The Droid Xyboard 8.2 by Motorola is an ultra-portable 8.2” tablet with the power to control
your connected devices and extract their precious content, remotely, at ferocious Verizon
4G LTE speed. Devour cinema-style videos, concert-like music, and serious gaming. Adaptive
virtual surround sound and booming bass are just part of the amazement.
Whenever you see the see the 4G LTE indicator, you know you're connected to the most
advanced and reliable 4G mobile network in America. Download speeds up to ten times
faster than 3G networks. Movies in minutes, photos in seconds. Stream your favorite video
without annoying buffering. Download and view full-length HD quality movies.
File streaming: Summon your home computer content on command—wherever you go
with “MotoCast™” on page 16.
1.2 GHz dual-core processor: Use your processing power for movies, games, music, and
more in “Powerful apps” on page 18.
Adaptive virtual surround sound: Hear music powered by multiple speakers and booming
bass.
Not all features, applications, or services may be available with your plan. Please contact
your wireless service provider for more information.
You’re now connected to America’s Fastest Most Reliable Verizon 4G LTE Network. That’s
ten times faster than Verizon’s 3G. So go ahead and make yourself heard.
This book will show you how to unleash the potential of your new device. Assistance is at
your fingertips at verizonwireless.com
1-800-922-0204 or at any Verizon Wireless Store. A comprehensive User Guide is available
on demand—simply download one at support.vzw.com/phones or call 1-800-734-5870 to
order a copy.
Note:
Devices and software are constantly evolving—the screen images and icons you see
here are for reference only.
IMPORTANT CUSTOMER INFORMATION
CONTENT AND INTERNET ACCESS
Many services and applications offered through your device may be provided by third
parties. Before you use, link to or download a service provided by a third party, or an
application such as a non-Verizon Wireless location-based GPS-type service, chat room,
marketplace or social network from your device, you should review the terms of such service
or application and applicable privacy policy. Personal information you submit may be read,
collected or used by the service or application provider and/or other users of those forums.
Verizon Wireless is not responsible for any information, content or services you access,
download or use from the Internet. You are responsible for maintaining virus and other
Internet security protections when accessing service F or additional information, visit the
Verizon Content Policy at responsibility.verizon.com/contentpolicy.
Your Verizon Wireless Customer Agreement terms and conditions and certain other
specially identified terms govern your use of any Verizon Wireless products and services.
. Customer Service is at your disposal at
MY VERIZON
3
REGISTER NOW
Save time. Save money. Register now at verizonwireless.com/myverizon.
Manage your account. Quickly check your usage or make adjustments to your plan at any
time.
Get personalized support. My Support answers your questions quickly.
Pay bills your way. Go green and set up paperless billing, make a one-time payment, or use
auto pay and never worry about missing a payment.
Much more. Move your media and transfer your contacts in no time with Backup
Assistant
SM
.
4
MY VERIZON
YOUR DROID XYBOARD 8.2 BY MOTOROLA
http
.
Your Droid Xyboard 8.2 by Motorola
Inbox
mike.higgins22...
Note:
All screen shots in this guide are simulated. Actual displays and instructions may vary
depending on your software version.
Note:
Certain apps and features may not be available in all countries.
Remote Control
Apps
5
FacebookMotorola
GoogleVerizon
://www
Tr ansmitter
Power/Sleep Key (on
back)
Hold=power,
Press=sleep
Volume Keys (on
back)
Notification Light
QelloFree
HD Concert …
Front Camera Lens
Headphone Jack
Talk
BooksMotoCast Madden NFL 12
YouTube
Market
Micro USB / Charger
Charging Light
11:35
HDMI
SIM card
YOUR DROID XYBOARD 8.2 BY MOTOROLA
5
FIRST STEPS
2
Remove the placeholder
SIM card.
4
Power up.
Power/Sleep Key
(on back)
Hold=power
5
Sign in.
Sign in with your Google Account
Email
Password
1
Charge up.
Note: This product
uses a non-removable battery.
3
Insert your SIM card.
SIM card
First steps
GETTING STARTED
ASSEMBLE & CHARGE
Caution:
Before assembling, charging, or using your device for the first time, please read
the important safety, regulatory, and legal information provided with your product.
FIRST STEPS
6
Caution:
Power off the tablet before removing the SIM card. If you remove a card while the
tablet is powered on, you may lose data.
