Wii Operations Manual

Channels and Settings

PRINTED IN CHINA

To protect your health and safety, and for correct use of the Wii system, please read and follow the instructions in the Wii Operations Manual - System Setup.

Wii contains browser technology (”Opera Browser”) licensed from Opera Software ASA (www.opera.com). (Opera® Browser from Opera Software ASA. Copyright 1995-2008 Opera Software ASA. All rights reserved.) The Opera Browser includes the Zlib compression library, developed by Jean-loup Gailly and Mark Adler. Copyright © 1995-2004 Jean-loup Gailly and Mark Adler. The Opera Browser includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. Copyright © 1998 2001 The OpenSSL Project. All rights reserved. THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT “AS IS” AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. The Opera Browser contains cryptographic software written by Eric Young. Copyright © 1995-1998 Eric Young (eay@cryptsoft.com). All rights reserved. THIS SOFTWARE IS PROVIDED BY ERIC YOUNG “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Number-to-string and string-to-number conversions are covered by the following notice: The author of this software is David M. Gay. Copyright © 1991, 2000, 2001 by Lucent Technologies. Permission to use, copy, modify, and distribute this software for any purpose without fee is hereby granted, provided that this entire notice is included in all copies of any software which is or includes a copy or modiﬁcation of this software and in all copies of the supporting documentation for such software. THIS SOFTWARE IS BEING PROVIDED "AS IS", WITHOUT ANY EXPRESS OR IMPLIED WARRANTY. IN PARTICULAR, NEITHER THE AUTHOR NOR LUCENT MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND CONCERNING THE MERCHANTABILITY OF THIS SOFTWARE OR ITS FITNESS FOR ANY PARTICULAR PURPOSE. Portions of this software are copyright © 2006 The FreeType Project (www.freetype.org). All rights reserved. eZiText® and Zi® are registered trademarks of Zi Corporation. “ ” and AOSS™ are the trademarks of BUFFALO INC. Windows and Windows Vista are trademarks of the Microsoft group of companies. This product is using Mobiclip™, a software video codec of Actimagine. Mobiclip is a trademark of Actimagine Corp. © 2008 Actimagine Corp. All rights reserved. www.mobiclip.com Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories. This product contains PrFILE®2 FAT file system, PrMAIL mail client library, and PrUSB/Host USB host stack of eSOL Co.,Ltd. Copyright © 2006 eSOL Co., Ltd. PrFILE®2 is a registered trademark of eSOL Co., Ltd. in Japan. PrMAIL and PrUSB/Host are trademarks of eSOL Co., Ltd. in Japan. The Wii console includes RSA BSAFE Cryptographic software from RSA Security Inc. RSA is a registered trademark of RSA Security Inc. BSAFE is a registered trademark of RSA Security Inc. in the United States and/or other countries. © 2005 RSA Security Inc. All Rights Reserved. Wii uses certain fonts provided by Fontworks Inc. Although an IBM logo appears on the Wii packaging, IBM is not responsible for warranty support of the Wii system. SDHC Logo is a trademark.

TM,

Authorized User in Canada. Elements of the Wii console and the Wii Network Services are patent pending, both in the United States and internationally.

Français – Page 79 Español – Página 159

Contents

Wii Menu 2 – 3 Channels Disc Channel 4 – 5 Mii™ Channel 6 – 13 Photo Channel 14 – 23 Wii Shop Channel 24 – 25 Virtual Console™ 26 – 27 WiiWare™ 28 – 29 Wii Message Board 30 – 39 Wii Settings and Data Management 40 – 63 HOME Menu 64 – 65 SD Card Menu 66 – 69 Wii Keyboard 70 – 71 USB Keyboard 72 Troubleshooting 72 – 77

Wii Menu

Using the Wii Menu

When the Wii console power is turned on, the ﬁrst screen you will see is the Wii Menu. From this screen, you can do several activities:

• Play a Game Disc

• Use one of the built-in software programs (Channels)

included with the Wii console

Wii Channels

Play a Wii or Nintendo GameCube Game Disc, start one of the built-in software programs included with the Wii console, or start other software programs downloaded to your console from the Wii Shop Channel. You can also select the Wii + Internet icon to view the Get Connected video about connecting your Wii system to the Internet.

