Netgear GSM7224P-100NES User Manual

Managed Switch

Hardware Installation Guide

Models:
GSM5212P
GSM7212F
GSM7212P
GSM7224P

350 East Plumeria Drive
San Jose, CA 95134
USA

September 2011
202-10889-01
v1.0

NETGEAR Managed Switch

© 2011 NETGEAR, Inc. All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated

into any language in any form or by any means without the written permission of NETGEAR, Inc.

Technical Support

When you register your product at http://www.netgear.com/register, we can provide you with faster expert technical
support and timely notices of product and software upgrades.

NETGEAR, Inc.

350 East Plumeria Drive
San Jose, CA 95134 USA

E-mail: [e-mail]
Website: http://www.netgear.com
Phone: 1-888-NETGEAR, for US & Canada only. For other countries, see your Support information card.

Trademarks

NETGEAR, the NETGEAR logo, ProSafe, Smart Wizard, and Auto Uplink are trademarks or registered
trademarks of NETGEAR, Inc. Microsoft, Windows, Windows NT, and Vista are registered trademarks of Microsoft
Corporation. Other brand and product names are registered trademarks or trademarks of their respective holders.

Statement of Conditions

To improve internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes
to the products described in this document without notice. NETGEAR does not assume any liability that may occur
due to the use or application of the product(s) or circuit layout(s) described herein.

Revision History

Publication Part Number Version Publish Date

202-10889-01 v1.0 September 2011

2

Contents

Chapter 1 Introduction

Chapter 2 Hardware Installation

Front Panels and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Rear Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Protecting Against Electrostatic Discharge. . . . . . . . . . . . . . . . . . . . . . . . .11

Unpacking the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Select a Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Install the Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Check the Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Connect to Power and Check the LEDs. . . . . . . . . . . . . . . . . . . . . . . . .16

SFP Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Connecting Equipment to the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

RJ-45 Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Connecting a Console to the Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Chapter 3 Troubleshooting

Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Additional Troubleshooting Suggestions . . . . . . . . . . . . . . . . . . . . . . . . . .21

Appendix A Technical Specifications

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Appendix B Default Configuration Settings
Appendix C Notification of Compliance

3

1. Introduction

The NETGEAR ProSafe GSM5212P, GSM7212F, GSM7212P, and GSM7224P managed
switches provide state-of-the-art, high-performance, IEEE-compliant network solutions. They
include powerful management features that you can use to eliminate bottlenecks, boost
performance, and increase productivity. This guide describes hardware installation and basic
troubleshooting for these managed switches.

This switches can be free-standing, wall mounted, or rack-mounted in a wiring closet or an
equipment room. For information about features for each product, see the NETGEAR website at

http://www.netgear.com.

Front Panels and LEDs

The following figures show the front panels of the GSM5212P, GSM7212F, GSM7212P, and
GSM7224P switches. The front panel contains LEDs, a Reset button, a USB flash port, RJ45
ports, copper (RJ45)/fiber (SFP) combo ports, and USB console selection slide switch, amd
USB console port.

1

LEDs

USB Port

eset button

Figure 1. GSM5212P Front Panel

Console Port

PoE Ports

4

SFP Ports

Console Selection Switch

USB Port

LEDs

Reset button

Figure 2. GSM7212F Front Panel

NETGEAR Managed Switch

RJ45 and Fiber Ports

Console Port

Console Selection Switch

USB Port

LEDs

Reset button

Figure 3. GSM7212P Front Panel

USB Port

LEDs

Reset button

Figure 4. GSM7224P Front Panel

PoE Ports

SFP Ports

PoE Ports

Console Selection Switch

Console Selection Switch

Console Port

SFP Ports

Console Port

Introduction

5

NETGEAR Managed Switch

Table 1. LED Descriptions

LED Description

Power Solid green: Internal power supply operating normally and supplying power to the

switch

Solid yellow: The system is in boot-up stage
Blinking yellow: Power module is present but has failed
Off: Power is disconnected.

Fan Solid green: The fan is operating normally

Solid yellow: The fan has failed
Off: No fan is detected

RPS Solid Green: RPS connected (Using internal power supply’s power)

Solid Yellow: The internal power supply has failed and the RPS is providing power

to switch.

