MOTOROLA DEVOUR™ with MOTOBLUR™

User Guide

Congratulations

MOTOROLATMDEVOUR with

MOTOBLUR

MOTOROLA DEVOUR with MOTOBLUR syncs contacts, posts, feeds, messages, email, photos and much more—from all your social networking sites—and automatically ser ves it up just the way you want it.

• Only MOTOBLUR syncs your favorite social

networking sites—all your contacts, all your messages, all the latest updates—straight to your MOTOROLA DEVOUR.

• Choose from thousands of cool apps to download

from Android Market™ to play and surf to your heart’s content.

• MOTOBLUR backs it all up too. So relax, already.

Caution: Before assembling, charging or using your

phone for the first time, please read “Safety, Regulatory & Legal” on page 59. Once your phone is up and running, touch Menu >

About phone > Safety & regulatory to read the full

> information.

Settings

More information

On your phone—Touch > Help Center.

You can also flick your home screen right to see

Getting Started and Tips & Tricks widgets. Touch them

for helpful advice.

On your computer—Go to

http://www.motorola.com/mydevour

After you create a MOTOBLUR account, you can also log in and find help with MOTOBLUR: http://www.motorola.com/mymotoblur

So, whether you want to read, watch, or play, we can help.

Notes:

• All screen shots in this guide are simulated.

Actual displays may vary.

• Instructions to perform tasks in this guide may

change depending on the software version on your phone.

• Unless specified otherwise, all instructions to

perform tasks in this guide assume that you are starting from the home screen.

1Congratulations

Your phone

Power Key

Press to put the display to sleep, or hold

to turn off.

Volume Keys

Camera Key

Voice Command Key

Menu Key

Touch to open menu options.

Battery & microSD Card Compartment

(under battery

cover)

Micro USB

Connector

Charge or

connect to PC.

Optical

Navigation Key.

Scroll & select

options.

Home Key

Back Key

3.5mm Headset Jack

Notification

LED

On=Charged.

Flashing=New

notification.

Delete Return

Space

Shift Function

For most applications, the screen

adjusts for you when

you open or turn the phone.

SYM

Tip: To activate/deactivate the Notification LED,

touch Menu >

Notification LED.

2 Your phone

Settings > Display & security

Note: Your phone might look a little different.

Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 6

Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

App menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

V CAST Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

V CAST Music with Rhapsody® . . . . . . . . . . . . . . . 37

Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

YouTube™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Maps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Latitude. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

VZ Navigator®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Bluetooth® wireless. . . . . . . . . . . . . . . . . . . . . . . . 48

Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Memory card & file management. . . . . . . . . . . . . . 51

Synchronize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Safety, Regulatory & Legal. . . . . . . . . . . . . . . . . . . . 60

3Your phone

Let’s go

let’s get you up and running

Assemble & charge

1 remove cover 2 slide red latch to left,

3 push battery

completely in

insert battery

4 insert microSD (may

already be done)

5 place strap over

6 charge up

battery, replace cover

Caution: Please read the battery use and safety text in

the important legal and safety information packaged with your phone.

Tip: To save battery life, see “Battery tips” on page 25.

Set up & go

Create or log into a MOTOBLUR account to get your contacts, email, messages, and status information, for all your accounts, all in one place, all the time. There’s more in “Your MOTOBLUR account” on page 11. Registration is secure, and should only take a few minutes.

4 Let’s go

MOTOBLUR ID:

Enter email address

Your name:

e.g. John Smith

Password:

Password

NextBack

Creating your

MOTOBLUR account...

Twitter Corporate SyncEmail

Facebook

Myspace Google

Picasa

Photobucket

1 Press and hold Power

to turn on.

2 Select a language.

3 Register or log in.

Note: If prompted, touch

Activate to activate your

phone.

To create a MOTOBLUR account, enter your name, a current email address (where MOTOBLUR can send account information), and a MOTOBLUR account password.

Tip: Open your phone to

type.

Tip: For more, or to

add accounts anytime, go to “Add accounts” on page 12.

4 Add your accounts to

MOTOBLUR.

Touch an account type, then enter the user name or email and password that you set up on that account.

Wi-Fi connect

If you want to use a Wi-Fi network for even faster Internet access, touch Menu >

Wireless controls > Wi-Fi settings. Touch Wi-Fi to

> search for and connect to wireless networks. There’s more in “Wi-Fi” on page 50.

Settings

Cool content & more

Browse and download thousands of the coolest apps on the planet from Android Market. On top of that, you get a full HTML browser with AdobeFlash ®, so you can surf in style.

Download new apps with “Android Market™” on page 47. Your phone comes with a microSD memory

5Let’s go

card installed—you can load it up with photos, videos,

and music from your computer using “Manage files

with a USB connection” on page 51.

Note: Do not remove your memory card while your

phone is using it or writing files on it.

Security

Your contacts are backed-up on MOTOBLUR, so don’t

worry. Even if you lose your phone, MOTOBLUR can

help you find it or wipe it. And when you get your next

MOTOBLUR product, your stored info makes it a snap

to set up with just a username and password.

Of course it doesn't stop there. There are plenty of

ways to protect your phone and your information,

in “Security” on page 56.

6 Touchscreen & keys

Touchscreen & keys

a few essentials

Touch tips

Here are some tips on how to navigate around your phone.

Touch

To choose an icon or option, Touch it. Try it: In the home screen, touch

Contacts.

Touch & hold

To open special options, touch and hold an icon or other item. Try it: In the home screen, touch

Contacts, then

touch and hold a contact to open options.

Contacts

Alex Pico

View contact

Call

Send Text Message

Delete contact

Drag

Touch lightly & move finger up,

down, right, & left to scroll.

Press to select.

Key

Home

Key

Back Key

To scroll through a list or

move slowly, drag across

the touchscreen. Try it: In

the home screen, touch

Contacts, then drag

Contacts list up or

your

down.

Tip: When you drag or flick

a list, a scroll bar appears

on the right. Drag the scroll

Contacts

Alex Pico

Dan Smith

Kate Shunney

Keith Zang

Luke Carmody

Mariana Bukvic

StatusHistory A-Z

bar to move the list to a

letter A - Z.

Flick

To scroll through a list or move quickly, flick across the

touchscreen (drag quickly and release).

Tip: When you flick a long list, touch the screen to stop

it from scrolling.

Optical navigation key

Move your finger lightly over the Optical Navigation Key to navigate your phone’s display and to highlight options. Press the key to select an option.

Tip: Adjust the

sensitivity of the Optical Navigation Key by touching Menu >

Display & security > Optical Joystick Sensitivity.

Settings

Key tips

Menu, home, & back

Touch Home to close any menu or app and return to the home screen. Touch and hold Home to show the last few apps you used, then touch an app to open it. In the home screen.

7Touchscreen & keys

Touch Menu to open menu options, or Back to

Volume Keys

go back. Touch and hold Menu to open the

touchscreen keypad.

Sleep & wake up

To save your battery, prevent accidental

touches, or when you want to wipe

smudges off your touchscreen, put the

touchscreen to sleep by pressing

Power . To wake up the

touchscreen, just press Power ,

touch Menu , or open the phone.

To change how long your phone waits before the

screen goes to sleep automatically, touch Menu

Settings > Display & security > Screen timeout.

Tip: To make the screen lock when it goes to sleep,

use “Screen lock” on page 56.

Power key menu

Press and hold Power to open the power key

menu, where you can turn off the phone (

or turn off features (

GPS).

Airplane mode, Bluetooth, Wi-Fi,

Power off),

Adjust volume

Press the volume keys to change the ring volume (in the home screen), or the earpiece volume (during a call).

Rotate the screen

In many apps, the touchscreen can rotate to stay right-side up when you rotate your phone:

Find it: Menu >

Orientation

Settings > Display & security

8 Touchscreen & keys

Home screen

Trevor Gilley

This seems like a good day to start exercising, right?

5 min ago

No recent status updates. Update now!

Browser

11:35

Messaging

No recent unseen messages.

Status Indicators

Your Online Status

Touch to change your status.

Widgets

Touch to open, or touch & hold to move or delete.

Flick left or right to open more panels of widgets.

Shortcuts

Open the app menu.

Notifications

Flick this bar down to see details.

quick access to the things you need most

Quick start: Home screen

The home screen gives you all your latest information

in one place. It’s what you see when you turn on the

phone or touch Home from a menu. It’s basically

like this:

Use & change your home screen

On your home screen, shortcuts are icons that you touch to open your favorite apps, Web bookmarks, contacts, mail labels, or music playlists. Widgets show you news, weather, messages, and other updates.

Flick the home screen left or right to open other panels of shortcuts and widgets.

• To open something, touch it. Touch Home to

return to the home screen.

• To change the settings for some widgets, open the

widget and then touch Menu > widgets don’t include this feature.)

You can find details about the settings for

Happenings (“Add accounts” on page 12), Messages

(“Set up messaging” on page 20), on page 33), page 12), or

Social Status (“Update your status” on

News or Weather (“Set up widgets” on

page 27).

• To add something or change your wallpaper, touch

and hold an empty spot until you see the

Home screen

menu.

You can add a folder to organize your shortcuts.

• To move or delete something, touch and hold it

until you feel a vibration, then drag it to another spot, another panel, or the trash at the bottom of the screen.

Setup. (Some

Music (“Music”

Add to

9Home screen

Search

10:47

Google

Voice Search

Text Search

To search, use a Search widget (if you have one on

your home screen), or touch Menu > Search .

Phone status & notifications

At the top of the screen,

icons on the left notify you

about new messages or

events (flick the bar down

for details). Icons on the

right tell you about phone

status:

Bluetooth® active network (full signal)

GPS active network (roaming)

Wi-Fi active downloading

vibrate 3G (fastest data)

silent flight mode

mute call battery (charging)

speakerphone active battery (full charge)

10 Home screen

December 9, 2009

Verizon Wireless

Notifications

New voicemail

Dial 1-800-555-5555

Missed call

John Smith 11/20/2009

2:55 PM

Clear

07:21

Google™ sync

alarm set

active

Tip: To see today’s date, touch and hold the status

indicators.

App menu

Quick start: App menu

The app (application) menu

shows you all of your

applications. To open it from the

home screen, touch . To

close it, touch again.

Note: Your app menu will vary.

Tip: To find an app in the app menu, open your phone

(or touch and hold Menu to open a display keypad),

then type the app name.

Recent apps

Touch and hold Home to see the last few apps you

used, then touch the app you want. Touch Home

to return to the home screen.

Social networking

my life, your life

Your MOTOBLUR account

The first time you turned on your phone, you registered for a MOTOBLUR account that manages your messages, contacts, and more (“Set up & go” on page 4). You can log into this account from a computer to upload contacts, reset your password, get help, or even locate your phone: www.motorola.com/mymotoblur

What is MOTOBLUR?

MOTOBLUR syncs all your contacts, posts, feeds, messages, emails, photos and much more—from sources like Facebook, Twitter, MySpace, your work email, Picasa, Photobucket—and automatically ser ves it up just the way you want it. No opening and closing apps and menus, it’s all front and center on your home screen and integrated throughout the entire phone so you can communicate anyway you like.

11App menu

Update your status

After you add a social networking account, you can

update and see your current status in a

widget on your home screen.

To update your status, just touch your

widget and enter text. If you have more than one

account, you can use the pull-down menu to limit

which accounts are updated. If you don’t see a

Status

widget, flick your home screen left or right to

check all panels.

