SPECIFICATIONS

Model
Type of camera
Number of effective pixels
CCD sensor

Storage media

File format

Number of recorded pixels
Lens mount
Picture angle
Sensitivity

Exposure metering

3

system*

Exposure modes

Exposure compensation
Shutter speed
Continuous shooting

Auto bracketing
Focus

mode
AF system
Focus Area

AF Frame
selection

White balance

Color Space
Film Simulation
Dynamic Range
Self-timer
Built-in flash

Frash modes

Flash control

Accessory shoe
Sync contact
Viewfinder

LCD back monitor

Photography functions
Playback functions

Other functions

Video output
Digital interface
Remote release
Power source

Dimensions

Camera mass (weight)
Operating Conditions

FinePix S5 Pro
Interchangeable-lens SLR-type digital camera

12.34 million (S-pixel: 6.17million, R- pixel: 6.17million) pixels
Large-format (23.0mm×15.5mm) Super CCD SR Pro with primary
color filter Total 12.9 megapixels (S-pixels: 6.45 million, R-pixels: 6.45million
Compact Flash™ (CF) Card (Type I/II) and Microdrive™*1
(

Compatibility is listed on Fujifilm website: http://www.fujifilm.com/products/digital
DCF-compliant, Compressed: Exif Ver. 2.21 JPEG,
DPOF-compatible Uncompressed: CCD-RAW(14bit)*
L: 4,256×2,848 / M: 3,024×2,016 / S: 2,304×1,536 pixels
Nikon F mount (with AF coupling, AF contacts
Approx. 1.5× focal length in 35mm format equivalent
Auto, ISO 100 / 125 / 160 / 200 / 250 / 320 / 400 / 500 / 640 / 800 /
1000 / 1250 / 1600 / 2000 / 2500 / 3200 (Standard Output Sensitivity
Three-mode through-the-lens (TTL) exposure metering.
3D Color Matrix Metering (metering performed by 1,005-segment
RGB sensor) / Center-weighted / Spot
Programmed Auto with flexible program [P], Shutter-Priority Auto [S],
Aperture-Priority Auto [A], and Manual [M

-

5.0EV to +5.0EV Step can be selected from 1/3, 1/2, 1EV step.
30 sec. to 1/8000 sec., Bulb.*
CH : Approx. 3 frames/sec. ([D-RANGE] set to [100% (STD
Approx. 1.6 frames/sec. ([D-RANGE] set to other than [100% (STD
CL : Approx. 2 frames/sec. ([D-RANGE] set to [100% (STD
Approx. 1.6 frames/sec. ([D-RANGE] set to other than [100% (STD
and approx. 1 frames/sec.
Number of shots 2-9 compensated EV value 1/3, 1/2, 2/3, 1 EV step
Single Servo AF(S) / Continuous Servo AF(C) / Manual focus(M
TTL phase detection. AF assist illuminator
Normal: 11 areas; single area or group can be selected;



Wide: focus area can be selected from 7 areas

1) Single Area AF 2) Dynamic AF 3) Group Dynamic AF

4) Dynamic AF with closest subject priority
Automatic / Incandescent light / Fluorescent lamp (1-5) / Fine / Flash /
Shade / Color temperature / Preset Custom (1-5) Fine tuning can be set.
sRGB / Adobe RGB (1998
(

STANDARD) / F1 / F1a / F1b / F1c / F2
AUTO / 100%(STD) / 130% / 170% / 230% (W1) / 300% / 400% (W2
20 sec. / 10 sec. / 5 sec. / 2 sec.
Manual pop-up with button release. Guide No.12 (ISO 100・m),
i-TTL balanced fill-flash or standard i-TTL flash
Flash synchronization up to 1/250 sec.
Front Synchro, Slow Synchro, Rear Synchro, Red-eye Reduction,
Red-eye Reduction + Slow Synchro

1) TTL: TTL flash control by 1,005-pixel RGB sensor
Built-in flash: i-TTL balanced fill-flash or standard i-TTL flash
(spot metering or mode dial set to [M])
SB-800, 600 or SB-R200: i-TTL balanced fill-flash for digital SLR
and standard i-TTL flash for digital SLR

2) Auto aperture: Available with SB-800 with CPU lens

3) Non-TTL Auto: Available with flash such as SB-800, SB-80DX,
SB-28DX, SB-28, SB-27, and SB-22s

4) Range-priority manual: available with SB-800
Standard ISO type with hot-shoe contact (Safety lock provided
X-contact only: flash synchronization up to 1/250 sec.
Fixed-eyelevel pentaprism, built-in diopter adjustment,
Frame coverage: Approx. 95%, Magnification: Approx. ×0.94

