NEXCOM APPC 1240T User Manual

NEXCOM International Co., Ltd.

IoT Automation Solutions Business Group

Applied Panel PC APPC 1240T/1245T/1540T/1740T/1940T

User Manual

NEXCOM International Co., Ltd.

Published August 2015

www.nexcom.com

Content

Contents

Preface

Copyright ............................................................................................. iv

Disclaimer .............................................................................................. iv

Acknowledgements ............................................................................... iv

Regulatory Compliance Statements ........................................................ iv

Declaration of Conformity ...................................................................... iv

RoHS Compliance ................................................................................... v

Warranty and RMA ................................................................................ vi

Safety Information ................................................................................. ix

Installation Recommendations ................................................................ ix

Safety Precautions ................................................................................... x

Technical Support and Assistance ........................................................... xi

Conventions Used in this Manual ........................................................... xi

Global Service Contact Information ........................................................xii

Package Contents ................................................................................. xiv

Ordering Information ............................................................................xvi

Chapter 1: Product Introduction

APPC 1240T/1245T .................................................................................1

Specifications .......................................................................................... 2

APPC 1540T ...........................................................................................4

Specifications .......................................................................................... 5

APPC 1740T ...........................................................................................7

Specifications .......................................................................................... 8

APPC 1940T .........................................................................................10

Specifications ........................................................................................ 11

Knowing Your APPC Series ...................................................................13

Rear Top ............................................................................................ 13

Rear Bottom ...................................................................................... 14

Rear ..................................................................................................15

Mechanical Dimensions .........................................................................16

APPC 1240T/1245T ...........................................................................16

APPC 1540T ...................................................................................... 17

APPC 1740T ...................................................................................... 18

APPC 1940T ...................................................................................... 19

Chapter 2: Jumpers and Connectors

Before You Begin ..................................................................................20

Precautions ..........................................................................................20

Jumper Settings ....................................................................................21

Locations of the Jumpers and Connectors ............................................. 22

Top View ...........................................................................................22

Bottom View .....................................................................................23

Jumpers and DIP Switch Settings ........................................................... 24

RTC and SRTC Clear Select ............................................................. 24

AT/ATX Power Select ......................................................................24

Dimming Signal Level Select ........................................................... 25

LCD Panel VDD Power Select .......................................................... 25

Touch 4/5 Wire Select .....................................................................26

COM1 RI Pin Power Select .............................................................. 26

COM2 RI Pin Power Select .............................................................. 27

Panel Resolution Select ...................................................................27

Dimming Type Select ...................................................................... 28

ii

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Content

Connector Pin Definitions .....................................................................29

External I/O Interfaces ........................................................................ 29

Line-out Connector ........................................................................ 29

Remote Power On/Off Switch .........................................................29

LAN1 Port ......................................................................................30

LAN2 Port ......................................................................................30

Dual USB 2.0 Port ..........................................................................31

Single USB 3.0 Port ........................................................................31

COM1 Port ....................................................................................32

COM2 Port ....................................................................................32

VGA Port .......................................................................................33

12V - 30V DC Power Input ............................................................. 33

CFast Card Slot ..............................................................................34

Reset Button ..................................................................................34

Internal Connectors ........................................................................... 35

CCFL Panel Backlight Connector ....................................................35

LVDS Channel A ............................................................................. 35

LVDS Channel B .............................................................................36

Line-in/Mic-in Connector ................................................................ 36

Speaker-out Connector ..................................................................37

USB Connector ..............................................................................37

Touch Sensor Connector ................................................................38

SATA Connector .............................................................................38

SATA DOM Power Connector .........................................................39

DIO Connector (Optional) ...............................................................39

Keyboard/Mouse Connector ...........................................................40

Active LED Connector ....................................................................40

Power Button ................................................................................. 41

Backlight Control Input Connector .................................................41

Dimming Control Input Connector .................................................42

LVDS MCU FW Debug Connector ................................................... 42

Smart Fan Connector .....................................................................43

Battery Connector .......................................................................... 43

Post Code Debug Connector .......................................................... 44

SIM Card Slot .................................................................................44

Mini-PCIe Slot ................................................................................45

Mini-PCIe Slot (Wi-Fi/3G) ................................................................ 46

Block Diagram ......................................................................................47

Chapter 3: System Setup

Installing a SATA Hard Drive .................................................................48

Installing a CFast Card ..........................................................................52

Installing a SO-DIMM ............................................................................ 54

Installing a SATA DOM (Half-Size Only) ..................................................57

Installing a Mini PCIe Module ................................................................ 60

Installing a Fieldbus Mini PCIe Module ..................................................62

Installing the Half-Size Mini PCIe Module ..............................................68

Installing the Full-Size Mini PCIe Module ...............................................69

Placing Panel Mount Hole Blocks ........................................................... 73

Installing the Power Adapter Bracket ..................................................... 75

Panel Mounting ....................................................................................79

Chapter 4: BIOS Setup

About BIOS Setup ................................................................................. 81

When to Configure the BIOS .................................................................81

Default Configuration ........................................................................... 82

Entering Setup ...................................................................................... 82

Legends ................................................................................................ 82

BIOS Setup Utility .................................................................................. 84

Main .................................................................................................84

Advanced ......................................................................................... 85

Chipset ..............................................................................................93

Security .............................................................................................96

Boot .................................................................................................. 96

Save & Exit ........................................................................................98

Appendix A: Power Consumption.........................99

iii

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

PrefaCe

Copyright

This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd.

Disclaimer

The information in this document is subject to change without prior notice and does not represent commitment from NEXCOM International Co., Ltd. However, users may update their knowledge of any product in use by constantly checking its manual posted on our website: http://www.nexcom.com. NEXCOM shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of any product, nor for any infringements upon the rights of third parties, which may result from such use. Any implied warranties of merchantability or fitness for any particular purpose is also disclaimed.

Acknowledgements

APPC 1240T/1245T/1540T/1740T/1940T are trademarks of NEXCOM International Co., Ltd. All other product names mentioned herein are registered trademarks of their respective owners.

Regulatory Compliance Statements

This section provides the FCC compliance statement for Class A devices and describes how to keep the system CE compliant.

Declaration of Conformity

FCC

This equipment has been tested and verified to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area (domestic environment) is likely to cause harmful interference, in which case the user will be required to correct the interference (take adequate measures) at their own expense.

CE

The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques.

iv

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

RoHS Compliance

NEXCOM RoHS Environmental Policy and Status Update

NEXCOM is a global citizen for building the digital infrastructure. We are committed to providing green

products and services, which are compliant with European Union RoHS (Restriction on Use of Hazardous Substance in Electronic Equipment) directive 2011/65/EU, to be your trusted green partner and to protect our environment.

RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1% or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium (Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.

In order to meet the RoHS compliant directives, NEXCOM has established an engineering and manufacturing task force to implement the introduction of green products. The task force will ensure that we follow the standard NEXCOM development procedure and that all the new RoHS components and new manufacturing processes maintain the highest industry quality levels for which NEXCOM are renowned.

The model selection criteria will be based on market demand. Vendors and suppliers will ensure that all designed components will be RoHS compliant.

How to recognize NEXCOM RoHS Products?

For existing products where there are non-RoHS and RoHS versions, the suffix “(LF)” will be added to the compliant product name.

All new product models launched after January 2013 will be RoHS compliant. They will use the usual NEXCOM naming convention.

v

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

Warranty and RMA

NEXCOM Warranty Period

1. NEXCOM makes products in accordance with the Industry standard and,

NEXCOM warrants that all her Industry-grade IPC and System products will be free from defect in neither material nor workmanship for twentyfour (24) months from the day of invoice issued.

2. For NEXCOM Panel PC product lines (the APPC, MPPC series), they are

also guaranteed against defect in materials and workmanship for the period of twenty-four (24) months in their motherboard design. For 3rd party parts, it follows with original suppliers’ standard: 12 months for battery pack and LCD, 24 months for adaptor / add on modules (including GSM module, RFID module, and antenna).

3. If NEXCOM determines customer’s warranty claim is valid, NEXCOM

will repair or replace product(s) without additional charge for parts and labor. An extended Warranty Program will extend the warranty period of the product accordingly.

Warranty Coverage

The warranty applies only to products manufactured or distributed by NEXCOM and her subsidiaries. This warranty covers all the products/ shipments except for:

1. Any claimed defect, products that have been repaired or modified by

persons who have not been authorized by NEXCOM or, products which have been subjected to misuse, abuse, accident, improper installation, or usage not in accordance with the product instruction. NEXCOM assumes no liability as a consequence of such events under the term of this warranty.

One example is the replacement of Tablet’s or Hand-held’s LCD display

due to scratching stains or other degradation; these will not be covered under this warranty.

2. Damages caused by customers’ delivery/shipping of the product or, product failure resulted from electrical power/voltage shock, or, installation of parts/components which are not supplied/approved by NEXCOM in advance.

3. Third-party products:

a. Software, such as the device drivers,

b. External devices such as HDD, printer, scanner, mouse, LCD panel,

battery, and so on,

c. Accessory/parts that were not approved by NEXCOM and,

d. Accessory/parts were added to products after they were shipped

from NEXCOM.

Product will be treated as “Out of Warranty “ if:

a. It expires the warranted 24 months period from the day it was purchased.

b. It had been altered by persons other than an authorized NEXCOM

service person or, which have been subjected to misuse, abuse, accident, or improper installation.

c. It doesn’t have the original NEXCOM Serial Number labeling for

NEXCOM’s warranty period identification or, tracking.

vi

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

RMA that NEXCOM has determined not to be covered by the warranty will be charged the NEXCOM Standard Repair Fee for the repairing. If a RMA is determined to be not repairable, customer will be notified and product(s) may be returned to customer at their request; a minimum service fee may be charged however.

