Nikon P100 User Manual
DIGITAL CAMERA
User’s Manual
En
Trademark Information
• Microsoft, Windows and Windows Vista are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
• Macintosh, Mac OS, and QuickTime are trademarks of Apple Inc.
• Adobe and Acrobat are registered trademarks of Adobe Systems Inc.
• SD and SDHC logos are trademarks of SD-3C, LLC.
• PictBridge is a trademark.
• HDMI, logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
• All other trade names mentioned in this manual or the other documentation
provided with your Nikon product are trademarks or registered trademarks of
their respective holders.
AVC Pate nt Por tfolio License
This product is licensed under the AVC Patent Portfolio License for the personal and
non-commercial use of a consumer to (i) encode video in compliance with the AVC
standard (“AVC video”) and/or (ii) decode AVC video that was encoded by a
consumer engaged in a personal and non-commercial activity and/or was
obtained from a video provider licensed to provide AVC video. No license is granted
or shall be implied for any other use. Additional information may be obtained from
MPEG LA, L.L.C.
See http://www.mpegla.com.
Introduction
First Steps
Basic Photography and Playback: A (Auto) Mode
More on Shooting
More on Playback
Editing Pictures
Movie Recording and Playback
Connecting to Televisions, Computers and Printers
Basic Camera Setup
Caring for the Camera
Technical Notes and Index
i
For Your Safety
To prevent damage to your Nikon product or injury to yourself or to others, read
the following safety precautions in their entirety before using this equipment.
Keep these safety instructions where all those who use the product will read them.
The consequences that could result from failure to observe the precautions listed
in this section are indicated by the following symbol:
This icon marks warnings, information that should be read before using this Nikon
product, to prevent possible injury.
WAR NIN GS
Turn off in the event of
malfunction
Should you notice smoke or an unusual
smell coming from the camera or
Charging AC Adapter, unplug the
Charging AC Adapter and remove the
battery immediately, taking care to
avoid burns. Continued operation could
result in injury. After removing or
disconnecting the power source, take
the equipment to a Nikon-authorized
service representative for inspection.
Do not disassemble
Touching the internal parts of the
camera or Charging AC Adapter could
result in injury. Repairs should be
performed only by qualified
technicians. Should the camera or
Charging AC Adapter break open as the
result of a fall or other accident, take the
product to a Nikon-authorized service
representative for inspection, after
unplugging the product and/or
removing the battery.
ii
Do not use the camera or
Charging AC Adapter in the
presence of flammable gas
Do not use electronic equipment in the
presence of flammable gas, as this
could result in explosion or fire.
Handle the camera strap with
care
Never place the strap around the neck
of an infant or child.
Keep out of reach of children
Particular care should be taken to
prevent infants from putting the
battery or other small parts into their
mouths.
For Your Safety
Observe caution when handling
the battery
The battery may leak or explode if
improperly handled. Observe the
following precautions when handling
the battery for use in this product:
• Before replacing the battery, turn the
product off. If you are using the
Charging AC Adapter/AC adapter, be
sure it is unplugged.
• Use only a Rechargeable Li-ion
Battery EN-EL5 (supplied). Charge the
battery by inserting it into the
camera and connecting the
Charging AC Adapter EH-68P/EH-68P
(AR) (supplied).
• When inserting the battery, do not
attempt to insert it upside down or
backwards.
• Do not short or disassemble the
battery or attempt to remove or
break the battery insulation or casing.
• Do not expose the battery to flame
or to excessive heat.
• Do not immerse in or expose to
water.
• Replace the terminal cover when
transporting the battery. Do not
transport or store with metal objects
such as necklaces or hairpins.
• The battery is prone to leakage when
fully discharged. To avoid damage to
the product, be sure to remove the
battery when no charge remains.
• Discontinue use immediately should
you notice any change in the battery,
such as discoloration or deformation.
• If liquid from the damaged battery
comes in contact with clothing or
skin, rinse immediately with plenty of
water.
Observe the following precautions
when handling the Charging AC
Adapter
• Keep dry. Failure to observe this
precaution could result in fire or
electric shock.
• Dust on or near the metal parts of
the plug should be removed with a
dry cloth. Continued use could result
in fire.
• Do not handle the plug or go near
the Charging AC Adapter during
lightning storms. Failure to observe
this precaution could result in
electric shock.
• Do not damage, modify, forcibly tug
or bend the USB cable, place it under
heavy objects, or expose it to heat or
flames. Should the insulation be
damaged and the wires become
exposed, take it to a Nikonauthorized service representative for
inspection. Failure to observe these
precautions could result in fire or
electric shock.
• Do not handle the plug or Charging
AC Adapter with wet hands. Failure
to observe this precaution could
result in electric shock.
• Do not use with travel converters or
adapters designed to convert from
one voltage to another or with DCto-AC inverters. Failure to observe
this precaution could damage the
product or cause overheating or fire.
iii
For Your Safety
Use appropriate cables
When connecting cables to the input
and output jacks, use only the cables
provided or sold by Nikon for the
purpose, to maintain compliance with
product regulations.