2.5-inch approx. 230,000 pixels low temperature polysilicon TFT color LCD
(

approx. 100% frame coverage for playback
framing guideline, frame no. memory, multiple exposure shooting, live view
Face Zoom In, cropping, slide show, multi-frame playback,
histogram display, brightness warning display
Function lock, PictBridge compatibility, Exif Print compatibility,
PRINT Image Matching II compatibility, language selection ( , English,
Francais, Deutsch, Español, Italiano, , , ), time difference,
Image comment, Barcode reader/GPS unit
NTSC / PAL selectable*5
USB 2.0 (High-Speed
Electronic shutter release (10-pin remote terminal
Rechargeable Li-ion battery NP-150*
AC Power Adapter AC-135VN (Optional

147.0mm (W
(

)

113.0mm (H

not including accessories and attachments

×

Approx. 830 g / 29.3 oz. (not including accessories, battery and memory card)
Temperature: 0°C to +40°C (+32°F to +104°F) 80% humidity or less
(

no condensation

)

◎

)

]

4

)

)

)

6

)

(included) or

)

)

74.0mm (D) / 5.8in. (W

×

)

4.4in. (H

×

)

When using a Microdrive, 5~40°C.

Memory Card capacity and image quality / size

Exposure mode M, ISO200, focus mode M, SanDisk SDCFX (Extreme III) 1GB card, and other
settings are factory default.

[

D-RANGE] set to [100% (STD

Image quality

)

Image size
File size

)

2

)

)])

/

)])

/

Number of images
Buffer capacity
maximum shooting cycle

[

D-RANGE] set to other than [100% (STD

Image quality
Image size

File size
Number of images
Buffer capacity
maximum shooting cycle

)])

Guide to the number of available frames for battery operation

)])

L

Approx.

18.1
55

Approx. Approx. Approx.

20

L

Approx.

30.3
32

Approx. Approx. Approx.

8

Battery Type

NP-150（1500mAh）

)]

RAW+FINE RAW+NORMAL RAW FINE NORMAL

M

S

L

M

Approx.

Approx.

61

21

M

34

8

Approx.

15.1

15.7

66

63

Approx. Approx. Approx.

21

21

S

L

Approx.

Approx.

27.3

28.0

36

35

Approx. Approx. Approx.

8

8

16.3

RAW+FINE RAW+NORMAL RAW FINE NORMAL

Approx.

28.6

S

Approx.

Approx.

14.8

14.2

67

70

21

21

Up to max. 3 frames/sec.

)]

M

S

Approx.

Approx.

27.1

26.5

36

37

8

8

Up to max. 1.6 frames/sec.

L

−

Approx.

Approx.

5.3

12.8
189

78

Approx. Approx. Approx.

Approx.

29

24

L

−

Approx.

Approx.

5.3

25.1
189

39

Approx. Approx. Approx.

Approx.

19

10

M

S

Approx.

Approx.

3.5

2.2

285

442

39

51

M

S

Approx.

Approx.

3.5

2.2

285

442

73

100

Number of frames*
Approx. 400 frames

L

M

Approx.

Approx.

2.9

2.0

345

495

Approx. Approx. Approx.

30

71

L

M

Approx.

Approx.

2.9

2.0

345

495

Approx. Approx. Approx.

19

90

7

S

Approx.

1.4

718

80

S

Approx.

1.4

718

100

)

OPTIONAL ACCESSORIES

NEW NEW

Rechargeable
Battery

)

NEW NEW

NP-150

Battery Charger

BC-150

Hyper-Utility Software

HS-V3

Hyper-Utility Software

AC Power Adapter

AC-135VN

Accessory availability may vary by country.
Please check with your local Fujifilm representative to confirm product availability.



HS-V3UP
(

an upgrade package

for HS-V2 and HS-S2

)

ACCESSORIES INCLUDED

)

)

2.9in. (D)

×

●Rechargeable battery NP-150 ●Battery charger BC-150 ●Shoulder strap ●Camera body cap

●Eyepiece cap ●LCD cover ●USB cable

●Accessory shoe cover ●Synchronizing terminal cap ●Remote release socket cap

●CD-ROM

＊1：Compact Flash is a trademark of SanDisk Corporation and Microdrive is a trademark of Hitachi GST. All other

trademarks and registered trademarks are the property of their respective holders.
＊2：CCD-RAW is a format specific to the FinePix S5 Pro. The enclosed "FinePix Viewer" software or the optional

Hyper-Utility software "HS-V3" is reguired to interpret images.

