Introducing your new Motorola V190 GSM wireless phone. Here’s a quick anatomy lesson.

Open menus.

Navigate menus.

Select menu items.

Left Soft Key

Volume Keys

Smart Key

Go online.

Make & answer calls.

Go handsfree.

Right Soft Key

Read messages.

Turn on & off, hang up, exit menus.

Charge up.

Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196

www.hellomoto.com

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States for hearing impaired)

1-800-461-4575 (Canada)

Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider's network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user's guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation.

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. All other product or service names are the property of their respective owners.

Manual Number: 6809496A31-O

menu map . . . . . . . . . . . . 5

essentials . . . . . . . . . . . . 7

about this guide . . . . . . 7

SIM card . . . . . . . . . . . . 8

battery. . . . . . . . . . . . . . 8

turn it on & off. . . . . . . 11

make a call . . . . . . . . . 11

answer a call . . . . . . . . 11

store a phone number 11 call a stored phone

number . . . . . . . . . . . . 12

your phone number . . 12

main attractions . . . . . . 13

play videos . . . . . . . . . 13

multimedia messages. 14

cable connections . . . . 16

basics. . . . . . . . . . . . . . . 17

display. . . . . . . . . . . . . 17

menus. . . . . . . . . . . . . 20

text entry . . . . . . . . . . 22

volume . . . . . . . . . . . . 27

navigation key . . . . . . . 27

external display . . . . . . 28

handsfree speaker . . . 28 codes & passwords . . 28 lock & unlock phone . . 29

customize . . . . . . . . . . . 30

ring style. . . . . . . . . . . 30

ring & event lights . . . 31

time & date. . . . . . . . . 31

wallpaper . . . . . . . . . . 32

screen saver . . . . . . . . 32

display appearance . . . 33

answer options . . . . . . 34

calls . . . . . . . . . . . . . . . . 35

turn off a call alert . . . . 35

recent calls . . . . . . . . . 35

redial . . . . . . . . . . . . . . 36

return a call. . . . . . . . . 37

caller ID. . . . . . . . . . . . 37

emergency calls . . . . . 37

voicemail. . . . . . . . . . . 38

other features . . . . . . . . 39

advanced calling . . . . . 39

phonebook . . . . . . . . . 44

messages . . . . . . . . . . 48

instant messaging . . . 50

chat. . . . . . . . . . . . . . . 52

personalizing. . . . . . . . 52

call times & costs . . . . 54

handsfree . . . . . . . . . . 55

data & fax calls . . . . . . 56

network . . . . . . . . . . . 57

contents

personal organizer . . . 57

security . . . . . . . . . . . 59

fun & games . . . . . . . 59

service and repairs . . . 62

SAR Data . . . . . . . . . . . 63

index . . . . . . . . . . . . . . 65

contents

main menu

Phonebook

Recent Calls

• Received Calls

• Dialed Calls

• Notepad

• Call Times *

• Call Cost *

•Data Times*

•Data Volumes*

Messages

• Create Message

• Message Inbox

•Voicemail

•Browser Msgs

• Info Services *

•Quick Notes

•Outbox

•Drafts

•MMS Templates

Tools

• SIM Tool Kit Apps *

•Calculator

• Datebook

• Shortcuts

•Alarm Clock

•Chat*

• Dialing Services

•Fixed Dial*

•Quick Dial

•Voice Dial

Games & Apps

menu map

Web Ac ces s *

•Browser

• Web Shortcuts

•Stored Pages

•History

•Go To URL

•Browser Setup

• Web Sessions *

Multimedia

•Pictures

• Sounds

• Videos *

Ring Styles

•Style

• style Detail

• Ring Lights

• Event Lights

IM *

• Log In

• Offline Convs.

•IM Account

• Offline Settings

•Help

Settings

• (see next page)

* optional features

This is the standard main menu layout. Your phone’s menu may be a little different.

menu map

settings menu

Personalize

• Home Screen

• Main Menu

•Color Style

• Greeting

• Wallpaper

• Screen Saver

Sync *

Call Forward *

• Voice Calls

•Fax Calls

• Data Calls

• Cancel All

• Forward Status

In-Call Setup

• In-Call Timer

•Call Cost Setup*

• My Caller ID

• Talk and Fax

• Answer Options

• Call Waiting

Initial Setup

• Time and Date

• 1-Touch Dial

• Display Timeout

• Backlight

•TTYSetup*

•Scroll

• Language

• Contrast

•DTMF

• Master Reset

• Master Clear

Phone Status

• My Tel. Numbers

• Credit Info/Available *

• Active Line *

• Battery Meter

• Other Information

Headset

• Auto Answer

•Voice Dial

Car Settings

• Auto Answer

• Auto Handsfree

• Power-Off Delay

• Charger Time

Network

•New Network

•Network Setup

• Available Networks

• My Network List *

• Service Tone *

•Network Jingle*

•Call Drop Tone

Security

• Phone Lock

• Lock Application

• Fixed Dial *

• Restrict Calls *

•Call Barring*

• SIM PIN

•New Passwords

• Certificate Mgmt *

Java Settings

• Java System

• Delete All Apps

• App Vibration

• App Volume

• App Priority *

• App Backlight

• Set Standby App *

• DNS IP *

* optional features

menu map

essentials

CAUTION: Before using the phone for the first time, read the

Legal Information

gray-edged pages at the back of this guide.

about this guide

This guide shows how to locate a menu feature as follows:

Find it:

This example shows that, from the home screen, you press the menu key

s Recent Calls

Press M >

to open the menu. Scroll to and select

, then scroll to and select

Important Safety and

included in the

032257o

s Recent Calls >Dialed Calls

Dialed Calls

Press the navigation key Press the center key feature.

symbols

This means a feature is network/subscription dependent and may not be available in all areas. Contact your service provider for more information.

This means a feature requires an optional accessory.

to scroll to a menu feature.

to select the highlighted menu

essentials

SIM card

Caution:

from static electricity, water, and dirt.

Your Subscriber Identity Module (SIM) card contains personal information like your phone number and phonebook entries.

Don’t bend or scratch your SIM card. Keep it away

battery

battery installation

essentials

battery charging

New batteries are not fully charged. Plug the battery charger into your phone and an electrical outlet. Your phone might take several seconds to start charging the battery. Your display shows when finished.

Tip:

Relax, you can’t overcharge your battery. It will perform

best after you fully charge and discharge it a few times.

Your phone has a light just below the external display that can pulse when you charge your battery. To turn this light on or off, see page 31.

You can charge your battery by connecting a cable from your phone's mini-USB port to a USB port on a computer. Both your phone and the computer must be turned on, and your computer must have the correct software drivers installed. Cables and software drivers are available in Motorola Original data kits, sold separately.

Charge Complete

essentials

battery tips

Battery life depends on the network, signal strength, temperature, features, and accessories you use.

•

Always use Motorola Original batteries and chargers. The warranty does not cover damage caused by non-Motorola batteries and/or chargers.

•

New batteries or batteries stored for a long time may take more time to charge.

•

When charging your battery, keep it near room temperature.

•

When storing your battery, keep it uncharged in a cool, dark, dry place, such as a refrigerator.

•

Never expose batteries to temperatures below -10°C (14°F) or above 45°C (113°F). Always take your phone with you when you leave your vehicle.

•

It is normal for batteries to gradually wear down and require longer charging times. If you notice a change in your battery life, it is probably time to purchase a new battery.

Contact your local recycling center for proper battery

032375o

disposal.

Warning:

may explode.

Before using your phone, read the battery safety information in the “Safety and General Information” section included in the gray-edged pages at the back of this guide.

Never dispose of batteries in a fire because they

essentials

turn it on & off

Caution:

when you turn them on. If you enter an incorrect PIN code 3 times in a row, your SIM card is disabled and your display shows

To turn on your phone, press and hold for a few seconds or until the display turns on. If prompted, enter your 6-digit SIM card PIN code and/or 4-digit unlock code.

