Motorola ColdFire MCF5281, ColdFire MCF5282 User Manual

Download

MCF5282UM/D

Rev. 2

1/2004

MCF5282 ColdFire

Microcontroller User’s Manual

Devices Supported:

MCF5281

HOW TO REACH US:

USA/EUROPE/LOCATIONS NOT LISTED:

Motorola Literature Distribution; P.O. Box 5405 Denver, Colorado 80217 1-800-521-6274 or 480-768-2130

JAPAN:

Motorola Japan Ltd.; SPS, Technical Information Center, 3-20-1, Minami-Azabu Minato-ku, Tokyo 106-8573 Japan 81-3-3440-3569

ASIA/PACIFIC:

Motorola Semiconductors H.K. Ltd.; Silicon Harbour Centre 2 Dai King Street, Tai Po Industrial Estate Tai Po, N.T., Hong Kong 852-26668334

HOME PAGE:

http://motorola.com/semiconductors

Information in this document is provided solely to enable system and software implementers to use

Motorola products. There are no express or implied copyright licenses granted hereunder to design

or fabricate any integrated circuits or integrated circuits based on the information in this document.

Motorola reserves the right to make changes without further notice to any products herein.

Motorola makes no warranty, representation or guarantee regarding the suitability of its products

for any particular purpose, nor does Motorola assume any liability arising out of the application or

use of any product or circuit, and specifically disclaims any and all liability, including without

limitation consequential or incidental damages. “Typical” parameters which may be provided in

Motorola data sheets and/or specifications can and do vary in different applications and actual

performance may vary over time. All operating parameters, including “Typicals” must be validated

for each customer application by customer’s technical experts. Motorola does not convey any

license under its patent rights nor the rights of others. Motorola products are not designed,

intended, or authorized for use as components in systems intended for surgical implant into the

body, or other applications intended to support or sustain life, or for any other application in which

the failure of the Motorola product could create a situation where personal injury or death may

occur. Should Buyer purchase or use Motorola products for any such unintended or unauthorized

application, Buyer shall indemnify and hold Motorola and its officers, employees, subsidiaries,

affiliates, and distributors harmless against all claims, costs, damages, and expenses, and

reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death

associated with such unintended or unauthorized use, even if such claim alleges that Motorola was

negligent regarding the design or manufacture of the part.

Motorola and the Stylized M Logo are registered in the U.S. Patent and Trademark Office. digital dna is a trademark of Motorola, Inc. All other product or service names are the property of their respective owners. Motorola, Inc. is an Equal Opportunity/Affirmative Action Employer.

Overview

ColdFire Core

Enhanced Multiply-Accumulate Unit (EMAC)

Cache

Static RAM (SRAM)

ColdFire Flash Module (CFM)

Power Management

System Control Module (SCM)

Clock Module

Interrupt Controller Modules

Edge Port Module (EPORT)

Chip Select Module

External Interface Module (EIM)

Signal Descriptions

Synchronous DRAM Controller Module

DMA Controller Module

Fast Ethernet Controller (FEC)

Watchdog Timer Module

Programmable Interrupt Timer (PIT) Modules

General Purpose Timer (GPT) Modules

DMA Timers

Queued Serial Peripheral Interface Module (QSPI)

UART Modules

C Module

FlexCAN Module

General Purpose I/O Module

Chip Configuration Module (CCM)

Queued Analog-to-Digital Converter (QADC)

Reset Controller Module

IEEE 1149.1 Test Access Port (JTAG)

Debug Support

Mechanical Data

Electrical Characteristics

Appendix A: List of Memory Maps

Index

IND

Overview

ColdFire Core

Enhanced Multiply-Accumulate Unit (EMAC)

Cache

Static RAM (SRAM)

ColdFire Flash Module (CFM)

Power Management

System Control Module (SCM)

Clock Module

Interrupt Controller Modules

Edge Port Module (EPORT)

Chip Select Module

External Interface Module (EIM)

Signal Descriptions

Synchronous DRAM Controller Module

DMA Controller Module

Fast Ethernet Controller (FEC)

Watchdog Timer Module

Programmable Interrupt Timer (PIT) Modules

General Purpose Timer (GPT) Modules

DMA Timers

Queued Serial Peripheral Interface Module (QSPI)

UART Modules

C Module

I FlexCAN Module

General Purpose I/O Module

Chip Configuration Module (CCM)

Queued Analog-to-Digital Converter (QADC)

Reset Controller Module

IND

Debug Support

IEEE 1149.1 Test Access Port (JTAG)

Mechanical Data

Electrical Characteristics

Appendix A: List of Memory Maps

Index

CONTENTS

Paragraph Number

Title

Page

Number

Chapter 1

Overview

1.1 MCF5282 Key Features...................................................................................... 1-1

1.1.1 Version 2 ColdFire Core................................................................................. 1-8

1.1.2 System Control Module................................................................................ 1-10

1.1.3 External Interface Module (EIM) ................................................................. 1-10

1.1.4 Chip Select.................................................................................................... 1-11

1.1.5 Power Management ...................................................................................... 1-11

1.1.6 General Input/Output Ports........................................................................... 1-11

1.1.7 Interrupt Controllers (INTC0/INTC1).......................................................... 1-11

1.1.8 SDRAM Controller....................................................................................... 1-11

1.1.9 Test Access Port............................................................................................ 1-12

1.1.10 UART Modules............................................................................................. 1-12

1.1.11 DMA Timers (DTIM0-DTIM3) ................................................................... 1-13

1.1.12 General-Purpose Timers (GPTA/GPTB)...................................................... 1-13

1.1.13 Periodic Interrupt Timers (PIT0-PIT3)......................................................... 1-13

1.1.14 Software Watchdog Timer............................................................................ 1-14

1.1.15 Phase Locked Loop (PLL)............................................................................ 1-14

1.1.16 DMA Controller............................................................................................ 1-14

1.1.17 Reset.............................................................................................................. 1-14

1.2 MCF5282-Specific Features ............................................................................. 1-15

1.2.1 Fast Ethernet Controller (FEC)..................................................................... 1-15

1.2.2 FlexCAN....................................................................................................... 1-15

1.2.3 I

1.2.4 Queued Serial Peripheral Interface (QSPI)................................................... 1-15

1.2.5 Queued Analog-to-Digital Converter (QADC) ............................................ 1-15

C Bus.......................................................................................................... 1-15

2.1 Processor Pipelines ............................................................................................. 2-1

2.2 Processor Register Description........................................................................... 2-2

2.2.1 User Programming Model .............................................................................. 2-2

2.2.2 EMAC Programming Model ......................................................................... 2-5

2.2.3 Supervisor Programming Model..................................................................... 2-5

MOTOROLA Contents v

Chapter 2

ColdFire Core

CONTENTS

Paragraph Number

2.3 Programming Model ........................................................................................... 2-8

2.4 Additions to the Instruction Set Architecture ..................................................... 2-9

2.5 Exception Processing Overview ....................................................................... 2-10

2.6 Exception Stack Frame Definition.................................................................... 2-12

2.7 Processor Exceptions ........................................................................................ 2-13

2.7.1 Access Error Exception ................................................................................ 2-13

2.7.2 Address Error Exception............................................................................... 2-14

2.7.3 Illegal Instruction Exception......................................................................... 2-14

2.7.4 Divide-By-Zero............................................................................................. 2-14

2.7.5 Privilege Violation........................................................................................ 2-14

2.7.6 Trace Exception ............................................................................................ 2-14

2.7.7 Unimplemented Line-A Opcode................................................................... 2-15

2.7.8 Unimplemented Line-F Opcode ................................................................... 2-15

2.7.9 Debug Interrupt............................................................................................. 2-15

2.7.10 RTE and Format Error Exception................................................................. 2-16

2.7.11 TRAP Instruction Exception......................................................................... 2-16

2.7.12 Interrupt Exception ....................................................................................... 2-16

2.7.13 Fault-on-Fault Halt ....................................................................................... 2-16

2.7.14 Reset Exception ............................................................................................ 2-16

2.8 Instruction Execution Timing ........................................................................... 2-21

2.8.1 Timing Assumptions..................................................................................... 2-21

2.8.2 MOVE Instruction Execution Times ............................................................ 2-22

2.9 Standard One Operand Instruction Execution Times ....................................... 2-24

2.10 Standard Two Operand Instruction Execution Times....................................... 2-24

2.11 Miscellaneous Instruction Execution Times..................................................... 2-26

2.12 EMAC Instruction Execution Times ................................................................ 2-27

2.13 Branch Instruction Execution Times ................................................................ 2-28

2.14 ColdFire Instruction Set Architecture Enhancements ...................................... 2-28

Title

Page

Number

Enhanced Multiply-Accumulate Unit (EMAC)

3.1 Multiply-Accumulate Unit.................................................................................. 3-1

3.2 Introduction to the MAC..................................................................................... 3-2

3.3 General Operation............................................................................................... 3-3

3.4 Memory Map/Register Set.................................................................................. 3-6

3.4.1 MAC Status Register (MACSR) .................................................................... 3-6

3.4.2 Mask Register (MASK)................................................................................ 3-11

3.5 EMAC Instruction Set Summary...................................................................... 3-12

3.5.1 EMAC Instruction Execution Times ............................................................ 3-12

3.5.2 Data Representation...................................................................................... 3-13

3.5.3 MAC Opcodes .............................................................................................. 3-14

vi MCF5282 User’s Manual MOTOROLA

Chapter 3

CONTENTS

Paragraph Number

Title

Page

Number

Chapter 4

Cache

4.1 Cache Features.................................................................................................... 4-1

4.2 Cache Physical Organization .............................................................................. 4-1

4.3 Cache Operation ................................................................................................. 4-3

4.3.1 Interaction with Other Modules...................................................................... 4-3

4.3.2 Memory Reference Attributes ........................................................................ 4-4

4.3.3 Cache Coherency and Invalidation................................................................. 4-4

4.3.4 Reset................................................................................................................ 4-5

4.3.5 Cache Miss Fetch Algorithm/Line Fills ......................................................... 4-5

4.4 Cache Programming Model ................................................................................ 4-7

4.4.1 Cache Registers Memory Map ....................................................................... 4-7

4.4.2 Cache Registers............................................................................................... 4-7

Chapter 5

Static RAM (SRAM)

5.1 SRAM Features................................................................................................... 5-1

5.2 SRAM Operation ................................................................................................ 5-1

5.3 SRAM Programming Model............................................................................... 5-1

5.3.1 SRAM Base Address Register (RAMBAR)................................................... 5-2

5.3.2 SRAM Initialization........................................................................................ 5-3

5.3.3 SRAM Initialization Code .............................................................................. 5-4

5.3.4 Power Management ........................................................................................ 5-4

6.1 Features............................................................................................................... 6-1

