NEXCOM ICES 254 User Manual

NEXCOM International Co., Ltd.

Industrial Computing Solutions

COM Express Type 2 ICEK 254-T2 (ICES 254 and ICEB 8050C)

Starter Kit User Manual

NEXCOM International Co., Ltd.

Published May 2013

www.nexcom.com

Content

Contents

Preface

Copyright ............................................................................................. iv

Disclaimer .............................................................................................. iv

Acknowledgements ............................................................................... iv

Regulatory Compliance Statements ........................................................ iv

Declaration of Conformity ...................................................................... iv

RoHS Compliance ................................................................................... v

Warranty and RMA ................................................................................ vi

Safety Information ................................................................................viii

Installation Recommendations ...............................................................viii

Safety Precautions .................................................................................. ix

Technical Support and Assistance ............................................................ x

Conventions Used in this Manual ............................................................ x

Global Service Contact Information ........................................................ xi

Package Contents ................................................................................. xiii

Ordering Information ............................................................................xiv

Chapter 1: Product Introduction

Overview - ICES 254 ...............................................................................1

Key Features ...........................................................................................1

Hardware Specifications ..........................................................................2

Knowing Your ICES 254 .......................................................................... 3

Overview - ICEB 8050C ........................................................................... 4

Key Features ...........................................................................................4

Hardware Specifications ..........................................................................5

Knowing Your ICEB 8050C .....................................................................7

Block Diagram ........................................................................................8

ICES 254 .............................................................................................8

ICEB 8050C ......................................................................................... 9

Chapter 2: Jumpers and Connectors

Before You Begin ..................................................................................10

Precautions ..........................................................................................10

Jumper Settings ....................................................................................11

Locations of the Jumpers and Connectors for ICES 254 ......................... 12

Connector Pin Definitions .....................................................................13

Internal Connectors ........................................................................... 13

PCIe DIP Switch .............................................................................. 13

CPU Fan Connector ........................................................................13

High Speed Board-to-Board Connector:

Row A and B, Row C and D ...........................................................14

Locations of the Jumpers and Connectors for ICEB 8050C ....................19

Jumpers ................................................................................................ 20

AT/ATX Power Type Select ..................................................................20

RTC Clear .......................................................................................... 20

LVDS Backlight Power Select .............................................................. 21

COM1 RS232 RI# Pin Power Select ....................................................21

Termal R ............................................................................................22

CF Mode Select .................................................................................22

mPCIe Select .....................................................................................23

DIP Switch Settings ...............................................................................24

ii

ICEK 254-T2 Starter Kit User Manual

Content

Close to Net LPC_SIO1_CLK ..............................................................24

RS232/ RS422/ RS485 Mode Select .................................................... 24

BIOS Select ........................................................................................ 25

Connector Pin Definitions .....................................................................26

External Connectors ..........................................................................26

PS2 Keyboard and Mouse ..............................................................26

Parallel Port .................................................................................... 26

COM1 Port ....................................................................................27

VGA Port .......................................................................................27

LAN and USB1/2 Ports .................................................................... 28

USB2/3 Ports .................................................................................. 28

Audio Connectors .......................................................................... 29

Internal Connectors ........................................................................... 30

HDD LED ........................................................................................ 30

Internal Speaker ............................................................................. 30

USB 5 Port .....................................................................................31

USB 6 Port .....................................................................................31

USB 7 Port .....................................................................................32

COM2 RS232 ................................................................................. 32

GPIO .............................................................................................. 33

CCFL .............................................................................................. 33

LVDS Channel A ............................................................................. 34

LVDS Channel B .............................................................................34

GAL Download Port .......................................................................35

SPI .................................................................................................35

Disable EEPROM .............................................................................36

HW Reset Function .........................................................................36

Power Button ................................................................................. 37

4-Pin Power Connector ..................................................................37

ATX Power Connector ....................................................................38

High Speed Board-to-Board Connector:

Row A and B, Row C and D ...........................................................39

PCIe x16 ........................................................................................44

PCIe x4 ..........................................................................................46

PCIe x1 ..........................................................................................47

Mini-PCIe Slot (3G) .........................................................................48

Mini-PCIe Slot (mSATA) ..................................................................49

SIM Card Slot .................................................................................50

SATA Connectors ...........................................................................50

CFast Slot .......................................................................................51

CF-Master ...................................................................................... 52

IDE-Slave ........................................................................................ 53

PCI Slot .......................................................................................... 54

Chapter 3: System Setup

Setting up the System ........................................................................... 56

External Soft-Power On/Off and Hardware Reset Switches.....................62

Closing the Case ................................................................................... 63

Chapter 4: BIOS Setup

About BIOS Setup ................................................................................. 64

When to Configure the BIOS .................................................................64

Default Configuration ........................................................................... 65

Entering Setup ...................................................................................... 65

Legends ................................................................................................ 65

BIOS Setup Utility .................................................................................. 67

Main .................................................................................................67

Advanced .......................................................................................... 68

Chipset ..............................................................................................76

Boot .................................................................................................. 78

Security .............................................................................................79

Save & Exit ........................................................................................79

Appendix A: Watchdog Timer................................81

WDT Programming Guide .....................................................................81

Appendix B: GPI/O Programming Guide...............83

iii

ICEK 254-T2 Starter Kit User Manual

Preface

Copyright

This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd.

Disclaimer

The information in this document is subject to change without prior notice and does not represent commitment from NEXCOM International Co., Ltd. However, users may update their knowledge of any product in use by constantly checking its manual posted on our website: http://www.nexcom.com. NEXCOM shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of any product, nor for any infringements upon the rights of third parties, which may result from such use. Any implied warranties of merchantability or fitness for any particular purpose is also disclaimed.

Acknowledgements

ICEK 254-T2 is a trademark of NEXCOM International Co., Ltd. All other product names mentioned herein are registered trademarks of their respective owners.

Regulatory Compliance Statements

This section provides the FCC compliance statement for Class B devices and describes how to keep the system CE compliant.

Declaration of Conformity

FCC

This equipment has been tested and verified to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area (domestic environment) is likely to cause harmful interference, in which case the user will be required to correct the interference (take adequate measures) at their own expense.

CE

The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques.

iv

ICEK 254-T2 Starter Kit User Manual

Preface

RoHS Compliance

NEXCOM RoHS Environmental Policy and Status Update

This publication, including all photographs, illustrations and software, is protected under international copyright

laws, with all rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd.

RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1% or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium (Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.

In order to meet the RoHS compliant directives, NEXCOM has established an engineering and manufacturing task force to implement the introduction of green products. The task force will ensure that we follow the standard NEXCOM development procedure and that all the new RoHS components and new manufacturing processes maintain the highest industry quality levels for which NEXCOM are renowned.

The model selection criteria will be based on market demand. Vendors and suppliers will ensure that all designed components will be RoHS compliant.

How to recognize NEXCOM RoHS Products?

For existing products where there are non-RoHS and RoHS versions, the suffix “(LF)” will be added to the compliant product name.

All new product models launched after January 2006 will be RoHS compliant. They will use the usual NEXCOM naming convention.

v

ICEK 254-T2 Starter Kit User Manual

Preface

Warranty and RMA

NEXCOM Warranty Period

NEXCOM manufactures products that are new or equivalent to new in accordance with industry standard. NEXCOM warrants that products will be free from defect in material and workmanship for 2 years, beginning on the date of invoice by NEXCOM. HCP series products (Blade Server) which are manufactured by NEXCOM are covered by a three year warranty period.

NEXCOM Return Merchandise Authorization (RMA)

▪ Customers shall enclose the “NEXCOM RMA Service Form” with the

returned packages.

▪ Customers must collect all the information about the problems

encountered and note anything abnormal or, print out any on-screen messages, and describe the problems on the “NEXCOM RMA Service Form” for the RMA number apply process.

▪ Customers can send back the faulty products with or without accessories

(manuals, cable, etc.) and any components from the card, such as CPU and RAM. If the components were suspected as part of the problems, please note clearly which components are included. Otherwise, NEXCOM is not responsible for the devices/parts.

▪ Customers are responsible for the safe packaging of defective products,

making sure it is durable enough to be resistant against further damage and deterioration during transportation. In case of damages occurred during transportation, the repair is treated as “Out of Warranty.”

▪ Any products returned by NEXCOM to other locations besides the

customers’ site will bear an extra charge and will be billed to the customer.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

System Level

▪ Component fee: NEXCOM will only charge for main components such as

SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistor, capacitor.

▪ Items will be replaced with NEXCOM products if the original one cannot

be repaired. Ex: motherboard, power supply, etc.

▪ Replace with 3rd party products if needed.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

Board Level

▪ Component fee: NEXCOM will only charge for main components, such

as SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistors, capacitors.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

vi

ICEK 254-T2 Starter Kit User Manual

Preface

Warnings

Read and adhere to all warnings, cautions, and notices in this guide and the documentation supplied with the chassis, power supply, and accessory modules. If the instructions for the chassis and power supply are inconsistent with these instructions or the instructions for accessory modules, contact the supplier to find out how you can ensure that your computer meets safety and regulatory requirements.

Cautions

Electrostatic discharge (ESD) can damage system components. Do the described procedures only at an ESD workstation. If no such station is available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis.

vii

ICEK 254-T2 Starter Kit User Manual

Preface

Safety Information

Before installing and using the device, note the following precautions:

▪ Read all instructions carefully.

▪ Do not place the unit on an unstable surface, cart, or stand.

▪ Follow all warnings and cautions in this manual.

▪ When replacing parts, ensure that your service technician uses parts

specified by the manufacturer.

▪ Avoid using the system near water, in direct sunlight, or near a heating

device.

▪ The load of the system unit does not solely rely for support from the

rackmounts located on the sides. Firm support from the bottom is highly necessary in order to provide balance stability.

▪ The computer is provided with a battery-powered real-time clock circuit.

There is a danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

Installation Recommendations

Ensure you have a stable, clean working environment. Dust and dirt can get into components and cause a malfunction. Use containers to keep small components separated.

Adequate lighting and proper tools can prevent you from accidentally damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following:

▪ A Philips screwdriver

▪ A flat-tipped screwdriver

▪ A grounding strap

▪ An anti-static pad

Using your fingers can disconnect most of the connections. It is recommended that you do not use needle-nose pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

viii

ICEK 254-T2 Starter Kit User Manual

Preface

Safety Precautions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a

damp cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a stable surface during installation. Dropping it or

letting it fall may cause damage.

7. The openings on the enclosure are for air convection to protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting

the equipment to the power outlet.

9. Place the power cord in a way so that people will not step on it. Do not

place anything on top of the power cord. Use a power cord that has been approved for use with the product and that it matches the voltage and current marked on the product’s electrical range label. The voltage and current rating of the cord must be greater than the voltage and current rating marked on the product.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service personnel:

a. The power cord or plug is damaged. b. Liquid has penetrated into the equipment. c. The equipment has been exposed to moisture. d. The equipment does not work well, or you cannot get it to work

according to the user’s manual. e. The equipment has been dropped and damaged. f. The equipment has obvious signs of breakage.

15. Do not place heavy objects on the equipment.

16. The unit uses a three-wire ground cable which is equipped with a third pin to ground the unit and prevent electric shock. Do not defeat the purpose of this pin. If your outlet does not support this kind of plug, contact your electrician to replace your obsolete outlet.

17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

ix

ICEK 254-T2 Starter Kit User Manual

Preface

CAUTION!

Technical Support and Assistance

1. For the most updated information of NEXCOM products, visit NEXCOM’s website at www.nexcom.com.

2. For technical issues that require contacting our technical support team or sales representative, please have the following information ready before calling: – Product name and serial number – Detailed information of the peripheral devices – Detailed information of the installed software (operating system,

version, application software, etc.) – A complete description of the problem – The exact wordings of the error messages

Warning!

1. Handling the unit: carry the unit with both hands and handle it with care.

2. Maintenance: to keep the unit clean, use only approved cleaning products or clean with a dry cloth.

3. CompactFlash: Turn off the unit’s power before inserting or removing a CompactFlash storage card.

Conventions Used in this Manual

Warning: Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself when performing a task.

CAUTION!CAUTION!

Caution: Information to avoid damaging components or losing data.

Note: Provides additional information to complete a task easily.

x

ICEK 254-T2 Starter Kit User Manual

Preface

Global Service Contact Information

Headquarters

NEXCOM International Co., Ltd.

