NEXCOM EBC 355 User Manual

NEXCOM International Co., Ltd.

IoT Automation Solutions

Embedded Computing (3.5” CPU Board) EBC 355

User Manual

NEXCOM International Co., Ltd.

Published April 2015

www.nexcom.com

Content

Contents

Preface

Copyright ............................................................................................. iv

Disclaimer .............................................................................................. iv

Acknowledgements ............................................................................... iv

Regulatory Compliance Statements ........................................................ iv

Declaration of Conformity ...................................................................... iv

RoHS Compliance ................................................................................... v

Warranty and RMA ................................................................................ vi

Safety Information ................................................................................viii

Installation Recommendations ...............................................................viii

Safety Precautions .................................................................................. ix

Technical Support and Assistance ............................................................ x

Conventions Used in this Manual ............................................................ x

Global Service Contact Information ........................................................ xi

Package Contents ................................................................................. xiii

Ordering Information ............................................................................xiv

Chapter 1: Product Introduction

Overview ................................................................................................1

Key Features ...........................................................................................1

Hardware Specifications ..........................................................................2

Knowing Your EBC 355 ..........................................................................4

Top View .............................................................................................4

Bottom View .......................................................................................5

Chapter 2: Jumpers and Connectors

Before You Begin ....................................................................................6

Precautions ............................................................................................6

Jumper Settings ......................................................................................7

Locations of the Jumpers and Connectors ............................................... 8

Top View .............................................................................................8

Bottom View .......................................................................................9

Jumpers ................................................................................................ 10

AT/ATX Power Type Select ..................................................................10

LCD Power Select ..............................................................................10

PWM/CCFL Select ............................................................................. 11

Connector Pin Definitions .....................................................................12

External I/O Interfaces ........................................................................ 12

VGA ...............................................................................................12

HDMI ............................................................................................. 12

USB 3.0 Connector B .....................................................................13

USB 3.0 Connector A ..................................................................... 13

LAN1 Port ......................................................................................14

LAN2 Port ......................................................................................14

Internal Connectors ........................................................................... 15

ATX Power Output Connector ........................................................15

Power Button (ATX) ........................................................................15

RTC Clear Select .............................................................................16

System Reset .................................................................................. 16

ii

EBC 355 User Manual

Content

SMBus ..........................................................................................17

PS/2 Keyboard/Mouse Connector ...................................................17

System Fan Connector ...................................................................18

GPIO Connector ............................................................................. 18

COM Port 1 (RS232) .......................................................................19

COM Port 2 (RS232/RS422/RS485) ................................................. 19

COM Port 3 (RS232) .......................................................................20

COM Port 4 (RS232) .......................................................................20

Mic-in Connector ........................................................................... 21

Line-out Connector ........................................................................ 21

Speaker-out Connector ..................................................................22

LVDS Connector A .........................................................................22

LVDS Connector B .......................................................................... 23

LVDS Panel Inverter Connector ....................................................... 23

Mini-PCIe Slot (Wi-Fi) .....................................................................24

Mini-PCIe Slot (3G) .........................................................................25

SIM Card Connector ......................................................................26

SATA Connector A .........................................................................26

SATA DOM Connector ...................................................................27

SATA Power Connector ..................................................................27

SATA DOM Power Connector .........................................................28

Power/HDD LED Connector ............................................................ 28

Block Diagram

.................................................................................29

Chapter 3: BIOS Setup

About BIOS Setup ................................................................................. 30

When to Configure the BIOS .................................................................30

Default Configuration ........................................................................... 31

Entering Setup ...................................................................................... 31

Legends ................................................................................................ 31

BIOS Setup Utility .................................................................................. 33

Main .................................................................................................33

Advanced ......................................................................................... 33

Chipset ..............................................................................................41

Security .............................................................................................44

Boot .................................................................................................. 45

Save & Exit ........................................................................................46

Appendix A: Watchdog Timer Setting...................47

Appendix B: GPI/O Programming Guide................48

iii

EBC 355 User Manual

Preface

Copyright

This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd.

Disclaimer

The information in this document is subject to change without prior notice and does not represent commitment from NEXCOM International Co., Ltd. However, users may update their knowledge of any product in use by constantly checking its manual posted on our website: http://www.nexcom.com. NEXCOM shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of any product, nor for any infringements upon the rights of third parties, which may result from such use. Any implied warranties of merchantability or fitness for any particular purpose is also disclaimed.

Acknowledgements

EBC 355 is a trademark of NEXCOM International Co., Ltd. All other product names mentioned herein are registered trademarks of their respective owners.

Regulatory Compliance Statements

This section provides the FCC compliance statement for Class B devices and describes how to keep the system CE compliant.

Declaration of Conformity

FCC

This equipment has been tested and verified to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area (domestic environment) is likely to cause harmful interference, in which case the user will be required to correct the interference (take adequate measures) at their own expense.

CE

The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques.

iv

EBC 355 User Manual

Preface

RoHS Compliance

NEXCOM RoHS Environmental Policy and Status Update

NEXCOM is a global citizen for building the digital infrastructure. We are committed to providing green

products and services, which are compliant with European Union RoHS (Restriction on Use of Hazardous Substance in Electronic Equipment) directive 2011/65/EU, to be your trusted green partner and to protect our environment.

RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1% or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium (Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) <

0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.

In order to meet the RoHS compliant directives, NEXCOM has established an engineering and manufacturing task force in to implement the introduction of green products. The task force will ensure that we follow the standard NEXCOM development procedure and that all the new RoHS components and new manufacturing processes maintain the highest industry quality levels for which NEXCOM are renowned.

The model selection criteria will be based on market demand. Vendors and suppliers will ensure that all designed components will be RoHS compliant.

How to recognize NEXCOM RoHS Products?

For existing products where there are non-RoHS and RoHS versions, the suffix “(LF)” will be added to the compliant product name.

All new product models launched after January 2013 will be RoHS compliant. They will use the usual NEXCOM naming convention.

v

EBC 355 User Manual

Preface

Warranty and RMA

NEXCOM Warranty Period

NEXCOM manufactures products that are new or equivalent to new in accordance with industry standard. NEXCOM warrants that products will be free from defect in material and workmanship for 2 years, beginning on the date of invoice by NEXCOM. HCP series products (Blade Server) which are manufactured by NEXCOM are covered by a three year warranty period.

NEXCOM Return Merchandise Authorization (RMA)

▪ Customers shall enclose the “NEXCOM RMA Service Form” with the

returned packages.

▪ Customers must collect all the information about the problems

encountered and note anything abnormal or, print out any on-screen messages, and describe the problems on the “NEXCOM RMA Service Form” for the RMA number apply process.

▪ Customers can send back the faulty products with or without accessories

(manuals, cable, etc.) and any components from the card, such as CPU and RAM. If the components were suspected as part of the problems, please note clearly which components are included. Otherwise, NEXCOM is not responsible for the devices/parts.

▪ Customers are responsible for the safe packaging of defective products,

making sure it is durable enough to be resistant against further damage and deterioration during transportation. In case of damages occurred during transportation, the repair is treated as “Out of Warranty.”

