SPARE PARTS LIST FOR MD120 with 31i Control
MMUSA PART NO. PARTS LIST NO. DESCRIPTION PART LOCATION QTY. RANK
Z074947900 MC81315017 SWITCH (PROX.) DOOR & COVER 2
MC81341160 MC81315046 WIPER DOOR & COVER 2
MC81344160 MC81315049 BRUSH DOOR & COVER 2
Z066260910 MC81315061 LAMP (FL) DOOR & COVER 2
Z066913130 MC86330005 CONTROL VALVE -P COOLANT LEVEL SW 1 ○
Z071948750 MC88122003 RING (X) LOADER CHUCK (AB_LINK) 2
ZK92144100 MC88122004 RING (O) LOADER CHUCK (AB_LINK) 2
Z065961320 MC88122006 JOINT (NPL) LOADER CHUCK (AB_LINK) 4 ○
Z073268700 MC88122008 PCKNG LOADER CHUCK (AB_LINK) 2
Z066576460 MC88122009 WASHER LOADER CHUCK (AB_LINK) 2
Z070441720 MC88122014 HOSE (AIR) LOADER CHUCK (AB_LINK) 2 ○
Z071948750 MC88123003 RING (X) LOADER CHUCK (EF_LINK) 1
Z060181800 MC88123004 RING (O) LOADER CHUCK (EF_LINK) 1
Z065961320 MC88123006 JOINT (NPL) LOADER CHUCK (EF_LINK) 2 ○
Z066574840 MC88123008 PCKNG LOADER CHUCK (EF_LINK) 1
Z066576460 MC88123009 WASHER LOADER CHUCK (EF_LINK) 1
Z065961240 MC88123017 JOINT (NPL) LOADER CHUCK (EF_LINK) 2 ○
Z070441720 MC88123018 HOSE (AIR) LOADER CHUCK (EF_LINK) 1 ○
Z067045550 MC88138010 SPRNG (COIL) CHUCK GUIDE (3-JAW_LINK) 3 ○
Z055001000 MC88138011 GREASE-NIPPLE CHUCK GUIDE (3-JAW_LINK) 1 ○
Z055001000 MC88144010 GREASE-NIPPLE CHUCK GUIDE (3-JAW EF LINK) 1 ○
Z074733000 MC99001001 SWITCH (PROX.) SUPPLEMENT (MWA) 1
88719523 MC99001007 PPG-TEE SUPPLEMENT (MWA) 2 ○
Z070892730 MC99001011 CONTROL VALVE -P SUPPLEMENT (MWA) 6 ○
Z067984100 MC99003001 BOND OIL PROOF SILICON SEAL 1
Z076121700 MM81103024 CABLE-CHAIN STAND & FRAME(HG) 2 ○
Z060458960 MM81131004 BOLT SUB LOADER STAND 16
Z064710460 MM81131024 DMPR SUB LOADER STAND 2 ○
MM81340060 MM81303026 WIPER (SIDE L) COOLANT SHIELD 10
MM81340160 MM81303027 WIPER (SIDE R) COOLANT SHIELD 10
MM81341061 MM81303028 WIPER (SIDE LOW L) COOLANT SHIELD 4
MM81341161 MM81303029 WIPER (SIDE LOW R) COOLANT SHIELD 4
MM81341261 MM81303030 WIPER (SIDE LOW L) COOLANT SHIELD 6
MM81341361 MM81303031 WIPER (SIDE LOW R) COOLANT SHIELD 6
MS31311060 MM81303034 WIPER COOLANT SHIELD 8
MM81360061 MM81303035 WIPER(L) COOLANT SHIELD 2
MM81360161 MM81303036 WIPER(R) COOLANT SHIELD 2
MM81361061 MM81303037 WIPER(L) COOLANT SHIELD 2
Z90-68086-01 MM81303058 SLD-CVR-TLSC COOLANT SHIELD 2 ○
Z066271780 MM81303063 JOINT(ELBOW) COOLANT SHIELD 2 ○
ZK66550700 MM81303064 JOINT(ELBOW) COOLANT SHIELD 2 ○
Z066260580 MM81322005 SW(LMT) REAR & SIDE COVER (HG) 1
Z061618880 MM82000002 BEARING-RTNR HEADSTOCK & SPINDLE 2 ○
Z060394540 MM82000008 RING(O) HEADSTOCK & SPINDLE 2
ZK59001500 MM82000011 RING(O) HEADSTOCK & SPINDLE 2
