GS716T and GS724T Smart Switches

Software Administration Manual

350 East Plumeria Drive San Jose, CA 95134 USA

February 2012 202-10484-04 v1.0

GS716Tv2 and GS724Tv3 Software Administration Manual

into any language in any form or by any means without the written permission of NETGEAR, Inc.

Technical Support

Thank you for choosing NETGEAR. To register your product, get the latest product updates, or get support online, visit us at http://support.netgear.com.

Phone (US & Canada only): 1-888-NETGEAR Phone (Other Countries): See Support information card.

Trademarks

NETGEAR, the NETGEAR logo, ReadyNAS, ProSafe, Smart Control Center, Auto Uplink, X-RAID2, and NeoTV are trademarks or registered trademarks of NETGEAR, Inc. Microsoft, Windows, Windows NT, and Vista are registered trademarks of Microsoft Corporation. Other brand and product names are registered trademarks or trademarks of their respective holders.

Statement of Conditions

To improve internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use, or application of, the product(s) or circuit layout(s) described herein.

Revision History

Publication Part Number Version Publish Date Comments

202-10484-04 v1.0 February 2012 Changed Appendix A:

Port Trunking specification 2 for GS716T, 4 for GS724T

2 |

Chapter 1 Getting Started

Getting Started with the GS716T and GS724T Gigabit Smart Switches. . 10

Switch Management Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting the Switch to the Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Switch Discovery in a Network with a DHCP Server . . . . . . . . . . . . . . . . . 13

Switch Discovery in a Network without a DHCP Server . . . . . . . . . . . . . . 15

Configuring the Network Settings on the Administrative System . . . . . . . 16

Web Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Smart Control Center Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Network Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Configuration Upload and Download. . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Firmware Upgrade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Viewing and Managing Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Understanding the User Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Using the Web Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Using SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Interface Naming Convention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Chapter 2 Configuring System Information

Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

IP Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Denial of Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

DNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Green Ethernet Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

License Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

SNMPV1/V2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Trap Flags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

SNMP v3 User Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

LLDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

LLDP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

LLDP Port Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

LLDP-MED Network Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

LLDP-MED Port Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Local Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Neighbors Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Table of Contents | 3

GS716Tv2 and GS724Tv3 Software Administration Manual

Services — DHCP Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

DHCP Filtering Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

Interface Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

Chapter 3 Configuring Switching Information

Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70

Port Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70

Flow Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

Link Aggregation Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74

LAG Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

LAG Membership . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

LACP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

LACP Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80

VLAN Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80

VLAN Membership Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

Port VLAN ID Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83

Voice VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86

Voice VLAN Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86

Voice VLAN Port Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87

Voice VLAN OUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88

Auto-VoIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90

Spanning Tree Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93

STP Switch Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93

CST Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95

CST Port Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

CST Port Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

Rapid STP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102

MST Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103

MST Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

STP Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107

Multicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109

Auto-Video Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109

IGMP Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110

IGMP Snooping Querier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

Forwarding Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122

MAC Address Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122

Dynamic Address Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124

Static MAC Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125

Chapter 4 Configuring Quality of Service

Class of Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128

4 | Table of Contents

Basic CoS Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128

CoS Interface Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .129

Interface Queue Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131

802.1p to Queue Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132

GS716Tv2 and GS724Tv3 Software Administration Manual

DSCP to Queue Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Differentiated Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135

Defining DiffServ. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Diffserv Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

Class Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Policy Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Service Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Service Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Chapter 5 Managing Device Security

Management Security Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150

Change Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

RADIUS Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Configuring TACACS+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Authentication List Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . .159

Configuring Management Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .161

HTTP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .161

Secure HTTP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162

Certificate Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163

Access Profile Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .165

Access Rule Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166

Port Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

802.1X Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168

Port Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

Port Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

Traffic Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

MAC Filter Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

MAC Filter Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Storm Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .177

Port Security Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Port Security Interface Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 179

Security MAC Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .181

Protected Ports Membership . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

Configuring Access Control Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .183

ACL Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .183

MAC ACL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

MAC Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .186

MAC Binding Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

MAC Binding Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

IP ACL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190

IP Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

IP Extended Rule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

IP Binding Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .196

IP Binding Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Table of Contents | 5

GS716Tv2 and GS724Tv3 Software Administration Manual

Chapter 6 Monitoring the System

Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200

Switch Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .201

Port Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203

Port Detailed Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205

EAP Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .211

System Logs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .213

Memory Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214

FLASH Log Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .215

Server Log Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .217

Trap Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .219

Event Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .220

Port Mirroring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .222

Multiple Port Mirroring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .222

Chapter 7 Maintenance

Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .226

Device Reboot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .226

Factory Default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .226

Upload File From Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .228

Download File To Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

TFTP File Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .230

HTTP File Download. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .232

File Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .234

Dual Image Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .234

Dual Image Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .235

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .237

Ping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .237

Traceroute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .238

Chapter 8 Help

Online Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .241

Appendix A Hardware Specifications and Default Values

GS716T and GS724T Gigabit Smart Switches Specifications . . . . . . . . .244

GS716T and GS724T Switch Features and Defaults. . . . . . . . . . . . . . . .245

6 | Table of Contents

Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .241

User Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .242

GS716T Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .244

GS724T Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .244

GS716T and GS724T Switch Performance . . . . . . . . . . . . . . . . . . . . .245

Port Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .245

Traffic Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .246

Quality Of Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .246

GS716Tv2 and GS724Tv3 Software Administration Manual

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246

System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

Other Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .248

Appendix B Configuration Examples

Virtual Local Area Networks (VLANs). . . . . . . . . . . . . . . . . . . . . . . . . . . .250

VLAN Example Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .251

Access Control Lists (ACLs). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252

MAC ACL Example Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252

Standard IP ACL Example Configuration . . . . . . . . . . . . . . . . . . . . . . . 253

Differentiated Services (DiffServ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .255

Class. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

DiffServ Traffic Classes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256

Creating Policies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256

DiffServ Example Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .258

802.1X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260

802.1X Example Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .261

MSTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263

MSTP Example Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264

Appendix C Notification of Compliance

Index

Table of Contents | 7

GS716Tv2 and GS724Tv3 Software Administration Manual

8 | Table of Contents

1. Getting Started

The NETGEAR® GS716T and GS724T Smart Switch Software Administration Manual describes how to configure and operate the GS716T and GS724T Gigabit Smart Switches by using the Web-based graphical user interface (GUI). This manual describes the software configuration procedures and explains the options available within those procedures.

Document Organization

The GS716Tv2 and GS724Tv3 Software Administration Manual contains the following chapters:

• Chapter 1, Getting Started, contains information about performing the initial system

configuration and accessing the user interface.

• Chapter 2, Configuring System Information, describes how to configure administrative

features such as SNMP, DHCP, and port information.

• Chapter 3, Configuring Switching Information, describes how to manage and monitor the

layer 2 switching features.

• Chapter 4, Configuring Quality of Service, describes how to manage the Access Control

Lists (ACLs), and how to configure Differentiated Services and Class of Service features.

• Chapter 5, Managing Device Security, contains information about configuring switch

security information such as port access control and RADIUS server settings.

• Chapter 6, Monitoring the System, describes how to view a variety of information about

the switch and its ports, and to configure how the switch monitors events.

• Chapter 7, Maintenance, describes features to help you manage the switch.

• Chapter 8, Help, describes how to access Online Help resources for the switch.

• Appendix A, Hardware Specifications and Default Values, contains hardware

specifications and default values on the GS716T and GS724T Smart Switches.

• Appendix B, Configuration Examples, contains examples of how to configure various

features on the GS716T and GS724T Smart Switches, such as VLANs and ACLs.

Note: Refer to the release notes for the GS716T and GS724T Gigabit

Smart Switches for information about issues and workarounds.

Chapter 1: Getting Started | 9

GS716Tv2 and GS724Tv3 Software Administration Manual

Getting Started with the GS716T and GS724T Gigabit Smart Switches

This chapter provides an overview of starting your NETGEAR GS716T or GS724T Smart Switch and accessing the user interface. It also leads you through the steps to use the Smart Control Center utility. This chapter contains the following sections:

• Switch Management Interface on page 11

• Connecting the Switch to the Network on page 12

• Switch Discovery in a Network with a DHCP Server on page 13

• Switch Discovery in a Network without a DHCP Server on page 15

• Configuring the Network Settings on the Administrative System on page 16

• Web Access on page 18

• Smart Control Center Utilities on page 19

• Understanding the User Interfaces on page 24

• Interface Naming Convention on page 29

10 | Chapter 1: Getting Started

GS716Tv2 and GS724Tv3 Software Administration Manual

Switch Management Interface

The NETGEAR GS716T and GS724T Smart Switches contain embedded Web server and management software for managing and monitoring switch functions. The switches function as a simple switch without the management software. However, you can use the management software to configure more advanced features that can improve switch efficiency and overall network performance.