To add a

1 Touch and hold an empty spot on your home screen

2 Touch

Social Status widget:

to open the

Add to Home screen menu.

Widgets > Social Status. The widget appears

in the empty spot, and will show your status the next time your phone updates from the network.

Social Status

Social

Add accounts

Note: You can add your Facebook, MySpace, Twitter,

or other accounts to your phone. If you don’t have

accounts, you can visit their Web sites to set them up.

Find it: Menu >

account

To sign into your account, use the user name or email

and password that you set up on that account (the

same as on your computer).

12 Social networking

Settings > Accounts > Add

When you sign into social networking accounts, you’ll see your friends and contacts in your your status and updates can appear in

Happenings widgets.

and

Contacts list, and

Social Status

Twitter and MySpace messages will always appear

as “read” on your phone, but your phone notifies you when you receive a new message. MySpace marks your messages as “read” online.

For email accounts, see “Set up messaging” on

page 20.

Tip: To download updates faster, use “Wi-Fi” on

page 50.

View account updates & features

After you add a social networking account, you can see and respond to friends’ updates with the widget on your home screen. If you don’t see one, set one up in “Widgets” on page 27.

When you touch the

Happenings widget to open an

update, you can touch the social network’s icon to open its Web site.

Note: Your network or other factors might affect the

speed of widget updates.

Happenings

Edit & delete accounts

GHI

ABC DEF

MNO

TUVPQRS WXY

123

JKL

Call

10:47

Dialer

Recent

Frequent

Spd dial

Speed Dial List

Touch to open, then touch to add or edit.

Delete

Touch to delete a digit you entered.

Recent

Calls List

Touch to open,

then touch an

entry to call.

Frequent

Calls List

Touch to open,

then touch an

entry to call.

Call

Enter a phone number & touch here to call it.

Open Your

Contacts

Find it: Menu > Settings > Accounts

Touch and hold an account, then touch Open account

to edit it, or touch

with its contacts and messages).

Note: You can’t delete your MOTOBLUR or Google

accounts. They are locked when you set them up.

Delete account to remove it (along

Calls

it’s good to talk

Quick start: Calls

Dialing options

Find it:

Dialer

13Calls

In-call options

Alex Pico

Mobile (555) 555-2505

Just found $100 on the street! Dinner on me tonight!

End call

SpeakerMute

Active call ( 00:12 )

Call Timer

Mute

Touch to mute or unmute the call.

End Call

Touch to hang up.

Speakerphone

Touch to turn the speakerphone on or off.

Dial Pad

Touch to open a dial pad, to enter numbers during a call.

Slide to Answer

Press Power/Lock button to ignore

During a call, touch Menu to choose

pad

, New call, Use Bluetooth, and End Call, or to wake

up the touchscreen if it’s dark.

Tip: You can touch Home or Back to hide the

active call display. To reopen it, touch

Make & answer calls

To make a call, touch Dialer, enter a number,

then touch

14 Calls

Call.

Mute, Dial

Dialer.

Tip: To enter the international dialing code, touch and

hold . To add a pause or wait after numbers, touch Menu .

To answer a call, drag

Answer to

the right (when your phone is unlocked,

Answer is just a touch

button).

End calls

Touch End call.

Note: When you hold your phone

to your ear, the display goes dark to avoid accidental touches. When you move your phone away from your ear, the display lights up again.

SpeakerMute

End call

Speed dial

Find it: Dialer > Spd Dial

• To call a number, touch it.

• To add, edit, or clear entries, touch Menu .

Handsfree

Note: Using a mobile device or accessory while

driving may cause distraction and may be illegal. Always obey the laws and drive safely.

During a call:

• To use the speakerphone, touch Speaker.

End call

SpeakerMute

• To use a Bluetooth® device, touch Menu >

Bluetooth

Use

Mute

To mute the current call, touch Mute.

Enter numbers during a call

To enter numbers during a call,

touch and then touch the dial

pad.

Recent calls

Find it: Dialer > Recent

• To call a number, touch it.

• To send a text message, create a contact, add the

call to speed dial, or remove the call from the call log, touch and hold an entry.

• To filter the list, touch the view name (like

All calls)

at the top.

• To clear the list, touch Menu >

Clear List.

Frequent calls

Find it: Dialer > Frequent

• To call a number, touch it.

• To speed dial, call the contact, or view the contact,

touch and hold an entry.

Conference calls

To start a conference call, call the first number. After they answer, touch Menu > next number. When the next number answers, touch

Join calls.

New call and call the

Your phone number

Find it: Menu > Settings > About phone > Status

My Phone number

Emergency calls

Note: Your service provider programs one or more

emergency phone numbers (such as 911 or 112) that you can call under any circumstances, even when your phone is locked. Emergency numbers vary by country. Your pre-programmed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

1 Touch Dialer. (If your phone is locked, touch

Emergency Call.)

2 Enter the emergency number.

Call to call the emergency number.

3 Touch

15Calls

Note: Your mobile device can use AGPS satellite

Contacts

StatusHistory A-Z

Alex Pico

Mariana Bukvic

Luke Carmody

Dan Smith

Keith Zang

Kate Shunney

Group

Touch Menu to choose which group to show (like All, Favorites, or Facebook).

Create Contacts

Views

Touch a list view to show:

History - recently used A-Z - list without status Status - list with status

Contacts List

Touch to view contact information. Touch & hold to call, send a text message, & more.

signals to help emergency services find you (see the

important legal and safety information packaged with

your phone).

Contacts

contacts like you’ve never had before

Quick start: Contacts

Find it: Contacts

16 Contacts

Tip: To search the list, open your phone (or touch and

hold Menu to open a display keypad), then type a name. When you flick or drag this list, a scroll bar appears on the right. Drag the scroll bar to move the list faster.

Call, text, or email contacts

Find it: Contacts

For Call, Send Text Message, Email, View contact, or

other options, touch and hold the contact.

View & use contacts

With a MOTOROLA DEVOURTM with MOTOBLURTM,

you’ll know what everybody’s up to and when. Every

time you pick up a call, check a message, or look up a

friend’s contact info, sure, you’ll see their name and

number, but you’ll see their social network status and

smiling face, too.

Find it:

• To filter the contacts by group (All, Facebook, and so

on) touch the filter name at the top.

Tip: To change which account provides the pictures

for your Menu >

Picture source.

• To change the list view, touch

used), status) at the bottom.

• To find a contact, just type the name.

Touch a contact to open its details. To start a call or message, just touch a phone number or other info.

Contacts

Contacts, from the home screen touch

Settings > Accounts > Menu

History (recently

A-Z (list without status), or Status (list with

You can touch History, Info, or Happenings at the bottom of the screen to see more.

Edit or delete contacts

Find it: Contacts

Touch the contact, then touch Menu > Edit or

Delete. You can set a ringer, address, and other details

that will be saved on your phone and your MOTOBLUR account.

Where are contacts edited or deleted? Your phone

edits the contacts in its memory, and also updates your MOTOBLUR account.

Link contacts

You might have two Contacts for the same person, such as a friend with two email addresses. To combine these two contacts:

Find it:

Touch a contact to open it, then touch Menu

Link contact and touch the second entry. Your

> MOTOBLUR account remembers this connection.

Contacts

17Contacts

Create contacts

Adam Aaronson

Emails

Phone

First Last

Add contact

Other

Mobile

Phone

Touch Mobile to

choose a different

type for this entry.

Touch + to add

another entry.

Touch - to remove

this entry.

To see more details, flick up.

Find it: Contacts >Menu >Add contact

Open your phone to type the name and details.

When you’re finished, touch Menu >

18 Contacts

Save.

Where are contacts saved? Your phone saves new

contacts in its memory, and also updates your MOTOBLUR account. So, if you get another MOTOBLUR phone, you can just log into MOTOBLUR to download your contacts and update your accounts:

Contacts, touch Menu > Settings to choose

In which accounts are updated with new contacts.

Synchronize contacts

When you change one of your Contacts, your phone automatically updates your MOTOBLUR account online. Also, your phone updates your

Contacts and

MOTOBLUR account whenever you change a friend in your social networking accounts.

So, you don’t have to do anything to synchronize your

Contacts with your other accounts! MOTOBLUR takes

care of it for you.

My details

Find it: Contacts >Menu >View my

details

To edit details, touch them.

Groups

8:34 PM

Alex Pico

Some guys have all the luck - me... Right now, you’re busy flexing...

Sep 25

Keith Zang

Job It’s only a freelance gig, but it pays...

Sep 25

Kate Shunney

I have so much energy today, I have no IDEA why.

Universal Inbox (4)

Sep 25

Seth Rementer

The cinnamon bun place is right next to the store. It’s like 8 hours...

Create Message

Touch to create a new message, & see a list of you drafts (indicated by the number).

Message List

Touch to open a message. Touch & hold to move, delete, & more.

Check for Messages Now

Message Type

Message Status

Icons indicate a message: unread urgent has attachments

You can put your Contacts into groups that you create

(like “friends,” “family,” or “work”). Then, you can find

contacts faster by showing one group at a time.

To create a group in your

Add group. Enter a group name, then touch Add to

add members.

To show only one group in your

Contacts at the top of your screen and choose the

group name.

Contacts, touch Menu

Contacts, touch

Messaging

sometimes it’s best to text, or IM, or email . . .

Quick start: Messaging

Find it: > Messaging > Universal Inbox

Tip: To see more messages, flick or drag up.

Read & reply to messages

Find it: > Messaging > Universal Inbox

Note: Universal Inbox shows all of your messages

together—text, email, and social networking

19Messaging

messages. To show only one type of message, touch a

Messaging

message account type instead of

Universal Inbox.

• To open a text message or social networking

message and all of its replies, touch it.

• To respond to a message, just open it and enter

your response in the text box at the bottom.

To forward a text message, touch and hold a message in the conversation, then touch

message

Forward

For email, touch to choose a reply or forward option.

• To open options, touch and

hold a message.

Tip: Try the

Messages widget in “Widgets” on

page 27.

Create messages

Find it: > Messaging

Choose a message type. Then,

enter the recipient and message. In text messages

and emails, touch Menu for options like

Attach Files.

20 Messaging

Insert... or

Send & receive attachments text message attachments

To send a file in a message, open a new message and touch Menu >

When you receive a message with an attachment, open the message and touch the file name to download it. Then, touch the name again to open it. Some file formats can be converted to HTML for faster viewing, and your phone will show a button that says

Get HTML version.

Tip: To send and receive large attachments faster, use

a Wi-Fi connection, in “Wi-Fi” on page 50.

Insert.

Set up messaging

To add email accounts, touch Menu > Settings

Accounts > Add account.

Corporate Sync is for Exchange server work email

•

accounts. Enter details from your IT administrator.

Tip: You might need to enter your domain name

with your user name (like domain/username)

Note: Some work accounts might require you to

add a password lock to your phone, for security. To stop an account from showing the contacts you create on your phone, touch Menu > under

Settings, then uncheck the account

New contacts.

Contacts, touch

• Email is for most personal email accounts. For

account details, contact the account provider.

Note: While you are using a W i-Fi network, you

cannot access

Yahoo Mail accounts. You can still

use your browser to see these accounts at mail.yahoo.com

To change your settings, touch >

Messaging

> Menu , then touch:

Manage accounts to change your user name or

•

password (or server settings, for email).

