Nesco NC-5135 User Manual

Page 1
Page 2
1
Page 3
ภาษาไทย
ตู้อบไฟฟ้า 23 ลิตร
รุ่น เชฟ โปร 23 NC-5135
1500 วัตต์ 220 โวลต์ 50 เฮิร์ซ
ถึงท่านผู้มีอุปการะคุณทุกท่าน
ขอขอบคุณทุกท่านที่ไว้วางใจเลือก ใช้ผลิตภัณฑ์ของเนสโก้ด้วยประสบการณ์ และการออกแบบที่ทันสมัยและโดดเด่น ของผลิตภัณฑ์ที่มากด้วยคุ ในการใช้งานจะสามารถตอบสนองความ พึงพอใจในการใช้งานของท่านได้อย่างคุ้ม ค่า
คำแนะนำ
โปรดอ่านและทำความเข้าใจคู่มือฉบับนี้ รวมทั้งป้ายผนึกต่างๆที่ติดกับตัวเครื่อง อย่างดีก่อนการใช้งานโปรดเก็บรักษาคู่มือนี้ ไว้กับตัวผลิตภัณฑ์สำหรับการใช้งานใน ครั้งต่อไป ก่อนใช้งานควรแน่ใจว่าบุคคล ที่ใช้งานและบำรุงรักษาเครื่องทุกคนนั้น มีความรู้และเข้าใจคู่มือฉบับนี้
ส่วนประกอบ
ตะแกรง
A.
ถาดอาหาร
B.
ปุ่มควบคุมอุณหภูมิ
C.
ปุ่มเปิด/ปิดและเลือกรูปแบบการทำงาน
D.
ไฟแสดงสถานะ การทำงาน
E.
ณประโยชน์
F.
ปุ่มตั้งเวลา
G.
ปุ่มเปิดปิดระบบหมุนไก่และระบบ กระจายความร้อน
H.
ขาตู้อบ
I.
ปลั๊กและสายไฟ
J.
ประตูตู้อบแบบกระจกทนความร้อนสูง
K.
มือจับประตู
L.
ระบบกระจายความร้อน
M.
ตัวทำความร้อน
N.
มือจับเหล็กเสียบไก่
O.
เหล็กเสียบไก่
P.
ส้อม
Q.
น็อตยึดส้อมกับเหล็กเสียบ
R.
ตัวจับถาด
S.
ถาดรองเศษอาหาร
คำเตือนเพื่อความปลอดภัย
1. กรุณาศึกษาคู่มือการใช้งานนี้อย่าง ละเอียดก่อนการใช้งาน
2. ห้ามสัมผัสตัวเครื่องที่มีความร้อน ควรใช้มือจับบริเวณมือจับ
3. ห้ามนำตัวเครื่อง สายไฟ หรือปลั๊ก จุ่มลงน้ำหรือของเหลวอื่นๆ เพื่อป้องกัน ความเสียหายของเครื่อง
4. ควรควบคุมดูแลอย่างใกล้ชิดเมื่อมี ความจำเป็นต้องใช้งานเครื่องบริเวณที่ มีเด็กอยู่
2
Page 4
5. ต้องถอดปลั๊กก่อนทำความสะอาด เครื่องทุกครั้งและถอดปลั๊กหากไม่ได้ใช้ งานและควรปล่อยให้เครื่องเย็นลง ก่อน ถอดหรือประกอบเครื่อง
6. ไม่ควรใช้งานเครื่องในขณะที่สายไฟ หรือปลั๊กได้รับความเสียหายหรือหลัง จากเครื่องไม่สามารถทำงานได้หรือ ความเสียหายที่เกิดจากสาเหตุอื่น
7. การใช้อุปกรณ์อื่นที่ไม่ได้มาพร้อมกับ ตัวเครื่องอาจทำให้เครื่องเกิดความเสีย หายได้
8. ไม่ควรใช้งานนอกตัวอาคาร
9. ไม่ควรปล่อยให้สายไฟพาดผ่านหรือ
แขวนบนขอบโต๊ะที่มีความแหลมคม หรือสัมผัสกับพื้นผิวที่มีความร้อน
10. ไม่ควรวางเครื่องใกล้กับแหล่งความ ร้อนหรือหัวเตาแก๊สหรือตู้อบที่ให้ความ ร้อน
