User Guide
Guide d’utilisation
Nokia 6085 User Guide
Remarque: La version française du guide se trouve à la page 101.
9253175
Issue 1
1
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-198 product is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
A copy of the Declaration of Conformity can be found at
http://www.nokiausa.com/phones/declaration_of_conformity/
.
0434
The crossed-out wheeled bin means that within the European Union the product
must be taken to separate collection at the product end-of-life. This applies to your
device but also to any enhancements marked with this symbol. Do not dispose of
these products as unsorted municipal waste. For more information, see product
Eco-Declaration or country specific information at www.nokiausa.com
Part No. 9253175, Issue No.
Copyright © 2006 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, Pop-Port, PC Suite, and the Nokia Original Enhancements
logos are trademarks or registered trademarks of Nokia Corporation. Other company and
product names mentioned herein may be trademarks or trade names of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C)
1997-2006. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from
RSA Security.
Java and all Java-based marks are trademarks or registered trademarks
of Sun Microsystems, Inc.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and
noncommercial use in connection with information which has been encoded in compliance
with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial
activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider.
No license is granted or shall be implied for any other use. Additional information, including
that related to promotional, internal, and commercial uses, may be obtained from MPEG LA,
LLC. See http://www.mpegla.com
Nokia operates a policy of continuous development. Nokia reserves the right to make changes
and improvements to any of the products described in this document without prior notice.
This device complies with Directive 2002/95/EC on the restriction of the use of certain
hazardous substances in electrical and electronic equipment.
1
.
.
2
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law,
no warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer
nearest to you.
Export Controls
This device may contain commodities, technology, or software subject to export laws and
regulations from the U.S. and other countries. Diversion contrary to law is prohibited.
FCC/Industry Canada Notice
Your device may cause TV or radio interference (for example, when using a telephone in close
proximity to receiving equipment). The FCC or Industry Canada can require you to stop using
your telephone if such interference cannot be eliminated. If you require assistance, contact
your local service facility. This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation. Any changes or modifications not expressly approved by Nokia
could void the user's authority to operate this equipment
.
3
Contents
Contents
For your safety.......................... 6
General information................. 9
Access codes............................................. 9
Copyright protection........................... 10
Configuration settings service ......... 10
Download content and applications 10
1. Get started........................ 11
Install the SIM card and battery ..... 11
Charge the battery............................... 12
Memory card installation.................. 12
Switch the phone on and off............ 13
Open the fold........................................ 14
Normal operating position................ 14
Antenna.................................................. 14
Wrist strap............................................. 15
2. Your phone....................... 16
Keys and parts....................................... 16
Standby mode....................................... 17
Indicators and icons............................ 19
Keys lock (keyguard)........................... 20
3. Call functions................... 21
Make a call ............................................ 21
1-touch dialing..................................... 21
Enhanced voice dialing....................... 21
Answer or decline a call..................... 22
Options during a call........................... 22
4. Phone menus.................... 23
Menu views............................................ 23
Access a menu function..................... 23
5. Messaging......................... 24
Text messages....................................... 24
SIM messages........................................ 27
Multimedia messages......................... 27
Nokia Xpress audio messaging......... 30
Instant messaging................................ 31
E-mail application............................... 34
Voice messages..................................... 36
Info messages ....................................... 37
Service commands............................... 37
Delete messages................................... 37
Message settings.................................. 38
6. Contacts ............................ 40
Search ..................................................... 40
Save names and phone numbers..... 40
Save numbers, items, or an image.. 40
Copy a contact...................................... 41
Edit contact details............................. 41
Delete contacts or details.................. 41
Business cards....................................... 41
Settings................................................... 41
Groups..................................................... 42
1-touch dialing..................................... 42
Service and my numbers.................... 42
7. Call log .............................. 43
Positioning information..................... 43
8. Settings ............................. 44
Profiles.................................................... 44
Themes.................................................... 44
Tones........................................................ 44
Display..................................................... 45
Time and date ....................................... 46
My shortcuts......................................... 46
Connectivity.......................................... 48
Call........................................................... 52
Phone....................................................... 52
Enhancements ...................................... 53
Configuration........................................ 54
Security................................................... 55
Restore factory settings..................... 55
Phone software updates.................... 56
4
Contents
9. Operator menu ................. 57
10. Gallery............................... 58
Format memory card........................... 58
11. Media ................................ 59
Camera .................................................... 59
Media player.......................................... 60
Music player........................................... 60
