUMPs

VCP

VBATT

TXP

VXOENA

SYNPWR

RXPWR TXPWR

Technical Documentation

PAMS

NSE–3

Technical Documentation

DC Characteristics

Regulators

Transceiver has got a multi function power management IC, which contains among other functions, also 7 pcs of 2.8 V regulators. All regulators can be controlled individually with 2.8 V logic directly or through control register. In GSM direct controls are used to get fast switching, because regulators are used to enable RF–functions.

Use of the regulators can be seen in the power distribution diagram. CCONT also provides 1.5 V reference voltage for PLUSSA and CRFU1a

( and for DACs and ADCs in COBBA too ).

Control Signals

All control signals are coming from MAD and they are 2.8 V logic signals.

System Module UP8

Functional Description

RF block diagram has conventional dual conversion receiver and in transmitter there is a upconversion mixer for the final TX–frequency.

Architecture contains three ICs. Most of the functions are horizontally and vertically integrated. UHF functions except power amplifier and VCO are integrated into CRFU_1a, which is a BiCMOS–circuit suitable for LNA– and mixer–function. Most of the functions are in PLUSSA, which also is a BiCMOS–circuit. PLUSSA is a IF–circuit including IQ–modulator and PLLs for VHF– and UHF–synthesizers.

Power amplifier is also an ASIC, it is a so called MMIC ( monolithic microwave integrated circuit ). It has three amplifier stages including input and interstage matchings. Output matching network is external. Also TX gain control is integrated into this chip.

Frequency synthesizers

Both VCOs are locked with PLLs into stable frequency source ( see figure 3 ), which is a VCTCXO–module ( voltage controlled temperature compensated crystal oscillator ). VCTCXO is running at 13 MHz. Temperature effect is controlled with AFC ( automatic frequency control ) voltage, VCTCXO is locked into frequency of the base station. AFC is generated by baseband with a 11 bit conventional DAC in COBBA.

Original 09/98

Page 3 – 51

NSE–3

PAMS

System Module UP8

UHF PLL is located into PLUSSA. There is 64/65 (P/P+1) prescaler, N– and A–divider, reference divider, phase detector and charge pump for the external loop filter. UHF local signal is generated by a VCO–module (VCO = voltage controlled oscillator ) and sample of frequency of VCO is fed to prescaler. Prescaler is a dual modulus divider. Output of the prescaler is fed to N– and A–divider, which produce the input to phase detector. Phase detector compares this signal to reference signal, which is divided with reference divider from VCTCXO output. Output of the phase detector is connected into charge pump, which charges or discharges integrator capacitor in the loop filter depending on the phase of the measured frequency compared to reference frequency. Loop filter filters out the pulses and generates DC to control the frequency of UHF–VCO. Loop filter defines step response of the PLL ( settling time ) and effects to stability of the loop, that’s why integrator capacitor has got a resistor for phase compensation. Other filter components are for sideband rejection. Dividers are controlled via serial bus. SDATA is for data, SCLK is serial clock for the bus and SENA1 is a latch enable, which stores new data into dividers. HF–synthesizer is the channel synthesizer, so the channel spacing is 200 kHz. 200 kHz is reference frequency for the phase detector.

Technical Documentation

ref

f_out /

freq. reference AFC–controlled VCTCXO

f_out

PHASE

DET.

CHARGE

PUMP

VCO

Kvco

M = A(P+1) + (N–A)P= = NP+A

VHF PLL is also located into PLUSSA. There is 16/17 ( P/P+1 ) dual modulus prescaler, N– and A–dividers, reference divider, phase detector and charge pump for the loop filter. VHF local signal is generated with a discrete VCO–circuit. VHF PLL works in the same way as UHF–PLL. VHF– PLL is locked on fixed frequency, so higher reference frequency is used to decrease phase noise.

Page 3 – 52

Original 09/98

PAMS

NSE–3

Technical Documentation

Receiver

Receiver is a dual conversion linear receiver. Received RF–signal from the antenna is fed via the duplex filter to LNA (low noise amplifier ) in CRFU_1a. Active parts ( RF–transistor and biasing and AGC–step circuitry ) are integrated into this chip. Input and output matching networks are external. Gain selection is done with PDATA0 control. Gain step in LNA is activated when RF–level in antenna is about –45 dBm. After the LNA amplified signal ( with low noise level ) is fed to bandpass filter, which is a SAW–filter ( SAW, surface acoustic wave ). Duplex filter and RX interstage bandpass filters together define, how good are the blocking characteristics against spurious signals outside receive band and the protection against spurious responses, mainly the image of the first mixer.

This bandpass filtered signal is then mixed down to 71 MHz, which is first intermediate frequency. 1st mixer is located into CRFU_1a ASIC. This integrated mixer is a double balanced Gilbert cell. All active parts and biasing are integrated and matching components are external. Because this is an axtive mixer it also amplifies IF–frequency. Also local signal buffering is integrated and upper side injection is used. First local signal is generated with UHF–synthesizer.

System Module UP8

First IF–signal is then bandpass filtered with a selective SAW–filter. From the mixer output to IF–circuit input signal path is balanced. IF–filter provides selectivity for channels greater than +/–200 kHz. Also it attenuates image frequency of the second mixer and intermodulating signals. Selectivity is required in this place, because of needed linearity and adjacent channel interferers will be on too high signal level for the stages following.

Next stage in the receiver chain is AGC–amplifier. It is integrated into PLUSSA–ASIC. AGC has analog gain control. Control voltage for the AGC is generated with DA–converter in COBBA in baseband. AGC–stage provides accurate gain control range ( min. 60 dB ) for the receiver. After the AGC there is second mixer, which generates second intermediate frequency, 13 MHz. Local signal is generated in PLUSSA by dividing VHF– synthesizer output ( 232 MHz ) by four, so the 2nd LO–frequency is 58 MHz.

2nd IF–filter is a ceramic bandpass filter at 13 MHz. It attenuates adjacent channels, except for +/– 200 kHz there is not much attenuation. Those +/– 200 kHz interferers are filtered digitally by the baseband . So RX DACs are so good, that there is enough dynamic range for the faded 200 kHz interferer. Also the whole RX has to be able to handle signal levels in a linear way. After the 13 MHz filter there is a buffer for the IF–signal, which also converts and amplifies single ended signal from filter to balanced signal for the buffer and AD–converters in COBBA. Buffer in PLUSSA has got voltage gain of 36 dB and buffer gain setting in COBBA is 0 dB. It is possible to set gainstep ( 9.5 dB ) into COBBA via control bus, if needed.

Original 09/98

Page 3 – 53

NSE–3

PAMS

System Module UP8

Transmitter

Transmitter chain consists of IQ–modulator, upconversion mixer, power amplifier and there is a power control loop.

I– and Q–signals are generated by baseband also in COBBA–ASIC. After post filtering ( RC–network ) they go into IQ–modulator in PLUSSA. It generates modulated TX IF–frequency, which is VHF–synthesizer output divided by two, meaning 116 MHz. There is also an AGC–amplifier in PLUSSA, but it is not used in GSM. Output is set to maximum with a 5–bit message in control register. AGC–amplifier is used in other digital systems, because PLUSSA is a core IC. After PLUSSA signal is attenuated and filtered for upconversion into final TX–frequency in CRFU_1a. Upconversion mixer in CRFU_1a is a so called image reject mixer. It is able to attenuate unwanted sideband in the upconverter output. Mixer itself is a double balanced Gilbert cell. Phase shifters required for image rejection are also integrated. Local signal needed in upconversion is generated by the UHF–synthesizer, but buffers for the mixer are integrated into CRFU_1a. Output of the upconverter is buffered and matching network makes a single ended 50 ohm impedance.