Web-based management lets you monitor, configure, and control your switch remotely using a standard Web browser instead of using expensive and complicated SNMP software products. From your Web browser, you can monitor the performance of your switch and optimize its configuration for your network. You can configure all switch features, such as VLANs, QoS, and ACLs by using the Web-based management interface.

NETGEAR provides the Smart Control Center utility with this product. This program runs under Microsoft that discovers the switches on your network segment (L2 broadcast domain). When you power up your switch for the first time, use the Smart Control Center to discover the switch and view the network information that has been automatically assigned to the switch by a DHCP server; or, if no DHCP server is present on the network, use the Smart Control Center to discover the switch and assign static network information.

In addition to enabling NETGEAR switch discovery, the Smart Control Center provides several utilities to help you maintain the NETGEAR switches on your network, such as password management, firmware upgrade, and configuration file backup. For more information, see Smart Control Center Utilities on page 19.

Windows® XP, Windows 2000, or Windows Vista® and provides a front end

Chapter 1: Getting Started | 11

GS716Tv2 and GS724Tv3 Software Administration Manual

Connecting the Switch to the Network

To enable remote management of the switch through a Web browser or SNMP, you must connect the switch to the network and configure it with network information (an IP address, subnet mask, and default gateway). The switch has a default IP address of 192.168.0.239 and a default subnet mask of 255.255.255.0.

Use one of the following three methods to change the default network information on the switch:

• Dynamic assignment through DHCP—DHCP is enabled by default on the switch. If you

connect the switch to a network with a DHCP server, the switch obtains its network information automatically. You can use the Smart Control Center to discover the automatically-assigned network information. For more information, see Switch Discovery

in a Network with a DHCP Server on page 13

• Static assignment through the Smart Control Center—If you connect the switch to a

network that does not have a DHCP server, you can use the Smart Control Center to assign a static IP address, subnet mask, and default gateway. For more information, see

Switch Discovery in a Network without a DHCP Server on page 15

• Static assignment by connecting from a local host—If you do not want to use the Smart

Control Center to assign a static address, you can connect to the switch from a host (administrative system) in the 192.168.0.0/24 network and change the settings by using the Web-based management interface on the switch. For information about how to set the IP address on the administrative system so it is in the same subnet as the default IP address of the switch, see Configuring the Network Settings on the Administrative

System on page 16.

12 | Chapter 1: Getting Started

GS716Tv2 and GS724Tv3 Software Administration Manual

Switch Discovery in a Network with a DHCP Server

This section describes how to set up your switch in a network that has a DHCP server. The DHCP client on the switch is enabled by default. When you connect it to your network, the DHCP server will automatically assign an IP address to your switch. Use the Smart Control Center to discover the IP address automatically assigned to the switch.

To install the switch in a network with a DHCP server, use the following steps:

1. Connect the switch to a network with a DHCP server.

2. Power on the switch by connecting its AC-DC power adapter.

3. Install the Smart Control Center on your computer.

4. Start the Smart Control Center.

5. Click Discover for the Smart Control Center to find your switch. You should see a screen

similar to the one shown in the following figure.

6. Make a note of the displayed IP address assigned by the DHCP server. You will need this

value to access the switch directly from a Web browser (without using the Smart Control Center).

7. Select your switch by clicking the line that displays the switch, then click the

Web Browser Access button. The Smart Control Center displays a login window similar to

the following figure.

Chapter 1: Getting Started | 13

GS716Tv2 and GS724Tv3 Software Administration Manual

Use your Web browser to manage your switch. The default password is password. Then use this page to proceed to management of the switch covered in Using the Web

Interface on page 24.

14 | Chapter 1: Getting Started

GS716Tv2 and GS724Tv3 Software Administration Manual

Switch Discovery in a Network without a DHCP Server

This section describes how to use the Smart Control Center to set up your switch in a network without a DHCP server. If your network has no DHCP service, you must assign a static IP address to your switch. If you choose, you can assign it a static IP address, even if your network has DHCP service.

To assign a static IP address:

1. Connect the switch to your existing network.

2. Power on the switch by plugging in the AC-DC power adapter.

3. Install the Smart Control Center on your computer.

4. Start the Smart Control Center.

5. Click Discover for the Smart Control Center to find your GS716T and GS724T switch. The

utility broadcasts Layer 2 discovery packets within the broadcast domain to discover the switch. You should see a screen similar to Figure on page 13.

6. Select the switch, then click Configure Device. The page expands to display additional

fields at the bottom of the page, as the following figure shows.

7. Choose the Disabled radio button to disable DHCP.

8. Enter the static switch IP address, gateway IP address, and subnet mask for the switch, and

then type your password.

Tip: You must enter the current password every time you use the Smart

Control Center to update the switch setting. The default password is password.

Chapter 1: Getting Started | 15

GS716Tv2 and GS724Tv3 Software Administration Manual

9. Click Apply to configure the switch with the network settings.

Please ensure that your PC and the switch are in the same subnet. Make a note of these settings for later use.

Configuring the Network Settings on the Administrative System

If you choose not to use the Smart Control Center to configure the network information on the switch, you can connect directly to the switch from an administrative system, such as a PC or laptop computer. The IP address of the administrative system must be in the same subnet as the default IP address on the switch. For most networks, this means you must change the IP address of the administrative system to be on the same subnet as the default IP address of the switch (192.168.0.239).

To change the IP address on an administrative system running a Microsoft operating system, open the Internet Protocol (TCP/IP) properties screen that you access from the Local Area Connection properties, as shown in the following figure. You need Windows Administrator privileges to change these settings.

Windows®

WARNING!

When you change the IP address of your administrative system, you will loose your connection to the rest of the network. Be sure to write down your current network address settings before you change them.

16 | Chapter 1: Getting Started

GS716Tv2 and GS724Tv3 Software Administration Manual

To modify the network settings on your administrative system:

1. On your PC, access the MS Windows operating system TCP/IP Properties.

2. Set the IP address of the administrative system to an address in the 192.168.0.0 network,

such as 192.168.0.200. The IP address must be different from that of the switch but within the same subnet.

3. Click OK.

To configure a static address on the switch:

1. Use a straight-through cable to connect the Ethernet port on the administrative system

directly to any port on the GS716T and GS724T.

2. Open a Web browser on your PC and connect to the management interface as described in

Web Access on page 18.

3. Change the network settings on the switch to match those of your network (this procedure is

described in IP Configuration on page 33).

After you change the network settings on the switch, return the network configuration on your administrative system to the original settings.

Chapter 1: Getting Started | 17

GS716Tv2 and GS724Tv3 Software Administration Manual

Web Access

To access the GS716T or GS724T management interface, use one of the following methods:

• From the Smart Control Center, select the switch and click Web Browser Access.

• Open a Web browser and enter the IP address of the switch in the address field.

You must be able to ping the IP address of the GS716T or GS724T management interface from your administrative system for Web access to be available. If you used the Smart Control Center to set up the IP address and subnet mask, either with or without a DHCP server, use that IP address in the address field of your Web browser. If you did not change the IP address of the switch from the default value, enter 192.168.0.239 into the address field.

Clicking Web Browser Access on the Smart Control Center or accessing the switch directly from your Web browser displays the login screen shown in the following figure.

18 | Chapter 1: Getting Started

GS716Tv2 and GS724Tv3 Software Administration Manual

Smart Control Center Utilities

In addition to device discovery and network address assignment, the Smart Control Center includes several maintenance features. This section describes the following Smart Control Center utilities:

• Network Utilities on page 19

• Configuration Upload and Download on page 19

• Firmware Upgrade on page 21

Network Utilities

From the Network tab, you can perform the following functions:

• DHCP Refresh—Forces the switch to release the current bindings and request new

address information from the DHCP server.

• Reboot Device—Reboots the selected device.

• Web Browser Access—Launches a Web browser and connects to the management

interface for the selected device.

• Configure Device—Allows you to change network information for the switch such as the

IP address, and DHCP client mode.

• Change Password—Allows you to set a new password for the device. In this process,

you are required to enter the old password and to confirm the new one, which can contain up to 20 ASCII characters.

From the Maintenance tab, you can upload or download a switch configuration file and upgrade the switch firmware.

Configuration Upload and Download

When you make changes to the switch, the configuration information is stored in a file on the switch. You can backup the configuration by uploading the configuration file from the switch to an administrative system. You can download a saved configuration file from the administrative system to the switch. The configuration file you download to the switch overwrites the running configuration on the switch.

