MSI CR600-013 User Manual

CHAPTER 1

Preface

1-2

Preface

Table of Content

Preface

Table of Content............................................................................................................................ 1-2

Regulations Information............................................................................................................... 1-5

FCC-B Radio Frequency Interference Statement .................................................................... 1-5

FCC Conditions ........................................................................................................................ 1-6

Safety Instructions........................................................................................................................ 1-7

Safety Guideline for Using Lithium Battery ............................................................................... 1-9

WEEE Statement......................................................................................................................... 1-13

Optical Drive Device Notice....................................................................................................... 1-20

Trademarks.................................................................................................................................. 1-20

Release History........................................................................................................................... 1-20

Introductions

Manual Map ................................................................................................................................... 2-2

Unpacking...................................................................................................................................... 2-3

Specification.................................................................................................................................. 2-4

Product Overview ......................................................................................................................... 2-9

Top-Open View......................................................................................................................... 2-9

Front Side View ...................................................................................................................... 2-14

Right Side View ...................................................................................................................... 2-15

1-3

Preface

Left Side View......................................................................................................................... 2-16

Rear Side View....................................................................................................................... 2-18

Bottom Side View ................................................................................................................... 2-20

Getting Started

Power Management...................................................................................................................... 3-2

ECO Engine -- Power Saving Function.................................................................................... 3-2

AC Adapter ............................................................................................................................... 3-4

Battery Pack ............................................................................................................................. 3-6

Using the Battery Pack........................................................................................................... 3-10

Basic Operations ........................................................................................................................ 3-12

Safety and Comfort Tips......................................................................................................... 3-12

Having a Good Work Habit..................................................................................................... 3-13

Knowing the Keyboard ........................................................................................................... 3-14

Knowing the Touchpad........................................................................................................... 3-18

About Hard Disk Drive............................................................................................................ 3-21

Using the Optical Drive Device............................................................................................... 3-22

Connecting the External Devices.............................................................................................. 3-25

Connecting the Peripheral Devices ........................................................................................ 3-25

Connecting the Communication Devices................................................................................ 3-28

ExpressCard Installation............................................................................................................ 3-29

Removing the ExpressCard.................................................................................................... 3-29

Installing the ExpressCard......................................................................................................3-29

1-4

Preface

Safely Remove Hardware........................................................................................................... 3-31

BIOS Setup

About BIOS Setup......................................................................................................................... 4-2

When to Use BIOS Setup......................................................................................................... 4-2

How to Run BIOS Setup...........................................................................................................4-2

Control Keys............................................................................................................................. 4-3

BIOS Setup Menu.......................................................................................................................... 4-4

Main menu................................................................................................................................ 4-5

Advanced menu........................................................................................................................ 4-7

Security menu........................................................................................................................... 4-9

Boot menu ...............................................................................................................................4-11

Exit menu................................................................................................................................ 4-12

1-5

Preface

Regulations Information

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and

radiates radio frequency energy, and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.

 Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

 Consult the dealer or an experienced radio TV technician for help.

NOTE

 The changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

1-6

Preface

 Shield interface cables and AC power cord, if any, must be used in order to comply with the

emission limits.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

 This device may not cause harmful interference.

 This device must accept any interference received, including interference that may cause

undesired operation.

1-7

Preface

Safety Instructions

Read the safety instructions

carefully and thoroughly.

All cautions and warnings on the

equipment or user’s manual

should be noted.

Keep this equipment away from

humidity and high temperature.

The openings on the enclosure

are used for air convection and

to prevent the equipment from

overheating. Do not cover the

openings.

Never pour liquid into the

opening that could damage the

equipment or cause an electrical

shock.

Keep the User’s Guide that

comes with the package for

future reference.

Lay this equipment on a stable

surface before setting it up.

Make sure the power voltage is

within safety range and has

been adjusted properly to the

value of 100~240V before

connecting the equipment to the

power outlet.

Do not leave the equipment in an

unconditioned environment with

a storage temperature above

O

60

C (140OF) or below 0OC

O

(32

F), which may damage the

equipment.

1-8

Preface

Place the power cord in a way

Always unplug the power cord

that people are unlikely to step

before inserting any add-on card

on it. Do not place anything on

or module.

top of the power cord.

To prevent explosion caused by

improper battery replacement,

use the same or equivalent type

of battery recommended by the

manufacturer only.

When installing the coaxial cable

to the TV Tuner, it is necessary

to ensure that the metal shield is

reliable connected to protective

earthing system of the building.

Always keep the strong

Always keep the battery in a

magnetic or electrical objects

safe place.

away from the equipment.

If any of the following situations arises, get the equipment checked by a service

personnel:

 The power cord or plug is damaged.

 Liquid has penetrated into the equipment.

 The equipment has been exposed to moisture.

 The equipment has not worked well or you can not get it work according to

User’s Manual.

 The equipment was dropped and damaged.

 The equipment has obvious signs of breakage.

1-9

Preface

Safety Guideline for Using Lithium Battery

(English) CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type

recommended by the equipment manufacturer. Discard used batteries according to manufacturer’s instructions.

(French) (Français) ATTENTION: II y a danger d’ex;losion s’il y a remplacement incorrect de la batterie. Remplacer

uniquement avec une batterie du meme type ou d’un type équivalent recommandé par le constructeur. Mettre au rebut

les batteries usages conformément aux instructions du fabricant.

(German) (Deutsch) VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch

denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ. Entsorgung gebrauchter Batterien nach

Angaben des Herstellers.

(Spanish) (Español) PRECAUCIÓN: Peligro de explosión si la batería es reemplazada incorrectamente. Cámbiela solo

por la misma o un tipo equivalente recomendado por el fabricante. Descarte usar baterías usadas de acuerdo con las

instrucciones del fabricante.

(Italian) (Italiano) ATTENZIONE: Pericolo di esplosione della batteria se sostituita in modo non corretto. Sostituire solo

con la stesso tipo o con uno equivalente come indicato nel manuale del produttore. Smaltire le batterie usate come da

istruzioni del produttore.

(Russian) (Русский) Внимание: Существует опасность взрыва батареи в случае неправильной замены. Для

замены всегда используйте такую же или эквивалентную, рекомендованную производителем оборудования.

Следуйте инструкциям производителя при утилизации использованных батарей.

(Turkish) (Türkçe) UYARI: Pil yanlıs yerleştirilirse patlayabilir. Aynı ya da muadili bir pille degistiriniz. Kullanılmış pilleri

1-10

Preface

üreticinin talimatlarına göre degerlendiriniz.

(Greek) (Ελληνικά) ΠΡΟΣΟΧΗ: Κίνδυνος έκρηξης εάν η μπαταρία τοποθετηθεί λανθασμένα. Να αντικαθιστάτε μόνο με

τον ίδιο ή αντίστοιχο τύπο με αυτό που συνιστά ο κατασκευαστής του εξοπλισμού. Να απορρίπτετε τις χρησιμοποιημένες

μπαταρίες ως απορρίμματα σύμφωνα με τις οδηγίες του κατασκευαστή.

(Polish) (Polski) OSTRZEŻENIE: Nieprawidłowa wymiana może spowodować eksplozję baterii. Zamianę można wykonać

wyłącznie na baterię tego samego lub równoważnego typu zalecaną przez producenta urządzenia. Zużyte baterie można

wyrzucać zgodnie z instrukcjami producenta.

(Hungarian) (Magyar) VIGYÁZAT: A nem megfelelő akkumul tor haszn lata robban svesz lyes. Kizárólag ugyanolyan,

vagy a berendezés gyártója által ajánlott, egyenértékű típust használjon. Az elhasznált akkumulátorokat a gyártó

utasításának megfelelően ártalmatlanítsák.

(Czech) (Čeština) UPOZORNĚNÍ: Nebezpečí výbuchu při chybné výměně baterie. Nahraďte pouze stejným nebo

ekvivalentním typem doporučeným výrobcem zařízení. Použité baterie zlikvidujte podle pokynů výrobce

(Traditional Chinese ) (繁體中文) 注意: 若電池若未正確更換，可能會爆炸。請用原廠建議之同款或同等級的電池來更換。

請依原廠指示處理廢棄電池。

(Simplified Chinese ) (简体中文) 注意: 若电池若未正确更换，可能会爆炸。请用原厂建议之同款或同等级的电池来更换。

请依原厂指示处理废弃电池。

(Japanese) (日本語) 警告：バッテリーの取り扱いを誤ると、液漏れや破裂などにより生命や財産に重大な影響を及ぼす

恐れがあります。指定された型番以外のバッテリーは使用しないでください。バッテリーを廃棄する場合は、各自治体

の規則に従って適切に処理して下さい。

(Korean) (한국어) 주의: 배터리를 올바로 교체하지 않으면 폭발할 위험이 있습니다. 타입이 장치 제조업체에서

1-11

Preface

권장하는 것과 동일하거나 동등한 배터리로만 교체하십시오. 사용한 배터리는 제조업체의 지침에 따라

폐기하십시오.