Radio........................................................ 61
Recorder.................................................. 63
Equalizer.................................................. 64
Stereo widening.................................... 64
12. Push to talk ...................... 65
Connect and disconnect..................... 65
Make and receive a PTT call.............. 65
Callback requests.................................. 67
Add a one-to-one contact................. 68
PTT channels .......................................... 68
PTT settings............................................ 69
13. Organizer........................... 70
Alarm clock............................................. 70
Calendar.................................................. 70
To-do list................................................. 71
Notes........................................................ 71
Calculator............................................... 72
Timer ........................................................ 72
Stopwatch .............................................. 72
14. Applications...................... 73
Games...................................................... 73
Collection................................................ 73
15. Web................................... 75
Technology background...................... 75
Service provider.................................... 75
Access service........................................ 75
Browse..................................................... 76
Security settings................................... 77
Bookmarks.............................................. 78
Download settings............................... 78
Service inbox ......................................... 78
Cache memory....................................... 79
Browser security................................... 79
16. SIM services...................... 82
17. Computer connectivity.... 83
USB data storage.................................. 83
Nokia PC Suite....................................... 83
EGPRS, GPRS, HSCSD, and CSD ........ 83
Data communication applications .. 83
Bluetooth................................................ 84
18. Enhancements.................. 85
19. Battery information......... 86
Charging and discharging.................. 86
Nokia battery
authentication guidelines.................. 87
Care and maintenance ........... 89
Additional safety information... 90
Index........................................ 95
5
For your safety
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the phone on when wireless phone use is prohibited
or when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle
while driving. Your first consid eration while driving sho uld be road safety.
INTERFERENCE
All wireless phones may be susceptible to interference, which could
affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the phone off near medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference
in aircraft.
SWITCH OFF WHEN REFUELING
Do not use the phone at a refueling point. Do not use near fuel
or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the phone where blasting
is in progress.
USE SENSIBLY
Use only in the normal position as explained in the product
documentation. Do not touch the antenna unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect
incompatible products.
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
6
For your safety
BACK-UP COPIES
Remember to make back-up copies or keep a written record of all
important information stored in your phone.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed
safety instructions. Do not connect incompatible products.
EMERGENCY CALLS
Ensure the phone is switched on and in service. Press the end key
as many times as needed to clear the display and return to the start
screen. Enter the emergency number, then press the call key. Give
your location. Do not end the call until given permission to do so.
■ About your device
The wireless device described in this guide is approved for use on the GSM 850,
900, 1800, and 1900 networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and respect the privacy
and legitimate rights of others, including copyrights.
When taking and using images or video clips, obey all laws and respect local
customs as well as privacy and legitimate rights of others.
Warning: To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on when
wireless device use may cause interference or danger.
■ Network services
To use the phone you must have service from a wireless service provider.
Many of the features in this device depend on features in the wireless network
to function. These network services may not be available on all networks or you
may have to make specific arrangements with your service provider before you
can utilize network services. Your service provider may need to give you additional
instructions for their use and explain what charges will apply. Some networks
may have limitations that affect how you can use network services. For instance,
some networks may not support all language-dependent characters and services.
Your service provider may have requested that certain features be disabled
or not activated in your device. If so, they will not appear on your device menu.
Your device may also have been specially configured. This configuration may
include changes in menu names, menu order, and icons. Contact your service
provider for more information.
7
For your safety
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP
protocols. Some features of this device, such as multimedia messaging service
(MMS), browsing, e-mail application, instant messaging, remote synchronization,
and content downloading using the browser or MMS, require network support
for these technologies.
■ Shared memory
The following features in this device may share memory: gallery, contacts, text
messages, multimedia messages, instant messages, e-mail, calendar, to-do notes,
TM
and Java
reduce the memory available for the remaining features sharing memory.
For example, saving many Java applications may use all of the available memory.
Your device may display a message that the memory is full when you try to use
a shared memory feature. In this case, delete some of the information or entries
stored in the shared memory features before continuing. Some of the features,
such as text messages, may have a certain amount of memory specially allotted
to them in addition to the memory shared with other features.
games and applications. Use of one or more of these features may
■ Enhancements, batteries, and chargers
Check the model number of any charger before use with this device. This device
is intended for use when supplied with power from the AC-3 charger. This device
uses BL-5C batteries.
Warning: Use only batteries, chargers, and enhancements approved
by Nokia for use with this particular model. The use of any other types
may invalidate any approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with your dealer.
