Navman PSAA05R-050, S30 Deluxe, S30 Traffic, S80 Deluxe User Manual
Ofrecido por www.electromanuales.com
S-Series
English
en
User Manual
Ofrecido por www.electromanuales.com
S-Series
2
Important safety information
PLEASE READ CAREFULLY BEFORE INSTALLING PRODUCT IN VEHICLE
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury or death.
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate
injury.
CAUTION used without the safety alert symbol indicates a potentially hazardous situation which, if not
avoided, may result in property damage.
Removing original equipment, adding accessories or modifying your vehicle could affect the vehicle’s safety or make it illegal to operate
in some jurisdictions.
Follow all product instructions and all instructions in your vehicle owner’s manual regarding accessories or modifications.
Consult your country’s and/or state’s laws regarding operation of a vehicle with any accessories or modifications.
It is your sole responsibility to place, secure and use your Navman in a manner that will not cause accidents, personal injury or property
damage. Always observe safe driving practices.
Do not mount your Navman in a way that may interfere with the safe operation of the vehicle, the deployment of air bags or other safety
equipment.
Do not operate your Navman while driving.
Before you use your Navman for the first time, familiarize yourself with your device and its operation.
On main roads, the distance to an exit calculated by the Navman may be further than the distance shown on road signs. Road signs
show the distance to the start of an exit while the Navman shows the distance to the next intersection, i.e., the end of the exit ramp or
road. To prepare to exit a road, always follow distance information on road signs.
The use of information regarding safety or speed camera locations may be subject to local laws in the country of use. You are
responsible for checking that you can legally use the information in your country or in the country where the information will be used.
Do not handle the Navman while it is hot. Let the product cool, out of direct sunlight.
At full power, prolonged listening to the Navman via headphones or earphones can damage the ear of the user.
Do not expose the Navman to direct sunlight in an unattended vehicle for prolonged periods. Overheating may damage the unit.
To discourage theft, do not leave the Navman, mounting bracket or any cables in plain view in an
unattended vehicle.
Home Charger-specific safety information
To charge your Navman from the mains power, use the home charger (Model: PSAA05R-050; Input: 100-240V AC 50-60Hz; Output: 5V
DC 1A Max) supplied by Navman as an accessory (may be sold separately). Using other home chargers with your Navman could result
in serious injury or property damage.
Never use the charger if the plug or cord are damaged.
Do not expose the charger to moisture or water. Do not use the charger in a high moisture environment. Exposure to water may cause
electrical sparks or fires.
Never touch the charger when your hands or feet are wet.
Allow adequate ventilation around the charger when using it to operate your Navman or charge the Navman internal battery. Do not
cover the charger with paper or other objects that will reduce ventilation. Do not use the charger while it is inside a carrying case or
other container.
Ensure that the charger is connected to a power source with the correct fitting and voltage requirements. The voltage requirements can
be found on the home charger casing and/or packaging.
Do not attempt to service the charger as this could result in personal injury. Replace the charger if it is damaged or exposed to
excess moisture.
Ofrecido por www.electromanuales.com
S-Series
3
Internal battery-specific safety information
The Navman contains a non-replaceable internal lithium-ion polymer battery. The battery may burst or explode if mishandled, releasing
hazardous chemicals. To reduce the risk of fire or burns, do not disassemble, crush or puncture the battery.
Recycle or dispose of the battery safely and properly according to local laws and regulations. Do not dispose of the battery in
fire or water.
Only use the correct mains power charger (sold separately) or in-vehicle charger supplied by Navman to charge the Navman
internal battery.
Only use the Navman internal battery with the Navman unit.
The Navman battery will stop charging when the ambient temperature is less than 0ºC (32ºF) or more than 45ºC (113ºF).
Warning Notice to Drivers in the United States
State law may prohibit drivers in states such as Arizona, California and Minnesota from mounting objects on their windshields while
driving. Please make sure you research and follow your most current State laws. An alternative mounting option is provided in the box
with your product, also, stores offer additional mounting alternatives. Navman does not take any responsibility for any fines, penalties, or
damages that may be incurred as a result of disregarding this notice.
