Nexcom NISE 3640M2, NISE 3640M, NISE 3640M2E, 10J00364006X0, 10J00364009X0 User Manual

NEXCOM International Co., Ltd.

Published August 2014

www.nexcom.com

Industrial Computing Solutions

Fan-less Computer NISE 3640M Series

User Manual

ii

NISE 3640M Series User Manual

Content

Contents

Preface

Copyright ............................................................................................. iv

Disclaimer .............................................................................................. iv

Acknowledgements ............................................................................... iv

Regulatory Compliance Statements ........................................................ iv

Declaration of Conformity ...................................................................... iv

RoHS Compliance ................................................................................... v

Warranty and RMA ................................................................................ vi

Safety Information ................................................................................viii

Installation Recommendations ...............................................................viii

Safety Precautions .................................................................................. ix

Medical Equipment Precautions .............................................................. x

Technical Support and Assistance ............................................................ x

Conventions Used in this Manual ........................................................... xi

Conventions Used in this Manual Cont. .................................................xii

MC Potential Equalization Connector .....................................................xii

Guidance and Manufacturer’s Declaration – Electromagnetic Immunity .xiii

Global Service Contact Information .......................................................xiv

Package Contents .................................................................................xvi

Ordering Information ........................................................................... xvii

Chapter 1: Product Introduction

Overview ................................................................................................1

Key Features ...........................................................................................1

Hardware Specifications ..........................................................................2

Knowing Your NISE 3640M ..................................................................... 4

Front Panel ..........................................................................................4

Rear Panel ...........................................................................................5

Mechanical Dimensions ...........................................................................6

Chapter 2: Jumpers and Connectors

Before You Begin ....................................................................................7

Precautions ............................................................................................7

Jumper Settings ......................................................................................8

Locations of the Jumpers and Connectors for NISB 3640 .........................9

NISB 3640 ...........................................................................................9

Jumpers ................................................................................................10

ME Pin Header ...................................................................................10

COM4 RS232 RI# Pin Power Select ....................................................10

LVDS Power Pin Header .....................................................................11

Connector Pin Definitions .....................................................................12

External I/O Interfaces - Front Panel ...................................................12

USB 3.0 ..........................................................................................12

USB 2.0 ..........................................................................................12

DisplayPort A .................................................................................13

DisplayPort B ..................................................................................13

CFast .............................................................................................14

SIM Card Connector ......................................................................14

Power Switch .................................................................................15

External I/O Interfaces - Rear Panel.....................................................16

Remote Power on/off Switch ..........................................................16

DC-in Power Jack ...........................................................................16

COM 1 and COM 2 Ports ...............................................................17

COM3 to COM6 ............................................................................18

LAN1 and LAN2 Ports .....................................................................19

LAN3 and LAN4 Ports .....................................................................20

VGA and DVI-D Connectors ...........................................................21

Audio Connectors ..........................................................................22

Internal Connectors ........................................................................... 23

iii

NISE 3640M Series User Manual

Content

SIM Card Line-out Pin Header ........................................................23

SIM Card Mic-in Pin Header ...........................................................23

DC-in Power Connector .................................................................24

CMOS Pin Header ..........................................................................24

Reset JST Connector .......................................................................25

LVDS Channel A Connector ............................................................ 25

LVDS Channel B Connector ............................................................ 26

LVDS Backlight Connector .............................................................. 26

Line-in 1 Pin Header .......................................................................27

Line-in 2 Pin Header .......................................................................27

SATA3 Connector 1 ........................................................................28

SATA3 Connector 2 ........................................................................28

SATA3 Power Connector 1 .............................................................29

SATA3 Power Connector 2 .............................................................29

GPS JST Connector .........................................................................30

USB 2.0 JST Connector ...................................................................30

PCIe x8 Slot ....................................................................................31

Mini-PCIe Connector ......................................................................32

GPIO Pin Header ............................................................................33

GPIO LED Pin Header ......................................................................33

Smart Fan1 Connector ...................................................................34

Smart Fan2 Connector ...................................................................34

External LED Pin Header ................................................................. 35

Power/PSON Header .......................................................................35

80 Port ...........................................................................................36

External SMbus .............................................................................. 36

Flash BIOS CON ..............................................................................37

Mini-PCIe Slot ................................................................................38

Chapter 3: System Setup

Mount the System to the Wall ..............................................................39

Removing the Chassis Bottom Cover ....................................................40

Installing a SATA Hard Drive ..................................................................41

Installing a SATA DOM ..........................................................................44

Installing a PCIe/PCI Expansion Card ......................................................46

Removing the Chassis Top Cover ...........................................................48

Installing a SO DIMM ............................................................................49

Installing a Wireless LAN Module (half-size) ........................................... 50

Installing a Wireless LAN Module (full-size) ............................................ 51

Installing a GPS Module ........................................................................52

Installing Antennas ...............................................................................54

Installing a SIM Card .............................................................................55

Installing a CompactFlash Card .............................................................56

Power ON Sequence on NISE 3640M ....................................................56

Power OFF Sequence on NISE 3640M ...................................................56

Chapter 4: BIOS Setup

About BIOS Setup .................................................................................57

When to Configure the BIOS .................................................................57

Default Configuration ...........................................................................58

Entering Setup ......................................................................................58

Legends ................................................................................................58

BIOS Setup Utility ..................................................................................60

Main .................................................................................................60

Advanced .........................................................................................61

Chipset ..............................................................................................72

Boot ..................................................................................................84

Security .............................................................................................86

Save & Exit ........................................................................................86

Appendix A: Power Consumption.........................87

Appendix B: GPI/O Programming Guide...............89

Appendix C: Watchdog Timer Setting...................91

iv

NISE 3640M Series User Manual

Preface

Copyright

This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd.

Disclaimer

The information in this document is subject to change without prior notice and does not represent commitment from NEXCOM International Co., Ltd. However, users may update their knowledge of any product in use by constantly checking its manual posted on our website: http://www.nexcom.com. NEXCOM shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of any product, nor for any infringements upon the rights of third parties, which may result from such use. Any implied warranties of merchantability or fitness for any particular purpose is also disclaimed.

Acknowledgements

NISE 3640M is a trademark of NEXCOM International Co., Ltd. All other product names mentioned herein are registered trademarks of their respective owners.

Regulatory Compliance Statements

This section provides the FCC compliance statement for Class B devices and describes how to keep the system CE compliant.

Declaration of Conformity

FCC

This equipment has been tested and verified to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area (domestic environment) is likely to cause harmful interference, in which case the user will be required to correct the interference (take adequate measures) at their own expense.

CE

The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques.

v

NISE 3640M Series User Manual

Preface

RoHS Compliance

NEXCOM RoHS Environmental Policy and Status Update

This publication, including all photographs, illustrations and software, is protected under international copyright

laws, with all rights reserved. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd.

RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1% or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium (Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.

In order to meet the RoHS compliant directives, NEXCOM has established an engineering and manufacturing task force to implement the introduction of green products. The task force will ensure that we follow the standard NEXCOM development procedure and that all the new RoHS components and new manufacturing processes maintain the highest industry quality levels for which NEXCOM are renowned.

The model selection criteria will be based on market demand. Vendors and suppliers will ensure that all designed components will be RoHS compliant.

How to recognize NEXCOM RoHS Products?

For existing products where there are non-RoHS and RoHS versions, the suffix “(LF)” will be added to the compliant product name.

All new product models launched after January 2006 will be RoHS compliant. They will use the usual NEXCOM naming convention.

vi

NISE 3640M Series User Manual

Preface

Warranty and RMA

NEXCOM Warranty Period

NEXCOM manufactures products that are new or equivalent to new in accordance with industry standard. NEXCOM warrants that products will be free from defect in material and workmanship for 2 years, beginning on the date of invoice by NEXCOM. HCP series products (Blade Server) which are manufactured by NEXCOM are covered by a three year warranty period.

NEXCOM Return Merchandise Authorization (RMA)

▪ Customers shall enclose the “NEXCOM RMA Service Form” with the

returned packages.

▪ Customers must collect all the information about the problems

encountered and note anything abnormal or, print out any on-screen messages, and describe the problems on the “NEXCOM RMA Service Form” for the RMA number apply process.

▪ Customers can send back the faulty products with or without accessories

(manuals, cable, etc.) and any components from the card, such as CPU and RAM. If the components were suspected as part of the problems, please note clearly which components are included. Otherwise, NEXCOM is not responsible for the devices/parts.

▪ Customers are responsible for the safe packaging of defective products,

making sure it is durable enough to be resistant against further damage and deterioration during transportation. In case of damages occurred during transportation, the repair is treated as “Out of Warranty.”

▪ Any products returned by NEXCOM to other locations besides the

customers’ site will bear an extra charge and will be billed to the customer.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

Repair Service Charges for Out-of-Warranty Products

NEXCOM will charge for out-of-warranty products in two categories, one is basic diagnostic fee and another is component (product) fee.

System Level

▪ Component fee: NEXCOM will only charge for main components such as

SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistor, capacitor.

▪ Items will be replaced with NEXCOM products if the original one cannot

be repaired. Ex: motherboard, power supply, etc.

▪ Replace with 3rd party products if needed.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

Board Level

▪ Component fee: NEXCOM will only charge for main components, such

as SMD chip, BGA chip, etc. Passive components will be repaired for free, ex: resistors, capacitors.

▪ If RMA goods can not be repaired, NEXCOM will return it to the customer

without any charge.

vii

NISE 3640M Series User Manual

Preface

Warnings

Read and adhere to all warnings, cautions, and notices in this guide and the documentation supplied with the chassis, power supply, and accessory modules. If the instructions for the chassis and power supply are inconsistent with these instructions or the instructions for accessory modules, contact the supplier to find out how you can ensure that your computer meets safety and regulatory requirements.

Failure to complete all earth ground connection can cause EMI/EMC problem and could create shock hazard in the event of wiring insulation damage.

To avoid risk of electric shock, this equipment must only be connected to a supply mains with protective earth.

Do not modify this equipment without authorization of the manufacturer.

Cautions

Electrostatic discharge (ESD) can damage system components. Do the described procedures only at an ESD workstation. If no such station is available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis.

viii

NISE 3640M Series User Manual

Preface

Installation Recommendations

Ensure you have a stable, clean working environment. Dust and dirt can get into components and cause a malfunction. Use containers to keep small components separated.

Adequate lighting and proper tools can prevent you from accidentally damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following:

▪ A Philips screwdriver

▪ A flat-tipped screwdriver

▪ A grounding strap

▪ An anti-static pad

Using your fingers can disconnect most of the connections. It is recommended that you do not use needle-nose pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

Safety Information

Before installing and using the device, note the following precautions:

▪ Read all instructions carefully.

▪ Do not place the unit on an unstable surface, cart, or stand.

▪ Follow all warnings and cautions in this manual.

▪ When replacing parts, ensure that your service technician uses parts

specified by the manufacturer.

▪ Avoid using the system near water, in direct sunlight, or near a heating

device.

▪ The load of the system unit does not solely rely for support from the

rackmounts located on the sides. Firm support from the bottom is highly necessary in order to provide balance stability.

▪ The computer is provided with a battery-powered real-time clock circuit.