NEXCOM Return Merchandise Authorization (RMA) Procedure

For the RMA (Return Merchandise Authorization) shipment, customer is responsible for packaging and shipping the product to the designated NEXCOM service sites, with shipping charges prepaid by the customer. The original NEXCOM shipping box should be used whenever possible. NEXCOM shall pay for the return of the product to the customer’s location. In case of expedited shipping request, an extra service charge shall be assessed and the customer is responsible for this extra return shipping charge.

1. Customers should enclose the “NEXCOM RMA Service Form” with the returned products.

2. Customers need to write down all the information related to the problem on the “ NEXCOM RMA Service Form “ when applying for the RMA service; information will help to understand the problem, including the fault description, on-screen messages, and pictures if possible.

3. Customers could send back the faulty product with or without the accessories and key parts such as the CPU and DIMM. If the key parts are included, please be noted clearly within the return form. NEXCOM takes no responsibility for the parts which are not listed in the return form.

customer registered delivery address will incur an extra shipping charge, the customer is responsible for paying the extra shipping charges, duties, and taxes of this shipment.

Product Repairing

1. NEXCOM will repair defective products covered under this limited warranty that are returned to NEXCOM; if products do prove to be defective, they will be repaired during their warranty period unless other warranty terms have been specified.

2. NEXCOM owns all parts removed from repaired products.

3. NEXCOM will use parts made by various manufacturers in performing the repair.

4. The repaired products will be warranted subjected to the original warranty coverage and period only.

5. For products returned as defective but, proved to be no defect/fault after the RMA process, NEXCOM reserves the right to claim for a NDF (No Defect Found) Service Charge.

6. NEXCOM will issue RMA Report which included Repair Detailed Information to the customer when the defective products were repaired and returned.

7. In addition to the above, NEXCOM may authorize Independent/Thirdparty suppliers to repair the defective products for NEXCOM.

4. Customers hold the responsibility to ensure that the packing of defective products is durable enough to be resistant against further damage due to the transportation; damage caused by transportation is treated as “ Out of Warranty “ under our Warranty specification.

5. RMA product(s) returned by NEXCOM to any location other than the

vii

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

Out Of Warranty Service

There will be a service charge from NEXCOM for the “Out Of Warranty” product service; they are the Basic Diagnostic Service Fee and the Advanced Component Replacement Fee respectively. And, if the product can not be repaired, NEXCOM will either return the product to the customer or, just scrap it, followed by customer’s instruction.

1. Testing and Parts Replacement

NEXCOM will have the following Handling Charges for those OoW

products that returned:

a. Basic Labor Cost and Testing Fee: as Table listed.

b. Parts Fee: NEXCOM will charge for main IC chipsets such as the N.B.,

S.B., Super-IO, LAN, Sound, Memory, and so on.

c. 3rd-party Device Fee: products replacement for CPU, DIMM, HDD,

Chassis, and UPS.

2. Out of Warranty product will have a three months warranty for the fixed

issues. If the product failed with different problem within 3 months, they will still incur the service charge of “Out of Warranty”.

3. Out of Warranty “products will not be repaired without a signed PI from

the customer, the agreement of the repair process.

Add-on card, 3rd Party Device and board level repair cost higher than

new product prices, customer can abandon to sign PI to repair and, please contact with sales to buy new products.

viii

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

Safety Information

Before installing and using the device, note the following precautions:

▪ Read all instructions carefully.

▪ Do not place the unit on an unstable surface, cart, or stand.

▪ Follow all warnings and cautions in this manual.

▪ When replacing parts, ensure that your service technician uses parts

specified by the manufacturer.

▪ Avoid using the system near water, in direct sunlight, or near a heating

device.

▪ The load of the system unit does not solely rely for support from the

rackmounts located on the sides. Firm support from the bottom is highly necessary in order to provide balance stability.

▪ The computer is provided with a battery-powered real-time clock circuit.

There is a danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

Installation Recommendations

Ensure you have a stable, clean working environment. Dust and dirt can get into components and cause a malfunction. Use containers to keep small components separated.

Adequate lighting and proper tools can prevent you from accidentally damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following:

▪ A Philips screwdriver

▪ A flat-tipped screwdriver

▪ A grounding strap

▪ An anti-static pad

Using your fingers can disconnect most of the connections. It is recommended that you do not use needle-nose pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

ix

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

Safety Precautions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a

damp cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a stable surface during installation. Dropping it or

letting it fall may cause damage.

7. The openings on the enclosure are for air convection to protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting

the equipment to the power outlet.

9. Place the power cord in a way so that people will not step on it. Do not

place anything on top of the power cord. Use a power cord that has been approved for use with the product and that it matches the voltage and current marked on the product’s electrical range label. The voltage and current rating of the cord must be greater than the voltage and current rating marked on the product.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service personnel:

a. The power cord or plug is damaged. b. Liquid has penetrated into the equipment. c. The equipment has been exposed to moisture. d. The equipment does not work well, or you cannot get it to work

according to the user’s manual. e. The equipment has been dropped and damaged. f. The equipment has obvious signs of breakage.

15. Do not place heavy objects on the equipment.

16. The unit uses a three-wire ground cable which is equipped with a third pin to ground the unit and prevent electric shock. Do not defeat the purpose of this pin. If your outlet does not support this kind of plug, contact your electrician to replace your obsolete outlet.

17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

x

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

CAUTION!

Technical Support and Assistance

1. For the most updated information of NEXCOM products, visit NEXCOM’s website at www.nexcom.com.

2. For technical issues that require contacting our technical support team or sales representative, please have the following information ready before calling: – Product name and serial number – Detailed information of the peripheral devices – Detailed information of the installed software (operating system,

version, application software, etc.) – A complete description of the problem – The exact wordings of the error messages

Warning!

1. Handling the unit: carry the unit with both hands and handle it with care.

2. Maintenance: to keep the unit clean, use only approved cleaning products or clean with a dry cloth.

3. CompactFlash: Turn off the unit’s power before inserting or removing a CompactFlash storage card.

Conventions Used in this Manual

Warning: Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself when performing a task.

CAUTION!CAUTION!

Caution: Information to avoid damaging components or losing data.

Note: Provides additional information to complete a task easily.

xi

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

Global Service Contact Information

Headquarters

NEXCOM International Co., Ltd.

15F, No. 920, Chung-Cheng Rd., ZhongHe District, New Taipei City, 23586, Taiwan, R.O.C. Tel: +886-2-8226-7786 Fax: +886-2-8226-7782 www.nexcom.com

America

USA NEXCOM USA

2883 Bayview Drive, Fremont CA 94538, USA Tel: +1-510-656-2248 Fax: +1-510-656-2158 Email: sales@nexcom.com www.nexcom.com

Asia

Taiwan NEXCOM Intelligent Systems

Taipei Office

13F, No.920, Chung-Cheng Rd., ZhongHe District, New Taipei City, 23586, Taiwan, R.O.C. Tel: +886-2-8226-7796 Fax: +886-2-8226-7792 Email: sales@nexcom.com.tw

www.nexcom.com.tw

NEXCOM Intelligent Systems Taichung Office

16F, No.250, Sec. 2, Chongde Rd., Beitun Dist., Taichung City 406, R.O.C. Tel: +886-4-2249-1179 Fax: +886-4-2249-1172 Email: sales@nexcom.com.tw www.nexcom.com.tw

Japan NEXCOM Japan

9F, Tamachi Hara Bldg., 4-11-5, Shiba Minato-ku, Tokyo, 108-0014, Japan Tel: +81-3-5419-7830 Fax: +81-3-5419-7832 Email: sales@nexcom-jp.com www.nexcom-jp.com

China

NEXCOM China

1F & 2F, Block A, No. 16 Yonyou Software Park, No. 68 Beiqing Road, Haidian District, Beijing, 100094, China Tel: +86-010-5704-2680 Fax: +86-010-5704-2681 Email: sales@nexcom.cn www.nexcom.cn

xii

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

Chengdu Office

9F, Shuxiangxie, Xuefu Garden, No.12 Section 1, South Yihuan Rd., Chengdu, 610061, China Tel: +86-28-8523-0186 Fax: +86-28-8523-0186 Email: sales@nexcom.cn www.nexcom.cn

Shanghai Office

Room 603/604, Huiyinmingzun Plaza Bldg., 1, No.609, Yunlin East Rd., Shanghai, 200333, China Tel: +86-21-5278-5868 Fax: +86-21-3251-6358 Email: sales@nexcom.cn www.nexcom.cn

Shenzhen Office

Room1707, North Block, Pines Bldg., No.7 Tairan Rd., Futian Area, Shenzhen, 518040, China Tel: +86-755-8332-7203 Fax: +86-755-8332-7213 Email: sales@nexcom.cn www.nexcom.cn

Wuhan Office

1-C1804/1805, Mingze Liwan, No. 519 South Luoshi Rd., Hongshan District, Wuhan, 430070, China Tel: +86-27-8722-7400 Fax: +86-27-8722-7400 Email: sales@nexcom.cn www.nexcom.cn

Europe

United Kingdom NEXCOM EUROPE

10 Vincent Avenue, Crownhill Business Centre, Milton Keynes, Buckinghamshire MK8 0AB, United Kingdom Tel: +44-1908-267121 Fax: +44-1908-262042 Email: sales.uk@nexcom.eu www.nexcom.eu

Italy NEXCOM ITALIA S.r.l

Via Lanino 42, 21047 Saronno (VA), Italia Tel: +39 02 9628 0333 Fax: +39 02 9625570 Email: nexcomitalia@nexcom.eu www.nexcomitalia.it

xiii

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

Package Contents

Before continuing, verify that the package you received is complete. Your APPC 1740T/1540T/1245T/1240T package should have all the items listed in the table.

APPC 1740T/1540T/1245T/1240T

Item Description Qty

1 PS/2 Y cable 1 2 Panel Mount Kit 12 3 Driver CD 1 4 Touch Pen 1 5 Terminal block 3-pin Phoenix Contact Plug 1 6 Flat Head for HDD Installation 4 7 Panel Mount Hole Block 12

Note: Package contents may vary depending on your country region, some items may be optional. Please contact your local distributor for more information.