(Vietnam) (Tieng Viet) LƯU Ý: Thay thế pin không tương thích có thể dẫn đến nguy cơ bị nổ. Chỉ thay thế bằng pin cùng

loại hoặc loại tương ứng khuyên dùng bởi nhà sản xuất thiết bị. Vứt bỏ pin đã sử dụng theo hướng dẫn của nhà sản xuất.

(Thai) (ไทย ) ขอควรระวัง: ถาใสแบตเตอรี่อยางไมถูกตอง อาจมีอันตรายจากการระเบิดขึ้นได ใชเฉพาะแบตเตอรี่ชนิดเดียวกัน

หรือเทียบเทา ที่แนะนําโดยผูผลิตอุปกรณเทานั้น ทิ้งแบตเตอรี่ที่ใชแลวตามคําแนะนําของผูผลิต

(Indonesia) (Bahasa Indonesia) PERHATIAN: Bahaya ledakan dapat terjadi jika salah memasang baterai. Ganti baterai

hanya dengan jenis yang sama atau setara sesuai rekomendasi pabrik peralatan tersebut. Buang baterai bekas sesuai

petunjuk pabrik

(Serbian) (Srpski) OPREZ: Ukoliko baterija nije ispravno postavljena, postoji opasnost od eksplozije. Zamenu izvršite

koristeći isključivo istu ili ekvivalentnu bateriju koju preporučuje proizvođač opreme. Odbacite iskorišćene baterije u

skladu sa uputstvima proizvođača.

(Netherlands) (Nederlands) LET OP: Er is explosiegevaar als de batterij niet goed geplaatst wordt. Uitsluitend te

vervangen door een batterij van hetzelfde of een gelijkwaardig type,zoals aanbevolen door de fabrikant. Gooi batterijen

weg volgens de plaatselijke instructies.

(Romanian) (Română) ATEN ŢIE: Pericol de explozie dacă bateria este înlocuită incorect. Înlocuiţi doar cu acelaşi tip sau

echivalent recomandat de fabricantul echipamentului. Evacuaţi bateriile folosite conform instrucţiunilor fabricantului.

(Portuguese) (Português) ADVERTÊNCIA: Perigo de explosão se a bateria é substituída incorrectamente. Substitua

somente com o mesmo tipo ou equivalente recomendado por o fabricante do seu equipamento. Descarte as baterias

utilizadas de acordo com as instruções do fabricante.

1-12

Preface

(Swedish) (Svenska) VARNING: Explosionsfara vid felaktigt batteribyte. Använd samma batterityp eller en ekvivalent

typ som rekommenderas av apparattillverkaren. Kassera använt batteri enligt fabrikantens instruction.

(Finnish) (Suomi) VAROITUS: Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan

valmistajan suosittelemaan tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden mukaisesti.

(Slovak) (Slovenčina) UPOZORNENIE: V prípade nesprávnej výmeny batérie existuje nebezpečenstvo výbuchu.

Vymeňte iba za rovnakú batériu alebo za rovnocenný typ batérie, ktorý odporúča výrobca zariadenia. Batérie zneškodnite

podľa pokynov výrobcu.

(Slovenian) (Slovenščina) POZOR: V primeru nepravilne zamenjave baterije obstaja nevarnost njene eksplozije.

Baterijo zamenjajte le z enako ali ekvivalentno vrsto, ki jo priporoča proizvajalec. Odpadne baterije odstranite skladno z

navodili proizvajalca.

(Danish) (Dansk) ADVARSEL! Lithiumbatteri --- Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med

batteri af same fabrikat og type. Levé det brugte batteri tilbage til leverandøren.

(Norwegian) (Norsk) ADVARSEL: Eksplosjonsfare ved feilaktig skifte av batteri. Benytt same batteritype eller en

tilsvarende type anbefalt av apparatfabrikanten. Brukte batterier kasseres I henhold til fabrikantens instruksjoner.

(Bulgarian) (български) ВНИМАНИЕ: Опасност от експлозия ако батерията бъде неправилно поставена. Поставете

батерия от същия вид или еквивалентна батерия, която се препоръчва от производителя. Изхвърлете

използваните батерии като спазвате указанията на производителя.

(Croatian) (Hrvatski) OPREZ: Opasnost od eksplozije ako se baterija zamijeni neprikladnom. Zamijenite je samo

jednakom ili nadomjesnom vrstom prema preporuci proizvođača. Istrošene baterije zbrinite u skladu s uputama

proizvođača.

1-13

Preface

(Estonia) (Eesti) ETTEVAATUST! Plahvatusoht, kui aku on valesti paigaldatud. Asendage ainult sama või tootja poolt

soovitatud võrdväärse akuga. Hävitage kasutatud aku vastavalt tootja juhistele.

(ﻲﺳرﺎﻓ) (Persian)

ارﺎﻄﺧ :ﺎﺑ رﺎﺠﻔﻧا لﺎﻤﺘﺣا ،ﯼﺮﺗﺎﺑ ﺢﻴﺤﺻ ﯼراﺬﮔ ﺎﺟ و ﺐﺼﻧ مﺪﻋ ترﻮﺻ رددراد دﻮﺟو ﯼﺮﺗ . ﻩﺪﻨﻨﮐ ﺪﻴﻟﻮﺗ ﺖﮐﺮﺷ ﯼدﺎﻬﻨﺸﻴﭘ ﯼﺎﻬﻳﺮﺗﺎﺑ زا ﺎﻬﻨﺗ ،ﯼﺮﺗﺎﺑ ﺾﻳﻮﻌﺗ ترﻮﺻ رد

ﺪﻴﻳﺎﻤﻧ ﻩدﺎﻔﺘﺳا .ﺪﻴﻳﺎﻤﻧ ﻞﻤﻋ ﻩﺪﻨﻨﮐ ﺪﻴﻟﻮﺗ ﺖﮐﺮﺷ ﯽﻳﺎﻤﻨهار ﻖﺒﻃ ﺮﺑ و ﺪﻴﻨﮐ ﯼراددﻮﺧ ﯼﺮﺗﺎﺑ ﻦﺘﺧاﺪﻧا رود زا.

)Arabic ()ﺔﻴﺑﺮﻌﻟا(

ﺮﻳﺬﺤﺗ :ﺮﻄﺧ، ﻒﻠﺘﻟاو رﺎﺠﻔﻧﻼﻟ ﺔﻳرﺎﻄﺒﻟا ضﺮﻌﺘﺗ ﺪﻗ اذإ ﻢﺗﺪﺒﺘﺳا ﺎﻬﻟاﻰﻠﺻأ ﺮﻴﻏ عﻮﻨﺑ . لﺪﺒﺘﺳأﻰﺻوأ ﺊﻓﺎﻜﻣ عﻮﻧ وأ ﺲﻔﻨﺑ ﻂﻘﻓ ﻪﺑ ﻞﺒﻗ ﻦﻣ

ﺞﺘﻨﻣزﺎﻬﺠﻟا . تﺎﻳرﺎﻄﺒﻟا ﻞهﺎﺠﺗﺔﻠﻤﻌﺘﺴﻤﻟا ﺎﻘﻓو تادﺎﺷرﻹ ﺔآﺮﺸﻟا ﺔﻌﻨﺼﻤﻟا.

WEEE Statement

(English) Under the European Union ("EU") Directive on Waste Electrical and Electronic Equipment, Directive

2002/96/EC, which takes effect on August 13, 2005, products of "electrical and electronic equipment" cannot be discarded

as municipal waste anymore and manufacturers of covered electronic equipment will be obligated to take back such

products at the end of their useful life.

(French) (Français) Au sujet de la directive européenne (EU) relative aux déchets des équipement électriques et

électroniques, directive 2002/96/EC, prenant effet le 13 août 2005, que les produits électriques et électroniques ne

peuvent être déposés dans les décharges ou tout simplement mis à la poubelle. Les fabricants de ces équipements

seront obligés de récupérer certains produits en fin de vie.

1-14

Preface

(German) (Deutsch) Gemäß der Richtlinie 2002/96/EG über Elektro- und Elektronik-Altgeräte dürfen Elektro- und

Elektronik-Altgeräte nicht mehr als kommunale Abfälle entsorgt werden, die sich auf 13.August, 2005 wirken. Und der

Hersteller von bedeckt Elektronik-Altgeräte gesetzlich zur gebrachten Produkte am Ende seines Baruchbarkeitsdauer

zurückzunehmen.