There is a danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

▪ Never open the equipment. For safety reasons, only qualified service

personnel should open the equipment.

Danger of explosion if battery is incorrectly replaced. Replace with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

ix

NISE 3640M Series User Manual

Preface

Safety Precautions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a

damp cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the

equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a stable surface during installation. Dropping it or

letting it fall may cause damage.

7. The openings on the enclosure are for air convection to protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting

the equipment to the power outlet.

9. Place the power cord in a way so that people will not step on it. Do not

place anything on top of the power cord. Use a power cord that has been approved for use with the product and that it matches the voltage and current marked on the product’s electrical range label. The voltage and current rating of the cord must be greater than the voltage and current rating marked on the product.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service personnel:

a. The power cord or plug is damaged. b. Liquid has penetrated into the equipment. c. The equipment has been exposed to moisture. d. The equipment does not work well, or you cannot get it to work

according to the user’s manual. e. The equipment has been dropped and damaged. f. The equipment has obvious signs of breakage.

15. Do not place heavy objects on the equipment.

16. The unit uses a three-wire ground cable which is equipped with a third pin to ground the unit and prevent electric shock. Do not defeat the purpose of this pin. If your outlet does not support this kind of plug, contact your electrician to replace your obsolete outlet.

17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

x

NISE 3640M Series User Manual

Preface

Medical Equipment Precautions

Intend Use Information

The product covered is an accessory intended for use with Medical Equipment to process data.

Disconnect Device Information

To fully disengage the power to the unit, please disconnect the power cord from the AC inlet.

Cleaning Information

Cleaning (Gently wipe it with a piece of soft dry cloth).

Dispose Information

Follow the national requirement to dispose unit.

Type of Protection Against Electric Shock

Class I equipment.

Technical Support and Assistance

1. For the most updated information of NEXCOM products, visit NEXCOM’s

website at www.nexcom.com.

2. For technical issues that require contacting our technical support team or

sales representative, please have the following information ready before calling: – Product name and serial number – Detailed information of the peripheral devices – Detailed information of the installed software (operating system,

version, application software, etc.) – A complete description of the problem – The exact wordings of the error messages

Warning!

1. Handling the unit: Carry the unit with both hands and handle it with care.

2. Maintenance: To keep the unit clean, use only approved cleaning products or clean with a dry cloth.

3. CompactFlash: Turn off the unit’s power before inserting or removing a CompactFlash storage card.

4. Replacement: If the components of the NISE 3640XXXXXXX fail they must be replaced. Please contact the system reseller or vendor to purchase the replacement parts.

xi

NISE 3640M Series User Manual

Preface

Conventions Used in this Manual

Warning: Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself when performing a task.

Hot Surface: Do not touch.

Power On

RJ45 Ethernet Port

VGA Monitor

Audio Mic-in

Audio Line-out

Caution: Information to avoid damaging components or losing data.

Note: Provides additional information to complete a task easily.

Safety Warning: This equipment is intended for installation in a Restricted Access Location only.

Information: Represents detailed information that can be found in the user manual.

USB 2.0

xii

NISE 3640M Series User Manual

Preface

Conventions Used in this Manual Cont. MC Potential Equalization Connector

AC

DC

Dispose of in accordance with your country’s requirement.

Power Adapter AC Input

Power Adapter DC Input

The purpose of additional potential equalization is to equalize potentials between different metal parts that can be touched simultaneously, or to reduce differences of potential which can occur during operation between the bodies of medical electrical devices and conductive parts of other objects.

The MC connector is specially shaped so as to prevent chance disconnection when used as intended, while allowing the lead to be removed without the need for tools.

xiii

NISE 3640M Series User Manual

Preface

Immunity Test IEC 60601 Test Level Compliance Level

interruptions and voltage variations on power supply input lines

IEC 61000-4-11

0 % UT (>95 % dip in UT) for 0,5 cycle

40 % UT (60 % dip in UT) for 5 cycles

70 % UT (30 % dip in UT) for 25 cycles

0 % UT (>95 % dip in UT) for 5 sec

0 % UT (>95 % dip in UT) for 0,5 cycle

40 % UT (60 % dip in UT) for 5 cycles

70 % UT (30 % dip in UT) for 25 cycles

0 % UT (>95 % dip in UT) for 5 sec

Power frequency (50/60 Hz) magnetic field

3 A/m 3 A/m

NOTE: UT is the a.c. mains voltage prior to application of the test level.

Guidance and Manufacturer’s Declaration – Electromagnetic Immunity

The models in NISE 3640M series are intended for use in the electromagnetic environment specified below. The customer or the user of the models in NISE 3640M series should assure that it is used in such an environment.

Immunity Test IEC 60601 Test Level Compliance Level

Conducted RF IEC 61000-4-6

3 Vrms 150 kHz to 80 MHz

3 Vrms

Radiated RF IEC 61000-4-3

3 V/m 80 MHz to 2,5 GHz

3 V/m

Electrostatic discharge (ESD) IEC 61000-4-2

±6 kV contact ±8 kV air

±2 kV ±4 kV ±6 kV contact ±2 kV ±4 kV ±8 kV kV air

Electrical fast transient/burst

IEC 61000-4-4

±2 kV for power supply lines ±1 kV for input/output lines

Surge IEC 61000-4-5

±1 kV line(s) to line(s) ±2 kV line(s) to earth

xiv

NISE 3640M Series User Manual

Preface

Global Service Contact Information

Headquarters

NEXCOM International Co., Ltd.

15F, No. 920, Chung-Cheng Rd., ZhongHe District, New Taipei City, 23586, Taiwan, R.O.C. Tel: +886-2-8226-7786 Fax: +886-2-8226-7782 www.nexcom.com

America

USA NEXCOM USA

2883 Bayview Drive, Fremont CA 94538, USA Tel: +1-510-656-2248 Fax: +1-510-656-2158 Email: sales@nexcom.com www.nexcom.com

Asia

Taiwan NEXCOM Intelligent Systems

Taipei Office

13F, No.920, Chung-Cheng Rd., ZhongHe District, New Taipei City, 23586, Taiwan, R.O.C. Tel: +886-2-8226-7796 Fax: +886-2-8226-7792 Email: sales@nexcom.com.tw www.nexcom.com.tw

NEXCOM Intelligent Systems Taichung Office

16F, No.250, Sec. 2, Chongde Rd., Beitun Dist., Taichung City 406, R.O.C. Tel: +886-4-2249-1179 Fax: +886-4-2249-1172 Email: sales@nexcom.com.tw www.nexcom.com.tw

Japan NEXCOM Japan

9F, Tamachi Hara Bldg., 4-11-5, Shiba Minato-ku, Tokyo, 108-0014, Japan Tel: +81-3-5419-7830 Fax: +81-3-5419-7832 Email: sales@nexcom-jp.com www.nexcom-jp.com

China

NEXCOM China

1F & 2F, Block A, No. 16 Yonyou Software Park, No. 68 Beiqing Road, Haidian District, Beijing, 100094, China Tel: +86-010-5704-2680 Fax: +86-010-5704-2681 Email: sales@nexcom.cn www.nexcom.cn

xv

NISE 3640M Series User Manual

Preface

Wuhan Office

1-C1804/1805, Mingze Liwan, No. 519 South Luoshi Rd., Hongshan District, Wuhan, 430070, China Tel: +86-27-8722-7400 Fax: +86-27-8722-7400 Email: sales@nexcom.cn www.nexcom.cn

Europe

United Kingdom NEXCOM EUROPE

10 Vincent Avenue, Crownhill Business Centre, Milton Keynes, Buckinghamshire MK8 0AB, United Kingdom Tel: +44-1908-267121 Fax: +44-1908-262042 Email: sales.uk@nexcom.eu www.nexcom.eu

Italy NEXCOM ITALIA S.r.l

Via Gaudenzio Ferrari 29, 21047 Saronno (VA), Italia Tel: +39 02 9628 0333 Fax: +39 02 9625570 Email: nexcomitalia@nexcom.eu www.nexcomitalia.it

Chengdu Office

9F, Shuxiangxie, Xuefu Garden, No.12 Section 1, South Yihuan Rd., Chengdu, 610061, China Tel: +86-28-8523-0186 Fax: +86-28-8523-0186 Email: sales@nexcom.cn www.nexcom.cn

Shanghai Office

Room 603/604, Huiyinmingzun Plaza Bldg., 1, No.609, Yunlin East Rd., Shanghai, 200333, China Tel: +86-21-5278-5868 Fax: +86-21-3251-6358 Email: sales@nexcom.cn www.nexcom.cn

Shenzhen Office

Room1707, North Block, Pines Bldg., No.7 Tairan Rd., Futian Area, Shenzhen, 518040, China Tel: +86-755-8332-7203 Fax: +86-755-8332-7213 Email: sales@nexcom.cn www.nexcom.cn

xvi

NISE 3640M Series User Manual

Preface

Package Contents

Before continuing, verify that the NISE 3640M package that you received is complete. Your package should have all the items listed in the following table.

Item Part Number Description Qty

1 4NCPM00203X00 Terminal Blocks 2P Phoenix Contact:1803578 2 2 50311P0001X00 Price For Plastic Screw 1 3 50322P0002X00 Plastic Nut GIN LIAN:M6HW 1 4 60177A0311X00 NISB3640 Quick Reference Guide VER:A 1 5 6023344361X00 Cable EDI:231441090251-RS 1

6 60233POW33X00 DC Cord EDI:281040051051-RS 1 7 50311F0294X00 I Head Screw Long FEI:I2x4 NYLOK NIGP 4 8 50311F0326X00 Flat Head Screw Long FEI:F3x5 NYLOK NI+HEAT TREATMENT 4 9 50311F0143X00 Flat Head Screw Long FEI:F#6-32x8 1

10 50311F0100X00 Round Head Screw w/Spring+Flat Washer Long FEI:P3x6L 2 11 50311F0315X00 Round Head Screw Long FEI:P6#32T T10 NYLOK 1 12 602DCD0654X00 NISE3640E CD Driver VER:1.0 1

xvii

NISE 3640M Series User Manual

Preface

Ordering Information

The following information below provides ordering information for NISE 3640M series.

