NEC EX201W-BK User manual

MultiSync EX201W
MultiSync EX231W

MultiSync EX231Wp

User’s Manual

Index

Warning, Caution .........................................................................................................................English-1

Registration Information ...............................................................................................................English-1

Recommended use ......................................................................................................................English-3

Contents ....................................................................................................................................... English-5

Quick Start ...................................................................................................................................English-6

Controls ...................................................................................................................................... English-10

Specifications - EX201W ...........................................................................................................English-16

Specifications - EX231W ...........................................................................................................English-17

Specifications - EX231Wp .........................................................................................................English-18

Features .....................................................................................................................................English-19

Troubleshooting .........................................................................................................................English-20

Using the Auto Brightness function ............................................................................................English-21

TCO Displays 5 ..........................................................................................................................English-22

Manufacturer’s Recycling and Energy Information ....................................................................English-23

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT
USE THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS
THE PRONGS CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM

WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE
POWER CORD FROM THE AC OUTLET. DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit
has been included. Therefore, it should be read carefully in order to avoid any problems.

CAUTION: Please use the power cord provided with this display in accordance with the table below. If a power cord is not
supplied with this equipment, please contact your supplier. For all other cases, please use a power cord that matches the
AC voltage of the power outlet and has been approved by and complies with the safety standard of your particular country.

Plug Type North America

European

Continental

U.K. Chinese Japanese

English

Plug Shape

Country

Voltage

*When operating the MultiSync monitor with its AC 125-240V power supply, use a power supply cord that matches the power

supply voltage of the AC power outlet being used.

NOTE: This product can only be serviced in the country where it was purchased.

U.S.A./Canada U.K. China JapanEU (except U.K.)

120* 230 220 100*230

Registration Information

Declaration

Declaration of the Manufacturer

We hereby certify that the colour monitor MultiSync
EX201W (L200UF)/MultiSync EX231W (L230NW)/
MultiSync EX231Wp (L230UH) are in compliance with

Council Directive 2006/95/EC:

– EN 60950-1

Council Directive 2004/108/EC:

– EN 55022
– EN 61000-3-2
– EN 61000-3-3
– EN 55024

Council Directive 2009/125/EC:

EC No.1275/2008
– EN 62301:2005

and marked with

NEC Display Solutions, Ltd.

4-13-23, Shibaura,

Minato-Ku

Tokyo 108-0023, Japan

English-1

Canadian Department of Communications Compliance Statement

DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2 No. 60950-1.

FCC Information

1. Use the attached specified cables with the MultiSync EX201W (L200UF)/MultiSync EX231W (L230NW)/MultiSync
EX231Wp (L230UH) color monitor so as not to interfere with radio and television reception.

(1) The power supply cord you use must have been approved by and comply with the safety standards of U.S.A.,

and meet the following condition.

Power supply cord Non shield type, 3-conductor
Plug shape

U.S.A
(2) Please use the supplied AC Adapter.
(3) Please use the supplied shielded video signal cable, 15-pin mini D-SUB to DVI-A cable or DVI-D to DVI-D cable.

Use of other cables and adapters may cause interference with radio and television reception.

2. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult your dealer or an experienced radio/TV technician for help.

If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions.
The user may find the following booklet, prepared by the Federal Communications Commission, helpful: “How to Identify
and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Office,
Washington, D.C., 20402, Stock No. 004-000-00345-4.

Declaration of Conformity

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.

U.S. Responsible Party: NEC Display Solutions of America, Inc.
Address: 500 Park Blvd, Suite 1100

Itasca, Illinois 60143

Tel. No.: [phone]

Type of Product: Display Monitor

Equipment Classification: Class B Peripheral

Models: MultiSync EX201W (L200UF)

MultiSync EX231W (L230NW)
MultiSync EX231Wp (L230UH)

We hereby declare that the equipment specified above conforms

to the technical standards as specified in the FCC Rules.

Windows is a registered trademark of Microsoft Corporation. NEC is a registered trademark of NEC Corporation.
ENERGY STAR is a U.S. registered trademark.
ErgoDesign is a registered trademark of NEC Display Solutions, Ltd. in Austria, Benelux, Denmark, France, Germany, Italy,
Norway, Spain, Sweden, U.K.
NaViSet is a trademark of NEC Display Solutions Europe GmbH in the countries of EU and Switzerland.
MultiSync is a registered trademark of NEC Display Solutions, Ltd. in the countries of U.K., Italy, Austria, Netherlands,
Switzerland, Sweden, Spain, Denmark, Germany, Norway and Finland.
All other brands and product names are trademarks or registered trademarks of their respective owners.
As an ENERGY STAR® Partner, NEC Display Solutions of America, Inc. has determined that this product meets
the ENERGY STA R guidelines for energy efficiency. The ENERGY STA R emblem does not represent EPA
endorsement of any product or service.
DisplayPort is trademarks of Video Electronics Standards Association.