15F, No. 920, Chung-Cheng Rd., ZhongHe District, New Taipei City, 23586, Taiwan, R.O.C. Tel: +886-2-8226-7786 Fax: +886-2-8226-7782 www.nexcom.com

America

USA NEXCOM USA

2883 Bayview Drive,Fremont CA 94538, USA Tel: +1-510-656-2248 Fax: +1-510-656-2158 Email: [email protected] www.nexcom.com

Asia

Taiwan Central Taiwan Office

16F, No.250, Sec. 2, Chongde Rd., Beitun Dist., Taichung City 406, R.O.C. Tel: +886-4-2249-1179 Fax: +886-4-2249-1172 Email: [email protected] www.nexcom.com.tw

Japan NEXCOM Japan

9F, Tamachi Hara Bldg.,4-11-5, Shiba Minato-ku, Tokyo, 108-0014, Japan Tel: +81-3-5419-7830 Fax: +81-3-5419-7832 Email: [email protected] www.nexcom-jp.com

China NEXCOM China

2F, Block 4, Venus Plaza, Bldg. 21, ZhongGuanCun Software Park, No. 8, Dongbeiwang West Rd., Haidian District, Beijing, 100193, China Tel: +86-10-8282-5880 Fax: +86-10-8282-5955 Email: [email protected] www.nexcom.cn

Shanghai Office

Room 1505, Greenland He Chuang Bldg., No. 450 Caoyang Rd., Shanghai, 200062, China Tel: +86-21-6150-8008 Fax: +86-21-3251-6358 Email: [email protected] www.nexcom.cn

Nanjing Office

Hall C, Block 17, Tian Xing Cui Lang Bldg., No. 49 Yunnan North Rd., Nanjing, 210018, China Tel: +86-25-8315-3486 Fax: +86-25-8315-3489 Email: [email protected] www.nexcom.cn

Shenzhen Office

Western Room 708, Block 210, Tairan Industry & Trading Place, Futian Area, Shenzhen, 518040, China Tel: +86-755-8332-7203 Fax: +86-755-8332-7213 Email: [email protected] www.nexcom.cn

Wuhan Office

1-C1804/ 1805, Mingze Liwan, No. 519 South Luoshi Rd., Hongshan District, Wuhan, 430070, China Tel: +86-27-8722-7400 Fax: +86-27-8722-7400 Email: [email protected] www.nexcom.cn

xi

ICEK 254-T2 Starter Kit User Manual

Preface

Chengdu Office

9F, Shuxiangxie, Xuefu Garden, No.12 Section 1, South Yihuan Rd., Chengdu, 610061, China Tel: +86-28-8523-0186 Fax: +86-28-8523-0186 Email: [email protected] www.nexcom.cn

Europe

France NEXCOM France

La Grande Arche-Paroi Nord, 92044 Paris La Défense, France Tel: +33 (0) 1 40 90 33 35 Fax: +33 (0) 1 40 90 31 01 Email: [email protected] www.nexcom.eu

Germany

NEXCOM GmbH Leopoldstraße Business Centre, Leopoldstraße 244, 80807 Munich, Germany Tel: +49-89-208039-278 Fax: +49-89-208039-279 Email: [email protected] www.nexcom.eu

Italy

NEXCOM ITALIA S.r.l Via Gaudenzio Ferrari 29, 21047 Saronno (VA), Italia Tel: +39 02 9628 0333 Fax: +39 02 9286 9215 Email: [email protected] www.nexcomitalia.it

United Kingdom NEXCOM EUROPE

10 Vincent Avenue, Crownhill Business Centre, Milton Keynes, Buckinghamshire MK8 0AB, United Kingdom Tel: +44-1908-267121 Fax: +44-1908-262042 Email: [email protected] www.nexcom.eu

xii

ICEK 254-T2 Starter Kit User Manual

Preface

Package Contents

Before continuing, verify that the ICEK 254-T2 package that you received is complete. Your package should have all the items listed in the following table.

Item Description Qty

1 ICES 254 1 2 ICEB 8050C 1 3 Built-in 10.4” LED LCD Panel 1 4 Built-in 100W or 150W Flex-ATX power supply for AC 110V/220V input 1 5 NEXCOM USB card containing ICEK 254-T2 Design-in documentation 1

xiii

ICEK 254-T2 Starter Kit User Manual

Preface

Ordering Information

The following information below provides ordering information for ICEK 254-T2.

ICES 254 (P/N: 10K00025400X0)

Type 2 COM Express Compact Module Atom D2550/ ICH10R/ GbE/ 4SATA/ IDE/ LVDS/ 5PCIe and HDMI

ICES 254-2800 (P/N: 10K00025400X0)

Type 2 COM Express Compact Module Atom N2899/ ICH10R/ GbE/ 4SATA/ IDE/ LVDS/ 5PCIe and HDMI

ICEB 8050C (P/N: 10KB0805001X0) RoHS Compliant

COM Express Type 2, COM.0 Rev. 2.0 Evaluation CRB, VGA/ LVDS/ 8USB2.0/ 2COM/ GbE/ LPT/ 5.1 HD/ SPDIF/ CF/ shared IDE/ mSATA/ CFAST/ PCIex16/ PCIex4/ PCI/ mPCIe, ATX power input

xiv

ICEK 254-T2 Starter Kit User Manual

Chapter 1: Product Introduction

Overview - ICES 254

Key Features

▪ Intel® Atom Dual Core D2550, 1.86GHz

▪ Intel® ICH10R to support Intel® Matrix Storage RAID 0/ 1/ 5/ 10

▪ 1x DDR3 SO-DIMM Socket up to 4GB

▪ Type 2 COM Express Compact size to Support 5 Express Lanes, 32 bit PCI

interface, One IDE, Gigabit LAN and HDMI

1

ICEK 254-T2 Starter Kit User Manual

Chapter 1: Product Introduction

Hardware Specifications

CPU Support

▪ Intel® Atom™ Dual Core processor D2550 1.86Ghz

Chipset

▪ Intel® ICH10R chipset

Main Memory

▪ One DDR3 1067MHz SO-DIMM socket up to 4GB

BIOS

▪ AMI System BIOS ▪ Plug and play support ▪ ACPI 3.0b

Display

▪ Intel® HD graphics with DX10 support ▪ One HDMI down to the carried board ▪ Support single channel 18/24-bit LVDS

Audio

▪ HD audio interface

On-board LAN

▪ Intel® 82574L GbE controller, support boot from LAN, wake on LAN

function

▪ Signals down to I/O board

COM Express Connector

▪ AB

VGA/ LVDS/ GbE/ 8x USB 2.0/ HD Audio/ 4x SATA/ LAN/ GPIO (3.3V)/ LPC bus Five PCIe X1/ SMBus (I2C)/ SPI BIOS

▪ CD

IDE, PCI, HDMI

Power Requirements

▪ +12V, +5VSB ▪ Support both AT and ATX power supply mode ▪ One 3-pins 90 degree edge-connector for DC + 12V fan

Dimensions

▪ 95mm (W) x 95mm (L)

Environment

▪ Board level operating temperatures: -15°C to 60°C ▪ Storage temperatures: -20°C to 80°C ▪ Relative humidity: ▪ 10% to 90% (operating, non-condensing) ▪ 5% to 95% (non-operating, non-condensing)

Certifications

▪ CE approval ▪ FCC Class A

2

ICEK 254-T2 Starter Kit User Manual

Chapter 1: Product Introduction

Knowing Your ICES 254

PCIe DIP

switch

Intel® ICH10R

chipset

SODIMM socket

CPU Fan

Intel® Atom™

CPU

3

ICEK 254-T2 Starter Kit User Manual

Chapter 1: Product Introduction

Overview - ICEB 8050C

Key Features

▪ COM Express COM.0, Rev2.0 evaluation carrier, ATX form-factor

▪ Support Type 2 pin-outs, COMe Extended/ Basic/ Compact Module

▪ Display: VGA & dual channels 18/24-bit LVDS

▪ Bootable CFAST or mini-SATA, CF and shared IDE

▪ PCIe x16, PCIe x4, PCIe x1, PCIx 1 and mini-PCIe for Wi-Fi

▪ PS2/KB/Mouse, LPT/ RS232/422/485, VGA/GbE/4USB/ 5.1, S/PDIF

4

ICEK 254-T2 Starter Kit User Manual

Chapter 1: Product Introduction

Hardware Specifications

Form Factor

▪ ATX Carrier MB, dimension: 305mm x 244mm (12” x 9.9”) ▪ COM Express Evaluation CRB: PICMB COM Express board-to-board

interconnectors, type 2 pin-puts, female, 8mm stack-up height, COM.0 Rev. 2.0

NEXCOM Computer-on-Modules Support List

▪ Compact Size (95x 95mm) : ICES 251/ ICES 251X, ICES 253, ICES 254 ▪ Basic Size (125x 95mm) : ICES 270, ICES 267/ ICES 267S

Expansion

▪ 1x PCIe x16 slot, support PEG interfaces ▪ 1x PCIe x4 slot, optional 4x PCIe x1 signals ▪ 1x PCIe x1 slot and 1x PCI (v2.3) slot ▪ 1x mini-PCIe slot for Wi-Fi with SIM tray

Graphic Interfaces

▪ Graphic Chip: from Type 2 pin-out, COM Express module ▪ CRT: support analog VGA with DB15 connector on the I/O edge ▪ LVDS: dual channels 18/24-bit LVDS connector (dual DF-13-20P) ▪ PCIe x16: optional EBK-A2HDMI (ICES254 only) riser card for HDMI or DP

Super I/O

▪ Winbond W83627DHG-PT

I/O Interface

▪ Serial COM: 2 ports

– 1x edge DB9 connector to support RS232/ 422/ 485 (+5/ +12V by

Ring)

– 1x internal box-header 2.0 pitch to support RS232

▪ USB 2.0: 8 ports

– 4x USB 2.0 ports by stack Type A on edge – 3x USB 2.0 by 4-pins JST 2.0mm JST connector, – 1x internal USB 2.0 to mini-PCIe slot for external wi-fi module

▪ SATA 2.0: 4 ports

– 2x SATA 2.0 ports – 1x mini-SATA by mini-PCIe slot for half-/ full size mSATA-SSD

– 1x CFAST slot for CFAST/ SATA 2.0 ▪ CF: 1x CF/ shared IDE slot onboard (default master-mode) ▪ IDE: 1x 44pins box-header for legacy IDE-HDD ▪ PS/2: 2x PS/2 connectors on edge for Keyboard/ Mouse ▪ Printer Port: 1x DB25 on edge for legacy printer interface ▪ GPIO ports: 8x pins GPIO signals from COMe

(default 5V TTL/ option 3.3V)

Network

▪ LAN chip: from COMe CPU module ▪ Support 1x RJ45/ GbE port on the edge I/O

Audio

▪ HD Audio AL886 with 5.1 channels ▪ Support external S/PDIF interface ▪ Support internal pin-header for L/R speaker-out 2W/ 4 Ohm

5

ICEK 254-T2 Starter Kit User Manual

Chapter 1: Product Introduction

Audio

▪ 1x 2K EEPROM to record PCI Express Lane configuration ▪ ATMEL AT24C32 (or C02) and address 0x57 or (0xAE)

Watchdog Timer

▪ Watchdog timeout can be programmed by software from 1 second to 255

seconds and from 1 minute to 255 minutes (Tolerance 15% temperature 25°C)

On-board RTC

▪ On-chip RTC with battery BR2032

Power Input

▪ Standard ATX 24 pins and AUX 4-pins with 12V

Dimensions

▪ ATX form factor, 305x 244mm (Lx W, 12”x9.6”)

Environment

▪ Operating temperatures: -20°C to 60°C ▪ Storage temperature: -40°C to 85°C ▪ Relative humidity: Operating 10% to 90%, non-condensing

Certifications

▪ CE approval ▪ FCC Class A

6

ICEK 254-T2 Starter Kit User Manual

Chapter 1: Product Introduction

Knowing Your ICEB 8050C

CFast/ SSD

PCIe x1

PCI (v2.3)

PCIe x4

Audio, S/PDIF

PCIe x16

HD 5.1

2USB

GbE LAN/2USB

RS232/422/485

LPT/ VGA

PS/2/ KB & Mouse

mPCIe/ Wi-Fi

Option SIM

mSATA/SSD

ATX Power

18/24-bit LVDS

7

CF SlotIDE (44pins)

Port 80

Battery RTC

ICEK 254-T2 Starter Kit User Manual

Chapter 1: Product Introduction

Block Diagram

ICES 254

COM Express connector A and B

VGA BUS

LVDS BUS

HDA_SDI0

HDA_SDI1

PORT:0-7 USB2.0 BUS

Azalia

DDI PORT0 DDI PORT1

CedarView

VGA

Dual Core CPU

DX10.1 Graphics

DDR3-800/1067

LVDS

559 balls

22*22mm

IHDA

DMI

x4 DMI 4 Lanes

DMI

82801JIR

HDA

PCH

ICH10R

676 mBGA 31x31 mm

USB 2.0 (12)

LPC PCIe *1 (6)

SATA (6)

SPI

HDMI BUS

DDR3

DDR3 800/1067

PCI

SM BUS

VRD12 / IMVP7

COM Express connector C and D

DDR3 SO-DIMM

PCI BUS

LPC BUS

INTEL 82574L

TYPE 2

SATA BUS PORT:0-3 SATA BUS

PCI-E*1 BUS PORT:6

PCI-E*1 BUS PORT:1,2,3,4,5

TYPE 2

SATA to IDE

SATA BUS PORT:4

SATA BUS

8

Marvell

88SA8052B1

ICEK 254-T2 Starter Kit User Manual

Chapter 1: Product Introduction

COM Express connector C and D

TYPE 2TYPE 2

IDE 44PIN

PATA 100/66/33

Box header

Master

Slave

33MHz/32bit

PCI SLOT

PCI BUS

IDSEL=AD20 IRQ=A B C D

PCI-E x16

SLOT

x16 PEG BUS

VGA

Connector

R/G/B

LVDS A

(18/24 bit)LVDS Channel A

Audio CodecHD Audio interface

Audio Connector

EEPROM

I2C BUS

Line IN / Line OUT / MIC IN

SATA *2

SATA x2 BUS

Connector

USB 2.0 *7

USB BUS

Connector

PCI-E x1

PCI-E x4 BUS

SLOT

PCI-E x4

PCI-E x1 BUS

SLOT

LPC BUS

SUPER I/O

KB/MS

COM 1

CF Socket

COM Express connector A and B

LPT

COM 2

(ALC886)

(W83627DHG-PT)

Connector

Page 3

GPI *4

GPIO BUS

GPO *4

TTL LEVLE

232/422/485

RJ45

Giga LAN

Connector

LVDS B (18/24 bit)LVDS Channel B

Connector

232

MiniPCIE

SLOT

PCI-E x1 BUS

USB x1

mSATA

Connector

CFAST

SATA x1 BUS

CEN OUT / SIDE OUT / SPDIF

AMP

Line OUT

SPEAKER

HEARD

ICEB 8050C

9

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

This chapter describes how to set the jumpers and connectors on the ICES 254 and ICEB 8050C motherboard.

