Nec MULTISYNC LCD1560V+ User Guide

MultiSync

 





LCD1560V+

Index

Warning .................................................................................................................... 1

Contents ................................................................................................................. 2

Quick Start ............................................................................................................. 3

Controls ...................................................................................................................7

Recommended Use.............................................................................................. 10

Specifications .......................................................................................................12

Features .................................................................................................................13

Troubleshooting .................................................................................................. 14

References.............................................................................................................16

Limited Warranty ................................................................................................. 17

TCO’99 .....................................................................................................................18

Avertissement.....................................................................................................21

Contenu.................................................................................................................22

Mise en marche rapide......................................................................................23

Commandes..........................................................................................................27

Usage recommandé............................................................................................30

Fiche technique...................................................................................................32

Fonctions..............................................................................................................33

Dépannage............................................................................................................34

Références...........................................................................................................36

Garantie limitée..................................................................................................37

TCO’99 ....................................................................................................................38

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED. REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM

WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER CORD FROM THE AC OUTLET.DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This

symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause

electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included. Therefore, it should be read carefully in order to avoid any problems.

Canadian Department of Communications Compliance Statement

DOC: This Class B digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations

according to

CAN/CSA C22.2 No. 950.

FCC Information

Use the attached specified cables with the so as not to interfere with radio and television reception. (1)

Please use the supplied power cord or equivalent to ensure FCC compliance.

(2) Please use the supplied shielded video signal cable.

Use of other cables and adapters may cause interference with radio and television reception.

MultiSync LCD1560V+

(NL2501) color monitor

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult your dealer or an experienced radio/TV technician for help.

If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet, prepared by the Federal Communications Commission, helpful: ”How to Identify and Resolve Radio-TV Interference Problems.“ This booklet is available from the U.S. Government Printing Office, Washington, D.C., 20402, Stock No. 004-000-00345-4.

Contents

Your new NEC MultiSync® LCD monitor box* should contain the following:

• MultiSync LCD1560V+™ monitor with tilt base

• Power Cord

• Video Signal Cable

• User’s Manual

Power Cord

Video Signal Cable

MultiSync

LCD1560V+

User’s Manual

* Remember to save your original box and packing material to transport or ship the monitor.

Quick Start

To attach the MultiSync® LCD monitor to your system, follow these instructions:

1. Turn off the power to your computer.

2. Remove cable cover.

3. For the PC: Connect the 15-pin mini D-SUB of the appropriate signal cable to the

connector of the display card in your system (Figure A.1). Tighten all screws. For the Mac: Connect the MultiSync LCD1560V+ Macintosh cable adapter to the computer (Figure B.1). Attach the 15-pin mini D-SUB end of the appropriate signal cable to the MultiSync LCD1560V+ Macintosh cable adapter (Figure B.1). Tighten all screws.

NOTE: To obtain the MultiSync LCD1560V+ Macintosh cable adapter, call NEC-Mitsubishi

Electronics Display of America, Inc. at (800) 632-4662.

4. Connect the 15-pin mini D-SUB of the video signal cable to the appropriate connector

on the back of the monitor (Figure C.1).

5. Connect one end of the power cord to the MultiSync LCD Series monitor and the other end to the power outlet. Place the video signal cable and power cord under cable cover (Figure C.1). Replace cable cover.

NOTE: Adjust position of cable that place under cable cover, to avoid damage for cable

or monitor.

NOTE: If you use this monitor at AC125-240V, please refer to Recommended Use

section of this manual for proper selection of power cord.

6. The vacation switch on the right side of the monitor must be turned on (Figure D.1). Turn on the monitor with the front power button and the computer.

NOTE: The vacation switch is a true on/off switch. If this switch is on the OFF position,

the monitor cannot be turned on using the front button. DO NOT switch on/off repeatedly.

7. No-touch Auto Adjust automatically adjusts the monitor to optimal settings upon initial

setup for most timings. For further adjustments, use the following OSM

• Auto Adjust Contrast

• Auto Adjust Refer to the Controls section of this User ’s Manual for a full description of these

OSM controls.

NOTE: For download information on the Windows® 95/98/Me/2000/XP INF file for your MultiSync

LCD1560V+ monitor, refer to the References section of this User’s Manual.

