QUICK R EFE RENCE GUIDE
2006 FRONTIER
Sh ift_capability
04
03
TRIP COMPUTE R
05
WINDSHIELD WIPER/
WASHER SWITCH
INSTRUME NT BRIGHTNESS
CONTROL/TRIP CHANGE
BUT TON
08
FOUR-WHEEL DRIVE
(4WD) SHIFT SWITCH
10
09
E-LOCK SWITCH
HILL DESCENT
CONTROL
(HDC) SWITCH
02
TIRE PRESSURE
MONITORING SYSTE M
01
HEADLIGHT AND TURN SIG NAL CONTROL
07
FRONT-PASSENG ER AIR BAG
STATUS LIGHT (B EH IND STEE RING WHE EL)
06
CRUISE CONTROL
12
11
CLIMATE
CONTROLS
AUDIO
SYSTEM
01
HEADLIGHT AND TURN SIGNAL CONTROL
HEADLIGHT SWITCH
Turn the headlight switch to the
to turn on the front parking, tail, license plate and
position
instrument panel lights.
Turn the headlight switch to the
turn on the headlights. All other lights remain on.
HIGH BEAM
position to
Push the headlight switch forward to select the high beam function. The blue
indicator light illuminates. Pull the headlight switch back to the original position to
select the low beam. The blue
indicator light goes off.
Pull and release the headlight switch to flash the headlight high beams on and off.
TURN SIGNAL SWITCH
Move the headlight control switch up or down to signal the turning direction.
When the turn is completed, the turn signals cancel automatically.
To signal a lane change, move the headlight control switch up or down to the
point where the indicator light begins to flash, but the headlight control switch
does not latch.
AUTOMATIC HEADLIGHT OPERATION (if so equipped)
The autolight system can:
Turn the headlights on automatically when it is dark.
Turn the headlights off automatically when it is light.
Keep the headlights on for 45 seconds after you turn the ignition switch to OFF
and all doors are closed.
TO ACTIVATE THE AUTOLIGHT SYSTEM:
Turn the headlight switch to the AUTO position, then turn the ignition switch to ON.
TO DEACTIVATE THE AUTOLIGHT SYSTEM :
Turn the headlight switch to the OFF,
FOG LIGHT OPERATION (if so equipped)
or
position.
Note: The headlights must be on and the low beams selected for the fog lights to
operate.
Turn the switch to the
position to turn on the fog lights.
Turn the switch to the OFF position to turn off the fog lights.
02
TIRE PRESSURE MONITORING SYSTEM (TPMS)
This system monitors tire pressure. Please remember,
this system does not detect a sudden drop in tire
pressure (for example, a blowout while driving). It also
does not monitor the air pressure in the spare tire.
Tire pressure is affected by temperature. Low outside temperature causes lower tire
pressure. This may cause the low tire pressure warning light to illuminate.
If the low tire pressure warning light illuminates, check the tire pressure in all four
tires. Adjust the low tire pressure to the recommended COLD tire pressure shown on
the Tire and Loading Information label to turn the low tire pressure warning light off.
If TPMS is not functioning properly, the low tire pressure warning light will flash for
approximately 60 seconds when the key is turned on. After 60 seconds, the light will
remain on. Have the system checked by a NISSAN dealer.
03
TRIP COMPUTER (if so equipped)
The trip computer readout is in the speedometer
display. It can show the following items:
TRIP “A” – Measures the distance of one
specific trip.
TRIP “B” – Measures the distance of a second
specific trip.
DISTANCE TO EMPTY (dte) – Estimates the
distance that can be driven before refueling.
AVERAGE SPEED – (MPH or km/h) Shows the average speed since the
last reset.
AVERAGE FUEL CONSUMPTION – (mpg or l/100 km) Shows the average
fuel consumption since the last reset.
JOURNEY TIME – Shows the time since the last reset.
RESET – Press the CHANGE button on the instrument panel for more than 1
second to reset the trip odometer to zero.
With the ignition key in the ON position or the vehicle running, you can select an
item by pressing the CHANGE button on the instrument panel.
04
INSTRUMENT BRIGHTNESS CONTROL/
TRIP CHANGE BUTTON
The instrument brightness control operates when
the headlight control switch is in the
or
position.
Turn the control to adjust the brightness of the
instrument panel lights.
Press the change button to select trip computer
features. See above for more information on the
trip computer.
05
WINDSHIELD WIPER/WASHER SWITCH
The ignition switch must be in the ON
position to activate the windshield wipers.
Push the lever down to operate the windshield
wipers.
Switch operation includes:
Intermittent – Wipers operate
INT
intermittently and can be adjusted by turning the time control.
Low speed – Wipers operate at a continuous low speed.
