Parts List
EX500 Series
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
5
1
2
3
4
#
#
#
#
8/03
8/03
Parts List
EX500 Series
REF.
NO. PART NO. DESCRIPTION
REF.
NO. PART NO. DESCRIPTION
1 ---- Antenna (refer to antenna section)
2 JMLN4638A Dust Cover
3 1385905Z01 Universal Connector Seal
4 0302020P03 Screw for Dust Cover
5 HKLN4054A EX500 Name Plate
6 6102001P10 Light Pipe
7 0104031G98 EX500 Non Key Housing
8 3680530Z02 Frequency Knob
9 3680529Z01 Volume Knob
10 1302012P06 Top Plastic Plate
11 3385906Z01 Top Sheet
12 3202000P15 Top Seal Rubber
13 3502416P03 Speaker Mesh
14 Part of item 7 PTT Rubber
15 Part of item 7 PTT Plastic Cover
16 5005679X01 Speaker
17 1480577C01 Boot Microphone
18 8404079G05 Flex PCB Universal
19 ---20 0385913Z02 4 M2x4 Philips Screws
21 0385913Z02 1 M2x1 Philips Screws
22 8404078G03 Flex PCB RF Controller
23 ---24 3280534Z01 Seal Contact
25 3285892Z01 “O” ring
26 1502001P31 Chassis
46
8/03
Parts List
EX600/600•XLS Series
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
20
19
21
22
23
24
25
26
27
28
29
30
31
32
33
34
13
8/03
Parts List
EX600/600•XLS Series
REF.
NO. PART NO. DESCRIPTION
REF.
NO. PART NO. DESCRIPTION
1 ---- Antenna (refer to antenna section)
2 3680529Z01 Volume Knob
3 3680530Z02 Channel Selector Knob
4 1386160Z01 Top Plastic Plate (EX600)
1386160Z02 Top Plastic Plate (EX600•XLS)
5 3385906Z01 Top Sheet
6 3286159Z01 Control Top Seal
7 6186158Z01 Lightpipe
8 1386091Z01 PTT Bezel
9 7586090Z01 PTT Rubber
10 HKLN4055A EX600 Nameplate
HKLN4187A EX600•XLS Nameplate
11 1586088Z01 Front Cover Assembly
12 1385905Z01 Escutcheon, Universal Connector
13 JMLN4638A Dust Cover
14 7580540Z01 LCD Front Pad
15 5104949J11 LCD Module
16 7586096Z01 Main Keypad
17 4086199Z01 Keypad Polydome
18 ---- Controller Board (must order front cover kit)
19 8404078G03 Flex RF Controller
20 3586092Z01 Speaker Felt
21 1480577C01 Microphone Boot
22 5013920A04 Microphone
23 5086094Z01 Speaker
24 8486095Z01 Flex, Universal Connector
25 4286097Z01 Keypad Retainer
26 0386104Z01 Chassis Screw
27 1480503Z01 Backup Battery Boot
28 6080656Z01 Battery Backup
29 ---- RF Board (must order back cover kit)
30 7580556Z01 Thermal Pad
31 3280534Z01 Battery Module Seal
32 1485673Z01 Antenna Nut Insulator
33 3285892Z01 Main “O” Ring
34 2786154Z01 Chassis