NOTE: If you have any problems, please refer to the Troubleshooting section of this User’s Manual.

controls:

Quick Start –continued

Macintosh

Cable

Adapter

(not include)

Figure A.1

Figure B.1

Note: Some Macintosh systems do not require a Macintosh Cable Adapter

Cable Cover

Figure C.1

Figure D.1

Vacation

switch

Power button

Quick Start –continued

Non-abrasive surface

hinge cover

Tilt

Grasp both sides of the monitor screen with your hands and adjust the tilt as desired (Figure TS.1).

Remove Monitor Stand for Mounting

To prepare the monitor for alternate mounting purposes:

1.Disconnect all cables.

2.Place monitor face down on a non-abrasive surface (Figure R.1).

3.Remove the hinge cover (Figure R.1).

4.Remove the 4 screws connecting the monitor to the stand and lift off the stand assembly (Figure R.2). The monitor is now ready for mounting in an alternate manner.

5.Connect the AC cord and signal cable to the back of the monitor (Figure R.3).

6. Reverse this process to reattach stand.

NOTE: Use only VESA-compatible alternative mounting method. NOTE: Handle with care when removing monitor stand.

Figure R.1

Figure TS.1

Figure R.2

Figure R.3

Quick Start –continued

This LCD monitor is designed for use with a flexible arm. Please use the attached screws (4pcs) as shown in the picture when installing.

To meet the safety requirements, the monitor must be mounted to an arm which guaranties the necessary stability under consideration of the weight of the monitor.

The LCD monitor shall only be used with an approved arm (e.g. GS mark).

Thickness of Bracket(Arm)

2.0~3.2mm

Tighten all screws.

Specifications

If using other screws, check depth of hole.

Weight of LCD assembly: 2.8kg(MAX)

Controls

OSM® (On-Screen Manager) control buttons on the front of the monitor function as follows:

To access OSM menu, press any of the control buttons (<, > , –, +,

EXIT

EXIT Exits the OSM controls.

< / >

– / +

SELECT RESET Resets the highlighted control menu to the factory setting.

NOTE: When RESET is pressed in the main and sub-menu, a warning window allowing you to cancel the RESET function by pressing the EXIT button.

Exits to the OSM main menu. Moves the highlighted area left/right to select control menus.

Moves the highlighted area up/down to select one of the controls. Moves the bar left/right to increase or decrease the adjustment. Active Auto Adjust function. Enter the OSM controls. Enter the OSM sub menu.

Brightness/Contrast Controls

BRIGHTNESS

Adjusts the overall image and background screen brightness.

CONTRAST

Adjusts the image brightness in relation to the background.

AUTO

Adjusts the image displayed for non-standard video inputs.

Auto Adjust

Automatically adjusts the Image Position and H. Size settings and Fine settings.

Image Controls

LEFT / RIGHT

Controls Horizontal Image Position within the display area of the LCD.

DOWN / UP

Controls Vertical Image Position within the display area of the LCD.

H.SIZE

Adjusts the horizontal size by increasing or decreasing this setting.

FINE

Improves focus, clarity and image stability by increasing or decreasing this setting.

will appear

Controls –continued

AccuColor® Control Systems

AccuColor Control Systems: Six color presets select the desired color setting. (NATIVE color preset cannot be changed.)

R,G,B : Increases or decreases Red, Green or Blue color depending upon which is selected. The change in color will appear on screen and the direction (increase or decrease) will be shown by the bars.

NATIVE: Original color displayed by the LCD panel that is unadjustable.

Tools

LANGUAGE: OSM control menus are available in seven languages. OSM Position: You can choose where you would like the OSM control

image to appear on your screen. Selecting OSM Location allows you to manually adjust the position of the OSM control menu left, right, down or up.

OSM TURN OFF: The OSM control menu will stay on as long as it is in use. In

the OSM Turn Off submenu, you can select how long the monitor waits after the last touch of a button to shut off the OSM control menu. The preset choices are 10, 20, 30, 45, 60 and 120 seconds.

