Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Data Sheet
D7000
Performance & Use
1GHz
Dual Core
Processor
Extreme
Speed & Range
WIFI VDSL2/ADSL
MODEM ROUTER
• Two-in-One—DSL Modem + AC1900
WiFi Router
• Auto Detection for Universal
DSL Support
• Compatible with VDSL, VDSL2, ADSL,
ADSL2, & ADSL2+
• Gigabit Ethernet WAN port provides
universal compatibility with any
Internet service
AC1900
1900
DUAL BAND
600+1300
RANGE
• Extreme combined WiFi speed—Up to 1900 Mbps
• 1GHz dual-core processor
• Fast VDSL/ADSL modem for fibre broadband
• Compatible with VDSL, VDSL2, ADSL, ADSL2, & ADSL2+
The NETGEAR Dierence - D7000
• Beamforming+—Faster, more reliable connections
• High-powered amplifiers & antennas to extend your WiFi coverage
• Twice the USB storage access & faster connections using two USB 3.0 ports
• Gigabit Ethernet WAN port provides universal compatibility with any
Internet service
• NETGEAR genie App®—Easily manage, monitor, & control your home
network from PC, tablet, or smartphone
STREAMING & GAMING
• Extreme combined WiFi speed—Up to
1900 Mbps
• Dual-core 1GHz processor boosts
performance for gaming & streaming
• Uninterrupted video streaming with
advanced QoS
• Implicit & Explicit Beamforming for
whole home HD coverage across all
your devices
• Find & play stored media on TVs &
game consoles via DLNA® server
• Secure remote access to your home
network via VPN
†
†
MOBILE
• Beamforming+ boosts speed & range
for new and legacy mobile devices
• Amplifiers & external antennas increase
range for mobile devices throughout
your home
• Print from an iPad® or iPhone®—
NETGEAR genie® makes any printer
AirPrint® compatible
• EZ Mobile Connect—Scan QR code on
your smartphone to connect to your
home network
• NETGEAR genie® provides device-level
parental controls
PAGE 1 OF 6
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Data Sheet
D7000
Speed
Get the fastest WiFi currently available & enjoy a
blazing-fast, lag-free WiFi experience for gaming,
video streaming or surfing.
WiFi Range
Got range? Homes come in all shapes and sizes
and the Nighthawk AC1900 WiFi VDSL/ADSL
Modem Router provides WiFi coverage no
matter where you connect in your home.
WORLD’S FASTEST WIFI—Up to 600+1300 Mbps
1900
DUAL BAND
†
GIGABIT WIFI—Next-generation WiFi now at Gigabit speeds
GIGABIT WIRED—Ideal for HD gaming & video
DUAL-CORE PROCESSOR—Dual-core 1GHz processor boosts
1GHz
Dual Core
Processor
wireless, wired & WAN-to-LAN performance
CABLE OR FIBRE—Also connects to cable modem via Gigabit
Ethernet WAN port
VDSL MODEM—Compatible with VDSL, VDSL2, ADSL,
ADSL2, & ADSL2+
ULTIMATE RANGE—WiFi coverage throughout very large homes
ANTENNAS—High-powered amplifiers with 3 external antennas
Sharing
With NETGEAR, sharing across your network is fun
and easy, anything from accessing stored photos
& music to wireless printing. And make sure you
keep it safe by using the included ReadySHARE Vault
application for backing up Windows-based PCs.
DLNA®—Find & play your media on DLNA TVs & game consoles
READYSHARE® USB ACCESS—Wirelessly access & share
USB hard drive & printer via two (2) USB ports
TWO SUPERSPEED USB 3.0 PORTS—Up to 10x faster than USB 2.0
READYSHARE PRINTER—Wirelessly access & share a USB printer
PAGE 2 OF 6
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Data Sheet
D7000
Reliable Connections
There’s nothing more frustrating than lost
connections! With NETGEAR’s advanced
features & best-in-class technology, you’ll
reduce interference & enjoy more reliable
WiFi connectivity.
Ease Of Use
Start enjoying your new device faster than ever.
NETGEAR wants to make sure installation and
management is simple & easy, so you can connect
quickly & make sure you stay that way!
SIMULTANEOUS DUAL BAND—Reduces interference for better
connections to more WiFi devices
ADVANCED QoS—Downstream & upstream QoS automatically
recognizes & prioritizes streaming & gaming applications
BEAMFORMING+—Boosts speed, reliability, & range of WiFi
connections for 2.4 & 5GHz
EASY INSTALL—Easy setup for iPad®, tablets, smartphones
& computers
NETGEAR GENIE® APP—Personal dashboard to monitor, control &
repair your home network
PUSH ‘N’ CONNECT —Easy push button WiFi connections (WPS)
WIFI & POWER ON/OFF —Convenient power savings
Security
Maintain the highest security across your network
to ensure your privacy & family is safe while
online. Whether it’s preventing phishing & spyware
or just limiting access for kids & guests, NETGEAR
has you covered.
VPN SUPPORT —Secure access to your home network
VPN
PARENTAL CONTROLS—Web site filtering for all your
connected devices
GUEST NETWORK ACCESS—Separate & secure access for guests
SECURE WIFI CONNECTIONS—Highest level wireless security
with WPA/ WPA2
PERSONAL FTP SERVER—Customized free URL to create FTP server
FTP
PAGE 3 OF 6
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Data Sheet
D7000
BEAMFORMING+—FOR MORE RELIABLE CONNECTIONS
Unlike typical Wi-Fi routers that just blast the Wi-Fi signals in all directions,
with Beamforming+ the router & device communicate with each other, so the
router can directly beam the Wi-Fi signal to the device. The result is a stronger,
faster, more reliable connection that is locked in even when the device is moved
around the home.