▪ Any products returned by NEXCOM to other locations besides the

customers’ site will bear an extra charge and will be billed to the customer.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

System Level

▪ Component fee: NEXCOM will only charge for main components such as

SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistor, capacitor.

▪ Items will be replaced with NEXCOM products if the original one cannot

be repaired. Ex: motherboard, power supply, etc.

▪ Replace with 3rd party products if needed.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

Board Level

▪ Component fee: NEXCOM will only charge for main components, such

as SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistors, capacitors.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

vi

EBC 355 User Manual

Preface

Warnings

Read and adhere to all warnings, cautions, and notices in this guide and the documentation supplied with the chassis, power supply, and accessory modules. If the instructions for the chassis and power supply are inconsistent with these instructions or the instructions for accessory modules, contact the supplier to find out how you can ensure that your computer meets safety and regulatory requirements.

Cautions

Electrostatic discharge (ESD) can damage system components. Do the described procedures only at an ESD workstation. If no such station is available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis.

vii

EBC 355 User Manual

Preface

Safety Information

Before installing and using the device, note the following precautions:

▪ Read all instructions carefully.

▪ Do not place the unit on an unstable surface, cart, or stand.

▪ Follow all warnings and cautions in this manual.

▪ When replacing parts, ensure that your service technician uses parts

specified by the manufacturer.

▪ Avoid using the system near water, in direct sunlight, or near a heating

device.

▪ The load of the system unit does not solely rely for support from the

rackmounts located on the sides. Firm support from the bottom is highly necessary in order to provide balance stability.

▪ The computer is provided with a battery-powered real-time clock circuit.

There is a danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

Installation Recommendations

Ensure you have a stable, clean working environment. Dust and dirt can get into components and cause a malfunction. Use containers to keep small components separated.

Adequate lighting and proper tools can prevent you from accidentally damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following:

▪ A Philips screwdriver

▪ A flat-tipped screwdriver

▪ A grounding strap

▪ An anti-static pad

Using your fingers can disconnect most of the connections. It is recommended that you do not use needle-nose pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

viii

EBC 355 User Manual

Preface

Safety Precautions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect the equipment from any AC outlet before cleaning or installing

a component inside the chassis. Use a damp cloth. Do not use liquid or spray detergents for cleaning.

4. To prevent electrostatic build-up, leave the board in its anti-static bag until you are ready to install it.

5. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

6. Keep the board away from humidity.

7. Put the board on a stable surface. Dropping it or letting it fall may cause

damage.

8. Wear anti-static wrist strap.

9. Do all preparation work on a static-free surface.

12. All cautions and warnings on the board should be noted.

13. Use the correct mounting screws and do not over tighten the screws.

14. Keep the original packaging and the anti-static bag; in case the board has to be returned for repair or replacement.

10. Make sure the voltage of the power source is correct before

connecting the equipment to the power outlet.

11. Hold the board only by its edges. Be careful not to touch any of the

components, contacts or connections.

ix

EBC 355 User Manual

Preface

CAUTION!

Technical Support and Assistance

1. For the most updated information of NEXCOM products, visit NEXCOM’s

website at www.nexcom.com.

2. For technical issues that require contacting our technical support team or

sales representative, please have the following information ready before calling: – Product name and serial number – Detailed information of the peripheral devices – Detailed information of the installed software (operating system,

version, application software, etc.) – A complete description of the problem – The exact wordings of the error messages

Warning!

1. Handling the unit: carry the unit with both hands and handle it with care.

2. Maintenance: to keep the unit clean, use only approved cleaning products or clean with a dry cloth.

3. CompactFlash: Turn off the unit’s power before inserting or removing a CompactFlash storage card.

Conventions Used in this Manual

Warning: Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself when performing a task.

CAUTION!CAUTION!

Caution: Information to avoid damaging components or losing data.

Note: Provides additional information to complete a task easily.

x

EBC 355 User Manual

Preface

Global Service Contact Information

Headquarters

NEXCOM International Co., Ltd.

15F, No. 920, Chung-Cheng Rd., ZhongHe District, New Taipei City, 23586, Taiwan, R.O.C. Tel: +886-2-8226-7786 Fax: +886-2-8226-7782 www.nexcom.com

America

USA NEXCOM USA

2883 Bayview Drive, Fremont CA 94538, USA Tel: +1-510-656-2248 Fax: +1-510-656-2158 Email: sales@nexcom.com www.nexcom.com

Asia

Taiwan NEXCOM Intelligent Systems

Taipei Office

13F, No.920, Chung-Cheng Rd., ZhongHe District, New Taipei City, 23586, Taiwan, R.O.C. Tel: +886-2-8226-7796 Fax: +886-2-8226-7792 Email: sales@nexcom.com.tw

www.nexcom.com.tw

NEXCOM Intelligent Systems Taichung Office

16F, No.250, Sec. 2, Chongde Rd., Beitun Dist., Taichung City 406, R.O.C. Tel: +886-4-2249-1179 Fax: +886-4-2249-1172 Email: sales@nexcom.com.tw www.nexcom.com.tw

Japan NEXCOM Japan

9F, Tamachi Hara Bldg., 4-11-5, Shiba Minato-ku, Tokyo, 108-0014, Japan Tel: +81-3-5419-7830 Fax: +81-3-5419-7832 Email: sales@nexcom-jp.com www.nexcom-jp.com

China

NEXCOM China

1F & 2F, Block A, No. 16 Yonyou Software Park, No. 68 Beiqing Road, Haidian District, Beijing, 100094, China Tel: +86-010-5704-2680 Fax: +86-010-5704-2681 Email: sales@nexcom.cn www.nexcom.cn

xi

EBC 355 User Manual

Preface

Chengdu Office

9F, Shuxiangxie, Xuefu Garden, No.12 Section 1, South Yihuan Rd., Chengdu, 610061, China Tel: +86-28-8523-0186 Fax: +86-28-8523-0186 Email: sales@nexcom.cn www.nexcom.cn

Shanghai Office

Room 603/604, Huiyinmingzun Plaza Bldg., 1, No.609, Yunlin East Rd., Shanghai, 200333, China Tel: +86-21-5278-5868 Fax: +86-21-3251-6358 Email: sales@nexcom.cn www.nexcom.cn

Shenzhen Office

Room1707, North Block, Pines Bldg., No.7 Tairan Rd., Futian Area, Shenzhen, 518040, China Tel: +86-755-8332-7203 Fax: +86-755-8332-7213 Email: sales@nexcom.cn www.nexcom.cn

Wuhan Office

1-C1804/1805, Mingze Liwan, No. 519 South Luoshi Rd., Hongshan District, Wuhan, 430070, China Tel: +86-27-8722-7400 Fax: +86-27-8722-7400 Email: sales@nexcom.cn www.nexcom.cn

Europe

United Kingdom NEXCOM EUROPE

10 Vincent Avenue, Crownhill Business Centre, Milton Keynes, Buckinghamshire MK8 0AB, United Kingdom Tel: +44-1908-267121 Fax: +44-1908-262042 Email: sales.uk@nexcom.eu www.nexcom.eu

Italy NEXCOM ITALIA S.r.l

Via Lanino 42, 21047 Saronno (VA), Italia Tel: +39 02 9628 0333 Fax: +39 02 9625570 Email: nexcomitalia@nexcom.eu www.nexcomitalia.it

xii

EBC 355 User Manual

Preface

Package Contents

Before continuing, verify that the EBC 355 package that you received is complete. Your package should have all the items listed in the following table.