Handle moving parts with care
Be careful that your fingers or other
objects are not pinched by the lens
cover or other moving parts.
CD-ROMs
The CD-ROMs supplied with this device
should not be played back on audio CD
equipment. Playing CD-ROMs on an
audio CD player could cause hearing
loss or damage the equipment.
Observe caution when using
the flash
Using the flash close to your subject’s
eyes could cause temporary visual
impairment. Particular care should be
observed if photographing infants,
when the flash should be no less than
1 m (3 ft. 4 in.) from the subject.
Do not operate the flash with
the flash window touching a
person or object
Failure to observe this precaution could
result in burns or fire.
Avoid contact with liquid
crystal
Should the monitor break, care should
be taken to avoid injury caused by
broken glass and to prevent liquid
crystal from the monitor touching the
skin or entering the eyes or mouth.
Turn the power off when using
inside an airplane or the
hospital
Turn the power off while inside the
airplane during take off or landing.
Follow the instructions of the hospital
when using while in a hospital. The
electromagnetic waves given out by
this camera may disrupt the electronic
systems of the airplane or the
instruments of the hospital.
iv
Notices
Notice for Customers in the
U.S.A.
Federal Communications
Commission (FCC) Radio
Frequency Interference
Statement
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part
15 of the FCC rules. These limits are
designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses, and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is no
guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an
outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced
radio/television technician for help.
COOLPIX P100
CAUTIONS
Modifications
The FCC requires the user to be notified
that any changes or modifications
made to this device that are not
expressly approved by Nikon
Corporation may void the user’s
authority to operate the equipment.
Interface Cables
Use the interface cables sold or
provided by Nikon for your equipment.
Using other interface cables may
exceed the limits of Class B Part 15 of
the FCC rules.
Notice for customers in the State of
California
WAR NIN G
Handling the cord on this product will
expose you to lead, a chemical known
to the State of California to cause birth
defects or other reproductive harm.
Wash hands after handling.
Nikon Inc.,
1300 Walt Whitman Road
Melville, New York 11747-3064
USA
Tel: 631-547-4200
v
Notices
Notice for customers in Canada
CAUTION
This Class B digital apparatus complies
with Canadian ICES-003.
AT T EN T I ON
Cet appareil numérique de la classe B
est conforme à la norme NMB-003 du
Canada.
Notice for customers in Europe
This symbol indicates that this
product is to be collected
separately.
The following apply only to
users in European countries:
• This product is designated for
separate collection at an appropriate
collection point. Do not dispose of as
household waste.
• For more information, contact the
retailer or the local authorities in
charge of waste management.
This symbol on the battery
indicates that the battery is
to be collected separately.
The following apply only to
users in European countries:
• All batteries, whether marked with
this symbol or not, are designated for
separate collection at an appropriate
collection point. Do not dispose of as
household waste.
• For more information, contact the
retailer or the local authorities in
charge of waste management.
vi
Table of Contents
For Your Safety........................................................................................................................................ ii
WARNINGS..................................................................................................................................................................ii
Notices ....................................................................................................................................................... v
Introduction ...........................................................................................................................................1
About This Manual ................................................................................................................................1
Information and Precautions.............................................................................................................2
Parts of the Camera............................................................................................................................... 4
The Camera Body....................................................................................................................................................4
Changing the Angle of the Monitor ...........................................................................................................6
Raising and Lowering the Built-in Flash ...................................................................................................7
Attaching the Camera Strap and Lens Cap............................................................................................7
The Monitor................................................................................................................................................................8
Basic Operations...................................................................................................................................11
The Command Dial.............................................................................................................................................11
The Multi Selector ...............................................................................................................................................12
The d Button....................................................................................................................................................13
Switching Between Tabs.................................................................................................................................13
Help Displays..........................................................................................................................................................14
The x (monitor) Button ...............................................................................................................................14
The s (display) Button .............................................................................................................................15
First Steps............................................................................................................................................. 16
Inserting the Battery ...........................................................................................................................16
Removing the Battery .......................................................................................................................................17
Charging the Battery ..........................................................................................................................18
Turning On and Off the Camera.................................................................................................................21
Setting Display Language, Date and Time..................................................................................22
Inserting Memory Cards ....................................................................................................................24
Removing Memory Cards...............................................................................................................................24
Basic Photography and Playback: A (Auto) Mode...............................................................26
Step 1 Turn the Camera On and Select A (Auto) Mode........................................................26
Indicators Displayed in A (Auto) Mode...............................................................................................27
Step 2 Frame a Picture........................................................................................................................28
Using the Electronic Viewfinder .................................................................................................................28
Using the Zoom....................................................................................................................................................29
Step 3 Focus and Shoot .....................................................................................................................30
Pressing the Shutter-Release Button Halfway/All the Way Down.........................................30
Step 4 Viewing and Deleting Pictures ..........................................................................................32
Viewing Pictures (Playback Mode)............................................................................................................32
Deleting Pictures..................................................................................................................................................32
Using the Flash......................................................................................................................................34
Setting the Flash Mode....................................................................................................................................35
Taking Pictures with the Self-Timer ...............................................................................................37
Using Focus Mode ...............................................................................................................................38
vii
Table o f Co ntents
Setting the Focus Mode..................................................................................................................................39
Using Manual Focus...........................................................................................................................................40
Adjusting the Brightness (Exposure Compensation)..............................................................41
