MSD 8253 Installation

MSD Blaster HVC-2 Coil

PN 8253

ONLINE PRODUCT REGISTRATION: Register your MSD product online and you’ll be entered in our monthly 8.5mm Super Conductor Spark Plug Wire give-away! Registering your product will help if there is ever a warranty issue with your product and helps the MSD R&D team create new products that you ask for! Go to www.msdignition.com/registration.

Parts Included:

1 - Blaster HVC-2 Coil 2 - Ring Lug Terminals 4 - Vibration Mounts and Hardware 2 - Brass Screws 2 - Brass Lock Washers

WARNING: Disconnect the battery during installation. When disconnecting the battery, always remove the negative cable ﬁrst and install it last.

The Blaster HVC-2 Coil is designed to be used with an MSD 6 Series Ignition Control only.

INSTALLATION

1. The Coil can be mounted in any position, but should be away from direct heat sources. Use the Coil Template (page 3) and mark the location of the mounting holes. Use a 3/16" bit to drill the holes.

2. Install the supplied vibration mounts to the coil and install the coil.

3. The MSD Orange wire connects to coil positive (+). Black connects to coil negative (-).

Note: If the wires need to be lengthened, it is recommended to use 14-Gauge wiring for the primary

coil wiring.

4. Connect the coil secondary wire to the coil and distributor cap.

WARNING: Very high voltages are present at the coil when the engine is running. Never connect

any test equipment or touch the coil while the engine is cranking or running.

M S D I G N I T I O N • WW W. MSD IG NI TIO N. CO M • (9 15 ) 8 57 -52 00 • FA X ( 91 5) 8 57 -3 34 4

2 INSTALLATION INSTRUCTIONS

Figure 1 Wiring to an MSD Digital-6 Plus and MSD Distributor.

WARNING: Very high voltages are present at the coil when the engine is running. Never connect

any test equipment or touch the coil while the engine is cranking or running.

Figure 2 Wiring to an MSD Ignition with a Points/Ampliﬁer Distributor.

M S D I G N I T I O N • WW W. MSD IG NI TIO N. CO M • (9 15 ) 8 57 -52 00 • FA X ( 91 5) 8 57 -3 34 4

INSTALLATION INSTRUCTIONS 3

MOUNTING TEMPLATE

CAUTION: Due to some printer settings, it is recommended to compare the document to the actual

part dimensions before drilling holes! If the printed document does not match the actual part dimensions, correct the printer scaling settings and print again.

M S D I G N I T I O N • WW W. MSD IG NI TIO N. CO M • (9 15 ) 8 57 -52 00 • FA X ( 91 5) 8 57 -3 34 4

TECH NOTES

_________________________________________________________________________________________________________________________

Service

In case of malfunction, this MSD component will be repaired free of charge according to the terms of the warranty.

When returning MSD components for warranty service, Proof of Purchase must be supplied for veriﬁcation. After the warranty period has expired, repair service is based on a minimum and maximum fee.

All returns must have a Return Material Authorization (RMA) number issued to them before

being returned. To obtain an RMA number please contact MSD Customer Service at 1 (888) MSD-7859 or visit our website at www.msdignition.com/rma to automatically obtain a number and shipping information.

When returning the unit for repair, leave all wires at the length in which you have them installed. Be sure to include a detailed account of any problems experienced, and what components and accessories are installed on the vehicle. The repaired unit will be returned as soon as possible using Ground shipping methods (ground shipping is covered by warranty). For more information, call MSD Ignition at (915) 855-7123. MSD technicians are available from 7:00 a.m. to 5:00 p.m. Monday - Friday (mountain time).
