User Manual

AC1750 WiFi Cable Modem Router

Model C6300v2

NETGEAR, Inc.

350 E. Plumeria DriveSeptember 2018 San Jose, CA 95134, USA202-11901-01

AC1750 WiFi Cable Modem Router

Support

Thank you for purchasing this NETGEAR product.

You can visit https://www.netgear.com/support to register your product, get help, access the latest downloads and user manuals, and join our community. We recommend that you use only official NETGEAR support resources. Contact your Internet service provider for technical support.

Trademarks

©NETGEAR, Inc. NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc. Any non-NETGEAR trademarks are used for reference purposes only.

Compliance

For regulatory compliance information including the EU Declaration of Conformity, visit https://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.

Chapter 1 Hardware Setup

Unpack Your Cable Modem Router...................................................8

Front Panel LEDs and Buttons.............................................................9

Rear Panel............................................................................................12

Label.....................................................................................................13

System Requirements........................................................................13

Position Your Cable Modem Router................................................14

Install and Activate Your Cable Modem Router.............................15

Set Up the Hardware.....................................................................15

Activate Your Internet Service......................................................17

Perform a Speed Test....................................................................18

Connect Your Cable Modem Router to a Router After Installation

and Activation.....................................................................................18

Chapter 2 Connect to the Network and Access the Cable Modem Router

Connect to the Network....................................................................21

Wired Connection..........................................................................21

Find and Select the Cable Modem Router WiFi Network.........21

Use WPS to Connect to the Cable Modem Router WiFi

Network...........................................................................................21

Types of Logins...................................................................................22

Chapter 3 Specify Your Internet Settings

Specify the Cable Connection Starting Frequency........................25

View Modem Router Initialization.....................................................25

Manually Set Up the Internet Connection.......................................26

Chapter 4 Control Access to the Internet

Set Up Parental Controls...................................................................29

Block Access to Your Network..........................................................29

Use Keywords to Block Internet Sites...............................................30

Delete a Keyword...............................................................................32

Block Services From the Internet......................................................32

Schedule When to Block Internet Sites and Services.....................34

AC1750 WiFi Cable Modem Router

Avoid Blocking on a Trusted Computer..........................................35

Set Up Security Event Email Notifications.......................................35

Chapter 5 Share USB Devices Attached to the CableModem Router

USB Storage Device Requirements..................................................39

Connect a USB Storage Device to the Cable Modem Router......39

Access a USB Device Connected to the Cable Modem Router From

a Windows-Based Computer............................................................40

Map a USB Device to a Windows Network Drive...........................40

Access a USB Storage Device That Is Connected to the Cable

Modem Router From a Mac..............................................................41

Control Access to the USB Storage Device.....................................42

Use FTP Within the Network.............................................................43

View or Change Network Folders on a USB Storage Device........43

Add a Network Folder on a USB Storage Device...........................44

Edit a Network Folder on a USB Storage Device...........................45

Approve USB Devices........................................................................46

Access the USB Storage Device Through the Internet..................47

Set Up FTP Access Through the Internet.........................................48

Access the USB Storage Device Through the Internet With FTP...48

Safely Remove a USB Storage Device..............................................49

Chapter 6 Share a USB Printer

Install the Printer Driver and Cable the Printer...............................51

Download the ReadySHARE Printer Utility......................................51

Install the ReadySHARE Printer Utility..............................................51

Print Using the NETGEAR USB Control Center...............................52

Chapter 7 Specify Network Settings

View or Change the WAN Settings..................................................55

Set Up a Default DMZ Server............................................................56

Change the Cable Modem Router’s Device Name........................57

Change the LAN TCP/IP Settings.....................................................57

Specify the IP Addresses That the Cable Modem Router Assigns.58

Disable the DHCP Server Feature in the Cable Modem Router....60

Manage LAN IP Addresses................................................................60

Reserve an IP Address...................................................................61

Edit a Reserved IP Address Entry.................................................61

Delete a Reserved IP Address Entry............................................62

Improve Network Connections With Universal Plug-N-Play.........63

Use the WPS Wizard for WiFi Connections.....................................64

Specify Basic WiFi Settings................................................................65

Change the WiFi Security Option.....................................................66

Set Up a Guest Network....................................................................67

AC1750 WiFi Cable Modem Router

Control the WiFi Radios.....................................................................68

Use the WiFi On/Off Button..........................................................69

Enable or Disable the WiFi Radios...............................................69

Specify WPS Settings..........................................................................70

Enable or Disable Router Mode.......................................................70

Chapter 8 Manage Your Network

Change the admin Password............................................................73

Set Up Password Recovery................................................................73

Recover the admin Password............................................................74

View Modem Router Status...............................................................75

Display Internet Port Statistics...........................................................76

Check the Internet Connection Status.............................................77

View Logs of Cable Modem Router Activity....................................78

View Event Logs..................................................................................78

Run the Ping Utility.............................................................................79

Run the Traceroute Utility..................................................................80

Monitor Internet Traffic......................................................................81

View Devices Currently on the Network..........................................82

Manage the Cable Modem Router Configuration File..................83

Back Up Settings............................................................................84

Restore Configuration Settings....................................................84

Erase the Current Configuration Settings...................................85

View or Change the Cable Modem Router WiFi Channel.............85

Set Up and Manage Dynamic DNS..................................................86

Specify a DNS Account..................................................................87

Change the Dynamic DNS Settings.............................................87

Remote Management........................................................................88

Set Up Remote Management.......................................................88

Use Remote Access.......................................................................89

Chapter 9 Specify Internet Port Settings

Set Up Port Forwarding to a Local Server.......................................91

Add a Custom Port Forwarding Service..........................................92

Edit a Port Forwarding Service.........................................................93

Delete a Port Forwarding Entry........................................................94

Application Example: Make a Local Web Server Public................94

How the Cable Modem Router Implements the Port Forwarding

Rule.......................................................................................................95

Set Up Port Triggering.......................................................................95

Add a Port Triggering Service......................................................96

Application Example: Port Triggering for Internet Relay Chat.97

AC1750 WiFi Cable Modem Router

Chapter 10 Troubleshooting

Troubleshoot With the LEDs...........................................................100

Power LED Is Off..........................................................................100

LEDs Never Turn Off....................................................................100

Internet LED Is Off........................................................................100

Troubleshoot the Cable Internet Connection..............................101

Cannot Log In to the Cable Modem Router.................................101

Changes Not Saved.........................................................................102

WiFi Connectivity..............................................................................102

Troubleshoot Your Network Using the Ping Utility......................103

Test the LAN Path to Your Cable Modem Router....................103

Test the Path From Your Computer to a Remote Device.......104

Chapter 11 Supplemental Information

Factory Settings................................................................................107

Technical Specifications..................................................................108

Hardware Setup

This chapter covers the following topics:

• Unpack Your Cable Modem Router

• Front Panel LEDs and Buttons

• Rear Panel

• Label

• System Requirements

• Position Your Cable Modem Router

• Install and Activate Your Cable Modem Router

• Connect Your Cable Modem Router to a Router After Installation and Activation

For more information about the topics covered in this manual, visit the support website at support.netgear.com.

AC1750 WiFi Cable Modem Router

Unpack Your Cable Modem Router

Your package contains the following items.

Figure 1. Package contents

1. AC1750 WiFi Cable Modem Router (Model C6300v2)

2. Ethernet cable

3. Power adapter

User Manual8Hardware Setup

AC1750 WiFi Cable Modem Router

Front Panel LEDs and Buttons

You can use the LEDs to verify status and connections.

The following buttons are located on the front of the cable modem router:

Table 1. Front panel buttons

DescriptionButton

WPS

This button lets you use WPS to join the WiFi network without typing the WiFi password. The WPS LED blinks during this process and then lights solid.

•

Solid green. Your cable modem router connected to a WPS-enabled device.

•

Blinking green. Your cable modem router is attempting to connect to a WPS-enabled device.

•

Off. A WPS connection is not in progress.

User Manual9Hardware Setup

AC1750 WiFi Cable Modem Router

Table 1. Front panel buttons (Continued)

DescriptionButton

WiFi Pressing this button for two seconds turns the WiFi radios in the cable modem router on and off.

•

Solid green. The WiFi radios are on.

•

Off. The WiFi radios are off. You cannot use WiFi to connect to the cable modem router..

The following table lists and describes each LED on the front panel of the cable modem router.

Table 2. LED descriptions

DescriptionLED

Power

Downstream

Upstream

Online

•

Solid green. Power is supplied to the cable modem router.

•

Off. No power is supplied to the cable modem router.

•

Solid red. Thermal cutoff mode. Power off the cable modem router, let it cool, and move it away from heat sources (such as a TV, DVD player, or speakers).

•

Solid amber. One downstream channel is locked.

•

Solid green. Two or more downstream channels are locked.

•

Blinking green. The cable modem router is scanning for a downstream channel.

•

Off. No downstream channel is locked.

•

Solid amber. One upstream channel is locked.

•

Solid green. Two or more upstream channels are locked.

•

Blinking green. The cable modem router is scanning for an upstream channel.

•

Off. No upstream channel is locked.

•

Solid green. The cable modem router is online.

•

Blinking green. The cable modem router is synchronizing with the cable provider’s cable modem termination system (CMTS).

•

Slow blinking amber and green. The cable modem router reached the traffic meter limit.

•

Off. The cable modem router is offline.

User Manual10Hardware Setup

AC1750 WiFi Cable Modem Router

Table 2. LED descriptions (Continued)

DescriptionLED

2.4 GHz radio

5 GHz radio

Ethernet

USB

•

Solid green. The 2.4 GHz WiFi radio is operating.

•

Blinking green. The router is sending or receiving WiFi traffic.

•

Off. The 2.4 GHz WiFi radio is off.

•

Solid green. The 5 GHz WiFi radio is operating.

•

Blinking green. The router is sending or receiving WiFi traffic.

•

Off. The 5 GHz WiFi radio is off.

•

Solid green. A powered-on device is connected to the Ethernet port.

•

Blinking green. The port is sending or receiving traffic.

•

Off. No device is connected to this Ethernet port.

•

Solid green. A USB device is connected and is ready.

•

Off. No USB device is connected, or someone clicked the Safely Remove Hardware button and it is now safe to remove the attached USB device.

User Manual11Hardware Setup

AC1750 WiFi Cable Modem Router

Rear Panel

The connections and button on the rear panel are shown in the following figure.

Figure 2. Cable modem router rear panel

Viewed from left to right, the back panel contains the following components:

•

USB port. Use the USB port to connect a USB storage device to the cable modem router.

•

Ethernet ports 1–4. Four Gigabit Ethernet RJ-45 LAN ports to connect the cable modem router to LAN devices.

•

Reset button. Pressing the Reset button resets the cable modem router. If the Reset button is pressed for at least seven seconds and the Power LED blinks green, the

cable modem router returns to its factory settings.

•

Coaxial cable connector. Use a coaxial cable to connect the coaxial cable connector to a cable wall outlet.

User Manual12Hardware Setup

AC1750 WiFi Cable Modem Router

•

DC power connector. Connect the power adapter that came in the product package to the DC power connector.

•

Power On/Off button. Press the Power On/Off button to provide power to the cable modem router.

Label

The cable modem router label shows the login information, MAC address, and serial number.

Figure 3. Cable modem router label

System Requirements

You need the following to install your modem router:

Compatible operating system:

•

- Windows® 7

- Windows 8

- Windows 10

- Windows Vista®

- Windows XP®

- Windows 2000

- Mac OS®

- UNIX®

- Linux®

Compatible web browser:

•

Microsoft® Internet Explorer® 5.0 or higher

Firefox® 2.0 or higher

User Manual13Hardware Setup

AC1750 WiFi Cable Modem Router

Safari® 1.4 or higher

- Google Chrome™ 11.0 or higher

Cable broadband Internet service

•

Position Your Cable Modem Router

The cable modem router lets you access your network anywhere within the operating range of your WiFi network. However, the operating distance or range of your WiFi connection can vary significantly depending on the physical placement of your cable modem router. For example, the thickness and number of walls the WiFi signal passes through can limit the range.