＊3：Exposure metering modes may be limited depending on the type of lens used.
＊4：Images shot with long exposures may appear coarse and may also be affected by noise such as white dots.
＊5：When connecting the Video cable (included) to TV, the camera's screen is turned off.
＊6：Li-ion rechargeable batteries other than model NP-150 cannot be used with FinePix S5 Pro.
＊7："CIPA DC-002-2003 'Standard Procedure for Measuring Digital Still Camera Battery Consumption'"

(extract); Using included rechargeable Li-ion battery NP-150, AF50mm F1.4D lens, Compact Flash™ (CF) Card.
Pictures shall be taken at a temperature of 23°C (73.4F) every 30 seconds, the flash used at full power every second
shot and the camera turned off and then on again once every 10 shots.

＊8：For Windows 98SE/Me/2000Pro/XP, Mac OS X (10.3.9〜10.4.8) Updater for Windows Vista
available from March, 2007. Visit http://www.fujifilm.com/products/digital/download/ to update.

Microsoft, Windows, and Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the
United States and/or other countries. Macintosh and Mac OS are trademarks of Apple Computer, Inc., registered in
the U.S. and other countries. All other trademarks are the property of their respective holders.

[

image browser with CCD-RAW converting function]*8 ●Owner's manual

(

mini-B) ●Video cable for FinePix S5 Pro

Specifications are subject to change without notice.

TM

will be

For more information, please visit our Website:

http://www.fujifilm.com/products/d i gital

Ref. No. EB-616E (SK・07・1・F2586・F9711) Printed in Japan 2007 FUJIFILM Corporation

c

The Next Evolutionary Stage

FUJIFILM Takes the Digital SLR to the Next Level.

CCD-RAW, 1/200 sec., f/14, ISO100

Real Photo Technology Pro

The next evolutionary stage of advanced digital image processing technology

FUJIFILM’s long experience in film photography and cutting-edge digital image processing technology have crystallized in the ultimate image quality technology –
“Real Photo Technology Pro.” This fusion of our new Super CCD SR Pro and RP (Real Photo) Processor Pro realizes ultrahigh resolution with a superb S/N ratio,
wider dynamic range and rich tonality for performance and image quality beyond even the imagination of professionals.

Super CCD SR Pro
High Sensitivity ISO3200 & High S/N Ratio

Emulating the composition of negative film, the unique double-photodiode
matrix

of Super CCD SR Pro consists of 6.17 million high-sensitivity S-pixels
with large
with small light receptor area. The large 23.0mm
resolution canvas of 12.3 million effective pixels also achieves a dynamic range
of 400%, approaching that of negative film. Also its optimized optical low pass
filter enables high resolution while minimizing moiré. Achieving both high
resolution and high S/N ratio, it captures subjects in clear, exquisite detail.

light receptor area and 6.17 million R-pixels for wide dynamic range

pixel for extended dynamic range

R

pixel for high sensitivity

S

×

15.5mm

CCD with its high

Freedom to customize
the extended dynamic range

255

The extended dynamic range setting can be precisely and
optimally set according to subject and scene conditions. In
addition to Auto for automatic range selection, there is a
Manual mode offer ing a selection of 6 steps: 100% (STD),
130%, 170%, 230% (W1), 300% and 400% (W2). Select
400% (W2) and get maximum performance of both “S” and
“R” pixels for an exposure level equivalent to +2EV and
capability to capture outstanding photos in high-contrast
scenes such as outdoors under clear skies.

255

Digital
Value

0

0

■ Extended dynamic range image formation

RP (REAL PHOTO) PROCESSOR Pro
Exhaustive Noise Reduction & Smoother Tonality

This newly developed processor features the very latest in digital image
processing technology. Using “Double Noise Reduction” and a unique
advanced algorithm, RP Processor
Pro accurately identifies, separates
and thoroughly eliminates noise
only from the image data signal.
Even at the highest sensitivity
of ISO3200, the clarity is amazing.

100%（STD）

400%（W2）

+2EV

Exposure Value



The solid body holds the spirit

and legacy of our film technology.

The professional desires nothing less than the ultimate photograph.

Built for the severe conditions of professional photography,

the solid body of the FinePix S5 Pro holds the legacy of FUJIFILM's film technology and know-how.

Newly developed “Real Photo Technology Pro” brings images to life with rich tonal expression,

defies convention with ultrahigh resolution and a high signal-to-noise ratio,

and impressive color reproduction. It empowers you with the unlimited potential to

translate a language of creative expression into outstanding photographs.

FinePix S5 Pro, the Digital SLR that embodies FUJIFILM’s passion for photography.

AdobeRGB

sRGB

Adobe RGB Color Space Support

FinePix S5 Pro fully supports Adobe RGB color space, the
choice and standard of graphics professionals and the printing
industry. The superior color gamut of Adobe RGB color space
fills the photographic expression needs of today’s professional.

