NAVMAN

w w w . n a v m a n . c o m

Operation Manual

VHF 7000,

7100US, 7100EU

2 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

IMPORTANT:

1. Some features described in this manual are not available on every model. In particular, DSC functions are NOT available on the 7000.

2. DSC functions will not operate on the 7100US or the 7100EU until your MMSID has been entered. Refer to section 4.2 for details.

3. The radio channels installed into the Navman VHF radio may vary from country to country, depending upon the model, and government or national communications authority regulations.

4. Navman NZ Ltd recommends that you check the radio operating licensing requirements of your country before using the Navman VHF radio. The operator is solely responsible for observing proper radio installation and usage practices.

5. A DSC warning label is supplied with the 7100US. To comply with FCC regulations, this label must be afxed in a location that is clearly visible from the operating controls of this radio. Make sure that the chosen location is clean and dry before applying this label.

It is the owner’s sole responsibility to install and use the instrument in such a manner that will not cause accidents, personal injury or property damage.

Navman NZ Limited disclaims all liability for any use of this product in a way that may cause accidents, damage or that may violate the law.

Governing Language: This statement, any instruction manuals, user guides and other information relating to the product (Documentation) may be translated to, or has been translated from, another language (Translation). In the event of any conict between any Translation of Documentation, the English language version of the Documentation will be the ofcial version of the Documentation.

This manual represents the Navman VHF 7000, 7100US, and &7100EU radios at the time of printing. Navman NZ Limited reserves the right to make changes to specications without notice.

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide a reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures:

• reorient or relocate the receiving antenna.

• increase the separation between the equipment and receiver.

• connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• consult the dealer or an experienced radio/TV technician for help.

3VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Contents

Section 1 - General Information .............................................................. 5

1-1 Features.................................................................................................... 5

1-2 Customizing Your Navman VHF Radio ..................................................... 6

1-3 How to Display and Navigate Menus ........................................................ 6

1-4 How to Enter Alphanumeric Data.............................................................. 6

1-5 LCD Symbols and Meanings ................................................................... 6

1-6 Basic Operation and Key Functions.......................................................... 8

Section 2 - The Radio Menu (MENU)..................................................... 11

2-1 Radio Menu Options (Menu) ...................................................................11

2-2 Maintain Your Buddy List (BUDDY LIST) ................................................ 12

2-2-1 Add an Entry...................................................................................... 12

2-2-2 Edit an Entry...................................................................................... 12

2-2-3 Delete an Entry.................................................................................. 13

2-3 Local or Distance Sensitivity (LOCAL/DIST)........................................... 13

2-3-1 Set Distance Sensitivity..................................................................... 13

2-3-2 Set Local Sensitivity .......................................................................... 13

2-4 Backlighting (BACKLIGHT) and Contrast (CONTRAST) ........................ 13

2-4-1 Set the Backlighting Level ................................................................. 14

2-4-2 Set the Contrast Level....................................................................... 14

2-5 GPS Data and Time (GPS/DATA) ........................................................... 14

2-5-1 Manually Enter Position and UTC Time (MANUAL) .......................... 14

2-5-2 Local Time (TIME OFFSET).............................................................. 14

2-5-3 Time Format Options (TIME FORMAT)............................................. 15

2-5-4 Time Display Options (TIME DISPLAY) ............................................ 15

2-5-5 Position Display Options (LL display)................................................ 16

2-5-6 Course and Speed Display Options (COG/SOG).............................. 16

2-5-7 GPS Alert Options (ALERT) ............................................................. 16

2-6 GPS Simulator (SIMULATOR) ................................................................ 17

2-7 Reset to factory defaults (RESET).......................................................... 17

Section 3 - Radio Setup Menu (RADIO SETUP)................................... 18

3-1 Radio Setup Menu (RADIO SETUP) ...................................................... 18

3-2 Channel Names (CH NAME) ................................................................. 18

3-3 RING & BEEP Volume (RING VOLUME) & (BEEP VOLUME).............. 19

3-4 Internal Speaker connections (INT SPEAKER) ...................................... 19

3-5 Set the Priority Channel (watch MODE) ................................................. 19

3-6 Weather Alert (Wx ALERT) .................................................................... 20

3-7 NMEA protocol (COM PORT) ................................................................. 20

Section 4 - DSC Setup Menu (DSC SETUP) ......................................... 21

4-1 DSC Setup - Menu Options .................................................................... 21

4-2 Enter Your User MMSID (USER MMSID) ............................................... 21

4-3 Maintain Your Groups (GROUP SETUP) ................................................ 22

4-3-1 Create a Group (GROUP SETUP) .................................................... 22

4 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

4-3-2 Edit Group Name Details .................................................................. 22

4-3-3 Delete a Group .................................................................................. 23

4-4 Response to Individual Calls (INDIV REPLY) ......................................... 23

4-5 atis MMSID & ATIS FUNCTIONALITY .................................................... 23

4-5-1 Enter or Edit YOUR ATIS MMSID ..................................................... 23

4-5-2 Enable ATIS Functionality (ATIS FUNC) ........................................... 24

4-6 DSC functionality options (DSC FUNC).................................................. 24

4-7 Response Type to LL POLLING Calls (LL REPLY)................................. 25

Section 5 - Sending and Receiving DSC Calls .................................... 26

5-1 WHAT IS DSC?....................................................................................... 26

5-2 Sending dsc calls .................................................................................... 26

5-2-1 Make a Routine Call (INDIvidual) ...................................................... 27

5-2-2 Retrying a Routine Call ..................................................................... 27

5-2-3 Acknowledgement of an Individual Incoming Call (INDIV) ................ 27

5-2-4 Recall the Most Recent Incoming Call (LAST) .................................. 28

5-2-5 Call a Group (GROUP)...................................................................... 28

5-2-7 Call using the Call Log (CALL LOG................................................... 29

5-2-8 Call using the Distress Log (DIST LOG) ........................................... 29

5-2-9 Request the LL Position of a Buddy (LL REQUEST) ........................ 30

5-3 Receiving DSC Calls............................................................................... 30

5-3-1 Receiving an All Ships Call (ALL SHIPS) .......................................... 31

5-3-2 Receiving an Individual Call (INDIV) ................................................. 31

5-3-3 Receiving a Group Call (GROUP)..................................................... 31

5-3-4 Receiving a Geographic Call (GEOGRAPH)..................................... 31

5-3-5 Receiving a Polled Position Call (POSITION) ................................... 32

Section 6 - Distress Calls ...................................................................... 33

6-1 Sending a Distress Call .......................................................................... 33

6-2 Receiving a Distress Call (DISTRESS!).................................................. 34

6-3 Distress Acknowledgement (distress ack) or Relay .............................. 34

Appendix A - Technical Specications ........................................................... 35

Appendix B - Troubleshooting ....................................................................... 38

Appendix C - VHF Marine Channel Charts........................................... 39

C-1 international Channel Chart.................................................................... 39

C-2 USA Channel Chart ................................................................................ 42

C-3 CANADA Channel CHART..................................................................... 45

C-4 EU Channel Chart .................................................................................. 48

Special Channels 7................................................................................. 50

Appendix D - MMSID & License Information........................................ 51

Appendix E - How to Contact Us........................................................... 52

5VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Section 1 - General Information 1-1 Features

Congratulations on your purchase of a Navman VHF 7000, 7100US, or 7100EU marine band VHF radio. All of these models provide the following useful features:

• prominent channel display

• adjustable contrast settings for the LCD

• adjustable keypad backlighting for easy night-time use

• waterproof and submersible to comply with JIS-7

• GPS latitude and longitude (LL) and time display (when connected

to a GPS)

• choice of High or Low (25 W or 1 W) transmission power

• top centred PTT button for comfortable left- or right-handed use

• powerful 4 W external audio output

• access to all currently-available marine VHF channel banks (USA, Canada, International) including weather channels where available

• special CH16 or CH16/9 key for quick access to the priority (international distress) channel

• special 3CH key to select your three favourite channels

• PSCAN (similar to dual watch) facility

In addition, the VHF 7100 models also provide:

• DSC (Digital Select Calling) capability that meets USCG SC101 and Class D Standards. 7100US only.

• DSC (Digital Select Calling) capability that meets EC Class D Standards. VHF 7100EU only.

• DISTRESS call button to automatically transmit the MMSID and position until an acknowledgement is received

• easy access to a buddy list of up to 20 favourite people

• MMSID storage for three favourite groups

• Group Call and All Ships Call facility

• LL position polling information

• Weather alert facility. VHF 7100US only.

• ATIS facility for inland waterways. VHF 7100EU only.

6 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

1-2 Customizing your Navman VHF Radio

You can customize the radio to suit your individual preferences. Some preferences can be set directly through the keys as explained in this Section.

Other preferences are set up through the built-in menus and these are explained in the other Sections.

1-3 How to Display and Navigate Menus

1. Hold down MENU (or CALL/MENU). Note that only four menu items can be displayed at any one time on the screen.

2. Press + CH - to scroll up and down the menu until the cursor is positioned at the desired option. Press ENT to display that option.

3. Make any entries or changes as explained in the following section.

4. Press ENT to conrm changes. Otherwise, press ESC to keep the original entry.

5. Press ESC to backup one screen or exit. Any changes are active as soon as you exit the screen.

1-4 How to Enter Alphanumeric Data

If your radio does not have the optional alphanumeric microphone, use the + CH - key to enter alphanumeric data.