Additionally, other WiFi access points in and around your home might affect your cable modem router’s signal. WiFi access points are routers, repeaters, WiFi range extenders, and any other device that emits a WiFi signal for network access.

Position your cable modem router according to the following guidelines:

Place your cable modem router near the center of the area where your computers

• and other devices operate, and within line of sight to your WiFi devices.

Make sure that the cable modem router is within reach of an AC power outlet and

• near Ethernet cables for wired computers.

Place the cable modem router in an elevated location, minimizing the number walls

• and ceilings between the cable modem router and your other devices.

Place the cable modem router away from electrical devices such as these:

•

Ceiling fans

- Home security systems

- Microwaves

- Computers

Base of a cordless phone

- 2.4 GHz cordless phone

Place the cable modem router away from large metal surfaces, large glass surfaces,

• and insulated walls, and items such as these:

- Solid metal doors

- Aluminum studs

- Fish tanks

User Manual14Hardware Setup

AC1750 WiFi Cable Modem Router

- Mirrors

- Brick

- Concrete

Install and Activate Your Cable Modem Router

The cable modem router provides a connection between your cable Internet provider’s network and your computer, router, or WiFi router.

Set Up the Hardware

During the installation and activation, you must connect the cable modem router directly to a computer. After installation and activation, you can connect the cable modem router to a router.

Figure 4. Connect the cable modem router directly to a computer

Note: Before you connect your cable modem router and contact your cable Internet provider, collect your cable account number, account phone number, and login

information (your email address or user name and password).

User Manual15Hardware Setup

AC1750 WiFi Cable Modem Router

To set up your cable modem router:

Turn off and disconnect existing modems and routers. If you are replacing a modem that is currently connected in your home, unplug the

modem and plug the new cable modem router into the same outlet.

Note: Xfinity recommends connecting your cable modem router directly to a cable wall outlet.

2. Connect a coaxial cable. Use a coaxial cable to connect the coaxial cable connector on the cable modem

router to the cable wall outlet.

3. Connect the power adapter. Connect the power adapter to the cable modem router and plug the power adapter

into an electrical outlet.

The startup procedure takes about one minute. When it is complete, the Power LED lights solid green. If the Power LED does not light, make sure that the Power On/Off button is in the On position.

Wait for the cable modem router to come online. This process might take up to three minutes.

Note: When the Online LED lights, your cable modem router is still not connected to the Internet. You must activate your cable modem router with your ISP.

5. Connect a computer or mobile device to the cable modem router with a WiFi or wired connection:

WiFi. Use the WiFi network name and password on the cable modem router

•

label.

Wired. Use an Ethernet cable to connect a computer to an Ethernet port on the

•

cable modem router.

6. Launch a web browser and set up your cable modem router. You are automatically redirected to the cable modem router web interface. If you’re

not redirected, enter http://routerlogin.net or http://192.168.0.1 in the address field of the web browser.

Follow the prompts to set up your cable modem router.

User Manual16Hardware Setup

AC1750 WiFi Cable Modem Router

Make sure that you can log in to the cable modem router web interface after the setup.

In a new web browser window, enter http://routerlogin.net or http://192.168.0.1 and then enter the cable modem router admin user name and password.

If the BASIC Home page displays, you are ready to activate your Internet service.

8. Activate your Internet service. Even though an Internet connection is established, Internet service is available only

after you set it up with your cable Internet provider. For information about how to activate your Internet service, see Activate Your Internet Service on page 17.

Activate Your Internet Service

Before you activate your Internet service, gather the following information:

Your cable Internet provider account information

•

Cable modem router model number, which is C6300v2

•

Cable modem router serial number, which is on the cable modem router label

•

Cable modem router MAC address, which is on the cable modem router label

•

Figure 5. Cable modem router label example

The following is contact information for cable Internet providers that support your cable modem router.

Table 3. Cable Internet provider contact information

Contact InformationCable Internet

Provider

CableOne

Cox

Mediacom

https://www.cableone.net/ 1-877-MY-CABLE (1-877-692-2253)

https://www.cox.com/activate 1-888-556-1193

https://maestro.mediacomcc.com/walledgarden/page/login.jsp 1-855-Mediacom (1-855-633-4226)

User Manual17Hardware Setup

AC1750 WiFi Cable Modem Router

Table 3. Cable Internet provider contact information (Continued)

Contact InformationCable Internet

Provider

Optimum

Spectrum

Xfinity

https://install.optimum.com/JointInstall/ 1-877-810-6750

http://www.spectrum.net/support/internet/activating-new-modem/ 1-833-267-6094

https://xfinity.com/activate https://xfinity.com/Internetsetup 1-800-XFINITY (1-800-934-6489)

Note: Your cable Internet provider’s contact information might change. You can find the contact information in your monthly Internet service billing statement.

To activate your Internet service:

Visit your cable Internet provider’s website and follow the onscreen instructions to activate your Internet service.

If you are unable to activate your Internet service using the instructions on your cable Internet provider’s website, call your cable Internet provider for support.

3. To determine the accurate Internet speed, visit your cable Internet provider's speed test website and perform a speed test. .

If your actual speed is lower than your subscribed speed, contact your cable Internet provider.

Perform a Speed Test

To determine the accurate Internet speed, visit the speed test website of your cable Internet provider and perform a speed test.

If your actual speed is lower than your subscribed speed, contact your cable Internet provider.

Connect Your Cable Modem Router to a Router After Installation and Activation

During the installation and activation, you must connect the cable modem router directly to a computer. After installation and activation, you can connect the cable modem router to a router.

User Manual18Hardware Setup

AC1750 WiFi Cable Modem Router

If you want to connect your cable modem router to a router, you must disable router mode on the cable modem router. Disable router mode so that your cable modem router avoids conflicting with the other router on the network.

To disable router mode on your cable modem router:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Router Mode. The Router Mode page displays.

Select the No radio button.

Click the Apply button. Your settings are saved.

7. Follow the instructions that came with your router or gateway to connect your cable modem router to a router.

User Manual19Hardware Setup

Connect to the Network and Access the Cable Modem Router

This chapter contains the following sections:

• Connect to the Network

• Types of Logins

• Log In to the Cable Modem Router

AC1750 WiFi Cable Modem Router

Connect to the Network

You can connect to the cable modem router’s network through a wired or WiFi connection. If you set up your computer to use a static IP address, change the settings so that it uses Dynamic Host Configuration Protocol (DHCP).

Wired Connection

You can connect your computer to the cable modem router using an Ethernet cable and join the cable modem router’s local area network (LAN).

To connect your computer to the cable modem router with an Ethernet cable:

1. Make sure that the cable modem router is receiving power (its Power LED is lit).

2. Connect an Ethernet cable to an Ethernet port on your computer.

Connect the other end of the Ethernet cable to one of the numbered Ethernet ports. Your computer connects to the local area network (LAN). A message might display

on your computer screen to notify you that an Ethernet cable is connected.

Find and Select the Cable Modem Router WiFi Network

To find and select the WiFi network:

1. Make sure that the cable modem router is receiving power (its Power LED is lit).

On your computer or mobile device, find and select the WiFi network. The WiFi network name is on the cable modem router label.

3. Join the WiFi network and enter the WiFi password. The password is on the cable modem router label.

Your computer or mobile device connects to the WiFi network.

Use WPS to Connect to the Cable Modem Router WiFi Network

You can connect a WPS-enabled device to the cable modem router’s WiFi network with Wi-Fi Protected Setup (WPS).

To use WPS to connect to the WiFi network:

1. Make sure that the cable modem router is receiving power (its Power LED is lit).

Check the WPS instructions for your WPS-enabled device.

User Manual21Connect to the Network and

Access the Cable Modem Router

AC1750 WiFi Cable Modem Router

Press the WPS button on the cable modem router.

Within two minutes, on your WPS-enabled device, press its WPS button or follow its instructions for WPS connections.

Your WPS-enabled device connects to the WiFi network.

Types of Logins

Separate types of logins serve different purposes. It is important that you understand the difference so that you know which login to use when.

Types of logins:

WiFi network key or password. Your cable modem router is preset with a unique

• WiFi network name (SSID) and password for WiFi access. This information is on the cable modem router label.

Note: Your cable modem router broadcasts dual-band 2.4 GHz and 5 GHz WiFi signals. The label shows the SSID for the 2.4 GHz signal. For information about 5 GHz WiFi settings, see Specify Basic WiFi Settings on page 65.

Modem router login. This logs you in to the cable modem router web pages as

• admin from an Internet browser.

Log In to the Cable Modem Router

When you connect to the network (either with WiFi or with an Ethernet cable), you can use a web browser to access the cable modem router to view or change its settings. The first time you access the cable modem router, the cable modem router automatically checks to see if it can connect to your Internet service.

To log in to the cable modem router:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Type http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

User Manual22Connect to the Network and

Access the Cable Modem Router

AC1750 WiFi Cable Modem Router

Note: The first time that you log in to the cable modem router, you are prompted

to set the admin password and set up security questions. You must enter these settings before you can access the Internet.

The BASIC Home page displays the status of the Internet connection.

Access the Cable Modem Router

User Manual23Connect to the Network and

Specify Your Internet Settings

Usually, the quickest way to set up the cable modem router to use your Internet connection is to allow the cable modem router to detect the Internet connection when you first access the cable modem router with an Internet browser. You can also customize or specify your Internet settings.

This chapter contains the following sections:

• Specify the Cable Connection Starting Frequency

• View Modem Router Initialization

• Manually Set Up the Internet Connection

AC1750 WiFi Cable Modem Router

Specify the Cable Connection Starting Frequency

The starting frequency is automatically generated. For most Internet connections, you do not need to specify this information. If you must enter a starting frequency, contact your Internet provider.

To change the starting frequency:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select Cable Connection. The Cable Connection page displays the status of all downstream and upstream

channels.

In the Starting Frequency field, enter a frequency.

Click the Apply button. Your settings are saved.

View Modem Router Initialization

You can track the initialization procedure of the cable modem router and get details about the downstream and upstream cable channel. The time is displayed after the cable modem router is initialized.

The cable modem router automatically goes through the following steps in the provisioning process:

1. Scans and locks the downstream frequency and then ranges the upstream channels.

2. Obtains a WAN address for the cable modem router.

3. Connects to the Internet.

User Manual25Specify Your Internet Settings

AC1750 WiFi Cable Modem Router

To view the status of the cable modem router initialization:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select Cable Connection. The Cable Connection page displays.

The Startup Procedure section displays the initialization progress. The page also displays the status of all downstream and upstream channels. (You must scroll down to view all the channels.) The number of downstream and upstream channels that are locked depends on the number of channels that your Internet provider uses.

Manually Set Up the Internet Connection

In most situations, you do not need to change these settings. We recommend that you use the default settings for DHCP because most cable Internet services provide the IP address through DHCP.

To specify the Internet connection settings:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Setup > Internet. The Internet Setup page displays.

User Manual26Specify Your Internet Settings

AC1750 WiFi Cable Modem Router

If your Internet connection requires an account name or host name, type it in the Account Name (If Required) field.

If your Internet connection requires a domain name, type it in the Domain Name (If Required) field.

For the other sections in this page, the default settings usually work, but you can change them.

7. Select an Internet IP Address radio button:

Get Dynamically from ISP. Your ISP uses DHCP to assign your IP address. Your

•

ISP automatically assigns these addresses.

Use Static IP Address. Enter the IP address, IP subnet mask, and the gateway IP

•

address that your ISP assigned. The gateway is the ISP cable modem router to which your cable modem router connects.

8. Select a Domain Name Server (DNS) Address radio button:

Get Automatically from ISP. Your ISP uses DHCP to assign your DNS servers.

•

Your ISP automatically assigns this address.

Use These DNS Servers. If you know that your ISP requires specific servers, select

•

this option. Enter the IP address of your ISP’s primary DNS server. If a secondary DNS server address is available, enter it also.