• Barebone

NISE 3640M (P/N: 10J00364006X0)

- 3rd Generation Intel

®

Core™ i7 Fanless System with one PCIe x4 Expansion

NISE 3640M2 (P/N: 10J00364008X0)

- 3rd Generation Intel

®

Core™ i7 Fanless System with two PCI Expansion

NISE 3640M2E (P/N: 10J00364009X0)

- 3rd Generation Intel

®

Core™ i7 Fanless System with one PCIe x4 Expansion and one PCI Expansion

NISE 3640ME2 (P/N: 10J00364007X0)

- 3rd Generation Intel

®

Core™ i7 Fanless System with two PCIe x4 Expansion

Power Supply SINPRO HPU101-108 24V/4.16A w/EN60601-1 (P/N: 7400100006X00)

1

NISE 3640M Series User Manual

Chapter 1: Product Introduction

Key Features

▪ Onboard 3rd generation Intel® Core™ i7 BGA processor

▪ Mobile Intel

®

QM77 PCH

▪ Support 1x 2.5” SATA HDD or 2x SATA DOM

▪ 2x Display Port; 1x VGA; 1x DVI-D; 2x USB3.0; 2x USB2.0

▪ 4x Intel

®

82574IT GbE LAN ports; support WoL, teaming and PXE

Overview

▪ 2x DB9 for RS232/422/485; 1x DB44 Serial Port for 4x RS232

▪ 1x Internal Mini-PCIe socket supports optional Wi-Fi or 3.5G module

▪ 1x CFast socket; 1xSIM card socket;

▪ Support +24VDC input; support ATX Power mode

▪ TUV/RH Certificate: EN60601-1:2006

2

NISE 3640M Series User Manual

Chapter 1: Product Introduction

Hardware Specifications

CPU Support

▪ Onboard 3rd generation Intel® Core™ i7 BGA processor

Core™ i7-3517UE, Dual Core, 1.7GHz, 6M Cache

▪ Mobile Intel

®

QM77 PCH

Main Memory

▪ On-board 2x DDR3/DDR3L SO-DIMM, supports up to 8GB DDR3/DDR3L

1333/1600 SDRAM, with un-buffered and non-ECC

▪ Pre-install 4G Industrial Grade Memory as the manufacture configuration

for shipment

Display Option

▪ Three Independent Display (only support on 3rd Generation Processor)

- Two Display Port and 1x VGA

- Two Display Port and 1x DVI-D

▪ Dual Independent Display

- VGA and DVI-D

- Display Port and VGA

I/O Interface-Front

▪ ATX power on/off switch ▪ HDD access/ Power status/ LAN status LEDs ▪ 2x USB3.0 (Blue color) ▪ 2x USB2.0 ▪ 2x DisplayPort (Can be converted to DVI-D or HDMI via active cables) ▪ 1x CFast socket ▪ 1x SIM card socket ▪ 2x Antenna holes

I/O Interface-Rear

▪ 2x DB9 for RS232/422/485 ▪ 1x DB44 for 4x RS232 ▪ 4x Intel

®

82574IT GbE LAN ports; support WoL, teaming and PXE ▪ 1x DB15 VGA port ▪ 1x DVI-D ▪ 1x Line-out and 1x Mic-in ▪ 2-pin Remote Power on/off switch ▪ +24VDC Input ▪ 1x Potential Equalization Connector (M6 Type)

Storage Device

▪ 1x 2.5” SATA HDD or 2x SATA DOM

(support 90°C horizontal type only)

▪ 1x CFast socket

Expansion Slot

▪ NISE 3640E: One PCIe x4 Expansion Slot

– Add-on card length: 169mm max. – Power consumption: 10W/slot max.

▪ NISE 3640ME2: Two PCIe x4 expansion

– Add-on card length: One 169mm max. and One 240mm max. – Power consumption: 10W/slot max.

▪ NISE 3640M2: Two PCI expansion

– Add-on card length: One 169mm max. and One 240mm max. – Power consumption: 10W/slot max.

▪ NISE 3640M2E: One PCI expansion and One PCIe x4 expansion

– Add-on card length: 169mm max. for PCIe x4 and 240mm max. for

PCI expansion

– Power consumption: 10W/slot max.

▪ 2x Mini-PCIe sockets (Top side Mini-PCIe Socket support optional Wi-Fi

or 3.5G module)

3

NISE 3640M Series User Manual

Chapter 1: Product Introduction

Power Requirements

▪ Support +24VDC Input

Dimensions

▪ 215mm (W) x 272mm (D) x 93mm (H) without wall mount bracket

(8.5” x 10.7” x 3.7”)

Construction

▪ Aluminum Chassis with fanless design

Environment

▪ Normal Operating Temperature:

- Operating Temperature: -20°C to 45°C, ambient with air flow (According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)

- Relative Humidity: 10% ~ 90%, non-condensing Limits to be at 90% RH at max 40°C

- Atmosphere Pressure: 700-1060hPa

▪ Transport and Storage Temperature:

- Operating Temperature: -30°C to 85°C, ambient with air flow

- Relative Humidity: 10% ~ 90%, non-condensing

- Atmosphere Pressure: 500-1060hPa

▪ Shock protection:

- HDD: 20G, half sine, 11ms, IEC60068-2-27

- CFast: 50G, half sine, 11ms, IEC60068-2-27 ▪ Vibration protection w/ HDD Condition

- Random: 0.5Grms @ 5~500 Hz according to IEC60068-2-64

- Sinusoidal: 0.5Grms @ 5~500 Hz according to IEC60068-2-6

Certifications

▪ CE/FCC Class B ▪ TUV/RH Certificate: EN60601-1:2006

4

NISE 3640M Series User Manual

Chapter 1: Product Introduction

Knowing Your NISE 3640M

Front Panel

USB 3.0

USB 2.0

CFast

SIM Card Power button

Antenna hole Antenna hole

Power/HDD/LAN LEDs

USB 3.0

Dual USB 3.0 ports to connect the system with USB 3.0/2.0 devices.

USB 2.0

Dual USB 2.0 ports to connect the system with USB 2.0 devices.

Antenna Hole

Used to install external antennas.

DisplayPort

Dual DisplayPort to connect the system with display devices.

SIM

Used to insert a SIM card.

CFast Socket

Used to insert a CompactFlash card.

Power/LAN LED

Indicates the power status and LAN activity of the system.

- The Power LED Color: Green

- The LAN LED Color: Green/Amber

HDD/CFast/RF LEDS

Indicates the HDD/CFast/RF activity of the system.

- The HDD/CFast/RF LED Color: Amber

Power Switch

Press to power-on or power-off the system.

- Power off/Standby LED Status Color: Reddish Orange

- Power on LED Status Color: Blue

DisplayPort

5

NISE 3640M Series User Manual

Chapter 1: Product Introduction

Rear Panel

Remote power on/off

Digital Output

24V DC Input

COM3-COM6: RS232

DVI-D

Line-out

Mic-in

COM1-COM2: RS232/422/485

LAN

VGA

Remote Power On/Off

Used to connect a remote to power on/off the system.

Digital Output

Support S3 Wake on LAN.

24V DC Input

Used to plug a DC power cord.

COM1 and COM2

Two DB9 ports used to connect RS232/422/485 compatible devices.

COM3 to COM6

The DB44 port supports RS232 compatible serial devices.

LAN

Used to connect the system to a local area network.

VGA

Used to connect an analog VGA monitor.

DVI-D

Used to connect a digital LCD panel.

Line-out

Used to connect a headphone or a speaker.

Mic-in

Used to connect an external microphone.

6

NISE 3640M Series User Manual

Chapter 1: Product Introduction

Mechanical Dimensions

NISE 3600M

214.6613

272.0000

264.0000

234.0000

204.0000

68.0000

224.68

236.68

92.7305

100.7305

7

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

This chapter describes how to set the jumpers and connectors on the NISE 3640M motherboard.

Before You Begin

▪ Ensure you have a stable, clean working environment. Dust and dirt can

get into components and cause a malfunction. Use containers to keep small components separated.

▪ Adequate lighting and proper tools can prevent you from accidentally

damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following: – A Philips screwdriver – A flat-tipped screwdriver – A set of jewelers screwdrivers – A grounding strap – An anti-static pad

▪ Using your fingers can disconnect most of the connections. It is

recommended that you do not use needle-nosed pliers to disconnect connections as these can damage the soft metal or plastic parts of the connectors.

▪ Before working on internal components, make sure that the power is off.

Ground yourself before touching any internal components, by touching a metal object. Static electricity can damage many of the electronic components. Humid environments tend to have less static electricity than

dry environments. A grounding strap is warranted whenever danger of static electricity exists.

Precautions

Computer components and electronic circuit boards can be damaged by discharges of static electricity. Working on computers that are still connected to a power supply can be extremely dangerous.

Follow the guidelines below to avoid damage to your computer or yourself:

▪ Always disconnect the unit from the power outlet whenever you are

working inside the case.

▪ If possible, wear a grounded wrist strap when you are working inside the

computer case. Alternatively, discharge any static electricity by touching the bare metal chassis of the unit case, or the bare metal body of any other grounded appliance.

▪ Hold electronic circuit boards by the edges only. Do not touch the

components on the board unless it is necessary to do so. Don’t flex or stress the circuit board.

▪ Leave all components inside the static-proof packaging that they shipped

with until they are ready for installation.

▪ Use correct screws and do not over tighten screws.

8

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

Jumper Settings

A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open.

Refer to the illustrations below for examples of what the 2-pin and 3-pin jumpers look like when they are short (on) and open (off).

Two-Pin Jumpers: Open (Left) and Short (Right)

Three-Pin Jumpers: Pins 1 and 2 are Short

1

2

3

1

2

3

9

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

Locations of the Jumpers and Connectors for NISB 3640

NISB 3640

The figures below are the top and bottom views of the NISB 3640 main board which is the main board used in the NISE 3640M. It shows the locations of the jumpers and connectors.