Press - to count through numbers, or hold down to scroll rapidly to the desired number.

Press + to step through the alphabet, or hold down to scroll rapidly to the desired character.

If you make an error, press - until < is displayed, then press ENT to backup and correct the entry.

1-5 LCD Symbols and Meanings

This simulation shows the locations of all the following information symbols:

7VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Symbol Meaning

TX Transmitting.

HI LO Transmission power. High (HI) 25W or Low (LO) 1W.

WX Weather channel.

WX ALT Weather Alert. Alarm beeps will sound. VHF 7100US only.

BUSY Receiver busy with an incoming signal.

PRI Priority channel is selected.

D Duplex operation. Otherwise, blank for Simplex operation.

LOCAL Local calling is selected. Otherwise, blank for distance calling.

DSC DSC capability is available. VHF 7100US and VHF 7100EU only.

Incoming DSC call.

Low Battery warning (activates at 10.5 V)

88 Channel selected.

USA INT CAN Selected channel bank for VHF radio operations and regulations.

X Channel is temporarily deleted from the ALL SCAN operation.

B A Channel sufx, if applicable.

CH1 CH2 CH3 Shows which of the 3 favourite channels, if any, are selected.

Otherwise blank.

ATIS Enabled for use in European inland waterways. Otherwise blank.

VHF 7100EU only.

A typical operational display is shown here.

The latitude and longitude of the vessel and the local time are shown.

A transmission on Channel 16 is being made at high power using the International channel bank.

Channel 16 is set as the Priority channel. It is also set as favourite channel 1.

There is an incoming DSC call so the receiver is busy.

8 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

1-6 Basic Operation and Key Functions

All possible keys and their functions are listed. Note that some of the keys are not available depending on your Navman VHF radio model.

Key Function

VOL/PWR Volume and Power. Turn clockwise to power on. Continue to turn until a

comfortable volume is reached. VOL/PWR will also adjust the settings of an external speaker, if connected.

SQL Squelch or Threshold Level. Sets the threshold level for the minimum

receiver signal. Turn fully counterclockwise until random noise is heard, then turn slowly clockwise until the random noise disappears. Make another 1/4 turn clockwise for best reception in open sea conditions.

In areas of high noise (eg close to large cities) reception may improve if

sensitivity is reduced. Either turn SQL slowly clockwise or use the LOCAL setting. See section 2.3.

16/9 Priority Channel. VHF 7100US only. Also on the microphone. Press to

cancel all other modes and to tune into the priority channel. Press again to return to your original channel.

The default is Channel 16. To make Channel 09 the priority channel, hold

down 16/9 until a beep sounds and 09 is displayed.

16 Priority Channel. VHF 7100EU and VHF 7000 only. Also on the microphone.

Press to cancel all other modes and to tune into the priority channel, Channel 16, on high power. Press again to return to your original channel.

WX Weather Channel. VHF 7100US and VHF 7000 only. In USA and Canadian

waters, press to hear the most recently selected weather station. The WX symbol is displayed on the LCD.

Press + or - to change to a different weather channel. Press WX again to

return to the most recent channel.

If the weather alert mode (ALT) is ON and an alert tone of 1050Hz is

broadcast from the weather station, it is picked up automatically and the alarm sounds. Press any key to hear the weather alert voice message.

9VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

H/L Transmission Power. High (HI) 25W or Low (LO) 1W. Press to toggle

between high or low transmission power for the entire channel bank. The HI or LO selection is shown on the LCD.

Some channels allow only low power transmissions. Error beeps will sound if

the power transmission setting is incorrect.

Some channels allow only low power transmissions initially, but can be

changed to high power by holding down H/L and PTT at the same time. See Appendix C for a complete listing of channel charts.

3CH Three Favourite Channels. Also on the microphone. Press to toggle

between your favourite channels. The CH1, CH2, or CH3 symbol appears on the LCD to show which favourite channel is selected.

To scan only one of your favourite channels, press 3CH then immediately

press and release SCAN. If you want to scan all three favourite channels, press 3CH then immediately press and hold SCAN.

To add a favourite channel for the rst time, select that channel then hold

3CH to store it in the CH1 location. Repeat the procedure to store two more favourite channels in the CH2 and CH3 locations respectively.

If you try and add another favourite channel it will overwrite the existing CH3.

CH1 and CH2 remain unless you delete them.

To delete a favourite channel, select that channel then hold down 3CH until

the CH1, CH2 or CH3 symbol disappears off the LCD.

UIC Channel Bank. 7100US only. Press to toggle between USA, International

or Canadian channel banks. The selected channel bank is displayed on the LCD along with the last used channel. All the channel charts are shown in Appendix C.

U/I Channel Bank. 7000 only. Press to toggle between channel banks. Note

that the channel banks available are dependent upon your VHF radio model. The selected channel bank is displayed on the LCD along with the last used channel. All the channel charts are shown in Appendix C.

DIM Backlighting. 7100EU only. Press to toggle between the backlighting

settings. OFF will extinguish all the backlighting except for the DISTRESS key. (Otherwise, use the menu to change the backlight setting.)

SCAN Scan. Press to scan between your current channel and the priority channel in

DUAL or TRI WATCH mode. The weather channel is also scanned if the USA channel bank is selected and the weather alert mode (ALT) is ON.

Hold down SCAN to enter ALL SCAN mode where the priority channel is

checked every 1.5 seconds.

When a signal is received, scanning stops at that channel and BUSY

appears on the screen. If the signal ceases for more than 5 seconds, the scan restarts.

Press ENT to temporarily skip over (lock out) an “always busy” channel when

in ALL SCAN mode and resume the scan. An X is shown on the screen to designate a skipped channel. Note that it is not possible to skip over the priority channel.

Press SCAN to stop at the current channel.

10 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

+ CH - Channel Select. Also on the microphone. The current channel is shown on

the screen in BIG digits with an appropriate designator sufx A or B in small letters below the channel number.

Press + or - to step through the available channels one at a time, or hold

down to scroll rapidly through all the available channels. See Appendix C for a listing of channel charts.

Alphanumeric Entry. This key can also be used for menu selection and for

alphanumeric entry. Press + or - to scroll the cursor up or down menu options when navigating menus.

When editing an item containing only numbers, press - to count through the

numbers or hold down to scroll rapidly.

To enter a character, press + to step through the alphabet or hold down to

scroll rapidly.

ENT Enter. Use ENT when navigating menus, to conrm entries and edits.

ESC Escape. Use ESC when navigating menus, to clear incorrect entries, to

exit from a menu without saving changes, and to back up to the previous screen.

CALL/MENU DSC Setup Menu and DSC Call Menu. 7100US and 7100EU only. Press to

enter the DSC Call Menu and make DSC calls. See Section 5.

Hold down to enter the DSC Setup Menu and customize your radio. See

Section 4.

MENU Radio menu. 7000 only. Press to enter the Radio Menu and customize your

NAVMAN VHF radio. See Section 3.

DISTRESS Send DSC Distress Call. 7100US & 7100EU only. See Section 6

PTT Press To Talk. Press PTT to transmit at any time on an allowable channel.

This automatically exits you from menu mode and stops scanning. You must release PTT to receive a signal.

If PTT sticks, a built-in timer will automatically shut down a transmission after

ve minutes and sound the error beeps.

11VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Section 2 - The Radio Menu (MENU)

2-1 Radio Menu Options (Menu)

The following options are available through MENU (or CALL/MENU):

Sections 1-3 and 1-4 explain how to navigate around the menu and enter, save and change data.

CH NAME RING VOLUME BEEP VOLUME INTERNAL SP WATCH MODE WX ALERT COM PORT

USER MMSID GROUP SETUP INDIV REPLY DSC FUNC ATIS MMSID ATIS FUNC LL REPLY

MANUAL SETTING

Maintain your buddy list. See Section 2-2.

Set radio sensitivity.

See Section 2-3.

Set backlight level.

See Section 2-4.

Set contrast level.

See Section 2-4.

Set position & UTC manually.

See Section 2-5.

Set local time and time format.

See Section 2-5.

DSC Setup Menu.

7100US and 7100EU only. See Section 4.

Make DSC calls.

7100US and 7100EU only. See Section 5.

Radio Setup Menu. See Section 3.

Turn the GPS Simulator on/off.

See Section 2.6.

Reset factory settings. See Section 2.7.

12 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

2-2 Maintain Your Buddy List (BUDDY LIST)

VHF 7100US and VHF 7100EU only.

Use the Buddy List to store the names and associated MMSIDs of 20 favourite people. Names are stored in the order of entry, with the most recent entry shown rst.

The following sections show to use BUDDY LIST to add, edit, and delete entries on your buddy list.

Section 3 explains how to call a buddy.

2-2-1 Add an Entry

1. Select BUDDY LIST. The cursor is at MANUAL NEW. Press ENT.

2. Enter the buddy name, one character at a time (this may be alphanumeric) then press ENT repeatedly until the cursor moves to the MMSID entry line.

4. Enter the MMSID associated with that buddy name (this must be numeric) then press ENT.

5. The new buddy name and MMSID are displayed. Press ENT to store the new entry, which is displayed at the top of your buddy list.

