Precautions And Reminders

Do not place the display

in conned spaces or in a

box when in use� Maintain ample ventilation for the display when in use�

Keep the display away from direct sunlight, dust, humidity, smoke and oily areas�

Unplug the AC cord from the AC outlet before cleaning� Do not use liquid cleaners or aerosol cleaners to clean the display�

Do not open the display cabinet�

Unplug immediately if the display falls�

Do not place the display near water such as a bathtub, washbasin, sink, laundry tub, swimming pool, or a damp basement� Unplug immediately if the display has been exposed to rain or water�

Call a NEC certied

service personnel for any internal service needed for your display�

Unplug immediately if there is a display malfunction such as a loss of audio/video, the presence of smoke, or a bad odor coming from the display�

Do not cover or block any vents or openings� Inadequate ventilation may shorten the life of the display and cause overheating�

English

Place the unit on a sturdy, even surface�

Notice for Remote Controller

Avoid Liquids

PRE CH

CH-List

Do not insert any foreign objects into the display cabinet� Unplug immediately if objects have fallen into the display�

Avoid Aerosol Cleaners

PRE CH

CH-List

English-1

Unplug the power cord from the outlet when the display is not in use for long periods of time (days)�

Avoid Dropping

PRE CH

CH-List

Important Safety Instructions

S3125A

Read before operating equipment

Follow all warnings and instructions marked on this display�

1� Read these instructions� 2� Keep these instructions� 3� Heed all warnings� 4� Follow all instructions� 5� Do not use this apparatus near water� 6� Clean only with dry cloth� 7� Do not block any ventilation openings� Install in accordance with

the manufacturer's instructions�

8� Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliers) that

produce heat�

9� Do not defeat the safety purpose of the polarized or grounding-

type plug� A polarized plug has two blades with one wider than the other� A grounding type plug has two blades and a third grounding prong� The wide blade or the third prong are provided for your

safety. If the provided plug does not t into your outlet, consult an

electrician for replacement of the obsolete outlet�

10� Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point where

they exit from the apparatus� 11� Only use attachments/accessories specied by the manufacturer. 12� Use only with the cart, stand, tripod, bracket, or table specied by

the manufacturer, or sold with the apparatus� When a cart is used,

use caution when moving the cart/apparatus combination to avoid

injury from tip-over�

13� Unplug this apparatus during lightning storms or when unused for

long periods of time� 14� Refer all servicing to qualied service personnel. Servicing is

required when the apparatus has been damaged in any way, such

as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has

been dropped� Unplug immediately if the display faces above

condition�

15� The display complies with the recommended safety standards

for stability� Do not put excessive force on the front or top of

the cabinet� This could cause the product to tip over and cause

damage and/or personal injury� 16� If display or glass is broken, do not come in contact with the liquid

crystal and handle with care� 17� Follow instructions for wall, shelf or ceiling mounting as

recommended by the manufacturer� 18� Rest your eyes periodically by focusing on an object at least 5 feet

away� Blink often� 19� Do not place any heavy objects on the power cord�

Damage to the cord may cause shock or re.

20� Do not use display in high temperature, humid, dusty, or oily areas� 21� Do not bend, crimp or otherwise damage the power cord� 22� Apparatus shall not be exposed to dripping or splashing and no

objects lled with liquids, such as vases, shall be placed on the

apparatus

English

WARNING:

To prevent the apread of re, keep

candles or other open ames away fram this

product at all times�

IMPORTANT INFORMATION

If a display is not positioned in a sufciently stable location, it can

be potentially hazardous due to falling� Many injuries, particularly to children, can be avoided by taking simple precautions such as:

• Using cabinets or stands recommended by the manufacturer of the display�

• Only using furniture that can safely support the display�

• Ensuring the display is not overhanging the edge of the supporting

furniture�

• Not placing the display on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the display to a suitable support�

• Not standing the displays on cloth or other materials placed between the display and supporting furniture�

• Educating children about the dangers of climbing on furniture to reach the display or its controls�

English-3English-2

Important Information

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE� ALSO, DO NOT USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED�

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE�

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL�

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE

POWER CORD IS UNPLUGGED FROM WALL SOCKET� TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER CORD FROM THE AC OUTLET� DO NOT REMOVE COVER (OR BACK)� NO USER SERVICEABLE PARTS INSIDE� REFER SERVICING TO QUALIFIED SERVICE PERSONNEL�

This symbol warns user that uninsulated voltage within the unit may

have sufcient magnitude to cause electric shock. Therefore, it is

dangerous to make any kind of contact with any part inside this unit�

This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included� Therefore, it should be read carefully in order to avoid any problems�

CAUTION:

Please use the power cord provided with this display in accordance with the table below� If a power cord is not supplied with this equipment, please contact your supplier� For all other cases, please use a power cord that matches the AC voltage of the power outlet and has been approved by and complies with the safety standard of your particular country�

Plug Type

Plug Shape

Region

Voltage

European

Continental

EU

(except U�K�)

230 230 100 120

U.K. Japanese North America

U�K� Japan U�S�A�/Canada

This LCD display operates on 100-240 volts 50-60 Hz, AC current� Insert the power cord into a 100-240 volts 50-60 Hz outlet� The mains plug is used as the disconnect device and shall remain readily operable�

To prevent electric shock from the display, do not use with an extension cord, receptacle, or other outlet unless the blades and ground terminal can be fully inserted to prevent blade exposure�

Never connect the LCD display to other than the specied voltage.