When you plug in a charger, your tablet turns on. If you have a low battery, the Charging Light
shows until your tablet can turn on. When your tablet is on, touch the battery icon in the
bottom right of the display for detailed charging status.
Note:
The battery should only be replaced by a Motorola-approved service facility. Any
attempt to remove or replace your battery may damage the product and void your warranty.
This product meets the applicable limit for exposure to radio waves (known as SAR)
of 1.6 W/kg (FCC & IC). The limits and guidelines include a substantial safety margin
designed to assure the safety of all persons, regardless of age and health. The
highest SAR values measured for this device are listed in the regulatory information
packaged with your product.
STARTUP
1
Press and hold Power/Lock on the back of your tablet to turn it on.
2
If desired, change the language setting, then touch
Start
When you touch
, your tablet attempts to activate your mobile service (if not already
Start
.
activated).
3
If you go on to Wi-Fi setup, you see a
Wi-Fi setup
screen. Connect to an existing network,
add a new network, or skip Wi-Fi setup for now and set up later (see “Wi-Fi” on page 15).
4
Choose location settings and touch
Next
(for the most accurate location features, check
both services).
5
Follow the setup wizard to create or log into your Google™ Account and go to the home
screen.
Record your Google Account information for future reference.
Username: ________________________________________________________
If you have an existing Gmail account, your contacts from that account are synced to your
device. Whenever you select a contact from one group, the tablet shows contacts from every
group.
PREPAID MONTH TO MONTH DATA PLANS FOR TABLETS—ACTIVATE YOUR DEVICE
Verizon Wireless offers month to month, pay as you go 4G LTE Mobile Broadband service
that puts you in charge of your Internet access on your tablet. Surf the web at blazing speeds
and enjoy thousands of Apps with the freedom of no long-term contract, no activation fees,
and no termination fees. Easily manage your account directly from the Settings menu of your
device. Data plans require a Credit Card or select Debit Cards and will automatically renew
every month unless cancelled.
Note:
Subject to specific terms of use. For coverage details, please visit
www.verizonwireless.com/coveragelocator
1
Make sure your device's SIM card is inserted. Then, from the “Set up data service” screen,
.
select “Sign up now.”
2
You will automatically be directed to your “Verizon Wireless Mobile Broadband portal.”
3
Select your data plan and follow the “Next Steps” instructions on the screen to complete
your activation.
You will receive a confirmation email when registration is complete and your data plan is
active.
Note:
You can change your account settings or data plan at any time by visiting the “Verizon
Wireless Mobile Broadband portal.” Just touch
networks
>
Mobile networks
>
Verizon data service
Apps >Settings
.
>
Wireless &
Service Coming Soon.
FIRST STEPS
8
SAVE THE DEVICE LABEL
Device Label
ATTACH LABEL ATTACH LABELABEL ATTACH LABEL ATTACH LABEL ATT
Remove the device label from the back
of your device and affix it below for
safekeeping.
Device
Label
FIRST STEPS
9
BASICS
Inbox
mike.higgins22...
5
FacebookMotorola
GoogleVerizon
http
.
QelloFree
HD Concert …
Apps
11:35
Talk
YouTube
Market
BooksMotoCast Madden NFL 12
Touch & hold to move
items on the home
screen, or to open
options for items in
lists.
Touch to open.
Flick or drag to scroll.
Basics
TO U CH
It’s all in the touch:
Touch: Choose an icon or
option.
Touch & Hold: Move, or
open options.
Drag: Scroll or move
slowly.
Flick: Scroll or move
quickly.
Pinch-to-zoom: Get a
closer look at Google
Maps™, web pages, or
photos.
Tip:
When using a mouse with
the device, you can also
double-click to zoom.
BASICS
://www
10
HOME SCREEN
Inbox
mike.higgins22...
5
FacebookMotorola
GoogleVerizon
http
.
QelloFree
HD Concert …
Apps
11:35
Talk
YouTube
Market
BooksMotoCast Madden NFL 12
Search.
Widgets
Flick left or right to see
more panels.
Open apps.
Recent Apps
Notifications & Quick
Settings
Touch for details.
Home
Back
Shortcuts
Your home screen is your
personally designed launch
pad. You’ll see the home
screen when you turn on the
tablet or touch Home
from a menu.
Note:
display is simulated. Actual
displays may vary.
This home screen
://www
Search: Search with
text or voice.