11. ต้องใช้ความระมัดระวังเป็นอย่างยิ่ง หากต้องเคลื่อนย้ายตู้อบหรือถอดถาดรอง เศษอาหารที่มีน้ำมันร้อนๆ หรือของเหลว ร้อนๆ อยู่
12. ควรแน่ใจว่าปลั๊กและสายไฟเชื่อม ต่อ อยู่กับตู้อบจากนั้นเสียบปลั๊กเข้า กับเต้ารับ และก่อนถอดปลั๊กต้องหมุน ปรับปุ่มการทำงานให้อยู่ในตำแหน่ง ปิด
“Off”เสมอ แล้วจึงถอดปลั๊กออก
13. ไม่ควรทำความสะอาดตู้อบด้วยใย
ขัดที่เป็นโลหะเพราะอาจทำให้เกิดความ เสียหายและเกิดไฟรั่วหรือไฟช็อตได้
14. ควรถอดปลั๊กเสมอเมื่อไม่ได้ใช้งาน หรือก่อนถอดประกอบเครื่องหรือก่อน ทำความสะอาดเครื่องและควรปล่อย ให้เครื่องเย็นลงก่อนสัมผัสตัวเครื่อง
15. ไม่ควรบรรจุอาหารที่มีขนาดใหญ่ เกินไปหรือวัสดุเครื่องใช้ที่เป็นโลหะลง ในตู้อบเนื่องจากอาจทำให้เกิดเปลวไฟ ทำให้เครื่องเสียหายได้
16. อาจเกิดไฟลุกขึ้นได้หากตู้อบถูกปก คลุมหรือสัมผัสกับวัสดุที่ติดไฟง่ายเช่น ผ้าม่าน ฝาผนังและวัสดุที่ติดไฟง่ายอื่นๆ ในระหว่างการใช้งานไม่ควรเก็บหรือวาง สิ่งของใด ๆไว้บนตู้อบ
17.ไม่ควรเก็บสิ่งของใด ๆ หรือสิ่งของ อย่างอื่นนอกเหนือจากส่วนประกอบของ เครื่อง ไว้ในตู้อบเมื่อไม่ได้ใช้งาน
18. ควรแน่ใจว่าไม่มีวัสดุอื่น ที่ติดมา กับเครื่องติดอยู่ในตู้อบ เช่นกระดาษหรือ แผ่นพลาสติกอื่น ๆ
19. ตู้อบจะหยุดการทำงานเมื่อหมุนปรับ ปุ่มตั้งเวลาไปยังตำแหน่ง 0
20. ไม่ควรใช้งานเครื่องเพื่อวัตถุประสงค์ อื่นที่นอกเหนือไปจากที่ระบุไว้ในคู่มือ
3
Page 5
ข้อควรระวัง
การใช้งานเครื่องไม่ถูกวิธีหรือไม่เหมาะสม อาจก่อให้เกิดอุบัติเหตุสร้างความเสียหาย และอันตรายต่อผู้ใช้งานได้ดังนั้นจึงควร ปฏิบัติตามคู่มืออย่างเคร่งครัดและระมัด ระวัง
1. ไม่ควรใช้งานปลั๊กไฟ(เต้ารับ)ร่วมกับ เครื่องใช้ไฟฟ้าอื่น พร้อมๆกัน
2. ไม่ควรเทน้ำลงบนตัวเครื่องหรือใน ตัวเครื่องและไม่ควรจับเครื่องด้วยมือที่เปียก เนื่องจากอาจทำให้เกิดอันตรายต่อผู้ใช้และ เกิดความเสียหายต่อเครื่องได้
3. ไม่ควรวางตู้อบบนพื้นโต๊ะ พรม หรือ พื้นผิวอื่นๆ ท
ี่ไม่ทนความร้อนโดยเฉพาะ อย่างยิ่งไม่ควรให้ตัวเครื่องสัมผัสกับ ผ้าม่านหรือวัสดุอื่นๆ ที่ติดไฟได้ง่าย
4.ไม่ควรสัมผัสเครื่องในระหว่างทำงาน หรือหลังการใช้งานทันที * เนื่องจากความร้อนสูงจากเครื่องอาจทำ ให้เกิดอันตรายกับผู้ใช้งานได้และหาก บริเวณฝาตู้อบที่เป็นกระจกโดนน้ำก็จะทำ ให้กระจกเกิดรอยแตกร้าวได้ ดังนั้นควร หลีกเลี่ยงไม่ให้น้ำสาดหรือกระเด็นโดนตู้อบ
5. ไม่ควรวางสิ่งของหรืออุปกรณ์ใด ๆ ไว้บนตัวตู้อบ