Edit Universal Inbox to choose which accounts

•

show messages in the

Messaging Settings to set the notification for each

•

Universal Inbox.

account type (along with other preferences, for email).

To g e t Gmail™ in your Messages widget and

Universal Inbox, you’ll need to add it as an Email

account: Touch >

then touch

Manage accounts > Add account > Email

Messaging >Menu ,

and enter your Gmail™ details. If you added your

Google account too, turn off its email sync to avoid

duplicate email notices: Touch >

Accounts, touch

your Google™ account, and touch the checkmark to

Gmail syncing through the Google application.

turn off

(It will continue to sync through MOTOBLUR™ if you

set up Gmail as a MOTOBLUR email account.

Tip: For social network accounts, see “Add accounts”

on page 12.

Instant messages

To send and receive instant messages, you can use an instant messaging app or your browser.

• To download and use an instant messaging app,

touch Home >

Communication, then choose an app for your

Market > Apps

provider. Once you download the app, you’ll see it in “App menu” on page 11.

• If you don’t see an app for your IM provider, you can

use your Web browser. Touch Home >

Browser >Menu >Go, then

enter your provider’s Web site. Once you’re there, follow the link to sign in.

Note: Your IM options will depend on your IM provider.

To browse instant messaging apps from your computer, go to www.android.com/market

Voi cema il

When you have a new voicemail, shows at the top of your screen. To hear the voicemail, touch , then touch and hold .

If you need to change your voicemail number, in the home screen touch Menu >

settings

> Voicemail.

Settings > Call

21Messaging

Text entry

SYM

think keyboard, now think smaller

Typing tips

To .. .

Enter symbols chosen from a list

Enter special function characters in the corners of keys

Enter several special

function characters, until

you touch Alternate again

Enter one capital letter Press Shift

Enter only capital letters, until you press Shift again

Select text (only in certain

apps)

Cut, Copy, or Paste text

you selected

22 Text entry

Press Function +

SYM

Shift

Press Function

Press Function twice

SYM

Press Shift twice

Hold Shift +

SYM

touch Optical Navigation Key

Touch and hold the text box to open the

Edit text menu

To...

Select text Hold Shift +

touch Optical Navigation Key

Cut, Copy, or Paste text

you selected

Delete a character (hold to

Touch and hold the text box to open the

Edit text menu

Press Delete

delete more)

Delete the current line Press Function +

Delete

Jump to the beginning/end

of a line

Press Function + Optical Navigation Key

Start a new line (email or

Press Return

social networking) or send the message (text messages)

To change your text entry settings and see the dictionary of terms you’ve used, from the home screen, touch Menu >

Settings > Language & text.

Touchscreen keypad

New message

To:

Subject:

Send Discard

Font

Bold, Italic, or Underline

Bullet FontSmiley

When your phone is closed, you can open a display

keypad by touching a text field, or touching and holding

Menu . To close the keypad, touch Back .

wer ty u i o p

dfghjkl

Shift

Symbols/

Numbers

Touch to open a

keypad for

symbols and

numbers.

zxcvbnm

?123

Space

To change your settings for this keypad, from the home

screen, touch Menu >

Android keyboard.

Settings > Language & text

DEL

Delete

Return/ Line Feed

Format text in emails

You can format your email messages. To select text for formatting, press and hold Shift , then touch the Optical Navigation Key.

SYM

Text entry settings

When you use the touchscreen keypad, your phone suggests words from your dictionary and chosen language. Your phone also automatically enters apostrophes in some words, like “dont.”

Find it: Menu >

• To edit your dictionary, touch User dictionary.

• To change the language and the style for your

touchscreen keypad, touch

Settings > Language & text

Select language.

23Text entry

• To change the sounds, corrections, and other

settings for your touchscreen keypad, touch

keyboard

Android

• To change the automatic correction settings for your

full keypad, touch

24 Tips & tricks

Device keyboard.

Tips & tricks

a few handy hints

Shortcuts

To...

Return to the home

screen

See recently dialed numbers

Sleep/wake your

phone

Set lock screen Touch Menu >

Google™ search Touch Menu >

Show last few apps used

Tu rn airplane mode on/off

Tu rn Bluetooth® on/off

Tu rn Wi-Fi on/off Press and hold Power

Touch H o m e .

To uc h

Recent.

Dialer

To sleep, press Power . To wake, touch Menu .

Display & security

Screen lock.

Settings

Search.

Touch and hold Home .

Press and hold Power

Airplane mode.

Press and hold Power

Bluetooth.

Wi-Fi.

To .. .

SYM

Tu rn GPS on/off Press and hold Power

GPS.

Zoom in to select a

Touch > link.

link on a web page

Scroll list up one

screen

Scroll list down

one screen

Sync contacts from

your desktop / laptop to your phone

Show email or updates from a

group of friends

Press Shift > Optical Navigation Key up.

Press Shift > Optical Navigation Key down.

Use the MOTOBLUR portal: www.motorola.com/mymoto blur.

Touch

Contacts

>Menu > Create a group, then open the group (touch the top of your

History to see this

Touch group’s messages, or to see their updates.

Change which messages appear in the Universal Inbox

Open the Universal Inbox then touch Menu >

Universal Inbox

Add Group.

Contacts at

Contacts list).

Status

Edit

To...

Add a shortcut on

your home screen for an app or contact

Touch and hold an open area on your home screen to open

Add to Home screen

the menu, then choose

Shortcuts. Then, you can

choose from the

Applications or Contact lists.

Move a widget or shortcut

Touch and hold the widget or shortcut until you feel a vibration, then drag it to where you want.

Delete a widget or shortcut

Touch and hold a widget or shortcut until you feel a vibration, then drag it to the trash can at the bottom of your screen.

Battery tips

Your phone is like a small computer, giving you a lot of information and apps, at 3G speed, with a touch display! Depending on what you use, that can take a lot of power.

Power Control widget is a simple way to

The enable/disable Wi-Fi, Bluetooth® wireless, GPS, Sync (turns on/off all active accounts, Google, and

25Tips & tricks

Exchange), and display brightness. To add a Power

Control

widget, touch Menu > Add > Widgets

Power Control.

You can also conserve battery life by touching

Menu >

Profile

Settings > Battery Manager > Battery

> Battery Saver Mode.

There are many more ways to save battery life

between charges. You can reduce:

• recording or watching videos, listening to music, or

taking pictures.

• widgets that stream information to your home

screen, like news or weather (see “Use & change your home screen” on page 9).

• unused online accounts that you registered with

MOTOBLUR (see “Edit & delete accounts” on page 13).

• GPS, Wi-Fi, and Bluetooth® use: Press and hold

Power to open the Power key menu, then touch items to turn them off or on.

• Email updates: Touch

Messaging settings > Email > Get new email

Every hour.

• Google™ app updates: Touch Menu >

Google Synchronization > Background data.

26 Tips & tricks

Messaging >Menu

Settings

• network searching: If you are out of coverage, to

keep your phone from looking for networks, press and hold Power to open the Power key menu, then touch

• display brightness: Touch Menu >

Airplane mode.

Settings

Display & security > Brightness > (dimmer

setting).

• display timeout delay: Touch Menu >

Display & security > Screen timeout > (shorter

Settings

setting).

Personalize

add your personal touch

Widgets

Create widgets

1 Find an empty spot on your home screen where you

want to add a widget. You can flick left or right to open other panels on your home screen.

2 Touch and hold the empty spot until you see the

Add to Home screen menu.

Widgets.

3 Touch

4 Touch the type of widget. If necessary, enter the

widget settings.

Set up widgets

You can customize some widgets. Touch a widget to

open it, then touch Menu :

Happenings: Update your status, choose which

•

accounts appear in this widget, or manage your accounts (the same as “Add accounts” on page 12).

Messages: Change the widget name or choose how

•

long it shows new messages. To add email accounts, “Set up messaging” on page 20.

• Music: Set this widget to an artist, album, song,

playlist, or just touch Menu >

Party shuffle.

There’s more about “Music” on page 33.

News: Change the widget name, choose how long it

•

shows new stories, or choose a news source. To choose a source, touch , then choose preset

Bundles or Channels, or choose Custom to enter a

URL for a

Weather: Change temperature units or add

•

Webpage or an RSS feed.

locations. To add locations, touch , enter a city, and touch

Search. When you open the weather

widget, flick left to see other locations you added.

Note: Some apps have custom widget types that you

can add and set up after you install the app.

Ringtones

To personalize your ringtones:

Find it: Menu >

Phone ringtone or Notification ringtone

To set your ringer and vibrate options:

To change your ringtone to silent, slide the ringer off switch down.

Tip: To use a song as a ringtone,

touch > song name, then touch

Settings > Sound & ringtones

Music > Songs, touch and hold the

Use as phone ringtone.

27Personalize

Sounds

features

set volume for media and videos

Menu >

volume

play tones when using dial pad

Menu >

touch tones

play sound on screen selection

Menu >

selection

Settings > Sound & ringtones > Media

Settings > Sound & ringtones > Audible

features

set orientation

Menu >

Orientation

Settings > Display & security

set animation

Menu >

Animation

Settings > Display & security

Date & time

Set date, time, time zone, and formats:

Find it: Menu >

Settings > Date & time

Display settings

features

notification LED

Blinks to tell you that a notification has been received. Menu >

Notification LED

set display brightness

Menu >

Brightness

28 Personalize

Settings > Display & security

Language

Set your menu language:

Find it: Menu >

Select language

Settings > Language & text

Photos & videos

6842

3MP

Before taking photo, touch Menu to choose special effects or change camera settings.

After taking photo, touch

the screen to see options.

see it, capture it, share it!

Photos

Take & share photos

Take that family photo, and post it online for everyone

to see.

Find it: Press

Tip: While the camera is active, switch to camcorder

by touching Menu >

Camcorder.

Note: Photos are stored on your microSD memory

Picture Resolution is 3MP, unless you change it

card. (see “Photo options” on page 29).

To take the photo, press Camera .

Touch the screen, then:

• To set the photo as a wallpaper, contact photo, or

social network profile photo, touch

Set as.

• To send the photo in a message or post it online,

Share. For more info on sharing your photos,

touch see “Share your photo gallery” on page 30.

• To delete the photo and return to the viewfinder,

Delete.

touch

Photo options

To create special effects, in the viewfinder, touch Menu >

Effects, then flick left or right to select

Normal, Aqua, Negative, Sepia, or Black and White.

To change camera settings, in the viewfinder, touch Menu >

Settings:

options

Picture Size Store photos at 3MP, 2MP, or 1MP.

Store location in pictures

Save the details of where the photo was taken.

29Photos & videos

options

All Pictures (10/43) 2010-07-12 12.00.00

201

200

432

)

2010-0

My Pictures All Pictures

Picture Dates

Touch on the left side to open the date list, then drag the dates to find pictures.

Videos

Record & share videos

Find it: >

Camcorder

Tip: To send your video in a message, set the video

quality to Menu >

Low (for MMS messages): Touch

Settings > Video Profile.

To record the video, press Camera . To stop the

video recording, press Camera again. Touch the viewfinder to see a thumbnail of the video you’ve just taken. Touch the thumbnail, then:

• To send the video in a message or post it online,

Share. For more info on sharing your photos,

touch see “Share your video gallery” on page 32.

• To delete the video, touch

Delete.