App menu: See all your
apps (if you have a lot, flick
left and right to see them
all).
Back: Go back one
screen.
Home: Return to the
home screen at any point.
Recent apps: Show
thumbnails of your recent apps (touch a thumbnail to open the app).
Panels: Flick left or right to show the five home screen panels. Use panels to organize your
widgets and shortcuts. To return to the center panel, touch Home.
Notifications: Touch the clock in the bottom right to show your tablet’s status and details
about any new messages or other notifications.
Menu: When you see in the top right, or in the bottom left, you can touch them to
open a menu for the screen you’re on.
BASICS
11
USE & CHANGE YOUR HOME SCREEN
11:35
1
11:35
2
Wi-Fi
Airplane mode
Auto-rotate screen
Notifications
Settings
AUTO
ON
ON
OFF
3
Inbox
mike.higgins22...
5
FacebookMotorola
GoogleVerizon
http
.
QelloFree
HD Concert …
Apps
11:35
Talk
YouTube
Market
BooksMotoCast Madden NFL 12
Add widgets,
wallpaper, and more to
your home screen.
Touch the status
indicators, then touch
twice to change
your
screen,
sound, or
other
settings.
Touch & hold, then
drag widgets or
shortcuts to a new
spot or the trash can in
the top right.
On your home screen,
shortcuts are icons that open
your favorite apps, Web
bookmarks, music playlists,
and more. Widgets show you
the date, updates, and more.
The Calendar widget is an
example of a scrollable
widget—you can scroll
through your calendar within
the widget itself, on the home
page, without opening the
calendar app. The Books
widget is an example of a
stacked widget—you can flick
through your content within
the widget itself, on the home
screen, without opening the
Books app.
Flick left and right to see
more home screen panels of
shortcuts and widgets.
Customize: To add widgets, app shortcuts, wallpapers, and more to your home screen,
touchat the top right of the screen.
Resize a widget: Touch and hold the widget until it vibrates, then let go. A highlighted
frame appears around the widget—drag a corner to resize.
NOTIFICATIONS
The notification panel at the bottom right of the home screen contains icons that tell you
about new messages, available app downloads, network signal strength, and other tablet
BASICS
12
://www
status indicators. Touch an individual icon to see that email, meeting reminder, or other
notification. Or, touch the digital time display to open the entire notification panel to see all
new message notifications, status icons, and other useful data.
SEARCH
The search window on your home screen gives you two search options. For a text search,
touch the search window, enter your keyword(s), then touch . To search by voice, touch
and speak your keyword(s) when prompted.
SETTINGS
Open the Quick Settings Menu to change
settings for brightness, sound, screen
orientation, airplane mode, network, and
notifications.
1
Touch the clock at the bottom of the home
screen.
2
Touch .
3
Change a quick setting, or touch
Settings
to see all tablet settings.
Tip:
You can also go to tablet settings by touching
Apps >Settings
.
APP MENU
Touch
your tablet’s apps.
To close the app tray, touch Homeor Back.
Apps
from the home screen to see
Monday
Mar 5, 2012
Airplane mode
Wi-Fi
Auto-rotate screen
Notifications
Settings
AUTO
100%Wi-Fi
11:35
11:35
ON
ON
OFF
Connect Wi-Fi.
Change quick
settings.
Change any
settings.
13
BASICS
KEY TIPS
SLEEP & WAKE UP
Put the touchscreen to sleep by pressing Power/Lock.
To wake up the touchscreen, just press the
Power/Lock again, then drag out of the circle.
CHANGE VOLUME
Press the volume keys to adjust the volume.
On the back:
Power/Sleep Key
Hold=power,
Press=sleep
Volume Keys
SET UP EMAIL
The first time you turned on your tablet (see page 6), you may have logged in to your Google
Account.
You can add other email accounts:
If you want to set up additional Google Accounts, touch
Accounts & sync >Add account
>
If you want to set up other email accounts, touch
.
Apps >Settings
Apps >Email
, then follow the
step-by-step instructions to set up a POP3, IMAP, or corporate account.
WANT MORE?
More help, more accessories, more free stuff. We’re here to help.
BASICS
Answers: Check out the help center on your tablet—touch
Support: Software updates, PC software, user guides, online help, and more at
www.motorola.com/myxyboard8.2
Accessories: Find accessories for your tablet at www.motorola.com/accessories.