OSM LOCK OUT: This control completely locks out access to all OSM control functions without Brightness and Contrast. When attempting to activate OSM controls while in the Lock Out mode, a screen will appear indicating the OSM controls are locked out. To activate the OSM Lock Out function, press SELECT, then “+” key and hold down simultaneously. To de-activate the OSM Lock Out, press SELECT, then “+” key and hold down simultaneously.

RESOLUTION NOTIFIER: This optimal resolution is 1024 x 768. If ON is selected, a message will appear on the screen after 30 seconds, notifying you

that the resolution is not at 1024 x 768. HOT KEY: You can adjust the brightness and contrast directly. When this

function is set to ON, you can adjust the brightness with + or - key, while the OSM menu is off.

OFF TIMER: Monitor will automatically power-down when the end user has selected a pre-determined amount of time.

FACTORY PRESET: Selecting Factory Preset allows you to reset all OSM control settings back to the factory settings. The RESET button will need to be held down for several seconds to take effect. Individual settings can be reset by highlighting the control to be reset and pressing the RESET button.

< or

>, contrast with

Controls –continued

Information

DISPLAY MODE: Indicates the current display resolution and frequency setting of the monitor.

MONITOR INFO.: Indicates the model and serial numbers of your monitor.

OSM Warning: OSM Warning menus disappear with Exit button. NO SIGNAL: This function gives a warning when there is no signal present. After power is turned on or when there is a change of input signal or video is inactive, the No Signal window will appear. RESOLUTION NOTIFIER: This function gives a warning of use with optimized resolution. After power is turned on or when there is a change of input signal or the video signal doesn’t have proper resolution, the Resolution Notifier window will open. This function can be disabled in the TOOL menu. OUT OF RANGE: This function gives a recommendation of the optimized resolution and refresh rate. After the power is turned on or there is a change of input signal or the video signal doesn’t have proper timing, the Out Of Range menu will appear.

Recommended Use

Safety Precautions and Maintenance

FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE

FOLLOWING WHEN SETTING UP AND USING

THE MULTISYNC® LCD COLOR MONITOR:

• DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or

removing covers may expose you to dangerous shock hazards or other risks. Refer all servicing to qualified service personnel.

• Do not spill any liquids into the cabinet or use your monitor near water.

• Do not insert objects of any kind into the cabinet slots, as they may touch dangerous voltage

points, which can be harmful or fatal or may cause electric shock, fire or equipment failure.

• Do not place any heavy objects on the power cord. Damage to the cord may cause shock or fire.

• Do not place this product on a sloping or unstable cart, stand or table, as the monitor may fall,

causing serious damage to the monitor.

• When operating the MultiSync LCD monitor with its AC 125-240V power supply, use a power

supply cord that matches the power supply voltage of the AC power outlet being used. The power supply cord you use must have been approved by and comply with the safety standards of your country. (Type H05VV-F should be used in Europe)

• In UK, use a BS-approved power cord with molded plug having a black (5A) fuse installed for use with

this monitor. If a power cord is not supplied with this monitor, please contact your supplier.

• Do not place any objects onto the monitor and do not use the monitor outdoors.

• The inside of the flourescent tube located within the LCD monitor contains mercury.

Please follow the bylaws or rules of your municipality to dispose of the tube properly.

Immediately unplug your monitor from the wall outlet and refer servicing to qualified service personnel under the following conditions:

• When the power supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the monitor.

• If the monitor has been exposed to rain or water.

• If the monitor has been dropped or the cabinet damaged.

• If the monitor does not operate normally by following operating instructions.

• Do not bend power cord.

• Do not use monitor in high temperatured, humid, dusty, or oily areas.

• If glass is broken, handle with care.

• Do not cover vent on monitor.

• If monitor or glass is broken, do not come in contact with the liquid crystal and handle with care.

• Allow adequate ventilation around the monitor so that heat can properly

dissipate. Do not block ventilated openings or place the monitor near a radiator or other heat sources. Do not put anything on top of monitor.

• The power cable connector is the primary means of detaching the system

CAUTION

Image Persistence

Image persistence is when a residual or “ghost ” image of a previous image remains visible on the screen. Unlike CRT monitors, LCD monitors’ image persistence is not permanent, but constant images being displayed for a long period of time should be avoided.

To alleviate image persistence, turn off the monitor for as long as the previous image was displayed. For example, if an image was on the monitor for one hour and a residual image remains, the monitor should be turned off for one hour to erase the image.