0.8

0.6

0.4

0.2

0 0.2 0.4 0.6 0.8

■ Adobe RGB Color Gamut (chromaticity diagram)

“Face Detection Technology” based on FUJIFILM “Image Intelligence™”

“Image Intelligence™”– the distillation of the vast image processing technology and know-how of FUJIFILM into a database for
application in diverse domains from the printing industry to the medical field. In the case of the FinePix S5 Pro, high-accuracy
face analysis and detection technology has been integrated in a custom IC chip that can analyze a captured image in an instant
and simultaneously detect up to 10 faces. It is a powerful new solution to meet the high quality demands of portrait photography.

◎Above images are simulated representations.

CCD-RAW, 1/8 sec., f/22, ISO160CCD-RAW, 1/125 sec., f/8, ISO100

F2F1b

FILM SIMULATION MODE
selection of the ideal “f ilm” for the scene

Film Simulation responds to the sophisticated color reproduction and tonality demands of the
professional with a choice of five modes: “Professional portrait” (F1, F1a, F1b and F1c) Modes
for expanded potential in portrait photography and “Fujichrome” (F2) Mode which replicates
the color vibrancy of reversal film.

“PROFESSIONAL PORTRAIT” MODES

Studio Portrait Standard

F1
F1

Suppresses highlight washout with studio flash and produces smooth tonality and natural skin
color. Replicates the “feel” of negative film used in conventional studio photography.

Warm natural skin tones Pro-grade negative profile

a

Slightly higher saturation of skin tones and blue. Exploits the extended dynamic range for fine
tonality even under studio lighting. Superb expression of the natural tone and skin color.

CCD-RAW, 1/60 sec., f/11, ISO100

F1b
F1c

Vivid blue skies and silky skin tones

Characterized by saturated blues and reproduction of the transparent quality of skin tones. Produces smooth
tonality and superb shadow detail under high contrast conditions. Ideal for impressive outdoor portrait results.

Highly modulated impression Pro-grade negative profile

Heightens contrast while expressing just the right shadow detail even under soft light sources.
Natural skin tones in flat studio lighting or under cloudy skies.

FUJICHROME MODE

F2

CCD-RAW, 1/160 sec., f/18, ISO100F1c

Color Reversal Film Profile for vivid color

Captures images with high sharpness, highly saturated colors and dynamic tonality. Brings
colorful landscapes to life with vibrantly rich color.

Film Simulation Mode

Pro-grade Perf or mance

Satisfy scene conditions and your artistic vision
with a choice of 4 exposure control modes

Select from 4 exposure modes: [P] Program, [S]
Shutter Priority Auto, [A] Aperture Priority Auto and
[M]

Manual.

From IS0100 to ISO3200,
select the optimum sensitivity for any scene

Selectable in 1/3 EV steps, FinePix S5 Pro offers a
sensitivity range of IS0100 to IS03200. When the
brightness of the subject exceeds the exposure
control range in the [P], [S] or [A] modes, or an
appropriate level of exposure cannot be achieved
for the Manual [M] mode shutter speed and
aperture, it automatically adjusts sensitivity within
the range of ISO100 to 3200 for optimum exposure.

White Balance Mode with 8 presets

Choose “Auto” for automatic assessment of light
sources or select one of the white balance presets:
Incandescent Light, Fluorescent Lamp (1-5), Fine,
Flash, Shade and Color Temperature. You can also
create and save up to 5 Custom white balance settings,
and fine tune each white balance setting.

1/8,000-second high-speed shutter and
1/250-second high-speed synchro

Shutter speed range of 30 seconds to 1 /8,000 second
and manual setting in 1, 1 /2 or 1 / 3 EV steps put the
professional in total control. Flash synchronization at
speeds up to 1/250 second.

Multi Exposure Function for a single
image from a maximum of 10 exposures

A series of 2 to 10 exposures is recorded as a single image.

Shooting Functions

11-point AF system for high-speed,
high-precision focusing

All eleven focus areas support up to F5.6, and the
range finding is effective down to -1EV of
brightness. Everything from focus accuracy to
subject compensation/tracking and response have
been enhanced by a new cutting-edge algorithm.

[

4 Focus Modes to Match Scene Requirements

●

Single-area AF

Select a single area out of the 7-point or 11-point focus
areas to restrict focusing to only the selected area.

●

Dynamic-area AF

Even if the subject momentarily moves out of one focus
area, other focus areas track and keep it in sharp focus.

●

Dynamic-area AF with Closest Subject Priority

Using the 11-point focus areas to detect the closest
subject, it selects the corresponding focus area and
provides optimum focus.

●

Group Dynamic-AF

Select and activate a cross-pattern group of 5 focus
areas: the center area selected by the user, and the
areas above, below, to the left and right.

AF Lock-On Function with
predictive focus tracking

Even if the subject momentarily shifts out of the focus
area or another object comes between the subject and
the camera, the camera continues to track and adjust
focus to the subject without lens hunting.

