Ninja F300C Owner's Manual

Professional Frying System
OWNER’S GUIDE
®
www.ninjakitchen.com
®
HELP
LINE
F300 F300C
F300_15_F300C_15_IB_ENG_121114_3.indd 1 12-11-14 2:38 PM
1
TOLL FREE: 1-877-646-5288
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING YOUR NINJA® PROFESSIONAL FRYING SYSTEM.
POLARIZED PLUG WARNING: To reduce the risk of electric
shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet.
DO NOT modify the plug in any way.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
1. DO NOT touch hot surfaces, always use handles or knobs.
2. To protect against electrical shock, DO NOT immerse break-away safety
power cord or plug in water or other liquids.
3. Close supervision is necessary when any appliance is used by or near children.
4. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.
5. DO NOT operate any appliance with a damaged cord or plug or after the appliance malfunctions, has been dropped or damaged in any manner. Return the damaged appliance to EURO-PRO Operating LLC for examination, repair or adjustment. (See Warranty.)
6. Never plug in before the unit is assembled and before oil is added to the oil reservoir.
7. Never overfill the fryer with oil. Fill only to the fill line indicated inside the removable oil reservoir.
8. Be sure the basket handle is properly assembled to the basket and locked in place. (See assembly instructions.)
9. Only use EURO-PRO approved accessories and attachments. Use of accessory attachments not recommended by the appliance manufacturer may cause hazard or injury.
F300_15_F300C_15_IB_ENG_121114_3.indd 1 12-11-14 2:38 PM
2
www.ninjakitchen.com
SPECIAL SAFETY INSTRUCTIONS
• Adetachablemagneticpower
cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord. An extension cord (or
longer detachable cord) is not recommended for use with deep fryers.
• Never plug the unit into an electrical outlet before the oil reservoir has been filled with oil.
• DO NOT immerse the deep fryer or the break-away safety power cord in water.
• CAUTION: Condensation from the deep fryer lid may cause splattering when being opened and closed.
• Whenopeningthelidafterfrying,
lift slowly and carefully away from you to allow the steam inside to escape before opening fully.
• Toavoidacircuitoverload,DO NOT operate another high wattage
appliance on the same circuit.
WARNING: Extension cords
are not recommended for use with this product.
SAVE THESE INSTRUCTIONS
10. Extreme caution must be used
when moving any appliance containing hot oil or other hot liquids.
11. DO NOT leave appliance unattended while in use.
12. DO NOT use outdoors.
13. DO NOT place on or near a hot gas
or electric burner, or in a heated oven.
14. Place your deep fryer on a heat resistant countertop or table close to an electrical outlet.
15. DO NOT place anything on top of the deep fryer.
16. Only use appliance for its intended purpose.
17. DO NOT add food with ice crystals or if it has water droplets to the hot oil.
18. DO NOT let the power cord hang over the edge of the table or counter or let it touch hot surfaces.
19. When the unit is in use, ensure that the fryer basket handle does not extend over the counter surface to help avoid accidental spills and tipping of unit.
20. Before disconnecting the Ninja® Professional Frying System from the electrical outlet, press the Start/Stop button to stop cooking. Wait at least 60 seconds before removing the break-away safety power cord from the outlet. Always hold the plug, and never pull the cord.
21. Store the appliance indoors to prevent electronic parts failure.
F300_15_F300C_15_IB_ENG_121114_3.indd 2 12-11-14 2:38 PM
3
TOLL FREE: 1-877-646-5288
THIS BOOK COVERS MODEL NUMBERS:
F300 15 F300C 15
TECHNICAL SPECIFICATIONS
Voltage: 120V., 60Hz. Power: 1800 Watts
F300_15_F300C_15_IB_ENG_121114_3.indd 3 12-11-14 2:38 PM
4
www.ninjakitchen.com
Contents
Thank you for purchasing the Ninja
®
Professional Frying System.