5

1

JP12

BAT1

4

231

9

2

JP2

1

10

J4

25

1

24

JP1

2

SW1

C4 C3

C2

C1

A4 A3

LED1

A2

A1

C4 C3

C2

C1

A4

A3

LED2

A2

A1

C4

C3

C2

C1

A4

LED3

A2

A1

CN5

1

2

15

16

17

18

51

52

S1

PC1S7 P17

CN3

CN5

2

1

22

21

J6

201939

40

JP11

1

4

JP10

1

8

4

USB1

5

1

14

5

4

18

9

1

USB2

3

1

JP13

1

JP4

3

JP6

1

7

J7

J3

6

1

4

FAN1

1

4

FAN2

1

204

203

72

74

73 71

2

1

DIMM2

203

204

7274

73 71

2

1

DIMM1

1

4

2

3

1

4

2

3

1

5

CN1

4

2

CN2

30

44

15

16311

BHFDK

MPT

Y

ABVADAFAHAKAMAPATAYAVBBBD

BF

59 57

61

56

58

60

55

51

53

50

52

54

43

47 45

49

44

46

48

37

39

41

38

40

42

35

31

33

32 30

34

36

23

29 27 25

22

24

26

28

17

19

21

18 16

20

9

11

13

15

14 12 10

U16

5 3

7

2

4

6

8

1

ACGELJR

N

AA

W

U

ACAEAGAJALANARAUAWBABGBEBC

JP7

3

1

3

1

JP8

JP9

3

1

A11

B11

A1

Y

A10

GO

B1

B14

A14

COP1

B10 A10

B11

A11

COP2

A1

YGO

B14

A14

B1

B10

CN6

17

9

1

39

29

34

24

16

8

35

25

30

4248464438364028323034222426141620

18812

10

426

BJ

BB

BF BD

BH

BE BC

BG

AT

AV

AY

AR

AU

AW

BA

AH

AK

AM

AP

AJ

AL

AN

AB

AD

AF

AA

AC

AE

AG

P

T

V

Y

R

U

W

H

K

M

J

L

N

B

D

F

A

C

E

G

494345

47

U31

413937353331292523212719171513

11

97531

5

25

CN9

2

22

J1

1

6

119

CN4

2

20

2

CN8

19 1

20

2

19

CN7

1

H5

H7

A3

10

JP3

JP5

3

1

CON1

J2

J5

24V Input

COM1~COM6

LAN1/LAN2

LAN3/LAN4

VGA/DVI-D

MIC-In/ Line-Out

Power Switch

CFAST

DisplayPort

USB2.0

USB3.0

CN12

7

1

7

1

CN13

4

CN15

1

4

CN11

1

Top View Bottom View

10

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

Jumpers

ME Pin Header

Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP5

Pin Definition

1 SRTC_RST#_PU 2 SRTC_RST# 3 CLR_ME

COM4 RS232 RI# Pin Power Select

Connector type: 1x3 3-pin header, 2.0mm pitch Connector location: JP12

Pin Definition

1 VCC5_RI# 2 SP4_RI_T 3 +12V_RI# 4 SP4_RI_T 5 SP4_RI 6 NA

1 3

15

11

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

LVDS Power Pin Header

Connector type: 1x3 3-pin header, 2.54mm Connector location: JP6

Pin Definition

1 VCC3 2 VCCLCDIN 3 VCC5

1-2 On: default

1 3

12

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

Connector Pin Definitions

External I/O Interfaces - Front Panel

USB 3.0

Connector type: Dual USB 3.0 ports Connector location: USB2

Pin Definition Pin Definition

1 5VSB 2 USB_2N 3 USB_2P 4 GND 5 USB3_RX2_N 6 USB3_RX2_P 7 GND 8 USB3_TX2_N

9 USB3_TX2_P 10 5VSB 11 USB_3N 12 USB_3P 13 GND 14 USB3_RX3_N 15 USB3_RX3_P 16 GND 17 USB3_TX3_N 18 USB3_TX3_P

MH1 F_GND MH2 F_GND MH3 F_GND MH4 F_GND

Pin Definition Pin Definition

1 5VSB 2 USB2_8N 3 USB2_8P 4 GND 5 5VSB 6 USB2_9N

7 USB2_9P 8 GND MH1 F_GND MH2 F_GND MH3 F_GND MH4 F_GND

9

1

5

4

10 13

1418

USB 2.0

Connector type: Dual USB 2.0 ports Connector location: USB1

5

1

8

4

13

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

DisplayPort A

Connector type: DisplayPort Connector location: J6A

Pin Definition Pin Definition

1 DPC_LANE0_P 2 GND_DP 3 DPC_LANE0_N 4 DPC_LANE1_P 5 GND_DP 6 DPC_LANE1_N 7 DPC_LANE2_P 8 GND_DP

9 DPC_LANE2_N 10 DPC_LANE3_P 11 GND_DP 12 DPC_LANE3_N 13 DPC_CONFIG1 14 DPC_CONFIG2 15 DPC_AUX_P 16 GND_DP 17 DPC_AUX_N 18 DPC_HPD 19 GND_DP 20 VCC3

MH1 F_GND MH2 F_GND MH3 F_GND MH4 F_GND

While using DisplayPort to HDMI cable or DisplayPort to DVI cable, the cable must be active type.

2

1

19

20

DisplayPort B

Connector type: DisplayPort Connector location: J6A

Pin Definition Pin Definition

1 DPD_LANE0_P 2 GND_DP 3 DPD_LANE0_N 4 DPD_LANE1_P 5 GND_DP 6 DPD_LANE1_N 7 DPD_LANE2_P 8 GND_DP

9 DPD_LANE2_N 10 DPD_LANE3_P 11 GND_DP 12 DPD_LANE3_N 13 DPD_CONFIG1 14 DPD_CONFIG2 15 DPD_AUX_P 16 GND_DP 17 DPD_AUX_N 18 DPD_HPD 19 GND_DP 20 VCC3

MH1 F_GND MH2 F_GND MH3 F_GND MH4 F_GND

2

1

19

20

14

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

CFast

Connector type: Standard CFast connector Connector location: CN3

Pin Definition Pin Definition

S1 GND PC6 NC S2 SATA_TXP3 PC7 GND S3 SATA_TXN3 PC8 CFAST_LED1_C S4 GND PC9 CFAST_LED2_C S5 SATA_RXN3 PC10 NC S6 SATA_RXP3 PC11 NC

S7 GND PC12 NC PC1 CFAST_CDI PC13 VCC3 PC2 GND PC14 VCC3 PC3 NC PC15 GND PC4 NC PC16 GND PC5 NC PC17 CFAST_CDO

S1 S7 PC1 PC17

SIM Card Connector

Connector location: IDE1

C3 C2 C1

C7 C6 C5

Pin Definition Pin Definition

C1 UIM_PWR C2 UIM_RESET C3 UIM_CLK C5 GND C6 UIM_VPP C7 UIM_DATA

SW1 NC SW2 NC

15

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

Power Switch

Connector location: SW1

Pin Definition Pin Definition

1 GND 2 PBT_PU 3 PBT_PU 4 GND

A1 PWR_SW_N C1 PWR_SW_P

MH1 GND MH2 GND

16

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

DC-in Power Jack

Connector type: CompactFlash Type 2 Connector location: CN1

Pin Definition Pin Definition

1 VIN 2 VIN 3 GND 4 GND

5 GND MH1 R_GND MH2 R_GND MH3 R_GND MH4 R_GND

External I/O Interfaces - Rear Panel

Remote Power on/off Switch

Connector type: 4-pin switch Connector location: J2

Pin Definition Pin Definition

1 GND 2 PBT_PU 3 SLP_S3# 4 GND

34

21

12

34

17

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

COM 1 and COM 2 Ports

Connector type: DB-9 port, 9-pin D-Sub 2x10 20-pin header, 1.25mm pitch Connector location: CN4

COM 1

COM 2

Pin Definition Pin Definition

1 SP1_DCD 2 SP2_DCD 3 SP1_TXD 4 SP2_TXD 5 SP1_RTS 6 SP2_RTS 7 SP1_RI 8 SP2_RI

9 COM56_GND 10 COM56_GND 11 SP1_RXD 12 SP2_RXD 13 SP1_DTR 14 SP2_DTR 15 SP1_DSR 16 SP2_DSR 17 SP1_CTS 18 SP2_CTS 19 COM56_GND 20 COM56_GND

MH1 COM56_GND MH2 COM56_GND

1

6

5

9

19

20

1

2

19

20

RS232 RS422 RS485

Pin Definition Pin Definition Pin Definition

1 SP1_DCD 1 SP1_TX- 1 SP1_DATA2 SP1_RXD 2 SP1_TX+ 2 SP1_DATA+ 3 SP1_TXD 3 SP1_RX+ 3 NC 4 SP1_DTR 4 SP1_RX- 4 NC 5 GND 5 GND 5 GND 6 SP1_DSR 6 SP1_RTS- 6 NC 7 SP1_RTS 7 SP1_RTS+ 7 NC 8 SP1_CTS 8 SP1_CTS+ 8 NC 9 SP3_RI 9 SP1_CTS- 9 NC

RS232 RS422 RS485

Pin Definition Pin Definition Pin Definition

1 SP2_DCD 1 SP2_TX- 1 SP2_DATA2 SP2_RXD 2 SP2_TX+ 2 SP2_DATA+ 3 SP2_TXD 3 SP2_RX+ 3 NC 4 SP2_DTR 4 SP2_RX- 4 NC 5 GND 5 GND 5 GND 6 SP2_DSR 6 SP2_RTS- 6 NC 7 SP2_RTS 7 SP2_RTS+ 7 NC 8 SP2_CTS 8 SP2_CTS+ 8 NC 9 SP3_RI 9 SP2_CTS- 9 NC

COM1 Connector Pin Definition

COM2 Connector Pin Definition

18

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

COM3 to COM6

Connector type: DB-44 port, 44-pin D-Sub Connector location: CN2

Pin Definition Pin Definition

1 COM3_DCD 2 COM3_RXD

3 COM3_TXD 4 COM3_DTR

5 GND 6 COM3_DSR

7 COM3_RTS 8 COM3_CTS

9 COM3_RI 10 GND 11 COM4_DCD 12 COM4_RXD 13 COM4_TXD 14 COM4_DTR 15 GND 16 COM4_DSR 17 COM4_RTS 18 COM4_CTS 19 COM4_RI 20 GND 21 COM5_DCD 22 COM5_RXD 23 COM5_TXD 24 COM5_DTR 25 GND 26 COM5_DSR 27 COM5_RTS 28 COM5_CTS 29 COM5_RI 30 GND 31 COM6_DCD 32 COM6_RXD

Pin Definition Pin Definition

33 COM6_TXD 34 COM6_DTR 35 GND 36 COM6_DSR 37 COM6_RTS 38 COM6_CTS 39 COM6_RI 40 GND 41 NC 42 NC 43 NC 44 NC

MH1 R_GND MH2 R_GND

1

16

31

15

30

44

19

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

LAN1 and LAN2 Ports

Connector type: Dual RJ45 port with LEDs Connector location: COP1B (LAN1) and COP1A (LAN2)

Pin Definition Pin Definition

B1 MDI0P_LAN1 B2 MDI0N_LAN1 B3 MDI1P_LAN1 B4 MDI1N_LAN1 B5 MDI2P_LAN1 B6 MDI2N_LAN1 B7 MDI3P_LAN1 B8 MDI3N_LAN1 B9 VCC_LAN1 B10 GND

B11 3VSB B12 LED_ACT#_LAN1

B13 LINK100#_LAN1 B14 LINK1G#_LAN1 MH4 R_GND MH5 R_GND MH6 R_GND

LAN1

Pin Definition Pin Definition

A1 MDI0P_LAN2 A2 MDI0N_LAN2 A3 MDI1P_LAN2 A4 MDI1N_LAN2 A5 MDI2P_LAN2 A6 MDI2N_LAN2 A7 MDI3P_LAN2 A8 MDI3N_LAN2

A9 VCC_LAN2 A10 GND A11 3VSA A12 LED_ACT#_LAN2 A13 LINK100#_LAN2 A14 LINK1G#_LAN2

MH4 R_GND MH5 R_GND MH6 R_GND

LAN2

ACT LINK

Act Status

Flashing Yellow Data activity

Off No activity

Link Status

Steady Green 1G network link

Steady Orange 100Mbps network link

Off No link

A1

B8

A8

B1

LAN1

LAN2

20

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

LAN3 and LAN4 Ports

Connector type: Dual RJ45 port with LEDs Connector location: COP2B (LAN3) and COP2A (LAN4)

ACT LINK

Pin Definition Pin Definition

B1 MDI0P_LAN3 B2 MDI0N_LAN3 B3 MDI1P_LAN3 B4 MDI1N_LAN3 B5 MDI2P_LAN3 B6 MDI2N_LAN3 B7 MDI3P_LAN3 B8 MDI3N_LAN3

B9 VCC_LAN3 B10 GND B11 3VSB B12 LED_ACT#_LAN3 B13 LINK100#_LAN3 B14 LINK1G#_LAN3

MH4 R_GND MH5 R_GND MH6 R_GND

Act Status

Flashing Yellow Data activity

Off No activity

Link Status

Steady Green 1G network link

Steady Orange 100Mbps network link

Off No link

LAN3

A1

B8

A8

B1

LAN3

LAN4

Pin Definition Pin Definition

A1 MDI0P_LAN4 A2 MDI0N_LAN4 A3 MDI1P_LAN4 A4 MDI1N_LAN4 A5 MDI2P_LAN4 A6 MDI2N_LAN4 A7 MDI3P_LAN4 A8 MDI3N_LAN4

A9 VCC_LAN4 A10 GND A11 3VSA A12 LED_ACT#_LAN4 A13 LINK100#_LAN4 A14 LINK1G#_LAN4

MH4 R_GND MH5 R_GND MH6 R_GND

LAN4

21

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

VGA and DVI-D Connectors

Connector type: DB-15 port, 15-pin D-Sub (VGA) 24-pin D-Sub, 2.0mm-M-180 (DVI) Connector location: CN6B (VGA) and CN6A (DVI-D)

