NILFISK Advolution 20 User Manual

Advolution

20 & 20XP

Cord Electric Burnishers

™

Smart cleaning.

A Nilfisk-Advance Brand

Advolution

™

20 inch High Performance Burnishers.

20 & 20XP

Cord Electric Burnishers

The Advolution™ 20 and 20XP cord-electric burnishers from Advance

are designed to maximize performance, productivity, and operator

ease. Both models feature the unique Flex Floor™ Technology – based

on a patented, pintle-mounted motor design – that enables the motor

to pivot and hug the contours of the floor’s surface. The Advolution

also utilizes a patented gas spring technology that precisely regulates

the head pressure for a maximum shine on floor surfaces, regardless

of the operator’s previous burnisher experience. This exclusive patent

also enables the machine to be smaller, more maneuverable, and

requires virtually no training.

Advance had uncompromised facility safety in mind when it added

a 75 foot safety yellow, SuperFlex™ cord and a hospital-grade plug.

The SuperFlex cord is secured with a quick-release rotating cord hook

which allows the operator to release all 75 feet of the cord at once

to save time and effort. Another key safety feature is the SafeStart™

function which requires the handle to be in the operating position

before the machine can be started. This helps to prevent unmanned

use of the burnisher. Operating at less than 67 dB A, the volume of

standard conversation, the Advolution 20 & 20XP burnishers are

perfect for daytime burnishing.

Ideal applications include:

• Healthcare Facilities

• Hotels / Hospitality

• Schools

• Religious Facilities

• Government Facilities

• Grocery Stores

• Retail Facilities

The space-saving EZ Store™ handle minimizes the storage space

necessary for the Advolution 20 & 20XP burnishers. While in the EZ

Store space-saving position, the operator has easy access to check

wear or replace the burnishing pad.

The Advolution 20 has a 20 inch burnishing surface which runs at

1,500 rpm. The Advolution 20XP is a 20 inch dust control model that

runs at 2,000 rpm. The powerful suction on the Advolution 20XP sends

all of the burnishing dust into the unit’s dual-port dust bag and not into

the air. This provides total dust control for improved indoor air quality,

while operating at higher speeds, to protect the health of the operators

and facility occupants. When using the Advolution 20XP, operator

productivity is increased by eliminating the need for dust mopping

after burnishing.

A Nilfisk-Advance Brand

Red SafeStart™ button only

allows activation when handle

is tilted back for use

Electrically

detachable motor for

easy service access

75 foot SuperFlex™

safety yellow cord with

hospital grade plug

Patented gas spring technology provides for
consistent results regardless of the operator.

Simple, one step handle release.

Rotomolded body provides lasting durability.
Dust bags are easy to access.

Carbon brush

replacement

indicator light

Easy access

to change
dust bags

Maintenance free

transmission and

direct drive motors

Rotating cord hook lets 75 feet
of cord be removed at one time.

Flexible pad

driver

Rotating

cord hook

saves time

and effort

Wrap-around skirt

seals tightly to floor

to control dust

EZ Store™ construction makes for easy
pad changing.

EZ Store™ construction allows the Advance
Advolution™ 20 and 20XP to be stored in
the smallest of cleaning closets.

Red SafeStart™ button only
operates in operator position.

Carbon brush indicator lights
red when brushes need to
be replaced.

Patented design enables machine to be more
maneuverable and easier to train on.

The direct drive transmission eliminates
adjustment of noisy belts, bearings
and pulleys.

Rotomolded body provides lasting
durability.

Low sound level permits
operation anywhere
anytime.

FEATURES AND BENEFITS

Technical Specifications

Model Advolution™ 20 Advolution™ 20XP
Angle Activated Safety Switch Yes Yes
Safety Yellow Cord Yes Yes
Hospital Grade Plug Yes Yes
Maintenance Free Transmission Yes Yes
Motor Protection Indicator Light Yes Yes
Folding Handle Yes Yes
Factory Assembled Yes Yes
Sound Level 62.1 dB A 66.5 dB A
Pad Size 20 in 20 in
Pad Speed 1,500 R.P.M. 2,000 R.P.M.
Transmission Direct Drive Direct Drive
Construction Rotomolded Rotomolded
Motor 1.5 hp 1.5 hp
Cord 75 ft (23 m) 75 ft (23 m)
Height 45.5 in (116 cm) 45.5 in (116 cm)
Width 24 in (61 cm) 24 in (61 cm)
Minimum Depth 16.5 in (42 cm) 16.5 in (42 cm)
Maximum Depth 28 in (71 cm) 32 in (81 cm)
Weight 85 lb (39 kg) 87 lb (39 kg)
Part Number 01510A 01520A

Specifications are subject to change without notice.

Advolution™ 20 & 20XP

Consistent, High Gloss Performance with Easy Operation.

Standard features:

• Flex Floor™ Technology

• 75 foot Safety Yellow

• Dual Port Dust Bag (20XP)

• Rotating Cord Hook

SuperFlex™ Cord

• EZ Store™ Folding Handle

Smart cleaning.

Our products are designed using innovative technology that
increases productivity and drives down the cost to clean.

Maintain peak performance with Nilfisk Genuine OEM Parts.

14600 21st Avenue North

Plymouth, MN 55447-3408

www.advance-us.com

Phone [phone]

Fax [phone]

240 Superior Boulevard

Mississauga, Ontario, Canada L5T 2L2

www.nilfisk-advance.com

Phone [phone]

Fax [phone]

©2009 Nilfisk-Advance, Inc. Form L3014A 9-10-09

A Nilfisk-Advance Brand

www.advance-us.com