PS/2 Y Cable

Driver CD Touch Pen

Flat Head Screw

Panel Mount Kit

(APPC 1740T/1540T/1245T/1240T)

Terminal block

3-pin Phoenix

Contact Plug

Panel Mount Hole Block

(APPC 1740T/1540T/1245T/1240T)

xiv

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

Your APPC 1940T package should have all the items listed in the table.

APPC 1940T

Item Description Qty

1 PS/2 Y cable 1 2 Panel Mount Kit 14 3 Driver CD 1 4 Touch Pen 1 5 Terminal block 3-pin Phoenix Contact Plug 1 6 Flat Head for HDD Installation 4 7 Panel Mount Hole Block 14

Note: Package contents may vary depending on your country region, some items may be optional. Please contact your local distributor for more information.

PS/2 Y Cable

Driver CD Touch Pen

Panel Mount Kit

(APPC 1940T)

Terminal block

3-pin Phoenix

Contact Plug

xv

Flat Head Screw

Panel Mount Hole Block

(APPC 1940T)

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Preface

Ordering Information

The following information below provides ordering information for the Applied Panel PC series.

Barebone

• APPC 1240T (P/N: 10IA1240T00X0)

12.1” SVGA LED Backlight Touch Panel PC, Intel

1.46GHz, touch screen, 2GB DDR3L, 2 x RS232/422/485, Brightness adjustment buttons

• APPC 1245T (P/N: 10IA1245T00X0)

12.1” XGA LED Backlight Touch Panel PC, Intel

®

touch screen, 2GB DDR3L, 2 x RS232/422/485, Brightness adjustment buttons.

• APPC 1540T (P/N: 10IA1540T00X0)

®

15” XGA LED Backlight Touch Panel PC, Intel

Atom™ E3826 1.46GHz, touch screen, 2GB DDR3L, 2 x RS232/422/485, Brightness adjustment buttons.

• APPC 1740T (P/N: 10IA1740T00X0)

17” SXGA LED Backlight Touch Panel PC, Intel

®

touch screen, 2GB DDR3L, 2 x RS232/422/485, Brightness adjustment buttons.

• APPC 1940T (P/N: 10IA1940T00X0)

19” SXGA LED Backlight Touch Panel PC, Intel

®

touch screen, 2GB DDR3L, 2 x RS232/422/485, Brightness adjustment buttons.

®

Atom™ E3826

Atom™ E3826 1.46GHz,

Optional

• 12V, 60W AC/DC power adapter w/o power cord (P/N: 7400060017X00)

• PROFINET Master Interface: FBI90E-PNM for APPC (Protocol Option P/N: 88IA1932T00X0)

• EtherNet/IP Interface: FBI90E-EP for APPC (Protocol Option P/N: 88IA1932T01X0)

• EtherCAT Master Interface: FBI90E-ECM for APPC (Protocol Option P/N: 88IA1932T02X0)

• PROFIBUS Master Interface: FBI90E-PBM for APPC (Protocol Option P/N: 88IA1932T03X0)

• DeviceNet Master Interface: FBI90E-DNM for APPC (Protocol Option P/N: 88IA1932T04X0)

xvi

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

ChaPter 1: ProduCt IntroduCtIon

APPC 1240T/1245T

Overview

Key Features

▪ 4:3 12.1” SVGA Fanless LED Panel Computer (APPC 1240T)

▪ 4:3 12.1” XGA Fanless LED Panel Computer (APPC 1245T)

®

Atom™ E3826, Dual Core, Low Consumption CPU

▪ Intel

▪ Flush Panel by 5-wire Touch Screen

▪ Dual GbE/2nd display-VGA/Line-out/PS2 KB/MS

▪ USB x 3/2 x Mini-PCIe sockets/1 x CFast/2 x RS232/422/485

▪ Fieldbus port

▪ DDR3L 2GB/2.5” HDD Bracket

▪ IP65 Compliant Front Panel

▪ Mounting Support: Panel/Wall/Stand/VESA 100mm x 100mm

▪ Wide Range Power Input 12V~30V DC

1

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

Specifications

Panel

APPC 1240T

▪ LED Size: 12.1”, 4:3 ▪ Resolution: SVGA 800x600 ▪ Luminance: 450cd/m

2

▪ Contrast ratio: 700 ▪ LCD color: 16.2M ▪ Viewing Angle: 65(U), 75(D), 80(L), 80(R) ▪ Backlight: LED

APPC 1245T

▪ LED Size: 12.1”, 4:3 ▪ Resolution: XGA 1024 x 768 ▪ Luminance: 500cd/m

2

▪ Contrast ratio: 700 ▪ LCD color: 16.2M ▪ Viewing Angle: 80(U), 80(D), 80(L), 80(R) ▪ Backlight: LED

Touch Screen

▪ 5-wire resistive (flush panel type) ▪ Light transmission: 80% ▪ Interface: USB

System

▪ CPU: On-board Intel® Atom™ Dual Core processor E3826, 1.46GHz,

1M L2 Cache

▪ BIOS: AMI BIOS

▪ System memory: 2x 204-pin DDR3L SO-DIMM socket, 2GB DDR3L

(Default), Support up to 8GB DDR3L-1066/1333, Non-ECC and Un-buffered

▪ Storage Device:

– 1x external locked CFast socket – 1x hard drive bay: optional 1x 2.5” SATA HDD or 1x SATA DOM

▪ Watchdog timer: Watchdog timeout can be programmed by software

from 1 second to 255 seconds and from 1 minute to 255 minutes

(Tolerance 15% under room temperature 25°C) ▪ H/W status monitor: Monitoring system temperature, and voltage ▪ Expansion: 2x Mini-PCIe sockets (support optional Wi-Fi, 3.5G module or

Fieldbus Card)

Rear I/O

▪ Ethernet: 2x RJ45 ▪ 2nd display VGA port: 1x DB15 ▪ Audio port: 1x Line-out ▪ USB: 2x USB 2.0, 1x USB 3.0 ▪ PS2 keyboard/mouse ▪ Power switch ▪ Reset button ▪ 2-pin Remote Power on/ off switch ▪ DIO w/ 2.5kv isolated (Optional):

– 4x Digital Input (Source type) – Input Voltage (Dry Contact): Logic 0: Close to GND – Logic 1: Open – Input Voltage: Logic 0: 3V max – Logic 1: +5V ~ +30V

2

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

– 4x Digital Output (Sink type) – Output Voltage: 3.6V ~ 5V

– Sink current: 200 mA max. per channel ▪ COM #1: RS232/422/485 w/ 2.5kv isolated ▪ COM #2: RS232/422/485 w/ 2.5kv isolated ▪ Fieldbus: (Protocol interface Optional)

Model Protocol Connector

FBI90E-PNM PROFINET Master

Dual RJ-45FBI90E-EP EtherNet/IP Master

FBI90E-ECM EtherCAT Master

FBI90E-PBM PROFIBUS Master DB9

FBI90E-DNM DeviceNet Master 5-pins Phoenix Contact Terminal

Audio

▪ HD audio codec: Realtek ALC886-GR ▪ Audio interface: Line-out/ Line-in (optional)/ Mic-in (optional)

Ethernet

▪ LAN chip: dual Intel® I210AT Gigabit LAN ▪ Ethernet interface: 10/100/1000 Based-Tx Ethernet compatible

▪ Power adapter: Optional AC to DC power adaptor (+12V, 60W) ▪ Vibration:

– IEC 68 2-64 (w/ HDD) – 1Grms @ sine, 5~500Hz, 1hr/axis (HDD Operating) – 2Grms @ sine, 5~500Hz, 1hr/axis (CFast Operating) – 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (Non-operating)

▪ Shock:

– IEC 68 2-27

– HDD: 20G @ wall mount, half sine, 11ms ▪ Operating temperature: -5°C to 60°C ▪ Storage temperature: -20°C to 75°C ▪ Operating humidity: 10%~90% relative humidity, non-condensing

Limits to be at 90% RH at max 50°C

▪ Dimension: 317 x 243 x 65.89mm ▪ Weight: 4kg

Certifications

▪ CE approval ▪ FCC Class A

Mechanical & Environment

▪ Color: pantone black\RAL 15 00 front bezel w/ Pantone 400C\RAL 090

80 10 metal style membrane ▪ IP protection: IP65 front ▪ Mounting: panel/wall/stand/VESA 100mm x 100mm ▪ Power input: 12V ~ 30V DC

3

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

APPC 1540T

Key Features

▪ 4:3 15” XGA Fanless LED Panel Computer

®

Atom™ E3826, Dual Core, Low Consumption CPU

▪ Intel

▪ Flush Panel by 5-wire Touch Screen

▪ Dual GbE/2nd display-VGA/Line-out/PS2 KB/MS

▪ USB x 3/2 x Mini-PCIe sockets/1 x CFast/2 x RS232/422/485

▪ Fieldbus port

▪ DDR3L 2GB/2.5” HDD Bracket

▪ IP65 Compliant Front Panel

▪ Mounting Support: Panel/Wall/Stand/VESA 100mm x 100mm

▪ Wide Range Power Input 12V~30V DC

4

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

Specifications

Panel

▪ LED Size: 15”, 4:3 ▪ Resolution: XGA 1024 x 768 ▪ Luminance: 400cd/m

2

▪ Contrast ratio: 700 ▪ LCD color: 16.2M ▪ Viewing Angle: 60 (U), 80(D), 80(L), 80(R) ▪ Backlight: LED

Touch Screen

▪ 5-wire resistive (flush panel type) ▪ Light transmission: 80% ▪ Interface: USB

System

▪ CPU: On-board Intel® Atom™ Dual Core processor E3826, 1.46GHz,

1M L2 Cache ▪ BIOS: AMI BIOS ▪ System memory: 2x 204-pin DDR3L SO-DIMM socket, 2GB DDR3L

