Nec EA274WMI User Manual

MultiSync EA274WMi MultiSync EA304WMi

User’s Manual

Index

Warning, Caution ..........................................................................................................................English-1

Registration Information ...............................................................................................................English-2

Recommended use ......................................................................................................................English-3

Contents .......................................................................................................................................English-5

Quick Start ....................................................................................................................................English-6

Controls ........................................................................................................................................English-11

Speciﬁ cations - EA274WMi ..........................................................................................................English-18

Speciﬁ cations - EA304WMi ..........................................................................................................English-19

Features .......................................................................................................................................English-20

Troubleshooting ............................................................................................................................English-21

Using the Auto Brightness function ..............................................................................................English-23

ControlSync ..................................................................................................................................English-24

TCO Certiﬁ ed Edge Displays 2.0 .................................................................................................English-25

Manufacturer’s Recycling and Energy Information .......................................................................English-26

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED

FROM WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER CORD FROM THE AC OUTLET.DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may have sufﬁ cient magnitude to cause

electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit

has been included. Therefore, it should be read carefully in order to avoid any problems.

CAUTION: Please use the power cord provided with this display in accordance with the table below. If a power cord is not supplied with this equipment, please contact your supplier. For all other cases, please use a power cord that matches the AC voltage of the power outlet and has been approved by and complies with the safety standard of your particular country.

Plug Type North America

European

Continental

U.K. Chinese Japanese

English

Plug Shape

Country

Voltage

U.S.A./Canada U.K. China JapanEU (except U.K.)

120* 230 220 100230

* When operating the monitor with its AC 125-240V power supply, use a power supply cord that matches the power supply

voltage of the AC power outlet being used.

NOTE: This product can only be serviced in the country where it was purchased.

Windows is a registered trademark of Microsoft Corporation. NEC is a registered trademark of NEC Corporation. ErgoDesign is a registered trademark of NEC Display Solutions, Ltd. in Austria, Benelux, Denmark, France, Germany, Italy, Norway, Spain, Sweden, U.K.

NERGY STAR is a U.S. registered trademark.

All other brands and product names are trademarks or registered trademarks of their respective owners. As an E

NERGY STAR

meets the E

Partner, NEC Display Solutions of America, Inc. has determined that this product

NERGY STAR guidelines for energy efﬁ ciency. The ENERGY STAR emblem does not represent EPA

endorsement of any product or service. DisplayPort and DisplayPort Compliance Logo are trademarks owned by the Video Electronics Standards Association.

HDMI, the HDMI logo and High-Deﬁ nition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

• The intended primary use of this product is as an Information Technical Equipment in an ofﬁ ce or domestic environment.

• The product is intended to be connected to a computer and is not intended for the display of television broadcast signals.

English-1

Registration Information

FCC Information

1. Use the attached speciﬁ ed cables with the MultiSync EA274WMi (L273QL)/MultiSync EA304WMi (L303QW) monitor so as not to interfere with radio and television reception.

(1) The power supply cord you use must have been approved by and comply with the safety standards of U.S.A., and meet the following condition.

Power supply cord Length Plug shape

(2) Please use the supplied shielded video signal cable. Use of other cables and adapters may cause interference with radio and television reception.

2. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult your dealer or an experienced radio/TV technician for help.

Non shield type, 3-conductor

1.8 m

U.S.A

If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions. The user may ﬁ nd the following booklet, prepared by the Federal Communications Commission, helpful: “How to Identify and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Ofﬁ ce, Washington, D.C., 20402, Stock No. 004-000-00345-4.

Declaration of Conformity

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

U.S. Responsible Party: NEC Display Solutions of America, Inc. Address: 500 Park Boulevard, Suite 1100 Itasca, Illinois 60143 Tel. No.: (630) 467-3000

Type of Product: Display Monitor

Equipment Classiﬁ cation: Class B Peripheral

Model: MultiSync EA274WMi (L273QL) MultiSync EA304WMi (L303QW)

We hereby declare that the equipment speciﬁ ed above conforms

to the technical standards as speciﬁ ed in the FCC Rules.

English-2

Recommended use

Safety Precautions and Maintenance

FOR OPTIMUM PERFORMANCE, PLEASE NOTE

THE FOLLOWING WHEN SETTING UP AND

USING THE LCD COLOR MONITOR:

• DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or removing covers may expose

you to dangerous shock hazards or other risks. Refer all servicing to qualiﬁ ed service personnel.

• Do not spill any liquids into the cabinet or use your monitor near water.

• Do not insert objects of any kind into the cabinet slots, as they may touch dangerous voltage points, which can be harmful or

fatal or may cause electric shock, ﬁ re or equipment failure.

• Do not place any heavy objects on the power cord. Damage to the cord may cause shock or ﬁ re.

• Do not place this product on a sloping or unstable cart, stand or table, as the monitor may fall, causing serious damage to

the monitor.

• The power supply cord you use must have been approved by and comply with the safety standards of your country.