Blinking Yellow: RPS is present but RPS has failed
Off: RPS Disconnected

Note: only for GSM7212F,GSM7212P,GSM7224P

PD Solid Green: PD port 1 is connected to PSE getting 802.3at specified power

Blinking Green: PD port 1 is connected to PSE getting 802.3af specified power
Off: PD port 1 is not connected to PSE

Note: only for GSM5212P

Max PoE Solid Yellow: Indicates less than 7W of PoE power is available

Blinking Yellow: Indicates the PoE MAX LED was active in the previous two
minutes

Off: There is at least 7W of PoE power available for another device

SPD/Link/ACT
(RJ45 port)

OFF: No link is established on the port
Solid Green: A valid 1000Mbps link is established on the port
Blinking Green: Packets transmission or reception is occurring on the port at

1000Mbps

Solid Yellow: A valid 10/100Mbps link is established on the port
Blinking Yellow: Packets transmission or reception is occurring on the port at

10/100Mbps
Note: If combo port media change to fiber, the Ethernet LED will change to OFF

status

Introduction

6

NETGEAR Managed Switch

Table 1. LED Descriptions (Continued)

LED Description
PoE OFF: No PoE powered device (PD) connected

Solid Green:The PoE powered device (PD) is connected and the port is supplying

power successfully
Solid Yellow: Indicates one of the following failures resulted in stopping power to

that port:

- Short circuit on PoE power circuit

- PoE power demand exceeds power available

- PoE current exceeds PD's classification

- Out of proper voltage (44 ~ 57 VDC for af, 50~57 VDC for at)

Link/ACT
(RJ45 port)

SPD (RJ45 port) OFF: No link is established on the port

PoE-PD OFF: No PSE is connected or connected but has failed

SPD/Link/ACT
(SFP port)

OFF: No link is established on the port
Solid Green: A valid link is established on the port
Blinking Green: Packets transmission or reception is occurring on the port

Note: On the GSM7212F, if a combo port media changes to fiber, the copper port
LED will change to OFF status.

Solid Green: A valid 1000Mbps link is established on the port
Solid Yellow: A valid 10/100Mbps link is established on the por.

Note: On the GSM7212F, if a combo port media changes to fiber, the copper port
LED will change to OFF status

Solid Green: The PSE is connected and get 30W power from PSE successfully
Solid Yellow: The PSE is connected and get 15.4W power from PSE successfully

Note: only for GSM5212P port 1 and 2

Off: No SFP/SFP+ module link is established on the port
Solid green: A valid 1000Mbps SFP+ module link is established on the port
Blinking green: The port is transmitting or receiving packets at 1000Mbps
Solid yellow: A valid 100Mbps SFP module link is established on the port
Blinking yellow: Packet transmission or reception is occurring on the port at

100Mbps
Note:If combo port media change to Copper, the SFP port LED will change to OFF

status.

Rear Panels

The rear panels have a console port, a redundant power supply connector (only for
GSM7212F, GSM7212P, and GSM7224P), and a standard AC power receptacle for the
supplied power cord.

Introduction

7

Lock

Console Port

Figure 5. GSM5212P Rear Panel

NETGEAR Managed Switch

AC Power
Connector

Console

Port

Figure 6. GSM7212F, GSM7212P, and GSM7224P Rear Panels

RPS

Power Supply

Connector

Lock

AC Power

Connector

Safety Instructions

Use the following safety guidelines to ensure your own personal safety and to help protect
your system from potential damage.

To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment,
observe the following precautions.

• Observe and follow service markings.

- Do not service any product except as explained in your system documentation.

- Opening or removing covers that are marked with the triangular symbol with a

lightning bolt may expose you to electrical shock. Only a trained service
technician should service components inside these compartments.

• If any of the following conditions occur, unplug the product from the electrical outlet and

replace the part or contact your trained service provider:

Introduction

8

NETGEAR Managed Switch

- The power cable, extension cable, or plug is damaged.

- An object has fallen into the product.

- The product has been exposed to water.

- The product has been dropped or damaged.

- The product does not operate correctly when you follow the operating instructions.

