Congratulations!
You are now the proud owner of one of the most versatile keyboard amplifiers available, the Crate KX-220
Four Channel Stereo Keyboard Amplifier. This incredible unit features Crate’s legendary performance and high
quality construction in a rugged and easy to operate package.
Your KX-220 is proudly made in America, using only the best components. Extensive testing and Crate’s
Five-Year Warranty assure you that your new amplifier is the absolute best it can be. In order to get the most
out of it, we strongly urge you to read this manual before using the amplifier.
And thank you
for choosing
Table of Contents:
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
The Top Panel . . . . . . . . . . . . . . . . . . . . . . . . .4
The Back Panel . . . . . . . . . . . . . . . . . . . . . . . .5
Sample Hookup Diagram . . . . . . . . . . . . . . . . .6
System Block Diagram . . . . . . . . . . . . . . . . . . .7
Technical Specifications . . . . . . . . . . .back cover
KX-220 Stereo Keyboard Amplifier
3
KX-220 Stereo Keyboard Amplifier
Features:
Below are some of the outstanding features which set the KX-220 in a class by itself. Additional information on
these features can be found throughout the remainder of this manual.
•Complete stereo circuitry all the way to the internal power amplifier
•Four separate input channels, each with its own level, pan and
reverb/effect send controls
•Three stereo line level channels, each with 1/4” left and right/mono
input jacks
•One “dual mono” channel, with a 1/4” instrument and an XLR
microphone input jack, plus a two band EQ
•Line out select switches (channels 3 and 4) – keeps those channels
out of the external mix if desired
•Eight band stereo graphic EQ for total tone control
•Master level, effects return, reverb return, and line out level controls
•Internal spring reverb
•Stereo effects loop for external effects
•Stereo line out jacks for connecting to a mixing board, recording
unit, or PA system
•Stereo preamp out jacks for connecting to additional amplifiers
•Power amp in jack (use two KX-220’s for total stereo performance)
• Built in power amp limiter for clean sound at full output
• Rugged construction and easily accessed controls
• Removable casters for greater mobility
• Crate’s exclusive Five Year Warranty (where applicable)
4
KX-220 Stereo Keyboard Amplifier
The Top Panel:
5
KX-220 Stereo Keyboard Amplifier
The Rear Panel:
15
15
15
16
17
18
19
23
22
21
24
20
15: Input Jacks (channel 1–3): Connection of an instrument,
drum machine, tape deck channel, microphone or other
high impedance (balanced or unbalanced) line level signal
with 1/4” plug can be made here. For stereo inputs use the
right/mono jack for the right channel input and the left jack
for the left channel input. For two mono inputs into one
channel, use the right/mono jack for one and the left jack for
the other. For a single mono input into one channel, use the
right/mono jack only.
16: Instrument Input Jack (channel 4): Connection of an instru-
ment (such as a bass guitar) can be made here.
17: Microphone Input Jack (channel 4): Connection of a low
impedance microphone can be made here. This XLR jack
carries +16 volts phantom power on pins 2 and 3.
18: Effects Loop: Connection of an external effects unit can be
made here. Plug a signal cable from the amplifier’s send jack
to the unit’s input jack. Plug another cable (or, for stereo
effects, a pair of cables) from the effect unit’s output jack(s) to
the amplifier’s return jack(s). (Mono effects connect into the
jack labeled right/mono.) The level of the effects can be controlled by the channel rev/eff send controls (#3) and the
effects return control (#11).
19: Line Out Jacks: These pre-eq jacks allow connection to a
mixing board, recording unit, or house PA system. (These are
non-balanced output jacks.)
20: Preamp Out Jacks: These post-eq jacks allow connection to
an external power amp. When a plug is inserted into the left
preamp out jack, the amplifier’s left channel signal is interrupted from its internal power amp and is routed only
through the jack. This allows you to achieve a true stereo
output if you connect your main KX-220’s left preamp out
jack to a second KX-220’s power amp input jack (see #21).
21: Power Amp Input Jack: Connection directly into the KX-
220’s internal power amplifier is possible through this jack.
The amp will ignore any other input signals, all control settings and any external effects, and will only amplify the signal sent into the power amp input jack.
22: External Speaker Jack: Connection to an extension speaker
cabinet can be made here. The extension cabinet must have
a minimum impedance of 4 ohms. This jack is in parallel
with the internal speakers and using this jack does not disconnect them.