A few practical rules about accessories and enhancements
• Keep all accessories and enhancements out of the reach of small children.
• When you disconnect the power cord of any accessory or enhancement,
grasp and pull the plug, not the cord.
• Check regularly that enhancements installed in a vehicle are mounted
and are operating properly.
• Installation of any complex car enhancements must be made by qualified
personnel only.
8
General information
General information
Congratulations on your purchase of this Nokia mobile phone. Some of its other
features include a calendar, a clock, an alarm clock, a radio, a music player,
and a built-in camera.
■ Access codes
Security code
The security code (5 to 10 digits) helps to protect your phone against unauthorized
use. The preset code is 12345. To change the code and to set the phone to request
the code, see “Security,” p. 55.
If you enter an incorrect security code five times in succession, the phone ignores
further entries of the code. Wait for five minutes, and enter the code again.
PIN codes
The personal identification number (PIN) code and the universal personal
identification number (UPIN) code (4 to 8 digits) help to protect your SIM card
against unauthorized use. See “Security,” p. 55. The PIN code is usually supplied
with the SIM card. To set the phone to request the PIN code, see “Security,” p. 55.
The PIN2 code (4 to 8 digits) may be supplied with the SIM card and is required
for some functions.
The module PIN is required to access the information in the security module.
See “Security module,” p. 79. The module PIN is supplied with the SIM card
if the SIM card has a security module in it.
The signing PIN is required for the digital signature. See “Digital signature,” p. 80.
The signing PIN is supplied with the SIM card if the SIM card has a security
module in it.
PUK codes
The personal unblocking key (PUK) code and the universal personal unblocking
key (UPUK) code (8 digits) are required to change a blocked PIN code and UPIN
code, respectively. The PUK2 code is required to change a blocked PIN2 code.
If the codes are not supplied with the SIM card, contact your service provider
for the codes.
9
General information
Restriction password
The restriction password (4 digits) is required when using Call restrictions .
See “Security,” p. 55. You can obtain the password from your service provider.
If you enter an incorrect restricting password three times in succession,
the password is blocked. Contact your service provider for assistance.
■ Copyright protection
Copyright protections may prevent some images, music (including ringing tones),
and other content from being copied, modified, transferred, or forwarded.
■ Configuration settings service
To use some of the network services, such as mobile Internet services, MMS,
or remote Internet server synchronization, your phone needs the correct
configuration settings. You may be able to receive the settings directly as a
configuration message. After receiving the settings, you must save them on your
phone. The service provider may provide a PIN that is needed to save the settings.
For more information on availability of the settings, contact your service provider.
When you receive a configuration message, Configuration sett. received is displayed.
To save the settings, select Show > Save. If the phone requests Enter settings'
PIN:, enter the PIN code for the settings and select OK. To receive the PIN code,
contact the service provider that supplies the settings. If no settings are saved,
these settings are saved and set as default configuration settings. Otherwise,
the phone asks Activate saved configuration settings?
To discard the received settings, select Show > Discard.
To edit the settings, see “Configuration,” p. 54.
■ Download content and applications
You may be able to download content (for example, themes, tones, and video clips)
to the phone (network service). Select the download function (for example, in the
Gallery menu). To access the download function, see the respective menu descriptions.
For the availability of different services, pricing, and fees, contact your
service provider.
Important: Use only services that you trust and that offer adequate
security and protection against harmful software.
10
Get started
1. Get started
■ Install the SIM card and battery
Always switch the device off and disconnect the charger before removing
the battery.
Keep all SIM cards out of the reach of small children.
For availability and information on using SIM card services, contact your SIM
card vendor. This may be the service provider, network operator, or other vendor.
The SIM card and its contacts can easily be damaged by scratches or bending,
so be careful when handling, inserting, or removing the card.
To install the SIM card:
1. Press firmly and slide the top of the back
cover to release it; then remove the back
cover by lifting it from the phone.
2. After you have removed the back cover,
insert your fingernail under the battery
and lift it as shown.
3. Place a fingernail in the middle of the metal
SIM card holder. Then, unlatch and swing
the SIM card holder open.
4. I ns er t th e SIM ca rd in to the ho ld er as shown,
beveled corner first, with the gold-colored
contacts on the SIM card face up (away
from the phone).
5. Swing the SIM card holder closed. The goldcolored contacts on the SIM card meet the
gold-colored contacts on the inside of the
phone. Gently press the SIM card holder into
the phone until it clicks into place.