More on Shooting .............................................................................................................................42
Selecting a Shooting Mode (Mode Dial)......................................................................................42
Shooting Suited for the Scene ........................................................................................................43
Shooting in the Scene Selected by the Camera (Scene Auto Selector)............................43
Selecting Scenes for Shooting (Scene Mode)....................................................................................45
Features......................................................................................................................................................................46
Taking Pictures for a Panorama...................................................................................................................53
Taking Pictures of Smiling Faces (Smart Portrait Mode) ........................................................55
Smart Portrait Menu...........................................................................................................................................57
Focusing on a Moving Subject in Subject Tracking Mode....................................................59
Subject Tracking Menu ....................................................................................................................................61
Shooting with a High-Speed Burst (Sport Continuous Mode) ............................................62
Sport Continuous Menu..................................................................................................................................64
Setting the Exposure for Shooting (A, B, C, D Modes).......................................................66
A, B, C, D Modes .............................................................................................................................................66
A (Programmed Auto) Mode.......................................................................................................................68
B (Shutter-Priority Auto) Mode..................................................................................................................69
C (Aperture-Priority Auto) Mode..............................................................................................................70
D (Manual) Mode ...............................................................................................................................................71
Shooting Options: Shooting Menu (A, B, C, D Modes) ......................................................73
q Image Quality ................................................................................................................................................75
r Image Size........................................................................................................................................................76
F Optimize Image............................................................................................................................................79
B White Balance...............................................................................................................................................82
E ISO Sensitivity................................................................................................................................................84
G Metering...........................................................................................................................................................85
C Continuous.....................................................................................................................................................86
H Auto Bracketing...........................................................................................................................................89
G AF-Area Mode ...............................................................................................................................................90
I Autofocus Mode..........................................................................................................................................93
J Flash Exp. Comp...........................................................................................................................................93
M Noise Reduction .........................................................................................................................................94
Q Distortion Control.......................................................................................................................................94
J Active D-Lighting........................................................................................................................................95
Functions that Cannot be Applied Simultaneously.......................................................................96
M (User Setting Mode)...........................................................................................................98
Using
Save the Settings in M ......................................................................................................................................99
Resetting Saved Settings .............................................................................................................................100
More on Playback............................................................................................................................101
viii
Operations in Full-Frame Playback.............................................................................................101
Table of Contents
Viewing Continuously Shot Pictures (Pictures in a sequence) .............................................102
Viewing Multiple Pictures: Thumbnail Playback....................................................................104
Calendar display................................................................................................................................................105
Taking a Closer Look: Playback Zoom ....................................................................................... 106
Playback Options: Playback Menu..............................................................................................107
a Print Set: Setting the Pictures and Number of Copies to Print ....................................108
b Slide Show....................................................................................................................................................110
c Delete: Deleting Multiple Pictures .................................................................................................111
d Protect...........................................................................................................................................................113
f Rotate Image...............................................................................................................................................114
i Hide Image...................................................................................................................................................114
h Copy: Copying Between the Internal Memory and Memory Card..........................115
C Sequence Display Options.................................................................................................................116
C Choose Key Picture.................................................................................................................................116
Voice Memos: Recording and Playback ....................................................................................117
Recording Voice Memos..............................................................................................................................117
Playing Voice Memos.....................................................................................................................................117
Deleting Voice Memos..................................................................................................................................117
Editing Pictures ................................................................................................................................118
Picture Editing Functions............................................................................................................... 118
Editing Pictures.................................................................................................................................. 120
k Quick Retouch: Enhancing Contrast and Saturation ........................................................120
I D-Lighting: Enhancing Brightness and Contrast ..................................................................121
e Skin Softening: Making Skin Appear Smoother ....................................................................122
g Small Picture: Resizing Pictures.......................................................................................................124
j Black Border: Adding a Black Border to a Picture .................................................................125
a Crop: Cutting Out Part of a Picture.................................................................................................126
Movie Recording and Playback..................................................................................................127
Recording Movies ............................................................................................................................. 127
Recording Slow Motion Movies or Fast Motion Movies (HS Movie).................................130
Movie Menu.........................................................................................................................................................132
D Movie Options............................................................................................................................................133
D HS Movie Options....................................................................................................................................134
I Autofocus Mode.......................................................................................................................................135