(Spanish) (Español) Bajo la directiva 2002/96/EC de la Unión Europea en materia de desechos y/o equipos electrónicos,

con fecha de rigor desde el 13 de agosto de 2005, los productos clasificados como "eléctricos y equipos electrónicos" no

pueden ser depositados en los contenedores habituales de su municipio, los fabricantes de equipos electrónicos, están

obligados a hacerse cargo de dichos productos al termino de su período de vida.

(Italian) (Italiano) In base alla Direttiva dell’Unione Europea (EU) sullo Smaltimento dei Materiali Elettrici ed Elettronici,

Direttiva 2002/96/EC in vigore dal 13 Agosto 2005, prodotti appartenenti alla categoria dei Materiali Elettrici ed Elettronici

non possono più essere eliminati come rifiuti municipali: i produttori di detti materiali saranno obbligati a ritirare ogni

prodotto alla fine del suo ciclo di vita.

(Russian) (Русский) В соответствии с директивой Европейского Союза (ЕС) по предотвращению загрязнения

окружающей среды использованным электрическим и электронным оборудованием (директива WEEE

2002/96/EC), вступающей в силу 13 августа 2005 года, изделия, относящиеся к электрическому и электронному

оборудованию, не могут рассматриваться как бытовой мусор, поэтому производители вышеперечисленного

электронного оборудования обязаны принимать его для переработки по окончании

(Turkish) (Türkçe) Avrupa Birliği (AB) Kararnamesi Elektrik ve Elektronik Malzeme Atığı, 2002/96/EC Kararnamesi altında

13 Ağustos 2005 tarihinden itibaren geçerli olmak üzere, elektrikli ve elektronik malzemeler diğer atıklar gibi çöpe

atılamayacak ve bu elektonik cihazların üreticileri, cihazların kullanım süreleri bittikten sonra ürünleri geri toplamakla

yükümlü olacaktır.

срока службы.

1-15

Preface

(Greek) (Ελληνικά) Σύμφωνα με την Οδηγία 2002/96/ΕΚ της Ευρωπαϊκής Ένωσης («ΕΕ») περί Απόρριψης Ηλεκτρικού

και Ηλεκτρονικού Εξοπλισμού (WEEE), η οποία λαμβάνει ισχύ στις 13 Αυγούστου 2005, τα προϊόντα «ηλεκτρικού και

ηλεκτρονικού εξοπλισμού» δεν είναι δυνατόν να απορριφθούν πλέον ως κοινά απορρίμματα και οι κατασκευαστές

κεκαλυμμένου ηλεκτρονικού εξοπλισμού είναι υποχρεωμένοι να πάρουν πίσω αυτά

ζωής τους.

(Polish) (Polski) Zgodnie z Dyrektywą Unii Europejskiej ("UE") dotyczącą odpadów produktów elektrycznych i

elektronicznych (Dyrektywa 2002/96/EC), która wchodzi w życie 13 sierpnia 2005, tzw. “produkty oraz wyposażenie

elektryczne i elektroniczne " nie mogą być traktowane jako śmieci komunalne, tak więc producenci tych produktów będą

zobowiązani do odbierania ich w momencie gdy produkt jest wycofywany z użycia.

(Hungarian) (Magyar) Az Európai Unió („EU") 2005. augusztus 13-án hatályba lépő, az elektromos és elektronikus

berendezések hulladékairól szóló 2002/96/EK irányelve szerint az elektromos és elektronikus berendezések többé nem

kezelhetőek lakossági hulladékként, és az ilyen elektronikus berendezések gyártói kötelessé válnak az ilyen termékek

visszavételére azok hasznos élettartama végén.

(Czech) (Čeština) Podle směrnice Evropské unie ("EU") o likvidaci elektrických a elektronických výrobků 2002/96/EC

platné od 13. srpna 2005 je zakázáno likvidovat "elektrické a elektronické výrobky" v běžném komunálním odpadu a

výrobci elektronických výrobků, na které se tato směrnice vztahuje, budou povinni odebírat takové výrobky zpět po

skončení jejich životnosti.

(Traditional Chinese ) (繁體中文) 歐盟已制訂有關廢電機電子設備法令，亦即自 2005 年 8 月 13 日生效的 2002/96/EC，明

τα προϊόντα στο τέλος της ωφέλιμης

文規定「電機電子設備產品」不可再以都市廢棄物處理，且所有相關電子設備製造商，均須在產品使用壽命結束後進行回

收。

(Simplified Chinese ) (简体中文) 欧盟已制订有关废电机电子设备法令，亦即自 2005 年 8 月 13 日生效的 2002/96/EC，明

1-16

Preface

文规定「电机电子设备产品」不可再以都市废弃物处理，且所有相关电子设备制造商，均须在产品使用寿命结束后进行回

收。

(Japanese) (日本語) 2005 年 8 月 13 日以降に EU 加盟国を流通する電気・電子製品には WEEE 指令によりゴミ箱に×印のリサ

イクルマークの表示が義務づけられており、廃棄物として捨てることの禁止とリサイクルが義務づけられています。

(Korean) (한국어) 2005 년 8월 13 일자로 시행된 폐전기전자제품에 대한 유럽연합("EU") 지침, 지침 2002/96/EC 에

의거하여, "전기전자제품"은 일반 쓰레기로 폐기할 수 없으며 제품의 수명이 다하면 해당 전자제품의 제조업체가

이러한 제품을 회수할 책임이 있습니다.

(Vietnam) (Tieng Viet) Theo Hướng dẫn của Liên minh Châu Âu ("EU") về Thiết bị điện & điện tử đã qua sử dụng, Hướng

dẫn 2002/96/EC, vốn đã có hiệu lực vào ngày 13/8/2005, các sản phẩm thuộc "thiết bị điện và điện tử" sẽ không còn

được vứt bỏ như là rác thải đô thị nữa và các nhà sản xuất thiết bị điện tử tuân thủ hướ

phẩm này vào cuối vòng đời.

(Thai) (ไทย) ภายใตขอกําหนดของสหภาพยุโรป ("EU") เกี่ยวกับของเสียจากอุปกรณไฟฟา และอิเล็กทรอนิกส เลขที่ 2002/96/EC

ซึ่งมีผลบังคับใชตั้งแตวันที่ 13 สิงหาคม 2005 ผูใชไมสามารถทิ้งผลิตภัณฑที่เปน "อุปกรณไฟฟาและอิเล็กทรอนิกส"

ปะปนกับของเสียทั่วไปของชุมชนไดอีกตอไป และผูผลิตอุปกรณอิเล็กทรอนิกสดังกลาวจะถูกบังคับใหนําผลิตภัณฑ

สิ้นสุดอายุการใชงานของผลิตภัณฑ

(Indonesia) (Bahasa Indonesia) Sesuai dengan Regulasi Uni Eropa ("UE") perihal WEEE (Limbah Peralatan Listrik dan

Elektronik), Directive 2002/96/EC, yang berlaku sejak 13, 2005, produk "peralatan listrik dan elektronik" tidak lagi dapat

dibuang sebagai sampah umum dan pabrik peralatan elektronik diwajibkan untuk mengambil kembali produk tersebut

pada saat masa pakainya habis.

(Serbian) (Srpski) Po Direktivi Evropske unije ("EU") o odbačenoj ekektronskoj i električnoj opremi, Direktiva 2002/96/EC,

koja stupa na snagu od 13. Avgusta 2005, proizvodi koji spadaju pod "elektronsku i električnu opremu" ne mogu više biti

ng dẫn sẽ phải thu hồi các sản

ดังกลาวกลับคืนเมื่อ

1-17

Preface

odbačeni kao običan otpad i proizvođači ove opreme biće prinuđeni da uzmu natrag ove proizvode na kraju njihovog

uobičajenog veka trajanja.

(Netherlands) (Nederlands) De richtlijn van de Europese Unie (EU) met betrekking tot Vervuiling van Electrische en

Electronische producten (2002/96/EC), die op 13 Augustus 2005 in zal gaan kunnen niet meer beschouwd worden als

vervuiling. Fabrikanten van dit soort producten worden verplicht om producten retour te nemen aan het eind van hun

levenscyclus..

(Romanian) (Română) În baza Directivei Uniunii Europene ("UE") privind Evacuarea Echipamentului Electric şi Electronic,

Directiva 2002/96/EC, care intră în vigoare pe 13 august, 2005, produsele din categoria "echipament electric şi electronic"

nu mai pot fi evacuate ca deşeuri municipale, iar fabricanţii echipamentului electronic vizat vor fi obligaţi să primească

înapoi produsele respective la sfârşitul duratei lor de utilizare.

(Portuguese) (Português) De acordo com a Directiva 2002/96/EC de Resíduos de Equipamentos Eléctricos e

Electrónicos da União Europeia (UE), efectiva desde o 13 de Agosto do ano 2005, os produtos de "equipamento eléctrico

e electrónico" não podem ser descartados como resíduo municipal e os fabricantes do equipamento electrónico sujeitos a

esta legislação estarão obligados a recolhar estes produtos ao finalizar sua vida útil.