To turn off your phone, press and hold

Some phones ask for your SIM card PIN code

SIM Blocked

. Contact your service provider.

for 2 seconds.

make a call

Enter a phone number and press U to make a call.

To “hang up,” close the flip or press

answer a call

When your phone rings and/or vibrates, just open the flip or press

to answer.

To “hang up,” close the flip or press

store a phone number

You can store a phone number in your

Enter a phone number in the home screen.

Press the

Store

key.

Phonebook

essentials

Enter a name and other details for the phone number. To select a highlighted item, press the center key

Note:

You can store a phonebook entry on your phone or

on your SIM card. In the entry, select

Phone

SIM

. Entries stored on the SIM card can only

include name and number details.

Press the

Done

key to store the number.

Store To

and choose

To edit or delete a To store an email address, press

press

M>New>Email Address

Phonebook

entry, see page 44.

M >n Phonebook

, then

call a stored phone number

Find it: M >

Scroll to the phonebook entry.

Shortcut:

the first letters of an entry name, then press the to jump to the entry.

Press U to call the entry.

n Phonebook

In the phonebook, press keypad keys to enter

your phone number

From the home screen, press

Tip:

Want to see your phone number while you’re on a call?

Press

M>My Tel. Numbers

You can edit the name and phone number stored on your SIM card. From the home screen, press select an entry, and press the phone number, contact your service provider.

essentials

to see your number.

Edit

key. If you don’t know your

key

main attractions

You can do much more with your phone than make and receive calls!

play videos

Find it:

The video clip plays:

To download a video with the micro-browser, see page 60. You can also attach videos to multimedia messages.

Press M>

Press S up to pause or play the video.

Press S

down to stop

the video.

Return to previous screen.

h Multimedia >Videos

VIDEO

CLIP

AREA

Video Clip Name

Playing...

Back Details

main attractions

> video name

Status

View video details.

Press M to open Videos Menu.

multimedia messages

To create a group mailing list, see page 47. For more message features, see page 48.

send a multimedia message

A Multimedia Messaging Service (MMS) message contains pages with text and media objects (including pictures, animations, or sounds). You can send the multimedia message to other MMS-capable phones, and to email addresses.

Find it:

Press R >

Create Message >New Multimedia Msg

Press keypad keys to enter text on the page (for details about text entry, see page 22).

To insert a press

To insert

picture, sound, or other object

M>Insert

. Select the file type and the file.

another page

in the message, enter text or

on the page,

objects on the current page and press

M>Insert>New Page

. You can enter more text and objects

on the new page.

When you finish the message, press the

Choose one or more people for

To select a press the center key

phonebook entry

. Repeat to add other phonebook

Send To

, scroll to the entry and

Send To

entries.

main attractions

key.

[New Number]

center key

enter

a new number or email address, scroll to

[New Email Address]

send

the message, press the

and press the

Send

key.

Before you send a message, press

Save to Drafts, Abort Message

message

Subject

, or open

or CC addresses).

to choose

Message Options

(such as

receive a multimedia message

When you receive a multimedia message or letter, your phone plays an alert and the display shows with a message indicator such as

Press the

If a multimedia message contains media objects:

Read

key to open the message.

•

Photos, pictures, and animations show as you read the message.

•

A sound file plays when its slide shows. Use the volume keys to adjust the sound volume.

Note:

In a multimedia letter, you may have to scroll to

an indicator in the text to play a sound file.

•

Attached files are added to the end of the message. To open an attachment, scroll to the file indicator/filename and press the

Open

key (phonebook vCard, datebook vCalendar entry,

or unknown file type).

View

key (image),

New Message

Play

key (sound), or

main attractions

cable connections

Your phone has a

mini-USB port so you can connect it to a computer to transfer data.

You can use data cables and supporting software on your computer to:

•

Synchronize phonebook and datebook information between your phone and a computer or hand-held device.

•

Use your phone as a modem to connect to the Internet.

•

Use your phone to send and receive data calls from your computer or handheld device.

Note:

Motorola Original USB data cables and supporting software are sold separately. Check your computer or hand-held device to determine the type of cable you need. To between your phone and computer, you must install the software included with the Motorola Original data kit. See the data kit user’s guide for more information. To make

and fax calls

through a connected computer, see page 56.

transfer data

data

main attractions

basics

See page 1 for a basic phone diagram.

display

The home screen shows when you turn on the phone. To dial a number from the home screen, press number keys and

Note:

Your home screen may look different from the one

below, depending on your service provider.

Date

Clock

Service Provider

12/31/05

12:00

Styles Settings

Right Soft Key LabelLeft Soft Key Label

Menu Indicator

The Menu Indicator the menu. Soft Key Labels show the current soft key functions. For soft key locations, see page 1.

shows that you can press M to open

basics

Status indicators can show at the top of the home screen:

Signal

Strength

Service Provider

Battery

Level

12/31/05

GPRS

Data

Roam

Active Line

12:00

Styles Settings

Ring Style

Message

Messaging

Presence

1 Signal Strength Indicator –

strength of the network connection. You can’t make or receive calls when

2 GPRS Indicator –

a high-speed General Packet Radio Service (GPRS) network connection. Indicators show PDP context active

or packet data available +.

3Data Indicator –

= secure packet data

transfer

= secure application

connection

= secure Circuit Switch

Data (CSD) call

basics

or ) shows.

Shows when your phone is using

Shows connection status.

Vertical bars show the

= unsecure packet data

transfer

= unsecure application

connection

= unsecure CSD call

4 Roam Indicator –

Shows when your phone is seeking or using a network outside your home network. Indicators can include:

= 2G home

= 2.5G home

;

= 2G roam

= 2.5G roam

5 Active Line Indicator –

active call, or

to indicate when call forwarding is

Shows ? to indicate an

on. Indicators for dual-line-enabled SIM cards can include:

= line 1 active

= line 2 active

6 Messaging Presence Indicator –

= line 1 active, call forward on

= line 2 active, call forward on

Shows when Instant Messaging (IM) is active. Indicators can include:

= IM active

= busy

= available for phone

= available for IM

= invisible to IM

= offline

calls

When a Java™ application is active,

7 Message Indicator –

Shows when you receive a

can show here.

new message. Indicators can include:

= text message

= voicemail & text message

= IM message

= voicemail message

= active chat session

basics

8 Ring Style Indicator –

= loud ring

= soft ring

= vibrate

Shows the ring style setting.

= vibrate then ring

= silent

9 Battery Level Indicator –

Vertical bars show the battery charge level. Recharge the battery when your phone shows

Low Battery

menus

From the home screen, press M to enter the main menu.

Currently

Highlighted

Menu Feature

Exit the main

Scroll up, down,

Press center to

menu feature.

Icon

menu.

left, or right.

select

highlighted

Games & Apps

Exit Select

Select highlighted menu feature.

Exit menu without making changes.

basics

The following menu icons may be available, depending on your service provider and service subscription options.

menu features

n Phonebook á Web Access s Recent Calls h Multimedia e Messages ã IM É Tools w Settings Q Games & Apps K Chat

Note:

Yo u r Instant Messaging (IM) menu icon may be different from the icon in the table, depending on your service provider.

Some features require you to select an option from a list:

Highlighted

Option

Press Back key

to go back to

screen.

Dialed Calls

10) John Smith

9) Lisa Owens

8) Adda Thomas

7) Jack Bradshaw

6) Mary Smith

5) Carlos Emrys

4) Dave Thompson

3) Lisa Owens

Back View

Press

Press to scroll down to other options.

Press View key to view details of highlighted option.

open sub-menu

•

Scroll up or down to scroll to the option you want.

•

In a numbered list, press a number key to highlight an

option.

basics

•

In an alphabetized list, press a key repeatedly to cycle through its letters and highlight the closest matching list option.

