Page 1
Managed Switch
Hardware Installation Guide
Models:
M4100 Series
350 East Plumeria Drive
San Jose, CA 95134
USA
January 2013
202-11217-01
v1.0
Page 2
NETGEAR Managed Switch
Support
Thank you for selecting NETGEAR products.
After installing your device, locate the serial number on the label of your product and use it to register your product
at https://my.netgear.com. You must register your product before you can use NETGEAR telephone support.
NETGEAR recommends registering your product through the NETGEAR website. For product updates and web
support, visit http://support.netgear.com.
Phone (US & Canada only): 1-888-NETGEAR.
Phone (Other Countries): Check the list of phone numbers at
http://support.netgear.com/general/contact/default.aspx.
Trademarks
NETGEAR, the NETGEAR logo, ProSafe, Smart Wizard, and Auto Uplink are trademarks or registered
trademarks of NETGEAR, Inc. Microsoft, Windows, Windows NT, and Vista are registered trademarks of Microsoft
Corporation. Other brand and product names are registered trademarks or trademarks of their respective holders.
Revision History
Publication Part Number Version Publish Date
202-11217-01202-11217-01
202-11217-01 v1.0 January 2013
2
Page 3
Contents
Chapter 1 Introduction
Chapter 2 Hardware Installation
Front Panels and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Rear Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Protecting against Electrostatic Discharge. . . . . . . . . . . . . . . . . . . . . . . . .13
Unpack the Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Select a Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Install the Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Install the M4100-D12G or M4100-D10-PoE Using Magnets. . . . . . . . .18
Check the Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Connect to Power and Check the LEDs. . . . . . . . . . . . . . . . . . . . . . . . .19
SFP Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Connect Equipment to the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
RJ-45 Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Connect a Console to the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Chapter 3 Troubleshooting
Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Additional Troubleshooting Suggestions . . . . . . . . . . . . . . . . . . . . . . . . . .24
Appendix A Technical Specifications
Appendix B Default Configuration Settings
Appendix C Notification of Compliance
3
Page 4
1. Introduction
The NETGEAR ProSafe® 4100 series managed switches provide state-of-the-art,
high-performance, IEEE-compliant network solutions. They include powerful management
features that you can use to eliminate bottlenecks, boost performance, and increase productivity .
The M4100 Series switches include the following:
M4100-26G
M4100-50G
M4100-26-POE
M4100-26G-POE
M4100-50G-POE+
M4100-50-POE
M4100-D10-POE
M4100-D12G
M4100-12GF
M4100-D12G-POE+
M4100-24G-POE+
M4100-12G-POE+
1
This guide describes hardware installation and basic troubleshooting for these managed
switches.
These switches can be freestanding, wall mounted, or rack mounted in a wiring closet or an
equipment room. For information about features for each product, visit the NETGEAR website at
http://www.netgear.com.
Front Panels and LEDs
The following figures show the front panels of the ProSafe 4100 series managed switches.
The front panel contains LEDs, a Reset button, a USB flash port, RJ45 ports, copper
(RJ-45)/fiber (SFP) combo ports, and USB console selection slide switch, and USB console
port.
4
Page 5
LEDs
USB port
Reset button
Figure 1. M4100-26G front panel
Power
Fan
RPS
Reset
RJ45 SPD/Link/ACT mode: Green = 1G Yellow = 10/100M Blink = ACT
USB
NETGEAR Managed Switch
RJ-45 ports
SFP ports
SFP SPD/Link/ACT mode: Green = Link at 1G Yellow = Link at 100M Blink = ACT
Combo Ports
LEDs
USB port
Reset button
Figure 2. M4100-50G front panel
LEDs
USB port
Reset button
Figure 3. M4100-26-POE front panel
LEDs
USB port
Reset button
Figure 4. M4100-50-POE front panel
RJ-45 ports
POE ports
POE ports
RJ-45 ports
RJ-45 ports
SFP ports
SFP ports
SFP ports
5
Page 6
NETGEAR Managed Switch
LEDs
USB port
Reset button
Figure 5. M4100-26G-POE front panel
POE ports
RJ-45 ports
SFP ports
LEDs
USB port
Reset button
Figure 6. M4100-50G-POE+ front panel
LEDs
USB port
Reset button
Figure 7. M4100-D10-POE Front Panel
POE ports
POE ports
RJ45 ports
RJ45 ports
SFP ports
SFP ports
USB port
LEDs
Reset button
Figure 8. M4100-D12G front panel
RJ45 ports
6
SFP ports
Page 7
NETGEAR Managed Switch
Power
Fan
PD
MaxPoE
Reset
USB
PoE (Max 30W per port):
Green = PoE Powered
Yellow = PoE Fault
RJ45 SPD/Link/ACT mode:
Yellow = 10/100M
LEDs
USB port
Reset button
Figure 9. M4100-24G-POE+ front panel
Power
Fan
PD
MaxPoE
LEDs
USB
USB port
Reset
Reset button
Figure 10. M4100-D12G-POE+ front panel
Off = No PD