Play your videos

Find it: >

Video Gallery

Tip: While the camcorder is active, switch to camera

by touching Menu >

Camera.

31Photos & videos

Share your video gallery

Find it: >

Videos > video

To send your video in a message or post online:

1 Touch & hold a video, then touch Share.

2 Choose how you want to share—like

Messaging

Picture Gallery > Menu

Text

, Facebook, or MySpace.

Manage your videos

Find it: >

Video Gallery

To delete a video, touch and hold a video, then touch

Delete.

32 V CAST Videos

V CAST Videos

now playing on your phone

Quick start: V CAST Videos

Find it: > VCAST Videos

11:35

CAST Videos

Kids Entertainment

Sports Music

News Comedy

Information Pop Culture

Latino Women

V CAST Videos is a high quality video content delivery service. With V CAST Videos, enjoy your favorite full length TV shows, plus the latest in news, sports, weather, and live entertainment, on demand and right to your phone.

Browse videos

Music Artist

Album Title

Song Title

1:14 3:45

Artists Albums

Songs Playlists

Music

Music ControlsCategories

Touch a category, then

touch a song or playlist.

From the VCAST Videos menu, touch a category, then

flick up or down to browse through a list of videos.

Download videos

Note: Not all videos can be downloaded.

1 From the VCAST Videos menu, touch a category,

then flick up or down to the video you want to download.

2 If charges are to be applied, you’ll see a notification

screen. Touch

3 Follow the prompts to begin downloading the video.

It will be saved to

When the download is finished, your phone shows

Download Complete. Play Video Now?.

4 Touch

VCAST Videos menu.

the

To play a downloaded V CAST video that you saved to

Video Gallery, see “Play your videos” on page 31.

Share, edit, or delete videos

Find it: > Video Gallery

Touch and hold a video, then touch Delete.

Yes to accept charges.

Video Gallery on your phone.

Yes to view the video, or touch No to return to

Music

when music is what you need...

Quick start: Music

Touch, touch, play—instant music. Just open your music library, then select what you want to play.

Find it: >

Tip: When a song is playing, you can add it to a playlist

by touching Menu >

Music

Add to playlist.

33Music

Set up music

What music transfer tools do I need?

To put music on your computer and then load it on

your phone, you need:

• Microsoft™ Windows™ PC or Apple™

Macintosh™.

• USB data cable (included with your phone).

• memory card (8 GB—included with your phone)

Your music is stored on your memory card. Your phone supports removable microSD memory cards up to 16 GB capacity. To make sure your memory card is installed, go to “Assemble & charge” on page 4.

Tip: To see the available memory on your memory

card, touch Menu >

Mass Storage, & Phone storage

What music file formats can I play?

Your phone can play many types of files: AAC, AMR,

H.263, H.264, MP3, MPEG-4, WAV, WMA, WMV,

AAC+, and MIDI.

Note: Your phone does not support any DRM

protected files.

34 Music

Settings > SD card, USB

What headphones can I use?

Your phone has a 3.5mm headset jack for wired stereo listening. You can go wireless with Bluetooth® stereo headphones or speakers (see “Bluetooth® wireless” on page 48).

Get music

Transfer using USB

To use a USB cable, see “Manage files with a USB connection” on page 51.

Transfer using Motorola Media Link

Motorola Media Link (MML) and Moto Phone Portal bridge your digital world by connecting your phone, computer, and the Web, so you can manage the media on your phone and back up your media to your computer. MML supports iTunes® and Windows Media® Player song lists.

For more information, see “Manage files with a USB connection” on page 51.

Play music

Music library

Open your music library, then select what you want to play.

Find it: > Music

Artists Albums

Songs Playlists

Music

Music Artist

Song Title

V CAST Music with Rhapsody®

What’s New What’s Hot

Features Recommended

Browse

Search My Music

Download

11:35

CAST Music

Rhapsody

your music collection

Subscription, Wireless, & PC Download

Quick start: V CAST Music with Rhapsody

Note: Your phone must be in an 3G coverage area to

download music.

Find it: >

V CAST Music | Rhapsody

Buy music with your phone

From the V CAST Music with Rhapsody menu, select

What’s New, What’s Hot, or Recommended to see lists

of specially-selected songs. Or select search for specific songs.

You can preview a song by selecting and touching the song title.

When you find the song you want:

1 Touch Buy.

Note: You are charged when you select

Song

. You can purchase the same music multiple

times.

2 Review the items and price, then confirm your

purchase by touching

Buy This Song.

You’ll receive a confirmation of your purchase and that the music is ready for download.

Download Now to save the music to your

3 Touch

phone.

If you select

Download Later, you can download the

the purchased music later by selecting from the V CAST Music with Rhapsody main menu.

Browse to

Buy This

Download

Note: If you can’t connect, contact your service

provider.

Transfer music from a computer

You can use V CAST Music with Rhapsody to transfer songs from a computer to your phone through a USB

37V CAST Music with Rhapsody®

cable connection. You can purchase these songs using

V CAST Music with Rhapsody or import them from

your CD collection.

To transfer music from a computer to your phone, you

need the Windows® XP, Windows Vista®, or

Windows 7 operating system and an active internet

connection.

To download V CAST Music with Rhapsody to your

computer for free, use your computer’s web browser

to go to http://www.verizonwireless.com/music

. Follow the on-screen instructions to select, download, and install V CAST Music with Rhapsody.

Import songs from audio CD

1 On your computer, launch V CAST Music with

Rhapsody.

2 Insert an audio CD into your computer’s CD ROM

drive.

The tracks on the CD are listed in the window. (You may need to enter artist name and other information for the tracks.)

3 Select the tracks you want to import or by clicking

the check box next to them.

Select all tracks by checking the check box above the list of tracks.

4 Click on the “Import CD” button.

38 V CAST Music with Rhapsody®

The songs you selected are imported to the My Library section of the V CAST Music with Rhapsody PC software.

Sync music from your PC

To sync music from your PC to your phone:

1 On your computer, launch V CAST Music with

Rhapsody.

2 Connect the USB cable (included) to your phone and

to an available USB port on your computer.

The USB connection screen will appear on your phone.

3 On your phone, select

Ok. Your phone should display Connecting

touch

Windows Media Sync and

until the connection to the PC is complete.

On the PC, you should see the phone listed in the “Sources” area of the V CAST Music with Rhapsody screen.

4 On your computer, drag songs or playlists that you

want to transfer to the phone listing in the “Sources” area.

5 On your phone, when synchronization is complete,

press Done on the Sync Music screen.

6 Disconnect the cable from the phone and the

computer.

Play your music

To play your music, and for other information on how to use the music player, see “Play music” on page 34.

Web

you don’t need a computer, surf the web with your phone

Quick start: Browser

Find it: Home > Browser

mw3.vzmwap.com: Verizon MW3.0

100% FIBER OPTICS STRAIGHT TO THE HOME

VZ Services My Web Channels

Today’s Weather

Basking Ridge, NJ

32.1°F

Jan 6th, 2010

results by

Hi: 37° Lo: 21°

10:47

Note: If you can’t connect, contact your service

provider.

39Web

Connect

Your phone uses the mobile phone network (over the air) to automatically connect to the Web.

Note: Your service provider may charge to surf the

Web or download data.

To use a wireless network, touch Menu >

Wireless controls. Touch Wi-Fi to turn it on, then

Wi-Fi settings to search for nearby wireless

touch

Settings

networks. Touch a network to connect. There’s more in “Wi-Fi” on page 50.

Web touch tips

Magnify

In Web pages, when you scroll (drag or flick), a magnify icon appears at the bottom of your screen. Touch the icon to open a magnifying window that you can drag.

Select links

When you touch a link, your phone outlines it. If you touch and hold the link, your phone shows options, like

Open in new window or Bookmark link.

40 Web

Browser options

Touch Menu to see browser options:

options

Go Enter the Web address (URL) you

want.

Tip: Some sites are optimized for

mobile phones, and they use an “m” in the URL instead of “www” (like m.youtube.com

Bookmarks Shows a list of your bookmarks.

Add bookmark... to add the

To uc h

current page to your list.

New window Opens a new window.

Refresh Reloads the current page.

More Shows browser options, like Find

on page

, Select text, Page info,

Share page, Downloads, and Settings.

Download apps

Warning: Apps downloaded from the Web can be

from unknown sources. To protect your phone and personal data, only download apps from sources you trust, like “Android Market™” on page 47.

Note: All apps downloaded are stored in your phone

Yo u Tu be ™

go and create your own classic

Quick start: YouTube

Find it: > YouTube

The YouTube user-generated content Web site lets you share videos with YouTube users everywhere. You don’t need a YouTube account to browse and view videos.

41YouTube™

Note: If you don’t have a YouTube account, visit

www.youtube.com

to find out more. To create an

account or sign in, go to “Your account” on page 42.

Watch YouTube videos

See popular video categories, like Featured, Most viewed, and Top rated. Touch a category, then touch the video to start playing it.

To see more video categories, touch Menu

Categories.

Search for YouTube videos

Find it: > YouTube >Menu >Search

Enter text, then touch Search.To clear your search history, touch Menu >

history

Settings > Clear search

Share videos

Send someone a link to a video that you are watching.

1 Touch Menu > Share.

Tip: Just touch and hold a video to open the

menu.

2 Address and complete your email, then touch

42 YouTube™

Send.

Your account

Find it: >

account

1 To create your YouTube account, touch the “Don’t

have a YouTube account? Click here to create one” link.

If you already have a YouTube account, enter your username, password and touch

2 For a new account, enter a username, and complete

the fields, then touch

Upload videos

Find it: >

1 Touch the video you want to upload. You can change

the video title, description, set the access, and add tags.

Upload.

2 Touch

YouTube >Menu >My

I accept.

YouTube >Menu >Upload

Maps

44 West Street

E Ontario St

E Onta

E Ohio St

N Rush St

N Park St

N New St

N Wabash Ave

N Dearborn St

N Clark St

E Grand Ave

Wacker Dr

E Randolph St

N Micigan Ave

rD submuloC N

W Lake St W Lake St

E Wacker Pl

State/Lake

Grand Red

Lake

Randolph St Metra

Randolph/

Wabash

Washington-Blue

E S WaterSt

Water St

Search Directions Map mode

My Location Clear map More

Map View

Drag or flick to scroll. Tap to show zoom.

Touch to open a menu where you can open a Web page, your bookmarks, a new window, and more.

where you are, where you’re going

Quick start: Maps

Where am I? What’s around here? Don’t worry—let Maps help you explore your surroundings and find what you’re looking for.

Maps

E S W

Find it: >

Ontario St

io St

nd Ave

ois St

ubbard St

rk/Lake

ubway

andolph St

Set your location sources

Set your phone to determine your location using GPS satellite signals (highly accurate, but uses battery power) or using the mobile network (less accurate, but conserves battery power).

To set your location, touch Menu >

Location & security > Use GPS satellites and/or Use

wireless networks

Settings

Find your location

Note: Don’t forget to set your location sources.

From the main Map screen, touch Menu >

Location

. Your location is shown on the map as .

The bigger the circle, the less accurate the location.

Find any location

1 Touch Menu > Search.

2 Enter text in the search box, like an address,

business, or city, then touch .

Tip: If it’s an address you have visited before, select

from the list shown.

3 Touch the search box to view all the results, then

touch the one you want.

