Motorola DCT3080 User Manual

DCT3080 Installation Manual

CAUTION

RISK OF ELECTRIC SHOCK

TO REDUCE THE RISK OF ELECTRIC SHOCK,

CAUTION:

DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Caution

These servicing instructions are for use by qualified personnel only. To reduce the risk of electrical
shock, do not perform any servicing other than that contained in the Installation and Troubleshooting
Instructions unless you are qualified to do so. Refer all servicing to qualified service personnel.

Special Symbols That Might Appear on the Equipment

This symbol indicates that dangerous voltage levels are present within the
equipment. These voltages are not insulated and may be of sufficient strength to
cause serious bodily injury when touched. The symbol may also appear on
schematics.

The exclamation point, within an equilateral triangle, is intended to alert the user to
the presence of important installation, servicing, and operating instructions in the
documents accompanying the equipment.

For continued protection against fire, replace all fuses only with fuses having the
same electrical ratings marked at the location of the fuse.

WARNING: TO REDUCE THE RISK OF FIRE OR SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE. THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING
AND NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE
APPARATUS.

CAUTION: TO PREVENT ELECTRICAL SHOCK, DO NOT USE THIS (POLARIZED) PLUG WITH AN
EXTENSION CORD, RECEPTACLE, OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE EXPOSURE.

This equipment operates over the marked Voltage and Frequency range without
requiring manual setting of any selector switches. Different types of line cord sets
may be used for connections to the mains supply circuit and should comply with
the electrical code requirements of the country of use. The line cord provided with
the equipment is acceptable for use with NEMA Style 5-15R ac receptacles
supplying nominal 120 Volts.

I

DCT3080 Installation Manual

d

CAUTION: TO ENSURE REGULATORY AND SAFETY COMPLIANCE, USE ONLY THE PROVIDED
POWER CABLES.

It is recommended that the customer install an AC surge arrestor in the AC outlet to which this device is
connected. This is to avoid damaging the equipment by local lightning strikes and other electrical surges.

NOTE TO CATV SYSTEM INSTALLER

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close as possible to the point of cable entry as
practical.

EXAMPLE OF ANTENNA GROUNDING

Electri c s erv ice

equipment

Groun

clamp

Antenna lead
in wire

Antenna
discharge unit
(NEC Section 81 0-20)

Grounding

clamps

Pow er s e rvic e gro u nd i ng

electrode system

(NEC Arti cle 25 0, Part H)

NEC=NATIONAL E LECTR ICAL CO DE

Grounding co n duct ors

(NEC Se c tion 810-21)

IMPORTANT SAFETY INSTRUCTIONS

1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance with

the manufacturer’s instructions.

8 Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that
produce heat.

II

DCT3080 Installation Manual

9 Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety.
If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched,

particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.

11 Only use attachments/accessories specified by the manufacturer.
12 Unplug this apparatus during lightning storms or when unused for

long periods of time.

13 Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way, such
as the power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or
has been dropped.

REPAIRS

If you find the unit in need of repair, call Motorola Support at 1-866-668-2271 or 1-866-MOT-BCS1.

FCC Compliance

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a residential environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his/her own expense. Any changes or modifications not expressly
approved by Motorola could void the user’s authority to operate this equipment under the rules and
regulations of the FCC. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:

 Re-orient or relocate the receiving antenna
 Increase the separation between the equipment and receiver
 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
 Consult the dealer or an experienced radio/TV technician for help.

III

DCT3080 Installation Manual

You may find the following booklet, prepared by the Federal Communication Commission, helpful: How
to Identify and Resolve Radio-TV Interference Problems, Stock No. 004-000-0342-4, U.S. Government
Printing Office, Washington, DC 20402.

Changes or modification not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

FCC Declaration of Conformity

According to 47 CFR, Parts 2 and 15 for Class B Personal Computers and Peripherals; and/or CPU
Boards and Power Supplies used with Class B Personal Computers, Motorola, Inc., 6450 Sequence
Drive, San Diego, CA 92121, 1-800-225-9446 or 101 Tournament Drive, Horsham, PA 19044,
1-888-944-4357, declares under sole responsibility that the product identifies with 47 CFR Part 2 and 15
of the FCC Rules as a Class B digital device. Each product marketed is identical to the representative
unit tested and founded to be compliant with the standards. Records maintained continue to reflect the
equipment being produced can be expected to be within the variation accepted, due to quantity
production and testing on a statistical basis as required by 47 CFR 2.909. Operation is subject to the
following condition: This device must accept any interference received, including interference that may
cause undesired operation. The above named party is responsible for ensuring that the equipment
complies with the standards of 47 CFR, Paragraphs 15.107 to 15.109

Canadian Compliance

This Class B digital device complies with Canadian ICES-003. Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.

NOTE TO CATV SYSTEM INSTALLER: This reminder is provided to call CATV system installer’s
attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the grounding system of the building, as close as
possible to the point of cable entry as practical.

IV

DCT3080 Installation Manual

Copyright © 2006 by Motorola, Inc.

All rights reserved. No part of this publication may be reproduced in any form or by any means or used
to make any derivative work (such as translation, transformation or adaptation) without written
permission from Motorola, Inc.

Motorola reserves the right to revise this publication and to make changes in content from time to time
without obligation on the part of Motorola to provide notification of such revision or change. Motorola
provides this guide without warranty of any kind, either implied or expressed, including, but not limited to,
the implied warranties of merchantability and fitness for a particular purpose. Motorola may make
improvements or changes in the product(s) described in this manual at any time.

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Dolby Digital
manufactured under license from Dolby Laboratories Licensing Corporation. Dolby, ProLogic and the
double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation. DOCSIS is a
registered trademark of Cable Television Laboratories, Inc. This device incorporates a copyright
protection technology that is protected by U.S. patents and other intellectual property rights. Use of the
copyright protection technology is granted by Macrovision for home and other limited pay-per-view uses
only, unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
Macrovision is a registered trademark of Macrovision Corporation. HDMI, the HDMI logo and High­Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
other product or service names are the property of their respective owners. © Motorola, Inc. 2006.

All

V

DCT3080 Installation Manual

Table of Contents

IMPORTANT SAFETY INSTRUCTIONS.............................................................................. II

REPAIRS...................................................................................................................... III

FCC Declaration of Conformity .................................................................................IV

Canadian Compliance ................................................................................................IV

Table of Contents..................................................................................1

Introduction............................................................................................4

Features................................................................................................................................6

Tuners..........................................................................................................................6

Standard Audio/Video Features ................................................................................6

Standard DVR Functionality ......................................................................................7

Standard Data Features..............................................................................................8

Standard Miscellaneous Features............................................................................. 8

Available Optional Features.......................................................................................8

Using This Manual...............................................................................................................9

Related Documentation.......................................................................................................9

Document Conventions ......................................................................................................10

If You Need Help..................................................................................................................10

Calling for Repairs...............................................................................................................12

Overview.................................................................................................13

Front Panel...........................................................................................................................13

Rear Panel ............................................................................................................................15

Installation..............................................................................................17

Important Safety Considerations.......................................................................................17

During Transportation to the Subscriber Home......................................................17

During Installation ......................................................................................................17

Before You Begin.................................................................................................................18

Clearing the Hard Drive..............................................................................................18

1

DCT3080 Installation Manual

Video Connection Options.........................................................................................19

Audio Connection Options ........................................................................................20

Installation Overview...........................................................................................................21

Connecting to an A/V Receiver – Audio Only ..........................................................22

Connecting to a Stereo TV..................................................................................................23

Connecting a Stereo TV .............................................................................................23

Connecting a Stereo TV and Stereo VCR..........................................................................25

Connecting an A/V Receiver, TV, and VCR.......................................................................27

Recording Your Connections.............................................................................................29

Data Device Connections....................................................................................................31

Boot Cycle............................................................................................................................32

Boot Cycle Error Codes .............................................................................................34

Operational Check for the Remote Control....................................................................... 36

Optimizing Video Settings..................................................................................................37

Graphics Overlaying the Video ..........................................................................................40

Diagnostics............................................................................................41

Using the Diagnostics..................................................................................................................41

d01 General Status..............................................................................................................43

d02 Purchase Status ...........................................................................................................45

d03 Out-Of-Band (OOB) Status ..........................................................................................46

d04 In-Band Status..............................................................................................................48

d05 Unit Address.................................................................................................................51

d06 Current Channel Status ...............................................................................................54

d07 RF Modem (Upstream).................................................................................................58

d08 Code Modules............................................................................................................... 59

d09 Memory Configuration.................................................................................................62

d10 Keypad–LED .................................................................................................................63

d11 Interface Status............................................................................................................. 63

d12 User Setting Status ......................................................................................................66

d13 DVR/Hard Drive Status.................................................................................................70

d14 DOCSIS Status..............................................................................................................74

d15 Application Specific Information ................................................................................81

d16 Interactive Status.......................................................................................................... 82

2

DCT3080 Installation Manual

Troubleshooting....................................................................................86

Specifications........................................................................................89

3

DCT3080 Installation Manual

Introduction

This manual provides instructions for cable operator personnel to install
the Motorola DCT3080 high-definition digital video recorder (DVR) cable
terminals. The DCT3080 terminals include a high-end processor,
expanded memory and enhanced graphics to support digital and
on-demand, broadcast, and interactive services. They provide a full
complement of interconnection options.

The DCT3080 advanced capabilities include:

 Authorization and purchase of on-demand programming

 HDTV support through down-conversion that allows high-definition

programming to be viewed in standard definition format

 Surround-sound audio through a variety of digital interconnection

options

 Dual-tuner DVR functionality to pause and time shift live video and

seamlessly record in conjunction with the interactive programming
guide (IPG)

®

P

 Built-in DOCSIS

cable modem

 Ethernet and Universal Serial Bus (USB) 2.0 ports for future home

networking applications

 Adaptability to various software platforms

As with all Motorola digital cable terminals, the hardware features are
enabled by core operating and third party application software.

4

Figure 1-1
Front and rear views

DCT3080 Installation Manual

5

DCT3080 Installation Manual

Features
Tuners

 Two 54 to 860 MHz video tuners with digital MPEG-2 main profile

high level video processor

 One dedicated tuner for the DOCSIS high-speed data/voice services

channel, up to 860 MHz

 One dedicated tuner for the out-of-band (OOB) control channel

Standard Audio/Video Features

 ITU standard 64/256 QAM/FEC enhanced adaptive equalizer

 DES based encryption/DCII access control

 Out-of-band data receiver (70-130 MHz) 2.048 Mbps

 Digital video scaling (picture in graphics)

 32-bit 2D/3D graphics support in hardware

®

 Macrovision

 Standard-definition (and down-converted high-definition) video

output through:

P

P

copy protection

 S-Video

 Baseband

 RF

 Audio output through:

 S/PDIF ATSC standard Dolby Digital® AC-3 electrical or optical

 Baseband L/R

6

DCT3080 Installation Manual

Standard DVR Functionality

DVR functionality integrated with the IPG enables subscribers to:

 Pause, rewind, fast-forward, or record live TV

 Maintain a personal recorded program library and access it using the

IPG

 Select programs to record across multiple channels and time slots

 Rewind and replay recorded programs

 Simultaneously watch two programs, switching easily between

them using the

 Record a program in the background while viewing another live

program

 Simultaneously record programs from two channels while watching

a different pre-recorded program, with the ability to switch viewing
between any of the three programs

Motorola cannot guarantee the exact amount of programming that each
subscriber will be able to record. The approximate time depends on the

programming type and the drive size:
All times are approximate. The actual hours a subscriber can record are a
function of program bit rate, the IPG type, and the reserved buffer
space. A SATA port is available to connect an external drive to add DVR
recording capacity (advanced feature requiring firmware support).

