NAPCO GEM-PX Installation Instruction

R

333 Bayview Avenue

Amityville, New York 11701

For Sales and Repairs, [phone]

For Technical Service, [phone]

Publicly traded on NASDAQ Symbol: NSSC

Proximity Reader

Installation Instructions

© NAPCO 2004

GENERAL DESCRIPTION

The GEM-PX is a NAPCO proprietary proximity card reader

which combines with the GEM-PXCV cover to provide com­plete system status using indicator LED’s. The GEM-PX
reader can only be used with GEM 36-bit proprietary prox­imity cards. The GEM-PX reader consists of the proximity
reader module, which is fully encapsulated in weather resis­tant potting and the snap on GEM-PXCV cover which
houses additional LED’s. The multicolored LED on the
GEM-PX provides standard visual feedback as to

condition

(door “locked” or “unlocked”), and the additional

access

LED’s in the GEM-PXCV cover provide feedback as to sys­tem condition (system “armed” or “disarmed”). Together,

the GEM-PX and GEM-PXCV is an indoor/outdoor prox­imity card reader providing potted electronics, low power
consumption and durability all in a small, easy to install
package.

SPECIFICATIONS

12V Nominal, 50mA standby current.

LED Indications

The GEM-PX reader contains a multicolored LED which

Access
Status LED
(see table 1)

System
Status LED's
(see table 2)

Stealth Mode

LEDs. When

LED INDICATION ACCESS CONDITION

Steady Red Door Locked

Steady Green Door Unlocked

Momentary Green Card Read--Door Remains Locked

Alternating Green & Red (Downloading PCD-Windows Program to ACM)

LED INDICATION SYSTEM CONDITION

Steady Red System Armed

Red LED is off System Disarmed

Blinking Red System in Alarm

Steady Green System Ready to Arm

Green LED is off System Not Ready to Arm

is used to hide the ACM’s Armed and Status

Stealth Mode

Table 1: Access Status LED (Top)

Table 2: System Status LED's (Bottom)

provides visual feedback
as to access condition
when access cards are
presented to the reader.
Table 1 below displays
the LED indications and
their meanings.

The GEM-PXCV pro­vides two LED's to indi­cate system condition,
as displayed in Table 2
below:

is enabled, the GEM-PXCV

GEM-PX

WI1269B 10/04

system status LEDs are normally off but are turned on for 1
minute by any of the following events:

• Press a request to exit button

•

Press a request to arm button

• Present a valid ARM/DISARM or ARM card to the

reader

When Stealth Mode is disabled ("normal operation"), the

LED's are always enabled and mimic the Keypad Status
LEDs for the following functions only: Armed, Disarmed,
Ready to Arm, Not-Ready to Arm and Alarm.
the system is in alarm, Stealth Mode is disabled. "Access
Only" cards do not affect the status of Stealth Mode.

MOUNTING THE GEM-PX

Table 3: Proximity Card Reader Connections

GEM-ACM1D Termi-

nal Number

17 (+) Reader Power Red (+ DC)

18 (-) Reader Power Black (- Ground) & (Shielded

19 Reader Data 1 White (Data 1)

20 Reader Data 0 Green (Data 0)

21 (-) Red LED Brown (Red LED)

22 (-) Red & Green LED Orange (Green LED)

23 (-) Reader Sounder Yellow (Beeper)

(Not Used) (Not Used) Blue (Hold)

(Not Used) (Not Used) Violet (Card Present)

* Tamper Connection not available on HID 6005B
Be sure to place jumper JP1 in correct configuration for 5 volt of 12 volt reader
operation.

Table 4: GEM-PX Wire Connections

GEM-PX Wir es GEM-ACM1D

Red Reader Power 17 (+) 35 (+)

Orange Active Low Red

Green Status Green LED 31 49

Before mounting the card reader, always plan ahead and deter­mine the route all wires will follow before drilling into wall mount­ing surfaces. For more information regarding various system
designs, refer to WI1121 for complete installation instructions.
Install the GEM-PX as follows:

1.

Determine mounting location.

(Figure 1) and a pencil, lightly mark the location of the two
mounting holes and the two wire feed holes.

2.

Route the Reader Wires.

required to activate the reader are displayed in Table 3.
Determine which wires will be needed and plan how these
wires will be accessed from behind the mounting location.

3.

Install dry wall mounting hardware.

as molly bolts, toggle bolts or other anchoring devices.
Drill the smallest hole needed for the device.
Use caution when drilling holes--there may be high voltage
wiring in wall.

4.

Drill wire feed holes.

GEM-ACM1D Terminal

Description

Terminal

Description

Armed LED

GEM-ACM1D

Terminal Number

The minimum number of wires

Minimum size for the top feed hole

HID Model 6005B (Prox Point

Plus ) Wires

Ground)

GEM-2D Terminal

30 48

Using the template

Use hardware such

Note:

Number

Warning:

When

1

(A) is 1/2", but can be made larger if necessary.
not exceed a diameter that can be concealed by the GEM­PXCV reader cover. The diameter of the bottom feed hole
(B) should not exceed 1/2" and should be made as small
as possible.

Use care to ensure that the bottom

Note:

feed hole (B) does not damage the structural integrity of
the bottom mounting hole anchoring device.

5.

Route the reader wires

from behind the mounting loca-

tion through the top wire feed hole (A).

6.

Insert the 3 LED System Status wires

into the bottom
wire feed hole (B) and then out of the top wire feed hole
(A).

7.

Connect the reader wires

as displayed in Table 3. Con-

nect the GEM-PX wires as displayed in table 4, below.

8.

9.

Do not apply power until all wiring is complete.

Note:
Push all wires back into wall

. Use care not to damage

the wiring or the mounting surface.

10.

Mount the reader base

using two #4 mounting screws

(supplied).

11.

Install cover

. Place the GEM-PXCV proximity reader

cover over the reader base and snap on to secure.

The device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate the equipment.

Note:

Do

PROGRAMMING THE PANEL

In PCD-Windows Quickloader Download software, you must
enable the ACM1D to use the NAPCO proprietary proximity
card format. In the

Keypad Assignment Screen

ACM Assignment tab (see image below). Check

Napco Proprietary Access Format

to enable. Click

save.

, click the

Enable

to

OK