Technical Documentation

Next stage is TX interstage filter, which attenuates unwanted signals from the upconverter, mainly LO–leakage and image frequency from the upconverter. Also it attenuates wideband noise. This bandpass filter is a SAW–filter.

After TX SAW–filter, there is a discrete transistor stage. Function of this block is to reduce the AM–content. This feature is realized with saturated operation of the V640 transistor. Typical input level into this amplifier is higher than output level.

The final amplication is realized with third IC, power amplifier is a MMIC. It has got a 50 ohm input, output requires an external matching network. MMIC contains three amplifier stages and interstage matchings. Also there is a gain control, which is controlled with a power control loop. PA has got over 35 dB power gain and it is able to produce 2.5 W into output with 0 dBm input level. Gain control range is over 35 dB to get desired power levels and power ramping up and down. Harmonics generated by the nonlinear PA ( class AB ) are filtered out with the matching network and lowpass/bandstop filtering in the duplexer. Bandstop is required because of wideband noise located on RX–band.

Power control circuitry consists of power detector in the PA output and error amplifier in PLUSSA. There is a directional coupler connected between PA output and duplex filter. It takes a sample from the forward going power with certain ratio. This signal is rectified in a schottky–diode and it produces a DC–signal signal after filtering. This peak–detector is linear on absolute scale, except it saturates on very low and high power levels – it produces a S–shape curve.

Page 3 – 54

Original 09/98

PAMS

NSE–3

Technical Documentation

This detected voltage is compared in the error–amplifier in PLUSSA to TXC–voltage, which is generated by DA–converter in COBBA. Because also gain control characteristics in PA are linear in absolute scale, control loop defines a voltage loop, when closed. Closed loop tracks the TXC– voltage quite linearilly. TXC has got a raised cosine form ( cos ), which reduces switching transients, when pulsing power up and down. Because dynamic range of the detector is not wide enough to control the power ( actually RF output voltage ) over the whole range, there is a control named TXP to work under detected levels. Burst is enabled and set to rise with TXP until the output level is high enough, that feedback loop works. Loop controls the output via the control pin in PA MMIC to the desired output level and burst has got the waveform of TXC–ramps. Because feedback loops could be unstable, this loop is compensated with a dominating pole. This pole decreases gain on higher frequencies to get phase margins high enough.

System Module UP8

– function

PADIR.COUPLER

RF_OUT

DETECTOR

RF_IN

det

= –R1/R2

ERROR AMPLIFIER

DOMINATING POLE

TXC

Original 09/98

Page 3 – 55

NSE–3

PAMS

System Module UP8

AGC strategy

AGC–amplifier is used to maintain output level of the receiver almost constant. AGC has to be set before each received burst, this is called pre–monitoring. Receiver is switched on roughly 150 ms before the burst begins, DSP measures received signal level and adjusts RXC, which controls RX AGC–amplifier or it switches off the LNA with PDATA0 control line. This pre–monitoring is done in three phases and this sets the settling times for RX AGC. Pre–monitoring is required because of linear receiver, received signal must be in full swing, no clipping is allowed and because DSP doesn’t know, what is the level going to be in next burst.

There is at least 60 dB accurate gain control ( continous, analog ) and one digital step in LNA. It is typically about 30...35 dB.

RSSI must be measured on range –48...–110 dBm. After –48 dBm level MS reports to base station the same reading.

Because of RSSI–requirements, gain step in LNA is used roughly on –45 dBm RF–level and up to –10 dBm input RF–level accurate AGC is used to set RX output level. LNA is ON below –45 dBm. from –45 dBm down to –95 dBm this accurate AGC in PLUSSA is used to adjust the gain to desired value. RSSI–function is in DSP, but it works out received signal level by measuring RX IQ–level after all selectivity filtering ( meaning IF–filters, Σ∆±converter and FIR–filter in DSP). So 50 dB accurate AGC dynamic range is required. Remaining 10 dB is for gain variations in RX–chain ( for calibration ). Below –95 dBm RF–levels, output level of the receiver drops dB by dB. At –95 dBm level output of the receiver gives 50 mVpp differentially. This is the target value for DSP. Below this it drops down to ca. 9 mVpp differentially @ –110 dBm RF–level.

Technical Documentation

This strategy is chosen because we have to roll off the AGC in PLUSSA early enough, that it won’t saturate in selectivity tests. Also we can’t start too early, then we will sacrifice the signal to noise ratio and it would require more accurate AGC dynamic range. 50 mVpp target level is set, because RX–DAC will saturate at 1.4 Vpp. This over 28 dB headroom is required to have margin for +/– 200 kHz faded adjacent channel ( ca. 19 dB ) and extra 9 dB for pre–monitoring.

Production calibration is done with two RF–levels, LNA gain step is not calibrated. Gain changes in the receiver are taken off from the dynamic range of accurate AGC. Variable gain stage in PLUSSA is designed in a way, that it is capable of compensating itself, there is good enough margin in AGC.

Page 3 – 56

Original 09/98

PAMS

NSE–3

Technical Documentation

AFC function

AFC is used to lock the transceivers clock to frequency of the base station. AFC–voltage is generated in COBBA with 11 bit AD–converter. There is a RC–filter in AFC control line to reduce the noise from the converter. Settling time requirement for the RC–network comes from signalling, how often PSW ( pure sine wave ) slots occur. They are repeated after 10 frames , meaning that there is PSW in every 46 ms. AFC tracks base station frequency continously, so transceiver has got a stable frequency, because changes in VCTCXO–output don’t occur so fast ( temperature ). Settling time requirement comes also from the start up–time allowed. When transceiver is in sleep mode and ”wakes” up to receive mode , there is only about 5 ms for the AFC–voltage to settle. When the first burst comes in system clock has to be settled into +/– 0.1 ppm frequency accuracy. The VCTCXO–module requires also 5 ms to settle into final frequency. Amplitude rises into full swing in 1 ... 2 ms, but frequency settling time is higher so this oscillator must be powered up early enough.

System Module UP8

Receiver blocks

RX interstage filter

Parameter Min. Typ. Max. Unit

Passband 935 – 960 MHz Insertion loss 3.8 dB Maximum drive level +10 dBm

1st mixer in CRFU_1a

Parameter Min. Typ./

Nom.

Supply voltage 2.7 2.8 2.85 V RX frequency range 935 960 MHz LO frequency range 1006 1031 MHz IF frequency 71 MHz Output resistance (balanced) 10 k ohm

Max. Unit/Notes

1st IF–filter

Parameter min. typ. max. unit

Operating temperature range –20 +75 deg.C Center frequency , fo 71 MHz Maximum ins. loss at 1dBBW 11 dB

Original 09/98

Page 3 – 57

NSE–3

PAMS

System Module UP8

Technical Documentation

Transmitter Blocks

TX interstage filter

Parameter Min. Typ. Max. Unit

Passband 890 – 915 MHz Insertion loss 3.8 dB

Power amplifier MMIC

Parameter Symbol Test condition Min Typ Max Unit

Operating freq. range 880 915 MHz Supply voltage Vcc 3.1 3.5 5.0 V Gain control range

( overall dynamic range)

Vpc= 0.5 ... 2.2 V 45 dB

Synthesizer blocks

VHF VCO and low pass filter

Parameter Min. Typ. Max. Unit/Notes

Supply voltage range 2.7 2.8 2.58 V Current consumption 4 7 mA Control voltage 0.5 4.0 V Operation frequency 232 MHz Output level –13 –10 dBm ( output after

the lowpass filter )

UHF PLL

UHF PLL block in PLUSSA

Parameter Min. Typ. Max. Unit/notes

Input frequency range 650 1300 MHz Reference input level 100 mVpp Reference input frequency 30 MHz Reference input impedance tbd.