Table 1-1
DVR Recording Time Guidelines

SWAP key

Model Drive Size

DCT3080

80 GB 25 to 35 7 to 12

Estimated Recording Hours for

Standard

Digital

Channels

7

Digital

HDTV Channels

DCT3080 Installation Manual

Standard Data Features

Integrated DOCSIS 1.0/1.1 capable cable modem

16 MB flash memory

128 MB SDRAM

One rear Universal Serial Bus (USB) 2.0 port

10/100 Base-T Ethernet Port (RJ-45)

On-board real-time RF return (DOCSIS compliant)

Renewable security connector

Standard Miscellaneous Features

Unswitched accessory outlet

Messaging capabilities

On-screen diagnostics

Full feature access from front panel using a four-digit, seven-segment
LED display

Available Optional Features

Factory-installed expansion flash memory (32 MB)

8

DCT3080 Installation Manual

Using This Manual

This manual provides instructions to install and configure a DCT3080:

Section 1 Introduction provides a product description, a list of related

documentation, the technical help line telephone number, and
the repair/return procedure.

Section 2 Overview describes the DCT3080 and provides an overview of

its use. This section also identifies the front-panel displays and
keys and describes the rear-panel features.

Section 3 Installation provides subscriber location installation and testing

instructions.

Section 4 Diagnostics provides instructions on accessing and

interpreting the built-in diagnostics.

Section 5 Troubleshooting provides information on common error

conditions and their resolution.

Appendix A Specifications provides the technical specifications.
Appendix B Connection Record provides a diagram for recording the

connections between the DCT3080 and other devices.

Abbreviations
and
Acronyms

The Abbreviations and Acronyms list contains the full

spelling of the short forms used in this manual.

Related Documentation

The following documentation may be helpful when operating the
DCT3080:

 DCT3080 User Guide

 User documentation for the remote control, audio receiver, TV, and

other components

Separate instruction manuals are available for associated components.

9

DCT3080 Installation Manual

Document Conventions

Before you begin working with this manual, familiarize yourself with the
following stylistic conventions:

SMALL CAPS

*

(asterisk)

Italic type Used for emphasis

Courier
font

Denotes silk screening on the equipment, typically representing
front- and rear-panel controls, input/output (I/O) connections, and
LEDs

Indicates that several versions of the same model number exist
and the information applies to all models; when the information
applies to a specific model, the complete model number is given

Displayed text

If You Need Help

If you need assistance while working with the DCT3080, contact the
Motorola Technical Response Center (TRC):

 Inside the U.S.: 1-888-944-HELP (1-888-944-4357)

 Outside the U.S.: 1-215-323-0044

 Motorola Online:

H62HTUhttp://businessonline.motorola.comUTH

The TRC is on call 24 hours a day, 7 days a week. In addition, Motorola
Online offers a searchable solutions database, technical documentation,
and low-priority issue creation and tracking.

10

Technical Response Center

Telephone Menu Options

DCT3080 Installation Manual

Connected Home Solutions

888-944-HELP / 215-323-0044

PRESS 1

Controllers

Digital

Cable Modems

PRESS 2

Analog

PRESS 2

VOIP

PRESS 1

PRESS 1

Cable Router

Products

Severity Level

1 - Critical Failure
2 - Serious Failure
3 - Lesser Failure
4 - Technical Assistance

Video Products

PRESS 1

PRESS 2

Headend

Data Networks/

Transmission Products

PRESS 3

PRESS 3

Transmission

Products

PRESS 1

Network

Licensing

Management

PRESS 3

Set-tops

PRESS 4

Network

PRESS 2

Network

Management

Products

PRESS 5

Multiservice

Transport
Products

(MBT/MWT/MEA)

http://businessonline.motorola.com

Broadcaster,

Satellite IRD or

Encoder Products

PRESS 2

PRESS 1

Commercial

IRD

PRESS 1

Consumer

Satellite

C Band

Consumer

Products

PRESS 4

PRESS 2

Broadband

Retail

Support

PRESS 2

Uplink

Encoder

Issued: 04/2005

11

DCT3080 Installation Manual

Calling for Repairs

If a Motorola DCT3xxx set-top requires repair service, please call one of
the following Motorola Authorized Service Centers:

Company

World Wide Digital
Teleplan

To ensure efficient service, request a Return for Service Authorization
(RSA) number. Be sure to display the RSA number prominently on all
equipment boxes.

The Service Center will provide the shipping address of the location
performing your repairs.
To ship your equipment for repair:

1 Pack the unit securely, if possible in its original factory shipping

carton.

2 Print or display the RSA number so it is easily visible on all

equipment boxes.

From USA or Canada Outside USA or Canada

1-800-227-0450 1-956-541-0600

1-800-352-5274 1-302-322-6088

3 Enclose a note describing the exact problem. Complete and

enclose the checklist provided with the unit.

4 Ship the unit PREPAID to the address provided by the Service

Center.

12

DCT3080 Installation Manual

Overview

This section describes the front and rear panel.

Front Panel

The front panel controls provide functional navigation if the remote
control is lost or is temporarily out of service. Certain functions, such as
those requiring a numeric entry, require a remote control. Some

connectors are not enabled and require the support of application
software.

Figure 2-2
Front panel

Table 2-2
Front panel

Key Feature Function

1

INFO Displays the current channel and program

information (not supported by all applications)

13

DCT3080 Installation Manual

Key Feature Function

2 LED DISPLAY Displays the channel number or time of day. The

indicators are:

MSGS — the DCT3080 has received messages for
you to read

ON — the DCT3080 is powered on

RECORD — the DVR is recording

REMOTE — the remote control is in use

3 OPTION Reserved for future use

4 CURSOR Moves the cursor around the program guide and

menu screens

5

6

7 GUIDE Displays the program guide

8

9

POWER Turns the unit on or off

MENU Displays the main menu

SELECT Selects menu options or programs from the program

guide

CHANNEL Changes the channel

14

DCT3080 Installation Manual

Rear Panel

The rear panel contains an unswitched power outlet; connectors for
video, audio, and RF cabling; data output; and modem and data interface
connectors. Some connectors are not enabled and require the support of
application software.

Figure 2-3
Rear panel

Table 2-3
Rear panel connections

Key Item Function

1
2
3
4

5
6

7*

8

RF IN F-type coaxial cable input

RF OUT RF video output

SPDIF Coaxial Dolby

S-VIDEO

S-Video high-quality video output to a VCR or TV
that accepts S-Video

VIDEO OUT RCA-type video output to a VCR or TV

AUDIO OUT L and R (left and right) RCA-type stereo audio

output jacks

ETHERNET Ethernet 10/100Base-T input

OPTICAL SPDIF Optical digital Dolby Digital audio or PCM audio

output

®

Digital or PCM audio output

15

DCT3080 Installation Manual

Key Item Function

9*

10

11

* These connectors (USB and ETHERNET) might not enabled and might
require the support of the application software

USB USB 2.0 connector for devices such as keyboards,

joysticks, scanners, disk storage, PCs, printers, or
digital cameras

SATA Connector for optional external hard drive

AC power AC power connector:

 The bottom plug is an input for the AC power

cord

 The top plug is an unswitched power outlet for

a device such as a TV or VCR

16

DCT3080 Installation Manual

Installation

This section provides instructions to cable the DCT3080 and check its
operation. The cabling diagrams illustrate connections to high-definition
or standard-definition TVs, home theater receivers, and stereo VCRs.

Important Safety Considerations

The DCT3080 requires careful handling to avoid potential damage to its
internal hard disk drive or the loss of recorded data. Be sure to follow these
requirements during transportation and installation.

During Transportation to the Subscriber Home

Transport the cable terminal in its shipping box or an equally padded
container.
Do not expose the terminal to rain or moisture.

During Installation

• Do not place the cable terminal in an enclosed area where the

cooling vents are blocked or impede the flow of air through the

ventilation openings.

• Install the terminal so that its position does not interfere with its

proper ventilation. For example, do not place the terminal on a

bed, sofa, rug, or similar surface that could block the ventilation

openings.

• Install the terminal away from heat sources such as radiators,

heat registers, and stoves. Installation of the terminal near

17

DCT3080 Installation Manual

consumer electronics devices, such as stereo receiver/amplifiers

and televisions, is permitted as long as the air surrounding the

terminal does not exceed 40 ºC (104 ºF).

• Place the terminal on a flat surface not prone to vibration or

impact.

• Do not install the terminal in an area where condensation

occurs.

• To prevent the temporary loss of guide data and cause a

temporarily non-responding terminal, do not plug the AC power

cord into a switched power outlet.

• To avoid shock and vibration damage to the internal hard drive,

do not move the terminal while it is plugged in.

• To allow the hard drive to spin down and park its heads, wait at

least 10 seconds after disconnecting power before moving the

terminal.

Before You Begin

Before you move or change components on the subscriber
entertainment system:

 Review the installation instructions.

 Determine if you are connecting to a standard TV, a composite

(baseband) monitor, or a component monitor.

 Verify that you have the necessary cables and other required items.

Note: If the terminal was previously used, clear its hard drive before
installing it at a new subscriber location.

Clearing the Hard Drive

On a previously used cable terminal, delete all recorded programs from
the hard drive before installing it at a new subscriber location. This
prevents your new subscriber from viewing programming they may not
have purchased or may not want to see.

To prevent subscribers from accidentally deleting all of their recorded
programs, a specific set of keystrokes is required to clear the hard drive.
Having a TV connected is optional.
To clear the hard drive:

18

DCT3080 Installation Manual

1 Start the Diagnostics as described in Section 4, “Diagnostics.” d 01

is displayed on the front-panel LED.

2 Using a remote control, within five seconds press

three times, and
may be labeled “

LIVE TV. (On some remote controls, the MY DVR key
LIST.”)

REPLAY, MY DVR

If you correctly enter this key sequence in five seconds or less, the
hard drive is cleared and the front-panel LED displays

3 If

Clr is not displayed, re-enter the key sequence in step 2.

If

Clr is displayed, press any other key to reset the terminal, turn it

Clr.

off, and complete the clearing process.

Video Connection Options

Use the following guidelines to determine the best video connection for
the subscriber home entertainment system. To determine the available
video inputs on the TV, check the manual supplied with the TV or the TV
itself.

The DCT3080 offers the following video outputs:

S-Video

Video
(composite)

SDTV

only

SDTV

only

If your TV has an S-Video input, use S-Video. S-Video is
the highest quality standard-definition video output on
the DCT3080.

If your TV does not have an S-Video input, use the
composite video (

VIDEO) output.

RF

SDTV

only

If your TV only has a coaxial RF input, connect it to the

DCT3080

RF OUT connector.

19

DCT3080 Installation Manual

Audio Connection Options

Connect the stereo audio cable to the AUDIO R and L connectors on the
DCT3080 and the audio left and right connectors on the TV. If the
equipment supports it, use the
output instead of the

AUDIO R and L outputs. In most cases, these

outputs offer better audio quality, including support for 5.1 Surround
Sound.
When connecting to a home theater receiver, depending on its inputs,
you can use the following DCT3080 audio outputs:

OPTICAL SPDIF OR
COAXIAL SPDIF

BASEBAND
AUDIO

R AND L

If the receiver supports it, use the

SPDIF audio output to deliver Dolby AC-3 audio to a Dolby

Digital home theater receiver.