6.2 Block Diagram.................................................................................................... 6-2

6.3 Memory Map ...................................................................................................... 6-4

6.3.1 CFM Configuration Field ............................................................................... 6-5

6.3.2 Flash Base Address Register (FLASHBAR).................................................. 6-5

6.3.3 CFM Registers ................................................................................................ 6-8

6.3.4 Register Descriptions...................................................................................... 6-9

6.4 CFM Operation ................................................................................................. 6-17

6.4.1 Read Operations............................................................................................ 6-17

6.4.2 Write Operations........................................................................................... 6-17

6.4.3 Program and Erase Operations ..................................................................... 6-17

6.4.4 Stop Mode..................................................................................................... 6-22

6.4.5 Master Mode................................................................................................. 6-23

MOTOROLA Contents vii

Chapter 6

ColdFire Flash Module (CFM)

CONTENTS

Paragraph Number

6.5 Flash Security Operation .................................................................................. 6-23

6.5.1 Back Door Access......................................................................................... 6-24

6.5.2 Erase Verify Check....................................................................................... 6-24

6.6 Reset.................................................................................................................. 6-24

6.7 Interrupts........................................................................................................... 6-25

Title

Page

Number

Chapter 7

Power Management

7.1 Features............................................................................................................... 7-1

7.2 Memory Map and Registers................................................................................ 7-1

7.2.1 Programming Model....................................................................................... 7-1

7.2.2 Memory Map .................................................................................................. 7-2

7.2.3 Register Descriptions...................................................................................... 7-2

7.3 Functional Description........................................................................................ 7-5

7.3.1 Low-Power Modes.......................................................................................... 7-5

7.3.2 Peripheral Behavior in Low-Power Modes .................................................... 7-7

7.3.3 Summary of Peripheral State During Low-Power Modes............................ 7-16

Chapter 8

System Control Module (SCM)

8.1 Overview............................................................................................................. 8-1

8.2 Features............................................................................................................... 8-1

8.3 Memory Map and Register Definition................................................................ 8-2

8.4 Register Descriptions.......................................................................................... 8-3

8.4.1 Internal Peripheral System Base Address Register (IPSBAR)....................... 8-3

8.4.2 Memory Base Address Register (RAMBAR) ................................................ 8-4

8.4.3 Core Reset Status Register (CRSR)................................................................ 8-6

8.4.4 Core Watchdog Control Register (CWCR) .................................................... 8-6

8.4.5 Core Watchdog Service Register (CWSR)..................................................... 8-9

8.5 Internal Bus Arbitration ...................................................................................... 8-9

8.5.1 Overview....................................................................................................... 8-11

8.5.2 Arbitration Algorithms ................................................................................. 8-11

8.5.3 Bus Master Park Register (MPARK)............................................................ 8-12

8.6 System Access Control Unit (SACU)............................................................... 8-14

8.6.1 Overview....................................................................................................... 8-14

8.6.2 Features......................................................................................................... 8-14

8.6.3 Memory Map/Register Definition ................................................................ 8-15

viii MCF5282 User’s Manual MOTOROLA

CONTENTS

Paragraph Number

Title

Page

Number

Chapter 9

Clock Module

9.1 Features............................................................................................................... 9-1

9.2 Modes of Operation ............................................................................................ 9-1

9.2.1 Normal PLL Mode.......................................................................................... 9-1

9.2.2 1:1 PLL Mode................................................................................................. 9-2

9.2.3 External Clock Mode...................................................................................... 9-2

9.3 Low-power Mode Operation .............................................................................. 9-2

9.4 Block Diagram.................................................................................................... 9-3

9.5 Signal Descriptions ............................................................................................. 9-4

9.5.1 EXTAL ........................................................................................................... 9-4

9.5.2 XTAL.............................................................................................................. 9-5

9.5.3 CLKOUT ........................................................................................................ 9-5

9.5.4 CLKMOD[1:0] ............................................................................................... 9-5

9.5.5 RSTOUT......................................................................................................... 9-5

9.6 Memory Map and Registers................................................................................ 9-5

9.6.1 Module Memory Map..................................................................................... 9-5

9.6.2 Register Descriptions...................................................................................... 9-6

9.7 Functional Description...................................................................................... 9-10

9.7.1 System Clock Modes .................................................................................... 9-10

9.7.2 Clock Operation During Reset...................................................................... 9-11

9.7.3 System Clock Generation ............................................................................. 9-11

9.7.4 PLL Operation .............................................................................................. 9-12

Chapter 10

Interrupt Controller Modules

10.1 68K/ColdFire Interrupt Architecture Overview ............................................... 10-1

10.1.1 Interrupt Controller Theory of Operation ..................................................... 10-3

10.2 Memory Map .................................................................................................... 10-5

10.3 Register Descriptions........................................................................................ 10-6

10.3.1 Interrupt Pending Registers (IPRHn, IPRLn)............................................... 10-6

10.3.2 Interrupt Mask Register (IMRHn, IMRLn) .................................................. 10-8

10.3.3 Interrupt Force Registers (INTFRCHn, INTFRCLn)................................... 10-9

10.3.4 Interrupt Request Level Register (IRLRn) ................................................. 10-10

10.3.5 Interrupt Acknowledge Level and Priority Register (IACKLPRn)............ 10-11

10.3.6 Interrupt Control Register (ICRnx, (x = 1, 2,..., 63)).................................. 10-11

10.3.7 Software and Level n IACK Registers (SWIACKR, L1IACK–L7IACK). 10-15

10.4 Prioritization Between Interrupt Controllers .................................................. 10-16

10.5 Low-Power Wakeup Operation ...................................................................... 10-17

MOTOROLA Contents ix

CONTENTS

Paragraph Number

Title

Page

Number

Chapter 11

Edge Port Module (EPORT)

11.1 Introduction....................................................................................................... 11-1

11.2 Low-Power Mode Operation ............................................................................ 11-1

11.3 Interrupt/General-Purpose I/O Pin Descriptions............................................... 11-2

11.4 Memory Map and Registers.............................................................................. 11-3

11.4.1 Memory Map ................................................................................................ 11-3

11.4.2 Registers........................................................................................................ 11-3

Chapter 12

Chip Select Module

12.1 Overview........................................................................................................... 12-1

12.2 Chip Select Module Signals.............................................................................. 12-1

12.3 Chip Select Operation....................................................................................... 12-3

12.3.1 General Chip Select Operation ..................................................................... 12-3

12.4 Chip Select Registers ........................................................................................ 12-5

12.4.1 Chip Select Module Registers....................................................................... 12-6

Chapter 13

External Interface Module (EIM)

13.1 Features............................................................................................................. 13-1

13.2 Bus and Control Signals ................................................................................... 13-1

13.3 Bus Characteristics ........................................................................................... 13-2

13.4 Data Transfer Operation ................................................................................... 13-2

13.4.1 Bus Cycle Execution..................................................................................... 13-3

13.4.2 Data Transfer Cycle States ........................................................................... 13-5

13.4.3 Read Cycle.................................................................................................... 13-6

13.4.4 Write Cycle................................................................................................... 13-8

13.4.5 Fast Termination Cycles ............................................................................... 13-9

13.4.6 Back-to-Back Bus Cycles ........................................................................... 13-10

13.4.7 Burst Cycles................................................................................................ 13-10

13.5 Misaligned Operands ...................................................................................... 13-14

Chapter 14

Signal Descriptions

14.1 Overview........................................................................................................... 14-1

14.1.1 Single-Chip Mode....................................................................................... 14-17

14.1.2 External Boot Mode.................................................................................... 14-17

x MCF5282 User’s Manual MOTOROLA

CONTENTS

Paragraph Number

14.2 MCF5282 External Signals............................................................................. 14-18

14.2.1 External Interface Module (EIM) Signals .................................................. 14-18

14.2.2 SDRAM Controller Signals........................................................................ 14-21

14.2.3 Clock and Reset Signals ............................................................................. 14-22

14.2.4 Chip Configuration Signals ........................................................................ 14-22

14.2.5 External Interrupt Signals ........................................................................... 14-23

14.2.6 Ethernet Module Signals............................................................................. 14-23

14.2.7 Queued Serial Peripheral Interface (QSPI) Signals.................................... 14-25

14.2.8 FlexCAN Signals ........................................................................................ 14-26

14.2.9 I2C Signals .................................................................................................. 14-26

14.2.10 UART Module Signals ............................................................................... 14-26

14.2.11 General Purpose Timer Signals .................................................................. 14-27

14.2.12 DMA Timer Signals.................................................................................... 14-28

14.2.13 Analog-to-Digital Converter Signals.......................................................... 14-29

14.2.14 Debug Support Signals ............................................................................... 14-30

14.2.15 Test Signals................................................................................................. 14-32

14.2.16 Power and Reference Signals ..................................................................... 14-33

Title

Page

Number

Chapter 15

Synchronous DRAM Controller Module

15.1 Overview........................................................................................................... 15-1

15.1.1 Definitions .................................................................................................... 15-1

15.1.2 Block Diagram and Major Components ....................................................... 15-2

15.2 SDRAM Controller Operation.......................................................................... 15-3

15.2.1 DRAM Controller Signals ............................................................................ 15-4

15.2.2 Memory Map for SDRAMC Registers......................................................... 15-4

15.2.3 General Synchronous Operation Guidelines................................................. 15-9

15.2.4 Initialization Sequence................................................................................ 15-17

15.3 SDRAM Example ........................................................................................... 15-19

15.3.1 SDRAM Interface Configuration................................................................ 15-20

15.3.2 DCR Initialization....................................................................................... 15-20

15.3.3 DACR Initialization.................................................................................... 15-21

15.3.4 DMR Initialization...................................................................................... 15-22

15.3.5 Mode Register Initialization ....................................................................... 15-23

15.3.6 Initialization Code....................................................................................... 15-24

Chapter 16

DMA Controller Module

16.1 Overview........................................................................................................... 16-1