• Keep your system away from radiators and heat sources. Also, do not block cooling

vents.

• Do not spill food or liquids on your system components, and never operate the product in

a wet environment. If the system gets wet, see the appropriate section in your
troubleshooting guide or contact your trained service provider.

• Do not push any objects into the openings of your system. Doing so can cause fire or

electric shock by shorting out interior components.

• Use the product only with approved equipment.

• Allow the product to cool before removing covers or touching internal components.

• Operate the product only from the type of external power source indicated on the

electrical ratings label. If you are not sure of the type of power source required, consult
your service provider or local power company.

• To help avoid damaging your system, be sure that the voltage selection switch (if

provided) on the power supply is set to match the power available at your location:

- 115 volts (V), 60 hertz (Hz) in most of North and South America and some Far

Eastern countries such as South Korea and Taiwan

- 100 V, 50 Hz in eastern Japan and 100 V, 60 Hz in western Japan

- 230 V, 50 Hz in most of Europe, the Middle East, and the Far East

• Also, be sure that attached devices are electrically rated to operate with the power

available in your location.

• Use only approved power cables. If you have not been provided with a power cable for

your system or for any AC powered option intended for your system, purchase a power
cable that is approved for use in your country. The power cable must be rated for the
product and for the voltage and current marked on the product's electrical ratings label.
The voltage and current rating of the cable should be greater than the ratings marked on
the product.

• To help prevent electric shock, plug the system and peripheral power cables into properly

grounded electrical outlets.

• The peripheral power cables are equipped with three-prong plugs to help ensure proper

grounding. Do not use adapter plugs or remove the grounding prong from a cable. If you
must use an extension cable, use a three-wire cable with properly grounded plugs.

• Observe extension cable and power strip ratings. Make sure that the total ampere rating

of all products plugged into the extension cable or power strip does not exceed 80
percent of the ampere ratings limit for the extension cable or power strip.

• To help protect your system from sudden, transient increases and decreases in electrical

power, use a surge suppressor, line conditioner, or uninterruptible power supply (UPS).

Introduction

9

NETGEAR Managed Switch

• Position system cables and power cables carefully; route cables so that they cannot be

stepped on or tripped over. Be sure that nothing rests on any cables.

• Do not modify power cables or plugs. Consult a licensed electrician or your power

company for site modifications.

• Always follow your local and national wiring rules.

Introduction

10

2. Hardware Installation

This chapter explains how to install the hardware for the managed switches.

Package Contents

Each switch is packed and shipped separately. The package contains the following items:

• Managed Stackable Switch with preinstalled software

• Power cord

• Rubber footpads for tabletop installation

• Rubber caps for the SFP sockets

• Rack-mounting kit

• USB console cable with one Mini B connector and one type A connector

• Resource CD: The CD either includes these documents or links to access them:

- ProSafe Managed Switch CLI Manual, Version 9.0.2

- NETGEAR Managed Switch Administration Guide

- NETGEAR Managed Switch Installation Guide

- This Hardware Installation Guide

• ProSafe NMS200 Network Management System 30-day trial DVD

2

Protecting Against Electrostatic Discharge

WARNING!

Static electricity can harm delicate components inside your
system. To prevent static damage, discharge static electricity
from your body before you touch any of the electronic
components, such as the microprocessor. You can do so by
periodically touching an unpainted metal surface on the switch.

You can also take the following steps to prevent damage from electrostatic discharge (ESD):

11

NETGEAR Managed Switch

1. When unpacking a static-sensitive component from its shipping carton, leave it in the

antistatic package until you are ready to install it. Just before unwrapping the antistatic
package, discharge static electricity from your body.

2. Before moving a sensitive component, place it in an antistatic container or package.

3. Handle all sensitive components in a static-safe area. If possible, use antistatic floor pads,

workbench pads, and an antistatic grounding strap.

Unpacking the Hardware

Check the contents of the boxes to make sure that all items are present before installing the
switch.

1. Place the container on a clean flat surface and cut all straps securing the container.

2. Unpack the hardware from the boxes.

Carefully remove the hardware and place it on a secure and clean surface. See “Select a
Location” on page 2-12.