If the audio receiver does not support Dolby Digital, use the
baseband
receiver.

The cabling diagrams show sample audio/video (A/V) connections to an
audio receiver, where the receiver functions as an A/V router. When
connecting to an audio receiver, reference its installation instructions for
directions on connecting to baseband and SPDIF ports.

The VCR and TV receive their A/V signals from the currently selected
input device on the audio receiver. This is important when the subscriber
has another A/V device such as a DVD player, a secondary VCR, a CD
player, or other electronic component. We recommend connecting the
TV to the monitor output so on-screen menus for the receiver can be
displayed. (In many cases, the receivers themselves have interactive
on-screen menus.)

OPTICAL SPDIF or coaxial digital SPDIF

OPTICAL SPDIF or coaxial

AUDIO R and L outputs to connect to the audio

20

DCT3080 Installation Manual

Installation Overview

You are connecting to a standard definition TV – Connect the S-VIDEO
connector using an S-video cable, or connect the composite
connector using an RCA phono cable. If the TV only has a coaxial RF
input, connect it to the DCT3080

RF OUT connector.

Determine if you are connecting the audio to a home theater receiver or
directly to the TV:
 If the receiver or TV has an SPDIF input, use the optical spdif or

coaxial spdif outputs.

 Otherwise, use the baseband left and right audio out outputs.

1 Locate the cabling diagram(s) that best match the subscriber

configuration.

 Connect the audio and video cables in a manner matching that

diagram.

 Determine if you are connecting to a data device (see “Data

Device Connections” in this section). For installation details,

refer to instructions included with the data device.

Connect the cable terminal to the coaxial cable wall outlet.

VIDEO

 Perform the boot cycle, including the download to the terminal,

as described in “Boot Cycle” in this section.

2 Perform the operational check for the remote control.

 Optimize the video settings. See “Optimizing Video Settings” in

this section.

Verify that the appropriate configuration information has been
downloaded using the addressable controller, such as the DAC 6000.

21

DCT3080 Installation Manual

Connecting to an A/V Receiver – Audio Only

Connect the stereo audio cable to the AUDIO R and L connectors on the
cable terminal and the corresponding connectors on the HDTV.
If your equipment supports it, use the

SPDIF outputs instead of the AUDIO R and L outputs. In most cases,

digital
SPDIF offers better audio quality, including support for Dolby 5.1
Surround Sound.

Figure 2-4
Connecting to an A/V Receiver – Audio Only

OPTICAL SPDIF or coaxial

22

Connecting to a Stereo TV

Depending on the TV’s inputs:
 If possible, use the

S-VIDEO and AUDIO connectors on the DCT3080.

DCT3080 Installation Manual

 If the TV has no S-Video input, use the composite

VIDEO and AUDIO

connectors on the DCT3080.

 If the TV has an RF input only, use the

RF OUT connector on the cable

terminal. The RF connection carries video and audio.

Connecting a Stereo TV

 Connect an RF coaxial cable to the cable wall outlet and the CABLE IN

connector on the cable terminal.

 Connect the stereo audio cable to the

the cable terminal and the corresponding connectors on the stereo
TV.

 Connect an S-video cable to the

terminal and the TV. or

 Connect a video cable to the

terminal and the

VIDEO IN connector on the TV. or

 Connect an RF coaxial cable to the cable wall outlet and the

CABLE IN connector on the cable terminal.

 Connect an RF coaxial cable to the

terminal and the RF connector on the TV.

To connect to an audio receiver, such as a home mini system, follow a
daisy-chain convention. The A/V configuration illustrated (Figure 3-4)
enables digital stereo recording, including Dolby Surround sound. Use
only one set of RCA input connectors on the stereo:

AUDIO R and L connectors on

S-VIDEO connectors on the cable

VIDEO OUT connector on the cable

RF OUT connector on the cable

23

Figure 2-5
Connecting a Stereo TV

DCT3080 Installation Manual

24

DCT3080 Installation Manual

Connecting a Stereo TV and Stereo VCR

1 Connect an RF coaxial cable to the cable wall outlet and the CABLE IN

connector on the cable terminal.

2 Connect a stereo audio cable to the

the cable terminal and the

INPUT AUDIO R and L connectors on the

stereo VCR.

3 Connect a video cable to the

terminal and the

INPUT VIDEO connector on the stereo VCR.

VIDEO OUT connector on the cable

4 Connect a stereo audio cable to the

connectors on the stereo VCR and the
connectors on the stereo TV.

5 Connect a video cable to the

VCR and the

INPUT VIDEO connector on the stereo TV.

OUTPUT VIDEO connector on the stereo

AUDIO OUT R and L connectors on

OUTPUT AUDIO R and L

INPUT AUDIO RIGHT and LEFT

25

Figure 2-6
Connecting a Stereo TV and Stereo VCR

DCT3080 Installation Manual

26

DCT3080 Installation Manual

Connecting an A/V Receiver, TV, and VCR

 Connect an RF coaxial cable to the cable wall outlet and the CABLE IN

connector on the cable terminal.

 Connect a stereo audio cable to the

the cable terminal and the

INPUT R and L connectors on the

AUDIO OUT R and L connectors on

A/V receiver.

 Connect a video cable to the

terminal and the

CABLE/TV VIDEO connector on the A/V receiver.

 Connect a stereo audio cable to the

connectors on the A/V receiver and the

VIDEO OUT connector on the cable

VCR AUDIO OUT R and L

INPUT AUDIO R and L

connectors on the stereo VCR.

 Connect a stereo audio cable to the

connectors on the stereo VCR and the

OUTPUT AUDIO OUT R and L

VCR AUDIO IN R and L

connectors on the A/V receiver.

 Connect a video cable to the

VCR and the

VIDEO VCR OUT connector on the A/V receiver.

 Connect a video cable to the

VCR and the

VIDEO VCR IN connector on the A/V receiver.

 Connect a video cable to the

and the

TV/MONITOR OUTPUT video connector on the A/V receiver.

INPUT VIDEO connector on the stereo

OUTPUT VIDEO connector on the stereo

INPUT VIDEO connector on the stereo TV

If you can:

 Use the optical spdif or coaxial spdif outputs instead of the stereo

audio r and l outputs. In most cases, SPDIF offers better audio
quality, including support for Dolby 5.1 Surround Sound.

 Use the S-video connections instead of the standard RCA video

connections. In most cases, S-video offers better video quality.

27

Figure 2-7
Connecting an A/V Receiver, TV, and VCR

DCT3080 Installation Manual

28

DCT3080 Installation Manual

Recording Your Connections

Use this diagram to record the home entertainment component
connections. You can use this diagram to reconnect your system if you
move the equipment or add new equipment.

Disconnect the power from the cable terminal before connecting or
changing cable connections. Do not place another component or object
on top of the cable terminal.

29

DCT3080 Installation Manual

30

DCT3080 Installation Manual

Data Device Connections

The DCT3080 provides optional high-speed data services such as
Internet access, USB, Ethernet, and more. The functionality of each data

device port requires, and depends on, installed application software.

The DCT3080 rear panel provides the following data ports:

USB 2.0

Ethernet
SATA

Figure 2-8
Sample data devices you can connect to the DCT3080

Can be used to daisy-chain USB devices such as printers and
storage devices, or to interface with keyboards, joysticks, and
other USB PC peripherals.

10/100Base-T RJ-45 port

Can be used to connect an external hard drive to increase DVR
capacity

31

DCT3080 Installation Manual

Boot Cycle

After connecting the proper cabling to the DCT3080, plug the power
cord into the DCT3080 and electrical wall outlet. Begin performing the
boot cycle procedure:

 After a few moments, the LED displays HUNT and then FR 1.

 The DCT3080 searches for the headend out-of-band (OOB)

frequency carrier. If the OOB frequency is not set to 75.25 MHz, the
LED flashes FR 1 and then flashes FR 2. This searching process
repeats until the correct OOB frequency is found and the required
message for the DCT3080 model is acquired.

 The LED displays and OOB frequencies are:

Table 2-4
LED displays and OOB frequencies

Display Frequency Description

dl

EF

FP

____

Hunt

FR 1

FR 2

FR 3

FR 4

FR 5

FR 6

N/A
N/A
N/A
N/A
N/A

75.25
MHz

104.20
MHz

72.75
MHz

92.25
MHz

98.25
MHz

103.75
MHz

OOB network download in progress

Erasing Flash memory

Flash memory is being programmed

Network download complete

Hunting for OOB frequency

Attempting to lock on frequency 1

Attempting to lock on frequency 2

Attempting to lock on frequency 3

Attempting to lock on frequency 4

Attempting to lock on frequency 5

Attempting to lock on frequency 6

32

DCT3080 Installation Manual

Display Frequency Description

FR 7

FR 8

FR 9

FR 10

Au

 When the correct OOB frequency is acquired, the LED flashes FR

number.

 When multiple OOB frequencies are used, the DCT3080 pauses 40

seconds on each valid frequency. The LED displays dl and a
progress indicator, which identifies a software object download. The
progress indicator, or crawling ant, moves one position around the
dl display for each segment of download received. If the dl stops
moving up and down on the LED for an extended period of time,
contact the headend operator.

107.25
MHz

107.40
MHz

110.25
MHz

116.25
MHz

N/A

Attempting to lock on frequency 7

Attempting to lock on frequency 8

Attempting to lock on frequency 9

Attempting to lock on frequency 10

Authenticating code object (displays only after download)

The progress indicator usually moves at a consistent rate as segment
downloads are received. If all the segments are retrieved in the first
pass, the EF, AU, and FP messages are displayed on the LED. If
segments are dropped, the progress indicator appears to stall and then
inch forward after the dropped segments are retired.
The software download may take up to 45 minutes (or longer if the
system is experiencing high demand). As long as the progress indicator
is spinning, the download is progressing.

When the progress indicator alternates between rapid and sluggish
movement, this may indicate that the stream is spinning too fast for
existing plant conditions.

 When the software object download is complete, the LED displays:

EF

For up to 60 seconds during flash erasure

FP

For up to 60 seconds during flash programming

33

DCT3080 Installation Manual

 When the LED display is blank, the terminal is ready for initialization

and service authorization using the addressable controller. Verify that
the terminal is powered up or reset within two minutes of a
completed download.

Boot Cycle Error Codes

If hardware or software problems occur, the terminal displays error
codes on the LED display.
during boot cycle startup:

Table 2-5
Boot cycle error codes

Code Description When Error Occurs Action Required

125HTable 2-5 lists error codes that can occur

Eb
01

Eb
02

Eb
03

Eb
04

Eb
05

Eb
06

Object failed
validation

Download
time-out

Flash erase
failed

Flash
programming
failed

Invalid DLC
frequency

Hardware
initialization
failed

After the LED displays dl,
indicating validation check
failed

After cycling twice through the
OOB frequencies

After software object
download complete and EF is
displayed

After software object
download complete and FP is
displayed

After the LED displays dl,
indicating validation check
failed

After plugging the terminal
into an electrical outlet to
begin the boot cycle

Contact headend
operator

None

Replace the terminal

Contact headend
operator

Contact headend
operator

Replace the terminal

34

DCT3080 Installation Manual

Code Description When Error Occurs Action Required

Eb
07

Eb
08

Eb
09

Eb
10

Eb
11

Eb
12

Eb
13

Eb
14

Eb15

Object failed
validation

Reserved None

Check failed Reset within two minutes of a

SUDB
recreation

Failed to lock
OOB frequency

No COAC
message
received

No DLC
message
received

Bad object type
or class

No matching After cycling twice through the Contact headend

After software object
download complete and FP is
displayed

After a successful software
object download and the
terminal is reset

complete software object
download

After plugging the terminal
into an electrical outlet to
begin the boot cycle

After cycling twice through the
OOB frequencies (LED then
displays Eb 02, indicating
the software object download
was unsuccessful.)