Join us: Get the latest news, apps, tips & tricks, videos and so much more—join us on:
YouTube™
Facebook
Twitter
www.youtube.com/motorola
www.facebook.com/motorola
www.twitter.com/motomobile
.
Apps> Help Center
.
14
MANAGE CONTENT
Manage content
CONNECTIONS
Your tablet gives you many ways to connect with your world.
4G LTE CONNECTION
Your tablet uses the 4G LTE mobile network wherever it's available. You'll know you're
connected when you see on the screen.
WI-FI
It's easy to connect to a Wi-Fi network. Newly added proxy support makes sure you stay
connected.
1
Touch the clock at the bottom of the screen.
2
To uc h.
3
To uc h
4
In
Your tablet scans for and shows all available Wi-Fi networks.
USB CONNECTION
You can transfer HD video, music, pictures, photos and other media content between your
tablet and a computer. A USB connection makes it easy. Use the USB cable that came with
your tablet to make the connection and do the following:
Microsoft™ Windows™ XP, Windows Vista, and Windows 7—On your computer, press
Start, open your list of programs, and select Windows Explorer. Then drag and drop files
from your computer to your tablet.
Apple™ Macintosh™—Use Android File Transfer. (You can download it from
android.com/filetransfer
Settings
Wi-Fi
.
Wireless & networks
, select
Wi-Fi
.
. This requires Mac OS x 10.5 or later.)
MANAGE CONTENT
15
HDMI
You can snap photos and capture videos, then sit back and enjoy them on your HDTV at home.
Your tablet’s HDMI port lets you connect it to other HDMI devices.
BLUETOOTH® WIRELESS
With Bluetooth wireless technology, you can enjoy your music on a Bluetooth-enabled stereo
headset, or connect to a Bluetooth keypad and mouse for quick and easy text entry. With
newly added Bluetooth support for Google Talk, you can chat hands-free using a Bluetooth
headset or car kit.
MOTOCAST™
MotoCast
is an exclusive free app from Motorola that lets you stream content from your PC
to your tablet any time you have a network connection—music, photos, videos and
documents!
1
On your computer, download and install
MotoCast
from www.mymotocast.com. Then,
create or enter or create your Motorola ID.
2
On your tablet, touch
MotoCast
3
Follow the
shows you the music, photos, and videos stored on your computer.
MotoCast
Apps >MotoCast
. Then, enter your Motorola ID.
prompts to stream or download files from your computer—now,
you can access your music, photos, and videos on your tablet anywhere you have an
Internet connection.
CONTENT BACKUP
BACKUP ASSISTANT
Backup Assistant is a free service from Verizon Wireless which saves your device’s address
book to a secure server. If your device is lost or damaged, or if you upgrade to a new device,
Backup Assistant will restore your contacts.
SM
MANAGE CONTENT
16
V CAST™ MEDIA MANAGER
Transfer pictures, videos and music between your device and computer with just a USB cable
connection. Includes a media player and media management tools. Go to
verizonwireless.com/vmm
to download your free copy.
GOOGLE™ ACCOUNT
You can choose to back up some of your data, such as bookmarks, user dictionary, Wi-Fi
passwords, and other settings, to your Google Account on Google servers. Some third-party
application may also take advantage of this feature. If you get a new tablet, your tablet is
lost or stolen, or if you reinstall an application, you can restore your settings and other data.
17
MANAGE CONTENT
APPS & FEATURES
Remote Control
Tr ansmitter
Control your TV or other
devices.
Apps & features
POWERFUL APPS
Make your device do more with music, ringtones, wallpapers, apps and games. Check the
latest scores, keep up with Twitter and Facebook, even plan a vacation, we’ve got apps that
help you do it all.
Note:
Data charges may apply.
Dijit™ Universal Remote—Turn your tablet into a remote control
with a program guide, recommendations, and social TV features.
Just touch
your devices and programming provider.
Cinematic HD movie playback—Watch HD movies in HD, on your
tablet’s huge 8.2-inch widescreen display. Thousands of movie
titles are now available for rental from Android Market.
Games—Gaming reaches a whole new level—rich graphics on an
HD display, an accelerometer, and a gyroscope. Your tablet
delivers it all at lightning-fast speeds with its powerful dual-core
processor and 16 or 32GB of RAM.
Google eBooks™—Get your favorite books and read them right on your tablet.