Z905355000 MM83010009 BEARING(LN) CROSS SLIDE (L) 1 ○
Z905355100 MM83010011 BEARING(LN) CROSS SLIDE (L) 1 ○
Z076129000 MM83010024 JOINT(NPL) CROSS SLIDE (L) 1 ○
MM83014062 MM83020012 BEARING(LN) CROSS SLIDE (R) 1 ○
Z905384701 MM83310002 PCKNG TURRET (10ST) 1
ZK59003800 MM83310003 RING(O) TURRET (10ST) 1
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
1 OF 5 June 2013
SPARE PARTS LIST FOR MD120 with 31i Control
MMUSA PART NO. PARTS LIST NO. DESCRIPTION PART LOCATION QTY. RANK
88609105 MM83310007 WASHER TURRET (10ST) 8
Z025070000 MM83310008 RING(O) TURRET (10ST) 1
ZK59000300 MM83310010 RING(O) TURRET (10ST) 10
Z065869350 MM83310013 RING(O) TURRET (10ST) 2
Z0695224A0 MM83310014 SPRNG(COIL) TURRET (10ST) 1 ○
Z071267130 MM83310016 RING(O) TURRET (10ST) 2
ZK59001100 MM83410003 RING(O) TURRET (10ST) 1
MB01210060 MM83410005 DU BUSH TURRET (10ST) 1 ○
Z075768900 MM83410009 PCKNG TURRET (10ST) 1
Z075769100 MM83410010 RING(BK-UP) TURRET (10ST) 1
Z076107500 MM83410011 RING(X) TURRET (10ST) 1
Z076119900 MM83410012 RING(BK-UP) TURRET (10ST) 2
Z076107300 MM83410013 PCKNG TURRET (10ST) 1
Z076107400 MM83410014 RING(BK-UP) TURRET (10ST) 1
Z060115840 MM83410016 RING(O) TURRET (10ST) 1
ZK59107000 MM83410017 RING(O) TURRET (10ST) 1
ZK59001200 MM83410018 RING(O) TURRET (10ST) 1
Z076109300 MM83410019 BEARING(RB) TURRET (10ST) 1 ○
Z076121600 MM83410022 RING(O) TURRET (10ST) 1
Z0677578A0 MM83410025 BEARING(RB) TURRET (10ST) 1 ○
Z211011800 MM83410028 BEARING(RB) TURRET (10ST) 1 ○
Z0601665A0 MM83410030 BEARING NUT TURRET (10ST) 1 ○
Z31-10108-00 MM83410034 BEARING(RB) TURRET (10ST) 2 ○
Z079617200 MM83410037 O-RING TURRET (10ST) 2
Z076106900 MM83410042 PACKING TURRET (10ST) 1
Z076112700 MM83410044 SPRNG(COIL) TURRET (10ST) 1 ○
MB01010060 MM83410046 DU BUSH TURRET (10ST) 1 ○
Z074947600 MM83410051 SWITCH (PROX.) TURRET (10ST) 2
Z905425100 MM83410055 SCRPR TURRET (10ST) 1
Z905425200 MM83410056 SCRPR TURRET (10ST) 1
Z063008020 MM83410057 JOINT(ELBOW) TURRET (10ST) 2 ○
Z068635130 MM83510002 OIL-CAP LIVE TOOL 2
Z068635210 MM83510003 GAUGE(LVL) LIVE TOOL 2 ○
Z068621180 MM83510005 BEARING (ANG) LIVE TOOL 4 ○
Z111010100 MM83510006 BEARING (RB) LIVE TOOL 2 ○
Z068799080 MM83510007 RING(O) LIVE TOOL 2
ZV20073200 MM83510008 BEARING NUT LIVE TOOL 4 ○
ZV20073400 MM83510009 BEARING NUT LIVE TOOL 2 ○
Z070461160 MM83510010 OIL SEAL LIVE TOOL 4
Z902729650 MM83510012 GEAR LIVE TOOL 2 ○
Z325005800 MM83510016 RING(O) LIVE TOOL 6
Z111012800 MM83510021 BEARING (RB) LIVE TOOL 2 ○
Z068634670 MM83510022 BEARING-P LIVE TOOL 2 ○
Z068634910 MM83510023 BEARING(ND) LIVE TOOL 2 ○
Z068634320 MM83510024 OIL SEAL LIVE TOOL 2