Page 3 – 58

Original 09/98

PAMS

NSE–3

Technical Documentation

System Module UP8

UHF VCO module

Parameter Conditions Rating Unit/

Supply voltage, Vcc 2.8 +/– 0.1 V Supply current, Icc Vcc = 2.8 V,

Vc= 2.25 V Control voltage, Vc Vcc = 2.8 V 0.8... 3.7 V Oscillation frequency Vcc = 2.8 V

Vc = 0.8 V

Vc = 3.7 V Tuning voltage in center frequency f = 1018.5 MHz 2.25 +/– 0.25 V Tuning voltage sensitivity in operating

frequency range on each spot freq.

Output power level Vcc=2.7 V

Vcc = 2.8 V

f=1006...1031

MHz

f=1006...1031

MHz

< 10 mA

< 1006 > 1031

14 +/– 2 MHz/V

–6.0 min. dBm

Notes

MHz MHz

UHF local signal input in CRFU_1a

Parameter Min. Typ. Max. Unit/Notes

Input frequency range 990 1040 MHz Input level 200 700 mVpp

Connections

RF connector and antenna switch

Parameter Min. Typ. Max. Unit/Notes

Operating frequency range 890 960 MHz Insertion loss, COM to INT 0.2 dB Insertion loss, COM to EXT 0.4 dB Nominal impedance 50 ohm Return loss 15

Signal

name

VBATT Battery RF Voltage 3.0 3.6 5.0/6.0 V Supply voltage for

VXOE-NAMAD CCONT

From To Parameter Mini-

mum

Logic high ”1” 2.0 2.85 V VR1, VR6 in

Logic low ”0” 0 0.8 V VR1, VR6 in

Typi-

cal

Maximum

Unit Function

CCONT ON

CCONT OFF

Original 09/98

Page 3 – 59

NSE–3

signal for the logic

for the RF modu

PAMS

System Module UP8

ParameterToFromSignal

name

SYNPWRMAD CCONT

RXPWRMAD CCONT

TXPWRMAD CCONT

VREF CCONTPLUSSA Voltage 1.478 1.5 1.523 V Reference voltage

Logic high ”1” 2.0 2.85 V VR3, VR4 in

Logic low ”0” 0 0.8 V VR3,VR4 in

Logic high ”1” 2.0 2.85 V VR2, VR5 in

Logic low ”0” 0 0.8 V VR2, VR5 in

Logic high ”1” 2.0 2.85 V VR7 in CCONT

Logic low ”0” 0 0.8 V VR7 in CCONT

Mini-

mum

Typi-

cal

Technical Documentation

FunctionUnitMaxi-

mum

CCONT ON

CCONT OFF

CCONT ON

CCONT OFF

OFF

for PLUSSA and CRFU1a

PDATA0

SENA1 MAD PLUSSA

SDATA MAD PLUSSA

SCLK MAD PLUSSA

AFC COB-BAVCTCXOVoltage 0.046 2.254 V Automatic fre-

RFC VCTCX

RXIP/ RXIN

MAD CRFU_1

MAD

PLUS-SACOBBA Output level 50 1344 mVppDifferential RX 13

Logic high ”1” 2.0 2.85 V Nominal gain in

LNA

Logic low ”0” 0 0.8 V Reduced gain in

LNA Logic high ”1” 2.0 2.85 V Logic low ”0” 0 0.8 V Logic high ”1” 2.0 2.85 V Logic low ”0” 0 0.8 V Logic high ”1” 2.0 2.85 V Logic low ”0” 0 0.8 V

Frequency 13 MHz Signal amplitude 0.5 1.0 2.0 Vpp

PLL enable

Synthesizer data

Synthesizer clock

quency control

signal for

VC(TC)XO

High stability clock

circuits

MHz signal to

baseband

TXIP/ TXIN

TXQP/ TXQN

Page 3 – 60

COB-BAPLUSSA

Differential voltage swing

DC level 0.784 0.8 0.816 V Differential voltage

swing

DC level 0.784 0.8 0.816 V

0.75 x

1.022

0.75 x

1.022

0.75 x

1.1

0.75 x

1.1

0.75 x

1.18

0.75 x

1.18

Vpp

Differential in–

phase TX base-

band signal for the

RF modulator

Differential quad-

rature phase TX

baseband signal

lator

Original 09/98

PAMS

control

NSE–3

Technical Documentation

name

TXP MAD PLUSSA

TXC COB-

RXC COB-BAPLUSSA

PLUSSA

ParameterToFromSignal

Logic high ”1” 2.0 2.85 V Logic low ”0” 0 0.8 V Voltage Min 0.12 0.18 V

Voltage Max 2.27 2.33 V Voltage Min 0.12 0.18 V

Voltage Max 2.27 2.33 V

Mini-

mum

Typi-

cal

mum

System Module UP8

FunctionUnitMaxi-

Transmitter power

control enable

Transmitter power

Receiver gain

control

Original 09/98

Page 3 – 61

NSE–3

PAMS

System Module UP8

Timings

Synthesizer control timing

100 us min.

RXPWR

SYNTHPWR

SENA

10 us 10 us

6.9 ms ( 1.5 x 4.6 ms ( frame )

min. min. min. min.

10 us

2us min

10 us

Technical Documentation

8 us

SDATA/ SCLK

VXOENA

SYNTHPWR

RXPWR

RXC

SENA

SDATA/ SCLK

MODE VHF R VHF N/A UHF R UHF N/A

#bits 23 23 23 23 23

Synthesizer Start–up Timing / clocking

MON MON MON MONRX RX RX RX

20 ms

6.9 ms

150 us 150 us

4.6 ms

0.5–2 sec.

Page 3 – 62

Synthesizer Timing / IDLE, one monitoring frame, frame can start also from RX–burst

Original 09/98

PAMS

NSE–3

Technical Documentation

In case of long list of adjacent channels, there might be two monitoring– bursts/frame. Extra monitoring ”replaces” TX–burst.

20 ms

VXOENA

SYNTHPWR

RXPWR

RXC

SENA

SDATA/ SCLK

6.9 ms

150 us 150 us

System Module UP8

MON MON MON MONRX RX RX RX

MON MON MON

4.6 ms

0.5–2 sec.

SYNTHPWR

TXPWR

TXP

TXC

RXPWR

RXC SENA

SDATA/ SCLK

Synthesizer Timing / IDLE 2, frame can start from RX–burst

MON MON MON MONRX RX RX RX

150 us

150 us 150 us

TX TX TX

Original 09/98

Sunthesizer Timing / traffic channel

Page 3 – 63

NSE–3

PAMS

System Module UP8

Transmitter power switching timing diagram

542.8 us

Pout

8.3..56.7 us

TXC

TXP

0...56.7 us

Technical Documentation

0...58 us

TXPWR

150 us 50 us

Synthesizer clocking

Synthesizers are controlled via serial control bus, which consists of SDATA, SCLK and SENA1 signals. These lines form a synchronous data transfer line. SDATA is for the data bits, SCLK is 3.25 MHz clock and SENA1 is latch enable, which stores the data into counters or registers.

Page 3 – 64

Original 09/98

PAMS

NSE–3

Technical Documentation

Block Diagram of Baseband Blocks

REGULATORS

CHARGER

CHAPS

N101

SO16

CHR_CONTR

VBATT

BACK UP BATTERY

G100

32 kHz

EEPROM

2k*8 / 8k*8

D230/240

SO8

SIO

FLASH

512k*16 1024k*16

D210

TSOP48

memory control

lines: CE,WE...