(Type H05VV-F 3G 1mm

• In UK, use a BS-approved power cord with molded plug having a black (5A) fuse installed for use with this monitor.

• Do not place any objects onto the monitor and do not use the monitor outdoors.

• Do not bend power cord.

• Do not use monitor in high temperatured, humid, dusty, or oily areas.

• Do not cover vent on monitor.

• Vibration can damage the backlight. Do not install where the monitor will be exposed to continual vibration.

• If monitor or glass is broken, do not come in contact with the liquid crystal and handle with care.

• To prevent damage to the LCD monitor caused by tipping over due to earthquakes or other shocks, make sure to install the

monitor in a stable location and take measures to prevent falling.

Immediately turn off the power, unplug your monitor from the wall outlet and move to a safe location then refer servicing to qualiﬁ ed service personnel under the following conditions. If the monitor is used in this condition, the monitor may cause fall, ﬁ re and electric shock:

• If the monitor stand has been cracked or peeled.

• If the monitor has been wobbled.

• If the monitor has an unusual odor.

• When the power supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the monitor.

• If the monitor has been exposed to rain or water.

• If the monitor has been dropped or the cabinet damaged.

• If the monitor does not operate normally by following operating instructions.

• Allow adequate ventilation around the monitor so that heat can properly dissipate. Do not block ventilated

CAUTION

Image Persistence: Image persistence is when a residual or “ghost” image of a previous image remains visible on the screen. Unlike CRT monitors, LCD monitors’ image persistence is not permanent, but constant images being displayed for a long period of time should be avoided.

To alleviate image persistence, turn off the monitor for as long as the previous image was displayed. For example, if an image was on the monitor for one hour and a residual image remains, the monitor should be turned off for one hour to erase the image.

NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.

• The power cable connector is the primary means of detaching the system from the power supply.

• Handle with care when transporting. Save packaging for transporting.

• Do not touch LCD panel surface while transporting, mounting and setting.

should be used in Europe).

openings or place the monitor near a radiator or other heat sources. Do not put anything on top of monitor.

The monitor should be installed close to a power outlet which is easily accessible.

Applying pressure on the LCD panel can cause serious damage.

English

English-3

CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR CAN

REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE

FOLLOWING WHEN YOU POSITION THE MONITOR:

• For optimum performance, allow 20 minutes for the display to warm up.

• Adjust the monitor height so that the top of the screen is at or slightly below eye level.

Your eyes should look slightly downward when viewing the middle of the screen.

• Position your monitor no closer than 40 cm (15.75 inches) and no further away than

70 cm (27.56 inches) from your eyes. The optimal distance is 50 cm (19.69 inches).

• Rest your eyes periodically by focusing on an object at least 20 feet away. Blink often.

• Position the monitor at a 90° angle to windows and other light sources to minimize glare

and reﬂ ections. Adjust the monitor tilt so that ceiling lights do not reﬂ ect on your screen.

• If reﬂ ected light makes it hard for you to see your screen, use an anti-glare ﬁ lter.

• Clean the LCD monitor surface with a lint-free, non-abrasive cloth. Avoid using any

cleaning solution or glass cleaner!

• Adjust the monitor’s brightness and contrast controls to enhance readability.

• Use a document holder placed close to the screen.

• Position whatever you are looking at most of the time (the screen or reference material) directly in front of you to minimize

turning your head while you are typing.

• Avoid displaying ﬁ xed patterns on the monitor for long periods of time to avoid image persistence (after-image effects).

• Get regular eye checkups.

Ergonomics

To realize the maximum ergonomics beneﬁ ts, we recommend the following:

• To avoid eye fatigue, adjust the brightness to a moderate setting. Place a sheet of white paper next to the LCD screen for

luminance reference.

• Do not position the Contrast control to its maximum setting.

• Use the preset Size and Position controls with standard signals.

• Use the preset Color Setting.

• Use non-interlaced signals with a vertical refresh rate of 60 Hz.

• Do not use primary color blue on a dark background, as it is difﬁ cult to see and may produce eye fatigue due to insufﬁ cient

contrast.

Cleaning the LCD Panel

• When the LCD is dusty, please gently wipe with a soft cloth.

• Please do not rub the LCD panel with hard or coarse material.

• Please do not apply pressure to the LCD surface.

• Please do not use OA cleaner as it will cause deterioration or discoloration on the LCD surface.

Cleaning the Cabinet

• Unplug the power supply

• Gently wipe the cabinet with a soft cloth

• To clean the cabinet, dampen the cloth with a neutral detergent and water, wipe the cabinet and follow with a dry cloth.

NOTE: Many plastics are used on the surface of the cabinet. DO NOT clean with benzene, thinner, alkaline detergent,

alcoholic system detergent, glass cleaner, wax, polish cleaner, soap powder, or insecticide. Do not touch rubber or vinyl to the cabinet for a long time. These types of ﬂ uids and fabrics can cause the paint to deteriorate, crack or peel.