(Swedish) (Svenska) Under Europeiska unionens ("EU") Weee-direktiv (Waste Electrical and Electronic Equipment),

Direktiv 2002/96/EC, vilket trädde i kraft 13 augusti, 2005, kan inte produkter från "elektriska och elektroniska

utrustningar" kastas i den vanliga hushållssoporna längre och tillverkare av inbyggd elektronisk utrustning kommer att

tvingas att ta tillbaka sådan produkter när de är förbrukade.

(Finnish) (Suomi) Euroopan unionin (EU) 13.8.2005 voimaan tulleen sähkö- ja elektroniikkalaiteromua koskevan

direktiivin 2002/96/EY mukaisesti ”sähkö- ja elektroniikkalaitteita” ei saa enää hävittää talousjätteiden mukana. Direktiivin

alaisen sähkö- tai elektroniikkalaitteen valmistajan on otettava laitteet takaisin niiden käyttöiän päättyessä.

1-18

Preface

(Slovak) (Slovenčina) Na základe smernice Európskej únie („EU“) o elektrických a elektronických zariadeniach číslo

2002/96/ES, ktorá vstúpila do platnosti 13. augusta 2005, výrobky, ktorými sú „elektrické a elektronické zariadenia” nesmú

byť zneškodňované spolu s komunálnym odpadom a výrobcovia patričných elektronických zariadení sú povinní takéto

výrobky na konci životnosti prevziať naspäť.

(Slovenian) (Slovenščina) Skladno z določili direktive Evropske unije ("EU") o odpadni električni in elektronski opremi,

Direktiva 2002/96/ES, ki je veljavna od 13. avgusta, izdelkov "električne in elektronske opreme" ni dovoljeno odstranjevati

kot običajne komunalne odpadke, proizvajalci zadevne elektronske opreme pa so zavezani, da tovrstne izdelke na koncu

njihove življenjske dobe sprejmejo nazaj.

(Danish) (Dansk) I henhold til direktiv fra den europæiske union (EU) vedrørende elektrisk og elektronisk affald , Direktiv

2002/96/EC, som træder i kraft den 13. august 2005, må produkter som "elektrisk og elektronisk udstyr" ikke mere

bortskaffes som kommunalt affald. Producenter af det pågældende, elektroniske udstyr vil være forpligtet til at tage disse

produkter tilbage ved afslutningen på produkternes levetid.

(Norwegian) (Norsk) Under den europeiske unionens ("EU") direktiv om deponering av elektronisk og elektrisk utstyr,

direktiv 2002/96/EC, som trer i effekt 13. august 2005, kan ikke produkter av "elektronisk og elektrisk ustyr" lenger

deponeres som husholdningsavfall og fabrikantene av disse produktene er forpliktet å ta tilbake slike produkter ved

slutten av produktets levetid.

(Bulgarian) (български) Според директивата на Европейския съюз относно отпадъците от електрическо и

електронно оборудване, директива 2002/96/EC, важаща от 13 август, 2005 г., електрическо и електронно

оборудване не може да се изхвърля заедно с битовите отпадъци и производителите на такова оборудване са

задължени да приемат обратно съответните продукти в края на експлоатационния им период.

(Croatian) (Hrvatski) U okviru Direktive Europske Unije ("EU") o Otpadnim električnim i elektroničkim uređajima, Direktiva

1-19

Preface

2002/96/EC, koja je na snazi od 13. kolovoza 2005., "električni i elektronički uređaji" se ne smiju više bacati zajedno s

kućnim otpadom i proizvođači su obvezni zbrinuti takve proizvode na kraju njihovog životnog vijeka.

(Estonia) (Eesti) Vastavalt Euroopa Liidu ("EL") direktiivile 2002/96/EÜ (elektri- ja elektroonikaseadmete jäätmete kohta),

mis jõustus 13. augustil 2005, on keelatud kodumajapidamiste "elektri- ja elektroonikaseadmete" jäätmete hävitamine

koos majapidamisjäätmetega, ja elektri- ja elektroonikaseadmete tootjad on kohustatud sellised tooted pärast nende

kasutuselt kõrvaldamist tagasi võtma.

(ﻲﺳرﺎﻓ) (Persian)

ﺎﻗ ﻖﺒﻃ ﺮﺑﻮﻧ ﯽﮑﻴﻧوﺮﺘﮑﻟا و ﯽﮑﻳﺮﺘﮑﻟا ﯼﺎه ﻪﻟﺎﺑز ﻊﻓد ن) ﺪﻨﺑ 2002/96/EC ﺎﭘورا ﻪﻳدﺎﺤﺗا ( ﺦﻳرﺎﺗ زا ﻪﮐ13 لﺎﺳ ﺖﺳﻮﮔﺁ 2005 ﯼﺎه ﺖﮐﺮﺷ ﻪﻴﻠﮐ ، ﺖﺳاﺮﺟا ﻞﺑﺎﻗ ﯼدﻼﻴﻣ

ﻪﻟﺎﺑز ﯼروﺁ ﻊﻤﺟ ﻪﺑ ﻒﻇﻮﻣ ﻩﺪﻨﻨﮐ ﺪﻴﻟﻮﺗﺪﻨﺷﺎﺑ ﯽﻣ فﺮﺼﻣ ﻩرود نﺎﻳﺎﭘ زا ﺲﭘ دﻮﺧ تﻻﻮﺼﺤﻣ .

)Arabic ()ﺔﻴﺑﺮﻌﻟا(

ﻲﺑروﻷا دﺎﺤﺗﻹا ﺔﻴﻗﺎﻔﺗا رﺎﻃإ ﻲﻓ")ﻲﺑروﻷا دﺎﺤﺗﻹا (" ﻪﻴﺟﻮﺗ ،ﺔﻴﻧوﺮﺘﻜﻟﻹاو ﺔﻴﺋﺎﺑﺮﻬﻜﻟا ةﺰﻬﺟﻷا و تاﺪﻌﻤﻟا تﺎﻳﺎﻔﻧ نﺄﺸﺑ ﻪﻴﺟﻮﺘﻟا2002/96/EC

ﺎﻬﺘﻴﺣﻼﺻ ةﺪﻣ ﺔﻳﺎﻬﻧ ﻲﻓ تﺎﺠﺘﻨﻤﻟا ﻩﺬه ﻞﺜﻣ دادﺮﺘﺳا ﻢﻬﻴﻠﻋ ﺎﻣاﺰﻟ نﻮﻜﻴﺳ ﺔﻴﻧوﺮﺘﻜﻟﻻا تاﺪﻌﻤﻟا

،ﺔﻴﺑروﻷا ﺔﻋﻮﻤﺠﻤﻠﻟىﺬﻟا ﻲﻓ لﻮﻌﻔﻤﻟا يرﺎﺳ ﺢﺒﺻأ 13ﺲﻄﺴﻏأ / ،بﺁ2005 تﺎﺠﺘﻨﻣ نا ،"ﺔﻴﻧوﺮﺘﻜﻟإو ﺔﻴﺋﺎﺑﺮﻬآ ةﺰﻬﺟأ " ﻲﻠﺨﺘﻟا ﻦﻜﻤﻳ ﻻ

ﻮﺠﺘﻨﻣو ،تﺎﻳﺎﻔﻧ ﺎﻬﻔﺻﻮﺑ ﺎﻬﻨﻋ.

1-20

Preface

Optical Drive Device Notice

CAUTION: This appliance contains a laser system and is classified as a “CLASS 1 LASER

PRODUCT.” To use this model properly, read the instruction manual carefully and keep this manual

for your future reference. In case of any trouble with this model, please contact your nearest

“AUTHORIZED service station.” To prevent direct exposure to the laser beam, do not try to

disassemble the enclosure.

Trademarks

All trademarks are the properties of their respective owners.

Release History

Version Revision Note Date

1.0 First Released 04, 2009

1.1 07, 2009

CHAPTER 2

Introductions

2-2

Introductions

Congratulations on becoming an user of this notebook, the finely designed notebook. This

brand-new exquisite notebook will give you a delightful and professional experience in using
notebook. We are proud to tell our users that this notebook is thoroughly tested and certified by
our reputation for unsurpassed dependability and customer satisfaction

.

Manual Map

This User’s Manual provides instructions and illustrations on how to operate this notebook. It is
recommended to read this manual carefully before using this notebook.

Chapter 1, Preface

this notebook. It is recommended to read these information or caution when using this notebook
for the first time.

Chapter 2, Introductions

recommended to check out that if you have all the accessories included when you open the packing
box. If any of these accessories is damaged or missing, please contact the vendor where you
purchased this notebook. Also, this chapter provides the specification of this notebook, and
introduces the function buttons, quick launch buttons, connectors, LEDs and externals of this
notebook.