Green = 1G
Blink = ACT
PoE SPD/Link/ACT
PoE (Max 30W per port):
Off = No PD
Green = PoE Powered
Yellow = PoE Fault
PoE-PD (Port 1, 2):
Off = No PSE
Green = PSE 30w
Yellow = PSE 15.4w
RJ45 SPD/Link/ACT mode:
Green = 1G
Yellow = 10/100M
Blink = ACT
POE ports
PoE SPD/Link/ACT
POE ports
SFP ports
SFP ports
SPD/Link/ACT
Mini
USB port
M4100-D12G-POE+
SPD/Link/ACT
Mini
USB prt
M4100-24G-POE+
SFP SPD/Link/ACT mode
Green = Link at 1G
Yellow = Link at 100M
Blink = ACT
USB DB9
Console(USB)
115200,N,8,1
Console
switch
SFP SPD/Link/ACT mode
Green = Link at 1G
Yellow = Link at 100M
Blink = ACT
USB DB9
Console(USB)
115200,N,8,1
Console
switch
Power
Fan
PD
MaxPoE
Reset
LEDs
USB
USB port
Reset button
Figure 11. M4100-12G-POE+ front panel
Power
Fan
PD
MaxPoE
Reset
LEDs
USB
USB Port
Reset button
Figure 12. M4100-12GF front panel
PoE (Max 30W per port):
OFF = No PD
Green = PoE Powered
Yellow = PoE Fault
Link/ACT mode:
Green = Link at 1G
Yellow = Link at 10/100M
Blink = ACT
SPF Link/Act mode:
Green = Link at 1G
Yellow = Link at 100M
Blink = ACT
PoE SPD/Link/ACT
SPD/Link/ACT
POE ports
PoE (Max 30W per port):
Off = No PD
Green = PoE Powered
Yellow = PoE Fault
RJ45 SPD/Link/ACT mode:
Green = 1G
Yellow = 10/100M
Blink = ACT
SPD Link/ACT
PoE SPD/Link/ACT
SFP ports
SPD/Link/ACT
RJ45 ports
POE ports
SFP ports
USB prt
SPD/Link/ACT
Mini
USB prt
Mini
M4100-12G-POE+
SFP SPD/Link/ACT mode
Green = Link at 1G
Yellow = Link at 100M
Blink = ACT
USB DB9
Console(USB)
115200,N,8,1
Console
switch
M4100-12GF
SFP
Green = 1G
Yellow = 10/100M
Link/Act mode
OFF = No Link
Green = Link
Blinking = ACT
USB DB9
Console(USB)
115200,N,8,1
Console
switch
7
Page 8
NETGEAR Managed Switch
Table 1. LED descriptions
LED Description
Power Solid green: Internal power supply operating normally and supplying power to the
switch.
Solid yellow: The system is in boot-up stage.
Blinking yellow: Power module is present but has failed.
Off: Power is disconnected.
Fan Solid green: The fan is operating normally.
Solid yellow: The fan has failed.
Off: No fan is detected.
RPS Solid green: RPS connected (using internal power supply’s power).
Solid yellow: The internal power supply has failed and the RPS is providing power to
the switch.
Blinking yellow: RPS is present but RPS has failed.
Off: RPS disconnected.
Note: Only for M4100-26G, 50G, 26-POE, 26G-POE, 50G-POE+, and 50-POE
PD Solid green: PD port 1 is connected to PSE getting 802.3at specified power.
Blinking green: PD port 1 is connected to PSE getting 802.3af specified power.
Off: PD port 1 is not connected to PSE.
Note: Only for M4100-D12G, -24G-POE, D12G-POE, 12G-POE+, -12GF
Max PoE Solid yellow: Indicates less than 7 watts of PoE power is available.
Blinking yellow: Indicates the PoE MAX LED was active in the previous 2 minutes.
Off: There is at least 7 watts of PoE power available for another device.
SPD/Link/ACT
(RJ-45 port)
PoE Off: No PoE powered device (PD) connected.
Off: No link is established on the port.
Solid green: A valid 1000 Mbps link is established on the port.
Blinking green: Packet transmission or reception is occurring on the port at 1000
Mbps.
Solid yellow: A valid 10/100 Mbps link is established on the port.
Blinking yellow: Packet transmission or reception is occurring on the port at 10/100
Mbps.
Note: If combo port media change to fiber, the Ethernet LED changes to off status.
Solid green: The PoE powered device (PD) is connected and the port is supplying
power successfully.
Solid yellow: Indicates that one of the following failures resulted in stopping power to
that port:
- Short circuit on PoE power circuit
- PoE power demand exceeds power available
- PoE current exceeds PD’s classification
- Out of proper voltage (44 VDC–57 VDC for af, 50 VDC–57 VDC for at)
8
Page 9
NETGEAR Managed Switch
Table 1. LED descriptions (Continued)
LED Description
Link/ACT
(RJ45 port)
SPD (RJ45 port) Off: No link is established on the port.
PoE-PD Off: No PSE is connected or PSE is connected but connection has failed.
SPD/Link/ACT
(SFP port)
Off: No link is established on the port.
Solid green: A valid link is established on the port.
Blinking green: Packets transmission or reception is occurring on the port.
Note: If a combo port media changes to fiber, the copper port LED changes to off
status.
Solid green: A valid 1000 Mbps link is established on the port.
Solid yellow: A valid 10/100 Mbps link is established on the port.
Solid green: The PSE is connected and get 30 W power from PSE successfully.
Solid yellow: The PSE is connected and get 15.4 W power from PSE successfully.
Off: No SFP/SFP+ module link is established on the port.
Solid green: A valid 1000 Mbps SFP+ module link is established on the port.
Blinking green: The port is transmitting or receiving packets at 1000 Mbps.
Solid yellow: A valid 100 Mbps SFP module link is established on the port.