• Focuses WiFi signals from the wireless router to WiFi devices like
smartphones, tablets & laptops
• Automatic signal management checks with your device to keep WiFi
signal at its optimal strength
• Designed for home environments to support multiple WiFi device
connections for highest quality
• Extends WiFi coverage, reduces deadpots, & boosts signal strength
• Implicit & Explicit Beamforming boosts speed, reliability & range
for both 2.4 & 5GHz WiFi devices—an industry first
NETGEAR genie®—HOME NETWORKING SIMPLIFIED
NETGEAR genie makes getting the most out of your home network fun & easy.
Installation is almost eortless - just by opening a browser, genie helps you
setup your NETGEAR WiFi Router & connect all of your WiFi devices. Genie also
allows you to easily monitor, connect & control your home network from a PC,
Mac, tablet or smartphone. With NETGEAR genie you can share & stream music
or videos, diagnose & repair network issues, set up parental controls & more.
• Home network manager
• Network Map—Real-time map of all the connected devices on
your network
• Makes any printer AirPrint® compatible to print from an iPad® or iPhone
• MyMedia™—Find & play media files in your network
• EZ Mobile Connect—Scan QR code to connect to your home network
• Turbo Transfer—Quickly transfer files within your home network
across various devices 40% faster than normal file transfers
• For PC, Mac®, iPhone®, iPad®, & Android™ devices
®
PAGE 4 OF 6
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Data Sheet
D7000
Connection Diagram
USB 3.0
Push ‘N’ Connect
with WPS
(front)
Gigabit Ethernet
Connects to Cable
or Fiber Modem
WiFi
On/O
(front)
Gigabit
Wired
USB 3.0
Connects to
Telephone Line
(built-in modem)
PAGE 5 OF 6
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Data Sheet
D7000
Package Contents
• Nighthawk AC1900 WiFi VDSL/ADSL
Modem Router (D7000)
• Ethernet cable
• Phone cable
• DSL filter
• Quick start guide
• Power adapter, localized to country of sale
Physical Specifications
• Dimensions: 11.22 x 7.26 x 1.97 in
(285 x 185 x 50 mm)
• Weight: 1.65 lb (750 g)
Standards
• Two (2) USB 3.0 ports
• One (1) VDSL/ADSL port
• IEEE® 802.11 b/g/n 2.4GHz +
256 QAM support
®
• IEEE
802.11 a/n/ac 5.0GHz
• Five (5) 10/100/1000 Mbps—(1 WAN & 4 LAN)
Gigabit Ethernet ports
Technical Specifications
• High-speed VDSL2/ADSL2+ modem built-in
• Simultaneous Dual Band WiFi—Tx/Rx
3x3 (2.4GHz) + 3x3 (5GHz)
• Implicit & explicit Beamforming
• Powerful dual-core 1GHz processor
• WiFi Boost with high-powered radio amplifiers
• Memory: 128 MB flash and 256 MB RAM
• Advanced Quality of Service (QoS)
• ReadySHARE® USB—Share your USB hard drive
and printer
• ReadySHARE Vault—Software for automatic
PC backup to USB hard drive connected to the
router
• IPv6 Support (Internet Protocol Version 6)
• Push ‘N’ Connect—Easy push button WiFi
connections (WPS)
• Turn LED lights on/off through router settings
Support
• 24/7 basic technical phone support for
90 days from date of purchase
Broadband Internet Service
• VDSL/ADSL broadband Internet service
• Gigabit Ethernet WAN provides broadband
connectivity options to cable, DSL or fibre
modems
System Requirements
• Microsoft® Windows 7, 8, Vista®, XP®,
2000, Mac OS
• Microsoft® Internet Explorer® 5.0, Firefox® 2.0,
Safari
or higher
®
, UNIX®, or Linux
®
1.4, or Google Chrome™ 11.0 browsers
®
Security
• Customized free URL to set up personal
FTP server
• VPN support—secure remote access
• Guest network access—separate & secure
• WiFi Protected Access
®
(WPA/ WPA2—PSK)
• Double firewall protection (SPI and NAT)
• Denial-of-service (DoS) attack prevention
Warranty
• www.netgear.com/about/warranty/
SCAN TO L EARN MORE
This product comes with a limited warranty that is valid only if purchased from a NETGE AR authorized reseller.
*
24/7 basic technical phone suppor t provided for 90 days from purchase date.
†
Maximum wireless signal rate derived from IEEE 802.11 specifications. Actual data throughput and wireless coverage will vary and may be lowered by network and environmental
conditions, including network trac volume and building construction. NETGEAR makes no representations or warranties about this product’s compatibility with future standards.
‡
Up to 130 0 Mbps wireless speeds achieved when connecting to other 802.11ac 1300 Mbps devices. 2.4GHz performance mode requires 256QAM support on WiFi client.
©2015 NETGE AR, Inc. NE TGEAR, the NETGEA R Logo, ReadySHARE, ReadySHARE Vault, and NETGEAR genie, are trademarks of NETGEAR, Inc. Mac and the Mac logo are trademarks of
Apple Inc. Any other trademarks herein are for reference purposes only.
NETGEAR, Inc. 350 E. Plumeria Drive, San Jose, CA 95134-1911 USA, 1-888-NETGEAR (638-4327), E-mail: info@NETGE AR.com, www.NETGE AR.com D-D7000-2
PAGE 6 of 6