EBC 355-E3845 (PN: 10E00035502X0) / EBC 355-E3826 (PN: 10E00035500X0)

Item Part Number Name Description Qty

1 20E00035502X0 ASSY EBC 355-E3845 1 2 60177A0359X00 (N)EBC 355 Quick Reference Guide VER:A SIZE:A4 KRAMER 1 3 602DCD0845X00 (N)EBC 355 CD DRIVER VER:1.0 JCL 1

EBC 355 Cable Kit Optional (PN: 10E00035501X0)

Item Part Number Name Description Qty

1 60233ATA73X00 SATA Cable ACMELUX:19922413 Standard L:300mm 1 2 60233PS223X00 EBC563IO PS2 KB/MS Cable ACMELUX:19922439 PS2 to JST 8PIN 2.54mm L:200mm+-10mm 1 3 60233PW148X00 SATA Power Cable BEST:901-0405-300R Housing 4P to Housing 5P L:300mm 1 4 60233SIO62X00 COM Port Cable CP:NEX-110819-01 UL2651#28x9C-DB9+TU1001-10 L:200mm 2

EBC 355 Heatsink Kit Optional (PN: 10E00035504X0)

Item Part Number Name Description Qty

1 5044440079X00 Gasket for VIA CPU KGS:C-4505(20X20x1)+G4000 20x20x1.1mm 1 2 5044440090X00 (H)Thermal Pad APUS:3A2015001001500 15x10x1.5mm XR-PE 1 3 5050300683X00 (N)EBC 355 Heatsink VER:A THERMO TOUCH 74.3x98x21.4mm AL:6063 1

xiii

EBC 355 User Manual

Preface

Ordering Information

The following below provides ordering information for EBC 355.

EBC 355-E3826 (P/N: 10E00035500X0) RoHS Compliant

Low power embedded board with Intel® Atom™ processor E3826 and based on Intel COMs/2x Mini-PCIe/2x Gigabit LAN/2x SATA

EBC 355-E3845 (P/N: 10E000355001X0) RoHS Compliant

Low power embedded board with Intel® Atom™ processor E3845 and based on Intel COMs/2x Mini-PCIe/2x Gigabit LAN/2x SATA

®

integrated graphics engine w/ HDMI/24/48bit LVDS/4x USB3.0/4x

®

integrated graphics engine w/ HDMI/24/48bit LVDS/4x USB3.0/4x

xiv

EBC 355 User Manual

Chapter 1: Product Introduction

Overview

Key Features

▪ On-board Intel® Atom™ Processor E3800 Product Family

▪ One 204-pin SO-DIMM socket supports up to 8GB DDR3L 1066/1333

MHz SDRAM

▪ Display: HDMI/VGA/1x LVDS (2x DF13 20-pin 24/48-bit Single channel)

▪ 2x Mini-PCIe

®

▪ 2x Intel

▪ 2x SATA2.0

▪ 4x USB3.0, 4-in/4-out GPIO, Mic-in , Speak out

▪ Serial port: 3x RS232, 1x RS232/422/485 port

▪ Support AT/ATX mode and single +12VDC input

i210 PCI Express Gigabit Ethernet

1

EBC 355 User Manual

Chapter 1: Product Introduction

Hardware Specifications

CPU Support

▪ Support Intel® Atom™ processor E3800 product family

Main Memory

▪ Single 204-pin SO-DIMM socket supports up to 8 GB DDR3L 1066/1333

MHz SDRAM

Platform Control Hub

▪ Atom™ processor E3800 product family (formerly codenamed “Bay

Trail-I”)

BIOS

▪ AMI System BIOS ▪ Plug and play support ▪ Advanced Power Management and Advanced Configuration & Power

Interface support

▪ LVDS interface: 1x dual (24/48-bit) LVDS panel, resolution up to 1920 x

1200 DF13 20-pin LVDS connector for internal connection

Audio

▪ Realtek ALC886 CODEC for High Definition: 1x 4 2.0 pitch pin-header for Mic-in 1x 4 2.0 pitch pin-header for Line-out 1x 5 2.0 pitch pin-header for speaker out

On-board LAN

▪ 2x Intel® i210 Gigabit Ethernet

▪ Support PXE boot from LAN, wake on LAN function

Expansion

▪ 2x Mini-PCIe

On-board LAN

▪ 2x Intel® PCI Express Gigabit Ethernet ▪ Support Boot From LAN (PXE) ▪ 2x RJ45 with LED

Display

▪ Integrated Intel® Gen.7 Graphics Engine ▪ Analog VGA interface ▪ Analog VGA interface: 1x DB-15 connector, resolution up to 1920 x 1200

@75Hz

▪ HDMI interface: 1x HDMI connector, resolution up to 1920 x 1200

I/O Interface

▪ Serial port: 4 ports COM1, 3, 4 support RS232 with 10-pin box header COM2 support RS232/422/485 with 10-pin box header

▪ USB 3.0: 4 ports 4x ports edge connector

▪ 8 GPIO lines via header (GPI 0~3 and GPO0~3) TTL level (0/5V)

▪ On-board power LED and HDD active LED pin header

▪ 1x 4-pin fan connector (for CPU)

▪ 1x keyboard/mouse pin header

▪ Onboard buzzer/SMBus2.0/reset SW/on & off switch button

2

EBC 355 User Manual

Chapter 1: Product Introduction

Edge I/O Interface

▪ 1x VGA connector ▪ 1x HDMI connector ▪ 2x dual stack USB 3.0 connector ▪ 2x RJ45 with LED connector

Watchdog Timer

▪ Watchdog time-out can be programmed by software from 1 second to

255 seconds, and from 1 minute to 255 minutes (tolerance 15% under room temperature 25°C)

Storage

▪ 2x SATA2.0 ports

System Monitor

▪ Monitoring of 4 voltages and 2 temperatures ▪ 4 voltage (Vcore, +12V, +3.3V, 5V) ▪ 2 temperatures (CPU, system) ▪ 1 fan speed detection

On-board RTC

▪ On-chip RTC with battery backup ▪ 1x external Li-ion battery

Dimensions

▪ 146mm (L) x 102mm (W) 5.7” x 4.0”

Environment

▪ Board level operating temperatures: -20°C to 60°C

▪ Storage temperatures: -25°C to 85°C

▪ Relative humidity: 10% to 90% (operating, non-condensing) 5% to 95% (non-operating, non-condensing)

Certifications

▪ Meet CE

▪ FCC Class A

Power Requirements

▪ Power requirement: +12V DC Input ▪ One 4-pin power connector

3

EBC 355 User Manual

Chapter 1: Product Introduction

Knowing Your EBC 355

Top View

+12V DC Input

Reset

Power

PWM/CCFL

Select

JP2: SMBus JP3: LCD Power Select

LVDS Panel Inverter

System FAN

LVDS A

LVDS B

SATA

SATA DOM

SATA Power

SATA DOM

Power

COM2 COM3

J6: COM1, J7: COM4 Speaker-out

Line-out

Mic-in

Power/HDD LED

PS/2 K/B Mouse

GPIO

AT/ATX Select

VGA

LAN2LAN1USB 2/3 USB 0/1HDMI

4

EBC 355 User Manual

Chapter 1: Product Introduction

Bottom View

Mini-PCIe SIM

SO-DIMM

5

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

This chapter describes how to set the jumpers and connectors on the EBC 355 motherboard.