Before You Begin

▪ Ensure you have a stable, clean working environment. Dust and dirt can

get into components and cause a malfunction. Use containers to keep small components separated.

▪ Adequate lighting and proper tools can prevent you from accidentally

damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following: – A Philips screwdriver – A flat-tipped screwdriver – A set of jewelers screwdrivers – A grounding strap – An anti-static pad

▪ Using your fingers can disconnect most of the connections. It is

recommended that you do not use needle-nosed pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

▪ Before working on internal components, make sure that the power is off.

Ground yourself before touching any internal components, by touching a metal object. Static electricity can damage many of the electronic components. Humid environments tend to have less static electricity than

dry environments. A grounding strap is warranted whenever danger of static electricity exists.

Precautions

Computer components and electronic circuit boards can be damaged by discharges of static electricity. Working on computers that are still connected to a power supply can be extremely dangerous.

Follow the guidelines below to avoid damage to your computer or yourself:

▪ Always disconnect the unit from the power outlet whenever you are

working inside the case.

▪ If possible, wear a grounded wrist strap when you are working inside the

computer case. Alternatively, discharge any static electricity by touching the bare metal chassis of the unit case, or the bare metal body of any other grounded appliance.

▪ Hold electronic circuit boards by the edges only. Do not touch the

components on the board unless it is necessary to do so. Don’t flex or stress the circuit board.

▪ Leave all components inside the static-proof packaging that they shipped

with until they are ready for installation.

▪ Use correct screws and do not over tighten screws.

10

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Jumper Settings

A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open.

Refer to the illustrations below for examples of what the 2-pin and 3-pin jumpers look like when they are short (on) and open (off).

Two-Pin Jumpers: Open (Left) and Short (Right)

Three-Pin Jumpers: Pins 1 and 2 are Short

3

2

1

3

2

11

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Locations of the Jumpers and Connectors for ICES 254

The figure below shows the location of the jumpers and connectors for ICES 254.

J2

2

7472

204

H4H1

SW1

H2

1

A

10 J1

CT1

C9

1

A

Y

AK

B

3

U2

ICES254 4BKS0254C1X10 MADE IN TAIWAN

71 73

VER:C

302010

31

203

C126

U6

262524232221201918161413121110

272930

RT4

C132

C131

98754321

H3

FB15

3

1

AL AK AJ AH AG AE AD AC AB AA

YW

T

MV

J HPN

F EDLK

C B AG

C139

FAN1

12

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Connector Pin Definitions

Internal Connectors

PCIe DIP Switch

Connector type: 1x4 4-pin DIP switch Connector location: SW1

N

O

1

2

Pin Definition Pin Definition

1 ICH_HDA_SDOUT 2 VCC3 3 ATAIOSEL 4 GND

1 2 3 4

PCIe x1 V X X X

PCIe x4 X X V X

CF Enable X V X X

CF Disable X X X V

CPU Fan Connector

Connector type: 1x3 3-pin header Connector location: FAN1

1 3

Pin Definition Pin Definition

1 GND 2 VCC12 3 VCC5_S

13

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

High Speed Board-to-Board Connector: Row A and B, Row C and D

Connector location: J3

Com Express A&B Connector

Com Express C&D Connector

Pin Definition Pin Definition Pin Definition Pin Definition

A1 GND(FIXED) B1 GND(FIXED) C1 GND(FIXED) D1 GND(FIXED) A2 GBE0_MDI3- B2 GBE0_ACT# C2 IDE_D7 D2 IDE_D5 A3 GBE0_MDI3+ B3 LPC_FRAME# C3 IDE_D6 D3 IDE_D10 A4 GBE0_LINK100# B4 LPC_AD0 C4 IDE_D3 D4 IDE_D11 A5 GBE0_LINK1000# B5 LPC_AD1 C5 IDE_D15 D5 IDE_D12 A6 GBE0_MDI2- B6 LPC_AD2 C6 IDE_D8 D6 IDE_D4 A7 GBE0_MDI2+ B7 LPC_AD3 C7 IDE_D9 D7 IDE_D0 A8 GBE0_LINK# B8 LPC_DRQ0# C8 IDE_D2 D8 IDE_REQ

A9 GBE0_MDI1- B9 LPC_DRQ1# C9 IDE_D13 D9 IDE_IOW# A10 GBE0_MDI1+ B10 LPC_CLK C10 IDE_D1 D10 IDE_ACK# A11 GND(FIXED) B11 GND(FIXED) C11 GND(FIXED) D11 GND(FIXED) A12 GBE0_MDI0- B12 PWRBTN# C12 IDE_D14 D12 IDE_IRQ A13 GBE0_MDI0+ B13 SMB_CK C13 IDE_IORDY D13 IDE_A0

14

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Pin Definition Pin Definition Pin Definition Pin Definition

A14 GBE0_CTREF B14 SMB_DAT C14 IDE_IOR# D14 IDE_A1 A15 SUS_S3# B15 SMB_ALERT# C15 PCI_PME# D15 IDE_A2 A16 SATA0_TX+ B16 SATA1_TX+ C16 PCI_GNT2# D16 IDE_CS1# A17 SATA0_TX- B17 SATA1_TX- C17 PCI_REQ2# D17 IDE_CS3# A18 SUS_S4# B18 SUS_STAT# C18 PCI_GNT1# D18 IDE_RESET# A19 SATA0_RX+ B19 SATA1_RX+ C19 PCI_REQ1# D19 PCI_GNT3# A20 SATA0_RX- B20 SATA1_RX- C20 PCI_GNT0# D20 PCI_REQ3# A21 GND(FIXED) B21 GND(FIXED) C21 GND(FIXED) D21 GND(FIXED) A22 SATA2_TX+ B22 SATA3_TX+ C22 PCI_REQ0# D22 PCI_AD1 A23 SATA2_TX- B23 SATA3_TX- C23 PCI_RESET# D23 PCI_AD3 A24 SUS_S5# B24 PWR_OK C24 PCI_AD0 D24 PCI_AD5 A25 SATA2_RX+ B25 SATA3_RX+ C25 PCI_AD2 D25 PCI_AD7 A26 SATA2_RX- B26 SATA3_RX- C26 PCI_AD4 D26 PCI_C/BE0# A27 BATLOW# B27 WDT C27 PCI_AD6 D27 PCI_AD9 A28 (S)ATA_ACT# B28 AC/HDA_SDIN2 C28 PCI_AD8 D28 PCI_AD11 A29 AC/HDA_SYNC B29 AC/HDA_SDIN1 C29 PCI_AD10 D29 PCI_AD13 A30 AC/HDA_RST# B30 AC/HDA_SDIN0 C30 PCI_AD12 D30 PCI_AD15 A31 GND(FIXED) B31 GND(FIXED) C31 GND(FIXED) D31 GND(FIXED) A32 AC/HDA_BITCLK B32 SPKR C32 PCI_AD14 D32 PCI_PAR A33 AC/HDA_SDOUT B33 I2C_CK C33 PCI_C/BE1# D33 PCI_SERR# A34 BIOS_DIS0# B34 I2C_DAT C34 PCI_PERR# D34 PCI_STOP# A35 THRMTRIP# B35 THRM# C35 PCI_LOCK# D35 PCI_TRDY# A36 USB6- B36 USB7- C36 PCI_DEVSEL# D36 PCI_FRAME# A37 USB6+ B37 USB7+ C37 PCI_IRDY# D37 PCI_AD16 A38 USB_6_7_OC# B38 USB_4_5_OC# C38 PCI_C/BE2# D38 PCI_AD18 A39 USB4- B39 USB5- C39 PCI_AD17 D39 PCI_AD20 A40 USB4+ B40 USB5+ C40 PCI_AD19 D40 PCI_AD22 A41 GND(FIXED) B41 GND(FIXED) C41 GND(FIXED) D41 GND(FIXED)

15

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Pin Definition Pin Definition Pin Definition Pin Definition

A42 USB2- B42 USB3- C42 PCI_AD21 D42 PCI_AD24 A43 USB2+ B43 USB3+ C43 PCI_AD23 D43 PCI_AD26 A44 USB_2_3_OC# B44 USB_0_1_OC# C44 PCI_C/BE3# D44 PCI_AD28 A45 USB0- B45 USB1- C45 PCI_AD25 D45 PCI_AD30 A46 USB0+ B46 USB1+ C46 PCI_AD27 D46 PCI_IRQC# A47 VCC_RTC B47 EXCD1_PERST# C47 PCI_AD29 D47 PCI_IRQD# A48 EXCD0_PERST# B48 EXCD1_CPPE# C48 PCI_AD31 D48 PCI_CLKRUN# A49 EXCD0_CPPE# B49 SYS_RESET# C49 PCI_IRQA# D49 PCI_M66EN A50 LPC_SERIRQ B50 CB_RESET# C50 PCI_IRQB# D50 PCI_CLK A51 GND(FIXED) B51 GND(FIXED) C51 GND(FIXED) D51 GND(FIXED) A52 PCIE_TX5+ B52 PCIE_RX5+ C52 DDI0_AUXP D52 DDI0_TX0_P A53 PCIE_TX5- B53 PCIE_RX5- C53 DDI0_AUXN D53 DDI0_TX0_N A54 GPI0 B54 GPO1 C54 TYPE0# D54 PEG_LANE_RV# A55 PCIE_TX4+ B55 PCIE_RX4+ C55 PEG_RX1+ D55 DDI0_TX1_P A56 PCIE_TX4- B56 PCIE_RX4- C56 PEG_RX1- D56 DDI0_TX1_N A57 GND B57 GPO2 C57 TYPE1# D57 TYPE2# A58 PCIE_TX3+ B58 PCIE_RX3+ C58 PEG_RX2+ D58 DDI0_TX2_P A59 PCIE_TX3- B59 PCIE_RX3- C59 PEG_RX2- D59 DDI0_TX2_N A60 GND(FIXED) B60 GND(FIXED) C60 GND(FIXED) D60 GND(FIXED) A61 PCIE_TX2+ B61 PCIE_RX2+ C61 PEG_RX3+ D61 DDI0_TX3_P A62 PCIE_TX2- B62 PCIE_RX2- C62 PEG_RX3- D62 DDI0_TX3_N A63 GPI1 B63 GPO3 C63 RSVD D63 RSVD A64 PCIE_TX1+ B64 PCIE_RX1+ C64 RSVD D64 RSVD A65 PCIE_TX1- B65 PCIE_RX1- C65 PEG_RX4+ D65 PEG_TX4+ A66 GND B66 WAKE0# C66 PEG_RX4- D66 PEG_TX4A67 GPI2 B67 WAKE1# C67 RSVD D67 GND A68 PCIE_TX0+ B68 PCIE_RX0+ C68 PEG_RX5+ D68 PEG_TX5+ A69 PCIE_TX0- B69 PCIE_RX0- C69 PEG_RX5- D69 PEG_TX5-

16

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Pin Definition Pin Definition Pin Definition Pin Definition

A70 GND(FIXED) B70 GND(FIXED) C70 GND(FIXED) D70 GND(FIXED) A71 LVDS_A0+ B71 LVDS_B0+ C71 PEG_RX6+ D71 DDI0_HPD A72 LVDS_A0- B72 LVDS_B0- C72 PEG_RX6- D72 PEG_TX6A73 LVDS_A1+ B73 LVDS_B1+ C73 SDVO_DATA D73 DDI0_DDC_SCL A74 LVDS_A1- B74 LVDS_B1- C74 PEG_RX7+ D74 PEG_TX7+ A75 LVDS_A2+ B75 LVDS_B2+ C75 PEG_RX7- D75 PEG_TX7A76 LVDS_A2- B76 LVDS_B2- C76 GND D76 GND A77 LVDS_VDD_EN B77 LVDS_B3+ C77 RSVD D77 IDE_CBLID# A78 LVDS_A3+ B78 LVDS_B3- C78 PEG_RX8+ D78 PEG_TX8+ A79 LVDS_A3- B79 LVDS_BKLT_EN C79 PEG_RX8- D79 PEG_TX8A80 GND(FIXED) B80 GND(FIXED) C80 GND(FIXED) D80 GND(FIXED) A81 LVDS_A_CK+ B81 LVDS_B_CK+ C81 PEG_RX9+ D81 PEG_TX9+ A82 LVDS_A_CK- B82 LVDS_B_CK- C82 PEG_RX9- D82 PEG_TX9A83 LVDS_I2C_CK B83 LVDS_BKLT_CTRL C83 RSVD D83 RSVD A84 LVDS_I2C_DAT B84 VCC_5V_SBY C84 GND D84 GND A85 GPI3 B85 VCC_5V_SBY C85 PEG_RX10+ D85 PEG_TX10+ A86 KBD_RST# B86 VCC_5V_SBY C86 PEG_RX10- D86 PEG_TX10A87 KBD_A20GATE B87 VCC_5V_SBY C87 GND D87 GND A88 PCIE_CLK_REF+ B88 BIOS_DIS1# C88 PEG_RX11+ D88 PEG_TX11+ A89 PCIE_CLK_REF- B89 VGA_RED C89 PEG_RX11- D89 PEG_TX11A90 GND(FIXED) B90 GND(FIXED) C90 GND(FIXED) D90 GND(FIXED) A91 SPI_POWER B91 VGA_GRN C91 PEG_RX12+ D91 PEG_TX12+ A92 SPI_MISO B92 VGA_BLU C92 PEG_RX12- D92 PEG_TX12A93 GPO0 B93 VGA_HSYNC C93 GND D93 GND A94 SPI_CLK B94 VGA_VSYNC C94 PEG_RX13+ D94 PEG_TX13+ A95 SPI_MOSI B95 VGA_I2C_CK C95 PEG_RX13- D95 PEG_TX13A96 GND B96 VGA_I2C_DAT C96 GND D96 GND A97 TYPE10# B97 SPI_CS# C97 RSVD D97 PEG_ENABLE#