Z068786340 MM83510036 NUT LOCK-NUT LIVE TOOL 2
Z311011300 MM85100022 BEARING X-AXIS DRIVE 3 ○
Z903485850 MM85100024 AIR-MANIFOLD X-AXIS DRIVE 1 ○
Z066139080 MM85200016 BEARING Z-AXIS DRIVE 2 ○
Z905391300 MM85310023 LINEAR GUIDE Y-AXIS DRIVE 1 ○
Z060786380 MM85310024 BEARING Y-AXIS DRIVE 2 ○
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
2 OF 5 June 2013
SPARE PARTS LIST FOR MD120 with 31i Control
MMUSA PART NO. PARTS LIST NO. DESCRIPTION PART LOCATION QTY. RANK
Z076122300 MM85310025 BEARING Y-AXIS DRIVE 1 ○
Z061175100 MM85310026 BEARING Y-AXIS DRIVE 2 ○
Z060608950 MM85410011 BEARING α-AXIS DRIVE 1 ○
ZK81007400 MM85410012 DU-BUSH α-AXIS DRIVE 1 ○
MM95118160 MM85514008 RACK RAIL 1 ○
MM95118160 MM85514009 RACK RAIL 1 ○
MM95118060 MM85514010 RACK RAIL 1 ○
MM95118060 MM85514011 RACK RAIL 1 ○
Z067396510 MM85610013 BEARING GANTRY HEAD 1 ○
Z111003300 MM85610014 BEARING GANTRY HEAD 2 ○
Z063394660 MM85610015 PROXIMITY SW. GANTRY HEAD 2
ZK92264400 MM86010002 MNFLD (LUB) LUBRICATION SYSTEM 2 ○
Z070603480 MM86010003 MNFLD (LUB) LUBRICATION SYSTEM 2 ○
Z076117400 MM86010004 MNFLD (LUB) LUBRICATION SYSTEM 2 ○
Z062246770 MM86010005 MNFLD (LUB) LUBRICATION SYSTEM 2 ○
ZK69015200 MM86010006 PPG-TEE LUBRICATION SYSTEM 1 ○
Z060721330 MM86010007 JOINT(INLET) LUBRICATION SYSTEM 56 ○
ZK69022400 MM86010008 JOINT(SLV) LUBRICATION SYSTEM 56 ○
ZK69022600 MM86010009 JOINT(NUT) LUBRICATION SYSTEM 56 ○
ZK69022100 MM86010010 JOINT(INLET) LUBRICATION SYSTEM 14 ○
ZK69022300 MM86010011 JOINT(SLV) LUBRICATION SYSTEM 14 ○
ZK69022500 MM86010012 JOINT(NUT) LUBRICATION SYSTEM 14 ○
ZK69023100 MM86010013 JOINT(ELBOW) LUBRICATION SYSTEM 11 ○
Z060715610 MM86010014 PPG-ELB(S) LUBRICATION SYSTEM 4 ○
Z060715870 MM86010015 PPG-ELB(S) LUBRICATION SYSTEM 6 ○
Z056200300 MM86010016 PPG-SCKT LUBRICATION SYSTEM 18
ZK69017100 MM86010017 PPG-NPPL(CL) LUBRICATION SYSTEM 1 ○
Z056201500 MM86010018 PPG-PLUG LUBRICATION SYSTEM 2 ○
Z056202500 MM86010019 GSKT LUBRICATION SYSTEM 2 ○
ZK74001500 MM86010020 HOSE(AIR) LUBRICATION SYSTEM 14 ○
ZK74001600 MM86010021 HOSE(AIR) LUBRICATION SYSTEM 14 ○
Z066014200 MM86010022 SDL LUBRICATION SYSTEM 8 ○
Z066014380 MM86010023 SDL LUBRICATION SYSTEM 8 ○
Z066520240 MM86010024 GREASE LUBRICATION SYSTEM 2 ○
Z067839780 MM86300050 HOSE-ASSY COOLANT SYSTEM 2 ○
Z067840100 MM86300051 HOSE-ASSY COOLANT SYSTEM 1 ○
Z071462340 MM86300052 HOSE-ASSY COOLANT SYSTEM 1 ○
Z070256400 MM86300055 HOSE-ASSY COOLANT SYSTEM 2 ○
Z068496770 MM86300102 JOINT(SWVL) COOLANT SYSTEM 2 ○
88712110M MM86300105 PPG-NPL COOLANT SYSTEM 2 ○
ZK66501100 MM86300108 JOINT(NPL) COOLANT SYSTEM 2 ○