English-2

Recommended use

Safety Precautions and Maintenance

FOR OPTIMUM PERFORMANCE, PLEASE NOTE

THE FOLLOWING WHEN SETTING UP AND USING

THE MULTISYNC LCD COLOUR MONITOR:

• DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or removing covers may expose

you to dangerous shock hazards or other risks. Refer all servicing to qualified service personnel.

• Do not spill any liquids into the cabinet or use your monitor near water.

• Do not insert objects of any kind into the cabinet slots, as they may touch dangerous voltage points, which can be harmful

or fatal or may cause electric shock, fire or equipment failure.

• Do not place any heavy objects on the power cord. Damage to the cord may cause shock or fire.

• Do not place this product on a sloping or unstable cart, stand or table, as the monitor may fall, causing serious damage to

the monitor.

• The power supply cord you use must have been approved by and comply with the safety standards of your country.

(Type H05VV-F 3G 0.75mm

• In U.K, use a BS-approved power cord with molded plug having a black (5A) fuse installed for use with this monitor.

• Do not place any objects onto the monitor and do not use the monitor outdoors.

• Use supplied AC Adapter. Do not place any objects onto the AC Adapter and do not use the AC Adapter outdoors.

• Do not bend, crimp or otherwise damage the power cord.

• Do not use monitor in high temperatured, humid, dusty, or oily areas.

• Do not cover monitor and AC adapter.

• Do not touch LCD panel surface while transporting, mounting and setting. Applying pressure on the LCD panel can cause

serious damage.

• To prevent damage to the LCD monitor caused by tipping over due to earthquakes or other shocks, make sure to install

the monitor in a stable location and take measures to prevent falling.

Immediately unplug your monitor from the wall outlet and refer servicing to qualified service personnel under the following
conditions:

• When the power supply cord or plug is damaged.

• When AC adapter is damaged.

• If liquid has been spilled, or objects have fallen into the monitor.

• If the monitor has been exposed to rain or water.

• If the monitor has been dropped or the cabinet damaged.

• If the monitor does not operate normally by following operating instructions.

• If you notice any structural damage such as cracks or unnatural wobbling.

• If glass is broken, handle with care.

• If monitor or glass is broken, do not come in contact with the liquid crystal and handle with care.

• Allow adequate ventilation around the monitor so that heat can properly dissipate.
Do not block ventilated openings or place the monitor near a radiator or other heat

CAUTION

• Image Persistence: Please be aware that LCD Technology may experience a phenomenon known as Image Persistence.
Image Persistence occurs when a residual or “ghost” image of a previous image remains visible on the screen. Unlike
CRT monitors, LCD monitors’ image persistence is not permanent, but constant images being displayed for a long period
of time should be avoided. To alleviate image persistence, turn off the monitor for as long as the previous image was
displayed. For example, if an image was on the monitor for one hour and a residual image remains, the monitor should be
turned off for one hour to erase the image.

NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying moving images and
using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.

sources. Do not put anything on top of monitor.

• The power cable connector is the primary means of detaching the system from the
power supply. The monitor should be installed close to a power outlet which is easily
accessible.

• Handle with care when transporting. Save packaging for transporting.

• Carry the monitor holding the built-in handle and bottom frames of the monitor.

• Do not carry holding only the stand.

2

should be used in Europe).

English

English-3

CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR CAN

REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE

FOLLOWING WHEN YOU POSITION THE MONITOR:

• For optimum performance, allow 20 minutes for warm-up.

• Adjust the monitor height so that the top of the screen is at or slightly below eye level.
Your eyes should look slightly downward when viewing the middle of the screen.

• Position your monitor no closer than 40 cm and no further away than 70 cm from your
eyes. The optimal distance is 50 cm.

• Rest your eyes periodically by focusing on an object at least 20 feet away. Blink often.

• Position the monitor at a 90° angle to windows and other light sources to minimize
glare and reflections. Adjust the monitor tilt so that ceiling lights do not reflect on your
screen.

• If reflected light makes it hard for you to see your screen, use an anti-glare filter.

• Adjust the monitor’s brightness and contrast controls to enhance readability.

• Use a document holder placed close to the screen.

• Position whatever you are looking at most of the time (the screen or reference material) directly in front of you to minimize
turning your head while you are typing.

• Avoid displaying fixed patterns on the monitor for long periods of time to avoid image persistence (after-image effects).

• Get regular eye checkups.

Ergonomics

To realize the maximum ergonomics benefits, we recommend the following:

• Adjust the Brightness until the background raster disappears.