17

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Pin Definition Pin Definition Pin Definition Pin Definition

A98 RSVD B98 RSVD C98 PEG_RX14+ D98 PEG_TX14+ A99 RSVD B99 RSVD C99 PEG_RX14- D99 PEG_TX14-

A100 GND(FIXED) B100 GND(FIXED) C100 GND(FIXED) D100 GND(FIXED) A101 RSVD B101 RSVD C101 PEG_RX15+ D101 PEG_TX15+ A102 RSVD B102 RSVD C102 PEG_RX15- D102 PEG_TX15A103 RSVD B103 RSVD C103 GND D103 GND A104 VCC_12V B104 VCC_12V C104 VCC_12V D104 VCC_12V A105 VCC_12V B105 VCC_12V C105 VCC_12V D105 VCC_12V A106 VCC_12V B106 VCC_12V C106 VCC_12V D106 VCC_12V A107 VCC_12V B107 VCC_12V C107 VCC_12V D107 VCC_12V A108 VCC_12V B108 VCC_12V C108 VCC_12V D108 VCC_12V A109 VCC_12V B109 VCC_12V C109 VCC_12V D109 VCC_12V A110 GND(FIXED) B110 GND(FIXED) C110 GND(FIXED) D110 GND(FIXED)

18

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

JP5

JP8

JP3

Locations of the Jumpers and Connectors for ICEB 8050C

The figure below shows the location of the jumpers and connectors for ICEB 8050C.

1

21

2 1

31

2 1

RaRfRbLbLfLaLg

LED5

1

3

1

6

1

910

JP1

H3

H2

2

1

3

1

5

12 10

6 4

Rg

J1

JP2

H1

JP12

J2

103

128

U2

C14

KM1

1

26

25 50

44

2

VGA1

43

1

CN1

H8

H9

3 1

JP4

JP6

J3

J4

J5

1

4

CN2

21

20

22

18

Y

17

1 14

5 1

1

CF MODEJP3

DIR

MODE2

SW2.4

SW2.3

COM1 MODE SELECT

SW2

65

64

39

38

25

HDDLEDJP4 1 HDDLED+ 2 HDDLED-

H4

1

00

1T/1R

RS485

00

0

1

2T/2R

RS422

10

X0

RS232

X

0

BACK

LOOP

MODE

REG

MODE0

MODE2

MODE1

DIR

H21

RTC

COM1 422/485 TERMALR

J1

1-2 NORMAL

2-3 CLEAR CMOS

2-3 DISABLE

1-2 ENABLE

JP1

ALL ONALL OFF

DISABLEENABLESIO

COM1 RI MODEJP2

SW1

1-2 5V

2-3 12V

H5

PRT1

13

5 9

IDE1

H6

JP12 GAL DOWNLOAD PORT

4-5 RI

H7

5

15 11

1-2 MASTER 2-3 SLAVE

OFF:1

MODE1

MODE0

ON:0

SW2

SW2.2

SW2.1

Lc Le Ld cm1cm2 Rd Re Rc

BAT1

76

U21

100

75

1

51

25

5026

102

1

11 9

7

8

1

2

5 3

1 6

COM1

2

JP5 POWER BUTTON JP6 HW RESET JP8 DISABLE EEPROM WP

JP7 BIOS PROGRAM

2

1

JP7

7

8

J6

1

2

10

9

19

10

G/R

9

5

8

1

4

CON1

JP9

J7

1

7

D1 C1

CN3

7

31

8 4

45

55

C110

1

JP10

CN4

2

20

B110J8D110

B1 A1

41

BAC

42

52

CN5

1

19

35

25

JP9 1-2 ATX 2-3 AT

H10

H11

H12

A110

H13

CN6

7

45

POWER MODE

CN7

2

20

32

22

3

1

12

24

1

19

13

H14

JP10 LVDS POWER 1-2 3.3V 2-3 5V

1

CON2

MH6

MH5

CN9CN8

H15

MH3

MH4

MH3MH4

mSATA

2

18

16

17

15

1

J9

B82

B81

A82

A81

C131 C129

A2

B2

A1

B1

1

2

H16

mPCIE

52

2

16

18

15

17

51

1

CN10

J11

A61

B62

J10

B32

B31

A32

A2

A1

B1

B2

A1

INTERNAL

JP11

SPEAKER 1 L+ 2 L3 GND 4 R+

H17

JP11

5

1

5 R-

1

2

CON3

3

52

51

MH6MH5

4

JP13

BIOS_ DIS1#

3

1

SW3

1 1 001 0

JP13

1-2

2-3

BIOS_

CARRIER

DIS0#

SPI_CS#

1

SPI0

0

SPI1

ICEB8050C 4BK08050B2X10 MADE IN TAIWAN

mPCIESELECT

WIFI

3.5G

BIOS SELECT

DESCRIPTOR

MODULEHIGH CARRIER MODULE

VER:B

H20

ON:0

SW3

OFF:1 SW3.1

BIOS_DIS0#

SW3.2

BIOS_DIS1#

SPI

BIOS ENTRY

SIP0/SPI1MODULEHIGH CARRIER FWH SIP0/SPI1 SIP0/SPI1

H18

CFAST

CON4

B18

B17

A18

A17

R350

A2A1B1

B2

S1

S7

PC1

CN11

P17

H19

19

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Jumpers

AT/ATX Power Type Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP9

1 3 1 3

Pin Settings

1-2 On ATX 2-3 On AT

1-2 On: default

RTC Clear

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: J1

Pin Settings

1-2 On Normal 2-3 On Clear CMOS

1-2 On: default

20

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

15

LVDS Backlight Power Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP10

1 3

Pin Settings

1-2 On +3.3V 2-3 On +5V

1-2 On: default

COM1 RS232 RI# Pin Power Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP2

Pin Settings

1-2 On +5V 2-3 On +12V 4-5 On RI

4-5 On: default

21

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Termal R

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP1

1 3

Pin Settings

1-2 On Enable COM1 422/485 Termal R 2-3 On Disable COM1 422/485 Termal R

2-3 On: default

CF Mode Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP3

1 3

Pin Settings

1-2 On Master 2-3 On Slave

1-2 On: default

22

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

mPCIe Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP13

1 3

Pin Settings

1-2 On Wi-Fi 2-3 On 3.5G

1-2 On: default

23

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

DIP Switch Settings

Close to Net LPC_SIO1_CLK

Connector type: 2x2 4-pin DIP switch Connector location: SW1

N

O

1

2

Pin Settings

1-2 Off Enable 1-2 On Disable

RS232/ RS422/ RS485 Mode Select

Connector type: 2x4 8-pin DIP switch Connector location: SW2

N

O

3

1

MODE0 0 1 0 0

MODE1 0 0 0 1

MODE2 0 0 1 0

MODE3 X X 1 0

4

2

SW2 ON:0 OFF:1

SW2.1 MODE0

SW2.2 MODE1

SW2.3 MODE2

SW2.4 DIR

Loop Back RS232 RS422 RS485

24

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

BIOS Select

Connector type: 2x2 4-pin DIP switch Connector location: SW3

N

O

1

2

SW3 ON:0 OFF:1

SW3.1 BIOS_DIS0#

SW3.2 BIOS_DIS1#

BIOS_DIS1# BIOS_DIS0#

1 1 High Module SPI0/SPI1

1 0 High Module Carrier FWH

0 1 SPI0 CARRIER SPI0/SPI1

0 0 SPI1 MODULE SPI0/SPI1

Carrier

SPI_CS#

SPI

Descriptor

BIOS Entry

25

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Connector Pin Definitions

External Connectors

PS2 Keyboard and Mouse

Connector type: PS/2, Mini-DIN-6 Connector location: KM1

Mouse

Keyboard

Pin Definition Pin Definition

1 KDAT 2 NC 3 GND 4 +5V 5 KCLK 6 NC 7 MDAT 8 NC 9 GND 10 +5V

11 MCLK 12 NC MH1 GND MH2 GND MH3 GND MH4 GND MH5 GND

Parallel Port

Connector type: 26-pin D-Sub, 2x13 (2.0mm) Connector location: PRT1

Pin Definition Pin Definition

1 RP_-STB 2 RP_PRD0 3 RP_PRD1 4 RP_PRD2 5 RP_PRD3 6 RP_PRD4 7 RP_PRD5 8 RP_PRD6

9 RP_PRD7 10 ACK# 11 BUSY 12 PE 13 SLCT 14 AFD# 15 ERR# 16 INIT# 17 SLIN# 18 GND 19 GND 20 GND 21 GND 22 GND 23 GND 24 GND 25 GND MH1 GND

MH2 GND MH3 GND

26

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

COM1 Port

Connector type: DB-9 port, 9-pin D-Sub Connector location: COM1

Pin Definition Pin Definition

1 SP_DCD1 2 SP_RXD1 3 SP_TXD1 4 SP_DTR1 5 GND 6 SP_DSR1 7 SP_RTS1 8 SP_CTS1 9 SP_RI1_T MH1 GND

MH2 GND

VGA Port

Connector type: DB-15 port, 15-pin D-Sub (VGA) Connector location: VGA1

Pin Definition Pin Definition

1 VGA_R 2 VGA_G

3 VGA_B 4 NC

5 GND 6 VGADET

7 GND 8 GND

9 +5V 10 GND 11 NC 12 VGA_DAT 13 VGA_HSYNC 14 VGA_VSYNC 15 VGA_CLK MH1 GND

MH2 GND

27

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

LAN and USB1/2 Ports

Connector type: RJ45 port with LEDs and dual USB 2.0 ports, Type A Connector location: CN2A (USB) and CN2B (LAN)

ACT LINK

Pin Definition Pin Definition

1 +5V_USB 2 USB_0N 3 USB_0P 4 GND 5 +5V_USB 6 USB_1N

7 USB_1P 8 GND MH1 GND MH2 GND MH3 GND MH4 GND

9 V25_LA1 10 LAN_MDI0P

11 LAN_MDI0N 12 LAN_MDI1P 13 LAN_MDI1N 14 LAN_MDI2P 15 LAN_MDI2N 16 LAN_MDI3P 17 LAN_MDI3N 18 GND 19 LAN_SPEED100# 20 LAN_SPEED1000# 21 LAN_ACTLED# 22 +3.3VSBY

MH5 GND MH6 GND

MH7 GND MH8 GND

USB2/3 Ports

Connector type: Dual USB 2.0 ports, Type A Connector location: CON1

Pin Definition Pin Definition

1 +5V_USB 2 USB_2N 3 USB_2P 4 GND 5 +5V_USB 6 USB_3N

7 USB_3P 8 GND MH1 GND MH2 GND MH3 GND MH4 GND

28

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Audio Connectors

Connector type: 5x 3.5mm TRS, 1x S/PDIF Connector location: CN5

Rear Surround

Center Subwoofer

S/PDIF

Line-in

Line-out

Mic-in

Pin Definition Pin Definition

1 GND 2 MIC_L 3 MIC_JD1 4 GND

5 MIC_R 22 FRONT_L2 23 FRONT_JD 24 GND 25 FRONT_R2 32 LINEIN_L 33 LINE1_JD 34 GND 35 LINEIN_R 41 GND 42 CEN_OUT 43 CEN_JD 44 GND 45 LEF_OUT 52 SIDE_L 53 SIDESURR_JD 54 GND 55 SIDE_R

A SPDIFO B +5V

C GND MH1 GND

MH2 GND MH3 GND MH4 GND

29

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

12

15

Internal Connectors

HDD LED

Connector type: 1x2 2-pin header, 2.54mm pitch Connector location: JP4

Pin Definition

1 +5V

2 GND

Internal Speaker

Connector type: 1x5 5-pin header, 2.0mm pitch Connector location: JP11

Pin Definition

1 SPKR_L+ 2 SPKR_L3 GND 4 SPKR_R+ 5 SPKR_R-

30

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

USB 5 Port

Connector type: 1x4 4-pin header, 2.0mm pitch Connector location: J3

4 1

Pin Definition

1 +5V_USB

2 USB_5N

3 USB_5P

4 GND

USB 6 Port

Connector type: 1x4 4-pin header, 2.0mm pitch Connector location: J4

4 1

Pin Definition

1 +5V_USB 2 USB_6N 3 USB_6P 4 GND

31

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

19

21

USB 7 Port

Connector type: 1x4 4-pin header, 2.0mm pitch Connector location: J5

4 1

Pin Definition

1 +5V_USB

2 USB_7N

3 USB_7P

4 GND

COM2 RS232

Connector type: 2x5 10-pin header, 2.0mm pitch Connector location: J2

0

Pin Definition Pin Definition

1 SP_DCD2 2 SP_RXD2 3 SP_TXD2 4 SP_DTR2 5 GND 6 SP_DSR2 7 SP_RTS2 8 SP_CTS2 9 SP_RI2 10 NC

32

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

19

21

GPIO

Connector type: 2x5 10-pin header, 2.0mm pitch Connector location: J6

0

Pin Definition Pin Definition

1 +5V 2 GND

3 ICH_GPO0_OUT 4 ICH_GPI0_IN

5 ICH_GPO1_OUT 6 ICH_GPI1_IN

7 ICH_GPO2_OUT 8 ICH_GPI2_IN

9 ICH_GPO3_OUT 10 ICH_GPI3_IN

CCFL

Connector type: 1x7 7-pin header, 2.0mm pitch Connector location: J7

7 1

Pin Definition Pin Definition

1 +5V 2 GND 3 ICH_GPO0_OUT 4 ICH_GPI0_IN 5 ICH_GPO1_OUT 6 ICH_GPI1_IN 7 ICH_GPO2_OUT 8 ICH_GPI2_IN 9 ICH_GPO3_OUT 10 ICH_GPI3_IN

