Motorola V120X User Manual

DIGITAL WIRELESS

TELEPHONE

User's Guide >

Welcome

Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola V120x wireless phone.

Earpiece

Power Key

Headset Jack

Insert headset accessory.

Display

Volume Keys

Adjust earpiece and ringer volume.

Left Soft Key

Perform functions identiﬁed by left display prompt.

End Key

End phone calls, exit menu system.

Antenna

Accessory Connector Port

Insert charger and phone accessories.

Menu Key

Voice Key

Record voice notes, phonebook and shortcut names.

Right Soft Key

Perform functions identiﬁed by right display prompt.

Send Key

Send and answer calls, view recent dialed calls list.

Scroll Keys

Move through menus and lists.

Microphone

Personal Communications Sector 600 North U.S. Highway 45 Libertyville, Illinois 60048

1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada)

www.motorola.com www.motorola.ca

(United States)

(Canada)

MOTOROLA, the Stylized M Logo and all other trademarks indicated as such herein are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off. TrueSync, Sidekick, Starﬁsh, and the Stylized Starﬁsh Logo are registered trademarks of Starﬁsh Software, Inc., a wholly owned independent subsidiary of Motorola, Inc. All other product or service names are the property of their respective owners.

Software Copyright Notice

The Motorola products described in this manual may include copyrighted Motorola and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modiﬁed, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Manual number: 6809440A47-O Cover number: 8988485L49-O

✂

Main Menu

Menu Map

• Recent Calls

• Received Calls

• Dialed Calls

• Notepad

• Call Times

• Phonebook

• Datebook

• Quick Dial

• Radio

• Messages

• Create Msg

• Voicemail

• Text Msgs Inbox

• Browser Alerts

• Quick Notes

• Outbox

• Drafts

• Shortcuts

• Voice Notes

• Browser

• Calculator

• Games

• Settings

(see next page)

Note: This is the standard phone menu layout. You or your service provider may have changed the menu layout or changed some feature names. Not all features may be available for all users.

For example , the Radio feature on the main menu (left) is displayed only when the optional FM Stereo Radio Headset accessory is plugged into the accessory connector port on your phone (see phone illustration, page 1).

Shortcuts

Change display zoom:

Press M, then press and hold

Lock/unlock keypad:

Press M

Display my phone number:

Press M

Dial voicemail number:

Press and hold

Go to dialed calls list:

Press

Exit menu system:

Press

Settings Menu

✂

• Ring Styles

• Style

•

Style

Detail

• My T ones

• Phone Status

• My T el. Number

• Active Line

• Battery Meter

• Other Information

• Connection

• Incoming Call

• In-Call Setup

• In-Call Timer

• Answer Options

• Security

• Phone Lock

• Lock Keypad

• Lock Application

• Restrict Calls

• New Passwords

• Other Settings

• Personalize

• Main Menu

•Keys

• Greeting

• Banner

• Quick Dial

• Initial Setup

• Time and Date

• Auto PIN Dial

• Auto Redial

• Backlight

• Zoom

• Scroll

• Animation

• Language

• Contrast

• DTMF

• Master Reset

• Master Clear

• Network

• Car Settings

• Headset

Menu Map About This Guide Safety and General Information Getting Started

What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . .18

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . .19

Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . .21

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Seeing Your Phone Number . . . . . . . . . . . . . . . . . . . .22

About Y our Phone

Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Zooming In and Out . . . . . . . . . . . . . . . . . . . . . . . . . .25

Adjusting Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Making and Answering Calls

Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . .28

Using Automatic Redial . . . . . . . . . . . . . . . . . . . . . . .28

Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Returning an Unanswered Call . . . . . . . . . . . . . . . . .29

Calling an Emergency Number . . . . . . . . . . . . . . . . .30

Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . .30

Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . .30

Calling With Speed Dial . . . . . . . . . . . . . . . . . . . . . . .31

Calling With One-Touch Dial . . . . . . . . . . . . . . . . . . . .31

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

. . . . . . . . . . . . . . . . . .11

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

. . . . . . . . . . . . . . . . . . . .28

Contents

Calling a Number In a Text Message . . . . . . . . . . . . . 32

Additional Calling Features . . . . . . . . . . . . . . . . . . . . 32

Using Features While On a Call

Using Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Making a Three-Way Call . . . . . . . . . . . . . . . . . . . . . 34

