User Guide

Nokia Lumia 525

RM-998

Issue 1.1 EN

Psst...

This guide isn't all there is...

There's a user guide in your phone – it's always with you, available when needed. On the start screen, swipe left, and tap Nokia Care.

Check out the videos at www.youtube.com/NokiaSupportVideos.

For info on Nokia Service terms and Privacy policy, go to www.nokia.com/privacy.

© 2013 Nokia. All rights reserved.	2

User Guide

Nokia Lumia 525

Safety	5	Social networks	49
Get started	6	Messages	51
Keys and parts	6	Mail	56
Back, start, and search key	6	Camera	61
Antenna locations	7	Camera basics	61
Insert the SIM card	7	Advanced photography	65
Insert the memory card	9	Photos and videos	67
Remove the SIM and memory card	11	Maps & navigation	71
Charge your phone	12	Switch location services on	71
First start-up	13	HERE Maps	71
Lock the keys and screen	16	HERE Drive	77
Connect the headset	17	Positioning methods	81
Change the volume	18	Internet	82
Icons shown on your phone	18	Define internet connections	82
Basics	20	Connect your computer to the web	82
Get to know your phone	20	Use your data plan efficiently	83
Personalise your phone	25	Web browser	83
Take a screenshot	29	Search the web	85
Extend battery life	30	Close all internet connections	85
Save on data roaming costs	32	Entertainment	86
Write text	32	Watch and listen	86
Scan codes or text	36	FM radio	86
Clock	36	Nokia Music	87
SkyDrive	38	Sync music and videos between your
Nokia account	39	phone and computer	89
Nokia account	39	Games	90
Browse your SIM apps	39	Games	90
Browse your SIM apps	39	Office	92
Store	40	Office	92
Store	40	Microsoft Office Mobile	92
People & messaging	43	Microsoft Office Mobile	92
People & messaging	43	Write a note	95
Calls	43	Write a note	95
Calls	43	Continue with a document on another
Contacts	46	Continue with a document on another
Contacts	46	device	95
		device	95

© 2013 Nokia. All rights reserved.	3

Calendar	96
Make a calculation	97
Use your work phone	97
Tips for business users	97
Share your screen on another screen	99
Phone management & connectivity	100
Keep your phone up to date	100
Wi-Fi	101
Bluetooth	102
Memory and storage	104
Copy content between your phone and
computer	105
Security	106
Wallet	108
Access codes	109
Troubleshooting and support	111
Product and safety information	113

© 2013 Nokia. All rights reserved.	4

Safety

Read these simple guidelines. Not following them may be dangerous or illegal.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or

blasting areas. Obey all instructions in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS, AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Third-party chargers that comply with the IEC/EN 62684 standard, and that can connect to

your device micro USB connector, may be compatible. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

GLASS PARTS

The device screen is made of glass. This glass can break if the device is dropped on a hard surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of

the device or attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by qualified service personnel.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.

© 2013 Nokia. All rights reserved.	5

Get started

Get to grips with the basics, and have your phone up and running in no time.

Keys and parts

Explore the keys and parts of your new phone.

1 Connector for headphones and loudspeakers (3.5 mm)

2 Earpiece

3Volume keys

4Power/Lock key

5Camera key

6Back key

7Start key

8Search key

9Micro-USB connector

10Microphone

11 Camera lens

12 Loudspeaker

Back, start, and search key

The back, start, and search keys help you navigate your phone.

•To switch between open apps, press and hold, swipe left or right, and tap the app you want.

•To go back to the previous screen you were in, press. Your phone remembers all the apps and websites you've visited since the last time your screen was locked.

© 2013 Nokia. All rights reserved.	6

•To go to the start screen, press . The app you were in remains open in the background.

•To control your phone with your voice, press and hold , and say a voice command.

This feature is not available in all languages. For more info on feature and service availability, see the How-to section at www.windowsphone.com.

•To search the web, press .

Antenna locations

Learn where the antennas are located on your phone to get the best possible performance.

Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation.

The antenna areas are highlighted.

Insert the SIM card

Read on to learn how to insert your SIM card into your phone.

Important: Your device uses a mini-UICC SIM card, also known as a micro-SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card.

Note: Switch the device off and disconnect the charger and any other device before removing any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.

Make sure your phone is switched off.

1. At the top corner of your phone, put the nail of your index finger in the seam between the screen frame and the back cover. Press the middle of the back cover, and bend the cover to loosen the top hooks. Remove the cover.