Configuration upload and download is useful if you want to save a copy of the current switch configuration (Upload Configuration) before you make changes. If you do not like the changes, you can use the Download Configuration option to restore the switch to the settings in the saved configuration file.

To save a copy of the current switch configuration on your administrative system:

1. Click the Maintenance tab and select the device with the configuration to save.

2. Click Upload Configuration.

3. From the Browse for Folder window that appears, navigate to and select the folder where

you want to store the configuration file.

Chapter 1: Getting Started | 19

GS716Tv2 and GS724Tv3 Software Administration Manual

4. Click OK.

5. Enter the switch password and click Apply.

The file is uploaded to the administrative computer as a *.cfg file. You can open it and view the contents with a text editor.

To restore the configuration to a previously saved version:

1. Click the Maintenance tab and select the device with the configuration to restore.

2. Click Download Configuration.

3. From the Select a Configuration window that appears, navigate to and select the

configuration file to download to the switch.

4. Click Open.

5. Enter the switch password and click Apply to begin the download process.

Note: Click the Tasks tab to view status information about the

configuration download.

20 | Chapter 1: Getting Started

GS716Tv2 and GS724Tv3 Software Administration Manual

Firmware Upgrade

The application software for the GS716T and GS724T Smart Switches is upgradeable, enabling your switch to take advantage of improvements and additional features as they become available. The upgrade procedure and the required equipment are described in this section. This procedure assumes that you have downloaded or otherwise obtained the firmware upgrade and that you have it available as a binary file on your computer. This procedure uses the TFTP protocol to implement the transfer from computer to switch.

Note: You can also upgrade the firmware using the TFTP Download and

HTTP Download features mentioned in this book.

To upgrade your firmware:

1. Click the Maintenance tab, and then click the Firmware link directly below the tabs

(see Figure on page 13).

2. Select the switch to upgrade and click Download Firmware.

By default, the firmware is downloaded to primary storage and will be become the active image after the download completes and the switch reboots. To download firmware to use as a backup image, select the Secondary Storage option. To prevent the switch from using the downloaded firmware as the active image, make sure the Run this FW after

download option is clear.

3. From the Select new firmware window that appears, navigate to and select the firmware

image to download to the switch.

4. Click Open.

You can choose to schedule a later time to complete the download and installation by clearing the Run Now? option and selecting a date and time to perform the firmware download and installation. The scheduled firmware download appears in the Tasks list.

5. Enter the switch password to continue downloading the firmware.

6. Click Apply to download the firmware and upgrade the switch with the new image.

Chapter 1: Getting Started | 21

GS716Tv2 and GS724Tv3 Software Administration Manual

7. When the process is complete, the switch automatically reboots.

Note: Click the Tasks tab to view status information about the firmware

upgrade.

WARNING!

It is important that you do not power-off the administrative system or the switch while the firmware upgrade is in progress.

22 | Chapter 1: Getting Started

GS716Tv2 and GS724Tv3 Software Administration Manual

Viewing and Managing Tasks

From the Tasks tab, you can view information about configuration downloads and firmware upgrades that have already occurred, are in progress, or are scheduled to take place at a later time. You can also delete or reschedule selected tasks. The following figure shows the Tasks page.

The following list describes the command buttons that are specific to the Tasks page:

• Delete Task—Remove a completed or schedule task from the list.

• Reschedule—Change the scheduled date and time for a pending firmware upgrade.

• Select Range—Select all tasks that occurred or are scheduled to occur within a certain

period of time.

Chapter 1: Getting Started | 23

GS716Tv2 and GS724Tv3 Software Administration Manual

Understanding the User Interfaces

The switch software includes a set of comprehensive management functions for configuring and monitoring the system by using one of the following methods:

• Web user interface

• Simple Network Management Protocol (SNMP)

Each of the standards-based management methods allows you to configure and monitor the components of the switch software. The method you use to manage the system depends on your network size and requirements, and on your preference.

This manual describes how to use the Web-based interface to manage and monitor the system.

Using the Web Interface

To access the switch by using a Web browser, the browser must meet the following software requirements:

• HTML version 4.0, or later

• HTTP version 1.1, or later

• Java Runtime Environment 1.6 or later

Use the following procedures to log on to the Web interface:

1. Open a Web browser and enter the IP address of the switch in the Web browser

address field.

2. The factory default password is password. Type the password into the field on the login

screen, and then click Login. Passwords are case sensitive.

3. After the system authenticates you, the System Information page displays.

Figure 1 on page 25 shows the layout of the Smart Switch Web interface.

24 | Chapter 1: Getting Started

GS716Tv2 and GS724Tv3 Software Administration Manual

Figure 1. Administrative Page Layout

Navigation Tabs, Feature Links, and Page Menu

The navigation tabs along the top of the Web interface give you quick access to the various switch functions. The tabs are always available and remain constant, regardless of which feature you configure.

When you select a tab, the features for that tab appear as links directly under the tabs. The feature links in the blue bar change according to the navigation tab that is selected.

The configuration pages for each feature are available as links in the page menu on the left side of the page. Some items in the menu expand to reveal multiple configuration pages, as

Figure 2 on page 25. shows. When you click a menu item that includes multiple configuration

pages, the item becomes preceded by a down arrow symbol and expands to display the additional pages.

Figure 2. Menu Hierarchy

Chapter 1: Getting Started | 25

GS716Tv2 and GS724Tv3 Software Administration Manual

Configuration and Status Options

The area directly under the feature links and to the right of the page menu displays the configuration information or status for the page you select. On pages that contain configuration options, you can input information into fields or select options from drop-down menus.

Each page contains access to the HTML-based help that explains the fields and configuration options for the page. Each page also contains command buttons.

The following table shows the command buttons that are used throughout the pages in the Web interface:

Button Function

Add Clicking Add adds the new item configured in the heading row of a table.

Apply Clicking the Apply button sends the updated configuration to the switch. Configuration

changes take effect immediately.

Cancel Clicking Cancel cancels the configuration on the screen and resets the data on the screen

to the latest value of the switch.

Delete Clicking Delete removes the selected item.

Refresh Clicking the Refresh button refreshes the page with the latest information from the device.

Logout Clicking the Logout button ends the session.

Device View

The Device View is a Java® applet that displays the ports on the switch. This graphic provides an alternate way to navigate to configuration and monitoring options. The graphic also provides information about device ports, current configuration and status, table information, and feature components.

The Device View is available from the System Device View page.

The port coloring indicates whether a port is currently active. Green indicates that the port is enabled, red indicates that an error has occurred on the port, or red indicates that the link is disabled.

The following image shows the Device View of the GS716T and GS724T.

Click the port you want to view or configure to see a menu that displays statistics and configuration options. Click the menu option to access the page that contains the configuration or monitoring options.

26 | Chapter 1: Getting Started

GS716Tv2 and GS724Tv3 Software Administration Manual

If you click the graphic, but do not click a specific port, the main menu appears, as the following figure shows. This menu contains the same option as the navigation tabs at the top of the page.

Chapter 1: Getting Started | 27

GS716Tv2 and GS724Tv3 Software Administration Manual

Help Page Access

Every page contains a link to the online help , which contains information to assist in configuring and managing the switch. The online help pages are context sensitive. For example, if the IP Addressing page is open, the help topic for that page displays if you click Help. Figure 1 shows the location of the Help link on the Web interface.

User-Defined Fields

User-defined fields can contain 1 to 159 characters, unless otherwise noted on the configuration Web page. All characters may be used except for the following (unless specifically noted in for that feature):

/>|

Using SNMP

The switch software supports the configuration of SNMP groups and users that can manage traps that the SNMP agent generates.

switch switches use both standard public MIBs for standard functionality and private MIBs that support additional switch functionality. All private MIBs begin with a “-” prefix. The main object for interface configuration is in -SWITCHING-MIB, which is a private MIB. Some interface configurations also involve objects in the public MIB, IF-MIB.

SNMP is enabled by default. The System  Management  System Information Web page, which is the page that displays after a successful login, displays the information you need to configure an SNMP manager to access the switch.

Any user can connect to the switch using the SNMPv3 protocol, but for authentication and encryption, the switch supports only one user which is admin; therefore there is only one profile that can be created or modified.

To configure authentication and encryption settings for the SNMPv3 admin profile by using the Web interface:

1. Navigate to the System  SNMP  SNMPv3  User Configuration page.

2. To enable authentication, select an Authentication Protocol option, which is either MD5 or

SHA.

3. To enable encryption, select the DES option in the Encryption Protocol field. Then, enter

an encryption code of eight or more alphanumeric characters in the Encryption Key field.