w Electronic VR...............................................................................................................................................136
Y Wind Noise Reduction .........................................................................................................................136
Movie Playback ..................................................................................................................................137
Deleting Movie...................................................................................................................................................137
Connecting to Televisions, Computers and Printers...........................................................138
Connecting to a TV ........................................................................................................................... 138
Connecting to a Computer............................................................................................................140
Before Connecting the Camera...............................................................................................................140
ix
Table o f Co ntents
Transferring Pictures from a Camera to a Computer..................................................................141
Charging While Connecting to a Computer....................................................................................145
Connecting to a Printer................................................................................................................... 146
Connecting the Camera and Printer.....................................................................................................147
Printing Pictures One at a Time................................................................................................................148
Printing Multiple Pictures ............................................................................................................................149
Basic Camera Setup ........................................................................................................................152
Setup Menu......................................................................................................................................... 152
c Welcome Screen.......................................................................................................................................154
d Date ..................................................................................................................................................................155
e Monitor Settings......................................................................................................................................158
f Date Imprint ................................................................................................................................................159
g Vibration Reduction...............................................................................................................................160
U Motion Detection.....................................................................................................................................162
h AF Assist........................................................................................................................................................163
K Red-eye reduction..................................................................................................................................163
u Digital Zoom...............................................................................................................................................164
i Sound Settings..........................................................................................................................................165
k Auto Off..........................................................................................................................................................165
l/m Format Memory/Format Card..................................................................................................166
n Language.......................................................................................................................................................167
H TV Settings....................................................................................................................................................167
V Charge by Computer.............................................................................................................................168
d Blink Warning..............................................................................................................................................169
p Reset All..........................................................................................................................................................171
P Reset file numbering..............................................................................................................................174
r Firmware Version.....................................................................................................................................174
Caring for the Camera....................................................................................................................175
Caring for the Camera ..................................................................................................................... 175
Cleaning .................................................................................................................................................................177
Storage....................................................................................................................................................................178
Technical Notes and Index...........................................................................................................179
Optional Accessories ....................................................................................................................... 179
Approved Memory Cards ............................................................................................................................180
File and Folder Names.....................................................................................................................181
Error Messages ................................................................................................................................... 183
Troubleshooting................................................................................................................................ 188
Specifications ..................................................................................................................................... 195
Supported Standards .....................................................................................................................................198
Index ...................................................................................................................................................... 199
x
Introduction
About This Manual
Thank you for your purchase of Nikon COOLPIX P100 digital camera. This manual is
written to help you enjoy taking pictures with your Nikon digital camera. Read this
manual thoroughly before use, and keep it where all those who use the product w ill
read it.
Symbols and Conventions
To make it easier to find the information you need, the following symbols and
conventions are used:
Introduction
This icon marks cautions,
information that should be read
BD
before use, to prevent damage to
the camera.
This icon marks notes,
information that should be read
C
before using the camera.
This icon marks tips, additional
information that may be helpful
when using the camera.
This icon indicates that more
information is available
A
elsewhere in this manual or in t he
Quick Start Guide.
Notations
• A Secure Digital (SD) memor y card is referred to as a “memory card”.
• The setting at the time of purchase is referred to as the “default setting”.
• The names of menu items displayed in the camera monitor, and the names of
buttons or messages displayed in a computer monitor are indicated in bold text.
Screen Samples
In this manual, images are sometimes omitted from monitor and electronic
viewfinder display samples so that monitor indicators can be more clearly shown.
Illustrations and Screen Display
Illustrations and text displays shown in this manual may differ from actual display.
C Memory Cards
Pictures taken with this camera can be stored in the camera’s internal memory or on removable
memory cards. If a memory card is inserted, all new pictures will be stored on the memory card and
delete, playback, and format operations will apply only to the pictures on the memory card. The
memory card must be removed before the internal memory can be formatted or used to store
pictures to, or delete, or view pictures.
1
Information and Precautions
Life-Long Learning
As part of Nikon’s “Life-Long Learning” commitment to ongoing product support and education,
continually updated information is available online at the following sites:
Introduction
• For users in the U.S.A .: http://www.nikonusa.com/
• For users in Europe and Africa: http://ww w.europe -nikon.com/support/
• For users in Asia, Oceania, and the Middle East: http://www.nikon-asia.com/
Visit these sites to keep up-to-date with the latest product information, tips, answers to frequently
asked questions (FAQs), and general advice on digital imaging and photography. Additional
information may be available from the Nikon representative in your area. See the URL below for
contact information:
http://imaging.nikon.com/
Use Only Nikon Brand Electronic Accessories
Nikon COOLPIX cameras are designed to the highest standards and include complex electronic
circuitry. Only Nikon brand electronic accessories (including battery chargers, batteries, Charging AC
Adapters and AC adapters) cer tified by Nikon specifically for use with this Nikon digital camera are
engineered and proven to operate within the operational and safety requirements of this electronic
circuitry.