Note that when the BUDDY LIST is full (20 entries), you cannot make a new entry until you have deleted an existing entry.

2-2-2 Edit an Entry

1. Select BUDDY LIST. Press ENT to display the list of entries.

2. Scroll down (if required) to the incorrect entry and press ENT.

3. Select EDIT. The cursor is at the rst character of the name.

4. Edit the buddy name or, to edit only the MMSID, press ENT repeatedly until the cursor moves to the MMSID line.

5. When you are nished, press ENT (repeatedly if necessary) to display the next screen.

6. Press ENT to store the changes. The buddy list is displayed again. If more changes are required, repeat Steps 2 thru 6. Otherwise, press ESC to exit.

MENU SELECT >BUDDY LIST

LOCAL/DIST BACKLIGHT

BUDDY LIST >MANUAL NEW

ALEX TOM

ENTER NAME –––––––––––– ENTER MMSID –––––––––

ENTER NAME BOB ENTER MMSID 123456789

BOB 123456789 >STORE

CANCEL

ALEX >EDIT

DELETE

EDIT NAME ALEX EDIT MMSID 112233445

ALEX 111223344 >STORE

CANCEL

BUDDY LIST >MANUAL NEW

ALEX TOM

13VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

2-2-3 Delete an Entry

1. Select BUDDY LIST. Press ENT to display the list of entries.

2. Scroll down (if required) to the entry you want to delete and press ENT.

3. Select DELETE then select YES.

4. The entry is deleted immediately and the buddy list is displayed again.

2-3 Local or Distance Sensitivity (LOCAL/DIST)

Use LOCAL/DIST to improve the sensitivity of the receiver either locally (LOCAL) or over distances (DIST).

LOCAL is not recommended for use in open sea conditions. It is designed for use in areas of high radio noise; for example, close to cities.

See also SQL (Squelch Control) in Section 1.6.

2-3-1 Set Distance Sensitivity

1. Select LOCAL/DIST then select DIST.

2. Press ENT to activate the DIST setting. This disables local sensitivity and the menu is displayed again.

2-3-2 Set Local Sensitivity

1. Select LOCAL/DIST then scroll to LOCAL.

2. Press ENT to activate the LOCAL setting. This disables distance sensitivity and the menu is displayed again.

LOCAL is displayed on the LCD as a reminder that local sensitivity is selected.

2-4 Backlighting (BACKLIGHT) and Contrast (CONTRAST)

Use BACKLIGHT to set the backlight levels for the LCD and the keypad at a comfortable level.

The microphone keypad backlighting is either ON or OFF.

Use CONTRAST to set the contrast level for the LCD.

BUDDY LIST >MANUAL NEW

ALEX TOM

BUDDY LIST MANUAL NEW

ALEX

>TOM

TOM EDIT >DELETE

DELETE BUDDY TOM >YES

MENU SELECT BUDDY LIST >LOCAL/DIST

BACKLIGHT

SENSITIVITY >DISTANT

LOCAL

SENSITIVITY DISTANT >LOCAL

MENU SELECT LOCAL/DIST >BACKLIGHT CONTRAST

14 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

2-4-1 Set the Backlighting Level

1. Select BACKLIGHT.

2. Select a comfortable backlight level using + or - to change the setting.

3. Press ENT to enable the setting and return to the menu.

Note that the DISTRESS key backlighting cannot be switched off.

2.4.2 Set the Contrast Level

1. Select CONTRAST.

2. Select a comfortable contrast level using + or - to change the setting.

3. Press ENT to enable the setting and return to the menu.

2-5 GPS Data and Time (GPS/DATA)

If the boat has an operational GPS navigation receiver, the VHF radio automatically detects and updates the vessel position and the local time.

However, if the GPS navigation receiver is disconnected or absent, you can specify the vessel position and the local time manually, using the GPS/DATA option.

This information is important because it will be used if a DSC distress call is transmitted.

You can also enter the course (COG) and speed (SOG) and select GPS Alert and GPS Simulator options.

2-5-1 Manually Enter Position and UTC Time (MANUAL)

Note that this function is available only if an operational GPS receiver is not connected.

1. Select GPS/DATA, then MANUAL.

2. Enter the latitude, then the longitude, then the UTC.

3. Press ENT when all the information is correct.

The vessel’s latitude and longitude are shown on the screen, with the UTC time. The prex

MAN indicates a manual entry. The manual entries are cancelled if a real GPS position is received.

2-5-2 Local Time (TIME OFFSET)

The local time can be set by entering the time offset between UTC and local time as follows.

MANUAL LL ––’ ––’ ––––N ––’ ––’ ––––W MAN ––:––UTC

GPS/DATA >MANUAL

SETTING

BACKLIGHT

LO HI

CONTRAST

LO HI

MENU SELECT

BACKLIGHT CONTRAST

>GPS/DATA

15VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

1. Select GPS/DATA, then SETTING.

2. Select TIME OFFSET to enter the difference between UTC and local time. Half hour increments can be used with a maximum offset of ±13 hours.

In this example, a difference of +1.5 hours has been entered and the local time is displayed

with the sufx LOC.

2-5-3 Time Format Options (TIME FORMAT)

Time can be shown in 12 or 24 hour format.

1. Select GPS/DATA, then SETTING.

2. Select TIME FORMAT.

3. Select 12 Hr or 24 Hr as desired. In this example, 12 hour format has been selected and so the LCD shows the AM or PM sufx.

2-5-4 Time Display Options (TIME DISPLAY)

If you have entered the time manually as described in the previous sections, the time is always shown on the screen with the prex M.

11 10 9 8 7 6 5 4 3 2 1 0 1 2 3 4 5 6 7 8 9 10 11

5.5

9.5

11 10 9 8 7 6 5 4 3 2 1 0 1 2 3 4 5 6 7 8 9 10 11

TIME FORMAT >12 Hr 24 Hr 07:15AM LOC

GPS/DATA MANUAL >SETTING

GPS/DATA TIME OFFSET >TIME FORMAT

TIME DISPLY

GPS/DATA MANUAL >SETTING

GPS/DATA >TIME OFFSET

TIME FORMAT TIME DISPLY

TIME OFFSET >+01:30

02:30PM LOC

16 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

However, if the vessel position is being updated through a GPS navigation receiver, you can switch the time display on the screen ON or OFF as follows:

1. Select GPS/DATA, then SETTING.

2. Select TIME DISPLAY.

3. Select ON (on) or OFF (off) as desired. In this example, OFF has been selected and so the screen no longer shows the time.

If the time display is set ON, course and speed data are not displayed on the LCD (see section 2-5-6).

2-5-5 Position Display Options (LL display)

If you have entered the vessel position manually as described in the previous section, the vessel position is always shown on the screen with the sufx M.

However, if the time is being updated through a GPS navigation receiver, you can switch the vessel position display on the screen on or off as follows:

1. Select GPS/DATA, then SETTING.

2. Select LL DISPLAY.

3. Select ON (on) or OFF (off) as desired. In this example, OFF has been selected and the screen no longer shows the vessel position.

2-5-6 Course & Speed Display Options (COG/SOG)

Use this option to display course over ground (COG) and speed over ground (SOG) data on the screen.

1. Select GPS/DATA, then SETTING.

2. Select COG/SOG.

3. Select ON (on) or OFF (off) as desired. In this example, ON has been selected and so the screen shows the bearing and speed.

If GOG/SOG is set ON (on), the time is not displayed on the screen (see section 2-5-4).

2-5-7 GPS Alert Options (ALERT)

The GPS alert is usually set to ON (on) so that if the GPS navigation receiver is disconnected, the alarm sounds.

1. Select GPS/DATA, then SETTING.

2. Select GPS ALERT.

3. Select ON (on) or OFF (off) as desired.

GPS/DATA TIME OFFSET

TIME FORMAT

>TIME DISPLY

TIME DISPLY ON >OFF

GPS/DATA

TIME FORMAT TIME DISPLY

>LL DISPLAY

LL DISPLAY ON >OFF

GPS/DATA TIME DISPLY LL DISPLY >COG/SOG

COG/SOG >ON OFF

GPS/DATA LL DISPLY COG/SOG >GPS ALERT

GPS ALERT >ON OFF

17VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

2-6 GPS Simulator (SIMULATOR)

The GPS Simulator is set to OFF whenever the radio is turned ON or whenever real GPS data is available through the COM port. However, if you want to test it, turn it on.

1. Select GPS SIM, then select ON (on) or OFF (off) as desired.

Whenever the GPS Simulator is turned ON (on), simulated

Speed Over Ground (SOG), Course Over Ground (COG), and LL position appear on the screen. This data is updated automatically during the simulation.

It is not possible to send a DSC transmission when in Simulator mode.

2-7 Reset to Factory Defaults (RESET)

Use this to return every setting to the factory defaults except all MMSID settings and the entries in your buddy list.

1. Select RESET. The radio asks for conrmation.

2. Select YES to reset the radio and return to the menu.

MENU SELECT DSC SETUP RADIO SETUP >GPS SIM

MENU SELECT RADIO SETUP GPS SIM >RESET

RESET RADIO ARE YOU SURE >YES NO

18 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Section 3 - Radio Setup Menu (RADIO SETUP) 3-1 Radio Setup Menu (RADIO SETUP)

Sections 1-3 and 1-4 explain how to navigate around the menu and enter, save and change data.