Click the Apply button. Your settings are saved.

User Manual27Specify Your Internet Settings

Control Access to the Internet

The cable modem router comes with a built-in firewall that helps protect your home network from unwanted intrusions from the Internet.

This chapter includes the following sections:

• Set Up Parental Controls

• Block Access to Your Network

• Use Keywords to Block Internet Sites

• Block Services From the Internet

• Schedule When to Block Internet Sites and Services

• Avoid Blocking on a Trusted Computer

• Set Up Security Event Email Notifications

AC1750 WiFi Cable Modem Router

Set Up Parental Controls

To set up Parental Controls, you must download the NETGEAR genie app on your mobile device. For more information about the NETGEAR genie app, visit NETGEAR.com/genie.

After you set up and enable Parental Controls, you can change the web filtering level for each device on the network through the network map page on the genie app.

To set up Parental Controls:

1. Connect your mobile device to your cable modem router’s WiFi network.

2. Launch the app store on your mobile device and download the NETGEAR genie app.

3. Launch the NETGEAR genie app. The dashboard displays.

Tap Parental Controls. The Parental Controls page displays.

To log in to your OpenDNS account, tap the LOGIN button, enter your OpenDNS user name, and tap the LOGIN button.

Parental Controls is automatically enabled.

To create an OpenDNS account, tap CREATE ACCOUNT, fill in the fields, tap the SIGN UP button.

Your account is created and Parental Controls is automatically enabled. For more information about how to setup Parental Controls using the NETGEAR

genie app, see the genie Mobile App User Manual, which is available at downloadcenter.netgear.com/.

Block Access to Your Network

You can use access control to block access to your network.

To set up access control:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password.

User Manual29Control Access to the Internet

AC1750 WiFi Cable Modem Router

The user name is admin. The password is the one that you specified the first time that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Security > Access Control. The Access Control page displays.

Select the Turn on Access Control check box. You must select this check box before you can specify an access rule and use the

Allow and Block buttons. When this check box is cleared, all devices are allowed to connect, even if the device is in the blocked list.

6. Select an access rule:

Allow all new devices to connect. With this setting, if you buy a new device, it

•

can access your network. You don’t need to enter its MAC address on this page. We recommend that you leave this radio button selected.

Block all new devices from connecting. With this setting, if you buy a new

•

device, before it can access your network, you must enter its MAC address for an Ethernet connection and its MAC address for a WiFi connection in the allowed list.

The access rule does not affect previously blocked or allowed devices. It applies only to devices joining your network in the future after you apply these settings.

7. To allow the computer or device you’re currently using to continue to access the network, select the check box next to your computer or device, and click the Allow button.

Click the Apply button. Your settings are saved.

Use Keywords to Block Internet Sites

You can use keywords to block certain Internet sites from your network. You can use blocking all the time or based on a schedule.

To block Internet sites:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

User Manual30Control Access to the Internet

AC1750 WiFi Cable Modem Router

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Security > Block Sites. The Block Sites page displays.

5. Select a keyword blocking option:

Never. Turn off keyword blocking.

•

Per Schedule. Turn on keyword blocking according to a schedule that you set.

•

(See Schedule When to Block Internet Sites and Services on page 34.)

Always. Turn on keyword blocking all the time, independent of the Schedule

•

page.

In the Type keyword or domain here field, enter a keyword or domain that you want to block.

For example:

Specify XXX to block http://www.badstuff.com/xxx.html.

•

Specify .com if you want to allow only sites with domain suffixes such as .edu or

•

.gov.

Enter a period (.) to block all Internet browsing access.

•

Click the Add Keyword button. The keyword is added to the keyword list. The keyword list supports up to 64 entries.

Click the Apply button. Your settings are saved.

User Manual31Control Access to the Internet

AC1750 WiFi Cable Modem Router

Delete a Keyword

To delete keywords from the list:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Security >Block Sites. The Block Sites page displays.

Do one of the following:

To delete a single word, select it and click the Delete Keyword button.

•

The keyword is removed from the list.

To delete all keywords on the list, click the Clear List button.

•

All keywords are removed from the list.

Click the Apply button. Your settings are saved.

Block Services From the Internet

You can block Internet services on your network based on the type of service. You can block the services all the time or based on a schedule.

To block services:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem routerr admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

User Manual32Control Access to the Internet

AC1750 WiFi Cable Modem Router

The BASIC Home page displays.

Select ADVANCED > Security > Block Services. The Block Services page displays.

Specify when to block the services:

If you don't want to block services, select the Never radio button.

•

If you want to block services all the time, select the Always radio button.

•

If you want to block services based on a schedule, select the Per Schedule radio

•

button. For information about how to specify the schedule, see Schedule When to Block Internet Sites and Services on page 34.

Click the Add button. The Block Services Setup page displays.

To add a service that is in the Service Type menu, select the application or service. The settings for this service automatically display in the fields.

To add a service or application that is not in the menu, select User Defined, and do the following:

If you know that the application uses either TCP or UDP, select the appropriate protocol. Otherwise, select TCP/UDP (both) .

b. Enter the starting port and ending port numbers.

If the service uses a single port number, enter that number in both fields.

To find out which port numbers the service or application uses, you can contact the publisher of the application, ask user groups or newsgroups, or search on the Internet.

Specify which devices on your LAN are affected by the rule, based on their IP addresses:

Only This IP Address. Block services for a single computer.

•

IP Address Range. Block services for a range of computers with consecutive IP

•

addresses on your network.

All lP Addresses. Block services for all computers on your network.

•

10.

Click the Add button. Your settings are saved.

User Manual33Control Access to the Internet

AC1750 WiFi Cable Modem Router

Schedule When to Block Internet Sites and Services

When you schedule blocking, the same schedule is used to block sites and to block services. For information about how to specify what you want the cable modem router to block, see Use Keywords to Block Internet Sites on page 30 and Block Services From the Internet on page 32.

To schedule blocking:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Security > Schedule. The Schedule page displays.

Specify when to block keywords and services:

Days to Block. Select the check box for each day that you want to block the

•

keywords or select the Every Day check box, which automatically selects the check boxes for all days.

Time of Day to Block. Select a start and end time in 24-hour format, or select

•

All Day for 24-hour blocking.

Click the Apply button. Your settings are saved.

User Manual34Control Access to the Internet

AC1750 WiFi Cable Modem Router

Avoid Blocking on a Trusted Computer

You can exempt one trusted computer from blocking. The computer you exempt must use a fixed IP address. You can use the reserved IP address feature to specify the IP address. See Manage LAN IP Addresses on page 60.

To specify a trusted computer:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Security > Block Sites. The Block Sites page displays.

Scroll down and select the Allow trusted IP address to visit blocked sites check box.

In the Trusted IP Address field, enter the IP address of the trusted computer.

Click the Apply button. Your settings are saved.

Set Up Security Event Email Notifications

The cable modem router can email you its logs. The log records activity and security events such as attempts to access blocked sites or services.

To set up email notifications:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password.

User Manual35Control Access to the Internet

AC1750 WiFi Cable Modem Router

The user name is admin. The password is the one that you specified the first time that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Security >E-mail. The Email page displays.

Select the Turn E-mail Notification On check box.

In the Your Outgoing Mail Server field, enter the name of your ISP outgoing (SMTP) mail server (such as mail.myISP.com).

You might be able to find this information in the configuration page of your email program. If you leave this field blank, log and alert messages are not sent.

In the Your Outgoing Mail Server field, enter the name of your Internet provider’s outgoing (SMTP) mail server (such as mail.myISP.com).

You might be able to find this information in the configuration window of your email program. If you leave this field blank, log and alert messages are not sent.

In the Send to This E-mail Address field, enter the email address to which logs and alerts are to be sent.

This email address is also used for the From address. If this field is blank, log and alert messages are not sent.

If your outgoing email server requires authentication, select the My Mail Server requires authentication check box, and do the following:

In the User Name field, type the user name for the outgoing email server.

In the Password field, type the password for the outgoing email server.

10.

To send alerts when someone attempts to visit a blocked site, select the Send Alerts Immediately check box.

11.

To send logs based on a schedule, specify these settings:

From the Send logs according to this schedule menu, select the schedule type.

•

From the Day menu, select the day.

•

From the Time menu, select the time, and select the am or pm radio button.

•

12.

Click the Apply button. Your settings are saved.

Logs are sent automatically. If the log fills before the specified time, it is sent. After the log is sent, it is cleared from the cable modem router memory. If the cable modem

User Manual36Control Access to the Internet

AC1750 WiFi Cable Modem Router

router cannot email the log and the log buffer is full, the cable modem router overwrites the log.

User Manual37Control Access to the Internet

Share USB Devices Attached to the Cable Modem Router

This chapter describes how to access and configure a USB storage device attached to your cable modem router. The USB port on the cable modem router can be used only to connect USB storage devices like flash drives or hard drives, or a printer. Do not connect computers, USB modems, CD drives, or DVD drives to the cable modem router USB port.

This chapter contains the following sections:

• USB Storage Device Requirements

• Connect a USB Storage Device to the Cable Modem Router

• Access a USB Device Connected to the Cable Modem Router From a Windows-Based Computer

• Map a USB Device to a Windows Network Drive

• Access a USB Storage Device That Is Connected to the Cable Modem Router From a Mac

• Control Access to the USB Storage Device

• Use FTP Within the Network

• View or Change Network Folders on a USB Storage Device

• Add a Network Folder on a USB Storage Device

• Edit a Network Folder on a USB Storage Device

• Approve USB Devices

• Access the USB Storage Device Through the Internet

• Safely Remove a USB Storage Device

For more information about ReadySHARE® features, visit netgear.com/readyshare.

AC1750 WiFi Cable Modem Router

USB Storage Device Requirements

The cable modem router works with most USB-compliant external flash and hard drives. For the most up-to-date list of USB storage devices that the cable modem router supports, visit https://kb.netgear.com/18985.

Some USB external hard drives and flash drives require you to load the drivers onto the computer before the computer can access the USB device. Such USB devices do not work with the cable modem router.

The cable modem router supports the following file system types for full read/write access:

FAT16

•

FAT32

•

NTFS

•

NTFS with compression format enabled

•

Ext2

•

Ext3

•

Ext4

•

XFS

•

HFS+

•

Connect a USB Storage Device to the Cable Modem Router

ReadySHARE lets you access and share a USB storage device connected to the cable modem router USB port. (If your USB storage device includes special drivers, it is not compatible.)

To connect a USB storage device:

1. Insert your USB storage device into the USB port on the cable modem router.

If your USB storage device uses a power supply, connect it. You must use the power supply when you connect the USB storage device to the

cable modem router.

When you connect the USB storage device to the cable modem router USB port, it might take up to two minutes before it is ready for sharing. By default, the USB storage device is available to all computers on your local area network (LAN).

User Manual39Share USB Devices Attached to

the Cable Modem Router

AC1750 WiFi Cable Modem Router

Access a USB Device Connected to the Cable Modem Router From a Windows-Based Computer

To access a USB storage device from a Windows-based computer:

1. Connect a USB storage device to a USB port on your router.

If your USB storage device uses a power supply, connect it. You must use the power supply when you connect the USB storage device to the

cable modem router.

When you connect the USB storage device to the cable modem router’s port, it might take up to two minutes before it is ready for sharing. By default, the USB storage device is available to all computers on your local area network (LAN).

Select Start > Run.

Enter \\readyshare in the dialog box.

Click the OK button. A window automatically opens and displays the files and folders on the USB storage

device.

Map a USB Device to a Windows Network Drive

To map a USB device to a Windows network drive:

1. Connect a USB storage device to a USB port on the cable modem router.

If your USB storage device uses a power supply, connect it. You must use the power supply when you connect the USB storage device to the

cable modem router.

When you connect the USB storage device to the cable modem router’s port, it might take up to two minutes before it is ready for sharing. By default, the device is available to all computers on your local area network (LAN).

Select Start > Run.