16.1.1 DMA Module Features ................................................................................. 16-2

MOTOROLA Contents xi

CONTENTS

Paragraph Number

16.2 DMA Request Control (DMAREQC) .............................................................. 16-3

16.3 DMA Transfer Overview.................................................................................. 16-4

16.4 DMA Controller Module Programming Model................................................ 16-5

16.4.1 Source Address Registers (SAR0–SAR3) .................................................... 16-6

16.4.2 Destination Address Registers (DAR0–DAR3) ........................................... 16-6

16.4.3 Byte Count Registers (BCR0–BCR3) .......................................................... 16-7

16.4.4 DMA Control Registers (DCR0–DCR3)...................................................... 16-8

16.4.5 DMA Status Registers (DSR0–DSR3) ....................................................... 16-10

16.5 DMA Controller Module Functional Description .......................................... 16-11

16.5.1 Transfer Requests (Cycle-Steal and Continuous Modes)........................... 16-11

16.5.2 Data Transfer Modes .................................................................................. 16-12

16.5.3 Channel Initialization and Startup .............................................................. 16-13

16.5.4 Data Transfer .............................................................................................. 16-14

16.5.5 Termination................................................................................................. 16-15

Title

Page

Number

Chapter 17

Fast Ethernet Controller (FEC)

17.1 Overview........................................................................................................... 17-1

17.1.1 Features......................................................................................................... 17-1

17.2 Modes of Operation .......................................................................................... 17-2

17.2.1 Full and Half Duplex Operation ................................................................... 17-2

17.2.2 Interface Options........................................................................................... 17-2

17.2.3 Address Recognition Options ....................................................................... 17-3

17.2.4 Internal Loopback......................................................................................... 17-3

17.3 FEC Top-Level Functional Diagram ................................................................ 17-4

17.4 Functional Description...................................................................................... 17-5

17.4.1 Initialization Sequence.................................................................................. 17-6

17.4.2 User Initialization (Prior to Asserting ECR[ETHER_EN]).......................... 17-6

17.4.3 Microcontroller Initialization........................................................................ 17-7

17.4.4 User Initialization (After Asserting ECR[ETHER_EN]) ............................. 17-7

17.4.5 Network Interface Options............................................................................ 17-8

17.4.6 FEC Frame Transmission ............................................................................. 17-9

17.4.7 FEC Frame Reception................................................................................. 17-10

17.4.8 Ethernet Address Recognition .................................................................... 17-11

17.4.9 Hash Algorithm........................................................................................... 17-13

17.4.10 Full Duplex Flow Control........................................................................... 17-16

17.4.11 Inter-Packet Gap (IPG) Time...................................................................... 17-17

17.4.12 Collision Handling...................................................................................... 17-17

17.4.13 Internal and External Loopback.................................................................. 17-17

17.4.14 Ethernet Error-Handling Procedure............................................................ 17-18

17.5 Programming Model ....................................................................................... 17-20

xii MCF5282 User’s Manual MOTOROLA

CONTENTS

Paragraph Number

17.5.1 Top Level Module Memory Map ............................................................... 17-20

17.5.2 Detailed Memory Map (Control/Status Registers) ..................................... 17-20

17.5.3 MIB Block Counters Memory Map............................................................ 17-21

17.5.4 Registers...................................................................................................... 17-23

17.6 Buffer Descriptors........................................................................................... 17-45

17.6.1 Driver/DMA Operation with Buffer Descriptors........................................ 17-45

17.6.2 Ethernet Receive Buffer Descriptor (RxBD).............................................. 17-47

17.6.3 Ethernet Transmit Buffer Descriptor (TxBD) ............................................ 17-49

Title

Page

Number

Chapter 18

Watchdog Timer Module

18.1 Introduction....................................................................................................... 18-1

18.2 Low-Power Mode Operation ............................................................................ 18-1

18.3 Block Diagram.................................................................................................. 18-2

18.4 Signals............................................................................................................... 18-2

18.5 Memory Map and Registers.............................................................................. 18-2

18.5.1 Memory Map ................................................................................................ 18-2

18.5.2 Registers........................................................................................................ 18-3

Chapter 19

Programmable Interrupt Timer Modules (PIT0–PIT3)

19.1 Overview........................................................................................................... 19-1

19.2 Block Diagram.................................................................................................. 19-1

19.3 Low-Power Mode Operation ............................................................................ 19-2

19.4 Signals............................................................................................................... 19-2

19.5 Memory Map and Registers.............................................................................. 19-3

19.5.1 Memory Map ................................................................................................ 19-3

19.5.2 Registers........................................................................................................ 19-3

19.6 Functional Description...................................................................................... 19-6

19.6.1 Set-and-Forget Timer Operation................................................................... 19-6

19.6.2 Free-Running Timer Operation .................................................................... 19-7

19.6.3 Timeout Specifications ................................................................................. 19-7

19.7 Interrupt Operation ........................................................................................... 19-8

Chapter 20

General Purpose Timer Modules

(GPTA and GPTB)

20.1 Features............................................................................................................. 20-1

20.2 Block Diagram.................................................................................................. 20-2

MOTOROLA Contents xiii

CONTENTS

Paragraph Number

Title

Page

Number

20.3 Low-Power Mode Operation ............................................................................ 20-3

20.4 Signal Description............................................................................................. 20-3

20.4.1 GPTn[2:0] ..................................................................................................... 20-3

20.4.2 GPTn3........................................................................................................... 20-4

20.4.3 SYNCn.......................................................................................................... 20-4

20.5 Memory Map and Registers.............................................................................. 20-4

20.5.1 GPT Input Capture/Output Compare Select Register (GPTIOS) ................. 20-5

20.5.2 GPT Compare Force Register (GPCFORC)................................................. 20-6

20.5.3 GPT Output Compare 3 Mask Register (GPTOC3M).................................. 20-6

20.5.4 GPT Output Compare 3 Data Register (GPTOC3D).................................... 20-7

20.5.5 GPT Counter Register (GPTCNT) ............................................................... 20-7

20.5.6 GPT System Control Register 1 (GPTSCR1)............................................... 20-8

20.5.7 GPT Toggle-On-Overflow Register (GPTTOV).......................................... 20-9

20.5.8 GPT Control Register 1 (GPTCTL1)............................................................ 20-9

20.5.9 GPT Control Register 2 (GPTCTL2).......................................................... 20-10

20.5.10 GPT Interrupt Enable Register (GPTIE) .................................................... 20-10

20.5.11 GPT System Control Register 2 (GPTSCR2)............................................. 20-11

20.5.12 GPT Flag Register 1 (GPTFLG1)............................................................... 20-12

20.5.13 GPT Flag Register 2 (GPTFLG2)............................................................... 20-12

20.5.14 GPT Channel Registers (GPTCn)............................................................... 20-13

20.5.15 Pulse Accumulator Control Register (GPTPACTL) .................................. 20-13

20.5.16 Pulse Accumulator Flag Register (GPTPAFLG)........................................ 20-14

20.5.17 Pulse Accumulator Counter Register (GPTPACNT) ................................. 20-15

20.5.18 GPT Port Data Register (GPTPORT)......................................................... 20-16

20.5.19 GPT Port Data Direction Register (GPTDDR)........................................... 20-16

20.6 Functional Description.................................................................................... 20-17

20.6.1 Prescaler...................................................................................................... 20-17

20.6.2 Input Capture .............................................................................................. 20-17

20.6.3 Output Compare.......................................................................................... 20-17

20.6.4 Pulse Accumulator...................................................................................... 20-18

20.6.5 Event Counter Mode................................................................................... 20-18

20.6.6 Gated Time Accumulation Mode ............................................................... 20-19

20.6.7 General-Purpose I/O Ports.......................................................................... 20-19

20.7 Reset................................................................................................................ 20-21

20.8 Interrupts......................................................................................................... 20-21

20.8.1 GPT Channel Interrupts (CnF) ................................................................... 20-22

20.8.2 Pulse Accumulator Overflow (PAOVF)..................................................... 20-22

20.8.3 Pulse Accumulator Input (PAIF) ................................................................ 20-22

20.8.4 Timer Overflow (TOF) ............................................................................... 20-22

xiv MCF5282 User’s Manual MOTOROLA

CONTENTS

Paragraph Number

Title

Page

Number

Chapter 21

DMA Timers (DTIM0–DTIM3)

21.1 Overview........................................................................................................... 21-1

21.1.1 Key Features ................................................................................................. 21-2

21.2 DMA Timer Programming Model.................................................................... 21-2

21.2.1 Prescaler........................................................................................................ 21-2

21.2.2 Capture Mode ............................................................................................... 21-3

21.2.3 Reference Compare....................................................................................... 21-3

21.2.4 Output Mode................................................................................................. 21-3

21.2.5 Memory Map ................................................................................................ 21-3

21.2.6 DMA Timer Mode Registers (DTMRn)....................................................... 21-4

21.2.7 DMA Timer Extended Mode Registers (DTXMRn).................................... 21-5

21.2.8 DMA Timer Event Registers (DTERn)........................................................ 21-6

21.2.9 DMA Timer Reference Registers (DTRRn)................................................. 21-7

21.2.10 DMA Timer Capture Registers (DTCRn) .................................................... 21-7

21.2.11 DMA Timer Counters (DTCNn) .................................................................. 21-8

21.3 Using the DMA Timer Modules....................................................................... 21-8

21.3.1 Code Example............................................................................................... 21-9

21.3.2 Calculating Time-Out Values ..................................................................... 21-10

Chapter 22

Queued Serial Peripheral Interface

(QSPI) Module

22.1 Overview........................................................................................................... 22-1

22.2 Features............................................................................................................. 22-1

22.3 Module Description .......................................................................................... 22-1

22.3.1 Interface and Signals..................................................................................... 22-2

22.3.2 Internal Bus Interface.................................................................................... 22-3

22.4 Operation .......................................................................................................... 22-3

22.4.1 QSPI RAM.................................................................................................... 22-4

22.4.2 Baud Rate Selection...................................................................................... 22-6

22.4.3 Transfer Delays............................................................................................. 22-7

22.4.4 Transfer Length............................................................................................. 22-8

22.4.5 Data Transfer ................................................................................................ 22-8

22.5 Programming Model ......................................................................................... 22-9

22.5.1 QSPI Mode Register (QMR) ...................................................................... 22-10

22.5.2 QSPI Delay Register (QDLYR) ................................................................. 22-11

22.5.3 QSPI Wrap Register (QWR)....................................................................... 22-12

22.5.4 QSPI Interrupt Register (QIR).................................................................... 22-13

22.5.5 QSPI Address Register (QAR) ................................................................... 22-14

MOTOROLA Contents xv

CONTENTS

Paragraph Number

22.5.6 QSPI Data Register (QDR)......................................................................... 22-14

22.5.7 Command RAM Registers (QCR0–QCR15).............................................. 22-15

22.5.8 Programming Example ............................................................................... 22-16

Title

Page

Number

Chapter 23

UART Modules

23.1 Overview........................................................................................................... 23-1