Blinking yellow: Packet transmission or reception is occurring on the port at
100
Mbps.
Note: If combo port media changes to copper, the SFP port LED changes to off
status.
Rear Panels
The rear panels have a DB9 console port, a mini USB port (only for M4100-26G, 50G,
26-POE, 26G-POE, 50G-POE+, 50-POE, D12-PoE, and D12G), a redundant power supply
connector (only for M4100-26G, 50G, 26-POE, 26G-POE, 50G-POE+, 50-POE, 12GF,
24G-POE+, and 12G-POE+), and a standard AC power receptacle for the supplied power
cord.
Mini
USB
port
Console
port
RPS
power supply
connector
Lock
Figure 13. M4100-26G, 50G, 26-POE, 26G-POE, 50G-POE+, and 50-POE rear panels
AC power
connector
9
Page 10
Console
switch
NETGEAR Managed Switch
Console
ports
Lock
Figure 14. M4100-D10-POE and M4100-D12G rear panels
Console
port
RPS
power supply
connector
Lock
Figure 15. M4100-12GF, 24G-POE+, 12G-POE+ rear panel
Power adapter
connector
AC power
connector
Lock
Console
port
AC power
connector
Figure 16. M4100-D12G-POE+ rear panel
Safety Instructions
Use the following safety guidelines to ensure your own personal safety and to help protect
your system from potential damage.
To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment,
observe the following precautions.
• Observe and follow service markings.
- Do not service any product except as explained in your system documentation.
10
Page 11
NETGEAR Managed Switch
- Opening or removing covers that are marked with the triangular symbol with a
lightning bolt might expose you to electrical shock. Only a trained service
technician should service components inside these compartments.
• If any of the following conditions occur, unplug the product from the electrical outlet and
replace the part or contact your trained service provider:
- The power cable, extension cable, or plug is damaged.
- An object has fallen into the product.
- The product has been exposed to water.
- The product has been dropped or damaged.
- The product does not operate correctly when you follow the operating instructions.
• Keep your system away from radiators and heat sources. Also, do not block cooling
vents.
• Do not spill food or liquids on your system components, and never operate the product in
a wet environment. If the system gets wet, see the appropriate section in your
troubleshooting guide or contact your trained service provider.
• Do not push any objects into the openings of your system. Doing so can cause fire or
electric shock by shorting out interior components.
• Use the product only with approved equipment.
• Allow the product to cool before removing covers or touching internal components.
• Operate the product only from the type of external power source indicated on the
electrical ratings label. If you are not sure of the type of power source required, consult
your service provider or local power company.
• To help avoid damaging your system, be sure that the voltage selection switch (if
provided) on the power supply is set to match the power available at your location:
- 115 volts (V), 60 hertz (Hz) in most of North and South America and some far
eastern countries such as South Korea and Taiwan
- 100-V, 50 Hz in eastern Japan and 100-V, 60 Hz in western Japan
- 230-V, 50 Hz in most of Europe, the Middle East, and the Far East
• Be sure that attached devices are electrically rated to operate with the power available in
your location.
• Use only approved power cables. If you have not been provided with a power cable for
your system or for any AC-powered option intended for your system, purchase a power
cable that is approved for use in your country. The power cable must be rated for the
product and for the voltage and current marked on the product’s electrical ratings label.
The voltage and current rating of the cable should be greater than the ratings marked on
the product.
• To help prevent electric shock, plug the system and peripheral power cables into properly
grounded electrical outlets.
• The peripheral power cables are equipped with three-prong plugs to help ensure proper
grounding. Do not use adapter plugs or remove the grounding prong from a cable. If you
must use an extension cable, use a three-wire cable with properly grounded plugs.
11
Page 12
NETGEAR Managed Switch
• Observe extension cable and power strip ratings. Make sure that the total ampere rating
of all products plugged into the extension cable or power strip does not exceed 80
percent of the ampere ratings limit for the extension cable or power strip.
• To help protect your system from sudden, transient increases and decreases in electrical
power, use a surge suppressor, line conditioner, or uninterruptible power supply (UPS).
• Position system cables and power cables carefully; route cables so that they cannot be
stepped on or tripped over. Be sure that nothing rests on any cables.
• Do not modify power cables or plugs. Consult a licensed electrician or your power
company for site modifications.
• Always follow your local and national wiring rules.
12
Page 13
2. Hardware Installation
This chapter explains how to install the hardware for the managed switches.
Package Contents
Each switch is packed and shipped separately. The package contains the following items:
• Managed stackable switch with preinstalled software
• Power cord
• Rubber footpads for tabletop installation
• Rubber caps for the SFP sockets
• Rack-mounting kit
• Wall-mounting kit (M4100-D10-POE, M4100-D12G, and M4100-D12G-POE+ only)
• Magnetic mounting kit (M4100-D10-POE and M4100-D12G only)
• USB console cable with one mini B connector and one type A connector
• Resource CD: The CD includes either these documents or links to access them:
- ProSafe Managed Switch Command-Line Interface (CLI) User Manual
- ProSafe M4100 and M7100 Managed Switches Software Administration Manual
- ProSafe M4100 Managed Switch Installation Guide
- This hardware installation guide
• ProSafe NMS200 Network Management System 30-day trial DVD
2
Protecting against Electrostatic Discharge
WARNING!
Static electricity can harm delicate components inside your
system. To prevent static damage, discharge static electricity
from your body before you touch any of the electronic
components, such as the microprocessor. You can do so by
periodically touching an unpainted metal surface on the switch.