Failure to adhere to these warnings and cautions may lead to death, serious injury or property damage. Navman disclaims all
liability for installation or use of the Navman that causes or contributes to death, injury or property damage or that violates any
law.
Ofrecido por www.electromanuales.com
S-Series
4
Contents
Important safety information...................................................................................................................2
Welcome................................................................................................................................................7
Important information for using the manual.......................................................................................7
Getting to know your Navman................................................................................................................8
Components .....................................................................................................................................8
S30 Deluxe/S30 Traffic.................................................................................................................8
S80 Deluxe...................................................................................................................................9
How do I get started?...........................................................................................................................10
How do I turn my Navman on for the first time? ..............................................................................10
How do I adjust the volume?...........................................................................................................14
How do I monitor the battery status?...............................................................................................14
What are the main screens I will use?..................................................................................................15
Main Menu screen ..........................................................................................................................15
Map screens ...................................................................................................................................15
How do I navigate with GPS? ..............................................................................................................16
How do I go from A to B?.....................................................................................................................17
What if I miss a turn? ......................................................................................................................17
How do I search for an address? ....................................................................................................18
Case Study: How do I search for an address?............................................................................18
Using the Keyboard screen ........................................................................................................20
Using the Destination Search screen..........................................................................................20
How do I create a trip with multiple stops? ......................................................................................22
Case Study: How do I navigate to multiple addresses? ..............................................................22
How do I skip a waypoint during a multi-stop trip?......................................................................26
How do I search for a Point of Interest (POI)?.................................................................................27
Case Study: How do I search for a Point of Interest?..................................................................27
How do I save Favourites and My Home?............................................................................................30
How do I save a Favourite or My Home? ........................................................................................30
How do I navigate to a Favourite?...................................................................................................31
How do I navigate to My Home? .....................................................................................................31
How do I edit the name of a Favourite? ..........................................................................................32
How do I delete a Favourite? ..........................................................................................................33
How do I navigate to a recent location? ...............................................................................................34
How do I view my route?......................................................................................................................35
3D Map screen ...............................................................................................................................35
2D Map screen ...............................................................................................................................37
Traffic Overview screen ..................................................................................................................39
Route Overview screen...................................................................................................................41
Turn-by-Turn screen .......................................................................................................................43
How do I use the Map Menu? .........................................................................................................45
How do I avoid an area?.................................................................................................................46
How do I add an Avoid Area?.....................................................................................................46
How do I delete an Avoid Area? .................................................................................................46
How do I delete all Avoid Areas?................................................................................................46
How do I preview a route? ...................................................................................................................47
How do I view my route statistics? .......................................................................................................48
How do I view statistics on my current route?............................................................................. 48
How do I view statistics of my trips to date?................................................................................49
How do I view my trip logs? ........................................................................................................50
How do I manage my NavPix?..........................................................................................................51
Album management ...................................................................................................................51
Ofrecido por www.electromanuales.com
S-Series
5
NavPix management................................................................................................................53
How do I add or edit a NavPix description?..............................................................................54
How do I navigate to a NavPix? ...................................................................................................55
How do I save a NavPix to a favourite?........................................................................................56
How do I save a NavPix to a POI? ............................................................................................... 57
How do I make a hands-free call?........................................................................................................58
How can I pair my Navman with a Bluetooth mobile phone?...........................................................58
How can I pair my Navman with a Bluetooth headset? ...............................................................58
How can I make a phone call using the Dial screen? ...................................................................... 59
How do I receive a phone call?.......................................................................................................60
How do I add a contact to my Navman?..........................................................................................60
How can I make a phone call to a contact?.....................................................................................60
How do I view my call history?........................................................................................................61
How do I receive current traffic information?........................................................................................62
How does my Navman receive traffic information? .........................................................................62
How will I know when a Traffic Event occurs?.................................................................................63
How do I view a list of all events on my route?................................................................................64
How do I view traffic details?...........................................................................................................65
How do I know if a detour is recommended? ..................................................................................66
Traffic Messages.............................................................................................................................67
What can I customize?.........................................................................................................................68
Route Options.................................................................................................................................69
Route Calculation 1/4 .................................................................................................................69
Road Types 2/4 ..........................................................................................................................70
Driver Alerts 3/4..........................................................................................................................71
Data Recording 4/4.....................................................................................................................72
Map Display....................................................................................................................................73