THE USE OF NON-NIKON ELECTRONIC ACCESSORIES COULD DAMAGE THE CAMERA AND MAY VOID
YOUR
NIKON WARRANTY.
The use of third-party rechargeable Li-ion batteries not bearing the Nikon holographic seal could
interfere with normal operation of the camera or result in the batteries overheating, igniting,
rupturing, or leaking.
For more information about Nikon brand accessories, contact a local authorized Nikon dealer.
Holographic seal: Identifies this
device as an authentic Nikon produc t.
Before Taking Important Pictures
Before taking pictures on important occasions (such as at weddings or before taking the camera on
a trip), take a test shot to ensure that the camera is functioning normally. Nikon will not be held liable
for damages or lost profits that may result from product malfunction.
About the Manuals
• No part of the manuals included with this product may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language in any form, by any means, without
Nikon’s prior written permission.
• Nikon reserves the right to change the specifications of the hardware and software described in
these manuals at any time and without prior notice.
• Nikon will not be held liable for any damages resulting from the use of this product.
• While every effort was made to ensure that the information in these manuals is accurate and
complete, we would appreciate it were you to bring any errors or omissions to the attention of the
Nikon representative in your area (address provided separately).
2
Information and Precautions
Notice Concerning Prohibition of Copying or Reproduction
Note that si mply be ing in po ssessi on of ma terial t hat was digitally copied or reproduced by means of
a scanner, digital camera or other device may be punishable by law.
• Items prohibited by law from being copied or reproduced
Do not copy or reproduce paper money, coins, securities, government bonds or local government
bonds, even if such copies or reproductions are stamped “Sample”. The copying or reproduction of
paper money, coins, or securities which are circulated in a foreign country is prohibited. Unless the
prior permission of the government was obtained, the copying or reproduction of unused postage
stamps or post cards issued by the government is prohibited.
The copying or reproduction of stamps issued by the government and of certified documents
stipulated by law is prohibited.
• Caution s on certain copies and repro ductions
The government has issued cautions on copies or reproductions of securities issued by private
companies (shares, bills, checks, gift certificates, etc.), commuter passes or coupon tickets, except
when a minimum of necessary copies are to be provided for business use by a company. Al so, do not
copy or reproduce passports issued by the government, licenses issued by public agencies and
private groups, ID cards and tickets, such as passes and meal coupons.
• Comply with copyright notices
The copying or reproduction of copyrig hted creative wo rks such as b ooks, music, p aintings, wood cut
prints, maps, drawings, movies and photographs is governed by national and international copyright
laws. Do not use this product for the purpose of making illegal copies or to infringe copyright laws.
Disposing of Data Storage Devices
Please note that deleting images or formatting data storage devices such as memory cards or built-in
camera memory does not completely erase the original image data. Deleted files can sometimes be
recovered from discarded storage devices using commercially available software, potentially
resulting in the malicious use of personal image data. Ensuring the privacy of such data is the user’s
responsibility.
Before discarding a data storage device or transferring ownership to another person, erase all data
using commercial deletion software, or format the device and then completely refill it with images
containing no private information (for example, pictures of empty sky). Be sure to also replace any
pictures selected for the welcome screen (A154). Care should be taken to avoid injury or damage
to property when physically destroying data storage devices.
Introduction
3
Parts of the Camera
The Camera Body
Introduction
1 2 3
6
7
Power switch/Power-on lamp
1
....................................................19, 21, 145, 165
2 Mode dial...........................................................42
3 Microphone (stereo)......................117, 127
4 Built-in flash ................................................7, 34
5 m (Flash pop-up) button....................7, 35
Eyelet for camera strap (at two places)
6
....................................................................................7
Power connector cover (for connec tion
7
with an optional AC Adapter)............179
Built-in flash raised
4
5
8
10
9
11
8 Shutter-release button..............................30
Zoom control..................................................29
f : Wide ................................................... 29
g : Tele......................................................29
9
h: Thumbnail playback.............. 104
i : Playback zoom..........................106
j : Help ....................................................14
Self-timer lamp...............................................37
10
AF-assist illuminator.................................163
11 Lens .........................................................177, 195
4
PUSH T
O EJECT
21 3 4 87 965
Parts of the Camera
Introduction
10
11
1 Speaker ..................................................117, 137
2 x (monitor) button .................................14
3 Diopter adjustment control................... 14
4 Electronic viewfinder .................................14
5 s (display) button ...............................15
6 b (movie-record) button....................127
7 Movie mode switch .................................127
8 Command dial ...............................................11
9 k (apply selection) button ...................12
10 HDMI Mini Connector ............................138
USB/Audio video connector
11
.........................................................138, 141, 147
12 Connector cover ...................138, 141, 147
12
13
18 19
17
16
15
14
13 Monitor ..................................................8, 15, 27
14 c (playback) button.................................32
15 d button ......13, 45, 74, 107, 132, 153
16 Multi selector...................................................12
17 l (delete) button............32, 33, 117, 137
18 Tripod socke t
Battery-chamber/
19
memory card slot cover ...................16, 24
20 Cover latch................................................16, 24
21 Memory card slot .........................................24
22 Battery latch.............................................16, 17
23 Battery chamber............................................16
21 22 23
20
5
Parts of the Camera
Changing the Angle of the Monitor
The angle of the monitor can be lowered down to 82° or raised upward to 90°. This
is convenient when taking pictures with the camera held at high or low positions.
