Ninja BL665Q, BL665QBK, BL665QCN, BL665QWH Owner's Manual

BL665Q series
®
OWNER’S GUIDE
ninjakitchen.com
1 877 646-5288
IMPORTANT SAFETY INSTRUCTIONS
WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING YOUR NINJA® KITCHEN SYSTEM.
POLARIZED PLUG
3 WARNING: Stacked Blade Assembly
4 WARNING: Chopping Blade Assembly
WARNING: To reduce the risk of
electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. DO NOT modify the
plug in any way.
5 CAUTION: Do not blend hot liquids,
WARNING: Extension cords are
not recommended for use with this product.
6 CAUTION: We do not recommend
7 CAUTION: Remove the Nutri Ninja
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
1 WARNING: Remove utensils prior to
processing. Failure to remove may cause the jar to be damaged or to shatter which may cause personal injury.
2 WARNING: Stacked Blade Assembly
is sharp, not locked in place and removable, handle with care. When handling the Stacked Blade Assembly always hold by the shaft. Failure to do so will result in a risk of laceration.
8 To protect against electrical shock, do not
9 DO NOT allow the appliance to be used by
is sharp and not locked in place. If using the pour spout, ensure the lid is fully locked onto the pitcher. If pouring with the lid removed, carefully remove the Stacked Blade Assembly first, holding it by the shaft. Failure to do so will result in a risk of laceration.
is sharp and not locked in place. Make sure to carefully remove lid and Chopping Blade Assembly, holding it by the shaft, before emptying contents. Failure to do so will result in a risk of laceration.
doing so may cause excessive pressure build-up, resulting in risk of the user being burned.
grinding in any of our Nutri Ninja
Blades Assembly from the Nutri Ninja Cup upon completion of blending. Do not store ingredients before or after blending them in the cup with the blade assembly attached. Some foods may contain active ingredients or release gases that will expand if left in a sealed container, resulting in excessive pressure buildup that can pose a risk of injury.
submerge the appliance or allow the power cord to come into contact with water or any other liquid.
children. Close supervision is necessary when used near children. This is not a toy.
®
cups.
1
1-877-646-5288
10 Never leave an appliance unattended when
inuse.
11 Appliance accessories are not intended to
be used in the microwave as it may result in damage to the accessories.
12 Turn the appliance Off and remove the
power cord from the electrical outlet when not in use, before assembling or disassembling parts and before cleaning. To unplug, grasp the plug and pull from the electrical outlet. Never pull from the power cord.
13 DO NOT abuse the power cord. Never carry
the appliance by the power cord or yank it to disconnect from electrical outlet; instead grasp the plug and pull to disconnect.
14 DO NOT operate any appliance with a
damaged cord or plug, or after the appliance malfunctions, has been dropped or damaged in any manner. This appliance has no serviceable parts. Return the appliance to SharkNinja Operating LLC for examination, repair or adjustment.
15 DO NOT let the power cord hang over
the edge of table or counter or touch hot surfaces such as the stove.
16 Always use appliance on a dry, level surface. 17 Keep hands, hair, clothing, as well as
utensils out of container while processing to reduce the risk of severe injury to persons or damage to the appliance. A scraper may be used but only when the appliance is not running.
18 Avoid contact with moving parts. 19 DO NOT attempt to sharpen blades. 20 DO NOT use the appliance if blade
assemblies are bent or damaged.
21 To reduce risk of injury, never place the
blade assemblies on the base without the pitcher or Nutri Ninja® cup properly attached.
22 DO NOT operate this appliance on or near
any hot surfaces (such as gas or electric burner or in a heated oven).
23 The use of attachments or accessories
including canning jars, not recommended by the manufacturer may result in fire, electric shock or personal injury.
24 DO NOT remove the container from the
motor base while the appliance is in operation.
25 To reduce the risk of injury, NEVER operate
the appliance without the lid in place; DO NOT try to defeat the interlock mechanism; make sure that the attachment is properly installed before operating the appliance.
26 DO NOT expose containers to extreme
temperature changes.
27 DO NOT overfill. 28 DO NOT operate the appliance empty. 29 If the appliance overheats, a thermal switch
will become activated and shut off the motor. To reset, unplug the appliance and let it cool down for approximately 15 minutes before using again.
30 THIS PRODUCT IS INTENDED FOR
HOUSEHOLD USE ONLY. Do not use
this appliance for anything other than its intended use. Do not use outdoors.
31 The maximum rating is based on the
Stacked Blade Assembly (pitcher) that drives the greatest power and other recommended attachments may draw significantly less power or current.
INSTRUCTIONS
SAVE THESE
ninjakitchen.com
2
THIS BOOK COVERS MODEL NUMBER:
BL665QBK BL665QCN BL665QWH
TECHNICAL SPECIFICATIONS
Voltage: 120V., 60Hz. Power: 1200 Watts
Pitcher Capacity: 72 oz. (9 cups, 2.15 L)
MAX Liquid Capacity: 64 oz. (8 cups, 1.9 L) Bowl Capacity: 64 oz. (8 cups, 1.9 L) Nutri Ninja® Cup Capacity: 16 oz. (2 cups, 470 ml)
3
1-877-646-5288
Contents
Thank you for purchasing the Ninja® Kitchen System.
Getting to Know Your Ninja Kitchen System ........................................................................... 5
Before First Use .................................................................................................................. 7
Assembly & Use of the Pitcher ............................................................................................. 8
Assembly & Use of the Nutri Ninja® Cup ............................................................................ 10
Assembly & Use of the Food Processor Bowl ...................................................................... 11
Using the Chopping Blade Assembly ................................................................................ 12
Using the Dough Blade Assembly .................................................................................... 12
Removing the Dough Station ........................................................................................... 12
Care & Maintenance ........................................................................................................ 13
Speed Chart .................................................................................................................... 14
Troubleshooting Guide ....................................................................................................... 15
Replacement Parts ............................................................................................................ 15
Warranty & Registration ..................................................................................................... 18
ninjakitchen.com
4
Getting To Know Your Ninja® Kitchen System
a
b
c
d
e
f
g
h
i
j
k
a To-Go Lid (x2)
b Chopping Blade Assembly
c Dough Blade Assembly
d Nutri Ninja® Cup
e Stacked Blade Assembly
f Pitcher Lid with Locking Handle
g Bowl Lid with Locking Handle
h 72 oz. Pitcher
NOTE: Attachments are not interchangeable.
5
1-877-646-5288
l
m
i 64 oz. Food Processor Bowl
j Gear Shaft
k Nutri Ninja Blade Assembly
l Motor Base
m Dough Station
n Power Cord (not shown)
o Cord Storage (in back) (not shown)