33

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

11 22

LVDS Channel A

Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN7

9 0

Pin Definition Pin Definition

1 LVDS_DDC_CLK 2 LVDS_DDC_DATA

3 Panel_VDD 4 LVDSA_DATA0

5 LVDSA_DATA3 6 LVDSA_DATA#0

7 LVDSA_DATA#3 8 Panel_VDD

9 GND 10 LVDSA_DATA1

11 LVDSA_CLK 12 LVDSA_DATA#1 13 LVDSA_CLK# 14 GND 15 GND 16 Panel_backlight 17 LVDSA_DATA2 18 Panel_backlight 19 LVDSA_DATA#2 20 GND

MH1 GND MH2 GND

LVDS Channel B

Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN4

9 0

Pin Definition Pin Definition

1 LVDS_DDC_CLK 2 LVDS_DDC_DATA 3 Panel_VDD 4 LVDSB_DATA0 5 LVDSB_DATA3 6 LVDSB_DATA#0 7 LVDSB_DATA#3 8 Panel_VDD

9 GND 10 LVDSB_DATA1 11 LVDSB_CLK 12 LVDSB_DATA#1 13 LVDSB_CLK# 14 GND 15 GND 16 Panel_backlight 17 LVDSB_DATA2 18 Panel_backlight 19 LVDSB_DATA#2 20 GND

MH1 GND

34

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

16

17

28

GAL Download Port

Connector type: 1x6 6-pin header, 2.54mm pitch Connector location: JP12

Pin Definition Pin Definition

1 +3.3V 2 GND 3 TCK 4 TDO 5 TDI 6 TMS

SPI

Connector type: 2x4 8-pin header, 1.27mm pitch Connector location: JP7

Pin Definition Pin Definition

1 SPI_CS 2 ISPIMISO

3 ISPIWP# 4 GND

5 SPI_MOSI 6 SPI_CLK

7 SPI_POWER 8 SPI_POWER

35

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

12

Disable EEPROM

Connector type: 1x2 2-pin header, 2.54mm pitch Connector location: JP8

Pin Definition

1 EEPROM_WP 2 GND

HW Reset Function

Connector type: 1x2 2-pin header, 2.54mm pitch Connector location: JP6

Pin Definition

1 +3.3V

2 GND

36

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

12

34

Power Button

Connector type: 1x2 2-pin header, 2.54mm pitch Connector location: JP5

Pin Definition

1 +3.3VSBY 2 GND

4-Pin Power Connector

Connector type: 2x2 4-pin header Connector location: CON3

Pin Definition

1 GND

2 GND

3 +12V

4 +12V

37

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

11

ATX Power Connector

Connector type: 2x12 24-pin header, 4.2mm pitch Connector location: CON2

2

13 24

Pin Definition Pin Definition

1 +3.3V 2 +3.3V 3 GND 4 +5V 5 GND 6 +5V 7 GND 8 PS_PWRGD

9 +5VSBY 10 +12V 11 +12V 12 +3.3V 13 +3.3V 14 -12V 15 GND 16 PSON# R 17 GND 18 GND 19 GND 20 -5V 21 +5V 22 +5V 23 +5V 24 GND

38

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

High Speed Board-to-Board Connector: Row A and B, Row C and D

Connector location: J8

Com Express A&B Connector

Com Express C&D Connector

Pin Definition Pin Definition Pin Definition Pin Definition

A1 GND(FIXED) B1 GND(FIXED) C1 GND(FIXED) D1 GND(FIXED) A2 LAN_MDI3N B2 LAN_ACTLED# C2 ICH_IDE_DD7 D2 ICH_IDE_DD5 A3 LAN_MDI3P B3 LPC_FRAME# C3 ICH_IDE_DD6 D3 ICH_IDE_DD10 A4 LAN_SPEED100# B4 LPC_AD0 C4 ICH_IDE_DD3 D4 ICH_IDE_DD11 A5 LAN_SPEED1000# B5 LPC_AD1 C5 ICH_IDE_DD15 D5 ICH_IDE_DD12 A6 LAN_MDI2N B6 LPC_AD2 C6 ICH_IDE_DD8 D6 ICH_IDE_DD4 A7 LAN_MDI2P B7 LPC_AD3 C7 ICH_IDE_DD9 D7 ICH_IDE_DD0 A8 LAN_LINK B8 LPC_DRQ0# C8 ICH_IDE_DD2 D8 ICH_IDE_DDREQ

A9 LAN_MDI1N B9 LPC_DRQ1# C9 ICH_IDE_DD13 D9 ICH_IDE_DIOW# A10 LAN_MDI1P B10 LPC_CLK C10 ICH_IDE_DD1 D10 ICH_IDE_DDACK# A11 GND(FIXED) B11 GND(FIXED) C11 GND(FIXED) D11 GND(FIXED) A12 LAN_MDI0N B12 PM_PWRBTN# C12 ICH_IDE_DD14 D12 ICH_IDE_IRQ A13 LAN_MDI0P B13 SMB_CLK C13 ICH_IDE_IORDY D13 ICH_IDE_DA0

39

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Pin Definition Pin Definition Pin Definition Pin Definition

A14 LAN_CTREF B14 SMB_DATA C14 ICH_IDE_DIOR# D14 ICH_IDE_DA1 A15 PM_SLP_S3# B15 SMB_ALERT# C15 PCI_PME# D15 ICH_IDE_DA2 A16 SATA_TXP0 B16 SATA_TXP1 C16 PCI_GNT#2 D16 ICH_IDE_DCS1# A17 SATA_TXN0 B17 SATA_TXN1 C17 PCI_REQ#2 D17 ICH_IDE_DCS3# A18 PM_SLP_S4# B18 SUS_STAT# C18 PCI_GNT#1 D18 IDE_RST# A19 SATA_RXP0 B19 SATA_RXP1 C19 PCI_REQ#1 D19 PCI_GNT#3 A20 SATA_RXN0 B20 SATA_RXN1 C20 PCI_GNT#0 D20 PCI_REQ#3 A21 GND(FIXED) B21 GND(FIXED) C21 GND(FIXED) D21 GND(FIXED) A22 SATA_TXP2 B22 SATA_TXP3 C22 PCI_REQ#0 D22 ICH_PCI_AD1 A23 SATA_TXN2 B23 SATA_TXN3 C23 ICH_PCI_RST# D23 ICH_PCI_AD3 A24 PM_SLP_S5# B24 PS_PWRGD C24 ICH_PCI_AD0 D24 ICH_PCI_AD5 A25 SATA_RXP2 B25 SATA_RXP3 C25 ICH_PCI_AD2 D25 ICH_PCI_AD7 A26 SATA_RXN2 B26 SATA_RXN3 C26 ICH_PCI_AD4 D26 PCI_CBE#0 A27 PM_BATLOW# B27 GAL_WDT# C27 ICH_PCI_AD6 D27 ICH_PCI_AD9 A28 ICH_SATA_LED# B28 HDA_SDIN2 C28 ICH_PCI_AD8 D28 ICH_PCI_AD11 A29 HDA_SYNC B29 HDA_SDIN1 C29 ICH_PCI_AD10 D29 ICH_PCI_AD13 A30 HDA_RST# B30 HDA_SDIN0 C30 ICH_PCI_AD12 D30 ICH_PCI_AD15 A31 GND(FIXED) B31 GND(FIXED) C31 GND(FIXED) D31 GND(FIXED) A32 HDA_BIT_CLK B32 HDA_SPKR C32 ICH_PCI_AD14 D32 PCI_PAR A33 HDA_SDOUT B33 I2C_CLK C33 PCI_CBE#1 D33 PCI_SERR# A34 BIOS_DIS0# B34 I2C_DAT C34 PCI_PERR# D34 PCI_STOP# A35 PM_THRMTRIP# B35 PM_THRM# C35 PCI_LOCK# D35 PCI_TRDY# A36 USB_6N B36 USB_7N C36 PCI_DEVSEL# D36 PCI_FRAME# A37 USB_6P B37 USB_7P C37 PCI_IRDY# D37 ICH_PCI_AD16 A38 USB_OC67# B38 USB_OC45# C38 PCI_CBE#2 D38 ICH_PCI_AD18 A39 USB_4N B39 USB_5N C39 ICH_PCI_AD17 D39 ICH_PCI_AD20 A40 USB_4P B40 USB_5P C40 ICH_PCI_AD19 D40 ICH_PCI_AD22 A41 GND(FIXED) B41 GND(FIXED) C41 GND(FIXED) D41 GND(FIXED)

40

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Pin Definition Pin Definition Pin Definition Pin Definition

A42 USB_2N B42 USB_3N C42 ICH_PCI_AD21 D42 ICH_PCI_AD24 A43 USB_2P B43 USB_3P C43 ICH_PCI_AD23 D43 ICH_PCI_AD26 A44 USB_OC23# B44 USB_OC01# C44 PCI_CBE#3 D44 ICH_PCI_AD28 A45 USB_0N B45 USB_1N C45 ICH_PCI_AD25 D45 ICH_PCI_AD30 A46 USB_0P B46 USB_1P C46 ICH_PCI_AD27 D46 PCI_IRQ#C A47 +VBAT B47 EXCD1_PERST# C47 ICH_PCI_AD29 D47 PCI_IRQ#D A48 EXCD0_PERST# B48 EXCD1_CPPE# C48 ICH_PCI_AD31 D48 PM_CLKRUN# A49 EXCD0_CPPE# B49 HW_RST# C49 PCI_IRQ#A D49 PCI_M66EN A50 INT_SERIRQ B50 CB_RESET# C50 PCI_IRQ#B D50 CLK_PCI A51 GND(FIXED) B51 GND(FIXED) C51 GND(FIXED) D51 GND(FIXED) A52 PCIE_TXP5 B52 PCIE_RXP5 C52 PEG_RXP0 D52 PEG_TXP0 A53 PCIE_TXN5 B53 PCIE_RXN5 C53 PEG_RXN0 D53 PEG_TXN0 A54 ICH_GPI0 B54 ICH_GPO1 C54 TYPE0# D54 PEG_LANE_RV# A55 PCIE_TXP4 B55 PCIE_RXP4 C55 PEG_RXP1 D55 PEG_TXP1 A56 PCIE_TXN4 B56 PCIE_RXN4 C56 PEG_RXN1 D56 PEG_TXN1 A57 GND(FIXED) B57 ICH_GPO2 C57 TYPE1# D57 TYPE2# A58 PCIE_TXP3 B58 PCIE_RXP3 C58 PEG_RXP2 D58 PEG_TXP2 A59 PCIE_TXN3 B59 PCIE_RXN3 C59 PEG_RXN2 D59 PEG_TXN2 A60 GND(FIXED) B60 GND(FIXED) C60 GND(FIXED) D60 GND(FIXED) A61 PCIE_TXP2 B61 PCIE_RXP2 C61 PEG_RXP3 D61 PEG_TXP3 A62 PCIE_TXN2 B62 PCIE_RXN2 C62 PEG_RXN3 D62 PEG_TXN3 A63 ICH_GPI1 B63 ICH_GPO3 C63 NC D63 NC A64 PCIE_TXP1 B64 PCIE_RXP1 C64 NC D64 NC A65 PCIE_TXN1 B65 PCIE_RXN1 C65 PEG_RXP4 D65 PEG_TXP4 A66 GND(FIXED) B66 PCIE_WAKE# C66 PEG_RXN4 D66 PEG_TXN4 A67 ICH_GPI2 B67 WAKE1# C67 NC D67 GND A68 PCIE_TXP0 B68 PCIE_RXP0 C68 PEG_RXP5 D68 PEG_TXP5 A69 PCIE_TXN0 B69 PCIE_RXN0 C69 PEG_RXN5 D69 PEG_TXN5

41

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Pin Definition Pin Definition Pin Definition Pin Definition

