Nokia 6103 User Manual

Nokia 6103 User Guide

9245707

Issue 1

DECLARATION OF CONFORMITY We, NOKIA CORPORATION declare under our sole responsibility that the product RM-161 is in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Confo rmity can be found from http://w ww.nokia.com/phones/declaration_of_conformity/.

The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end-of life. This applies to your device but also to any enhancements marked with this symbol. Do not dispose of these products as unsorted municipal waste.

Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Nokia, Nokia Connecting People, Xpress-on and Pop-Port are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Nokia tune is a sound mark of Nokia Corporation.

Includes RSA BSAFE cryptographic or sec urity protocol software from RSA Security.

Java is a trademark of Sun Microsystems, Inc.

Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

This Nokia device complies with Directive 2002/95/EC on the restriction of the use of certain hazard ous substances in electrical and electronic equipment.

Under no c ircumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.

Th e con tents of th is do cum ent a re pr ovide d "as is ". Excep t as r equire d by appl icab le l aw, n o warr anti es of any kind, either exp ress or implied, including, bu t not limited to, the implied w arranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.

This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries . Diversion contrary to law is prohibite d.

9245707/issue 1

For your safety ..................................................................................................... 9

General information.......................................................................................... 13

Overview of functions ............................................................................................................................. 13

Access codes .............................................................................................................................................. 14

Configuration settings service.............................................................................................................. 15

Download content and applications ................................................................................................... 16

Nokia support on the Web..................................................................................................................... 16

1. Get started..................................................................................................... 17

Open the fold............................................................................................................................................. 17

Install the SIM card and the battery................................................................................................... 17

Charge the battery ................................................................................................................................... 19

Switch the phone on and off ................................................................................................................ 19

Normal operating position ..................................................................................................................... 20

Wrist strap.................................................................................................................................................. 20

2. Your phone..................................................................................................... 21

Keys and parts........................................................................................................................................... 21

Standby mode............................................................................................................................................ 22

Keypad lock (keyguard) ........................................................................................................................... 26

3. Call functions ................................................................................................ 27

Make a call ................................................................................................................................................. 27

Answer or reject a call ............................................................................................................................ 28

Options during a call ............................................................................................................................... 28

4. Write text....................................................................................................... 30

Settings ....................................................................................................................................................... 30

Predictive text input................................................................................................................................ 30

Traditional text input .............................................................................................................................. 31

5. Navigate the menus...................................................................................... 32

6. Messages........................................................................................................ 33

Text messages (SMS)............................................................................................................................... 33

Multimedia messages ............................................................................................................................ 36

Memory full................................................................................................................................................ 39

Folders.......................................................................................................................................................... 39

Flash messages.......................................................................................................................................... 40

Nokia Xpress audio messaging ............................................................................................................. 41

Instant messaging .................................................................................................................................... 42

E-mail application .................................................................................................................................... 48

Voice messages ......................................................................................................................................... 51

Info messages ............................................................................................................................................ 51

Service commands.................................................................................................................................... 52

Delete messages........................................................................................................................................ 52

Message settings ...................................................................................................................................... 52

Message counter....................................................................................................................................... 55

7. Contacts ......................................................................................................... 56

Search for a contact ................................................................................................................................ 56

Save names and phone numbers ......................................................................................................... 56

Save numbers, items, or an image....................................................................................................... 56

Copy contacts ............................................................................................................................................ 57

Edit contact details.................................................................................................................................. 58

Delete contacts or contact details ...................................................................................................... 58

Business cards ........................................................................................................................................... 58

My presence ............................................................................................................................................... 59

Subscribed names..................................................................................................................................... 60

Settings ....................................................................................................................................................... 62

Groups.......................................................................................................................................................... 62

Voice dialing .............................................................................................................................................. 62

Speed dials.................................................................................................................................................. 64

Info, service, and my numbers .............................................................................................................. 64

8. Call register.................................................................................................... 65

Recent calls lists....................................................................................................................................... 65

Counters and timers ................................................................................................................................ 65

9. Settings......................................................................................................... 66

Profiles......................................................................................................................................................... 66

Themes......................................................................................................................................................... 66

Tones ............................................................................................................................................................ 67

My shortcuts .............................................................................................................................................. 67

Main display............................................................................................................................................... 68

Mini display................................................................................................................................................ 69

Time and date ............................................................................................................................................ 69

Call................................................................................................................................................................ 70