LO
HI
High speed – Wipers operate at a continuous high speed.
Mist – Lift the lever up for one sweep operation of the wiper.
MIST
Wash – Pull the lever toward you. Wipers automatically wipe several times.
CRUISE CONTROL (if so equipped)
06
To activate the cruise control, push the ON/OFF
switch. The indicator light in the instrument
panel will illuminate.
To set cruising speed, accelerate the vehicle
to the desired speed, push the COAST/SET
switch and release it. The SET indicator light in
the instrument panel will illuminate.
To reset at a faster cruising speed, push and hold the ACCEL/RES switch.
When the vehicle attains the speed you desire, release the switch.
To reset at a slower cruising speed, push and hold the COAST/SET switch.
Release the switch when the vehicle slows to the desired speed.
To resume a preset speed, push and release the ACCEL/RES switch. The
vehicle returns to the last set cruising speed when the vehicle speed is over
25 MPH (40 km/h).
To cancel cruise control, push the CANCEL switch or tap the brake pedal. The
SET indicator light in the instrument panel will go out.
To turn off cruise control, push the ON/OFF switch. Both the CRUISE indicator
light and the SET indicator light in the instrument panel will go out.
07
FRONT-PASSENGER AIR BAG STATUS LIGHT
This vehicle is equipped with the Nissan Advanced
Air Bag system. Under some conditions, depending
on pressure detected on the passenger seat and
how the seat belt is used, the front-passenger air
bag is designed to automatically turn OFF. When
the front-passenger air bag is OFF, the frontpassenger air bag status light will illuminate*. For
example:
When the system detects that the front-
passenger’s seat is occupied by a small adult, child or child restraint as outlined in
the Owner’s Manual, the
bag is OFF and will not inflate in a crash.
will illuminate to indicate that the front-passenger air
When the front-passenger’s seat is occupied and the passenger meets the
conditions outlined in the Owner’s Manual, the
that the front-passenger air bag is operational.
will not illuminate to indicate
*When the system detects that the front-passenger’s seat is unoccupied,
the passenger air bag status light will not illuminate even though the frontpassenger air bag is OFF.
Refer to the Owner’s Manual for detailed information regarding the Nissan Advanced
Air Bag System.
08
FOUR-WHEEL DRIVE (4WD ) SHIFT SWITCH
(if so equipped)
This system provides three positions so the
driver can select the desired drive mode
according to driving conditions.
2WD – Dry, paved roads.
4H – Rocky, sandy or snow-covered roads.
(Before placing 4WD shift switch in 4H position from 2WD, ensure vehicle
speed is less than 62.5 mph [100 km/h]).
4LO – When maximum power and traction are required (steep grades, rocky,
sandy or muddy roads).
09
E-LOCK SWITCH (if so equipped)
The Electronic Locking Rear Differential (E-Lock)
system can help provide added traction if the
vehicle is stuck or becoming stuck. This system
is available on 2WD and 4WD vehicles.
To activate the system:
The 4WD switch must be in the 4LO position
(4-wheel drive vehicles),
The vehicle must be stopped or moving at 4
mph (7 km/h) or less, and
The E-Lock system switch must be turned on.
Once the vehicle is free, the system should be
turned off.
10
HILL DESCENT CONTROL (HDC) SWITCH
(if so equipped)
The hill descent control system is designed to reduce
driver workload when going down steep hills. The HDC
system helps to control vehicle speed so the driver can
concentrate on steering the vehicle.
To activate the HDC system:
The automatic transmission selector lever must be in
forward or reverse gear,
The 4WD switch must be in the 4L position and the
vehicle speed must be under 15 MPH (25 km/h), or
The 4WD switch must be in the 4H position and the vehicle speed must be
under 21 MPH (35 km/h), and
The HDC system switch must be ON.
The HDC indicator light will come on when the system is activated. Also, the
stop/tail lights illuminate while the HDC system applies the brakes to control
vehicle speed. To turn off the HDC system, push the switch to the off position.
The HDC system is temporarily disabled when the brake or accelerator pedal
is depressed.
Refer to your Owner’s Manual for detailed information.
HILL START ASSIST (HSA) (if so equipped)
The hill start assist system automatically keeps the brakes applied to help prevent
the vehicle from rolling backwards in the time it takes the driver to release the brake
pedal and apply the accelerator when the vehicle is stopped on a hill.
HSA will operate automatically under the following conditions:
The selector lever is shifted to a forward or reverse gear.
The vehicle is stopped completely on a hill by applying the brake.
The maximum holding time is 2 seconds.
Please see reverse side for 11 and 12.
04
01
11
MANUAL CLIMATE CONTROL
01
FAN SPEED CONTROL DIAL
02
06
0705
03
Turn the fan speed control dial to the left (slow) or right (fast) to control fan
speed.