23.2 Serial Module Overview................................................................................... 23-2

23.3 Register Descriptions........................................................................................ 23-3

23.3.1 UART Mode Registers 1 (UMR1n).............................................................. 23-4

23.3.2 UART Mode Register 2 (UMR2n) ............................................................... 23-6

23.3.3 UART Status Registers (USRn) ................................................................... 23-7

23.3.4 UART Clock Select Registers (UCSRn) ...................................................... 23-8

23.3.5 UART Command Registers (UCRn) ............................................................ 23-9

23.3.6 UART Receive Buffers (URBn)................................................................. 23-11

23.3.7 UART Transmit Buffers (UTBn) ............................................................... 23-11

23.3.8 UART Input Port Change Registers (UIPCRn).......................................... 23-12

23.3.9 UART Auxiliary Control Register (UACRn)............................................. 23-13

23.3.10 UART Interrupt Status/Mask Registers (UISRn/UIMRn).......................... 23-13

23.3.11 UART Baud Rate Generator Registers (UBG1n/UBG2n) ......................... 23-14

23.3.12 UART Input Port Register (UIPn).............................................................. 23-15

23.3.13 UART Output Port Command Registers (UOP1n/UOP0n) ....................... 23-15

23.4 UART Module Signal Definitions.................................................................. 23-17

23.5 Operation ........................................................................................................ 23-18

23.5.1 Transmitter/Receiver Clock Source............................................................ 23-18

23.5.2 Transmitter and Receiver Operating Modes............................................... 23-20

23.5.3 Looping Modes........................................................................................... 23-25

23.5.4 Multidrop Mode.......................................................................................... 23-26

23.5.5 Bus Operation ............................................................................................. 23-28

23.5.6 Programming .............................................................................................. 23-28

24.1 Overview........................................................................................................... 24-1

24.2 Interface Features.............................................................................................. 24-1

24.3 I2C System Configuration................................................................................. 24-3

24.4 I

24.4.1 Arbitration Procedure ................................................................................... 24-4

24.4.2 Clock Synchronization.................................................................................. 24-5

24.4.3 Handshaking ................................................................................................. 24-5

xvi MCF5282 User’s Manual MOTOROLA

C Protocol ...................................................................................................... 24-3

Chapter 24

C Interface

CONTENTS

Paragraph Number

Title

Page

Number

24.4.4 Clock Stretching ........................................................................................... 24-5

24.5 Programming Model ......................................................................................... 24-6

24.5.1 I2C Address Register (I2ADR)..................................................................... 24-6

24.5.2 I2C Frequency Divider Register (I2FDR)..................................................... 24-7

24.5.3 I

24.5.4 I

C Control Register (I2CR)......................................................................... 24-8

C Status Register (I2SR)............................................................................ 24-9

24.5.5 I2C Data I/O Register (I2DR) ..................................................................... 24-10

24.6 I

C Programming Examples ........................................................................... 24-10

24.6.1 Initialization Sequence................................................................................ 24-10

24.6.2 Generation of START................................................................................. 24-11

24.6.3 Post-Transfer Software Response............................................................... 24-11

24.6.4 Generation of STOP.................................................................................... 24-12

24.6.5 Generation of Repeated START................................................................. 24-13

24.6.6 Slave Mode ................................................................................................. 24-13

24.6.7 Arbitration Lost........................................................................................... 24-14

Chapter 25

FlexCAN

25.1 Features............................................................................................................. 25-1

25.1.1 FlexCAN Memory Map................................................................................ 25-3

25.1.2 External Signals ............................................................................................ 25-3

25.2 The CAN System .............................................................................................. 25-4

25.3 Message Buffers ............................................................................................... 25-4

25.3.1 Message Buffer Structure ............................................................................. 25-4

25.3.2 Message Buffer Memory Map...................................................................... 25-7

25.4 Functional Overview......................................................................................... 25-8

25.4.1 Transmit Process........................................................................................... 25-9

25.4.2 Receive Process ............................................................................................ 25-9

25.4.3 Message Buffer Handling ........................................................................... 25-10

25.4.4 Remote Frames ........................................................................................... 25-12

25.4.5 Overload Frames......................................................................................... 25-13

25.4.6 Time Stamp................................................................................................. 25-13

25.4.7 Listen-Only Mode....................................................................................... 25-13

25.4.8 Bit Timing................................................................................................... 25-14

25.4.9 FlexCAN Error Counters............................................................................ 25-15

25.4.10 FlexCAN Initialization Sequence ............................................................... 25-16

25.4.11 Special Operating Modes............................................................................ 25-17

25.4.12 Interrupts..................................................................................................... 25-19

25.5 Programmer’s Model ...................................................................................... 25-20

25.5.1 CAN Module Configuration Register (CANMCR).................................... 25-20

25.5.2 FlexCAN Control Register 0 (CANCTRL0).............................................. 25-22

MOTOROLA Contents xvii

CONTENTS

Paragraph Number

25.5.3 FlexCAN Control Register 1 (CANCTRL1).............................................. 25-23

25.5.4 Prescaler Divide Register (PRESDIV) ....................................................... 25-24

25.5.5 FlexCAN Control Register 2 (CANCTRL2).............................................. 25-25

25.5.6 Free Running Timer (TIMER).................................................................... 25-26

25.5.7 Rx Mask Registers...................................................................................... 25-26

25.5.8 FlexCAN Error and Status Register (ESTAT) ........................................... 25-28

25.5.9 Interrupt Mask Register (IMASK).............................................................. 25-30

25.5.10 Interrupt Flag Register (IFLAG)................................................................. 25-31

25.5.11 FlexCAN Receive Error Counter (RXECTR) ............................................ 25-32

25.5.12 FlexCAN Transmit Error Counter (TXECTR)........................................... 25-32

Title

Page

Number

Chapter 26

General Purpose I/O Module

26.1 Introduction....................................................................................................... 26-1

26.1.1 Overview....................................................................................................... 26-3

26.1.2 Features......................................................................................................... 26-3

26.1.3 Modes of Operation ...................................................................................... 26-3

26.2 External Signal Description .............................................................................. 26-4

26.3 Memory Map/Register Definition .................................................................... 26-6

26.3.1 Register Overview ........................................................................................ 26-6

26.3.2 Register Descriptions.................................................................................... 26-8

26.4 Functional Description.................................................................................... 26-25

26.4.1 Overview..................................................................................................... 26-25

26.4.2 Port Digital I/O Timing .............................................................................. 26-25

26.5 Initialization/Application Information............................................................ 26-26

Queued Analog-to-Digital Converter (QADC)

27.1 Features............................................................................................................. 27-1

27.2 Block Diagram.................................................................................................. 27-2

27.3 Modes of Operation .......................................................................................... 27-3

27.3.1 Debug Mode ................................................................................................. 27-3

27.3.2 Stop Mode..................................................................................................... 27-3

27.4 Signals............................................................................................................... 27-4

27.4.1 Port QA Signal Functions............................................................................. 27-4

27.4.2 Port QB Signal Functions ............................................................................. 27-5

27.4.3 External Trigger Input Signals...................................................................... 27-6

27.4.4 Multiplexed Address Output Signals............................................................ 27-6

27.4.5 Multiplexed Analog Input Signals................................................................ 27-6

27.4.6 Voltage Reference Signals............................................................................ 27-7

xviii MCF5282 User’s Manual MOTOROLA

Chapter 27

CONTENTS

Paragraph Number

Title

Page

Number

27.4.7 Dedicated Analog Supply Signals ................................................................ 27-7

27.4.8 Dedicated Digital I/O Port Supply Signal..................................................... 27-7

27.5 Memory Map .................................................................................................... 27-7

27.6 Register Descriptions........................................................................................ 27-8

27.6.1 QADC Module Configuration Register (QADCMCR)................................ 27-8

27.6.2 QADC Test Register (QADCTEST) ............................................................ 27-9

27.6.3 Port Data Registers (PORTQA and PORTQB) ............................................ 27-9

27.6.4 Port QA and QB Data Direction Register (DDRQA and DDRQB)........... 27-10

27.6.5 Control Registers ........................................................................................ 27-11

27.6.6 Status Registers........................................................................................... 27-19

27.6.7 Conversion Command Word Table (CCW) ............................................... 27-26

27.6.8 Result Registers .......................................................................................... 27-29

27.7 Functional Description.................................................................................... 27-31

27.7.1 Result Coherency........................................................................................ 27-31

27.7.2 External Multiplexing ................................................................................. 27-31

27.7.3 Analog Subsystem ...................................................................................... 27-34

27.8 Digital Control Subsystem.............................................................................. 27-37

27.8.1 Queue Priority Timing Examples ............................................................... 27-38

27.8.2 Boundary Conditions .................................................................................. 27-49

27.8.3 Scan Modes................................................................................................. 27-50

27.8.4 Disabled Mode............................................................................................ 27-50

27.8.5 Reserved Mode ........................................................................................... 27-50

27.8.6 Single-Scan Modes ..................................................................................... 27-50

27.8.7 Continuous-Scan Modes............................................................................. 27-54

27.8.8 QADC Clock (QCLK) Generation ............................................................. 27-57

27.8.9 Periodic/Interval Timer............................................................................... 27-58

27.8.10 Conversion Command Word Table ............................................................ 27-59

27.8.11 Result Word Table...................................................................................... 27-62

27.9 Signal Connection Considerations.................................................................. 27-62

27.9.1 Analog Reference Signals........................................................................... 27-63

27.9.2 Analog Power Signals................................................................................. 27-63

27.9.3 Conversion Timing Schemes...................................................................... 27-64

27.9.4 Analog Supply Filtering and Grounding .................................................... 27-67

27.9.5 Accommodating Positive/Negative Stress Conditions ............................... 27-69

27.9.6 Analog Input Considerations ...................................................................... 27-71

27.9.7 Analog Input Pins ....................................................................................... 27-73

27.10 Interrupts......................................................................................................... 27-75

27.10.1 Interrupt Operation ..................................................................................... 27-75

27.10.2 Interrupt Sources......................................................................................... 27-76

MOTOROLA Contents xix

CONTENTS

Paragraph Number

Title

Page

Number

Chapter 28

Reset Controller Module

28.1 Features............................................................................................................. 28-1

28.2 Block Diagram.................................................................................................. 28-2

28.3 Signals............................................................................................................... 28-2

28.3.1 RSTI............................................................................................................. 28-2