After cycling twice through the
OOB frequencies (LED then
displays Eb 02, indicating
the software object download
was unsuccessful.)

After cycling twice through the
OOB frequencies (LED then
displays Eb 02, indicating
the software object download
was unsuccessful.)

After the LED displays dl,
indicating failed during
attempted download

Contact the headend
operator

No action required
because the terminal
repeats the software
object download

No action required
because the terminal
repeats software
object download
process

None

Ensure proper cable
connections

Contact headend
operator

Contact headend
operator

Contact headend
operator

35

DCT3080 Installation Manual

Code Description When Error Occurs Action Required

Eb18

Eb19

Eb20

Platform ID
found

Object size
mismatch

Object size
failed range
check

Invalid SUDB
pointer

OOB frequencies (LED then
displays Eb 02, indicating
the software object download
was unsuccessful.)

After the LED displays dl,
indicating failed during
attempted download

After the LED displays dl,
indicating failed during
attempted download

After plugging the terminal
into an electrical outlet to
begin the boot cycle

operator

Contact headend
operator

Contact headend
operator

None

Operational Check for the Remote Control

The operational check tests communication with the remote control:

Table 2-6
Operational check procedures

Feature Testing Procedure

Power on Press POWER on the remote control to turn on the DCT3080.

Channel
selection

Volume
control

Tune to the output channel (3 or 4).

Scan through the channels using the

Tune to several channels by entering the channel number using
the numeric keys.

VOLUME + or - on the remote control to increase the

Press
volume to its upper limit, lowest level, and to a comfortable
level.

Press

MUTE to turn the sound off. Press MUTE again to restore

the sound.

CHANNEL + or - keys.

If the DCT3080 does not operate properly, refer to Section 5,
“Troubleshooting.”

36

DCT3080 Installation Manual

Optimizing Video Settings

This subsection describes how to optimize standard definition video
settings and closed captioning based on subscriber preferences.
Before you optimize the output settings:

 Connect the DCT3080 to other home entertainment devices

 Plug the DCT3080 into a power outlet

 Perform the boot cycle

 Initialize the DCT3080 and authorize services

 Turn the TV on

For optimal viewing:

1 Power off the DCT3080, and then immediately press the menu

key on the front panel. If the TV is on, the on-screen menu lists
the settings you can configure:

USER SETTINGS

> TV TYPE 4:3 PAN/SCAN
YPbPr OUTPUT 480I
4:3 OVERRIDE OFF

CLOSED CAPTION DISABLED

SERVICE SELECTION

ANALOG CC1

DIGITAL PRIMARY LANGUAGE

FONT SIZE AUTO

FONT COLOR AUTO

FONT OPACITY AUTO

FONT EDGE TYPE AUTO

FONT EDGE COLOR AUTO

BACKGROUND COLOR AUTO

BACKGROUND OPACITY AUTO

SETTINGS AUTO

37

DCT3080 Installation Manual

RESTORE ALL DEFAULTS

2 Use the remote control or the cursor keys on the front panel to

navigate the on-screen menus:

 Press the ▲ and ▼ keys to highlight the setting you wish to

change.

 Press the ► key to select an option.

 To exit the setting and move to another setting, press the ▲ or

▼ key.

If the User Settings menu does not display on the TV screen, the TV
may not support the default video output setting. Use the front panel
LED to adjust the settings as described in “There is no video on the TV
screen” in “Troubleshooting.”
The User Settings menu options are:

Setting Description

TV Type

Sets the aspect ratio. The front panel display indicates the type
you select. Defaults to 4:3 PAN/SCAN. Options are 16:9 for
widescreen TVs or 4:3 LETTERBOX or 4:3 PAN/SCAN for
standard TVs.

YPbPr Output
4:3 Override
Closed

Caption

 4:3 LETTERBOX fits widescreen programming on

the screen by placing black bars at the top and
bottom.

 4:3 PAN/SCAN fills the screen by cropping the left

and right edges of widescreen programming.

Not user-configurable on the DCT3080.

Not user-configurable on the DCT3080.

Turns closed captions off or on. The front panel display
indicates the status of the closed captions. Defaults to
DISABLED. Options are ENABLED or DISABLED.

38

Setting Description

Service
Selection

 Analog: Not configurable on the DCT3080.

 Digital: PRIMARY LANGUAGE, SECONDARY

LANGUAGE, 3, 4, 5, or 6. The default is PRIMARY
LANGUAGE.

Font Size

Font Style

Font Color

Font Opacity

Font Edge
Type

Font Edge
Color

Background
Color

Background
Opacity

Settings

Restore All
Defaults

Sets the font size for closed captions. Defaults to AUTO.
Options are AUTO, STANDARD, LARGE, or SMALL.

Sets the font style. Defaults to AUTO. Options are AUTO,
MONO SERIF, PROPORTION SERIF, MONO NO SERIF,
PROPORTION NO SERIF, CASUAL, CURSIVE, or SMALL.

Sets the font color. Defaults to AUTO. Options are AUTO,
WHITE, BLACK, RED, GREEN, BLUE, YELLOW, MAGENTA,
or CYAN.

Sets the opacity. Defaults to AUTO. Options are AUTO,
TRANSPARENT, TRANSLUCENT, SOLID, or FLASHING.

Sets the edge appearance — AUTO, NONE, RAISED,
DEPRESSED, UNIFORM, LEFT SHADOWED, or RIGHT
SHADOWED. The default is AUTO.

Sets the edge color — AUTO, WHITE, BLACK, RED, GREEN,
BLUE, YELLOW, MAGENTA, or CYAN. The default is AUTO.

Sets the background color for closed captions. Defaults to
AUTO. Options are AUTO, WHITE, BLACK, RED, GREEN,
BLUE, YELLOW, MAGENTA, or CYAN.

Sets the background opacity for closed captions. Defaults to
AUTO. Options are AUTO, TRANSPARENT, TRANSLUCENT,
SOLID, or FLASHING.

Sets the default settings for closed captions (AUTO) or the
settings you have configured (USER). Defaults to AUTO.
Options are AUTO or USER.

To reset all User Settings to their defaults, select this option
and press the ► key.

DCT3080 Installation Manual

To exit the menu and save your settings, press the POWER or MENU key.

39

DCT3080 Installation Manual

Graphics Overlaying the Video

The DCT3080 can generate graphics that overlay the video programming
or fill the entire television screen. Common examples include on-screen
menus (such as the User Setting menu), closed captions, and EPG. The
DCT3080 overlays these graphics whenever the subscriber opens a
menu, enables closed captions, or scrolls through a program grid.
On-screen graphics are available for all DCT3080 video outputs except.

40

DCT3080 Installation Manual

Diagnostics

This section describes the diagnostics that confirm proper installation,
including:

 Checking error states and signal integrity

 Identifying the cable terminal on the network

 Verify communications with the headend

Diagnostics are displayed on the on-screen display (OSD) and front-panel
LEDs.
For the diagnostics described in this section:

 All indicators are in decimal notation, unless otherwise noted.

 All signal-level and quality indicators use a 1% to 100% scale, unless

otherwise noted.

 All sample displays are illustrative; actual data may differ from the

examples.

You can use the diagnostics when running the base platform or Thin
Client software.

Note: Diagnostics are continually updated through software upgrades to provide

expanded information regarding the status of the DCT-3080. Check the

Motorola website for updated versions of this manual (www.motorola.com).

Using the Diagnostics

To use the diagnostics:

1 Ensure that the DCT3080 is installed with the base platform or

Thin Client software and that it is connected to an AC outlet.

41

DCT3080 Installation Manual

2 Press POWER and immediately press SELECT to enable diagnostic

mode. The Diagnostics main menu is displayed on the OSD and
“d01” is displayed on the front-panel LED:

DIAGNOSTICS

> d01 GENERAL STATUS

d02 PURCHASE STATUS

d03 OOB STATUS

d04 INBAND STATUS

d05 UNIT ADDRESS

d06 CURRENT CHANNEL STATUS

d07 UPSTREAM MODEM

d08 CODE MODULES

d09 MEMORY CONFIG

d10 KEYPAD/LED

d11 INTERFACE STATUS

d12 USER SETTING STATUS

d13 PVR/HDD STATUS

d14 DOCSIS

d15 APPLICATION SPECIFIC INFORMATION

d16 INTERACTIVE STATUS (displayed only when Thin Client is

running)

E EXIT

Figure 3-1
Example of the LED for the main menu

MUTE

42

MUTE

P

DCT3080 Installation Manual

You can use the following keys to navigate the diagnostics menus:

 Press

CHANNEL ▲, CHANNEL ▼, CURSOR ▲, or CURSOR ▼ to select d01

through E.

 Press

CURSOR ◄, CURSOR ►, SELECT, or ENTER to execute the selected

diagnostic.

 Select E from the main menu or press

POWER to exit.

d01 General Status

This diagnostic displays system status information on the OSD and LED.
The information is updated each time the diagnostic is displayed.

GENERAL STATUS

ERROR: EP00 CONNECTED

PLATFORM ID: 0x02D0

FAMILY ID: 0x0000

MODEL ID: 0X34CA

REMOD CHAN:

SETTOP TIME:

Figure 3-2
Example GENERAL STATUS LED (no error)

03

xxxxxxxxxx GPS

P

Environment code Error code

The General Status fields are:

MUTE MUTE

43

Field Description

Error

Connected
State

Platform
ID

Family ID
Model ID
Remod

Chan
Settop

Time

Error codes display on the LED and OSD when an error occurs. If
multiple errors occur, the last recorded error is displayed:

EP00 No error

EP01 Not connected

EP03 DRAM error

EP04 SRAM error

EP07 ROM verification failure

EP08 RAM test failure

EP09 Battery test failure

EP11 Invalid unit address

EP12 Power on self test failure

EP14 GITV startup failure

EP15 TSI structure corrupt

EP18 Driver initialization failure

A DCT-operations connect or disconnect message determines
whether the DCT3080 is CONNECTED or DISCONNECTED.

A unique 16-bit hexadecimal number that identifies the platform
image (also called the ROM ID).

The manufacturer and product family, in hexadecimal

The model, in hexadecimal

The interface to the subscriber TV; channel 3 or 4 in the USA

The current OOB time displayed in global positioning system
(GPS) seconds from Jan 6, 1980. It is an integer from 0 to

4294967295.

DCT3080 Installation Manual

44

DCT3080 Installation Manual

d02 Purchase Status

This diagnostic displays the status of subscriber event purchases on the
OSD and LED. The OSD and LED information displays are updated each
time this diagnostic is displayed:

PURCHASE STATUS

PURCHASES

UNSENT:

UNACK:

LAST SEQ NUM:

LAST RB TIME:

IPPV STATUS: Enabled

Figure 3-3
LED display for PURCHASE STATUS diagnostic

Purchase indicator

xx
xx
xxxx
xxxxxxxxxx

P

MUTE MUTE

On when

enabled

is

The Purchase Status fields are:

Field Description

Unsent

Unack

Last Seq
Num

Last RB
Time

The number of purchases in the DCT remaining to be polled. It can
be an integer from 0 to 63.