•

When an option has a list of possible settings, scroll left or right to select the setting.

•

When an option has a list of possible numeric values, press a number key to set the value.

text entry

Some features let you enter text.

For indicator

descriptions,

see following

section.

ìh

Msg

450

Press open submenu.

Flashing

indicates

insertion

Press

entry modes

in a text entry view to select an entry mode:

or gYo u r

basics

cursor

point.

iTAP®

After you

Cancel Send To

enter text, press the Send To key to enter

Press the Cancel

key to

exit

recipients.

without making changes.

Primary

text entry mode can be set to any

or tapg mode.

entry modes

or mYo u r

è Numeric

[ Symbol

To set your primary and secondary text entry modes, press

M>Entry Setup

Secondary Setup

Tip:

WANT TO SHOUT YOUR MESSAGE? Press 0 in a text entry view to change text case to all capital letters ( letter capital (

Secondary

text entry mode can be set to any

iTAP

or tapm mode, or set to

want a secondary entry mode.

mode enters numbers only.

mode enters symbols only.

in a text entry view and select

), or no capitals (í).

None

if you don’t

Primary Setup

), next

iTAP® mode

Press # in a text entry view to switch to iTAP mode. If you don’t see your primary or secondary text entry mode.

iTAP mode lets you enter words using one keypress per letter. The iTAP software combines your keypresses into common words, and predicts each word as you enter it.

or p, press M>

Entry Setup

to set iTAP mode as

basics

For example, if you press

7764

, your display shows:

Press

Msg Prog ram

up to accept

443

Program.

Press to highlight

Press the Delete

key to delete

the last letter.

Prog Proh

Delete Select

Press the Select key to lock the highlighted

another combination. Press * to enter Prog and a space.

combination.

•

If you want a different word (such as

Progress

pressing keypad keys to enter the remaining letters.

•

To enter numbers quickly, press and hold a number key to temporarily switch to numeric mode. Press the number keys to enter the numbers you want. Enter a space to change back to iTAP mode.

•

Press 1 to enter punctuation or other characters.

right

), continue

tap mode

Press # in a text entry view to switch to tap mode. If you don’t see your primary or secondary text entry mode.

ìg

or ìm, press M>

basics

Entry Setup

to set tap mode as

To enter text in tap mode, press a keypad key repeatedly to cycle through the letters and number on the key. Repeat this step to enter each letter.

For example, if you press

one time, your display shows:

Character

displays at

insertion point.

Press the Delete

íg

Msg T

Delete Send To

key to

character to left of insertion

delete

point.

After 2 seconds,

449

character is accepted and cursor moves to next position.

After you enter text, press the Send To key to enter recipients.

basics

When you enter three or more characters in a row, your phone may guess the rest of the word. For example, if you enter

prog

your display might show:

Character

displays at

insertion point.

íg

Msg Prog ram

Press S

445

right to accept Program, or press * to reject it and enter a space after Prog.

Delete Send To

•

The first character of every sentence is capitalized. If necessary, press

down to change the character to lowercase before the cursor moves to the next position.

•

Press S to move the flashing cursor to enter or edit message text.

•

If you don’t want to save your text or text edits, press

to exit without saving.

•

Tap extended mode cycles through additional special characters and symbols as you repeatedly press a keypad key.

numeric mode

Press # in a text entry view until you see è. Press the number keys to enter the numbers you want.

basics

symbol mode

Press # in a text entry view until you see [. Press a keypad key to show its symbols at the bottom of the display. Scroll to the symbol you want, then press the center key

volume

Press the volume keys to:

•

turn off an incoming call alert

•

change the earpiece volume during calls

•

change the ringer volume from the home screen

Tip:

Sometimes silence really is golden. That’s why you can quickly set your ringer to holding the down volume key in the home screen.

To change your ringer volume when your phone is closed, see page 28.

Vibrate

Silent

navigation key

Press the navigation keyS up, down, left, or right to scroll to items in the display. When you scroll to something, press the center key

to select it.

basics

external display

When your phone is closed, the external display shows the time and indicates phone status, incoming calls, and other events. For a list of phone status indicators, see page 18.

handsfree speaker

You can use your phone’s handsfree speaker to make calls without holding the phone to your ear.

During a call, press the speaker on. Your display shows or end the call.

Note:

The handsfree speaker won’t work when your phone is

connected to a handsfree car kit or headset.

Speaker

key to turn the handsfree

Spkrphone On

until you turn it off

codes & passwords

Your phone’s 4-digit The 6-digit service provider didn’t change these codes, you should change them:

Find it:

You can also change your

If you forget your unlock code:

try entering 1234 or the last four digits of your phone number. If that doesn’t work, press security code instead.

security code

Press M >

basics

unlock code

w Settings >Security >New Passwords

is originally set to

SIM PIN

password.

At the

Enter Unlock Code

and enter your 6-digit

000000

1234

. If your

prompt,

If you forget other codes:

SIM PIN code, or PIN2 code, contact your service provider.

If you forget your security code,

lock & unlock phone

You can lock your phone to keep others from using it. To lock or unlock your phone, you need the 4-digit unlock code.

manually lock

Phone Lock >Lock Now

automatically lock

Press

M>w Settings >Security >Phone Lock >Automatic Lock >On

Note:

You can make emergency calls on a locked phone (see

page 37). A locked phone still rings or vibrates for incoming calls or messages,

your phone: PressM>

your phone whenever you turn it off:

but you need to unlock it to answer

w Settings>Security

basics

customize

ring style

Each ring style profile uses a different set of sounds or vibrations for incoming calls and other events. Here are the profiles you can choose:

y Loud | Vibrate Ò Silent z Soft Ó Vibe then Ring

The ring style profile’s indicator shows at the top of your home screen. To choose your profile:

Find it:

Press M >

t Ring Styles >Style:

style name

Shortcut:

down to quickly change your ring style profile. With your

phone closed

profile, press the smart key to change it, then press a volume key to store the change.

In the

home screen

, press a volume key to see your ring style

, press the volume keys up or

change alerts in a ring style

You can change the alerts for incoming calls and other events. Your changes are saved in the current ring style profile.

Find it:

Note:

alert for the

Press M >

Style represents the current ring style. You can’t set an

Silent

customize

t Ring Styles

ring style setting.

> style

Detail

Scroll to press the

Scroll to the alert you want, then press the

center key

Press the

Tip:

If you want a ring that sets you apart, you can use an

MP3 sound file. To download files, see page 60.

Calls

(or

Line 1

Line 2

for dual-line phones), then

Change

key to change it.

Back

key to save the alert setting.

ring & event lights

Your phone has a light just below the external display that can pulse for incoming calls or messages, or while you charge your battery.

To set the light for your

M>t Ring Styles >Ring Lights

You can also turn the ring light on or off for calls from phonebook entries in a

To set the light for your

charging

, press M>

incoming calls

time & date

Your phone needs the time and date for the datebook.

synchronize

Press

M>w Settings >Initial Setup >Time and Date >Autoupdate

the time and date with the network:

customize

manually

Press

To choose an press

set the time and date, turn off

M>w Settings >Initial Setup >Time and Date

analog or digital

M>w Settings >Personalize >Home Screen >Display >Clock

clock for your home screen,

Autoupdate

, then:

> time or date.

wallpaper

Set a photo, picture, or animation as a wallpaper (background) image in your home screen.

Find it:

options


Layout

Press M>

Press S up or down to select a picture, or select

Select to repeat the image across the display, or

Fit-to-screen

w Settings >Personalize >Wallpaper

None

for no wallpaper.

Center

to center the image in the display,

to stretch the image across the display.

Tile

screen saver

Set a photo, picture, or animation as a screen saver. The screen saver shows when the flip is open and no activity is detected for a specified time.