6. ไม่ควรใช้งานเครื่องหากสายไฟอยู่ใน สภาพเสียหาย
วิธีการใช้งาน
1. วางตู้อบบนพื้นผิวที่ราบเรียบ จากนั้น เสียบปลั๊กของตู้อบเข้ากับเต้าเสียบ
2. การอบอาหารโดยใช้ถาดวางอาหาร(B) ต้องใส่ตะแกรง(A)ในตู้อบก่อนจากนั้น จัดวางอาหารที่ต้องการอบไว้บนถาด และปรับตั้งอุณหภูมิ (ปุ่มC) ตั้งเวลา (ปุ่มF) และตั้งระดับความร้อน (ปุ่มD) ตามลำดับ เมื่ออุณหภูมิได้ที่นำถาด อาหารที่เตรียมอาหารไว้วางบนตะแกรง ด้วยที่จับถาดวางอาหาร
ตัวอย่าง
ประเภทอาหาร ระยะเวลา
เนื้อย่าง
หมูย่าง
แฮม
ไก่
ไก่งวง
อุณหภูมิ(C)
165 องศา 165 องศา 165 องศา 190 องศา 190 องศา
30-35 นาที 45-50 นาที 45-50 นาที 25-30 นาที 25-30 นาที
3.ทาน้ำมันพืชบนถาดวางอาหารเล็กน้อย
ก่อนวางถาดอาหารในตู้อบเพื่อป้องกันอาหาร ติดถาด
4.ควรวางอาหารให้สม่ำเสมอกันเพื่อ อาหารจะได้สุกทั่วถึงเท่ากัน
5. คุณสามารถสังเกตุอาหารได้จากประตู
กระจกใสของตู้อบได้ตลอดเวลาที่ตั้งไว้
หากอาหารที่มีชิ้นใหญ่หรือเป็นชิ้นหนา สามารถพลิกอาหารกลับไปกลับมาได้
4
Page 6
เพื่อให้อาหารสุกทั่วถึงทุกด้าน โดยเปิด ประตูตู้อบแล้วพลิกกลับอาหาร (โปรด ระมัดระวังความร้อน) แล้วปิดประตู ตู้อบทันที
6. เมื่อหมดเวลาที่ตั้งไว้จะมีเสียงสัญญาณ เตือน จากนั้นเปิดฝาตู้อบแล้วนำอาหาร ออกจากตู้อบ หากท่านต้องการนำอาหาร ออกจากตู้อบในขณะที่ตู้อบกำลังทำงานอยู่ ให้ปรับปุ่มตั้งเวลาไปยังเลข 0 จากนั้น จะมีเสียงสัญญาณเตือนแล้วจึงค่อยนำ อาหารออกจากตู้อบได้อย่างปลอดภัย
7. เมื่อเสร็จการใช้งาน ถอดปลั๊ก จากนั้น ปล่อยให้ตู้อบเย็นลงก่อนทำความ สะอาด หรือเคลื่อนย้าย
วิธีการใช้งานระบบหมุนไก่
อาหารที่จะนำมาย่างไม่ควรมีน้ำหนักเกิน 2-3 กิโลกรัม หรือมีขนาดใหญ่เกินกว่า จะหมุนได้ในตู้อบ การย่างไก่ ให้นำเหล็ก เสียบไก่ เสียบไก่เข้าไปตามยาว มัดขา และปีกไม่ให้เลื่อน หลังจากนั้นใช้ส้อม เสียบเข้าไปตรึงไก่ไว้และขันน๊อตให้แน่น ตรวจดูอีกครั้งว่าไก่อยู่กึ่งกลางหรือไม่ นำเหล็กที่เสียบไก่แล้วไปวางลงให้ตรง ตำแหน่งแกนรองรับที่เสียบภายในตู้อบ สำหรับการอบให้มีประสิทธิภาพ ควรตั้ง ตู้อบให้ร้อนก่อน 10-15 นาที ให้ได้ อุณหภูมิที่ต้องการ หลังจาก 10-15 นาที
5
แล้ว จึงค่อยนำถาดอาหารใส่เข้าไปในตู้อบ
การใช้งานระบบ กระจายความร้อน
ระบบกระจายความร้อนจะใช้งานได้ ก็ต่อเมื่อ กดเปิดสวิตซ์ระบบหมุนไก่ และระบบกระจายความร้อน (G) แล้ว เท่านั้น.