Before You Begin

▪ Ensure you have a stable, clean working environment. Dust and dirt can

get into components and cause a malfunction. Use containers to keep small components separated.

▪ Adequate lighting and proper tools can prevent you from accidentally

damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following: – A Philips screwdriver – A flat-tipped screwdriver – A set of jewelers screwdrivers – A grounding strap – An anti-static pad

▪ Using your fingers can disconnect most of the connections. It is

recommended that you do not use needle-nosed pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

▪ Before working on internal components, make sure that the power is off.

Ground yourself before touching any internal components, by touching a metal object. Static electricity can damage many of the electronic components. Humid environments tend to have less static electricity than

dry environments. A grounding strap is warranted whenever danger of static electricity exists.

Precautions

Computer components and electronic circuit boards can be damaged by discharges of static electricity. Working on computers that are still connected to a power supply can be extremely dangerous.

Follow the guidelines below to avoid damage to your computer or yourself:

▪ Always disconnect the unit from the power outlet whenever you are

working inside the case.

▪ If possible, wear a grounded wrist strap when you are working inside the

computer case. Alternatively, discharge any static electricity by touching the bare metal chassis of the unit case, or the bare metal body of any other grounded appliance.

▪ Hold electronic circuit boards by the edges only. Do not touch the

components on the board unless it is necessary to do so. Don’t flex or stress the circuit board.

▪ Leave all components inside the static-proof packaging that they shipped

with until they are ready for installation.

▪ Use correct screws and do not over tighten screws.

6

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

Jumper Settings

A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open.

Refer to the illustrations below for examples of what the 2-pin and 3-pin jumpers look like when they are short (on) and open (off).

Two-Pin Jumpers: Open (Left) and Short (Right)

Three-Pin Jumpers: Pins 1 and 2 are Short

3

2

1

3

2

7

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

J2CN2CN3

Locations of the Jumpers and Connectors

The figure below shows the location of the jumpers and connectors.