The number of reports that have not been acknowledged by the
controller. It is an integer.

The last acknowledged sequence number of a purchase sent by the
controller. It is a 16-bit, unsigned hexadecimal number.

The last time the DCT3080 attempted to report back purchases to
the controller, in GPS seconds.

IPPV

Number of unsent

purchases

45

DCT3080 Installation Manual

Field Description

IPPV
Status

If IPPV is enabled, the IPPV status indicator LED is on. If IPPV is
disabled, the IPPV status indicator LED is off.

d03 Out-Of-Band (OOB) Status

This diagnostic indicates the out-of-band control channel status. The
information is updated every 5 seconds.

OOB DIAGNOSTIC

OOB FREQUENCY: 075.25 MHz

CARRIER LOCK: YES

DATA: YES

EMM DATA: YES

SNR: 22.1 dB GOOD

AGC: 23 % GOOD

EMM PROVIDER ID: 0x0400

EMM PID: 0x0403

NETWORK PID: 0x0003

Figure 3-4
LED display for the OOB diagnostic

STARVUE
frequency

OOB diagnostic

indicato r

MUTE MUTE

Carrie r lock in dicat or

(L = locked, U = unlocked)

46

EMM data activity indicatorData activity indicator

PP

DCT3080 Installation Manual

The Out-Of-Band Status fields are:

Field Description

OOB
Frequency

Carrier
Lock

OSD LED Description

Data

OSD LED Description

EMM Data

OSD LED Description

SNR

AGC

EMM
Provider
ID

Indicates the OOB tuner center frequency, from 70 to 130 MHz.

Indicates whether the OOB receiver is locked to the carrier:

YES L Carrier locked

NO U Carrier unlocked

Indicates whether data is being carried by the OOB and EMM
traffic, which is tracked separately:

YES On OOB data detected within last 5 seconds

NO Off OOB data not detected within last 5 seconds

Indicates whether EMM data is being carried on the OOB stream:

YES On EMM data detected within last 5 seconds

NO Off EMM data not detected within last 5 seconds

When carrier lock has been established, displays an estimate of
the carrier signal-to-noise ratio in dB, with an explanation:

 GOOD — Good value
 FAIR — Marginal signal level; check the signal
 POOR — Unusable signal
 INVALID — Invalid SNR value

When carrier lock has been established, displays an estimate of
the AGC as a percentage, with an explanation:

 GOOD — Good value
 FAIR — Marginal signal level; check the signal
 POOR — Unusable signal
 INVALID — Invalid AGC value

Displays the conditional access stream for the DCT3080, in
hexadecimal

47

DCT3080 Installation Manual

Field Description

EMM PID

Network
PID

Displays the packet identifier (PID) stream the DCT3080 tunes to
for EMM data, in hexadecimal

Displays the network PID to which the DCT3080 is tuned to
receive network messages, in hexadecimal

d04 In-Band Status

This diagnostic displays the in-band status for the last attempted tuned
channel. The information is updated every 5 seconds.

IN-BAND DIAGNOSTIC

IN-BAND TUNER 1

MODE: 64 QAM

CARRIER LOCK: YES

DATA: YES

SNR 32.0 Db GOOD

AGC: 23 % FAIR

5 SECOND ERROR COUNTS:

UNCORRECTABLE: 1234 CORRECTABLE: 5678

IN-BAND TUNER 2

MODE: 64 QAM

CARRIER LOCK: YES

DATA: YES

SNR 32.0 Db GOOD

AGC: 23 % FAIR

5 SECOND ERROR COUNTS:

UNCORRECTABLE: 1234 CORRECTABLE: 5678

48

Figure 3-5
LED display for in-band diagnostic

DCT3080 Installation Manual

Data activity indicator

P

MUTE MUTE

IB diagnostic

indicator

Carrier lock indicator

(L = locked, U = unlocked)

The In-Band Status fields are:

Field Description

Mode

The values displayed on the OSD are:

 64 QAM — 64 QAM digital channel
 256 QAM — 256 QAM digital channel

Carrier
Lock

Indicates whether the in-band receiver is locked to the carrier. If a
digital carrier is not present, it indicates the carrier is not locked:

OSD LED Description

Data

YES L Carrier locked

NO U Carrier not locked

Indicates whether data is being carried on the in-band stream.
The indicators cover all packet processors, regardless of the
stream they are monitoring:

OSD LED Description

SNR

YES On In-band data detected within last 5 seconds

NO Off In-band data not detected within last 5 seconds

When carrier lock has been established, displays an estimate of
the carrier signal-to-noise ratio in dB, with an explanation:

 GOOD — Good value
 FAIR — Marginal signal level; check the signal
 POOR — Unusable signal
 INVALID — Invalid SNR value

49

Field Description

AGC

When carrier lock has been established, displays an estimate of
the automatic gain control as a percentage, with an explanation:

 GOOD — Good value
 FAIR — Marginal signal level; check the signal
 POOR — Unusable signal
 INVALID — Invalid AGC value

5 Second
Error
Counts

Indicates the number of correctable and uncorrectable digital
multiplex errors, up to 9999. It is updated every 5 seconds and
reset each time the DCT3080 is power cycled or another digital
multiplex is tuned. The maximum value displayed is 9999, even if
there were more than 9999 errors.

DCT3080 Installation Manual

50

d05 Unit Address

This diagnostic displays the unit address:

UNIT ADDRESS

TVPC INSTALLED NO

UNIT ADDRESS:

123-45678-90123-456

OOB ADDRESSES:

NETWORK: 123-45678-90123-456

MULTICAST 16 ADDRESS FOR:

0x0000 0x0000

0x0000 0x0000

MAC ADDRESSES:

DOCSIS: xx xx xx xx xx xx

Ethernet:

1394:

USB:

Settop:

xx xx xx xx xx xx
xx xx xx xx xx xx
xx xx xx xx xx xx
xx xx xx xx xx xx

DCT3080 Installation Manual

nnnn

51

Figure 3-6
LED display of a unit address

DCT3080 Installation Manual

P

MUTE

MUTE

MUTE

MUTE

MUTE

The Unit Address fields are:

Field Description

TvPC
Installed

Indicates whether the TVPC renewable security system is
installed:

 YES — TvPC is installed
 NO — TvPC is not installed

Unit
Address

OOB Addresses

Network
Multicast

16
Address
For

A unique decimal number that indicates the unit address or
physical address.

The DCT3080 network address displayed in decimal format.

Specifies the stream to which the OOB multicast 16 addresses
are assigned. The stream type and multicast 16 addresses cycle

on the OSD every 5 seconds. The valid stream types nnnn are:

 Net — Network

P

P

P

P

52

MAC
Addresses

DCT3080 Installation Manual

 EMM — EMM
 SCC — SCC_ECM
 Dnld — Download
 Data — Data
 Poll — Polling packet identifier (PID)

The 16-bit multicast address is displayed in 4-byte hexadecimal
format. The Multicast 16 addressed messages filter on a 16-bit
multicast address. The user processor can define up to four
multicast addresses in hardware, and any message matching
one of the four is processed. Messages not matching the
multicast address are discarded.

The DOCSIS, Ethernet, 1394, USB, and MAC addresses are
stored in protected flash and displayed in hexadecimal.

53

DCT3080 Installation Manual

d06 Current Channel Status

This diagnostic displays a status of the last attempted tuned channel on
the in-band stream. The channel type determines the status display.

This is an example for a digital channel:

CURRENT CHANNEL STATUS

PRIMARY A/V SOURCE IB TUNER 1

IB TUNER 1

TYPE: DIGITAL aaa 0xbb

INBAND FREQUENCY: 199.2500 MHz

AUTHORIZED: YES

PURCHASABLE: NO

PURCHASED: NO

PREVIEW: NO

MPEG VIDEO LOCK YES

MPEG AUDIO LOCK YES

PCR LOCK YES

CCI: 0x00 APS: 0x00 RC Flag: 0x00

CIT: 0x00 DRM: 0x00 RS: Forever

Page 1 of 3 vvv Scroll Down vvv

54

e

:

Figure 3-7
Current channel status LED displays

DCT3080 Installation Manual

Digital channel

Digital channel indicator Epoch authorization cod

Purchasable indicator

MUTE

Preview indicator

P

P

MUTE

The Current Channel status fields are:

Field Description

Type

aaa Displays the encryption mode for the channel on the OSD and

Indicates that the channel is digital:

OSD LED Description

DIGITAL d Digital

LED. It is updated every 5 seconds.

For a digital channel:

 ENC − encrypted
 UNE − unencrypted
 CLR − clear

bb (Digital channels only) The current epoch authorization reason is

displayed in the hexadecimal format 0xbb on the OSD and LED.

In-Band
Frequency

Authorized

(Digital channels only) The center RF carrier frequency for the

digital service. It can be from 54 to 860 MHz.

Indicates whether the DCT3080 is authorized for the currently
tuned service:

 YES — authorized
 NO — not authorized

Purchasable

Indicates whether the current program can be purchased for
viewing:

OSD LED Description

YES on Can be purchased

NO off Cannot be purchased

55

Field Description

Preview

MPEG Video
Lock

Indicates whether the current program is in preview mode:

OSD LED Description

YES on In preview mode

NO off Not in preview mode

Indicates whether the video processor is locked to the video
stream:

 YES — locked
 NO — not locked

MPEG
Audio Lock

Indicates whether the audio processor is locked to the audio
stream:

 YES — locked
 NO — not locked

PCR Lock

Indicates whether the in-band receiver is locked to the program
clock reference (PCR):

 YES — locked
 NO — not locked

CCI

The copy control information:

 00 — copy free
 01 — no more copies
 10 — copy once
 11 — never copy
 N/A — the value is invalid or cannot be retrieved

RC Flag

Displays whether the broadcast flag is present:

 0 — no flag/not defined
 1 — the flag is present/enabled
 N/A — the value is invalid or cannot be retrieved

CIT

The constrained image trigger as delivered in the PRK or the Set
DRM API:

 1 — set
 0 — not set
 N/A — the value is invalid or cannot be retrieved

DCT3080 Installation Manual

56

Field Description

DRM

The digital rights management valid flag bit:

 1 — set
 0 — not set
 N/A — the value is invalid or cannot be retrieved

RS

The retention state:

 Forever, 1 week, 2 days, 1 day, 12 hours, 6 hours, 3 hours,

90 minutes, or Not Defined

 N/A — the value is invalid or cannot be retrieved

DCT3080 Installation Manual

57

DCT3080 Installation Manual

f

d07 RF Modem (Upstream)

This diagnostic displays the RF modem status, if an RF modem is
installed in the DCT3080. The information is updated each time this
diagnostic is displayed.