4. Click Apply.

To access configuration information for SNMPv1 or SNMPv2, click System  SNMP  SNMPv1/v2 and click the page that contains the information to configure.

28 | Chapter 1: Getting Started

GS716Tv2 and GS724Tv3 Software Administration Manual

Interface Naming Convention

The switch supports physical and logical interfaces. Interfaces are identified by their type and the interface number. The physical ports are gigabit interfaces and are numbered on the front panel. You configure the logical interfaces by using the software. The following table describes the naming convention for all interfaces available on the switch.

Interface Description Example

Physical The physical ports are gigabit Ethernet interfaces and

are numbered sequentially starting from one.

Link Aggregation Group (LAG) LAG interfaces are logical interfaces that are only

used for bridging functions.

CPU Management Interface This is the internal switch interface responsible for the

switch base MAC address. This interface is not configurable and is always listed in the MAC Address Table.

g1, g2, g3

l1, l2, l3 LAG1, LAG2

Chapter 1: Getting Started | 29

GS716Tv2 and GS724Tv3 Software Administration Manual

30 | Chapter 1: Getting Started

2. Configuring System Information

Use the features in the System tab to define the switch’s relationship to its environment. The

System tab contains links to the following features:

• Management on page 32

• License Key on page 47

• SNMP on page 47

• LLDP on page 52

• Services — DHCP Filtering on page 65

Chapter 2: Configuring System Information | 31

GS716Tv2 and GS724Tv3 Software Administration Manual

Management

This section describes how to display the switch status and specify some basic switch information, such as the management interface IP address, system clock settings, and DNS information. From the Management link, you can access the following pages:

• System Information on page 32

• IP Configuration on page 33

• Time on page 35

• Denial of Service on page 41

• DNS on page 43

• Green Ethernet Configuration on page 46

System Information

After a successful login, the System Information page displays. Use this page to configure and view general device information.

To display the System Information page, click System  Management System Information. A screen similar to the following displays.

32 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

To define system information:

1. Open the System Information page.

2. Define the following fields:

• System Name. Enter the name you want to use to identify this switch. You may use

up to 31 alphanumeric characters. The factory default is blank.

• System Location. Enter the location of this switch. You may use up to 31

alphanumeric characters. The factory default is blank.

• System Contact. Enter the contact person for this switch. You may use up to 31

alphanumeric characters. The factory default is blank.

3. Click Apply.

The system parameters are applied, and the device is updated.

The following table describes the status information the System Page displays.

Field Description

Serial Number The serial number of the switch.

System Object ID The base object ID for the switch's enterprise MIB.

Date & Time The current date and time.

System Up Time Displays the number of days, hours, and minutes since the last system

restart.

Base MAC Address The universally assigned network address.

Model Name The model name of the switch.

Boot Version The boot code version of the switch.

Software Version The software version of the switch.

IP Configuration

Use the IP Configuration page to configure network information for the management interface, which is the logical interface used for in-band connectivity with the switch through any of the switch's front panel ports. The configuration parameters associated with the switch's network interface do not affect the configuration of the front panel ports through which traffic is switched or routed.

To access the page, click System  Management  IP Configuration. A screen similar to the following displays.

Chapter 2: Configuring System Information | 33

GS716Tv2 and GS724Tv3 Software Administration Manual

To configure the network information for the management interface:

1. Select the appropriate radio button to determine how to configure the network

information for the switch management interface:

• Dynamic IP Address (DHCP). Specifies that the switch must obtain the IP address

through a DHCP server.

• Dynamic IP Address (BOOTP). Specifies that the switch must obtain the IP address

through a BootP server.

• Static IP Address. Specifies that the IP address, subnet mask, and default gateway

must be manually configured. Enter this information in the fields below this radio button.

2. If you selected the Static IP Address option, configure the following network information:

• IP Address. The IP address of the network interface. The factory default value is

192.168.0.239. Each part of the IP address must start with a number other than zero. For example, IP addresses 001.100.192.6 and 192.001.10.3 are not valid.

• Subnet Mask. The IP subnet mask for the interface. The factory default value is

255.255.255.0.

• Default Gateway. The default gateway for the IP interface. The factory default value

is 192.168.0.254.

3. Specify the VLAN ID for the management VLAN.

The management VLAN is used to establish an IP connection to the switch from a workstation that is connected to a port in the same VLAN. If not specified, the active management VLAN ID is 1 (default), which allows an IP connection to be established through any port.

When the management VLAN is set to a different value, an IP connection can be made only through a port that is part of the management VLAN. It is also mandatory that the

34 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

port VLAN ID (PVID) of the port to be connected in that management VLAN be the same as the management VLAN ID.

The management VLAN has the following requirements:

• Only one management VLAN can be active at a time.

• When a new management VLAN is configured, connectivity through the existing

management VLAN is lost.

• The management station should be reconnected to the port in the new management

VLAN.

Note: Make sure that the VLAN to be configured as the management

VLAN exists. And make sure that the PVID of at least one port that is a port of the VLAN is the same as the management VLAN ID. For information about creating VLANs and configuring the PVID for a port, see VLANs on page 80.

4. If you change any of the network connection parameters, click Apply to apply the changes

to the system.

5. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

Time

switch software supports the Simple Network Time Protocol (SNTP). You can also set the system time manually

SNTP assures accurate network device clock time synchronization up to the millisecond. Time synchronization is performed by a network SNTP server. switch software operates only as an SNTP client and cannot provide time services to other systems.

Time sources are established by Stratums. Stratums define the accuracy of the reference clock. The higher the stratum (where zero is the highest), the more accurate the clock. The device receives time from stratum 1 and above since it is itself a stratum 2 device.

The following is an example of stratums:

• Stratum 0: A real-time clock is used as the time source, for example, a GPS system.

• Stratum 1: A server that is directly linked to a Stratum 0 time source is used. Stratum 1

time servers provide primary network time standards.

• Stratum 2: The time source is distanced from the Stratum 1 server over a network path.

For example, a Stratum 2 server receives the time over a network link, via NTP, from a Stratum 1 server.

Information received from SNTP servers is evaluated based on the time level and server type.

Chapter 2: Configuring System Information | 35

GS716Tv2 and GS724Tv3 Software Administration Manual

SNTP time definitions are assessed and determined by the following time levels:

• T1: Time at which the original request was sent by the client.

• T2: Time at which the original request was received by the server.

• T3: Time at which the server sent a reply.

• T4: Time at which the client received the server's reply.

The device can poll Unicast server types for the server time.

Polling for Unicast information is used for polling a server for which the IP address is known. SNTP servers that have been configured on the device are the only ones that are polled for synchronization information. T1 through T4 are used to determine server time. This is the preferred method for synchronizing device time because it is the most secure method. If this method is selected, SNTP information is accepted only from SNTP servers defined on the device using the SNTP Server Configuration page.

The device retrieves synchronization information, either by actively requesting information or at every poll interval.

Time Configuration

Use the Time Configuration page to view and adjust date and time settings.

To display the Time Configuration page, click System  Management > Time  SNTP Global

Configuration.

36 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

To configure the time by using the CPU clock cycle as the source:

1. From the Clock Source field, select Local.

2. In the Date field, enter the date in the DD/MM/YYYY format.

3. In the Time field, enter the time in HH:MM:SS format.

Note: If you do not enter a date and time, the switch will calculate the date

and time using the CPU’s clock cycle.

When the Clock Source is set to Local, the Time Zone field is grayed out (disabled):

4. Click Apply to send the updated configuration to the switch. Configuration changes occur

immediately.

To configure the time through SNTP:

1. From the Clock Source field, select SNTP.

When the Clock Source is set to SNTP, the Date and Time fields are grayed out (disabled). The switch gets the date and time from the network.

Chapter 2: Configuring System Information | 37

GS716Tv2 and GS724Tv3 Software Administration Manual

2. Use the menu to select the Coordinated Universal Time (UTC) time zone in which the switch

is located, expressed as the number of hours.

3. Click Apply to send the updated configuration to the switch. Configuration changes take

effect immediately.

4. Use the SNTP Server Configuration page to configure the SNTP server settings, as

described in SNTP Server Configuration on page 39.

5. Click Refresh to refresh the page with the most current data from the switch.

6. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

The SNTP Global Status table on the Time Configuration page displays information about the system’s SNTP client. The following table describes the SNTP Global Status fields.

Field Description

Version Specifies the SNTP Version the client supports.

Supported Mode Specifies the SNTP modes the client supports. Multiple modes may be

supported by a client.