DVI-D

Pin Definition Pin Definition

1 DVI_TDC2N 2 DVI_TDC2P 3 GND_DVI 4 NC 5 NC 6 DVI_DDC_CLK 7 DVI_DDC_DATA 8 NC

9 DVI_TDC1N 10 DVI_TDC1P 11 GND_DVI 12 NC 13 NC 14 VCC5 15 GND_DVI 16 DVI_HPD 17 DVI_TDC0N 18 DVI_TDC0P 19 GND_DVI 20 NC 21 NC 22 NC 23 DVI_CLK_P 24 DVI_CLK_N

MH1 R_GND MH2 R_GND

2529

3539

1 8

17 24

Pin Definition Pin Definition

25 VGA_RED 26 VGA_GREEN 27 VGA_BLUE 28 GND_DVI 29 GND_DVI 30 VGA_DET 31 GND_DVI 32 GND_DVI 33 VCC5 34 GND_DVI 35 GND_DVI 36 DDC_DATA 37 VGA_HSYNC 38 VGA_VSYNC 39 DDC_CLK MH3 R_GND

MH4 R_GND

VGA

22

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

Audio Connectors

Connector type: 2x 3.5mm TRS Connector location: CN9A (Mic-in) and CN9B (Line-out)

Pin Definition Pin Definition

1 GND_AUD 2 MIC_L

3 GND_AUD 4 MIC-JD1

5 MIC_R MH1 R_GND

MH2 R_GND MH3 R_GND MH4 R_GND 22 LOUT_LBR

23 GND_AUD 24 FRONT-JD 25 LOUT_RBR MH1 NC

Line-out

Mic-in

23

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

Internal Connectors

SIM Card Line-out Pin Header

Connector type: 1x3 3-pin header, 2.0mm Connector location: JP8

SIM Card Mic-in Pin Header

Connector type: 1x3 3-pin header, 2.0mm Connector location: JP9

Pin Definition

1 MIC_RL 2 MIC_RR 3 ANGND

1 3

Pin Definition

1 LOUT_RL 2 LOUT_RR 3 ANGND

1 3

24

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

DC-in Power Connector

Connector type: 2x2 4-pin header Connector location: CON1

Pin Definition

1 GND 2 GND 3 VIN 4 VIN

12

34

CMOS Pin Header

Connector type: 1x3 3-pin header, 2.54mm Connector location: JP4

Pin Definition

1 RTC_RST#_PU 2 RTC_RST# 3 CLR_CMOS

1 3

25

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

Reset JST Connector

Connector type: 1x2 2-pin header, 2.5mm pitch Connector location: J1

Pin Definition

1 PM_RESET#_J

2 GND

12

LVDS Channel A Connector

Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN7

Pin Definition Pin Definition

1 LVDS_DDC_CLK 2 LVDS_DDC_DATA 3 PANEL1_VDD 4 LVDSA_DATA0 5 LVDSA_DATA3 6 LVDSA_DATA#0 7 LVDSA_DATA#3 8 PANEL1_VDD

9 GND 10 LVDSA_DATA1 11 LVDSA_CLK 12 LVDSA_DATA#1 13 LVDSA_CLK# 14 GND 15 GND 16 PANEL1_BACKLIGHT 17 LVDSA_DATA2 18 PANEL1_BACKLIGHT 19 LVDSA_DATA#2 20 GND

MH1 GND MH2 GND

11

9

22

0

26

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

LVDS Channel B Connector

Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN8

Pin Definition Pin Definition

1 DDC_CLK 2 DDC_DATA 3 VDD 4 LVDSB_DATAP0 5 LVDSB_DATAP3 6 LVDSB_DATAN0 7 LVDSB_DATAN3 8 VDD

9 GND 10 LVDSB_DATAP1 11 LVDSB_CLKP 12 LVDSB_DATAN1 13 LVDSB_CLKN 14 GND 15 GND 16 PANEL1_BACKLIGHT 17 LVDSB_DATAP2 18 LVDSB_BACKLIGHT 19 LVDSB_DATAN2 20 GND

MH1 GND MH2 GND

11

9

22

0

71

LVDS Backlight Connector

Connector type: 1x7 JST, 7-pin header, 2.5mm pitch Connector location: J7

Pin Definition Pin Definition

1 VCC5 2 PANEL1_BACKLIGHT 3 PANEL1_BACKLIGHT 4 L_BKLTCTL 5 GND 6 GND 7 LVDS_BKLT_EN

27

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

14

Line-in 1 Pin Header

Connector type: 1x4 4-pin header, 2.5mm pitch Connector location: JP10

Pin Definition

1 LINE1-L

2 R_GND

3 LINE1-JD

4 LINE1-R

14

Line-in 2 Pin Header

Connector type: 1x4 4-pin header, 2.5mm pitch Connector location: JP11

Pin Definition

1 LINE2-L 2 R_GND 3 LINE2-JD 4 LINE2-R

28

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

SATA3 Connector 1

Connector type: Standard Serial ATAIII 7P (1.27mm, SATA-M-180) Connector location: CN13

Pin Definition Pin Definition

1 GND 2 SATA_TXP1

3 SATA_TXN1 4 GND

5 SATA_RXN1 6 SATA_RXP1

7 GND

1 7

SATA3 Connector 2

Connector type: Standard Serial ATAIII 7P (1.27mm, SATA-M-180) Connector location: CN12

Pin Definition Pin Definition

1 GND 2 SATA_TXP0 3 SATA_TXN0 4 GND 5 SATA_RXN0 6 SATA_RXP0 7 GND

1 7

29

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

SATA3 Power Connector 2

Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: CN15

Pin Definition

1 +12V 2 GND 3 GND 4 VCC5

SATA3 Power Connector 1

Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: CN11

Pin Definition

1 +12V

2 GND

3 GND

4 VCC5

14

30

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

GPS JST Connector

Connector type: 1x6 JST, 6-pin header, 1.00mm pitch Connector location: J5

16

Pin Definition Pin Definition

1 3VSB 2 GPS_LED

3 COM6_TXD 4 COM6_RXD

5 GND 6 VCC3

MH1 GND MH2 GND

USB 2.0 JST Connector

Connector type: 1x6 JST, 6-pin header, 2.00mm pitch Connector location: J3

16

Pin Definition Pin Definition

1 5VSB 2 USB2_10N 3 USB2_10P 4 USB2_11N 5 USB2_11P 6 GND

31

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

PCIe x8 Slot

Connector type: PCIe x8 Slot Connector location: SLOT1

Pin Definition Pin Definition

A1 PCIE_PRSNT1 B1 +12V A2 +12V B2 +12V A3 +12V B3 +12V A4 GND B4 GND A5 NC B5 SMB_CLK A6 NC B6 SMB_DATA A7 NC B7 GND A8 NC B8 VCC3

A9 VCC3 B9 NC A10 VCC3 B10 3VSB A11 PLT_RST_CPU_PCIE# B11 PCIE_WAKE# A12 GND B12 NC A13 CLK_PEG_P B13 GND A14 CLK_PEG_N B14 PEG_TXP0 A15 GND B15 PEG_TXN0 A16 PEG_RXP0 B16 GND A17 PEG_RXN0 B17 PRSNT2_1 A18 GND B18 GND A19 NC B19 PEG_TXP0 A20 GND B20 PEG_TXN0 A21 PEG_RXP1 B21 GND

Pin Definition Pin Definition

A22 PEG_RXN1 B22 GND A23 GND B23 PEG_TXP0 A24 GND B24 PEG_TXN0 A25 PEG_RXP2 B25 GND A26 PEG_RXN2 B26 GND A27 GND B27 PEG_TXP0 A28 GND B28 PEG_TXN0 A29 PEG_RXP3 B29 GND A30 PEG_RXN3 B30 NC A31 GND B31 PRSNT2_2 A32 NC B32 GND A33 NC B33 PEG_TXP0 A34 GND B34 PEG_TXN0 A35 PEG_RXP4 B35 GND A36 PEG_RXN4 B36 GND A37 GND B37 PEG_TXP0 A38 GND B38 PEG_TXN0 A39 PEG_RXP5 B39 GND A40 PEG_RXN5 B40 GND A41 GND B41 PEG_TXP0 A42 GND B42 PEG_TXN0 A43 PEG_RXP6 B43 GND A44 PEG_RXN6 B44 GND A45 GND B45 PEG_TXP0 A46 GND B46 PEG_TXN0 A47 PEG_RXP7 B47 GND A48 PEG_RXN7 B48 PRSNT2_3 A49 GND B49 GND

A1B1A11

B11

A12

B12

A49

B49

32

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

12

51 52

Pin Definition Pin Definition

1 MIC_R 2 3VSB 3 MIC_L 4 GND 5 LOUT_R 6 V1_5 7 LOUT_L 8 3VSB

9 GND 10 UIM_DATA 11 PCIE_MINI_CLK_N 12 UIM_CLK 13 PCIE_MINI_CLK_P 14 UIM_RESET 15 GND 16 UIM_VCCP 17 GND 18 GND 19 GND 20 3VSB 21 GND 22 PLT_RST 23 PCIE_MINI_RXN 24 3VSB 25 PCIE_MINI_RXP 26 GND

Mini-PCIe Connector

Connector location: CN5

Pin Definition Pin Definition

27 GND 28 V1_5 29 GND 30 SMB_CLK 31 PCIE_MINI_TXN 32 SMB_DATA 33 PCIE_MINI_TXP 34 GND 35 GND 36 USB_N 37 GND 38 USB_P 39 3VSB 40 GND 41 3VSB 42 WLAN_ACT 43 GND 44 WLAN_ACT 45 NA 46 WLAN_ACT 47 NA 48 V1_5 49 NA 50 GND 51 NA 52 3VSB