ข้อแนะนำ
1. การใช้ถาดรองในการอบอาหาร บาง ประเภท เช่น การอบไก่ ที่จะมีน้ำหรือ น้ำมันออกมาจากเนื้อไก่ในระหว่างการ อบ ซึ่งอาจทำให้น้ำหรือน้ำมันนั้นล้น ออกจากถาด ฉะนั้นไม่ควรบรรจุอาหาร ในถาดเยอะมากเกินไป ควรแน่ใจว่า ใส่ถาดรองลงไปในตู้อบแล้วและใส่ถาด ได้ระดับ ไม่เอียง
2. หากต้องอบอาหารที่มีน้ำหรือน้ำมัน ควรแน่ใจว่าห่ออาหารด้วยอลูมินัมฟอยล์ แล้วทุกครั้งและนอกจากนี้ควรระวัง การไหม้ของอาหารที่ยังอยู่ในตู้อบหลัง การอบอาหาร
3. ก่อนนำอาหารเข้าตู้อบหรือออกจากตู้อบ ควรแน่ใจว่า ได้หมุนปุ่มตั้งเวลาไปยัง ตำแหน่งปิดแล้ว
การทำความสะอาดและดูแลรักษา
1. ปิดสวิตซ์ตู้อบ ถอดปลั๊ก และปล่อยไว้
Page 7
ให้เย็นก่อนทำความสะอาดทุกครั้ง
2. ถาดรองอีนาเมล ตะแกรง กระทะ และอุปกรณ์สำหรับย่างไก่สามารถล้างได้ด้วย น้ำร้อน หรือน้ำยาล้างจาน
3. กรุณาอย่าใช้แปรงหรือสก๊อตไบรท์ และใยขัดที่เป็นโลหะ ขัดทำความสะอาด ตู้อบเพราะอาจทำให้ตู้อบเป็นรอยได้
4. ท่านสามารถทำความสะอาดตู้อบได้ ด้วยวิธีง่าย ๆ โดยการนำฟองน้ำชุบน้ำ หมาด ๆ เช็ดบริเวณภายนอกและภายใน ตู้อบที่สกปรกเป็นคราบ
5. ระวังอย่าให้น้ำกระเด็นไปโดนกระจก ตู้อบขณะที่ตู้อบยังร้อน หรืออุ่น ๆ เพราะ กระจกตู้อบอาจจะแตกได้ ถ้าโดนน้ำทันที
6. ตัวทำความร้อน หรือ ฮีทเตอร์สามารถ ทำความสะอาดได้โดยใช้ผ้าแห้ง ๆ เช็ดเท่านั้น
7. โปรดระวังอย่าให้ปลั๊กไฟถูกน้ำขณะทำ ความสะอาด
เงื่อนไขการรับประกันสินค้า
- สัญญาการรับประกันมีระยะเวลา 1 ปี นับจากวันที่ท่านซื้อสินค้า ( รับประกัน เฉพาะฮีทเตอร์)
- การรับประกันจะมีผลกับความบกพร่อง ที่เกิดจากความผิดพลาดของบริษัท เท่านั้น ทางบริษัทจะไม่รับประกันสินค้า ที่เสียหายจากการที่ท่านไม่ปฏิบัติตาม
คำแนะนำในคู่มือนี้เด็ดขาดรวมถึงการตก แตก การสึกหรอจากการใช้งาน
- หากท่านดัดแปลง เปลี่ยนชิ้นส่วนใดๆ ที่ไม่ใช่อุปกรณ์ที่มาเป็นชุดของผลิตภัณฑ์ การรับประกันสินค้าถือว่าเป็นโมฆะทันที
- หากเครื่องของท่านเกิดความเสียหาย แล้วยังอยู่ในเงื่อนไขของการรับประกัน ท่านสามารถส่งเครื่องคืนศูนย์ตัวแทน จัดจำหน่ายได้โดยบรรจุหีบห่อผลิตภัณฑ์ ให้เรียบร้อยแล้วเขียนชื่อ ที่อยู่ เบอร์ โทรศัพท์และเขียนสาเหตุที่ส่งเครื่องคืน ว่าเป็นเพราะเหตุใดพร้อมแนบสัญญา การรับประกันมาด้วย
สินค้าจะหลุดพ้นจากการรับประกันเมื่อ
- เสียหายจากการใช้งานไม่ถูกต้อง (ไม่ ปฏิบัติตามคู่มือ)หรือดัดแปลงสินค้า
- เสียหายจากการขนส่ง
- เสียหายจากการใช้งานเป็นประจำหรือ
ขาดการดูแลรักษาเครื่อง
- เสียหายจากการสูญหาย หรือชิ้นส่วน บางอย่างหายไปจากการถอดประกอบ สินค้า
หมายเหตุ
- รับประกันเฉพาะในพื้นที่รับประกัน เท่านั้น
6
Page 8
7
Page 9
English
TOASTER OVEN
CHEF PRO 23 NC-5135
1500 W 220 V 50Hz
Dear Customer