Last Update Time Specifies the local date and time (UTC) the SNTP client last updated the

system clock.

Last Attempt Time Specifies the local date and time (UTC) of the last SNTP request or receipt

of an unsolicited message.

Last Attempt Status Specifies the status of the last SNTP request or unsolicited message for both

unicast mode. If no message has been received from a server, a status of Other is displayed. These values are appropriate for all operational modes:

• Other: None of the following enumeration values.

• Success: The SNTP operation was successful and the system time was

updated.

• Request Timed Out: A directed SNTP request timed out without

receiving a response from the SNTP server.

• Bad Date Encoded: The time provided by the SNTP server is not valid.

• Version Not Supported: The SNTP version supported by the server is

not compatible with the version supported by the client.

• Server Unsynchronized: The SNTP server is not synchronized with its

peers. This is indicated via the 'leap indicator' field on the SNTP message.

• Server Kiss Of Death: The SNTP server indicated that no further

queries were to be sent to this server. This is indicated by a stratum field equal to 0 in a message received from a server.

Server IP Address Specifies the IP address of the server for the last received valid packet. If no

message has been received from any server, an empty string is shown.

Address Type Specifies the address type of the SNTP Server address for the last received

valid packet.

Server Stratum Specifies the claimed stratum of the server for the last received valid packet.

38 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

Field Description

Reference Clock Id Specifies the reference clock identifier of the server for the last received valid

packet.

Server Mode Specifies the mode of the server for the last received valid packet.

Unicast Sever Max Entries Specifies the maximum number of unicast server entries that can be

configured on this client.

Unicast Server Current Entries

Specifies the number of current valid unicast server entries configured for this client.

Click Refresh to refresh the page with the most current data from the switch.

SNTP Server Configuration

Use the SNTP Server Configuration page to view and modify information for adding and modifying Simple Network Time Protocol SNTP servers.

To display the SNTP Server Configuration page, click System  Management  Time  SNTP Server Configuration.

To configure a new SNTP Server:

1. Enter the appropriate SNTP server information in the available fields:

• Server Type. Specifies whether the address for the SNTP server is an IP address

(IPv4) or hostname (DNS).

• Address. Enter the IP address or the hostname of the SNTP server.

• Port. Enter a port number on the SNTP server to which SNTP requests are sent. The

valid range is 1–65535. The default is 123.

Chapter 2: Configuring System Information | 39

GS716Tv2 and GS724Tv3 Software Administration Manual

• Priority . Specifies the priority of this server entry in determining the sequence of

servers to which SNTP requests are sent. Enter a priority from 1–3, with 1 being the default and the highest priority. Servers with lowest numbers have priority.

• Version. Enter the protocol version number. The range is 1–4.

2. Click Add.

3. Repeat the previous steps to add additional SNTP servers. You can configure up to three

SNTP servers.

4. To removing an SNTP server, select the check box next to the configured server to remove,

and then click Delete. The entry is removed, and the device is updated.

5. To change the settings for an existing SNTP server, select the check box next to the

configured server and enter new values in the available fields, and then click Apply. Configuration changes take effect immediately.

6. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

The SNTP Server Status table displays status information about the SNTP servers configured on your switch. The following table describes the SNTP Global Status fields.

Field Description

Address Specifies all the existing Server Addresses. If no Server configuration exists, a

message saying “No SNTP server exists” flashes on the screen.

Last Update Time Specifies the local date and time (UTC) that the response from this server was

used to update the system clock.

Last Attempt Time Specifies the local date and time (UTC) that this SNTP server was last queried.

Last Attempt Status Specifies the status of the last SNTP request to this server. If no packet has been

received from this server, a status of Other is displayed:

• Other: None of the following enumeration values.

• Success: The SNTP operation was successful and the system time was

updated.

• Request Timed Out: A directed SNTP request timed out without receiving a

response from the SNTP server.

• Bad Date Encoded: The time provided by the SNTP server is not valid.

• Version Not Supported: The SNTP version supported by the server is not

compatible with the version supported by the client.

• Server Unsynchronized: The SNTP server is not synchronized with its

peers. This is indicated via the 'leap indicator' field on the SNTP message.

• Server Kiss Of Death: The SNTP server indicated that no further queries

were to be sent to this server. This is indicated by a stratum field equal to 0 in a message received from a server.

Requests Specifies the number of SNTP requests made to this server since last agent

reboot.

Failed Requests Specifies the number of failed SNTP requests made to this server since last

reboot.

40 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

Click Refresh to refresh the page with the most current data from the switch.

Denial of Service

Use the Denial of Service (DoS) page to configure DoS control. The switch software provides support for classifying and blocking specific types of DoS attacks. You can configure your system to monitor and block six types of attacks:

• SIP=DIP: Source IP address = Destination IP address.

• First Fragment: TCP Header size is smaller than the configured value.

• TCP Fragment: IP Fragment Offset = 1.

• TCP Flag: TCP Flag SYN set and Source Port < 1024 or TCP Control Flags = 0 and TCP

Sequence Number = 0 or TCP Flags FIN, URG, and PSH set and TCP Sequence Number = 0 or TCP Flags SYN and FIN set.

• L4 Port: Source TCP/UDP Port = Destination TCP/UDP Port.

• ICMP: Limiting the size of ICMP Ping packets.

Auto-DoS Configuration

The Auto-DoS Configuration page lets you automatically enable all the DoS features available on the switch, except for the L4 Port attack. See the previous section for information about the types of DoS attacks the switch can monitor and block.

Note: When Auto-DoS is enabled, a port that is under attack is

automatically shut down and does not forward traffic

To access the Auto-DoS Configuration page, click System  Management  Denial of

Service > Auto-DoS Configuration.

Chapter 2: Configuring System Information | 41

GS716Tv2 and GS724Tv3 Software Administration Manual

To configure the Auto-DoS feature:

1. Select a radio button to enable or disable Auto-DoS:

• Disable. Auto-DoS is disabled (default).

• Enable. Auto-DoS is enabled.

2. Click Apply to send the updated configuration to the switch. Configuration changes occur

immediately.

3. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

DoS Configuration

The DoS Configuration page lets you to select which types of DoS attacks for the switch to monitor and block.

To access the DoS Configuration page, click System  Management  Denial of Service > DoS Configuration.

To configure individual DoS settings:

1. Select the types of DoS attacks for the switch to monitor and block and configure any

associated values, as the following list describes.

• Denial of Service SIP=DIP. Enable or disable this option by selecting the appropriate

radio button. Enabling SIP=DIP DoS prevention causes the switch to drop packets that have a source IP address equal to the destination IP address. The factory default is Disable.

• Denial of Service First Fragment. Enable or disable this option by selecting the

appropriate radio button. Enabling First Fragment DoS prevention causes the switch

42 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

to drop packets that have a TCP header smaller than the configured Min TCP Hdr Size. The factory default is Disable.

• Denial of Service Min TCP Hdr Size. Specify the Min TCP Hdr Size allowed. If First

Fragment DoS prevention is enabled, the switch will drop packets that have a TCP header smaller than this configured Min TCP Hdr Size. The factory default is 20 bytes.

• Denial of Service TCP Fragment. Enable or disable this option by selecting the

appropriate radio button. Enabling TCP Fragment DoS prevention causes the switch to drop packets that have an IP fragment offset equal to 1. The factory default is Disable.

• Denial of Service TCP Flag. Enable or disable this option by selecting the

appropriate radio button. Enabling TCP Flag DoS prevention causes the switch to drop packets that have TCP flag SYN set and TCP source port less than 1024 or TCP control flags set to 0 and TCP sequence number set to 0 or TCP flags FIN, URG, and PSH set and TCP sequence number set to 0 or both TCP flags SYN and FIN set. The factory default is Disable.

• Denial of Service L4 Port. Enable or disable this option by selecting the appropriate

radio button. Enabling L4 Port DoS prevention causes the switch to drop packets that have TCP/UDP source port equal to TCP/UDP destination port. The factory default is Disable.

• Denial of Service ICMP. Enable or disable this option by selecting the appropriate

radio button. Enabling ICMP DoS prevention causes the switch to drop ICMP packets that have a type set to ECHO_REQ (ping) and a size greater than the configured ICMP packet size. The factory default is Disable.

• Denial of Service Max ICMP Size. Specify the Max ICMP packet size allowed. If

ICMP DoS prevention is enabled, the switch will drop ICMP ping packets that have a size greater then this configured Max ICMP packet size. The factory default is Disable.

2. If you change any of the DoS settings, click Apply to apply the changes to the switch.

3. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

DNS

You can use these pages to configure information about DNS servers the network uses and how the switch operates as a DNS client.