3D Color Matrix Metering
for Precision Evaluation of Lighting
Under Diverse Conditions

]

With its powerful 1,005 pixel-RGB sensor, 3D
Color Matrix Metering not only uses conventional
exposure algorithms but also detects highlight area
size and calculates their optimum exposure value
with an exposure assessment algorithm. When
shooting in cloudy conditions or a subject that
is white overall, it can correct for potential
underexposure, or in the case of photographing a
subject against a dark background, it can reduce
washout.

●

Center-Weighted Metering

Metering is calculated with 75% weighting on the
central viewfinder area. You can select the metered
area diameter from 6mm, 8mm, 10mm, 13mm, and
Average in the setup menu.

●

Spot Metering

Working together with the 11-point AF system, Spot
Metering evaluates the optimum exposure of a spot
with a diameter of about 3mm (approx. 2% of the
entire screen) in the selected focus area.

Solid Body Face Zoom In

Rugged magnesium-alloy body
for extreme shooting conditions

The tough and lightweight magnesium alloy shell
of the FinePix S5 Pro frees you to focus on getting
the photo and not worrying about your equipment
under severe shooting conditions. Every seam and
joint has been carefully sealed to prevent invasion
of moisture and dust.

Shutter release durability ­tested to exceed approx.100,000 cycles

Shutter release boasts not only high precision but also
superb durability. A shock-absorbing mirror balancer
minimizes mirror bounce after shutter release,
bringing it instantly to a standstill while vibration
suppression has enhanced silent operation. Also
improved mirror motion speed significantly reduces
image blackout.

Face Zoom In function puts
high-accuracy face detection to work

With a press of the Face Zoom In button on the rear
panel, this function instantly and simultaneously
detects up to 10 faces in an image and zooms in for
an enlarged and sequential display of each for easy
checking of facial details and focus on the LCD
monitor.* This smart function fills a vital gap in the
portrait photography workflow.

＊Depending on the scene conditions, face detection performance may vary.

Complete Image

◎Sample photo is a simulated image

Other Functions

High-performance Viewfinder boasts
magnification of 0.94× and
approximately 95% coverage

The high -magnification viewfinder supports comfortable
viewing and composition. Photographic data and setting
status are clearly displayed in digital readout of the
viewfinder. The Vari-Brite Focus Area display aids
smooth confirmation of the selected focus area, while a
Multi-Display Screen provides a convenient grid display.

Spacious 2.5-inch LCD
with 100% coverage

With approx. 230,000 pixels of resolution, the 2.5-inch
low-temperature polysilicon TFT LCD provides
comfortable viewing of not only image data but also
the large characters and optimized color scheme of the
menu screens. Multi-image playback of 9 thumbnails
is just one example of its functional versatility.

“Live View” Function for more
precise focusing and view angle setting

With the mirror in the up position, the image captured
through the lens can be directly confirmed on the
LCD monitor. According to the scene and the subject,
you can select color or B/W display.

◎Image display time is restricted to a maximum of 30 seconds.

Multi-Data Display Function for a
precise grasp of captured image data

In addition to a standard histogram display, you can
check color and brightness for each RGB channel with
the RGB histogram or receive “washout” warnings.
You can also confirm the “active” AF focus area and
other shooting details for each captured image.

Histogram display

Data display

AF display

Nikon F mount compatibility including
D/G types and AF Nikkor lenses

FinePix S5 Pro is compatible with all D/G-type
AF Nikkor lenses with built-in CPU including the
AF-S series, and is also ready for manual focus Ai
Nikkor lenses and the AF-VR lenses with camera
shake correction.

＊

Certain lens models may not be compatible or may have restrictions on their functionality.

Built-in Pop-up Flash
with i-TTL flash control

The built-in pop-up flash features high-precision
flash output using i-TTL flash control. Ready for
advanced wireless lighting, the built-in Commander
function serves as the master for remote wireless
control of up to 2 “slaved” groups. With a guide number
of approximately 12 (ISO100 • m, 20°C), it provides
view angle coverage for an 18mm lens. Convenient
functions such as repeating flash for multiple-exposure
photography and modeling flash for assessing overall
lighting prior to shooting are also available.

i-TTL Flash with monitor pre-f lash
for precision control of flash output

When working with i-TTL-compatible outboard
flash equipment, the i-TTL flash system with
monitor pre-f lash metering technology can determine
the appropriate flash output by emitting a flash
immediately prior to the shot and metering both
ambient light and the reflected light from the
primary subject with the 1,005-pixel RGB sensor.
Compared with conventional D-TTL, i-TTL
enhances the frequency and output of monitor
flash for more precise lighting. Moreover with the
attachment of a G- or D-type AF Nikkor lens and
the acquisition of subject ranging data from the
lens, it can determine the ideal flash volume.