3. Remove all packing material.

4. Make sure that all items are present. See “Package Contents” on page -11.

Note: If any item is found missing or damaged, contact your local

NETGEAR reseller for replacement.

5. Inspect the products and accessories for damage. Report any damage immediately.

Installation

Install the equipment in the sequence presented in this section:

1. Select a Location. See “Select a Location” on page -12.

2. Install the Switch. See “Install the Switch” on page -13.

3. Check the installation. See “Check the Installation” on page -12.

4. Apply power and check the LEDs. See “Connect to Power and Check the LEDs” on

page -16.

Select a Location

The switch can be mounted in a standard 19-inch (48.26-centimeter) rack, wall-mounted, or
left freestanding (placed on a tabletop).

Hardware Installation

12

NETGEAR Managed Switch

The site where you install the switch may greatly affect its performance. Before installing the
switch or switches, make sure that the chosen installation location meets the following site
requirements.

Table 2. Site Requirements for Switch Location

Requirements

Mounting • Desktop Installations: Provide a flat table or shelf surface.

• Rack-mount Installations: Use a 19-inch (48.3-centimeter) EIA standard
equipment rack that is grounded and physically secure. You need the
rack-mount kit supplied with your switch.

Access Locate the switch in a position that lets you access the front panel RJ-45 ports,

view the front panel LEDs, and access the rear-panel power connector.

Power source Provide a power source within 6 feet (1.8 meters) of the installation location.

Power specifications for the switch are shown in Appendix A. Be sure that the
AC outlet is not controlled by a wall switch, which can accidentally turn off power
to the outlet and the switch.

Environment Install the switch in a site free from strong electromagnetic field generators (such

as motors), vibration, dust, and direct exposure to sunlight.

Temperature The ambient switch operating temperature range is 0º to 50ºC (32º and 122ºF).

Keep the switch away from heat sources such as direct sunlight, warm air
exhausts, hot-air vents, and heaters.

Operating humidity Install the switch in a dry area with a maximum relative humidity of 90%,

noncondensing.

Ventilation Do not restrict airflow by covering or obstructing air inlets on the sides of the

switch. Keep at least 2 inches (5.08 centimeters) free on all sides for cooling. Be
sure that there is adequate airflow in the room or wiring closet where you intend
to install the switch.

Cabling Route the cable to avoid sources of electrical noise such as radio transmitters,

broadcast amplifiers, power lines, and fluorescent lighting fixtures.

Install the Switch

You can install the switch on a flat surface or in a standard 19-inch rack.

Installing the Switch on a Flat Surface

The switch ships with four self-adhesive rubber footpads. Stick one rubber footpad on
each of the four concave spaces on the bottom of the switch. The rubber footpads
cushion the switch against shock and vibrations.

Installing the Switch in a Rack

To install the switch in a rack, you will need the 19-inch rack-mount kit supplied with your
switch.

1. Attach the supplied mounting brackets to the side of the switch.

Hardware Installation

13

NETGEAR Managed Switch

2. Use the provided Phillips head screws to fasten the brackets to the sides of the

switch.

mounting
bracket

Figure 7. Installing the Switch in a Rack

3. Tighten the screws with a No. 1 Phillips screwdriver to secure each bracket.

4. Align the bracket and rack holes. Use two pan-head screws with nylon washers to

fasten each bracket to the rack.

5. Tighten the screws with a No. 2 Phillips screwdriver to secure the switch in the rack.

Installing the Switch on a Wall (GSM5212P Only)

To install the switch in a rack, you will need the wall-mount kit supplied with your switch.

1. Attach the supplied mounting brackets to the side of the switch.

2. Use four Phillips head screws to fasten each bracket to the sides of the switch

3. Tighten the screws with a No. 1 Phillips screwdriver to secure each bracket.

4. Mark the position of bracket holes on the wall.

5. Drill 4.7mm-diameter and 22.2mm-depth wells at each mark.

6. Hammer caps into the wall.

7. Use two Phillips head screws to fasten each bracket to the wall.

Hardware Installation

14

NETGEAR Managed Switch

8. Tighten the screws with a No. 2 Phillips screwdriver to secure the switch in the wall.

Figure 8. Installing the Switch on a Wall

Check the Installation

Before you apply power, perform the following checks:

1. Inspect the equipment thoroughly.

2. Verify that all cables are installed correctly.

3. Check cable routing to ensure that cables are not damaged and will not create a safety

hazard.