Top View

JP11

H1

C150

C152

VER:C

EBC355

4BE00355C1X10

1

2

JP13

3

2

1

JP12

2

1

3

CN1

JP1

JP2

CON1

4

JP3

BJ BH BG BE BC BA AW AU AR AN

AL AJ AG AE AC AA W U R N L J G

E C A

1

357

9

11

1315171921

232527

2931333537

3941434547

G

R284

FB12

C201

FB13FB11FB14

R306R322

C211

C210

C227

MADE IN TAIWAN

H4

1

495153

R264

L

C175 R274

F

R905

R278

R906 R288

BZ1

CN8

USB2 USB1

18

9

1

VGA1

9

2

4

7

15

11

711132

4

9

CN4J1

20

1

19

1

20

19

CN6

65

97

18

14

9

5

1

4

R1

2

1

2

7

OZI

2

1NO

1

SW1

7

4

C12

1

CN5

1

L1

M5

CN7

18

16

32

H3

1

LAN1 LAN2

1

14

10

14

9

1

5

4

2

11

14

2

10

2

10

1

9

19

H2

1

JP4

3

2

J3

JP6

17

15

J4

1

J6

2

19

1

5

6

2

1

7

8

9

10

JP7

1

2

1

2

10

J5

1

10

J7

1

JP8

5

1

4

JP10

JP9

2

1

8

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

Bottom View

3

4 2

1

5

6

2

10

9

718

1

2

1

4

17

1 7

1 31 3

1 3

1 4

2

3

4

DIMM1

CN10

1

2

15

16

17

18

CN9

204

203

51

5 1

414

1

52

74

73

72

MADE IN TAIWAN

4BE00355C1X10

EBC355

71

VER:C

2

611121

381314 10

5

15

4

2

9

7

9

1 3

1

1 2

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

Jumpers

AT/ATX Power Type Select

Connector type: 1x3 3-pin header, 2.0mm pitch Connector location: JP13

1 3 1 3

Pin Settings

1-2 On AT Mode 2-3 On ATX Mode

LCD Power Select

Connector type: 1x3 3-pin header, 2.54mm Connector location: JP3

Pin Settings

1-2 On VCC3 2-3 On VCC5

10

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

PWM/CCFL Select

Connector type: 1x3 3-pin header, 2.0mm pitch Connector location: JP1

1 3

Pin Definition

1-2 CCFL 2-3 PWM

11

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

Connector Pin Definitions

External I/O Interfaces

VGA

Connector type: DB-15 port, 15-pin D-Sub Connector location: VGA1

5

1

15 11

Pin Definition Pin Definition

1 RED_VGA 2 GREEN_VGA

3 BLUE_VGA 4 NC

5 GND 6 VGADET

7 GND 8 GND

9 VCC5 10 GND

11 NC 12 DATA_VGA

13 HSYNC_VGA 14 VSYNC_VGA

15 DDCCLK_VGA

HDMI

Connector type: HDMI port Connector location: CN8

119

20 2

Pin Definition Pin Definition

1 DATA2P 2 GND

3 DATA2N 4 DATA1P

5 GND 6 DATA1N

7 DATA0P 8 GND

9 DATA0N 10 CLKP

11 GND 12 CLKN

13 NC 14 NC

15 SCL CLK 16 SCL Data

17 GND 18 VCC5

19 HPD MH1 GND

MH2 GND MH3 GND

MH4 GND

12

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

USB 3.0 Connector B

Connector type: Dual USB port, Type A Connector location: USB2

10 13

9

1

Pin Definition Pin Definition

1 VCC5 2 DATA03 DATA0+ 4 GND 5 USB_RX2- 6 USB_RX2+ 7 GND 8 USB_TX2-

9 USB_TX2+ 10 VCC5 11 DATA1- 12 DATA1+ 13 GND 14 USB_RX315 USB_RX3+ 16 GND 17 USB_TX3- 18 USB_TX3+

1418

5 9

4

USB 3.0 Connector A

Connector type: Dual USB port, Type A Connector location: USB1

10 13

1

Pin Definition Pin Definition

1 VCC5 2 DATA03 DATA0+ 4 GND 5 USB_RX0- 6 USB_RX0+ 7 GND 8 USB_TX0-

9 USB_TX0+ 10 VCC5 11 DATA1- 12 DATA1+ 13 GND 14 USB_RX115 USB_RX1+ 16 GND 17 USB_TX1- 18 USB_TX1+

1418

5

4

13

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

ACT LINK

LAN1 Port

Connector type: RJ45 port with LEDs Connector location: LAN1

Act Status

Flashing Yellow Data activity

Off No activity

8 1

Link Status

Steady Green 1G network link

Steady Orange 100Mbps network link

Off No link

Pin Definition Pin Definition

1 LAN1_MDI0P 2 LAN1_MDI0N 3 LAN1_MDI1P 4 LAN1_MDI1N 5 1.5V 6 GND 7 LAN1_MDI2P 8 LAN1_MDI2N

9 LAN1_MDI3P 10 LAN1_MDI3N 11 LAN1_LED_LINK# 12 LAN1_LED_LINK1G# 13 LAN1_LED_ACT# 14 3VSB

LAN2 Port

Connector type: RJ45 port with LEDs Connector location: LAN2

Act Status

Flashing Yellow Data activity

Off No activity

8 1

Link Status

Steady Green 1G network link

Steady Orange 100Mbps network link

Off No link

Pin Definition Pin Definition

1 LAN2_MDI0P 2 LAN2_MDI0P 3 LAN2_MDI1P 4 LAN2_MDI1N 5 1.5V 6 GND 7 LAN2_MDI2P 8 LAN2_MDI2N

9 LAN2_MDI3P 10 LAN2_MDI3N 11 LAN2_LED_LINK# 12 LAN2_LED_LINK1G# 13 LAN2_LED_ACT# 14 3VSB

14

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

12

Internal Connectors

ATX Power Output Connector

Connector type: 2x2 Aux power connector Connector location: CON1

1 2

3 4

Power Button (ATX)

Connector type: 1x2 2-pin header, 2.0mm pitch Connector location: JP12

Pin Definition

1 GND 2 GND 3 12V 4 12V

15

Pin Definition

1 ATXBT 2 GND

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

12

RTC Clear Select

Connector type: 2x2 4-pin DIP switch Connector location: SW1

O

N

1

2

Pin Definition

1 ON Clear CMOS 2 ON Clear ME

System Reset

Connector type: 1x2 2-pin header, 2.0mm pitch Connector location: JP11

Pin Definition

1 Reset 2 GND

16

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

17

28

SMBus

Connector type: 1x3 3-pin header, 2.0mm pitch Connector location: JP2

1 3

Pin Definition

1 SMB_CLK 2 SMB_DATA 3 GND

PS/2 Keyboard/Mouse Connector

Connector type: 2x4 8-pin header, 2.54mm pitch Connector location: JP6

Pin Definition Pin Definition

1 VCC5 2 VCC5

3 KDAT_R 4 MDAT_R

5 KCLK_R 6 MCLK_R

7 GND 8 GND

17

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

19

21

System Fan Connector

Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: CN1

1 4

Pin Definition

1 GND 2 12V 3 FANIN 4 FANOUT

GPIO Connector

Connector type: 2x5 10-pin header, 2.0mm pitch Connector location: JP7

0

Pin Definition Pin Definition

1 VCC5 2 GND

3 GPO0 4 GPI0

5 GPO1 6 GPI1

7 GPO2 8 GPI2

9 GPO3 10 GPI3

18

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

10 1

COM Port 1 (RS232)

Connector type: 1x10 10-pin Wafer, 1.0mm pitch Connector location: J6

Pin Definition Pin Definition

1 DCD1 2 RXD1 3 TXD1 4 DTR1 5 GND 6 DSR1 7 RTS1 8 CTS1 9 RI1 10 GND

COM Port 2 (RS232/RS422/RS485)

Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J4

Pin Definition Pin Definition

1 DCD2 2 RXD2

3 TXD2 4 DTR2

5 GND 6 DSR2

7 RTS2 8 CTS2

9 RI2 10 GND

19

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

10 1

COM Port 3 (RS232)

Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J5

Pin Definition Pin Definition

1 DCD3 2 RXD3 3 TXD3 4 DTR3 5 GND 6 DSR3 7 RTS3 8 CTS3 9 RI3 10 GND

COM Port 4 (RS232)

Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J7

Pin Definition Pin Definition

1 DCD4 2 RXD4

3 TXD4 4 DTR4

5 GND 6 DSR4

7 RTS4 8 CTS4

9 RI4 10 GND

20

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

14

Mic-in Connector

Connector type: 1x4 4-pin header, 2.0mm pitch Connector location: JP9

Pin Definition

1 MIC1_L 2 GND 3 MIC_JD 4 MIC1_R

Line-out Connector

Connector type: 1x4 4-pin header, 2.0mm pitch Connector location: JP10

Pin Definition

1 LOUT_L 2 GND 3 LOUT_JD 4 LOUT_R

21

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

Speaker-out Connector

Connector type: 1x5 5-pin header, 2.0mm pitch Connector location: JP8

1 5

Pin Definition Pin Definition

1 FRONT_L+ 2 FRONT_L3 GND 4 FRONT_R+ 5 FRONT_R

LVDS Connector A

Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN4

1 19 2 20

Pin Definition Pin Definition

1 LVDS_DDC_CLK 2 LVDS_DDC_DATA

3 Panel_VDD 4 LVDSA_DATA0

5 LVDSA_DATA3 6 LVDS_DATA#0

7 LVDSA_DATA#3 8 Panel_VDD

9 GND 10 LVDSA_DATA1

11 LVDSA_CLK 12 LVDSA_DATA#1 13 LVDSA_CLK# 14 GND 15 GND 16 Panel Inverter 12V 17 LVDSA_DATA2 18 Panel_backlight 19 LVDSA_DATA#2 20 GND

22

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

LVDS Connector B

Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN6

1 19 2 20

Pin Definition Pin Definition

1 LVDS_DDC_CLK 2 LVDS_DDC_DATA 3 Panel_VDD 4 LVDSB_DATA0 5 LVDSB_DATA3 6 LVDSB_DATA#0 7 LVDSB_DATA#3 8 Panel_VDD

9 GND 10 LVDSB_DATA1 11 LVDSB_CLK 12 LVDSB_DATA#1 13 LVDSB_CLK# 14 GND 15 GND 16 Panel Inverter 12V 17 LVDSB_DATA2 18 Panel_backlight 19 LVDSB_DATA#2 20 GND

LVDS Panel Inverter Connector

Connector type: 1x7 JST, 7-pin header, 2.0mm pitch Connector location: J1

7 1

Pin Definition Pin Definition

1 VCC5 2 +12V

3 +12V 4

5 GND 6 GND 7 Panel Backlight Enable

Panel Backlight

Brightness Control

23

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

Mini-PCIe Slot (Wi-Fi)

Connector location: CN7

1 2

51 52

Pin Definition Pin Definition

1 WAKE# 2 +3VSB

3 NC 4 GND

5 NC 6 +1.5V

7 CLKREQ# 8 NC

9 GND 10 NC

11 REF CLK- 12 NC

13 REF CLK+ 14 NC

15 GND 16 NC

17 NC 18 GND

19 NC 20 Disable#

21 GND 22 PERST#

23 PCIERX1N 24 +3VSB

25 PCIERX1P 26 GND

24

Pin Definition Pin Definition

27 GND 28 +1.5V

29 GND 30 SMBCLK

31 PCIETX- 32 SMBDATA

33 PCIETX+ 34 GND

35 GND 36 USB_0N

37 GND 38 USB_0P

39 +3VSB 40 GND

41 +3VSB 42 NC

43 GND 44 NC

45 NC 46 NC

47 NC 48 +1.5V

49 NC 50 GND

51 NC 52 +3VSB

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

Mini-PCIe Slot (3G)