© 2013 Nokia. All rights reserved.	7

Do not use any sharp tools, as they may damage the screen. 2. If the battery is in, lift it out.

3. Push the SIM into the SIM slot until it is fully inserted. Make sure the contact area is facing down.

4. Line up the battery contacts, and replace the battery.

© 2013 Nokia. All rights reserved.	8

5. Press the bottom corner of the back cover against the bottom corner of your phone. The edge with the keys goes first.

6. Press the back of the cover until it snaps into place. Don't press the keys while attaching the cover.

Insert the memory card

Learn how to insert your memory card into your phone.

Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

Your phone supports memory cards with a capacity of up to 64 GB. Make sure your phone is switched off.

Do not use any sharp tools, as they may damage the screen.

© 2013 Nokia. All rights reserved.	9

2. If the battery is in, lift it out.

3. Push the memory card into the memory card slot until it locks into place.

4. Line up the battery contacts, and replace the battery.

5. Press the bottom corner of the back cover against the bottom corner of your phone. The edge with the keys goes first.

6. Press the back of the cover until it snaps into place. Don't press the keys while attaching the cover.

© 2013 Nokia. All rights reserved.	10

Remove the SIM and memory card

Got a new SIM or memory card? Learn how to remove the previous card from your phone. Make sure your phone is switched off.

Do not use any sharp tools, as they may damage the screen. 2. If the battery is in, lift it out.

3. Push the SIM through the opening, then pull it out.

4. To remove the memory card, pull it out from the slot.

© 2013 Nokia. All rights reserved.	11

5. Line up the battery contacts, and replace the battery.

6. Press the bottom corner of the back cover against the bottom corner of your phone. The edge with the keys goes first.

7. Press the back of the cover until it snaps into place. Don't press the keys while attaching the cover.

Charge your phone

Learn how to charge your phone.

Charge your phone with a USB charger

Your battery has been partially charged at the factory, but you may need to recharge it before you can switch the phone on for the first time.

Make sure you use a compatible USB charger to charge your phone.

1. Plug the charger into a wall outlet, then connect the micro-USB end of the charger's cable to your phone.

© 2013 Nokia. All rights reserved.	12

2. When the battery is full, disconnect the charger from the phone, then from the wall outlet.

You don't need to charge the battery for a specific length of time, and you can use the phone while it's charging.

If the battery is completely discharged, it may need to charge for up to 20 minutes before you can use your phone. The charging indicator may not be displayed in this time.

Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while charging the device. The efficiency of USB charging power varies significantly, and it may take a long time for charging to start and the device to start functioning.

Make sure your computer is switched on.

First connect the USB cable to the computer, then to your phone. When the battery is full, first disconnect the USB cable from your phone, then from the computer.

The battery can be charged and discharged hundreds of times, but it will eventually wear out. When the talk and standby times are noticeably shorter than normal, replace the battery.

Battery

Take good care of your battery, it's the life force of your phone.

Use only Nokia approved chargers designated for this phone. You can also use a compatible USB cable to charge your phone (included).

First start-up

Learn how to get your new phone up and running.

Your new phone comes with great features that will be installed when you start your phone for the first time. Allow some minutes for your phone to be ready.

© 2013 Nokia. All rights reserved.	13

Switch the phone on

Are you ready? Switch your phone on, and start exploring it.

Press and hold the power key until the phone vibrates.

Switch the phone off

Press and hold the power key, and drag the lock screen down.

Microsoft account

With a Microsoft account, you can access Microsoft services with a single username and password on your computer or phone. You can also use the same username and password on your Xbox.

With your Microsoft account, you can, for example:

•Download content from Store

© 2013 Nokia. All rights reserved.	14

•Back up your contacts

•Upload, store, and share pictures and documents.

•Back up your phone on SkyDrive.

•Play Xbox games

•Get your avatar and gaming achievements on your phone, and add to them when you play games on your phone

•Keep track of and lock your lost phone with Find My Phone

•Get feeds from social networking services to your People hub

To learn more about Microsoft account and what can you do with it, go to

www.windowsphone.com.

Create your Microsoft account

Spice up your life and get more from your phone – create a Microsoft account.

To create a Microsoft account, you need an internet connection. If you don't have a data plan, the data transmission costs may pile up quickly. For info about possible data costs, contact your network service provider. If you can't connect to the internet, you can create the account later.

1.Switch on your phone with the SIM card in the phone.

