NEC DISPLAY SOLUTIONS

PRODUCT OVERVIEW 2013

DESKTOP DISPLAYS | PUBLIC DISPLAYS | PROJECTORS

NEW IN THIS EDITION

NEW DESKTOP DISPLAYS AND

PUBLIC DISPLAY SOLUTIONS

PUBLIC DISPLAYS

X462HB X462UNV X463UN X551UN X401S X462S

Order Code 60003174 60003594 60003302 60003146 60003327 60003399

Panel Technology / Backlight S-PVA / CCFL S-PVA / Direct LED S-PVA / Direct LED S-PVA / Direct LED S-PVA / Edge LED S-PVA / Edge LED

Screen Size [inch / cm] 46 / 117 46 / 117 46 / 117 55 / 139 40 / 102 46 / 117

Aspect Ratio 16:9 16:9 16:9 16:9 16:9 16:9

Pixel Pitch [mm] 0.530 0.746 0.746 0.63 0.461 TBD

Brightness (Max.) [cd/m2] 1500 450 700 700 700 700

Contrast (typ.) 3500:1 3500:1 3500:1 4000:1 3500:1 4000:1

Viewing Angle Hor / Vert [°] 178 / 178 178 / 178 178 / 178 178 / 178 178 / 178 178 / 178

Response Time grey-grey (typ.) [ms] 8 8 8 8 8 8

Colours [Mio.] 16.77 16.77 16.77 16.77 16.77 16.77

Native Resolution at 60 Hz 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080

Special Connectors DVI-D In, HDMI®, VGA

Slot-In Option STv1 STv1 or STv2 (OPS) STv1 or STv2 (OPS) STv1 or STv2 (OPS) STv2 (OPS) STv2 (OPS)

Power Use Normal [W] 320 120 120 190 120 110

Power Use Savings Mode [W] <1 <1 <1 <1 <1 <1

Power Management VESA DPMS

Dimensions (W x H x D) [mm] 1055 x 609 x 140 1024 x 577 x 118 1024 x 577 x 118 1215 x 686 x 128 925 x 537 x 43 1059 x 613 x 46

Weight [kg] 31 24.3 24.3 36.4 18.9 20.7

Bezel Width [mm] 16.5 / 17.0 3.7 T/L 1.8 B/R 3.7 T/L 1.8 B/R 3.7 T/L 1.8 B/R 21.0 18.7

Integrated Speakers - - - - 2 x 5W 2 x 5W

Energy Star

DisplayPort

= = = = = =

DVI-D In/Out, HDMI®, VGA

DisplayPort In/Out

= = = = =

DVI-D In/Out, HDMI®, VGA

DisplayPort In/Out

DVI-D In/Out, HDMI®, VGA

DisplayPort In/Out

DVI-D In/Out, HDMI, VGA

DisplayPort

DVI-D In/Out, HDMI,

DisplayPort

YEARS

WARRANTY

XUN SERIES

VALUE AND REFERENCE MODELS 24/7 TRUSTED PERFORMANCE

LEDBackl itLCD

DIRECT LED BACKLIGHTING DISPLAYPORT, HDMI ADVANCED HEAT MANAGEMENT

46” | 55”

LEDBackl itLCD

X SERIES | SPECIALIST EXTREME

FOR MORE DETAILED INFORMATION: PLEASE VISIT WWW.NEC-DISPLAY-SOLUTIONS.COM

XS SERIES

SLIM - SLIM ELEGANT DESIGN 24/7 REFERENCE PERFORMANCE EDGE LED BACKLIGHTING DISPLAYPORT, HDMI ULTRA LIGHT WEIGHT 40% LESS POWER CONSUMPTION

40” | 46” | 55”