(Default), Support up to 8GB DDR3L-1066/1333, Non-ECC and

Un-buffered ▪ Storage Device:

– 1x external locked CFast socket – 1x hard drive bay: optional 1x 2.5” SATA HDD or 1x SATA DOM

▪ Watchdog timer: Watchdog timeout can be programmed by software

from 1 second to 255 seconds and from 1 minute to 255 minutes

(Tolerance 15% under room temperature 25°C) ▪ H/W status monitor: Monitoring system temperature, and voltage ▪ Expansion: 2x Mini-PCIe sockets (support optional Wi-Fi, 3.5G module or

Fieldbus Card)

Rear I/O

▪ Ethernet: 2x RJ45 ▪ 2nd display VGA port: 1x DB15 ▪ Audio port: 1x Line-out ▪ USB: 2x USB 2.0, 1x USB 3.0 ▪ PS2 keyboard/mouse ▪ Power switch ▪ Reset button ▪ 2-pin Remote Power on/ off switch ▪ DIO w/ 2.5kv isolated (Optional):

– 4x Digital Input (Source type) – Input Voltage (Dry Contact): Logic 0: Close to GND – Logic 1: Open – Input Voltage: Logic 0: 3V max – Logic 1: +5V ~ +30V – 4x Digital Output (Sink type) – Output Voltage: 3.6V ~ 5V

– Sink current: 200 mA max. per channel ▪ COM #1: RS232/422/485 w/ 2.5kv isolated ▪ COM #2: RS232/422/485 w/ 2.5kv isolated ▪ Fieldbus: (Protocol interface Optional)

Model Protocol Connector

FBI90E-PNM PROFINET Master

Dual RJ-45FBI90E-EP EtherNet/IP Master

FBI90E-ECM EtherCAT Master

FBI90E-PBM PROFIBUS Master DB9

FBI90E-DNM DeviceNet Master 5-pins Phoenix Contact Terminal

5

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

Audio

▪ HD audio codec: Realtek ALC886-GR ▪ Audio interface: Line-out/ Line-in (optional)/ Mic-in (optional)

Ethernet

▪ LAN chip: dual Intel® I210AT Gigabit LAN ▪ Ethernet interface: 10/100/1000 Based-Tx Ethernet compatible

Mechanical & Environment

▪ Color: pantone black\RAL 15 00 front bezel w/ Pantone 400C\RAL 090

80 10 metal style membrane ▪ IP protection: IP65 front ▪ Mounting: panel/wall/stand/VESA 100mm x 100mm ▪ Power input: 12V~30VDC ▪ Power adapter: Optional AC to DC power adaptor (+12V, 60W) ▪ Vibration:

– IEC 68 2-64 (w/ HDD) – 1Grms @ sine, 5~500Hz, 1hr/axis (HDD Operating) – 2Grms @ sine, 5~500Hz, 1hr/axis (CFast Operating) – 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (Non-operating)

▪ Shock:

– IEC 68 2-27

– HDD: 20G @ wall mount, half sine, 11ms ▪ Operating temperature: -5°C to 60°C ▪ Storage temperature: -20°C to 75°C ▪ Operating humidity: 10%~90% relative humidity, non-condensing

Limits to be at 90% RH at max 50°C

▪ Dimension: 384.37 x 309.95 x 63.2 mm ▪ Weight: 5.1kg

Certifications

▪ CE approval ▪ FCC Class A

6

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

APPC 1740T

Key Features

▪ 4:3 17” SXGA Fanless Panel Computer

®

Atom™ E3826, Dual Core, Low Consumption CPU

▪ Intel

▪ Flush Panel by 5-wire Touch Screen

▪ Dual GbE/2nd display-VGA/Line-out/PS2 KB/MS

▪ USB x 3/2 x Mini-PCIe sockets/1 x CFast/2 x RS232/422/485

▪ Fieldbus port

▪ DDR3L 2GB/2.5” HDD Bracket

▪ IP65 Compliant Front Panel

▪ Mounting Support: Panel/Wall/Stand/VESA 100mm x 100mm

▪ Wide Range Power Input 12V~30V DC

7

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

Specifications

Panel

▪ LED Size: 17”, 4:3 ▪ Resolution: SXGA 1280x1024 ▪ Luminance: 350cd/m

2

▪ Contrast ratio: 1000 ▪ LCD color: 16.7M ▪ Viewing Angle: 80(U), 80(D), 85(L), 85(R) ▪ Backlight: LED

Touch Screen

▪ 5-wire resistive (flush panel type) ▪ Light transmission: 81% ▪ Interface: USB

System

▪ CPU: On-board Intel® Atom™ Dual Core processor E3826, 1.46GHz,

1M L2 Cache ▪ BIOS: AMI BIOS ▪ System memory: 2x 204-pin DDR3L SO-DIMM socket, 2GB DDR3L

(Default), Support up to 8GB DDR3L-1066/1333, Non-ECC and

Un-buffered ▪ Storage Device:

– 1x external locked CFast socket – 1x hard drive bay: optional 1x 2.5” SATA HDD or 1x SATA DOM

▪ Watchdog timer: Watchdog timeout can be programmed by

software from 1 second to 255 seconds and from 1 minute to 255 minutes (Tolerance 15% under room temperature 25°C)

▪ H/W status monitor: Monitoring system temperature, and voltage ▪ Expansion: 2 x Mini-PCIe sockets (support optional Wi-Fi, 3.5G module

or Fieldbus Card)

Rear I/O

▪ Ethernet: 2x RJ45 ▪ 2nd display VGA port: 1x DB15 ▪ Audio port: 1x Line-out ▪ USB: 2x USB 2.0, 1x USB 3.0 ▪ PS2 keyboard/mouse ▪ Power switch ▪ Reset button ▪ 2-pin Remote Power on/ off switch ▪ DIO w/ 2.5kv isolated (Optional):

– 4x Digital Input (Source type) – Input Voltage (Dry Contact): Logic 0: Close to GND – Logic 1: Open – Input Voltage: Logic 0: 3V max – Logic 1: +5V ~ +30V – 4x Digital Output (Sink type) – Output Voltage: 3.6V ~ 5V

– Sink current: 200 mA max. per channel ▪ COM #1: RS232/422/485 w/ 2.5kv isolated ▪ COM #2: RS232/422/485 w/ 2.5kv isolated ▪ Fieldbus: (Protocol interface Optional)

Model Protocol Connector

FBI90E-PNM PROFINET Master

Dual RJ-45FBI90E-EP EtherNet/IP Master

FBI90E-ECM EtherCAT Master

FBI90E-PBM PROFIBUS Master DB9

FBI90E-DNM DeviceNet Master 5-pins Phoenix Contact Terminal

8

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

Audio

▪ HD audio codec: Realtek ALC886-GR ▪ Audio interface: Line-out/ Line-in (optional)/ Mic-in (optional)

Ethernet

▪ LAN chip: dual Intel® I210AT Gigabit LAN ▪ Ethernet interface: 10/100/1000 Based-Tx Ethernet compatible

Mechanical & Environment

▪ Color: pantone black\RAL 15 00 front bezel w/ Pantone 400C\RAL 090

80 10 metal style membrane ▪ IP protection: IP65 front ▪ Mounting: panel/wall/stand/VESA 100mm x 100mm ▪ Power input: 12V~30VDC ▪ Power adapter: Optional AC to DC power adaptor (+12V, 60W) ▪ Vibration:

– IEC 68 2-64 (w/ HDD) – 1Grms @ sine, 5~500Hz, 1hr/axis (HDD Operating) – 2Grms @ sine, 5~500Hz, 1hr/axis (CFast Operating) – 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (Non-operating)

▪ Shock:

– IEC 68 2-27

– HDD: 20G @ wall mount, half sine, 11ms ▪ Operating temperature: -5°C to 60°C ▪ Storage temperature: -20°C to 75°C ▪ Operating humidity: 10%~90% relative humidity, non-condensing

Limits to be at 90% RH at max 50°C

▪ Dimension: 410.4 x 340.4 x 65.9mm ▪ Weight: 6.7 Kg

Certifications

▪ CE approval ▪ FCC Class A

9

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

APPC 1940T

Key Features

▪ 4:3 19” SXGA Fanless LED Panel Computer

®

Atom™ E3826, Dual Core, Low Consumption CPU

▪ Intel

▪ Flush Panel by 5-wire Touch Screen

▪ Dual GbE/2nd display-VGA/Line-out/PS2 KB/MS

▪ USB x 3/2 x Mini-PCIe sockets/1 x CFast/2 x RS232/422/485

▪ Fieldbus port

▪ DDR3L 2GB/2.5” HDD Bracket

▪ IP65 Compliant Front Panel

▪ Mounting Support: Panel/Wall/Stand/VESA 100mm x 100mm

▪ Wide Range Power Input 12V~ 30V DC

10

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

Specifications

Panel

▪ LED Size: 19”, 4:3 ▪ Resolution: SXGA 1280x1024 ▪ Luminance: 350cd/m

2

▪ Contrast ratio: 1000 ▪ LCD color: 16.7M ▪ Viewing Angle: 80(U), 80(D), 85(L), 85(R) ▪ Backlight: LED

Touch Screen

▪ 5-wire resistive (flush panel type) ▪ Light transmission: 81% ▪ Interface: USB

System

▪ CPU: On-board Intel® Atom™ Dual Core processor E3826, 1.46GHz,

1M L2 Cache ▪ BIOS: AMI BIOS ▪ System memory: 2x 204-pin DDR3L SO-DIMM socket, 2GB DDR3L

(Default), Support up to 8GB DDR3L-1066/1333, Non-ECC and

Un-buffered ▪ Storage Device:

– 1x external locked CFast socket – 1x hard drive bay: optional 1x 2.5” SATA HDD or 1x SATA DOM