2.To set up your phone, follow the instructions shown on the screen.

3.Create your Microsoft account, or sign in with your existing username and password.

To make an emergency call during the initial set-up, tap emergency call.

To create a Microsoft account later, open a Microsoft app or service on your phone. Or on the start screen, swipe left, and tap Settings > email+accounts > add an account. To create your account on the internet, or to reset your password, go to www.live.com.

© 2013 Nokia. All rights reserved.	15

Copy contacts

Have your nearest and dearest instantly at your fingertips. Use the Transfer my Data app to easily copy your contacts, text messages, and pictures from your old phone. The app does not work with all phone models.

Tip: If you have an older Windows Phone device, or have previously backed up your contacts in your Microsoft Account, you can also add your account to your phone, and import the contacts to your phone straight from the service.

Tip: When you create your Microsoft Account, your contacts are backed up automatically.

To restore the backed up contacts when setting up a new phone, sign in using the same Microsoft Account. You can then choose the backup you want to use.

Your old phone needs to support Bluetooth. The contacts on your old phone need to be stored in the phone memory, not on the SIM.

1.On your old phone, switch Bluetooth on.

2.On the start screen of your new phone, swipe left, and tap Transfer my Data.

3.Tap continue, and switch Bluetooth on.

4.Select your old phone from the list of found devices, and follow the instructions shown on both phones.

If your contacts are written in a language that is not supported by your new phone, the contact info may not be shown correctly.

Lock the keys and screen

Want to avoid accidentally making a call when your phone is in your pocket or bag? Press the power key.

© 2013 Nokia. All rights reserved.	16

Unlock the keys and screen

Press the power key, and drag the lock screen up.

Tip: Instead of pressing the power key, you can also double-tap the screen if double-tap is switched on. To switch on double-tap, tap Settings > touch, and switch Double tap to wake up phone to On.

Set the keys and screen to lock automatically

On the start screen, swipe left, tap Settings > lock screen > Screen times out after, and select the length of time after which the keys and screen are locked automatically.

Connect the headset

Enjoy your favourite music, or free your hands for other things when in a call. Connect the headset to your phone.

© 2013 Nokia. All rights reserved.	17

Do not connect products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to volume levels.

Change the volume

Trouble hearing your phone ringing in noisy environments, or calls too loud? You can change the volume to your liking.

Use the volume keys.

The volume keys control all sounds, including the volume of alarms and reminders.

Tip: When you change the volume, you can also switch your phone to vibrate, silent, or normal mode. On the volume control bar at the top of the screen, tap , , or . The available options vary depending on your mode settings. To change the settings, on the start screen, swipe left, and tap Settings > ringtones+sounds.

Icons shown on your phone

The status bar at the top of the screen tells you the current time, battery and signal strength, and much more.

© 2013 Nokia. All rights reserved.	18

Tip: To see hidden icons, tap the status bar.

Signal strength

Battery power level

The battery is charging.

Battery saver mode is switched on.

Your calls are forwarded to another number or your voice mailbox.

There is no SIM card in your phone.

Your SIM card is locked.

A Bluetooth device is connected to your phone.

A Wi-Fi connection is available.

A Wi-Fi connection is active.

An app or service is using your location info.

Your phone is roaming and not on your home mobile network.

Vibrate mode is switched on.

Flight mode is switched on.

Silent mode is switched on.

Single letters, combinations of letters, or combinations of letters and numbers show the type of

mobile network to which you're connected,	, for example, or or	to indicate high-speed
connections.

Icons that show the network connection type may vary between regions and network service providers.

© 2013 Nokia. All rights reserved.	19

Basics

Learn how to get the most out of your new phone.

Get to know your phone

Your phone has two views, making it easy for you to keep up with what's going on.

To switch between the start screen and the apps menu, simply swipe left or right.

Start screen: The animated live tiles show your missed calls and received messages, the latest news and weather forecasts, and more.

You can rearrange and resize the tiles, and pin contacts, apps, feeds, mailboxes, websites, and other favourites. Updates of your pinned contacts are shown on the tile, and you can view your contacts' details directly from the start screen.

Apps menu: All your apps are listed here, all neatly ordered. Got a lot of apps? To look one up, tap .

The software in this device includes software licensed by Nokia from Microsoft Corporation or its affiliates. To access the Windows Phone software license terms, select Settings > about. Please read the terms. Please note that by using the software, you accept the terms. If you do not accept the terms, do not use the device or software. Instead contact Nokia or the party from which you purchased the device to determine its return policy.