3-2 Channel Names (CH NAME)

The channel charts are listed in Appendix C with their default name tags. CH NAME gives you the option to edit or delete the channel name tags displayed on the screen.

1. Select RADIO SETUP, then CH NAME.

2. Use + or - to step through the channels with their name tags until you see the channel name tag you want to change, then press ENT. In this example, the channel name TELEPHONE associated with channel 01 is being changed to PHONE1.

3. Select EDIT and press ENT to edit the existing name tag. Input the new name over the

existing name. It can be a maximum of 12 characters.

To delete the channel name, select DELETE and press ENT.

CH NAME

RING VOLUME

BEEP VOLUME

INT SPEAKER

WATCH MODE

WX ALERT

COM PORT

Edit or delete channel names.

See Section 3-2.

(Selects if the WX Alert scanning mode is ON (on) or OFF (off). (VHF 7100US only.) See section 3-6.

Selects the operation of Dual or Tri watch scanning.

See section 3-5.

Switch ON/OFF (on/off) the radio’s internal speakers. See section 3-4.

Select NMEA protocol for communications between the VHF radio and any other instruments. See section 3-7.

Set the volume level of the beeps.

See section 3-3.

Set the volume level of the incoming call notication beeps. See section 3-3.

RADIO SETUP >CH NAME RING VOLUME BEEP VOLUME

CH NAME TELEPHONE

TELEPHONE >EDIT DELETE

EDIT CH NAME TELEPHONE

EDIT CH NAME PHONE1 >YES NO

19VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

4. Press ENT (repeatedly if necessary) to display the YES/NO conrmation.

5. Press ENT to conrm the new channel name tag or the deletion, then press ESC to return to the menu.

3-3 RING & BEEP Volume (RING VOLUME)

& (BEEP VOLUME)

Set the volume level of the incoming signal beeps (RING VOLUME) and/or the error and warning beeps (BEEP VOLUME) to HIGH (high) or LOW (low) as follows:

1. Select RADIO SETUP, then RING VOLUME or BEEP VOLUME as appropriate.

2. Select a HIGH or LOW volume. (It is possible to turn the beeps off completely by selecting BEEP VOLUME then OFF.)

3. Press ENT to enable the new volume setting and return to the menu.

3-4 Internal Speaker Connections (INT SPEAKER)

Switch the radio’s internal speaker ON (on) or OFF (off). The external speaker is always ON (on) if a speaker is plugged into the external speaker jack.

1. Select RADIO SETUP, then INT SPEAKER.

2. Select ON (on) or OFF (off) then press ENT to enable the setting and return to the menu.

3-5 Set the Priority Channel (WATCH MODE)

If you have a VHF7000 or a VHF 7100EU, watch mode is similar to a dual watch, scanning between the priority channel and the working channel. CH16 is the priority channel.

However, if you have a VHF 7100US and are operating on USA or Canadian channel banks, you can set the priority channel to cover both CH16 and CH09 as well as the working channel, as follows:

1. Select RADIO SETUP, then WATCH MODE.

2. Select ONLY 16CH for dual watch mode, or 16CH+9CH for tri watch mode.

INT SPEAKER >ON OFF

RADIO SETUP RING VOLUME BEEP VOLUME >INT SPEAKER

RADIO SETUP CH NAME >RING VOLUME BEEP VOLUME

RING VOLUME >HIGH LOW

BEEP VOLUME >HIGH LOW OFF

RADIO SETUP BEEP VOLUME INT SPEAKER >WATCH MODE

WATCH MODE >ONLY 16CH 16CH+9CH

20 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

3-6 Weather Alert (Wx ALERT)

VHF 7100US only.

The NOAA provides several weather forecast channels on USA and Canadian channel banks. If severe weather such as storms or hurricanes are forecast, the NOAA broadcasts a weather alert on 1050 Hz. You can set up the radio to pick up weather alerts, as follows:

1. Select RADIO SETUP, then WX ALERT.

2. Select ON (on) or OFF (off) then press ENT to enable the setting and return to the menu.

When a weather alert is broadcast, the alarm will sound. Press any key to hear the weather alert voice message.

3-7 NMEA protocol (COM PORT)

The radio can be added to a group of instruments using NMEA protocol.

1. Select RADIO SETUP, then COM PORT.

2. Select CHECKSUM ON (on) or OFF (off) then press ENT to enable the setting and return to the menu.

CHECKSUM ON is the usual setting.

WX ALERT ON >OFF

RADIO SETUP INT SPEAKER WATCH MODE >WX ALERT

RADIO SETUP WATCH MODE WX ALERT >COM PORT

NMEA CHECKSUM >ON OFF

21VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Section 4 - DSC Setup Menu (DSC SETUP)

These DSC facilities are available only on the 7100US and 7100EU and a valid user MMSID must be entered to access the DSC functions.

4-1 DSC Setup - Menu Options

The following options are available:

Sections 1.3 and 1.4 explain how to navigate around the menu and enter, save and change data.

4-2 Enter Your USER MMSID (USER MMSID)

This is a once-only operation. You must enter your user MMSID before you can access the DSC functions.

You can display and read your user MMSID at any time, but you get only one opportunity to enter your user MMSID.

1. Select DSC SETUP, then USER MMSID.

2. If this is the rst time that you are entering your user MMSID, a dashed line appears.

Enter your user MMSID along the dashed line. Press ENT to conrm each correct

entry and to move to the next digit.

Enter your user MMSID. See section 4.2. (If you do not have a user MMSID, see Appendix D.)

USER MMSID

GROUP SETUP

INDIV REPLY

ATIS MMSID

ATIS FUNC

DSC FUNC

LL REPLY

Enter or change the name and/or details of a group.

See section 4.3.

Enter or change your ATIS MMSID (VHF 7100EU only). See section 4.5.

Enable/disable the ATIS function (VHF 7100EU only). See section 4.5.

Select the type of response to an LL polling request.

See section 4.7.

Turn the DSC operation ON/OFF (on/off).

See section 4.6.

Choose an automatic or manual response to calls (VHF 7100US only). See section 4.4.

DSC SETUP >USER MMSID GROUP SETUP INDIV REPLY

USER MMSID INPUT AGAIN –––––––––

INPUT USER MMSID –––––––––

187654321 MMSID >STORE CANCEL

22 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

If you make an error, press - until < appears, then press ENT to backup and correct the

entry.

3. Press ENT to store your user MMSID.

4. Enter your user MMSID again as a password check, then press ENT to permanently store the user MMSID and return to the menu.

You can view your stored user MMSID at anytime by selecting USER MMSID in the main

menu.

4-3 Maintain Your Groups (GROUP SETUP)

Use GROUP SETUP to create, edit, or delete 1, 2, or 3 groups of frequently called people stored in alphanumeric order. A group MMSID always starts with 0.

4-3-1 Create a Group (GROUP SETUP)

1. Select DSC SETUP, then GROUP SETUP.

2. If this is the rst time that you are entering a group name, a line of nine zeros appears. Otherwise, any existing group names are displayed. Press ENT to display the input screen.

3. Enter the group name along the dashed line. It can be alphanumeric. Press ENT to conrm each correct entry and to move to the next digit. When you have nished, press ENT repeatedly until the cursor moves to the MMSID line.

If you make an error, press - until < appears, then press ENT to backup and correct the

entry.

4. Enter the group MMSID. (Note that the rst number is always 0.) Press ENT.

5. The group name and group MMSID are shown in a conrmation screen. Press ENT to store the details and return to the GROUP SETUP screen.

4-3-2 Edit Group Name Details

1. Select DSC SETUP, then GROUP SETUP. The existing group names are displayed. Press + or - to scroll to the incorrect entry then press ENT.

2. Press ENT to edit. The group name details are displayed, with the cursor at the rst character of the name.

3. Edit the buddy name or, to edit only the MMSID, press ENT repeatedly until the cursor moves to the MMSID line.

4. When you are nished, press ENT (repeatedly if necessary) to display the next screen.

5. Press ENT to store the changes and return to the GROUP SETUP screen.

DSC SETUP USER MMSID >GROUP SETUP INDIV REPLY

GROUP SETUP >MANUAL NEW 000000000

GROUP NAME –––––––––––– GROUP MMSID 0––––––––

FISHER1 012345678 >STORE CANCEL

FISHER1 >EDIT DELETE

GROUP SETUP MANUAL NEW >FISHER1 FRIENDS1

FISHER2 012345678 >STORE CANCEL

EDIT NAME FISHER1 EDIT MMSID 012345678

23VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

FISHER2 EDIT >DELETE

GROUP SETUP MANUAL NEW >FISHER2 FRIENDS1

4-3-3 Delete a Group

1. Select DSC SETUP, then GROUP SETUP. The existing group names are displayed.

2. Press + or - to scroll to the incorrect entry then press ENT.

3. Select DELETE and press ENT. The radio asks for conrmation.

4. Press ENT to delete the group and return to the GROUP SETUP screen.

4-4 Response to Individual Calls (INDIV REPLY)

VHF 7100US only. You can respond to incoming individual calls with an automatic response or with a manual response.

An automatic response sends an acknowledgement and then sets the request link channel, ready for a conversation.

A manual response asks if you want to acknowledge the call, and then asks if you want to converse with the caller.

