Noco Genius 2D User Manual
2
D
DANGER
READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT. Failure to
follow these safety instructions may result in ELECTRICAL SHOCK, EXPLOSION, FIRE, which
may result in a SERIOUS INJURY, DEATH, or PROPERTY DAMAGE.
Electrical Shock. Product is an electrical device that can shock and cause serious injury. Do not cut
power cords. Do not submerge in water or get wet.
Explosion. Unmonitored, incompatible, or damaged batteries can explode if used with product. Do not
leave product unattended while in use. Do not attempt to charge a damaged or frozen battery. Use product
only with batteries of recommended voltage. Operate product in well ventilated areas.
Fire. Product is an electrical device that emits heat and is capable of causing burns. Do not cover product.
Do not smoke or use any source of electrical spark or fire when operating product. Keep product away
from combustible materials.
Eye Injury. Wear eye protection when operating product. Batteries can explode and cause flying debris.
Battery acid can cause eye and skin irritation. In the case of contamination of eyes or skin, flush aected
area with running clean water and contact poison control immediately.
Explosive Gases. Working in the vicinity of a lead-acid is dangerous. Batteries generate explosive
gases during normal battery operation. To reduce risk of battery explosion, follow all safety information
instructions and those published by the battery manufacturer and manufacturer of any equipment intended
to be used in the vicinity of battery. Review cautionary markings on these products and on engine.
User Guide & Warranty
For more information
and support visit:
www.no.co/support
Important Safety Warnings
About Genius 2D. The Genius 2D is designed for charging the types of 12V lead-acid batteries, including Wet (Flooded), Gel, MF (Maintenance-Free) CA (Calcium),
EFB (Enhanced Flooded Battery), and AGM (Absorption Glass Mat) batteries. It is suitable for charging battery capacities up to 40 Amp-hours and maintaining all
battery sizes. Getting Started. Before using the charger, carefully read the battery manufacture's specific precautions and recommended rates of charge for the
battery. Make sure to determine the voltage and chemistry of the battery by referring to your battery owner's manual prior to charging. Location & Mounting. The
Genius 2D is designed to remain directly connected to a battery. Prevent battery acid from coming in contact with the product. Do not operate the product in a closedin area or an area with restricted ventilation. Never mount directly to the battery. Do not set a battery on top of product. Mount the charger near the battery, ensuring
the cables and charger are secure and away from any moving parts (eg. fan blades, belts, pulleys). Do not allow cords to be pinched, cut, or damaged by hood or
other moving parts, as it may cause a short circuit, which may result in property damage, injury, and/or death. Proposition 65. Battery posts, terminals, and related
accessories contain chemicals, including lead. These materials are known to the State of California to cause cancer and birth defects and other reproductive harm.
Personal Precaution. Only use product as intended. Someone should be within range of your voice or close enough to come to your aid in case of emergency.
Have a supply of clean water and soap nearby in the case of battery acid contamination. Wear complete eye protection and protective clothing while working near
a battery. Always wash hands after handling batteries and related materials. Do not handle or wear any metal objects when working with batteries including; tools,
watches or jewelry. If metal is dropped onto battery, it may spark or create a short circuit resulting in electrical shock, fire, explosion which may result in injury, death
or property damage. Minors. If the product is intended by “Purchaser” to be used by a minor, purchasing adult agrees to provide detailed instructions and warnings
to any minor prior to use. Failure to do so is the sole responsibility of the “Purchaser,” who agrees to indemnify NOCO for any unintended use or misuse by a minor.
Choking Hazard. Accessories may present a choking hazard to children. Do not leave children unattended with product or any accessory. The product is not a
toy. Handling. Handle product with care. The product can become damaged if impacted. Do not use a damaged product, including, but not limited to, cracks to
the casing or damaged cables. Do not use product with a damaged power cord. Humidity and liquids may damage product. Do not handle product or any electrical
components near any liquid. Store and operate product in dry locations. Do not operate product if it becomes wet. If product is already operating and becomes wet,
disconnect it from the battery and discontinue use immediately. Do not disconnect the product by pulling on the cables. Modifications. Do not attempt to alter,
modify or repair any part of the product. Disassembling product may cause injury, death or damage to property. If product becomes damaged, malfunctions or comes
in contact with any liquid, discontinue use, and contact NOCO. Any modifications to the product will void your warranty. Accessories. This product is only approved
for use with NOCO accessories. NOCO is not responsible for user safety or damage when using accessories not approved by NOCO. Operating Temperature.