Getting to Know Your Ninja® Professional Frying System .............................5
Features ........................................................................................................6
Using the Ninja
®
Professional Frying System ...............................................7
Clean Before First Use ................................................................................ 7
Assembling .................................................................................................7
Filling the Oil Reservoir ..............................................................................8
Programming the Professional Frying System ................................................9
Using the Ninja
®
Professional Frying System ................................................9
Filling the Fryer Basket ...................................................................................9
Frying Food ....................................................................................................10
Emptying the Professional Frying System .......................................................10
Suggested Frying Guide and Tips....................................................................11
Cleaning and Storing Your Ninja
®
Professional Frying System ......................12
Troubleshooting Guide ...................................................................................12
Warranty & Registration.................................................................................14
F300_15_F300C_15_IB_ENG_121114_3.indd 4 12-11-14 2:38 PM
5
TOLL FREE: 1-877-646-5288
e Deep Fryer Control Panel
f Removable Oil Reservoir
g Deep Fryer Housing
h Break-Away Safety Power Cord
a Deep Fryer Lid with Viewing Window
b Removable Fryer Basket Lid
c Fryer Basket Handle
d Fryer Basket
NOTE: Attachments are not interchangeable.
Getting To Know Your Ninja® Professional Frying System
a
f
c
d
g
e
b
h
READY
MINUTES
TIME
START/STOP
TEMP
+
PRÊT
˚F ˚C
F300_15_F300C_15_IB_ENG_121114_3.indd 5 12-11-14 2:38 PM
6
www.ninjakitchen.com
The Ninja® Professional Frying System is an 1800W, high powered innovative tool with a sleek design and outstanding performance, a true asset to any kitchen. The revolutionary heat combination keeps oil at a uniform temperature, so food cooks light and crispy. For best results, be sure to carefully read all the instructions contained in the manual before using this appliance.
FEATURES:
• Patentpendingremovablefryerbasketwithfryerbasketlid
• Largestusablebasketcapacityperamountofoilrequired
• Coolzonetechnologyhelpspreventfoodparticlesfromburningandhelpskeepoilclean
• DeepFryerLidwithglasswindowforeasyviewing
• DigitalLCDdisplaywithcountdowntimer
• Powerful1800wattsimmersionelementprovidesquickheatingandfastoiltemperature
recovery
• ElectronicControlPanel
• Break-AwaySafetyPowerCorddesignedtoeasilydetachfromthemainunitifaccidentallypulled
• Easytoremoveoilreservoir
F300_15_F300C_15_IB_ENG_121114_3.indd 6 12-11-14 2:38 PM
7
TOLL FREE: 1-877-646-5288
CLEAN BEFORE FIRST USE
1 Remove all packaging material and any
stickers. Read all literature.
2 Wash the fryer housing, lid, oil reservoir, fryer
basket, fryer basket lid and detachable handle in hot, soapy water and wipe dry thoroughly. The deep fryer lid and oil reservoir are dishwasher safe. Dry all the parts thoroughly before adding oil.
WARNING: DO NOT immerse the control panel or the break-away safety power cord in water. Do not put the control panel or the break-away safety power cord in the dishwasher.
WARNING: All components must be
completely dry before filling the reservoir with oil.
ASSEMBLY & SETUP
WARNING: Never plug the deep fryer into
the electrical outlet while the oil reservoir is empty.
1 Make sure that the oil reservoir is inside the
housing of the deep fryer. Hold the control panel with the heating element and insert the guide edges on the control panel into the guide rails mounted on the back of the deep fryer housing. (Fig. 1) Slide the guide edges down as far as they will go.
NOTE: Your deep fryer has an automatic safety switch to ensure that the appliance will not operate unless the control panel is inserted securely into the guide rails on the back of the deep fryer housing.
