Nec 60003607 Datasheet
NEC MultiSync® EA273WMi
Order Code: 60003608 (BK), 60003607 (WH)
The NEC MultiSync® EA273WMi features an extremely thin
27" IPS LED backlight panel with a resolution of 1920x1080
which results in an ultra-modern and slim design. Ambient
Light and Human Sensors enforce the sustainable product
concept while offering improved ergonomics with 130 mm
height adjustability. The ergonomic performance of this display
is further enhanced by the relatively large dot pitch for easy
text readability, which complements the excellent IPS image
quality. Finally, the display offers future-proof connectivity with
four inputs: DisplayPort, DVI-D, HDMI and D-Sub.
Ideal for the corporate office that values personal productivity,
demands stylish products and insists on the best future proof
technology.
DELIVERING GENUINE BENEFITS
NEC LCD 27" Desktop Display
Ambient Light Sensor - with Auto Brightness function always
sets optimised brightness level according to ambient light and
content conditions.
Ergonomic Office - full height adjustability (130 mm), swivel,
tilt and pivot functionality ensures perfect individual ergonomic
set-up.
Feature Set for Perfect Office Use - Integrated Speakers,
headphone jack and USB Hub provide excellent options for
office communication.
Green Product Concept - Eco Mode and Carbon Footprint
Meter / Carbon Savings Meter, Ambient Light Sensor.
Human Sensor - detects the presence of a person in front of
the screen; display switches on/off automatically depending
on the presence of the user.
Image display - 27inch 16:9 IPS with LED backlight.
DICOM Simulation - for straightforward radiological review
applications.
OUTSTANDING PERFORMANCE
Ultra-modern and slim design. The product design is discreet and puts priority on the
•
screen image and function.
Ambient Light and Human Sensors. The new sensor technologies provide a perfect
•
image with minimum power consumption.
Improved ergonomics. The ergonomic stand with 130 mm height adjustability allows
•
greatest set-up flexibility.
Integrated Speakers, headphone jack and USB. Hub provide excellent options for
•
office communication.
ControlSync® technology allows users to control up to six units in a multi-monitor
•
configuration.
This document is © copyright 2013 NEC Display Solutions Europe GmbH.
All rights reserved in favour of their respective owners. All hardware and software names are brand names and/or registered trademarks of the respective manufacturers. All
specifications are subject to change without notice. Errors and omissions are excepted. 14.10.2013
www.nec-display-solutions.com
NEC MultiSync® EA273WMi
Technical Specification NEC MultiSync® EA273WMi
DISPLAY
Panel Technology
IPS TFT with W-LED backlight
Screen Size [inch/cm]
27 / 68.6
Screen Aspect Ratio
16:9
Pixel Pitch [mm]
0.311
Brightness (typ.) [cd/m2]
250
Contrast Ratio (typ.)
1000:1 (25000:1 dynamic contrast ratio)
Viewing Angle [°]
178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Response Time (typ.) [ms]
6
Colours [Mio.]
16.77
SYNCHRONISATION RATE
Horizontal Frequency [kHz]
31.5 - 83
Vertical Frequency [Hz]
56 - 75
RESOLUTION
Optimum Resolution
1920 x 1080 at 60 Hz
Supported
1920 x 1080; 1600 x 1200; 1280 x 1024; 1152 x 864; 1024 x 768; 832 x 624; 800 x
600; 640 x 480
CONNECTIVITY
Digital
1 x DVI-D (with HDCP); 1 x HDMI; USB ver. 2.0 (1 down / 4 up); 1 x DisplayPort
Analog
1 x mini D-sub 15 pin
ELECTRICAL
Power Consumption on Mode [W]
23 (typ.); 16 (Eco Mode); 31 (max.)
Power Savings Mode [W]
< 0.5
Power Supply
100-120 V/220-0 V; 0.85 A/0.45 A; internal power supply
ENVIRONMENTAL CONDITIONS
Operating Temperature [°C]
+5 to +35
Operating Humidity [%]
20 to 80
ERGONOMICS
Height adjustable stand [mm]
130
Screen Tilt [°]
5 to 30
Screen Tilt / Swivel [°]
170 to 170
Screen Rotate [°]
0 to 90 (landscape to portrait mode)
MECHANICAL
Dimensions (W x H x D) [mm]
639.3 x 418 x 230
Weight [kg]
8.7
VESA Mounting [mm]
100 x 100
ADDITIONAL FEATURES
Colour Versions
White Front Bezel, White Back Cabinet; Black Front Bezel, Black Back Cabinet
Cable Management
yes
Kensington security slot
yes
Plug and Play
VESA DDC/CI; DDC2B/2Bi; EDID Standard
Audio
1W + 1W (De-activateable); Headphone Jack
Adjust Functions
Audio Volume / Lock-Out; Auto Adjust; Brightness; Colour Temperature Control;
Contrast; Control Sync; DV Mode; EcoMode; Fine Adjust (analog); Human
Sensing; Intelligent Power Management; Language Select; Monitor Information;
NTAA (Non-Touch-Auto-Adjustment); On-Screen-Display (OSD) lock-out; One
Touch Recovery; Power-Off Timer; sRGB
Shipping Content
Monitor; Power Cable; Control Sync Cable; USB Cable; Audio Cable; CD-ROM;
Sales Office List; User Manual
Signal Cable: VGA - VGA; DVI-D - DVI-D
Safety and Ergonomics
Energy Star 6.0; EPEAT™ Gold; CE; ErP; TCO 6.0; TÜV Ergonomics; TÜV GS; FCC
Class B; PCT/Gost; UL/C-UL or CSA; ISO 9241-307 (pixel failure class I); MPR II/
MPR III; RoHS
Warranty
3 years warranty incl. backlight
SPECIAL CHARACTERISTICS
Ambient light sensor for optimized brightness levels, Auto
Contrast, Carbon Footprint Meter, Carbon Savings Meter,
ControlSync®, Customize Setting, DICOM Simulation, EcoModes,
Energy Star 6.0, ErgoDesign®: Height adjustable stand (130 mm)
with 90° Pivot features, Human Sensor, LED Backlight Technology,
USB ver. 2.0 (4 down / 1 up), Versatile and easy installation (VESA
standard) with NaViSet and NaViKey, Windows 8 compatible
Energy Efficiency Ambient light sensor; Carbon Footprint
Meter / Carbon Savings Meter; ECOMode;
Human sensor
Ecological
Materials
Ecological
Standards
Efficient mechanical design for minimised
packaging; Minimal use of harmful material
TCO edge; EPEAT Gold; ErP compliant; TCO
6.0