Enter \\readyshare in the dialog box.

the Cable Modem Router

User Manual40Share USB Devices Attached to

AC1750 WiFi Cable Modem Router

Click the OK button.

Right-click the USB device and select Map network drive.

Select the drive letter to map to the new network folder.

Click the Finish button. The USB storage device is mapped to the drive letter that you specified.

To connect to the USB storage device as a different user, select the Connect using different credentials check box, click the Finish button, and do the following:

a. Type the user name and password.

Click the OK button.

Access a USB Storage Device That Is Connected to the Cable Modem Router From a Mac

To access the device from a Mac:

1. Connect a USB storage device to a USB port on your cable modem router.

If your USB storage device uses a power supply, connect it. You must use the power supply when you connect the USB storage device to the

cable modem router.

On a Mac that is connected to the network, select Go > Connect to Server.

In the Server Address field, enter smb://readyshare.

When prompted, select the Guest radio button. If you set up access control on the cable modem router and you allowed your Mac

to access the network, select the Registered User radio button and enter admin for the name and password for the password. For more information about access control, see .

Click the Connect button. A window automatically opens and displays the files and folders on the USB storage

device.

User Manual41Share USB Devices Attached to

the Cable Modem Router

AC1750 WiFi Cable Modem Router

Control Access to the USB Storage Device

You can specify the device name, workgroups, and network folders for your USB device.

To specify the USB access settings:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

>Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > USB Storage > Advanced Settings. The USB Storage (Advanced Settings) page displays.

Specify access to the USB storage device:

Network Device Name. This is the name used to access the USB device

•

connected to the cable modem router. The default is readyshare.

Workgroup. If you are using a Windows workgroup rather than a domain, the

•

workgroup name is displayed here. The name works only in an operating system that supports NetBIOS, such as Microsoft Windows.

Access Method. Select the check boxes for the access methods that you want:

•

Network Neighborhood/MacShare. Enabled by default.

HTTP. Enabled by default. You can type http://readyshare.routerlogin.net/shares to access the USB storage device.

HTTP (via Internet). Disabled by default. If you enable this feature, remote users can type http:// <public IP address/shares> (for example,http://1.1.10.102/shares) or a URL domain name to access the USB storage device over the Internet. This feature supports file uploading only.

FTP. Disabled by default.

FTP (via Internet). Disabled by default. If you select this check box, remote users can access the USB storage device through FTP over the Internet. This feature supports both downloading and uploading of files.

the Cable Modem Router

User Manual42Share USB Devices Attached to

AC1750 WiFi Cable Modem Router

If you changed the settings, click the Apply button. Your settings are saved.

Use FTP Within the Network

File Transfer Protocol (FTP) lets you send and receive large files faster.

To set up FTP access:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > USB Storage > Advanced Settings. The USB Storage (Advanced Settings) page displays.

Select the FTP check box.

Click the Apply button. Your settings are saved.

View or Change Network Folders on a USB Storage Device

You can view or change the network folders on the USB storage device.

To view or change network folders:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

User Manual43Share USB Devices Attached to

the Cable Modem Router

AC1750 WiFi Cable Modem Router

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > USB Storage > Advanced Settings. The USB Storage (Advanced Settings) page displays.

Scroll down to the Available Networks Folder section, and view or adjust the following settings:

Share Name. If only one device is connected, the default share name is

•

USB_Storage. (Some cable modem router models include more than one USB port.) You can click the name, or you can type it in the address field of your web browser. If Not Shared is shown, the default share was deleted, and no other share for the root folder exists. Click the link to change this setting.

Read Access and Write Access. Show the permissions and access controls on

•

the network folder. All-no password (the default) allows all users to access the network folder. The password for admin is the same one that you use to log in to the cable modem router.

Folder Name. Full path of the network folder.

•

Volume Name. Volume name from the storage device (either USB storage device

•

or HDD).

Total Space and Free Space. Show the current utilization of the storage device.

•

Add a Network Folder on a USB Storage Device

You can add network folders on the USB storage device.

To add a network folder:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password.

the Cable Modem Router

User Manual44Share USB Devices Attached to

AC1750 WiFi Cable Modem Router

The user name is admin. The password is the one that you specified the first time that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > USB Storage > Advanced Settings. The USB Storage (Advanced Settings) page displays.

Click the Create Network Folder button. The Create network Folder window opens.

If this window does not open, your web browser might be blocking pop-ups. If it is, change the browser settings to allow pop-ups.

In the USB Device menu, select the USB storage device.

Click the Browse button and in the Folder field, select the folder.

In the Share Name field, type the name of the share.

In the Read Access menu and the Write Access menu, select the settings that you want.

The user name (account name) for All-no password is guest. The password for admin is the same one that is used to log in to the cable modem router. By default, it is password.

10.

Click the Apply button. Your settings are saved.

Edit a Network Folder on a USB Storage Device

You can edit network folders on the USB storage device.

To edit a network folder:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

User Manual45Share USB Devices Attached to

the Cable Modem Router

AC1750 WiFi Cable Modem Router

The BASIC Home page displays.

Select ADVANCED > USB Storage > Advanced Settings. The USB Storage (Advanced Settings) page displays.

Click the Edit button. The Edit Network Folder page displays the same settings shown in the Add a Network

Folder page.

Change the settings in the fields as needed.

Click the Apply button. Your settings are saved.

Approve USB Devices

For more security, you can set up the cable modem router to share only USB devices that you approve.

To approve USB devices:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > USB Settings. The USB Settings page displays.

By default the Enable any USB Device connection to the USB port radio button is selected. This setting lets you connect and access all your USB storage devices.

Select the No radio button.

Click the Approved Devices button. The approved and available USB devices display.

In the Available USB Devices menu, select the drive that you want to approve.

the Cable Modem Router

User Manual46Share USB Devices Attached to

AC1750 WiFi Cable Modem Router

Click the Add button.

Select the Allow only approved devices check box.

10.

Click the Apply button. Your settings are saved.

11.

To work with another USB device, first click the Safely Remove USB Device button for the currently connected USB device.

12. Connect the other USB device, and repeat this process.

Access the USB Storage Device Through the Internet

You can access the USB storage device through the Internet when you’re not home.

To access the USB storage device from a remote computer:

1. Launch a web browser on a computer that is not on your home network.

2. Connect to your cable modem router:

To connect with Dynamic DNS, type the DNS name.

•

To use a Dynamic DNS account, you must enter the account information in the Dynamic DNS page. See Set Up and Manage Dynamic DNS on page 86.

To connect without Dynamic DNS, type the cable modem router’s Internet port

•

IP address.

You can view the cable modem router’s Internet IP address on the BASIC Home page.

You can use FTP to share files on a USB storage device connected to the cable modem router.

the Cable Modem Router

User Manual47Share USB Devices Attached to

AC1750 WiFi Cable Modem Router

Set Up FTP Access Through the Internet

To set up FTP access:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > USB Storage > Advanced Settings. The USB Storage (Advanced Settings) page displays.

Select the FTP (via Internet) check box.

Click the Apply button. Your settings are saved.

To limit access to the admin user, click the Edit button. The Edit Network Folder page displays.

In the Read Access menu, select admin.

In the Write Access menu, select admin.

10.

Click the Apply button. Your settings are saved.

Access the USB Storage Device Through the Internet With FTP

You must first set up FTP access through the Internet as described in the previous section.

To access the USB storage device with FTP from a remote computer:

1. To download, launch an Internet browser.

To upload, use an FTP client such as filezilla.

Type ftp:// and the Internet port IP address in the address field of the browser. For example, type ftp://10.1.65.4.

the Cable Modem Router

User Manual48Share USB Devices Attached to

AC1750 WiFi Cable Modem Router

If you are using Dynamic DNS, type the DNS name.

For example, type ftp://MyName.mynetgear.com.

4. When prompted, log in:

To log in as admin, in the user name field, type admin and in the password field,

•

type the same password that you use to log in to the cable modem router.

To log in as guest, in the user name field, enter guest.

•

The guest user name does not require a password. To restrict access to the USB storage device, you can specify that only the admin user can access it. See Approve USB Devices on page 46. The files and folders of the USB storage device that your account can access to display. For example, you might see share/partition1/directory1.

Safely Remove a USB Storage Device

Before you physically disconnect a USB storage device from the cable modem router USB port, log in to the cable modem router and take the device offline.

To remove a USB storage device safely:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > USB Storage > Advanced Settings. The USB Storage (Advanced Settings) page displays.

Click the Safely Remove USB Device button. This takes the device offline.

6. Physically disconnect the USB storage device.

the Cable Modem Router

User Manual49Share USB Devices Attached to

Share a USB Printer

The ReadySHARE Printer utility lets you share a USB printer that is connected to a USB port on your cable modem router. You can share this USB printer among the Windows-based and Mac computers on your network.

For more information about the features available in the NETGEAR USB Control Center, see the ReadySHARE Printer User Manual, which is available at

http://downloadcenter.netgear.com.

This chapter contains the following sections:

• Install the Printer Driver and Cable the Printer

• Download the ReadySHARE Printer Utility

• Install the ReadySHARE Printer Utility

• Print Using the NETGEAR USB Control Center

AC1750 WiFi Cable Modem Router

Install the Printer Driver and Cable the Printer

Some USB printer manufacturers (for example, HP and Lexmark) request that you do not connect the USB cable until the installation software prompts you to do so.

To install the driver and cable the printer:

1. On each computer on your network that shares the USB printer, install the driver software for the USB printer.

If you cannot find the printer driver, contact the printer manufacturer.

2. Use a USB printer cable to connect the USB printer to a cable modem router USB port.

Download the ReadySHARE Printer Utility

The utility works on Windows-based and Mac computers.

To download the utility:

1. Visit netgear.com/readyshare.

Scroll down to the Print From the Comfort of Your Home Network section at the bottom of the page.

Click one of the following links:

Download PC installer and get started. This is the utility for Windows-based

•

computers.

Download Mac installer and get started. This is the utility for MAC computers.

•

4. Follow the onscreen instructions to download the ReadySHARE Printer utility setup file and install it.

Install the ReadySHARE Printer Utility

You must install the ReadySHARE Printer utility on each computer that will share the printer. After you install it, the utility displays as NETGEAR USB Control Center on your computer. For more information about how to use the NETGEAR USB Control Center, visit https://www.netgear.com/support/product/ReadySHARE_USB_Printer.aspx.

User Manual51Share a USB Printer

AC1750 WiFi Cable Modem Router

To install the utility:

If necessary, unzip the ReadySHARE Printer utility setup file.

Double-click the ReadySHARE Printer utility setup file that you downloaded. The InstallShield Wizard opens.

3. Follow the prompts to install NETGEAR USB Control Center. After the InstallShield Wizard completes the installation, the NETGEAR USB Control

Center prompts you to select a language.

Select a language from the menu and click the OK button. The NETGEAR USb Control Center opens.

Some firewall software, such as Comodo, blocks NETGEAR USB Control Center from accessing the USB printer. If you do not see the USB printer displayed onscreen, you can disable the firewall temporarily to allow the utility to work.

Select the printer and click the Connect button. The printer status changes to Manually connected by Mycomputer. Now only the

computer that you are using can use this printer.

Click the Disconnect button. The status changes to Available. Now all computers on the network can use the

printer.

To exit the utility, select System > Exit.

Print Using the NETGEAR USB Control Center

For each computer, after you click the Connect and Disconnect buttons once, the utility automatically manages the printing queue and handling. By default, the utility starts

automatically whenever you log on to Windows and runs in the background.

To print a document using the NETGEAR USB Control Center:

Click the NETGEAR USB Control Center icon . The NETGEAR USB Control Center page displays.

Select a printer and click the Connect button. The printer status changes to Manually connected by Mycomputer. Now only the

computer that you are using can use this printer.

User Manual52Share a USB Printer

AC1750 WiFi Cable Modem Router

Use the print feature in your application to print your document. The NETGEAR USB Control Center automatically connects your computer to the

USB printer and prints the document. If another computer is already connected to the printer, your print job goes into a queue to wait to be printed.