For more detailed information on setting up a healthy work environment, write to the American National Standard for Human Factors Engineering of Computer Workstations - ANSI/HFES 100-2007 - The Human Factors Society, Inc. P.O. Box 1369, Santa Monica, California 90406.

English-4

Your new NEC monitor box* should contain the following:

• MultiSync monitor with tilt/swivel/pivot/height adjust stand

• Power Cord*

• Video Signal Cable (DVI-D to DVI-D cable)*

• Video Signal Cable (DisplayPort cable)

• USB Cable*

• ControlSync Cable (ø 2.5 stereo micro plug)

• Setup Manual.

2, *4

English

Power Cord*

DisplayPort cable

Setup Manual

ControlSync Cable

Setup Manual DVI-D to DVI-D cable*

USB Cable*

2, *4

* Remember to save your original box and packing material to transport or ship the monitor.

The type and number of power cords included will depend on the where the LCD monitor is to be shipped. When more than one power cord

is included, please use the power cord that matches the AC voltage of the power outlet and has been approved by and complies with the safety standard of your particular country.

Dual link DVI cable.

USB 3.0 cable.

The type and number of cables included will depend on the where the LCD monitor is to be shipped.

English-5

Quick Start

Macintosh Cable Adapter (not included)

To connect the LCD monitor to your system, follow these instructions:

NOTE: Make sure to read “Recommended Use” (page 3) before installation.

1. Turn off the power of your computer.

2. For a PC with DisplayPort output: Connect the DisplayPort cable to the connector of the display card in your system

(Figure A.1).

For a PC or MAC with DVI digital output: Connect the DVI signal cable to the connector of the display card in your system

(Figure A.2). Tighten all screws. For a PC with HDMI output: Connect the HDMI cable to the connector of the display card in your system (Figure A.3). For a PC with Analog output: Connect a 15-pin mini D-SUB signal cable to the connector of the display card in your

system (Figure A.4). For a MAC: Connect a Macintosh cable adapter (not included) to the computer, then attach the 15-pin mini D-SUB signal

cable to the Macintosh cable adapter (Figure A.5).

NOTE: Some Macintosh systems do not require any Macintosh cable adapter.

DisplayPort cable DVI cable*

HDMI cable (not included)

Figure A.1 Figure A.3Figure A.2

15-pin mini D-SUB cable (not included)

Macintosh Cable Adapter (not included)

Figure A.4 Figure A.5

NOTE: 1. When removing the DisplayPort cable, hold down the top button to release the lock.

2. Please use a High Speed HDMI cable with HDMI logo.

*1 The type and number of cables included will depend on the where the LCD monitor is to be shipped.

English-6

3. Place hands on each side of the monitor to tilt the LCD panel 30-degree angle and lift up to the highest position.

DisplayPort

Audio Input

USB 3.0 Downstream

USB 3.0 Upstream

EA304WMi

4. Connect all cables to the appropriate connectors (Figure C.1). When using the USB cable, connect the B type connector

to the USB upstream port on the right back side of the monitor and the A type connector to the downstream port on the

computer (Figure C.1a). If using the cord from a USB device, plug into the downstream port of the monitor.

NOTE: Incorrect cable connections may cause abnormal operation, damage display quality/components of LCD module and/

or shorten the module’s life.

NOTE: Use an audio cable without a built-in resistor. Using an audio cable with a built-in resistor turns down the sound.

30° Tilt

EA274WMi

USB 2.0 Downstream

A Type

English

Highest

Headphone

USB 2.0 Downstream

B Type

Stand

Position

EA304WMi

Headphone

B Type

Figure C.1a

Audio Input

HDMI

DisplayPort D-SUB

ControlSync IN/OUT*

DVI*

USB 3.0 Upstream

USB 3.0 Downstream

Power cord

Figure C.1

*: See page 24. *1: DualLink.

5. To keep the cables neatly organized, place them into the cable management system that is built into the stand. Place the cables in the hooks ﬁ rmly and evenly (Figure C.2 and Figure C.3).

NOTE: Cable cover is not removable.

6. Please check that you can still rotate, raise and lower the monitor screen after you have installed the cables.

Power Cord

DisplayPort Cable

HDMI Cable*

Power Cord

DVI Cable*

D-SUB Cable* Audio Cable*

2, *3

DisplayPort Cable

HDMI Cable*

ControlSync Cables

DVI Cable* D-SUB Cable* Audio Cable* ControlSync Cables USB Cables

USB Cables

Figure C.2 Figure C.3

*2: Cable not included. *3: ø 3.5 stereo mini plug. *4: The type and number of cables included will depend on the where the LCD monitor is to be shipped.

7. Connect one end of the power cord to the AC inlet on the back of the monitor and the other end to the power outlet.

NOTE: Please refer to Caution section of this manual for proper selection of AC power cord.

English-7

2, *3

+ 19 hidden pages