Get directions

1 Touch Menu > Directions.

43Maps

2 Enter a starting point address or touch and select

My current location, Contacts, or Points on map.

3 Enter an end point address or touch and select

Contacts or Points on map.

4 Select your mode of transport (car, public transport

or walk), then touch

Go. Your directions are shown

as a list. To view your directions on a map, touch

Show on map.

5 When you have finished, touch Menu >

Clear map.

Enhanced views

From the Maps home screen, touch Menu

Layers, then touch:

Traffic—If available in your area, real-time traffic

•

conditions are shown on the roads as color-coded lines.

Satellite—See the map on top of an aerial photo.

•

44 Latitude

Latitude

where are your friends & family?

Join Latitude

Keep track of where your friends and family are on Maps. Plan to meet up, check that your parents got home safely, or just stay in touch.

Don’t worry, your location is not shared unless you agree to it. You need to join Latitude, and then invite your friends to view your location or accept their invitations. When using Maps (in any mode except in Street View), touch Menu > the privacy policy and if you agree with it, touch

& Share

Add & remove friends

Find it: > Maps > Menu > Latitude

To add friends:

1 Touch Menu > Add friends.

Select from Contacts, then touch a contact.

2 Touch

Or, touch email address.

3 Touch

If your friends already use Latitude, they’ll receive an email request and a notification. If they have not yet joined Latitude, they’ll receive an email request that

Add via email address, then enter an

Add friends.

Join Latitude. Read

Allow

invites them to sign in to Latitude with their Google

11:35

Events: Theater & Live Performances

45.2mi

Dearly Departed

77.1 mi

Heywood Banks

78.7 mi

JR Brow

99.8 mi

Bridal Expo

109 mi

The Foreigner

VZ Navigator

Denton,IL

Near

5555 Tindale Dr

Navigate

Find Share

Content Carousel

Flick left or right to see useful information such as local weather, gas prices, movies, & more.

account.

To remove friends:

1 Touch Menu > Latitude to show your friend’s

list, then touch a friend in your list.

Remove this friend.

2 Touch

Share location

When you receive a request to share location details you can choose to

Share only city level information, or Hide from this friend

Share best available information,

Hide your location

To hide your location from a friend, touch Menu

Latitude to show your friend’s list. Touch your

> contact name, then touch Menu >

settings

> Hide your location.

Turn off Latitude

Touch Menu > Latitude to show your friend’s list. Touch Menu >

Latitude

Edit privacy

Edit privacy settings > Turn off

VZ Navigator®

find your way, all the way

Quick start: VZ Navigator

VZ Navigator makes it easy for you to get directions, view maps, check out weather, find gas prices, look for movies and events, and get voice-announced step-by-step traffic enhanced directions.

Find it: >

VZ Navigator

45VZ Navigator®

Find a location

1 From the main VZ Navigator screen, touch Find.

2 Select a location from

Address, or Airport, then touch . View all the

Places, Movies, Events,

results and touch the one you want

Or, enter text in the search box, like an address, business, or city, then touch .

Tip: If it’s an address you have visited before, select

it from the list shown.

When VZ Navigator finds the location your want, touch the icons at the bottom of the screen to:

• get directions to the location

• see the location on a map

• share the location with a friend

• mark the location as a favorite for easy retrieval later

You can also touch Menu for more useful options.

Get directions

1 From the main VZ Navigator screen, touch

Navigate.

2 Enter a starting point address and touch

Current location, Recents, Favorites,

touch

Contacts, or Airport, and select from the list shown.

46 VZ Naviga tor®

Find, or

3 Enter an end point address and touch Find, or touch

Current location, Recents, Favorites, Contacts, or Airport, and select from the list shown.

Navigate.

4 Touch

VZ Navigator now gives you voice-prompted turn-by-turn directions in a map view. You also see

Arrival Time, Distance Traveled, and the length of any

delays.

Touch Menu to see these useful options:

3d View gives you an enhanced map view of your

•

route.

Detour to display information about traffic

• Touch

congestion on your route, or enter information about any detour you will take intentionally.

Trip Summary shows a map of the entire route and

•

lists other information about the trip.

List displays turn-by-turn directions as addresses

•

and highway numbers, with no map view.

Incidents lists occurrences along the route such as

•

lane closures and traffic accidents.

Find lets you see points of interest along your route.

•

More, then touch Share to send your location

• Touch

or destination in an email message.

You can quickly send email messages to share your current location, a location that you specify, or a point of interest that you select. From the screen, touch

Share.

VZ Navigator main

Apps for all

get the app you want

Android Market™

Find it: Home > Market

Get all the fun games and cool apps you want! Android Market provides access to applications developed by developers worldwide, so you can find the app you want. If you need help or have questions about Android Market, touch Menu >

Browse & install apps

Scroll to and touch the app you want to install. Then,

Install (if app is free) or Buy.

touch

Manage & restore apps

Find it: Menu > Settings > Applications

Manage applications

Touch an app in the list, then touch Uninstall (for apps you downloaded),

To reinstall any downloaded items, touch Home

Market > My downloads.

Clear cache, or other options.

Important customer information

Please be advised that many services and applications offered through this unique device are provided by

Help.

47Apps for all

Google and various application developers. If you use,

Bluetooth devices

Bluetooth settings

A555

Device name

Pair with this device

Motorola HS850

Make device discoverable

Discoverable

Scan for devices

Bluetooth

Touch to turn on & off & to scan.

Touch to re-scan.

Touch to connect.

link to or download a Google service, or an application such as a non-Verizon Wireless location based GPS-type service, chat room, marketplace or social network from this device, you should carefully review the terms of such service or application. If you use any of these non-Verizon Wireless services or applications, personal information you submit may be read, collected, or used by the service or application provider and/or other users of those forums.

Motorola, Inc. and Verizon Wireless are not responsible for your use of those applications or information you choose to submit or share with others. Specific terms and conditions, terms of use, and privacy polices apply to those applications and services. Please review carefully any and all terms and conditions applicable to those applications and services including those related to any location-based services for any particular privacy policies, risks or waivers.

Your Verizon Wireless customer agreement terms and conditions and certain other specifically identified terms govern your use of any Verizon Wireless products and services.

48 Bluetooth® wireless

Bluetooth® wireless

lose the wires and go wireless

Quick start: Bluetooth wireless

Find it: Menu > Settings > Wireless controls

Bluetooth settings

Turn Bluetooth power on or off

Find it: Press and hold Power > Bluetooth

Note: To extend battery life, turn Bluetooth power

off when not in use.

Connect new devices

Note: This feature requires an optional accessory.

To connect with a new device, you need to pair with it. You only need to do this once for each device—to connect again, just turn on the device.

1 Make sure the device you are pairing with is in

discoverable mode.

Note: Refer to the guide that came with the device

for details.

2 Touch Menu >

Bluetooth settings.

Bluetooth to turn on and scan. If Bluetooth

3 Touch

power is already on, touch

Settings > Wireless controls

Scan for devices.

4 Touch a device to connect.

5 If necessary, touch

0000) to connect to the device. When the

(like

OK, or enter the device passkey

device is connected, the Bluetooth indicator appears in the status bar.

Note: Using a mobile device or accessory while

driving may cause distraction and may be illegal. Always obey the laws and drive safely.

Reconnect devices

To automatically reconnect your phone with a paired device, simply turn on the device.

To manually reconnect your phone with a paired device, touch the device name in the

devices

list.

Bluetooth

Disconnect devices

To automatically disconnect your phone from a paired device, simply turn off the device.

To manually disconnect your phone from a paired device, touch the device name in the devices list, then touch Menu >

Disconnect.

Edit properties

Touch Menu > Settings > Wireless controls

Bluetooth settings > Device name. Enter a name

> and touch

OK.

49Bluetooth® wireless

Wi-Fi

Wi-Fi networks

Wi-Fi settings

Notify me when an open network is available

Network notification

Your network

Add Wi-Fi network

Wi-Fi

Touch to turn on & scan.

Touch to connect.

home, office, or hotspot

Quick start: Wi-Fi

Find it: Menu > Settings > Wireless

controls

> Wi-Fi settings

Note: Your phone's Wi-Fi features and power levels

are not allowed for outdoor operation in France. To avoid unlawful interference with radio signals, do not use the Wi-Fi features in France unless you are indoors.

Use a wireless network for fast Internet access and to download data.

50 Wi-Fi

Turn Wi-Fi on or off

Find it: Press and hold Power > Wi-Fi

Note: To extend battery life, turn off Wi-Fi power when

not in use.

Wi-Fi search & connect

To find networks in your range:

1 Touch Menu > Settings > Wireless controls

Wi-Fi settings.

Wi-Fi to turn on and scan. If Wi-Fi is already

2 Touch

on, touch Menu > networks it finds within range.

Tip: To see your phone’s MAC address or other

Wi-Fi details, touch Menu >

3 Touch a network to connect.

4 If necessary, enter

Wireless password, and touch Connect. When your

phone is connected to the network, the wireless indicator appears in the status bar.

Tip: When you are in range and Wi-Fi is on, you will

automatically reconnect to available networks you’ve connected to before.

Scan. Your phone lists the

Advanced.

Network SSID, Security, and

Memory card & file management

copy photos, music, and more to your phone

Memory card

Note: You need the memory card installed for some

features on your phone, like

Manage files on your phone

Find it: >

Touch a file or folder to open, touch and hold a file to

Delete or Share.

Remove or format your memor y card

Note: Do not remove your memory card while your

phone is using it or writing files on it.

Before you remove or format your memory card you need to unmount it. Touch Menu >

card & storage

> Unmount SD card.

To format your memory card, touch

Warning: All data on your memory card will be

deleted.

Manage files without wires

When you connect your phone to a Wi-Fi network, Moto Phone Portal lets you use another computer on the network to access your phone's files.

Camera.

Quickoffice > Memory card

Settings > SD

Format SD card.

Connect your phone to a Wi-Fi network, then touch

Phone Portal > Wi-Fi enable computer

WiFi enabled and follow the instructions on the

> screen to find your Moto Phone Portal URL. Enter the URL in the browser on a computer on the Wi-Fi network to see your phone’s files.

Manage files with a USB connection

You can manage and transfer files with a USB connection to a PC. Here are two ways to do it:

• Use Motorola Media Link (MML) on your computer

to manage, sync, and back up files.

To use MML, you first need to download it to your PC from: http://www.motorola.com/medialink

• Use “My Computer” on the PC to drag and drop

files between your phone and PC.

Tip: You can also use

On your phone, touch >

Moto PC Tools.

To manage files with a USB connection:

1 With a memory card inserted, and your phone

Phone Portal to manage files:

Phone Portal

showing the home screen, connect a Motorola micro USB data cable from your phone’s micro USB

51Memory card & file management

port to a USB port on your computer. Your phone should show in the status bar.

Note: Make sure to connect the phone to a high

power USB port. Typically, these are located directly on your computer.

Note: The first time you connect to a PC, your PC

may indicate that drivers are being installed. Follow any prompts you may see to complete the installation. This may take a few minutes.

2 On your phone, flick down the USB connection

dialog at the top of the screen and touch

Memory Card

Manage

3 To manage files using MML:

• On your PC, open MML.

• Select a tab to manage

Music. You can back up content with the SYNC

Photos, Videos, or

button, drag and drop content, or upload files to social networking sites. MML supports iTunes® and Windows Media® Player song lists.