Introduction
B Notes on Monitor
• Do not apply excessive force when changing the angle of the monitor.
• The monitor cannot be moved horizontally.
• Put the monitor back in the original position when using in normal situations.
6
Parts of the Camera
Raising and Lowering the Built-in Flash
Press the m (flash pop-up) button to raise the built-in flash.
• See “Using the Flash” (A34) for more information on setting the flash.
• When not using the built-in flash, gently push the flash down.
Attaching the Camera Strap and Lens Cap
Attach the lens cap to the strap, and then attach the strap
to the camera (at two places).
Introduction
B Lens Cap
• Remove the lens cap before you shoot a picture.
• At times when you will not be shooting pictures such as when
the power is off, or while you are carrying the camera, attach the
lens cap to the camera to protect the lens.
7
Parts of the Camera
1/2 50
999
F5.6
1m0 0s
1m0 0s
99 9
99 99
1/2 50
F5. 6
The Monitor
The following indicators may appear in the monitor during shooting and playback
(actual display varies with current camera settings).
Introduction
See page 15 for details on changing the monitor display.
Shooting
43
42
40
44
41
39
33
32
2
13 89
38
37
36
35
34
1/250
1/250
282930
27
6
F5.6
F5.6
2631 24
54
10
13
14
18
17
16
999
999
25
999
999
9999
9999
a
19
1211
1m00s
1m00s
1m00s
1m00s
b
7
15
20
21
22
23
45
46
F5.6
F5.6
171717
1/250
1/250
8
Parts of the Camera
Introduction
Shooting mode
1
...........................26, 43, 45, 55, 59, 62, 66, 98
Focus mode......................................................38
2
Zoom indicator ..............................................29
3
Focus indicator...............................................30
4
AE/AF-L indicator..........................................54
5
Flash indicator.................................................36
6
Flash mode .......................................................34
7
Flash exposure compensation.............93
8
Battery level indicator ................................26
9
Motion detection icon ...........................162
10
Vibration reduction icon (still pictures)
11
...............................................................................160
Electronic VR icon (movies) .................136
12
Noise reduction .............................................94
13
Distortion control .........................................94
14
Active D-Lighting..........................................95
15
Wind noise reduction..............................136
16
“Date not set” indicator..........................183
17
Travel destination indicator.................155
18
Date imprint..................................................159
19
Movie options..............................................132
20
HS movie options ......................................134
21
Image size..........................................................76
22
*
(a) Number of exposures remaining
(still pictures) ............................................26
23
(b) Movie length.........................................127
* Differs according to the current shooting mode.
Internal memory indicator ..................... 27
24
Image quality.................................................. 75
25
Aperture............................................................. 67
26
Focus area (for manual, center)....30, 90
27
Focus area (for auto)................................... 90
28
Focus area (for face priority)...........55, 90
29
Focus area
30
(for subject tracking mode) ................... 59
Shutter speed................................................. 67
31
Exposure display...........................................71
32
ISO sensitivity ..........................................36, 84
33
Exposure compensation value............ 41
34
Skin softening ................................................ 57
35
Smile timer.......................................................57
36
Blink proof ........................................................58
37
B&W + color.....................................................81
38
Image optimization ....................................79
39
White balance mode .................................82
40
Self-timer indicator .....................................37
41
Bracketing.........................................................89
42
Continuous shooting mode.................. 86
43
High-speed mode ....................................... 64
44
Pre-shooting cache..............................64, 65
Spot metering area..................................... 85
45
Center-weighted area............................... 85
46
9
Parts of the Camera
999/999
15/05/2010
12:00
1m0 0s
1m0 0s
99 99 /9 99 9
99 9/ 99 9
Introduction
Playback
20
19
18
22
21
17
16
15
14
Date of recording.........................................22
1
Time of recording ........................................22
2
Protect icon....................................................113
3
Volume indicator.............................117, 137
4
Battery level indicator ............................... 26
5
Image quality
6
Movie options
7
Image size
8
(a) Current frame number/ total
number of frames................................. 32
9
(b) Movie length .........................................137
Internal memory indicator .....................32
10
Voice memo recording guide............117
11
* Differs according to the selected option.