11
Get started
6. Replace the battery, by positioning it (with the
label side facing up), so the gold-colored contacts
match up with those on the phone. Slide the
battery in until it snaps into place.
7. Slide the back cover until it locks into place.
■ Charge the battery
1. Connect the charger to a standard wall
outlet.
2. Insert the charger plug into the round
jack in the bottom of the phone.
If the battery is completely discharged,
it may take a few minutes before
the charging indicator appears on the
display or before any calls can be made.
3. Disconnect the charger from the phone
when the battery is fully charged.
You can use the phone while the charger is connected. The charging time
depends on the charger and the battery used. For example, charging a BL-5C
battery with the AC-3 charger takes approximately 2 hours and 20 minutes
while the phone is in the standby mode.
■ Memory card installation
Keep all microSD memory cards out of the reach
of small children.
Use only compatible microSD cards approved by Nokia for use with this device.
Nokia uses approved industry standards for memory cards, but some brands may
not be fully compatible with this device. Incompatible cards may damage the
card and the device and corrupt data stored on the card.
You can use a memory card to extend the memory of the Gallery. See “Gallery,”
p. 58. You can insert or change the memory card without turning the phone off.
12
Get started
Insert a microSD card
To insert a memory card, use a fingernail
as a lever, place it in the recessed area of the
memory card holder, and swing the holder
open (1). Place the memory card in the card
holder (2). Make sure that the memory card
is properly inserted and that the gold-colored
contacts on the card are facing upwards.
Close the memory card holder (3).
You can use the memory card to save your
multimedia files, such as video clips, sound
files, and images, in the Gallery.
Remove the microSD card
Important: Do not remove the memory card in the middle of an operation
when the card is being accessed. Removing the card in the middle of an
operation may damage the memory card as well as the device, and data
stored on the card may be corrupted.
To remove the memory card, use a fingernail as a lever, place it in the recessed
area of the memory card holder, and swing the holder open. Push gently with
a fingernail against the card to loosen it from the holder. Pull the card out.
Close the memory card holder.
Format the memory card
To format the memory card, see “Format memory card,” p. 58.
■ Switch the phone on and off
Press and hold the end key until the phone
switches on or off. If the phone asks for
a PIN, enter the code and select OK.
Plug and play service
When you turn on your phone for the
first time and the phone is in the standby
mode, you are prompted to get the configuration settings from your service provider
(network service). Confirm or decline the query. See Connect to service provider
support in “Configuration,” p. 54 and “Configuration settings service,” p. 10.
13
Get started
■ Open the fold
When you open the fold
of the phone, it opens up to
approximately 155 degrees.
Do not try to force the fold
open more.
■ Normal operating position
Use the phone only in its normal
operating position.
■ Antenna
Your device has an internal antenna.
Note: As with any other radio transmitting
device, do not touch the antenna
unnecessarily when the device is switched on.
Contact with the antenna affects call quality
and may cause the device to operate at a
higher power level than otherwise needed.
Avoiding contact with the antenna area when
operating the device optimizes the antenna
performance and the battery life.
14
■ Wrist strap
To attach a wrist strap to the
phone, remove the back cover
from the phone and thread a strap
as shown in the picture.
Get started
15
Your phone
2. Your phone
■ Keys and parts
Earpiece (1)
Main display (2)
Left, middle, and right selection keys (3)
Four-way navigation key (4)
Call key (5)
End key (6) ends calls (short keypress) and turns phone
on and off (long keypress)
Keys (7)
Camera lens (8)
Mini display (9)
Memory card holder (10)
Loudspeaker (11)
Microphone (12)
TM
Pop-Port connector
Charger connector (14)
Camera release key (15)
Volume up or down key (16) activates volume (short keypress), voice dialing
(long keypress of the volume down key), and push to talk (PTT) (long keypress
of the volume up key).
(13)
16
Your phone
■ Standby mode
When you turn on your phone, the first
screen that appears is the start screen, which
indicates your phone is in the standby mode.
When your phone is in the standby mode,
the selection keys access specific functions,
and the indicators appear on the start screen.
Indicators show the status of the phone.
Display
• Network signal strength (1)
• Battery charge status (2)
• Clock (3) — If the time is set to appear
on the display. See “Time and date,”
in “Settings,” p. 46.
• Name of the service provider or the operator logo (4)
• Calendar (5) — The date is displayed if it is set to appear on the display and
the active standby is not set. See “Active standby mode,” p. 18 and “Time and
date,” p. 46.