English

CAUTION:

Never remove the back cover of the LCD display as this can expose you to very high voltages and other hazards� If the display does not operate properly, unplug the LCD display and call your authorized dealer or service center�

Adjust only those controls that are covered in the instructions, as improper

changes or modications not expressly approved by NEC could void the

user’s warranty�

Batteries installed warning

Incorrect usage of batteries can result in leaks or bursting� NEC recommends the following battery use:

• Do not mix battery brands�

• Danger of explosion if battery is incorrectly replaced� Replace only with

the same or equivalent type�

• Do not combine new and old batteries� This can shorten the battery life or cause liquid leakage of the batteries�

• Remove dead batteries immediately to prevent battery acid from leaking into the battery compartment�

• Do not touch exposed battery acid as it may injure skin�

• Remove the batteries if you do not intend to use the remote control for a

long period of time�

• The batteries shall not be exposed to excessive heat such as sunshine, re or the like�

Image persistence

Please be aware that LCD Technology may experience a phenomenon known as Image Persistence� Image Persistence occurs when a residual or "ghost" image of a previous image remains visible on the screen� Unlike CRT monitors, LCD monitors' image persistence is not permanent, but constant images being displayed for a long period of time should be avoided� To alleviate image persistence, turn off the display for as long as the previous image was displayed� For example, if an image was on the display for one hour and a residual image remains, the display should be turned off for one hour to erase the image�

NOTE:

As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying moving images and using a moving screen saver at regular intervals whenever the screen is idle or turning off the display when not in use�

English-5English-4

CAUTION:

These servicing instructions are for use by qualied service personnel only.

To reduce the risk of electric shock, do not perform any servicing other than

that contained in the operating instructions unless you are qualied to do so.

Ventilation

The slots and openings in the display are provided for necessary ventilation� To ensure reliable operation of the display and to protect it from overheating, these slots and openings must never be blocked or covered�

Unless proper ventilation is provided, the display may gather dust and get dirty� For proper ventilation, observe the following:

• Do not install the display face up, down or sideways�

• Do not install the display turned over or upside down�

• Never cover the slots and openings with a cloth or other materials�

• Never block the slots and openings by placing the display on a bed,

sofa, rug or other similar surface�

• Never place the display in a conned space, such as a bookcase or

built-in cabinet, unless proper ventilation is provided�

Leave some space around the display set as shown below� Otherwise, aircirculation may be inadequate and will cause overheating, which may cause a

re or damage to the display set.

Install on the wall

11 7/8 inches

30 cm

4 inches

10 cm

2.36 inches 6 cm

4 inches

10 cm10 cm

Leave at least this space around the set.

For use only with UL Listed Wall Mount Bracket with minimum weight/load:

Please refer to the Specication on page 31.

Unit without base weight: The equipment and its associated mounting means still remain secure during the test�

Used wall mounting kit, VESA-compatible wall bracket distance, diameter of

Screw dimension: Please refer to the Specication on page 31.

Installed with stand

11 7/8 inches

30 cm

English

4 inches

10 cm

4 inches

10 cm

4 inches

10 cm

Leave at least this space around the set.

Never install the display set where air-circulation is blocked�

Objects and ventilation holes

Never push objects of any kind into the display through the cabinet slots as they may touch dangerous voltage points or short out parts that could result in

a re or an electric shock. Do not place any objects on the display.

English-7English-6

License Notice and Trademark

®

Acknowledgement

Windows is a registered trademark of Microsoft Corporation� NEC is a registered trademark of NEC Corporation� All other brands and product names are trademarks or registered trademarks of their respective owners�

HDMI, the HDMI logo and High-Denition Multimedia Interface are trademarks

or registered trademarks of HDMI Licensing LLC in the United States and other countries�

Declaration Of Conformity

This device complies with Part 15 of FCC Rules� Operation is subject to the following two conditions� (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation�

U.S. Responsible Party: NEC Display Solutions of America, Inc. Address: 500 Park Boulevard, Suite 1100

Tel. No.: (630) 467-3000

Type of Product: Display Equipment Classication: Class B Peripheral Model: E585

conforms to the technical standards as specied in the FCC Rules.

Canadian Department of Communications Compliance Statement

DOC: This Class B digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations�

C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations

according to CAN/CSA C22�2 No� 60065-03�

FCC information

1� Use the attached specied cables with the E585/E505/E425/E325 color display so

as not to interfere with radio and television reception�

(1) Please use the supplied power cord or equivalent to ensure FCC compliance� (2) Please use the supplied shielded video signal cable, Mini D-SUB 15pin to Mini D-SUB 15 pin�

2� This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules� These limits are designed to provide reasonable protection against harmful interference in a residential installation� This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications� However, there is no guarantee that interference will not occur in a particular installation� If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna�

• Increase the separation between the equipment and receiver�

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected�

• Consult the dealer or an experienced radio/TV technician for help�

Canadian notice

CAN ICES-3 (B) / NMB-3(B)

Itasca, Illinois 60143

E425

E505

We hereby declare that the equipment specied above

E325

English

English-9English-8

Preparation

IMPORTANT:

compromise the integrity of the display� The manufacturer’s warranty does not cover user abuse or improper installations�

Do not apply pressure to the screen display area which may

Attaching the Base

E585

Stand Screw x 6 E585:M4 (14mm)

E505 / E425 / E325

Stand Screw x 4 E505:M6 (20mm) E425/E325:M4 (20mm)

1� Place the display face down on a soft and at surface to prevent

scratching and damage�

2� Carefully align the base to the button of the display and fasten the screws

with a cross-head screwdriver�

CAUTION:

The base of the stand is very heavy� Install with care to avoid injury such as dropping the base onto one's foot�

English

English-11English-10

Using Cable Clamper

Tie the cables together using the cable clamper�

Preparing Your LCD Display For Wall Mounting (optional)

We suggest that you keep your display at least 2�36 inches (60 mm) from the wall to prevent cable interference� Before mounting your display on the wall, you need to remove the base� For your safety, only mount with a UL listed wall mount bracket that supports the weight of the display� (Please see page 31�) To attach a wall mount bracket to your display:

E585 E505/E425/E325

VESA Hole

Neck Screw

1� Loosen the screws on the button of the base, and remove the base� 2� Secure the wall mount bracket to the back of your display using four M4

screws (for 32" only) or M6 screws(for 42"/50"/58" only)�

screen size (inches) required pitch (mm) VESA hole depth

58 400 x 400 4 x M6 (22 mm)