Chapter 3, Getting Started

, gives users the basic safety information and caution that is interrelated to using

, includes the descriptions of all the accessories of this notebook. It is

, gives the basic operation instructions on using keyboard, touchpad,

hard disk drive, and optical storage drive. Beside, the steps of installing and uninstalling the
battery; and the procedures of connecting the various external devices, communication devices,
and so on, are also provided to help users getting familiar with this notebook.

2-3

Introductions

Chapter 4, BIOS Setup, provides information on BIOS Setup program and allows you to configure
the system for optimum use.

Unpacking

First, unpack the shipping carton and check all items carefully. If any item contained is damaged or
missing, please contact your local dealer immediately. Also, keep the box and packing materials in
case you need to ship the unit in the future. The package should contain the followin g items:

These accessories listed
above may change without
notice.

Notebook

High-capacity Li-ion battery

Carry bag (optional)

All-in-one application disk, containing the full version of user’s manual,
drivers, utilities, and optional recovery function, etc…

Quick Start Manual

AC adapter and power cord

2-4

Introductions

Specification

Physical Characteristic

Dimension 247.5 (W) x 374 (D) x 35 (H) mm
Weight 2.5KG

CPU

Processor Ty pe Intel® PBGA 478 pin
Support Processor Intel
L2 Cache 3MB/ 6MB
FSB Speed 1066/ 800/ 533Mhz (optional)
Special Notification The actual processor preinstalled in the notebook depends on

®

Merom Core 2 Duo / Penryn processor (45nm)

the model you purchased. Please contact the local dealer for
detailed information.

Core Chips

Option A North Bridge: SiS M672 DX
South Bridge: SiS 968
Option B Chipset: NVIDIA MCP79MVL
Special Notification The actual core chips preinstalled in the notebook depends on

the model you purchased. Please contact the local dealer for
detailed information.

2-5

Introductions

Memory

Technology DDR2 533/ 677/ 800 Mhz
Memory DDR2 SO-DIMM X 2 slot
256/ 512/ 1024/ 2048 MB DDR2 SDRAM
Maximum up to 4GB (2048MB DDR2 SO-DIMMM x 2) (optional)

Power

AC Adapter 65W, 19V
Battery Type 6 cells (optional)
RTC Battery Yes

I/O Port

Monitor (VGA) 15 pin D-Sub x 1
USB x 3 (USB version 2.0)
Mic-in x 1
Headphone Out x 1
RJ45 x 1
HDMI x 1 (optional)
Card Reader x 1 (XD / SD/ MMC / MS)
The supported memory cards may vary without notice.

ExpressCard

Slot ExpressCard Slot x 1 (optional)

2-6

Introductions

Storage (Items listed here may vary depending on the model users purchased)

HDD form factor 2.5”, 9.5mm High, 5400rpm
160/ 250/ 320 GB (optional)
Optical Drive Device Super Multi / Combo (optional)
(Devices listed here may vary without notice)

Communication Port (Items listed here may vary without notice)

LAN Supported
Wireless Lan Supported
Bluetooth Supported

Audio

Internal Speaker 2 speakers with housing
Sound Volume Adjust by volume button, K/B hot-key & SW

Video

Dual View Function LCD or CRT will be auto detected when connected.
CRT Output Supported

Display

LCD Type 16” / 15.6” (optional)
Brightness Brightness controlled by K/B hot-keys

2-7

Introductions

WebCam

CMOS (optional) Supported

Software & BIOS

USB Flash Boot Yes, USB floppy boot up DOS only
BIOS Fast Boot Support --- Yes

Others

Kensington Lock Hole x 1
Compliance WHQL

Upgrade and Warranty

Please be noticed that the memory, hard disk drive, and battery pack preinstalled in the product
users purchased may be upgradable or replaceable by user’ s request.

To learn more about upgrade limitation, please refer to the specification in the User’s Manual. For
any further information about the product users purchased, please contact the local dealer.

Do not attempt to upgrade or replace any component of the product, if you are not an authorized
dealer or service center, since it may cause the warranty void. It is strongly recommended to
contact the authorized dealer or service center for any upgrade or replace service.

The figures show here are
for reference only.

2-8

Introductions

Product Overview

This section provides the description of basic aspects of the notebook. It will help you to know
more about the appearance of this notebook before using it. Please be aware that the notebook
shown in this section may vary from the actual one that users purchased.

Top-open View

The figure of top-open view and description shown below will lead you to browse the main operating
area of your notebook.

1

2

3

6 5 4

1. Webcam /
Webcam LED

2. Power Button /
Power LED

3. Quick Launch Buttons

4. Status LED

5. Touchpad

6. Keyboard

2-9

Introductions

1. Webcam/ Webcam LED (optional)

 This built-in Webcam can be used for picture taking, video recoding or conferencing, and

other interactive applications.

 Webcam LED indicator, next to the webcam, grows orange when webcam function is

activated; LED goes out when this function is turned off.

2. Power Button / Power LED
Power Button

 Press the power button to turn the notebook power ON and OFF.

Power/ Power Saving function LED:

 Glowing blue when the notebook power is turned on.
 Glowing green when the Power Saving Function is activated.
 LED goes off when this function is turned off.

3. Quick Launch Buttons

Press the quick launch buttons to activate the specific applications or tools. With the help of
these quick launch buttons, users will be able to do work more efficiently.

Webcam

Wireless LAN

Bluetooth

Press this button to turn the Webcam function on or off

Press this button repeatedly to turn the WLAN or Bluetooth function on or of f
recurrently

2-10

Introductions

P1

User Defined

ECO

ECO Engine

(Power Saving)

4. Status LED

Bluetooth

Press this button to launch the User Defined application.

 Press the ECO quick launch button repeatedly to switch among these

five different power saving modes – Gaming mode, Movie mode,
Presentation mode, Office mode, and Turbo Battery mode provided
by ECO Engine, or to turn this function off recurrently.

 Refer to the Power Management section in chapter 3 of this manual for

the detailed information of this ECO Engine, Power Saving Function.

Bluetooth and Wireless LAN (optional):

 Wireless LAN LED indicator glows green when Wireless LAN function is

enabled.

 Bluetooth LED indicator glows blue when Bluetooth function is enabled.
 Both LED indicators glow green and blue at the same time when both

functions are enabled.

Wireless LAN

 Both LED indicators go out when both functions are disabled.
 Warning: For flight safety consideration, make sure these two LED

indicators go out when you are in flight.

 Note: The Bluetooth Function may be optional supported depending on

the model users purchased.

2-11

Introductions

Power On/ Off/ Suspend:

 Blinking blue when the system is in suspend mode.
 LED goes out when the system is turned off.

Battery Status

 Glowing green when the battery is being charged.
 Glowing amber when the battery is in low battery status.
 Blinking amber if the battery fails and it is recommended to replace a new

battery. Consult the local dealer for purchasing an equivalent type of
battery recommended by the manufacturer.

 Battery LED goes out when it is fully charged or when the AC adapter is

disconnected.

Hard Disk/ Optical Drive Device In-use:
Blinking blue when the system is accessing the hard disk drive or the optical
drive device.

Num Lock: Glowing blue when the Num Lock function is activated.

Caps Lock: Glowing blue when the Caps L ock function is activated.

Scroll Lock: Glowing blue when the Scroll Lock function is activated.

2-12

Introductions

5. Touchpad

This is the pointing device of the notebook.

6. Keyboard

The built-in keyboard provides all the functions of a full-sized keyboard.

2-13

Introductions

Front Side View

1

1. Consumer Infrared Receiver

2. Stereo Speakers

2

2

1. Consumer Infrared Receiver (CIR) (Optional)

CIR refers to a wide variety of devices employing the infrared electromagnetic spectrum for wireless
communications.

2. Stereo Speakers

Give high quality sound blaster with stereo system and Hi-Fi function supported.

2-14

Introductions

Right Side View

1

2

1. USB Port

The USB 2.0 port allows you to connect USB-interface peripheral devices, such as the mouse,

1. USB Port

2. Optical Drive Device

keyboard, modem, portable hard disk module, printer and more.

2. Optical Drive Device

This notebook is equipped with an optical drive device. The actual device preinstalled in the
notebook depends on the model you purchased.

2-15

Introductions

Left Side View

3

2

1

4 5

1. RJ-45 Connector

2. Audio Port Connectors

3. Ventilator

4. Card Reader

5. ExpressCard Slot

1. RJ-45 Connector

The Ethernet connector is used to connect a LAN cable for network connection.

2. Audio Port Connectors

Make high quality sound blaster with stereo system and Hi-Fi function supported.

Headphone: A connector for speakers or
headphones.

Microphone: Used for an external microphone.

2-16

Introductions

3. Ventilator

The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.