Android Market™—Android Market is your one-stop shop for movies, books, apps, and
games.
Desktop-like tabbed browsing—Open multiple tabs in a single browser window, and
switch between them in a flash.
Google Talk™—Google Talk now has voice and video capabilities, allowing you to chat
"face-to-face" with any Google Talk enabled device over Wi-Fi, 3G, or 4G LTE. You can even
chat handsfree with a Bluetooth headset or car kit.
Google Maps™—Of course you can still find local businesses, view maps, and get driving
APPS & FEATURES
18
directions. Some new additions make Google Maps really stands out from the rest. Street
Apps
>
Dijit
and follow the prompts to set up
View zooms you all the way in—you're virtually standing on the street. 3D building
Start/stop recording. Zoom
Back Camera Lens
Camera Flash
On the back of your tablet:
Choose
photo or
video.
Choose the front
or back camera.
Open the
gallery.
outlines give you fantastic detail to the central areas of many cities.
Photos and Videos—Snap
killer photos with a 5MP
camera. Capture videos
like never before—in
amazing 720p HD—with
the fully functioning HD
camcorder. Choose the
lens on the rear of the
tablet or, for
self-portraits, the lens on
the front. From the home
screen, touch
> >
to take a photo or touch
to switch to videos.
You can also view and
import photos from a
digital camera with a USB
connection and Picture
Transfer Protocol.
For details and pricing, go to verizonwireless.com.
Note:
For more information on your tablet’s apps and features, see the user guide.
ANDROID MARKET™
Android Market provides direct access to thousands of apps and games that you can
download and install.
Touch
Touch an app or book to see details and reviews, then install, buy, or try it.
Camera
Apps
. Touch
Apps
>
Market
. Select a category or touch
Search
to find the app you want.
APPS & FEATURES
19
Tip:
Choose your apps and updates carefully, from trusted sites like
impact your product’s performance.
Note:
When installing an app, make sure you read the alerts that tell you what information
Market
, as some may
the app will access. If you don’t want the app to have access to this information, cancel the
installation.
20
APPS & FEATURES
TROUBLESHOOTING
Troubl es ho o ti ng
FORCED REBOOT
In the unlikely event that your device becomes unresponsive, try a forced reboot: Press and
hold both Power/Lock and the down volume key for more than 12 seconds.
RESET
If you forget your unlock pattern or password, you can do a factory data reset to restore your
tablet to its factory settings:
War ning :
This deletes all of your data on the tablet. This includes pictures, videos,
documents, and other files that you have not backed up online or on a PC.
1
Turn off your tablet (if necessary, see “Forced reboot”).
2
Press and hold both volume keys while you press Power/Lock. Your tablet should
show the Boot Mode menu.
Press the volume down key to scroll to Recovery mode, then press the volume up key to
activate it.
3
When you see the Android logo, press both volume keys at the same time. Your tablet
should show the Recovery screen.
a Press the volume down key to scroll to the factory reset option, then press
Power/Lock to activate it.
b Press the volume down key to scroll to the Yes confirmation, then press
Power/Lock to activate it.
TOTAL EQUIPMENT COVERAGE
Sign up for Total Equipment Coverage and if your device breaks, gets lost or stolen, or
malfunctions after the manufacturer’s warranty expires, you’re covered. Total Equipment
Coverage combines Verizon Wireless Extended Warranty and Asurion’s Wireless Phone
Protection. For details, go to verizonwireless.com/equipmentprotection
.
TR OU B L ES H O OT I N G
21
22
COPYRIGHT & TRADEMARKS
Motorola Mobility, Inc.
Consumer Advocacy Office
600 N US Hwy 45
Libertyville, IL 60048
www.motorola.com
Note:
Do not ship your product to the above address. If you need to return your product for repairs, replacement, or warranty
service, please contact the Motorola Customer Support Center at:
1-800-734-5870 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain features, services and applications are network dependent and may not be available in all areas; additional terms,
conditions and/or charges may apply. Contact your service provider for details.
All features, functionality, and other product specifications, a s well as the information contained in this guide, are based upon
the latest available information and believed to be accurate at the time of printing. Motorola reserves the right to change or
modify any information or specifications without notice or obligation.
Motorola does not take responsibility for changes/modification to the transceiver.
Product ID: Droid Xyboard 8.2 by Motorola (Model: MZ609)
Manual Number: 68016494001-B
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