13
Page 14
NETGEAR Managed Switch
You can also take the following steps to prevent damage from electrostatic discharge (ESD):
1. When unpacking a static-sensitive component from its shipping carton, leave it in the
antistatic package until you are ready to install it. Just before unwrapping the antistatic
package, discharge static electricity from your body.
2. Before moving a sensitive component, place it in an antistatic container or package.
3. Handle all sensitive components in a static-safe area. If possible, use antistatic floor pads,
workbench pads, and an antistatic grounding strap.
Unpack the Hardware
Check the contents of the boxes to make sure that all items are present before installing the
switch.
1. Place the container on a clean flat surface and cut all straps securing the container.
2. Unpack the hardware from the boxes.
Carefully remove the hardware and place it on a secure and clean surface. For more
information, see
Select a Location on page 15.
3. Remove all packing material.
4. Make sure that all items are present. For more information, see Package Contents on
page 13.
Note: If any item is missing or damaged, contact your local NETGEAR
reseller for replacement.
5. Inspect the products and accessories for damage.
Report any damage immediately.
Installation
Install the equipment in the sequence presented in this section:
1. Select a location.
For more information, see Select a Location on page 15.
2. Install the switch.
For more information, see Install the Switch on page 16.
3. Check the installation.
For more information, see Check the Installation on page 19.
4. Apply power and check the LEDs.
Hardware Installation
14
Page 15
NETGEAR Managed Switch
For more information, see Connect to Power and Check the LEDs on page 19.
Select a Location
The switch can be mounted in a standard 19-inch (48.26-centimeter) rack, wall mounted, or
left freestanding (placed on a tabletop).
The site where you install the switch might greatly affect its performance. Before installing the
switch or switches, make sure that the chosen installation location meets the following site
requirements.
Table 2. Site requirements for switch location
Requirements
Mounting • Desktop installations: Provide a flat table or shelf surface.
• Rack-mount installations: Use a 19-inch (48.3-centimeter) EIA standard
equipment rack that is grounded and physically secure. You need the
rack-mount kit supplied with your switch.
Access Locate the switch in a position that lets you access the front panel RJ-45 ports,
view the front panel LEDs, and access the rear panel power connector.
Power source Provide a power source within 6 feet (1.8 meters) of the installation location.
Power specifications for the switch are shown in Appendix A. Be sure that the
AC outlet is not controlled by a wall switch, which can accidentally turn off power
to the outlet and the switch.
Environment Install the switch in a site free from strong electromagnetic field generators (such
as motors), vibration, dust, and direct exposure to sunlight.
Temperature The ambient switch operating temperature range is 0º to 50ºC (32º to 122ºF).
Keep the switch away from heat sources such as direct sunlight, warm air
exhausts, hot-air vents, and heaters.
Operating humidity Install the switch in a dry area with a maximum relative humidity of 90%,
noncondensing.
Ventilation Do not restrict airflow by covering or obstructing air inlets on the sides of the
switch. Keep at least 2 inches (5.08 centimeters) free on all sides for cooling. Be
sure that there is adequate airflow in the room or wiring closet where you intend
to install the switch.
Cabling Route the cable to avoid sources of electrical noise such as radio transmitters,
broadcast amplifiers, power lines, and fluorescent lighting fixtures.
Hardware Installation
15
Page 16
NETGEAR Managed Switch
Install the Switch
You can install the switch on a flat surface or in a standard 19-inch rack.
Install the Switch on a Flat Surface
The switch ships with four self-adhesive rubber footpads. Stick one rubber footpad on
each of the four concave spaces on the bottom of the switch. The rubber footpads
cushion the switch against shock and vibrations.
Install the Switch in a Rack.
Note: The M4100-D10-PoE, M4100-D12G, and M4100-D12G-POE+ are
not rack mountable.
To install the switch in a rack, you will need the 19-inch rack-mount kit supplied with your
switch.
1. Attach the supplied mounting brackets to the side of the switch.
2. Use the provided Phillips head screws to fasten the brackets to the sides of the
switch.
Mounting
bracket
M4100-24G-POE+
3. Tighten the screws with a No. 1 Phillips screwdriver to secure each bracket.
4. Align the bracket and rack holes. Use two pan-head screws with nylon washers to
fasten each bracket to the rack.
5. T
ighten the screws with a No. 2 Phillips screwdriver to secure the switch in the rack.
Hardware Installation
16
Page 17
NETGEAR Managed Switch
Install the Switch on a Wall (M4100-D12G, M4100-D10-PoE, and
M4100-D12G-POE+ Only)
If you install the switch on a wall in the vertical position, be sure to orient the switch as
shown in the following figure. The switch should be mounted so that the ports face up or
down. Do not mount the switch with the ports to the side. The exhaust air should come
out the side of the switch case.
Note: The switch should have a minimum of 5 inches (130 millimeters) of
clearance on all sides.
1. Attach the supplied mounting brackets to the sides of the switch.
2. Use four Phillips head screws to fasten each bracket to the sides of the switch.
3. T
ighten the screws with a No. 1 Phillips screwdriver to secure each bracket.
4. Mark the position of bracket holes on the wall.
5. Drill holes 4.7 mm diameter and 22.2 mm depth at each mark.
6. Hammer caps into holes in the wall.
7. Use two Phillips head screws to fasten each bracket to the wall.
8. T
ighten the screws with a No. 2 Phillips screwdriver to secure the switch to the wall.