NOTE: As with all personal display devices, NEC-Mitsubishi Electronics Display recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.

from the power supply. The monitor should be installed close to a power outlet which is easily accessible.

• Handle with care when transporting. Save packaging for transporting.

Recommended Use –continued

CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR

CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE

FOLLOWING WHEN YOU POSITION THE MONITOR:

• For optimum performance, allow 20 minutes for

warm-up.

• Adjust the monitor height so that the top of the

screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.

•

Position your monitor no closer than 16 inches and no further away than 28 inches from your eyes. The optimal distance is 20 inches.

• Rest your eyes periodically by focusing on an

object at least 20 feet away. Blink often.

• Position the monitor at a 90° angle to windows and other light sources to

minimize glare and reflections. Adjust the monitor tilt so that ceiling lights do not reflect on your screen.

• If reflected light makes it hard for you to see your screen, use an anti-glare filter.

• Clean the LCD monitor surface with a lint-free, non-abrasive cloth. Avoid using

any cleaning solution or glass cleaner!

• Adjust the monitor’s brightness and contrast controls to enhance readability.

• Use a document holder placed close to the screen.

• Position whatever you are looking at most of the time (the screen or

reference material) directly in front of you to minimize turning your head while you are typing.

• Avoid displaying fixed patterns on the monitor for long periods of time to avoid

image persistence (after-image effects).

• Get regular eye checkups.

Ergonomics

To realize the maximum ergonomics benefits, we recommend the following:

•

Use the preset Size and Position controls with standard signals

•

Use the preset Color Setting

•

Use non-interlaced signals with a vertical refresh rate between 60-75Hz

•

Do not use primary color blue on a dark background, as it is difficult to see and may produce eye fatigue to insufficient contrast

For more detailed information on setting up a healthy work environment, write the American National Standard for Human Factors Engineering of Visual Display Terminal Workstations – ANSI-HFS Standard No. 100-1988 – The Human Factors Society, Inc. P.O. Box 1369, Santa Monica, California 90406.

Specifications

Monitor MultiSync® LCD1560V+

™

Notes

Specifications Monitor

LCD Module Diagonal: 15.0 inch Active matrix; thin film transistor (TFT)

Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms

Display Colors Analog input: 16,194,277 Dependent on display card used. Maximum Left/right: 60°/60 ° (CR > 10)

Viewing Angles Up/Down: 45°/45 ° (CR > 10) Synchronization Horizontal: 31.5 kHz to 60.0 kHz Automatically

Range Vertical: 56.2 Hz to 75.1 Hz Automatically Resolutions Supported 720 x 400*

Active Display Area Horizontal :

Power Supply Current Rating 0.4 A

Dimensions

Weight 3.7 kg

Environmental Considerations

Viewable Image Size: 15.0 inch liquid crystal display (LCD); 0.297 mm dot

Native Resolution (Pixel Count): 1024 x 768 pitch; 250cd/m

Sync: Separate sync TTL Level

Horizontal sync Positive/Negative Vertical sync Positive/Negative

240 V –

0.2 A

:VGA text

at 75 Hz

~ 50/60 Hz

640 x 480*1 at 60 Hz to 75 Hz 800 x 600*1 at 56 Hz to 75 Hz 832 x 624*

1024 x 768 at 60 Hz to 75 Hz ..................

Vertical :

Operating Temperature: 5°C to 35°C/41°F to 95°F

Humidity: 30% to 80%

Storage Temperature: -10°C to 60°C/14°F to 140°F

Humidity: 10% to 85%

304 mm/12.0 inches 228 mm/9.0 inches

100 –

344.8 mm (W) x 344.2 mm (H) x 166.0 mm (D)

13.6 inches (W) x 13.6 inches (H) x 6.5 inches (D)

8.2 lbs

Feet: 0 to 10,000 Feet

Feet: 0 to 40,000 Feet

350:1 contrast ratio, typical

Some systems may not support all modes listed.

NEC-Mitsubishi Electronics Display cites recommended resolution at 75 Hz for optimal display performance.

white luminence;

*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is

normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.

NOTE: Technical specifications are subject to change without notice.

+ 30 hidden pages