50 200 x 400 4 x M6 (15 mm)

42 200 x 200 4 x M6 (15 mm)

32 100 x 100 4 x M4 (12�5 mm)

VESA Hole

Neck Screw

NOTE:

Wall mounting solution is not included with the unit and is sold separately� Contact your NEC representative for details�

It is necessary to provide screw of appropriate length (Wall mount bracket thickness + VESA hole depth)�

Prohibit portrait condition use

English

CAUTION:

Do not rotate the diplay from landscape to portrait�

English-13English-12

Place The Display On A Solid Surface

Ensure that the LCD display is

placed in a position to allow free ow

of air� Do not cover the ventilation openings on the back cover� Do not place the display near any open

ames. Do not allow the display to

be placed in an environment where it can be exposed to heat, direct

Min 1 m

sunlight, or rain and water� Do not expose the equipment to any liquid�

Battery Installation and Replacement

The remote control is powered by two 1�5V AAA batteries� To install or replace batteries:

1� Open the battery cover of the remote

control by pushing and pulling it in the direction of the arrow�

2� Insert two new “AAA” size batteries

for the remote control� When replacing old batteries, push them towards the springs and lift them out�

3� Match the batteries to the (+) and (-)

marks in the battery compartment�

4� Insert the bottom of the battery, the

(-) side, into the battery compartment

rst, push towards the springs and

insert the top of the battery, the (+) side, into place� Do not force the battery into the battery compartment�

5� Close the battery cover making sure the tabs rest in the corresponding

holes and push down the cover until it clicks shut�

Connect To The Power Source

The display should be installed close to an easily accessible power outlet� Fully insert the prongs into the power outlet socket� A loose connection may cause image degradation�

If there is power to the display, the front LED at the bottom of the display will be either none or red� A red LED means the display is in standby mode�

Power On/Off Your New LCD Display

Press the power button on the remote control or press the power button located on the side of the display� The display will power on�

Power button

or

English

Power Mode Status

Mode On Standby Warming up

LED Status

When in on mode, the Display operates as follows if no external signal is input�

1� When the external device is connected to the VGA terminal, the NO

SIGNAL menu is displayed and 15 seconds later the Display switches to

None Red Blinking Red

English-15English-14

warming up mode�

2� In warming up mode, when the Display receives a signal from an external

VGA device, it switches automatically to on mode�

NOTE:

Note that in warming up mode, the Display does not switch automatically to on mode even if a signal is input from an external device using HDMI, component video or composite video� If the power cord is unplugged during warming up mode, the Display will starts in standby mode the next time it is turned on�

3� When the external device is connected to another terminal (HDMI,

component video, composite video), the NO SIGNAL menu is displayed and 15 minutes later the Display switches to standby mode�

4� In standby mode, press the power button on the remote control or on the

side panel to switch the Display to on mode�

NOTE:

Note that in standby mode, the Display does not switch automatically to on mode even if a signal is input from an external device using VGA, HDMI, component video or composite video� If the power cord is unplugged during standby mode, the Display will starts in the same standby mode the next time it is turned on�

TIP:

When Home mode is set under Energy Options in the on-screen display menu, the Display switches to power saving mode if no external signal is input� When Retail mode is set under Energy Options in the on-screen display menu, the Display does not switch to power saving mode when no external signal is input� When On is set under Auto Power Off in the on-screen display menu, the Display automatically turns off if the user does not operate the Display for more than 4 hours� When the sleep timer has been set in the on-screen display menu, the Display automatically turns off after the set time has elapsed�

Source Connection Guide

E585

AC POWER

English

❶

❷

❸

RS-232C –

1�

❺❻

Connect to your PC, and receive the control commands from

❹

the PC�

HDMI (HDMI1, HDMI2, HDMI3) –

2�

USB port –

3�

PC IN (VGA / AUDIO) –

4�

COMPONENT / AV IN –

5�

Used for accessing photo, music, and movie les.

Connect to your PC video and audio�

Connect to your HDMI devices�

• Component: Connect to digital video equipment to the Video Green (Y), Blue (Pb), Red (Pr) jacks, and matching Audio White (L) and Red (R) jacks�

• Composite: Connect to digital video equipment to the Video Green (AV), jacks, and matching Audio White (L) and Red (R) jacks�

SPDIF OUT-

6�

Use a digital audio cable to connect to stereo home theater

system�

English-17English-16

E505 / E425 / E325

AC POWER

RS-232C –

1�

E325 / E425 E505

❺❻

❹

Connect to your PC, and receive the control commands from

❶

❷

❸

the PC�

HDMI (HDMI1, HDMI2, HDMI3) –

2�

USB port –

3�

PC IN (VGA / AUDIO) –

4�

COMPONENT / AV IN –

5�

Used for accessing photo, music, and movie les.

Connect to your PC video and audio�

Connect to your HDMI devices�

• Component: Connect to digital video equipment to the Video Green (Y), Blue (Pb), Red (Pr) jacks, and matching Audio White (L) and Red (R) jacks�

• Composite: Connect to digital video equipment to the Video Green (AV), jacks, and matching Audio White (L) and Red (R) jacks�

SPDIF OUT-

6�

Use a digital audio cable to connect to stereo home theater

system�

Once your AV device is connected, press the

Source

relevant source to view� (ex: Press

button on the remote control to select the

COMP

button to select “Component” if you have connected a source to the Component input�)

PRE CH

Operating Instructions

Using The Side Panel Controls

1� VOL +

2� VOL -

3� CH Press this button to shift up in the OSD menu�

Press to increase the volume�

Press this button to shift Right in the OSD menu�

Press to decrease the volume�

Press this button to shift Left in the OSD menu�

English

4� CH Press this button to shift down in the OSD menu�

5� MENU Press to open or exit the OSD (On-Screen Display) menu�

6� INPUT Press to select the input source�

7� POWER Press to turn on / off (standby) the display�

English-19English-18

, , ,

Using The Remote Control

(Power)