Switch between views

If you don't have all the apps you need on your start screen, you can find them from the apps menu. Simply swipe left or right between the views.

© 2013 Nokia. All rights reserved.	20

Switch between apps

Press and hold, swipe to the app you want, and tap the app.

Tip: To close the app, tap .

View the apps running in the background

On the start screen, swipe left, and tap Settings. Swipe left, and tap background tasks.

Use the touch screen

Explore your phone with a tap, swipe, or drag.

1.To use your phone, simply tap or tap and hold the touch screen.

2.To open further options, place your finger on an item until the menu opens.

© 2013 Nokia. All rights reserved.	21

Tip: You can even use your phone while wearing gloves. On the start screen, swipe left, and tap

Settings > touch, and switch Touch sensitivity to high.

Example: To open an app or other item, tap the app or item. To edit or delete a calendar appointment, tap and hold the appointment, and select the appropriate option.

Tap and hold to drag an item

Place your finger on the item for a couple of seconds, and slide your finger across the screen.

Swipe

Place your finger on the screen, and slide your finger in the desired direction.

© 2013 Nokia. All rights reserved.	22

Example: Swipe left or right between the start screen and the apps menu, or between different views in the hubs. To quickly scroll through a long list or menu, slide your finger quickly in a flicking motion up or down the screen, and lift your finger. To stop the scrolling, tap the screen.

Zoom in or out

Place 2 fingers on an item, such as a map, photo, or web page, and slide your fingers apart or together.

© 2013 Nokia. All rights reserved.	23

Important: Avoid scratching the touch screen.

Tip: The screen rotates automatically when you turn the phone 90 degrees. To lock the screen in its current orientation, on the start screen, swipe left, and tap Settings > screen rotation. Switch Auto-rotate screen to Off .

Use your phone in flight mode

In places where you don't want to make or receive calls, you can still access your music, videos, and offline games if you switch flight mode on.

Flight mode closes connections to the mobile network and switches your phone's wireless features off. Comply with the instructions and safety requirements given by, for example, an airline, and any applicable laws and regulations. Where allowed, you can connect to a Wi-Fi network to, for example, browse the internet or switch Bluetooth on in flight mode.

1.On the start screen, swipe left, and tap Settings > flight mode.

2.Switch Status to On .

Control your phone with your voice

Got your hands full, but need to use your phone? You can use your voice to make a call, send a text message, search the web, or open an app.

This feature is not available in all languages. For info on the supported languages, go to www.windowsphone.com.

1.Press and hold .

2.Say a voice command into your phone.

Example: To check your schedule, say Open calendar.

© 2013 Nokia. All rights reserved.	24

Personalise your phone

Learn how to personalise the start screen, and how to change ringtones.

Personalise the start screen

Would you like to have only your most-used apps on the start screen? You can pin your favourite apps, websites, and much more to the start screen, and move or resize tiles as you like.

1.To pin an app, swipe left to go to the apps menu.

2.Tap and hold the app, and tap pin to start.

Pin a contact

Tap People, tap and hold the contact, and tap pin to start.

When you pin contacts, their feed updates are shown on the tile, and you can call them directly from the start screen.

Pin a website

Go to a website, and tap > pin to start.

Move a tile

Tap and hold the tile, drag and drop it to the new location, and tap the screen.

© 2013 Nokia. All rights reserved.	25

Resize or unpin a tile

To resize, tap and hold the tile, and tap the arrow icon.

The tiles can be either small, medium, or wide. The bigger the tile is, the more info it can show.

To unpin the tile, tap and hold the tile, and tap .

Create a safe, fun start screen for kids

You can let your kids use some apps on your phone without having to worry about them accidentally deleting your work mail, making online purchases, or doing anything else they shouldn't. Put selected apps, games, and other favourites for kids to enjoy in their own start screen.

© 2013 Nokia. All rights reserved.	26

1.On the start screen, swipe left, and tap Settings.

2.Tap kid's corner.

3.Choose which content your kids can use. You can also set a password to keep your kids from accessing your own start screen.

Tip: Show your kids how they can personalise their start screen. To change, for example, the background picture, tap customise. On the start screen, you can resize or move tiles in the normal way.

Tip: To let your kids make an in-app purchase, such as buy game points, define a Wallet PIN. You must enter the Wallet PIN to make each purchase. To define a Wallet PIN, on the start screen, swipe left, and tap Wallet > > settings+PIN. Some purchases may not be available for all ages.