▪ Watchdog timer: Watchdog timeout can be programmed by

software from 1 second to 255 seconds and from 1 minute to 255 minutes (Tolerance 15% under room temperature 25°C)

▪ H/W status monitor: Monitoring system temperature, and voltage ▪ Expansion: 2x Mini-PCIe sockets (support optional Wi-Fi, 3.5G module or

Fieldbus Card)

Rear I/O

▪ Ethernet: 2x RJ45 ▪ 2nd display VGA port: 1x DB15 ▪ Audio port: 1x Line-out ▪ USB: 2x USB2.0, 1x USB3.0 ▪ PS2 keyboard/mouse ▪ Power switch ▪ Reset button ▪ 2-pin Remote Power on/ off switch ▪ DIO w/ 2.5kv isolated (Optional):

– 4x Digital Input (Source type) – Input Voltage (Dry Contact): Logic 0: Close to GND – Logic 1: Open – Input Voltage: Logic 0: 3V max – Logic 1: +5V ~ +30V – 4x Digital Output (Sink type) – Output Voltage: 3.6V ~ 5V

– Sink current: 200 mA max. per channel ▪ COM #1: RS232/422/485 w/ 2.5kv isolated ▪ COM #2: RS232/422/485 w/ 2.5kv isolated ▪ Fieldbus: (Protocol interface Optional)

Model Protocol Connector

FBI90E-PNM PROFINET Master

Dual RJ-45FBI90E-EP EtherNet/IP Master

FBI90E-ECM EtherCAT Master

FBI90E-PBM PROFIBUS Master DB9

FBI90E-DNM DeviceNet Master 5-pins Phoenix Contact Terminal

11

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

Audio

▪ HD audio codec: Realtek ALC886-GR ▪ Audio interface: Line-out/ Line-in (optional)/ Mic-in (optional)

Ethernet

▪ LAN chip: dual Intel® I210AT Gigabit LAN ▪ Ethernet interface: 10/100/1000 Based-Tx Ethernet compatible

Mechanical & Environment

▪ Color: pantone black\RAL 15 00 front bezel w/ Pantone 400C\RAL 090

80 10 metal style membrane ▪ IP protection: IP65 front ▪ Mounting: panel/wall/stand/VESA 100mm x 100mm ▪ Power input: 12V~30V DC ▪ Power adapter: Optional AC to DC power adaptor (+12V, 60W) ▪ Vibration:

– IEC 68 2-64 (w/ HDD) – 1Grms @ sine, 5~500Hz, 1hr/axis (HDD Operating) – 2Grms @ sine, 5~500Hz, 1hr/axis (CFast Operating) – 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (Non-operating)

▪ Shock:

– IEC 68 2-27

– HDD: 20G @ wall mount, half sine, 11ms ▪ Operating temperature: -5°C to 50°C ▪ Storage temperature: -20°C to 75°C ▪ Operating humidity: 10%~90% relative humidity, non-condensing

Limits to be at 90% RH at max 50°C

▪ Dimension: 457.64 x 379.24 x 61.25 mm ▪ Weight: 6.7kg

Certifications

▪ CE approval ▪ FCC Class A

12

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

Knowing Your APPC Series

Rear Top

Antenna holes

Panel mounting hole

Backlight on/off

CFast

Increase Brightness

Decrease Brightness

Power switch

Panel mounting hole

Antenna holes for optional 3.5G/Wi-Fi

The 3 external antenna holes are used to mount and connect optional 3.5G/ Wi-Fi antennas.

CFast Card Socket

Used to insert a CFast card.

Power Switch

Press to power-on or power-off the panel PC.

Panel Backlight Control Buttons

Backlight On/Off

Press to turn-on or turn-off the display

Increase Brightness

Press to increase brightness of the screen.

Decrease Brightness

Press to decrease brightness of the screen.

13

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

Rear Bottom

Line-outPS/2 KB/MS COM 2USB 3.0

Remote

On/Off

USB 2.0

COM 1 Reset

LAN 1 VGA 12V-30V

LAN 2

DC Input

PS/2 KB/MS

Used to connect a PS/2 keyboard or a PS/2 mouse.

Line-out

Used to connect a headphone or a speaker.

Remote On/Off Switch

Used to connect a remote to power on/off the system.

LAN 1 and LAN 2

Used to connect the system to a local area network. LAN1 supports Wake up on LAN.

USB 2.0

Used to connect USB 2.0/1.1 devices.

USB 3.0

USB 3.0 port to connect the system with USB 3.0/2.0 devices.

COM 1 and COM 2

These COM ports support RS232/422/485 compatible series device through BIOS setting, and have 2.5kV isolated protection.

Reset Button

Press this button to restart the system.

VGA

Used to connect an analog VGA monitor.

12V-30V DC Input

Used to plug a DC power cord.

14

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

Rear

VESA Mounting Hole

VESA Mounting Holes

These are the mounting holes for VESA mount (100x100mm)

15

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

Mechanical Dimensions

APPC 1240T/1245T

56.90

8.80

67.22 67.23

301.73

317.00

304.50 5mm

230.00

100.25100.2534.86

CUT OUT SIZE T=5MM (MAX)

243.00

65.89

8.50

8.80

7.62

15

84.37 83.13

14.78

227.76

173.90

108.68 100.00

50.95100.00

16

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

APPC 1540T

89.26 67.22 67.23

7.41

8.80

160 160.00

366.32

384.37

309.95

63.20

7

19.20

56.2

10.40

371.00 5mm

297.00

CUT OUT SIZE T=5MM (MAX)

142.27

77.70

292.20

70.35 70.35 60

100.00

100

17

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

APPC 1740T

47.40

8.70

67.22

134.45

392.40

410.42

6.00

65.90

28.90

181.60

322.38

329.00

173.90

100.00

399.00

CUT OUT SIZE T=12MM (MAX)

270.00

100.00

12mm

18

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 1: Product Introduction

APPC 1940T

431.34

121.32 67.22 67.23

41.49 104.50 97.35 104.50

6.90

270.36

457.64

8.10

379.24

61.25

16.15

24.25

10.15

52.90

111.52111.52

76.38

174.32

361.34

436.00 3mm

366.00

CUT OUT SIZE T=3MM (MAX)

179.30 100.00

114.89

100.00

19

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

ChaPter 2: JumPers and ConneCtors

This chapter describes how to set the jumpers and connectors on the motherboard. Note that information in this chapter applies to APPC 1240T/ 1245T/1540T/1740T/1940T.

Before You Begin

▪ Ensure you have a stable, clean working environment. Dust and dirt can

get into components and cause a malfunction. Use containers to keep small components separated.

▪ Adequate lighting and proper tools can prevent you from accidentally

damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following: – A Philips screwdriver – A flat-tipped screwdriver – A set of jewelers screwdrivers – A grounding strap – An anti-static pad

▪ Using your fingers can disconnect most of the connections. It is

recommended that you do not use needle-nosed pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

▪ Before working on internal components, make sure that the power is off.

Ground yourself before touching any internal components, by touching a metal object. Static electricity can damage many of the electronic

components. Humid environments tend to have less static electricity than dry environments. A grounding strap is warranted whenever danger of static electricity exists.

Precautions

Computer components and electronic circuit boards can be damaged by discharges of static electricity. Working on computers that are still connected to a power supply can be extremely dangerous.

Follow the guidelines below to avoid damage to your computer or yourself:

▪ Always disconnect the unit from the power outlet whenever you are

working inside the case.

▪ If possible, wear a grounded wrist strap when you are working inside the

computer case. Alternatively, discharge any static electricity by touching the bare metal chassis of the unit case, or the bare metal body of any other grounded appliance.

▪ Hold electronic circuit boards by the edges only. Do not touch the

components on the board unless it is necessary to do so. Don’t flex or stress the circuit board.

▪ Leave all components inside the static-proof packaging that they shipped

with until they are ready for installation. Use correct screws and do not over tighten screws.

20

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Jumper Settings

A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open.

Refer to the illustrations below for examples of what the 2-pin and 3-pin jumpers look like when they are short (on) and open (off).

Two-Pin Jumpers: Open (Left) and Short (Right)

Three-Pin Jumpers: Pins 1 and 2 are Short

3

2

1

3

2

21

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Locations of the Jumpers and Connectors

Top View

J4

J3

J1

JP1

J5

J2

JP2

J6

CN3

JP7JP5

J8

CN1

CN2

JP3 JP6

JP4

J7

SW1

JP10

LAN1

J9

LAN2

CN4

SW2

USB1

J10

CN7

CN5

CN8

CN6

CN9

J11

CN11

J12

J13

CN12CN10

JP14JP12

CN16

VGA1

22

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Bottom View

J14

23

SW3

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Jumpers and DIP Switch Settings

RTC and SRTC Clear Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: J12 (RTC) and J13 (SRTC)

1 3

Pin Settings

1-2 On Normal 2-3 On Clear

1-2 On: default

Pin Definition

1 NC 2 RTC Power 3 GND

AT/ATX Power Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP2

1 3

Pin Settings

1-2 On AT Mode 2-3 On ATX Mode

2-3 On: default

Pin Definition

1 AUTO (AT MODE) 2 PWRBT In 3 Manual ( ATX MODE)

24

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Dimming Signal Level Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP6

1 3

Pin Settings Model

1-2 On 3.3V

2-3 On 5V

1-2 On: default

Pin Definition

1 VCC3 2 Power for Dimming 3 VCC5

APPC 1240T APPC 1940T APPC 1540T APPC 1740T

LCD Panel VDD Power Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP3

1 3

Pin Settings Model

1-2 On 3.3V

2-3 On 5V

1-2 On: default

Pin Definition

1 VCC3 2 Power for VDD 3 VCC5

APPC 1240T APPC 1540T APPC 1740T APPC 1940T

25

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Touch 4/5 Wire Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP4