2 Attach the fryer basket handle to the fryer
basket by pinching the metal ends together so that they will fit into the metal bracket on the inside of the fryer basket. (Fig. 2)
3 Hold the fryer basket securely in one hand
and lift the fryer basket handle with the other hand to lock in place. (Fig. 3, Fig. 4)
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Using Your Ninja® Professional Frying System
F300_15_F300C_15_IB_ENG_121114_3.indd 7 12-11-14 2:38 PM
8
www.ninjakitchen.com
TIME
START/STOP
TEMP
+
ATTACHING THE BREAK-AWAY SAFETY POWER CORD
1 Plug the break-away safety power cord into
the back of the deep fryer. Make sure the top of the plug reads ‘THIS SIDE UP’. You will feel a magnetic pull if installed correctly. (Fig. 6)
WARNING: The break-away safety power cord is intended to prevent the tipping of the appliance and hazardous spillage of hot oil. It is NOT intended to disconnect the fryer during normal use.
WARNING: DO NOT attempt to defeat the magnetic cord connection by attempting to permanently attach the power cord to the deep fryer.
WARNING: Use only the break-away safety power cord provided with the deep fryer. Use of any other magnetic cord could cause fire, electric shock or injury.
WARNING: DO NOT come in contact with the magnetic connection on the break-away safety power cord while it is plugged into the electrical wall outlet. Injury can occur.
FILLING THE OIL RESERVOIR
It is recommended to use oils such as; vegetable, canola or peanut oil. Oils such as olive oil or extra virgin olive oil should not be used and are not ideal for deep frying.
1 Pour cooking oil into the reservoir until the
oil level is at the “FILL” line on the inside of the oil reservoir. For best results, keep the oil close to the “FILL” line. Ensure that the heating element is installed prior to adding oil. For best results, keep the oil close to the “FILL” line. DO NOT exceed the “FILL” level. (Fig. 5)
NOTE: DO NOT use olive oil, margarine, lard or drippings. DO NOT mix old and new oil together.
WARNING: Only turn on the unit if oil is
present in the oil reservoir and filled properly.
Fig. 5
Fig. 6
NOTE: Your deep fryer has been specifically designed with your safety in mind and is equipped with a unique break-away safety power cord. This break-away safety power cord is designed to detach from the fryer in the event that the power cord or fryer is inadvertently pulled or tugged.
F300_15_F300C_15_IB_ENG_121114_3.indd 8 12-11-14 2:38 PM
9
TOLL FREE: 1-877-646-5288
PROGRAMMING THE PROFESSIONAL FRYING SYSTEM
IMPORTANT: Always place the deep fryer on a
flat, heat resistant surface.
1 Press the TEMP button once and then the “+/-”
buttons to select the desired frying temperature. Use the “+/-” buttons to increase or decrease the temperature in 25°F increments. The temperature is adjustable from 275°F to 375°F.
2 The LCD display on the control panel will show
the temperature.
3 Press the TIME button once and then the “+/-”
buttons to set the desired cooking time. Use the “+/-” buttons to increase or decrease the time in 1 minute increments for up to 30 minutes. Holding down the “+” button will add minute increments at a faster rate to reach the 30 minute set point faster. (Fig. 7)
4 Press the START/STOP button to begin
preheating the oil.
5 When the selected temperature is reached, the
unit will beep and the LCD display will show “RE A DY ”.
WARNING: DO NOT use any type of outlet
other than a polarized electrical outlet. NOTE: To change the temperature reading from
Fahrenheit (°F) to Celsius (°C) press both the “+” and “-” at the same time for 3 seconds and the display will change accordingly.
WARNING: Never leave the appliance
unattended while in use.
FILLING THE FRYER BASKET
WARNING: DO NOT use Ninja® Professional
Frying System without the fryer basket as food may adhere to the heating element and burn.
WARNING: Always remove and replace the
fryer basket carefully.
1 When frying frozen foods, it is suggested
that you fill the fryer basket outside of the oil reservoir. Align the removable fryer basket lid into the fryer basket and lock into place. Then gently lower the fryer basket into the oil for cooking. To minimize splattering, hold the deep fryer lid over the fryer basket as you lower it into the oil. (Fig. 8)
2 When frying battered foods, it is suggested
that the fryer basket be placed inside the oil reservoir. Be sure to wear mitts to protect against splattering. Using tongs, place each piece of food into the fryer basket individually and hold in the oil for at least 3 seconds before releasing into the fryer basket. This helps prevent the food from sticking to the basket. Once all the food is in the fryer basket, align the fryer basket lid and lock in place.