Hardware Installation
17
Page 18
NETGEAR Managed Switch
Install the M4100-D12G or M4100-D10-PoE Using Magnets
If you use the magnets (included) to install the M4100-D12G or M4100-D10-PoE switch
to a vertical metal surface, the maximum height above the floor is 75 centimeters (29.5
inches). Be sure to orient the switch as shown in the following figure. Exhaust air should
come out the side of the switch case.
1. Attach the magnets to the switch using a No. 1 Phillips screwdriver and 4 screws
(provided).
See the following figure.
2. Press each of the 4 rubber feet firmly into the indentations on the bottom of the switch.
3. Position the switch so that it is no more than 75 centimeters (29.5 inches) above the floor.
Hardware Installation
18
Page 19
NETGEAR Managed Switch
Check the Installation
Before you apply power, perform the following checks:
1. Inspect the equipment thoroughly.
2. Verify that all cables are installed correctly.
3. Check cable routing to ensure that cables are not damaged and will not create a safety
hazard.
4. Be sure that all equipment is mounted properly and securely.
Connect to Power and Check the LEDs
The switch does not have an on/off switch. The only way to apply or remove power is to
connect or disconnect the power cord. Before you connect the power cord, select an AC
outlet that is not controlled by a wall switch (which can turn off power to the switch).
To apply AC power:
1. Select an appropriate outlet.
2. Connect one end of the AC power adapter cable (M4100-DG12 or M4100-D10-PoE) or the
AC power cord to the rear of the switch, and the other end to a grounded three-pronged AC
outlet.
Note: The M4100-26G, 50G, 26-PoE, 26G-PoE, 50-PoE+, 50G-PoE,
12GF, 24G-POE+, 12G-POE+ can also obtain power from an RPS.
Supported RPS models are the RPS5412 and RPS4000.
Note: Normally the M4100-D12G and M4100-D12G-POE+ will get power
using the supplied power adapter. These switches can also get
power from a PSE (power sourcing equipment) switch if AC power is
not available. Connect port 1 of these switches to a PSE switch. The
PSE device should support IEEE802.3at so that it can provide full
power to these switches for system operation. If the PSE device
used does not support IEEE802.3at, theses switches might not
operate correctly.
3. Check the Power LED on the front panel of the switch.
The LED should light in the following sequence:
• The LED turns yellow as the switch runs a power-on self-test (POST).
• If the switch passes the test, the LED turns green. The switch is working and ready to
pass data.
Hardware Installation
19
Page 20
NETGEAR Managed Switch
• If the POST fails, the Power LED blinks yellow.
Note: If the PD LED on the front panel of the M4100-D12G and
M4100-D12G-POE+ blinks green, port 1 is connected to a
IEEE802.3af PoE device. Check the PoE device specification to
make sure that it supports IEEE802.3at.
If the Power LED does not light up, check that the power cable is plugged in correctly and
that the power source is good. For more information, see Troubleshooting on page 23.
SFP Modules
SFP modules (sold separately) can be inserted directly into the switch’s ports.
Note: Use only optical transceiver modules that are UL approved and that
are certified as Laser class 1 products.
• AGM731F: SFP module with LC connector
1000Base-SX standard
• AGM732F: SFP module with LC connector
1000Base-LX standard
• AFM735: SFP module with LC connector
standard
To insert an SFP module into the switch port:
1. Insert the module into the switch port.
2. Press firmly to ensure that the module seats into the connector
, compatible with the IEEE 802.3z
, compatible with the IEEE 802.3z
, compatible with the IEEE 802.3u 100Base-FX
.
Hardware Installation
20
Page 21
NETGEAR Managed Switch
Connect Equipment to the Switch
You can connect devices, a Gigabit Ethernet module, and/or a console to the switch.
RJ-45 Ports
The switch uses Auto Uplink technology, which enables you to attach devices using either
straight-through or crossover cables. Use a Category 5 (Cat 5) unshielded twisted-pair (UTP)
cable terminated with an RJ-45 connector.
Note: Ethernet specifications limit the cable length between the switch and
the attached device to 328 feet (100 meters).
Connect a Console to the Switch
After you install the switch and apply power, you can connect to it with a terminal or
workstation. You can use the command-line interface (CLI) to identify the IP address.
To use a console, you need the following items:
• VT100/ANSI terminal, or a Windows computer
workstation
• USB console cable (shipped with the product) or a null-modem cable (shipped with the
product) with 9-pin connectors on each end
To connect a console to the switch:
1. Connect the null-modem cable to the console port on the rear of the switch, or connect
the USB console cable to the USB console port on the rear of the switch.
2. Select the console port through the console slide switch on the rear panel:
a. Select the mini USB (cable included) as the console port by pushing the slide switch
to the left.
, Apple Macintosh computer, or UNIX
Console ports
Use the Resource CD to install the USB driver on your computer.
b. Select the DB9 (cable included) as the console port by pushing the slide switch to
the right.
Hardware Installation
21
Page 22
NETGEAR Managed Switch
3. Connect the other end of the cable to a workstation or terminal.
4. If you attached a workstation, start a terminal emulation program.
• Microsoft Windows users can use HyperTerminal if it comes with the Windows
operating system. If it does not, you need to install another third-party terminal
emulator such as Tera Term.
• Macintosh users can use ZTerm.
• UNIX users can use a terminal-emulator such as TIP.