If your document does not print, use the NETGEAR USB Control Center to check the printer status.

5. To release the printer so that all computers on the network can use it, click the Disconnect button.

The status changes to Available. Now any computers on the network can use the printer.

To exit the utility, select System > Exit.

User Manual53Share a USB Printer

Specify Network Settings

This chapter includes the following sections:

• View or Change the WAN Settings

• Set Up a Default DMZ Server

• Change the Cable Modem Router’s Device Name

• Change the LAN TCP/IP Settings

• Specify the IP Addresses That the Cable Modem Router Assigns

• Disable the DHCP Server Feature in the Cable Modem Router

• Manage LAN IP Addresses

• Improve Network Connections With Universal Plug-N-Play

• Use the WPS Wizard for WiFi Connections

• Specify Basic WiFi Settings

• Change the WiFi Security Option

• Set Up a Guest Network

• Control the WiFi Radios

• Specify WPS Settings

• Enable or Disable Router Mode

AC1750 WiFi Cable Modem Router

View or Change the WAN Settings

You can view or configure wide area network (WAN) settings for the Internet port. You can set up a DMZ (demilitarized zone) server, change the maximum transmit unit (MTU) size, and enable the cable modem router to respond to a ping to its WAN (Internet) port.

To view or change the WAN settings:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Setup > WAN Setup. The WAN Setup page displays.

View or change the following settings:

Disable IPv4 Firewall Protection. We recommend that you leave this check box

•

cleared so that the firewall protects your cable modem router.

Disable Port Scan and DoS Protection. DoS protection protects your LAN against

•

denial of service attacks such as Syn flood, Smurf Attack, Ping of Death, and many others. Select this check box only in special circumstances.

Default DMZ Server. This feature is disabled by default. It is sometimes helpful

•

when you are playing online games or videoconferencing, but it makes the firewall security less effective. See Set Up a Default DMZ Server on page 56.

Respond to Ping on Internet Port. This feature allows your cable modem router

•

to be discovered. Use this feature only as a diagnostic tool or for a specific reason.

MTU Size (in bytes). The normal MTU (maximum transmit unit) value for most

•

Ethernet networks is 1500 bytes, or 1492 bytes for PPPoE connections. Change the MTU only if you are sure that it is necessary for your ISP connection. See .

Disable SIP ALG. Some VoIP applications do not work well with the SIP ALG.

•

Selecting this check box to turn off the SIP ALG might help your VoIP devices to create or accept a call through the cable modem router.

User Manual55Specify Network Settings

AC1750 WiFi Cable Modem Router

Click the Apply button. Your settings are saved.

Set Up a Default DMZ Server

The default DMZ server feature is helpful when you are using some online games and videoconferencing applications that are incompatible with Network Address Translation (NAT). The cable modem router is programmed to recognize some of these applications and to work correctly with them, but other applications might not function well. In some cases, one local computer can run the application correctly if the IP address for that computer is entered as the default DMZ server.

Warning: DMZ servers pose a security risk. A computer designated as the default DMZ

server loses much of the protection of the firewall and is exposed to exploits from the Internet. If compromised, the DMZ server computer can be used to attack other computers on your network.

The cable modem router usually detects and discards incoming traffic from the Internet that is not a response to one of your local computers or a service that you configured in the Port Forwarding/Port Triggering page. Instead of discarding this traffic, the cable modem router can forward the traffic to one computer on your network. This computer is called the default DMZ server.

To set up a default DMZ server:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Setup > WAN Setup. The WAN Setup page displays.

Select the Default DMZ Server check box.

6. Type the IP address.

Click the Apply button.

User Manual56Specify Network Settings

AC1750 WiFi Cable Modem Router

Your settings are saved.

Change the Cable Modem Router’s Device Name

The cable modem router’s device name is the cable modem router model number. This device name displays in a file manager when you browse your network.

To change the cable modem router’s device name:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Setup > LAN Setup. The LAN Setup page displays.

In the Device Name field, type a new name.

Click the Apply button. Your settings are saved.

Change the LAN TCP/IP Settings

The cable modem router is preconfigured to use private IP addresses on the LAN side and to act as a DHCP server. The cable modem router’s default LAN IP configuration is as follows:

•

LAN IP address. 192.168.0.1

•

Subnet mask. 255.255.255.0

User Manual57Specify Network Settings

AC1750 WiFi Cable Modem Router

These addresses are part of the designated private address range for use in private networks and are suitable for most applications. If your network requires a different IP addressing scheme, you can change these settings.

You might want to change these settings if you need a specific IP subnet that one or more devices on the network uses, or if you use competing subnets with the same IP scheme.

To change the LAN TCP/IP settings:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Setup > LAN Setup. The LAN Setup page displays.

In the IP Address field, type the IP address.

In the IP Subnet Mask, type the subnet mask of the cable modem router. The IP address and subnet mask identify which addresses are local to a specific

device and which must be reached through a gateway or cable modem router.

Click the Apply button. Your settings are saved.

If you changed the LAN IP address of the cable modem router, you are disconnected when this change takes effect.

8. To reconnect, close your browser, relaunch it, and log in to the cable modem router.

Specify the IP Addresses That the Cable Modem Router Assigns

By default, the cable modem router acts as a Dynamic Host Configuration Protocol (DHCP) server. The cable modem router assigns IP, DNS server, and default gateway

User Manual58Specify Network Settings

AC1750 WiFi Cable Modem Router

addresses to all computers connected to the LAN. The assigned default gateway address is the LAN address of the cable modem router.

These addresses must be part of the same IP address subnet as the cable modem router’s LAN IP address. Using the default addressing scheme, define a range between

192.168.0.2 and 192.168.0.254, although you can save part of the range for devices

with fixed addresses.

To specify the pool of IP addresses that the cable modem router assigns:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Setup > LAN Setup. The LAN Setup page displays.

Make sure that the Use Router as DHCP Server check box is selected.

Specify the range of IP addresses that the cable modem router assigns: a.

In the Starting IP Address field, type the lowest number in the range. This IP address must be in the same subnet as the cable modem router.

In the Ending IP Address field, type the number at the end of the range of IP addresses.

This IP address must be in the same subnet as the cable modem router.

Click the Apply button. Your settings are saved.

The cable modem router delivers the following parameters to any LAN device that requests DHCP:

An IP address from the range that you defined

•

Subnet mask

•

Gateway IP address (the cable modem router’s LAN IP address)

•

DNS server IP address (the cable modem router’s LAN IP address)

•

User Manual59Specify Network Settings

AC1750 WiFi Cable Modem Router

Disable the DHCP Server Feature in the Cable Modem Router

By default, the cable modem router acts as a DHCP server. The cable modem router assigns IP, DNS server, and default gateway addresses to all computers connected to the LAN. The assigned default gateway address is the LAN address of the cable modem router.

You can use another device on your network as the DHCP server, or specify the network settings of all your computers.

To disable the DHCP server feature in the modem router:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Setup > LAN Setup. The LAN Setup page displays.

Clear the Use Router as DHCP Server check box.

Click the Apply button.

(Optional) If this service is disabled and no other DHCP server is on your network, set your computer IP addresses manually so that they can access the cable modem router.

Manage LAN IP Addresses

When you specify a reserved IP address for a computer on the LAN, that computer always receives the same IP address each time it accesses the cable modem router’s DHCP server. Assign reserved IP addresses to computers or servers that require permanent IP settings.

User Manual60Specify Network Settings

AC1750 WiFi Cable Modem Router

Reserve an IP Address

To reserve an IP address:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Setup > LAN Setup. The LAN Setup page displays.

In the Address Reservation section, click the Add button.

In the IP Address field, type the IP address to assign to the computer or server. Choose an IP address from the cable modem router’s LAN subnet, such as

192.168.0.x.

Type the MAC address of the computer or server.

Tip: If the computer is already on your network, you can copy its MAC address from the Attached Devices page and paste it here.

Click the Apply button. The reserved address is entered into the table.

The reserved address is not assigned until the next time the computer contacts the cable modem router’s DHCP server. Reboot the computer, or access its IP configuration and force a DHCP release and renew.

Edit a Reserved IP Address Entry

To edit a reserved IP address entry:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password.

User Manual61Specify Network Settings

AC1750 WiFi Cable Modem Router

The user name is admin. The password is the one that you specified the first time that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Setup > LAN Setup. The LAN Setup page displays.

5. Select the radio button next to the reserved address.

Click the Edit button.

7. Change the settings.

Click the Apply button. Your settings are saved.

Delete a Reserved IP Address Entry

To delete a reserved IP address entry:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Setup > LAN Setup. The LAN Setup page displays.

5. Select the radio button next to the reserved address.

Click the Delete button. The address is removed.

User Manual62Specify Network Settings

AC1750 WiFi Cable Modem Router

Improve Network Connections With Universal Plug-N-Play

Universal Plug-N-Play (UPnP) helps devices, such as Internet appliances and computers, access the network and connect to other devices as needed. UPnP devices can automatically discover the services from other registered UPnP devices on the network.

If you use applications such as multiplayer gaming, peer-to-peer connections, or real-time communications such as instant messaging or remote assistance (a feature in Windows XP), enable UPnP.

To enable Universal Plug and Play:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > UPnP. The UPnP page displays.

Select the Turn UPnP On check box. By default, the Turn UPnP On check box is selected. UPnP for automatic device

configuration can be enabled or disabled. If the Turn UPnP On check box is cleared, the cable modem router does not allow any device to automatically control cable modem router resources, such as port forwarding.

6. Type the advertisement period in minutes. The advertisement period specifies how often the cable modem router broadcasts

its UPnP information. This value can range from 1 to 1440 minutes. The default period is 30 minutes. Shorter durations ensure that control points receive current device status at the expense of more network traffic. Longer durations can compromise the freshness of the device status, but can significantly reduce network traffic.

7. Type the advertisement time to live in hops. The time to live for the advertisement is measured in hops (steps) for each UPnP

packet sent. Hops are the steps a packet takes between routers. The number of hops

User Manual63Specify Network Settings

AC1750 WiFi Cable Modem Router

can range from 1 to 255. The default value for the advertisement time to live is 4 hops, which is fine for most home networks. If you notice that some devices are not being updated or reached correctly, it might be necessary to increase this value.

Click the Apply button. The UPnP Portmap Table displays the IP address of each UPnP device that is accessing

the cable modem router and which ports (internal and external) that device opened. The UPnP Portmap Table also displays what type of port is open and whether that port is still active for each IP address.

To refresh the information in the UPnP Portmap Table, click the Refresh button.

Use the WPS Wizard for WiFi Connections

The WPS Wizard helps you add a computer or mobile device to your WiFi network without typing the WiFi password.

To use the WPS Wizard:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > WPS Wizard. A page displays that explains WPS.

Click the Next button. The WPS page displays.

Select the radio button for the setup method that you want to use:

Push button. Click the WPS button on this page.

•

PIN Number. The page adjusts. Enter the client security PIN, and click the Next

•

button.

Within two minutes, go to the client device and use its WPS software to connect to the WiFi network.

User Manual64Specify Network Settings

AC1750 WiFi Cable Modem Router

The WPS process automatically sets up your computer or mobile device with the network password when it connects. The cable modem router WPS page displays a confirmation message.

Specify Basic WiFi Settings

The cable modem router comes with preset security. This means that the WiFi network name (SSID), network key (password), and security option (encryption protocol) are preset in the factory. You can find the preset SSID and password on the cable modem router label.

The preset SSID and password are uniquely generated for every device to protect and maximize your WiFi security.

If you change your preset security settings, make a note of the new settings and store it in a safe place where you can easily find it.

If you use a WiFi connection to change the WiFi network name (SSID) or other WiFi security settings, you are disconnected when you click the Apply button. To avoid this problem, use a computer with a wired connection to access the cable modem router.

To specify basic WiFi settings:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select Wireless. The Wireless Setup page displays.

In the Region menu, select your region. In some locations, you cannot change this setting.