Additional On-Call Features . . . . . . . . . . . . . . . . . . . 35

Using the Menu

Navigating to a Feature . . . . . . . . . . . . . . . . . . . . . . . 36

Selecting a Feature Option . . . . . . . . . . . . . . . . . . . . 37

Entering Feature Information . . . . . . . . . . . . . . . . . . . 38

Entering Te xt

Contents

Choosing a Text Mode . . . . . . . . . . . . . . . . . . . . . . . . 40

Using Tap Method . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Using Symbol Mode . . . . . . . . . . . . . . . . . . . . . . . . . 44

Using iTAP™ Software Predictive Text Entry Method

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Menu Feature Descriptions Recent Calls

Viewing Received Calls or Dialed Calls . . . . . . . . . . . 61

Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Viewing and Resetting Call Timers . . . . . . . . . . . . . . 63

Phonebook

Viewing Entry Details . . . . . . . . . . . . . . . . . . . . . . . . . 66

Storing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . 66

Storing a PIN Code With the Phone Number . . . . . . 69

Recording a Voice Name For a Phonebook Entry . . . 70

Dialing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . 71

Editing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . 72

Deleting a Phonebook Entry . . . . . . . . . . . . . . . . . . . 72

Synchronizing with TrueSync Software . . . . . . . . . . . 72

Sorting the Phonebook List . . . . . . . . . . . . . . . . . . . . 73

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

. . . . . . . . . . . . . . . . . 34

. . . . . . . . . . . . . . . . . . . . . 49

Datebook

Week View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74

Day View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

Event View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

Adding a Datebook Event . . . . . . . . . . . . . . . . . . . . . .76

Changing Event Information . . . . . . . . . . . . . . . . . . . .76

Copying an Event . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

Deleting an Event . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

Radio

Turning the Radio On and Off . . . . . . . . . . . . . . . . . .79

Tuning a Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80

Storing a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80

Selecting a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . .80

Sending and Receiving Calls With the Radio On . . . .80

Messages—Voicemail

Storing Your Voicemail Number . . . . . . . . . . . . . . . . .82

Receiving a Voicemail Message . . . . . . . . . . . . . . . . .83

Listening to a Voicemail Message . . . . . . . . . . . . . . .83

Turning Off the Voice Message Waiting Indicator . . . .83

Messages—Text

Setting Up the Text Message Inbox . . . . . . . . . . . . . .84

Receiving a Text Message . . . . . . . . . . . . . . . . . . . . .85

Reading, Locking, or Deleting a Text Message . . . . .85

Sending a Text Message . . . . . . . . . . . . . . . . . . . . . .87

Sending a Quick Note Text Message . . . . . . . . . . . . .89

Viewing the Status of Sent Text Messages . . . . . . . . .90

Ring Styles

Selecting a Ring Style . . . . . . . . . . . . . . . . . . . . . . . .91

Customizing a Ring Style . . . . . . . . . . . . . . . . . . . . . .91

Creating Alert Tones . . . . . . . . . . . . . . . . . . . . . . . . . .93

Setting Reminders . . . . . . . . . . . . . . . . . . . . . . . . . . .98

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79

. . . . . . . . . . . . . . . . . . . . . . . . . .82

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

Contents

Shortcuts

Standard Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Creating a Shortcut . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Using Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Voice Notes

Recording a Voice Note . . . . . . . . . . . . . . . . . . . . . . 102

Viewing the Voice Notes List . . . . . . . . . . . . . . . . . . 103

Playing a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . 104

Locking and Unlocking a Voice Note . . . . . . . . . . . . 106

Deleting a Voice Note . . . . . . . . . . . . . . . . . . . . . . . 107

Micro-Browser

Contents

Starting a Micro-Browser Session . . . . . . . . . . . . . . 108

Interacting With Web Pages . . . . . . . . . . . . . . . . . . . 109

Calculator

Calculating Numbers . . . . . . . . . . . . . . . . . . . . . . . . 110

Converting Currency . . . . . . . . . . . . . . . . . . . . . . . . 112

Games

Playing a Game . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Game Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Blackjack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Mindblaster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Paddleball . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Adjusting Y our Settings

Reordering Menu Items . . . . . . . . . . . . . . . . . . . . . . 118

Customizing a Soft Key Function . . . . . . . . . . . . . . . 118

Hands-Free Use . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Data and Fax Calls

Connecting Your Phone to an External Device . . . . 122

Sending a Data or Fax Call . . . . . . . . . . . . . . . . . . . 125

Receiving a Data or Fax Call . . . . . . . . . . . . . . . . . . 126

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

. . . . . . . . . . . . . . . . . . . . . . . 118

. . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Security

Troubleshooting Programming Instructions Speciﬁc Absorption Rate Data Additional Health and Safety Information Warranty Product Registration Export Law Assurances Index Wireless Phone Safety Tips