The Wii Menu can have up to 48 Channels at one time. If you have more Channels than can be shown on the screen at one time, these can be accessed by selecting the blue scroll arrows.

• Change Wii console settings

• Access the SD Card Menu screen

(To use this menu item, an SD Card [sold separately] must be inserted into the SD Card slot. The icon will appear gray if there is no SD Card inserted.)

• Interact with the Wii Message Board

To select any of these activities, simply point at one with the Wii Remote and press the A Button.

Current Time

Wii Settings and Data Management

Change console settings or organize the contents of an SD Card or Nintendo GameCube Memory Card (see page 40).

Current

SD Card Menu

Open the SD Card Menu (see page 66).

2 3

Date

Wii Message Board

Open the Wii Message Board (see page 30).

• Blinks when you have received a message.

Wii Channels

These are the current Channels available:

Disc Channel

Play Wii and Nintendo GameCube games.

Mii Channel

Create characters that can be used in Mii-compatible software programs.

Photo Channel

View digital photos and videos from SD Cards.

Wii Shop Channel (Internet connection required)

Download new Channels, or use Wii Points™ to download Virtual Console

supported games and other Wii programs such as WiiWare titles, or purchase

goods (when available) offered on the Wii Shop Channel.

Forecast Channel (Internet connection required)

Check the weather conditions in different locations.

News Channel (Internet connection required)

View news from around the world.

Shortcut Channels (Internet connection required)

Some channels are not installed on the Wii system, but can be downloaded for free from the Wii Shop Channel. Select a channel icon from the Wii Menu to ﬁnd out more information about the Channel and to connect to the Wii Shop Channel

to download it.

NOTE: Formatting your Wii System Memory (see page 63) will permanently delete Shortcut Channels from your system. However, these Channels can be downloaded again free from the Wii Shop Channel.

Get Connected Video

Select the Wii + Internet icon from the Wii Menu to watch a video showing the many advantages of connecting your Wii system to the Internet.

Once you have connected your Wii system to the Internet, if you select this icon again, you will be asked if you would like to keep the video or delete it. Deleting the video will free up Wii system memory.

If this program is deleted, it cannot be recovered. It will also be permanently deleted if you format the Wii system memory (see page 63).

WiiConnect24

The Wii console can communicate with the Internet even when the power is turned off. The WiiConnect24 service can deliver game updates or other information even if the system is idle. (Broadband Internet connection required.)

See page 62 for more information on WiiConnect24.

™

Wii Menu

Disc Channel

On the Disc Channel, you can play your Wii and Nintendo

GameCube Game Discs.

Disc Channel

Wii Menu

Playing a Wii or Nintendo GameCube Game Disc

Before Inserting a Game Disc

• Make sure that your TV and any audio equipment that is connected to your Wii

console is turned on.

• Choose the correct input setting for your TV (see page 18 in the Wii Operations Manual - System Setup).

Inserting a Game Disc

Insert your Game Disc into the Disc Slot on the front of the Wii console. The console will turn on automatically and the Wii Menu will appear.

• If your console is placed vertically, the disc label will face to the right.

• If your console is placed horizontally, the disc label will face upward.

To select an on-screen option, simply point at it with the Wii Remote and press the A Button.

Wii Disc

Label

faces towards

the right side of

the console

IMPORTANT: To avoid damage to your Wii console or game discs:

Do not insert anything into the Game Disc slot except Wii or GameCube game discs.

•

• Do not move the Wii console during use.

Nintendo GameCube Disc

Label

faces towards

the right side of

the console

NOTE: A GameCube controller is required for playing GameCube games.

Starting the Game

1. Using the Wii Remote, select the Disc Channel on the Wii Menu.

2. Select Start on the game’s Channel Preview screen to begin the game.

• Review the instruction booklet for the game you are playing for speciﬁc game

control information.

Channel Preview screen

Dolby, Pro Logic and the double-D symbol are trademarks of Dolby Laboratories.