4. Card Reader

The built-in card reader may support various types of memory card, such as MMC (Multi-Media
Card), XD (eXtreme Digital), SD (Secure Digital ), SDHC (SD High Cap acity), MS (Memory Stick)
or MS Pro (Memory Stick Pro) ca rds, and so on. Contact the local dealer for further and correct
information and be noted that the supported memory cards may vary without notice.

5. ExpressCard Slot (Optional)

The notebook provides an ExpressCard slot. The new ExpressCard interface is smaller and
faster than PC Card interface. The ExpressCard technology takes advantage of the scalable,
high-bandwidth serial PCI Express and USB 2.0 interfaces.

2-17

Introductions

Rear Side View

1. Kensington Lock

1

4 6

5

2 3

7

1. Kensington Lock

2. Power Connector

3. USB Ports

4. TV-Tuner Antenna Connector

5. SIM Card Slot

6. VGA Port

7. HDMI Connector

This notebook provides a Kensington Lock

with a key or some mechanical PIN device and attached through a rubberised metal cable. The end of the
cable has a small loop which allows the whole cable to be looped around a permanent object, such as a
heavy table or other similar equipment, thus securing the notebook in place.

hole, which allows users to secure the notebook in place

2. Power Connector

To connect the AC adapter and supply power for the notebook.

3. USB Ports

The USB 2.0 port allows you to connect USB-interface peripheral devices, such as the mouse,
keyboard, modem, portable hard disk module, printer and more.

2-18

Introductions

4. TV-Tuner Antenna Connector (Optional)

Notebook with Analog TV tuner — plug the supplied TV-Tuner adaptor into the

connector first,

and then screw the TV cable at the other end of adaptor.
Notebook with Digital TV tuner — simply plug the su pplied TV Antenna into the connector.

5. SIM Card Slot (Optional)

Insert the SIM card properly into the SIM Card Slot provided in the notebook for

internet service.

Contact your internet service provider for any internet connecting issue.

6. VGA Port

The 15-pin-D-sub VGA port allows you to connect an external monitor or other standard
VGA-compatible device (such as a projector) for a great view of the computer

display.

7. HDMI Connector (Optional)

HDMI (High Definition Multimedia Interface Support) is a new interface standard for PCs,
displays and consumer electronics devices that supports st andard,

enhanced and high-definition

video, plus multi-channel digital audio on a single cable.

2-19

Introductions

Bottom Side View

1

1. Battery Lock/ Unlock Button

2

3

2. Battery Release Button

3. Battery Pack

1. Battery Lock/ Unlock Button

Battery cannot be moved when the button is positioned on lock st a tus. On ce the button is slid to
unlock position, the battery is removable.

2. Battery Release Button

It is a bounce-back device as a preparation for releasing the battery pack. Slide it with one hand
and pull the battery pack carefully with the other.

3. Battery Pack

This notebook will be powered by the battery pack when the AC adapter is disconnected.

CHAPTER 3

Getting Started

3-2

Getting Started

Power Management

ECO Engine -- Power Saving Function

ECO Engine, the outstanding and unique power saving function, provides 5 different power saving
modes – Gaming mode, Movie mode, Presentation mode, Office mode, and Tur bo Batt er y
mode, to extend the battery running time while performing different tasks with this notebook.

Press the ECO quick launch button repeatedly to switch among these 5 different modes or to turn
this ECO Engine, Power Saving Function off recurrently.

To learn which power saving mode is activated presently, read the icon on behalf of each mode
appearing on the display when selected.

Gaming Mode
Select this mode while performing game applications.

Movie Mode

Select this mode while playing multimedia applications.

3-3

Getting Started

Presentation Mode

Select this mode while performing presentation applications.

Office Mode

Select this mode while dealing with office documentation tasks.

T urbo Batter y Mode

Select this mode to maximize the battery running time.

ECO Off

Selected to disable ECO Engine.

3-4

Getting Started

AC Adapter

Please be noted that it is strongly recommended to connect the AC adapter and use the AC power
while using this notebook for the first time. When the AC adapter is connected, the battery is being
charged immediately.

Note that the AC adapter included in the package is approved for your notebook; using other
adapter model may damage either the notebook or other devices attached to it.

Connecting the AC Power

1. Unpack the package to find the AC adapter and power cord.

2. Attach the power cord to the connector of the AC adapter.

3. Plug the DC end of the adapter to the notebook, and the male end of the power cord to the
electrical outlet.

Disconnecting the AC Power

When you disconnect the AC adapter, you should:

1. Unplug the power cord from the electrical outlet first.

2. Unplug the connector from the notebook.

3. Disconnect the power cord and the connector of AC a dapter.

4. When unplugging the power cord, always hold the connector part of the cord. Never pull the
cord directly!

3-5

Getting Started

3-6

Getting Started

Battery Pack

This notebook is equipped with a high-capacity Li-ion battery pack. The rechargeable Li-ion battery
pack is an internal power source of the notebook.

Be aware of that this battery pack may be damaged if users try to disassemble the battery pack on
their own.

Also, note that the limited warranty to the battery pack may also lose its efficacy when this battery
pack is disassembled not by an authorized machinist.

Please follow your local laws and regulations to recycle the unused battery pa ck.

Be noted that the figures show here are for reference only.

3-7

Getting Started

Releasing the Battery Pack

It is always recommended to have another battery pack in reserve for enough power supply.
Please contact your local dealer to purchase a battery pack that is compliant to your notebook.

To remove the battery pack, following the steps below:

1. Make sure the notebook is turned of f, and the AC power is disconnected.

2. Press the lock/unlock button to the unlocked position.

3. Locate the battery release button on the bottom side.

4. Push and hold the release button to the battery releasing direction as shown on the bottom
side.

5. Dig the edge of battery pack out of the battery tray with your finger tip. Be careful with your
finger while trying to take out the battery pack.

6. And then pull the battery pack out.

3-8

Getting Started

2

4

5

4

5

6

3

3-9

Getting Started

Replacing the Battery Pack

To insert the battery pack, following the steps below:

1. Align and place the battery to the
battery tray with correct orientation.

2. Press down the battery pack to fasten

1

2

the battery pack in the battery tray.

3. Press the lock/ unlock button to the
Lock position to make sure the battery
pack is securely fastened.

3

3-10

Getting Started

Using the Battery Pack

Battery Safety Tips

Replacing or handling the battery incorrectly may present a risk of fire or explosion, which could
cause serious injury.

 Only replace the main battery pack with the same or equivalent type of battery.
 Do not disassemble, short-circuit or incinerate batteries or store them to temperatures above

+60° C (+140° F).

 Do not temper with batteries. Keep away from the reach of children.
 Do not use rusty or damaged batteries.
 Dispose of batteries according to local regulations. Check with your local solid waste

officials for details about recycling options or for proper disposal in your area.

Conserving Battery Power

Efficient battery power is critical to maintain a normal operation. If the battery power is not
managed well, the saved data and customized settings may be lost.

To optimize battery life and avoid a sudden power loss, read the tips below:

 Suspend system operation if the system will be idle for a while or shorten the suspend timer’s

time period.

 Turn off the system if you won’t be using it for a period of time.
 Disable unnecessary settings or remove idle peripherals.
 Connect an AC adapter to the system whenever possible.

3-11

Getting Started

Charging the Battery Pack

The battery pack can be recharged while it is installed in the notebook. Please pay attention to the
following tips before recharging the battery:

 If a charged battery pack is not available, save your work and close all running programs and

shut down the system or Save-to-Disk.

 Plug in an external AC/DC power source.
 You can use the system, suspend system operation or shut down and turn off the system

without interrupting the charging process.

 The battery pack uses Lithium-ion battery cells that have no “memory effect.” It is

unnecessary to discharge the battery before recharging. However, to optimize the life of
battery , we sugge st that consuming the battery power completely once a month is necessa ry.

 If you do not use the notebook for a long time, it is suggested to remove the battery pack from

your notebook. This may be helpful to extend your battery life.

 The actual charging time will be determined by the applications in use.

3-12

Getting Started

Basic Operations

If you are a beginner to the notebook, please read the following instructions to assure your own
safety, and make yourself comfortable during the operations.

Safety and Comfort Tips

The notebook is a portable platform that allows you to work anywhere. However, choosing a good
workspace is important if you have to work with your notebook for a long pe riod of time.

 Your work area should have enough illumination.
 Choose the proper desk and chair and adjust their height to fit your posture when operating.
 When sitting on the chair, adjust the chair’s back (if available) to support your back

comfortably.

 Place you feet flat and naturally on the floor, so that your knees and elbows have the proper

position (about 90-degree) when operating.

 Put your hands on the desk naturally to support your wrists.
 Adjust the angle/position of the LCD panel to have an optimal view.
 Avoid using your notebook in the space where may cause you discomfort (such as on the

bed).