Thank you for choosing a NESCO appliance. The experience, design, feature and technology of this appliance, as well as the strict quality controls used during manufacture, will provide full satisfaction for many years.
Introduction
Carefully read and understand this manual and any label attached to the tool before use. Keep these instructions with the product for future reference. Ensure all persons who use and service this product are acquainted with this manual.
Description
Wire rack
A.
Tray
B.
Thermostat knob
C.
Switch knob
D.
Power indicator
E.
Timer
F.
Convection / rotisserie
G.
switch Foot
H.
Plug cord
I.
Door with high
J.
temperature resistant glass
Door handle
K.
Convection
L.
Heating element
M.
Rotisserie handle
N.
Rotisserie forks
O.
Skewer
P.
Thumbscrew
Q.
Handle
R.
Crumb tray
S.
8
Page 10
Tip&safty precautions
When using electrical appliances,basic safety precautions should always be followed including the folowing:
1. Read all instructions.
2. Do not touch hot surfaces, Use handles of knobs.
3. T o protect against electrical shock do not immerse equipment body, cord or plugs in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts.
6. Do not operate any appliance with a damaded cord or plug or after the appliance malfunctions or has been damaged in any manner
7. The use of accesory attachments not recommended by the appliance manufacturer may cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table of counters, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution must be used when moving an appliance containing hot oil or other hot liquids and when removing tray or disposing of hot grease.
12. Always attach plug to appliance first, then plug cord into the wall outlet. To disconnect, turn any control to “off” , then remove plug from wall outlet.
13. Do not clean with metal scouring pads. Pieces can break off the pad and touch electrical parts. Creating a risk of electric shock.
14. Portable-Remove plug from outlet when the appliance is not in use,before putting on or taking off parts, and before cleaning. Allow to cool beforehandling.
9
Page 11
15. Oversize foods or metal utensils must not be inserted in an oven as they may create a fire or risk of electric shock.
16. A fire may occur if the oven is covered or touching flammable material, including curtains, draperies, walls, and the like , when in operation, Do not store any item on top of the appliance when in operation.