28.3.2 RSTO

28.4 Memory Map and Registers.............................................................................. 28-3

28.4.1 Reset Control Register (RCR) ...................................................................... 28-3

28.4.2 Reset Status Register (RSR) ......................................................................... 28-4

28.5 Functional Description...................................................................................... 28-6

28.5.1 Reset Sources................................................................................................ 28-6

28.5.2 Reset Control Flow ....................................................................................... 28-8

28.5.3 Concurrent Resets....................................................................................... 28-10

........................................................................................................... 28-2

Chapter 29

Debug Support

29.1 Overview........................................................................................................... 29-1

29.2 Signal Description............................................................................................. 29-2

29.3 Real-Time Trace Support.................................................................................. 29-3

29.3.1 Begin Execution of Taken Branch (PST = 0x5)........................................... 29-4

29.4 Programming Model ......................................................................................... 29-5

29.4.1 Revision A Shared Debug Resources ........................................................... 29-7

29.4.2 Address Attribute Trigger Register (AATR)................................................ 29-8

29.4.3 Address Breakpoint Registers (ABLR, ABHR) ........................................... 29-9

29.4.4 Configuration/Status Register (CSR) ......................................................... 29-10

29.4.5 Data Breakpoint/Mask Registers (DBR, DBMR)....................................... 29-12

29.4.6 Program Counter Breakpoint/Mask Registers (PBR, PBMR).................... 29-13

29.4.7 Trigger Definition Register (TDR)............................................................. 29-14

29.5 Background Debug Mode (BDM) .................................................................. 29-16

29.5.1 CPU Halt..................................................................................................... 29-16

29.5.2 BDM Serial Interface.................................................................................. 29-18

29.5.3 BDM Command Set ................................................................................... 29-20

29.6 Real-Time Debug Support .............................................................................. 29-37

29.6.1 Theory of Operation.................................................................................... 29-37

29.6.2 Concurrent BDM and Processor Operation................................................ 29-39

29.7 Processor Status, DDATA Definition............................................................. 29-40

29.7.1 User Instruction Set .................................................................................... 29-40

29.7.2 Supervisor Instruction Set........................................................................... 29-44

29.8 Motorola-Recommended BDM Pinout........................................................... 29-46

xx MCF5282 User’s Manual MOTOROLA

CONTENTS

Paragraph Number

Title

Page

Number

Chapter 30

Chip Configuration Module (CCM)

30.1 Features............................................................................................................. 30-1

30.2 Modes of Operation .......................................................................................... 30-1

30.2.1 Master Mode................................................................................................. 30-2

30.2.2 Single-Chip Mode......................................................................................... 30-2

30.3 Block Diagram.................................................................................................. 30-2

30.4 Signal Descriptions ........................................................................................... 30-3

30.4.1 RCON ........................................................................................................... 30-3

30.4.2 CLKMOD[1:0] ............................................................................................. 30-3

30.4.3 D[26:24, 21, 19:16] (Reset Configuration Override) ................................... 30-3

30.5 Memory Map and Registers.............................................................................. 30-3

30.5.1 Programming Model..................................................................................... 30-3

30.5.2 Memory Map ................................................................................................ 30-4

30.5.3 Register Descriptions.................................................................................... 30-5

30.6 Functional Description...................................................................................... 30-8

30.6.1 Reset Configuration ...................................................................................... 30-8

30.6.2 Chip Mode Selection .................................................................................. 30-10

30.6.3 Boot Device Selection ................................................................................ 30-11

30.6.4 Output Pad Strength Configuration ............................................................ 30-11

30.6.5 Clock Mode Selection................................................................................. 30-11

30.6.6 Chip Select Configuration .......................................................................... 30-12

30.7 Reset................................................................................................................ 30-12

30.8 Interrupts......................................................................................................... 30-12

Chapter 31

IEEE 1149.1 Test Access Port (JTAG)

31.1 Features............................................................................................................. 31-2

31.2 Modes of Operation .......................................................................................... 31-3

31.3 External Signal Description .............................................................................. 31-3

31.3.1 Detailed Signal Description.......................................................................... 31-3

31.4 Memory Map/Register Definition .................................................................... 31-5

31.4.1 Memory Map ................................................................................................ 31-5

31.4.2 Register Descriptions.................................................................................... 31-5

31.5 Functional Description...................................................................................... 31-7

31.5.1 JTAG Module ............................................................................................... 31-7

31.5.2 TAP Controller ............................................................................................. 31-7

31.5.3 JTAG Instructions......................................................................................... 31-8

31.6 Initialization/Application Information............................................................ 31-11

31.6.1 Restrictions ................................................................................................. 31-11

MOTOROLA Contents xxi

CONTENTS

Paragraph Number

31.6.2 Nonscan Chain Operation........................................................................... 31-12

Title

Page

Number

Chapter 32

Mechanical Data

32.1 Pinout ................................................................................................................ 32-2

32.2 Ordering Information........................................................................................ 32-7

Chapter 33

Electrical Characteristics

33.1 Maximum Ratings............................................................................................. 33-1

33.2 Thermal Characteristics .................................................................................... 33-3

33.3 DC Electrical Specifications............................................................................. 33-4

33.4 Phase Lock Loop Electrical Specifications ...................................................... 33-6

33.5 QADC Electrical Characteristics ...................................................................... 33-7

33.6 Flash Memory Characteristics .......................................................................... 33-9

33.7 External Interface Timing Characteristics ...................................................... 33-10

33.8 Processor Bus Output Timing Specifications ................................................. 33-11

33.9 General Purpose I/O Timing........................................................................... 33-17

33.10 Reset and Configuration Override Timing ..................................................... 33-18

33.11 I2C Input/Output Timing Specifications......................................................... 33-19

33.12 Fast Ethernet AC Timing Specifications ........................................................ 33-20

33.12.1 MII Receive Signal Timing (ERXD[3:0], ERXDV, ERXER,

and ERXCLK) ........................................................................................ 33-21

33.12.2 MII Transmit Signal Timing (ETXD[3:0], ETXEN, ETXER, ETXCLK). 33-21

33.12.3 MII Async Inputs Signal Timing (ECRS and ECOL) ................................ 33-22

33.12.4 MII Serial Management Channel Timing (EMDIO and EMDC)............... 33-23

33.13 DMA Timer Module AC Timing Specifications............................................ 33-24

33.14 QSPI Electrical Specifications........................................................................ 33-24

33.15 JTAG and Boundary Scan Timing.................................................................. 33-25

33.16 Debug AC Timing Specifications................................................................... 33-27

xxii MCF5282 User’s Manual MOTOROLA

Appendix A

ILLUSTRATIONS

Figure Number

Title

Page

Number

1-1 MCF5282 Block Diagram ............................................................................................ 1-7

2-1 ColdFire Processor Core Pipelines ............................................................................... 2-1

2-2 User Programming Model ............................................................................................ 2-4

2-3 Condition Code Register (CCR) ................................................................................... 2-4

2-4 EMAC Register Set ...................................................................................................... 2-5

2-5 Supervisor Programming Model................................................................................... 2-6

2-6 Status Register ..............................................................................................................2-6

2-7 Exception Stack Frame Form ..................................................................................... 2-12

2-8 D0 Hardware Configuration Info................................................................................ 2-17

2-9 D1 Hardware Configuration Info................................................................................ 2-19

3-1 Multiply-Accumulate Functionality Diagram .............................................................. 3-2

3-2 Infinite Impulse Response (IIR) Filter.......................................................................... 3-3

3-3 Four-Tap FIR Filter ...................................................................................................... 3-3

3-4 Fractional Alignment .................................................................................................... 3-4

3-5 Signed and Unsigned Integer Alignment...................................................................... 3-4

3-6 EMAC Register Set ...................................................................................................... 3-6

3-7 MAC Status Register (MACSR)................................................................................... 3-6

3-8 EMAC-Specific OEP Sequence Stall ......................................................................... 3-13

3-9 Two’s Complement, Signed Fractional Equation....................................................... 3-14

4-1 Cache Block Diagram................................................................................................... 4-3

4-2 Cache Control Register (CACR) .................................................................................. 4-8

4-3 Access Control Registers (ACR0, ACR1).................................................................. 4-11

5-1 SRAM Base Address Register (RAMBAR)................................................................. 5-2

6-1 CFM Block Diagram .................................................................................................... 6-3

6-2 CFM Array Memory Map............................................................................................. 6-4

6-3 Flash Base Address Register (FLASHBAR) ................................................................ 6-7

6-4 CFM Module Configuration Register (CFMCR) ......................................................... 6-9

6-5 CFM Clock Divider Register (CFMCLKD)............................................................... 6-10

6-6 CFM Security Register (CFMSEC)............................................................................ 6-11

6-7 CFM Protection Register (CFMPROT)...................................................................... 6-12

6-8 CFMPROT Protection Diagram ................................................................................. 6-13

6-9 CFM Supervisor Access Register (CFMSACC) ........................................................ 6-13

6-10 CFM Data Access Register (CFMDACC).................................................................. 6-14

6-11 CFM User Status Register (CFMUSTAT) ................................................................. 6-15

6-12 CFM Command Register (CFMCMD)....................................................................... 6-16

6-13 Example Program Algorithm...................................................................................... 6-21

MOTOROLA Illustrations xxiii

ILLUSTRATIONS

Figure Number

Title

Page

Number

7-1 Low-Power Interrupt Control Register (LPICR) ......................................................... 7-3

7-2 Low-Power Control Register (LPCR) ......................................................................... 7-4

8-1 IPS Base Address Register (IPSBAR).......................................................................... 8-4

8-2 Memory Base Address Register (RAMBAR) .............................................................. 8-5

8-3 Core Reset Status Register (CRSR)............................................................................. 8-6

8-4 Core Watchdog Control Register (CWCR) ................................................................. 8-8

8-5 Core Watchdog Service Register (CWSR).................................................................. 8-9

8-6 Arbiter Module Functions........................................................................................... 8-10

8-7 Default Bus Master Park Register (MPARK)............................................................. 8-12

8-8 Master Privilege Register (MPR) .............................................................................. 8-16

8-9 Peripheral Access Control Register (PACRn) ............................................................ 8-17

8-10 GPACR Register......................................................................................................... 8-18

9-1 Clock Module Block Diagram...................................................................................... 9-3

9-2 PLL Block Diagram...................................................................................................... 9-4

9-3 Synthesizer Control Register (SYNCR) ....................................................................... 9-6

9-4 Synthesizer Status Register (SYNSR) .......................................................................... 9-8

9-5 Crystal Oscillator Example......................................................................................... 9-12

9-6 Lock Detect Sequence ................................................................................................ 9-15

10-1 Interrupt Pending Register High (IPRHn) .................................................................. 10-7