4. Be sure that all equipment is mounted properly and securely.

Hardware Installation

15

NETGEAR Managed Switch

Connect to Power and Check the LEDs

The switch does not have an On/Off switch. The only way to apply or remove power is to
connect or disconnect the power cord. Before you connect the power cord, select an AC
outlet that is not controlled by a wall switch (which can turn off power to the switch).

After you select an appropriate outlet, follow these steps to apply AC power.

1. Connect one end of the AC power adapter cable to the rear of the switch, and the other

end to a grounded 3-pronged AC outlet.

Note: The GSM5212P can get power from PSE if AC power is not

available. Just connect port 1 of the switch to a PSE (Power
Sourcing Equipment) switch. The PSE device should support
IEEE802.1at so that it can provide full power to GSM5212P for
system operation. If the PSE device used does not support
IEEE802.1at, the GSM5212P may not operate correctly. GSM7224P
and GSM7212P switches support IEEE 802.1at on all ports.

2. Check the Power LED on the front panel of the switch. The LED should light up in the

following sequence:

• The LED turns yellow as the switch runs a Power-On Self-Test (POST).

• If the switch passes the test, the LED turns green. The switch is working and ready to

pass data.

• If the POST fails, the Power LED blinks yellow.

Note: If the PD LED on the front panel of GSM5212P blinks yellow, port 1

is connected to a IEEE802.1af PoE device. Check the PoE device
specification to make sure it supports IEEE802.1at.

If the Power LED does not light up, check that the power cable is plugged in correctly and
that the power source is good. For help with troubleshooting, see

“Troubleshooting.”

Chapter 3.3,

SFP Modules

SFP modules (sold separately) can be inserted directly into the switch’s ports.

• AGM731F - SFP module with LC connector, compatible with the IEEE 802.3z

1000Base-SX standard.

Hardware Installation

16

NETGEAR Managed Switch

• AGM732F - SFP module with LC connector, compatible with the IEEE 802.3z

1000Base-LX standard.

• AFM735 - SFP module with LC connector, compatible with the IEEE 802.3u 100Base-FX

standard.

1. insert the module into the switch port.

2. Press firmly to ensure that the module seats into the connector.

Figure 9. Insert the SPF Module into the Switch

Connecting Equipment to the Switch

You can connect devices, a Gigabit Ethernet module, and/or a console to the switch.

RJ-45 Ports

The switch uses Auto Uplink technology, which enables you to attach devices using either
straight-through or crossover cables. Use a Category 5 (Cat5) unshielded twisted-pair (UTP)
cable terminated with an RJ-45 connector.

Note: Ethernet specifications limit the cable length between the switch and

the attached device to 328 feet (100 meters).

Hardware Installation

17

NETGEAR Managed Switch

Connecting a Console to the Switch

After you install the switch and apply power, you can connect to it with a terminal or
workstation. You can use the Command Line Interface (CLI) to identify the IP address.

To use a console you need the following items:

• VT100/ANSI terminal, or a Windows PC, Apple Macintosh PC, or UNIX workstation.

• USB console cable (shipped with the product) or a Null-modem cable with 9-pin

connectors on each end.

To connect a console to the switch:

1. Connect the null-modem cable to the console port on the rear of the switch or connect

the USB console cable to the console USB port on the front of the switch.

Rear Panel

Console Port

Front Panel
Console Port

Figure 10. Console Ports

2. Select console port via the console slide switch on the front panel:

a. Select the mini USB (cable included) as console port by pushing the slide switch to

the left. Use the Resource CD to install the USB driver on your PC.

b. Select the DB9 (cable not included) in the back as console port by pushing the slide

switch to the right.

3. Connect the other end of the cable to a workstation or terminal.

4. If you attached a workstation, start a terminal-emulation program.

• Microsoft Windows users can use HyperTerminal if it comes with the Windows

operating systems. If not, you need to install another 3rd party terminal emulator such
as Tera Term.

• Macintosh users can use ZTerm.