33

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

GPIO Pin Header

Connector type: 2x5 10-pin header, 2.00mm pitch Connector location: JP2

19

21

0

Pin Definition Pin Definition

1 VCC5 2 GND

3 GPO24 4 GPI20

5 GPO25 6 GPI21

7 GPO26 8 GPI22

9 GPO27 10 GPI23

GPIO LED Pin Header

Connector type: 2x2 4-pin header, 2.00mm pitch Connector location: JP3

34

12

Pin Definition

1 GPO24 2 GND 3 GPO25 4 GND

34

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

Smart Fan1 Connector

Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: FAN1

Pin Definition

1 GND

2 +12V

3 FAN_TAC1

4 FAN_CTL1

14

Smart Fan2 Connector

Connector type: 1x4 4-pin Wafer, 2.54mm pitch Connector location: FAN2

Pin Definition

1 GND 2 +12V 3 FAN_TAC2 4 FAN_CTL2

14

35

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

External LED Pin Header

Connector type: 2x13 26-pin, 2.00mm pitch Connector location: JP1

1

2

25

26

Pin Definition Pin Definition

1 PWR_LED_N 2 PWR_LED_P

3 PCH_SATA_LED# 4 LED_HDDP

5 CFAST_ACCESS 6 CFAST_LED_P

7 RF_LED_N 8 RF_LED_P

9 LAN1_LINK# 10 LAN1_LINKP 11 LED_ACT#_LAN1 12 LAN1_ACTP 13 LAN2_LINK# 14 LAN2_LINKP 15 LED_ACT#_LAN2 16 LAN2_ACTP 17 LAN3_LINK# 18 LAN3_LINKP 19 LED_ACT#_LAN3 20 LAN3_ACTP 21 LAN4_LINK# 22 LAN4_LINKP 23 LED_ACT#_LAN4 24 LAN4_ACTP 25 NC 26 NC

Power/PSON Header

Connector type: 1x4 4-pin header, 3.81mm pitch Connector location: J2

14

Pin Definition Pin Definition

1 GND 2 PBT_PU 3 SLP_S3# 4 GND

36

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

80 Port

Connector type: 1x10 10-pin header, 1.00mm pitch Connector location: J4

110

Pin Definition Pin Definition

1 GND 2 PLT_RST_SIO#

3 CLK_PCI_P80 4 LPC_FRAME#

5 LPC_AD3 6 LPC_AD2

7 LPC_AD1 8 LPC_AD0 9 3VSB 10 3VSB

MH1 GND MH2 GND

External SMbus

Connector type: 1x3 3-pin header, 2.00mm pitch Connector location: JP7

Pin Definition

1 SMB_CLK 2 SMB_DATA 3 GND

1 3

37

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

Flash BIOS CON

Connector type: 2x3 6-pin, 2.00mm pitch Connector location: JFW1

15

26

Pin Definition Pin Definition

1 VSPI 2 GND

3 BIOS_SPI_CS#0 4 BIOS_SPI_CLK

5 BIOS_SPI_SO 6 BIOS_SPI_SI

38

NISE 3640M Series User Manual

Chapter 2: Jumpers and Connectors

12

51 52

Pin Definition Pin Definition

1 PCIE_WAKE# 2 3VSB

3 NC 4 GND

5 NC 6 V1_5

7 PCIE_MINI2_CLKREQ#A 8 NC

9 GND 10 NC 11 CLK_PCIE_MINI2_N 12 NC 13 CLK_PCIE_MINI2_P 14 NC 15 GND 16 NC 17 NC 18 GND 19 NC 20 3VSB_MINI1 21 GND 22 PLT_RST_SP338# 23 PCIE_RXN2_MINI_PCIE 24 3VSB 25 PCIE_RXP2_MINI_PCIE 26 GND

Mini-PCIe Slot

Connector location: CN14

Pin Definition Pin Definition

27 GND 28 V1_5 29 GND 30 SMB_CLK 31 PCIE_TXN2_MINI_PCIE 32 SMB_DATA 33 PCIE_TXP2_MINI_PCIE 34 GND 35 GND 36 USB_1N 37 GND 38 USB_1P 39 3VSB_MINI1 40 GND 41 3VSB_MINI1 42 NA 43 GND 44 NA 45 NA 46 NA 47 NA 48 V1_5 49 NA 50 GND 51 NA 52 3VSB_MINI1

39

NISE 3640M Series User Manual

Chapter 3: System Setup

Mount the System to the Wall

The wallmount brackets provides a convenient and economical way of mounting the system on the wall.

1. The mounting holes are located at the bottom of the system. Secure the brackets on each side of the system using the provided mounting screws.

2. Now mount the system on the wall by fastening screws through the bracket’s mounting holes.

Wall Mount Bracket

Secure the bracket to the system

40

NISE 3640M Series User Manual

Chapter 3: System Setup

Removing the Chassis Bottom Cover

Note: Installation for SATA Hard Drive and SATA DOM only

Prior to removing the chassis cover, make sure the unit’s power is off and disconnected from the power sources to prevent electric shock or system damage.

1. With the bottom side of the chassis facing up, remove the mounting screw of the bottom cover and then put them in a safe place for later use.

2. Lift up the cover and remove it from the chassis.

41

NISE 3640M Series User Manual

Chapter 3: System Setup

1. Remove 4 screws around the empty HDD bracket.

Installing a SATA Hard Drive

2. Use the provided screws to secure the drive in place.

42

NISE 3640M Series User Manual

Chapter 3: System Setup

SATA data/power cable

SATA drive/bracket

3. Connect the SATA data/power cable and fasten the cable to HDD bracket by provided screw.

Panel

4. Insert the HDD bracket onto the panel at a 45 degree angle, and gently slide the HDD bracket in place.

43

NISE 3640M Series User Manual

Chapter 3: System Setup

5. Connect the SATA data/power cable to the connector on the SATA drive then secure the HDD bracket to its original place.

Screws

SATA drive/bracket

44

NISE 3640M Series User Manual

Chapter 3: System Setup

1. Remove the HDD bracket before installing a SATA DOM.

2. Locate the SATA connector on the board and fasten with the copper post included in the accessory package.

Installing a SATA DOM

SATA Connector/ SATA Power Connector

Copper Post

3. Connect one side of power cable to the SATA DOM.

45

NISE 3640M Series User Manual

Chapter 3: System Setup

4. Install the SATA DOMM and connect the other side of SATA power cable to the SATA power connector.

ScrewSATA Connector

Power Connector

5. Fasten the screw on the top of copper post.

The SATA DOMM is locked after installation. Be sure to push the lock when releasing.

46

NISE 3640M Series User Manual

Chapter 3: System Setup

Installing a PCIe/PCI Expansion Card

Note: NISE 3640E is equipped with one PCIe x4 expansion slot. NISE 3640E2 is equipped with two PCIe x4 expansion slot. NISE 3640P2 is equipped with two PCI expansion slot. NISE 3640P2E is equipped with one PCIe x4 expansion slot and one PCI expansion slot.

1. Remove the chassis bottom cover.

2. Remove screws of the riser bracket.

Riser bracket

3. Remove screws on the expansion cover.

Note: Example shown is NISE 3640P2E

Screw

47

NISE 3640M Series User Manual

Chapter 3: System Setup

Note: Example shown is NISE 3640P2E

4. Insert PCIe/PCI expansion card and fasten the screw.

5. Secure the riser bracket to its original position.

Screw

48

NISE 3640M Series User Manual

Chapter 3: System Setup

Removing the Chassis Top Cover

1. Remove the mounting screw on the top cover and then put them in a safe place for later use.

2. Lift up the cover and remove it from the chassis.

49

NISE 3640M Series User Manual

Chapter 3: System Setup

3. Insert the module into the socket at an 90 degree angle. Apply firm even pressure to each end of the module until it slips into the socket.

SO DIMM

4. While pushing the SO DIMM into the position, the lock will close automatically.

Installing a SO DIMM

1. Locate the SO DIMM socket.

SO DIMM Socket

2. Release the lock on the SO DIMM socket.

Lock

50

NISE 3640M Series User Manual

Chapter 3: System Setup

Installing a Wireless LAN Module (half-size)

1. Locate the Mini PCI Express slot on the board.

Mini PCI Express Slot

Screw

2. Fasten the Wireless LAN module with the mini PCI express bracket.

3. Insert the wireless LAN module into the Mini PCI Express slot at a 45 degree angle until the gold-plated connector on the edge of the module completely disappears inside the slot.

4. Push the module down and then secure it with mounting screws.

Screw

51

NISE 3640M Series User Manual

Chapter 3: System Setup

Installing a Wireless LAN Module (full-size)

1. Locate the Mini PCI Express slot on the board.

Mini PCI Express Slot

2. Insert the wireless LAN module into the Mini PCI Express slot at a 45 degree angle until the gold-plated connector on the edge of the module completely disappears inside the slot.

3. Push the module down and then secure it with mounting screws.

Screw

52

NISE 3640M Series User Manual

Chapter 3: System Setup

Installing a GPS Module

1. Locate the GPS module install location and remove the two screws on the board.

Screw

2. Fasten the copper post included in the accessory bag onto the screw holes.

Copper Post

3. Secure the GPS bracket on the copper post.

Screws

53

NISE 3640M Series User Manual

Chapter 3: System Setup

4. Secure the GPS module to the bracket.

Screws

5. Connect the GPS cable

54

NISE 3640M Series User Manual

Chapter 3: System Setup

Installing Antennas

1. Remove the antenna hole covers located in the front panel.

Antenna hole coversAntenna hole covers

3. Insert the 2 rings (ring 1 and ring2) onto the antenna jack.

Antenna jack

2. Insert the antenna jack through the antenna hole.

4. Attach one end of the RF cable onto the module.

RF Cable

55

NISE 3640M Series User Manual

Chapter 3: System Setup

1. Locate the SIM card on the front panel.

Installing a SIM Card

SIM Card

2. Push the yellow button to release the SIM card holder.

3. Place the SIM card to the SIM card holder and secure it to the original position.

56

NISE 3640M Series User Manual

Chapter 3: System Setup

Installing a CompactFlash Card

1. The CompactFlash socket is located at the front side of the chassis.

CompactFlash

2. Remove the mounting screws and cover of the CompactFlash socket.

3. Insert the CFast

4. Fasten the cover after installation.

Mounting screw

Power ON Sequence on NISE 3640M

Power OFF Sequence on NISE 3640M

1. Connect Power Supply SINPRO HPU101-108 24V into AC Power Source. The AC Power Source needs to comply with following requirement:

▪ 100-240V~47-63Hz, 1.2-0.5A

2. Connect Power Supply SINPRO HPU101-108 24V into NISE 3640M DC IN Mini-DIN Connector at rear panel.

3. Push the Power button on NISE 3640M.

1. Shut down the system by OS or by pushing the power button.

2. Disconnect the power cord from the AC inlet.

57

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

This chapter describes how to use the BIOS setup program for the NISE 3640M. The BIOS screens provided in this chapter are for reference only and may change if the BIOS is updated in the future.

To check for the latest updates and revisions, visit the NEXCOM Web site at www.nexcom.com.tw.

About BIOS Setup

The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to suit your individual work needs. It is a ROM-based configuration utility that displays the system’s configuration status and provides you with a tool to set system parameters.

These parameters are stored in non-volatile battery-backed-up CMOS RAM that saves this information even when the power is turned off. When the system is turned back on, the system is configured with the values found in CMOS.

With easy-to-use pull down menus, you can configure such items as:

▪ Hard drives, diskette drives, and peripherals

▪ Video display type and display options

▪ Password protection from unauthorized use

▪ Power management features

The settings made in the setup program affect how the computer performs. It is important, therefore, first to try to understand all the setup options, and second, to make settings appropriate for the way you use the computer.

When to Configure the BIOS

▪ This program should be executed under the following conditions:

▪ When changing the system configuration

▪ When a configuration error is detected by the system and you are

prompted to make changes to the setup program

▪ When resetting the system clock

▪ When redefining the communication ports to prevent any conflicts

▪ When making changes to the Power Management configuration

▪ When changing the password or making other changes to the security

setup

Normally, CMOS setup is needed when the system hardware is not consistent with the information contained in the CMOS RAM, whenever the CMOS RAM has lost power, or the system features need to be changed.