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128

Assigning a New Code or Password . . . . . . . . . . . .128

If You Forget a Code or Password . . . . . . . . . . . . . .129

Locking and Unlocking Your Phone . . . . . . . . . . . . .130

Locking and Unlocking Your Keypad . . . . . . . . . . . .131

Restricting Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . .131

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .133

. . . . . . . . . . . . . . . . . . . . .142

. . . . . . . . . . . . . . . . .144

. . . . . . . .147

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .156

. . . . . . . . . . . . . . . . . . . . . . . . .164

. . . . . . . . . . . . . . . . . . . . . . .164

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .165

. . . . . . . . . . . . . . . . . . . .177

Contents

About This Guide

This user guide introduces you to the many features in your Motorola wireless phone.

Navigating To a Menu Feature

Use the menu system to access your phone’s features. This guide shows you how to select a menu feature as follows:

Find the Feature

This example shows that you must press and select

Messages

, then scroll to and select

Optional Features

About This Guide

provider for more information.

This label identiﬁes an optional network or subscription-dependent feature that may not be offered by all service providers in all geographical areas. Contact your service

Optional Accessories

This label identiﬁes a feature that requires an optional Motorola Original™ accessory.

Messages

Text Msgs

, scroll to

Text Msgs

Safety and General Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ THIS INFORMATION BEFORE USING YOUR PHONE.

The information provided in this document supersedes the general safety information contained in user guides published prior to July 2000. For information regarding radio use in a hazardous atmosphere please refer to the Factory Mutual (FM) Approval Manual Supplement or Instruction Card, which is included with radio models that offer this capability.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

RF Operational Characteristics

Your phone contains a transmitter and a receiver. When it is ON, it receives and transmits radio frequency (RF) energy. The phone operates in the frequency range of 824 MHz to 849 MHz in analog and digital mode and 1851.25 MHz to

1908.75 MHz in digital mode. When you communicate with your phone, the system handling

your call controls the power levels at which your phone transmits. The output power level typically may vary over a

Safety and General Information

range from 0.05 watts to 0.56 watts in analog mode and 0.0 watts to 0.32 watts in digital mode.

Exposure To Radio Frequency Energy

Your Motorola phone is designed to comply with the following national and international standards and guidelines regarding exposure of human beings to radio frequency electromagnetic energy:

• United States Federal Communications Commission, Code of Regulations; 47 CFR part 2 sub-part J

• American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992

• Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition

• National Council on Radiation Protection and Measurements (NCRP) of the United States, Report

86, 1986

• International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998

• Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999

• Australian Communications Authority Radiocommunications (Electromagnetic Radiation-Human Exposure) Standard 1999

To assure optimal phone performance and make sure human

Safety and General Information

exposure to radio frequency electromagnetic energy is within

the guidelines set forth in the above standards, always adhere to the following procedures:

Portable Phone Operation and EME Exposure

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modiﬁcations, or

attachments could damage the phone and may violate FCC regulations.

Do NOT hold the antenna when the phone is in use. Holding the antenna affects call quality and may cause the phone to operate at a higher power level than needed.

Phone Operation

When placing or receiving a phone call, hold your phone as you would a wireline telephone. Speak directly into

the microphone.

Body-Worn Operation

To maintain compliance with FCC/Health Canada RF exposure guidelines, if you wear a phone on your body when transmitting, always place the phone in a Motorola-supplied or approved clip, holder, holster, case, or body harness for this product. Use of non-Motorola-approved accessories may exceed FCC/Health Canada RF exposure guidelines. If you do not use one of the Motorola-supplied or approved body-worn accessories, and are not using the phone held in the normal use position, ensure the phone and its antenna

are at least one inch (2.5 centimeters) from your body when transmitting.

Safety and General Information

Data Operation

When using any data feature of the phone, with or without an accessory cable, position the phone and its antenna at

least one inch (2.5 centimeters) from your body.

Approved Accessories

For a list of approved Motorola accessories, visit our website at

www.mot.com

Electromagnetic Interference/Compatibility

Note: Nearly every electronic device is susceptible to

electromagnetic interference (EMI) if inadequately shielded, designed, or otherwise conﬁgured for electromagnetic compatibility.

Facilities

To avoid electromagnetic interference and/or compatibility

conﬂicts, turn off your phone in any facility where posted notices instruct you to do so. Hospitals or health care f acilities may be using equipment that is sensitive to external RF energy.

Aircraft

When instructed to do so, turn off your phone when on board an aircraft. Any use of a phone must be in accordance with applicable regulations per airline crew instructions.