• UNIX users can use a terminal emulator such as TIP.

5. Configure the terminal-emulation program to use the following settings:

• Baud rate: 115,200 bps

• Data bits: 8

• Parity: none

• Stop bit: 1

• Flow control: none

Hardware Installation

18

NETGEAR Managed Switch

After you connect a console to the switch, you will need to configure it. The following
documents are provided for this purpose:

• Quick Installation Guide: Explains basic setup and configuration (provided as both a print

document and in PDF format on the Resource CD).

• ProSafe Managed Switch CLI Manual, Version 9.0.2: Gives detailed examples of how to

use the CLI.

• NETGEAR Managed Switch Administration Guide: Describes configuration tasks.

Hardware Installation

19

3. Troubleshooting

Troubleshooting Chart

The following table lists symptoms, causes, and solutions of possible problems.

Table 3. Troubleshooting Chart

Problem Cause Solution

Power LED is off. No power is received Check the power cord connections for the switch

3

at the switch and the connected device.
Make sure that all cables used are correct and

comply with Ethernet specifications.

Link LED is off or intermittent. Port connection is not

working.

Slow file transfer or there is
performance degradation.

A segment or device is not

recognized as part of the
network.

ACT LED flashes

continuously on all connected
ports and the network is
disabled.

Half- or full-duplex setting on
the switch and the connected
device are not the same.

One or more devices are not
properly connected, or cabling
does not meet Ethernet
guidelines.

A network loop (redundant
path) has been created.

• Check the crimp on the connectors. Make sure
the plug is fully inserted and locked into the
port at both the switch and the connecting
device.

• Make sure that all cables used are correct
and comply with Ethernet specifications. See

Appendix A.

• Check for a defective adapter card, cable, or
port by testing it in an alternate environment
where all products are functioning.

• Make sure that the attached device is set to
auto negotiate.

• Check the system message log.

Verify that the cabling is correct. Be sure that all
connectors are securely positioned in the
required ports. Equipment may have been
accidentally disconnected.

Break the loop by ensuring that there is only one
path from any networked device to any other
networked device.

20

NETGEAR Managed Switch

Additional Troubleshooting Suggestions

If the suggestions in See Table 3 on page -20.do not resolve your problem, refer to the
troubleshooting suggestions in this section.

• Network Adapter Cards

Make sure that the network adapter cards installed in the PCs are in working condition
and the software driver has been installed.

• Configuration:

If problems occur after you change the network configuration, restore the original
connections. Then find the problem by making the changes, one step at a time. Make
sure that cable distances, repeater limits, and other physical aspects of the installation do
not exceed the Ethernet limitations.

• Switch Integrity:

You can verify the integrity of the switch by resetting the switch. To reset the switch, use
the Tools> Reset command or remove AC power from the switch and then reapply AC
power. If the problem continues, contact NETGEAR technical support.

Auto-Negotiation:
The copper 10/100/1000 Mbps ports negotiate the correct duplex mode and speed if the device
at the other end of the link supports auto-negotiation. If the device does not support
auto-negotiation, the switch only determines the speed correctly and the duplex mode defaults to
half-duplex. The fiber gigabit ports negotiate speed, duplex mode, and flow control, provided that
the attached device supports auto-negotiation.

Troubleshooting

21

A. Technical Specifications

Specifications

Table 4. Technical Specifications

Feature Description

A

IEEE Network Protocol
and Standards
compatibility

Switch management • Port mirroring support

• 802.3i 10BASE-T

• 802.3u 100BASE-TX

• 802.3z 1000BASE-X

• 802.3ab 1000BASE-T

• 802.3az EEE

• 802.3x flow control

• 802.3af power over Ethernet

• 802.3at power over Ethernet

• SNMP v1, v2c, v3

• RFC1757 RMON 1 groups 1, 2, 3, and 9 , RFC1213 MIB II

• RFC1643 Ethernet Interface MIB

• RFC1493 bridge MIB

• RFC2131 DHCP client (and BootP)

• RFC2138 RADIUS client

• Broadcast storm control

• Telnet sessions for management CPU (5)