58

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Default Configuration

Most of the configuration settings are either predefined according to the Load Optimal Defaults settings which are stored in the BIOS or are automatically detected and configured without requiring any actions. There are a few settings that you may need to change depending on your system configuration.

Entering Setup

When the system is powered on, the BIOS will enter the Power-On Self Test (POST) routines. These routines perform various diagnostic checks; if an error is encountered, the error will be reported in one of two different ways:

▪ If the error occurs before the display device is initialized, a series of beeps

will be transmitted.

▪ If the error occurs after the display device is initialized, the screen will

display the error message.

Powering on the computer and immediately pressing <Del> allows you to enter Setup. Another way to enter Setup is to power on the computer and wait for the following message during the POST:

TO ENTER SETUP BEFORE BOOT PRESS

Ctrl

+

Alt

+

Press the

key to enter Setup:

Legends

Key Function

Moves the highlight left or right to select a menu.

Moves the highlight up or down between sub¬menus or fields.

Exits the BIOS Setup Utility.

Scrolls forward through the values or options of the highlighted field.

Scrolls backward through the values or options of the highlighted field.

Selects a field.

Displays General Help.

Load previous values.

Load optimized default values.

Saves and exits the Setup program.

Press <Enter> to enter the highlighted sub¬menu

59

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Scroll Bar

When a scroll bar appears to the right of the setup screen, it indicates that there are more available fields not shown on the screen. Use the up and down arrow keys to scroll through all the available fields.

Submenu

When “” appears on the left of a particular field, it indicates that a submenu which contains additional options are available for that field. To display the submenu, move the highlight to that field and press .

60

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

BIOS Setup Utility

Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on the screen. The main menu allows you to select from several setup functions and one exit. Use arrow keys to select among the items and press to accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.

Save & Exit

Advanced Chipset Boot SecurityMain

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Set the Date. Use Tab to switch between Date elements.

BIOS Information BIOS Vendor Core Version Compliancy Project Version Build Date and Time

Memory Information Memory Frequency Total Memory DIMM#0 DIMM#2

ME Firmware Information ME FW Version ME Firmware Mode ME Firmware SKU

System Date

System Time

American Megatrends

4.6.5.3 UEFI 2.3; PI 1.2 N364-004 03/05/2013 15:27:37

1600 Mhz 8192 MB (DDR3) 4096 MB (DDR3) 4096 MB (DDR3)

8.0.3.1427 Normal Mode

1.5MB

[Mon 03/25/2013] [13:27:32]

System Date

The date format is <day>, <month>, <date>, <year>. Day displays a day, from Monday to Sunday. Month displays the month, from January to December. Date displays the date, from 1 to 31. Year displays the year, from 1999 to 2099.

System Time

The time format is <hour>, <minute>, <second>. The time is based on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays seconds from 00 to 59.

61

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Save & Exit

Advanced Chipset Boot Security

Main

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

System ACPI Parameters.

► ACPI Settings

► RTC Wake Settings ► CPU Conguration ► SATA Conguration ► USB Conguration ► Super IO Conguration ► Smart Fan Function ► H/W Monitor ► CPU PPM Conguration

Advanced

The Advanced menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference.

Setting incorrect field values may cause the system to malfunction.

Exit

Advanced Chipset PCIPnP Security

Main

← Select Screen ↑↓ Select Item +/- Change Field Tab Select Field F1 General Help F10 Save & Exit ESC Exit

Enables or Disables System

ability to Hibernate (OS/S4 Sleep

State). This option may be not effective with some OS.

ACPI Settings

Enable Hibernation

ACPI Sleep State

Enable Hibernation

Disabled

[Enabled]

[S3 only(Suspend to. . .]

ACPI Settings

This section is used to configure ACPI Settings.

Enable Hibernation

Enables or disables system ability to hibernate (OS/S4 Sleep State). This option may not be effective with some OS.

Enabled

62

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Exit

Advanced Chipset PCIPnP Security

Main

Select the ACPI sleep state the system will enter when the SUSPEND button is pressed.

ACPI Settings

Enable Hibernation

ACPI Sleep State

Suspend Disabled

S1 only (CPU Stop Clock)

[Enabled]

[S3 only(Suspend to...]

Select the highest ACPI sleep state the system will enter when the suspend button is pressed. The options are Suspend Disabled, S1 (CPU Stop Clock) and S3 (Suspend to RAM).

ACPI Sleep State

S3 only (Suspend to RAM)

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Exit

Advanced Chipset PCIPnP Security

Main

Enable or disable System

wake on alarm event. When enabled, System will wake on the hr::min::sec specied

Wake system with Fixed Time

Enabled

[Disabled]

Enables or disables the system’s wake on alarm event. When enabled, the system will wake up on the specified time.

Wake System with Fixed Time

This section is used to configure the wake up function.

Disabled

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

63

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

CPU Configuration

This section is used to configure the CPU.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enabled for Windows XP and Linux (OS optimized for

Hyper-Threading Technology)

and Disabled for other OS (OS not optimized for

Hyper-Threading Technology).

When Disabled only one thread per enabled core is enabled.

CPU Conguration

Intel(R) Core(TM) CPU i5-3610ME CPU @ 2.70GHz

CPU Signature Microcode Patch CPU Speed Processor Cores

Intel HT Technology

Intel VT-x Technology Intel SMX Technology 64-bit

Hyper-threading

Limit CPUID Maximum Intel Virtualization Technology

306a9 10

1600 MHz

2 Supported Supported Supported Supported

[Enabled]

[Disabled] [Disabled]

Hyper Threading

Enables or disables hyper-threading technology.

Limit CPUID Maximum

The CPUID instruction of some newer CPUs will return a value greater than 3. The default is Disabled because this problem does not exist in the Windows series operating systems. If you are using an operating system other than Windows, this problem may occur. To avoid this problem, enable this field to limit the return value to 3 or lesser than 3.

Intel® Virtualization Technology

Enables or disables Intel® Virtualization technology.

64

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

SATA Configuration

This section is used to configure the SATA drives.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enable or disable SATA Device.

SATA Controller(s)

SATA Mode Selection

Serial ATA Port 0 Software Preserve Serial ATA Port 1 Software Preserve Serial ATA Port 2 Software Preserve Serial ATA Port 3 Software Preserve

[Enabled]

[IDE]

ST9160314AS (160.0 SUPPORTED Empty

Unknown

Empty

Unknown

32GB SATA Flas (32.0G SUPPORTED

SATA Controller(s)

Enables or disables SATA device.

SATA Mode Selection

Configures the SATA as IDE, AHCI or RAID mode.

IDE This option configures the Serial ATA drives as Parallel ATA physical storage device. RAID This option allows you to create RAID or Intel Matrix Storage configuration on Serial ATA devices. AHCI This option configures the Serial ATA drives to use AHCI (Advanced Host Controller Interface). AHCI allows the storage driver to enable the advanced Serial ATA features which will increase storage performance.

Serial ATA Port 0 to Serial ATA Port 3

Displays information on the SATA devices detected.

65

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will

keep USB devices available

only for EFI applications.

USB Conguration

USB Devices:

1 Keyboard, 2 Hubs

Legacy USB Support

USB3.0 Support

[Enabled]

Legacy USB Support

Enable Enables Legacy USB. Auto Disables support for Legacy when no USB devices are connected. Disable Keeps USB devices available only for EFI applications.

USB3.0 Support

Enables or disables USB 3.0 controller support.

USB Configuration

This section is used to configure the USB.

Super IO Configuration

This section is used to configure the serial ports.

Super IO Chip

Displays the Super I/O chip used on the board.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Set Parameters of Serial Port O (COMA)

Super IO Conguration

Super IO Chip



Serial Port 0 Conguration



Serial Port 1 Conguration



Serial Port 2 Conguration



Serial Port 3 Conguration



Serial Port 4 Conguration



Serial Port 5 Conguration

IT8783F

66

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Serial Port 0 Configuration

This section is used to configure serial port 0.

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port 1 Mode

Select this to change the serial port mode to RS232, RS422, RS485 or RS485 Auto.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enable or Disable Serial Port (COM)

Serial Port 0 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port 1 Mode Onboard Serial Port Max Baud Rate

[Enabled]

IO=3F8h; IRQ=4;

[IO=3F8h; IRQ=4;] [RS232] [115200 bps]

Serial Port 1 Configuration

This section is used to configure serial port 1.

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port 1 Mode

Select this to change the serial port mode to RS232, RS422, RS485 or RS485 Auto.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enable or Disable Serial Port (COM)

Serial Port 1 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port 1 Mode Onboard Serial Port Max Baud Rate

[Enabled]

IO=2F8h; IRQ=3;

[IO=2F8h; IRQ=3;] [RS232] [115200 bps]

67

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Serial Port 2 Configuration

This section is used to configure serial port 2.

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enable or Disable Serial Port (COM)

Serial Port 2 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port Max Baud Rate

[Enabled]

IO=3E8h; IRQ=10;

[IO=3E8h; IRQ=10;] [115200 bps]

Serial Port 3 Configuration

This section is used to configure serial port 3.

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enable or Disable Serial Port (COM)

Serial Port 3 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port Max Baud Rate

[Enabled]

IO=2E8h; IRQ=11;

[IO=2E8h; IRQ=11;] [115200 bps]

68

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Serial Port 4 Configuration

This section is used to configure serial port 4.

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enable or Disable Serial Port (COM)

Serial Port 4 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port Max Baud Rate

[Enabled]

IO=2F0h; IRQ=6;

[IO=2F0h; IRQ=6;] [115200 bps]

Serial Port 5 Configuration

This section is used to configure serial port 5.

Serial Port

Enables or disables the serial port.

Change Settings

Selects an optimal setting for the Super IO device.

Onboard Serial Port Max Baud Rate

Select this to change the max baud rate of the serial port.

Onboard Serial Port 6 Mode

Select this to change the serial port mode to RS232, RS422, RS485 or RS485 Auto.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enable or Disable Serial Port (COM)

Serial Port 5 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port Max Baud Rate Onboard Serial Port 6 Mode

[Enabled]

IO=2E0h; IRQ=7;

[IO=2E0h; IRQ=7;] [115200 bps] [RS232]

69

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Onboard Serial Port 6 Mode

Select this to change the serial port mode to RS232 or GPS.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enable or Disable Serial Port (COM)

Serial Port 5 Conguration

Serial Port

Device Settings

Change Settings Onboard Serial Port Max Baud Rate

Onboard Serial Port 6 Mode

[Enabled]

IO=2E0h; IRQ=7;

[IO=2E0h; IRQ=7;] [115200 bps]

[RS232]

Smart Fan Function

This section is used to configure the fan’s function.

Smart Fan Mode

Selects the mode of the fan, the options are Full on Mode, Automatic Mode and Disable Mode.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Smart Fan Mode Select

PC Health Status

Smart Fan Mode

[Full on Mode]

GPS

RS232

Onboard Serial Port 6 Mode

Automatic Mode Disable Mode

Full on Mode

Smart Fan Mode

70

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

H/W Monitor

This section is used to monitor hardware status such as temperature, fan speed and voltages.