To control the SSID broadcast, select or clear the Enable SSID Broadcast check box.

When this check box is selected, the cable modem router broadcasts its network name (SSID) so that it displays when you scan for local WiFi networks on your computer or mobile device.

User Manual65Specify Network Settings

AC1750 WiFi Cable Modem Router

To change the network name (SSID), type a new name in the Name (SSID) field. The name can be up to 32 characters long and it is case-sensitive. The default SSID

is randomly generated and is on the cable modem router label. If you change the name, make sure to write down the new name and keep it in a safe place.

To change the WiFi channel, select a number in the Channel menu. In some regions, not all channels are available. Do not change the channel unless

you experience interference (shown by lost connections or slow data transfers). If this happens, experiment with different channels to see which is the best.

When you use multiple access points, it is better if adjacent access points use different channels to reduce interference. The recommended channel spacing between adjacent access points is four channels (for example, use Channels 1 and 5, or 6 and

10).

To change the mode, select it from the Mode menu.

10.

Click the Apply button. Your settings are saved.

If you used WiFi to connect to the network and you changed the SSID, you are disconnected from the network.

11. Make sure that you can connect to the WiFi network with the new settings. If you cannot connect with WiFi, check the following:

Is your computer or mobile device connected to another WiFi network in your

•

area? Some computers and mobile devices automatically connect to the first open network without WiFi security that they discover.

Is your computer or mobile device trying to connect to your network with its old

•

settings (before you changed the settings)? If so, update the WiFi network selection in your computer or mobile device to match the current settings for your network.

Change the WiFi Security Option

Your cable modem router comes with preset WPA2 or WPA security. The password that you enter to connect to your network is unique to your cable modem router and is on the cable modem router label. We recommend that you do not disable security.

User Manual66Specify Network Settings

AC1750 WiFi Cable Modem Router

To change the WPA settings:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select Wireless. The Wireless page displays.

5. Under Security Options, select a WPA option. The WPA2 options use the newest standard for the strongest security, but some

older computers and mobile devices cannot use WPA2. This setting protects your WiFi network and lets computers and mobile devices connect to the WiFi network by using either WPA2 or WPA security.

The Passphrase field displays.

In the Passphrase field, enter the network key (password) that you want to use. It is a text string from 8 to 63 characters.

Write down the new password and keep it in a secure place for future reference.

Click the Apply button. Your settings are saved.

Set Up a Guest Network

A guest network allows visitors at your home to use the Internet without using your WiFi security key. You can add a guest network to each WiFi network: 2.4 GHz b/g/n and 5.0 GHz a/n.

To set up a guest network:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

User Manual67Specify Network Settings

AC1750 WiFi Cable Modem Router

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select Guest Network. The Guest Network Settings page displays.

Select any of the following settings:

Enable Guest Network. When this check box is selected, the guest network is

•

enabled, and guests can connect to your network using the SSID of this profile.

Enable SSID Broadcast. If this check box is selected, the WiFi access point

•

broadcasts its name (SSID) to all WiFi stations. Stations with no SSID can adopt the correct SSID for connections to this access point.

Allow guests to see each other and access my local network. If this check box

•

is selected, anyone who connects to this SSID can access your local network, not just the Internet.

6. Give the guest network a name. The guest network name is case-sensitive and can be up to 32 characters. You then

manually configure the computers and mobile devices in your network to use the guest network name in addition to the main SSID.

7. Select a security option. The WPA2 options use the newest standard for the strongest security, but some

older computers and mobile devices cannot use it. We recommend that you select the WPA-PSK [TKIP] + WPA2-PSK [AES] radio button. This setting protects your WiFi network and lets computers and mobile devices can connect to the WiFi network by using either WPA2 or WPA security.

Click the Apply button. Your settings are saved.

Control the WiFi Radios

The cable modem router’s internal WiFi radios broadcast signals in the 2.4 GHz and 5 GHz ranges. By default, they are on so that you can use WiFi to connect to the cable modem router. When the WiFi radios are off, you can still use an Ethernet cable for a LAN connection to the cable modem router.

User Manual68Specify Network Settings

AC1750 WiFi Cable Modem Router

You can turn the WiFi radios on and off with the WiFi On/Off button on the cable modem router, or you can log in to the cable modem router and enable or disable the WiFi radios. If you are close to the cable modem router, it might be easier to press its WiFi On/Off button. If you are away from the cable modem router or you already logged in, it might be easier to enable or disable them. You can also turn the WiFi radios off and on based on a schedule. (See Set Up a WiFi Schedule on page ?).

Use the WiFi On/Off Button

To turn the WiFi radios off and on with the WiFi On/Off button:

Press the WiFi On/Off button on the front of the cable modem router for two seconds.

If you turned off the WiFi radios, the WiFi On/Off LED and the WPS LED turn off. If you turned on the WiFi radios, the WiFi On/Off LED and the WPS LED light.

Enable or Disable the WiFi Radios

If you used the WiFi On/Off button to turn off the WiFi radios, you can’t log in to the cable modem router to turn them back on. You must press the WiFi On/Off button again for two seconds to turn the WiFi radios back on.

To enable or disable the WiFi radios:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > Wireless Settings. The Wireless Settings page displays.

Select or clear the Enable Wireless Gateway Radio check boxes in the 2.4 GHz and 5 GHz sections of the page.

Clearing this check box turns off the WiFi feature of the cable modem router.

Click the Apply button.

User Manual69Specify Network Settings

AC1750 WiFi Cable Modem Router

If you turned off both WiFi radios, the WiFi On/Off LED and the WPS LED turn off. If you turned on the WiFi radios, the WiFi On/Off LED and the WPS LED light.

Specify WPS Settings

Wi-Fi Protected Setup (WPS) lets you join the WiFi network without typing the WiFi password.

To specify WPS settings:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > Wireless Settings. The Advanced Wireless Settings page displays.

The Gateway’s PIN field displays the fixed PIN that you can use to configure the cable modem router’s WiFi settings from another device through WPS.

(Optional) Select or clear the Disable Router’s PIN check box. The PIN function might temporarily be disabled when the cable modem router

detects suspicious attempts to break into the cable modem router’s WiFi settings by using the cable modem router’s PIN through WPS. You can manually enable the PIN function by selecting the Disable Router’s PIN check box.

Click the Apply button. Your settings are saved.

Enable or Disable Router Mode

Your can enable router mode if you want to use your cable modem router as a cable modem and router. If you want use your cable modem router as a cable modem and connect another router, disable router mode.

User Manual70Specify Network Settings

AC1750 WiFi Cable Modem Router

To enable or disable router mode:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Router Mode. The Router Mode page displays.

5. Enable or disable router mode:

To enable router mode, select the Yes radio button.

•

To disable router mode, select the No radio button.

•

Click the Apply button. Your settings are saved.

User Manual71Specify Network Settings

Manage Your Network

This chapter describes the cable modem router settings for administering and maintaining your cable modem router and home network.

The chapter includes the following sections:

• Change the admin Password

• Set Up Password Recovery

• Recover the admin Password

• View Modem Router Status

• View Logs of Cable Modem Router Activity

• View Event Logs

• Run the Ping Utility

• Run the Traceroute Utility

• Monitor Internet Traffic

• View Devices Currently on the Network

• Manage the Cable Modem Router Configuration File

• View or Change the Cable Modem Router WiFi Channel

• Set Up and Manage Dynamic DNS

• Remote Management

AC1750 WiFi Cable Modem Router

Change the admin Password

You can change the admin password that is used to log in to the cable modem router with the user name admin. This password is not the one that you use for WiFi access. The cable modem router label shows your unique WiFi network name (SSID) and password for WiFi access.

Note: Be sure to change the password for the user name admin to a secure password. The ideal password contains no dictionary words from any language and contains

uppercase and lowercase letters, numbers, and symbols. It can be up to 30 characters.

To set the password for the user name admin:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Set Password. The Set Password page display.

5. Type the old password, and type the new password twice. We recommend that you enable password recovery. See Set Up Password Recovery

on page 73.

Click the Apply button. Your settings are saved.

Set Up Password Recovery

We recommend that you enable password recovery if you change the password for the cable modem router admin user name. Then you can recover the password if it is forgotten. This recovery process is supported in Internet Explorer, Firefox, and Chrome browsers but not in the Safari browser.

User Manual73Manage Your Network

AC1750 WiFi Cable Modem Router

To set up password recovery:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified. The user name

and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Set Password. The Set Password page displays.

Select the Enable Password Recovery check box.

6. Select two security questions and provide answers to them.

Click the Apply button. Your settings are saved.

Recover the admin Password

To recover your password:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

Click the Cancel button. If password recovery is enabled, you are prompted to enter the serial number of the

cable modem router.

Enter the serial number of the cable modem router. The serial number is on the cable modem router label.

Click the Continue button. A window opens requesting the answers to your security questions.

6. Enter the answers to the security questions.

User Manual74Manage Your Network

AC1750 WiFi Cable Modem Router

Click the Continue button. A window opens and displays your recovered password.

Click the Login again button. A login window opens.

9. With your recovered password, log in to the cable modem router.

View Modem Router Status

To view cable modem router status and usage information:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Click the ADVANCED tab. The ADVANCED Home page displays information about your cable modem router.

For information about the displayed settings, click the Show/Hide Help Center link at the bottom of the page.

User Manual75Manage Your Network

AC1750 WiFi Cable Modem Router

Display Internet Port Statistics

To display Internet port statistics:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Click the ADVANCED tab. The Advanced page displays.

In the Internet Port pane, click the Show Statistics button. The Show Statistics window displays the following information:

System Up Time. The time elapsed since the cable modem router was last

•

restarted.

Port. The statistics for the WAN (Internet) and LAN (Ethernet) ports. For each

•

port, the page displays the following:

Status. The link status of the port.

TxPkts. The number of packets transmitted on this port since reset or manual clear.

RxPkts. The number of packets received on this port since reset or manual clear.

Collisions. The number of collisions on this port since reset or manual clear.

Tx B/s. The current transmission (outbound) bandwidth used on the WAN and LAN ports.

Rx B/s. The current reception (inbound) bandwidth used on the WAN and LAN ports.

Up Time. The time elapsed since this port acquired the link.

Poll Interval. The interval at which the statistics are updated in this page.

To change the polling frequency, enter a time in seconds in the Poll Interval field and click the Set Interval button.

User Manual76Manage Your Network

AC1750 WiFi Cable Modem Router

To stop the polling entirely, click the Stop button.

Check the Internet Connection Status

To check the Internet connection status:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Click the ADVANCED tab. The Advanced page displays.

In the Internet Port pane, click the Connection Status button. The Connection Satus window displays the following information:

IP Address. The IP address that is assigned to the cable modem router.

•

Subnet Mask. The subnet mask that is assigned to the cable modem router.

•

Default Gateway. The IP address for the default gateway that the cable modem

•

router communicates with.

DHCP Server. The IP address for the Dynamic Host Configuration Protocol server

•

that provides the TCP/IP configuration for all the computers that are connected to the cable modem router.

DNS Server. The IP address of the Domain Name Service server that provides

•

translation of network names to IP addresses.

Lease Obtained. The date and time when the lease was obtained.

•

Lease Expires. The date and time that the lease expires.

•

To return the status of all items to 0, click the Release button.

To refresh the window, click the Renew button.

To exit, click the Close Window button.

User Manual77Manage Your Network

AC1750 WiFi Cable Modem Router

View Logs of Cable Modem Router Activity

The log is a detailed record of the websites you accessed or attempted to access and other cable modem router actions. Up to 256 entries are stored in the log. Log entries display only when keyword blocking is enabled, and no log entries are made for the trusted user.

To view logs:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Logs. The Logs page displays the following information:

Date and time. The date and time the log entry was recorded.

•

Source IP. The IP address of the initiating device for this log entry.

•

Target address. The name or IP address of the website or news group visited or

•

to which access was attempted.

Action. The action that occurred, such as whether Internet access was blocked

•

or allowed.

To customize the log, scroll down to view the bottom of the page and clear or select the check boxes.