Press to turn On/Off (standby) the power� (NOTE: To completely turn off the power, unplug the power cord from the power outlet�)

TV

No function�

AV

Press to choose Composite source mode�

COMP

Press to choose Component source mode�

HDMI/PC

Press repeatedly to choose PC IN or HDMI source mode�

0 9 / -

Only available on Input List menu�

PRE CH

No function�

Source

Press repeatedly to choose the various input sources�

Mute

Switch the sound On/Off�

VOL + / VOL

Press + or – to adjust the volume�

CH + / CH

No function�

Exit

Press to exit the OSD menu�

Display

Press to show the information�

FAV

No function�

Menu

Press to open the OSD menu�

, , , , OK

Press to select or confirm the various function items on the menu�

Use in the USB menu and HDMI CEC function�

MTS

No function�

Wide

Press to choose the display aspect ratio: Normal / Zoom / Wide / Cinema �

PRE CH

CH-List


Press to choose the picture mode: Dynamic / Standard / Energy Savings / Theater / Custom�

Audio

Press to choose sound mode: Standard / Movie / Music / News / Custom�

CH-List

No function�

C C

No function�

Operating Range for the Remote Control

Point the top of the remote control toward the LCD monitor’s remote sensor during button operation�

Use the remote control within a distance of about 7 m (23 ft�) from remote control sensor or at a horizontal and vertical angle of within 30° within a distance of about 3�5 m (10 ft�)�

E585 / E505 / E425 / E325

English

CAUTION:

Important, the remote control system may not function when direct sunlight or strong illumination strikes the remote control sensor or when there is an object in the path�

English-21English-20

Timing Table

WXGA (E325)

Resolution

640 × 48 0@60 Hz ● ● ● ● 31�4 69 – 59�94 – 2 5�175

720 × 400 @70Hz ● ● ● ● 31�4 69 – 70�0 87 + 28�32 2

800 × 6 00@6 0Hz ● ● ● ● 3 7�87 9 + 60� 317 + 40

1024 × 768@ 60Hz ● ● ● ● 48�363 – 60�004 – 65

1280 × 720@ 60Hz ● ● ● ● 45 – 60 + 74 �2 5

1280 × 800@60H z ▲ ▲ ● ● 49 �702 – 59�81 + 83�5

1366 × 768 @60Hz

1920 × 1080 @60Hz ▲ ▲

Resolution

480i 6 0Hz ● ● ● ●

480p 6 0Hz ● ● ● ●

720p 60 Hz ● ● ● ●

1080i 60Hz ▲ ▲ ● ●

1080p 24Hz ▲ Not support ● Not support

VGA DVI VGA DV I

●

(Na ti ve)●(Na ti ve)

HDMI Component HDMI Component

FHD

(E585/E505/E425)

Not

support

(Na ti ve)●(Na ti ve)

WXGA (E325)

● 4 7�712 + 59 �79 + 85�5

●

Horizontal Vert ica l

Nominal

Freq. (kHz)

67� 5 + 60 + 148 �5

Sync

Polari ty

Nominal

(E585/E505/E425)

Freq.

(Hz)

FHD

Sync

Polari ty

Nominal

Pixel Clock (MHz)

1080p 30Hz ▲ Not support ● Not support

1080 p 60Hz ▲ Not suppor t ● Not support

720p 50 Hz ● ● ● ●

576p 50 Hz ● ● ● ●

576i 50Hz ● ● ● ●

1080i 50Hz ● ● ● ●

1080 p 50Hz ● ● ● ●

NOTE:

:

Use Down-scaling function� Image quality is limited�

Navigating The On-Screen Menu

Press the

Use the Navigation Ring to navigate, select, adjust or conrm an item on the OSD (On

Screen Display) menu�

NOTE: Some features may only be available in a particular source mode�

Menu

button to display and

Video Menu

This menu adjusts video items�

Exit

to close the main menu�

[Noise Reduction]

Set to reduce the video noise�

[Tint]

Video

Audio

Setup

USB

Picture Mode

Brightness

Contrast

Color

Advanced Video

Reset Video Settings

Energy Savings

50

60

55

Adjust the hue (Red, Green, Blue) of the picture from R50 G50�

[Sharpness]

Adjust object edges to optimize picture detail from 0 100�

Adjust picture settings and customize picture quality

OK

MOVE EXIT

MOVE SELECT RETURN

MENU

EXIT

[Adaptive Contrast]

Set to automatically adjust the picture detail and brightness�

Picture Mode

1�

Enter this menu to select from preset picture settings to optimize your display’s performance:

Dynamic / Standard / Energy Savings / Theater / Custom

Brightness

2�

Adjust picture brightness from 0 100�

Contrast

3�

Adjust picture contrast from 0 100�

Color

4�

Adjust picture color from 0 100�

Advanced Video

5�

Select advanced video settings�

[Dynamic Backlight (DCR)]

Enhance the contrasts between darkness and brightness to optimization the picture�

[Color Temperature]

Select a choice from

Normal

, or

Warm

Cool

�

,

[Aspect Ratio]

Adjust how the picture lls the

screen�

Cinema

Normal / Zoom / Wide /

[Overscan (On/Off)]

Some video formats may require different scanning modes in order to best display the image�

On:

Image size is larger than what can be displayed� The image edge will appear cropped� Approximately 95% of the image will be shown on the screen�

Off:

Image size stays within the display area� The whole image is displayed on the screen�

NOTE:

When you use a

computer with HDMI out, please

OFF

set “

”�

[Backlight]

Set the backlight brightness from

0 ─ 50.

Reset Video Settings

6�

Reset Video settings to factory default settings�

English

English-23English-22

Audio Menu

The Audio menu provides an audio adjustment for user to modify the audio setting�

Setup Menu

According to various requirements in different source modes, certain features could be hidden (disabled) on the menu�

Video

Audio

Setup

USB

Adjust settings to affect sound quality.