Map Display 1/3..........................................................................................................................73
Map Display 2/3..........................................................................................................................74
Select Map 3/3............................................................................................................................75
Map POIs........................................................................................................................................76
Volume ...........................................................................................................................................77
Screen Display................................................................................................................................78
POI Alerts .......................................................................................................................................79
GPS................................................................................................................................................80
GPS Status 1/2...........................................................................................................................80
Set GPS Mode 2/2......................................................................................................................81
Language........................................................................................................................................82
Traffic..............................................................................................................................................83
Traffic System Status..................................................................................................................83
Traffic Event Notification.............................................................................................................84
Select event sorting type ............................................................................................................85
Power .............................................................................................................................................86
Select Keyboard .............................................................................................................................87
How does predictive text (abc, def…) work?...............................................................................87
Units ...............................................................................................................................................88
Units 1/2 .....................................................................................................................................88
Units 2/2 .....................................................................................................................................89
Start-up........................................................................................................................................... 90
Bluetooth preferences.....................................................................................................................91
Saved Information...........................................................................................................................92
Tutorial............................................................................................................................................93
About ..............................................................................................................................................94
Shop Demo.....................................................................................................................................94
What is NavDesk? ...............................................................................................................................95
Can I use NavDesk with my computer?......................................................................................95
How do I install a map for the first time?.....................................................................................95
How do I install NavDesk onto my computer?.................................................................................96
NavDesk features ...........................................................................................................................97
How do I keep NavDesk up-to-date? ..............................................................................................98
NavDesk Preferences.................................................................................................................98
My Maps .........................................................................................................................................99
How do I install maps onto my Navman?..................................................................................100
Ofrecido por www.electromanuales.com
S-Series
6
How do I install maps from DVD? ............................................................................................. 100
How do I remove maps from my Navman?...............................................................................102
How do I know which map contains a particular city or town?...................................................102
My Map Preferences.................................................................................................................102
What is a Major Road Network map? .......................................................................................103
NavAlbum .....................................................................................................................................104
Toolbar .....................................................................................................................................105
How do I use NavAlbum?..............................................................................................................106
How can I view and edit pictures or albums on my computer?..................................................106
What else can I do with pictures and albums on my computer?................................................107
NavAlbum Preferences.............................................................................................................108
Image Search ...............................................................................................................................109
How do I download NavPix from the internet? .......................................................................109
How do I import NavPix to NavAlbum? ..................................................................................109
Mileage Reporter ..........................................................................................................................110
How do I input my trip data?.....................................................................................................110
How do I export a mileage report?............................................................................................111
How do I delete travel logs from my Navman?..........................................................................111
Mileage Reporter preferences ..................................................................................................111
My subscriptions...........................................................................................................................112
Alerts ........................................................................................................................................112
How do I install Safety Camera information? ............................................................................ 112
How do I know which Safety Camera information is available? ................................................112
Purchase a Subscription...........................................................................................................112
Activate your Subscription ........................................................................................................ 113
How do I update Safety Camera information on my Navman?..................................................113
Custom POIs ................................................................................................................................114
How do I install custom Points of Interest? ...............................................................................114
How do I delete a Custom POI File from my Navman?.............................................................115
Voice Transfer ..............................................................................................................................116
How do I install a voice file?......................................................................................................116
How do I remove a voice file?...................................................................................................116
How do I backup my Navman? .....................................................................................................117
Reference .......................................................................................................................................... 118
How do I insert a Memory Card?...................................................................................................118
S30 Deluxe/S30 Traffic.............................................................................................................118
S80 Deluxe............................................................................................................................... 118
How do I remove a Memory Card? ........................................................................................... 118
Point of Interest categories ...........................................................................................................119
Traffic and other TMC Events .......................................................................................................121
For more information..........................................................................................................................124
Ofrecido por www.electromanuales.com
S-Series
7
Welcome
Thank you for purchasing this Navman. This manual has been prepared to guide you through the operation of your
Navman from first set-up through to continuous use. Please read this manual carefully before using your Navman for
the first time. Keep this manual in a safe place and use as your first point of reference.