Tip:

This feature helps save your screen, but not your battery.

To extend battery life, turn off the screen saver.

Find it:

Press M>

customize

w Settings >Personalize >Screen Saver

options


Delay

Press S up or down to select a picture or animation, or select

Select the length of inactivity before the screen saver shows.

None

display appearance

for no screen saver.

To choose the highlights, and soft key labels: Press >

Personalize >Color Style

To save battery life, your keypad you’re not using your phone. The backlight turns back on when you open the flip or press any key. To set how long your phone waits before the backlight turns off:

Press

M>w Settings >Initial Setup >Backlight

Note:

To turn the backlight on or off for Java™ applications,

press

M>w Settings >Java Settings >App Backlight

To save battery life, the using your phone. The display turns back on when you open the flip or press any key. To set how long your phone waits before the display turns off:

Press

M>w Settings >Initial Setup >Display Timeout

colors

that your phone uses for indicators,

M>w Settings

display

backlight

can turn off when you’re not

turns off when

customize

answer options

You can use different ways to answer an incoming call. To turn on or turn off an answer option:

Find it:

Press M>

options

Multi-Key Open to Answer

w Settings >In-Call Setup >Answer Options

Answer by pressing any key. Answer by opening the flip.

customize

calls

To make and answer calls, see page 11.

turn off a call alert

You can press the volume keys to turn off a call alert before answering the call.

recent calls

Your phone keeps lists of incoming and outgoing calls, even for calls that didn’t connect. The most recent calls are listed first. The oldest calls are deleted as new calls are added.

Shortcut:

recent calls.

Press U from the home screen to see a list of

Find it:

Scroll to a call. A % next to a call means the call connected.

Press M>

•

To call the number, press U.

•

To see call details (like time and date), press the

center key

•

To see the include:

s Recent Calls >Received CallsorDialed Calls

Last Calls Menu

, press M. This menu can

calls

options

Store

Create a phonebook entry with the number in the

No.

field.

Store

does not

appear if the number is already stored.

Delete

Delete All Hide ID/Show ID

Delete the entry. Delete all entries in the list. Hide or show your caller ID for the next

call.

Send Message

Add Digits Attach Number

Open a new text message with the number in the

field. Add digits after the number. Attach a number from the phonebook or

recent calls lists.

Send Tones

Send the number to the network as DTMF tones.

This option shows only during a call.

Talk then Fax

Talk and then send a fax in the same call (see page 56).

redial

Press U from the home screen to see a list of recent calls.

Scroll to the entry you want to call, then press U.

If you hear a

Call Failed, Number Busy

redial the number. When the call goes through, your phone

busy signal

and you see

, you can press U or the

Retry

key to

calls

rings or vibrates one time, shows the call.

Redial Successful

, and connects

return a call

Your phone keeps a record of your unanswered calls, and shows

X Missed Calls

Press the

Scroll to the call you want to return, then press U.

, where X is the number of missed calls.

View

key to see the received calls list.

caller ID

Calling line identification (caller ID) shows the phone number for an incoming call in your external and internal displays.

Your phone shows the caller’s name and picture when they’re stored in your phonebook, or information isn’t available.

You can set your phone to play a different ringer ID for an entry stored in your phonebook (see page 45).

To show or hide you call, enter the phone number and press

M>Hide ID/Show ID

your phone number

Incoming Call

from the next person

when caller ID

emergency calls

Your service provider programs one or more emergency phone numbers, such as 911 or 112, that you can call under

calls

any circumstances, even when your phone is locked or the SIM card is not inserted.

Note:

Emergency numbers vary by country. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

Press the keypad keys to dial the emergency number.

Press U to call the emergency number.

voicemail

Your network stores the voicemail messages you receive. To listen to your messages, call your voicemail number.

Note:

Your service provider may include additional information about using this feature.

When you the voicemail message indicator the

check

Find it:

Your phone may prompt you to store your voicemail phone number. If you don’t know your voicemail number, contact your service provider.

Note:

character in this number. If you want to store a voicemail number with these characters, create a phonebook entry for it. Then, you can use the entry to call your voicemail.

receive

a voicemail message, your phone shows

and

New Voicemail

Call

key to listen to the message.

voicemail messages:

Press R >

Voicemail

You can’t store a p (pause), w (wait), or n (number)

. Press

calls

other features

advanced calling

features 1-touch dial

To call phonebook entries 1 through 9, press and hold the single-digit speed dial number for one second.

You can set 1-touch dial to call the entries in your phone’s memory phonebook, your SIM card’s phonebook, or your Fixed Dial list: Press

M>w Settings >Initial Setup >1-Touch Dial

Phone,SIM

To add a new phonebook entry, see page 11. To edit the phonebook entry, press

M>n Phonebook

press

,or

M>Edit

Fixed Dial

Speed No.

for a

, scroll to the entry, and

other features

features speed dial

attach a phone number

notepad

Speed dial a phonebook entry:

Enter the speed dial number, press

, then press U.

To add a phonebook entry, see page 11.

Tip:

If you forget Aunt Mildred’s speed

dial number, press

M>n Phonebook

scroll to her entry, and press the

center key

Dial an area code or prefix for a phonebook number, then:

M >Attach Number

The last number you entered is stored in the notepad. You can use the notepad to “jot down” a number during a call for later use. To see the notepad:

Press

M>s Recent Calls >Notepad

•

To call the number, press U.

•

To create a phonebook entry with the number in the the

Store

key.

•

To open the

No.

Dialing Menu

field, press

to attach a number or insert a special character, press

other features

features international

calls

hold a call

mute a call

call waiting

conference call

If your phone service includes international dialing, press and hold

to insert your local international

access code (indicated by

). Then, press the keypad keys to dial the country code and phone number.

Press M>

Hold

to put all active calls on

hold. Press M>

Mute

to put all active calls on

mute. When you’re on a call, you’ll hear

an alert if you receive a second call.

Press

to answer the new call.

•

To switch between calls, press the

Switch

key.

•

To connect the two calls, press the

Link

key.

•

To end the call on hold, press

M>End Call On Hold

To turn the call waiting feature on or off, press

M>w Settings >In-Call Setup

Call Waiting >OnorOff

During a call:

Dial next number, press the

Link

key.

, press

other features

features transfer a call

call forwarding

restrict calls

call barring

TTY calls

change phone line

During a call:

M >Transfer

press

, dial transfer number,

Set up or cancel call forwarding:

M>w Settings >Call Forward

Restrict outgoing or incoming calls:

M>w Settings >Security >Restrict Calls

Restrict outgoing or incoming calls:

M>w Settings >Security >Call Barring

Set up your phone for use with an optional TTY device:

M>w Settings >Initial Setup >TTY Setup

If you have a dual-line-enabled SIM card, you can change your line to make and receive calls from your other phone number.

M>w Settings >Phone Status >Active Line

The active line indicator shows the active phone line (see page 19).

other features

features fixed dial

quick dial

DTMF tones

When you turn on fixed dialing, you can call only numbers stored in the fixed dial list.

Turn fixed dialing on or off:

M>w Settings >Security >Fixed Dial

Use the fixed dial list:

M>É Tools >Dialing Services >Fixed Dial

Dial preprogrammed phone numbers:

M>É Tools >Dialing Services >Quick Dial

Activate DTMF tones:

M>w Settings >Initial Setup >DTMF

To send DTMF tones during a call, just press number keys or scroll to a number in the phonebook or recent calls lists and press

M>Send Tones

other features

phonebook

features edit or delete a

phonebook entry

Edit a number stored in the phonebook:

M >n Phonebook

phonebook entry, and press select

Edit, Delete

, scroll to the

, or other options.

. You can

record voice name for a phonebook entry

other features

Shortcut:

keypad keys to enter the first letters of an entry name, then press the to jump to the entry.

When creating a phonebook entry, scroll to

Voice Name

Press the entry’s name (within 2 seconds). When prompted, press the the name.