 The notebook is an electrical device, please treat it with great care to avoid personal injury

3-13

Getting Started

1. Keep your hands and feet with optimal

4

comfort.

2. Adjust the angle and position of LCD
panel.

3. Adjust the desk’s height.

4. Sit straight and keep a good posture.

5. Adjust the chair’s height.

2

3

1

1

5

Having a Good Work Habit

Have a good work habit is important if you have to work with your notebook for long periods of time;
otherwise, it may cause discomfort or injury to you. Please keep the following tips in mind when
operating.

 Change your posture frequently.
 Stretch and exercise you body regularly.
 Remember to take a break after working for a period of time.

3-14

Getting Started

Knowing the Keyboard

This notebook provides a full-functioned keyboard. This keyboard can be divided into four
categories: Typewriter keys, Cursor keys, Numeric keys and Function keys.

Typewriter keys

Numeric keys

The keyboard shown here
may vary from the actual
one, depending on which
county users purchase the
notebook.

Cursor keys /
Function keys

3-15

Getting Started

Typewriter Keys

In addition to providing the major function of the keyboard, these typewrite keys also provide several
keys for special purposes, such as [Ctrl,] [Alt,] and [Esc] key.

When the lock keys are pressed, the corresponding LEDs will light up to indicate their status:

 Num Lock: Press and hold the [Fn] key and press this key to toggle the Num Lock on and off.

When this function is activated, you can use the numeric keys that are embedded in the
typewriter keys.

 Caps Lock: Press this key to toggle the Caps Lock on and off. When this function is activated,

the letters you type are kept in uppercase.

 Scroll Lock: Press and hold the [Fn] key and press this key to toggle the Scroll Lock on and off.

This function is defined by individual programs, and is usually used under DOS.

Numeric Keys

Find the numeric keys among the keyboard, and activate the Num Lock function to use these
numeric keys to enter numbers and calculations.

3-16

Getting Started

Cursor Keys

The four cursor (arrow) keys and [Home], [PgUp], [PgDn], [End] keys are used to control the cursor
movement.

Move the cursor left for one
space.

Move the cursor right for one
space.

Move the cursor up for one line.

Move the cursor down for one
line.

The Backspace key, [Ins] and [Del] keys at upper right corner are use for editing purp ose.

This key is used to switch
the typing mode between
“insert” and “overtype”
modes.

Move to the previous page.

Move to the next page.

Move to the beginning of the line
(or document).

Move to the end of the line (or
document).

Press this key to delete one
character to the right of the
cursor and move the following
text left for one space.

Press this key to delete one character to the left of the cursor and move the
following text left for one space.

3-17

Getting Started

Function Keys

 Windows Keys

You can find the Windows Logo key (

) and one Application Logo key ( ) on the

keyboard, which are used to perform Windows-specific functions, such as opening the Start
menu and launching the shortcut menu. For more information of the two keys, please refer to
your Windows manual or online help.

 [Fn] Key

Switch the display output

Decrease the built-in

mode between the LCD,

+

+

speaker’s volume.

external monitor and both.

Enable or disable the

+

touchpad function.

+

Decrease the LCD

+

brightness.

+

Increase the built-in
speaker’s volume.

Disable the computer’s
audio function.

Force the computer into

Increase the LCD

suspend mode (depending

+

brightness.

+

on system configuration).

3-18

Getting Started

Knowing the Touchpad

The touchpad integrated in your notebook is a pointing device that is compatible with standard
mouse, allowing you to control the notebook by pointing the location of the cursor on the screen and
making selection with its two buttons.

1. Cursor Movement Area

This pressure-sensitive area of the
touchpad, allows you to place your finger
on and control the cursor on the screen by

The touchpad figures shown
here are for reference only,
and may be different from
the notebook that users
purchased

moving one of your finger.

2. Enter Buttons

Acts as the Enter button of the keyboard.

1

2

3-19

Getting Started

Using the Touchpad

Read the following description to learn how to use the touchpad:

 Configuring the Touchpad

You can customize the pointing device to meet your personal needs. For example, if you are a
left-handed user, you may want to swap the functions of the two buttons. In addition, you can
change the size, shape, moving speed and other advanced features of the cursor on the screen.
To configure the touchpad, you can use the standard Microsoft or IBM PS/2 driver in your
Windows operating system. The Mouse Properties in Control Panel allows you to change
the configuration.

 Positioning and Moving

Place your finger on the touchpad (usually using the forefinger), and the rectangular p a d will act
as a miniature duplicate of your display. When you move your fingertip across the pad, the
cursor on the screen will move simultaneously to the same direction. When your finger
reaches the edge of the pad, lift your finger and place it on a proper location of the touchpad to
continue the movement.

 Point and Click

When you have moved and placed the cursor over an icon, a menu item or a command th at you
want to execute, simply tap slightly on the touchpad or press the left button to select. This
procedure, called as point and click is the basics of operating your notebook. Unlike the
traditional pointing device such as the mouse, the whole touchpad can act as a left button, so
that your each tap on the touchpad is equivalent to pressing the left button. Tapping twice
more rapidly on the touchpad is to execute a double-click.

3-20

Getting Started

 Drag and Drop

You can move files or objects in your notebook by using drag-and-drop. To do so, place the
cursor on the desired item and slightly tap twice on the touchpad, an d then keep your fingertip i n
contact with the touchpad on the second tap. Now, you can drag the selected item to the
desired location by moving your finger on the touchpad, and then lift your finger from the
touchpad to drop the item into place. Alternately, you can press and hold the left button when
you select an item, and then move your finger to the desired location; finally, release the left
button to finish the drag-and-drop operation.

1. Move the cursor by sliding

2

your fingertip.

2. Put your wrist on the desk
comfortably.

1

3-21

Getting Started

About Hard Disk Drive

Your notebook is equipped with a 2.5-inch hard disk drive. The hard disk drive is a storage device
with much higher speed and larger capacity than ot her storage device s, such as the floppy disk drive
and optical storage device. Therefore, it is usually used to install the operating system and
software applications.

To avoid unexpected data loss in your system, please backup your critical files regularly.

Do not turn off the notebook when the hard disk In-use LED is on.

Do not remove or install the hard disk drive when the notebook is turned on. The replacement of
hard disk drive should be done by an authorized retail er or service representative.

3-22

Getting Started

Using the Optical Drive Device

Your notebook is equipped with an optical drive device. The actual device preinstalled in your
notebook depends on the model you purchased.

 DVD Combo Drive: This device allows you to read DVD and CD, and record CD format.

 Super Multi: Works as a multi-functional DVD Dual Drive and a DVD RAM Drive.

3-23

Getting Started

Inserting the Disk

The following instructions describe the

1. Confirm tha t the disk is
placed correctly and
securely in the tray
before closing the tray.

2. Do not leave the disk
tray open.

general procedure when operating the
optical storage device:

1. Confirm that the notebook is turned on.

2. Press the eject button on the p anel and
the disk tray will slide out partially.

3. Gently pull the tray out until fully
extended.

4. Place your disk in the tray with its label
facing up. Slightly press the center of
the disk to secure it into place.

5. Push the tray back into the drive.

2

3

4

5

3-24

Getting Started

Removing the Disk

Follow the instructions below to remove the
disk that is placed in the optical storage
device:

6. Press the eject button on the drive’s
panel and the disk tray will slide out
partially.

7. Gently pull the tray out until fully
extended.

8. Hold the disk by its edge with your
fingers and lift it up from the tray.

6

7

8

9. Push the tray back into the drive.

9

3-25

Getting Started

Connecting the External Devices

The I/O (input/output) ports on the notebook allow you to connect peripheral devices. All devices
listed here are for reference only.

Connecting the Peripheral Devices

Connecting the USB devices

This notebook provides USB ports for connecting various USB devices, such as mouse, keyboard,
digital camera, webcam, printer, and external optical storage device, etc... To connect these
devices, install the drivers for each device first if necessary, and then connect the device to the
notebook. This notebook is capable to auto detect the USB devices installed, and if there is no
detection of the devices, please manually enable the USB devices by going to Start Menu / Control

The devices shown in the
reference figures here may
be different from the devices
users have.

Panel / Add Hardware to add the new device.

3-26

Getting Started

Connecting the External Display Devices

This notebook provides a VGA port for connecting a larger display with higher resolution. The
15-pin-D-sub VGA port allows users to connect an external monitor or other standard
VGA-compatible device (such as a projector) for a great view of the notebook display.

3-27

Getting Started

This notebook provides a HDMI port for connecting a larger display with higher resolution. HDMI
(High Definition Multimedia Interface Support) is a new interface standard for PCs, displays and
consumer electronics devices that supports standard, enhanced and high-definition video, plus
multi-channel digital audio on a single cable.

To connect the external display, make sure the notebook and the external display are both powered
off, and then connect the display to the notebook.

