Nesco DF-1250T User Manual

Deep Fryer
Use/Care and Recipe Guide Model DF-1250T
Electric Deep Fryer with 1800 watts and “cool zone” technology for better tasting food
2
DF-1250T Deep Fryer
DF-1250T DEEP FRYER
NESCO®is a registered trademark of The Metal Ware Corporation.
The Metal Ware Corporation 1700 Monroe St., P.O. Box 237 Two Rivers, WI 54241-0237 Phone: 800-288-4545 Fax: 920-794-3164
Visit our Website at http://www.nesco.com
©The Metal Ware Corp., 2001 Made in China. Printed in China. Revised 7/01
Table of Contents:
IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SAVE THESE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
GET TO KNOW YOUR NESCO
®
DEEP FRYER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
DIRECTIONS FOR USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CLEANING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
OPERATION OF TIMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
HELPFUL HINTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
TROUBLE SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
RECIPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-14
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
ABOUT YOUR WARRANTY AND SERVICE SATISFACTION . . . . . . . . . . . . . . . . . . . . . . . . . 15
US LISTED
3
DF-1250T Deep Fryer
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed including the following:
1. READ ALL INSTRUCTIONS BEFORE USING APPLIANCE.
2. DO NOT USE WITH AN EXTENSION CORD. Use of this 1800-WATT fryer on the same circuit or fuse with other electrical products or appliances may trip a 15-amp circuit breaker or blow a 15-amp fuse. NEVER replace the
fuse with one rated higher than the capacity of the circuit. Doing so could result in an electrical fire.
3. Hot oil can cause very serious burns. The appliance is hot during operation and retains heat for some time after being switched off. Do not touch hot surfaces such as oil reservoir or metal surface.
4. To protect against electrical shock, do not immerse the Heater Assembly or the Breakaway Cord
™
in water
or other liquids..
5. This appliance is not for use by children. Close supervision is necessary when any appliance is used near children.
6. Do not operate unattended, and never leave the appliance unattended when connected to the power outlet.
7. Always attach Breakaway Cord
™
to appliance first, then plug cord in wall outlet. To disconnect, turn the
switch to OFF, then remove plug from wall outlet.
8. Unplug the appliance from power outlet after use, and before filling and emptying. Detach Breakaway Cord
™
from appliance before cleaning.
9. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or has been damaged in any manner. Return appliance to NESCO Factory Service Department for examination, repair or adjustment.
10. Only use accessory attachments recommended by the manufacturer.
11. Do not use outdoors.
12. Do not let the cord hang over the edge of a table or counter, or touch hot surfaces.
13. Do not place on or near a hot gas or electric burner or in a heated oven.
14. DO NOT MOVE THE DEEP FRYER WHEN OIL IS HOT OR DURING COOKING. ALLOW OIL TO COOL BEFORE MOVING THIS APPLIANCE.
15. Do not use the appliance for other than intended use, as described in this manual.
16. Be sure Handle is properly assembled to basket and locked into place. See Illustration on page 5.
17. Always keep lid closed while deep fryer is cooking food. Use Basket Handle to raise and lower Basket. Always raise Basket out of hot oil and rest on hook to allow food to drain for 10-20 seconds before opening lid. BEWARE OF
STEAM WHEN OPENING LID.
18. Wet food should be dried first with paper towels. Remove loose ice from frozen food. Close the lid when frying. Beware of oil splattering when food is put into the oil.
19. Never obstruct the air outlet vent on top of the lid with any objects and beware of the hot steam coming from the air outlet vent.
20. Keep appliance at least 4 inches away from walls or other objects during operation. Do not place any objects on top of appliance while it is operating.
21. Be sure oil reservoir is filled with oil to at least the ‘MIN’ (minimum) oil level. Do not fill above ‘MAX’ (maximum). Do not operate appliance without oil or with an insufficient amount of oil. Never pour oil into heated reservoir.
22. Do not operate this appliance if the lid and the reservoir are NOT COMPLETELY DRY. Refer to the Cleaning
Instructions for the best draining position of the lid.
CAUTION: To prevent damage to countertop or tabletop finish, use a non-flammable, non­burnable, heat resistant coaster or placemat between the appliance and the countertop or tabletop surface. Never place on carpet, furniture, or other combustible materials.
SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY
4
DF-1250T Deep Fryer
SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLYShort Cord Instructions
CAUTION: A short power supply cord is provided to reduce the risk of personal injury resulting from becoming entangled in or tripping over a long cord.
Breakaway Cord
™
and Polarized Plug
This appliance features a patented Breakaway Cord
™
and polarized plug (one blade is wider than the other). The
Breakaway Cord
™
is designed to quickly disconnect from the appliance when a pulling force is applied. To reduce the risk of electric shock, a polarized plug is featured. This plug is intended to fit into a polarized outlet only. If the plug does not fit into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug.
Electric Power If electrical circuit is overloaded with other appliances, your appliance may not operate. It should be operated on a separate electrical circuit from other appliances. If you are not sure of the reason of overloading or
cannot find a separate circuit, contact a qualified electrician.
Get To Know Your Nesco DF-1250T Deep Fryer
Patented
Breakaway Cord
™
5
DF-1250T Deep Fryer
Directions for Use:
1. This appliance is designed for household and indoor use only. It is not intended for commercial use.
2. Before fryer is used the first time, remove all packaging materials and follow cleaning instructions in this book.
3. Lift off Lid covering Oil Reservoir.
4. Remove basket from Oil Reservoir. If required, unfold handle, snap into place on side of basket.
5. Pour approximately one gallon of good quality vegetable, corn, canola, soybean, or peanut oil into reservoir until
it reaches between ‘MIN’ and ‘MAX’ marks inside reservoir. DO NOT OVER OR UNDER FILL.
6. Put Lid on fryer.
7. Attach Breakaway Cord
™
to appliance, then plug into standard 120V AC electrical outlet.
8. Turn on fryer by pressing the main switch to ‘ON’. The green light will turn on showing that the appliance is
connected to power.
9. Rotate Temperature Control Knob to set the desired temperature. The red light will turn on and oil will heat.
When set temperature is reached the red light will turn off and your fryer is ready for cooking. If the red light turns back on, oil temperature has dropped and is being reheated back up to desired temperature. NOTE: If the oil is not heating see the Trouble Shooting section in this book.
10. Lift lid and place basket onto hook in Oil Reservoir. Put food into basket. Replace lid and then lower basket into
oil.
11. When food is ready, carefully lift and hang basket on hook inside Oil Reservoir. Allow oil to drain 10-20 seconds.
Open lid, remove basket, and place cooked food onto absorbent paper towels. NOTE: To preserve oil quality, do not add salt or spices to the food until after it has been removed from the fryer.
12. When cooking is finished, shut down fryer by rotating temperature control knob to position ‘O’ and press Main
Switch OFF. Unplug the Breakaway Cord
™
from the wall outlet before detaching from the appliance.
