PAMS Technical Documentation
Appendix 1
TRANSCEIVER NSE–1NX
Original 03/98
NSE–1NX
PAMS
Appendix 1
CONTENTS
Foreword 1 – 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transceiver NSE–1NX 1 – 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Functional Description 1 – 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Modules 1 – 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exploded View of Transceiver NSE–1NX 1 – 5. . . . . . . . . . . . . .
Assembly Parts of NSE–1NX 1 – 6. . . . . . . . . . . . . . . . . . . . . . . .
Technical Documentation
Page No
Page 1 – 2
Original 03/98
PAMS
NSE–1NX
Technical Documentation
Appendix 1
Foreword
This section of the service manual (Appendix) contains specific details for
the NSE–1NX handportable telephone.
The appendix comprises chapters as follows: Chapter 1, Foreword (this
chapter); Chapter 2, Transceiver NSE–1NX, containing an exploded view
of the NSE–1NX variant (including a list of assembly parts) plus
component parts lists covering the system module and the display
module.
NOTE: The Service Manual is intended for use by qualified
service personnel only.
Appendix 1
Transceiver NSE–1NX
Functional Description
The NSE–1 is a radio transceiver unit designed for the GSM network. It is
a GSM phase 2, power class 4 transceiver providing 15 power levels with
a maximum output power of 2 W. The transceiver a is true 3 V transceiver.
The transceiver consists of System/RF module, User interface module
(UE4S) and assembly parts. The System/RF module used in NSE–1NX is
either UP8R or UP8S. The baseband part is exactly the same but the
transmitter circuitry and it’s layout differs depending which one of the two
different power amplifiers is used.
Original 03/98
Page 1 – 3
NSE–1NX
PAMS
Appendix 1
Modules
Technical Documentation
Transceiver NSE–1NX Nokia Euro–A 0501010
Transceiver NSE–1NX Nokia Euro–A (Activa) 0502061
Transceiver NSE–1NX Nokia Euro–A (Continua) 0502060
Transceiver NSE–1NX Nokia Euro–A (Vodacom) 0502057
Transceiver NSE–1NX Nokia Euro–B 0501900
Transceiver NSE–1NX Nokia Euro–B (Era) 0502056
Transceiver NSE–1NX Nokia Euro–B (Panafon) 0502059
Transceiver NSE–1NX Nokia Euro–B (Pannon) 0502055
Transceiver NSE–1NX Nokia Euro–B (Telestet) 0502058
Transceiver NSE–1NX Nokia Euro–B (Westel) 0502054
Transceiver NSE–1NX Nokia APAC, K 0501635
Transceiver NSE–1NX Nokia APAC 0501636
Transceiver NSE–1NX Nokia Omnitel 0501637
Transceiver NSE–1NX Nokia CHINA, E off 0501903
• system module UP8R 0201036 or
• system module UP8S 0201841
• display module UE4S 0200860
• A–cover night blue 9456132
• mechanics MNSE1 0261284
Transceiver NSE–1NX Nokia TIM 0501638
Transceiver NSE–1NX Nokia Movistar 0501639
Transceiver NSE–1NX Nokia Airtel 0501640
Transceiver NSE–1NX Nokia Plus 0501641
Transceiver NSE–1NX Nokia D2 0501901
• system module UP8R 0201634 or
• system module UP8S 0201842
• display module UE4S 0200860
• A–cover night blue (logo recess) 9456147
• mechanics MNSE1 0261284
Transceiver NSE–1NX Nokia Euro–A (Olla) 0502063
• system module UP8S 0502062
• display module UE4S 0200860
• mechanics MNSE–1 0261284
Page 1 – 4
Original 03/98
PAMS
NSE–1NX
Technical Documentation
Exploded View of Transceiver NSE–1NX
Appendix 1
Original 03/98
Page 1 – 5
NSE–1NX
PAMS
Appendix 1
Technical Documentation
Assembly Parts of NSE–1NX
ITEM Q’TY CODE DESCRIPTION VALUE, TYPE
1 9456132 Window NSE–1NX DMC00937
2 9456132 A–cover (See module list)
3 9790300 Keymat DMC00911
4 9790256 Power Keymat
5 5140067 Speaker + Spring
6 0200921 GD40 LCD Module
M2 0201144 UI Module UE4S
7 9460208 Frame DMD02411
8 5140101 Microphone + Boot DMC00955
M1 0200951 System/RF Module UP8T
9 9457851 B–Cover DMC00945
9457853 C–Cover DMC00946
10 4700057 RTC Battery
11 2 6190015 Screw M1.6x10 T6
12 4 6190013 Screw M1.6x7 T6
13 0660160 Antenna 890 – 960 MHz
14 9380529 Type Label – continuous sheet
15 Logo Label
16 1 6190023 Screw M1.6x4 T6
17 9451139 Dust Cap DMD02859
18 9460215 Transducer gasket DMD02687
Page 1 – 6
Original 03/98