CPU Temperature

Detects and displays the current CPU temperature.

System Temperature

Detects and displays the current system temperature.

Fan1 Speed

Detects and displays Fan1 speed.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Pc Health Status

CPU temperature System temperature Fan1 Speed Fan2 Speed VCORE +3.3V +5V +12V

: +32C : +32C : N/A : N/A : +0.848 V : +3.328 V : +5.017 V : +11.932 V

Fan2 Speed

Detects and displays Fan2 speed.

VCORE

Detects and displays the Vcore CPU voltage.

3.3V

Detects and displays 3.3V voltage.

5V

Detects and displays 5V voltage.

12V

Detects and displays 12V voltage.

71

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

CPU PPM Configuration

This section is used to configure the Processor Power Management (PPM) configuration.

EIST

Enables or disables Intel® SpeedStep.

CPU C3 Report

Enables or disables C3 report to the operating system.

CPU C6 Report

Enables or disables C6 report to the operating system.

CPU C7 Report

Enables or disables C7 report to the operating system.

Advanced

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enable/Disable Intel SpeedStep

CPU PPM Conguration

EIST

CPU C3 Report CPU C6 report CPU C7 report

[Disabled]

[Disabled] [Disabled] [Disabled]

72

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Chipset

This section gives you functions to configure the system based on the specific features of the chipset. The chipset manages bus speeds and access to system memory resources.

PCH-IO Configuration

This section is used to configure PCH-IO configuration.

LAN1 to LAN4 Controller

Enables or disables the onboard controllers for LAN1 to LAN4.

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

USB Conguration settings

► USB Conguration

► PCH Azalia Conguration ► BIOS Security Conguration

LAN1 Controller LAN2 Controller LAN3 Controller LAN4 Controller

Restore AC Power Loss

[Enabled] [Enabled] [Enabled] [Enabled]

[Power On]

Save & Exit

Advanced Chipset Boot SecurityMain

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

PCH Parameters

►PCH-IO Conguration

►System Agent (SA) Conguration

PCH-IO Configuration

PCH-IO parameters.

System Agent (SA) Configuration

System Agent (SA) parameters.

73

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

USB Configuration

EHCI1 and EHCI2

Enables or disables the Enhanced Host Controller Interface (USB 2.0), one EHCI controller must always be enabled.

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Control the USB EHCI (USB 2.0)

functions.

One EHCI controller must always

be enabled.

USB Conguration

EHCI1

EHCI2

[Enabled]

PCH Azalia Configuration

Azalia

Control Detection of the Azalia device.

Disabled Azalia will be unconditionally disabled. Enabled Azalia will be unconditionally Enabled.

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Control Detection of the Azalia device. Disabled = Azalia will be unconditionally disabled Enabled = Azalia will be unconditionally Enabled Auto = Azalia will be enabled if present, disabled otherwise.

PCH Azalia Conguration

Azalia

[Enabled]

74

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

BIOS Security Configuration

RTC RAM Lock

Enables or disables bytes 38h-3Fh in the upper and lower 128-byte bank of RTC RAM lockdown.

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enable or disable bytes 38h-3Fh in the upper and lower 128-byte

bank of RTC RAM lockdown.

BIOS Security Conguration

RTC RAM Lcok

[Enabled]

Restore AC Power Loss

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Select AC power state when power is re-applied after a power failure.

► USB Conguration ► PCH Azalia Conguration

LAN2 Controller

PCH LAN Controller Wake on LAN

Restore AC Power Loss

[Enabled] [Enabled] [Enabled]

[Power On]

Restore AC Power Loss

Power Off

Restore AC Power Loss

Off When power returns after an AC power failure, the system’s power is off. You must press the Power button to power-on the system. On When power returns after an AC power failure, the system will automatically power-on.

Power On

75

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

System Agent (SA) Configuration

This section is used to configure the System Agent (SA) configuration.

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Check to enable VT-d function on MCH.

VT-d

► Graphics Conguration ► NB PCIe Conguration

[Enabled]

VT-d

Enables or disables VT-d function on MCH.

Graphics Configuration

Configures the graphic chip settings.

NB PCIe Configuration

Configures the NB PCI Express settings.

Graphics Configuration

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Select which of IGFX/PEG/ PCI Graphics device should be Primary Display Or select SG for Switchable Gfx.

Graphics Configuration

Primary Display

Internal Graphics DVMT Total Gfx Mem

► LCD Control

[IGFX]

[Auto] [256M]

76

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Primary Display

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Select which of IGFX/PEG/ PCI Graphics device should be Primary Display Or select SG for Switchable Gfx.

Graphics Configuration

Primary Display

Internal Graphics DVMT Total Gfx Mem

► LCD Control

[IGFX]

[Auto] [256M]

Select which of IGFX/PEG/PCI graphics device should be primary display or select SG for switchable GFx.

Internal Graphics

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Keep IGD enabled based on the setup options.

Graphics Configuration

Primary Display

Internal Graphics

DVMT Total Gfx Mem

► LCD Control

[Enabled]

[Auto]

[256M]

PEG

IGFX

Primary Display

Keep IGD enabled based on the setup options.

Disabled Enabled

Auto

Internal Graphics

77

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Internal Graphics

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Select DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device.

Graphics Configuration

Primary Display Internal Graphics

DVMT Total Gfx Mem

► LCD Control

[Enabled] [Auto]

[256M]

128M

MAX

256M

DVMT Total Gfx Mem

Selects DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device.

78

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

LCD Control

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Select the Video Device which will be activated during POST. This has no effect if external graphics present. Secondary boot display selection will appear based on your selection. VGA modes will be supported only on primary display

LCD Control

Primary IGFX Boot Display

Secondary IGFX Boot Display LCD Panel Type Active LFP Panel Color Depth

[CRT]

[Disabled] [1024x768 LVDS] [No LVDS] [18 Bit]

DP DP Other ports DP DP Other ports

Mode Extended Clone

3-display DP

1920 x 1080DP1920 x 1080

VGA

1920 x 1080DP1920 x 1080DP1920 x 1080

VGA

1920 x 1080

3-display DP

1920 x 1080DP1920 x 1080

DVI

1920 x 1080DP1920 x 1080DP1920 x 1080

DVI

1920 x 1080

3-display DP

1920 x 1080DP1920 x 1080

LVDS

1280 x 1024DP1920 x 1080DP1920 x 1080

LVDS

1280 x 1024

79

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Primary IGFX Boot Display

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Select the Video Device which will be activated during POST. This has no effect if external graphics present. Secondary boot display selection will appear based on your selection. VGA modes will be supported only on primary display

LCD Control

Primary IGFX Boot Display

Secondary IGFX Boot Display LCD Panel Type Active LFP Panel Color Depth

[CRT]

[Disabled] [1024x768 LVDS] [No LVDS] [18 Bit]

Primary IGFX Boot Display

DVI LFP DP2 DP1

Select the video device which will be activated during POST. Has no effect if external graphics is present. Secondary boot display selection will appear based on your selection. VGA modes will be supported only on primary display.

Secondary IGFX Boot Display

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Select Secondary Display Device

LCD Control

Primary IGFX Boot Display

Secondary IGFX Boot Display

LCD Panel Type Active LFP Panel Color Depth

[CRT]

[Disabled]

[1024x768 LVDS] [No LVDS] [18 Bit]

Secondary IGFX Boot Display

LFP

Select the secondary display device.

CRT

Disabled

80

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

LCD Panel Type

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Select LCD panel used by Internal Graphics Device by selecting the appropriate setup item.

LCD Control

Primary IGFX Boot Display Secondary IGFX Boot Display

LCD Panel Type

Active LFP Panel Color Depth

[CRT] [Disabled]

[1024x768 LVDS]

[No LVDS] [18 Bit]

Primary IGFX Boot Display 640x480 LVDS 800x600 LVDS

1280x1024 LVDS 1600x1200 LVDS 1366x768 LVDS 1680x1050 LVDS 1920x1200 LVDS 1600x900 LVDS 1280x800 LVDS 1920x1080 LVDS

Select the LCD panel used by the internal graphics device by selecting the appropriate setup item.

Active LFP

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Select the Active LFP

Conguration.

No LVDS: VBIOS does not enable LVDS. Int-LVDS: VBIOS enables LVDS driver by Integrated encoder. SDVO LVDS: VBIOS enables LVDS driver by SDVO encoder. eDP Port-A: LFP Driven by Int-DisplayPort encoder from Port-A.

LCD Control

Primary IGFX Boot Display Secondary IGFX Boot Display LCD Panel Type

Active LFP

Panel Color Depth

[CRT] [Disabled] [1024x768 LVDS]

[No LVDS]

[18 Bit]

Active LFP

Int-LVDS

Select the Active LFP configuration.

No LVDS VBIOS does not enable LVDS. Int-LVDS VBIOS enables LVDS driver by Integrated encoder.

1024x768 LVDS

No LVDS

81

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Panel Color Depth

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Select the LFP Panel Color Depth

LCD Control

Primary IGFX Boot Display Secondary IGFX Boot Display LCD Panel Type Active LFP

Panel Color Depth

[CRT] [Disabled] [1024x768 LVDS] [No LVDS]

[18 Bit]

Select the LFP Panel Color Depth.

Panel Color Depth

24 Bit

NB PCIe Configuration

This section is used to configure Northbridge PCI Express settings.

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Congure PEG0 B0:D1:F0

Gen1-Gen3. IVB maximum Gen3, SNB maximum Gen2.

NB PCIe Configuration PEG0

PEGO - Gen X

PEG1

PEG1 - Gen X

Enable PEG

Not Present

[Auto]

Not Present

[Auto]

[Enabled]

18 Bit

82

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

PEG0 - Gen X

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Congure PEG0 B0:D1:F0

Gen1-Gen3. IVB maximum Gen3, SNB maximum Gen2.

NB PCIe Configuration PEG0

PEGO - Gen X

PEG1

PEG1 - Gen X

Enable PEG

Not Present

[Auto]

Not Present

[Auto]

[Enabled]

Configure PEG0 B0:D1:F0 Gen1-Gen3, IVB maximum Gen3, SNB maximum Gen2.

PEG0 - Gen X

Gen1 Gen2 Gen3

PEG1 - Gen X

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Congure PEG1 B0:D1:F1

Gen1-Gen3.

NB PCIe Configuration PEG0

PEGO - Gen X

PEG1

PEG1 - Gen X

Enable PEG

Not Present

[Auto]

Not Present

[Auto]

[Enabled]

Configure PEG1 B0:D1:F1 Gen1-Gen3.

PEG1 - Gen X

Gen1 Gen2 Gen3

Auto

83

NISE 3640M Series User Manual

Chapter 4: BIOS Setup

Enable PEG

Chipset

→←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

To enable or disable the PEG.

NB PCIe Configuration PEG0

PEGO - Gen X

PEG1

PEG1 - Gen X

Enable PEG

Not Present

[Auto]

Not Present

[Auto]

[Enabled]

Enables or disables the PEG slot.

Nexcom NISE 3640M2, NISE 3640M, NISE 3640M2E, 10J00364006X0, 10J00364009X0 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