• Active standby (6) — See “Active standby mode,” on p. 18.
• Left selection key (7) — Go to or a shortcut to another function. See “Left
selection key,” p. 46.
• Middle selection key (8) — Menu.
• Right selection key (9) — May be Names to access the list of contacts in the
Contacts menu, an operator specific name to access an operator -specific
Web site, or a shortcut to a function that you selected. See “Right selection
key,” p. 47.
17
Your phone
Active standby mode
In the active standby mode, the phone can
display separate content item windows,
such as general indicators and operator
logo (1), shortcuts (2), audio functions (3),
and the calendar (4).
To select whether the active standby is
shown, see Active standby in “Standby
mode settings,” p. 45. The active standby is
in passive mode when the middle selection
key (5) is Menu; you can only view content.
To activate the navigation mode and scroll
through the content, use the navigation key.
To change the key for accessing the
navigation mode, see Active standby key in
“Standby mode settings,” p. 45. When the
arrow indicators are shown, you can scroll the item left and right.
To personalize and organize the active standby content, select Options and select
a corresponding option. See “Standby mode settings,” p. 45.
To exit the navigation mode, select Exit. If no keys are pressed after a certain
period of time, the phone automatically returns to the passive mode.
Content items in navigation mode
Shortcut bar — To select a shortcut, scroll to the function you want and select it.
To change or organize the shortcuts when in the navigation mode, select
Options > Personalize.
Radio and Music — To turn on the radio or the music player, scroll to and select it.
To change a track in the music player, scroll down or up. To start the radio
channel search, scroll and hold left or right.
Calendar — To view today’s notes, select the one you want. To view the notes
for the previous or next days, scroll left or right.
My note — To enter a note, select the content window, write your note, and save it.
Countdown timer — To start the countdown timer, select the content item.
The remaining time with a note is shown.
General indicators — To show standby indicators, such as date, cell info display,
info messages, PTT default group name, and closed user group index. The date
is shown if the calendar is not selected as active standby content.
18
Your phone
Standby mode shortcuts
To access the list of dialed numbers, press the call key once. See “Make a call,” p. 21.
To call your voice mailbox (network service) when you have saved your voice
mailbox number in the phone, press and hold 1.
To connect to a browser service, press and hold 0.
To set shortcut functions for the navigation key, see Navigation key
in “My shortcuts,” p. 46.
To make a call by pressing a number key with an assigned phone number,
see “1-touch dialing,” p. 21.
To toggle between the Normal profile and the Silent profile, press and hold #.
■ Indicators and icons
Your phone has two types of identifiers: indicators and icons.
Indicators
See “Standby mode,” p. 17 for information on indicators.
Icons
Icons are graphical representations of a specific item or situation. The following
list describes each icon.
You have unread messages in the Inbox folder.
You have unsent, canceled, or failed messages in the Outbox folder.
The phone logged a missed call.
You received one or several instant messages and you are connected
to the instant messaging service.
The keys are locked.
The alarm clock is set to On.
The phone does not ring for an incoming call or text message.
The countdown timer is running.
The stopwatch is running in the background.
/ The phone is registered to the GPRS or EGPRS network.
19
Your phone
/ A GPRS or EGPRS connection is established.
/ The GPRS or EGPRS connection is suspended (on hold), for example,
if there is an incoming or outgoing call during an EGPRS or GPRS
dial-up connection.
A Bluetooth connection is active.
If you have two phone lines, the second phone line is selected.
All incoming calls are forwarded to another number.
The loudspeaker is activated or the music stand is connected to the phone.
Calls are limited to a closed user group.
The timed profile is selected.
■ Keys lock (keyguard)
The keyguard disables the keys to prevent accidental keypresses.
• To lock the keys, select Menu and press * within 3.5 seconds.
• To unlock the keys, select Unlock and press * within 1.5 seconds.
• To enable automatic keyguard, select Menu >Settings > Phone > Automatic
keyguard > On. Set the delay in minutes and seconds in which the keys lock.
If the Security keyguard is set to On, enter the security code, if requested.
To answer a call when the keys are locked, press the call key. When you end
or decline the call, the keys automatically lock.
When the keys are locked, calls to the official emergency number programmed
into your device may still be possible. Enter the emergency number and press
the call key.
For information about Security keyguard, see “Phone,” p. 52.
20
Call functions
3. Call functions
■ Make a call
1. Enter the phone number, including the area code. To delete an incorrect
character, select Clear.