MOVE SELECT RETURN EXIT

Sound Mode

1�

Sound Mode

Balance

Advanced Audio

Reset Audio Settings

OK

0

MENU

Select preset audio modes�

Standard / Movie / Music / News / Custom

Balance

2�

�

Adjust the audio balance for the display's internal left and right speakers from L50 – R50�

Advanced Audio

3�

Select advanced audio settings�

[Bass]

Enhance the low frequencies�

[Treble]

Enhance the high frequencies�

[Internal Speakers]

Off

Select

to turn off the internal

speakers�

[Digital Output]

Select optical output options:

RAW

HDMI input source)

Reset Audio Settings

4�

or

PCM

(Only available for

�

Reset Audio settings to factory default settings�

Standard

Video

Audio

Setup

USB

Set various monitor options.

EXIT

MOVE SELECT RETURN EXIT

Menu Language

1�

Menu Language

Auto Power Down

RGB Options

Monitor ID

Time Schedule

OK

MENU

English

HomeEnergy Options

OffSleep Timer

Off

EXIT

Select the menu display language�

Sleep Timer

2�

Select how long the display will take to automatically turn intself

Off / 5 / 10 / 15 / 30 / 60 / 90

off�

/ 120 / 180 / 240 Energy Options

3�

Home

mode is intended for

(minutes)

home use, and will save much energy� In this mode, the Display automatically switches to power saving mode when no external signal is input�

Retail

mode is a relatively more

energy consuming mode� In this mode, the Display does

not switch to power saving mode when no external signal is input�

Auto Power Down

4�

Select On to enable your display to turn off automatically when you do not press any buttons in 4 hours�

RGB Options

5�

(Only available for VGA input, and when there is VGA signal input)

[Auto Adjust]

Automatically adjust the image settings such as position�

[H-Position]

Adjust horizontal position�

[V-Position]

Adjust vertical position�

[Clock]

Set to the minimum level if noise occurs�

[Phase]

Eliminate icker and distortion.

[Reset RGB Options]

Reset RGB Options to factory default settings�

Monitor ID

6�

Set the monitor ID number from

1-100, All Time Schedule

7�

This function enables your display to turn on and off automatically�

[Schedule Status]

Select On to enable Time Schedule�

[Current Time]

Set the current time before using this function�

[Power On]

Set the time for your display to turn on�

[Power Off]

Set the time for your display to turn off�

HDMI CEC

8�

This function enables you to control the HDMI CEC compliant device connected via the HDMI connector�

[Enable CEC]

Select On to enable HDMI CEC�

[Audio Receiver]

Select On to enable to return the audio signal to other speakers�

[Device List]

Show the device list�

Group A─J

, or

IR Lock Setting

9�

Select On to lock your remote control, and the remote control will disable to control the display�

Display

Press seconds can unlock it�

System Info

10�

Indicate the display information�

Reset AV & Setup

11�

Reset all

Setup

settings to factory default

settings

�

button for 5

Audio, Video

.

English

, and

English-25English-24

USB Menu

PLAY

Pause

Prev.

Info.

Zoom

Rotate

90º

Repeat

Music

PLAY

Pause

Prev.

You could browse images, listen to musics, or play videos from USB device�

Video

Audio

Setup

USB

View files from a USB flash drive that is connected to the monitor.

MOVE SELECT RETURN EXIT

If no USB device is detected, the message displayed: “Please Insert USB

ash drive."

• Change input source to exit the

USB mode�

To control while in folder:

• Press ▲, ▼, ◄, ► button to browse the les.

• Press OK button to open a folder or play the selected le.

• Press EXIT button to return to

previous folder�

To control the operation bar:

• Press OK / Menu button to display operation bar on the bottom of screen�

• Press Display button to show operation bar and information window�

• Press ◄, ► button to select the

item on operation bar�

• Press EXIT to hide operation bar�


USB

OK

MOVE

MENU

MUSIC MOVIE

OK

SELECT EXIT None

EXIT

To control while viewing photos:

• Select

or press button to

play image slideshow�

• Select

or press button to

pause the playing image�

• Select

or press ◄ button to go

to previous image�

• Select

or press ► button to go

to next image�

• Select

or press button to

stop the playing image slideshow�

• Select

or press Display button to show the playing image’s information�

• Select

to switch image size between the 4 styles by cycle� Full / X1 / X2 / X4

• Select

to rotate the image clockwise�

• Select

to repeat images in the folder� R_None / R_One / R_All

• Select

to play background

music. (The music le should be

in the same folder�)

To control while enjoying musics or videos:

• Select

or press button to

play the le.

• Select

or press button to

pause the playing le.

• Select FB to play fast backward�

FB2X / FB4X / FB8X / FB16X / FB32 (Only for video)

• Select FF button to play fast forward�

FF2X / FF4X / FF8X / FF16X / FF32 (Only for video)

• Select

or press button to

go to previous le. For playing musics, press ◄ button also can

go to previous song�

• Select

or press button to

go to next le. For playing musics, press ► button also can go to

next song�

• Select

or press button to

stop the playing le.

Info.

Repeat

• Select

or press Display

button to show the playing le’s

information�

• Select

to repeat les in the

folder� R_None / R_One / R_All

• Select to mute while playing

the music le.

• Press Wide button to choose the

display aspect ratio while playing the video le.