DNS Configuration

Use this page to configure global DNS settings and DNS server information.

To access this page, click System  Management  DNS  DNS Configuration.

Chapter 2: Configuring System Information | 43

GS716Tv2 and GS724Tv3 Software Administration Manual

To configure the global DNS settings:

1. Specify whether to enable or disable the administrative status of the DNS Client.

• Enable. Allow the switch to send DNS queries to a DNS server to resolve a DNS

domain name.

• Disable. Prevent the switch from sending DNS queries.

2. Enter the DNS default domain name to include in DNS queries. When the system is

performing a lookup on an unqualified hostname, this field is provided as the domain name (for example, if default domain name is netgear.com and the user enters test, then test is changed to test.netgear.com to resolve the name).

3. To specify the DNS server to which the switch sends DNS queries, enter an IP address in

standard IPv4 dot notation in the DNS Server Address and click Add. The server appears in the list below. You can specify up to eight DNS servers. The precedence is set in the order created.

4. To remove a DNS server from the list, select the check box next to the server you want to

remove and click Delete. If no DNS server is specified, the check box is global and will delete all the DNS servers listed.

5. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

6. Click Apply to send the updated configuration to the switch. Configuration changes take

effect immediately.

Host Configuration

Use this page to manually map host names to IP addresses or to view dynamic DNS mappings.

To access this page, click System  Management  DNS  Host Configuration.

44 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

To add a static entry to the local DNS table:

1. Specify the static host name to add. Enter up to 158 characters.

2. Specify the IP address in standard IPv4 dot notation to associate with the hostname.

3. Click Add. The entry appears in the list below.

4. To remove an entry from the static DNS table, select the check box next to the entry and

click Delete.

5. To change the hostname or IP address in an entry, select the check box next to the entry

and enter the new information in the appropriate field, and then click Apply.

6. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

The Dynamic Host Configuration table shows host name-to-IP address entries that the switch has learned. The following table describes the dynamic host fields:

Field Description

Host Lists the host name you assign to the specified IP address.

Total Amount of time since the dynamic entry was first added to the table.

Elapsed Amount of time since the dynamic entry was last updated.

Type The type of the dynamic entry.

Addresses Lists the IP address associated with the host name.

Click Refresh to refresh the table with the most current data from the switch.

Click Clear to delete Dynamic Host Entries. The table will be repopulated with entries as they are learned.

Chapter 2: Configuring System Information | 45

GS716Tv2 and GS724Tv3 Software Administration Manual

Green Ethernet Configuration

Use this page to configure Green Ethernet features. Using the Green Ethernet features allows for power consumption savings.

To access this page, click System  Management  Green Ethernet Configuration.

To configure the Green Ethernet feature:

1. Enable or disable the Short Cable Mode.

• Enable. The switch performs a cable test on each cable connect to its ports. If the

cable is less than 10m in length, the port is placed in low power mode (nominal power).

• Disable. Full transmit power is provided to all ports, regardless of cable length.

2. Click Apply to send the updated configuration to the switch. Configuration changes take

effect immediately.

46 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

License Key

This page provides information about available License Keys for various features. By default those License Keys are not available. If License Key for feature is not available, the user will not be allowed to configure this functionality. Available License Key allows the user to configure functionality.

Non Configurable Data

• License date - The date the license is purchased.

• License copy - The information about the number of license.

• License Status - Show whether License is Active/Inactive. "Inactive" means that user

should download a license file and reboot a system

• Description - Show status of License Key.

SNMP

From SNMP link under the System tab, you can configure SNMP settings for SNMP V1/V2 and SNMPv3.

From the SNMP link, you can access the following pages:

• SNMPV1/V2 on page 47

• Trap Flags on page 50

• SNMP v3 User Configuration on page 51

SNMPV1/V2

The pages under the SNMPV1/V2 menu allow you to configure SNMP community information, traps, and trap flags.

Chapter 2: Configuring System Information | 47

GS716Tv2 and GS724Tv3 Software Administration Manual

Community Configuration

To display this page, click System  SNMP  SNMP V1/V2  Community Configuration.

By default, two SNMP Communities exist:

• Private, with Read/Write privileges and status set to Enable.

• Public, with Read Only privileges and status set to Enable.

These are well-known communities. Use this page to change the defaults or to add other communities. Only the communities that you define using this page will have access to the switch using the SNMPv1 and SNMPv2c protocols. Only those communities with read/write level access can be used to change the configuration using SNMP.

Use this page when you are using the SNMPv1 and SNMPv2c protocol.

To configure SNMP communities:

1. To add a new SNMP community, enter community information in the available fields

described below, and then click Add.

• Management Station IP. Specify the IP address of the management station.Together,

the Management Station IP and the Management Station IP Mask denote a range of IP addresses from which SNMP clients may use that community to access this device. If either (Management Station IP or Management Station IP Mask) value is

0.0.0.0, access is allowed from any IP address. Otherwise, every client’s address is ANDed with the mask, as is the Management Station IP Address; and, if the values are equal, access is allowed. For example, if the Management Station IP and Management Station IP Mask parameters are 192.168.1.0/255.255.255.0, then any client whose address is 192.168.1.0 through 192.168.1.255 (inclusive) will be allowed access. To allow access from only one station, use a Management Station IP Mask value of 255.255.255.255, and use that machine’s IP address for Client Address.

• Management Station IP Mask. Specify the subnet mask to associate with the

management station IP address.

48 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

• Community String. Specify a community name. A valid entry is a case-sensitive

string of up to 16 characters.

• Access Mode. Specify the access level for this community by selecting Read/Write or

Read Only from the menu.

• Status. Specify the status of this community by selecting Enable or Disable from the

pull down menu. If you select Enable, the Community Name must be unique among all valid Community Names or the set request will be rejected. If you select Disable, the Community Name will become invalid.

2. To modify an existing community, select the check box next to the community, change the

desired fields, and then click Apply. Configuration changes take effect immediately.

3. To delete a community, select the check box next to the community and click Delete.

4. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

Trap Configuration

This page displays an entry for every active Trap Receiver. To access this page, click System  SNMP  SNMP V1/V2  Trap Configuration.

To configure SNMP trap settings:

1. To add a host that will receive SNMP traps, enter trap configuration information in the

available fields described below, and then click Add.

• Recipients IP. The address in x.x.x.x format to receive SNMP traps from this device.

• Version. The trap version to be used by the receiver from the menu.

• SNMP v1: Uses SNMP v1 to send traps to the receiver.

• SNMP v2: Uses SNMP v2 to send traps to the receiver.

• Community String. The community string for the SNMP trap packet to be sent to the

trap manager. This may be up to 16 characters and is case sensitive.

• Status. Select the receiver’s status from the menu:

• Enable: Send traps to the receiver.

• Disable: Do not send traps to the receiver.

Chapter 2: Configuring System Information | 49

GS716Tv2 and GS724Tv3 Software Administration Manual

2. To modify information about an existing SNMP recipient, select the check box next to the

recipient, change the desired fields, and then click Apply. Configuration changes take effect immediately.

3. To delete a recipient, select the check box next to the recipient and click Delete.

4. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

Trap Flags

The pages in the Trap Manager folder allow you to view and configure information about SNMP traps the system generates.

Use the Trap Flags page to enable or disable traps the switch can send to an SNMP manager. When the condition identified by an active trap is encountered by the switch, a trap message is sent to any enabled SNMP Trap Receivers, and a message is written to the trap log.

To access the Trap Flags page, click System  SNMP  SNMP V1/V2  Trap Flags.

To configure the trap flags:

1. From the Authentication field, enable or disable activation of authentication failure

traps by selecting the corresponding button. The factory default is Enable.

2. From the Link Up/Down field, enable or disable activation of link status traps by selecting

the corresponding button. The factory default is Enable.

3. From the Spanning Tree field, enable or disable activation of spanning tree traps by

selecting the corresponding button. The factory default is Enable.

4. If you make any changes to this page, click Apply to send the updated configuration to the

switch. Configuration changes take effect immediately.

5. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

50 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

SNMP v3 User Configuration

This is the configuration for SNMP v3.

To access this page, click System  SNMP  SNMP V3  User Configuration.

The SNMPv3 Access Mode is a read-only field that shows the access privileges for the user account. The admin account always has Read/Write access, and all other accounts have Read Only access.

To configure SNMPv3 settings for the user account:

1. In the Authentication Protocol field, specify the SNMPv3 Authentication Protocol setting

for the selected user account. The valid Authentication Protocols are None, MD5, or SHA. If you select:

• None: The user will be unable to access the SNMP data from an SNMP browser.