3 When the desired cooking is complete, carefully
lift the fryer basket out of the oil and hook it onto the edge of the oil reservoir to drain. Always hold the basket by the cool touch handle. (Fig. 9)
4 Always use the fryer basket lid when frying.
Insert the fryer basket lid into the opening at the front of the fryer basket and then push it down to lock in place on the basket handle. (Fig. 10)
READY
MINUTES
TIME
START/STOP
TEMP
+
PRÊT
˚F ˚C
Fig. 7
Fig. 9
Fig. 10
Fig. 8
F300_15_F300C_15_IB_ENG_121114_3.indd 9 12-11-14 2:38 PM
10
www.ninjakitchen.com
EMPTYING THE DEEP FRYER
IMPORTANT: Change oil frequently.
1 Make sure the deep fryer is turned off,
unplugged, and has cooled to room temperature before attempting to empty the oil.
2 Remove the deep fryer lid and fryer basket.
3 Carefully pour the oil from the reservoir into
an appropriate container. (Fig. 11)
IMPORTANT: DO NOT mix different oils or
new and old oil together.
Fig. 11
5 Place food carefully into the fryer basket. DO
NOT over fill the basket. Use the fryer basket lid
as an indicator for the maximum food load. The fryer basket lid should close easily with the food loaded.
IMPORTANT: Make sure that the food to be
fried is dry and free of excess moisture.
CAUTION: When frying frozen foods, be sure
to clean off any ice and remove excess moisture from the food before placing in the fryer basket. Failure to do so may cause the oil to splatter or overflow.
FRYING FOOD
CAUTION: Hot oil can cause severe injury.
1 When the desired temperature is reached,
lower the filled fryer basket into the heated oil slowly and carefully. Lowering the basket too quickly can result in the oil splattering and may cause burns. DO NOT drop the fryer basket into the oil.
2 Replace the deep fryer lid and set the timer
for the desired frying time.
CAUTION: It is normal for steam to escape through the sides of the lid while frying.
3 Use the viewing window to monitor your
food. To avoid burns, never place your hands above the deep fryer lid or the deep fryer itself while in use. When lifting the deep fryer lid, always lift away from you to allow the steam to escape.
CAUTION: Be careful with condensation from the deep fryer lid falling into the oil which may cause splattering.
4 Lift the fryer basket out of the oil and hook it
on the edge of the oil reservoir to allow the food to drain.
5 Remove the fryer basket lid and then the food
from the fryer basket either with tongs or by pouring the food into a serving container or onto a plate covered with paper towels.
6 When you have finished using your deep
fryer, press the Start/Stop button to turn the deep fryer off.
7 Unplug the deep fryer from the wall outlet
and allow to cool to room temperature before attempting to remove the oil or clean the deep fryer.
WARNING: Never use the break-away safety power cord to turn the deep fryer off.
WARNING: If the magnetic plug becomes disconnected from the unit during operation,
immediately unplug the break-away safety power cord by the plug from the
outlet. Do not attempt to reconnect the magnetic plug to the deep fryer unit.
WARNING: Never use your deep fryer to boil water.
F300_15_F300C_15_IB_ENG_121114_3.indd 10 12-11-14 2:38 PM
11
TOLL FREE: 1-877-646-5288
FOOD
ASPARAGUS
GREEN BEANS
TORTILLA CHIPS
ZUCCHINI
EGGPLANT
MUSHROOMS
CHICKEN PIECES (battered)
CHICKEN STRIPS
SHRIMP (raw, battered)
FISH CAKES or PIECES
FISH FILLETS (battered)
ONION RINGS
FRENCH FRIES (thick)
FRENCH FRIES (thin)
POTATO WEDGES
EGG ROLLS (small)
FRUIT FRITTERS
SUGGESTED FRYING GUIDE
NOTE: The cooking times and temperatures in this chart are a guide only and should be adjusted to suit the
quantity of food being deep fried and your personal preferences. In general, use lower settings for delicate foods (vegetables, fish) and higher settings for frozen foods, French Fries and chicken.