• Ping support

• ARP support

• Private enterprise MIB

• Configuration file upload, download

• Runtime image download

• Command Line Interface

• Web-based graphic user interface

• Simple Network Time Protocol (SNTP)

• Syslog

• SSLv3/TLSv1.0 Web security

• Secured Shell (SSHv1, v2)

22

NETGEAR Managed Switch

Table 4. Technical Specifications (Continued)

Feature Description

Layer 2 services • 802.1Q Static VLAN (Up to 1k)

• 802.1p Class of Service (CoS)

• 802.1D Spanning Tree Protocol (STP)

• 802.1w Rapid Spanning Tree Protocol (RSTP)

• 802.1s Multiple Spanning Tree Protocol (MSTP)

• 802.3ad Link Aggregation (LACP)

• IGMP v1, v2 Snooping Support

• MLD Snooping

• DHCP L2 Relay

• UDP relay

• SNTP

• SNMP v1/v2/v3

• LLDP

• ISDP

Layer 3 services

QoS • DiffServ QoS
System Service • DHCP, BOOTP Relay

Security • Radius

Address database size 16K MAC addresses per system
10/100/1000 buffer

memory

• Static routing

• DHCP server

• TACACS+

• 802.1x

• MAC filter

• Port Security

• Protected Port

• Private Group

• Storm Control

• DHCP Snooping

• IP Source Guard

• Dynamic ARP Inspection

• MAC ACL (inbound)

• IP ACL (inbound)

Max support 1.5 MB buffer memory

Performance • Forwarding modes: Store-and-forward

• Network latency:

4.760 us for 64 bytes for 1000 Mbps transmission

9.480 us for 64 bytes fro 100 Mbps transmission

Addressing 48-bit MAC address

Technical Specifications

23

NETGEAR Managed Switch

Table 4. Technical Specifications (Continued)

Feature Description

Environment Operating:

• Temperature: 32° to 122°F (0° to 50°C)

• Humidity: 90% maximum relative humidity, noncondensing

• Altitude: 10,000 ft (3,000 m) maximum

Storage:

• Temperature: – 4° to 158°F (–20° to 70°C)

• Humidity: 95% maximum relative humidity, noncondensing

• Altitude: 10,000 ft (3,000 m) maximum

Electromagnetic
emissions and immunity

Safety CE mark, commercial, CSA certified (CSA 22.2 #950), UL listed (UL 1950)/cUL

CE mark, commercial, FCC Part 15 Class A, VCCI Class A, Class A EN 55022
(CISPR 22) Class A, Class A C-Tick , EN 50082-1, EN 55024

IEC950/EN60950

Table 5. Specifications (by switch)

Feature GSM5212P GSM7212F GSM7212P GSM7224P

Interface
(Auto Uplink on
all RJ-45 ports)

Bandwidth 24 Gbps 24 Gbps 24 Gbps 48 Gbps
Weight (kg) 2.596 3.665 4.021 4.368
Dimensions (W x D x H)13x8.2x1.69in

Heat dissipation
(Btu/hr)

Acoustic noise (dB)
(ANSI-S10.12)

Maximum power
consumption
(100-240V AC,
50-60Hz)

Mean time between
failure (MTBF)

• 12 RJ-45 ports for
10/100/1000 Mbps

• 4 SFP ports for
10/100/1000 Mbps

• 12 PoE ports

• 1 USB Type A
Connector

• RS-232 console
port

• 1 USB mini B
console port

(330x207x43mm)
569 548 1543 1820

35.1 48 50.3 49.9

167W 161W 452W 533W

766618 hrs 670956 hrs 422436 hrs 394619 hrs

• 12 RJ-45 ports for
10/100/1000 Mbps

• 12 SFP ports for
10/100/1000 Mbps

• 4 PoE ports

• 1 USB Type A
Connector

• RS-232 console
port

• 1 USB mini B
console port

17.32x10.13x1.69in

( 440x257x43mm)

• 12 RJ-45 ports for
10/100/1000 Mbps

• 4 SFP ports for
10/100/1000 Mbps

• 12 PoE ports

• 1 USB Type A
Connector

• RS-232 console
port

• 1 USB mini B
console port

17.32x10.13x1.69in

( 440x257x43mm)

• 24 RJ-45 ports for
10/100/1000 Mbps

• 4 SFP ports for
10/100/1000 Mbps

• 24 PoE ports

• 1 USB Type A
Connector

• RS-232 console
port

• 1 USB mini B
console port

17.32x10.13x1.69in

( 440x257x43mm)

Technical Specifications

24

B. Default Configuration Settings

Table 7.