Important information for using the manual
It is important to understand the terms and typographical conventions used in this manual.
Formatting
The following formatting in the text identifies special information:
Convention Type of Information
Bold Navman components or items displayed on screen, including buttons, headings, field names and options.
Italics
Indicates the name of a screen.
Icons
The following icons are used throughout this manual:
Icon Description
Case study
Warning
Terms
The following terms are used throughout this manual to describe user actions.
Term Description
Tap Press and release an item displayed on the touch screen.
Tap and hold Tap and hold an item displayed on the touch screen for 2-3 seconds.
Select Tap an item in a list or tap a command from a menu.
Ofrecido por www.electromanuales.com
S-Series
8
Getting to know your Navman
We recommend that you familiarize yourself with the Navman's basic operations.
Components
S30 Deluxe/S30 Traffic
Power switch
Cradle socket
Slot for memory card
Socket for in-car charger, USB cable, home charger and TMC
accessory kit (sold separately)
Battery indicator
Speaker
Ofrecido por www.electromanuales.com
S-Series
9
S80 Deluxe
Slot for memory card
Cradle socket
Power switch
Socket for in-car charger, USB cable, home charger and TMC cradle
(sold separately)
Battery indicator
Speaker
Microphone
Ofrecido por www.electromanuales.com
S-Series
10
How do I get started?
Note: The first time you use your Navman, it may take up several minutes to establish a GPS connection. For more information about
GPS, refer to the GPS Frequently Asked Questions guide on the enclosed DVD.
How do I turn my Navman on for the first time?
To get started for the first time, complete the following steps:
1. Read the Important Safety Information on page 2.
2. Position your Navman
Follow the instructions below to position your Navman in your vehicle:
Note: Ensure that your Navman does not obstruct the driver's view, or interfere with the operation of the vehicle airbags and
safety devices.
S30 Deluxe/S30 Traffic
Ofrecido por www.electromanuales.com
S-Series
11
S80 Deluxe
Ofrecido por www.electromanuales.com
S-Series
12
3. Turn your Navman on
Slide the power switch to the ON position.
Your Navman will turn on and display the Language screen.
4. Select your preferred language
From the Select Language screen, tap your preferred language.
To prevent the Select Language screen from displaying on each start-up, clear the Show on start-up
check box.
You can change your preferred language while using your Navman (see "Language" on page 82).
5. Read the warning message
a) The Safety Agreement screen will display after you have selected your preferred language.
Read the Safety Agreement message.
b) To confirm that you have read and understood the message, tap Accept.
The Tutorial will display.
Ofrecido por www.electromanuales.com
S-Series
13
6. View the Tutorial
When you have accepted the Safety Agreement, the first Tutorial screen will display.
To prevent the Tutorial from displaying again on start-up, clear the Show on start-up check box.
To move forward through the Tutorial screens, tap
.
To view the previous screen, tap
.
To view the Tutorial again while using your Navman, see "Tutorial" on page 93.
Note: If you have maps installed from multiple continents, you may be prompted to select the maps you require.
To use maps from a different continent at a later time, you can select a different map via the Select Map screen in the
Select Map 3/3 preferences; refer to page 75.
When you have finished the Tutorial, the 3D Map screen will display. If you have a GPS fix, your current location will
be displayed on the map.
Ofrecido por www.electromanuales.com
S-Series
14
How do I adjust the volume?
The volume on your Navman can be adjusted by the volume control on the Volume preference screen.
To mute the volume from the map screens, tap
and then tap .
To adjust the volume, tap and hold
to display the Volume preference screen.
For more information on how to adjust the volume on your Navman, see “Volume” on page 77.
How do I monitor the battery status?
Your Navman has an internal battery that when fully charged, should provide power for up to 3 hours.