RF MODEM

STATUS: CONFIGURED

CENTER FREQUENCY: 9.0000 MHz

REQUESTED POWER LEVEL: 23 dB

ACTUAL POWER LEVEL: 20 dB

REPORT BACK ADDRESS:

LAST RB ATTEMPT TIME:

Figure 3-8
RF upstream modem LED display

STARVUE
frequency

MUTE MUTE

xx xx xx xx
xxxxxxxxxx

Decimal point

P

Frequency indicator Frequency in MHz

Alternating with

P

STARVUE
power level

MUTE MUTE

Power level in dicator Power level in dB (blank i

modem not configured)

58

DCT3080 Installation Manual

The RF Modem fields are:

Field Description

Status
Center

Frequency
Requested

Power
Level

Actual
Power
Level

Report
Back
Address

Last RB
Attempt
Time

CONFIGURED or NOT CONFIGURED.

The RF modem center frequency is displayed on the OSD and
LED in MHz.

The value assigned to the DCT3080 during RF leveling; in dB or
blank if not configured.

The power level is displayed on the OSD and LED; in dB or is
blank if the power level has not been set.

Displayed in 4-byte hexadecimal format, if configured.

The last attempted report back by the DCT3080, in GPS seconds.

d08 Code Modules

This diagnostic includes information about the firmware loaded in flash
memory and all non-volatile code versions installed on the DCT3080.
When the native suite is running, the diagnostics of the application
operating system and all associated objects should be accessible.

ASTB INVD

Boot Code: 05.04

Platform Built: 12.09

Version: Mar 24 2005 13:16:16

Digital Secure Processor: M02

Object Ver Status ID

ASMS____ 66.04 ENABLED 0881

CONFIG 50.01 ENABLED 0890

MSTVURIS 00.03 ENABLED 0860

59

Figure 3-9
LED display for code modules

Number of segments remaining
for download to complete. (Figure

Code module identifier (bPC for the
base platform; CODE or SYS for the
system obje ct)

segments remaining.)reflects 17012

DCT3080 Installation Manual

Download data received indicatoDownload status

P

MUTE MUTE

P

MUTE MUTE

P

MUTE MUTE

or

P

MUTE MUTE

Alte rna ting w ith

Code module version number

P

MUTE MUTE

Indicator separating major and

minor revision numbers

60

DCT3080 Installation Manual

The Code Modules fields are:

Field Description

Boot Code
Version
Digital Secure

Processor
Downloadable

Object
Information Table

Object
Ver
Status

OSD Status Description

The boot code version in ASCII format

The firmware version and build date in ASCII format

The digital secure processor version in ASCII format

Lists all objects loaded, or being loaded, onto the DCT3080
in ASCII format. The information displayed for each object
depends on the running environment. If a download is not
in progress, the LED displays the current environment
running and version number, as shown in Figure 4-9. On
the LED, “bPC” represents base platform or Thin Client
code.

The object name

The object version

The object status, updated on the OSD and LED every
5 seconds while you display the diagnostic:

MEM ALLOC Allocated Memory for object is

allocated

LOADING Loading Object is being loaded

STARTING Enabling Object is being started

(the constructor is
running)

ENABLED Enabled Object is running

ENA–NOT
RUN

STOPPING Disabling Object is being stopped

DISABLED Disabled Object has been disabled

DIS-NOT
RUN

Enabled_Not_
Runnable

Disabled_Not_
Runnable

Object is enabled, but
cannot run

(the destructor is running)

Object is disabled and
cannot run

61

DCT3080 Installation Manual

Field Description

ID

DELETING Deleting Object is being deleted

POSTPONED Postponed Object cannot run on the

current system; it will be
enabled during the next
boot

CONNECTED Connect Connected to download

PID − awaiting data

PEND
CONNECT

The object identifier

TryingToConnect Trying to connect

d09 Memory Configuration

This diagnostic displays the DCT3080 memory configuration. The
information is updated when you display the diagnostic.

MEMORY CONFIGURATION

SYSTEM RAM: 128 MB

FLASH: 16 MB

NVRAM: 256 KB

There is no LED display for this diagnostic.
The Memory Configuration fields are:

Field Description

System
RAM

Flash
NVRAM

The allocated system RAM in MB.

The allocated flash memory in MB.

The allocated NVRAM in KB.

62

DCT3080 Installation Manual

d10 Keypad–LED

This diagnostic verifies the functionality of the LEDs and the front-panel
keypad. Each highlighted character corresponds with a front-panel key
press.

< > U D Î M P B G S + -

d11 Interface Status

The Interface Status diagnostic displays when running in base platform
or Thin Client. There is no LED display. The information on the OSD is
updated when you display the diagnostic.

INTERFACE STATUS

DOCSIS TUNER & XMITTER: INST

1394 I/O DEVICE: NOT INST

ACTIVE PORTS 0

DATA XMISSION NO

5C IMPLEMENTATION 0

LOOP STATUS NO

ROOT STATUS YES

CYCLE MASTER STATUS YES

USB I/O DEVICE: INST

10BT ETHERNET DEVICE: INST

PARALLEL PORT: INST

IR BLASTER: INST

HARD DRIVE STATUS: INST

SMART CARD: INST

HDMI PORT

DEVICE CONNECTED: YES/NO

REPEATER: YES/NO

63

VIDEO XMISSION: ACTIVE/NOT ACTIVE

HDCP ENABLED: YES/NO

VIDEO CONSTRAINED YES/NO

OUTPUT FORMAT XXXX x XXXX

ASPECT RATIO:

EDID DATA

The Interface Status fields are:

Field Description

DOCSIS Tuner
& Xmitter

1394 I/O Device
USB I/O Device
10BT Ethernet

Device
Parallel Port
IR Blaster
Hard Drive

Status
Smart Card

INST (installed) or NOT INST (not installed)

INST (installed) or NOT INST (not installed)

INST (installed) or NOT INST (not installed)

INST (installed) or NOT INST (not installed)

INST (installed) or NOT INST (not installed)

INST (installed) or NOT INST (not installed)

INST (installed) or NOT INST (not installed)

INST (installed) or NOT INST (not installed)

DCT3080 Installation Manual

xx:x

64

Field Description

HDMI Port

Device
Connected

Repeater

Video Xmission
(transmission)

HDCP Enabled

Video
Constrained

Output Format

If a device is connected to the HDMI port only, the following

diagnostics display to help troubleshoot the HDMI interface.
They all display “N/A” if no device is connected to the HDMI
port or the value is invalid or cannot be retrieved.

Indicates whether a device is connected to the HDMI port —
Yes or No.

Indicates whether the connected device is a repeater —
Yes or No.

Indicates whether the DCT3080 is transmitting video over the
HDMI port — Not Active or Active.

Indicates whether the DCT3080 is using HDCP to encrypt
video transmitted over the HDMI link — Yes or No. If the
Video Xmission status is Not Active, the HDCP Enabled
status is No.

Indicates whether the DCT3080 is constraining the video sent
through HDMI — Yes or No. If the Video Xmission status is
Not Active, the Video Constrained status is No.

Indicates the timing format of the video sent through HDMI:

 1920 x 1080I — 1920 pixels wide by 1080 pixels high,

interlaced

 1280 x 720P — 1280 pixels wide by 720 pixels high,

progressive

 720 x 480P — 720 pixels wide by 480 pixels high,

progressive

 720 x 480I — 720 pixels wide by 480 pixels high,

interlaced

 640 x 480P — 640 pixels wide by 480 pixels high,

progressive

Aspect Ratio

Indicates the aspect ratio of the video sent through HDMI —
3:4 or 16:9.

DCT3080 Installation Manual

65

DCT3080 Installation Manual

Field Description

EDID Data

Indicates the video timing formats that were read from the
Extended Display Identification Data (EDID) registers for the
connected device, in particular the detailed timing description
blocks. The list displays all of the formats that the DCT3080
could read, up to a maximum of 12 formats. If the DCT3080
cannot read any formats, EDID Data is blank. An asterisk (*)
after the aspect ratio means the DCT3080 supports the
format. If more than twelve video timing formats are

discovered, the supported formats only are listed first,

followed by up to twelve remaining formats.

d12 User Setting Status

This diagnostic displays the user settings. The format may vary. The
information on the OSD and LED is updated when you display the
diagnostic.

USER SETTING STATUS

TV TYPE 4:3 PAN/SCAN

YPbPr OUTPUT 480i

4:3 OVERRIDE OFF

CLOSED CAPTION ENABLED

PEN SIZE STANDARD

FONT STYLE MONO SERIF

FOREGROUND COLOR BLACK

FOREGROUND OPACITY AUTO

BACKGROUND COLOR WHITE

BACKGROUND OPACITY AUTO

SERVICE SELECTION PRIMARY LANGUAGE

SETTINGS USER

66

The User Setting Status fields are:

Field Description

TV Type

The aspect ratio. Defaults to 16:9. Options are 16:9 for wide
screen TVs or for standard TVs:

 4:3 LETTERBOX places black bars at the top and bottom to

fit high-definition programs on the screen

 4:3 PAN/SCAN crops the left and right edges of

high-definition programs to fill the screen

HDMI/YPbPr
Output

4:3 Override

The video display format for the component video outputs.
Defaults to 1080i. Options are 1080i, 720p, 480p, or 480i. Some
TVs only support certain display formats. Check the TV user
manual for more information.

If you are not using an HDTV, selecting a format other than 480i
causes the on-screen display to go blank. If this occurs, view the
settings on the LED panel to change the format back to 480i.

If you are not using the HDMI video connection, the HDMI/YPbPr
OUTPUT setting displays as YPbPr OUTPUT.

The display format used for 4:3 standard-definition programming.

 OFF displays non-high-definition programs having a 4:3

aspect ratio in wide screen format. On an HDTV, black bars
display on the left and right of the picture. Selecting OFF for
a 4:3 TV may result in a small picture with black bars around
it.

Closed
Caption

Pen Size

Displays whether closed captions are ENABLED or DISABLED.

Displays the selected pen size — Auto (controlled by the closed
caption stream), Standard, Large, or Small.

DCT3080 Installation Manual

67

Field Description

Font Style

Displays the selected font style:

 AUTO — The font style is controlled by the closed caption

stream.

 MONO SERIF — Monospaced with serifs
 PROPORTION SERIF — Proportionally spaced with serifs
 MONO NO SERIF — Monospaced without serifs
 PROPORTION NO SERIF — Proportionally spaced without

serifs

 CASUAL — Casual font type
 CURSIVE — Cursive font type
 SMALL — Small capitals

Foreground
Color

Foreground
Opacity

Background
Color

Background
Opacity

Service
Selection

Displays the selected foreground color — Auto (controlled by the

closed caption stream), White, Black, Red, Green, Blue, Yellow,

Magenta, or Cyan.
Displays the selected foreground opacity — Auto (controlled by

the closed caption stream), Transparent, Translucent, Solid, or
Flashing.

Displays the selected background color — Auto (controlled by

the closed caption stream), White, Black, Red, Green, Blue,

Yellow, Magenta, or Cyan.
Displays the selected background opacity — Auto (controlled by

the closed caption stream), Transparent, Translucent, Solid, or
Flashing.

Displays the selected service selection:

 AUTO — Service selection is controlled by the closed

caption stream.

 PRIMARY LANGUAGE — Primary language set by the

provider.

 SECONDARY LANGUAGE — Secondary language set by

the provider.

 3, 4, 5, or 6 — Set by the provider.

DCT3080 Installation Manual

68

Field Description

Settings

Displays the selected setting:

 AUTO — Closed caption settings are determined by the

closed caption stream regardless of user modification.

 USER — The configured closed caption user settings are

used.

DCT3080 Installation Manual

69

DCT3080 Installation Manual

d13 DVR/Hard Drive Status

This two-page diagnostic displays the DVR and hard-drive status.