02
TEMPERATURE CONTROL DIAL
Turn the temperature control dial for the desired temperature. Turn the control dial
to the left for cold air or right for hot air.
03
AIR FLOW CONTROL DIAL
Turn the dial to select the following air flow outlets:
MAX
Air flows from center and side vents with maximum cooling (air conditioning).
A/C
Air flows from center and side vents.
Air flows from center and side vents and the front and rear floor outlets.
Air flows mainly from the front and rear floor outlets.
Air flows from defroster outlets and the front and rear floor outlets.
Air flows mainly from defroster outlets.
04
DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Turn the air flow control dial to the front window defroster mode . The A/C
automatically turns on when the defroster mode is selected.
Turn the temperature control dial left or right to set the desired temperature.
To set the defroster on high, turn the fan speed dial all the way to the right.
05
DEFROSTING/DEFOGGING REAR WINDOW AND OUTSIDE HEATED MIRROR
(if so equipped)
Push the rear window defroster switch on. Push the switch again to manually
turn the defroster off. Note: The rear window defroster automatically turns off in
approximately 15 minutes.
06
A/C ON/OFF BUTTON (if so equipped)
Press the A/C button to turn the A/C on or off.
07
AIR RECIRCULATION BUTTON (if so equipped)
Press the air recirculation button to recirculate air inside the vehicle.
Press the air recirculation button again to turn air recirculation off.
The air recirculation mode cannot be selected if the air flow control dial is in
the defrost position .
01
02
03
05
06
12
AM/FM/SAT* RADIO WITH CD PLAYER (if so equipped)
01
PRESET A.B.C BUTTON
04
07
08
Press the PRESET A ·B· C button until you reach the desired setting. The radio is
equipped with three separate banks, each with six station presets. You may store
any combination of AM, FM or SAT* radio presets on each bank.
02
CD BUTTON
When the CD button is pressed with a compact disc loaded and the radio playing,
the radio turns off and the compact disc starts to play.
03
BAND SELECT BUTTON
Press the BAND button to change from AM to FM reception.
04
CD EJECT BUTTON
When the CD eject button is pressed with a compact disc loaded, the compact
disc ejects. When the button is pressed while the compact disc is playing, the
compact disc ejects and the system turns off.
05
SEEK/TRACK BUTTON
To scan quickly through each broadcasting station, press and hold the SEEK/
TRACK button for more than 1.5 seconds to enter scan mode. The tuner will pause
for 5 seconds on each broadcasting station. To skip from one track to another on a
CD, press the SEEK/TRACK button. Each time the button is pressed, the CD will
advance or skip back one track.
06
STATION AND CD SELECT BUTTONS
To store a radio station in a preset you must first select A, B, or C memory bank
by pressing the PRESET A.B.C button and tune to the desired AM, FM or SAT*
station. Then, press and hold the desired station select button for at least 2
seconds. When the preset indicator illuminates, a beep will sound, indicating
memorization is complete. To retrieve a previously set station, select the memory
bank where the preset was set, then press the corresponding station select
button.
07
MENU BUTTON
When the MENU button is pressed while the compact disc is playing, the play
pattern changes as follows:
RPT – The current selection is repeated.
MIX – Tracks are played at random, not following the sequence on the compact
disc. The same track may be repeated twice. If the button is pressed in the MIX
mode, tracks will be chosen at random.
08
AUDIO BUTTON
To adjust the audio levels for bass, treble, fader, and balance, press the AUDIO
button and adjust the level with the SEEK/TRACK button.
* SAT presets are only available on SAT equipped vehicles.
ADDITIONAL FEATURES (continued)
REMOTE KEYLESS ENTRY SYSTEM
(if so equipped)
LOCK DOORS
Press the LOCK button to lock all doors.
UNLOCK DOORS
Press the UNLOCK button once to unlock the
driver’s door only. Press the button again within
5 seconds to unlock all doors.
USING THE PANIC ALARM
Press and hold the PANIC button for longer
than 0.5 seconds. The panic alarm will sound
and the headlights will stay on for 25 seconds. The panic alarm stops when it
has run for 25 seconds, or any button is pressed on the keyfob.
SILENCING THE HORN BEEP FEATURE
To deactivate – Press and hold the LOCK and UNLOCK buttons for at least
2 seconds.
To activate – Press and hold the LOCK and UNLOCK buttons for at least 2 seconds
once more.
CHILD SAFETY REAR DOOR LOCK
(Crew Cab Model only)
Child safety locks help prevent the rear doors from
being opened accidentally, especially when small
children are in the vehicle. The child safety lock levers
are located on the edge of the rear doors. When the
lever is in the LOCK position, the door can be opened
only from the outside.