To manage files using “My Computer” on your PC:

• Open “My Computer” on your PC and select

the icon for your memor y card folders.

Note: You can’t use the files on your

memory card with your phone while it is connected to the PC.

52 Memory card & file management

• Drag and drop files between your computer and

memory card folders.

4 When you’re done, use “Safely Remove Hardware”

on your PC before disconnecting the USB cable.

Synchronize

keep up-to-date

Google™ data synchronization

Find it: Menu > Settings > Google

synchronization

The Google apps on your phone give you access to the same personal information (emails, events, and contacts) that you have on a computer using Gmail™, Google Calendar™, and Contacts. It’s easy to synchronize the Google apps information you want to keep up-to-date.

Select apps to synchronize

1 Touch Background data and Auto-sync.

Tip: To save battery power do not touch

data

2 Touch the apps you want to synchronize, like

Calendar, or Contacts.

Sync with Microsoft™ Office Outlook

If you use Microsoft Office Outlook on your work computer, your phone can synchronize emails, events, and contacts with your Microsoft Exchange server.

Find it: Menu >

account

> Corporate Sync

Settings > Accounts > Add

Background

Gmail,

1 Enter your username (username@company.com),

password, email address, and ser ver details (server address is the same URL you use to access your company’s email using the Web on your computer).

Note: Contact your business IT department for

server details.

Next.

2 Touch

53Synchronize

Too l s

Alarm

7:00am

Wake Up

8:30am Tuesday

9:00am Tue, Fri

Alarm Clock

stay on top of things

Alarm clock

Find it: > Alarm Clock

To turn on an alarm, touch the check box.

When an alarm sounds, drag

Dismiss to turn it off or touch the

screen to delay.

To add an alarm, touch Menu

Add alarm, then enter alarm

> details.

To set a snooze period, touch the alarm, then touch Menu

Snooze time.

Calendar

Find it: > Calendar

54 Tools

Your calendar events can be viewed in different ways: Touch Menu >

Agenda,

Day, or Week. When you

highlight an event in the day

January 2010

Sun Mon Tue Wed Thu Fri Sat

272829

30 31

10:47

and week views, more details appear.

Add calendar events

From any calendar view, touch Menu >

event

. Enter event details

and touch

New

Save.

Manage calendar events

To edit an event, touch and hold it, then touch

event

. When you’re done, touch Save.

Edit

To delete an event, touch and hold it, then

Delete event.

touch

To go to today, touch Menu >

Today.

Calculator

Find it: > Calculator

Your calculator has two views: basic and advanced. To change your views, touch Menu >

Basic panel. To clear history, touch Menu

Clear history.

Advanced panel

Quickoffice

Voice Command Key

Use Quickoffice to view recent documents and files on your memory card.

Find it: >

Quickoffice

Voice commands

Use voice commands to make calls, send messages, and get other tasks done quickly. Just press the voice command key on the right side of the phone. When your phone prompts you to say a command, speak one of the commands on the screen.

Management

stay in control

Wireless manager

Find it: Menu > Settings > Wireless controls

Manage all your wireless connections: Wi-Fi, Bluetooth®, airplane mode, & mobile networks (“Network” on page 55).

Shortcut: Press and hold Power to display the

power menu—from here you can control Bluetooth power, Wi-Fi and GPS as well as turn the phone off and set airplane mode.

Airplane mode

Use airplane mode to turn all your wireless connections off—useful when flying. Press Power

Airplane mode.

Update my phone

To keep your phone current, software updates may be available. Touch Menu >

System updates to see if your phone is up to date. If

> it isn’t, touch

Update.

Network

You should not need to change any network settings. Contact your service provider for help.

Settings > About phone

55Management

Touch Menu > Settings > Wireless controls

Mobile networks to show options for roaming

> networks, network selection, operator selection, and access point names.

Security

help keep your phone safe

Quick start: Security

Find it: Menu > Settings > Display & security

You have lots of ways to keep your phone safe.

56 Security

Display & security

Security

Screen lock

Display a screen preventing accidental touches

Security lock

Passwords

Visible passwords

Show password as you type

Credential storage

Use secure credentials

Allow applications to access secure certificates and other credentials

Set password

2:55 PM

If you lose your phone, you can log into your MOTOBLUR account from a computer to locate your phone or clear the data on it: www.motorola.com/mymotoblur

Screen lock

Set your phone to display a lock screen, and prevent accidental touches, touch Menu >

Settings

> Display & security > Screen lock. You can also set a

Draw an unlock pattern

security lock to prevent others from using your phone.

To set your security level, touch Menu >

Display & security > Security lock > Security lock

type

Pattern lock - draw a pattern to unlock.

•

Passcode lock - enter a code to unlock.

•

Settings

Note: You can make emergency calls on a locked

phone (“Emergency calls” on page 15). A locked phone still rings, but you need to unlock it to

answer.

Lock pattern

To set the lock pattern, touch Menu >

Display & security > Security

lock

> Security lock type

Pattern lock.

Settings

Follow the instructions to draw your lock pattern.

When prompted, draw the pattern to unlock the phone.

Passcode lock

To set the passcode, touch Menu >

Display & security > Security lock > Security lock

type

> Passcode lock.

Settings

Enter a passcode, then confirm it.

When prompted, enter the passcode to unlock the phone.

Personalize your lock screen

To change your timeout, touch Menu >

Display & security > Screen timeout. If you don't

Settings

touch the screen or press any keys for this amount of time, the screen locks automatically. To unlock, see “Lock & unlock” on page 57.

To change your lock screen picture, touch Menu

Settings > Display & security > Wallpaper settings.

Lock & unlock

To lock the screen/phone:

• Press Power .

• Let the screen time out (don’t touch anything).

• Switch the power off.

To unlock the screen/phone:

• Touch Menu or switch the phone on to display

the lock screen.

57Security

• Touch Menu to unlock—if you've set a lock

pattern or passcode, you'll be asked to enter it.

Forgot your pattern or passcode?

In the passcode unlock screen, touch Menu

Forgot passcode? to unlock your phone with your

> MOTOBLUR email address and MOTOBLUR password.

In the pattern unlock screen, after you enter an incorrect pattern five times, you can touch

Forgot passcode? to unlock your phone with your

MOTOBLUR email address and MOTOBLUR password.

Reset

To reset your phone to factory settings and erase all the data on your phone, touch Menu >

SD card & storage > Factory data reset > Reset

phone

Warning: All downloaded apps and user data on your

phone will be deleted. Data on your memory card will not be deleted.

Settings

Lost, stolen, broken, cleared

Don't you just hate it when your life is on your phone and it all goes wrong. Lose it, break it, reset it, or even worse - stolen! Relax, MOTOBLUR can help find your

58 Security

phone, clear it (if you need to) and best of all, restore all your stuff.

Track your phone

To locate your phone:

1 Log into your MOTOBLUR account:

www.motorola.com/mymotoblur

2 On the phone profile page, follow the link to locate

your phone.

MOTOBLUR locates your phone using GPS and AGPS (see the important legal and safety information packaged with your phone).

Remote clear

To wipe your phone data:

1 Log into your MOTOBLUR account:

www.motorola.com/mymotoblur

2 On the phone profile page, follow the link to delete

data.

Warning: All downloaded apps and user data on

your phone will be deleted. Data on your memory card will not be deleted.

Restore your phone

If you lose your phone don’t worry, your contacts are backed-up on MOTOBLUR.

When you get your next MOTOBLUR product, just log into your existing MOTOBLUR account on your phone to recover all your stuff automatically.

To recover your Android Market apps, see “Manage & restore apps” on page 47.

Troubleshooting

Crash recovery

In the unlikely event that your phone stops responding to touches and key presses, try a quick reset. Remove the back cover and battery (“Assemble & charge” on page 4), then replace and turn on your phone as usual.

Service & repairs

If you have questions or need assistance, go to www.motorola.com/support from a number of customer care options. You can also contact the Motorola Customer Support Center at 1-800-734-5870 (United States), 1-888-390-6456 (TTY/TDD United States for hearing impaired), or 1-800-461-4575 (Canada).

, where you can select

Safety, Regulatory & Legal

032375o

Battery Use & Safety

Important: Handle and store batteries properly to avoid injury or damage.

Most battery issues arise from improper handling of batteries, and particularly from the continued use of damaged batteries.

DON’Ts

• Don’t disassemble, crush, puncture, shred, or otherwise attempt to

change the form of your battery.

• Don’t let the phone or battery come in contact with water.

into the phone’s circuits, leading to corrosion. If the phone and/or battery get wet, have them checked by your service provider or contact Motorola, even if they appear to be working properly.*

• Don’t allow the battery to touch metal objects.

jewelry, stay in prolonged contact with the battery contact points, the battery could become very hot.

• Don’t place your battery near a heat source.

phone or the battery. High temperatures can cause the battery to swell, leak, or malfunction. Therefore:

•

not

dry a wet or damp battery with an appliance or heat source, such as a

hair dryer or microwave oven.

•

Avoid leaving your phone in your car in high temperatures.*

DOs

• Do avoid dropping the battery or phone.

a hard surface, can potentially cause damage.*

• Do contact your service provider or Motorola if your phone or battery

has been damaged from dropping or high temperatures.

* Note:

If the product guide expressly states that your damage from exposure to certain rugged conditions, such as water immersion, rain, dust, high and low temperatures, shock, or other conditions, do stated limits, and ensure the stated precautions are taken. Always make sure that

Excessive heat can damage the

Dropping these items, especially on

Water can get

If metal objects, such as

phone

is designed to resist

not

exceed the

the battery compartment is closed and secure to avoid direct exposure of the battery to any of these conditions.

Important: Use Motorola Original products for quality assurance and safeguards.

To aid consumers in identifying authentic Motorola batteries from non-original or counterfeit batteries (that may not have adequate safety protection), Motorola provides holograms on its batteries. Consumers should confirm that any battery they purchase has a “Motorola Original” hologram.

Motorola recommends you always use Motorola-branded batteries and chargers.

Motorola mobile devices are designed to work with Motorola batteries.

If you see a message on your display such as

Unable to Charge

•

Remove the battery and inspect it to confirm that it has a “Motorola Original” hologram;

•

If there is no hologram, the battery is not a Motorola battery;

•

If there is a hologram, replace the battery and retry charging it;

•

If the message remains, contact a Motorola authorized service center.

Important:

Motorola’s warranty does not cover damage to the phone caused by

non-Motorola batteries and/or chargers.

Warning:

Use of a non-Motorola battery or charger may present a risk of fire,

explosion, leakage, or other hazard.

Proper and safe battery disposal and recycling:

only important for safety, it benefits the environment. Consumers may recycle their used batteries in many retail or service provider locations. Additional information on proper disposal and recycling may be found on the Web:

•

www.motorola.com/recycling

•

www.rbrc.org/call2recycle/

Disposal:

Promptly dispose of used batteries in accordance with local regulations. Contact your local recycling center or national recycling organizations for more information on how to dispose of batteries.

Warning:

Never dispose of batteries in a fire because they may explode.

, take the following steps:

Invalid Battery

(in English only)

Proper battery disposal is not

Battery Charging

Battery Chargi ng

Notes for charging your phone’s battery:

•

When charging your battery, keep it near room temperature. Never expose batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when charging.

•

New batteries are not fully charged.

•

New batteries or batteries stored for a long time may take more time to charge.