MCUDa 15...0

MCUAd 19...1

A/D CONV.

CNTVR 4...0

REGULATORS

CCONT

N100

SQFP64

SIMIF 4...0

MAD2 D200

MCU

ASIC

32 kHz CRYSTAL

SIMCARD 3...0

X300

PwrOnX

GenSIO,LCDEn,CCONTCSX

BUZZER KBLIGHTS

ROW 5...0

COL 4...0

System Module UP8

SIM

READER

X302

UI BOARD

DISPLAY

KEYBOARD

PData0 TxP

Synthe Control

RF UNIT

N500 N620 N620

SRAM

64k*8

128k*8

D221

TSOP32

X100

MCUAd 16..0

MCUDa 7...0

XEAR

XMIC

SYSTEM

CONNECTOR

Original 09/98

N250

MBUS

FBUS

DSP

SQFP176

N400

CobbaAd 3...0

CobbaDa 11...0

PCM 3...0

RFC 13 MHz / 1 Vpp from VCXO (G600)

MICP MICN

RFI

COBBA

N250

CODEC

SQFP64

TxIN,TxIP TxQN,TxQP

RxInN,RxInP

N620

AFC

N620

TxC N620 RxC

N620

UI BOARD

EARP EARN

Page 3 – 65

NSE–3

PAMS

System Module UP8

Technical Documentation

Parts list of UP8T (EDMS Issue 11.11) Code: 0200951

ITEM CODE DESCRIPTION VALUE TYPE

R100 1430826 Chip resistor 680 k 5 % 0.063 W 0402 R102 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R103 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402 R104 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R109 1620017 Res network 0w06 2x100r j 0404 0404 R113 1430726 Chip resistor 100 5 % 0.063 W 0402 R116 1430788 Chip resistor 22 k 5 % 0.063 W 0402 R118 1430778 Chip resistor 10 k 5 % 0.063 W 0402 R120 1620025 Res network 0w06 2x100k j 0404 0404 R122 1620019 Res network 0w06 2x10k j 0404 0404 R124 1620017 Res network 0w06 2x100r j 0404 0404 R127 1620031 Res network 0w06 2x1k0 j 0404 0404 R128 1430718 Chip resistor 47 5 % 0.063 W 0402 R131 1422881 Chip resistor 0.22 5 % 1 W 1218 R136 1430804 Chip resistor 100 k 5 % 0.063 W 0402 R140 1430690 Chip jumper 0402 R142 1430690 Chip jumper 0402 R152 1430690 Chip jumper 0402 R154 1430122 Chip resistor 4.7 M 5 % 0.063 W 0603 R201 1430812 Chip resistor 220 k 5 % 0.063 W 0402 R202 1430804 Chip resistor 100 k 5 % 0.063 W 0402 R203 1620029 Res network 0w06 2x4k7 j 0404 0404 R211 1430804 Chip resistor 100 k 5 % 0.063 W 0402 R213 1430690 Chip jumper 0402 R215 1620023 Res network 0w06 2x47k j 0404 0404 R252 1430740 Chip resistor 330 5 % 0.063 W 0402 R254 1620027 Res network 0w06 2x47r j 0404 0404 R256 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 R257 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R259 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R260 1430788 Chip resistor 22 k 5 % 0.063 W 0402 R261 1430788 Chip resistor 22 k 5 % 0.063 W 0402 R263 1430778 Chip resistor 10 k 5 % 0.063 W 0402 R265 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R267 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402 R268 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402 R270 1430804 Chip resistor 100 k 5 % 0.063 W 0402 R271 1430804 Chip resistor 100 k 5 % 0.063 W 0402 R281 1430792 Chip resistor 33 k 5 % 0.063 W 0402 R282 1430798 Chip resistor 56 k 5 % 0.063 W 0402 R301 1620031 Res network 0w06 2x1k0 j 0404 0404 R303 1620031 Res network 0w06 2x1k0 j 0404 0404 R305 1620031 Res network 0w06 2x1k0 j 0404 0404

Page 3 – 66

Original 09/98

PAMS

NSE–3

Technical Documentation

R307 1620031 Res network 0w06 2x1k0 j 0404 0404 R308 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402 R309 1620031 Res network 0w06 2x1k0 j 0404 0404 R401 1430778 Chip resistor 10 k 5 % 0.063 W 0402 R402 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402 R403 1430693 Chip resistor 5.6 5 % 0.063 W 0402 R404 1430693 Chip resistor 5.6 5 % 0.063 W 0402 R405 1430693 Chip resistor 5.6 5 % 0.063 W 0402 R406 1430693 Chip resistor 5.6 5 % 0.063 W 0402 R500 1430700 Chip resistor 10 5 % 0.063 W 0402 R501 1430700 Chip resistor 10 5 % 0.063 W 0402 R502 1430764 Chip resistor 3.3 k 5 % 0.063 W 0402 R504 1620019 Res network 0w06 2x10k j 0404 0404 R507 1430740 Chip resistor 330 5 % 0.063 W 0402 R530 1430700 Chip resistor 10 5 % 0.063 W 0402 R531 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 R533 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R550 1430752 Chip resistor 820 5 % 0.063 W 0402 R551 1430740 Chip resistor 330 5 % 0.063 W 0402 R552 1430740 Chip resistor 330 5 % 0.063 W 0402 R553 1430774 Chip resistor 6.8 k 5 % 0.063 W 0402 R554 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402 R555 1430726 Chip resistor 100 5 % 0.063 W 0402 R580 1430706 Chip resistor 15 5 % 0.063 W 0402 R581 1430832 Chip resistor 2.7 k 5 % 0.063 W 0402 R582 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 R584 1430780 Chip resistor 12 k 5 % 0.063 W 0402 R585 1430774 Chip resistor 6.8 k 5 % 0.063 W 0402 R586 1430738 Chip resistor 270 5 % 0.063 W 0402 R588 1430744 Chip resistor 470 5 % 0.063 W 0402 R589 1430710 Chip resistor 22 5 % 0.063 W 0402 R600 1430788 Chip resistor 22 k 5 % 0.063 W 0402 R620 1620029 Res network 0w06 2x4k7 j 0404 0404 R621 1430744 Chip resistor 470 5 % 0.063 W 0402 R622 1430758 Chip resistor 1.5 k 5 % 0.063 W 0402 R623 1430714 Chip resistor 33 5 % 0.063 W 0402 R624 1430714 Chip resistor 33 5 % 0.063 W 0402 R625 1430714 Chip resistor 33 5 % 0.063 W 0402 R626 1430740 Chip resistor 330 5 % 0.063 W 0402 R627 1430776 Chip resistor 8.2 k 5 % 0.063 W 0402 R628 1430744 Chip resistor 470 5 % 0.063 W 0402 R629 1430730 Chip resistor 150 5 % 0.063 W 0402 R630 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 R631 1430700 Chip resistor 10 5 % 0.063 W 0402 R632 1430848 Chip resistor 12 k 1 % 0.063 W 0402 R634 1430848 Chip resistor 12 k 1 % 0.063 W 0402 R635 1430851 Chip resistor 15 k 2 % 0.063 W 0402