DVR/Hard Drive Status

DVR Status

Enabled: True

Stream Indexer Ver: 131

Content Record Ver: 2

Encoder

Number Type Quality

1 MPEG2 HIGH2

2 MPEG2 HIGH2

Drive Record Capacity Remaining

IDE0

vvv Scroll Down vvv

xxxxxxxxxxxxxxxxxxxx

70

DCT3080 Installation Manual

Hard Drive Status

Number of Installed Drives: 1

Drive: 1 INTERNAL

Model

Number:

Device ID: N/A

Type: IDE

Total Size: 80 GB Used

System 1

GPFS 2

PVR
Content

PVR Index 35

State Active

Temp (F) 118 Max

Over Temp No Count: 0

ST3120025ACE

10864

122

Temp:

71

DCT3080 Installation Manual

The DVR/Hard Drive Status fields are:

Field Description

Enabled

OSD LED Description

Stream
Indexer Ver.

Content
Record Ver.

Number
Type

Drive

Record
Capacity
Remaining

Number of
Installed
Drives

Drive

Model
Number

Device ID

Type
Total Size

Indicates whether the DVR is enabled, based on the DCT3080
Connected State (CONNECTED or DISCONNECTED) and
resource availability (resource authorized; hard disk installed
and functional):

True En DVR enabled

False Un DVR disabled

The stream indexer version number, without leading zeros; for
example, version 0000000065 is displayed as “65”

The content record version number, displayed without leading
zeros

Indicates the encoder number — 1 or 2

Indicates the encoder type — Not Inst(alled), MPEG2, Other, or
Unknown

The drive type — IDE (internal), 1394, USB (external), or NOT
AVAILABLE (neither enabled nor configured)

The remaining recording capacity, in bytes

The number of internal and external hard drives, up to a
maximum of 9

The identification number sequentially assigned to each
installed drive and whether the drive is INTERNAL or
EXTERNAL

The drive model number assigned at the factory

A text string of up to 20 characters that identifies the disk drive;
“N/A” is displayed if the value is invalid or cannot be retrieved

The drive type — IDE, 1394, USB, or Unkn(own)

The drive size in decimal GB. (1 decimal GB = 1x10
example, 120 decimal GB = 120x10

9

bytes.)

9

bytes. For

72

Field Description

System,
GPFS, PVR
Content,
and PVR
Index

State

The space used and allocated for each of the internal hard
drive’s partitions —System, GPFS, PVR Content, and PVR
Index — in MB for each partition (1 binary MB = 2
“N/A” displays if the value is invalid or cannot be retrieved.

The hard drive state:

 Standby — The hard drive is working normally, but is at

rest. (The State returns to Active any time disc access is
necessary.)

 Active — The hard drive is accessing data.
 Failed — The hard drive hardware has failed.

Temp (F)

Max Temp

Over Temp

For an internal hard drive only, its temperature in degrees F
For an internal hard drive only, its maximum temperature in

degrees F

Indicates whether the drive is excessively hot:

 Yes — The internal drive temperature exceeds 140º F (60º

C). The LED Over-Temp Indicator is on and remains lit
until the next over-temp sample is taken (at least once an
hour).

 No — There is no over-temp problem.

Count

The cumulative number of times that the hard drive
temperature has been measured over 60º C, with the
temperature checked at least once an hour.

DCT3080 Installation Manual

20

bytes).

73

DCT3080 Installation Manual

d14 DOCSIS Status

This three-screen diagnostic displays status information for the
embedded cable modem (ECM):

DOCSIS STATUS

DOCSIS Enabled: YES

Acquire DS Channel: YES

Obtain US Parameters: YES

Establish IP Connectivity: YES

Obtain Configuration File: YES

eCM Registered: YES

Network Access: YES

Initialize BPI: YES

System Up Time:

xxx Days

xx Mins xx Seconds

IP Addresses

Cable Modem

Set-Top Box

Page 1 of 3 vvv Scroll Down vvv

xx Hours

xxx.xxx.xxx.xxx
xxx.xxx.xxx.xxx

74

DCT3080 Installation Manual

DOCSIS ^^^ Scroll Up ^^^

MAC Addresses

Cable Modem

Set-Top Box

Downstream Channel

Carrier Lock YES

Frequency

LKC:

Mode: QAM 256

Power Level:

SNR: xx.x

Upstream Channel

Frequency

Mode: QAM 128

Channel ID:

Power Level:

Symbol Rate:

Page 2 of 3 vvv Scroll Down vvv

xx.xx.xx.xx.xx.xx
xx.xx.xx.xx.xx.xx

xxx
xxx

xxx

xx

xxx
xxx
x.xxx

DOCSIS ^^^ Scroll Up ^^^

Known MAC Addresses

xx.xx.xx.xx.xx.xx

xx.xx.xx.xx.xx.xx

xx.xx.xx.xx.xx.xx

75

DCT3080 Installation Manual

Page 3 of 3

76

The fields are:

Field Description

DOCSIS
Enabled

Acquire DS
Channel

For a DOCSIS-enabled set-top, YES. Otherwise, NO.

The DOCSIS downstream channel acquisition status:

 YES — The downstream channel is acquired
 NO — The set-top is acquiring the downstream channel
 N/A — The value is invalid or cannot be retrieved, or

DOCSIS is not enabled

Obtain US
Parameters

The DOCSIS upstream channel descriptor (UCD) acquisition
status:

 YES — The UCD is acquired
 NO — The set-top is acquiring the UCD or the

downstream channel

 N/A — The value is invalid or cannot be retrieved, or

DOCSIS is not enabled

Establish IP
Connectivity

Displays whether the cable modem has acquired its IP address,
typically from a Dynamic Host Configuration Protocol (DHCP)
server:

 YES — The IP address is acquired
 NO — The set-top is acquiring its IP address
 N/A — The value is invalid or cannot be retrieved, or

DOCSIS is not enabled

Obtain
Configuration
File

Displays whether the cable modem has downloaded its
DOCSIS cable modem configuration file from the TFTP server:

 YES — The cable modem configuration file has been

successfully downloaded

 NO — The set-top is downloading its cable modem

configuration file

 N/A — The value is invalid or cannot be retrieved, or

DOCSIS is not enabled

DCT3080 Installation Manual

77

DCT3080 Installation Manual

Field Description

eCM
Registered

Network
Access

Initialize BPI

System Up
Time

IP Addresses The Cable Modem and Set-Top IP addresses in dotted-

MAC
Addresses

Displays whether the embedded cable modem has registered
with the cable modem termination system (CMTS):

 YES — DOCSIS registration is complete
 NO — DOCSIS registration is in progress or the set-top

could not register

 N/A — The value is invalid or cannot be retrieved, or

DOCSIS is not enabled

Displays whether the cable modem has been granted access to
the DOCSIS network:

 YES — The cable modem was granted DOCSIS network

access

 NO — The set-top is obtaining DOCSIS network access
 N/A — The value is invalid or cannot be retrieved, or

DOCSIS is not enabled

The Baseline Privacy Interface (BPI) status:

 YES — BPI has been successfully initialized for the cable

modem

 NO — BPI initialization is in progress, has failed, or was

not requested by the network

 N/A — The value is invalid or cannot be retrieved, or

DOCSIS is not enabled

The Days, Hours, Mins (minutes) and Seconds the DOCSIS

system has been operational. If the value is invalid or cannot be
retrieved, or DOCSIS is not enabled, each field displays zeros.

decimal format xxx.xxx.xxx.xxx. Each byte value is padded with

zeros when necessary. For example, 10.0.1.10 is displayed as

010.000.001.010. If the value is invalid or cannot be retrieved,
or DOCSIS is not enabled, 000.000.000.000 is displayed.

The Cable Modem and Set-Top MAC address in hexadecimal
format xx:xx:xx:xx:xx:xx. Each byte value xx ranges from 00 to

FF and is padded with zeros when necessary. For
example,0:0:2D:1:F1:D is displayed as 00:00:2D:01:F1:0D. If
the value is invalid or cannot be retrieved, or DOCSIS is not
enabled, 00:00:00:00:00:00 is displayed.

78

DCT3080 Installation Manual

Downstream Channel (carries data from the headend to the set-top)

Carrier
Lock

Frequency

LKC

Mode

Power
Level

SNR

YES — The cable modem is locked to a DOCSIS downstream
channel.

NO — The cable modem is not locked to a downstream
channel.

N/A — The value is invalid or cannot be retrieved, or DOCSIS
is not enabled.

The center frequency of the channel to which the DOCSIS
downstream channel receiver is tuned. It can be 54 to 860
MHz. If the value is invalid or cannot be retrieved, downstream
Carrier Lock is NO, or DOCSIS is not enabled, N/A is
displayed.

The last known carrier (LKC); the frequency of the last tuned
downstream channel used if the embedded cable modem
enters hunt mode. It can be 54 to 860 MHz. If the value is
invalid or cannot be retrieved, Carrier Lock is NO; if DOCSIS
is not enabled, N/A is displayed.

The DOCSIS downstream channel modulation: QAM 64 or
QAM 256. If the value is invalid or cannot be retrieved, Carrier
Lock is NO; if DOCSIS is not enabled, 000 is displayed.

The downstream channel power level in dBmV. If the value is
invalid or cannot be retrieved, Carrier Lock is NO; if DOCSIS
is not enabled, 000 is displayed.

The estimated downstream channel carrier signal-to-noise

ratio in the format xx.x dB. It is the value reported as SNR in

the MIB. If the value is invalid or cannot be retrieved, Carrier
Lock is NO; if DOCSIS is not enabled, 00.0 is displayed.

Upstream Channel (carries data from the set-top to the headend)

79

Frequency

Mode

Channel
ID

Power
Level

Symbol
Rate

Known MAC
Addresses

DCT3080 Installation Manual

The center frequency of the channel to which the DOCSIS
upstream channel receiver is tuned. It can be 5 to 42 MHz. If
the value is invalid or cannot be retrieved, Carrier Lock is NO;
if DOCSIS is not enabled, N/A is displayed.

The DOCSIS upstream channel modulation: QPSK, QAM 8,
QAM 16, QAM 32, QAM 64, or QAM 128. If the value is invalid
or cannot be retrieved, or DOCSIS is not enabled, N/A is
displayed.

The upstream channel identifier 0 to 255. If the value is invalid
or cannot be retrieved, or DOCSIS is not enabled, N/A is
displayed.

The upstream channel power level in dBmV. If the value is
invalid or cannot be retrieved, or DOCSIS is not enabled, 000
is displayed.

The upstream channel symbol rate in mega-symbols per
second. If the value is invalid or cannot be retrieved, or
DOCSIS is not enabled, 0.000 is displayed.

Displays up to 32 MAC addresses learned by the DCT3080
cable modem, including the Set-Top MAC and future MAC
addresses assigned by DSG, in hexadecimal format

xx:xx:xx:xx:xx:xx on two screens if necessary. If the value is

invalid or cannot be retrieved, or DOCSIS is not enabled, no
values are displayed.

80

DCT3080 Installation Manual

d15 Application Specific Information

This diagnostic displays information about application servers:

APPLICATION SPECIFIC INFORMATION

NO ADDITIONAL INFORMATION

SERVER1 NAME:
SRVR 1 IP ADDR:

SERVER2 NAME:
SRVR 2 IP ADDR:

SERVER3 NAME:
SRVR 3 IP ADDR:

SERVER4 NAME:
SRVR 4 IP ADDR:

SERVER5 NAME:
SRVR 5 IP ADDR:

The fields are:

Field Description

Server#
Name

Srvr # IP
Addr

The application server name of up to 14 alphanumeric
characters. It is blank if the value is invalid or no value can be
retrieved.