Note:

in entries stored on the SIM card.

In the phonebook, press

and press the

Record

key again and say the

Record

The

Voice Name

option isn’t available

key

Record

key.

key and repeat

features voice dial a

phonebook entry

set ringer ID for a phonebook entry

set picture ID for a phonebook entry

Voice dial a number stored in the phonebook:

M>É Tools >Dialing Services >Voice Dial

When prompted, say the entry’s voice name (within 2 seconds).

Tip:

If you use create a shortcut to it. Scroll to then press and hold shortcut, press

Voice Dial

a lot, you can

Voice Dial

. To use the

and the shortcut key

number. Assign a ring alert (ringer ID) to an entry:

M>n Phonebook M>Edit >Ringer ID

Note:

The

> entry, then press

> ringer name

Ringer ID

option isn’t available in

entries stored on the SIM card.

Activate ringer IDs:

M >t Ring Styles

> style

Detail >Ringer IDs

Assign a photo or picture to show when you receive a call from an entry:

M>n Phonebook M>Edit >Picture

> entry, then press

> picture name

Note:

The


option isn’t available in

entries stored on the SIM card.

other features

features set picture ID

view for phonebook

set category for a phonebook entry

set category view for phonebook

set light ID for phonebook category

Show entries as a text list, or with picture caller ID photos:

M>n Phonebook M>Setup>View by

M>n Phonebook M>Edit>Category

Note:

The

, then press

> view name

> entry, then press

> category name

messages

For basic multimedia message features, see page 14.

features send text

message send voice

message

R >Create Message >New Short Msg

R >Create Message >New Voice Msg

To record the voice message, press the

Record

key, speak, then press the key. Your phone inserts the voice recording into a message and lets you enter email addresses or phone numbers to receive the message.

Name

Stop

other features

features use a

multimedia template

read and manage messages

Open a multimedia message with preloaded animations:

R >Create Message >MMS Templates R >Message Inbox

Icons next to each message indicate if it is read

or unread<. Icons can also indicate if the message is locked

, urgent!, low priority↓, or has

an attachment

store message objects

store text messages on your SIM card

browser messages

To see message options like

Lock

, or

Delete

, scroll to a message and

press

Reply, Forward

Go to a multimedia message page, or scroll to an object in a message, then:

M>Store

To store incoming text messages on your SIM card, press:

M>e Messages

, then press

M>Message Setup >Text Msg Setup >Store To

SIM

Inbox Setup >Text Msg Setup >Store To

Read messages received by your micro-browser:

R >Browser Msgs

other features

features info services

Read subscription-based information services messages:

R >Info Services

instant messaging

features log in

M>ã IM >Log In

add contacts

find others online

start conversation

open active conversation

end conversation

log out

other features

After you log in:

Select

Contact List>Add Contact

enter the contact’s IM ID and nickname. After you log in:

Select

Contact List

others online. From your

name in

Send IM

key.

From your name in key.

From the conversation view:

M>End Conversation

Select

Log Out

menu.

to see a list of

Contact List

Online Contacts

Contact List

Conversations

from the

, press the

and

, scroll to a

, press the

, scroll to a

IM Online

View

features create or

change IM accounts

hide your online status

block contacts

set alerts for contacts

set IM ring style

M>ã IM >IM Account

Select an IM account, or select

New

to create a new IM account.

M>ã IM >Offline Settings

Turn on login whenever you select on

Auto-Login

Power-On Login

to start the IM

M>IM

to start the IM login

. Turn

whenever you turn on your phone. When you log in, other users can

see you are status in IM, press >

AwayorInvisible

Online

. To change your

M>My Status

To block instant messages from a contact, scroll to the contact in the

Contact List

and press M>

Block Contact

. You must be online to block a contact. Blocked contacts will not appear in your

Contact List

When a special contact comes online, your phone can ring or vibrate. Scroll to the contact in the

Contact List

and press M>

Set Online Alert

Select a ring or vibration for new IM messages and contact alerts.

M >t Ring Styles

> style

Detail >IM

other features

chat

features start chat

receive chat request

end chat

M>É Tools >Chat

press Press the

During a chat session:

M>End Chat

personalizing

features language

scroll

activate ringer IDs

Set menu language:

M>w Settings >Initial Setup >Language

Set the scroll bar to stop or wrap around in menu lists:

M>w Settings >Initial Setup >Scroll

Activate ringer IDs assigned to phonebook entries and categories:

M>New Chat

key or the

, then

Ignore

key.

ring volume

keypad volume

other features

M >t Ring Styles

Press M > >

Ring Volume

Press M > >

Key Volume

t Ring Styles

> style

Detail >Ringer IDs

> style

Detail

features reminders

menu view

main menu

show/hide menu icons

change home keys

Set reminder alerts for messages that you receive:

Press

M >t Ring Styles

Reminders

> style

Detail

Show the main menu as graphic icons or as a text-based list:

M>w Settings >Personalize >Main Menu

View

Reorder your phone’s main menu:

M>w Settings >Personalize >Main Menu

Reorder

Show or hide menu feature icons in the home screen:

M>w Settings >Personalize >Home Screen

Home Keys >Icons

Change the features for the soft keys and navigation key in the home screen:

shortcuts

M>w Settings>Personalize >Home Screen

Home Keys

Create a shortcut to a menu item:

Scroll to the menu item, then press and hold

Use a shortcut:

Press

, then press the shortcut

number.

other features

features master reset

master clear Caution:

Reset all options security code, and lifetime timer:

M>w Settings >Initial Setup >Master Reset

Master clear

information you have entered

(including phonebook and datebook entries)

downloaded

sounds) stored in your phone’s memory. After you erase the information, you can’t recover it.

M>w Settings >Initial Setup >Master Clear

and content you have

call times & costs

except

unlock code,

erases all

(including photos and

Network connection time

moment you connect to your service provider's network to the moment you end the call by pressing includes busy signals and ringing.

The amount of network connection time you track on your resettable timer may not equal the amount of time for which you are billed by your service provider. For billing information, contact your service provider.

features call times

other features

Show call timers:

M>s Recent Calls >Call Times

is the elapsed time from the

. This time

features in-call timer

call cost

Show time or cost information during a call:

M>w Settings >In-Call Setup >In-Call Timer

Show call cost trackers:

M>s Recent Calls >Call Cost

handsfree

Note:

The use of wireless devices and their accessories may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products.

features speakerphone

Activate the speakerphone during a call:

auto answer

(car kit or headset)

voice dial

(headset)

auto handsfree

(car kit)

Press the

M>Spkrphone On

Automatically answer calls when connected to a car kit or headset:

M>w Settings >Car Settings

Auto Answer

Enable voice dial with headset send/end key:

M>w Settings >Headset >Voice Dial

Automatically route calls to a car kit when connected:

M>w Settings >Car Settings >Auto Handsfree

Speaker

key (if available, or

other features

Headset

features power-off

delay

(car kit)

charger time

(car kit)

Set the phone to stay on for a specified time after the ignition is switched off:

M >w Settings >Car Settings >Power-Off Delay

Charge the phone for a specified time after the ignition is switched off:

M>w Settings >Car Settings >Charger Time

data & fax calls

To connect your phone with a USB cable, see page 16.

features send data or

fax

receive data or fax

talk then fax

Connect your phone to the device, then place the call through the device application.

Connect your phone to the device, then answer the call through the device application.

Connect your phone to the device, enter fax number, press

M>Talk then Fax

the call.

, then press U to make

other features

features using sync

You can call an Internet server and synchronize your phonebook and datebook entries with the server.

set up

an Internet sync partner, press

M>w Settings >Sync >[New Entry]

the server details, including can omit below the URL where your data is stored).