System Module UP8

Original 09/98

Page 3 – 67

NSE–3

PAMS

System Module UP8

R636 1430848 Chip resistor 12 k 1 % 0.063 W 0402 R638 1430848 Chip resistor 12 k 1 % 0.063 W 0402 R640 1430734 Chip resistor 220 5 % 0.063 W 0402 R641 1820031 NTC resistor 330 10 % 0.12 W 0805 R660 1430726 Chip resistor 100 5 % 0.063 W 0402 R662 1430714 Chip resistor 33 5 % 0.063 W 0402 R664 1430764 Chip resistor 3.3 k 5 % 0.063 W 0402 R666 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402 R668 1430732 Chip resistor 180 5 % 0.063 W 0402 R670 1430726 Chip resistor 100 5 % 0.063 W 0402 R706 1430812 Chip resistor 220 k 5 % 0.063 W 0402 R708 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 R710 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 C100 2610003 Tantalum cap. 10 u 20 % 10 V 3.2x1.6x1.6 C101 2320548 Ceramic cap. 33 p 5 % 50 V 0402 C102 2320538 Ceramic cap. 12 p 5 % 50 V 0402 C103 2604127 Tantalum cap. 1.0 u 20 % 35 V 3.5x2.8x1.9 C104 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C105 2610003 Tantalum cap. 10 u 20 % 10 V 3.2x1.6x1.6 C106 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C107 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C108 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C109 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C110 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C112 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C113 2320508 Ceramic cap. 1.0 p 0.25 % 50 V 0402 C114 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C115 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C116 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C117 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C118 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C119 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C120 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C121 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C122 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C127 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C128 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C129 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C130 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C131 2610003 Tantalum cap. 10 u 20 % 10 V 3.2x1.6x1.6 C132 2312403 Ceramic cap. 2.2 u 10 % 10 V 1206 C133 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C140 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C141 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C142 2610003 Tantalum cap. 10 u 20 % 10 V 3.2x1.6x1.6 C143 2610003 Tantalum cap. 10 u 20 % 10 V 3.2x1.6x1.6 C160 2320546 Ceramic cap. 27 p 5 % 50 V 0402

Technical Documentation

Page 3 – 68

Original 09/98

PAMS

NSE–3

Technical Documentation

C161 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C201 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C202 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C203 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C204 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C205 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C206 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C207 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C208 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C209 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C211 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C212 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C213 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C221 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C231 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C247 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C248 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C249 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C251 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C252 2312296 Ceramic cap. Y5 V 1210 C253 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C254 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C255 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C256 2312296 Ceramic cap. Y5 V 1210 C257 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C258 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C260 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C261 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C262 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C263 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C266 2610003 Tantalum cap. 10 u 20 % 10 V 3.2x1.6x1.6 C268 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C269 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C271 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C272 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C301 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C302 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C303 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C304 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C305 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C306 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C307 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C308 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C309 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C310 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C311 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C312 2320546 Ceramic cap. 27 p 5 % 50 V 0402

System Module UP8

Original 09/98

Page 3 – 69

NSE–3

PAMS

System Module UP8

C313 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C400 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C401 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C402 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C403 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C404 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C405 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C500 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402 C501 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C502 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C504 2320534 Ceramic cap. 8.2 p 0.25 % 50 V 0402 C505 2320550 Ceramic cap. 39 p 5 % 50 V 0402 C506 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C507 2320550 Ceramic cap. 39 p 5 % 50 V 0402 C511 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C512 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C513 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C514 2320540 Ceramic cap. 15 p 5 % 50 V 0402 C515 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C516 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402 C518 2320532 Ceramic cap. 6.8 p 0.25 % 50 V 0402 C520 2320602 Ceramic cap. 4.7 p 0.25 % 50 V 0402 C530 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C531 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C532 2320554 Ceramic cap. 56 p 5 % 50 V 0402 C535 2310181 Ceramic cap. 1.5 n 5 % 50 V 1206 C540 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C550 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C553 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C554 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C555 2320618 Ceramic cap. 4.7 n 5 % 25 V 0402 C559 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C562 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C563 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C564 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402 C565 2320532 Ceramic cap. 6.8 p 0.25 % 50 V 0402 C566 2320538 Ceramic cap. 12 p 5 % 50 V 0402 C567 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C568 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C570 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C571 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C572 2320532 Ceramic cap. 6.8 p 0.25 % 50 V 0402 C574 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C575 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C576 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C582 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C583 2320544 Ceramic cap. 22 p 5 % 50 V 0402

Technical Documentation

Page 3 – 70

Original 09/98

PAMS

NSE–3

Technical Documentation

C585 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C586 2320540 Ceramic cap. 15 p 5 % 50 V 0402 C587 2310248 Ceramic cap. 4.7 n 5 % 50 V 1206 C588 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C590 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C592 2610003 Tantalum cap. 10 u 20 % 10 V 3.2x1.6x1.6 C600 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C601 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C602 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C603 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C604 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C610 2610013 Tantalum cap. 220 u 10 % 10 V 7.3x4.3x4.1 C611 2610013 Tantalum cap. 220 u 10 % 10 V 7.3x4.3x4.1 C612 2610013 Tantalum cap. 220 u 10 % 10 V 7.3x4.3x4.1 C613 2320538 Ceramic cap. 12 p 5 % 50 V 0402 C614 2320526 Ceramic cap. 3.9 p 0.25 % 50 V 0402 C621 2320534 Ceramic cap. 8.2 p 0.25 % 50 V 0402 C622 2320514 Ceramic cap. 1.2 p 0.25 % 50 V 0402 C623 2320534 Ceramic cap. 8.2 p 0.25 % 50 V 0402 C624 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C627 2320738 Ceramic cap. 470 p 10 % 50 V 0402 C630 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C632 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402 C633 2320532 Ceramic cap. 6.8 p 0.25 % 50 V 0402 C635 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C636 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C638 2320552 Ceramic cap. 47 p 5 % 50 V 0402 C639 2320592 Ceramic cap. 2.2 n 5 % 50 V 0402 C640 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C641 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C642 2320552 Ceramic cap. 47 p 5 % 50 V 0402 C643 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C644 2320540 Ceramic cap. 15 p 5 % 50 V 0402 C649 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C652 2320536 Ceramic cap. 10 p 5 % 50 V 0402 C653 2320536 Ceramic cap. 10 p 5 % 50 V 0402 C655 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402 C656 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C660 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C662 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C695 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C700 2320524 Ceramic cap. 3.3 p 0.25 % 50 V 0402 L103 3203701 Ferrite bead 33r/100mhz 0805 0805 L104 3203701 Ferrite bead 33r/100mhz 0805 0805 L105 3203701 Ferrite bead 33r/100mhz 0805 0805 L106 3640035 Filt z>450r/100m 0r7max 0.2a 0603 0603 L107 3640035 Filt z>450r/100m 0r7max 0.2a 0603 0603

System Module UP8

Original 09/98

Page 3 – 71

NSE–3

PAMS

System Module UP8

L108 3640035 Filt z>450r/100m 0r7max 0.2a 0603 0603 L400 3640035 Filt z>450r/100m 0r7max 0.2a 0603 0603 L500 3643039 Chip coil 220 n 5 % Q=35/100 MHz 0805 L501 3643039 Chip coil 220 n 5 % Q=35/100 MHz 0805 L550 3640069 Filt 47pf 25v 0r01 6a 1206 L552 3645157 Chip coil 100 n 10 % Q=12/100 MHz 0603 L554 3645157 Chip coil 100 n 10 % Q=12/100 MHz 0603 L580 3645161 Chip coil 150 n 5 % Q=14/100 MHz 0603 L581 3643025 Chip coil 56 n 5 % Q=40/200 MHz 0805 L600 3641206 Chip coil 10 % Q=25/7.96 MHz