Connector location: CN10

1 2

51 52

Pin Definition Pin Definition

1 WAKE# 2 +3VSB

3 NC 4 GND

5 NC 6 +1.5V

7 CLKREQ# 8 UIM_PWR

9 GND 10 UIM_DATA

11 REF CLK- 12 UIM_CLK

13 REF CLK+ 14 UIM_RESET

15 GND 16 UIM_VPP

17 NC 18 GND

19 NC 20 Disable#

21 GND 22 PERST#

23 PCIERX1N 24 +3VSB

25 PCIERX1P 26 GND

25

Pin Definition Pin Definition

27 GND 28 +1.5V

29 GND 30 SMBCLK

31 PCIETX- 32 SMBDATA

33 PCIETX+ 34 GND

35 GND 36 USB_1N

37 GND 38 USB_1P

39 +3VSB 40 GND

41 +3VSB 42 NC

43 GND 44 NC

45 NC 46 NC

47 NC 48 +1.5V

49 NC 50 GND

51 NC 52 +3VSB

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

SIM Card Connector

Connector type: SIM card slot and 2x3 6-pin header, 2.0mm pitch Connector location: CN9 and JP5 (co-layout)

C5 C6 C7

CN7

Pin Definition Pin Definition

C1 UIM_PWR C2 UIM_RESET C3 UIM_CLK C5 GND C6 UIM_VPP C7 UIM_DATA

JP5

Pin Definition Pin Definition

1 UIM_PWR 2 GND

3 UIM_RESET 4 UIM_VPP

5 UIM_CLK 6 UIM_DATA

C1 C2 C3

SATA Connector A

Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180) Connector location: CN3

1 7

Pin Definition Pin Definition

1 GND 2 SATA_TXP0 3 SATA_TXN0 4 GND 5 SATA_RXN0 6 SATA_RXP0 7 GND

26

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

SATA DOM Connector

Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180) Connector location: CN5

1 7

Pin Definition Pin Definition

1 GND 2 SATA_TXP1

3 SATA_TXN1 4 GND

5 SATA_RXN1 6 SATA_RXP1

7 GND

SATA Power Connector

Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: CN2

1 4

Pin Definition

1 12V 2 GND 3 GND 4 VCC5

27

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

SATA DOM Power Connector

Connector type: 1x2 JST, 2-pin header, 2.5mm pitch Connector location: J2

1 2

Pin Definition

1 VCC5

2 GND

Power/HDD LED Connector

Connector type: 2x2 4-pin header, 2.0mm pitch Connector location: JP4

34

12

Pin Definition

1 PWRLEDP 2 GND 3 HDDLEDP 4 GND

28

EBC 355 User Manual

Chapter 2: Jumpers and Connectors

Block Diagram

VGA

HDMI

LVDS

CH7511B

USB3.0 X4 TUSB8040A

SATA x2

LAN1

LAN2

Intel I210

VGA

DDI

DP

USB3.0

SATA 2.0

PCIe x1

Display

USB

SATA

PCIe

Bay Trail

DDR3L

AUDIO

LPC

PCIe

DDR3L

HDA

LPC

PCIe x1

DDR3L SO-DIMM

ALC886

ITE8786

MiniPCie

3G

MiniPCie

WiFi

TPA6047A4RHBR

GPIO/COM1/COM3/COM4 COM2 RS232/422/485

PS2/HW Monitor

SIM Card

29

EBC 355 User Manual

Chapter 3: BIOS Setup

This chapter describes how to use the BIOS setup program for the EBC 355. The BIOS screens provided in this chapter are for reference only and may change if the BIOS is updated in the future.

To check for the latest updates and revisions, visit the NEXCOM Web site at www.nexcom.com.tw.

About BIOS Setup

The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to suit your individual work needs. It is a ROM-based configuration utility that displays the system’s configuration status and provides you with a tool to set system parameters.

These parameters are stored in non-volatile battery-backed-up CMOS RAM that saves this information even when the power is turned off. When the system is turned back on, the system is configured with the values found in CMOS.

With easy-to-use pull down menus, you can configure such items as:

▪ Hard drives, diskette drives, and peripherals

▪ Video display type and display options

▪ Password protection from unauthorized use

▪ Power management features

The settings made in the setup program affect how the computer performs. It is important, therefore, first to try to understand all the setup options, and second, to make settings appropriate for the way you use the computer.

When to Configure the BIOS

This program should be executed under the following conditions:

▪ When changing the system configuration

▪ When a configuration error is detected by the system and you are

prompted to make changes to the setup program

▪ When resetting the system clock

▪ When redefining the communication ports to prevent any conflicts

▪ When making changes to the Power Management configuration

▪ When changing the password or making other changes to the security

setup

Normally, CMOS setup is needed when the system hardware is not consistent with the information contained in the CMOS RAM, whenever the CMOS RAM has lost power, or the system features need to be changed.

30

EBC 355 User Manual

Chapter 3: BIOS Setup

Default Configuration

Most of the configuration settings are either predefined according to the Load Optimal Defaults settings which are stored in the BIOS or are automatically detected and configured without requiring any actions. There are a few settings that you may need to change depending on your system configuration.

Entering Setup

When the system is powered on, the BIOS will enter the Power-On Self Test (POST) routines. These routines perform various diagnostic checks; if an error is encountered, the error will be reported in one of two different ways:

▪ If the error occurs before the display device is initialized, a series of beeps

will be transmitted.

▪ If the error occurs after the display device is initialized, the screen will

display the error message.

Powering on the computer and immediately pressing <Del> allows you to enter Setup. Another way to enter Setup is to power on the computer and wait for the following message during the POST:

Legends

Key Function

Moves the highlight left or right to select a menu.

Moves the highlight up or down between sub-menu or fields.

Exits the BIOS Setup Utility.

Scrolls forward through the values or options of the highlighted field.

Scrolls backward through the values or options of the highlighted field.

Selects a field.

Displays General Help.

Load previous values.

Load optimized default values.

TO ENTER SETUP BEFORE BOOT PRESS

Press the

key to enter Setup:

Ctrl

+

Alt

+

31

Saves and exits the Setup program.

Press <Enter> to enter the highlighted sub-menu

EBC 355 User Manual

Chapter 3: BIOS Setup

Scroll Bar

When a scroll bar appears to the right of the setup screen, it indicates that there are more available fields not shown on the screen. Use the up and down arrow keys to scroll through all the available fields.

Submenu

When “” appears on the left of a particular field, it indicates that a submenu which contains additional options are available for that field. To display the submenu, move the highlight to that field and press .

32

EBC 355 User Manual

Chapter 3: BIOS Setup

BIOS Setup Utility

Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on the screen. The main menu allows you to select from several setup functions and one exit. Use arrow keys to select among the items and press to accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.

Advanced Chipset Security BootMain

BIOS Information BIOS Vendor Core Version Compliancy Project Version Build Date and Time

CPU Conguration

Microcode Patch

Memory Information Total Memory

System Date

System Time

American Megatrends

5.009 UEFI 2.3; PI 1.2 E355-009 x64 04/01/2014 14:10:54

31e

8192 MB

[Sun 03/09/2014] [18:12:04]

Save & Exit

Set the Date. Use Tab to switch between Date elements.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Advanced

The Advanced menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference.