To refresh the log page, click the Refresh button.

To clear the log entries, click the Clear Log button.

To email the log immediately, click the Send Log button.

View Event Logs

Event logs capture important cable modem router events.

User Manual78Manage Your Network

AC1750 WiFi Cable Modem Router

To view the event logs:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Event Log. The Event Log page displays the following information:

Time. The time the event was recorded.

•

Priority. The severity for this event.

•

Description. A description of this event.

•

To refresh the page, click the Refresh button.

To clear the log entries, click the Clear Log button.

Run the Ping Utility

Ping is an administration utility that tests whether a computer on the network is reachable and measures the time it takes messages sent from the originating device to reach a destination computer and return.

To run a ping test:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Diagnostics.

User Manual79Manage Your Network

AC1750 WiFi Cable Modem Router

The Diagnostics page displays.

In the Utility menu, Ping is selected by default.

Select the Ping Test Parameters IPv4 or IPv6 radio button.

Specify the following parameters for the ping utility:

Target. The IP address of the ping target computer.

•

Ping Size. The size (in bytes) of the ping packet.

•

No. of Pings. The number of times to ping the target computer. The maximum

•

number of pings is 128.

Ping Interval. The time between pings.

•

Click the Start Test button. The ping results display.

To stop a ping test, click the Abort Test button.

To clear the results from the display, click the Clear Results button.

Run the Traceroute Utility

To display the route and measure transit delays of packets across an IP, run the traceroute utility.

To run a traceroute test:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Diagnostics. The Diagnostics page displays.

In the Utility menu, select Traceroute.

User Manual80Manage Your Network

AC1750 WiFi Cable Modem Router

Specify the following parameters for the traceroute utility:

Target. The IP address or host name of the computer you are tracing.

•

Max Hops. The maximum number of hops to allow when tracing the route.

•

Data Size. The input the size (in bytes) of the packet.

•

Base Port. The port number to send the packet to.

•

Resolve Host. Select On to resolve the host name to the IP address.

•

Click the Start Test button. The traceroute results display.

To clear the results from the display, click the Clear Results button.

Monitor Internet Traffic

Traffic metering allows you to monitor the volume of Internet traffic that passes through the cable modem router Internet port. You can set limits for traffic volume.

To monitor Internet traffic:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > Traffic Meter. The Traffic Meter page displays.

Select the Enable Traffic Meter check box.

User Manual81Manage Your Network

AC1750 WiFi Cable Modem Router

To control the volume of Internet traffic, use either the traffic volume control feature or the connection time control feature:

Select the Traffic volume control by radio button and then select one of the

•

following options:

No Limit. No restriction is applied when the traffic limit is reached.

Download only. The restriction is applied to incoming traffic only.

Both Directions. The restriction is applied to both incoming and outgoing traffic.

Select the Connection time control radio button and enter the allowed hours

•

in the Monthly limit field.

If your ISP charges for extra data volume when you make a new connection, enter the extra data volume in MB in the Round up data volume for each connection by field.

In the Traffic Counter section, set the traffic counter to begin at a specific time and date.

To start the traffic counter immediately, click the Restart Counter Now button.

In the Traffic Control section, enter a value in minutes to specify when the cable modem router issues a warning message before the monthly limit of Mbytes or hours is reached.

By default, the value is 0 and no warning message is issued. Select one of the following to occur when the limit is attained:

The Internet LED blinks green or amber.

•

The Internet connection is disconnected and disabled.

•

10.

Click the Apply button. The Internet Traffic Statistics section helps you to monitor the data traffic.

11.

To update the Traffic Statistics section, click the Refresh button.

12.

To display more information about the data traffic on your cable modem router and to change the poll interval, click the Traffic Status button.

View Devices Currently on the Network

You can view all computers or devices that are currently connected to your network.

User Manual82Manage Your Network

AC1750 WiFi Cable Modem Router

To view devices on the network:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select Attached Devices. The Attached Devices page displays.

The Wired Devices section lists devices that are connected to the cable modem router with Ethernet cables. The Wireless Devices section lists devices that are connected to the WiFi network. The following information is displayed:

Status. The status of the device, Allowed or Blocked.

•

Device Name. If the device name is known, it is shown here.

•

IP Address. The IP address that the cable modem router assigned to this device

•

when it joined the network. This number can change if a device is disconnected and rejoins the network.

MAC Address. The unique MAC address for each device does not change. The

•

MAC address is typically shown on the product label.

To update this page, click the Refresh button.

Manage the Cable Modem Router Configuration File

The configuration settings of the cable modem router are stored within the cable modem router in a configuration file. You can back up (save) this file to your computer, restore it, or reset it to the factory default settings.

User Manual83Manage Your Network

AC1750 WiFi Cable Modem Router

Back Up Settings

To back up the cable modem router’s configuration settings:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Backup Settings. The Backup Settings page displays.

Click the Back Up button.

Specify a location on your network. A confirmation message displays.

Click the OK button. A copy of the current settings is saved in the location you specified.

Restore Configuration Settings

To restore configuration settings that you backed up:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Backup Settings. The Backup Settings page displays.

Click the Browse button to find and select the .cfg file.

User Manual84Manage Your Network

AC1750 WiFi Cable Modem Router

Click the Restore button. The file is uploaded to the cable modem router and the cable modem router reboots.

Warning: Do not interrupt the reboot process.

Erase the Current Configuration Settings

You can erase the current configuration and restore the factory default settings. You might want to do this if you move the cable modem router to a different network.

To erase the configuration settings

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Backup Settings. The Backup Settings page displays.

Click the Erase button. The factory default settings are restored. The user name is admin, the password is

password, and the LAN IP address is 192.168.0.1. DHCP is enabled.

View or Change the Cable Modem Router WiFi Channel

Laws or guidelines in many countries and geographic locations specify which channels can be used. Depending on your location, some channels might not be available. If many WiFi networks at your location use the same channel as your WiFi network, you might experience interference. You can change the channel to avoid the interference.

User Manual85Manage Your Network

AC1750 WiFi Cable Modem Router

To view or change your WiFi channel:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Administration > Wireless Channel. The Wireless Channel page displays WiFi channels in use in the 2.4 GHz WiFi band.

Your network is shown in blue. Yellow shows other networks in your area.

To view WiFi channels in use in the 5 GHz WiFi band, select the 5 GHz a/n radio button.

To change the WiFi channel, click the Change Channel button. The Wireless Setup page displays.

In the Channel menu, select a different channel setting.

Click the Apply button. Your settings are saved.

Set Up and Manage Dynamic DNS

Internet service providers (ISPs) assign numbers called IP addresses to identify each Internet account. Most ISPs use dynamically assigned IP addresses. This means that the IP address can change at any time. You can use the IP address to access your network remotely, but most people don’t know what their IP addresses are or when this number changes.

To make it easier to connect, you can get a free account with a Dynamic DNS service that lets you use a domain name to access your home network. To use this account, you must set up the cable modem router to use Dynamic DNS. Then the cable modem router notifies the Dynamic DNS service provider whenever its IP address changes. When you access your Dynamic DNS account, the service finds the current IP address of your home network and automatically connects you.

If your ISP assigns a private WAN IP address (such as 192.168.x.x or 10.x.x.x), the Dynamic DNS service does not work because private addresses are not routed on the Internet.

User Manual86Manage Your Network

AC1750 WiFi Cable Modem Router

Specify a DNS Account

To set up Dynamic DNS in the cable modem router:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Settings > Dynamic DNS. The Dynamic DNS page displays.

Select the Use a Dynamic DNS Service check box.

In the Service Provider menu, select your service provider.

In the Host Name field, type the host name (sometimes called the domain name) for your account.

In the User Name field, enter the user name for your account.

In the Password (6-32 characters) field, type the password for your DDNS account.

10.

Click the Apply button. Your settings are saved.

11.

To verify that your Dynamic DNS service is enabled in the cable modem router, click the Show Status button.

A message displays the Dynamic DNS status.

Change the Dynamic DNS Settings

To change your settings:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password.

User Manual87Manage Your Network

AC1750 WiFi Cable Modem Router

The user name is admin. The password is the one that you specified the first time that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > Dynamic DNS. The Dynamic DNS page displays.

5. Change your DDNS account settings as necessary.

Click the Apply button. Your settings are saved.

Remote Management

You can access your cable modem router over the Internet to view or change its settings. You must know the cable modem router’s WAN IP address to use this feature.

Be sure to change the password for the user name admin to a secure password. The ideal password contains no dictionary words from any language and contains uppercase and lowercase letters, numbers, and symbols. It can be up to 30 characters. See Change the admin Password on page 73.

Set Up Remote Management

To set up remote management:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > Remote Management. The Remote Management page displays.

Select the Turn Remote Management On check box.

In the Allow Remote Access By section, specify the external IP addresses to be allowed to access the cable modem router’s remote management.

User Manual88Manage Your Network

AC1750 WiFi Cable Modem Router

For enhanced security, restrict access to as few external IP addresses as practical.

Select one of the following:

Only This Computer. To allow access from a single IP address on the Internet,

•

select the Only This Computer radio button. Enter the IP address to be allowed access.

IP Address Range. To allow access from a range of IP addresses on the Internet,

•

select the IP Address Range radio button. Enter a beginning and ending IP address to define the allowed range.

Everyone. To allow access from any IP address on the Internet, select the

•

Everyone radio button.

Specify the port number for accessing the cable modem router’s web pages. Normal web browser access uses the standard HTTP service port 80. For greater

security, enter a custom port number for remote access to the cable modem router web pages. Choose a number from 1024 to 65535, but do not use the number of any common service port. The default is 8080, which is a common alternate for HTTP.

Click the Apply button. Your settings are saved.

Use Remote Access

To use remote access:

1. Launch an Internet browser on a computer that is not on your home network.

2. Type your cable modem router’s WAN IP address into your browser’s address or location field followed by a colon (:) and the custom port number.

For example, if your external address is 134.177.0.123 and you use port number 8080, enter http://134.177.0.123:8080 in your browser.

User Manual89Manage Your Network

Specify Internet Port Settings

You can use port forwarding and port triggering to set up rules for Internet traffic. You need networking knowledge to set up these features.

This chapter includes the following sections:

• Set Up Port Forwarding to a Local Server

• Set Up Port Triggering

AC1750 WiFi Cable Modem Router

Set Up Port Forwarding to a Local Server

If your home network includes a server, you can allow certain types of incoming traffic to reach the server. For example, you might want to make a local web server, FTP server, or game server visible and available to the Internet.

The cable modem router can forward incoming traffic with specific protocols to computers on your local network. You can specify the servers for applications and you can also specify a default DMZ server to which the cable modem router forwards all other incoming protocols.

To forward specific incoming protocols:

Decide which type of service, application, or game you want to provide.

Find the local IP address of the computer on your network that will provide the service.

The server computer must always use the same IP address. To specify this setting, use the reserved IP address feature. See Manage LAN IP Addresses on page 60.

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

5. Enter the modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > Port Forwarding/Port Triggering. The Port Forwarding/Port Triggering page displays.

Leave the Port Forwarding radio button selected as the service type.

In the Service Name menu, select the service name. If the service that you want to add is not in the menu, create a custom service. See

Add a Custom Port Forwarding Service on page 92.

In the Server IP Address field, enter the IP address of the computer that will provide the service.

10.

Click the Add button. The service displays in the menu.

User Manual91Specify Internet Port Settings

AC1750 WiFi Cable Modem Router

Add a Custom Port Forwarding Service

To add a custom service:

Find out which port number or range of numbers the application uses. You can usually find this information by contacting the publisher of the application

or user groups or news groups.

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

4. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > Port Forwarding/Port Triggering. The Port Forwarding/Port Triggering page displays.

Leave the Port Forwarding radio button selected as the service type.

Click the Add Custom Service button. The Ports-Custom Services page displays.

In the Service Name field, enter a descriptive name.

In the Service Type field, select the protocol. If you are unsure, select TCP/UDP.

10.