Feature Default Setting

Port speed Auto-negotiation
Port duplex Auto-negotiation
Flow control (half duplex) Enabled
Flow control (full duplex) Disabled
Broadcast storm control Enabled
Gigabit port type Auto detect

B

Management IP
configuration

Password protection Disabled
User name Admin
Password (none)
Web access Enabled
Java mode Enabled
VLAN All ports belong to default VLAN (VLAN 1) as untagged ports
IP multicast filtering Disabled
Spanning Tree Protocol Enabled (IEEE 802.1w)
Admin edge port Enabled
Link aggregation Disabled
Port mirroring Disabled
Traffic prioritization Disabled
ACL Disabled

DHCP

GVRP Disabled

26

NETGEAR Managed Switch

Table 7.

Feature Default Setting

GMRP Disabled
IP routing Disabled
MAC address aging 300 seconds
SNMP community public (read-only access), private (read/write access)
DHCP Server Disabled
VLAN Ingress filtering Enabled
IP multicast filtering Disabled

802.1x Disabled
Port Security Disabled
Auto Install Enabled
LLDP Enabled
LLDP-MED Enabled
ISDP Enabled

Default Configuration Settings

27

C. Notification of Compliance

C

Certificate of the Manufacturer/Importer

It is hereby certified that the NETGEAR ProSafe Gigabit Managed L2+ PoE+ Switches GSM5212P, GSM7212F,
GSM7212P, and GSM7224P have been suppressed in accordance with the conditions set out in the BMPT-AmtsblVfg
243/1991 and Vfg 46/1992.The operation of some equipment (for example, test transmitters) in accordance with the
regulations may, however, be subject to certain restrictions. Please refer to the notes in the operating instructions.

Federal Office for Telecommunications Approvals has been notified of the placing of this equipment on the market and
has been granted the right to test the series for compliance with the regulations.

Voluntary Control Council for Interference (VCCI) Statement

This is Class A product based on the standard of the Voluntary Control Council for Interference by Information
Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio interference may occur, in
which case, the user may be required to take corrective actions.”

Federal Communications Commission (FCC) Compliance Notice: Radio Frequency
Notice

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

• This device may not cause harmful interference.

• This device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications Radio Interference Regulations

This digital apparatus (NETGEAR ProSafe Gigabit Managed L2+ PoE+ Switches GSM5212P, GSM7212F,
GSM7212P, and GSM7224P) does not exceed the Class A limits for radio-noise emissions from digital apparatus as
set out in the Radio Interference Regulations of the Canadian Department of Communications.

28

NETGEAR Managed Switch

Règlement sur le brouillage radioélectrique du ministère des Communications

Cet appareil numérique (NETGEAR ProSafe Gigabit Managed L2+ PoE+ Switches GSM5212P, GSM7212F,
GSM7212P, and GSM7224P) respecte les limites de bruits radioélectriques visant les appareils numériques de classe
A prescrites dans le Règlement sur le brouillage radioélectrique du ministère des Communications du Canada.

EN 55 022 Declaration of Conformance

This is to certify that the NETGEAR ProSafe Gigabit Managed L2+ PoE+ Switches GSM5212P, GSM7212F,
GSM7212P, and GSM7224P are shielded against the generation of radio interference in accordance with the
application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by the application of EN 55024 Class A
(CISPR 22).

EN 55 022 and EN 55 024 Statements

This is to certify that the NETGEAR ProSafe Gigabit Managed L2+ PoE+ Switches GSM5212P, GSM7212F,
GSM7212P, and GSM7224P are shielded against the generation of radio interference in accordance with the
application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by the application of EN 55 022 Class A
(CISPR 22) and EN 55 024.

WARNING!

This is a Class A product. In a domestic environment, this product
may cause radio interference, in which case the user may be
required to take appropriate measures.

Notification of Compliance

29