When You’re Done Playing

1. Press the Eject Button to remove the Game Disc if you are ﬁnished playing the game.

2. Turn the power off by pressing the Power Button on the front of the console, or by pressing the Power Button on the Wii Remote for one second.

Power Button Power Button

Eject Button

Front View of

Wii console

Disc Channel

4 5

Mii Channel

Put yourself into your Wii console by making a Mii... or many Mii

characters! You can see Mii characters in your games, carry them

Fine-tune your Mii characters' face.

Change its eyes, brows, nose, and mouth, and even add glasses and accessories.

You've designed your ﬁrst Mii! After you give it a few personal proﬁle

details like a Nickname (see page 10), you're completely ﬁnished!

in your Wii Remote, and let them hang out with friends' Mii characters, whether they're across the street or around the world!

Mii Channel

Wii Menu

To select an on-screen option, simply point at

it with the Wii Remote and press the A Button.

Design an endless

variety of Mii characters!

Making Your First Mii

Selecting the Mii Channel from the Wii Menu

Use the Wii Remote to select the Mii Channel, then select START to begin creating your ﬁrst Mii. (This Channel is controlled by one remote at a time. )

Creating Your Mii

First select Male or Female. You'll then see a starter face that you can change, along with a style menu. Go through the following steps to make your Mii.

Select a gender.

6 7

Change your Mii characters' face shape, hair color, and skin tone.

Finally, tailor your Mii characters' proportions however you like.

What Are Mii characters For?

• You can choose one of your Mii characters to be "you" in Mii-compatible games.

• You can store up to 100 Mii characters in your Mii Plaza (see page 11).

• You can carry Mii characters in your Wii Remote to exchange them with Mii characters in friends' Wii consoles (see page 12). Yours will then appear in their

games. And vice versa!

• You can also exchange Mii characters with friends around the world via WiiConnect24™ and the Mii Parade (see page 13).

Mii Channel

Creating More Mii characters

Selecting the Mii Channel from the Wii Menu

Use the Wii Remote to select the Mii Channel, then select Start to enter Mii Plaza (see page 11).

Select the New Mii icon on the left side of the screen:

Select Male or Female. Then if you've created a Mii previously, you'll see two Mii start-up options: "Start from scratch" or "Choose a look-alike."

Starting from Scratch

If you select "Start from scratch," you'll instantly be given a basic starter face, then you'll ﬁne-tune all of its features, just as you did with your ﬁrst Mii.

Choosing a Look-alike

Select "Choose a look-alike" if you want to get a Mii designed very quickly. You'll be shown a wide variety of starter faces that show a spectrum of Mii looks.

When you ﬁnd a face you like, select "Use this face" to move onto the Feature Edit screen, where you can ﬁne-tune the face if you prefer.

If you ﬁnd one that's close but not quite right, select it and you'll see many variations on the face. You can use this method repeatedly to get closer and closer to the exact face that you want (as shown to the right). Select "Use this face" when you see the exact Mii face you want.

Mii Channel

Modifying a Mii

Changing Mii Features

Use the style menu when changing your Mii characters' face and body. As you select categories from the top Feature menu, you'll see the Feature style menu below ﬁll with variations that you can choose for your Mii characters' look.

Feature Edit screen

Edit Mii proﬁle

See page 10.

Change body type

See page 10.

Spin your Mii

Select your Mii to see it whirl around and show you what it looks like from all sides.

Stop modifying

When you quit styling your Mii, you can choose whether to save your changes, and then you'll go to the Mii Plaza, where you'll see your Mii walking around (see page 11).

Feature style menu

Scroll buttons will appear if there are more options available:

Feature adjustment menu

Change facial features

Select feature type to see variations appear below.

Change color

You can select a color for many features.

Move feature up or down

Make feature larger or smaller

Rotate feature

Change feature spacing

You can tighten and broaden the spaces between dual features such as eyes and brows.

Right/Left Part

This option will appear when modifying the hairstyle.

Mii Channel

8 9

Mii Channel

Changing Mii Features (continued)

Select the Body Type choice from the Feature Edit screen.