•

Motorola batteries and charging systems have circuitry that protects the battery from damage from overcharging.

Specific Absorption Rate (IEEE)

SAR (IEEE)

Your model wireless phone meets the governmental requirements for exposure to radio waves.

Your mobile device is a radio transmitter and receiver. It is designed and manufactured to not exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government and by the Canadian regulatory authorities. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed for the safety of all persons, regardless of age or health, and to account for any variations in measurements. The exposure standard for mobile devices employs a unit of measurement known as the Specific Absorption Rate (SAR). The IEEE SAR limit set by the FCC and by the Canadian regulatory authorities is 1.6 watts per kilogram (W/kg), a veraged over one gram of tissue. Tests for SAR are conducted using procedures accepted by the FCC and by Industry Canada with the mobile device transmitting at its highest certified power level in all tested frequencies. Although the SAR is determined at the highest certified power level, the actual SAR level of the mobile device while operating can be below the maximum value. This is because the mobile device is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station, the lower the power output.

Before a mobile device is available for sale to the public in the U.S. and Canada, it must be tested and certified to the FCC and Industry Canada that it does not exceed the limit established by each government for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) submitted to the FCC and available for review by Industry Canada. The highest SAR value for this mobile device when tested for use at the ear is 0.45 W/kg, and when worn on the body, as described in this guide, is 0.72 W/kg. Body-worn measurements can differ, depending upon available accessories and regulatory requirements. The SAR information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product. While there may be differences between the SAR levels of various mobile devices and at various positions, they meet the governmental requirements for safe exposure. Please note that improvements to this product model could cause differences i n the SAR value for later produc ts; in all cases, products are designed to be within the guidelines. Additional information on SAR can be found on the Cellular Telecommunications & Internet Association (CTIA) Web site: http://www.phonefacts.net or the Canadian Wireless Telecommunications Association (CWTA) Web site: http://www.cwta.ca

Software Copyright Notice

Motorola products may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Content Copyright

The unauthorized copying of copyrighted materials is contrary to the provisions of the Copyright Laws of the United States and other countries. This device is intended solely for copying non-copyrighted materials, materials in which you own the copyright, or materials which you are authorized or legally permitted to copy. If you are uncertain about your right to copy any material, please contact your legal advisor.

Open Source Software Information

OSS Information

For instructions on how to obtain a copy of any source code being made publicly available by Motorola related to software used in this Motorola mobile device, you may send your request in writing to the address below. Please make sure that the request includes the model number and the software version number. MOTOROLA, INC. OSS Management 600 North US Hwy 45 Libertyville, IL 60048 USA The Motorola website regarding Motorola's use of open source. Motorola has created the portal for interaction with the software community-at-large. To view additional information regarding licenses, acknowledgments and required copyright notices for open source packages used in this Motorola mobile device, please press Menu Key > >

Legal information >Open source licenses

Motorola device may include self-contained applications that present supplemental notices for open source packages used in those applications.

GPS & AGPS

Your mobile device can use Global Positioning System (GPS) signals for location-based applications. GPS uses satellites controlled by the U.S. government that are subject to changes implemented in accordance with the Department of

opensource.motorola.com

Settings >About Phone

also contains information

website to serve as a

. In addition, this

Defense policy and the Federal Radio Navigation Plan. These changes may affect the performance of location technology on your mobile device. Your mobile device can also use Assisted Global Positioning System (AGPS), which obtains information from the cellular network to improve GPS performance. AGPS uses your wireless service provider's network and therefore airtime, data charges, and/or additional charges may apply in accordance with your service plan. Contact your wireless service provider for details.

Your Location

Location-based information includes information that can be used to determine the approximate location of a mobile device. Mobile phones which are connected to a wireless network tran smit location-based information. Devices enabled with GPS or AGPS technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such applications transmit location-based information. This location-based information may be shared with third parties, including your wireless service provider, applications providers, Motorola, and other third parties providing services.

Emergency Calls

When you make an emergency call, the cellular network may activate the AGPS technology in your mobile device to tell the emergency respond ers your approximate location. AGPS has limitations and

•

Always tell the emergency responder your location to the best of your a bility; and

•

Remain on the phone for as long as the emergency responder instructs you.

might not work in your area

. Therefore:

Performance Tips

•

Go outside and away from underground locations, covered vehicles, structures with metal or concrete roofs, tall buildings, and foliage. Indoor performance might improve if you move closer to windows, but some window sun shielding films can block satellite signals.

•

Move away from radios, entertainment equipment, and other electronic devices.

Navigation

Motorola strives to provide complete and accurate mapping information, directions, and other navigational data, using a combination of governmental and private location information sources. These sources may contain inaccurate or incomplete data. In some countries, complete information may not be available. Therefore, you should visually confirm that the navigational instructions are consistent with what you see. All drivers should pay attention to road conditions, closures, traffic, and all other factors that may impact driving. Always obey posted road signs.

Safety & General Information

Safety Information

This section contains important information on the safe and efficient operation of your mobile device. Read this information before using your mobile device.

Exposure to Radio Frequency (RF) Energy

Your mobile device contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your mobile device, the system handling your call controls the power level at which your mobile device transmits. Your mobile device is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

Operational Precautions

For optimal mobile device performance, and to be sure that human exposure to RF energy does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions.

Product Operation

When placing or receiving a phone call, hold your mobile device just like you would a landline phone. If you wear the mobile device on your body, always place the mobile device in a Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do not use a body-worn accessory supplied or approved by Motorola, keep the mobile device and its antenna at least 2.5 centimeters (1 inch) from your body when transmitting.

Using accessories not supplied or approved by Motorola may cause your mobile device to exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved accessories, visit our Web site at:

www.motorola.com

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances, your mobile device may cause interference with other devices.

Follow Instructions to Avoid Interference Problems

Turn off your mobile device in any location where posted notices instruct you to do so. In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your mobile device offers an airplane mode or similar feature, consult airline staff about using it in flight.

Implantable Medical Devices

If you have an implantable medical device, such as a pacemaker or defibrillator, consult your physician before using this mobile device. Persons with implantable medical devices should observe the following precautions:

•

ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the implantable medical device when the mobile device is turned ON.

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the implantable medical device to minimize the potential for interference.

•

Turn OFF the mobile device immediately if you have any reason to suspect that

interference is taking place. Read and follow the directions from the manufacturer of your implantable medical device. If you have any questions about using your mobile device with your implantable medical device, consult your healthcare provider.

Driving Precautions

Using a mobile device while driving may cause distraction. End a call if you can’t concentrate on driving. Input information about your destination and route prior to your drive. Do not input data or engage in text messaging while driving. Keep your

eyes on the road while driving. Listen to the audible turn-by-turn directions, if

032374o

032376o

032375o

available. Also, using a mobile device or accessory may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products. Responsible driving practices can be found at (in English only).

www.motorola.com/callsmart

Operational Warnings

Obey all posted signs when using mobile devices in public areas.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often, but not always, posted and can include fueling areas, such as below decks on boats, fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain dust, or metal powders. When you are in such an area, turn off your mobile device, and do not remove, install, or charge batteries. In such areas, sparks can occur and cause an explosion or fire.

Symbol Key

Your battery, charger, or mobile device may contain symbols, defined as follows:

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile device in a fire.

Your battery or mobile device may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

Symbol Definition

Do not throw your battery or mobile device in the trash.

Do not let your battery, charger, or mobile device get wet.

Listening at full volume to music or voice through a headset may damage your hearing.

Batteries & Chargers

Caution:

Improper treatment or use of batteries may present a danger of fire, explosion, leakage, or other hazard. For more information, see “Battery Use & Safety.”

Keep Your Mobile Device & Its Accessories Away From Small Children

These products are not toys and may be hazardous to small children. For example:

•

A choking hazard may exist for small, detachable parts.

•

Improper use could result in loud sounds, possibly causing hearing injury.

•

Improperly handled batteries could overheat and cause a burn.

Glass Parts

Some parts of your mobile device may be made of glass. This glass could break if the product is dropped on a hard surface or receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your mobile device until the glass is replaced by a qualified service center.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing ligh ts, such as when playing video games . These may occur even if a per son has never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your physician before playing video games or enabling a flashing-lights feature (if available) on your mobile device. Discontinue use and consult a physician if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. It is always a good idea to hold the screen away from your eyes, leave the lights on in the room, take a 15-minute break every hour, and stop use if you are tired.

Caution About High Volume Usage

Warning:

Exposure to loud noise from any source for extended periods of time may affect your hearing. The louder the volume sound level, the less time is required before your hearing could be affected. To protect your hearing:

•

Limit the amount of time you use headsets or headphones at high volume.

•

Avoid turning up the volume to block out noisy surroundings.

•

Turn the volume down if you can’t hear people speaking near you. If you experience hearing discomfort, including the sensation of pressure or fullness in your ears, ringing in your ears, or muffled speech, you should stop listening to the device through your headset or headphones and have your hearing checked. For more information about hearing, see our Web site at direct.motorola.com/hellomoto/nss/AcousticSafety.asp only).

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you continue to have discomfort during or after such use, stop use and see a physician. [Nov0109]

(in English

Industry Canada Notice to Users

Industry Cana da Notice

Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This device must accept any interference, including interference that may cause undesired operation of the device. See RSS-GEN 7.1.5.

FCC Notice to Users

FCC Notice

The following statement applies to all products that have received FCC approval. Applicable products bear the FCC logo, and/or an FCC ID in the format FCC-ID:xxxxxx on the product label.

Motorola has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21. This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi tions: (1) This device may not cause harmful interfe rence, and (2) this device must accept any interference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3). This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, us es and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and the receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Use & Care

To care for your Motorola phone, please keep it away from:

liquids of any kind

Don’t expose your phone to water, rain, extreme humidity, sweat, or other moisture. If it does get wet, don’t try to accelerate drying with the use of an oven or dryer, as this may damage the phone.

extreme heat or cold

Avoid temperatures below 0°C/32°F or above 45°C/113°F.

microwaves

Don’t try to dry your phone in a microwave oven.

dust and dirt

Don’t expose your phone to dust, dirt, sand, food, or other inappropriate materials.

cleaning solutions

To clean your phone, use only a dry soft cloth. Don’t use alcoho l or other cleaning solutions.

shock and vibration

Don’t drop your phone.

Motorola Limited Warranty for the

United States and Canada

Warra nty

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc. warrants its mobile telephones (“Produc ts”), Motorola-branded or cer tified accessories sold for use with these Products (“Accessories”), and Motorola software contained on CD-ROMs or other tangible media and sold for use with these Products (“Software”) to be free from defects in materials and workmanship under normal consumer usage for the period(s) outlined below. This limited warranty is a consumer's exclusive remedy,

and applies as follows to new Motorola Products, Accessories, and Software purchased by consumers in the United States or Canada, which are accompanied by this written warranty:

Products and Accessories

Products Covered Length of Coverage

One (1) year

Products and Accessories

defined above, unless otherwise provided for below.

Decorative Accessories and Cases.

Decorative covers, bezels, PhoneWrap™ covers and cases.

Monaural Headsets.

and boom headsets that transmit mono sound through a wired connection.

Products and Accessories that are Repaired or Replaced.

Exclusions (Products and Accessories)

Normal Wear and Tear.

due to normal wear and tear are excluded from coverage.