1 3

Pin Settings

1-2 On 5 wire 2-3 On 4 wire

1-2 On: default

COM1 RI Pin Power Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP12

1 3

Pin Settings

1-2 On RING 2-3 On +5V

1-2 On: default

Pin Definition

1 SP1_RI 2 SP1_PSRI 3 VCC5

26

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

COM2 RI Pin Power Select

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP14

1 3

Pin Settings

1-2 On RING 2-3 On +12V

1-2 On: default

Pin Definition

1 SP2_RI 2 SP2_PSRI 3 12V

Panel Resolution Select

Connector type: 4-pin DIP switch Connector location: SW2

O

N

1

234

Resolution SW2-1 SW2-2 SW2-3 SW2-4 Model

800 x 600 ON ON ON ON APPC 1240T

1024 x 768 ON OFF ON ON APPC 1540T

1280 x 1024 OFF ON ON OFF

APPC 1740T APPC 1940T

27

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Dimming Type Select

Connector type: 2-pin DIP switch Connector location: SW1

O

N

1

2

TYPE SW1-1 SW1-2

PWM Mode ON OFF

Analog Mode OFF ON

28

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Connector Pin Definitions

External I/O Interfaces

Line-out Connector

Connector type: 1x 3.5mm TRS Connector location: CN3

Pin Definition Pin Definition

1 LOUT_R 2 JD 3 NC 4 LOUT_L 5 GND 6 GND

Remote Power On/Off Switch

Connector type: 2-pin switch Connector location: JP10

12

Pin Definition

1 PWRBT 2 GND

29

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

ACT LINK

LAN1 Port

Support Wake on LAN (WOL)

Connector type: RJ45 port with LEDs Connector location: LAN1

Act Status

Flashing Yellow Data activity

Off No activity

8 1

Pin Definition Pin Definition

1 LAN1M0P 2 LAN1M0N 3 LAN1M1P 4 LAN1M2P 5 LAN1M2N 6 LAN1M1N 7 LAN1M3P 8 LAN1M3N

Link Status

Steady Green 1G network link

Steady Orange 100Mbps network link

Off 10Mbps or no link

LAN2 Port

Connector type: RJ45 port with LEDs Connector location: LAN2

Act Status

Flashing Yellow Data activity

Off No activity

8 1

Pin Definition Pin Definition

1 LAN2M0P 2 LAN2M0N 3 LAN2M1P 4 LAN2M2P 5 LAN2M2N 6 LAN2M1N 7 LAN2M3P 8 LAN2M3N

Link Status

Steady Green 1G network link

Steady Orange 100Mbps network link

Off 10Mbps or no link

30

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Dual USB 2.0 Port

Connector type: USB 2.0 ports, Type A Connector location: USB1

1

5

Pin Definition Pin Definition

1 VCC5 2 USB 2N 3 USB 2P 4 GND 5 VCC5 6 USB 1N 7 USB 1P 8 GND

4

8

Single USB 3.0 Port

Connector type: USB 3.0 port, Type A Connector location: CN5

4

5

Pin Definition Pin Definition

1 VCC5 2 USB 0N 3 USB 0P 4 GND 5 USB3_RX0_N 6 USB3_RX0_P 7 GND 8 USB3_TX0_N 9 USB3_TX0_P

1

9

31

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

COM1 Port

Connector type: DB-9 port, 9-pin D-Sub Connector location: CN10

1

6

Pin RS232 RS422 RS485

1 COM1_DCD COM1_TXD-

2 COM1_RXD COM1_TXD+

3 COM1_TXD COM1_RXD+ Reserve 4 COM1_DTR COM1_RXD- Reserve 5 COM1_GND COM1_GND Reserve 6 COM1_DSR COM1_RTS- Reserve 7 COM1_RTS COM1_RTS+: Reserve 8 COM1_CTS COM1_CTS+ Reserve

COM1_RI

9

(Could be a +5V

Power Pin)

5

9

COM1_CTS-

(Could be a +5V

Power Pin)

COM1_TXD-

COM1_RXDCOM1_TXD+ COM1_RXD+

Reserve

(Could be a +5V

Power Pin)

COM2 Port

Connector type: DB-9 port, 9-pin D-Sub Connector location: CN12

1

6

Pin RS232 RS422 RS485

1 COM2_DCD COM2_TXD-

2 COM2_RXD COM2_TXD+

3 COM2_TXD COM2_RXD+ Reserve 4 COM2_DTR COM2_RXD- Reserve 5 COM2_GND COM2_GND Reserve 6 COM2_DSR COM2_RTS- Reserve 7 COM2_RTS COM2_RTS+ Reserve 8 COM2_CTS COM2_CTS+ Reserve

COM2_RI

9

(Could be a +12V

Power Pin)

5

9

COM2_CTS-

(Could be a +12V

Power Pin)

COM2_TXD-

COM2_RXDCOM2_TXD+ COM2_RXD+

Reserve

(Could be a +12V

Power Pin)

32

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

VGA Port

Connector type: DB-15 port, 15-pin D-Sub Connector location: VGA1

5

1

15 11

Pin Definition Pin Definition

1 Red 2 Green 3 Blue 4 N/C 5 GND 6 GND 7 GND 8 GND

9 +5V 10 GND 11 N/C 12 DDC Data 13 HSYNC 14 VSYNC 15 DDC Clock

12V - 30V DC Power Input

Connector type: Phoenix Contact 1x3 3-pin terminal block Connector location: CN16

31

+

Pin Definition

1 DC+ 2 DC3 GND

G

33

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

CFast Card Slot

Connector type: Standard CFast connector Connector location: J14

S7 PC17PC1S1

Pin Definition Pin Definition

S1 GND S2 SATA_TXP2 S3 SATA_TXN2 S4 GND S5 SATA_RXN2 S6 SATA_RXP2 S7 GND PC1 CFAST_CDI

PC2 GND PC3 NC PC4 NC PC5 NC PC6 NC PC7 GND

PC8 CFAST_LED1_C PC9 CFAST_LED2_C PC10 NC PC11 NC PC12 NC PC13 VCC3 PC14 VCC3 PC15 GND PC16 GND PC17 CFAST_CDO

Reset Button

Connector location: SW3

Pin Definition

1 Reset 2 Reset 3 GND 4 GND

34

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

71

11 22

Internal Connectors

CCFL Panel Backlight Connector

Connector type: 1x7 7-pin header JST, 2.5mm pitch Connector location: J4

Pin Definition Pin Definition

1 VCC5 2 12V 3 12V 4 BKCTRL 5 GND 6 GND 7 BKLEN

LVDS Channel A

Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN2

9 0

Pin Definition Pin Definition

1 NC 2 NC 3 VDD 4 LVDS_DAT0P 5 LVDS_DAT3P 6 LVDS_DAT0N 7 LVDS_DAT3N 8 VDD

9 GND 10 LVDS_DAT1P 11 LVDS_CLK1P 12 LVDS_DAT1N 13 LVDS_CLK1N 14 GND 15 GND 16 +12V 17 LVDS_DAT2P 18 +12V 19 LVDS_DAT2N

35

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

11 22

17

28

LVDS Channel B

Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN1

9 0

Pin Definition Pin Definition

1 NC 2 NC 3 VDD 4 LVDS_DAT4P 5 LVDS_DAT7P 6 LVDS_DAT4N 7 LVDS_DAT7N 8 VDD

9 GND 10 LVDS_DAT5P 11 LVDS_CLK2P 12 LVDS_DAT5N 13 LVDS_CLK2N 14 GND 15 GND 16 +12V 17 LVDS_DAT6P 18 +12V 19 LVDS_DAT6N

Line-in/Mic-in Connector

Connector type: 2x4 8-pin header, 2.54mm pitch Connector location: JP1

Pin Definition Pin Definition

1 LINE IN-LP 2 MIC1_L3 3 LINE IN-JD 4 MIC_JD 5 GND 6 GND 7 LINE IN-RP 8 MIC1_R3

36

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

14

61

Speaker-out Connector

Connector type: 1x4 4-pin header, 2.54mm pitch Connector location: J6

Pin Definition

1 OUT-L+

2 OUT-L-

3 OUT-R+

4 OUT-R-

USB Connector

Connector type: 1x6 6-pin header JST, 2.5mm pitch Connector location: J7

Pin Definition Pin Definition

1 +5V 2 HUBUSB DM1 3 HUBUSB DP1 4 HUBUSB DM2 5 HUBUSB DP2 6 GND

37

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Touch Sensor Connector

Connector type: 1x5 5-pin header JST, 2.5mm pitch Connector location: J3

15

Pin 4-wire 5-wire

1 Bottom UR (H)

2 Right LR (X)

3 N/A Sense (S)

4 Top UL (Y)

5 Left LL (L)

SATA Connector

Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180) Connector location: CN8

1 7

Pin Definition Pin Definition

1 GND 2 TXP0 3 TXN0 4 GND 5 RXN0 6 RXP0 7 GND 8

38

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

11

21

SATA DOM Power Connector

Connector type: 1x2 2-pin header, JST 2.5mm pitch Connector location: J10

1

Pin Definition

2

1 +5V

2 GND

DIO Connector (Optional)