1. Select DSC SETUP, then INDIV REPLY.

2. Select AUTO for an automatic response, or MANUAL for a manual response.

3. Press ENT to conrm your choice and return to the menu.

4-5 ATIS MMSID & ATIS FunctionalityVHF 7100EU only. You must

enter your ATIS MMSID to access ATIS functionality if you are navigating inland waterways within Europe.

ATIS sends a digital message anytime that you release the PTT key. Inland waterways rules require 1W Tx power on Channels 06, 08, 10, 11, 12, 13, 14, 15, 17, 71, 72, 74, and 77.

4-5-1 Enter or Edit YOUR ATIS MMSID

DSC SETUP GROUP SETUP INDIV REPLY >ATIS MMSID

VHF 7100EU only. An ATIS MMSID always starts with the number 9. To enter or edit your ATIS MMSID:

INDIV REPLY >AUTO MANUAL

DSC SETUP USER MMSID GROUP SETUP >INDIV REPLY

DELETE GROUP FISHER2 >YES NO

INPUT ATIS MMSID 9––––––––

INPUT ATIS MMSID >STORE CANCEL

INPUT AGAIN ATIS MMSID 9––––––––

ATIS MMSID 923456789 >STORE CANCEL

24 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

1. Select DSC SETUP, then ATIS MMSID.

2. If this is the rst time that you are entering your ATIS MMSID, a dashed line appears. Enter your ATIS MMSID along the dashed line. The rst number is always 9. Press ENT to conrm each correct entry and to move to the next digit.

If you make an error, press - until < appears, then press ENT to backup and correct the

entry.

If you are editing an existing ATIS MMSID, this will be displayed. Make the required

changes.

3. Press ENT to store your user MMSID.

4. Enter your ATIS MMSID again as a password check, then press ENT to permanently store the ATIS MMSID and return to the menu.

You can view your stored ATIS MMSID at anytime by selecting ATIS MMSID in the main

menu.

4-5-2 Enable ATIS Functionality (ATIS FUNC)

VHF 7100EU only. ATIS functionality will operate only after the ATIS MMSID has been entered (see previous section).

1. Select DSC SETUP, then ATIS FUNC.

2. Select ON (on) to enable the ATIS functionality and automatically disable DSC functionality. The ATIS annunciator appears on the screen.

It is not possible to have both ATIS ON (on) and DSC ON (on) simultaneously. When you

enable one, the other will turn OFF (off). If DSC and ATIS are both OFF (off), DSC will have to be switched ON (on) for normal DSC operation.

There are two annunciators in the screen to show you the current mode: if the DSC annunciator is shown, DSC is operational, if the ATIS annunciator is shown, ATIS is operational.

4-6 DSC functionality options (DSC FUNC)

DSC functionality can be disabled but this is not recommended.

1. Select DSC SETUP, then DSC FUNC.

2. Press ENT to select ON and to operate the DSC functionality. This will automatically disable ATIS functionality. The DSC annunciator appears on the screen.

It is not possible to have both ATIS ON (on) and DSC ON (on) simultaneously. When you enable one, the other will turn OFF (off). If DSC and ATIS are both OFF (off), DSC will have to be switched ON (on) for normal DSC operation.

ATIS FUNC >ON OFF

DSC SETUP INDIV REPLY ATIS MMSID >ATIS FUNC

DSC SETUP GROUP SETUP INDIV REPLY >DSC FUNC

DSC FUNC >ON OFF

ATIS

25VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

There are two annunciators in the screen to show you the current mode: if the DSC annunciator is shown, DSC is operational. If the ATIS annunciator is shown, ATIS is operational.

4-7 Response Type to LL Polling Calls (LL REPLY)

You can set up the radio to respond to an LL polling request in one of three ways:

AUTO automatically replies to any incoming LL polling requests from any of your buddies.

MANUAL choose whether to reply automatically or manually to any incoming buddy polling

requests.

OFF ignores all incoming buddy LL polling requests.

1. Select DSC SETUP, then LL REPLY.

2. Select your response and press ENT to conrm and return to the menu.

LL REPLY >AUTO MANUAL OFF

DSC SETUP INDIV REPLY DSC FUNC >LL REPLY

26 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Section 5 - Sending and Receiving DSC Calls

5-1 WHAT IS DSC?

DSC (Digital Selective Calling) is a semi-automated method of establishing VHF, MF, and HF radio calls. It has been designated as an international standard by the IMO (International Maritime Organization) and is part of the GMDSS (Global Maritime Distress and Safety System).

Currently, you are required to monitor Distress Channel 16, but DSC will eventually replace listening watches on distress frequencies and will be used to broadcast routine and urgent maritime safety information.

DSC enables you to send and receive calls from any vessel or coast station that is equipped with DSC functionality, and within geographic range. Calls can be categorised as distress, urgency, safety, or routine, and DSC selects a working channel automatically.

5-2 Sending DSC calls

1. Press CALL MENU to show the types of DSC call that can be made.

Note that only four DSC call types can be shown at any

one time on the screen.

2. Press + or - to scroll up and down the DSC call types until the cursor is positioned at the desired option. Then press ENT. The DSC call types are:

These DSC facilities are available only on the VHF 7100US and VHF 7100EU models, and a valid user MMSID must have been entered to access the DSC functions.

>INDIVIDUAL INDIV ACK LAST GROUP

INDIVIDUAL

LAST CALL

GROUP

ALL SHIPS

CALL LOG

DIST LOG

LL REQUEST

Make a routine call or acknowledgement to a new caller or a buddy. See Section 5-2-1, 5-2-2, and 5-2-3.

Make a call to one of your three groups.

See Section 5-2-5.

Show the details of the most recent incoming call.

See Section 5-2-4.

Make an All Ships call.

See Section 5-2-6.

Show the details of the 20 most recent incoming calls.

See Section 5-2-7.

Show the details of the 10 most recent distress calls.

See Section 5-2-8.

Request the LL position of a buddy.

See Section 5-2-9.

27VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

5-2-1 Make a Routine Call (Individual)

You can call any other person that has another DSC equipped radio.

1. Press CALL/MENU to enter DSC mode, then select INDIVIDUAL. This allows you to call another person.

2. Select MANUAL NEW to call a person that is not in your buddy list, otherwise select the name of your buddy. Press ENT.

If you selected MANUAL NEW, you need to enter the user MMSID and then press ENT.

3. Select the working channel and press ENT. (Note: Duplex channels cannot usually be called and are automatically eliminated from the suggested call list. If the call is to a Coast Station, the radio will recognize this and select the correct channel.)

4. The radio summarizes the call details and asks for conrmation to send the call (SEND?). Press ENT to send the call. The radio goes to CH70 and the Tx annunciator is displayed on the screen while the DSC call is being sent.

5. If the call is acknowledged (ACK), press PTT to talk. If there is no reply, retry making the call. See Section 5-2-2.

5-2-2 Retrying a Routine Call

1. If there is no reply to your call after one minute (UNABLE TO ACKNOWLEDGE) the radio asks if you want to retry the call (SEND AGAIN?).

2. Select YES and press ENT to retry the call.

The radio will repeat this cycle twice. If the call still cannot be

placed, the radio returns to normal operation.

5-2-3 Acknowledgement of an Individual Incoming Call (INDIV)

The VHF 7100EU requires the operator to manually send an acknowledgement to the requesting radio.

Press ENT to send an acknowledgement or ESC to cancel.

The VHF 7100US will automatically send an acknowledgement to the requesting radio within 10 seconds of receiving the call.

DSC CALL >INDIVIDUAL LAST CALL GROUP

INDIVIDUAL >MANUAL NEW BOBBY D REBECCA T

MANUAL MMSID 0––––––––

012345678 INDIVIDUAL ROUTINE >SET CHANNEL

012345678 INDIVIDUAL ROUTINE >SEND?

12345678 INDIVIDUAL ROUTINE CALLING...

012345678 INDIVIDUAL ROUTINE WAITING ACK

INDIV ACK 012345678 PRESS PTT ESC –> EXIT

VHF7100 SEND AGAIN? >YES CANCEL

RCV: INDIV 012345678 ENTER –> ACK ESC –> EXIT

28 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

5-2-4 Recall the Most Recent Incoming Call (LAST)

This facility is useful and used frequently.

1. Press CALL/MENU to enter DSC mode. LAST CALL is automatically selected. Press ENT to display the contact details of the most recent incoming call.

2. Select the working channel and press ENT. (Note: Duplex channels cannot usually be called and are automatically eliminated from the suggested call list. If the call is to a Coast Station, the radio will recognize this and select the correct channel.)

3. The radio summarizes the call details and asks for conrmation to send the call (SEND?). Press ENT to send the call, and continue as explained in Section 5-2-1.

5-2-5 Call a Group (GROUP)

1. Press CALL MENU to enter DSC mode, then select GROUP. The radio displays the names of your groups.

2. Select the group that you want to call (the Group MMSID must be set before making the call). Then set the channel and continue as explained in Section 5-2-1.

5-2-6 CALL ALL SHIPS (ALL SHIPS)

The ALL SHIPS ROUTINE call option is shown only on the VHF 7100US.

1. Press CALL MENU to enter DSC mode, then select ALL SHIPS.

2. The priority is set automatically to URGENCY. However, you can select one of the following call priorities:

URGENCY for use when a serious situation or problem arises that could lead to a

distress situation

SAFETY to send safety information to all other vessels in range;

ROUTINE routine call (VHS 7100US only).