Batteries.

rated capacity and batteries that leak are covered by this limited warranty.

Abuse & Misuse.

storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like,

Ear buds

Periodic maintenance, repair and replacement of parts

Only batteries whose fully charged capacity falls below 80% of their

Defects or damage that result from: (a) improper operation,

from the date of purchase by the first consumer purchaser of the product unless otherwise provided for below.

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

The balance of the original warranty or for ninety (90) days

returned to the consumer, whichever is longer.

for the

from the date

extreme heat, or food; (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories.

from the use of non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.

Unauthorized Service or Modification.

service, testing, adjustment, installation, maintenance, alteration, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage.

Altered Products.

that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, or parts, are excluded from coverage.

Communication Services.

Accessories or Software due to any communication service or signal you may subscribe to or use with the Products Accessories or Software is excluded from coverage.

Products or Accessories with (a) serial numbers or date tags

Defects, damages, or the failure of Products,

Defects or damage that res ult

Defects or damages resulting from

Software

Products Covered Length of Coverage

Applies only to physical defects in the

Software.

media that embodies the copy of the software (e.g. CD-ROM, or floppy disk).

Exclusions (Software)

Software Embodied in Physical Media.

will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be uninterrupted or error free, or that all defects in the software products will be corrected.

Ninety (90) days

the date of purchase.

No warranty is made that the software

from

Software NOT Embodied in Physical Media.

physical media (e.g. software that is downloaded from the Internet), is provided “as is” and without warranty.

Software that is not embodied in

Who is Covered?

This warranty extends only to the first consumer purchaser, and is not transferable.

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or refund the purchase price of any Products, Accessories or Software that does n ot conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new Products, Accessories or parts. No data, software or applications added to your Product, Accessory or Software, including but not limited to personal contacts, games and ringer tones, will be reinstalled. To avoid losing such data, software, and applications, please create a back up prior to requesting service.

How to Obtain Warranty Service or Other Information

USA All Products, Accessories, and Software:

Canada All Products:

TTY

You will receive instructions on how to ship the Products, Accessories or Software, at your expense, to a Motorola Authorized Repair Center. To obtain service, you must include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) the name and location of the installation facility (if applicable) and, most importantly; (e) your address and telephone number.

1-888-390-6456

1-800-461-4575

1-800-734-5870

What Other Limitations are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE

THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or from one jurisdiction to another.

Hearing Aid Compatibility with Mobile Phones

Hearing Aid Compatibility

Some Motorola phones are measured for compatibility with hearing aids. If the box for your particular model has “Rated for Hearing Aids” printed on it, the following explanation applies. When some mobile phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate. The wireless telephone industry has developed ratings for some of their mobile phones, to assist hearing device users in finding phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label on the box. To maintain the published Hearing Aid Compatibility (HAC) rating for this mobile p hone, use only the original equi pment battery model.

The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the phone with your hearing device is the best way to evaluate it for your personal needs.

M-Ratings:

Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.

T-Ratings:

Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated phones. T4 is the better/higher of the two ratings. (Note that not all hearing devices have telecoils in them.) Hearing devices may also be measured for immunity to this type of interference. Your hearing device manufacturer or hearing health professional may help you find results for your hearing device. The more immune your hearing aid is, the less likely you are to experience interference noise from mobile phones.

Information from the World Health Organization

WHO Information

Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If you are concerned, you may want to limit your own or your children’s RF exposure by limiting the length of calls or by using handsfree devices to keep mobile phones away from your head and body. Source: WHO Fact Sheet 193 Further information:

Product Registration

Registration

Online Product Registration: www.motorola.com/us/productregistration Product registration is an important step toward enjoying your new Motorola product. Registering permits us to contact you for product or software updates and allows you to subscribe to updates on new products or special promotions. Registration is not required for warranty coverage.

http://www.who.int/peh-emf

Please retain your original dated sales receipt for your records. For warranty service

032376o

of your Motorola Personal Communications Product you will need to provide a copy of your dated sales receipt to confirm warranty status. Thank you for choosing a Motorola product.

Export Law Assurances

Export Law

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

Caring for the Environment by Recycling

Recycling Infor mation

This symbol on a Motorola product means the product should not be disposed of with household waste.

Disposal of your Mobile Device & Accessories

Please do not dispose of mobile devices or electrical accessories (such as chargers, headsets, or batteries) with your household waste. Do not dispose of your battery or mobile device in a fire. These items should be disposed of in accordance with the national collection and recycling schemes operated by your local or regional authority. Alternatively, you may return unwanted mobile devices and electrical accessories to any Motorola Approved Service Center in your region. Details of Motorola approved national recycling schemes, and further information on Motorola recycling activities can be found at: www.motorola.com/recycling

Disposal of your Mobile Device Packaging & Product Guide

Product packaging and pr oduct guides should only be disp osed of in accordance with national collection and recycling requirements. Please contact your regional authorities for more details.

California Perchlorate Label

Perchlorate Label

Some mobile phones use an internal, permanent backup battery on the printed circuit board that may contain very small amounts of perchlorate. In such cases, California law requires the following label: Perchlorate Material – special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate There is no special handling required by consumers.

Privacy & Data Security

Privacy & Data Securit y

Motorola understands that privacy and data security are important to everyone. Because some features of your mobile device may affect your privacy or data security, please follow these recommendations to enhance protection of your information:

• Monitor access

others may have unmonitored access. Lock your device’s keypad where this feature is available.

• Keep software up to date

releases a patch or software fix for your mobile device that updates the device’s security, install it as soon as possible.

•Secure personal information

information in various locations including your SIM card, memory card, and phone memory. Be sure to remove or clear all personal information before you recycle, return, or give away your device. You can also backup your personal data to transfer to a new device.

Note:

go to

• Online accounts

(such as MOTOBLUR). Go to your account for information on how to manage the account, and how to use security features such as remote wipe and device location (where available).

• Location-based information

information that can be used to determine the approximate location of a mobile device. Mobile phones which are connected to a wireless network transmit

—Keep your mobile device with you and do not leave it where

—If Motorola or a software/application vendor

—Your mobile device can store personal

For information on how to backup or wipe data from your mobile device,

www.motorola.com/support

—Some mobile devices provide a Motorola online account

—Location-based information includes

location-based information. Devices enabled with GPS or AGPS technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such applications transmit location-based information. This location-based information may be shared with third parties, including your wireless service provider, applications providers, Motorola, and other third parties providing services.

•Other information your device may transmit

testing and other diagnostic (including location-based) information, and other non-personal information to Motorola or other third-party servers. This

information is used to help improve products and services offered by Motorola. If you have further questions regarding how the use of your mobile device may impact your privacy or data security, please contact Motorola at privacy@motorola.com

Smart Practices While Driving

Driving Safety

Check the laws and regulations on the use of mobile devices and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas—for example, handsfree use only. Go to (in English only) for more information.

Your mobile device lets you communicate by voice and data—almost anywhere, anytime, wherever wireless service is available and safe conditions allow. When driving a car, driving is your first responsibility. If you choose to use your mobile device while driving, remember the following tips:

• Get to know your Motorola mobile device and its features such as speed

dial and redial.

taking your attention off the road.

• When available, use a handsfree device.

an additional layer of convenience to your mobile device with

one of the many Motorola Original handsfree accessories

available today.

• Position your mobile device within easy reach.

access your mobile device without removing your eyes from the road. If you

, or contact your service provider.

Drive Safe, Call Smart

If available, these features help you to place your call without

—Your device may also transmit

www.motorola.com/callsmart

If possible, add

Be able to

receive an incoming call at an inconvenient time, if possible, let your voicemail answer it for you.

• Let the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions.

sleet, snow, ice, and even heavy traffic can be hazardous.

• Do not take notes or look up phone numbers while driving.

“to do” list or going through your address book takes attention away from your primary responsibility—driving safely.

• Dial sensibly and assess the traffic; if possible, place calls when your car is not moving or before pulling into traffic.

moving, dial only a few numbers, check the road and your mirrors, then continue.

• Do not engage in stressful or emotional conversations that may be distracting.

Make people you are talking with aware you are driving and

suspend conversations that can divert your attention away from the road.

•Use your mobile device to call for help.

number in the case of fire, traffic accident, or medical emergencies (wherever wireless phone service is available).

•Use your mobile device to help others in emergencies.

accident, crime in progress, or other serious emergency where lives are in danger, call 911 or other local emergency number (wherever wireless phone service is available), as you would want others to do for you.

•Call roadside assistance or a special non-emergency wireless assistance number when necessary.

posing no serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number (wherever wireless phone service is available).

If you must make a call while

Dial 911 or other local emergency

If you see a broken-down vehicle

Rain,

Jotting down a

If you see an auto

Motorola, Inc. Consumer Advocacy Office 600 N US Hwy 45 Libertyville, IL 60048 www.hellomoto.com

Note:

Do not ship your phone to the above address. If you need to return your phone for repairs, replacement, or warranty service, please contact the Motorola Customer Support Center at: 1-800-734-5870 (United States) 1-888-390-6456 (TTY/TDD United States for hearing impaired) 1-800-461-4575 (Canada) Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider’s network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this guide, are based upon the latest available information and believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation. MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. The MOTOBLUR logo is a trademark of Motorola.The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. The Rhapsody trademark and logo are property of RealNetworks Inc.Adobe Flash Lite is a registered trademark of Adobe Systems Incorporated in the United States and/or other countries.Microsoft, Windows, Windows Media, and Windows Vista are registered trademarks of Microsoft Corporation in the United States and other countries. Google, YouTube, Picasa, Gmail, and the Google logo are trademarks of Google, Inc. is a Certification Mark of the Wireless Fidelity Alliance, Inc. Facebook is a trademark of Facebook, Inc. All other product or service names are the property of their respective owners. © 2010 Motorola, Inc. All rights reserved.

Caution:

Changes or modificat ions made in the radio phone, no t expressly approved

by Motorola, will void the user’s authority to operate the equipment.

Bluetooth ID: B015716

Manual Number: 68000202479-B U.S. patent Re. 34,976

71Troubleshooting

www.motorola.com

Motorola DEVOUR User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Congratulations

Your phone

Contents

Let’s go

Assemble & charge

Set up & go

Wi-Fi connect

Cool content & more

Security

Touchscreen & keys

Touch tips

Key tips

Rotate the screen

Home screen

Quick start: Home screen

Use & change your home screen

Search

Phone status & notifications

App menu

Quick start: App menu

Recent apps

Social networking

Your MOTOBLUR account

Update your status

Add accounts

View account updates & features

Edit & delete accounts

Calls

Quick start: Calls

Make & answer calls

End calls

Speed dial

Handsfree

Mute

Enter numbers during a call

Recent calls

Frequent calls

Conference calls

Your phone number

Emergency calls

Contacts

Quick start: Contacts

Call, text, or email contacts

View & use contacts

Edit or delete contacts

Link contacts

Create contacts

Synchronize contacts

My details

Groups

Messaging

Quick start: Messaging

Read & reply to messages

Create messages

Send & receive attachments text message attachments

Set up messaging

Instant messages

Voi cema il

Text entry

Typing tips

Touchscreen keypad

Format text in emails

Text entry settings

Tips & tricks

Shortcuts

Battery tips

Personalize

Widgets

Ringtones

Sounds

Date & time

Display settings

Language

Photos & videos

Photos

Videos