5. Configure the terminal emulation program to use the following settings:
• Baud rate: 115,200 bps
• Data bits: 8
• Parity: none
• Stop bit: 1
• Flow control: none
After you connect a console to the switch, you need to configure it. The following documents
are provided for this purpose:
• Quick Installation Guide: Explains basic setup and configuration (provided as both a print
document and in PDF format on the Resource CD).
• ProSafe Managed Switch Command-Line Interface (CLI) User Manual: Gives detailed
examples of how to use the CLI.
• ProSafe M4100 and M7100 Managed Switches Software Administration Manual:
Describes configuration tasks.
Hardware Installation
22
Page 23
3. Troubleshooting
Troubleshooting Chart
The following table lists symptoms, causes, and solutions to possible problems.
Table 3. Troubleshooting chart
Problem Cause Solution
Power LED is off. No power is received. Check the power cord connections for the switch
3
at the switch and the connected device.
Make sure that all cables used are correct and
comply with Ethernet specifications.
Link LED is off or intermittent. Port connection is not
working.
Slow file transfer or there is
performance degradation.
A segment or device is not
recognized as part of the
network.
ACT LED blinks continuously
on all connected ports and the
network is disabled.
Half- or full-duplex setting on
the switch and the connected
device are not the same.
One or more devices are not
properly connected, or cabling
does not meet Ethernet
guidelines.
A network loop (redundant
path) has been created.
• Check the crimp on the connectors. Make sure
that the plug is fully inserted and locked into
the port at both the switch and the connecting
device.
• Make sure that all cables used are correct and
comply with Ethernet specifications. See
Appendix A.
• Check for a defective adapter card, cable, or
port by testing it in an alternate environment
where all products are functioning.
• Make sure that the attached device is set to
autonegotiate.
• Check the system message log.
Verify that the cabling is correct. Be sure that all
connectors are securely positioned in the
required ports. Equipment might have been
accidentally disconnected.
Break the loop by ensuring that there is only one
path from any networked device to any other
networked device.
23
Page 24
NETGEAR Managed Switch
Additional Troubleshooting Suggestions
If the suggestions in Table 3 do not resolve your problem, refer to the troubleshooting
suggestions in this section.
• Network adapter cards:
Make sure that the network adapter cards installed in the computers are in working
condition and the software driver has been installed.
• Configuration:
If problems occur after you change the network configuration, restore the original
connections. Then find the problem by making the changes, one step at a time. Make
sure that cable distances, repeater limits, and other physical aspects of the installation do
not exceed the Ethernet limitations.
• Switch integrity:
You can verify the integrity of the switch by resetting the switch. To reset the switch, use
the Tools > Reset command, or remove AC power from the switch and then reapply AC
power. If the problem continues, contact NETGEAR technical support.
• Autonegotiation:
The copper 10/100/1000 Mbps ports negotiate the correct duplex mode and speed if the
device at the other end of the link supports autonegotiation. If the device does not support
autonegotiation, the switch determines only the speed correctly and the duplex mode
defaults to half-duplex. The fiber gigabit ports negotiate speed, duplex mode, and flow
control if the attached device supports autonegotiation.
Troubleshooting
24
Page 25
A. Technical Specifications
Table 4. M4100-26G, 50G, 26G-POE, 50G-POE+, and D12G Gigabit switch physical
specifications
A
Specification M4100-26G
(GSM7224v2h2)
Interface
(Auto Uplink on all
RJ-45 ports)
Bandwidth 52 Gbps 100 Gbps 52 Gbps 100 Gbps 24 Gbps
Weight (Kg) 3.24 3.63 3.79 4.96 1.33
Dimensions
(W x D x H) (mm)
Mean time between
failure (MTBF)
Heat dissipation
(Btu/hr)
Acoustic noise (dB)
(ANSI-S10.12)
Maximum power
consumption (W)
(100–240V AC,
50–60 Hz)
26 RJ-45 ports for
10/100/1000 Mbps
4 SFP ports for
100/1000 Mbps
1 USB type A
connector
RS-232 console
port
1 USB mini B
console port
440 x 257 x 43.2 440 x 257 x 43.2 440 x 257 x 43.2 440 x 310 x 43.2 328 x 169 x 43.2
702,785.9 hrs 489,311.0 hrs 437,199.85 hrs 239,298.0 hrs 214,142.66 hrs
107.8824 168.99 931.68 1,896.48 64.18
35.6dB @ 25°C 37.2 dB @ 25°C 36.6 dB @ 25°C 47.7 dB @ 25°C0
31.6 49.5 272.90 555.5 18.80
M4100-50G
(GSM7248v2h2)
50 RJ-45 ports,
10/100/1000 Mbps
4 SFP ports for
100/1000 Mbps
1 USB type A
connector
RS-232 console