Medical Devices

Pacemakers

The Advanced Medical Technology Association recommends

Safety and General Information

that a minimum separation of 6 inches (15 centimeters) be

maintained between a handheld wireless phone and a pacemaker. These recommendations are consistent with the independent research by, and recommendations of, the United States Food and Drug Administration.

Persons with pacemakers should:

• ALWAYS keep the phone more than six inches (15 centimeters) from your pacemaker when the phone is turned ON.

• NOT carry the phone in the breast pocket.

• use the ear opposite the pacemaker to minimize the

potential for interference.

• turn OFF the phone immediately if you have any reason to suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy . Your physician may be able to assist you in obtaining this information.

Safety and General Information

Safety and General Use While Driving

Check the laws and regulations on the use of phones in the area where you drive. Always obey them.

When using your phone while driving, please:

• give full attention to driving and to the road.

• use hands-free operation, if available.

• pull off the road and park before making or answering a

call if driving conditions so require.

Operational Warnings

For Vehicles With an Air Bag

Do not place a portable phone in the area over an air bag or in the air bag deployment area. Air bags inﬂate with great force. If a portable phone is placed in the air bag deployment area and the air bag inﬂates, the phone may be propelled with

great force and cause serious injury to occupants of the vehicle.

Potentially Explosive Atmospheres

Turn off your phone prior to entering any area with a potentially explosive atmosphere, unless the phone is a model speciﬁcally identiﬁed as being “Intrinsically Safe.” Do not remove, install, or charge batteries in such areas. Sparks in a potentially explosive atmosphere can cause an explosion or ﬁre resulting in bodily injury or even death.

Note: The areas with potentially explosive atmospheres referred to above include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles, such as grain, dust, or metal powders, and any other area where you would normally be advised to turn off your v ehicle engine. Areas with potentially explosive atmospheres are often but not always

Safety and General Information

posted.

Blasting Caps and Areas

To avoid possible interference with blasting operations, turn OFF your phone when you are near electrical blasting caps, in a blasting area, or in areas posted: “Turn off two-way radio.” Obey all signs and instructions.

Operational Cautions

Antennas

Do not use any portable phone that has a damaged antenna. If a damaged antenna comes into contact with your

skin, a minor burn can result.

Batteries

All batteries can cause property damage and/or bodily injury such as burns if a conductive material such as jewelry, keys, or beaded chains touches exposed terminals. The conductive material may complete an electrical circuit (short circuit) and become quite hot. Ex ercise care in handling any charged battery, particularly when placing it inside a pocket, purse, or other container with metal objects.

ITC01-101

Safety and General Information

Getting Started

What’s in the Box?

Your wireless phone typically comes equipped with a battery and a charger. Other accessory options can customize your phone for maximum performance and portability.

To purchase Motorola Original™ accessories, contact the Motorola Customer Call Center at 1-800-331-6456 in the United States or 1-800-461-4575 in Canada.

Installing the Battery

You must install and charge the battery to use your phone.

Your phone is designed to be used only with

Getting Started

Motorola Original batteries and accessories. We recommend that you store batteries in their protective cases when not in use.

Do This

1 Remove the battery from its protective clear

plastic case.

Do This

2 If necessary, slide

down the battery door release latch and lift the door off of the phone.

Release latch

3 Insert the battery,

printed arrows ﬁrst, into the top of the battery compartment and push down.

4 Replace the battery door.

Charging the Battery

New batteries are shipped partially charged. Before you can use your phone, y ou need to install and charge the battery, as indicated by the following instructions.

Getting Started

Some batteries perform best after several full charge/ discharge cycles.

Do This

1 Plug the

travel charger into your phone

Release tab

with the release tab facing up.

2 Plug the other end of the travel charger into the

appropriate electrical outlet.

3 When your phone indicates that the battery is

fully charged (

Charge Complete

), press the

release tab and remove the travel charger.

Note: When you charge the battery, the battery level

Getting Started

indicator in the upper right corner of the display shows how

much of the charging process is complete.

Turning Your Phone On

Do This To

1 Press and hold

Power

key

turn on your phone

2 If necessary, enter

your four-digit unlock code and press

(+)

unlock your phone The unlock code is

originally set to 1234. Y our service provider may change this number before you receive your phone.

Making a Call

Press To

1 keypad keys dial the phone number

Tip: If you make a mistake,

press

DELETE

(-) to delete the last digit, or press and hold

DELETE

(-) to clear all

digits.

make the call

Getting Started

Ending a Call

Press To

end the call

Answering a Call

When you receive a call, your phone rings and/or vibrates and displays an incoming call message.