A70 GND(FIXED) B70 GND(FIXED) C70 GND(FIXED) D70 GND(FIXED) A71 LVDSA_DATA0 B71 LVDSB_DATA0 C71 PEG_RXP6 D71 PEG_TXP6 A72 LVDSA_DATA#0 B72 LVDSB_DATA#0 C72 PEG_RXN6 D72 PEG_TXN6 A73 LVDSA_DATA1 B73 LVDSB_DATA1 C73 SDVO_CTRLDATA D73 SDVO_CTRLCLK A74 LVDSA_DATA#1 B74 LVDSB_DATA#1 C74 PEG_RXP7 D74 PEG_TXP7 A75 LVDSA_DATA2 B75 LVDSB_DATA2 C75 PEG_RXN7 D75 PEG_TXN7 A76 LVDSA_DATA#2 B76 LVDSB_DATA#2 C76 GND D76 GND A77 LVDS_VDD_EN B77 LVDSB_DATA3 C77 NC D77 IDE_PATADET A78 LVDSA_DATA3 B78 LVDSB_DATA#3 C78 PEG_RXP8 D78 PEG_TXP8 A79 LVDSA_DATA#3 B79 L_BKLT_EN C79 PEG_RXN8 D79 PEG_TXN8 A80 GND(FIXED) B80 GND(FIXED) C80 GND(FIXED) D80 GND(FIXED) A81 LVDSA_CLK B81 LVDSB_CLK C81 PEG_RXP9 D81 PEG_TXP9 A82 LVDSA_CLK# B82 LVDSB_CLK# C82 PEG_RXN9 D82 PEG_TXN9 A83 LVDS_DDC_CLK B83 L_BKLT_CTRL C83 NC D83 NC A84 LVDS_DDC_DATA B84 +5VSBY C84 GND D84 GND A85 ICH_GPI3 B85 +5VSBY C85 PEG_RXP10 D85 PEG_TXP10 A86 KBD_RST# B86 +5VSBY C86 PEG_RXN10 D86 PEG_TXN10 A87 H_A20GATE B87 +5VSBY C87 GND D87 GND A88 PCIE0_CK_REF+ B88 BIOS_DIS1# C88 PEG_RXP11 D88 PEG_TXP11 A89 PCIE0_CK_REF- B89 CRT_RED C89 PEG_RXN11 D89 PEG_TXN11 A90 GND(FIXED) B90 GND(FIXED) C90 GND(FIXED) D90 GND(FIXED) A91 SPI_POWER B91 CRT_GREEN C91 PEG_RXP12 D91 PEG_TXP12 A92 SPI_MISO B92 CRT_BLUE C92 PEG_RXN12 D92 PEG_TXN12 A93 ICH_GPO0 B93 CRT_HSYNC C93 GND D93 GND A94 SPI_CLK B94 CRT_VSYNC C94 PEG_RXP13 D94 PEG_TXP13 A95 SPI_MOSI B95 CRT_DDC_CLK_MCH C95 PEG_RXN13 D95 PEG_TXN13 A96 GND(FIXED) B96 CRT_DDC_DATA_MCH C96 GND D96 GND A97 TYPE10# B97 SPI_CS# C97 NC D97 PEG_ENABLE#

42

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Pin Definition Pin Definition Pin Definition Pin Definition

A98 NC B98 NC C98 PEG_RXP14 D98 PEG_TXP14 A99 NC B99 CD1#_R C99 PEG_RXN14 D99 PEG_TXN14

A100 GND(FIXED) B100 GND(FIXED) C100 GND(FIXED) D100 GND(FIXED) A101 NC B101 NC C101 PEG_RXP15 D101 PEG_TXP15 A102 NC B102 NC C102 PEG_RXN15 D102 PEG_TXN15 A103 NC B103 NC C103 GND D103 GND A104 +12V B104 +12V C104 +12V D104 +12V A105 +12V B105 +12V C105 +12V D105 +12V A106 +12V B106 +12V C106 +12V D106 +12V A107 +12V B107 +12V C107 +12V D107 +12V A108 +12V B108 +12V C108 +12V D108 +12V A109 +12V B109 +12V C109 +12V D109 +12V A110 GND(FIXED) B110 GND(FIXED) C110 GND(FIXED) D110 GND(FIXED)

43

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

PCIe x16

Connector location: J9

Pin Definition Pin Definition

A1 NC B1 +12V

A2 +12V B2 +12V

A3 +12V B3 +12V

A4 GND B4 GND

A5 GND B5 SMB_CLK

A6 +3.3V B6 SMB_DATA

A7 NC B7 GND

A8 +3.3V B8 +3.3V

A9 +3.3V B9 GND A10 +3.3V B10 +3.3VSBY A11 CB_RESET# B11 PCIE_WAKE# A12 GND B12 NC A13 PCIE_X16_CLKP B13 GND A14 PCIE_X16_CLKN B14 PEG_TXP0 A15 GND B15 PEG_TXN0 A16 PEG_RXP0 B16 GND A17 PEG_RXN0 B17 SDVO_CTRLCLK A18 GND B18 GND

44

Pin Definition Pin Definition

A19 NC B19 PEG_TXP1 A20 GND B20 PEG_TXN1 A21 PEG_RXP1 B21 GND A22 PEG_RXN1 B22 GND A23 GND B23 PEG_TXP2 A24 GND B24 PEG_TXN2 A25 PEG_RXP2 B25 GND A26 PEG_RXN2 B26 GND A27 GND B27 PEG_TXP3 A28 GND B28 PEG_TXN3 A29 PEG_RXP3 B29 GND A30 PEG_RXN3 B30 NC A31 GND B31 SDVO_CTRLDATA A32 NC B32 GND A33 NC B33 PEG_TXP4 A34 GND B34 PEG_TXN4 A35 PEG_RXP4 B35 GND A36 PEG_RXN4 B36 GND

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Pin Definition Pin Definition

A37 GND B37 PEG_TXP5 A38 GND B38 PEG_TXN5 A39 PEG_RXP5 B39 GND A40 PEG_RXN5 B40 GND A41 GND B41 PEG_TXP6 A42 GND B42 PEG_TXN6 A43 PEG_RXP6 B43 GND A44 PEG_RXN6 B44 GND A45 GND B45 PEG_TXP7 A46 GND B46 PEG_TXN7 A47 PEG_RXP7 B47 GND A48 PEG_RXN7 B48 NC A49 GND B49 GND A50 NC B50 PEG_TXP8 A51 GND B51 PEG_TXN8 A52 PEG_RXP8 B52 GND A53 PEG_RXN8 B53 GND A54 GND B54 PEG_TXP9 A55 GND B55 PEG_TXN9 A56 PEG_RXP9 B56 GND A57 PEG_RXN9 B57 GND A58 GND B58 PEG_TXP10 A59 GND B59 PEG_TXN10

Pin Definition Pin Definition

A60 PEG_RXP10 B60 GND A61 PEG_RXN10 B61 GND A62 GND B62 PEG_TXP11 A63 GND B63 PEG_TXN11 A64 PEG_RXP11 B64 GND A65 PEG_RXN11 B65 GND A66 GND B66 PEG_TXP12 A67 GND B67 PEG_TXN12 A68 PEG_RXP12 B68 GND A69 PEG_RXN12 B69 GND A70 GND B70 PEG_TXP13 A71 GND B71 PEG_TXN13 A72 PEG_RXP13 B72 GND A73 PEG_RXN13 B73 GND A74 GND B74 PEG_TXP14 A75 GND B75 PEG_TXN14 A76 PEG_RXP14 B76 GND A77 PEG_RXN14 B77 GND A78 GND B78 PEG_TXP15 A79 GND B79 PEG_TXN15 A80 PEG_RXP15 B80 GND A81 PEG_RXN15 B81 NC A82 GND B82 NC

45

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

PCIe x4

Connector location: J10

Pin Definition Pin Definition

A1 GND B1 12V

A2 12V B2 12V

A3 12V B3 12V

A4 GND B4 GND

A5 NC B5 SMB_CLK

A6 NC B6 SMB_DATA

A7 NC B7 GND

A8 NC B8 +3.3V

A9 +3.3V B9 NC

A0 +3.3V B10 +3.3VSBY A11 CB_RESET# B11 PCIE_WAKE# A12 GND B12 NC A13 PCIE_X4_CLKP B13 GND A14 PCIE_X4_CLKN B14 PCIE_TXP0 A15 GND B15 PCIE_TXN0 A16 PCIE_RXP0 B16 GND

46

Pin Definition Pin Definition

A17 PCIE_RXN0 B17 NC A18 GND B18 GND A19 NC B19 PCIE_TXP1 A20 GND B20 PCIE_TXN1 A21 PCIE_RXP1 B21 GND A22 PCIE_RXN1 B22 GND A23 GND B23 PCIE_TXP2 A24 GND B24 PCIE_TXN2 A25 PCIE_RXP2 B25 GND A26 PCIE_RXN2 B26 GND A27 GND B27 PCIE_TXP3 A28 GND B28 PCIE_TXN3 A29 PCIE_RXP3 B29 GND A30 PCIE_RXN3 B30 NC A31 GND B31 NC A32 NC B32 GND

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

PCIe x1

Connector location: CON4

Pin Definition Pin Definition

A1 NC B1 +12V

A2 +12V B2 +12V

A3 +12V B3 +12V

A4 GND B4 GND

A5 NC B5 SMB_CLK

A6 NC B6 SMB_DATA

A7 NC B7 GND

A8 NC B8 +3.3V

A9 +3.3V B9 NC A10 +3.3V B10 +3.3VSBY A11 CB_RESET# B11 PCIE_WAKE# A12 GND B12 NC A13 PCIE_X1_CLKP0 B13 GND A14 PCIE_X1_CLKN0 B14 PCIE_TXP4 A15 GND B15 PCIE_TXN4 A16 PCIE_RXP4 B16 GND A17 PCIE_RXN4 B17 NC A18 GND B18 GND

47

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

12

Mini-PCIe Slot (3G)

Connector location: CN10

51 52

Pin Definition Pin Definition

1 PCIE_WAKE# 2 3VSB_MINI 3 NC 4 GND 5 NC 6 1V5 7 3VSB_MINI 8 UIM_PWR

9 GND 10 UIM_DATA 11 PCIE_X1_CLKN1 12 UIM_CLK 13 PCIE_X1_CLKP1 14 UIM_RESET 15 GND 16 UIM_VPP 17 NC 18 GND 19 NC 20 3VSB_MINI 21 GND 22 CB_RESET# 23 PCIE_RXN5 24 3VSB_MINI 25 PCIE_RXP5 26 GND

48

Pin Definition Pin Definition

27 GND 28 1V5 29 GND 30 SMB_CLK 31 PCIE_TXN5 32 SMB_DATA 33 PCIE_TXP5 34 GND 35 GND 36 USB_4N 37 GND 38 USB_4P 39 3VSB_MINI 40 GND 41 3VSB_MINI 42 NC 43 GND 44 NC 45 NC 46 NC 47 NC 48 1V5 49 NC 50 GND 51 NC 52 3VSB_MINI

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

12

Mini-PCIe Slot (mSATA)

Connector location: CN8

51 52

Pin Definition Pin Definition

1 NC 2 +3.3V

3 NC 4 GND

5 NC 6 1V5_MSATA

7 NC 8 NC

9 GND 10 NC 11 NC 12 NC 13 NC 14 NC 15 GND 16 NC 17 NC 18 GND 19 NC 20 NC 21 GND 22 NC 23 SATA_RXN3 24 +3.3V 25 SATA_RXP3 26 GND

49

Pin Definition Pin Definition

27 GND 28 1V5_MSATA 29 GND 30 SMBCLK_MAIN 31 SATA_TXN3 32 SMBDATA_MAIN 33 SATA_TXP3 34 GND 35 GND 36 NC 37 GND 38 NC 39 +3.3V 40 GND 41 +3.3V 42 NC 43 GND 44 NC 45 TEST POINT 46 NC 47 TEST POINT 48 1V5_MSATA 49 NC 50 GND 51 +3.3V 52 +3.3V

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

SIM Card Slot

Connector location: CN9

C3 C2 C1

Pin Definition Pin Definition

C1 UIM_PWR C5 GND C2 UIM_RESET C6 UIM_VPP C3 UIM_CLK C7 UIM_DATA

C7 C6 C5

SATA Connectors

Connector type: Standard Serial ATAII 7P (1.27mm, SATA-M-180) Connector location: CN6 and CN3

1 7

CN6

Pin Definition Pin Definition

1 GND 2 SATA_TXP0 3 SATA_TXN0 4 GND 5 SATA_RXN0 6 SATA_RXP0 7 GND

CN3

50

Pin Definition Pin Definition

1 GND 2 SATA_TXP1 3 SATA_TXN1 4 GND 5 SATA_RXN1 6 SATA_RXP1 7 GND

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

CFast Slot

Connector location: CN11

S7P17

Pin Definition Pin Definition

S1 GND S2 SATA_TXP2 S3 SATA_TXN2 S4 GND S5 SATA_RXN2 S6 SATA_RXP2 S7 GND P1 GND P2 GND P3 NC P4 NC P5 NC P6 NC P7 GND P8 TEST POINT P9 NC P10 NC

P11 NC P12 NC P13 +3.3V P14 +3.3V P15 GND P16 GND P17 NC MH1 GND

MH2 GND

51

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

CF-Master

Connector location: IDE1

Pin Definition Pin Definition

1 GND 2 ICH_IDE_DD3

3 ICH_IDE_DD4 4 ICH_IDE_DD5

5 ICH_IDE_DD6 6 NC

7 ICH_IDE_DCS1# 8 GND

9 GND 10 GND 11 GND 12 GND 13 +5V 14 GND 15 GND 16 GND 17 GND 18 ICH_IDE_DA2 19 ICH_IDE_DA1 20 ICH_IDE_DA0 21 ICH_IDE_DD0 22 ICH_IDE_DD1 23 ICH_IDE_DD2 24 NC 25 GND 26 CD1#_R