UTILITY BED WITH SPRAY-ON BED LINER
UTILITY BED WITH SPRAY-ON BED LINER
AND UTILI-TRACK ™ SYSTEM
AND UTILI-TRACK ™ SYSTEM
(if so equipped)
(if so equipped)
The Utili-track™ channel system allows you to move
The Utili-track™ channel system allows you to move
tie-down clamps in the bed to the best location to
tie-down clamps in the bed to the best location to
secure a load.
secure a load.
The tie-down cleats must be installed so the
The tie-down cleats must be installed so the
clamp is properly seated in the notches in the
clamp is properly seated in the notches in the
rail. If the tie-down cleat is not seated in the
rail. If the tie-down cleat is not seated in the
notches, it will not be flush with the rail and cannot be properly tightened. The bolt in
notches, it will not be flush with the rail and cannot be properly tightened. The bolt in
the center of the cleat must be tightened hand-tight (20 – 40 inch pounds).
the center of the cleat must be tightened hand-tight (20 – 40 inch pounds).
Check the tightness of the tie-down cleat periodically during a trip to make sure the
Check the tightness of the tie-down cleat periodically during a trip to make sure the
center bolt has not become loose.
center bolt has not become loose.
The channel end stoppers can be used to help prevent cargo from sliding or shifting
The channel end stoppers can be used to help prevent cargo from sliding or shifting
off the end of the truck bed. They must be installed so they are properly seated in
off the end of the truck bed. They must be installed so they are properly seated in
the detents in the channel.
the detents in the channel.
Refer to your Owner’s Manual for loading limits and tie-down recommendations.
Refer to your Owner’s Manual for loading limits and tie-down recommendations.
FRONT SEAT ADJUSTMENTS
WITH MANUAL SEATS (if so equipped):
Pull up on the lever under the front of the seat and
slide backward or forward. Release the lever to lock
02
the seat in position.
Lift the lever on the side of the seat
your seatback backward or forward; release when
01
to adjust
you have found a comfortable angle and the seat belt
fits properly.
Turn either dial
the seat cushion to the desired position.
WITH POWER SEATS (if so equipped):
Move the control forward or backward to adjust the
seat cushion forward or backward.
to adjust the angle and height of
02
01
02
02
01
03
Pull up to raise the seat cushion; press down
to lower the cushion.
02
Push the switch forward to move the seatback forward; push it back to move the
seatback backward.
03
Your driver’s seat has a lumbar support; adjust it by moving the lever up or down.
FOLD FLAT FRONT PASSENGER SEAT
(if so equipped)
To fold the front passenger’s seatback flat for extra
storage length when transporting long items:
Slide the seat to the rear-most position. Lift up on
01
the recline lever, located on the outside edge of
the seat, and fold the seatback forward as far as it
will go.
release the back of the seat.
Then lift up on the latch located on the upper corner of the seatback to
01
02
01
02
FOLDING THE REAR BENCH SEAT
(Crew Cab only)
FOLDING THE SEATBACK DOWN:
To fold the rear bench seatback down to access the
jacking tools, pull up on the straps located on the
outer edge of the seatbacks
and fold the
01
seatback forward.
FOLDING THE SEAT BASE UP:
To fold the rear bench seat base up to access the
under-seat storage bins:
Lift up on the lever
located on the side of the
01
seat, while lifting the front of the seat cushion up.
Fold the bottom of the seat cushion toward the
back of the vehicle until it locks into place.
Repeat this process to raise and secure the seat
cushion on the other side of the vehicle.
01
01
ADDITIONAL FEATURES
SEAT BELT WARNING LIGHT AND CHIME
The light and chime remind you to fasten your seat belts.
The light illuminates whenever the ignition key is turned to
the ON or START position and remains illuminated until the
driver’s seat belt is fastened. At the same time, the chime
sounds for about 6 seconds unless the driver’s seat belt is
securely fastened.
The seat belt warning light may also illuminate if the front
passenger’s seat belt is not fastened when the front passenger’s seat is
occupied (if so equipped). For 5 seconds after the ignition switch is in the ON
position, the system does not activate the warning light for the front passenger.
Refer to the Owner’s Manual for detailed information regarding seat belt usage.
This easy-to-use Quick Reference Guide is intended to help you more fully appreciate
some of the unique features and functions of your new vehicle. However, it is not
intended to replace your Owner’s Manual. The Owner’s Manual contains more
detailed information to help you better understand the important safety warnings,
features, operation, and maintenance of your vehicle.
Sh ift_
Nissan, the Nissan Brand Symbol, “SHIFT_ ” tagline, Z and Nissan model names are Nissan trademarks.
©2006 Nissan North America, Inc.
QR6E-0D40U2 Printing: April 2006 (06)
Loading...