Press To

ANSWER

(+)

Tip: If your phone is locked, you must unlock it to answer the call.

answer the call

Seeing Your Phone Number

Getting Started

Press To

M #

see your phone number

About Your Phone

See page 1 for a basic phone diagram.

Using the Display

➌

➋

Digital/ Analog Signal Indicator

➊

Signal Strength Indicator

➓

Ring Style Indicator

The

idle display

you are

In Use Indicator

not

➍

Roam Indicator

➎

Message Waiting Indicator

O,X&5E

12:00am

➏

➐

PH.BOOK MESSAGE

is the standard display that you see when

on a call or using the menu.

➒

Menu Indicator

Soft Key Labels

➑

Clock

Voice Message Waiting Indicator

Battery Level Indicator

Active line Indicator

About Your Phone

Labels at the bottom corners of the display show the

current soft key functions. A bottom center of the display indicates that you can press

to enter the main menu.

(menu) indicator at the

➊

Signal Strength Indicator Vertical bars show the strength of the network connection. You cannot make or receive calls when the

➋

Digital (F) or Analog (I) Signal

Indicator Shows whether you are receiving a

digital or analog signal.

➌

In Use Indicator Shows that a call is in progress.

➍

Roam Indicator Shows that your phone is seeking or using another network system outside your home network.

➎

Message Waiting Indicator Appears when you receive a text message.

➏

Voice Message Waiting Indicator Appears when you receive a voicemail message.

➐

Battery Level Indicator V ertical bars show the battery

charge level. Recharge the battery when you see

Low Battery

About Your Phone

and hear the low battery alert.

➑

Active Line Indicator Shows the current active phone line.

(no signal) indicator is displayed.

➒

Menu Indicator Indicates that you can press M

to enter the main menu or open a feature sub-menu.

➓

Ring Style Indicator Shows the ring style setting.

= loud ring

= vibrate

= silent

= soft ring

= vibrate and ring

Zooming In and Out

Press and release M, then press and hold M to zoom in and out on the display. Zoom in to increase text size, zoom out to display more information.

You can also zoom in and out from the menu. See page 57.

Adjusting Volume

Press the up and down volume keys to:

• increase and decrease earpiece volume during a call

• increase and decrease the ringer volume setting when the idle display is visible

Volume

keys

About Your Phone

Battery Use

Battery performance depends on many factors, including your wireless carrier’s network conﬁguration; signal strength; the temperature at which y ou oper ate y our

phone; the features and/or settings you select and use; and your voice, data, and other application usage patterns.

Battery Care

Caution: To prevent injuries or burns, do not allow metal

objects to contact or short-circuit the battery terminals. To maximize your battery’s performance:

• Always use Motorola Original™ batteries and battery chargers. The phone warranty does not co ver damage caused from using non-Motorola batteries and/or battery chargers.

• New batteries or batteries that have been stored for long periods of time may require a longer charge time.

• Maintain the battery at or near room temperature when charging.

• Do not expose batteries to temperatures below

-10°C (14°F) or above 45°C (113°F). Always take y our phone with you when you leave your vehicle.

• When you do not intend to use a battery for a while, store it uncharged in a cool, dark, dry place, such as a refrigerator.

About Your Phone

• Over extended periods of time, batteries gradually

wear down and require longer charging times. This is

normal. If you charge your battery regularly and notice a decrease in talk time or an increase in charging time, then it is probably time to purchase a new battery.

The rechargeable batteries that power this product must be disposed of properly and may

need to be recycled. Refer to your battery’s label for battery type. Contact your local recycling center for proper disposal methods. Never dispose of batteries in a ﬁre because they may explode.

Extending Battery Life

• Turn off your display backlight

The backlight uses power. To turn it off, see page 57.

• Minimize keypad-intense functions

Activities that require intensive ke ystroke use (such as playing a game or using messaging) reduce your phone’s talk and standby time. Lock the keypad when storing the phone in your purse or pocket to avoid unnecessary keypad and backlight activations. See page 131.

About Your Phone

Making and

Answering Calls

For basic instructions on how to make a call, end a call,

and answer a call, see pages 21–22.

Redialing a Number

If you hear an ordinary busy signal:

Press To

hang up

redial the busy number

Using Automatic Redial

Making and Answering Calls

If the network is busy, you hear a fast busy signal, and your phone displays

With automatic redial, your phone automatically redials the number for f our min utes. When the call goes through, your phone rings or vibrates one time, displays

Redial Successful

Call Failed

, and then connects the call.

You must turn on automatic redial to use the feature. See the “Auto Redial” option on page 56.

+ 154 hidden pages