52

Pin Definition Pin Definition

27 ICH_IDE_DD11 28 ICH_IDE_DD12 29 ICH_IDE_DD13 30 ICH_IDE_DD14 31 ICH_IDE_DD15 32 ICH_IDE_DCS3# 33 NC 34 ICH_IDE_DIOR# 35 ICH_IDE_DIOW# 36 +5V 37 ICH_IDE_IRQ 38 +5V 39 IDE_CABLE 40 NC 41 IDE_RST# 42 +5V 43 GND 44 ICH_IDE_DDACK# 45 IDEACTP# 46 GND 47 ICH_IDE_DD8 48 ICH_IDE_DD9 49 ICH_IDE_DD10 50 GND

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

IDE-Slave

Connector type: 2x22 44-pin header, 2.0mm pitch Connector location: CN1

2 1

44 43

Pin Definition Pin Definition

1 IDE_RST# 2 GND

3 ICH_IDE_DD7 4 ICH_IDE_DD8

5 ICH_IDE_DD6 6 ICH_IDE_DD9

7 ICH_IDE_DD5 8 ICH_IDE_DD10

9 ICH_IDE_DD4 10 ICH_IDE_DD11

11 ICH_IDE_DD3 12 ICH_IDE_DD12 13 ICH_IDE_DD2 14 ICH_IDE_DD13 15 ICH_IDE_DD1 16 ICH_IDE_DD14 17 ICH_IDE_DD0 18 ICH_IDE_DD15 19 GND 20 NC 21 ICH_IDE_DDREQ 22 GND

Pin Definition Pin Definition

23 ICH_IDE_DIOW# 24 GND 25 ICH_IDE_DIOR# 26 GND 27 ICH_IDE_IORDY 28 GND 29 ICH_IDE_DDACK# 30 GND 31 ICH_IDE_IRQ 32 NC 33 ICH_IDE_DA1 34 IDE_PATADET 35 ICH_IDE_DA0 36 ICH_IDE_DA2 37 ICH_IDE_DCS1# 38 ICH_IDE_DCS3# 39 IDEACTP# 40 GND 41 +5V 42 +5V 43 GND 44 NC

53

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

PCI Slot

Connector location: J11

Pin Definition Pin Definition

A1 NC B1 -12V A2 +12V B2 NC A3 NC B3 GND A4 NC B4 NC A5 +5V B5 +5V A6 PCI_IRQ#A B6 +5V A7 PCI_IRQ#C B7 PCI_IRQ#B A8 +5V B8 PCI_IRQ#D

A9 NC B9 NC A10 +5V B10 PCI_REQ#1 A11 PCI_GNT#1 B11 NC A12 GND B12 GND A13 GND B13 GND A14 +3.3VSBY B14 CLK_PCI_SIOT2 A15 ICH_PCI_RST# B15 GND A16 +5V B16 CLK_PCI_SIOT1 A17 PCI_GNT#0 B17 GND

54

Pin Definition Pin Definition

A18 GND B18 PCI_REQ#0 A19 PCI_PME# B19 +5V A20 ICH_PCI_AD30 B20 ICH_PCI_AD31 A21 +3.3V B21 ICH_PCI_AD29 A22 ICH_PCI_AD28 B22 GND A23 ICH_PCI_AD26 B23 ICH_PCI_AD27 A24 GND B24 ICH_PCI_AD25 A25 ICH_PCI_AD24 B25 +3.3V A26 ICH_PCI_AD20 B26 PCI_CBE#3 A27 +3.3V B27 ICH_PCI_AD23 A28 ICH_PCI_AD22 B28 GND A29 ICH_PCI_AD20 B29 ICH_PCI_AD21 A30 GND B30 ICH_PCI_AD19 A31 ICH_PCI_AD18 B31 +3.3V A32 ICH_PCI_AD16 B32 ICH_PCI_AD17 A33 +3.3V B33 PCI_CBE#2 A34 PCI_FRAME# B34 GND

ICEK 254-T2 Starter Kit User Manual

Chapter 2: Jumpers and Connectors

Pin Definition Pin Definition

A35 GND B35 PCI_IRDY# A36 PCI_TRDY# B36 +3.3V A37 GND B37 PCI_DEVSEL# A38 PCI_STOP# B38 GND A39 +3.3V B39 PCI_LOCK# A40 SMB_CLK B40 PCI_PERR# A41 SMB_DATA B41 +3.3V A42 GND B42 PCI_SERR# A43 PCI_PAR B43 +3.3V A44 ICH_PCI_AD15 B44 PCI_CBE#1 A45 +3.3V B45 ICH_PCI_AD14 A46 ICH_PCI_AD13 B46 GND A47 ICH_PCI_AD11 B47 ICH_PCI_AD12 A48 GND B48 ICH_PCI_AD10 A49 ICH_PCI_AD9 B49 PCI_M66EN A52 PCI_CBE#0 B52 ICH_PCI_AD8 A53 +3.3V B53 ICH_PCI_AD7 A54 ICH_PCI_AD6 B54 +3.3V A55 ICH_PCI_AD4 B55 ICH_PCI_AD5 A56 GND B56 ICH_PCI_AD3 A57 ICH_PCI_AD2 B57 GND A58 ICH_PCI_AD0 B58 ICH_PCI_AD1 A59 +5V B59 +5V A60 +3.3V B60 +3.3V A61 +5V B61 +5V A62 +5V B62 +5V

55

ICEK 254-T2 Starter Kit User Manual

Chapter 3: System Setup

CAUTION!

Chapter 3: System Setup

The starter kit is preconfigured and assembled. No addtional setup is required. However, if installation is needed, please refer to the instructions below.

Setting up the System

Make sure the power supply is switched off and disconnected

CAUTION!CAUTION!

from the power sources to prevent electric shock or system damage before installing.

1. Place the case on a stable surface and pull the yellow clasp to release the lock.

Clasp

56

ICEK 254-T2 Starter Kit User Manual

Chapter 3: System Setup

2. Open the case. 3. Align the mounting holes on the ICEB 8050C mainboard to the mounting holes inside the case.

ATX Connector

Mounting holes

4. Tighten screws onto the holes to secure the mainboard, and plug the ATX power supply connector to the ATX connector on the motherboard.

57

ICEK 254-T2 Starter Kit User Manual

Chapter 3: System Setup

5. Locate the COM Express connector on the mainboard. 6. Install the ICES 254 module onto the COM Express connector.

Mounting holes

7. Align the mounting holes on the ICES 254 to the heatsink mounting holes on the mainboard.

58

ICEK 254-T2 Starter Kit User Manual

Chapter 3: System Setup

8. Once the holes are aligned, place the heatsink on top and tighten mounting screws to secure the heatsink.

Mounting screws CFast slotCFast card

10. Align the mounting holes on the LCD panel to the mounting holes on top of the case.

Mounting holes

11. Tighten screws onto the mounting holes to secure the LCD panel.

9. Insert the CFast card into the CFast slot.

59

ICEK 254-T2 Starter Kit User Manual

Chapter 3: System Setup

12. Connect the LVDS and CCFL cables to the LVDS and CCFL connector on the mainboard.

CCFL LVDS

13. Plug the AC power cord to the power supply and connect the other end to a power outlet. Then switch on the system.

AC Power

60

ICEK 254-T2 Starter Kit User Manual

Chapter 3: System Setup

There is a metal plate supporting the mainboard that can be lifted up or lowered down. The instructions below illustrate the step-by-step procedures.

NOTE: Before lifting up or lowering down, make sure the two spring-nuts located on the left and right side of the metal support plate are inserted/ closed to the end-position as depicted in the diagram below.

Left spring-nut Right spring-nut

1. Hold on the left and right spring-nuts using both hands, and pull out

the spring-nuts to lift up or lower down.

2. After lifting up the mainboard, make sure the two spring-nuts are

inserted and closed to the end-position before plugging any connectors and I/O cards, then power on the system.

3. After lowering down the mainboard, make sure the two spring-nuts

are inserted and closed to the end position before powering off the system and closing the cover.

61

ICEK 254-T2 Starter Kit User Manual

Chapter 3: System Setup

External Soft-Power On/Off and Hardware Reset Switches

There are two special switches included inside the case to connect to JP5 and JP6 connectors for soft-power on/off and hardware reset function.

JP5: Soft-power on/off (red and black)

JP6: Hardware reset switch (green and black)

62

ICEK 254-T2 Starter Kit User Manual

Chapter 3: System Setup

Closing the Case

1. After lowering down the mainboard, make sure the two spring-nuts are inserted and closed to the end position before powering off.

2. Make sure to place the LCD cover protector onto the LCD panel before closing the case.

63

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

This chapter describes how to use the BIOS setup program for the ICEK 254-T2. The BIOS screens provided in this chapter are for reference only and may change if the BIOS is updated in the future.

To check for the latest updates and revisions, visit the NEXCOM Web site at www.nexcom.com.tw.

About BIOS Setup

The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to suit your individual work needs. It is a ROM-based configuration utility that displays the system’s configuration status and provides you with a tool to set system parameters.

These parameters are stored in non-volatile battery-backed-up CMOS RAM that saves this information even when the power is turned off. When the system is turned back on, the system is configured with the values found in CMOS.

With easy-to-use pull down menus, you can configure such items as:

▪ Hard drives, diskette drives, and peripherals

▪ Video display type and display options

▪ Password protection from unauthorized use

▪ Power management features

The settings made in the setup program affect how the computer performs. It is important, therefore, first to try to understand all the setup options, and second, to make settings appropriate for the way you use the computer.

When to Configure the BIOS

▪ This program should be executed under the following conditions:

▪ When changing the system configuration

▪ When a configuration error is detected by the system and you are

prompted to make changes to the setup program

▪ When resetting the system clock

▪ When redefining the communication ports to prevent any conflicts

▪ When making changes to the Power Management configuration

▪ When changing the password or making other changes to the security

setup

Normally, CMOS setup is needed when the system hardware is not consistent with the information contained in the CMOS RAM, whenever the CMOS RAM has lost power, or the system features need to be changed.

64

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

Default Configuration

Most of the configuration settings are either predefined according to the Load Optimal Defaults settings which are stored in the BIOS or are automatically detected and configured without requiring any actions. There are a few settings that you may need to change depending on your system configuration.

Entering Setup

When the system is powered on, the BIOS will enter the Power-On Self Test (POST) routines. These routines perform various diagnostic checks; if an error is encountered, the error will be reported in one of two different ways:

▪ If the error occurs before the display device is initialized, a series of beeps

will be transmitted.

▪ If the error occurs after the display device is initialized, the screen will

display the error message.

Powering on the computer and immediately pressing <Del> allows you to enter Setup. Another way to enter Setup is to power on the computer and wait for the following message during the POST:

Legends

Key Function

Moves the highlight left or right to select a menu.

Moves the highlight up or down between sub¬menus or fields.

Exits the BIOS Setup Utility.

Scrolls forward through the values or options of the highlighted field.

Scrolls backward through the values or options of the highlighted field.

Selects a field.

Displays General Help.

Load previous values.

Load optimized default values.

TO ENTER SETUP BEFORE BOOT PRESS

Press the

key to enter Setup:

Ctrl

+

Alt

+

65

Saves and exits the Setup program.

Press <Enter> to enter the highlighted sub¬menu

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

Scroll Bar

When a scroll bar appears to the right of the setup screen, it indicates that there are more available fields not shown on the screen. Use the up and down arrow keys to scroll through all the available fields.

Submenu

When “” appears on the left of a particular field, it indicates that a submenu which contains additional options are available for that field. To display the submenu, move the highlight to that field and press .

66

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

BIOS Setup Utility

Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on the screen. The main menu allows you to select from several setup functions and one exit. Use arrow keys to select among the items and press to accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.

Advanced Chipset Boot SecurityMain

BIOS Information BIOS Vendor Core Version Compliancy Project Version Build Date and Time

► Intel Reference Code Version

System Date System Time

Access Level

American Megatrends

4.6.5.1 UEFI 2.3; PI 1.2 I254-004 x64 06/06/2012 13:42:37

[Thu 06/26/2012] [14:48:45]

Administrator

Save & Exit

Intel Reference Code version

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Intel RC Version

Displays the Intel Reference Code version.

System Date

The date format is <day>, <month>, <date>, <year>. Day displays a day, from Monday to Sunday. Month displays the month, from January to December. Date displays the date, from 1 to 31. Year displays the year, from 1999 to 2099.

System Time

The time format is <hour>, <minute>, <second>. The time is based on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays seconds from 00 to 59.

Access Level

Displays the access level of the current user in the BIOS.

67

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

Advanced

The Advanced menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference.

Setting incorrect field values may cause the system to malfunction.

Advanced Chipset Boot SecurityMain

Legacy OpROM Support

Launch PXE OpROM

ACPI Settings

CPU Conguration SATA Conguration USB Conguration

W83792D H/W Monitor

Second Super IO Conguration Super IO Conguration

[Disabled]

Save & Exit

System ACPI Parameters

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Launch PXE OpROM

Enables or disables the boot option for legacy network devices connected to the LAN port.

68

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

ACPI Settings

This section is used to configure ACPI Settings.

Main

ACPI Settings

ACPI Sleep State [S3 (Suspend to RAM)]

Advanced Chipset PCIPnP Security

Exit

Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed.

← Select Screen ↑↓ Select Item +/- Change Field Tab Select Field F1 General Help F10 Save & Exit ESC Exit

ACPI Sleep State

Select the highest ACPI sleep state the system will enter when the suspend button is pressed. The options are Suspend Disabled, S1 (CPU Stop Clock) and S3 (Suspend to RAM).

CPU Configuration

This section is used to configure the CPU.