*
................................................ 75
*
............................................133
*
....................................................... 76
10
15/05/2010
15/05/2010
11
12
13
12:00
12:00
51234
6
7
999/999
999/999
8
10
999/999
999/999
9999/9999
9999/9999
a
Voice memo playback guide.............117
12
Sequence playback guide ...................102
13
Movie playback guide ............................137
Sequence display ......................................116
14
Skin softening icon...................................122
15
Print-order icon .......................................... 108
16
Small picture ......................................124, 126
17
Black border indicator............................125
18
D-Lighting icon ..........................................121
19
Quick retouch icon...................................120
20
Voice memo indicator............................ 117
21
File number and type ............................. 181
22
1m00s
1m00s
1m00s
1m00s
b
9
Basic Operations
The Command Dial
You can rotate the command dial to select items from a menu screen or to choose
and configure any of the following functions.
For Shooting
Mode Use Description
Programmed auto
(mode dial set to A)
Shutter-priority auto
(mode dial set to B)
Aperture-priority auto
(mode dial set to C)
Manual
(mode dial set to D)
Change the flexible program 68
Adjust shutter speed 69
Adjust aperture 70
Adjust shutter speed or aperture
(press the multi selector K to
select a different option)
For Playback
Mode Use Description
Full-frame playback or
thumbnail playback
Calendar display Choose a date 105
Choose a picture
A
71
A
32,
101,
104
Introduction
Playback zoom Change the zoom ratio 106
During sequen ce playback or
pause
During movie pause Advanced or Rewound 137
Select playback control 102
11
Basic Operations
444
15/ 05/2 010
000 4.JP G
15: 30
The Multi Selector
This section describes standard uses of the multi selector to select modes, select
menu options, and to apply selections.
Introduction
Operate by pressing the up, down, left, right section, or the k (apply selection) button.
For Shooting
Display m (flash mode) (A34) menu or
choose the option above
Display n
(self-timer)
(A37)
menu
Display D (focus mode) (A38) menu or
choose the option below
* In shooting mode D (manual), select whether to set the shutter speed or the aperture when the
command dial is rotated (A71).
For Playback
Choose the
previous
Display o
(exposure
compensation)
(A41) guide*
Apply selection
15/05/2010
15/05/2010
Flash mode
15:30
15:30
Choose the
next picture
For the Menu Screen
Choose the option
above
Choose the option
on the left/Return
display to the
previous screen
Choose the option
below
Choose the option
on the right/Display
sub-menu or apply
selection
Apply selection or
display sub-menu
Shooting menu
Image quality
Image size
Optimize image
White balance
ISO sensitivity
Metering
Continuous
C Note on the Multi Selector
In this manual, up, down, left, and right presses of the multi selector may be indicated with H, I, J and K.
12
4
Basic Operations
The d Button
Press the d button to display the menu and to select options for the menu items.
• Use the multi selector to navigate the menus (A12).
• Menu items can also be chosen by rotating the command dial.
• Select a tab on the left side of the monitor to display the corresponding menu.
• Press the d button again to exit the menu.
Displayed when
there are previous
menu options
Displayed when the menu contains
Displays the menus for the
mode selected by the mode dial
Displays the movie menu
Displays the playback menu
Displays the setup menu
Displayed when there are followin g
menu options
Shooting menu
Auto bracketing
AF area mode
Autofocus mode
Flash exp. comp.
Noise reduction
Distortion control
Active D-Lighting
0.0
two or more pages
Shooting menu
Image quality
Image size
Optimize image
White balance
ISO sensitivity
Metering
Continuous
Autofocus mode
Single AF
Full-time AF
Introduction
Select an item, then press
the k button or the multi
selector K to proceed to
the next set of options.
Switching Between Tabs
Shooting menu
Image quality
Image size
Optimize image
White balance
ISO sensitivity
Metering
Continuous
Press the multi selector J
to highlight the tab.
Shooting menu
Press the multi selector
HI to choose another
tab, and press either the
k button or K.
Image quality
Image size
Optimize image
White balance
ISO sensitivity
Metering
Continuous
Press the k button or the
multi selector K to apply
the selection.
Set up
Welcome screen
Date
Monitor settings
Date imprint
Vibration reduction
Motion detection
AF assist
The chosen menu is
displayed.
13
Basic Operations
1/2501/2501/250
171717
F5.6
F5.6F5.6
1/250
F5.6
1/25 0
F5.6
Help Displays
Rotate the zoom control to g (j) when M is displayed at the bottom of the menu
screen to view a description of the currently selected menu option.
Introduction
To return to the original menu, rotate the zoom control to g (j) again.
Shooting menu
Image quality
Image size
Optimize image
White balance
ISO sensitivity
Metering
Continuous
White balanceWhite balance
For accurate color reproduction,
choose a setting that matches the
light source.
Back
The x (monitor) Button
Press the x (monitor) button to switch between the monitor or electronic
viewfinder. Switch to the one that suits the shooting conditions. For example, use
the electronic viewfinder in bright locations when it is difficult to see the monitor.
Monitor
F5.6
1/250
1/250
F5.6
171717
Electronic viewfinder
171717
F5.6
1/250
1/250
F5.6
B Diopter Adjustment of Electronic Viewfinder
When the diopter for the electronic viewfinder is out of focus and
the display is difficult to see, adjust the diopter with the diopter
adjustment control. While looking into the viewfinder, rotate the
diopter adjustment control until the display is clearly visible.