Setting incorrect field values may cause the system to malfunction.

Advanced Chipset Boot SecurityMain



ACPI Settings



IT8786E Super IO Conguration



Hardware Monitor



CPU Conguration



PPM Conguration



IDE Conguration



USB Conguration

Save & Exit

System ACPI Parameters

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

33

EBC 355 User Manual

Chapter 3: BIOS Setup

IT8786E Super IO Configuration

This section is used to configure the serial ports.

Advanced

Super IO Conguration

Super IO Chip



Serial Port 0 Conguration



Serial Port 1 Conguration



Serial Port 2 Conguration



Serial Port 3 Conguration

IT8786E

Super IO Chip

Displays the Super I/O chip used on the board.

Set Parameters of Serial Port 1 (COMA)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port 1 Configuration

This section is used to configure serial port 1.

Advanced

Serial Port 1 Conguration

Serial Port

Device Settings

[Enabled]

IO=248h; IRQ=5;

Serial Port

Enables or disables the serial port.

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

34

EBC 355 User Manual

Chapter 3: BIOS Setup

Serial Port 2 Configuration

This section is used to configure serial port 2.

Advanced

Serial Port 2 Conguration

Serial Port

Device Settings

Onboard Serial Port Mode

[Enabled]

IO=2F8h; IRQ=3;

[RS232]

Serial Port

Enables or disables the serial port.

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port 3 Configuration

This section is used to configure serial port 3.

Advanced

Serial Port 3 Conguration

Serial Port

Device Settings

[Enabled]

IO=3E8h; IRQ=11;

Serial Port

Enables or disables the serial port.

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Onboard Serial Port Mode

Select this to change the serial port mode to RS232, RS422 or RS485.

35

EBC 355 User Manual

Chapter 3: BIOS Setup

Serial Port 4 Configuration

This section is used to configure serial port 4.

Advanced

Serial Port 4 Conguration

Serial Port

Device Settings

[Enabled]

IO=2E8h; IRQ=10;

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Serial Port

Enables or disables the serial port.

36

EBC 355 User Manual

Chapter 3: BIOS Setup

Hardware Monitor

This section is used to monitor hardware status such as temperature, fan speed and voltages.

Advanced

PC Health Status

CPU temperature System temperature SYS Fan Speed VCore VCC12 VCC5 VCC3

: +54 C : +38 C : N/A : +0.744 V : +11.880 V : +5.070 V : +3.663 V

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

CPU Temperature

Detects and displays the current CPU temperature.

VCore

Detects and displays the Vcore CPU voltage.

VCC12

Detects and displays 12V voltage.

VCC5

Detects and displays 5V voltage.

VCC3

Detects and displays 3.3V voltage.

System Temperature

Detects and displays the current system temperature.

SYS Fan Speed

Detects and displays the system fan speed.

37

EBC 355 User Manual

Chapter 3: BIOS Setup

CPU Configuration

This section is used to configure the CPU.

Advanced

CPU Conguration



Socket 0 CPU Information

CPU Speed 64-bit

Active Processor Cores Limit CPUID Maximum Execute Disable Bit Intel Virtualization Technology

1460 MHz Supported

[All] [Disabled] [Enabled] [Enabled]

Socket specic CPU Information

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Active Processor Cores

Select the number of cores to enable in each processor package.

Execute Disable Bit

When this field is set to Disabled, it will force the XD feature flag to always return to 0. XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3).

Intel® Virtualization Technology

When this field is set to Enabled, the VMM can utilize the additional hardware capabilities provided by Vanderpool Technology.

Limit CPUID Maximum

The CPUID instruction of some newer CPUs will return a value greater than 3. The default is Disabled because this problem does not exist in the Windows series operating systems. If you are using an operating system other than Windows, this problem may occur. To avoid this problem, enable this field to limit the return value to 3 or lesser than 3.

38

EBC 355 User Manual

Chapter 3: BIOS Setup

PPM Configuration

This section is used to configure Intel® PPM configuration.

Advanced

PPM Conguration

EIST

[Disabled]

Enable/Disable Intel SpeedStep

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

EIST

Enables or disables Intel® SpeedStep.

39

EBC 355 User Manual

Chapter 3: BIOS Setup

IDE Configuration

This section is used to configure the SATA drives.

Advanced

IDE Conguration

Serial-ATA (SATA)

SATA Speed Support SATA Mode

Serial-ATA Port 0 SATA Port0 HotPlug

Serial-ATA Port 1 SATA Port1 HotPlug

SATA Port0 Not Present

SATA Port1 Not Present

[Enabled]

[Gen2] [AHCI Mode]

[Enabled] [Disabled]

Serial-ATA (SATA)

Enables or disables the SATA device.

Enable / Disable Serial ATA

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Configure SATA As

Configures the SATA as IDE, AHCI or RAID mode.

IDE This option configures the Serial ATA drives as Parallel ATA physical storage device.

RAID This option allows you to create RAID or Intel Matrix Storage configuration on Serial ATA devices.

AHCI This option configures the Serial ATA drives to use AHCI (Advanced Host Controller Interface). AHCI allows the storage driver to enable the advanced Serial ATA features which will increase storage performance.

Serial-ATA Port 0 and Serial-ATA Port 1

Enables or disables SATA port 0 and SATA port 1.

SATA Port1 Hotplug and SATA Port2 Hotplug

Enables or disables hotplug support on SATA port 1 and SATA port 2.

SATA Speed Support

Configures the SATA controller to Gen1 or Gen2 speed.

40

EBC 355 User Manual

Chapter 3: BIOS Setup

USB Configuration

This section is used to configure the USB.

Advanced

USB Conguration

USB Module Version

USB Devices: 1 Keyboard, 2 Hubs

Legacy USB Support

USB3.0 Support XHCI Hand-off EHCI Hand-off

8.10.27

[Enabled]

[Enabled] [Enabled] [Disabled]

Enables Legacy USB support. AUTO option disables legacy Support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Legacy USB Support

Enable Enables Legacy USB. Auto Disables support for Legacy when no USB devices are connected. Disable Keeps USB devices available only for EFI applications.

USB3.0 Support

Enables or disables USB 3.0 controller support.

XHCI Hand-off and EHCI Hand-off

This is a workaround for OSs that does not support XHCI hand-off and EHCI Hand-off. The XHCI and EHCI ownership change should be claimed by the XHCI and EHCI driver respectively.

Chipset

This section gives you functions to configure the system based on the specific features of the chipset. The chipset manages bus speeds and access to system memory resources.

Advanced Chipset Security BootMain

LVDS Resolution Select

LVDS Dimming Select

►

South Bridge

[1280x1024 24bit D]

[80%]

LVDS Resolution Select

Configures the resolution of the LVDS.

LVDS Dimming Select

Adjusts the brightness of the LVDS backlight.

Save & Exit

Change LVDS Resolution.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

41

EBC 355 User Manual

Chapter 3: BIOS Setup

South Bridge

This section is used to configure the south bridge features.