To set up, select the partner from the list in

M>w Settings >Sync

http://

synchronize files

network

features network

settings

See network information and adjust network settings:

M>w Settings >Network

personal organizer

) and

Data Path

with a partner you

. Enter

Server URL

(the folder

(you

features set alarm

M>É Tools >Alarm Clock

other features

features turn off alarm

add new datebook event

see datebook event

event reminder

calculator currency

converter

When an alarm happens: To turn off the alarm, press the or

. To set an 8 minute delay, press

the

Snooze

key.

M>É Tools >Datebook

press

, press M>

, scroll to the day,

New

Disable

See or edit event details:

M>É Tools >Datebook

press

, press the

, scroll to the day,

View

key

When an event reminder happens: To see reminder details, press the

View

key. To close the reminder, press the

Exit

key.

M>É Tools >Calculator M >É Tools >Calculator

, then press

M>Exchange Rate

Enter exchange rate, press the OKkey, enter amount, and press

M>Convert Currency

key

other features

security

features SIM PIN Caution:

code 3 times in a row, your SIM card is disabled and your display shows

SIM Blocked

Lock or unlock the SIM card:

M>w Settings >Security >SIM PIN

lock feature manage

certificates

M>w Settings >Security >Lock Application

Enable or disable Internet access certificates stored on your phone:

M>w Settings >Security >Certificate Mgmt

Certificates are used to verify the identity and security of Web sites when you download files or share information.

If you enter an incorrect PIN

fun & games

Note:

A lock (9) icon next to a picture, sound, or other object means that you cannot send or copy it.

features view, delete,

or manage pictures

Manage photos, pictures, and animations:

M>h Multimedia >Pictures

other features

features view, delete,

or manage video clips

hear, delete, or manage sounds

create ring tones

start micro-browser

download objects from Web page

Web sessions

M>h Multimedia >Videos

Manage ring tones and music that you have downloaded or composed:

M>h Multimedia >Sounds

Create ring tones that you can use with your phone:

M>h Multimedia >Sounds >[New iMelody]

Just press L.

Download a picture, sound, or other object from a Web page:

Press

, go to the page that links to the

file, scroll to the link, and select it.

Note:

Normal airtime and/or carrier

usage charges apply. A Web Session stores settings that

your phone uses to access the Internet. To select or create a Web session:

M>á Web Access >Web Sessions

other features

features download

game or application

start game or application

You can download a Java™ game or application the same way you download pictures or other objects:

Press

, go to the page that links to the

file, scroll to the link, and select it.

Note:

Normal airtime and/or carrier

usage charges apply. Start a Java™ game or application:

M>Q Games & Apps

, scroll to the

game or application, press the

center key

other features

service and repairs

If you have questions or need assistance, we're here to help.

Go to

www.motorola.com/consumer/support

can select from a number of customer care options. You can also contact the Motorola Customer Support Center at 1-800-331-6456 (United States), 1-888-390-6456 (TTY/TDD United States for hearing impaired), or 1-800-461-4575 (Canada).

, where you

service and repairs

Specific Absorption Rate Data

SAR Data

This model wireless phone meets the government’s requirements for exposure to radio waves.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government and by the Canadian regulatory authorities. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age or health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC and by the Canadian regulatory authorities is

1.6 W/kg. accepted by the FCC and by Industry Canada with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station, the lower the power output.

Before a phone model is available for sale to the public in the U.S. and Canada, it must be tested and certified to the FCC and Industry Canada that it does not exceed the limit established by each government for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) reported to the FCC and available for review by Industry Canada. The highest SAR value for this model phone when tested

Tests for SAR are conducted using standard operating positions

SAR Data

for use at the ear is 1.39 W/kg , and when worn on the body, as described in this user guide, is 0.43 W/kg. The SAR value for this product in its data transmission mode (body-worn use) is 0.65 W/kg. (Body-worn measurements differ among phone models, depending upon available accessories and regulatory requirements).

While there may be differences between the SAR levels of various phones and at various positions, they all meet the governmental requirements for safe exposure. Please note that improvements to this product model could cause differences in the SAR value for later products; in all cases, products are designed to be within the guidelines.

Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications & Internet Association (CTIA) Web site:

http://www.phonefacts.net

or the Canadian Wireless Telecommunications Association (CWTA) Web site:

http://www.cwta.ca

1. In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

2. The SAR information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product.

SAR Data

index

accessories 5, 55 accessory connector port 1 active line indicator 18 active line, changing 42 alarm clock 57, 58 alert

lights 30 set 26, 29

turn off 26, 34 animation 59 answer a call 9, 32 attach a number 35, 40

backlight 32 battery 6, 7 battery indicator 19 battery life, extending 8,

31, 32 browser messages 49 browser. See micro-browser

cables 15 calculator 58 call

answer 9, 32 end 9

make 9 call barring 42 call forward indicator 18 call forwarding 42 call timers 54, 55 call waiting 41 caller ID 35, 36, 45 car kit 55 center key 1, 26 center select key 5 certificate management 59 chat 52 clock 30 codes 27, 28 color 32 conference call 41 costs, tracking 55

data call 56 data indicator 17 date, setting 30 datebook 58 dial a phone number 9, 43 dialed calls 34

index

display 16, 32 download media objects

49, 60 drafts folder 14 DTMF tones 35, 43

earpiece volume 26 emergency number 36 end a call 9 end key 1, 9 Enter Unlock Code

message 27 event lights 30 external display 27

fax call 35, 56 fixed dial 43 flip 9, 33 forward calls 42

headset jack 1 hold a call 41 home screen 16, 53

IM 50 IM indicators 18 in-call indicator 18 Incoming Call message 36 information services 50 instant messaging. See IM international access code

iTAP text entry mode 22

Java applications 61 Java indicator 18

keypad 33, 52

games 61 GPRS indicator 17 group mailing list 47

handsfree speaker 27 headset 55

index

language 52 light 30 light ID 46 lock

application 59 phone 28 SIM card 59

Low Battery message 19

optional feature 5

make a call 9 master clear 54 master reset 54 menu 5, 19, 52, 53 menu icons 20, 53 menu indicator 16 message 48, 49 message indicator 14, 18 message reminders 53 micro-browser 49, 60, 61 Missed Calls message 36 MMS, defined 13 MP3 sound files 30 multimedia message 13, 49 music 60 mute a call 41

navigation key 1, 5, 26 network settings 57 notepad 40 number. See phone number numeric entry mode 25

1-touch dial 39 open to answer 33 optional accessory 5

passwords. See codes personalize 52 phone number 10, 42 phonebook 35, 39, 40, 44 photo 59 picture 59 picture ID 36, 45 PIN code 9, 27, 59 PIN2 code 27 power key 1, 9

quick dial 43

received calls 34 recent calls 34 redial 35 reminders 53 restrict calls 42 return a call 36 ring lights 30 ring style indicator 19 ring style, setting 26, 29 ring tone 60 ringer ID 36, 45, 52 ringer volume 26, 52 roam indicator 18

index

screen saver 31 security code 27 send key 1, 9 shortcuts 53 signal strength indicator 17 SIM 49 SIM Blocked message 9,

59 SIM card 6, 9, 27, 59 soft keys 1, 16, 53 speakerphone 55 speed dial 40 store your number 10 symbol entry mode 26 synchronizing 57

tap text entry mode 23 telephone number. See

phone number text entry 21 text message 48, 49 time, setting 30 timers 54, 55 transfer a call 42 TTY device 42 turn on/off 9

unlock

application 59 phone 9, 27, 28

SIM card 59 unlock code 27, 28 USB cables 15

video clip 60 videos 12 voice dial 45, 55 voice message 48 voice name, recording 44 voicemail 37 voicemail message indicator

18, 37

volume 26, 52

wallpaper 31 Web pages 60 Web sessions 60

your phone number 10

U.S. patent Re. 34,976

index

IMPORTANT SAFETY AND

LEGAL INFORMATION >

Software Copyright Notice

The Motorola products described in this manual may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Manual Number: 6809497A47-O

A-2

Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Exposure To Radio Frequency (RF) Energy. . . . . . . . . . . . . . . . . . . . . . . . 4

Operational Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

RF Energy Interference/Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Driving Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Operational Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Choking Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Glass Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Seizures/Blackouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Repetitive Motion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

What Does this Warranty Cover? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Who Is Covered? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

What Will Motorola Do? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

How to Obtain Warranty Service or Other Information. . . . . . . . . . . . . 14

What Other Limitations Are There?. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Hearing Aid Compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

WHO Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Product Registration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Export Law Assurances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Wireless: The New Recyclable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Smart Practices While Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Contents

A-3

Safety and General Information

Safety Information

This section contains important information on the safe and efficient operation of your mobile device. Read this information before using your mobile device.