RAW+ JPEG Mode

Simultaneously record both RAW and JPEG files
of the same image for immediate viewing and
distribution. JPEG data can be saved in either

×

L (4256
S (2304

2848 pixels), M (3024×2016 pixels) and

×

1536 pixels) sizes.

DPI Setting for print-ready resolution setting

Select from 36 to 3,000 DPI, and effectively apply the
selected resolution data with compatible application
software.

“Function Lock” with password
protection prevents costly mishaps

Set password and lock everything except for playback
and shutter release. No accidental operation of the
command dial and function buttons. With a choice of
Total Lock, Basic Function Lock and Lock by
Function, it is easy to select or customize a security
level to match your needs.

●

Basic Function Lock: Lock the entire setup menu

(except Function Lock and Format)

●

Lock by Function: Select specific functions/settings
to lock (Format, Erase, Aperture, Shutter Speed,
Exposure Correction, White Balance, ISO Sensitivity,
Exposure Mode, Flash Correction and other image
quality settings)

Bar-code Management Function for easy
management and “commenting” of image files

Connect an RS-232C compatible bar-code reader* and
append various photographic remarks to image files for
more efficient image file management and workflow.

＊Special required cable sold separately.

High-capacity Lithium-Ion Battery tells you
the remaining capacity and battery health

Fully charged, the newly developed large-capacity
Lithium-Ion battery has sufficient power to capture
approximately 400 images*. Various status data stored
in the battery’s built-in IC chip such as remaining
capacity (%), number of shots since the last charge and
even performance degradation can be displayed on the
LCD monitor.

＊Tested in compliance with CIPA standard

■Functions

1

8

17
18
19
20

9

2

3

4

10

5

11
12

6

13
14

7

21

22

23
24

15

25

16

28

39
40

26

27

29

33

30

31

34
35
36

41
42

43

37

32

38

New Hyper-Utility Software “HS-V3”

Easily replicate even the
high color saturation of reversal film

HS-V3 Hyper-Utility Software uses 3D-LUT (Look
Up Table) image processing technology to convert
CCD-RAW 14bit data into image data files with high
precision. FUJIFILM technology lets you replicate
color quality that approaches that of film. Use
“Velvia” Mode to reproduce blue skies with amazing
clarity and enhance photos with luxuriously saturated
color. Choose the “Studio Portrait EX” Mode for
tonal touch and broad color reproduction rivaling
professional negative film.

RAW FILE
CONVERTER

Hyper-Utility 3
2-Screen Comparison

Masking function

Display the image with the masking size selected on
the camera. Confirm cropping to precisely meet the
various print sizes.

PC “Live View” function for accurate
confir mation of focus and
view angle on the computer display

With the mirror in the up position, PC “Live View” lets
you use the HS-V3 window to directly view the image
seen through the lens of the camera via USB cable. It is
ideal for focus and view angle settings for high-angle
shots that are difficult to check in the viewf inder.

PC Control mode for remote
shutter release from the computer

With FinePix S5 Pro connected to your computer by
USB cable, you can release the shutter with a mouse
click. Right after the shot, the image can be displayed
and checked for focus, color quality and other details.

CCD-RAW, 1/60 sec., f/10, ISO100

Face Zoom In function

In the PC control mode immediately after shooting or when reviewing the
image data stored in the personal computer, Face Zoom In detects the faces
and zooms in for smooth and detailed assessment of facial detail and focus.

■System Requirements

Windows Macintosh

CPU

Connection
Terminal
(Only in the
case of using
the “shooting”
control
application)

OS

Memory
Hard Disk Free

Space for Installation
Monitor

Drive for Installation

＊Please note that this product is not currently compatible with the Windows VistaTM

operating system. However, updater for Windows Vista
March, 2007. Visit http://www.fujifilm.com/products/digital/download/ to update.

PC/AT compatible model equipped
with an Intel Pentium 4-class
processor or higher.

FinePix

Built-in USB Port (USB 2.0 is recommended)

S5 Pro

IEEE1394 (OHCI standard)

FinePix

PCI Board-equipped model or

S3 Pro/

IEEE1394 (OHCI standard)

S2 Pro

CardBus Card equipped model

Windows 2000 Professional SP4
Windows XP Professional SP2
Windows XP Home SP2

Minimum of 512MB (1GB or higher is recommended.)
Minimum of 1GB of free space on the OS system

hard disk drive is required for installation.
1024×768〜3840×2400 dot,

High color (16bit or higher),

×

1200 dot / 32bit or

(1600
higher is recommended)

Optical drive with CD-ROM reading capability.

Macintosh models equipped with a
PowerPC G4 (excluding PCI Graphic
models), PowerPC G5 or an Intel processor.