10-2 Interrupt Pending Register Low (IPRLn) ................................................................... 10-7

10-3 Interrupt Mask Register High (IMRHn) ..................................................................... 10-8

10-4 Interrupt Mask Register Low (IMRLn) ...................................................................... 10-8

10-5 Interrupt Force Register High (INTFRCHn) .............................................................. 10-9

10-6 Interrupt Force Register Low (INTFRCLn) ............................................................. 10-10

10-7 Interrupt RequestLevel Register (IRLRn) ................................................................ 10-10

10-8 IACK Level and Priority Register (IACKLPRn) ..................................................... 10-11

10-9 Interrupt Control Register (ICRnx)........................................................................... 10-12

10-10 Software and Level n IACK Registers (SWIACKR, L1IACK–L7IACK)............... 10-16

11-1 EPORT Block Diagram .............................................................................................. 11-1

11-2 EPORT Pin Assignment Register (EPPAR)............................................................... 11-4

11-3 EPORT Data Direction Register (EPDDR) ................................................................ 11-4

11-4 EPORT Port Interrupt Enable Register (EPIER)........................................................ 11-5

11-5 EPORT Port Data Register (EPDR) ........................................................................... 11-5

11-6 EPORT Port Pin Data Register (EPPDR)................................................................... 11-6

11-7 EPORT Port Flag Register (EPFR) ............................................................................ 11-6

12-1 Connections for External Memory Port Sizes ............................................................ 12-4

12-2 Chip Select Address Registers (CSARn)................................................................... 12-6

12-3 Chip Select Mask Registers (CSMRn) ...................................................................... 12-7

12-4 Chip Select Control Registers (CSCRn)..................................................................... 12-8

13-1 Signal Relationship to CLKOUT for Non-DRAM Access ........................................ 13-2

13-2 Connections for External Memory Port Sizes ............................................................ 13-3

13-3 Chip-Select Module Output Timing Diagram ............................................................ 13-3

xxiv MCF5282 User’s Manual MOTOROLA

ILLUSTRATIONS

Figure Number

Title

Page

Number

13-4 Data Transfer State Transition Diagram..................................................................... 13-5

13-5 Read Cycle Flowchart................................................................................................. 13-7

13-6 Basic Read Bus Cycle................................................................................................. 13-7

13-7 Write Cycle Flowchart................................................................................................ 13-8

13-8 Basic Write Bus Cycle................................................................................................ 13-8

13-9 Read Cycle with Fast Termination ............................................................................. 13-9

13-10 Write Cycle with Fast Termination ............................................................................ 13-9

13-11 Back-to-Back Bus Cycles ......................................................................................... 13-10

13-12 Line Read Burst (2-1-1-1), External Termination .................................................... 13-11

13-13 Line Read Burst (2-1-1-1), Internal Termination ..................................................... 13-12

13-14 Line Read Burst (3-2-2-2), External Termination .................................................... 13-12

13-15 Line Read Burst-Inhibited, Fast Termination, External Termination....................... 13-13

13-16 Line Write Burst (2-1-1-1), Internal/External Termination...................................... 13-13

13-17 Line Write Burst (3-2-2-2) with One Wait State ...................................................... 13-14

13-18 Line Write Burst-Inhibited........................................................................................ 13-14

13-19 Example of a Misaligned Longword Transfer (32-Bit Port) .................................... 13-15

13-20 Example of a Misaligned Word Transfer (32-Bit Port)............................................ 13-15

14-1 MCF5282 Block Diagram with Signal Interfaces ...................................................... 14-2

15-1 Synchronous DRAM Controller Block Diagram........................................................ 15-2

15-2 DRAM Control Register (DCR) ................................................................................. 15-5

15-3 DRAM Address and Control Register (DACRn) ....................................................... 15-6

15-4 DRAM Controller Mask Registers (DMRn) .............................................................. 15-8

15-5 Connections for External Memory Port Sizes .......................................................... 15-13

15-6 Burst Read SDRAM Access ..................................................................................... 15-14

15-7 Burst Write SDRAM Access .................................................................................... 15-15

15-8 Auto-Refresh Operation............................................................................................ 15-16

15-9 Self-Refresh Operation ............................................................................................. 15-17

15-10 Mode Register Set (mrs) Command ......................................................................... 15-19

15-11 Initialization Values for DCR ................................................................................... 15-20

15-12 SDRAM Configuration............................................................................................. 15-21

15-13 DACR Register Configuration.................................................................................. 15-21

15-14 DMR0 Register ......................................................................................................... 15-22

16-1 DMA Signal Diagram................................................................................................. 16-2

16-2 DMA Request Control Register (DMAREQC) .......................................................... 16-3

16-3 Dual-Address Transfer................................................................................................ 16-4

16-4 Source Address Registers (SARn).............................................................................. 16-6

16-5 Destination Address Registers (DARn)...................................................................... 16-6

16-6 Byte Count Registers (BCRn)—BCR24BIT = 1........................................................ 16-7

16-7 Byte Count Registers (BCRn)—BCR24BIT = 0........................................................ 16-7

16-8 DMA Control Registers (DCRn) ................................................................................ 16-8

16-9 DMA Status Registers (DSRn) ................................................................................ 16-10

17-1 FEC Block Diagram.................................................................................................... 17-4

17-2 Ethernet Address Recognition—Receive Block Decisions ...................................... 17-12

MOTOROLA Illustrations xxv

ILLUSTRATIONS

Figure Number

Title

Page

Number

17-3 Ethernet Address Recognitionq—Microcode Decisions .......................................... 17-13

17-4 Ethernet Interrupt Event Register (EIR) ................................................................... 17-24

17-5 Interrupt Mask Register (EIMR)............................................................................... 17-26

17-6 Receive Descriptor Active Register (RDAR)........................................................... 17-27

17-7 Transmit Descriptor Active Register (TDAR).......................................................... 17-28

17-8 Ethernet Control Register (ECR)............................................................................. 17-28

17-9 MII Management Frame Register (MMFR) ............................................................. 17-29

17-10 MII Speed Control Register (MSCR) ....................................................................... 17-31

17-11 MIB Control Register (MIBC) ................................................................................. 17-32

17-12 Receive Control Register (RCR) .............................................................................. 17-33

17-13 Transmit Control Register (TCR) ............................................................................. 17-34

17-14 Physical Address Low Register (PALR) .................................................................. 17-36

17-15 Physical Address High Register (PAUR) ................................................................. 17-36

17-16 Opcode/Pause Duration Register (OPD) .................................................................. 17-37

17-17 Descriptor Individual Upper Address Register (IAUR) ........................................... 17-38

17-18 Descriptor Individual Lower Address Register (IALR) ........................................... 17-38

17-19 Descriptor Group Upper Address Register (GAUR)................................................ 17-39

17-20 Descriptor Group Lower Address Register (GALR)................................................ 17-40

17-21 FIFO Transmit FIFO Watermark Register (TFWR)................................................. 17-40

17-22 FIFO Receive Bound Register (FRBR) .................................................................... 17-41

17-23 FIFO Receive Start Register (FRSR)........................................................................ 17-42

17-24 Receive Descriptor Ring Start Register (ERDSR) ................................................... 17-43

17-25 Transmit Buffer Descriptor Ring Start Register (ETDSR)....................................... 17-43

17-26 Receive Buffer Size Register (EMRBR) .................................................................. 17-44

17-27 Receive Buffer Descriptor (RxBD) .......................................................................... 17-47

17-28 Transmit Buffer Descriptor (TxBD) ......................................................................... 17-50

18-1 Watchdog Timer Block Diagram................................................................................ 18-2

18-2 Watchdog Control Register (WCR)............................................................................ 18-3

18-3 Watchdog Modulus Register (WMR)......................................................................... 18-4

18-4 Watchdog Count Register (WCNTR)......................................................................... 18-5

18-5 Watchdog Service Register (WSR) ............................................................................ 18-6

19-1 PIT Block Diagram..................................................................................................... 19-1

19-2 PIT Control and Status Register (PCSR).................................................................... 19-4

19-3 PIT Modulus Register (PMR)..................................................................................... 19-6

19-4 PIT Count Register (PCNTR)..................................................................................... 19-6

19-5 Counter Reloading from the Modulus Latch .............................................................. 19-7

19-6 Counter in Free-Running Mode.................................................................................. 19-7

20-1 GPT Block Diagram ................................................................................................... 20-2

20-2 GPT Input Capture/Output Compare Select Register (GPTIOS) ............................... 20-5

20-3 GPT Input Compare Force Register (GPCFORC) ..................................................... 20-6

20-4 GPT Output Compare 3 Mask Register (GPTOC3M)................................................ 20-6

20-5 GPT Output Compare 3 Data Register (GPTOC3D).................................................. 20-7

xxvi MCF5282 User’s Manual MOTOROLA

ILLUSTRATIONS

Figure Number

Title

Page

Number

20-6 GPT Counter Register (GPTCNT) ............................................................................. 20-7

20-7 GPT System Control Register 1 (GPTSCR1)............................................................. 20-8

20-8 Fast Clear Flag Logic.................................................................................................. 20-9

20-9 GPT Toggle-On-Overflow Register (GPTTOV)........................................................ 20-9

20-10 GPT Control Register 1 (GPTCTL1).......................................................................... 20-9

20-11 GPT Control Register 2 (GPTCTL2)........................................................................ 20-10

20-12 GPT Interrupt Enable Register (GPTIE) .................................................................. 20-10

20-13 GPT System Control Register 2 (GPTSCR2)........................................................... 20-11

20-14 GPT Flag Register 1 (GPTFLG1)............................................................................. 20-12

20-15 GPT Flag Register 2 (GPTFLG2)............................................................................. 20-12

20-16 GPT Channel[0:3] Register (GPTCn)....................................................................... 20-13

20-17 Pulse Accumulator Control Register (GPTPACTL) ................................................ 20-13

20-18 Pulse Accumulator Flag Register (GPTPAFLG)...................................................... 20-14

20-19 Pulse Accumulator Counter Register (GPTPACNT) ............................................... 20-15

20-20 GPT Port Data Register (GPTPORT)....................................................................... 20-16

20-21 GPT Port Data Direction Register (GPTDDR)......................................................... 20-16

20-22 Channel 3 Output Compare/Pulse Accumulator Logic ............................................ 20-19

21-1 DMA Timer Block Diagram....................................................................................... 21-2

21-2 DTMRn Bit Definitions .............................................................................................. 21-4

21-3 DTXMRn Bit Definitions ........................................................................................... 21-5

21-4 DTERn Bit Definitions ............................................................................................... 21-6