• Do not position the Contrast control to its maximum setting.

• Use the preset Size and Position controls with standard signals.

• Use the preset Colour Setting.

• Use non-interlaced signals with a vertical refresh rate between 60-75 Hz.

• Do not use primary colour blue on a dark background, as it is difficult to see and may produce eye fatigue to insufficient
contrast.

Cleaning the LCD Panel

• When the liquid crystal panel is stained with dust or dirt, please wipe with soft cloth gently.

• Please do not rub the LCD panel with hard material.

• Please do not apply pressure to the LCD surface.

• Please do not use OA cleaner it will cause deterioration or discolor on the LCD surface.

Cleaning the Cabinet

• Unplug the power supply cord from the wall outlet.

• Gently wipe the cabinet with a soft cloth

• To clean the cabinet, dampen the cloth with a neutral detergent and water, wipe the cabinet and follow with a dry cloth.

NOTE: Many plastics are used on the surface of the cabinet. DO NOT clean with benzene, thinner, alkaline detergent,

alcoholic system detergent, glass cleaner, wax, polish cleaner, soap powder, or insecticide. Do not touch rubber or
vinyl to the cabinet for a long time. These types of fluids and fabrics can cause the paint to deteriorate, crack or
peel.

English-4

Contents

Your new NEC MultiSync LCD monitor box* should contain the following:

• MultiSync LCD Monitor

• Power Cord

• AC Adapter

• Stand

• Base Stand

• AC Adapter Holder

• Cable Holder

• Video Signal Cable (15-pin mini D-SUB male to DVI-A)

• Video Signal Cable (DVI-D to DVI-D)

• USB Cable

• Setup Manual

• CD-ROM (includes complete User’s Manual in PDF format).

English

CD-ROM

AC Adapter

Power Cord*

15-pin mini D-SUB male to DVI-A

1

DVI-D to DVI-D

Setup

Manual

Base Stand

Stand

USB Cable

Setup Manual

AC Adapter Holder

* Remember to save your original box and packing material to transport or ship the monitor.
*1 Type of power cord included will depend on the where the LCD monitor is to be shipped

English-5

Cable Holder

Quick Start

To attach the Base to the LCD stand:

1. Place monitor face down on a non-abrasive surface (Figure 1).

NOTE: Handle with care when placing monitor face down to avoid damaging the front control keys.

2. Put the upper hooks of the stand in the slot of the monitor then push stand into monitor in direction
of the arrow as shown in Figure 1 and confirm that the stand is locked.

NOTE: Handle with care when pulling the stand.

3. Attach the base stand to stand and turn the connecting screw at the bottom of the base
stand fully so that it is completely fixed (Figure 2).

NOTE: Reverse this procedure if you need to re-pack the monitor.

To attach the MultiSync LCD monitor to your computer system, follow these instructions:

1. Turn off the power of your computer.

2. For PC or MAC with DVI digital output: Connect the DVI signal cable to the
connector of the display card in your system (Figure A.1). Tighten all screws.

For PC with Analog output: Connect the 15-pin mini D-SUB to DVI-A signal cable
to the connector of the display card in your system (Figure A.2). Tighten all screws.

For MAC: Connect the Macintosh cable adapter to the computer, then attach the
15-pin mini D-SUB to DVI-A signal cable to the Macintosh cable adapter (Figure A.3).
Tighten all screws.

For PC with DisplayPort output: Connect the DisplayPort cable to the connector of the
display card in your system (Figure A.4).

Figure 1

Screw

Figure 2

DVI signal cable

Figure A.1

NOTE: Some Macintosh systems do not require a Macintosh cable adapter.

3. Place hands on each side of the monitor to tilt the LCD panel
30-degree angle and lift up to the highest position (Figure B.1).

4. Connect all cables to the appropriate connectors on the back of
the monitor, plug the captive power cord into the AC adapter
(Figure B.1). When using the USB cable, connect the B type
connector to the USB upstream port on the right back side
of the monitor and the A type connector to the downstream
port on the computer (Figure B.1a). If you can use the
cord from the USB device, use the downstream ports on
the back-Top side of the monitor.

5. Place AC adapter holder and cable holder onto the stand (Figure B.2).

6. Position the Video Signal Cable and AC adapter between the holes
on the cable holder, as indicated in Figure B.2/Figure B.3.
Position the AC adapter between the holes on the AC adapter
holder, as indicated in Figure B.2.

Figure A.2

Macintosh
Cable Adapter
(not included)

USB downstream port

Highest stand position

Figure A.3

Power Cord

DisplayPort cable
(not included)

30˚ Tilt

Figure B.1

Figure A.4

DisplayPort

DVI

USB upstream
port

English-6