Connector type: 2x8 16-pin header, 2.54mm pitch Connector location: CN9

6

5

Pin Definition Pin Definition

1 DI1 2 DO1 3 DI2 4 DO2 5 DI3 6 DO3 7 DI4 8 DO4

9 NC 10 NC 11 COM1 12 NC 13 GND 14 GND 15 GND 16 GND

39

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

17

28

51

Keyboard/Mouse Connector

Connector type: 2x4 8-pin header, 2.54mm pitch Connector location: JP7

Pin Definition Pin Definition

1 VCC5 2 VCC5 3 KB_DATA 4 MS_DATA 5 KB_CLK 6 MS_CLK 7 GND 8 GND

Active LED Connector

Connector type: 1x6 6-pin header JST, 2.5mm pitch Connector location: J2

Pin Definition Pin Definition

1 HDD_GND 2 HDD_PWR 3 PWR_GND 4 5VSB 5 VCC5

40

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Power Button

Connector type: 1x2 2-pin header JST, 2.0mm pitch Connector location: J1

1 2

Pin Definition

1 PWRBT 2 GND

Backlight Control Input Connector

Connector type: 1x4 4-pin header JST, 2.0mm pitch Connector location: J8

14

Pin Definition

1 GND

2 Tact Switch input

3 PIR IN

4 VCC3

41

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

14

Dimming Control Input Connector

Connector type: 1x5 5-pin header JST, 2.0mm pitch Connector location: J5

5

Pin Definition Pin Definition

1 GND 2 Decreased input 3 Increased input 4 Light sensor input 5 VCC3

1

LVDS MCU FW Debug Connector

Connector type: 1x4 4-pin header, 2.54mm pitch Connector location: JP5

Pin Definition

1 VCC3 2 MCU_TCK 3 MCU_TDIO 4 GND

42

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

14

Smart Fan Connector

Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: CN4

Pin Definition

1 GND 2 +12V 3 CPUFANIN 4 CPUFANOUT

Battery Connector

Connector type: 1x2 2-pin header JST, 1.25mm pitch Connector location: J11

1 2

Pin Definition

1 VBAT 2 GND

43

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Post Code Debug Connector

Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J9

10 1

Pin Definition Pin Definition

1 GND 2 PLTRST# 3 LPC_CLK 4 LPC_FRAME# 5 LPC_AD3 6 LPC_AD2 7 LPC_AD1 8 LPC_AD0 9 VCC3 10 VCC3

SIM Card Slot

Connector location: CN6

C5 C6 C7

Pin Definition Pin Definition

C1 UIM_PWR C2 UIM_RST C3 UIM_CLK C5 GND C6 UIM_VCCP C7 UIM_DAT

C1 C2 C3

44

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

12

Mini-PCIe Slot

Connector location: CN11

51 52

Pin Definition Pin Definition

1 WAKE0# 2 +V3.3_MINI 3 NC 4 GND 5 NC 6 +V1.5S_MINI 7 NC 8 NC

9 GND 10 NC 11 GPP_CLK1_N 12 NC 13 GPP_CLK1_P 14 NC 15 GND 16 NC 17 NC 18 GND 19 NC 20 MINICARD1_DIS# 21 GND 22 PCIE_RST# 23 PCIE_RX2N 24 +V3.3A_MINI 25 PCIE_RX2P 26 GND

45

Pin Definition Pin Definition

27 GND 28 +V1.5S_MINI 29 GND 30 SMB_CLK 31 PCIE_TX3N 32 SMB_DAT 33 PCIE_TX3P 34 GND 35 GND 36 USB_1N 37 GND 38 USB_1P 39 +V3.3A_MINI 40 GND 41 +V3.3A_MINI 42 NC 43 GND 44 NC 45 NC 46 NC 47 NC 48 +V1.5S_MINI 49 NC 50 GND 51 NC 52 +V3.3A_MINI

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

12

Mini-PCIe Slot (Wi-Fi/3G)

Connector location: CN7

51 52

Pin Definition Pin Definition

1 PCIEWAKE 2 3.3V

3 NC 4 GND

5 NC 6 1.5V

7 CLKREQ 8 UIM_PWR

9 GND 10 UIM_DAT 11 PCIECLKN 12 UIM_CLK 13 PCIECLKP 14 UIM_RST 15 GND 16 UIM_VCCP 17 NC 18 GND 19 NC 20 DISABLE 21 GND 22 PLTRSTBF 23 PCIERX4N 24 3.3V 25 PCIERX24P 26 GND

46

Pin Definition Pin Definition

27 GND 28 1.5V 29 GND 30 SMBCLK 31 PCIETX4N 32 SMBDATA 33 PCIETX4P 34 GND 35 GND 36 USB2N 37 GND 38 USB2P 39 3.3V 40 GND 41 3.3V 42 NC 43 GND 44 NC 45 NC 46 NC 47 NC 48 1.5V 49 NC 50 GND 51 NC 52 3.3V

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 2: Jumpers and Connectors

Block Diagram

LVDS 48bit Support

@ Maximum re solution:1920 * 1080

0 - Internal connector

1- Internal/mini-PCIe

Connector

2 - MiniPCIE Connector

3G(USB)

3- Penmount Touch

Controller

MIC-IN

Line-in

HEAD PHONE

SPEAK ER

VGA DB15Pin (Slim type) Co-layout with BOX HEADER

@ Maximum re solution:1900 * 1200

0 - Rear

1-2 - Rear

down stream

3- USB HUB 1~ 4

GENESYS GL850

SATA0 HDD

(DOM Support)

SATA1 CFAST

HDA_SDI0

Audio Codec ALC886

AMP TPS6047A4RHBR

CH7511

DP to LVDS

80 port

VGA

USB 3.0

USB 2.0X1

USB 2.0X3

SATA Gen2

Display Port

LPC Bus

VGA

Bay Trail-I

Dual Core CPU

E3826

DDR3L-1066

USB 3.0 (1)

3.25X27mm

USB 2.0 (4)

SATA (2)

Thermal Sensor *2 Voltages *4

DDI PORT1DDI PORT0

7W

Super I/O

ITE8786

DDR3L CH1

DDR3L CH2

DDR3L 1066

SPI

PCIe x1

PCI-E *1(4)

PCIe x1

LPCLCIHDA

DDR3L SO-DIMM

1 Slot

DDR3L SO-DIMM

2 Slot

@ Maximum 8GBytes

SPI 2MB

LAN i210

Mini-PCIe

Wi-Fi

Mini-PCIe

3G

Giga LAN

RJ45

WOL Support

GPIO2IN/2OUT

DIO BOX Header

COM1

COM2

COM3

RS-232/422/485

RS-232

RS-232COM4

ISOLATION

PS2 KB/MS

47

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

CAUTION!

ChaPter 3: system setuP

Installing a SATA Hard Drive

Prior to removing the chassis cover, make sure the unit’s power

CAUTION!CAUTION!

1. Remove the mounting screws around the chassis cover and then remove the cover.

is off and disconnected from the power sources to prevent electric shock or system damage.

The dots denote the locations of the screws.

48

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

2. Remove the mounting screws of the drive bay.

3. Remove the drive bay. The drive bay is used to hold a SATA hard drive.

Mounting screw

SATA power cable and SATA cable

49

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

4. Place the SATA hard drive on the drive bay.

Drive bay

5. Align the mounting holes that are on the sides of the SATA drive with the mounting holes on the drive bay and then use the provided mounting screws to secure the drive in place.

SATA drive

Mounting screw

50

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

6. Place the SATA drive in the chassis and then use the provided mounting screws to secure the drive in the chassis.

Connect the SATA data cable and SATA power cable to the

connectorson the SATA drive.

SATA drive

SATA data cable

SATA power cable

51

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

Installing a CFast Card

1. The CFast card socket is located on the rear top side of the chassis.

CFast card socket

2. Remove the mounting screws on the cover of the CFast socket.

Mounting screw

52

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

3. With the label of the CFast card facing up, insert the card until it is completely seated in the socket.

CFast card

4. Push the CFast card to remove it.

53

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

Installing a SO-DIMM

1. Remove the mounting screws around the chassis cover and then remove the cover.

54

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

2. Locate the SO-DIMM socket on the left side of the chassis as circled below, where you can install a SO-DIMM module.

3. Insert the module into the socket at an approximately 30 degrees angle. Apply firm even pressure to each end of the module until it slips into the socket. The gold-plated connector on the edge of the module will almost completely disappear inside the socket.

55

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

4. Push the module down until the clips on both sides of the socket lock into position. You will hear a distinctive “click” sound, indicating the module is correctly locked into position.

56

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

Installing a SATA DOM (Half-Size Only)

1. Remove the screw on the front of the SATA port.

2. The SATA DOM package includes a supporting stud. The stud is used to stabilize the SATA DOM module.

Supporting stud

Cable

SATA DOM

57

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

3. Install the supporting stud. Make sure the stud is fastened in place. 4. Connect one end of the provided cable to the connector on the module.

58

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

5. Install the module to the SATA port via the connector at the solder side of the module and then secure the module using the mounting screw you removed in step 1.

6. Connect the other end of the provided cable to the connector on the main board.

59

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

Installing a Mini PCIe Module

The Mini PCIe module package includes the following items:

RALINK 802.11b/g/n 2T3R wireless mini card module kit QCOM:Q802XKN

Mini PCIe Module

Antennas

3.5G module kit Sierra Wireless MC8790V

802.11b/g QN-MU-A0028 wireless mini card module kit

INTEL112.BNHMWG

RF Cables

60

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

If you are installing the 802.11b/g QN-MU-A0028 wireless mini card module (half-size), before proceeding with the installation, please assemble the Wi-Fi module bracket first by following the instructions below:

1. Align the mounting holes on the Wi-Fi mini card module to the mounting holes on the Wi-Fi module bracket.

Wi-Fi module bracketMounting holes

2. Tighten screws onto the mounting holes to secure the bracket.

61

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

Installing a Fieldbus Mini PCIe Module

Fieldbus Mini PCIe Module

Mini PCIe

Card

Connection

Cable

Universal PROFIBUS I/O Bracket

Connector Board

PROFINET

Dual RJ45

EtherNet/IP EtherCAT

DB9 PROFIBUS

5-pin

Connector

DeviceNet

Universal DeviceNet I/O Bracket

62

Universal PROFINET, EtherNet/IP and EtherCAT I/O Bracket

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

1. Remove the mounting screws around the chassis cover and then remove

the cover.

2. Remove the Fieldbus I/O cover.

3. Secure the FBI I/O bracket.

63

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

4. Plug the FBI cable to the I/O Connector Board and run the cable

through the hole of the bracket.