23: Power Switch: Turns the amplifier on (I) and off.
24: AC Line In: Connect the AC power cord here. Be sure the
cord is properly plugged into a safely wired, grounded 120
volt, 60Hz AC power outlet before use. (If your amplifier
was purchased outside the United States, refer to the rear
panel for power ratings.) For your safety, never attempt to
defeat the ground connection on this cord.
6
KX-220 Stereo Keyboard Amplifier
Sample Hookup Diagram:
In the diagram below, the two mono keyboards are both connected into channel 1. The channel 1 pan control lets you
adjust the relative level between the two signals. The metronome plugged into channel 3 may be heard through the amplifier but not the house sound system if the line out select switch is pressed in. A stereo effects device has been connected
to the effects loop, although a mono device can also be used. An additional KX-220 has been connected to the left channel preamp out jack, to achieve a true stereo output.
7
System Block Diagram:
RIGHT/MONO
INPUT
REV/EFF
SEND
LEFT
INPUT
LEVEL
PAN
MAIN
BUS
REV/
EFF
SEND
BUS
RL
LINE
OUT
BUS
RL
MAIN
BUS
REV/
EFF
SEND
BUS
RL
LINE
OUT
BUS
RL
LINE OUT
RIGHT/MONO
LINE OUT
LEFT
LINE OUT
LEVEL
PREAMP OUT
RIGHT/MONO
POWER
AMP IN
POWER
AMP
CROSSOVER
LIMITER
PREAMP OUT
LEFT
EXTERNAL
SPEAKER
RIGHT/MONO
INPUT
REV/EFF
SEND
LEFT
INPUT
LEVEL
PAN
RIGHT/MONO
INPUT
REV/EFF
SEND
LEFT
INPUT
LEVEL
LOW HIGH
LINEOUT
SELECT
PAN
LINE OUT
SELECT
REVERB
REVERB
RETURN LEVEL
LOW-Z
MIC
INPUT
REV/EFF
SEND
HIGH-Z
INPUT
PAN
EFF
SEND
EFF RET
RIGHT/MONO
EFF RET
LEFT
EQ
+16V PHANTOM POWER
PEAK LED
GAIN
GAIN
MASTER
RIGHT CHANNEL EQUALIZER
LEFT CHANNEL EQUALIZER
EFF RETURN
LEVEL
KX-220 Stereo Keyboard Amplifier
www.crateamps.com
©1999 SLMElectronics, Inc. • A Division of St. Louis Music, Inc.
1400 Ferguson Avenue • St. Louis, MO 63133
47-046-01 • 02/99
KX-220 Stereo Keyboard Amplifier
Technical Specifications
Due to ongoing product development and improvement, the specifications
contained herein are subject to change without notice.
Output Power Rating 160 watts RMS minimum @5% THD @ 4 ohm internal speaker
220 watts RMS with 4 ohm extension speaker
Maximum Signal Accepted Channels 1,2,&3 Right/mono / Left: 6 volts peak to peak
Channel 4 Instrument: 28 volts peak to peak; Microphone: 4 volts peak to peak
Effects Return Right/mono: 27 volts peak to peak; Left: 27 volts peak to peak
Nominal Input Impedance Channels 1,2,&3 Right/mono / Left: 22k ohm
Channel 4 Instrument: 220k ohm; Microphone: 600 ohm
Gain Channels 1,2,&3 Right/mono / Left: 30dB
Channel 4 Instrument: 37dB; Microphone: 64dB
Power Amp 36dB
Channel 4 EQ Low: ±10dB @ 50Hz; High: ±10dB @ 10kHz
Master EQ ±12dB @ 40Hz, 100Hz, 225Hz, 625Hz, 1.6kHz, 4kHz, 8kHz, 16kHz
Line Out/Line In Levels 1 volt RMS typical
Input Power Requirements 120 VAC, 60Hz, 205VA
100/110 VAC, 50/60Hz, 205VA
230 VAC, 50/60Hz, 205VA
Limiter Range 20dB, maximum distortion 1%
Speaker Specifications Low Frequency 15” Crate Custom Design, 2.5” voice coil, 56 oz. magnet
High Frequency 4”x4” Bullet Horn, 1” voice coil, replaceable phenolic diaphragm,
8 oz. magnet
Size and Weight 20.5” H* x 20.5” W x 17.5” D; 73 lbs (*add 1.5” for casters)