Once the display is connected to the notebook, power on the notebook and the external display
should respond by default. If not, you can switch the display mode by pressing [Fn]+[F2].
Alternately, you can change the display mode by configuring the settings in Display Properties of
Windows operating system.

3-28

Getting Started

Connecting the Communication Devices

Using the LAN

The RJ-45 connector of the notebook allows you to connect the LAN (local area network) devices,
such as a hub, switch and gateway, to build a network connection.

For more instructions or detailed steps on connecting to the LAN, please ask your MIS staff or
network manager for help.

3-29

Getting Started

ExpressCard Installation

This computer provides an ExpressCard slot. The new ExpressCard interface is smaller and faster
than PC Card interface. The ExpressCard technology takes advantage of the scalable,
high-bandwidth serial PCI Express and USB 2.0 interfaces.

The following instruction provides you with a basic installation for the ExpressCard, including how to
install and remove it. For more information, please refer to the manual of your ExpressCard.

Removing the ExpressCard

1. Locate the ExpressCard slot on your notebook. There might be a dummy card inserted in the
slot, remove the ExpressCard or dummy card with the same steps below.

2. Press the card to make the card stretch out first.

3. Pull the card out of the slot

4. Empty Slot

Installing the ExpressCard

5. Insert the card into the slot (usually with its label facing up)

6. Push the card into the slot until it is firmly seated.

3-30

Getting Started

Removing the ExpressCard

1 2

3

Installing the ExpressCard

2

3

4

6

5

5

4

3-31

Getting Started

Safely Remove Hardware

When any peripheral device is connected to the notebook, the Safely Remove Hardware icon will
appear on the taskbar. Double-click the icon to bring up the Safely Remove Hardware dialog box.
You can see all connected peripheral devices here. If you want to remove any of the devices,
move the cursor to the device and click Stop. The diagram shown below is for reference only.

Safely Remove Hardware

Select the device you want to unplug or eject, and then click Stop.
When Windows notifies you that it is safe to do so unplug the
device from your computer.

Hardware Devices:

USB Mass Storage Device

1

Stop a Hardware device

Confirm devices to be stopped. Choose OK To continue.
Windows will attempt to stop the following devices. After the

devices are stopped they may be removed safely.

USB Mass Storage Device

3

OK Cancel

Properties Stop

4

2

Close

CHAPTER 4

BIOS Setup

4-2

BIOS Setup

About BIOS Setup

When to Use BIOS Setup?

You may need to run the BIOS Setup when:

 An error message appears on the screen during the system booting up and is requested to

run SETUP.

 You want to change the default settings for customized features.
 You want to reload the default BIOS settings.

How to Run BIOS Setup?

To run the BIOS Setup Utility, turn on the notebook and press the [Del] key during the POST
procedure.
If the message disappears before you respond and you still wish to enter Setup, either restart the
system by turning it OFF and ON, or simultaneously pressing [Ctrl]+[Alt]+[Delete] keys to restart.

Be noted that the screen snaps and setting options in this chapter are for your references only.
The actual setting screens and options on your Notebook may be different because of BIOS update.

4-3

BIOS Setup

Control Keys

You can use only the keyboard to control the cursor in the BIOS Setup Utility.

Press left arrow to select one
menu title.

Press up arrow to select one item
under the menu title.

+

1) Open the selected item to change setting options.

2) Bring up a sub-menu when available.

In some items, press this key to change setting field.

Bring up help screen providing the information of control keys.

Increase the setting value or make changes.

Decrease the setting value or make changes.

Press right arrow to select one
menu title.

Press down arrow to select one
item under the menu title.

1) Exit the BIOS Setup Utility.

2) Return to the previous screen in a sub-menu.

4-4

BIOS Setup

BIOS Setup Menu

Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. Select the tags to
enter the other menus.

Main Menu

Show system overview information about BIOS version, CPU features, memory
size and setting of system time and date.

Advanced Menu
Adjust the advanced settings, such as power consumption, USB/ PCI devices,
of the notebook in order to achieve a better performance.

The BIOS items and
figures shown here are
for reference only.

Security Menu

Install or clear the password settings for supervisor and user.

Boot Menu

Set up boot type and boot sequence.

Exit Menu

Save or discard the changes before leaving the BIOS Setup Menu.

4-5

BIOS Setup

Main Menu

 System Date

This item allows you to set the system date. The date format is
[day:month:date:year].

Day

Month

Date

Year

 System Time

This item allows you to set the system time. The system clock will go on
no matter you shut down the PC or get into sleep mode. The time format
is [hour:minute:second].

 Serial_ATA

These items display the types of the SA TA devices installe d in the notebook.
Press [Enter] to bring up a window showing the detailed information of the
device, including the device name, vendor, LBA mode, PIO mode and

Day of the week, from Sun to Sat, which is determined by
BIOS (read-only).

The month from 01 (January) to 12 (December).

The date from 01 to 31.

The year can be adjusted by users.

more.

4-6

BIOS Setup

 System Information

This item provides the information about the firmware, processor, and
system memory.

4-7

BIOS Setup

Main Advanced Security Boot Exit

Intel (R) Speedstep (tm)

PCI Latency Timer
Legacy USB Support

Main Advanced Security Boot Exit

Intel (R) Speedstep (tm)

PCI TimerLatency
Legacy USB Support
AHCI [ ]Enabled

BISO SETUP UTILITY

[Enabled]

[64]
[]Enabled

BISO SETUP UTILITY

[Enabled]

[64]
[]Enabled

Advanced Menu

 Intel(R) SpeedStep(tm) tech.

This item allows you to enable or disable Intel SpeedStep technology.
When set to Disabled, the system always operates in a conserve power
mode (the processor works at FSB400-600MHz or FSB533-800MHz). If
you want optimize the processor, set this item to Enabled, so that the
processor’s speed will be controlled by the use of your operating system
and applications. Setting options: Enabled, and Disabled.

 PCI Latency Timer

:Select Screen
:Select Item

Enter:

Select

+/-:

Change Opt.

F1:

General Help

F2:

Previous Values

F9:

Optimized Default

F4:

Save

This item controls how long each PCI device can hold the bus before
another takes over. When set to higher values, every PCI device can
conduct transactions for a longer time and thus improve the effective PCI
bandwidth.
For better PCI performance, you should set the item to higher values.
Setting options: 32, 64, 96, 128, 160, 192, 224, and 248.

optional figures

:Select Screen
:Select Item

Enter:

Select

+/-:

Change Opt.

F1:

General Help

F2:

Previous Values

F9:

Optimized Default

F4:

Save

 Legacy USB Support

Selecting Enabled allows users to use USB devices, such as mouse,
keyboard, or portable disk, in DOS system; or allows users to boot the
system by USB device. Setting options: Enabled, Disabled and Auto.

4-8

BIOS Setup

 AHCI (Advanced Host Controller Interface) (Optional)

Use this item to enable or disable the AHCI Mode. Setting options:
Disabled and Enabled. The default setting is Disabled.

4-9

E

d

BIOS Setup

Security menu

 Change Supervisor Password

When this item is selected, a message box shall appear on the screen as
below:

nter New Passwor

Type a maximum of eight-digit password and press [Enter]. The
password typed now will replace any previously set password from CMOS
memory. You may also press [ESC] to abandon new password setting.

When the Supervisor Password is set, new items Change User Password
and Password Check

Select Change Us er Password
same as Change Supervisor Password item above.

Note that Supervisor Password field allows users to enter and change the
settings of the BIOS SETUP UTILITY, while User Password field only
allows users to enter the BIOS SETUP UTILITY without having the
authorization to make any change.

will be added in the menu.

to give or to abandon password setting

4-10

BIOS Setup

The Password Check item is used to specify the type of BIOS password
protection that is implemented. Settings are described below:

Setup

The password is required only when users try to access to
BIOS SETUP UTILITY.

The password is required every time when the Notebook is

Always

powered on or when users try to access to BIOS SETUP
UTILITY.

To clear a set Supervisor Password/ User Password, just press [Enter]
under Change Supervisor Password/ Change User Password field
when you are prompted to enter the password. Please note that when
Supervisor Password has been cleared, User Password will be cleared as
well. A message box will pop up confirming password will be disabled.
Once the password is disabled, the system will boot and user can enter
setup without entering password.

4-11

BIOS Setup

Boot menu

 Boot Settings Configuration

Configure settings during system boot.

 Boot Device Priority

These items showing the sequence of boot devices where BIOS attempts
to load the disk operating system.

4-12

BIOS Setup

Exit menu

 Exit & Save Changes

Save the changes you have made and exit the utility.

 Exit & Discard Changes

Exit the utility without saving the changes you have made.

 Discard Changes

Abandon your changes and reload the previous configuration before
running the utility.

 Load Setup Defaults

Select this item to load the default settings.