Phone ........................................................................................................................................................... 71

Connectivity ............................................................................................................................................... 72

Enhancements ........................................................................................................................................... 76

Configuration............................................................................................................................................. 77

Security........................................................................................................................................................ 78

Restore factory settings.......................................................................................................................... 79

10. Operator menu............................................................................................ 80

11. Gallery ......................................................................................................... 81

12. Media........................................................................................................... 82

Camera......................................................................................................................................................... 82

Radio ............................................................................................................................................................ 83

Recorder ...................................................................................................................................................... 85

13. Organiser ..................................................................................................... 86

Alarm clock................................................................................................................................................. 86

Calendar ...................................................................................................................................................... 87

To-do list ..................................................................................................................................................... 88

Notes............................................................................................................................................................ 88

Synchronization ........................................................................................................................................ 89

Calculator ................................................................................................................................................... 91

Stopwatch................................................................................................................................................... 92

Countdown timer...................................................................................................................................... 92

14. Applications ................................................................................................ 94

Games .......................................................................................................................................................... 94

Collection.................................................................................................................................................... 95

15. Push to talk................................................................................................. 97

Push to talk menu .................................................................................................................................... 98

Connect to PTT .......................................................................................................................................... 98

Make and receive a PTT call .................................................................................................................. 99

Callback requests................................................................................................................................... 101

Add a one-to-one contact .................................................................................................................. 103

Create and set up groups .................................................................................................................... 103

PTT settings ............................................................................................................................................. 106

16. Web............................................................................................................ 107

Set up browsing ..................................................................................................................................... 107

Connect to a service ............................................................................................................................. 107

Browse pages.......................................................................................................................................... 108

Appearance settings ............................................................................................................................. 110

Cookies ..................................................................................................................................................... 111

Scripts over secure connection.......................................................................................................... 111

Bookmarks ............................................................................................................................................... 111

Download files........................................................................................................................................ 112

Service inbox........................................................................................................................................... 112

Cache memory........................................................................................................................................ 114

Positioning information....................................................................................................................... 114

Browser security .................................................................................................................................... 114

17. SIM services .............................................................................................. 118

18. PC connectivity ......................................................................................... 119

PC Suite .................................................................................................................................................... 119

Packet data, HSCSD, and CSD............................................................................................................ 119

Data communication applications.................................................................................................... 120

19. Battery information.................................................................................. 121

Charging and discharging ................................................................................................................... 121

Nokia battery authentication guidelines ........................................................................................ 122

Care and maintenance .................................................................................... 125

Additional safety information........................................................................ 127

Index................................................................................................................. 132

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless phones may be susceptible to interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELLING

Do not use the phone at a refuelling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Do not use the phone where blasting is in progress.

USE SENSIBLY

Use only in the normal position as explained in the product documentation. Do not touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all important information stored in your phone.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press the end key as many times as needed to clear the display and return to the start screen. Enter the emergency number, then press the call key. Give your location. Do not end the call until given permission to do so.

■ About your device

The wireless device described in this guide is approved for use on the EGSM 900 and GSM 1800 and 1900 networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect the privacy and legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

■ Network services

To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These network services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize network services. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Your device may also have been specially configured for your network provider. This configuration may include changes in menu names, menu order and icons. Contact your service provider for more information.

This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some features of this device, such as text messages, multimedia messages, audio messages, instant messaging service, flash messages, e-mail, presence enhanced contacts, mobile

Internet services, content and application download, and synchronization with a remote Internet server, require network support for these technologies.

■ Shared memory

The phone has two memories. The following features may share the first memory: contacts, text messages, multimedia messages (without attachments), instant messaging, groups, voice commands, calendar, and to-do notes. The second shared memory is used by files stored in Gallery, attachments of multimedia messages, e-mail, and Java of one or more of these features may reduce the memory available for the remaining features sharing memory. For example, saving many Java applications may use all of the available memory. Your device may display a message that the memory is full when you try to use a shared memory feature. In this case, delete some of the information or entries stored in the shared memory features before continuing. Some of the features, such as text messages, may have a certain amount of memory specially allotted to them in addition to the memory shared with other features.

applications. Use

■ Enhancements

A few practical rules about accessories and enhancements are as follows:

• Keep all accessories and enhancements out of the reach of small children.

• When you disconnect the power cord of any accessory or enhancement, grasp and pull the plug, not the cord.