3. CH16 is selected automatically as the working channel and the radio asks for conrmation of the ALL SHIPS call. Press ENT to select YES and send the call. Continue as explained in Section 5-2-1.

VHF7100 USA INDIVIDUAL ROUTINE >SEND?

VHF7100 USA INDIVIDUAL ROUTINE 10:22AM LOC

DSC CALL INDIVIDUAL >LAST CALL GROUP

VHF7100 USA INDIVIDUAL ROUTINE >SET CHANNEL

RD GROUP 055554444 ROUTINE >SET CHANNEL

SELECT GROUP >RD GROUP GROUP #2 GROUP#3

DSC CALL INDIVIDUAL LAST CALL >GROUP

VHF7100 USA INDIVIDUAL ROUTINE >SEND?

ALL SHIPS URGENCY >YES NO

ALL SHIPS >URGENCY SAFETY ROUTINE

DSC CALL LAST CALL GROUP >ALL SHIPS

29VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

5-2-7 Call using the Call Log (CALL LOG

The Call Log contains the contact details for the 20 most recent incoming calls, so that you call any of them again quickly.

1. Press CALL MENU to enter DSC mode, then select CALL LOG.

Scroll down to the desired contact details.

The radio displays the contact details for the most recent incoming call as the rst entry

(01) in the call log. In the example, the contact details for the 11th most recent call are displayed.

2. Press ENT to conrm the call back, then set the working channel and press ENT to send the call. Continue as explained in Section 5-2-1.

5.2.8 Call using the Distress Log (DIST LOG)

The Distress Log contains the Distress Log data for the 10 most recent relayed Distress Calls, so that you can call any of them quickly. Always try to make voice contact on CH16 rst, as follows:

1. Press CALL/MENU to enter DSC mode, then select DIST LOG.

2. The most recently received Distress Call Is the rst entry (01) in the Distress Log. Select the entry that you want to call and press ENT.

The details are displayed over two screens that alternate every 1.5 seconds; the rst screen

shows the location and name or MMSID of the vessel in Distress, the second screen shows the nature of the emergency (if specied) and the MMSID of the vessel that relayed the Distress Call.

3. Set the channel and continue as explained in Section 5-2-1.

VHF7100 INDIVIDUAL ROUTINE >SEND?

DSC CALL GROUP ALL SHIPS >CALL LOG

11 VHF7100 INDIVIDUAL ROUTINE 10:45PM LOC

VHF7100 >CALL BACK DELETE

VHF7100 INDIVIDUAL ROUTINE >SET CHANNEL

DSC CALL ALL SHIPS CALL LOG >DIST LOG

VHF7100 >CALL BACK DELETE

DISTRESS RELAY PIRACY 987654321

02 10:03 UTC VHF7100 (xxx) 82º50. N 27º45. W

VHF7100 INDIVIDUAL ROUTINE >SET CHANNEL

VHF7100 INDIVIDUAL ROUTINE >SEND?

30 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

5-2-9 Request the LL Position of a Buddy (LL REQUEST)

1. Press CALL/MENU to enter DSC mode, then select LL REQUEST.

2. Select the buddy whose LL position you want to request then press ENT to send the request. (See Section 5-3-5 for the acknowledgement.)

3. The working channel name is displayed while the radio waits for an acknowledgement from your buddy. If there is no reply after 1 minute the radio asks if you want to retry. Continue as explained in Section 5-2-2.

5-3 Receiving DSC Calls

Several types of DSC calls can be received from vessels within range at various priority levels:

DISTRESS See Section 6.

ALL SHIPS Urgency or Safety priority (see Section 5-3-1)

INDIVIDUAL Urgency, Safety, or Routine priority (see Section 5-3-2)

GROUP Routine priority only (see Section 5-3-3)

GEOGRAPHIC Routine priority only (see Section 5-3-4)

POLLED POSITION

Routine priority only (see Section 5-3-5)

In addition to the audible alert, the telephone icon will ash on the screen.

SAM LL REQUEST >SEND?

LL REQUEST >SAM VHF7100 BUDDY #3

DSC CALL CALL LOG DIST LOG >LL REQUEST

channel name SAM LL REQUEST AWAITING ACK

SAM LL REQUEST

CALLING...

31VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

5-3-1 Receiving an All Ships Call (ALL SHIPS)

1. When you receive notication of an ALL SHIP call, press any key to cancel the alert. The radio automatically selects CH16.

The priority level and the user MMSID are displayed on the screen.

If the radio recognises the user MMSID as one of your buddies, the buddy’s name is displayed in place of the user MMSID.

2. No acknowledgement is required. Press PTT to initiate voice contact on CH16 and then switch to a working channel.

The call data is stored in the Call Log (see Section 5-2-7).

5-3-2 Receiving an Individual Call (INDIV)

1. When you receive notication of an INDIV call, press any key to cancel the alert. The radio automatically selects the channel designated in the incoming call. INDIV calls are almost always Routine priority.

If the radio recognises the user MMSID as one of your buddies, the buddy’s name is

displayed in place of the user MMSID.

2. The VHF 7100US responds automatically but the VHF 7100EU prompts you to press ENT to acknowledge the incoming call.

3. The caller should respond to your acknowledgement by making voice contact on the designated channel. If this does not happen, you can press PTT to initiate voice contact instead.

The call data is stored in the Call Log (see Section 5-2-7).

5-3-3 Receiving a Group Call (GROUP)

1. When you receive notication of a GROUP call, press any key to cancel the alert. The radio automatically selects the channel designated in the incoming call.

The priority level is always routine, and the group is identied on

the screen. The group will be one of the three groups of frequently called people that you set up earlier (see Section 4-3).

2. You do not need to send an acknowledgement. If desired, press PTT to initiate voice contact on the designated channel.

The call data is stored in the Call Log (see Section 5-2-7).

5-3-4 Receiving a Geographic Call (GEOGRAPH)

A geographic call is received by vessels within a specic geographic boundary area.

1. When you receive notication of a GEOGRAPH call, press any key to cancel the alert. The radio automatically selects the channel designated in the incoming call.

The time and the user MMSID or name are displayed on the screen. If the radio recognises

the user MMSID as one of your buddies, the buddy’s name is displayed in place of the user MMSID.

2. Monitor the working channel for an announcement from the calling vessel.

RCV: GROUP GP: RD GROUP VHF7100 ROUTINE

RCV: ALL SHIP priority VHF7100 ESC –> EXIT

RCV: INDIV VHF7100 ENTER –> ACK ESC –> EXIT

INDIV ACK VHF7100 PRESS PTT ESC –> EXIT

RCV: GEOGRAPH VHF7100 10:34 UTC ESC –> EXIT

32 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

5-3-5 Receiving a Polled Position Call (POSITION)

1. When you receive GPS position data from a buddy in response to your LL request (see Section 5-2-9), you are recommended to make a written note of the position, especially if it is a good shing position.

If enhanced LL position information is available from your buddy,

this is shown on the screen until the screen display changes.

RCV: POSITION SAM 82º50. 003'N 27º45.543'W

33VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Section 6 - Distress Calls

6-1 Sending a Distress Call

1. Open the red cover labelled DISTRESS.

If time is available to specify the nature of the distress, go to step 2. Otherwise, go directly to

step 3.

2. Press the DISTRESS key to display the following categories. Scroll to the category that describes your situation, then press ENT:

UNDEFINED

FIRE

FLOODING

COLLISION

GROUNDING

LISTING

SINKING

ADRIFT

ABANDONING

PIRACY

OVER BOARD

EPRIB

3. Hold down the DISTRESS key for about 3 seconds, until you see the distress call sent message (DISTRESS CALL SENT!) on the screen. The whole display starts to ash and beep loudly.

The distress call repeats ve times continuously. It then repeats randomly every 3.5 to 4.5

minutes until a distress acknowledgement (DISTRESS ACK) is received from a search and rescue authority or until you cancel the distress call manually.

The radio selects CH16 automatically so that you can hear any incoming voice contacts from

search and rescue authorities or other vessels within range.

Press ESC if you need to cancel the distress call. This is the only key that operates in distress

mode.

This DSC function is available only on the 7100US and 7100EU models, and a valid user MMSID must have been entered to access this DSC function.

DISTRESS CALL >PIRACY OVER BOARD EPRIB

DISTRESS CALL >PIRACY HOLD DISTRESS 2 SECONDS..

DISTRESS CALL SENT! WAIT.. PRESS ESC TO CANCEL...

34 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

6-2 Receiving a Distress Call (DISTRESS!)

1. An alert sounds when a distress call (DISTRESS!) is received. Press any key to cancel the alert. You do not need to send an acknowledgement.

2. The radio automatically selects CH16 and displays the details of the distress call on the screen. Press PTT to establish voice contact.

The details are displayed over two screens that alternate every 1.5 seconds; the rst screen

shows the user MMSID and nature of the emergency (if specied), the second screen shows the time and the location (if specied). If the location and time are not specied, these are replaced with sequences of 9s and 8s respectively.

The VHF7100 is capable of receiving enhanced LL position data if the vessel transmitting

the Distress Call is sending this. This provides the position of the distressed vessel to within 20 m (60ft).

6-3 Distress Acknowledgement (

DISTRESS ACK

) or Relay

An alert sounds when a Distress Relay (DISTRESS RELAY) is received. Press any key to cancel the alert.