Go to your own start screen

Press the power key twice, and swipe up on your own lock screen. If you've set a password, type it in.

Go back to the kid's start screen

On your own lock screen, swipe left, and on the kid's lock screen, swipe up.

Switch the kid's start screen off

On your start screen, swipe left, tap Settings, and switch kid's corner to Off .

Change your theme

You can change the display colours to match your taste and mood.

1.On the start screen, swipe left, and tap Settings > theme.

2.Tap Background or Accent colour.

Change colour profile

To adjust the saturation and colour temperature of your screen, tap Settings > display > Lumia colour profile > adjust.

© 2013 Nokia. All rights reserved.	27

Personalise the lock screen

Would you like to make your lock screen look unique? You can, for example, have your own favourite photo in the background.

On the start screen, swipe left, and tap Settings > lock screen.

Tip: You can decide which app notifications, such as missed calls or new messages, you want to see on the lock screen. Simply tap a notification slot, and choose the app you want to add.

Change the background photo

Tap change photo, select a photo, adjust it to get the best possible fit, and tap .

Tip: You can also shuffle photos from Bing on your lock screen. Switch Background to Bing.

Show the artist when playing music

Switch Show artist when playing music to On .

Personalise your phone tones

You can select the best sounds for your phone.

1.On the start screen, swipe left, and tap Settings > ringtones+sounds.

2.Select the type of ringtone or alert you want to change, and select the sound.

Add new ringtones from your PC to your phone

Connect your phone to your PC with a USB cable, and use the file manager of your PC to move the song you want to the ringtone folder in your phone.

To set the song as your ringtone, in the ringtones+sounds view, tap Ringtone, and under Custom, tap the song.

You can use a song as your ringtone if it is not protected with digital rights management (DRM), and it’s smaller than 30 MB.

Tip: Want to create your own unique ringtone? Tap Store, and download the Ringtone Maker app.

© 2013 Nokia. All rights reserved.	28

Your PC must have Windows Vista, Windows 7, or Windows 8.

Silence your phone

When you switch silent mode on, all ringtones and alert tones are muted. Use this when you are, for example, at the cinema or in a meeting.

1. Press a volume key to see the volume status bar at the top of the screen, and tap .

Silent mode is switched on. If you have set your phone to vibrate, vibrate mode is switched on instead of silent mode.

2. If you want to set your phone to vibrate, on the start screen, swipe left, tap Settings > ringtones +sounds, and switch Vibrate to On .

Set your phone to driving mode

Driving mode helps you minimise distraction when driving, letting you concentrate on your journey.

1.On the start screen, swipe left, and tap Settings > driving mode > next.

2.To set the phone to ignore calls, switch Ignore calls to On . To set the phone to ignore text messages, switch Ignore texts to On .

3.Tap next.

4.To send an automatic text message when someone calls or texts you, explaining why you can't

answer, switch Text replies to calls, Text replies to texts, or both to On . To edit the message, tap the text box.

5.Tap next > add a device, and tap the Bluetooth device you connect your phone to when driving, such as a headset.

Driving mode starts automatically when the phone and the added Bluetooth device connect.

Take a screenshot

Did you just finish personalising your start screen, and want to share your work of art? You can capture your screen and send it to your friends.

© 2013 Nokia. All rights reserved.	29

1. Press the power key and the start key at the same time.

2.Tap Photos > albums > Screenshots.

3.Tap and hold the screenshot you want to send, and tap share....

Extend battery life

Get the most out of your phone while getting the battery life you need. There are steps you can take to save power on your phone.

To save power:

Charge wisely	Always charge the battery fully.

Select only the sounds that you need	Mute unnecessary sounds, such as key press sounds.

Use wired headphones	Use wired headphones, rather than the loudspeaker.

Use the battery saver	• You can set your phone to automatically save power
	when the battery charge level is low. To check the
	battery status, and switch battery saver mode on, on
	the start screen, swipe left, and tap	Settings >
	battery saver.
	When your phone goes into battery saver mode, you
	may not be able to change the settings of all apps.
	• You can choose when you want battery saver mode
	to be activated. Tap advanced.

Change the phone screen settings	• Set the phone screen to switch off after a short time.
	On the start screen, swipe left, and tap		Settings >
	lock screen > Screen times out after.

© 2013 Nokia. All rights reserved.	30

+ 88 hidden pages