The battery indicator light on the top of the Navman indicates the level of internal battery charge:
Green - battery full
Orange - battery charging
You can monitor battery power status on the Power screen.
To access the Power screen, tap
and hold on the map screens.
How do I charge the battery?
The Battery Status bar displays External Power while the battery is charging; when the battery is fully charged, the
Battery Status bar will display at 100%.
To charge your Navman in a vehicle, plug the in-vehicle charger into
on the bottom of your Navman and the
other end into the vehicle power socket.
To charge your Navman using your computer, plug the large end of the USB cable directly into a USB port on
your computer (not a USB hub) and plug the small end into
on the bottom of your Navman. To begin
charging, ensure your Navman is turned off.
To charge your Navman using a mains power socket, plug the mains power charger cable into
on the
bottom of the Navman and the mains power charger power pack into the power socket.
Note: The mains power charger is not included with all models and may be purchased separately.
Ofrecido por www.electromanuales.com
S-Series
15
What are the main screens I will use?
Main Menu screen
The Main Menu screen is your starting point for searching for a destination. The Main Menu button allows you to
enter an address for your destination, customize preferences, receive updated traffic information and make and
receive phone calls.
The Main Menu can be accessed from the map screens by tapping
or by tapping the status bar at the
bottom of any screen.
Note: The Main Menu screens may differ from those displayed above, depending on your Navman model.
Map screens
There are five map screens used to view the route to your destination:
3D Map
2D Map
Traffic Overview (if available)
Route Overview
Turn-by-Turn™
The Map screens can be accessed from the Main Menu screen by tapping
.
You can cycle through the different map screens by pressing
on any map screen (the name of the map screen
will display briefly as your cycle through).
For more information on the map screens, see "How do I view my route?" on page 35.
For information on using the Map menu from the 3D Map and 2D Map screens, see "How do I use the Map
Menu?" on page 45.
Ofrecido por www.electromanuales.com
S-Series
16
How do I navigate with GPS?
The Global Positioning System (GPS) is available at any time, free of charge, and is accurate to within 5m (15ft).
GPS navigation is made possible by a network of satellites that orbit the Earth at around 20,200km (12,552mi). Each
satellite transmits a range of signals which are utilized by GPS receivers, such as your Navman, to determine an
exact location. Although a GPS receiver can detect signals from up to 12 satellites at any time, only four signals are
required to provide a position or "GPS fix" (latitude and longitude), for vehicle navigation systems.
How does my Navman receive GPS signals?
Your Navman receives GPS signals via the internal GPS antenna. To guarantee the optimum GPS signal strength,
ensure your Navman is outdoors, or in a vehicle outdoors, and has an unobstructed view of the sky. GPS reception is
not usually affected by weather, however, very heavy rain or snow may have a negative effect on your reception.
How do I view my GPS status?
You can view your GPS status at any time from the map screens or the Viewfinder screen. displays green
when a GPS fix is established and red when a GPS fix is unavailable. To indicate the reception strength of a GPS fix,
displays between one and four green vertical bars.
To view your GPS status in more detail, see "GPS Status" on page 80.
To set your GPS mode, see “Setting your GPS mode” on page 81.
For more information about GPS, refer to the GPS Navigation - Frequently Asked Questions guide on the
NavDesk DVD.
Ofrecido por www.electromanuales.com
S-Series
17
How do I go from A to B?
Your Navman is equipped with maps that provide street-level detail for door-to-door navigation, including Points of
Interest such as accommodation, parking areas, petrol stations, railway stations and airports.
When you ... Then ...
know the address of your destination use the address-entry wizard to enter the address on page 18.
want to make multiple stops
use the Multi-stop Trip Planner screen to enter multiple waypoints on page 22.
need to find a named site, feature, landmark or
public venue
search for a Point of Interest on page 27.
want to navigate to a NavPix™ location use the Go To NavPix screen to navigate to a preinstalled NavPix on page 55.
WARNING For your safety, enter destination information before you start a journey. Do not enter a destination while driving.
What if I miss a turn?
Back-On-Track™ Automatic Rerouting
You will be redirected if you make a wrong turn. A message informing you that your route is being re-calculated will
display at the top of the screen.