This product is designed to work in ambient temperatures between -20° to +60°C. Do not operate outside of temperature ranges. Do not charge a frozen battery.
Discontinue use of product immediately if the battery becomes excessively warm. Storage. Do not use or store your product in areas with high concentrations of dust
or airborne materials. Store your product on flat; secure surfaces so it’s not prone to falling. Store your product in a dry location. The storage temperature is -20° to
100°C (average under-hood temperature). Compatibility. The product is only compatible with 12-volt lead-acid batteries only. Do not attempt to use product with
any other type of battery. Charging other battery chemistries may result in injury, death or property damage. Contact the battery manufacturer prior to attempting to
charge the battery. Medical Devices. Do not charge pacemakers or other medical devices. Product may emit electromagnetic fields. Product contains magnetic
components which may interfere with pacemakers, defibrillators, or other medical devises. These electromagnetic fields may interfere with pacemakers or other
medical devices. Consult with your physician prior to use if you have any medical device including pacemakers. If you suspect the product is interfering with a medical
device, stop using the product immediately and consult your physician. Medical Conditions. If you have any medical condition that you believe could be aected
by product, including but not limited to; seizures, blackouts, eyestrain or headaches, consult your physician prior to use of product. Cleaning. Power o the product
before attempting any maintenance or cleaning. Clean and dry product immediately if it comes in contact with liquid or any type of contaminant. Use a soft, lint-free
(microfiber) cloth. Avoid getting moisture in openings. Explosive Atmospheres. Obey all signs and instructions. Do not operate product in any area with a potentially
explosive atmosphere, including fueling areas or areas which contain chemicals or particles such as grain, dust or metal powders. High-Consequence Activities.
This product is not intended for use where the failure of the product could lead to injury, death or severe environmental damage. Radio Frequency Interference.
Product is designed, tested, and manufactured to comply with regulations governing radio frequency emissions. Such emissions from the product can negatively
aect the operation of other electronic equipment, causing them to malfunction. Model Number: Genius 2D This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his/her own expense.
How To Use
Charging Modes.
The Genius 2D has two (2) automatic modes, and will begin charging when both the battery and power are connected. Do not operate the charger until you confirm
the Genius 2D charger is compatible with your battery type and voltage. Below is a brief description:
Mode Explanation
The charger is connected to AC power but no battery is detected, and the charger is not charging. Energy Save is activated during this mode,
Standby
12V NORM
drawing microscopic power from the electrical outlet.
No Power
For charging 12-volt Wet Cell, Gel Cell, Enhanced Flooded, Maintenance-Free, Calcium batteries and AGM.
14.5V | 2000mA | Up To 40Ah Batteries | Maintain all sizes
EN
On-Board Mounting.
Mount the charger near the battery, ensuring the cables and charger are secure and away from any moving parts (eg. fan blades, belts, pulleys). Secure the
provided mounting bracket to the vehicle’s chassis using the two included self-tapping screws. For best results, mark the position using the bracket, and pre-drill
two small pilot holes. Once the bracket is secured, use the velcro strap to secure the Genius 2D in place.
Connecting to the Battery.
Do not connect the AC power plug until all other connections are made. Identify the correct polarity of the battery terminals on the battery. Do not make any
connections to the carburetor, fuel lines, or thin, sheet metal parts. The below instructions are for a negative ground system (most common). If your vehicle is a
positive ground system (very uncommon), follow the below instructions in reverse order.
1.) Connect the positive (red) eyelet terminal connector to the positive (POS,P,+) battery terminal.
2.) Connect the negative (black) eyelet terminal connector to the negative (NEG,N,-) battery terminal.
3.) Connect the battery charger’s AC power plug into a suitable electrical outlet.
Begin Charging.
1.) Verify the voltage and chemistry of the battery.
2.) Confirm that you have connected the eyelet terminal connectors properly and the AC power plug is plugged into an electrical outlet.
3.) All LEDs will flash momentarily, then the charger will begin charging without user intervention.
4.) The charger can now be left connected to the battery at all times to provide maintenance charging.
Understanding Charge LEDs.