21-5 DTRRn Bit Definitions............................................................................................... 21-7

21-6 DTCRn Bit Definitions............................................................................................... 21-8

21-7 DTCNn Bit Definitions............................................................................................... 21-8

22-1 QSPI Block Diagram .................................................................................................. 22-2

22-2 QSPI RAM Model ...................................................................................................... 22-5

22-3 QSPI Mode Register (QMR) .................................................................................... 22-10

22-4 QSPI Clocking and Data Transfer Example ............................................................. 22-11

22-5 QSPI Delay Register (QDLYR) ............................................................................... 22-11

22-6 QSPI Wrap Register (QWR)..................................................................................... 22-12

22-7 QSPI Interrupt Register (QIR).................................................................................. 22-13

22-8 QSPI Address Register ............................................................................................. 22-14

22-9 QSPI Data Register (QDR)....................................................................................... 22-14

22-10 Command RAM Registers (QCR0–QCR15)............................................................ 22-15

22-11 QSPI Timing ............................................................................................................. 22-16

23-1 Simplified Block Diagram .......................................................................................... 23-1

23-2 UART Mode Registers 1 (UMR1n)............................................................................ 23-4

23-3 UART Mode Register 2 (UMR2n) ............................................................................. 23-6

23-4 UART Status Register (USRn) ................................................................................... 23-7

23-5 UART Clock Select Register (UCSRn)...................................................................... 23-8

23-6 UART Command Register (UCRn)............................................................................ 23-9

23-7 UART Receive Buffer (URBn) ................................................................................ 23-11

23-8 UART Transmit Buffer (UTBn) ............................................................................... 23-12

MOTOROLA Illustrations xxvii

ILLUSTRATIONS

Figure Number

Title

Page

Number

23-9 UART Input Port Change Register (UIPCRn) ......................................................... 23-12

23-10 UART Auxiliary Control Register (UACRn)........................................................... 23-13

23-11 UART Interrupt Status/Mask Registers (UISRn/UIMRn)........................................ 23-13

23-12 UART Baud Rate Generator Register (UBG1n) ...................................................... 23-14

23-13 UART Baud Rate Generator Register (UBG2n) ...................................................... 23-14

23-14 UART Input Port Register (UIPn) ............................................................................ 23-15

23-15 UART Output Port Command Registers (UOP1n/UOP0n) ..................................... 23-15

23-16 UART Block Diagram Showing External and Internal Interface Signals ................ 23-17

23-17 UART/RS-232 Interface ........................................................................................... 23-18

23-18 Clocking Source Diagram......................................................................................... 23-19

23-19 Transmitter and Receiver Functional Diagram......................................................... 23-20

23-20 Transmitter Timing Diagram ................................................................................... 23-22

23-21 Receiver Timing ....................................................................................................... 23-23

23-22 Automatic Echo ........................................................................................................ 23-25

23-23 Local Loop-Back ...................................................................................................... 23-25

23-24 Remote Loop-Back ................................................................................................... 23-26

23-25 Multidrop Mode Timing Diagram ............................................................................ 23-27

23-26 UART Mode Programming Flowchart ..................................................................... 23-31

24-1 I2C Module Block Diagram ....................................................................................... 24-2

24-2 I2C Standard Communication Protocol...................................................................... 24-3

24-3 Repeated START........................................................................................................ 24-4

24-4 Synchronized Clock SCL............................................................................................ 24-5

24-5 I2C Address Register (I2ADR)................................................................................... 24-6

24-6 I2C Frequency Divider Register (I2FDR) ................................................................. 24-7

24-7 I2C Control Register (I2CR)....................................................................................... 24-8

24-8 I2CR Status Register (I2SR) ...................................................................................... 24-9

24-9 I

C Data I/O Register (I2DR) .................................................................................. 24-10

24-10 Flow-Chart of Typical I2C Interrupt Routine........................................................... 24-15

25-1 FlexCAN Block Diagram and Pinout ........................................................................ 25-2

25-2 Typical CAN system................................................................................................... 25-4

25-3 Extended ID Message Buffer Structure ...................................................................... 25-5

25-4 Standard ID Message Buffer Structure....................................................................... 25-5

25-5 FlexCAN Memory Map.............................................................................................. 25-8

25-6 CAN Module Configuration Register (CANMCR).................................................. 25-20

25-7 FlexCAN Control Register 0 (CANCTRL0) ............................................................ 25-22

25-8 FlexCAN Control Register 1 (CANCTRL1) ............................................................ 25-23

25-9 Prescaler Divide Register (PRESDIV) ..................................................................... 25-24

25-10 FlexCAN Control Register 2 (CANCTRL2) ............................................................ 25-25

25-11 Free Running Timer (TIMER).................................................................................. 25-26

25-12 Rx Mask Registers (RXGMASK, RX14MASK, and RX15MASK) ....................... 25-27

25-13 FlexCAN Error and Status Register (ESTAT) ......................................................... 25-28

25-14 Interrupt Mask Register (IMASK)............................................................................ 25-30

xxviii MCF5282 User’s Manual MOTOROLA

ILLUSTRATIONS

Figure Number

Title

Page

Number

25-15 Interrupt Flag Register (IFLAG)............................................................................... 25-31

25-16 FlexCAN Receive Error Counter (RXECTR) .......................................................... 25-32

25-17 FlexCAN Transmit Error Counter (TXECTR)......................................................... 25-32

26-1 MCF5282 Ports Module Block Diagram.................................................................... 26-2

26-2 Port Output Data Registers (8-bit) .............................................................................. 26-8

26-3 Port Output Data Register (7-bit)................................................................................ 26-8

26-4 Port Output Data Registers (6-bit) .............................................................................. 26-8

26-5 Port Output Data Registers (4-bit) .............................................................................. 26-9

26-6 Port Data Direction Registers (8-bit) .......................................................................... 26-9

26-7 Port Data Direction Register (7-bit).......................................................................... 26-10

26-8 Port Data Direction Registers (6-bit) ........................................................................ 26-10

26-9 Port Data Direction Registers (4-bit) ........................................................................ 26-10

26-10 Port Pin Data/Set Data Registers (8-bit) .................................................................. 26-11

26-11 Port Pin Data/Set Data Register (7-bit)..................................................................... 26-11

26-12 Port Pin Data/Set Data Registers (6-bit) ................................................................... 26-11

26-13 Port Pin Data/Set Data Registers (4-bit) ................................................................... 26-12

26-14 Port Clear Output Data Registers (8-bit) .................................................................. 26-12

26-15 Port Clear Output Data Register (7-bit).................................................................... 26-13

26-16 Port Clear Output Data Registers (6-bit) .................................................................. 26-13

26-17 Port Clear Output Data Registers (4-bit) .................................................................. 26-13

26-18 Port B/C/D Pin Assignment Register (PBCDPAR).................................................. 26-14

26-19 Port E Pin Assignment Register (PEPAR) ............................................................... 26-15

26-20 Port F Pin Assignment Register (PFPAR)................................................................ 26-17

26-21 Port J Pin Assignment Register (PJPAR) ................................................................ 26-18

26-22 Port SD Pin Assignment Register (PSDPAR) .......................................................... 26-19

26-23 Port AS Pin Assignment Register (PASPAR) .......................................................... 26-19

26-24 Port EH/EL Pin Assignment Register (PEHLPAR) ................................................ 26-20

26-25 Port QS Pin Assignment Register (PQSPAR) .......................................................... 26-21

26-26 Port TC Pin Assignment Register (PTCPAR) ......................................................... 26-22

26-27 Port TD Pin Assignment Register (PTDPAR)......................................................... 26-23

26-28 Port UA Pin Assignment Register (PUAPAR)........................................................ 26-24

26-29 Digital Input Timing ................................................................................................. 26-25

26-30 Digital Output Timing .............................................................................................. 26-26

27-1 QADC Block Diagram................................................................................................ 27-2

27-2 QADC Input and Output Signals ................................................................................ 27-5

27-3 QADC Module Configuration Register (QADCMCR) .............................................. 27-9

27-4 QADC Port QA Data Register (PORTQA) .............................................................. 27-10

27-5 QADC Port QB Data Register (PORTQB)............................................................... 27-10

27-6 QADC Port QA Data Direction Register (DDRQA)................................................ 27-11

27-7 Port QB Data Direction Register (DDRQB)............................................................. 27-11

27-8 QADC Control Register 0 (QACR0)........................................................................ 27-12

27-9 QADC Control Register 1 (QACR1)........................................................................ 27-14

27-10 QADC Control Register 2 (QACR2)........................................................................ 27-17

MOTOROLA Illustrations xxix

ILLUSTRATIONS

Figure Number

Title

Page

Number

27-11 QADC Status Register 0 (QASR0)........................................................................... 27-22

27-12 Queue Status Transition............................................................................................ 27-25

27-13 QADC Status Register 1 (QASR1)........................................................................... 27-26

27-14 Conversion Command Word Table (CCW) ............................................................. 27-27

27-15 Right-Justified Unsigned Result Register (RJURR)................................................. 27-29

27-16 Left-Justified Signed Result Register (LJSRR) ........................................................ 27-30

27-17 Left-Justified Unsigned Result Register (LJURR) ................................................... 27-31

27-18 External Multiplexing Configuration........................................................................ 27-33

27-19 QADC Analog Subsystem Block Diagram .............................................................. 27-35

27-20 Conversion Timing ................................................................................................... 27-36

27-21 Bypass Mode Conversion Timing ............................................................................ 27-36

27-22 QADC Queue Operation with Pause ........................................................................ 27-39

27-23 CCW Priority Situation 1.......................................................................................... 27-41

27-24 CCW Priority Situation 2.......................................................................................... 27-42

27-25 CCW Priority Situation 3.......................................................................................... 27-42

27-26 CCW Priority Situation 4.......................................................................................... 27-43

27-27 CCW Priority Situation 5.......................................................................................... 27-43

27-28 CCW Priority Situation 6.......................................................................................... 27-44

27-29 CCW Priority Situation 7.......................................................................................... 27-44

27-30 CCW Priority Situation 8.......................................................................................... 27-45

27-31 CCW Priority Situation 9.......................................................................................... 27-45

27-32 CCW Priority Situation 10........................................................................................ 27-46

27-33 CCW Priority Situation 11........................................................................................ 27-46

27-34 CCW Freeze Situation 12 ......................................................................................... 27-47

27-35 CCW Freeze Situation 13 ......................................................................................... 27-47

27-36 CCW Freeze Situation 14 ......................................................................................... 27-47