17. Do not store any materials, other than manufacturers recommended accessories, in this oven when not in use.
18. Do not place any of the following materials in the oven : That is, paper, cardboard plasic,and the like
19. The oven is turned off by turning the timer button to 0 min position.
20. Do not use appliance for other than intended use.
Important Safeguards
If this appliance is not used in the proper manner, breakdown or an accident may result. Therefore, follow these instructions carefully.
1. Do not use the socket for other electrical appliances at the same time.
2. Do not put water on or in the unit handle the unit with wet hands. This may cause electric shock or breakdown to occur.
3. Do not place the unit on a table, carpet or other surface that has a low resistance to heat. – Furthermore, the unit should not come in contact with curtains or other easily combustible materials.
4. Do not touch the unit during or immediately after use. –At high temperatures it is possible to be burned by the unit, Also, if water comes in comtact with the unit’s glass door, the glass may crack. Therefore, avoid splashing water on the unit.
5. Do not place anything on top of the unit.
6. Do not use the unit when the cord is damaged.
10
Page 12
Instruction for use
1. Put the oven on a plain plate. Then plug in the power supply.
2. Prepare the food which is going to be baked in a tray, and regulate the temperature(C), time(F) and power level(D), then plug in to preheat the oven. Put the tray with handle into the oven at the fixed temperature.
Example
FOOD TIME PER
BEEF
ROAST
PORK
ROAST
HAM
CHICKEN
TURKEY
OVEN TEMP
165 c
165 c
165 c
190 c
190 c
30-35min
45-50min
45-50min
25-30min
25-30min
3. Spread the tray with eatable oil before putting preparation in it to provide again stickiness.
4. One tray once time ensure the food to be baked well distributed.
11
5. In the course of baking, watch the food from glass door. To the chunk of food, It is better to turn it over once or twice. Open the door when need turning or moving. But the door must be shut immediately.
6. A chime sounds when the time period has elapsed. Open the door and remove the cooked food from the oven toaster. When removing food while the unit is still in operation, be sure to turn the timer knob to the ‘0’ min position. The chime will then ring. Signalling that it is safe to remove the cooked food.
7. After use, unplug the plug from the wall socket and allow the unit to cool before storing it away.
How to use the rotisserie function
We recommend that you do not cook and roast larger than 4-5 lbs. On the Rotisserie fork (O) chicken should be bound in string to prevent the
Page 13
chicken legs or wings from unraveling during roasting and so that rotisserie assembly will rotate smoothly . For best results we recommend that you preheat the oven for 15 minutes on 250 C
How to use the convection function
It can choose the convection time and temperature of heating. This convection control works only when function control set on convection switch position.
Notes:
1. Because there are times when the tray to cook food on may become warped, do not overload it. Be sure to place the tray in the oven toaster so that it is level.
2. When cooking oily or watery food, be sure to use aluminum foil. Furthermore, avoid burning any food that remains after cooking.3. When putting food into or taking it out of the unit, be certain to turn the timer to the off position.
Maintenance &Cleaning
1. Switch off the oven and allow it to cool completely before cleaning or maintenance.
2. The baking tray, the rack and the accessories for the spit can be cleaned with hot water and washing- up liquid.
3. Do not use abrasive pads of cloths, scouring powders or oven cleaning products to clean the oven.
4. For ease of cleaning wipe with a damp soapy sponge over the walls of the oven. Rinse and dry carefully.
5. Never allow water to spill on the tempered glass door when it is still warm.
6.Never immerse the appliance and power cord in water.
7. The heating element can be cleaned with a damp detergent cloth. Wipe dry with a soft cloth.
12
Page 14
Warranty:
Warranty heater only
- Damage or defective from delivery.
- Damage or defective from manufacturer, dealer&service.
- 1 year warranty for house hold use only.
- Use according to this instruction carefully
Warranty is expired when (void of warranty)
- Damage or defect from misunderstand how to use or service from non authorized people.
- Electrical shock or any electrical problem.
- Lost or damage some part by accident or natural damage.
- Some parts are shelf life, need replacement.
Note :
- Service is available only in
Bangkok.
- This instruction may be changed with out prior notice.
- Company reserved the right to change all details before notice.
13