Take care not to scratch your eye with your fingertips or nails when
rotating the diopter adjustment control.
Diopter adjustment control
14
The s (display) Button
1/2 50
F5. 6
1/2 50
F5. 6
444
15/ 05/20 10
000 4.JPG
15: 30
To switch between the information displayed on
the monitor during shooting and playback, press
the s button.
For Shooting
Basic Operations
Introduction
1/250
F5.6
F5.6
Display information
Display the picture and the
shooting data.
171717
Display a boxed guide for
framing.
1/250
1/250
Framing grids
F5.61/250
F5.6
171717
1
Information hidden
Display the picture only.
For Playback
15/05/2010
15/05/2010
15:30
15:30
4
Display photo information
Display the picture taken and
the photo information.
Display shooting data
(except for movies)
Display highlight2, histogram3
and shooting data
1 Available only when mode dial is set to A, B, C, D or M.
2 The brightest portions of the image (portions that are highlighted) will blink. Use highlights as a
guide when setting exposure.
3 The histogram is a bar graph that shows the brightness distribution in the picture. The horizontal
axis corresponds to pixel brightness, with dark tones to the left and bright tones to the right. The
vertical axis shows the number of pixels.
4 The shooting data displayed includes the folder name, file name, shooting mode used (A, B, C or
D), shutter speed, aperture, exposure compensation, ISO sensitivity, and the current file number/
total number of exposures.
A is displayed when the shooting mode A, y, x, F, s, d or A is chosen.
100NIKON
P
1/250 F5.6
ISO
4
.
+1.0
200
44
Information hidden
Display only the taken picture.
15
First Steps
PUSH TO EJECT
Inserting the Battery
Insert a Rechargeable Li-ion Battery EN-EL5 (supplied) into the camera.
• Charge the battery before first use or when the battery is running low (A18).
1
Open the battery-chamber/memory card
slot cover.
First Steps
• Slide the cover latch to the Y position (1), and
open the battery-chamber/memory card slot cover
(2).
2
Insert the battery.
• Confirm that the positive (+) and negative (–) terminals
are oriented correctly, as shown on the label at the
entrance of the batter y chamber, and insert the battery.
• Use the battery to push the orange battery latch in the
direction indicated by the arrow (1) and fully insert the
battery (2).
• When the battery is fully inserted, the battery latch will
lock it in place.
B Inserting the Battery Correctly
Inserting the battery upside down or backwards
could d amage the c amera. Be sure to confirm that the
battery is in the correct orientation.
PUSH TO EJECT
16
3
Close the battery-chamber/memory card
slot cover.
• Close the batter y-chamber/memory card slot cover
(1), and slide the cover latch to the Z position
(2).
Inserting the Battery
PUSH TO EJECT
Removing the Battery
Turn the camera off (A21) and confirm that the poweron lamp and the monitor are off before opening the
battery-chamber/memory card slot cover.
Slide the orange battery latch in the direction shown
(1) and eject the battery. Pull the battery out straight
(2).
• Note that the battery may become hot during use; observe due caution when
removing the battery.
First Steps
B Notes on the Battery
• Be sure to read and follow the warnings and cautions of “For Your Safety” (Aii) thoroughly before
using the battery.
• Be sure to read and follow the warnings for “The Battery” (A176) of the section “Caring for the
Camera” thoroughly before using the battery.
• If the battery will not be used for an extended period, recharge it at least once every six months
and run it flat before returning it to storage.
17
Charging the Battery
Charge the supplied Rechargeable Li-ion Battery EN-EL5 inserted into the camera,
by connecting the supplied Charging AC Adapter EH-68P to the camera via the
supplied USB Cable UC-E6, and then plugging the Charging AC Adapter into an
electrical outlet.
1
First Steps
Prepare the Charging AC Adapter
EH-68P.
If a plug adapter* is included, attach the
plug adapter to the plug on the Charging
AC Adapter. Push the plug adapter firmly
until it is securely held in place. Once the
two are connected, attempting to forcibly
remove the plug adapter could damage the
product.
* The shape of the plug adapter varies
according to the country or region in which the camera was purchased.
For Customers in Argentina
If the camera was purchased in Argentina, the shape of
the Charging AC Adapter EH-68P (AR) differs from that
supplied in other countries, and a plug adapter is not
included. Proceed to step 2.
EH-68P (AR)
2
Be sure that the power-on lamp and the monitor are off.
• Be sure to insert the battery into the camera (A16) and turn off the camera (A21).
3
Use the supplied USB cable to connect the Charging AC Adapter to the camera.
USB cable
B Connecting the Cable
When connecting the cable, be sure that the camera connector is properly oriented. Do not use force when
connecting the cable to the camera. When disconnecting the cable, do not pull the connector at an angle.
18
Loading...