For international calls, press * twice for the international prefix (the + character
replaces the international access code), then enter the country code, the area
code without the leading 0, if necessary, and the phone number.
2. To call the number, press the call key.
3. To end the call or to cancel the call attempt, press the end key or select
Options > End call.
■ 1-touch dialing
Assign a phone number to one of the 1-touch-dialing keys, 2 to 9. Call the number
by one of the following ways:
• Press a 1-touch dialing key, then press the call key.
•If 1-touch dialing is set to On, press and hold a 1-touch dialing key until
the call begins. See 1-touch dialing in “Call,” p. 52.
■ Enhanced voice dialing
To make a phone call, say the name that is saved in the contact list of the phone.
A voice command is added automatically to all entries in the contact list of the phone.
Make a voice dialing call
If an application is sending or receiving data using a packet data connection,
end the application before you use voice dialing.
Voice commands are language-dependent. To set the language, see Voice
recognition language in “Phone,” p. 52.
Note: Using voice tags may be difficult in a noisy environment or
during an emergency, so you should not rely solely upon voice dialing
in all circumstances.
1. In the standby mode, press and hold the right selection key. A short tone
is played and Speak now is displayed.
If you are using a compatible headset with the headset key, press and hold
the headset key to start the voice dialing.
21
Call functions
2. Say the voice command clearly. If the voice recognition is successful, a list
of matches is shown. The phone plays the voice command of the match on the
top of the list. After about 1.5 seconds, the phone dials the number or, if the
result is not the correct one, scroll to another entry and select to dial the entry.
Using voice commands to carry out a selected phone function is similar
to voice dialing. See Voice commands in “My shortcuts,” p. 46.
■ Answer or decline a call
• To answer the call, open the fold or press the call key. To mute the ringing
tone if the fold is open, select Silence or, if the fold is closed, press the volume
up or down key.
• To decline an incoming call if the fold is open, press the end key.
If Forward if busy is activated in your voice mailbox, the call is forwarded to your
voice mail. If not, the call is declined. See Call forw arding in “Call,” p. 52.
• To answer and end a call if a compatible headset (supplied with the headset
key) is connected to the phone, press the headset key.
Call waiting
Call waiting is a network service. To answer the waiting call during an active call,
press the call key. The first call is put on hold. To end the active call, press the end key.
To activate the Call waiting function, see “Call,” p. 52.
■ Options during a call
Many of the options that you can use during a call are network services.
For availability, contact your service provider.
To increase or decrease the volume during a call, press the volume up or down key
on the side of the phone.
Select Options during a call and the following options may be available.
Touch tones — to send tone strings
Swap — to switch between the active call and the call on hold
Transfe r calls — to connect a call on hold to an active call and disconnect yourself
Conference — to make a conference call that allows up to five persons to take
part in a conference call
Private call — to discuss privately in a conference call
Warning: Do not hold the device near your ear when the loudspeaker
is in use because the volume may be extremely loud.
22
Phone menus
4. Phone menus
Phone features are grouped according to function and are accessed through
the main menus of your phone. Each main menu contains submenus and lists
from which you can select or view items and personalize phone features.
Scroll to access these menus and submenus.
Some menus may not be available, depending on your network. For more information,
contact your service provider.
■ Menu views
Your phone may have two types of menu views: List and Grid.
In the List interface, images introduce every menu. Scroll to navigate through the
menus. As you scroll through the menus, the menu number appears in the upper
right corner of the display. Below the menu number is a scroll bar with a tab.
The tab moves up or down as you scroll through the menus, providing a visual
representation of your current position in the menu structure.
In the Grid interface, multiple menu icons appear on a single display. Use the
four-way navigation key to scroll through the icons. The name of the menu
appears at the top of the display and the icon for the selected menu is outlined.
To change the menu view, select Menu > Options > Main menu vie w > List or Grid.
■ Access a menu function
1. Select Menu and the menu you want.
2. If the menu contains submenus, select the one that you want.
3. If the selected menu contains further submenus, select the one that you want.
4. To return to the previous menu level, select Back. To exit the menu, select Exit.
23
Messaging
5. Messaging
You can use mobile messages to keep in touch with friends, family,
and business associates by using the short message service (SMS), which is
a network service. Not all messaging features are available in all wireless networks.
Contact your service provider for availability and subscription information.
When sending messages, your phone may display the words Message sent.
This is an indication that the message has been sent by your device to the
message center number programmed into your device. This is not an indication
that the message has been received at the intended destination. For more details
about messaging services, check with your service provider.