ZK66500600 MM86300109 JOINT(NPL) COOLANT SYSTEM 2 ○
ZK74020800 MM86300112 HOSE-ADPTR COOLANT SYSTEM 4 ○
ZK74020700 MM86300113 HOSE-ADPTR COOLANT SYSTEM 8 ○
ZK74020400 MM86300114 HOSE-ADPTR COOLANT SYSTEM 6 ○
ZK74020300 MM86300115 HOSE-ADPTR COOLANT SYSTEM 2 ○
Z062163050 MM86300117 HOSE-ADPTR COOLANT SYSTEM 2 ○
Z078317100 MM86300119 HOSE-ASSY COOLANT SYSTEM 2 ○
Z067839860 MM86300120 HOSE-ASSY COOLANT SYSTEM 1 ○
Z067839940 MM86300121 HOSE-ASSY COOLANT SYSTEM 1 ○
Z056178700 MM86342010 HOSE-BAND OILMIST DUCT 2 ○
◎
◎
3 OF 5 June 2013
SPARE PARTS LIST FOR MD120 with 31i Control
MMUSA PART NO. PARTS LIST NO. DESCRIPTION PART LOCATION QTY. RANK
Z905017000 MM86402001 AIR-3P-SET AIR SYSTEM 1 ○
Z074719600 MM86402002 AIR-FLTR-REG AIR SYSTEM 1 ○
Z902478350 MM86402003 MNFLD-A-ASSY AIR SYSTEM 1 ○
Z903648850 MM86402004 MNFLD-A-ASSY AIR SYSTEM 1 ○
Z066397960 MM86402005 JOINT(ELBOW) AIR SYSTEM 4 ○
Z080753600 MM86402006 CONTROL VALVE (A-INT) AIR SYSTEM 1 ○
Z074383900 MM86402007 AIR-REG AIR SYSTEM 2 ○
Z067339201 MM86402010 JOINT(ELBOW) AIR SYSTEM 2 ○
Z071974160 MM86402011 JOINT(ELBOW) AIR SYSTEM 1 ○
Z0671666A1 MM86402012 JOINT(ELBOW) AIR SYSTEM 1 ○
Z076128900 MM86402014 JOINT(NPL) AIR SYSTEM 1 ○
Z061146180 MM86402015 JOINT(PBY) AIR SYSTEM 1 ○
Z071057410 MM86520001 HOSE-ASSY HYD PIPING 2 ○
Z08-20976-00 MM86520003 HOSE-ASSY HYD PIPING 2 ○
Z071057240 MM86520004 HOSE-ASSY HYD PIPING 2 ○
Z068984310 MM86520005 HOSE-ASSY HYD PIPING 2 ○
Z08-19990-00 MM86520006 HOSE-ASSY HYD PIPING 2 ○
Z08-20031-00 MM86520007 HOSE-ASSY HYD PIPING 1 ○
Z08-20031-00 MM86520008 HOSE-ASSY HYD PIPING 2 ○
Z070256400 MM86520009 HOSE-ASSY HYD PIPING 4 ○
Z08-19999-00 MM86520010 HOSE-ASSY HYD PIPING 2 ○
Z08-19976-00 MM86520011 HOSE-ASSY HYD PIPING 1 ○
Z068983920 MM86520012 HOSE-ASSY HYD PIPING 1 ○
Z08-20078-00 MM86520013 HOSE-ASSY HYD PIPING 1 ○
Z077392200 MM86520014 HOSE-ASSY HYD PIPING 1 ○
ZK74020300 MM86520101 HOSE-ADPTR HYD PIPING 8 ○
ZK74020400 MM86520102 HOSE-ADPTR HYD PIPING 2 ○
ZK74020700 MM86520103 HOSE-ADPTR HYD PIPING 6 ○
ZK74020800 MM86520104 HOSE-ADPTR HYD PIPING 3 ○
ZK92011300 MM86520105 HOSE-ADPTR HYD PIPING 2 ○
ZK92011400 MM86520106 HOSE-ADPTR HYD PIPING 4 ○
ZK92038200 MM86520107 HOSE-ADPTR HYD PIPING 3 ○
Z062163050 MM86520108 HOSE-ADPTR HYD PIPING 2 ○
ZR50114400 MM86520109 PPG-BUSH HYD PIPING 2 ○
88719523 MM86520110 PPG-TEE HYD PIPING 2 ○
Z061179940 MM86520111 PPG-TEE HYD PIPING 3 ○
88719532 MM86520112 PPG-ELB(SV) HYD PIPING 6 ○
88719582 MM86520113 PPG-NPL HYD PIPING 2 ○
ZR50048200 MM86520114 PPG-NPL HYD PIPING 3 ○
ZK66550700 MM86520115 JOINT(ELBOW) HYD PIPING 4 ○