4:3 / 16:9 / Auto

Data Format for USB

Supported le

system

Max. folder layer

Data format

Max. number of photos

Min. image resolution

Max. image resolution (Progressive DCT)

Max. image resolution (Baseline Sequential DCT)

Data format

Bit rate

FAT16/32

9

PHOTO mode

JPEG, JPG, JPE

1200

128 × 128 pixels

1,024 × 768 pixels

15,360 × 8,640 pixels

MUSIC mode

MP3

32Kbps ~ 448Kbps

MOVIE mode

Data format

MPG, MPEG, MPEG2-TS, MPEG2-PS, MP4, MKV, AVI, Motion JEPG

CAUTION:

• Only supports USB Mass storage

class devices�

• A JPEG image modied with PC

may not be displayed�

• Partly degraded les might be

displayed at a reduced resolution�

• Not guaranteed to support all

USB devices�

• Do not use a USB Hub�

• Do not support multi-partition

USB�

NOTES:

• The folder and le names may be

different depending on the digital camera used�

• Support USB 2�0 Type A

connector (DC5V, max� 500mA)� For USB device over 500mA, we suggest to use adaptor or external power�

English

English-27English-26

Maintenance and Recycling

Care Of The Screen

Do not rub or strike the screen with anything hard as this may scratch, mar, or even damage the screen permanently� Unplug the power cord before cleaning the screen� Dust the display by wiping the screen and the cabinet with a soft, clean cloth� If the screen requires additional cleaning, use a clean, damp cloth� Do not use liquid cleaners, aerosol cleaners, or solvents of any kind�

Mobile Telephone Warning

Keep your mobile telephone away from your display to avoid disturbances in the picture or sound, possibly causing permanent damage to your display�

End Of Life Directives

In an effort to produce environmentally friendly products, your new display contains materials that can be recycled and reused� At the end of your displays life, specialized companies can minimize display waste by separating the reusable materials from non-reusable materials� Please ensure you dispose of your display according to local regulations�

Italian Homologation declaration

Questo apparecchio è fabbricato nella Comunità Economica Europea nel rispetto delle disposizioni di cui al D� M� 26/03/92 ed in particolare è conforme alle prescrizioni dell’art� 1 dello stesso D�M� Si dichiara che l’apparecchi�

Manufacturer’s Recycling and Energy Information

NEC DISPLAY SOLUTIONS is strongly committed to environmental protection and sees recycling as one of the company’s top priorities in trying to minimize the burden placed on the environment� We are engaged in developing

environmentally-friendly products, and always strive to help dene and comply

with the latest independent standards from agencies such as ISO (International Organisation for Standardization) and TCO (Swedish Trades Union)�

Disposing of your old NEC product

The aim of recycling is to gain an environmental benet by means of re-use,

upgrading, reconditioning or reclamation of material� Dedicated recycling sites ensure that environmentally harmful components are properly handled and securely disposed� To ensure the best recycling of our products,

DISPLAY SOLUTIONS offers a variety of recycling procedures

advice on how to handle the product in an environmentally sensitive way, once it has reached the end of its life�

All required information concerning the disposal of the product and country-

specic information on recycling facilities can be found on our following

websites:

http://www.nec-display-solutions.com/greencompany/ http://www.nec-display.com http://www.necdisplay.com

(in Japan) or

(in USA)�

(in Europe),

NEC

and gives

Energy Saving

This display features an advanced energy saving capability� When a VESA Display Power Management Signalling (DPMS) Standard signal is sent to the display, the Energy Saving mode is activated� The display enters a single Energy Saving mode�

English

Mode Power consumption LED color

On mode

(with USB , with Audio)

Standby Mode Less than 0�5 W Red

Approx� 145 W (E585) Approx� 124 W (E505) Approx� 100 W (E425)

Approx� 53 W (E325)

English-29English-28

None

WEEE Mark (European Directive 2012/19/EU)

Within the European Union

EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste� This includes monitors and electrical accessories, such as signal cables or power cords� When you need to dispose of your NEC display products, please follow the guidance of your local authority, or ask the shop where you purchased the product, or if applicable, follow any agreements made between yourself and NEC�

The mark on electrical and electronic products only applies to the current European Union Member States�

Outside the European Union

If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method�

Restriction on Hazardous Substances statement (India)

This product complies with the “India E-waste Rule 2011” and prohibits use of lead, mercury, hexavalent chromium, polybrominated biphenyls or polybrominated diphenyl ethers in concentrations exceeding 0�1 weight % and 0�01 weight % for cadmium, except for the exemptions set in Schedule 2 of the Rule�

Specification

Product Specifications

E585

LCD Module

Frequency Horizontal:

Pixel Clock 25 – 156 MHz

Viewable Size 1270�08 (H) x 721�44 (V) mm

Input Signal

COMPONENT Component RCA

AV IN Composite RCA

VGA Analog RGB D-sub 15 pin

HDMI Type A Connectors

AUDIO

Audio Input Analog Audio Stereo mini jack

Audio Input AUDIO L / R RCA

Audio Output SPDIF OUT PCM, Fibre optic

Speaker Output Internal Speaker: 10 W + 10 W (8 ohm)

Control RS-232C: 9 Pin D-sub

Power Supply

Operational Environment Temperature:

Storage Environment Temperature:

Dimension with Stand and Base:

Weight with Stand and Base:

VESA compatible mounting interface 400 mm x 400 mm (M6, VESA hole depth 22 mm)

Power Management VESA DPM

Plug & Play VESA DDC2B

Accessories Remote control (1), 1�5 V AAA batteries (2)

without Stand and Base:

Resolution:

Power consumption:

Standby:

Humidity:

NOTE:

• All specications, weights, and dimensions are subject to change without prior

notice� Please access www�necdisplay�com for detailed specications and dimensions for custom installations�

• This model may not be compatible with features and/or specications that may be

added in the future�

58”/ 1,473 mm diagonal 1,920 x 1,080

Color:

Over 16 million colors (depending on video card used)

31 – 83KHz (Analog input) 15�625/15�734KHz, 31 – 83KHz (HDMI input)

Vertical:

60Hz – 75Hz (Analog input) 24Hz, 30Hz, 50Hz, 60Hz – 75Hz (HDMI input)

Y: 1�0 V p-p / 75ohm, Pb/Pr (Cb/Cr): 0�7 V p-p / 75 ohm

1�0 V p-p / 75 ohm

0�5 Vrms / 75 ohm

1�5 A – 0�7 A @ AC 100 – 240V, 50/60Hz < 0�5 W 145 W

0°C – 40°C / 32°F – 104°F 10% – 80%

Altitude:

0 – 2,000 m

-10°C – 60°C / 14°F – 140°F 5% – 85%

1300�9 (W) x 798�8 (H) x 349�2(D) mm 1300�9 (W) x 758�8 (H) x 108�8(D) mm

21�90 kg 21�07 kg

Power cord (1), D-sub cable (1), Setup Manual (1) CD ROM (1)

English

English-31English-30

E505

LCD Module

Frequency Horizontal:

Pixel Clock 25 – 156 MHz

Viewable Size 1095�84 (H) x 616�41 (V) mm

Input Signal

COMPONENT Component RCA

AV IN Composite RCA

VGA Analog RGB D-sub 15 pin

HDMI Type A Connectors

AUDIO

Audio Input Analog Audio Stereo mini jack

Audio Input AUDIO L / R RCA

Audio Output SPDIF OUT PCM, Fibre optic

Speaker Output Internal Speaker: 10 W + 10 W (8 ohm)

Control RS-232C: 9 Pin D-sub

Power Supply

Operational Environment Temperature:

Storage Environment Temperature:

Dimension with Stand and Base:

Weight with Stand and Base:

VESA compatible mounting interface 400 mm x 200 mm (M6, VESA hole depth 15 mm)

Power Management VESA DPM

Plug & Play VESA DDC2B

Accessories Remote control (1), 1�5 V AAA batteries (2)

without Stand and Base:

Resolution:

Power consumption:

Standby:

Humidity:

NOTE:

• All specications, weights, and dimensions are subject to change without prior

notice� Please access www�necdisplay�com for detailed specications and dimensions for custom installations�

• This model may not be compatible with features and/or specications that may be

added in the future�

50”/ 1,270 mm diagonal 1,920 x 1,080

Color:

Over 16 million colors (depending on video card used)

31 – 83KHz (Analog input) 15�625/15�734KHz, 31 – 83KHz (HDMI input)

Vertical:

60Hz – 75Hz (Analog input) 24Hz, 30Hz, 50Hz, 60Hz – 75Hz (HDMI input)

Y: 1�0 V p-p / 75ohm, Pb/Pr (Cb/Cr): 0�7 V p-p / 75 ohm

1�0 V p-p / 75 ohm

0�5 Vrms / 75 ohm

1�3 A – 0�6 A @ AC 100 – 240V, 50/60Hz < 0�5 W 124 W

0°C – 40°C / 32°F – 104°F 10% – 80%

Altitude:

0 – 2,000 m

-10°C – 60°C / 14°F – 140°F 5% – 85%

1123�6 (W) x 683�7 (H) x 255 (D) mm 1123�6 (W) x 646�7 (H) x 77 (D) mm

13�12 kg 12�62 kg

Power cord (1), D-sub cable (1), Setup Manual (1) CD ROM (1)

E425

LCD Module

Frequency Horizontal:

Pixel Clock 25 – 156 MHz

Viewable Size 930�24 (H) × 523�26 (V) mm

Input Signal

COMPONENT Component RCA

AV IN Composite RCA

VGA Analog RGB D-sub 15 pin

HDMI Type A Connectors

AUDIO

Audio Input Analog Audio Stereo mini jack

Audio Input AUDIO L / R RCA

Audio Output SPDIF OUT PCM, Fibre optic

Speaker Output Internal Speaker: 10 W + 10 W (8 ohm)

Control RS-232C: 9 Pin D-sub

Power Supply

Operational Environment Temperature:

Storage Environment Temperature:

Dimension with Stand and Base:

Weight with Stand and Base:

VESA compatible mounting interface 200 mm x 200 mm (M6, VESA hole depth 15 mm)

Power Management VESA DPM

Plug & Play VESA DDC2B

Accessories Remote control (1), 1�5 V AAA batteries (2)

without Stand and Base:

Resolution:

Power consumption:

Standby:

Humidity:

NOTE:

• All specications, weights, and dimensions are subject to change without prior

notice� Please access www�necdisplay�com for detailed specications and dimensions for custom installations�

• This model may not be compatible with features and/or specications that may be

added in the future�

42”/ 1,067 mm diagonal 1,920 x 1,080

Color:

Over 16 million colors (depending on video card used)

31 – 83KHz (Analog input) 15�625/15�734KHz, 31 – 83KHz (HDMI input)

Vertical:

60Hz – 75Hz (Analog input) 24Hz, 30Hz, 50Hz, 60Hz – 75Hz (HDMI input)

Y: 1�0 V p-p / 75ohm, Pb/Pr (Cb/Cr): 0�7 V p-p / 75 ohm

1�0 V p-p / 75 ohm

0�5 Vrms / 75 ohm

1�0 A – 0�5 A @ AC 100 – 240V, 50/60Hz < 0�5 W 100 W

0°C – 40°C / 32°F – 104°F 10% – 80%

Altitude:

0 – 2,000 m

-10°C – 60°C / 14°F – 140°F 5% – 85%

959�7 (W) x 591�7 (H) x 255 (D) mm 959�7 (W) x 555�2 (H) x 76�8 (D) mm

8�83 kg 8�33 kg

Power cord (1), D-sub cable (1), Setup Manual (1) CD ROM (1)

English

English-33English-32

E325

LCD Module

Frequency Horizontal:

Pixel Clock 25 – 156 MHz

Viewable Size 697�685 (H) × 392�256(V) mm

Input Signal

COMPONENT Component RCA

AV IN Composite RCA

VGA Analog RGB D-sub 15 pin

HDMI Type A Connectors

AUDIO

Audio Input Analog Audio Stereo mini jack

Audio Input AUDIO L / R RCA

Audio Output SPDIF OUT PCM, Fibre optic

Speaker Output Internal Speaker: 5 W + 5 W (8 ohm)

Control RS-232C: 9 Pin D-sub

Power Supply

Operational Environment Temperature:

Storage Environment Temperature:

Dimension with Stand and Base:

Weight with Stand and Base:

VESA compatible mounting interface 100 mm x 100 mm (M4, VESA hole depth 12�5 mm)

Power Management VESA DPM

Plug & Play VESA DDC2B

Accessories Remote control (1), 1�5 V AAA batteries (2)

without Stand and Base:

Resolution:

Power consumption:

Standby:

Humidity:

NOTE:

• All specications, weights, and dimensions are subject to change without prior

notice� Please access www�necdisplay�com for detailed specications and dimensions for custom installations�

• This model may not be compatible with features and/or specications that may be

added in the future�

32”/ 813 mm diagonal 1,366 x 7,68

Color:

Over 16 million colors (depending on video card used)

31 – 83KHz (Analog input) 15�625/15�734KHz, 31 – 83KHz (HDMI input)

Vertical:

60Hz – 75Hz (Analog input) 24Hz, 30Hz, 50Hz, 60Hz – 75Hz (HDMI input)

Y: 1�0 V p-p / 75ohm, Pb/Pr (Cb/Cr): 0�7 V p-p / 75 ohm

1�0 V p-p / 75 ohm

0�5 Vrms / 75 ohm

0�9 A – 0�5 A @ 100 – 240V AC, 50/60Hz < 0�5 W 53 W

0°C – 40°C / 32°F – 104°F 10% – 80%

Altitude:

0 – 2,000 m

-10°C – 60°C / 14°F – 140°F 5% – 85%

726�7 (W) x 461�1 (H) x 255 (D) mm 726�7 (W) x 424�3 (H) x 76�8 (D) mm

5�33 kg 4�83 kg

Power cord (1), D-sub cable (1), Setup Manual (1) CD ROM (1)

RS-232C Port Specifications

PC control of the Display

Attach an RS-232C cable cross-type (commercially available) to the supplied RS-232C for the connections�

NOTE:

This operation system should be used by a person who is accustomed to using computers�

Communication procedure

Send the control commands from the PC via the RS- 232C connector� The display operates according to the received command and sends a

response message to the PC� Do not send multiple commands at the same time� Wait until the PC receives

the response before sending the next command�

Interface

Protocol RS-232C

Baud rate 9,600 bps

Data length 8 bits

Parity bit None

Stop bit 1 bit

Communication code ASCII

This LCD display uses RXD, TXD and GND lines for RS-232C control� The reverse type cable (null modem cable) (not include) should be used for

RS-232C control�

Control command diagram

Function

(Monitor ID = 1)

Power ON 01 30 41 30 41 30 43 02 43 32 30 33 44 36 30 30 30 31 03 73 0d

Power OFF 01 30 41 30 41 30 43 02 43 32 30 33 44 36 30 30 30 34 03 76 0d

Input Source Select VGA

Input Source Select HDMI

Input Source Select Component

Input Source Select Composite

Sound Mute ON 01 30 41 30 45 30 41 02 30 30 38 44 30 30 30 31 03 09 0d

Sound Mute OFF 01 30 41 30 45 30 41 02 30 30 38 44 30 30 30 32 03 0a 0d

01 30 41 30 45 30 41 02 30 30 36 30 30 30 30 31 03 73 0d

01 30 41 30 45 30 41 02 30 30 36 30 30 30 31 31 03 72 0d

01 30 41 30 45 30 41 02 30 30 36 30 30 30 30 43 03 01 0d

01 30 41 30 45 30 41 02 30 30 36 30 30 30 30 35 03 77 0d

Code Data

English

English-35English-34

Before Calling Service

Please make these simple checks before calling service� These tips may save you time and money as charges for receiver installation and adjustments of customer controls are not covered under your warranty�

Symptoms Items To Check And Actions To Follow

• Check to see if the display’s AC power cord is plugged

No power

No picture

into the outlet�

• Unplug the display and after 60 seconds reinsert the plug into the outlet and power on the display�

• Adjust the contrast and brightness settings�

Good picture but no sound

Good sound but poor color

Poor picture

Presence of a horizontal dotted line

Display not responding via the remote control

• Increase the volume�

• Conrm that the display is not muted by pressing the

Mute button on the remote control�

• Adjust the contrast, color and brightness settings�

• Poor picture quality may occur when an activated S-VHS

camera or camcorder is connected to your display and another peripheral at the same time� Switch off one of the peripherals�

• This may be caused by electrical interference (e�g� hairdryer, nearby neon lights, etc�)�

• Power cycle the equipment by turning off and then turning back on�

• Determine if the batteries are working and replace batteries if necessary�

• Clean the remote control sensor lens on the display�

• If necessary, utilize the buttons located on the side of the

display�

Glossary

HDMI Inputs

High-Denition Multimedia Interface Audio / Video Inputs are located on the

receiver� These connectors are used for the input of audio and video signals� Designed to receive higher picture resolution and offer sound connection options�

Menu

An on-screen listing of features shown on the display screen is made available for user adjustments�

Sleep Timer

You can set a time period for which the display will automatically turn off�

English

English-37English-36

Nec 60003726 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Precautions And Reminders

Important Safety Instructions

Important Information

Declaration Of Conformity

Contents

Preparation

Attaching the Base

Using Cable Clamper

Preparing Your LCD Display For Wall Mounting (optional)

Prohibit portrait condition use

Place The Display On A Solid Surface

Battery Installation and Replacement

Connect To The Power Source

Power On/Off Your New LCD Display

Power Mode Status

Source Connection Guide

Operating Instructions

Using The Side Panel Controls

Using The Remote Control

Operating Range for the Remote Control

Timing Table

Navigating The On-Screen Menu

Video Menu

Audio Menu

Setup Menu

USB Menu

Maintenance and Recycling

Care Of The Screen

Mobile Telephone Warning

End Of Life Directives

Italian Homologation declaration

Manufacturer’s Recycling and Energy Information

Disposing of your old NEC product

Energy Saving

WEEE Mark (European Directive 2012/19/EU)

Specification

Product Specifications

RS-232C Port Specifications

Before Calling Service

Glossary