Advanced

CPU Conguration

Processor Type EMT64 Processor Speed System Bus Speed Ratio Status Actual Ratio System Bus Speed Processor Stepping Microcode Revision L1 Cache RAM L2 Cache RAM Processor Core Hyper-Threading

Hyper-Threading

Execute Disable Bit Limit CPUID Maximum

Intel(R) Atom (TM) CPU Supported 1865 MHZ 533 MHZ 14 14 533 MHZ 30661 259 2x56 k 2x512 k Dual Supported

[Enabled]

[Enabled] [Disabled]

Enabled for Windows XP and Linux (OS optimized for HyperThreading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology).

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Hyper-Threading

This field is used to enable or disable hyper-threading.

Execute Disable Bit

This field is used to enable or disable execute disable bit. When this field is set to Disabled, it will force the XD feature flag to always return to 0. XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3)

69

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

Limit CPUID Maximum

The CPUID instruction of some newer CPUs will return a value greater than 3. The default is Disabled because this problem does not exist in the Windows series operating systems. If you are using an operating system other than Windows, this problem may occur. To avoid this problem, enable this field to limit the return value to 3 or lesser than 3.

SATA Configuration

This section is used to configure the SATA drives.

Advanced

SATA Conguration

SATA Port0 Not Present SATA Port1 Not Present SATA Port2 Not Present SATA Port3 Not Present SATA Port4 Not Present SATA Port5 Not Present

SATA Mode [IDE Mode]

Serial-ATA Controller 0 [Compatible] Serial-ATA Controller 1 [Enhanced]

SATA Port 0 to Serial SATA Port 5

Displays information on the SATA devices detected.

Select IDE / AHCI / RAID Mode

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

70

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

SATA Mode Selection

Configures the SATA as IDE, AHCI or RAID mode.

IDE This option configures the Serial ATA drives as Parallel ATA physical storage device. RAID This option allows you to create RAID or Intel Matrix Storage configuration on Serial ATA devices. AHCI This option configures the Serial ATA drives to use AHCI (Advanced Host Controller Interface). AHCI allows the storage driver to enable the advanced Serial ATA features which will increase storage performance.

Serial-ATA Controller 0

Enables or disables SATA controller 0.

Serial-ATA Controller 1

Enables or disables SATA controller 1.

USB Configuration

This section is used to configure the USB.

Advanced

USB Conguration

USB Devices: None

Legacy USB Support

USB3.0 Support XHCI Hand-off EHCI Hand-off Device reset time-out

[Enabeld]

[Enabled] [Enabled] [Disabled] [20 sec]

Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Legacy USB Support

Enable Enables Legacy USB. Auto Disables support for Legacy when no USB devices are connected. Disable Keeps USB devices available only for EFI applications.

USB3.0 Support

Enables or disables USB 3.0 controller support.

71

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

XHCI Hand-off

This is a workaround for OSs that does not support XHCI hand-off. The XHCI ownership change should be claimed by the XHCI driver.

EHCI Hand-off

This is a workaround for OSs that does not support EHCI hand-off. The EHCI ownership change should be claimed by the EHCI driver.

Device reset time-out

Selects the USB mass storage device’s start unit command timeout.

W83792D H/W Monitor

This section is used to monitor hardware status such as temperature, fan speed and voltages.

Advanced

W83792D H/W Monitor Status

System temperature CPU temperature

System FAN Speed

CPU:Vcore +12V +5V +3.3V

: +56C : +55C

: N/A

: +1.200 V : +11.616 V : +4.992 V : +3.264 V

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

System Temperature

Detects and displays the current system temperature.

CPU Temperature

Detects and displays the current CPU temperature.

System Fan Speed

Detects and displays system fan speed.

72

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

CPU:Vcore

Detects and displays the Vcore CPU voltage.

+12V

Detects and displays 12V voltage.

+5V

Detects and displays 5V voltage.

+3.3V

Detects and displays 3.3V voltage.

Second Super IO Configuration

This section is used to configure serial ports 3 and 4.

Advanced

Super IO Conguration

Super IO Chip



Serial Port 3 Conguration



Serial Port 4 Conguration

Winbond W83627DHG

Set Parameters of Serial Port 3 (COMC)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Super IO Chip

Displays the Super I/O chip used on the board.

73

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

Super IO Configuration

This section is used to configure the parallel port and serial ports 1 and 2.

Advanced

Super IO Conguration

Super IO Chip



Serial Port 1 Conguration



Serial Port 2 Conguration



Parallel Port Conguration

Winbond W83627DHG

Set Parameters of Serial Port 1 (COMA)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Super IO Chip

Displays the Super I/O chip used on the board.

Serial Port 1 Configuration

This section is used to configure serial port 1.

Advanced

Serial Port 1 Conguration

Serial Port

Device Settings

Change Settings

[Enabled]

IO=3F8h; IRQ=4;

[IO=3F8h; IRQ=4;]

Serial Port

Enables or disables the serial port.

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Change Settings

Selects an optimal setting for the Super IO device.

74

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

Serial Port 2 Configuration

This section is used to configure serial port 2.

Advanced

Serial Port 2 Conguration

Serial Port

Device Settings

Change Settings

[Enabled]

IO=2F8h; IRQ=3;

[IO=2F8h; IRQ=3;]

Serial Port

Enables or disables the serial port.

Enable or Disable Serial Port (COM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Parallel Port Configuration

This section is used to configure the parallel port.

Advanced

Parallel Port Conguration

Parallel Port

Device Settings

Change Settings Device Mode

[Enabled]

IO=378h;

[IO=378h; IRQ=7;] [STD Printer Mode]

Parallel Port

Enables or disables the parallel port.

Enable or Disable Parallel Port (LPT/LPTE)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Change Settings

Selects an optimal setting for the Super IO device.

Change Settings

Selects an optimal setting for the Super IO device.

Device Mode

Configures the operating mode of the parallel port.

75

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

Chipset

This section is used to configure the system based on the specific features of the chipset.

Host Bridge

South Bridge

Advanced

Chipset Boot SecurityMain

[Disabled] [Disabled]

Save & Exit

Host Bridge Parameters

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Host Bridge

Displays the memory information

Advanced

Intel IGD Conguration

******* Memory Information******* Memory Frequency Total Memory DIMM#0 DIMM#1

Chipset Boot SecurityMain

1067 MHz (DDR3) 2048 MB Not Present 2048 MB

Save & Exit

Cong Intel IGD Settings

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Setting incorrect field values may cause the system to malfunction.

Intel® IGD Configuration

Settings for Intel® IGD.

76

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

South Bridge

Advanced

SB Chipset Conguration

SMBus Controller

Restore AC Power Loss

Audio Conguration

Azalia HD Audio

High Precision Event Timer Conguration

High Precision Timer

►USB Conguration

Chipset Boot SecurityMain

[Enabled]

[Power Off]

[Enabled]

SMBus Controller

This section is used to configure SMBus.

Save & Exit

Enable/Disable SMBus Controller.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

High Precision Timer

This section is used to configure High Precision Event Timer.

Restore AC Power Loss

Select AC power state when power is re-applied after a power failure.

Azalia HD Audio

This section disables Azalia or enables HD Audio.

77

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

Boot

This section is used to configure the boot features.

Advanced

Boot Conguration

Setup Prompt Timeout

Bootup NumLock State

Quiet Boot

CSM16 Module Version

GateA20 Active Option ROM Messages Interrupt 19 Capture

Boot Option Priorities

Setup Prompt Timeout

This section configures the number of seconds to wait for the setup activation key.

Chipset

Boot

1

[On]

[Disabled]

07.64

[Upon Request] [Force BIOS] [Disabled]

SecurityMain

Save & Exit

Number of seconds to wait for setup activation key.

65535(0xFFFF) means indenite

waiting.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Quiet Boot

Enabled Displays OEM logo instead of the POST messages. Disabled Displays normal POST messages.

GateA20 Active

Upon Request GA20 can be disabled using BIOS services. Always Do not allow disabling GA20; this option is useful when any RT code is executed above 1MB.

Option ROM Messages

This field is used to set display mode for Option ROM.

Interrupt 19 Capture

Allows Option ROMs to trap Interrupt 19 when enabled.

Boot Option Priorities

Adjust the boot sequence of the system. Boot Option #1 is the first boot device that the system will boot from, next will be #2 and so forth.

Bootup NumLock State

This allows you to determine the default state of the numeric keypad. By default, the system boots up with NumLock on wherein the function of the numeric keypad is the number keys. When set to Off, the function of the numeric keypad is the arrow keys.

78

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

Security

Advanced Chipset Boot SecurityMain

Password Description

If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter Setup. In Setup the User Will have Administrator rights. The password length must be in the following range: Minimum length 3 Maximum 20

Administrator Password

User Password

Administrator Password

Select this to reconfigure the administrator’s password.

User Password

Select this to reconfigure the user’s password.

Save & Exit

Set Administrator Password

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Save & Exit

Advanced

Save Changes and Exit

Discard Changes and Exit Save Changes and Reset Discard Changes and Reset

Save Options

Save Changes Discard Changes

Restore Defaults Save as User Defaults Restore User Defaults

Boot Override

Launch EFI Shell from lesystem device

Save Changes and Exit

To save the changes and exit the Setup utility, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes. You can also press <F4> to save and exit Setup.

Discard Changes and Exit

To exit the Setup utility without saving the changes, select this field then press <Enter>. You may be prompted to confirm again before exiting. You can also press <ESC> to exit without saving the changes.

Chipset

Boot SecurityMain

Save & Exit

Exit systm setup after saving the changes.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

79

ICEK 254-T2 Starter Kit User Manual

Chapter 4: BIOS Setup

Save Changes and Reset

To save the changes and reset, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Discard Changes and Reset

To exit the Setup utility and reboot the system without saving the changes, select this field then press <Enter>. You may be prompted to confirm again before exiting.

Save Changes

To save changes and continue configuring the BIOS, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Discard Changes

To discard the changes, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes to discard all changes made and restore the previously saved settings.

Restore Defaults

To restore the BIOS to default settings, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Boot Override

To bypass the boot sequence from the Boot Option List and boot from a particular device, select the desired device and press <Enter>.

Launch EFI Shell from filesystem device

To launch EFI shell from a filesystem device, select this field and press <Enter>.

Save as User Defaults

To use the current configurations as user default settings for the BIOS, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

Restore User Defaults

To restore the BIOS to user default settings, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes.

80

ICEK 254-T2 Starter Kit User Manual

Appendix A: Watchdog Timer

WDT Programming Guide

ICES 254 Watch Dog Function Configuration Sequence Description:

Start

Step1. See “SetupWDT” procedure #Setup Watchdog Timer Environment

Step2. See “TimeBaseWDT” procedure #Initial Watchdog Timer. Users can select second or minute.

Step3. See “TimeCountWDT” procedure #Set Watchdog Timer Time-out Value. Users can set time-out value.

Step4: See ExitSetup procedure #Exit Setup Environment

End

81

ICEK 254-T2 Starter Kit User Manual

Appendix A: Watchdog Timer

=============================================== SetupWDT PROC mov dx, 2eh mov al, 087h out dx, al nop nop out dx, al ;Write operations to special address port (2E) for entering MB PnP Mode. mov al, 07h out 2eh, al mov al, 08h ;Select logical device for Watch Dog. out 2fh, al ret SetupWDT ENDP =============================================== TimeBaseWDT PROC mov al, 0F5h out 2eh, al mov al, 04h ; Here!! set 04h for second, set 0Ch for minute(WDT output through WDTO) out 2fh, al ret TimeBaseWDT ENDP =============================================== TimeCountWDT PROC mov al, 0F6h ;WDT Time-out register. out 2eh, al mov al, 03h ;Here!! Set count 3. out 2fh, al ret

TimeCountWDT ENDP =============================================== ExitSetup PROC mov al, 0AAh out 2eh, al ret ExitSetup ENDP ===============================================

82

ICEK 254-T2 Starter Kit User Manual

Appendix B: GPI/O Programming Guide

GPI/O (General Purpose Input/Output) pins are provided for custom system design. This appendix provides definitions and its default setting for the ten GPI/O pins in the ICES 254. The pin definition is shown in the following table:

Pin No. GPI/O mode PowerOn

Default

1 VCC - - 2 GND - -

3 GPO0 High 538h (Bit3) 4 GPI0 High 50Fh (Bit0)

5 GPO1 High 538h (Bit6) 6 GPI1 High 538h (Bit4)

7 GPO2 High 538h (Bit7) 8 GPI2 High 538h (Bit5)

9 GPO3 High 53Ah (Bit1) 10 GPI3 High 53Bh (Bit1)

The bit is Set/Clear indicated output High/Low

Address Pin No. GPI/O mode PowerOn

Default

83

Address

ICEK 254-T2 Starter Kit User Manual

Appendix B: GPI/O Programming Guide

GPIO programming sample code

#define GPIO_PORT 0x538 #define GPO0 (0x01 << 3) #define GPO1 (0x01 << 6) #define GPO2 (0x01 << 7)

#define GPO0_HI outportb(GPIO_PORT, 0x08) #define GPO0_LO outportb(GPIO_PORT, 0x00) #define GPO1_HI outportb(GPIO_PORT, 0x40) #define GPO1_LO outportb(GPIO_PORT, 0x00) #define GPO2_HI outportb(GPIO_PORT, 0x80) #define GPO2_LO outportb(GPIO_PORT, 0x00)

void main(void) { GPO0_HI; GPO1_LO; GPO2_HI; }

84

ICEK 254-T2 Starter Kit User Manual