FireWire 400

FinePix

port is standard.

S3 Pro/
S2 Pro

MacOS X（10.3.9〜10.4.8）

1024×768〜3840×400 dot,
approx. 32,000 colors or higher

×

1200dot / Full Color or

(1600
higher is recommended)

TM

will be available from

1

AF-assist illuminator /
Self- timer lamp/
Red- eye reduction lamp

2

Sub-command dial

3

Depth-of-field preview button

4

FUNC. button

5

10-pin remote terminal

6

Lens release button

7

Focus-mode selector

8

Viewfinder

9

BKT (bracketing) button

10

Erase button / Format button

11

Playback button

12

MENU/OK button

13

DISP (display) / BACK button

14

SET UP button

15

Face zoom in button/
Help button

16

LCD monitor
Diopter adjustment control

17
18

Metering selector

19

AE- L/AF-L (AE /AF lock) button

20

AF- ON button

21

Main- command dial

22

Multi-selector

23

Focus selector lock

24

AF-area mode selector

25

Card slot cover latch

26

Flash pop-up button

27

Flash sync mode button/
Flash compensation button

28

Built-in flash

29

Sync terminal

30

VIDEO OUT (Video output) socket

31

DC IN (power input) socket

32

USB socket

■ Types of CPU lenses and other usable lenses / accessories

Camera setting

Lens / accessory

2

Type G or D AF Nikkor
AF-S, AF-I Nikkor

PC-Micro Nikkor 85mm f/2.8D

-

CPU

1

*

lenses

Non-CPU
lenses

＊1:IX Nikkor lenses cannot be used. ＊2 : Vibration Reduction (VR) supported with VR lenses. ＊3: Spot metering meters selected focus area.
＊4: The camera’s exposure metering and flash control systems do not work properly when shifting and/or tilting the lens, or when an

aperture other than the maximum aperture is used. ＊5 : Electronic range finder cannot be used with shifting or tilting. ＊6:Manual exposure
mode only. ＊7 : Compatible with AF-I Nikkor lenses and with all AF-S lens except AF-S DX VR ED 18-200mm f/3.5-5.6G; AF-S DX ED 12-
24mm f/4G, 17-55mm f/2.8G, 18-55mm f/3.5-5.6G, 18-70mm f/3.5-4.5G, and 55-200mm f/4-5.6G; AF-S VR ED 24-120mm f/3.5-5.6G; and AF-S
ED 17-35mm f/2.8D, 24-85mm f/3.5-4.5G, and 28-70mm f/2.8D. ＊8:With maximum effective aperture of f/5.6 or faster. ＊9:If AF 80­200mm f/2.8S, AF 35-70mm f/2.8S, new-model AF 28-85mm f/3.5-4.5S, or AF 28-85mm f/3.5-4.5S is zoomed in while focusing at minimum
range, image on matte screen in viewfinder may not be in focus when in-focus indicator is displayed. Focus manually using image in
viewfinder as guide. ＊10: With maximum aperture of f/5.6 or faster. ＊11: Some lenses cannot be used. ＊12: Range of rotation for Ai 80-
200mm f/2.8S ED tripod mount limited by camera body. Filters cannot be exchanged while Ai 200-400mm f/4S ED is mounted on camera. ＊
13: If maximum aperture is specified using [NON-CPU LENS DATA] under [MISC.] in the [SET UP] menu, aperture value will be displayed in
viewfinder and control panel. ＊14: Can be used only if lens focal length and maximum aperture are specified using [NON-CPU LENS DATA]
under [MISC.] in the [SET UP] menu. Use spot or center-weighted metering if desired results are not achieved. ＊15: For improved precision,
specify lens focal length and maximum aperture using [NON-CPU LENS DATA] under [MISC.] in the [SET UP] menu. ＊16: Can be used in
manual exposure modes at shutter speeds slower than 1/125 s. If maximum aperture is specified using [NON-CPU LENS DATA] under
[MISC.] in the [SET UP] menu, aperture value will be displayed in the viewfinder and control panel. ＊17: Exposure determined by presetting
lens aperture. In aperture-priority auto exposure mode, preset aperture using lens aperture ring before performing AE lock or shifting lens. In
manual exposure mode, preset aperture using lens aperture ring and determine exposure before shifting lens. ＊18: Exposure compensation
required when used with AI 28-85mm f/3.5-4.5S, AI 35-105mm f/3.5-4.5S, AI 35-135mm f/3.5-4.5S, or AF-S 80-200 mm f/2.8D. See
teleconverter manual for details. ＊19: Requires PK-12 or PK-13 auto extension ring. ＊20:Use preset aperture. In exposure mode A, set
aperture using focusing attachment before determining exposure and taking photograph. • PF-4 Reprocopy Outfit requires PA-4 Camera Holder.