• Check regularly that enhancements installed in a vehicle are mounted and are operating properly.

• Installation of any complex car enhancements must be made by qualified personnel only.

General information

■ Overview of functions

Your phone provides many functions that are practical for daily use, such as a calendar, a clock, an alarm clock, a radio, and a built-in camera. Your phone also supports the following functions:

• Enhanced data rates for GSM evolution (EDGE), see “Packet data (EGPRS),” p. 75

• Extensible hypertext markup language (XHTML), see “Web,” p. 107

• Audio messaging, see “Nokia Xpress audio messaging,” p. 41

• Instant messaging, see “Instant messaging,” p. 42

• E-mail application, see “E-mail application,” p. 48

• Bluetooth technology, see “Bluetooth wireless technology,” p. 72

• Push to talk, see “Push to talk,” p. 97

• Presence-enhanced contacts, see “My presence,” p. 59

• Java 2 Platform, Micro Edition (J2METM), see “Applications,” p. 94

■ Access codes

Security code

The security code (5 to 10 digits) helps to protect your phone against unauthorized use. The preset code is 12345. To change the code, and to set the phone to request the code, see “Security,” p. 78.

PIN codes

The personal identification number (PIN) code and the universal personal identification number (UPIN) code (4 to 8 digits) help to protect your SIM card against unauthorized use. See “Security,” p. 78.

The PIN2 code (4 to 8 digits) may be supplied with the SIM card and is required for some functions.

The module PIN is required to access the information in the security module. See

“Security module,” p. 115.

The signing PIN is required for the digital signature. See “Digital signature,” p. 117.

PUK codes

The personal unblocking key (PUK) code and the universal personal unblocking key (UPUK) code (8 digits) is required to change a blocked PIN code and UPIN code, respectively. The PUK2 code (8 digits) is required to change a blocked PIN2 code. If

the codes are not supplied with the SIM card, contact your local service provider for the codes.

Barring password

The barring password (4 digits) is required when using the Call barring service. See

“Security,” p. 78.

■ Configuration settings service

To use some of the network services, such as mobile Internet services, MMS, Nokia Xpress audio messaging, or remote Internet server synchronization, your phone needs the correct configuration settings. You may be able to receive the settings directly as a configuration message. After receiving the settings you need to save them on your phone. The service provider may provide a PIN that is needed to save the settings. For more information on availability, contact your service provider, nearest authorized Nokia dealer, or visit the support area on the Nokia Web site, <www.nokia.com/support>.

When you have received a configuration message Configuration sett. received is displayed.

To save the settings, select Show > Save. If the phone requests Enter settings'

PIN:, enter the PIN code for the settings, and select OK. To receive the PIN code,

contact the service provider that supplies the settings. If no settings are saved yet, these settings are saved and set as default configuration settings. Otherwise, the phone asks Activate saved configuration settings?.

To discard the received settings, select Exit or Show > Discard. To edit the settings, see “Configuration,” p. 77.

■ Download content and applications

You may be able to download new content (for example, themes) to the phone (network service). Select the download function (for example, in the Gallery menu). To access the download function, see the respective menu descriptions. For the availability of different services, pricing, and tariffs, contact your service provider.

Important: Use only services that you trust and that offer adequate security and protection against harmful software.

■ Nokia support on the Web

Check <www.nokia.com/support> or your local Nokia Web site for the latest version of this guide, additional information, downloads, and services related to your Nokia product.

1. Get started

■ Open the fold

When you open the fold of the phone, it opens up to approximately 155 degrees. Do not try to force the fold open more.

■ Install the SIM card and the battery

Always switch the device off and disconnect the charger before removing the battery.

Keep all SIM cards out of the reach of small children. For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider, network operator, or other vendor.

This device is intended for use with BL-4C battery.

The SIM card and its contacts can easily be damaged by scratches or bending, so be careful when handling, inserting, or removing the card.

To remove the back cover of the phone press the release button (1), and slide the back cover to remove it from the phone (2).

Remove the battery as shown(3). Release the SIM card holder (4).

Insert the SIM card (5). Make sure that the SIM card is properly inserted, and that the golden contact area on the card is facing downwards. Close the SIM card holder (6) and press it until it snaps into position.

Replace the battery (7). Observe the battery contacts. Always use original Nokia batteries. See “Nokia battery

authentication guidelines,” p. 122.

Slide the back cover into its place (8,

9).