The application server IP address in dotted-decimal format

xxx.xxx.xxx.xxx; each xxx is from 0 to 255. It is blank if the value

is invalid or no value can be retrieved.

81

DCT3080 Installation Manual

d16 Interactive Status

This diagnostic describes the interactive information that is displayed
only when the Thin Client platform is running. The information on the
OSD and LED is updated at least once every 5 seconds while the
diagnostic is displayed. This is an example of a code module display with
status descriptions:

INTERACTIVE STATUS

IP ADDRESS:

UPM:

UPSTREAM ID:

DOWNSTREAM ID:

STATE:

MAC ABORT CNTR:

SOCKET PORT STATE:

0 UNUSED

1 UNUSED

2 UNUSED

3 UNUSED

4 UNUSED

0.0.0.0

00000021

0000

0000

UNCONFIG

0000

Figure3-10
Interactive status LED display

MUTE MUTE

The Interactive Status fields are:

PP

82

Field Description

IP Address

UPM

Upstream ID

Downstream
ID

The IP address in dotted-decimal format xxx.xxx.xxx.xxx

assigned by the NC 1500 to the DCT3080. 0.0.0.0 is displayed if
the IP address is not configured or unknown.

The upstream modem address value is the same as the terminal
ID assigned by the DAC 6000. It is a unique, system-generated
eight-digit integer between 1 and 16777215. 00000000 is
displayed when the UPM is not configured or unknown.

A four-digit decimal value from 0000 to 9999 assigned by the
DAC 6000 to the DCT3080. 0000 is displayed if the Upstream ID
is not configured or unknown.

A four-digit decimal value from 0000 to 9999 assigned by the
DAC 6000 to the DCT3080. 0000 is displayed if the Downstream
ID is not configured or unknown.

DCT3080 Installation Manual

83

DCT3080 Installation Manual

Field Description

State
LED OSD Description

The interactive status of the DCT3080:

U UNCONFIG The DCT3080 is not

configured for the interactive
system, and, platform should
run as pre-interactive.

C MAC_CONNECT The DCT3080 is waiting to

establish connection to MAC
PID Stream.

I dc INIT_WAIT_DC_OR_C The DCT3080 is in the

interactive initialization state
and waiting for the default
configuration or the contention
channel list messages.

I L WAIT_LM_ACK The DCT3080 is in the

interactive initialization state
and waiting for Link
Management Response ACK
for Local Address Message.

I

WAIT_SO_ACK The DCT3080 is in the

SO

I LA WAIT_LA_OR_SO The DCT3080 is in the

S I INIT_STOPPED The DCT3080 is in the

r dc RUN_WAIT_DC_OR_C The DCT3080 is in the

interactive initialization state
and waiting for a Sign On
acknowledgement.

interactive initialization state
and waiting for Logical
Address or Sign On with
verification Frequency
message.

interactive initialization state,
and the TransMode has
stopped.

interactive state and waiting for
the default configuration or the
contention channel list
messages.

84

Field Description

MAC Abort
Cntr

Socket Port
State

r RUNNING Interactive state is running,

S RUN_STOPPED The interactive run state has

00 INVALID The interactive state is

This counter increments every time the MAC layer reaches the
cell abort count limit. It is reset by the successful upstream
transmission of a cell – for example, when the DCT3080
receives an ACK. If the counter reaches the MAC abort count
limit, the DCT3080 assumes the MAC layer is unavailable due to
noise, congestion, or some other problem. The DCT3080 stops
transmitting data upstream, reports an error to the calling
function, and attempts to re-enter the network using the
initialization process. 0000 is displayed as default or if the MAC
Abort CNTR is not configured or unknown.

The socket mode and activity:

 UNUSED — The socket is not being used.
 OPENED — The socket is open.
 READY — The socket is ready to send or receive.
 RECEIVING — The socket is receiving data from the

application server.

 SENDING — The socket is sending data to the application

server.

 UNKNOWN — The socket state is invalid or unknown.

DCT3080 Installation Manual

sending idle messages, and
waiting for any prepare for poll
or MAC messages.

stopped and DCT3080 is
waiting for status or
transmission control message.

unknown or invalid.

85

DCT3080 Installation Manual

Troubleshooting

This section provides troubleshooting guidelines. If problems still occur
after performing the diagnostics, call the TRC for assistance as
described in Section 1, “Introduction.”

Problem Possible Solutions

The cable
terminal will
not power on

The remote
control does
not work

The cable terminal may have received a software update and
may not power on while the new software is being installed.
Try again in a few minutes.

Verify that the AC power cord is connected to the cable terminal
and an AC outlet. Unplug the cable terminal from the AC
outlet, plug it back in, and then press the

If the cable terminal is connected to a switched outlet on
another unit, verify that that unit is powered on.

Press the POWER button on the cable terminal front panel
instead of the remote control. The batteries in the remote
control may be depleted.

Verify that the remote control is in “Cable” mode.

Verify that there are no obstructions between the remote
control and the cable terminal. Aim the remote control directly
at the cable terminal front panel, not the TV or VCR.

The angle between the remote control and the cable terminal
may be too large. Stand in front of the cable terminal and not
too far to either side.

Press and release operation keys one at a time, firmly and
deliberately.

Try changing channels using the buttons on the cable terminal
front panel.

Check the batteries in the remote control. Install new batteries
if needed.

POWER button.

86

Problem Possible Solutions

There is no
audio when
viewing cable
channels

There is no
audio from the
center and/or
surround
speakers of a
home theater
receiver
connected to
the cable
terminal

Verify that the MUTE button on the cable terminal or the remote
control was not pressed. Press
restore sound.

If the cable terminal audio output is connected to the TV,
verify that the

MUTE button on the TV was not pressed.

If the cable terminal audio output is connected to a home
theater receiver, verify that the receiver is set to the
appropriate input source and the mute button on the receiver
was not pressed.

Verify that you used the correct audio cables for the ports.

Verify that the audio cables are firmly connected between the
cable terminal and the audio playback device (TV, receiver,
DVD player, etc.).

Not all Dolby Digital programs feature full 5.1 surround sound.
In some cases, the programs may only contain left and right
stereo audio.

Verify that the coaxial or optical SPDIF cable is firmly
connected to the cable terminal and the home theater receiver.

Verify that the home theater receiver is set to a surround
sound audio mode (Dolby Digital, Dolby Pro Logic
Dolby Pro Logic).

Verify that the receiver is properly configured to work with all
connected speakers.

DCT3080 Installation Manual

MUTE on the remote control to

®

II, or

87

Problem Possible Solutions

There is no
video on the
TV screen

No closed
captions
display

There are
black bars
above and
below the

There are
black bars on
all four sides
of the picture

The cable
terminal is
making a
humming
noise.

Verify that the TV is powered on and set to the appropriate
input source for the cable terminal.

Verify that the cable terminal is powered on and tuned to an
authorized cable channel.

Verify that all video cables between the cable terminal and
the TV are firmly connected.

Verify that the coaxial cable feed is firmly connected to the
cable terminal and the wall jack.

If the cable terminal is connected to a home theater unit, verify
that the home theater unit is powered on and set to the
appropriate input source.

Press the • key to cycle through the available output
formats until a picture displays on the TV.

Verify on the User Settings menu that closed captions are
enabled on the cable terminal.

Verify that closed captions are enabled on the TV.

Some SD programs are broadcast in the letterbox format with
black bars above and below the picture. Some widescreens
TVs offer a zoom feature that may be able to remove the
black bars. Note: If tuned to HD and the TV Type = 4:3
LETTERBOX, black bars will appear above and below the
picture. Try setting the TV Type to 4:3 PAN/SCAN to get a
full-screen picture with no black bars.

A broadcaster may include black bars on either side of a wide
screen broadcast. This is called a “hybrid” aspect ratio and
results in a black border surrounding the video on a 4:3 TV.
Because this is part of the broadcast, the cable terminal
cannot correct the video. Borders can be eliminated by
selecting the 4:3 PAN/SCAN option on the TV Type setting.

The DCT3080 includes an integrated hard drive and a fan for
cooling. During normal operation, the DCT3080 emits a low
humming noise, similar to a personal computer. The noise
varies in volume occasionally when the speed of the internal
fan adjusts to changes in the temperature around the
DCT3080. Please note the hard drive will stay on even when
the DCT3080 is turned off.

DCT3080 Installation Manual

88

Specifications

DCT3080 Installation Manual

Input frequency (video
and DOCSIS)

HRC/IRC frequency
assignments

Number of channels

Digital

Input digital average
level

Data carrier

Frequency
Bandwidth

Level
Mechanical security
Operating environment

range

Temperature

Humidity
AC VOLTAGE
Power dissipation
Size
Weight
Hard Disk

54 to 864 MHz

Downloadable

136 carriers

More than 1 channel per carrier, content dependent

64 QAM: –15 to +15 dBmV

256 QAM: –12 to +15 dBmV

QPSK-modulated carrier

Agile Receiver 70 – 130 MHz

1.5 MHz

–15 to +15 dBmV

Standard: security screws, unichassis construction

15° to 40°C (32° to 104°F)

5% to 95% (noncondensing)

95 to 125, 57 to 63 Hz

60 W nominal at 115 Vac

17.13 in. × 13.13 in. × 2.75 in.

12 pounds

DCT3080: 120 GB

AGC
ASTB

automatic gain control

Advanced Set-top Box

89

BPI
CRC
CSR
DAC 6000
DOCSIS
DRAM
DVI
DVR
ECM
EDID
EMM
FLASH
GPS
HDMI
HDTV
HRC
IPG
IPPV
IR Blaster
IRC
ITU
LKC
MIB
MPAA
MPEG-2

NVRAM
OSD

DCT3080 Installation Manual

Baseline Privacy Interface (DOCSIS)

cyclic redundancy check

Customer Service Representative

Digital Addressable Controller 6000

Data Over Cable Service Interface Specification

dynamic random access memory

Digital Video Interface for HDTV

Digital Video Recorder

embedded cable modem (in a cable terminal)

Extended Display Identification Data

entitlement management message(s)

A type of nonvolatile memory

global positioning system

High-Definition Multimedia Interface

high-definition television

harmonically related carriers

interactive program guide

Impulse Pay-Per-View

Infrared Blaster

incrementally related carriers

International Telecommunication Union

last known carrier (DOCSIS)

management information base (DOCSIS)

Motion Picture Advisory Association

Motion Picture Experts Group-2 compression standard for digital
audio and video encoding

non-volatile random-access memory

on-screen display

90

PCR
PID
PPV
QAM
QPSK
RSA
SD
SNR
S/PDIF
TCP/IP
TRC
TvPC
USB
VOD
Y Pb Pr

DCT3080 Installation Manual

program clock reference

packet identifier

Pay-Per-View

Quadrature Amplitude Modulation

Quadrature Phase Shift Keying

Return for Service Authorization

standard definition

signal-to-noise ratio

Sony-Philips Digital Interchange Format

Transmission Control Protocol/Internet Protocol

Technical Response Center

TV PassCard

Universal Serial Bus

video on demand

component video connectors for HDTV

91