You can then adjust the height and weight of your Mii using two sliders.

“Grab” a slider and move the Wii Remote to change the setting.

Creating a Proﬁle For Your Mii

Select the Edit Mii Proﬁle choice from the Feature Edit screen.

You can then give your Mii personal details. Select a detail you want to edit, then enter the information.

Proﬁle settings

Seeing Your Mii characters in Mii Plaza

Mii characters that you create walk around in Mii Plaza. You can go to Mii Plaza to check out your Mii characters, edit and create Mii characters, prepare Mii characters for going to other Wii consoles, and do other useful things with your home Mii crowd. Up to 100 Mii characters can stay in Mii Plaza, and they'll all appear in any Mii-compatible games you play on your Wii console.

Return to Wii Menu

Edit a Mii

Drag and release a Mii over this icon to

send it to Feature Edit. (You can’t edit

Mii characters from other Wii users.)

Create a new Mii

Erase a Mii

Drag and release a Mii over this icon to delete it.

Consult Help

Get information on Mii Channel controls.

Go to Mii Parade

Drag and release a Mii over this icon to send it to the Mii Parade. See page 13.

• Once moved to the Mii Parade, a Mii

characters’ birthday and creator information will be deleted.

• If a different game uses a Mii from the Mii

Parade, that Mii will be removed from the current game and that game’s save data may be affected.

Store a Mii in a Wii Remote

See page 12.

Send a Mii to a Wii Friend

(requires an Internet connection)

Mii Channel

• Selecting some of the options will bring up a virtual keyboard to enter letters or

numbers (see page 70 for information on using the keyboard).

• Make the Mii one of your Favorites if you want to give this Mii preference for

showing up in Mii-compatible games.

• Turn a Mii characters’ Mingle setting on if you want it to appear in the Mii Parade found on other Wii consoles (see page 13). Turn the Mii's Mingle off if you want to

restrict it to your own home Wii console only.

• Hold down the B Button

and move the cursor to move the screen view.

• Press the + or – Buttons

to zoom in and out on the screen.

• Select a Mii to display your

Mii characters’ label and change its Favorite status:

• Grab and move a Mii by selecting it

with the Wii Remote and holding

down the A and B Buttons. You can

then drop it into menu options by dragging it onto the corresponding icon, then releasing the buttons.

NOTE: A Mii that is dragged onto the Erase icon can't be recovered.

Arrange your Mii characters

See page 12.

10 11

Mii Channel

Storing a Mii in Your Wii Remote

Select the Wii Remote icon from the Mii Plaza.

If you store a Mii on your Wii Remote, you can take it to a friend's house and give a copy of your Mii to another Wii console. Your Mii can then be used in your friend's Mii-compatible games or put in your friend's Mii Parade. (You can also use your Wii Remote to grab Mii characters from your friend's Wii system and later add it to your Mii Parade or your Mii-compatible game.)

Choose a Wii Remote

If more than one Wii Remote is in use with the console, you can choose which Wii Remote to save the Mii to.

Move a Mii to Wii Remote

Each Wii Remote can hold up to ten Mii characters. To copy a Mii to the Wii Remote, grab and drag the Mii to an open spot. Select Save & Quit when you're ﬁnished.

Arranging Mii characters in the Mii Plaza

Select the Organize icon from the Portrait Plaza screen.

This will bring up new icons that let you organize your Mii characters by different categories:

Lists the number of Mii characters in the Mii Plaza.

Causes the Mii characters to scatter.

Arrange the Mii characters alphabetically.

Arrange by Favorite status.

Arrange by Favorite Color.

Arrange by gender.

Checking Out Visitors in Mii Parade

Any of your friends' Mii characters that are set to Mingle will enter your Wii system ﬁrst via the Mii Parade. You can see if any have arrived by selecting the Mii Parade icon in the Mii Plaza. (You can also bring Mii characters in to the Mii Parade from the Mii Plaza, as described on page 11.)