The charger has one (1) Charge LED. This Charge LED indicates the connected battery(s) state-of-charge (SOC). See the explanation below:
LED
Pulsing Red LED The Red Charge LED will slowly pulse “on” and “o” when the battery is less than 75% fully charged.
Solid Green LED When the batter y is 100% charged, the Charge LED will be solid green.
Pulsing Green LED
Understanding Advanced Diagnostics.
The Error, Hot, and Standby LEDs together shall indicate error conditions shown in the table below:
Error
Error LED
Hot LED
Single alternating flash
- Error and Standby
Double alternating flash
- Error and Standby
Triple alternating flash
- Error and Standby
Explanation
The Green Charge LED will slowly pulse “on” and “o” when the battery is between 75% and 100% charged and during
battery optimization charging. It is normal for optimization charging to occur on a regular basis after the battery is fully
charged.
Reason/Solution
Reverse polarity. Reverse the battery connections. Or battery voltage is too low for charger to detect.
Charger is outside of its safe operating temperature and is not charging. Allow charger to cool down.
Battery will not hold a charge. Have battery checked by a professional.
Possible battery short. Have battery checked by a professional.
Battery voltage is too high for the selected charge mode. Check the battery.
EN
Charging Times.
The estimated time to charge a battery is shown below. The size of the battery (Ah) and its depth of
discharge (DOD) greatly aect its charging time. The charge time is based on an average depth of
discharge to a fully charged battery and is for reference purposes only. Actual data may dier due to
battery conditions. The time to charge a normally discharged battery is based on a 50% DOD.
Battery Size
8 2
12 3
24 6
40 10
Approximate Time to
Charge In Hours
12VAh (Amp hour)
Technical Specifications
Input Voltage AC: 110-240 VAC, 50-60Hz
Working Voltage AC: 90-264 VAC, 50-60Hz
Eciency: 87% Approximately
Power: 28 W Max
Charging Voltage: Various
Charging Current: 2000mA (12V)
Low-Voltage Detection: 1V
Back Current Drain: <0.5mA
Ambient Temperature: -20°C to +60°C
Type of Batteries: 12V
Battery Chemistries: Wet, Gel, MF, CA, EFB, AGM, Calcium
Battery Capacity: Up to 40Ah, Maintains All Battery Sizes
Housing Protection: IP65
Cooling: Natural Convection
Dimensions (L x W x H): 5 x 2.3 x 1.5 inches
Weight: 0.5 Pounds
3 Year Hassle-Free Warranty
NOCO warrants that this product (the “Product”) will be free from defects in material and workmanship for a period of Three (3) years from the date of purchase
(the “Warranty Period”). For defects reported during the Warranty Period, NOCO will, at its discretion, and subject to NOCO’s technical support analysis, either repair
or replace defective products. Replacement parts and products will be new or serviceably used, comparable in function and performance to the original part and
warranted for the remainder of the original Warranty Period.
NOCO’S LIABILITY HEREUNDER IS EXPRESSLY LIMITED TO REPLACEMENT OR REPAIR. TO THE MAXIMUM EXTENT PERMITTED BY LAW, NOCO SHALL NOT
BE LIABLE TO ANY PURCHASER OF THE PRODUCT OR ANY THIRD PARTY FOR ANY SPECIAL, INDIRECT, CONSEQUENTIAL OR EXEMPLARY DAMAGES,
INCLUDING, BUT NOT LIMITED TO, LOST PROFITS, PROPERTY DAMAGE OR PERSONAL INJURY, RELATED IN ANY WAY TO THE PRODUCT, HOWSOEVER CAUSED,
EVEN IF NOCO HAD KNOWLEDGE OF THE POSSIBILITY OF SUCH DAMAGES. THE WARRANTIES SET FORTH HEREIN ARE IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS, IMPLIED, STATUTORY OR OTHERWISE, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, AND THOSE ARISING FROM COURSE OF DEALING, USAGE OR TRADE PRACTICE. IN THE EVENT THAT ANY APPLICABLE LAWS IMPOSE
WARRANTIES, CONDITIONS OR OBLIGATIONS THAT CANNOT BE EXCLUDED OR MODIFIED, THIS PARAGRAPH SHALL APPLY TO THE GREATEST EXTENT ALLOWED
BY SUCH LAWS.