■ Charge the battery

Warning: Use only batteries, chargers, and enhancements approved by Nokia for

use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

Check the model number of any charger before use with this device. This device is intended for use when supplied with power from an AC-3, AC-4, and DC-4 charger, and from AC-1, ACP-7, ACP-12, and LCH-12 charger when used with the charger adapter CA-44.

For availability of approved enhancements, please check with your dealer.

1. Connect the charger to a wall socket.

2. Connect the lead from the charger to the socket on the bottom of your phone.

If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.

The charging time depends on the charger and the battery used. For example, charging a BL-4C battery with the AC-3 charger takes approximately 2 hours and 12 minutes while the phone is in the standby mode.

■ Switch the phone on and off

Warning: Do not switch the phone on when wireless phone use is prohibited or

when it may cause interference or danger.

Press and hold the power key. See “Keys and parts,” p. 21. If the phone asks for a PIN or a UPIN code, enter the code (displayed as ****), and select OK.

Plug and play service

When you switch on your phone for the first time, and the phone is in the standby mode, you are asked to get the configuration settings from your service provider (network service). Confirm or decline the query. See "Connect to service provider

support ," p. 77, and “Configuration settings service,” p. 15.

■ Normal operating position

Use the phone only in its normal operating position.

Your device has an external antenna.

As with any other radio transmitting device, do not touch the antenna unnecessarily when the device is switched on. Contact with the antenna affects call quality and may cause the device to operate at a higher power level than otherwise needed. Avoiding contact with the antenna area when operating the device optimizes the antenna performance and the battery life.

■ Wrist strap

Remove the back cover and the battery. Insert the strap as shown in the picture. Replace the battery and the back cover.

2. Your phone

■ Keys and parts

• Earpiece (1)

• Main display (2)

• Left selection key (3)

• Middle selection key (4)

• Right selection key (5)

• Volume key (6)

• 4-way navigation key (7)

• Call key (8)

• Push to talk (PTT) and camera release key (9)

• Infrared (IR) port (10)

• End and power key (11)

• Charger connector (12)

• Pop-PortTM connector (13)

• Microphone (14)

• Loudspeaker (15)

• Camera lens (16)

• Mini display (17)

Warning: The side keys (6) and (9) and the antenna cap of this device may contain nickel. These parts are not designed for prolonged contact with the skin. Continuous exposure to nickel on the skin may lead to a nickel allergy.

■ Standby mode

When the phone is ready for use, and you have not entered any characters, the phone is in the standby mode.

Mini display

When the fold is closed, the mini display may show the following:

• The signal strength of the cellular network at your current location and the battery charge level

• The name of the network, or if the phone is not in service, it is indicated by a text note

• The time, the active profile, and the alarm clock or calendar note alerts

When you have an incoming call, the caller’s name or number is shown if it is identified.

Main display

In the standby mode the main display may show the following:

• Name of the network or the operator logo (1)

• Signal strength of the cellular network at your current location (2)

• Battery charge level (3)

• Function of the left selection key is Go to (4).

• Function of the middle selection key is Menu (5)

• Function of the right selection key is Names (6) or another shortcut to a function that you selected. See

“My shortcuts,” p. 67. Operator variants may have an operator-specific name

to access an operator-specific Web site.

Personal shortcut list

The left selection key is Go to.

To view the functions in the personal shortcut list, select Go to. To activate a function select it.

To view a list with available functions, select Go to > Options > Select options. To add a function to the shortcut list, select Mark. To remove a function from the list, select Unmark.

To rearrange the functions on your personal shortcut list, select Go to >

Options > Organise. Select the desired function, Move, and the place where you

want to move the function.

Shortcuts in the standby mode

• To access the list of dialed numbers, press the call key once. Scroll to the number or name that you want; to call the number, press the call key.

• To open the web browser, press and hold 0.

• To call your voice mailbox, press and hold 1.

• Use the navigation key as a shortcut. See “My shortcuts,” p. 67.

Power saving

A digital clock view overwrites the display when no function of the phone has been used for a certain period of time. To activate the power saver, see Power saver in “Main display,” p. 68, and “Mini display,” p. 69. To deactivate the power saver, open the fold, or press any key.

Indicators

You received one or several text or picture messages. See “Read and reply

to a SMS message,” p. 34.

You received one or several multimedia messages. See “Read and reply to

a multimedia message,” p. 38.

The phone registered a missed call. See “Call register,” p. 65.