Each incoming Mii will stay in the Mii Parade until you transfer it to your Mii Plaza, where only then will it start showing up in your Mii-compatible games. Likewise, friends will ﬁrst see any Mingle-approved Mii characters in their own Mii Parades and must transfer them to their Mii Plaza to see them appear in their own games.

Go to Mii Plaza

Send Mii to Mii Plaza

Grab and drop a Mii on this icon to move it from the Mii Parade to the Mii Plaza, which allows it to appear in your Mii-compatible games and lets you perform most Mii Plaza functions on it. (You can't edit your friends'

Mii characters

Erase a Mii

About Mingling

Your

Mii characters

consoles. You can transfer

will enter friends' Mii Parades only if your

Mii characters

via your Wii Remote (see page 12), or you can let them travel on their own via WiiConnect24 (see page 62).

Mii characters

' individual Mingle settings are turned on. There are then two ways to send those

Change Mingle Setting

Your Mii Parade will accept incoming characters

only if you turn on this Mingle

option (see About Mingling below).

Mii Speed

Select to adjust the speed at which the characters

move.

Mii Number

Lists the number of and the total number of

Mii characters

on the screen

Mii

to their

Mii characters

NOTE: and your friends have Mingle options turned on.

s will travel to other Wii consoles via WiiConnect24 only if you've registered your friends in your Wii address book (requires an Internet connection), and if you

12 13

Mii Channel

Photo Channel

On the Photo Channel, you can view and play with any photos and videos you've saved onto an SD or SDHC Card.

Photo Channel

Wii Menu

Using the Photo Channel

You can do any of the following things using the Photo Channel:

• View your photos as a slide show.

• Draw on your photos.

• Save your photos to the Wii System Memory in the console using the Wii Message Board (see page 30).

• Send your pictures to anyone on your list of Wii Friends.

Inserting an SD or SDHC Card

Insert an SD Card into the SD Card Slot on the front of the console (32 GB maximum size).

NOTE: You can also use miniSD Cards and microSD Cards if you have an SD Card adapter, which can be found at most retail stores that sell SD Cards. See page 22 for more information on SD Cards.

Card

To select an on-screen option, simply point at it with the Wii Remote and press the A Button.

Selecting Your Photo Source

1. Using the Wii Remote, select the Photo Channel on the Wii Menu. (More than one remote can be used with the Photo Channel at one time.)

2. Select either Digital Camera/Cell Phone or View Wii Message Board photos to view your photo album.

NOTE: Photos will appear on the Wii Message Board (see pages 32 and 36) only if you have posted them there in a previous Photo Channel session.

View photos from the Wii Message Board

View photos from an SD Card

Viewing Your Photos and Videos

This on-screen menu will disappear temporarily if you move the cursor off the screen or stop moving the cursor for a moment.

Decrease size of photo views

Increase size of photo views

Scroll forward and backward through list of photos

Return to Photo Channel start screen

View your photos

in a slide show

(see page 17)

• Your photos will appear on the TV screen in the order they were taken. If this data is not available with the photo, the date that you update the photo in the Photo Channel will be used.

• Videos will appear as the ﬁrst frame from the ﬁle, with a ﬁlm icon in one corner.

• If the photo or video is in a format that is not supported by the Photo Channel, it will appear as a question mark icon. See page 22 for supported formats.

• If you have a large number of photos, or if they are very large in size, it may take a moment to open them all.

• The Photo Channel can display a maximum of approximately 1,000 photos. If your SD Card has more than 1,000 photos, remove the card from the Wii console and remove or reorganize your photos in your camera, cell phone, or computer.

Photo Channel

14 15

Photo Channel

Viewing a Photo Full Screen

Use the Wii Remote to select the photo you would like to view full screen. A new on-screen menu will appear with additional choices.

Scroll forward and backward through list of photos

Return to list of photos

Post photo to Message Board

See page 21.

Play with your photos

See page 18.

View a slide show of your photos

See page 17.

Rotate photo 90º clockwise

Zoom in or out

If part of the photo is off-screen, a scroll panel will appear: Move the cursor over an arrow and press the A Button to change the area of the photo that is viewed.