L621 3641300 Chip coil 330 n 5 % Q=30/25 MHz 1008 L623 3641626 Chip coil 220 n 2 % Q=30/100 MHz 0805 L624 3641626 Chip coil 220 n 2 % Q=30/100 MHz 0805 B100 4510003 Crystal 32.768 k +–20PPM 8x3.8 G530 4350099 Vco 1006–1031mhz 2.8v 10ma gsm G600 4510153 VCTCXO 13.0 M +–5PPM 2.8V GSM F101 5119019 SM, fuse f 1.5a 32v 0603 Z500 4511017 Saw filter 947.5+–12.5 M /3.8DB 4X4 Z505 4511015 Saw filter 902.5+–12.5 M /3.8DB 4X4 Z550 4512005 Dupl 890–915/935–960mhz 20x14 20x14 Z620 4510009 Cer.filt 13+–0.09mhz 7.2x3.2 7.2x3.2 Z621 4510137 Saw filter 71+–0.09 M 14.2x8.4 V100 1825005 Chip varistor vwm14v vc30v 0805 0805 V101 4113651 Trans. supr. QUAD 6 V SOT23–5 V102 4113651 Trans. supr. QUAD 6 V SOT23–5 V103 4113601 Emi filter emif01–5250sc5 sot23–5 SOT23–5 V104 4113651 Trans. supr. QUAD 6 V SOT23–5 V116 4110067 Schottky diode MBR0520L 20 V 0.5 A SOD123 V250 4210100 Transistor BC848W npn 30 V SOT323 V550 4110014 Sch. diode x 2 BAS70–07 70 V 15 mA SOT143 V580 4110062 Cap. diode BB535 30 V 2.1/18.7PFSOD323 V581 4210066 Transistor BFR93AW npn 12 V 35 mA SOT323 V640 4210066 Transistor BFR93AW npn 12 V 35 mA SOT323 V705 4210100 Transistor BC848W npn 30 V SOT323 D200 4370279 Mad2 rom3 f711604 c12 tqfp176 TQFP176 D211 4340261 Te28f800 flashm 512kx16 120ns D220 4340273 IC, SRAM STSOP32 D230 4342264 IC, EEPROM SO8S D402 4340369 IC, dual bus buffer ssoTC7W126FU SSOP8 N100 4370047 Ccont 2f dct3 bb asic tqfp64 TQFP64 N101 4370165 Uba2006t chaps charg.control so16 SO16 N201 4340423 IC, regulator TK11230M 3.0 V SOT23L N250 4370317 Cobba_gj b07 bb asic dct3 tqfp64 TQFP64 N400 4860031 Tfdu4100 irda tx/rx>2.7v 115kbits 115KBITS N500 4370253 Crfu1a rx+tx uhf gsm v5 sot401–1 SOT401–1 N550 4370319 Rf9106 pw amp 880–915mhz psop2–16 PSOP2–16

Technical Documentation

1008

Page 3 – 72

Original 09/98

PAMS

NSE–3

Technical Documentation

N620 4370273 Plussa txmod+rxif+2pll tqfp64 TQFP64 S301 5219005 IC, SWsp–no 30vdc 50ma smSW TACT SMD S302 5219005 IC, SWsp–no 30vdc 50ma smSW TACT SMD X100 5469061 SM, system conn 6af+3dc+mic+jack X101 5469069 SM, batt conn 2pol spr p3.5 100v 100V2A X102 5469069 SM, batt conn 2pol spr p3.5 100v 100V2A X300 5460021 SM, conn 2x14m spring p1.0 pcb/p PCB/PCB X302 5400085 Sim card reader 2x3pol p2.54 sm SM X540 5429007 SM, coax conn m sw 50r 0.4–2ghz A500 9517012 SM, d rf shield dmc00422 hd940 u UP8 A510 9517013 SM, d rf shield pa–can dmc00455

9380753 Bar code label dmd03311 27x6.5 27x6.5 9850051 PCB UP8 123.25X41.0X1.0 M6 4/PA

System Module UP8

Original 09/98

Page 3 – 73

NSE–3

PAMS

System Module UP8

Technical Documentation

Parts list of UP8T (EDMS Issue 14.3) Code: 0200951

ITEM CODE DESCRIPTION VALUE TYPE

R100 1430826 Chip resistor 680 k 5 % 0.063 W 0402 R102 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R103 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402 R104 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R109 1620017 Res network 0w06 2x100r j 0404 0404 R113 1430726 Chip resistor 100 5 % 0.063 W 0402 R116 1430788 Chip resistor 22 k 5 % 0.063 W 0402 R118 1430778 Chip resistor 10 k 5 % 0.063 W 0402 R120 1620025 Res network 0w06 2x100k j 0404 0404 R122 1620019 Res network 0w06 2x10k j 0404 0404 R124 1620027 Res network 0w06 2x47r j 0404 0404 R127 1620031 Res network 0w06 2x1k0 j 0404 0404 R128 1430718 Chip resistor 47 5 % 0.063 W 0402 R131 1422881 Chip resistor 0.22 5 % 1 W 1218 R136 1430804 Chip resistor 100 k 5 % 0.063 W 0402 R140 1430690 Chip jumper 0402 R142 1430690 Chip jumper 0402 R143 1430834 Chip resistor 3.3 M 5 % 0.063 W 0402 R144 1414364 Chip resistor 4.7 M 5 % 0.1 W 0805 R152 1430690 Chip jumper 0402 R154 1430122 Chip resistor 4.7 M 5 % 0.063 W 0603 R201 1430812 Chip resistor 220 k 5 % 0.063 W 0402 R202 1430804 Chip resistor 100 k 5 % 0.063 W 0402 R203 1620029 Res network 0w06 2x4k7 j 0404 0404 R211 1430804 Chip resistor 100 k 5 % 0.063 W 0402 R213 1430690 Chip jumper 0402 R215 1620023 Res network 0w06 2x47k j 0404 0404 R252 1430740 Chip resistor 330 5 % 0.063 W 0402 R254 1620027 Res network 0w06 2x47r j 0404 0404 R256 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 R257 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R259 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R260 1430788 Chip resistor 22 k 5 % 0.063 W 0402 R261 1430788 Chip resistor 22 k 5 % 0.063 W 0402 R263 1430778 Chip resistor 10 k 5 % 0.063 W 0402 R265 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R267 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402 R268 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402 R270 1430804 Chip resistor 100 k 5 % 0.063 W 0402 R271 1430804 Chip resistor 100 k 5 % 0.063 W 0402 R301 1620031 Res network 0w06 2x1k0 j 0404 0404 R303 1620031 Res network 0w06 2x1k0 j 0404 0404 R305 1620031 Res network 0w06 2x1k0 j 0404 0404