Exposure To Radio Frequency (RF) Energy

Your mobile device contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your mobile device, the system handling your call controls the power level at which your mobile device transmits.

Your Motorola mobile device is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

Operational Precautions

For optimal mobile device performance and to be sure that human exposure to RF energy does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions.

External Antenna Care

If your mobile device has an external antenna, use only a Motorola-supplied or approved replacement antenna. Use of unauthorized antennas, modifications, or attachments could damage the mobile device and/or may result in your device not complying with local regulatory requirements in your country.

* The information provided in this document supersedes the general safety

information in user’s guides published prior to September 1, 2005.

A-4

Safety Information

DO NOT hold the external antenna when the mobile device is IN USE. Holding the external antenna affects call quality and may cause the mobile device to operate at a higher power level than needed.

Product Operation

When placing or receiving a phone call, hold your mobile device just like you would a landline phone.

If you wear the mobile device on your body, always place the mobile device in a Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do not use a body-worn accessory supplied or approved by Motorola, keep the mobile device and its antenna at least 2.5 centimeters (1 inch) from your body when transmitting.

When using any data feature of the mobile device, with or without an accessory cable, position the mobile device and its antenna at least

2.5 centimeters (1 inch) from your body.

Using accessories not supplied or approved by Motorola may cause your mobile device to exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved accessories, visit our website at

www.motorola.com

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances your mobile device may cause interference with other devices.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Safety Information

A-5

Follow Instructions to Avoid Interference Problems

Turn off your mobile device in any location where posted notices instruct you to do so. These locations include hospitals or health care facilities that may be using equipment that is sensitive to external RF energy.

In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your mobile device offers an airplane mode or similar feature, consult airline staff about using it in flight.

Pacemakers

If you have a pacemaker, consult your physician before using this device.

Persons with pacemakers should observe the following precautions:

•

ALWAYS keep the mobile device more than 20 centimeters (8 inches) from your pacemaker when the mobile device is turned ON.

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the pacemaker to minimize the potential for interference.

•

Turn OFF the mobile device immediately if you have any reason to suspect that interference is taking place.

Hearing Aids

Some digital mobile devices may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer or physician to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult your physician or the manufacturer of your device to determine if it is adequately shielded from RF energy.

A-6

Safety Information

Driving Precautions

Check the laws and regulations on the use of mobile devices in the area where you drive. Always obey them.

When using your mobile device while driving, please:

•

Give full attention to driving and to the road. Using a mobile device may be distracting. Discontinue a call if you can’t concentrate on driving.

•

Use handsfree operation, if available.

•

Pull off the road and park before making or answering a call if driving conditions so require.

Responsible driving practices can be found in the “Smart Practices While Driving” section at the end of this guide and/or at the Motorola website:

www.motorola.com/callsmart

Operational Warnings

Obey all posted signs when using mobile devices in public areas, such as health care facilities or blasting areas.

Automobile Air Bags

Do not place a mobile device in the air bag deployment area.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often but not always posted, and can include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

When you are in such an area, turn off your mobile device, and do not remove, install, or charge batteries. In such areas, sparks can occur and cause an explosion or fire.

Safety Information

A-7

Damaged Products

If your mobile device or battery has been submerged in water, punctured, or subjected to a severe fall, do not use it until you take it to a Motorola Authorized Service Center. Do not attempt to dry it with an external heat source, such as a microwave oven.

Batteries and Chargers

If jewelry, keys, beaded chains, or other conductive materials touch exposed battery terminals, this could complete an electrical circuit (short circuit), become very hot, and could cause damage or injury. Be careful when handling a charged battery, particularly when placing it inside a pocket, purse, or other container with metal objects.

Motorola Original ™ batteries and chargers. Caution:

To avoid risk of personal injury, do not dispose of your battery in a

fire.

Your battery, charger, or mobile device may contain symbols, defined as follows:

Symbol Definition

032374o

Important safety information follows.

Use only

A-8

032376o

032375o

Do not dispose of your battery or mobile device in a fire.

Your battery or mobile device may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

032377o

Li Ion BATT

032378o

Do not throw your battery or mobile device in the trash.

Your mobile device contains an internal lithium ion battery.

Safety Information

Choking Hazards

Your mobile device or its accessories may include detachable parts, which may present a choking hazard to small children. Keep your mobile device and its accessories away from small children.

Glass Parts

Some parts of your mobile device may be made of glass. This glass could break if the product is dropped on a hard surface or receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your mobile device until the glass is replaced by a qualified service center.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such as when playing video games. These may occur even if a person has never had a previous seizure or blackout.

If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your physician before playing video games or enabling a flashing-lights feature (if available) on your mobile device.

Discontinue use and consult a physician if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. It is always a good idea to hold the screen away from your eyes, leave the lights on in the room, take a 15-minute break every hour, and stop use if you are very tired.

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you

Safety Information

A-9

continue to have discomfort during or after such use, stop use and see a physician.

A-10

Safety Information

Motorola Limited Warranty for the United States and Canada

Warranty

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc. warrants its telephones, pagers, messaging devices, and consumer and professional two-way radios (excluding commercial, government or industrial radios) that operate via Family Radio Service or General Mobile Radio Service, Motorola-branded or certified accessories sold for use with these Products (“Accessories”) and Motorola software contained on CD-ROMs or other tangible media and sold for use with these Products (“Software”) to be free from defects in materials and workmanship under normal consumer usage for the period(s) outlined below. This limited warranty is a consumer's exclusive remedy, and applies as follows to new Motorola Products, Accessories and Software purchased by consumers in the United States or Canada, which are accompanied by this written warranty:

Products and Accessories

Products Covered Length of Coverage

Products and Accessories

above, unless otherwise provided for below.

Decorative Accessories and Cases.

covers, bezels, PhoneWrap™ covers and cases.

as defined

Decorative

One (1) year

by the first consumer purchaser of the product unless otherwise provided for below.

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

from the date of purchase

for the

Warranty

A-11

Products Covered Length of Coverage

Monaural Headsets.

buds and boom headsets that transmit mono sound

Ear

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

for the

through a wired connection.

Consumer and Professional Two-Way Radio Accessories.

Products and Accessories that are Repaired or Replaced.

Ninety (90) days

purchase by the first consumer purchaser of the product.

The balance of the original warranty or for ninety (90) days

returned to the consumer, whichever is

from the date of

from the date

longer.

Exclusions

Normal Wear and Tear.

Periodic maintenance, repair and replacement of

parts due to normal wear and tear are excluded from coverage.

Batteries.

Only batteries whose fully charged capacity falls below 80% of their rated capacity and batteries that leak are covered by this limited warranty.

Abuse & Misuse.

Defects or damage that result from: (a) improper operation, storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories.

Defects or damage that result from the use of Non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.

A-12

Warranty

Unauthorized Service or Modification.

from service, testing, adjustment, installation, maintenance, alteration, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage.

Altered Products.

tags that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, or parts, are excluded from coverage.

Communication Services.