To cancel a route re-calculation tap
. A warning will display, asking you to confirm the cancellation. If confirmed,
both the re-calculation and your current route will be cancelled.
Ofrecido por www.electromanuales.com
S-Series
18
How do I search for an address?
Enter a destination using the Destination Search, Keyboard and Preview screens, which used together form an
address-entry wizard.
This section provides a case study to help guide you through setting your destination.
Note: In some countries, you can search for your destination by postcode or zip code. If you are in the United Kingdom, and you know
the postcode of your destination, you can search for it from the Destination Search screen by tapping Postcode, then entering a
postcode of up to eight characters.
Quick Steps
1. Open the Destination Search screen
2. Select the country
3. Search for the city/area
4. Search for the street
5. Search for the house number
6. Tap
.
Case Study: How do I search for an address?
This case study will show you how to enter an address and how to navigate to it.
The address we will be using in this example is:
Note: The below address is fictitious and used as an example only.
1 Navman Street
Horley
Surrey
RH6 8LD
United Kingdom
Tip: Before you enter your destination address, ensure that you have set your route preferences. For more information, see “Route
Options” on page 69.
1. Open the Destination Search screen
The Destination Search screen will display.
Note: If this is the first time you are setting your destination and you have maps from more than one country installed, then the
Select a map screen will display instead of the Destination Search screen. Go directly to step 2b.
The next time you perform this procedure, the Destination Search screen will open as expected.
Ofrecido por www.electromanuales.com
S-Series
19
2. Select the country
Note: If you only have the maps of one country installed and selected, that country is selected for your destination by default and cannot
be changed. Go to step 3.
a) From the Destination Search screen, tap .
The Select a map screen will display.
b) Select United Kingdom from the list.
The Destination Search screen will display.
3. Search for the City/Area
a) From the Destination Search screen, tap City/Area.
The Keyboard screen will display.
b) Use the Keyboard screen to search for Horley as the city or area of your destination, then tap the search
result.
The Destination Search screen will display.
4. Search for the street name and house number
a) From the Destination Search screen, tap Street Address.
The Keyboard screen will display.
Ofrecido por www.electromanuales.com
S-Series
20
Using the Keyboard screen
The Keyboard screen will display when you are required to enter text, such as when searching for a street name.
Search results will be listed in matching order, with the closest matches appearing at the top of the list. A maximum
of 99 results will display.
The Keyboard screen can display with various layouts depending on the information you need to enter, including
alphabet, number, alternate characters and combinations of these.
You can also choose the type of keyboard you prefer from alphabetic, QWERTY and keypad. For more information,
see “Keyboard” on page 87.
As you select each character, the first two results will display. Tap , then scroll to see more search results.
To select a character or a search result, tap the character or search result.
To delete a character, tap .
To display more characters, tap 123, alt or abc, if available.
Using the Destination Search screen
The Destination Search screen is used to select your destination by area, street, postal or ZIP code, Points of
Interest, intersection, city, area, state or country.
As you specify each part of the address, it will display at the top of the screen.
The available options will change to reflect the parts of the address still to be completed.
Ofrecido por www.electromanuales.com
S-Series
21
b) Use the Keyboard screen to enter Navman street as the street name of your destination, then tap the
search result.
Note: There may be multiple matches for a particular street name. Long streets that run through several neighbouring
areas, and common street names will produce search results ordered by their city or area name.
c) Use the Keyboard screen to enter 1 as the house number of your destination, then tap the search result.
The Preview screen will display.
Note: If house numbers are available, but not the one that you require, you may have to choose the same street in a
neighbouring area. Press and select another search result. If house numbers are not available for your selected
section of the street the Preview screen will display.
d) Complete one of the following:
If you want to ... Then ...
navigate to your selected destination
tap
.
Your route is calculated; the 3D Map screen will display.
view the position on the map screen
tap the map to display the position on the 2D Map screen.
view more information about your
destination
tap More.
The Destination Details screen will display.
add the destination to a multi-stop trip tap Add.