port
1 USB mini B
console port
M4100-26G-POE
(GSM7226LP)
26 RJ-45 ports for
10/100/1000 Mbps
4 SFP ports for
100/1000 Mbps
24 IEEE802.3at
PoE ports
1 USB type A
connector
RS-232 console
port
1 USB mini B
console port
M4100-50G-POE+
(GSM7248P)
50 RJ-45 ports for
10/100/1000 Mbps
4 SFP ports for
100/1000 Mbps
48 IEEE802.3at
PoE ports
1 USB type A
connector
RS-232 console
port
1 USB mini B
console port
M4100-D12G
(GSM5212)
12 RJ-45 ports for
10/100/1000 Mbps
2 SFP ports for
100/1000 Mbps
1 IEEE802.3at PD
port (port 1)
1 USB type A
connector
RS-232 console
port
1 USB mini B
console port
25
Page 26
NETGEAR Managed Switch
Table 5. M4100-24G-POE+, D12G-POE+, 12G-POE+, 12GF Gigabit switch physical
specification
Specification M4100-24G-POE+
(GSM7224P)
Interface
(Auto Uplink on all
RJ-45 ports)
Bandwidth 48 Gbps 24 Gbps 24 Gbps 24 Gbps
Weight (Kg) 4.368 2.596 4.021 3.665
Dimensions
(W x D x H) (mm)
Mean time between
failure (MTBF)
Heat dissipation
(Btu/hr)
Acoustic noise (dB)
(ANSI-S10.12)
Maximum power
consumption (W)
(100–240V AC,
50–60 Hz)
24 RJ-45 ports for
10/100/1000 Mbps
4 SFP ports for
100/1000 Mbps
24 IEEE802.3at PoE
ports
1 USB Type A
connector
RS-232 console port
1 USB mini B
console port
440 x 257 x 43.2 328 x 169 x 43.2 440 x 257 x 43.2 440 x 257 x 43.2
394,619 hrs 766,618 hrs 422,436 hrs 670,956 hrs
1820.00 569.00 1543.00 548.00
49.9 35.1 dB @ 25dC with
553.00 167.00 452.00 161.00
M4100-D12G-POE+
(GSM5212P)
12 RJ-45 ports for
10/100/1000 Mbps
2 SFP ports for
100/1000 Mbps
10 IEEE802.3at PoE
port (ports 3–12)
2 IEEE802.3at PD port
(ports 1–2)
1 USB type A
connector
RS-232 console port
1 USB mini B console
port
AC mode
0dB with PD mode
M4100-12G-POE+
(GSM7212P)
12 RJ-45 ports for
10/100/1000 Mbps
4 SFP ports for
100/1000 Mbps
12 IEEE802.3at PoE
ports
1 USB type A
connector
RS-232 console port
1 USB mini B console
port
50.3 48
M4100-12GF
(GSM7212F)
12 RJ-45 ports for
10/100/1000 Mbps
12 SFP ports for
100/1000 Mbps
4 IEEE802.3at PoE
ports
1 USB type A
connector
RS-232 console port
1 USB mini B console
port
T echnical Specifications
26
Page 27
NETGEAR Managed Switch
Table 6. Fast Ethernet switches physical specifications
Fast Ethernet Switches M4100-26-POE
(FSM7226P)
Interface
(AutoUplink on all RJ-45
ports)
Bandwidth 6.4 Gbps 9 Gbps 4.8 Gbps
Weight (Kg) 4.13 4.96 1.4
Dimensions
(W x D x H) mm
Mean time between failure
(MTBF)
24 RJ-45 ports for
10/100 Mbps
2 RJ-45 ports for
10/100/1000 Mbps
2 SFP ports for
100/1000 Mbps
24 PoE ports
1 USB type A connector
RS-232 console port
1 USB mini B console
port
440 x 257 x 43.2 440 x 310 x 43.2 328 x 169 x 43.2
242,281.66 hrs 163,019.5 hrs 579,985.8 hrs
M4100-50-POE
(FSM7250P)
48 RJ-45 ports for
10/100 Mbps
2 RJ-45 ports for
10/100/1000 Mbps
2 SFP ports for
100/1000 Mbps
48 IEEE802.3af PoE
ports
1 USB type A connector
RS-232 console port
1 USB mini B console
port
M4100-D10-POE
(FSM5210P)
8 RJ-45 ports for
10/100 Mbps
2 RJ-45 ports for
10/100/1000 Mbps
2 SFP ports for
100/1000 Mbps
8 IEEE802.3af PoE
ports
1 USB type A connector
RS-232 console port
1 USB mini B console
port
Heat dissipation (Btu/hr) 1,557.77 1,661.39 hrs 298.04
Acoustic noise (dB)
(ANSI-S10.12)
Maximum power
consumption (W)
(100–240V AC, 50–60 Hz)
37.3 dB @ 25
456.29 486.64 87.30
°C 38.9 dB @ 25°C 0
T echnical Specifications
27
Page 28
Table 7. Technical specifications
Feature Description
NETGEAR Managed Switch
IEEE Network Protocol
and Standards
compatibility
Switch management • Port mirroring support
• 802.3i 10BASE-T
• 802.3u 100BASE-TX
• 802.3z 1000BASE-X
• 802.3ab 1000BASE-T
• 802.3az EEE
• 802.3x flow control
• 802.3af power over Ethernet
• 802.3at power over Ethernet
• SNMP v1, v2c, v3
• RFC1757 RMON 1 groups 1, 2, 3, and 9, RFC1213 MIB II
• RFC1643 Ethernet Interface MIB
• RFC1493 bridge MIB
• RFC2131 DHCP client (and BootP)
• RFC2138 RADIUS client
• Broadcast storm control
• Telnet sessions for management CPU (5)
• Ping support
• ARP support
• Private enterprise MIB
• Configuration file upload, download
• Runtime image download
• Command-line interface
• Web-based graphic user interface
• Simple Network Time Protocol (SNTP)
• Syslog
• SSLv3/TLSv1.0 web security
• Secured Shell (SSHv1, v2)
Layer 2 services • 802.1Q Static VLAN (Up to 1 K)
• 802.1 p Class of Service (CoS)
• 802.1D Spanning Tree Protocol (STP)
• 802.1w Rapid Spanning Tree Protocol (RSTP)
• 802.1 s Multiple Spanning Tree Protocol (MSTP)
• 802.3ad link aggregation (LACP)
• IGMP v1, v2 snooping support
• MLD snooping
• DHCP L2 relay
• UDP relay
• SNTP
• SNMP v1/v2/v3
• LLDP
• ISDP
Layer 3 services • Static routing
QoS • DiffServ QoS
System Service • DHCP, BOOTP Relay
• DHCP server
T echnical Specifications
28
Page 29
NETGEAR Managed Switch