Chipset

►

Azalia HD Audio

►

USB Conguration PCI Express Conguration

►

High Precision Timer Restore AC Power Loss

[Enabled] [Power On]

Azalia HD Audio Options

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

High Precision Timer

Enables or disables the high precision event timer.

Restore AC Power Loss

Power Off When power returns after an AC power failure, the system’s power is off. You must press the Power button to power-on the system.

Power On When power returns after an AC power failure, the system will automatically power-on.

Last State When power returns after an AC power failure, the system will return to the state where you left off before power failure occurs. If the system’s power is off when AC power failure occurs, it will remain off when power returns. If the system’s power is on when AC power failure occurs, the system will power-on when power returns.

42

EBC 355 User Manual

Chapter 3: BIOS Setup

PCH Azalia Configuration

Chipset

Audio Conguration

Audio Controller

Azalia HDMI Codec

[Enabled]

Control Detection of the Azalia device. Disabled = Azalia will be unconditionally disabled Enabled = Azalia will be unconditionally Enabled Auto = Azalia will be enabled if present, disabled otherwise.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Azalia

Control detection of the Azalia device.

Disabled Azalia will be unconditionally disabled. Enabled Azalia will be unconditionally Enabled.

USB Configuration

Chipset

USB Conguration

XHCI Mode

USB2 Link Power Management

USB 2.0 EHCI debug

[Enabled]

[Disabled]

XHCI Mode

Enables or disables XHCI mode.

USB2 Link Power Management

Enables or disables USB link power management.

Mode of operation of xHCI controller

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Azalia HDMI Codec

Enables or disables internal HDMI codec for Azalia.

43

EBC 355 User Manual

Chapter 3: BIOS Setup

PCI Express Configuration

Chipset

PCI Express Conguration

PCI Express Port 0

Speed

PCI Express Port 1 Speed

PCI Express Port 2 Speed

PCI Express Port 3 Speed

[Enabled]

[Gen 1]

[Enabled] [Gen 1]

Enable or Disable the PCI Express Port 0 in the Chipset.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

PCI Express Port 0 to PCI Express Port 3

Enables or disables the PCI Express ports 0 to 3 on the chipset.

Speed

Configures the PCI Express speed of ports 0 to 3.

Security

Advanced Chipset Security BootMain

Password Description

If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter Setup. In Setup the User Will have Administrator rights. The password length must be in the following range: Minimum length 3 Maximum length 20

Administrator Password

User Password

Administrator Password

Select this to reconfigure the administrator’s password.

User Password

Select this to reconfigure the user’s password.

Save & Exit

Set Administrator Password

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

44

EBC 355 User Manual

Chapter 3: BIOS Setup

Boot

This section is used to configure the boot features.

Advanced

Boot Conguration

Bootup NumLock State

Fast Boot

Network Onboard LAN PXE

Boot Option Priorities

Boot Option #1

Bootup NumLock State

This allows you to determine the default state of the numeric keypad. By default, the system boots up with NumLock on wherein the function of the numeric keypad is the number keys. When set to Off, the function of the numeric keypad is the arrow keys.

Chipset

Security

[On]

[Disabled]

[Enabled] [Disabled]

[UEFI: Built-in EFI . . .]

BootMain

Save & Exit

Select the keyboard NumLock state

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Network

Controls the execution of UEFI and legacy PXE OpROM.

Onboard LAN PXE

Enables or disables onboard LAN PXE ROM.

Boot Option Priorities

Adjust the boot sequence of the system. Boot Option #1 is the first boot device that the system will boot from, next will be #2 and so forth.

Fast Boot

When enabled, the BIOS will shorten or skip some check items during POST. This will decrease the time needed to boot the system.

45

EBC 355 User Manual

Chapter 3: BIOS Setup

Save & Exit

Advanced Chipset Boot SecurityMain

Save Changes and Reset

Discard Changes and Reset

Restore Defaults

Save Changes and Reset

To save the changes and reset, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Save & Exit

Reset the system after saving the changes.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Discard Changes and Reset

To exit the Setup utility without saving the changes, select this field then press <Enter>. You may be prompted to confirm again before exiting.

Restore Defaults

To restore the BIOS to default settings, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

46

EBC 355 User Manual

Appendix A: Watchdog Timer Setting

EBC 355 WatchDog Programming Guide

#define SUPERIO_PORT 0x2E #define WDT_SET 0x72 #define WDT_VALUE 0x73

void main(void) { #Enter SuperIO Configuration outportb(SUPERIO_PORT, 0x87); outportb(SUPERIO_PORT, 0x01); outportb(SUPERIO_PORT, 0x55); outportb(SUPERIO_PORT, 0x55);

# Set LDN outportb(SUPERIO_PORT, 0x07); outportb(SUPERIO_PORT+1 ,0x07);

# Set WDT setting outportb(SUPERIO_PORT, WDT_SET); outportb(SUPERIO_PORT+1, 0x90); # Use the second # Use the minute, change value to 0x40 # Set WDT sec/min outportb(SUPERIO_PORT, WDT_VALUE); outportb(SUPERIO_PORT+1, 0x05); #Set 5 seconds }

47

EBC 355 User Manual

Appendix B: GPI/O Programming Guide

GPI/O (General Purpose Input/Output) pins are provided for custom system design. This appendix provides definitions and its default setting for the ten GPI/O pins. The pin definition is shown in the following table:

Pin GPI/O mode PowerOn

Default

1 VCC - - 2 GND - -

3 GPO0 Low A03h (Bit6) 4 GPI0 High A03h (Bit1)

5 GPO1 Low A02h (Bit5) 6 GPI1 High A05h (Bit5)

7 GPO2 Low A07h (Bit0) 8 GPI2 High A05h (Bit4)

9 GPO3 Low A07h (Bit1) 10 GPI3 High A00h (Bit1)

Control the GPI/O pin 3 level from I/O port A03h bit 6. Control the GPI/O pin 5 level from I/O port A02h bit 5. Control the GPI/O pin 7 level from I/O port A07h bit 0. Control the GPI/O pin 9 level from I/O port A07h bit 1.

The bit is Set/Clear indicated output High/Low.

Address Pin GPI/O mode PowerOn

Default

Address

48

EBC 355 User Manual

Appendix B: GPI/O Programming Guide

GPIO programming sample code

#define GPIO_PORT1 0xA03 #define GPIO_PORT2 0xA02 #define GPIO_PORT3 0xA07 #define GPO0 (0x01 << 6) #define GPO1 (0x01 << 5) #define GPO2 (0x01 << 0) #define GPO3 (0x01 << 1)

#define GPO0_HI outportb(GPIO_PORT1, GPO0) #define GPO0_LO outportb(GPIO_PORT1, 0x00) #define GPO1_HI outportb(GPIO_PORT2, GPO1) #define GPO1_LO outportb(GPIO_PORT2, 0x00) #define GPO2_HI outportb(GPIO_PORT3, GPO2) #define GPO2_LO outportb(GPIO_PORT3, 0x00) #define GPO3_HI outportb(GPIO_PORT3, GPO3) #define GPO3_LO outportb(GPIO_PORT3, 0x00) void main(void) { GPO0_HI; GPO1_LO; GPO2_HI; GPO3_LO; }

49

EBC 355 User Manual