DB9 Connector Board 5-pin Connector Board

Dual RJ45 Connector Board

64

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

5. Secure the FBI I/O board. 6. Secure the FBI housing.

65

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

7. Insert the Mini PCIe module into the Mini PCIe slot at a 45 degrees

angle until the gold-plated connector on the edge of the module completely disappears inside the slot.

8. Secure the module with mounting screws.

66

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

9. Plug the FBI cable to the FBI Mini PCIe card. 10. Stick the FBI protocol label onto the front cover of the connector

board.

67

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

Installing the Half-Size Mini PCIe Module

1. Insert the Mini PCIe module into the Mini PCIe slot at a 45 degrees

angle until the gold-plated connector on the edge of the module completely disappears inside the slot.

Mini PCIe slot

Mini PCIe module

2. Secure the module with mounting screws.

3. Please go to step 3 on page 69 to proceed.

68

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

Installing the Full-Size Mini PCIe Module

1. Insert the Mini PCIe module into the Mini PCIe slot at a 45 degrees

angle until the gold-plated connector on the edge of the module completely disappears inside the slot.

Mini PCIe module

Mini PCIe slot

2. Secure the module with mounting screws.

Mounting

screw

Mounting screw

69

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

3. Attach one end of the RF cables onto the module.

RF cable

4. Push the antenna hole cover.

RF cable

70

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

5. Remove the antenna hole covers. 6. Insert the antenna jack end of the cable through the antenna hole.

Antenna jack end of the cable

71

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

7. Insert the ring onto the antenna jack end of the cable.

Antenna jack

Ring

Antenna jack

Ring

8. Connect external antennas to the antenna jacks.

RF cable

Antenna

Mini PCIe module

Antenna

72

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

Placing Panel Mount Hole Blocks

The APPC series comes with panel mount hole blocks to cover the panel mount openings on the chassis to prevent dust invasion. You can also choose to cover the panel mount holes when VESA mount is used.

Panel Mount Hole Block

(APPC 1940T)

1. Locate the panel mount openings on the chassis.

Panel Mount Hole Block

(APPC 1240T/1245T/1540T/1740T)

73

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

2. Insert the hole block into the opening until it is pushed in completely.

74

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

Installing the Power Adapter Bracket

(For APPC 1940T only)

1. Locate the mounting screws for the bracket on the back side of the

chassis.

2. Remove the mounting screws and store them in a safe place for later use.

75

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

3. Wire the power adapter cabling into the cable opening on the bracket, then place the adapter inside the bracket.

Cable opening

Power adapter cable

76

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

4. Turn the bracket over to the back side, and place the cable tie into the two tie mounts.

Cable tieTie mount

5. Wrap the power adapter cable, then secure the cable firmly by tying the cable tie.

77

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

6. With the bracket still facing backwards, align the mounting holes on the bracket to the mounting holes on the back of the chassis, then tighten screws to secure it. Once secured, plug the power adapter cable into the DC input.

DC input

78

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

304.50 5mm

230.00

297.00

371.00 5mm

329.00

399.00

Panel Mounting

1. Select a place on the panel where you will mount the Panel PC.

2. Cut out a shape on the panel that corresponds to the Panel PC’s rear dimensions.

The thickness of the panel (e.g. steel board, plank, acrylic board, wall, etc.) where you will mount the Panel PC must not exceed 5mm for APPC 1240T/1245T/1540T, 12mm for APPC 1740T, and 3mm for APPC 1940T. If the distance between the front bezel and panel mount hole is too wide, it will not fit the panel mount kit.

APPC 1540T

12mm

APPC 1240T/1245T

79

APPC 1740T

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 3: System Setup

366.00

CAUTION!

436.00 3mm

APPC 1940T

3. Slide the Panel PC through the hole until it is properly fitted against the panel.

4. Position the mounting clamps along the rear edges of the Panel PC. The first and second clamps must be positioned and secured diagonally prior to mounting the rest of the clamps. Tighten the clamp’s screw until it touches the panel.

Clamp

80

CAUTION!CAUTION!

Panel

Do not overtighten the screws to prevent damaging the Panel PC.

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 4: BIOS Setup

ChaPter 4: BIos setuP

This chapter describes how to use the BIOS setup program for the APPC Series. The BIOS screens provided in this chapter are for reference only and may change if the BIOS is updated in the future.

To check for the latest updates and revisions, visit the NEXCOM Web site at www.nexcom.com.tw.

About BIOS Setup

The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to suit your individual work needs. It is a ROM-based configuration utility that displays the system’s configuration status and provides you with a tool to set system parameters.

These parameters are stored in non-volatile battery-backed-up CMOS RAM that saves this information even when the power is turned off. When the system is turned back on, the system is configured with the values found in CMOS.

With easy-to-use pull down menus, you can configure such items as:

▪ Hard drives, diskette drives, and peripherals

▪ Video display type and display options

▪ Password protection from unauthorized use

▪ Power management features

The settings made in the setup program affect how the computer performs. It is important, therefore, first to try to understand all the setup options, and second, to make settings appropriate for the way you use the computer.

When to Configure the BIOS

▪ This program should be executed under the following conditions:

▪ When changing the system configuration

▪ When a configuration error is detected by the system and you are

prompted to make changes to the setup program

▪ When resetting the system clock

▪ When redefining the communication ports to prevent any conflicts

▪ When making changes to the Power Management configuration

▪ When changing the password or making other changes to the security

setup

Normally, CMOS setup is needed when the system hardware is not consistent with the information contained in the CMOS RAM, whenever the CMOS RAM has lost power, or the system features need to be changed.

81

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 4: BIOS Setup

Default Configuration

Most of the configuration settings are either predefined according to the Load Optimal Defaults settings which are stored in the BIOS or are automatically detected and configured without requiring any actions. There are a few settings that you may need to change depending on your system configuration.

Entering Setup

When the system is powered on, the BIOS will enter the Power-On Self Test (POST) routines. These routines perform various diagnostic checks; if an error is encountered, the error will be reported in one of two different ways:

▪ If the error occurs before the display device is initialized, a series of beeps

will be transmitted.

▪ If the error occurs after the display device is initialized, the screen will

display the error message.

Powering on the computer and immediately pressing <Del> allows you to enter Setup.

Legends

Key Function

Moves the highlight left or right to select a menu.

Moves the highlight up or down between sub¬menus or fields.

Exits the BIOS Setup Utility.

Scrolls forward through the values or options of the highlighted field.

Scrolls backward through the values or options of the highlighted field.

Selects a field.

Displays General Help.

Load previous values.

Load optimized default values.

Press the

key to enter Setup:

82

Saves and exits the Setup program.

Press <Enter> to enter the highlighted sub¬menu

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 4: BIOS Setup

Scroll Bar

When a scroll bar appears to the right of the setup screen, it indicates that there are more available fields not shown on the screen. Use the up and down arrow keys to scroll through all the available fields.

Submenu

When “” appears on the left of a particular field, it indicates that a submenu which contains additional options are available for that field. To display the submenu, move the highlight to that field and press .

83

APPC 1240T/1245T/1540T/1740T/1940T User Manual

Chapter 4: BIOS Setup

BIOS Setup Utility

Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on the screen. The main menu allows you to select from several setup functions and one exit. Use arrow keys to select among the items and press to accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.

Save & ExitAdvanced Chipset Security BootMain

BIOS Information BIOS Vendor Core Version Compliancy Project Version Build Date and Time

CPU Conguration

Microcode Patch

Memory Information Total Memory

System Date

System Time

American Megatrends

5.009 UEFI 2.3; PI 1.2 A200A007 x64 10/24/2014 12:00:26

901

2048 MB

[Tue 07/09/2019] [12:01:07]

Set the Date. Use Tab to switch between Date elements.

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

System Date

The date format is <day>, <month>, <date>, <year>. Day displays a day, from Monday to Sunday. Month displays the month, from January to December. Date displays the date, from 1 to 31. Year displays the year, from 1999 to 2099.

System Time

The time format is <hour>, <minute>, <second>. The time is based on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays seconds from 00 to 59.

84

APPC 1240T/1245T/1540T/1740T/1940T User Manual

NEXCOM APPC 1240T User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Preface

Copyright

Disclaimer

Acknowledgements

Regulatory Compliance Statements

Declaration of Conformity

RoHS Compliance

Warranty and RMA

Safety Information

Installation Recommendations

Safety Precautions

Technical Support and Assistance

Conventions Used in this Manual

Global Service Contact Information

Package Contents

Ordering Information

Chapter 1: Product Introduction

APPC 1240T/1245T

Specifications

APPC 1540T

Specifications

APPC 1740T

Specifications

APPC 1940T

Specifications

Knowing Your APPC Series

Rear Top

Rear Bottom

Rear

Mechanical Dimensions

APPC 1240T/1245T

APPC 1540T

APPC 1740T

APPC 1940T

Chapter 2: Jumpers and Connectors

Before You Begin

Precautions

Jumper Settings

Locations of the Jumpers and Connectors

Top View

Bottom View

Jumpers and DIP Switch Settings

RTC and SRTC Clear Select

AT/ATX Power Select

Dimming Signal Level Select

LCD Panel VDD Power Select

Touch 4/5 Wire Select

COM1 RI Pin Power Select

COM2 RI Pin Power Select

Panel Resolution Select

Dimming Type Select

Connector Pin Definitions

External I/O Interfaces

Line-out Connector

Remote Power On/Off Switch

LAN1 Port

LAN2 Port

Dual USB 2.0 Port

Single USB 3.0 Port

COM1 Port

COM2 Port

VGA Port

12V - 30V DC Power Input

CFast Card Slot

Reset Button

Internal Connectors

CCFL Panel Backlight Connector

LVDS Channel A

LVDS Channel B

Line-in/Mic-in Connector

Speaker-out Connector

USB Connector

Touch Sensor Connector

SATA Connector

SATA DOM Power Connector

DIO Connector (Optional)