Page 3 – 74

Original 09/98

PAMS

NSE–3

Technical Documentation

R307 1620031 Res network 0w06 2x1k0 j 0404 0404 R308 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402 R309 1620031 Res network 0w06 2x1k0 j 0404 0404 R401 1430778 Chip resistor 10 k 5 % 0.063 W 0402 R402 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402 R403 1430693 Chip resistor 5.6 5 % 0.063 W 0402 R404 1430693 Chip resistor 5.6 5 % 0.063 W 0402 R405 1430693 Chip resistor 5.6 5 % 0.063 W 0402 R406 1430693 Chip resistor 5.6 5 % 0.063 W 0402 R411 1430760 Chip resistor 1.8 k 5 % 0.063 W 0402 R413 1430804 Chip resistor 100 k 5 % 0.063 W 0402 R500 1430700 Chip resistor 10 5 % 0.063 W 0402 R501 1430700 Chip resistor 10 5 % 0.063 W 0402 R502 1430764 Chip resistor 3.3 k 5 % 0.063 W 0402 R504 1620019 Res network 0w06 2x10k j 0404 0404 R507 1430740 Chip resistor 330 5 % 0.063 W 0402 R530 1430700 Chip resistor 10 5 % 0.063 W 0402 R531 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 R533 1430796 Chip resistor 47 k 5 % 0.063 W 0402 R550 1430752 Chip resistor 820 5 % 0.063 W 0402 R551 1430740 Chip resistor 330 5 % 0.063 W 0402 R552 1430740 Chip resistor 330 5 % 0.063 W 0402 R553 1430774 Chip resistor 6.8 k 5 % 0.063 W 0402 R554 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402 R555 1430726 Chip resistor 100 5 % 0.063 W 0402 R580 1430706 Chip resistor 15 5 % 0.063 W 0402 R581 1430832 Chip resistor 2.7 k 5 % 0.063 W 0402 R582 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 R584 1430780 Chip resistor 12 k 5 % 0.063 W 0402 R585 1430774 Chip resistor 6.8 k 5 % 0.063 W 0402 R586 1430738 Chip resistor 270 5 % 0.063 W 0402 R588 1430744 Chip resistor 470 5 % 0.063 W 0402 R589 1430710 Chip resistor 22 5 % 0.063 W 0402 R600 1430788 Chip resistor 22 k 5 % 0.063 W 0402 R620 1620029 Res network 0w06 2x4k7 j 0404 0404 R621 1430744 Chip resistor 470 5 % 0.063 W 0402 R622 1430758 Chip resistor 1.5 k 5 % 0.063 W 0402 R623 1430714 Chip resistor 33 5 % 0.063 W 0402 R624 1430714 Chip resistor 33 5 % 0.063 W 0402 R625 1430714 Chip resistor 33 5 % 0.063 W 0402 R626 1430740 Chip resistor 330 5 % 0.063 W 0402 R627 1430776 Chip resistor 8.2 k 5 % 0.063 W 0402 R628 1430744 Chip resistor 470 5 % 0.063 W 0402 R629 1430730 Chip resistor 150 5 % 0.063 W 0402 R630 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 R631 1430700 Chip resistor 10 5 % 0.063 W 0402 R632 1430848 Chip resistor 12 k 1 % 0.063 W 0402

System Module UP8

Original 09/98

Page 3 – 75

NSE–3

PAMS

System Module UP8

R634 1430848 Chip resistor 12 k 1 % 0.063 W 0402 R635 1430851 Chip resistor 15 k 2 % 0.063 W 0402 R636 1430848 Chip resistor 12 k 1 % 0.063 W 0402 R638 1430848 Chip resistor 12 k 1 % 0.063 W 0402 R640 1430734 Chip resistor 220 5 % 0.063 W 0402 R641 1820031 NTC resistor 330 10 % 0.12 W 0805 R660 1430726 Chip resistor 100 5 % 0.063 W 0402 R662 1430714 Chip resistor 33 5 % 0.063 W 0402 R664 1430764 Chip resistor 3.3 k 5 % 0.063 W 0402 R666 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402 R668 1430732 Chip resistor 180 5 % 0.063 W 0402 R670 1430726 Chip resistor 100 5 % 0.063 W 0402 R706 1430812 Chip resistor 220 k 5 % 0.063 W 0402 R708 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 R710 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402 R712 1430714 Chip resistor 33 5 % 0.063 W 0402 C100 2610003 Tantalum cap. 10 u 20 % 10 V

3.2x1.6x1.6 C101 2320548 Ceramic cap. 33 p 5 % 50 V 0402 C102 2320538 Ceramic cap. 12 p 5 % 50 V 0402 C103 2604127 Tantalum cap. 1.0 u 20 % 35 V

3.5x2.8x1.9 C104 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C105 2610003 Tantalum cap. 10 u 20 % 10 V

3.2x1.6x1.6 C106 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C107 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C108 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C109 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C110 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C112 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C113 2320508 Ceramic cap. 1.0 p 0.25 % 50 V 0402 C114 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C115 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C117 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C118 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C119 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C120 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C121 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C122 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C127 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C128 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C129 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C130 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C131 2610003 Tantalum cap. 10 u 20 % 10 V

3.2x1.6x1.6 C132 2312403 Ceramic cap. 2.2 u 10 % 10 V 1206

Technical Documentation

Page 3 – 76

Original 09/98

PAMS

NSE–3

Technical Documentation

C133 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C140 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C142 2610003 Tantalum cap. 10 u 20 % 10 V

3.2x1.6x1.6 C143 2610003 Tantalum cap. 10 u 20 % 10 V

3.2x1.6x1.6 C146 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C160 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C161 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C201 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C202 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C203 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C204 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C205 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C206 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C207 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C208 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C209 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C211 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C212 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C213 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C221 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C231 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C247 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C248 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C249 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C251 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C252 2312296 Ceramic cap. Y5 V 1210 C253 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C254 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C255 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C256 2312296 Ceramic cap. Y5 V 1210 C257 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C258 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C260 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C261 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C262 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C263 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C266 2610003 Tantalum cap. 10 u 20 % 10 V

3.2x1.6x1.6 C268 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C269 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C271 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C272 2320131 Ceramic cap. 33 n 10 % 16 V 0603 C301 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C302 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C303 2320560 Ceramic cap. 100 p 5 % 50 V 0402

System Module UP8

Original 09/98

Page 3 – 77

NSE–3

PAMS

System Module UP8

C304 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C305 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C306 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C307 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C308 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C309 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C310 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C311 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C312 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C313 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C400 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C401 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C402 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C403 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C404 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C405 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C406 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C500 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402 C501 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C502 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C504 2320534 Ceramic cap. 8.2 p 0.25 % 50 V 0402 C505 2320550 Ceramic cap. 39 p 5 % 50 V 0402 C506 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C507 2320550 Ceramic cap. 39 p 5 % 50 V 0402 C511 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C512 2320554 Ceramic cap. 56 p 5 % 50 V 0402 C513 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C514 2320540 Ceramic cap. 15 p 5 % 50 V 0402 C515 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C516 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402 C518 2320532 Ceramic cap. 6.8 p 0.25 % 50 V 0402 C520 2320602 Ceramic cap. 4.7 p 0.25 % 50 V 0402 C530 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C531 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C532 2320554 Ceramic cap. 56 p 5 % 50 V 0402 C535 2310181 Ceramic cap. 1.5 n 5 % 50 V 1206 C540 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C550 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C553 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C554 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C555 2320618 Ceramic cap. 4.7 n 5 % 25 V 0402 C562 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C563 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C564 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402 C565 2320532 Ceramic cap. 6.8 p 0.25 % 50 V 0402 C566 2320538 Ceramic cap. 12 p 5 % 50 V 0402 C567 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402

Technical Documentation

Page 3 – 78

Original 09/98

PAMS

NSE–3

Technical Documentation

C568 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C570 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C571 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C572 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402 C574 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C575 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C576 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C582 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C583 2320544 Ceramic cap. 22 p 5 % 50 V 0402 C585 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C586 2320540 Ceramic cap. 15 p 5 % 50 V 0402 C587 2310248 Ceramic cap. 4.7 n 5 % 50 V 1206 C588 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C590 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C592 2610003 Tantalum cap. 10 u 20 % 10 V

3.2x1.6x1.6 C600 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C601 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C602 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C603 2320584 Ceramic cap. 1.0 n 5 % 50 V 0402 C604 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C610 2610013 Tantalum cap. 220 u 10 % 10 V