The Multi-stop Trip Planner screen will display. The address is listed as a
waypoint on the multi-stop trip. See “How do I create a trip with multiple
stops?” on page 22.
save the destination as My Home
tap Save.
The New Favourite screen will display.
tap Save as My Home.
save the destination as a favourite
tap Save.
The New Favourite screen will display.
tap Save as Favourite.
Ofrecido por www.electromanuales.com
S-Series
22
How do I create a trip with multiple stops?
You can use the Multi-stop Trip Planner screen to set multiple stops or waypoints for your trip. Your route will be
calculated to go via each of these points in the specified order.
You can save up to 198 multi-stop trips, each with up to 14 waypoints.
Note: Waypoints added, updated or deleted after a multi-stop trip has commenced will not affect the current route.
Quick Steps
1. Start your Multi-stop trip
2. Select the country
3. Search for the city/area
4. Search for the street and house number
5. Add additional waypoints
6. Tap
.
Case Study: How do I navigate to multiple addresses?
This case study will show you how to set a multi-stop trip by entering multiple waypoints.
The address we will be using in this example is:
Note: The below address is fictitious and used as an example only.
1 Navman Street
Horley
Surrey
RH6 8LD
United Kingdom
Tip: Before you enter your destination address, ensure that you have set your route preferences. For more information, see “Route
Options” on page 69.
1. Open your Multi-stop Trip screen
The Multi-stop Trip Planner screen will display.
Ofrecido por www.electromanuales.com
S-Series
23
a) Tap Add.
The Add to Trip Menu will display.
b) Tap Address.
The Destination Search screen will open.
Note: You can also add waypoints using favourites, recent destinations, POI locations and NavPix.
2. Select the country
Note: If you only have the maps of one country installed and selected, that country is selected for your destination by default and cannot
be changed. Go to step 3.
a) From the Destination Search screen, tap .
The Select a map screen will display.
b) Select United Kingdom from the list.
The Destination Search screen will display.
3. Search for the City/Area
a) From the Destination Search screen, tap City/Area.
The Keyboard screen will display.
b) Use the Keyboard screen to search for Horley as the city or area of your destination, then tap the search
result.
The Destination Search screen will display.
Ofrecido por www.electromanuales.com
S-Series
24
4. Search for the street name and house number
a) From the Destination Search screen, tap Street Address.
The Keyboard screen will display.
b) Use the Keyboard screen to enter Navman Street as the street name of your destination, then tap the
search result.
Note: There may be multiple matches for a particular street name. Long streets that run through several neighbouring
areas, and common street names will produce search results ordered by their city or area name.
c) Use the Keyboard screen to enter 168 as the house number of your destination.
The Preview screen will display.
Note: If house numbers are available, but not that you require, you may have to choose the same street in a neighbouring
area. If house numbers are not available for your selected section of the street the Destination Preview screen will display.
d) Tap Add.
The waypoint is automatically saved and the Multi-stop-Trip screen will display.
Ofrecido por www.electromanuales.com
S-Series
25
e) Complete one or more of the following:
If you want to ... Then ...
add another waypoint
Note: Waypoints added after a multi-stop
trip has commenced will not be included in
the current route.
tap Add.
The Add To Trip Menu will display.
return to step 1a.
navigate to your selected destination
tap .
The Preview screen will display.
tap .
The 3D Map screen will display the calculated route.
change the order of your waypoints
tap a destination point to move.
The Preview screen will display.
tap Up or Down.
The Multi-stop Trip Planner screen will redisplay.
delete all waypoints tap Clear.
delete one waypoint
tap a destination point to delete.
The Preview screen will display.
tap Delete.
The Multi-stop Trip Planner screen will redisplay.
save the multi-stop trip as a favourite
tap Save.
The New Favourite screen will display.
tap Save as Favourite.
The Favourite will be saved.
Ofrecido por www.electromanuales.com
S-Series
26
How do I skip a waypoint during a multi-stop trip?
To skip a waypoint during a multi-stop trip, complete the following:
1. Tap the map.
The Map Menu will display.