Try to make voice contact with the calling vessel. Maintain a listening watch on CH16 and standby to lend assistance.

For a Distress Acknowledgement (DISTRESS ACK) sent from the Coast Guard, your radio automatically cancels Distress Mode transmissions and CH16 appears. Press PTT to establish voice contact with the Coast Guard.

The Coast Guard is the only agency allowed to send a Distress Acknowledgement (DISTRESS ACK).

RCV: DISTRESS 123456789 FLOODING ESC –> EXIT

RCV: DISTRESS 10:34 UTC 82º50.003'N 27º45.543'W

RCV: DISTRESS RELAY 123456789 ESC –> EXIT

35VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Navman VHF 7000

GENERAL

Power Supply: 13.6 V DC. Current drain: Transmit 6A at 25W Tx / 1.5A at 1W Tx Receive Less than 250 mA in standby Useable channels: International, USA (country specic) Mode: 16K0G3E (FM)

PHYSICAL

LCD display (viewing): 41(H) x 53(W) mm FSTN 4 x 12 character Contrast and Dimming control: Yes Antenna connector: SO-239 (50 ohm) Temperature Range: -15ºC to +50ºC Waterproof: JIS-7 Dimensions: 161(W) x 75(H) x 147(D) mm - without bracket Weight: 1.29 kg (2.8lbs) - without microphone Frequency stability: +/- 10ppm Frequency control: PLL GPS/NMEA input: Yes Comm. port: 4800 baud NMEA DSC: No

FEATURES

Flush Mount kit and dust cover: Yes Local/Distant control: Yes Position polling: No GPS Position & Data: Yes Call logs: Yes - 20 individual and 10 distress DSC (USCG SC101 and Class D): No Channel Naming: Yes Dual Watch, Favourite channel scan, All scan: Yes User programmable MMSID: No MMSID and NAME directory: No

TRANSMITTER

Frequency: 156.025 - 157.425MHz Output power: 25 W / 1 W selectable Transmitter protection: Open / short circuit of antenna

Appendix A - Technical Specications

36 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Max Freq deviation: +/- 5kHz Spurious & harmonics: 80dB@25W, 60dB@1W Modulation distortion: Less than 4%@ 1kHz for a +/-3kHz deviation

RECEIVER

Frequency: 156.025 - 163.275MHz 12dB SINAD sensitivity: 0.25uV (distant) / 2.5uV (local) 20db SINAD sensitivity: 0.35uV Adjacent CH selectivity:more than 70db Spurious response: more than 70db Intermodulation Rejection ratio: more than 68db Residual Noise level: more than -40db unsquelched Audio output power: 2W (with 8 ohm at 10% distortion) 4W with 4 ohm external speaker Compass safe distance: 0.5m (1.5')

Specications are subject to change without notice.

Navman VHF 7100

GENERAL

Power Supply: 13.6V DC. Current drain: Transmit 6 A at 25 W Tx / 1.5A at 1W Tx Receive Less than 250mA in standby Useable channels: International, USA, Canada, Weather (country specic) Mode: 16K0G3E (FM) / 16K0G2B (DSC)

PHYSICAL

LCD display (viewing): 41(H) x 53(W) mm FSTN 4 x 12 character Contrast and Dimming control: Yes Antenna connector: SO-239 (50 ohm) Temperature Range: -15ºC to +50ºC Waterproof: JIS-7 Dimensions: 161(W) x 75(H) x 147(D) mm - without bracket Weight: 1.29 kg (2.8 lbs) - without microphone Frequency stability: +/- 10ppm Frequency control: PLL GPS/NMEA input: Yes Comm. port: 4800 baud NMEA DSC: Yes

FEATURES

Flush Mount kit and dust cover: Yes Local/Distant control: Yes

37VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Position polling: Yes Group Call: Yes Call logs: Yes - 20 individual and 10 distress DSC (USCG SC101 and Class D): Yes (VHS 7100US) Channel Naming: Yes Tri watch, Favourite channel scan, All scan: Yes User programmable MMSID: Yes MMSID and NAME directory: Yes - 20 numbers & group

TRANSMITTER

Frequency: 156.025 - 157.425MHz Output power: 25 W / 1 W selectable Transmitter protection: Open / short circuit of antenna Max Freq deviation: +/- 5kHz Spurious & harmonics: better than 2.5µ W Modulation distortion: Less than 4%@ 1kHz for a +/-3kHz deviation

RECEIVER

Frequency: 156.025 - 163.275 MHz 12dB SINAD sensitivity: 0.25uV (distant) / 2.5uV (local) 20db SINAD sensitivity: 0.35uV Adjacent CH selectivity:more than 65db (VHS 7100US) more than 70 db (VHS 7100EU) Spurious response: more than 65 db (VHS 7100US) more than 70 db (VHS 7100EU) Intermodulation Rejection ratio: more than 65 db (VHS 7100US) more than 68 db (VHS 7100EU) Residual Noise level: more than -40db unsquelched Audio output power: 2 W (with 8 ohm at 10% distortion) 4 W with 4 ohm external speaker Compass safe distance: 0.5 m (1.5')

Specications are subject to change without notice.

38 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Appendix B - Troubleshooting

1. The transceiver will not power up.

A fuse may have blown OR there is no voltage getting to the transceiver.

a) Check the power cable for cuts, breaks, or squashed sections.

b) After checking the wiring, replace the 7 Amp fuse (2 spare fuses are supplied).

c) Check the battery voltage. This must be greater than 10.5V.

2. The transceiver blows the fuse when the power is switched on.

The power wires may have been reversed.

a) Check that the red wire is connected to the positive battery terminal, and the black wire

is connected to the negative battery terminal.

3. The speaker makes popping or whining noises when the engine is running.

Electrical noise may be interfering with the transceiver.

a) Re-route the power cables away from the engine.

b) Add a noise suppressor to the power cable.

c) Use resistive spark plug wires and/or use an alternator whine lter.

4. No sound from the external speaker.

a) Check that the external speaker cable is physically connected.

b) Check the soldering of the external speaker cable.

5. Transmissions are always on low power, even when high (HI) power is selected.

The antenna may be faulty.

a) Test the transceiver with a different antenna.

b) Have the antenna checked out.

6. Battery symbol is displayed.

The power supply is too low or too high.

a) Check the battery voltage. This should be at least 10.5V ± 0.5V DC.

b) Check the alternator on the vessel.

7. No position information is displayed.

The GPS cable may faulty or the GPS setting may be incorrect.

a) Check that the GPS cable is physically connected.

b) Check the polarity of the GPS cable.

c) Check the baud rate setting of the GPS if applicable. The baud rate setting should be

4800 and parity should be set to NONE.

39VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

Appendix C - VHF Marine Channel Charts

C.1 International Channel Chart

CH SEND

(MHz)

RECEIVE (MHz)

TRAFFIC TYPE SHIP

TO SHIP

SHIP TO SHORE

NAME TAG

01 156.050 160.650 Public Correspondence, Duplex No Yes TELEPHONE

02 156.100 160.700 Public Correspondence, Duplex No Yes TELEPHONE

03 156.150 160.750 Public Correspondence, Duplex No Yes TELEPHONE

04 156.200 160.800 Port Operations, Duplex No Yes PORT OPS

05 156.250 160.850

Port Operations, Selected VTS Areas

No Yes PORT OPS/VTS

06 156.300 156.300 Inter-ship Safety Yes No SAFETY

07 156.350 160.950 Port Operations, Duplex No Yes PORT OPS

08 156.400 156.400 Commercial (inter-ship only) Yes No COMMERCIAL

09 156.450 156.450 Recreational Calling Channel Yes Yes CALLING

10 156.500 156.500 Commercial Yes Yes COMMERCIAL

11 156.550 156.550 Commercial, VTS in Selected Areas Yes Yes VTS

12 156.600 156.600

Port Operations, Selected VTS Areas

Yes Yes PORT OPS/VTS

13 156.650 156.650 Intership Navigation Safety (bridge-

to-bridge)

Yes No BRIDGE COM

14 156.700 156.700

Port Operations, Selected VTS Areas

Yes Yes PORT OPS/VTS

15 1156.750 156.750 Port Operations – 1W Only Yes Yes PORT OPS

16 156.800 156.800 International Distress, Safety, and

Calling

Yes Yes DISTRESS

17 1156.850 156.850 State Controlled – 1W Only Yes Yes SAR

18 156.900 161.500 Port Operations, Duplex No Yes PORT OPS

19 156.950 161.550 Commercial, Duplex No Yes SHIP - SHORE

20 157.000 161.600 Port Operations, Duplex No Yes PORT OPS

21 157.050 161.650 Port Operations, Duplex No Yes PORT OPS

22 157.100 161.700 Port Operations, Duplex No Yes PORT OPS

23 157.150 161.750 Public Correspondence, Duplex No Yes TELEPHONE

24 157.200 161.800 Public Correspondence, Duplex No Yes TELEPHONE

25 157.250 161.850 Public Correspondence, Duplex No Yes TELEPHONE

26 157.300 161.900 Public Correspondence, Duplex No Yes TELEPHONE

27 157.350 161.950 Public Correspondence, Duplex No Yes TELEPHONE

28 157.400 162.000 Public Correspondence, Duplex No Yes TELEPHONE

40 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

CH SEND

(MHz)