AF-S / AF-I Teleconverter
Other AF Nikkor (except lenses for F3AF
AI-P Nikkor
AI-modified, Ai, Ai-S, or

Series E Nikkor
Medical Nikkor 120mm f/4
Reflex Nikkor
PC-Nikkor

11

*

AI-type Teleconverter
TC-16AS AF Teleconverter
PB-6 Bellows Focusing Attachment
Auto extension rings

-series

(PK

*

,

7

*

12

*

18

*

11-A, 12, or 13;PN-11)

Focus mode

M

(with electronic

AF

range finder)





○

○


─

＊8

○
○＊9
─

─


─
─
─
─
─
─

─


○＊5

＊8

○
○＊9

＊10

○

＊10

○


○
─

＊5

○

＊8

○

＊8

○

＊8

○

＊8

○

4

*

)

19

*

Exposure mode

MPSAM





○

○





○

─

○

○
○
○

○


○
○
○
○
○
○

○

○

○

─



─

─



─



─



─



─

─






○


○＊6



○
○
○

＊13

○


＊16

○

＊13 

○

＊17 

○

＊13 

○

＊13 

○

＊20 

○

＊13

○

3D Color

○


○
○
─
─

─







─
─
─
─
─
─

─





Metering


─


─
─
○
○

＊14

○




─

─
─

＊14 

○

＊14 

○
─

─

＊3

○


○＊3

＊3

○
○＊3
○＊3

＊15

○


─

＊15 

○



○

＊15 

○

＊15 

○



○

○





Release mode dial

33

unlock button

34

QUAL (image quality/ size
button / Reset button

35

WB (White Balance) button

36

ISO (ISO sensitivity) button

37

Release mode dial

38

Accessory shoe

MODE (exposure mode)

39

button / Format button

40

)

Power switch /
Illuminator switch

41

Shutter button

42

Exposure compensation
button / Reset button

43

Control panel

■ Lenses that can be used with the built-in flash

The built-in flash can be used with any CPU lens with a focal length of 18-300mm.Notethat

theflash maybe unable tolighttheentire subject ifthe following lensesarenotused ator
abovetheminimumrangesgivenbelow:

AF-S DX ED 12-24mmf/4G

AF-S ED 17-35mm f/2.8D
AF-S DX IF ED 17-55mm f/2.8G
AF ED 18-35mm f/3.5-4.5D
AF-S DX VR ED 18-200mm f/3.5-5.6G
AF 20-35mm f/2.8Ｄ
AF-S ED 28-70mm f/2.8D

AF Zoom Micro Nikkor ED 70-180mm f/4.5-5.6D

The built-in flash can also be used with Ai-S, Ai, and Ai-modified non-CPU lenses with a
focal length of 18-200mm. Restrictions apply to the following lenses:

• Ai 50-300mm f/4.5, Ai-modified 50-300mm f/4.5, and Ai-S ED 50-300mm f/4.5: use at
135mm and above

■ Lenses with limitations when using the AF-assist illuminator

●Autofocus using the camera’s AF-assist illuminator cannot be performed due to vignetting
with the following lenses at shooting distance within 0.7m (2ft. 4in.):

• AF Micro ED 200mm f/4D • AF-S ED 28-70mm f/2.8D

• AF-S VR ED 24-120mm f/3.5-5.6G • AF Micro ED 70-180mm f/4.5-5.6D

●Autofocus using the camera’s AF-assist illuminator cannot be performed due to vignetting
with the following lens at shooting distance within 1m (3ft. 3in.):

• AF-S DX ED 55-200mm f/4-5.6G

●Autofocus using the camera’s AF-assist illuminator cannot be performed due to vignetting
with the following lenses at shooting distance within 1.5m (4ft. 11in.):

• AF-S VR ED 70-200mm f/2.8G • AF ED 80-200mm f/2.8D

• AF-S ED 80-200mm f/2.8D

●Autofocus using the camera’s AF-assist illuminator cannot be performed due to vignetting
with the following lens at shooting distance within 2.5m (8ft. 2in.):

• AF VR ED 80-400mm f/4.5-5.6D

Lens Zoom position Minimum range

18mm
20mm
24mm
24mm
18mm
18mm
20mm
28mm
35mm
70mm

1.5 m / 4 ft. 11 in.

1.0 m / 3 ft. 3 in.

1.0 m / 3 ft. 3 in.

1.0 m / 3 ft. 3 in.

1.5 m / 4 ft. 11 in.

1.0 m / 3 ft. 3 in.

1.0 m / 3 ft. 3 in.

1.5 m / 4 ft. 11 in.

1.0 m / 3 ft. 3 in.

1.0 m / 3 ft. 3 in.

Hyper-Utility Software
