NILFISK Adgility Parts List

Adgility
Printed in Hungary
SPARE PARTS LIST
www.mn.nilfisk-advance.com
822 2739 010
Edition 3 2006-10
SPARE PARTS LIST ADGILITY
05-10
LINE DRAWING
41
06-06
06-06
SPARE PARTS LIST ADGILITY
06-10
SPARE PARTS NUMBER
ItemNo Qty.* Part No Description Note
1 1 140 7343 000 Belt cpl.w.locking 3 10 140 9214 150 Screw P Torx 30x40 FZB 4 1 140 5496 510 Switch 5 1 140 6560 000 Anti strain clip UL-approved 6 4 140 9214 040 Screw 7 1 140 3859 050 Cord set, grounded colour:yellow Length 49 ft (15 m) 8 2 140 8092 500 Carbon brushes Kit with 2 brushes
9 4 140 6792 000 Spring 10 1 140 8166 010 Suppressor - Capicator 11 1 P 140 8077 530 Fan unit, 8.5A 1000W Kit w. wires, silencer incl. 11B 1 >> 147 1120 540 Fan unit, Ametek 8.5A 1000W Kit w. wires. 12 1 140 6633 010 Silencer UL-approved 13 1 140 6558 000 Insulation, silencer 14 1 140 4325 010 Grounding plate 15 1 140 6791 000 Gasket 16 1 140 6556 000 Insulation, cover 17 1 140 6448 030 Exhaust gable, grey 18 1 140 6597 000 Exhaust filter 18b 1 >> 140 6597 500 Exhaust filter 3 pcs 19 1 140 6426 030 Cover strip, grey 20 1 140 6443 050 Cover, grey UL-approved 21 6 140 6796 000 C-clip 22 3 140 6797 000 Spring nut 23 1 140 6798 000 Gasket 24 1 140 6446 030 Inner suction gable, grey 25 1 140 6447 030 Outer suction gable, grey 26 1 140 6699 030 Suction gable compl. grey 27 1 140 7302 000 Gasket 28 1 140 6554 010 Dust bag 5-pack 5 pcs. 28 1 140 6554 020 Dust bag 10-pack 10 pcs. 28 1 140 6554 040 Dust bag high filtration, 5-pack 5 pcs. 28 1 140 6554 050 Dust bag high filtration, 10-pack 10 pcs. 29 1 140 6794 010 Pre filter, 29c 1 140 7160 010 Hepa-filter, cpl. 29d 1 140 5666 000 Gasket 30 1 140 7148 010 Partition wall UL-approved 31 1 140 6799 000 Gasket 32 1 140 6557 000 Insulation, back
33 1 093 1027 010 Sleeve 35 1 140 6444 060 Back part, grey UL-approved 35 1 140 6906 040 Back part cpl. grey With nuts, UL-approved 36 2 140 7696 000 Washer 37 2 140 6559 010 Screw for belt 140 7343 000 38 1 140 5358 000 Insulation 39 1 140 6824 000 Filter holder 40 1 140 3894 000 Thermo protector 41 1 147 0808 510 Cord retainer clip
* Qty. means: The amount of the item that are enclosed with the Adgility machine.
>>
Means: New or changed ref. number or/and changed/new specifications.
P Means: Depleted when no longer on stock