• MD5 or SHA: The user login password will be used as SNMPv3 authentication

password, and you must therefore specify a password. The password must be eight characters in length.

2. In the Encryption Protocol field, choose whether to encrypt SNMPv3 packets transmitted by

the switch.

• None. Do not encrypt the contents of SNMPv3 packets transmitted from the switch.

• DES. Encrypt SNMPv3 packets using the DES encryption protocol.

3. If you selected DES in the Encryption Protocol field, enter the SNMPv3 Encryption Key here.

Otherwise, this field is ignored. Valid keys are 0 to 15 characters long.

4. Click Apply to send the updated configuration to the switch. Configuration changes take

effect immediately.

5. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

Chapter 2: Configuring System Information | 51

GS716Tv2 and GS724Tv3 Software Administration Manual

LLDP

The IEEE 802.1AB-defined standard, Link Layer Discovery Protocol (LLDP), allows stations on an 802 LAN to advertise major capabilities and physical descriptions. This information is viewed by a network manager to identify system topology and detect bad configurations on the LAN.

From the LLDP link, you can access the following pages:

• LLDP Configuration on page 52

• LLDP Port Settings on page 53

• LLDP-MED Network Policy on page 55

• LLDP-MED Port Settings on page 56

• Local Information on page 57

• Neighbors Information on page 60

LLDP is a one-way protocol; there are no request/response sequences. Information is advertised by stations implementing the transmit function, and is received and processed by stations implementing the receive function. The transmit and receive functions can be enabled/disabled separately per port. By default, both transmit and receive are disabled on all ports. The application is responsible for starting each transmit and receive state machine appropriately, based on the configured status and operational state of the port.

The Link Layer Discovery Protocol-Media Endpoint Discovery (LLDP-MED) is an enhancement to LLDP with the following features:

• Auto-discovery of LAN policies (such as VLAN, Layer 2 Priority, and DiffServ settings),

enabling plug and play networking.

• Device location discovery for creation of location databases.

• Extended and automated power management of Power over Ethernet endpoints.

• Inventory management, enabling network administrators to track their network devices

and determine their characteristics (manufacturer, software and hardware versions, serial/asset number).

LLDP Configuration

Use the LLDP Configuration page to specify LLDP and LLDP-MED parameters that are applied to the switch.

To display the LLDP Configuration page, click System > LLDP > Basic > LLDP

Configuration.

Note: You can also access the LLDP Configuration page by clicking

System > LLDP > Advanced > LLDP Configuration.

52 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

To configure global LLDP settings:

1. Configure the following LLDP properties.

• TLV Advertised Interval. Specify the interval at which frames are transmitted. The

default is 30 seconds, and the valid range is 1–32768 seconds.

• Hold Multiplier. Specify multiplier on the transmit interval to assign to Time-to-Live

(TTL). The default is 4 seconds, and the range is 2–10.

• Reinitializing Delay. Specify the delay before a reinitialization. The default is 2

seconds, and the range is 1–10 seconds.

• Transmit Delay. Specify the interval for the transmission of notifications. The default

is 5 seconds, and the range is 5–3600 seconds.

2. To change the LLDP-MED properties in the Fast Start Duration field, specify the number of

LLDP packets sent when the LLDP-MED Fast Start mechanism is initialized, which occurs when a new endpoint device links with the LLDP-MED network connectivity device. The default value is 3 times, and the range is from 1–10.

3. Click Apply to apply the new settings to the system.

4. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

5. Click Refresh to update the screen with the current information.

LLDP Port Settings

Use the LLDP Port Settings page to specify LLDP parameters that are applied to a specific interface.

To display the LLDP Port Settings page, click System > LLDP > Advanced > LLDP Port

Settings.

Chapter 2: Configuring System Information | 53

GS716Tv2 and GS724Tv3 Software Administration Manual

To configure LLDP port settings:

1. Change the LLDP port settings described below:

• Interface. Specifies the port to be affected by these parameters.

• Admin Status. Select the status for transmitting and receiving LLDP packets:

• Tx Only: Enable only transmitting LLDP PDUs on the selected ports.

• Rx Only: Enable only receiving LLDP PDUs on the selected ports.

54 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

• Tx and Rx: Enable both transmitting and receiving LLDP PDUs on the selected

ports.

• Disabled: Do not transmit or receive LLDP PDUs on the selected ports.

• Management IP Address. Choose whether to advertise the management IP address

from the interface. The possible field values are:

• Stop Advertise: Do not advertise the management IP address from the interface.

• Auto Advertise: Advertise the current IP address of the device as the

management IP address.

• Notification. When notifications are enabled, LLDP interacts with the Trap Manager to

notify subscribers of remote data change statistics. The default is Disabled.

• Optional TLV(s). Enable or disable the transmission of optional type-length value

(TLV) information from the interface. The TLV information includes the system name, system description, system capabilities, and port description. To configure the System Name, see Management on page 32. To configure the Port Description, see Ports on page 70.

2. If you make any changes to the page, click Apply to apply the new settings to the system.

3. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

LLDP-MED Network Policy

This page displays information about the LLPD-MED network policy TLV transmitted in the LLDP frames on the selected local interface.

To display this page, click System  LLDP  Advanced  LLDP-MED Network Policy.

From the Interface menu, select the interface with the information to view. The following table describes the LLDP-MED network policy information that displays on the screen.

Chapter 2: Configuring System Information | 55

GS716Tv2 and GS724Tv3 Software Administration Manual

Field Description

Network Policy Number Specifies the policy number.

Application Specifies the media application type associated with the policy. Only the

Voice application type is supported. The application type that is received on the interface has the VLAN ID, priority, DSCP, tagged bit status and unknown bit status. This information is displayed only if a network policy TLV has been transmitted.

VLAN ID Specifies the VLAN ID associated with the policy.

VLAN Type Specifies whether the VLAN associated with the policy is tagged or

untagged.

User Priority Specifies the priority associated with the policy.

DSCP Specifies the DSCP associated with a particular policy type.

Click Refresh to refresh the page with the most current data from the switch.

LLDP-MED Port Settings

Use this page to enable LLDP-MED mode on an interface and configure its properties.

To display this page, click System  LLDP  Advanced  LLDP-MED Port Settings.

To configure LLDP-MED settings for a port:

1. From the Port field, select the port to configure.

2. From the LLDP-MED Status field, enable or disable the LLDP-MED mode for the selected

interface.

56 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

3. From the Notification field, specify whether the port should send a topology change

notification if a device is connected or removed.

4. From the Transmit Optional TLVs field, specify whether the port should transmit optional

type length values (TLVs) in the LLDP PDU frames. If enabled, the following LLDP-MED TLVs are transmitted:

• MED Capabilities

• Network Policy

• Location Identification

• Extended Power via MDI: PSE

• Extended Power via MDI: PD

• Inventory

5. Click Apply to send the updated configuration to the switch. These changes occur

immediately and the configuration will be saved.

6. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

Local Information

Use the LLDP Local Information page to view the data that each port advertises through LLDP.

To display the LLDP Local Device Information page, click System > Advanced > LLDP >

Local Information.

Chapter 2: Configuring System Information | 57

GS716Tv2 and GS724Tv3 Software Administration Manual

The following table describes the LLDP local information that displays for each port.

Field Description

Interface Select the interface with the information to display.

Port ID Subtype Identifies the type of data displayed in the Port ID field.

Port ID Identifies the physical address of the port.

Port Description Identifies the user-defined description of the port. To configure the Port

Description, see

Advertisement Displays the advertisement status of the port.

58 | Chapter 2: Configuring System Information

Ports on page 70.

GS716Tv2 and GS724Tv3 Software Administration Manual

Click Refresh to refresh the page with the most current data from the switch.

To view additional details about a port, click the name of the port in the Interface column of the Port Information table.

A popup window displays information for the selected port.

The following table describes the detailed local information that displays for the selected port.

Field Description

Managed Address

Address SubType Displays the type of address the management interface uses, such as an IPv4

address.

Address Displays the address used to manage the device.

Interface SubType Displays the port subtype.

Interface Number Displays the number that identifies the port.

MAC/PHY Details

Auto-Negotiation Supported Specifies whether the interface supports port-speed auto-negotiation. The

possible values are True or False.

Chapter 2: Configuring System Information | 59

GS716Tv2 and GS724Tv3 Software Administration Manual

Field Description

Auto-Negotiation Enabled Displays the port speed auto-negotiation support status. The possible values

are True (enabled) or False (disabled).