2. Tap Route, then Skip Waypoint.
The next waypoint will be skipped and the route recalculated to the following waypoint.
Ofrecido por www.electromanuales.com
S-Series
27
How do I search for a Point of Interest (POI)?
A POI is a named site, feature, landmark or public venue which can be displayed as an icon on the map. POIs are
grouped by type, such as petrol stations, parks, beaches and museums.
Select a POI using the Destination Search, Keyboard and Preview screens, which used together form a POI-entry
wizard.
Tip: You can also quickly search for certain POIs based upon your current location via the Main Menu screen.
This section provides a case study to help guide you through finding or setting your POI as a destination.
Quick Steps
1. Open the Destination Search screen
2. Select a country
3. Search for the City/Area
4. Search for a POI
5. Tap
.
Case Study: How do I search for a Point of Interest?
This case study will show you how to enter an address and navigate to it.
The address used in this example is:
Note: The below address is fictitious and used as an example only.
Waterloo Railway Station
Road A301
Waterloo
London
SE1 8UD
United Kingdom
1. Open the Destination Search screen
The Destination Search screen will display.
Note: If this is the first time you are setting your destination and you have maps from more than one country installed, then the
Select a map screen will display instead of the Destination Search screen. Go directly to step 2b.
The next time you perform this procedure, the Destination Search screen will open as expected.
Ofrecido por www.electromanuales.com
S-Series
28
2. Select the country
Note: If you only have the maps of one country installed and selected, that country is selected for your destination by default and cannot
be changed. Go to step 3.
a) From the Destination Search screen, tap .
The Select a map screen will display.
b) Select United Kingdom from the list.
The Destination Search screen will display.
3. Search for the city/area
a) From the Destination Search screen, tap City/Area.
The Keyboard screen will display.
b) Use the Keyboard screen to search for London as the city or area of your destination, then tap the search
result.
The Select POI Category screen will display.
Tip: The list of categories is divided into Enabled Categories which are set to display an icon on the map screens, and Other POI
Categories which will not display an icon.
Ofrecido por www.electromanuales.com
S-Series
29
4. Search for a POI
a) Either tap Search by name to search in all POI categories, or select a category from the list.
The Keyboard screen will display.
b) Use the Keyboard screen to search for Waterloo Railway Station as your destination, then tap the
search result.
The Preview screen will display.
c) Complete one of the following:
If you want to ... Then ...
navigate to your selected destination
tap
.
Your route is calculated and displayed on the 3D Map screen.
view your position on the map screen
tap the map to display the position on the 2D Map screen..
make a phone call to the POI tap Call.
Note: This feature is not available on all models.
view more information about your
destination
tap More.
The Destination Details screen will display.
add the destination to a multi stop trip tap Add.
The Multi-stop Trip Planner screen will display. The address is listed as a
waypoint on the multi-stop trip. See “How do I create a trip with multiple
stops?” on page 22.
save the destination as My Home
tap Save.
The New Favourite screen will display.
tap Save as My Home.
save the destination as a favourite
tap Save.
The New Favourite screen will display.
tap Save as Favourite.
Ofrecido por www.electromanuales.com
S-Series
30
How do I save Favourites and My Home?
You can save up to 200 destinations as favourites, one of which can be saved as My Home.
You can save a favourite from the Preview screen after searching for an address, or from the Map Menu on the 3D or
2D Map screens. For more information, see "How do I use the Map Menu?" on page 45.
Can I save a NavPix to a Favourite?
You can save a NavPix to any of your existing favourites. For more information, see "How do I save a NavPix to a
Favourite?" on page 56.
How do I save a Favourite or My Home?
1. Search for an address until the Preview screen is displayed.
2. Tap Save.
The New Favourite screen will display.
3. To change the name of the favourite, tap
.
The Keyboard screen will display.
4. After you have entered a name for the favourite, tap
.
The New Favourite screen will display.
5. Complete one of the following:
If you want to ... Then ...
save as a Favourite tap Save as Favourite.
The favourite is saved. The Preview screen will display.
save as My Home tap Save as My Home.
The favourite is saved as My Home. The Preview screen will display.
Loading...