In the External Starting Port field, enter the beginning port number. If the application uses a single port, enter the same port number in the External

Ending Port field.

If the application uses a range of ports, enter the ending port number of the range in the External Ending Port field.

11.

Specify the internal ports by one of these methods:

Leave the Use the same port range for Internal port check box selected.

•

Type the port numbers in the Internal Starting Port and Internal Ending Port

•

fields.

User Manual92Specify Internet Port Settings

AC1750 WiFi Cable Modem Router

12.

Type the IP address in the Internal IP address field or select the radio button for an attached device listed in the table.

13. Enter the external IP address.

14.

Click the Apply button. The service is now in the menu on the Port Forwarding/Port Triggering page.

Edit a Port Forwarding Service

To edit a port forwarding entry:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > Port Forwarding/Port Triggering. The Port Forwarding/Port Triggering page displays.

Leave the Port Forwarding radio button selected as the service type

6. In the table, select the radio button next to the service name.

Click the Edit Service button. The Ports - Custom Services page displays.

Specify changes to any of the settings. For more information about the settings see the previous section, see Add a Custom

Port Forwarding Service on page 92.

Click the Apply button. Your settings are saved.

User Manual93Specify Internet Port Settings

AC1750 WiFi Cable Modem Router

Delete a Port Forwarding Entry

To delete a port forwarding entry:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > Port Forwarding/Port Triggering. The Port Forwarding/Port Triggering page displays.

Select the Port Forwarding radio button as the service type.

6. In the table, select the radio button next to the service name.

Click the Delete Service button.

Application Example: Make a Local Web Server Public

If you host a web server on your local network, you can use port forwarding to allow web requests from anyone on the Internet to reach your web server.

To make a local web server public:

Assign your web server either a fixed IP address or a dynamic IP address using DHCP address reservation.

In this example, your cable modem router always gives your web server an IP address of 192.168.0.33.

On the Port Forwarding/Port Triggering page, configure the cable modem router to forward the HTTP service to the local address of your web server at 192.168.0.33.

HTTP (port 80) is the standard protocol for web servers.

(Optional) Register a host name with a Dynamic DNS service, and specify that name on the Dynamic DNS page of the cable modem router.

Dynamic DNS makes it much easier to access a server from the Internet because you can type the name in the Internet browser. Otherwise, you must know the IP address that the ISP assigned, which typically changes.

User Manual94Specify Internet Port Settings

AC1750 WiFi Cable Modem Router

How the Cable Modem Router Implements the Port Forwarding Rule

The following sequence shows the effects of a port forwarding rule:

1. When you type the URL www.example.com in your browser, the browser sends a web page request message with the following destination information:

Destination address. The IP address of www.example.com, which is the address

•

of your cable modem router.

Destination port number. 80, which is the standard port number for a web server

•

process.

Your cable modem router receives the message and finds your port forwarding rule for incoming port 80 traffic.

3. The cable modem router changes the destination in the message to IP address

192.168.0.123 and sends the message to that computer.

4. Your web server at IP address 192.168.0.123 receives the request and sends a reply message to your cable modem router.

Your cable modem router performs Network Address Translation (NAT) on the source IP address, and sends the reply through the Internet to the computer or mobile device that sent the web page request.

Set Up Port Triggering

Port triggering is a dynamic extension of port forwarding that is useful in these cases:

An application must use port forwarding to more than one local computer (but not

• simultaneously).

An application must open incoming ports that are different from the outgoing port.

•

With port triggering, the cable modem router monitors traffic to the Internet from an outbound “trigger” port that you specify. For outbound traffic from that port, the cable modem router saves the IP address of the computer that sent the traffic. The cable modem router temporarily opens the incoming port or ports that you specify in your rule and forwards that incoming traffic to that destination.

Port forwarding creates a static mapping of a port number or range of ports to a single local computer. Port triggering can dynamically open ports to any computer when needed and close the ports when they are no longer needed.

User Manual95Specify Internet Port Settings

AC1750 WiFi Cable Modem Router

Note: If you use applications such as multiplayer gaming, peer-to-peer connections,

real-time communications such as instant messaging, enable Universal Plug and Play (UPnP).

Add a Port Triggering Service

To add a port triggering service:

Launch a web browser from a computer or mobile device that is connected to the cable modem router network.

Enter http://routerlogin.net or http://192.168.0.1. A login window opens.

3. Enter the cable modem router admin user name and password. The user name is admin. The password is the one that you specified the first time

that you logged in. The user name and password are case-sensitive.

The BASIC Home page displays.

Select ADVANCED > Advanced Setup > Port Forwarding/Port Triggering. The Port Forwarding/Port Triggering page displays.

Select the Port Triggering radio button. The page adjusts.

Click the Add Service button. The Port Triggering-Services page displays.

In the Service Name field, type a descriptive service name.

In the Service User menu, select Any, or select Single address and enter the IP address of one computer:

Any (the default) allows any computer on the Internet to use this service.

•

Single address restricts the service to a particular computer.

•

Select the service type, either TCP or UDP or TCP/UDP (both). If you are not sure, select TCP/UDP.

10.

In the Triggering Starting Port field, enter the beginning port number.

11.

In the Triggering Ending Port field, enter the ending port number.

12.

Enter the inbound connection port information in the Connection Type, Starting Port, and Ending Port fields.

User Manual96Specify Internet Port Settings

AC1750 WiFi Cable Modem Router

13.

Click the Apply button. The service is now in the Portmap table. You must enable port triggering before the

cable modem router used port triggering for the service that you added. See the following section.

Application Example: Port Triggering for Internet Relay Chat

Some application servers, such as FTP and IRC servers, send replies to multiple port numbers. Using port triggering, you can tell the cable modem router to open more incoming ports when a particular outgoing port starts a session.

An example is Internet Relay Chat (IRC). Your computer connects to an IRC server at destination port 6667. The IRC server not only responds to your originating source port, but also sends an “identify” message to your computer on port 113. Using port triggering, you can tell the cable modem router, “When you initiate a session with destination port 6667, you must also allow incoming traffic on port 113 to reach the originating computer.” The following sequence shows the effects of this port triggering rule:

1. You open an IRC client program to start a chat session on your computer.

2. Your IRC client composes a request message to an IRC server using a destination port number of 6667, the standard port number for an IRC server process. Your computer then sends this request message to your cable modem router.

3. Your cable modem router creates an entry in its internal session table describing this communication session between your computer and the IRC server. Your cable modem router stores the original information, performs Network Address Translation (NAT) on the source address and port, and sends this request message through the Internet to the IRC server.

Based on your port triggering rule and the destination port number of 6667, your cable modem router creates another session entry to send any incoming port 113 traffic to your computer.

5. The IRC server sends a return message to your cable modem router using the NAT-assigned source port (for example, port 33333) as the destination port. The IRC server also sends an “identify” message to your cable modem router with destination port 113.

6. When your cable modem router receives the incoming message to destination port 33333, it checks its session table to see if a session is active for port number 33333. Finding an active session, the cable modem router restores the original address information replaced by NAT and sends this reply message to your computer.

7. When your cable modem router receives the incoming message to destination port 113, it checks its session table and finds an active session for port 113 associated with your computer. The cable modem router replaces the message’s destination

User Manual97Specify Internet Port Settings

AC1750 WiFi Cable Modem Router

IP address with your computer’s IP address and forwards the message to your computer.

When you finish your chat session, your cable modem router eventually senses a period of inactivity in the communications. The cable modem router then removes the session information from its session table, and incoming traffic is no longer accepted on port numbers 33333 or 113.

User Manual98Specify Internet Port Settings

Troubleshooting

This chapter provides information to help you diagnose and solve problems you might experience with your cable modem router. If you do not find the solution here, check

the NETGEAR support site at support.netgear.com for product and contact information.

This chapter contains the following sections:

• Troubleshoot With the LEDs

• Troubleshoot the Cable Internet Connection

• Cannot Log In to the Cable Modem Router

• Changes Not Saved

• WiFi Connectivity

• Troubleshoot Your Network Using the Ping Utility

AC1750 WiFi Cable Modem Router

Troubleshoot With the LEDs

You can use the LEDs on the front panel of the cable modem router for troubleshooting.

Power LED Is Off

Make sure that the power adapter is securely connected to your cable modem router

• and securely connected to a working power outlet.

Check that you are using the power adapter that NETGEAR supplied for this product.

•

If the problem persists, contact technical support for help at

•

LEDs Never Turn Off

When the cable modem router is turned on, the LEDs light for about 10 seconds and then turn off. If all the LEDs stay on, this indicates a fault within the cable modem router.

If all LEDs are still lit one minute after power-up, do the following:

Cycle the power to see if the cable modem router recovers.

•

Press and hold the Reset button to return the cable modem router to its factory settings.

If the error persists, a hardware problem might be the issue. Contact technical support at http://www.netgear.com/support.

Internet LED Is Off

If the Internet LED is off and the cable modem router is connected to the coaxial cable, try the following:

Make sure that the coaxial cable connections are secure at the cable modem router

• and at the wall jack.

Make sure that your cable Internet provider provisioned your cable Internet service.

• Your provider can verify that the signal quality is good enough for cable modem

router service.

Remove any excessive splitters that are on your cable line.

•

User Manual100Troubleshooting

NETGEAR C6300v2 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Hardware Setup

Unpack Your Cable Modem Router

Front Panel LEDs and Buttons

Rear Panel

Label

System Requirements

Position Your Cable Modem Router

Install and Activate Your Cable Modem Router

Set Up the Hardware

Activate Your Internet Service

Perform a Speed Test

Connect Your Cable Modem Router to a Router After Installation and Activation

Connect to the Network and Access the Cable Modem Router

Connect to the Network

Wired Connection

Find and Select the Cable Modem Router WiFi Network

Use WPS to Connect to the Cable Modem Router WiFi Network

Types of Logins

Log In to the Cable Modem Router

Specify Your Internet Settings

Specify the Cable Connection Starting Frequency

View Modem Router Initialization

Manually Set Up the Internet Connection

Control Access to the Internet

Set Up Parental Controls

Block Access to Your Network

Use Keywords to Block Internet Sites

Delete a Keyword

Block Services From the Internet

Schedule When to Block Internet Sites and Services

Avoid Blocking on a Trusted Computer

Set Up Security Event Email Notifications

Share USB Devices Attached to the Cable Modem Router

USB Storage Device Requirements

Connect a USB Storage Device to the Cable Modem Router

Access a USB Device Connected to the Cable Modem Router From a Windows-Based Computer

Map a USB Device to a Windows Network Drive

Access a USB Storage Device That Is Connected to the Cable Modem Router From a Mac

Control Access to the USB Storage Device

Use FTP Within the Network

View or Change Network Folders on a USB Storage Device

Add a Network Folder on a USB Storage Device

Edit a Network Folder on a USB Storage Device

Approve USB Devices

Access the USB Storage Device Through the Internet

Set Up FTP Access Through the Internet

Access the USB Storage Device Through the Internet With FTP

Safely Remove a USB Storage Device

Share a USB Printer

Install the Printer Driver and Cable the Printer

Download the ReadySHARE Printer Utility

Install the ReadySHARE Printer Utility

Print Using the NETGEAR USB Control Center

Specify Network Settings

View or Change the WAN Settings

Set Up a Default DMZ Server

Change the Cable Modem Router’s Device Name

Change the LAN TCP/IP Settings

Specify the IP Addresses That the Cable Modem Router Assigns

Disable the DHCP Server Feature in the Cable Modem Router

Manage LAN IP Addresses

Reserve an IP Address

Edit a Reserved IP Address Entry

Delete a Reserved IP Address Entry

Improve Network Connections With Universal Plug-N-Play

Use the WPS Wizard for WiFi Connections

Specify Basic WiFi Settings

Change the WiFi Security Option

Set Up a Guest Network

Control the WiFi Radios

Use the WiFi On/Off Button

Enable or Disable the WiFi Radios

Specify WPS Settings

Enable or Disable Router Mode

Manage Your Network