ZK66500600 MM86520116 JOINT(NPL) HYD PIPING 4 ○
Z060471210 MM86520117 PPG-PLUG HYD PIPING 2 ○
ZK92038300 MM86520118 PPG-SCKT HYD PIPING 3 ○
Z066240210 MM88322002 CSTR COOLANT TANK 4 ○
ZK75660300 MM88322004 GAUGE COOLANT TANK 1 ○
Z0615419A0 MM88322008 RUBBER(FT) COOLANT TANK 2 ○
ZK74020600 MM96010002 HOSE-ADPTR LUB-SYS(G) 1 ○
Z066137380 MS33200008 OIL SEAL Z-AXIS DRIVE 1
Z066137460 MS33200009 NUT LOCKNUT Z-AXIS DRIVE 1
Z073684400 MS52102004 BLT(V) M/T PULLEY & BELT 1
Z903169750 MS52700004 BRAKE C-AXIS 1
◎
◎
◎
◎
4 OF 5 June 2013
SPARE PARTS LIST FOR MD120 with 31i Control
△
△
MMUSA PART NO. PARTS LIST NO. DESCRIPTION PART LOCATION QTY. RANK
Z063000800 MS52700008 JOINT(NPL) C-AXIS 1 ○
ZK92011300 MS52700009 HOSE-ADPTR C-AXIS 1 ○
Z066137380 MS53100005 OIL SEAL X-AXIS DRIVE 2
Z066137460 MS53100007 NUT LOCKNUT X-AXIS DRIVE 1
Z066944440 MS53100011 NUT LOCKNUT X-AXIS DRIVE 1
Z905630500 CTRL-PNL OPE. BOX 1 ○
Z905342800 PCB-ASSY CONTROL BOX 3 ○
Z905342900 PCB-ASSY CONTROL BOX 4 ○
Z905456801 PCB-ASSY CONTROL BOX 2 ○
Z905563900 PCB-ASSY CONTROL BOX 2 ○
Z076810500 POWER-SPPLY CONTROL BOX 1 ○
Z076810700 POWER-SPPLY CONTROL BOX 1 ○
AS10031050B CABLE ASS'Y LOADER CABLE 1 ○
AS10032050B CABLE ASS'Y LOADER CABLE 1 ○
AS10033050B CABLE ASS'Y LOADER CABLE 1 ○
AS10034050B CABLE ASS'Y LOADER CABLE 1 ○
AS10035050B CABLE ASS'Y LOADER CABLE 1 ○
AS10036050B CABLE ASS'Y LOADER CABLE 1 ○
AS10271050B CABLE ASS'Y LOADER CABLE 1 ○
AS10272050B CABLE ASS'Y LOADER CABLE 1 ○
AS10273053 CABLE ASS'Y LOADER CABLE 1 ○
AS10274051 CABLE ASS'Y LOADER CABLE 1 ○
AS10278150 CABLE ASS'Y LOADER CABLE 1 ○
T038701150 MS5H059710 CYLINDER CHUCK & CYLINDER 1
Z063378970 MS5H059710 PROXIMATE SW CHUCK & CYLINDER 2 ○
Z0692324A0 TSLDAJ4210 SW(LMT)-P SAFETY FENCE (OUT) 1 ○
Z075990700 TSLDAJ4210 SW(LMT) SAFETY FENCE (OUT) 1 ○
Z070287460 TSLF059710 SW(LMT)-P QUALITY CHECKSTA.COV 1 ○
Z075990700 TSLF059710 SW(LMT) QUALITY CHECKSTA.COV 1 ○
Z070908670 TSSK001010 SW(PH)-P QC STATION BASE 1 ○
Z07-68196-00 TSSK001010 SW(PH) QC STATION BASE 1
Z070287460 TSSK003010 SW(LMT)-P QC STATION COVER 1 ○
Z075990700 TSSK003010 SW(LMT) QC STATION COVER 1 ○
Z065757041 TSST102010 CTRL(SPD) SHUTTLE(L640) 2 ○
Z066124300 TSST102010 BEARING(LN) SHUTTLE(L641) 2 ○
Z074425700 TSST102010 AIR-CYL SHUTTLE(L642) 1 ○
Z075424500 TSST102010 CBL-CHAIN SHUTTLE(L643) 1 ○
Z063560420 TSST405010 VALVE(BL) SHUTTLE(AIR EXT) 2 ○
Z065734420 TSSZ201C10 SLNCR PNEUMATIC DIAGRAM 1 ○
Z905713700 TSSZ201C10 MNFLD(AIR) PNEUMATIC DIAGRAM 1 ○
◎
◎
◎
◎
◎
=Highly Recommend Customer to Stock
○=Suggest Customer to Stock
=If Possible, Customer Should Stock
5 OF 5 June 2013
Loading...