Scroll left

Scroll up

Scroll right

Scroll down

Viewing Photos in a Slide Show

Select the slide show option using the Wii Remote. The photos will automatically be displayed in the order they appear on the screen.

Press the A Button during a slide show to open an on-screen menu with additional choices.

Resume slide show

Adjust settings

End slide show

Resume slide show

Choose display order

Choose your photos randomly or in the order in which they were taken.

Change transition effects between photos

Change music played during slide show

Select from the songs included in the Photo Channel, or use any AAC format music saved on your SD Card.

Song Menu screen

Photo Channel

16 17

Photo Channel

Having Fun With Your Photos

Select the Fun! option to open a new menu with additional options for playing with your photos or frames from your videos.

Adjust the overall appearance of your photo

Draw, cut and paste, and add text and stamps

Create a puzzle out of

a photo for others to

reassemble

Mood

Mood Menu Screen Options

• Brighten: Brighten the photo. Select repeatedly to increase effect.

• Black and White: Convert photo to gray scale monochrome.

• Zap!: Invert the photo.

• Hard-boiled: Convert the photo to stark black and white.

Select repeatedly to increase effect.

Doodle

Zoom out

Stamp selection

Select color for sketch pen

Erase tool

Zoom in

Eyedropper tool: Copy a color from the photo

1. Select the eyedropper icon and press the A Button.

2. Move the eyedropper icon over a part of the photo where

you want to copy the color and press the A Button.

3. The cursor will change to the selected color.

Scissors tool: Cut and paste a piece of the photo

1. Select the scissors icon and press the A Button.

2. Move the scissors icon over a part of the photo where you want to

cut and paste and press the A Button. A cut frame will appear.

3. Press the A Button to cut the area and again to paste it.

Erase all doodles and restore the photo to its original appearance

NOTE: Move the Wii Remote closer to the TV to increase the size of the sketch pen or stamp. Move the Wii Remote away from the TV to reduce the size of the pen or stamp. Twist the Wii Remote to rotate

the pen or stamp.

Photo Channel

18 19

Photo Channel

Puzzle

When you select this option, your photo will be divided into pieces.

To reassemble the pieces, move the cursor over a piece and press and hold the

A Button. Move the piece into place and drop it by releasing the A Button.

Move pieces

Get a hint

View the original image.

Number of puzzle pieces

The puzzle starts with six pieces.

After completing that level, you can

choose the number of pieces to start with.

View records for shortest completion time

Saving Mood and Doodle Changes

Changes made to your photos can only be saved by posting your photo to the Wii Message Board (see page 21).

You cannot save or overwrite photos or videos on the SD Card.

• You can make Doodle changes to

only one photo at a time. If you select another photo while you have a modiﬁed photo open, you will see the following warning screen, shown at right.

NOTE: Erased doodles cannot be recovered.

• When you return to the Photo

Channel start screen, any Mood or Doodle changes will be erased unless you post your modiﬁed photos to the Wii Message Board.

You will be notiﬁed by this screen:

Viewing Your Videos

Select a video from the photo album to begin playing it.

• Hold down the 1 Button on the Wii Remote to rewind the video.

• Hold down the 2 Button on the Wii Remote to advance the video.

Tap these buttons to rewind or advance the video a little.

NOTE: Any of the options available in the Fun! mode can be applied

to individual frames of a video.

Posting Photos to the Wii Message Board or Wii Menu

You can save your photos or single frames from videos from an SD Card to the Wii

System Memory by posting them to the Wii Message Board or Wii Menu.

When you display a photo or video frame in full-screen mode, you will have the

option to post that photo to the Wii Message Board or Wii Menu. If you select Post you will see the following conﬁrmation screen:

• Images that have been modiﬁed by Mood or Doodle changes also can be saved

to the Wii Message Board or Wii Menu.

• You can use the Wii Message Board to send photos to anyone on your list of Wii Friends (see page 36).

NOTE: See page 32 for information on deleting messages from the Wii Message Board. When deleting images posted to the Wii Message Board, you must delete the entire message.

20 21

Photo Channel

+ 28 hidden pages

Nintendo Wii User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