Accessories or Software due to any communication service or signal you may subscribe to or use with the Products Accessories or Software is excluded from coverage.

Products or Accessories with (a) serial numbers or date

Defects, damages, or the failure of Products,

Defects or damages resulting

Software

Products Covered Length of Coverage

Software.

defects in the media that embodies the copy of the software (e.g. CD-ROM, or floppy disk).

Exclusions

Software Embodied in Physical Media.

software will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be uninterrupted or error free, or that all defects in the software products will be corrected.

Software NOT Embodied in Physical Media.

embodied in physical media (e.g. software that is downloaded from the internet), is provided “as is” and without warranty.

Applies only to physical

Ninety (90) days

date of purchase.

No warranty is made that the

Software that is not

from the

Warranty

A-13

Who Is Covered?

This warranty extends only to the first consumer purchaser, and is not transferable.

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or refund the purchase price of any Products, Accessories or Software that does not conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new Products, Accessories or parts. No data, software or applications added to your Product, Accessory or Software, including but not limited to personal contacts, games and ringer tones, will be reinstalled. To avoid losing such data, software and applications please create a back up prior to requesting service.

How to Obtain Warranty Service or Other Information

USA Phones

1-800-331-6456

Pagers

1-800-548-9954

Two-Way Radios and Messaging Devices

1-800-353-2729

Canada All Products

1-800-461-4575

TTY

For

Accessories

designated above for the product with which they are used.

1-888-390-6456

and

Software

, please call the telephone number

A-14

Warranty

You will receive instructions on how to ship the Products, Accessories or Software, at your expense, to a Motorola Authorized Repair Center. To obtain service, you must include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) the name and location of the installation facility (if applicable) and, most importantly; (e) your address and telephone number.

What Other Limitations Are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or from one jurisdiction to another.

Warranty

A-15

Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted Motorola software such as the exclusive rights to reproduce and distribute copies of the Motorola software. Motorola software may only be copied into, used in, and redistributed with, the Products associated with such Motorola software. No other use, including without limitation disassembly of such Motorola software or exercise of the exclusive rights reserved for Motorola, is permitted.

A-16

Warranty

Hearing Aid Compatibility with Mobile Phones

Hearing Aid Compatibility

Some Motorola phones are measured for compatibility with hearing aids. If the box for your particular model has “Rated for Hearing Aids” printed on it, the following explanation applies.

When some mobile phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate.

The wireless telephone industry has developed ratings for some of their mobile phones, to assist hearing device users in finding phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label on the box.

The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the phone with your hearing device is the best way to evaluate it for your personal needs.

M-Ratings:

to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.

T-Ratings:

be more usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated phones. T4 is the better/higher of the two ratings. (Note that not all hearing devices have telecoils in them.)

Hearing devices may also be measured for immunity to this type of interference. Your hearing device manufacturer or hearing health

Phones rated M3 or M4 meet FCC requirements and are likely

Phones rated T3 or T4 meet FCC requirements and are likely to

Hearing Aid Compatibility

A-17

professional may help you find results for your hearing device. The more immune your hearing aid is, the less likely you are to experience interference noise from mobile phones.

A-18

Hearing Aid Compatibility

Information from the World Health Organization

WHO Informat ion

Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If you are concerned, you may want to limit your own or your children’s RF exposure by limiting the length of calls or by using handsfree devices to keep mobile phones away from your head and body.

Source: WHO Fact Sheet 193

Further information:

http://www.who.int./peh-emf

Product Registration

Online Product Registration:

http://www.motorola.com/warranty

Product registration is an important step toward enjoying your new Motorola product. Registering helps us facilitate warranty service, and permits us to contact you should your product require an update or other service. Registration is for U.S. residents only and is not required for warranty coverage.

Please retain your original dated sales receipt for your records. For warranty service of your Motorola Personal Communications Product you will need to provide a copy of your dated sales receipt to confirm warranty status.

Thank you for choosing a Motorola product.

WHO Information

A-19

Export Law Assurances

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

Wireless: The New Recyclable

Wireless: The New Recyc lable

Your wireless phone can be recycled. Recycling your wireless phone reduces the amount of waste disposed in landfills and allows recycled materials to be incorporated into new products.

The Cellular Telecommunications Industry Association (CTIA) and its members encourage consumers to recycle their phones and have taken steps to promote the collection and environmentally sound recycling of end-of-life wireless devices.

As a wireless phone user, you have an important role in ensuring that this phone is recycled properly. When it comes time to give this phone up or trade it in for a new one, please remember that the phone, the charger, and many of its accessories can be recycled. It's easy. To learn more about CTIA's Recycling Program for Used Wireless Devices, please visit us at

http://promo.motorola.com/recycle/phones/ whyrecycle.html

A-20

Export Law Assurances

Smart Practices While Driving

Smart Practice s While Dri ving

Drive Safe, Call Smart

Check the laws and regulations on the use of mobile devices and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas. Contact www.motorola.com/callsmart for more information.

Your mobile device lets you communicate by voice and data—almost anywhere, anytime, wherever wireless service is available and safe conditions allow. When driving a car, driving is your first responsibility. If you choose to use your mobile device while driving, remember the following tips:

• Get to know your Motorola mobile device and its features such as speed dial and redial.

If available, these features help

you to place your call without taking your attention off the road.

• When available, use a handsfree device.

additional layer of convenience to your mobile device with one of the many Motorola Original

™

handsfree accessories available

If possible, add an

today.

• Position your mobile device within easy reach.

Be able to access your mobile device without removing your eyes from the road. If you receive an incoming call at an inconvenient time, if possible, let your voice mail answer it for you.

• Let the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions.

Rain, sleet, snow, ice, and even heavy

traffic can be hazardous.

• Do not take notes or look up phone numbers while driving.

Jotting down a “to do” list or going through your address book

Smart Practices While Driving

A-21

takes attention away from your primary responsibility—driving safely.

• Dial sensibly and assess the traffic; if possible, place calls when your car is not moving or before pulling into traffic.

you must make a call while moving, dial only a few numbers, check the road and your mirrors, then continue.

• Do not engage in stressful or emotional conversations that may be distracting.

Make people you are talking with aware you are driving and suspend conversations that can divert your attention away from the road.

• Use your mobile device to call for help.

Dial 911 or other local emergency number in the case of fire, traffic accident, or medical emergencies.*

• Use your mobile device to help others in emergencies.

If you see an auto accident, crime in progress, or other serious emergency where lives are in danger, call 911 or other local emergency number, as you would want others to do for you.*

• Call roadside assistance or a special non-emergency wireless assistance number when necessary.

If you see a broken-down vehicle posing no serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number.*

* Wherever wireless phone service is available.

A-22

Smart Practices While Driving

motorola.com

Motorola V190 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

HELLOMOTO

contents

menu map

essentials

about this guide

SIM card

battery

turn it on & off

make a call

answer a call

store a phone number

call a stored phone number

your phone number

main attractions

play videos

multimedia messages

cable connections

basics

display

menus

text entry

volume

navigation key

external display

handsfree speaker

codes & passwords

lock & unlock phone

customize

ring style

ring & event lights

time & date

wallpaper

screen saver

display appearance

answer options

calls

turn off a call alert

recent calls

redial

return a call

caller ID

emergency calls

voicemail

other features

advanced calling

phonebook

messages

instant messaging

chat

personalizing

call times & costs

handsfree

data & fax calls

network

personal organizer

security

fun & games

service and repairs

SAR Data

index

Contents

Safety Information

Exposure To Radio Frequency (RF) Energy

Operational Precautions

RF Energy Interference/Compatibility

Driving Precautions

Operational Warnings

Choking Hazards

Glass Parts

Seizures/Blackouts

Repetitive Motion

Warranty

What Does this Warranty Cover?

Who Is Covered?

What Will Motorola Do?

How to Obtain Warranty Service or Other Information