This Warranty is made solely for the benefit of the original purchaser of the Product from NOCO or from a NOCO approved reseller or distributor and is not
assignable or transferable. To assert a warranty claim, the purchaser must: (1) request and obtain a return merchandise authorization (“RMA”) number and return
location information (the “Return Location”) from NOCO Support by emailing support@no.co or by calling 1.800.456.6626; and (2) send the Product, including
RMA number, and receipt to the Return Location. DO NOT SEND IN PRODUCT WITHOUT FIRST OBTAINING AN RMA FROM NOCO SUPPORT.
The original purchaser is responsible (and must prepay) all packaging and transportation costs to ship products for warranty service.
NOTWITHSTANDING THE ABOVE, THIS HASSLE-FREE WARRANTY IS VOID AND DOES NOT APPLY TO PRODUCTS THAT: (a) are misused, mishandled, subjected
to abuse or careless handling, accident, improperly stored, or operated under conditions of extreme voltage, temperature, shock, or vibration beyond NOCO's
recommendations for safe and eective use; (b) improperly installed, operated or maintained; (c) are/were modified without the express written consent of NOCO;
(d) have been disassembled, altered or repaired by anyone other than NOCO; (e) the defects of which were reported after the Warranty Period.
THIS HASSLE-FREE WARRANTY DOES NOT COVER: (1) normal wear and tear; (2) cosmetic damage that does not aect functionality; or (3) Products where the
NOCO serial number is missing, altered, or defaced.
HASSLE-FREE WARRANTY CONDITIONS
These conditions apply only to Product during the Warranty Period. The Hassle-Free Warranty is void either by elapsed time from date of purchase (elapsed time
from serial number date, if no proof of purchase) or from the conditions listed earlier in this document. Return Product with the appropriate documentation.
With Receipt:
0-3 Years: NO Charge. With proof of purchase, The warranty period begins on date of purchase.
With NO Receipt:
0-3 Years: NO Charge. With NO proof of purchase, The warranty period begins on the serial number date.
We recommend registering your NOCO product in order to upload proof of purchase and extend your eective warranty dates. You may register your NOCO product
online at: no.co/register. If you have any questions regarding your warranty or product, contact NOCO Support (email and phone number above) or write to: The
NOCO Company, at 30339 Diamond Parkway, #102, Glenwillow, OH 44139 USA.
EN
2
D
PELIGRO
ASEGÚRESE DE QUE LEE Y ENTIENDE TODA LA INFORMACIÓN DE SEGURIDAD ANTES DE USAR
ESTE PRODUCTO. El incumplimiento de estas instrucciones de seguridad podría resultar
en DESCARGA ELÉCTRICA, EXPLOSIÓN o INCENDIO, que podrían causar LESIONES GRAVES,
MUERTE o DAÑOS MATERIALES.
Descarga eléctrica. Este producto es un dispositivo eléctrico que puede producir descarga y causar
lesiones graves. No corte los cables de alimentación. No lo sumerja en agua ni deje que se moje.
Explosión. Baterías sin supervisar, incompatibles o dañadas pueden explotar si se utilizan con este
producto. No lo deje desatendido mientras está en uso. No intente cargar una batería dañada o congelada.
Utilice este producto solo con baterías del voltaje recomendado. Úselo solo en áreas bien ventiladas.
Incendio. Este producto es un dispositivo eléctrico que emite calor y puede causar quemaduras.
No cubra este producto. No fume ni utilice nada que pueda causar chispas o fuego mientras usa
este producto. Manténgalo alejado de materiales combustibles.
Lesión ocular. Use protección ocular cuando utilice este producto. Las baterías pueden explotar
y hacer que salgan disparadas pequeñas partículas. El ácido de la batería puede causar irritación en
los ojos y la piel. En el caso de contaminación de los ojos o la piel, aclare el área afectada con
abundante agua corriente y póngase en contacto inmediatamente con el servicio de control de
intoxicación y envenenamiento.
Gases explosivos. Es peligroso trabajar cerca de baterías de ácido-plomo. Las baterías generan gases
explosivos durante su funcionamiento normal. Para reducir el riesgo de explosión de la batería, siga todas
las instrucciones de seguridad publicadas por el fabricante de la batería y el fabricante de cualquier
equipo destinado a ser utilizado cerca de esta. Revise las señales de precaución en estos productos y
en el motor.
Guía de usuario y garantía
Español
Para obtener más información
y asistencia técnica consulte:
www.no.co/support
Loading...