7.3x4.3x4.1 C611 2610013 Tantalum cap. 220 u 10 % 10 V

7.3x4.3x4.1 C612 2610013 Tantalum cap. 220 u 10 % 10 V

7.3x4.3x4.1 C613 2320538 Ceramic cap. 12 p 5 % 50 V 0402 C614 2320526 Ceramic cap. 3.9 p 0.25 % 50 V 0402 C621 2320534 Ceramic cap. 8.2 p 0.25 % 50 V 0402 C622 2320514 Ceramic cap. 1.2 p 0.25 % 50 V 0402 C623 2320534 Ceramic cap. 8.2 p 0.25 % 50 V 0402 C624 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C627 2320738 Ceramic cap. 470 p 10 % 50 V 0402 C630 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C632 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402 C633 2320532 Ceramic cap. 6.8 p 0.25 % 50 V 0402 C635 2320560 Ceramic cap. 100 p 5 % 50 V 0402 C636 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C638 2320552 Ceramic cap. 47 p 5 % 50 V 0402 C639 2320592 Ceramic cap. 2.2 n 5 % 50 V 0402 C640 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C641 2310784 Ceramic cap. 100 n 10 % 25 V 0805 C642 2320552 Ceramic cap. 47 p 5 % 50 V 0402 C643 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C644 2320532 Ceramic cap. 6.8 p 0.25 % 50 V 0402 C649 2320131 Ceramic cap. 33 n 10 % 16 V 0603

System Module UP8

Original 09/98

Page 3 – 79

NSE–3

PAMS

System Module UP8

C652 2320536 Ceramic cap. 10 p 5 % 50 V 0402 C653 2320536 Ceramic cap. 10 p 5 % 50 V 0402 C655 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402 C656 2320620 Ceramic cap. 10 n 5 % 16 V 0402 C660 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C662 2320546 Ceramic cap. 27 p 5 % 50 V 0402 C695 2312401 Ceramic cap. 1.0 u 10 % 10 V 0805 C700 2320524 Ceramic cap. 3.3 p 0.25 % 50 V 0402 L103 3203701 Ferrite bead 33r/100mhz 0805 0805 L104 3203701 Ferrite bead 33r/100mhz 0805 0805 L105 3203701 Ferrite bead 33r/100mhz 0805 0805 L106 3640035 Filt z>450r/100m 0r7max 0.2a 0603 0603 L107 3640035 Filt z>450r/100m 0r7max 0.2a 0603 0603 L108 3640035 Filt z>450r/100m 0r7max 0.2a 0603 0603 L500 3643039 Chip coil 220 n 5 % Q=35/100 MHz 0805 L501 3643039 Chip coil 220 n 5 % Q=35/100 MHz 0805 L550 3640069 Filt 47pf 25v 0r01 6a 1206 L552 3645157 Chip coil 100 n 10 % Q=12/100 MHz 0603 L554 3645157 Chip coil 100 n 10 % Q=12/100 MHz 0603 L580 3645161 Chip coil 150 n 5 % Q=14/100 MHz 0603 L581 3643025 Chip coil 56 n 5 % Q=40/200 MH 0805 L600 3641206 Chip coil 10 % Q=25/7.96 MHz 1008 L621 3641300 Chip coil 330 n 5 % Q=30/25 MHz 1008 L623 3641626 Chip coil 220 n 2 % Q=30/100 MHz 0805 L624 3641626 Chip coil 220 n 2 % Q=30/100 MHz 0805 B100 4510159 Crystal 32.768 k +–20PPM G530 4350099 Vco 1006–1031mhz 2.8v 10ma gsm G600 4510153 VCTCXO 13.0 M +–5PPM 2.8V GSM F101 5119019 SM, fuse f 1.5a 32v 0603 Z500 4511017 Saw filter 947.5+–12.5 M /3.8DB 4X4 Z505 4511015 Saw filter 902.5+–12.5 M /3.8DB 4X4 Z550 4512071 Dupl 890–915/935–960mhz 20x14 20x14 Z620 4510009 Cer.filt 13+–0.09mhz 7.2x3.2 7.2x3.2 Z621 4510137 Saw filter 71+–0.09 M 14.2x8.4 V100 1825005 Chip varistor vwm14v vc30v 0805 0805 V101 4113651 Trans. supr. QUAD 6 V SOT23–5 V102 4113651 Trans. supr. QUAD 6 V SOT23–5 V103 4113601 Emi filter emif01–5250sc5 sot23–5 SOT23–5 V104 4113651 Trans. supr. QUAD 6 V SOT23–5 V116 4110067 Schottky diode MBR0520L 20 V 0.5 A SOD123 V250 4210100 Transistor BC848W npn 30 V SOT323 V401 4210052 Transistor DTC114EE npn RB V EM3 V402 4210102 Transistor BC858W pnp 30 V 100 mA 200MWSOT323 V550 4110014 Sch. diode x 2 BAS70–07 70 V 15 mA SOT143 V580 4110062 Cap. diode BB535 30 V

Technical Documentation

Page 3 – 80

Original 09/98

PAMS

NSE–3

Technical Documentation

2.1/18.7PFSOD323 V581 4210066 Transistor BFR93AW npn 12 V 35 mA SOT323 V640 4210066 Transistor BFR93AW npn 12 V 35 mA SOT323 V705 4210100 Transistor BC848W npn 30 V SOT323 D200 4370279 Mad2 rom3 f711604 c12 TQFP176 D211 4340261 IC, flash mem. TSO48 D220 4340273 IC, SRAM STSOP32 D230 4342264 IC, EEPROM SO8S D402 4340369 IC, dual bus buffer ssoTC7W126FU SSOP8 N100 4370391 Ccont2h dct3 bb asic TQFP64 N101 4370165 Chaps charger control SO16 N201 4340413 IC, regulator TK11230BMC 3.0 V SOT23L N250 4370363 Cobba_gj b09 bb asic TQFP64 N400 4860031 Tfdu4100 irda tx/rx>2.7v 115kbits 115KBITS N500 4370253 Crfu1a rx+tx uhf gsm v5 sot401–1 SOT401–1 N550 4370319 Rf9106 pw amp 880–915mhz PSOP2–16 N620 4370273 Plussa txmod+rxif+2pll t TQFP64 S301 5219005 IC, SWsp–no 30vdc 50ma SW TACT SMD S302 5219005 IC, SWsp–no 30vdc 50ma SW TACT SMD X100 5469061 SM, system conn 6af+3dc+mic+jack X101 5469069 SM, batt conn 2pol spr p3.5 100V2A X102 5469069 SM, batt conn 2pol spr p3.5 100V2A X300 5460021 SM, conn 2x14m spring p1.0 PCB/PCB X302 5400085 Sim card reader 2x3pol p2.54 s SM X540 5429007 SM, coax conn m sw 50r 0.4–2ghz A500 9517012 SM, d rf shield dmc00422 hd940 u UP8 A510 9517013 SM, d rf shield pa–can dmc00455

9380753 Bar code label dmd03311 27x6.5 27x6.5 9850051 PCB UP8 123.25X41.0X1.0 M6 4/PA

System Module UP8

Original 09/98

Page 3 – 81

NSE–3

PAMS

System Module UP8

Technical Documentation

This page intentionally left blank.

Page 3 – 82

Original 09/98

Nokia 6110 System Module 03

Specifications and Main Features

Frequently Asked Questions

User Manual

System Module UP8

AMENDMENT RECORD SHEET

Introduction

Interconnection Diagram

System Module

Functional Description

Baseband Module

Functional Description

RF Module

Functional Description

Connections

Parts list of UP8T (EDMS Issue 11.11) Code: 0200951