The keypad is locked. See “Keypad lock (keyguard),” p. 26.

The phone does not ring for an incoming call or text message when

Incoming call alert and Message alert tone are set to Off. See “Tones,”

p. 67.

The alarm clock is set to On. See “Alarm clock,” p. 86.

When the packet data connection mode Always online is selected and the packet data service is available, the indicator is shown. See “Packet data

(EGPRS),” p. 75.

A packet data connection is established. See “Packet data (EGPRS),” p. 75 and “Browse pages,” p. 108.

The packet data connection is suspended (on hold), for example, if there is an incoming or outgoing call during a packet data dial-up connection.

When the infrared connection is activated, the indicator is shown continuously.

Bluetooth connection indicator. See “Bluetooth wireless technology,”, p. 72.

■ Keypad lock (keyguard)

To prevent the keys from being accidentally pressed, select Menu, and press * within 3.5 seconds to lock the keypad.

To unlock the keypad, select Unlock, and press *. If the Security keyguard is set On, enter the security code if requested.

To answer a call when the keyguard is on, press the call key. When you end or reject the call, the keypad automatically locks.

For Automatic keyguard and Security keyguard, see “Phone,” p. 71.

When the keyguard is on, calls still may be possible to the official emergency number programmed into your device.

3. Call functions

■ Make a call

1. Enter the phone number, including the area code.

For international calls, press * twice for the international prefix (the + character replaces the international access code) and then enter the country code, the area code without the leading 0, if necessary, and the phone number.

2. To call the number, press the call key.

3. To end the call or to cancel the call attempt, press the end key, or close the phone.

To make a call using names, search for a name or phone number in Contacts, see

“Search for a contact,” p. 56. Press the call key to call the number.

To access the list of up to 20 numbers you last called or attempted to call, press the call key once in the standby mode. To call the number, select a number or name, and press the call key.

Speed dialing

Assign a phone number to one of the speed-dialing keys, 2 to 9. See “Speed dials,” p. 64. Call the number in either of the following ways:

• Press a speed-dialing key, then the call key.

•If Speed dialling is set to On, press and hold a speed-dialing key until the call begins. See Speed dialling in “Call,” p. 70.

■ Answer or reject a call

To answer an incoming call, press the call key, or open the phone. To end the call, press the end key, or close the phone.

To reject an incoming call when the phone is open, press the end key, or close the phone. To reject an incoming call when the phone is closed, open the phone, and press the end key within 1.5 seconds.

To mute the ringing tone, press one of the volume keys, or select Silence.

Tip: If the Divert if busy function is activated to divert the calls (for example, to your voice mailbox) rejecting an incoming call also diverts the call. See “Call,” p. 70.

If a compatible headset supplied with the headset key is connected to the phone, to answer and end a call, press the headset key.

Call waiting

To answer the waiting call during an active call, press the call key. The first call is put on hold. To end the active call, press the end key.

To activate the Call waiting function, see “Call,” p. 70.

■ Options during a call

Many of the options that you can use during a call are network services. For availability, contact your network operator or service provider.

During a call, select Options and from the following options:

Call options are Mute or Unmute, Contacts, Menu, Record, Lock keypad, Auto

volume on, Loudspeaker or Handset.

Network services options are Answer and Reject, Hold or Unhold, New call, Add to

conference, End call, End all calls, and the following:

Send DTMF — to send tone strings

Swap — to switch between the active call and the call on hold

Transfer — to connect a call on hold to an active call and disconnect yourself

Conference — to make a conference call that allows up to five persons to take part

in a conference call

Private call —to discuss privately in a conference call

Warning: Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.

4. Write text

You can enter text (for example, when writing messages) using traditional or predictive text input. When using traditional text input, press a number key, 1 to 9, repeatedly until the desired character appears. In predictive text input you can enter a letter with a single keypress.

When you are writing text, predictive text input is indicated by and traditional text input by at the top left of the display. , , or appear next to the text input indicator, indicating the character case.

To change the character case and the text input mode, press #. indicates number mode. To change from the letter to number mode, press and hold #, and select Number mode.

■ Settings

To set the writing language, select Options > Writing language. Predictive text input is only available for the languages listed.

Select Options > Dictionary on to set the predictive text input or Dictionary off to set traditional text input.

■ Predictive text input

Predictive text input is based on a built-in dictionary to which you can also add new words.

+ 110 hidden pages