■ Text messages
Your device supports the sending of text messages beyond the character limit for
a single message. Longer messages are sent as a series of two or more messages.
Your service provider may charge accordingly. Characters that use accents or other
marks and characters from some language opti on s, suc h a s C hi nes e, ta ke up m or e
space, which limits the number of characters that can be sent in a single message.
A message length indicator appears at the top of the phone display. This indicator
allows you to see how many characters remain in the message as you are entering
text. For example, 673/2 means that there are 673 characters left and that the
message will be sent as a series of two messages.
You can use predefined templates to help you write text messages. Before you
can send any text or e-mail messages, you need to configure the message
settings. See “Message settings,” p. 38.
To check SMS e-mail service availability and to subscribe to the service,
contact your service provider.
Text entry
To enter text while writing messages, use traditional or predictive text input.
When using traditional text input, press a number key, 1 to 9, repeatedly until
the character you want is displayed. In predictive text input you can enter a letter
with a single keypress.
When you write text, appears at the top left of the display, which indicates
predictive text input, and is displayed, which indicates traditional text input.
24
Messaging
, , or is displayed next to the text input indicator, which indicates
the character case. To change the character case, press #. indicates number
mode. To change from the letter to number mode, press and hold #, and select
Number mode.
Settings
To set the writing language to a different language, select Options > Writing
language. Predictive text input is only available for the languages listed.
To set the predictive text input option, select Options > Prediction on or to set
traditional text input option, select Options > Prediction off.
To quickly set predictive text input on or off when writing text, press # twice
or select and hold Options.
Predictive text input
Predictive text input allows you to write text quickly by using the phone keys
and a built-in dictionary.
1. Start writing a word, using the keys 2 to 9, and press each key only once
for one letter. The word changes after each keystroke.
2. When you finish writing the word and it is correct, press 0.
3. If a displayed word is not correct, press * repeatedly or select Options >
Matches. When the word tha t you wa nt is display ed, select Use.
4. If the ? character is displayed after the word, the word you intended to write
is not in the dictionary. To add the word to the dictionary, select Spell.
The phone displays the entered letters. Enter the word (traditional text input
is used) and select Save.
Traditional text input
Press a number key, 1 to 9, repeatedly until the character you want is displayed. Not
all characters available under a number key are printed on the key. The characters
available depends on the selected writing language. See “Settings,” p. 25.
If the next letter you want is located on the same key as the current one, wait
until the cursor is displayed or scroll in any direction and enter the letter.
To access the most common punctuation marks and special characters, press 1.
To insert a space, press 0.
If you want more characters, press *.
25
Messaging
Write and send
1. Select Menu > Messaging > Create message > Text message and enter the
recipient’s phone number in the To: field.
2. To retrieve a phone number from Contacts, select Add > Contact. To send
the message to multiple recipients, add the contacts you want one by one.
3. To send the message to persons in a group, select Contact group and the
group you want. To retrieve the contacts to which you recently sent
messages, select Add > Recently used.
4. Scroll down and enter a message. See “Text entry,” p. 24.
5. To insert a template to the text message, select Options > Use template
and the template you want to insert.
6. To see how the message will look to the recipient, select Options > Preview.
7. To send the message, select Send.
Read and reply
When you receive messages, either 1 message received or N messages received
is displayed, where N is the number of new messages.
1. To view a new message, select Show. To view it later, select Exit.
To read the message later, select Menu > Messaging > Inbox. If more than
one message has been received, select the message that you want to read.
indicates an unread message in Inbox.
2. While reading a message, select Options and delete or forward the message,
edit the message as a text message or an SMS e-mail or move it to another
folder, or view or extract message details. You can also copy text from the
beginning of the message to your phone calendar as a reminder note.
3. To reply to a message, select Reply > Text message, Multimedia,
Flash message, or Audio message.
To send a text message to an e-mail address, enter the e-mail address
in the To: field.
4. Scroll down and enter a message in the Message: field. See “Text entry,” p. 24.
To change the message type for your reply message, select Options >
Change msg. type.
5. To send the message, select Send.
26
Messaging
■ SIM messages
SIM messages are text messages that are saved to your SIM card. You can copy or
move those messages to the phone memory, but not vice versa. Received
messages are saved to the phone memory.
To read SIM messages, select Menu > Messaging > Options > SIM messages.
■ Multimedia messages
Note: Only devices that have compatible features can receive and
display multimedia messages. The appearance of a message may vary
depending on the receiving device.