Auto Negotiation Advertised Capabilities

Operational MAU Type Displays the Medium Attachment Unit (MAU) type. The MAU performs

MED Details

Capabilities Supported Displays the MED capabilities enabled on the port.

Current Capabilities Displays the TLVs advertised by the port.

Device Class Network Connectivity indicates the device is a network connectivity device.

Network Policies

Application Type Specifies the media application type associated with the policy.

VLAN ID Specifies the VLAN ID associated with the policy.

VLAN Type Specifies whether the VLAN associated with the policy is tagged or untagged.

User Priority Specifies the priority associated with the policy.

DSCP Specifies the DSCP associated with a particular policy type.

Displays the port speed auto-negotiation capabilities such as 1000BASE-T half-duplex mode or 100BASE-TX full-duplex mode.

physical layer functions, including digital data conversion from the Ethernet interface collision detection and bit injection into the network.

Neighbors Information

Use the LLDP Neighbors Information page to view the data that a specified interface has received from other LLDP-enabled systems.

To display the LLDP Neighbors Information page, click System > LLDP > Advanced >

Neighbors Information.

60 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

The following table describes the information that displays for all LLDP neighbors that have been discovered.

Field Description

MSAP Entry Displays the Media Service Access Point (MSAP) entry number for the

remote device.

Local Port Displays the interface on the local system that received LLDP information

from a remote system.

Chassis ID Subtype Identifies the type of data displayed in the Chassis ID field on the remote

system.

Chassis ID Identifies the remote 802 LAN device's chassis.

Port ID Subtype Identifies the type of data displayed in the remote system’s Port ID field.

Port ID Identifies the physical address of the port on the remote system from which

the data was sent.

System Name Identifies the system name associated with the remote device. If the field is

blank, the name might not be configured on the remote system.

Click Refresh to update the information on the screen with the most current data.

To view additional information about the remote device, click the link in the MSAP Entry field.

A popup window displays information for the selected port.

Chapter 2: Configuring System Information | 61

GS716Tv2 and GS724Tv3 Software Administration Manual

Field Description

Port Details

Local Port Displays the interface on the local system that received LLDP information

from a remote system.

MSAP Entry Displays the Media Service Access Point (MSAP) entry number for the

remote device.

Basic Details

Chassis ID Subtype Identifies the type of data displayed in the

system.

Chassis ID Identifies the remote 802 LAN device's chassis.

Port ID Subtype Identifies the type of data displayed in the remote system’s

Port ID Identifies the physical address of the port on the remote system from which

the data was sent.

Port Description Identifies the user-defined description of the port.

System Name Identifies the system name associated with the remote device.

System Description Specifies the description of the selected port associated with the remote

system.

Chassis ID field on the remote

Port ID field.

System Capabilities Specifies the system capabilities of the remote system.

Managed Addresses

Address SubType Specifies the type of the management address.

62 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

Field Description

Address Specifies the advertised management address of the remote system.

Interface SubType Specifies the port subtype.

Interface Number Identifies the port on the remote device that sent the information.

MAC/PHY Details

Auto-Negotiation Supported Specifies whether the remote device supports port-speed auto-negotiation.

The possible values are True or False

Auto-Negotiation Enabled Displays the port speed auto-negotiation support status. The possible values

are True or False

Auto Negotiation Advertised Capabilities

Operational MAU Type Displays the Medium Attachment Unit (MAU) type. The MAU performs

MED Details

Capabilities Supported Specifies the supported capabilities that were received in MED TLV from the

Current Capabilities Specifies the advertised capabilities that were received in MED TLV from the

Device Class Displays the LLDP-MED endpoint device class. The possible device classes

Displays the port speed auto-negotiation capabilities.

physical layer functions, including digital data conversion from the Ethernet interface collision detection and bit injection into the network.

device.

are:

• Endpoint Class 1 Indicates a generic endpoint class, offering basic LLDP

services.

• Endpoint Class 2 Indicates a media endpoint class, offering media

streaming capabilities as well as all Class 1 features.

• Endpoint Class 3 Indicates a communications device class, offering all

Class 1 and Class 2 features plus location, 911, Layer 2 switch support and device information management capabilities.

PoE Device Type Displays the port PoE type. For example, Powered.

PoE Power Source Displays the port's power source.

PoE Power Priority Displays the port's power priority.

PoE Power Value Displays the port's power value.

Hardware Revision Displays the hardware version advertised by the remote device.

Firmware Revision Displays the firmware version advertised by the remote device.

Software Revision Displays the software version advertised by the remote device.

Serial Number Displays the serial number advertised by the remote device.

Model Name Displays the model name advertised by the remote device.

Chapter 2: Configuring System Information | 63

GS716Tv2 and GS724Tv3 Software Administration Manual

Field Description

Asset ID Displays the asset ID advertised by the remote device.

Location Information

Civic Displays the physical location, such as the street address, the remote device

has advertised in the location TLV. For example, 123 45th St. E. The field value length range is 6–160 characters.

Coordinates Displays the location map coordinates the remote device has advertised in

the location TLV, including latitude, longitude and altitude.

ECS ELIN Displays the Emergency Call Service (ECS) Emergency Location

Identification Number (ELIN) the remote device has advertised in the location TLV. The field range is 10–25.

Unknown Displays unknown location information for the remote device.

Network Policies

Application Type Specifies the media application type associated with the policy advertised by

the remote device.

VLAN ID Specifies the VLAN ID associated with the policy.

VLAN Type Specifies whether the VLAN associated with the policy is tagged or untagged.

User Priority Specifies the priority associated with the policy.

DSCP Specifies the DSCP associated with a particular policy type.

LLDP Unknown TLVs

Type Displays the unknown TLV type field.

Value Displays the unknown TLV value field.

64 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

Services — DHCP Filtering

DHCP Filtering is a useful feature that can be employed as a security measure against unauthorized DHCP servers. A known attack is when an unauthorized DHCP server responds to a client that is requesting an IP address. The server configures the gateway for the client to be equal to the IP address of the server. At that point, the client sends all of its IP traffic destined to other networks to the unauthorized machine. This gives the attacker the possibility of snooping traffic for passwords or employing a man-in-the-middle attack. DHCP Filtering works by allowing the administrator to configure each port as either a trusted port or an untrusted port. The port that has the authorized DHCP server should be configured as a trusted port. Any DHCP responses received on a trusted port are forwarded. All other ports should be configured as untrusted. Any DHCP (or BootP) responses received are discarded.

From the Services link, you can access the following pages:

• DHCP Filtering Configuration on page 65

• Interface Configuration on page 66

DHCP Filtering Configuration

Use the DHCP Filtering Configuration page to enable or disable the DHCP Filtering feature on the switch.

To access the DHCP Filter Configuration page, click System Services  DHCP Filtering  Configuration.

To configure global DHCP filtering settings:

1. In the Admin Mode field, select Enable or Disable to turn the DHCP Filtering feature on

or off.

2. Click Apply to apply the change to the system. Configuration changes take effect

immediately.

3. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

Chapter 2: Configuring System Information | 65

GS716Tv2 and GS724Tv3 Software Administration Manual

Interface Configuration

Use the DHCP Filtering Interface Configuration page to view and configure each port as a trusted or untrusted port. Any DHCP responses received on a trusted port are forwarded. If a port is configured as untrusted, any DHCP (or BootP) responses received on that port are discarded.

To access the DHCP Filtering Interface Configuration page, click System Services  DHCP Filtering  Interface Configuration.

To configure DHCP filtering settings for an interface:

1. To configure DHCP filtering settings for a physical port, click PORTS.

2. To configure DHCP filtering settings for a Link Aggregation Group (LAG), click LAGS.

66 | Chapter 2: Configuring System Information

GS716Tv2 and GS724Tv3 Software Administration Manual

3. To configure DHCP filtering settings for both physical ports and LAGs, click ALL.

4. Select the check box next to the port or LAG to configure. You can select multiple ports and

LAGs to apply the same setting to the selected interfaces. Select the check box in the heading row to apply the same settings to all interfaces.

5. Choose the trust mode for the selected port(s) or LAG(s).

• Enable: Any DHCP responses received on this port are forwarded.

• Disable: Any DHCP (or BootP) responses received on this port are discarded.

6. Click Apply to apply the change to the system. Configuration changes take effect

immediately.

7. Click Cancel to cancel the configuration on the screen and reset the data on the screen to

the latest value of the switch.

Chapter 2: Configuring System Information | 67

GS716Tv2 and GS724Tv3 Software Administration Manual

68 | Chapter 2: Configuring System Information