APPROX. COOKING TIME
2-3 minutes
2-3 minutes
1-2 minutes
3-4 minutes
3-4 minutes
3-4 minutes
10-14 minutes
3-4 minutes
3-4 minutes
4-6 minutes
5-7 minutes
2-4 minutes
8-10 minutes
4-6 minutes
4-5 minutes
4-5 minutes
2-4 minutes
FRYING TIPS
For best cooking results, take note of these helpful tips:
• DONOT mix different oils or new and old oil together.
Deep frying at a high temperature ensures the best results. Speedy frying and searing of the exterior of foods to retain the foods moisture.
Make sure that the food to be fried is dry and free of excess moisture.
When frying frozen foods, be sure to clean off any ice or moisture from the food before placing in the fryer
basket. Fill the fryer basket with food, insert basket lid, place deep fryer lid over the basket and lower into the oil to minimize oil spattering.
To cook evenly, pieces of food should be the same size and thickness. Thicker pieces will take longer to cook.
Always use the fryer basket lid when frying to keep the food submerged in the oil for better fried results.
Do not fry small foods that will fall through the fryer basket.
Do not overload the fryer basket with food.
Follow recommended recipes and cooking portions.
Always make sure the fryer basket and lid are clean, dry and in good working order prior to use.
350°F 177°C
350°F 177°C
350°F 177°C
375°F 191°C
375°F 191°C
325°F 163°C
350°F 177°C
350°F 177°C
375°F 191°C
375°F 191°C
350°F 177°C
375°F 191°C
375°F 191°C
375°F 191°C
350°F 163°C
350°F 163°C
350°F 163°C
TEMPERATURE
F300_15_F300C_15_IB_ENG_121114_3.indd 11 12-11-14 2:38 PM
12
www.ninjakitchen.com
CLEANING INSTRUCTIONS
1 Make sure the deep fryer is turned off,
unplugged and has cooled to room temperature.
2 Remove the deep fryer lid and wash it and the
fryer basket in hot, soapy water and wipe dry thoroughly. The fryer lid may be washed in the dishwasher.
3 Clean the control panel with a damp cloth
ONLY.
4 Empty the oil from the reservoir. Wash the
oil reservoir in hot, soapy water. The oil reservoir may be washed in the top rack of the dishwasher.
5 Dry the oil reservoir thoroughly.
WARNING: DO NOT immerse the control panel or break-away safety power cord in water. Do not put the control panel or break-away safety power cord in the dishwasher.
WARNING: DO NOT use any type of abrasive
pad or steel wool to clean the power cord magnetic socket.
WARNING: DO NOT use alcohol or cleaning solutions to clean the deep fryer.
HOW TO STORE SAFELY
1 Ensure that your deep fryer is turned off,
unplugged, cooled and clean.
2 Store the fryer basket with the removable
fryer basket lid inside the deep fryer and replace the lid.
3 Detach the break-away safety cord from the
unit and store along with the deep fryer.
4 Store your deep fryer on a flat surface in a
cool dry area where it will be safe from being tipped over and won’t be damaged or be hazardous to anyone or anything.
HOW TO RESET THE DEEP FRYER
Your deep fryer is equipped with a reset feature. If for some reason the deep fryer stops heating, the reason may be that the reset switch has tripped. To reset the deep fryer:
1 Unplug the break-away safety power cord
from the outlet and remove the magnetic plug from the deep fryer.
2 Push the thermostat reset button located on
the back of the control panel with a ball point pen or pencil. (Fig. 12)
3 Plug in the break-away safety power cord to
the outlet, then attach the magnetic plug to the unit. The appliance will beep and the LCD display will turn on.
4 Reprogram the time and the temperature and
resume cooking.
TROUBLESHOOTING
If your deep fryer fails to operate, follow these instructions:
1 Make sure the plug is securely plugged into
the electrical outlet.