RECEIVE (MHz)

TRAFFIC TYPE SHIP

TO SHIP

SHIP TO

NAME TAG

61 156.075 160.675 Port Operations, Duplex No Yes PORT OPS

62 156.125 160.725 Port Operations, Duplex No Yes PORT OPS

63 156.175 160.775 Port Operations, Duplex No Yes PORT OPS

64 156.225 160.825 Public Correspondence, Duplex No Yes TELEPHONE

65 156.275 160.875 Port Operations, Duplex No Yes PORT OPS

66 156.325 160.925 Port Operations, Duplex No Yes PORT OPS

67 156.375 156.375 Commercial, bridge-to-bridge Yes No BRIDGE COM

68 156.425 156.425 Boat Operations, Recreational Yes No SHIP - SHIP

69 156.475 156.475 Port Operations Yes Yes PORT OPS

70 3156.525 156.525 Digital Selective Calling - DSC ------ ------ DSC

71 156.575 156.575 Port Operations Yes Yes PORT OPS

72 156.625 156.625 Intership Yes No SHIP - SHIP

73 156.675 156.675 Port Operations Yes Yes PORT OPS

74 156.725 156.725 Port Operations Yes Yes PORT OPS

77 156.875 156.875 Intership Yes No SHIP - SHIP

78 156.925 161.525 Non-Commercial, Duplex No Yes SHIP - SHORE

79 156.975 161.575 Commercial, Duplex No Yes SHIP - SHORE

80 157.025 161.625 Commercial, Duplex No Yes SHIP - SHORE

81 157.075 161.675 Port Operations, Duplex No Yes PORT OPS

82 157.125 161.725 Port Operations, Duplex No Yes PORT OPS

83 157.175 161.775 Public Correspondence, Duplex No Yes TELEPHONE

84 157.225 161.825 Public Correspondence, Duplex No Yes TELEPHONE

85 157.275 161.875 Public Correspondence, Duplex No Yes TELEPHONE

86 157.325 161.925 Public Correspondence, Duplex No Yes TELEPHONE

87 157.375 161.975 Public Correspondence, Duplex No Yes TELEPHONE

88 157.425 162.025 Public Correspondence, Duplex No Yes TELEPHONE

60 156.025 160.625 Public Correspondence, Duplex No Yes TELEPHONE

41VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

WEATHER MHz TRAFFIC TYPE NAME TAG

Wx01 RX Only 162.550 NOAA WEATHER CHANNEL ------ ------ NOAA WX

Wx02 RX Only 162.400 NOAA WEATHER CHANNEL ------ ------ NOAA WX

Wx03 RX Only 162.475 NOAA WEATHER CHANNEL ------ ------ NOAA WX

Wx04 RX Only 162.425 NOAA WEATHER CHANNEL ------ ------ NOAA WX

Wx05 RX Only 162.450 NOAA WEATHER CHANNEL ------ ------ NOAA WX

Wx06 RX Only 162.500 NOAA WEATHER CHANNEL ------ ------ NOAA WX

Wx07 RX Only 162.525 NOAA WEATHER CHANNEL ------ ------ NOAA WX

Wx08 RX Only 161.650 CANADIAN WEATHER CHANNEL ------ ------ CANADA WX

Wx09 RX Only 161.775 CANADIAN WEATHER CHANNEL ------ ------ CANADA WX

Wx10 RX Only 163.275 NOAA WEATHER CHANNEL ------ ------ NOAA WX

SPECIAL NOTES ON INTERNATIONAL CHANNEL USAGE

1. LOW POWER (1W) only.

2. LOW POWER (1W) initially. Override to HIGH POWER by holding down H/L key before transmitting. Used normally in bridge-to-bridge communications.

3. Channel 70 is designated for use exclusively for Digital Selective Calling (DSC), such as Distress, Safety, and Ship Calls. No voice communication is allowed on CH70.

4. The INTERNATIONAL mode is not legal for use in U.S. or Canada waters.

42 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

C.2 USA Channel Chart

CH SEND

(MHz)

RECEIVE (MHz)

TRAFFIC TYPE SHIP

TO SHIP

SHIP TO SHORE

NAME TAG

01A 156.050 156.050

Port Operations, Selected VTS Areas

Yes Yes PORT OPS/VTS

03A 4156.150 156.150 US Government, Coast Guard Yes Yes UNAUTHORIZED

05A 156.250 156.250

Port Operations, Selected VTS Areas

Yes Yes PORT OPS/VTS

06 156.300 156.300 Inter-ship Safety Yes No SAFETY

07A 156.350 156.350 Commercial Yes Yes COMMERCIAL

08 156.400 156.400 Commercial (inter-ship only) Yes No COMMERCIAL

09 156.450 156.450 Recreational Calling Channel Yes Yes CALLING

10 156.500 156.500 Commercial Yes Yes COMMERCIAL

11 156.550 156.550 Commercial, VTS in Selected

Areas

Yes Yes VTS

12 156.600 156.600

Port Operations, Selected VTS Areas

Yes Yes PORT OPS/VTS

13 3156.650 156.650 Intership Navigation Safety

(bridge-to-bridge), 1W with Power-up

Yes No BRIDGE COM

14 156.700 156.700

Port Operations, Selected VTS Areas

Yes Yes PORT OPS/VTS

15 2RX Only 156.750 Environmental, RX Only ------ ------ ENVIROMENTAL

16 156.800 156.800 International Distress, Safety, and

Calling

Yes Yes DISTRESS

17 1156.850 156.850 State Controlled – 1W Only Yes Yes SAR

18A 156.900 156.900 Commercial Yes Yes COMMERCIAL

19A 156.950 156.950 Commercial Yes Yes COMMERCIAL

20 157.000 161.600 Port Operations, Canadian Coast

Guard, Duplex

No Yes PORT OPS

20A 157.000 157.000 Port Operations Yes Yes PORT OPS

21A 4157.050 157.050 U.S. Government, Canadian

Coast Guard

Yes Yes UNAUTHORIZED

22A 157.100 157.100 Coast Guard Liaison Yes Yes COAST GUARD

23A 4157.150 157.150 U.S. Government, Coast Guard Yes Yes UNAUTHORIZED

24 157.200 161.800 Public Correspondence, Marine

Operator

No Yes TELEPHONE

25 157.250 161.850 Public Correspondence, Marine

Operator

No Yes TELEPHONE

26 157.300 161.900 Public Correspondence, Marine

Operator

No Yes TELEPHONE

27 157.350 161.950 Public Correspondence, Marine

Operator

No Yes TELEPHONE

28 157.400 162.000 Public Correspondence, Marine

Operator

No Yes TELEPHONE

43VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

CH SEND

(MHz)

RECEIVE (MHz)

TRAFFIC TYPE SHIP

TO SHIP

SHIP TONAME TAG

61A 4156.075 156.075 U.S. Government, Canadian

Coast Guard

Yes Yes UNAUTHORIZED

63A 156.175 156.175 Port Operations, VTS in Selected

Areas

Yes Yes PORT OPS/VTS

64A 4156.225 156.225 U.S. Government, Canadian

Commercial Fishing

Yes Yes UNAUTHORIZED

65A 156.275 156.275 Port Operations Yes Yes PORT OPS

66A 156.325 156.325 Port Operations Yes Yes PORT OPS

67 3156.375 156.375 Commercial, bridge-to-bridge, 1W

with Power-up

Yes No BRIDGE COM

68 156.425 156.425 Boat Operations, Recreational Yes No SHIP - SHIP

69 156.475 156.475 Boat Operations, Recreational Yes Yes PLEASURE

70 6156.525 156.525 Digital Selective Calling - DSC ------ ------ DSC

71 156.575 156.575 Boat Operations, Recreational Yes Yes PLEASURE

72 156.625 156.625 Boat Operations, Recreational Yes No SHIP - SHIP

73 156.675 156.675 Port Operations Yes Yes PORT OPS

74 156.725 156.725 Port Operations Yes Yes PORT OPS

77 1156.875 156.875 Port Operations –1W Only Yes Yes PORT OPS

78A 156.925 156.925 Boat Operations, Recreational Yes No SHIP - SHIP

79A 156.975 156.975 Commercial Yes Yes COMMERCIAL

80A 157.025 157.025 Commercial Yes Yes COMMERCIAL

81A 4157.075 157.075 U.S. Government, Environmental

Protection Agency Operations

Yes Yes UNAUTHORIZED

82A 4157.125 157.125 U.S. Government, Canadian

Coast Guard

Yes Yes UNAUTHORIZED

83A 4157.175 157.175 U.S. Government, Canadian

Coast Guard

Yes Yes UNAUTHORIZED

84 157.225 161.825 Public Correspondence, Marine

Operator

No Yes TELEPHONE

85 157.275 161.875 Public Correspondence, Marine

Operator

No Yes TELEPHONE

86 157.325 161.925 Public Correspondence, Marine

Operator

No Yes TELEPHONE

87 157.375 161.975 Public Correspondence, Marine

Operator

No Yes TELEPHONE

88 157.425 162.025 Public Correspondence, Marine

Operator

No Yes TELEPHONE

88A 157.425 157.425 Commercial, Intership Only Yes No COMMERCIAL

44 VHF 7000, 7100US, 7100EU Operation Manual