A multimedia message can contain text, sound, a picture, a calendar note,
a business card, or a video clip. If the message is too large, the phone may not
be able to receive it. Some networks allow text messages that include an Internet
address where you can view the multimedia message.
You cannot receive multimedia messages during a call or an active browsing
session over GSM data. Because delivery of multimedia messages can fail for
various reasons, do not rely solely upon them for essential communications.
Write and send a multimedia message
The wireless network may limit the size of multimedia messages. If the inserted image
exceeds this limit, the device may make it smaller so that it can be sent by MMS.
To set the settings for multimedia messaging, see “Multimedia,” p. 39. To check
availability and to subscribe to the multimedia messaging service, contact your
service provider.
1. Select Menu > Messaging > Create message > Multimedia.
2. Enter a message. See “Text entry,” p. 24.
Your phone supports multimedia messages that contain several pages
(slides). A message can contain a calendar note and a business card as
attachments. A slide can contain text, one image, and one sound clip; or text
and a video clip.
3. To insert a slide in the message, select New; or select Options > Insert >
Slide.
4. To view the message before sending it, select Options > Preview.
5. Scroll down and select Send. See “Message sending,” p. 28.
27
Messaging
6. Enter the recipient’s phone number in the To: field.
To retrieve a phone number from Contacts, select Add > Contact.
To send the message to multiple recipients, add the contacts you want one by one.
To send the message to persons in a group, select Contact group and the
group you want.
To retrieve the contacts to which you recently sent messages, select Add >
Recently used.
Message sending
When you finish writing your message, to send the message, select Send or press
the call key. The phone saves the message in the Outbox folder and sending
starts. If you select Save sent messages > Yes, the sent message is saved in the
Sent items folder. See “General settings,” p. 38.
When the phone is sending the message, the animated is shown. Actual receipt
of a message depends on a number of factors. For more details about messaging
services, check with your service provider.
It takes more time to send a multimedia message than to send a text message.
While the message is being sent, you can use other functions on the phone. If an
interruption occurs while the message is being sent, the phone tries to resend the
message a few times. If these attempts fail, the message remains in the Outbox
folder. You can try to resend it later.
To cancel the sending of the messages in the Outbox folder, scroll to the desired
message and select Options > Cancel sendi ng.
Read and reply
Important: Exercise caution when opening messages. Multimedia
message objects may contain malicious software or otherwise be
harmful to your device or PC.
When you receive multimedia messages, either Multimedia message received
or N messages received is displayed, where N is the number of new messages.
1. To read the message, select Show. To view it later, select Exit.
To read the message later, select Menu > Messaging > Inbox. In the list
of messages, indicates an unread message. Select the message that you
want to view.
2. To view the whole message if the received message contains a presentation,
select Play.
To view the files in the presentation or the attachments, select Options >
Objects or Attachments.
28
Messaging
3. To reply to the message, select Options > Reply > Text messag e, Multimedia,
Flash message, or Audio message. Write the reply message.
To change the message type for your reply message, select Options > Change
msg. type. The new message type may not support all the content that you
have added.
4. To send the message, select Send. See “Message sending,” p. 28.
Memory full
When you receive a message and the memory for the messages is full, Memory
full. Unable to receive msgs. is shown. To delete old messages, select OK > Yes
and the folder. Scroll to the message you want and select Delete.
To delete more than one message at the same time, scroll to one of the messages
you want to delete and select Options > Mark. Scroll to each additional message
you want to delete and select Mark or to delete all the messages, select
Options > Mark all. When you have finished marking the messages you want
to delete, select Options > Delete marked.
Folders
The phone saves received text and multimedia messages in the Inbox folder.
To set the phone to save the sent messages in the Sent items folder, see Save sent
messages in “General settings,” p. 38.
To see any message you want to send later and have saved as a draft in the Drafts
folder, select Menu > Messaging > Drafts.
You can move your messages to the Saved items folder. To organize your Saved
items subfolders, select Menu > Messaging > Saved items > Saved messages
or a folder you added. To add a new folder for your messages, select Options >
Add folder. To delete or rename a folder, scroll to the folder you want and select
Options > Delete folder or Re name folder.
Your phone has templates. To create a new template, save or copy a message
as a template. To access the template list, select Menu > Messaging >
Saved items > Templates.
Flash messages
Flash messages are text messages that are instantly displayed upon reception.
Flash messages are not automatically saved.
29
Loading...