2 Check to see if the magnetic end of the
break-away safety power cord is attached to the unit. If it is not, FIRST unplug the cord from the wall, then attach the magnetic end of the plug to the unit, and then plug back into the wall.
3 Make sure the electrical outlet is working.
Unplug the unit, check your fuse box or circuit breaker box and replace the fuse or reset the breaker as necessary, then plug the unit back in.
4 If the problem persists, contact Customer
Service at 1-877-646-5288, Monday to Friday between 8:30 A.M. - 5:00 P.M. Eastern Standard Time, or visit our website at: www.ninjakitchen.com.
Fi g . 12
Cleaning & Storing Your Ninja®
Professional Frying System
F300_15_F300C_15_IB_ENG_121114_3.indd 12 12-11-14 2:38 PM
13
TOLL FREE: 1-877-646-5288
Notes
F300_15_F300C_15_IB_ENG_121114_3.indd 13 12-11-14 2:38 PM
14
www.ninjakitchen.com
ProductRegistration
Please visit www.ninjakitchen.com or call 1-877-646-5288 to register your new Ninja
®
product
within ten (10) days of purchase. You will be asked to provide the store name, date of purchase and
model number along with your name and address.
The registration will enable us to contact you in the unlikely event of a product safety notification. By
registering you acknowledge to have read and understood the instructions for use, and warnings set forth
in the accompanying instructions.
ONE (1) YEAR LIMITED WARRANTY
EURO-PRO Operating LLC warrants this product to be free from material defects and workmanship for
a period of one (1) year from the date of purchase when utilized for normal household use, subject to the following conditions, exclusions and exceptions.
The liability of EURO-PRO Operating LLC is limited solely to the cost of the repair or replacement of the unit at our option. This Limited Warranty does not cover normal wear of parts and does not apply to any unit that has been tampered with or used for commercial purposes. This Limited Warranty does not cover damage caused by misuse, abuse, negligent handling or damage due to faulty packaging or mishandling in transit. This Limited Warranty does not cover damage or defects caused by or resulting from damages from shipping or repairs, service or alteration to the product or any of its parts, which have been performed by a repair person not authorized by EURO-PRO Operating LLC.
If your appliance fails to operate properly while in use under normal household conditions within the warranty period, return the complete appliance and accessories, freight prepaid. For assistance with warranty service options or customer support, please call our customer care and product specialists at , call 1 (877) 646-5288 or visit our website www.ninjakitchen.com.
If the appliance is found to be defective in material or workmanship, EURO-PRO Operating LLC will repair or replace it free of charge. Proof of purchase is required and a fee of $19.95 will apply to cover the cost of return freight. *
This Limited Warranty is extended to the original purchaser of the unit and excludes all other legal, implied and/ or conventional warranties. The responsibility of EURO-PRO Operating LLC if any, is limited to the specific obligations expressly assumed by it under the terms of this Limited Warranty. In no event is EURO-PRO Operating LLC liable for incidental or consequential damages to anyone of any nature whatsoever. Some states do not permit the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
This Limited Warranty gives you specific legal rights, and you may also have other rights which vary from state to state or from province to province.
*IMPORTANT: Carefully pack item to avoid damage in shipping. Be sure to include proof of purchase date and to attach tag to item before packing with your name, complete address and phone number with a note giving purchase information, model number and what you believe is the problem with the item. We recommend you insure the package (as damage in shipping is not covered by your Limited Warranty). Mark the outside of your package “ATTENTION CUSTOMER SERVICE”. We are constantly striving to improve our products, therefore the specifications contained herein are subject to change without notice.
F300_15_F300C_15_IB_ENG_121114_3.indd 14 12-11-14 2:38 PM
Euro-Pro Operating LLC US: Newton, MA 02459 CAN: Ville St-Laurent, QC H4S 1A7
1-877-646-5288
www.ninjakitchen.com
Copyright © 2012 Euro-Pro Operating LLC
Printed in China
Illustrations may differ from actual product.
F300-F300C.E.121114.3
F300_15_F300C_15_IB_ENG_121114_3.indd 15 12-11-14 2:38 PM
Loading...