Table 7. Technical specifications (Continued)
Feature Description
Security • Radius
• TACACS+
• 802.1x
• MAC filter
• Port security
• Protected port
• Private group
• Storm control
• DHCP snooping
• IP source guard
• Dynamic ARP inspection
• MAC ACL (inbound)
• IP ACL (inbound)
Address database size 16 K MAC addresses per system
10/100/1000 buffer
memory
Performance • Forwarding modes: Store-and-forward
Addressing 48-bit MAC address
Environment Operating:
Electromagnetic
emissions and
immunity
Safety CE mark, UL listed (UL 1950)/cUL, CB, CCC
Security • Radius
Max support 1.5 MB buffer memory
• Network latency:
< 3.91 us for 64 bytes for 1000 Mbps transmission
< 10.194 us for 64 bytes for 100 Mbps transmission
• Temperature: 32° to 122°F (0° to 50°C)
• Humidity: 90% maximum relative humidity, noncondensing
• Altitude: 10,000 ft (3,000 m) maximum
Storage:
• Temperature: –4° to 158°F (–20° to 70°C)
• Humidity: 95% maximum relative humidity, noncondensing
• Altitude: 10,000 ft (3,000 m) maximum
CE mark, FCC Part 15 Class A, VCCI Class A, Class A EN 55022 (CISPR 22) Class A, Class A
C-Tick, EN 50082-1, EN 55024
• TACACS+
• 802.1x
• MAC filter
• Port security
• Protected port
• Private group
• Storm control
• DHCP snooping
• IP source guard
• Dynamic ARP inspection
• MAC ACL (inbound)
• IP ACL (inbound)
T echnical Specifications
29
Page 30
B. Default Configuration Settings
Table 8. M4100 Series switch default settings
Feature Default Setting
Port speed Autonegotiation
Port duplex Autonegotiation
Flow control (half duplex) Enabled
Flow control (full duplex) Disabled
Broadcast storm control Enabled
Gigabit port type Auto detect
B
Management IP
configuration
Password protection Disabled
User name Admin
Password (none)
Web access Enabled
Java mode Enabled
VLAN All ports belong to default VLAN (VLAN 1) as untagged ports
IP multicast filtering Disabled
Spanning Tree Protocol Enabled (IEEE 802.1w)
Admin edge port Enabled
Link aggregation Disabled
Port mirroring Disabled
Traffic prioritization Disabled
ACL Disabled
DHCP
GVRP Disabled
30
Page 31
NETGEAR Managed Switch
Table 8. M4100 Series switch default settings (Continued)
Feature Default Setting
GMRP Disabled
IP routing Disabled
MAC address aging 300 seconds
SNMP community public (read-only access), private (read/write access)
DHCP Server Disabled
VLAN Ingress filtering Enabled
IP multicast filtering Disabled
802.1x Disabled
Port Security Disabled
Auto Install Enabled
LLDP Enabled
LLDP-MED Enabled
ISDP Enabled
Default Configuration Settings
31
Page 32
C. Notification of Compliance
C
Certificate of the Manufacturer/Importer
It is hereby certified that the NETGEAR ProSafe® 4100 series managed switches have been suppressed in
accordance with the conditions set out in the BMPT-AmtsblVfg 243/1991 and Vfg 46/1992.The operation of some
equipment (for example, test transmitters) in accordance with the regulations may, however, be subject to certain
restrictions. Please refer to the notes in the operating instructions.
Federal Office for Telecommunications Approvals has been notified of the placing of this equipment on the market and
has been granted the right to test the series for compliance with the regulations.
Federal Communications Commission (FCC) Compliance Notice: Radio Frequency
Notice
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Radio Interference Regulations
This digital apparatus (NETGEAR ProSafe® 4100 series managed switches) does not exceed the Class A limits for
radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian
Department of Communications.
Règlement sur le brouillage radioélectrique du ministère des Communications
Cet appareil numérique (NETGEAR ProSafe® 4100 series managed switches) respecte les limites de bruits
radioélectriques visant les appareils numériques de classe A prescrites dans le Règlement sur le brouillage
radioélectrique du ministère des Communications du Canada.
EN 55 022 Declaration of Conformance
This is to certify that the NETGEAR ProSafe® 4100 series managed switches are shielded against the generation of
radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is
declared by the application of EN 55024 Class A (CISPR 22).
32
Page 33
NETGEAR Managed Switch
EN 55 022 and EN 55 024 Statements
This is to certify that the NETGEAR ProSafe® 4100 series managed switches are shielded against the generation of
radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is
declared by the application of EN 55 022 Class A (CISPR 22) and EN 55 024.
WARNING!
This is a Class A product. In a domestic environment, this product
may cause radio interference, in which case the user may be
required to take appropriate measures.
Notification of Compliance
33
Loading...