27-37 . CCW Freeze Situation 15 ....................................................................................... 27-47

27-38 CCW Freeze Situation 16 ......................................................................................... 27-48

27-39 CCW Freeze Situation 17 ......................................................................................... 27-48

27-40 CCW Freeze Situation 18 ......................................................................................... 27-48

27-41 CCW Freeze Situation 19 ......................................................................................... 27-48

27-42 QADC Clock Subsystem Functions ......................................................................... 27-58

27-43 QADC Conversion Queue Operation ....................................................................... 27-60

27-44 Equivalent Analog Input Circuitry ........................................................................... 27-63

27-45 Errors Resulting from Clipping ................................................................................ 27-64

27-46 External Positive Edge Trigger Mode Timing with Pause ....................................... 27-65

27-47 Gated Mode, Single Scan Timing............................................................................. 27-66

27-48 Gated Mode, Continuous Scan Timing..................................................................... 27-67

27-49 Star-Ground at the Point of Power Supply Origin.................................................... 27-68

27-50 Input Signal Subjected to Negative Stress................................................................ 27-69

27-51 Input Signal Subjected to Positive Stress ................................................................. 27-70

27-52 External Multiplexing of Analog Signal Sources ..................................................... 27-72

xxx MCF5282 User’s Manual MOTOROLA

ILLUSTRATIONS

Figure Number

Title

Page

Number

27-53 Electrical Model of an A/D Input Signal .................................................................. 27-73

28-1 Reset Controller Block Diagram................................................................................. 28-2

28-2 Reset Control Register (RCR) .................................................................................... 28-3

28-3 Reset Status Register (RSR) ....................................................................................... 28-4

28-4 Reset Control Flow ..................................................................................................... 28-9

29-1 Processor/Debug Module Interface ............................................................................ 29-1

29-2 CLKOUT Timing ....................................................................................................... 29-2

29-3 Example JMP Instruction Output on PST/DDATA ................................................... 29-5

29-4 Debug Programming Model ....................................................................................... 29-6

29-5 Address Attribute Trigger Register (AATR) .............................................................. 29-8

29-6 Address Breakpoint Registers (ABLR, ABHR) ......................................................... 29-9

29-7 Configuration/Status Register (CSR)........................................................................ 29-10

29-8 Data Breakpoint/Mask Registers (DBR/DBMR) ..................................................... 29-12

29-9 Program Counter Breakpoint Register (PBR) .......................................................... 29-14

29-10 Program Counter Breakpoint Mask Register (PBMR) ............................................. 29-14

29-11 Trigger Definition Register (TDR) ........................................................................... 29-15

29-12 BDM Serial Interface Timing ................................................................................... 29-18

29-13 Receive BDM Packet................................................................................................ 29-19

29-14 Transmit BDM Packet .............................................................................................. 29-19

29-15 BDM Command Format ........................................................................................... 29-21

29-16 Command Sequence Diagram .................................................................................. 29-22

29-17 RAREG/RDREG Command Format ............................................................................. 29-23

29-18 RAREG/RDREG Command Sequence.......................................................................... 29-23

29-19 WAREG/WDREG Command Format............................................................................ 29-24

29-20 WAREG/WDREG Command Sequence........................................................................ 29-24

29-21 READ Command/Result Formats............................................................................... 29-25

29-22 READ Command Sequence........................................................................................ 29-25

29-23

WRITE Command Format .......................................................................................... 29-26

29-24 WRITE Command Sequence ...................................................................................... 29-27

29-25

DUMP Command/Result Formats ............................................................................. 29-28

29-26 DUMP Command Sequence ....................................................................................... 29-29

29-27

FILL Command Format ............................................................................................ 29-30

29-28 FILL Command Sequence.......................................................................................... 29-30

29-29 29-30

GO Command Format................................................................................................ 29-31

GO Command Sequence............................................................................................ 29-31

29-31 NOP Command Format.............................................................................................. 29-31

29-32 29-33 29-34 29-35

NOP Command Sequence .......................................................................................... 29-31

RCREG Command/Result Formats............................................................................. 29-32

RCREG Command Sequence...................................................................................... 29-33

WCREG Command/Result Formats............................................................................ 29-34

29-36 WCREG Command Sequence..................................................................................... 29-35

29-37 29-38

RDMREG Command/Result Formats......................................................................... 29-35

RDMREG Command Sequence................................................................................... 29-36

MOTOROLA Illustrations xxxi

ILLUSTRATIONS

Figure Number

Title

Page

Number

29-39 WDMREG BDM Command Format............................................................................ 29-36

29-40 WDMREG Command Sequence.................................................................................. 29-36

29-41 Recommended BDM Connector............................................................................... 29-46

30-1 Chip Configuration Module Block Diagram .............................................................. 30-2

30-2 Chip Configuration Register (CCR) ........................................................................... 30-5

30-3 Reset Configuration Register (RCON) ....................................................................... 30-6

30-4 Chip Identification Register (CIR) ............................................................................. 30-8

31-1 JTAG Block Diagram ................................................................................................. 31-2

31-2 IDCODE Register ....................................................................................................... 31-5

31-3 TAP Controller State Machine Flow .......................................................................... 31-8

32-1 MCF5282 Pinout (256 MAPBGA)............................................................................. 32-2

32-2 256 MAPBGA Package Dimensions.......................................................................... 32-7

33-1 General Input Timing Requirements ........................................................................ 33-11

33-2 Read/Write (Internally Terminated) Timing............................................................. 33-13

33-3 Read Bus Cycle Terminated by TA.......................................................................... 33-14

33-4 Read Bus Cycle Terminated by TEA ....................................................................... 33-15

33-5 SDRAM Read Cycle................................................................................................. 33-16

33-6 SDRAM Write Cycle................................................................................................ 33-17

33-7 GPIO Timing ............................................................................................................ 33-18

33-8 RSTI and Configuration Override Timing................................................................ 33-19

33-9 I2C Input/Output Timings......................................................................................... 33-20

33-10 MII Receive Signal Timing Diagram ....................................................................... 33-21

33-11 MII Transmit Signal Timing Diagram...................................................................... 33-22

33-12 MII Async Inputs Timing Diagram .......................................................................... 33-22

33-13 MII Serial Management Channel Timing Diagram.................................................. 33-23

33-14 QSPI Timing ............................................................................................................. 33-24

33-15 Test Clock Input Timing........................................................................................... 33-25

33-16 Boundary Scan (JTAG) Timing................................................................................ 33-26

33-17 Test Access Port Timing........................................................................................... 33-26

33-18 TRST Timing............................................................................................................ 33-26

33-19 BKPT Timing ........................................................................................................... 33-27

33-20 Real-Time Trace AC Timing.................................................................................... 33-28

33-21 BDM Serial Port AC Timing .................................................................................... 33-28

xxxii MCF5282 User’s Manual MOTOROLA

TABLES

Table Number

Title

Page

Number

1-1 Cache Configuration ..................................................................................................... 1-8

2-1 CCR Field Descriptions ................................................................................................ 2-4

2-2 SR Field Descriptions ................................................................................................... 2-6

2-3 ColdFire CPU Registers................................................................................................ 2-8

2-4 ISA Revision A+ New Instructions ............................................................................ 2-10

2-5 Exception Vector Assignments................................................................................... 2-11

2-6 Format Field Encodings.............................................................................................. 2-12

2-7 Fault Status Encodings................................................................................................ 2-13

2-8 D0 Hardware Configuration Info Field Description................................................... 2-18

2-9 D1 Local Memory Hardware Configuration Information Field Description ............. 2-19

2-10 Misaligned Operand References................................................................................. 2-22

2-11 Move Byte and Word Execution Times ..................................................................... 2-23

2-12 Move Long Execution Times .................................................................................... 2-23

2-13 One Operand Instruction Execution Times ................................................................ 2-24

2-14 Two Operand Instruction Execution Times................................................................ 2-24

2-15 Miscellaneous Instruction Execution Times............................................................... 2-26

2-16 EMAC Instruction Execution Times .......................................................................... 2-27

2-17 General Branch Instruction Execution Times............................................................. 2-28

2-18 BRA, Bcc Instruction Execution Times ..................................................................... 2-28

3-1 MACSR Field Descriptions .......................................................................................... 3-7

3-2 Summary of S/U, F/I, and R/T Control Bits ................................................................. 3-8

3-3 EMAC Instruction Summary ...................................................................................... 3-12

4-1 Initial Fetch Offset vs. CLNF Bits................................................................................ 4-5

4-2 Instruction Cache Operation as Defined by CACR[31, 10] ......................................... 4-6

4-3 Memory Map of Cache Registers ................................................................................. 4-7

4-4 CACR Field Descriptions ............................................................................................. 4-8

4-5 Cache Configuration as Defined by CACR[31, 23, 22] ............................................. 4-10

4-6 Cache Invalidate All as Defined by CACR[23, 22, 21, 20]........................................ 4-10

4-7 External Fetch Size Based on Miss Address and CLNF ............................................ 4-11

4-8 ACR Field Descriptions.............................................................................................. 4-11

5-1 SRAM Base Address Register...................................................................................... 5-2

5-2 Typical RAMBAR Setting Examples........................................................................... 5-4

6-1 CFM Configuration Field ............................................................................................ 6-5

6-2 FLASHBAR Field Descriptions ................................................................................... 6-7

6-3 CFM Register Address Map ......................................................................................... 6-8

6-4 CFMCR Field Descriptions .......................................................................................... 6-9

MOTOROLA Table s xxxiii

TABLES

Tabl e Number

Title

Page

Number

6-5 CFMCLKD Field Descriptions................................................................................... 6-10

6-6 CFMSEC Field Descriptions ...................................................................................... 6-11

6-7 CFMPROT Field Descriptions ................................................................................... 6-12

6-8 CFMSACC Field Descriptions ................................................................................... 6-14

6-9 CFMDACC Field Descriptions .................................................................................. 6-14

6-10 CFMUSTAT Field Descriptions................................................................................. 6-15

6-11 CFMCMD Field Descriptions .................................................................................... 6-16

6-12 CFMCMD User Mode Commands............................................................................. 6-16

6-13 Flash User Commands ................................................................................................ 6-20

6-14 CFM Interrupt Sources ............................................................................................... 6-25

7-1 Chip Configuration Module Memory Map................................................................... 7-2

7-2 LPICR Field Description .............................................................................................. 7-3

7-3 XLPM_IPL Settings ..................................................................................................... 7-4

7-4 LPCR Field Descriptions .............................................................................................. 7-4

7-5 Low-Power Modes........................................................................................................ 7-5

7-6 PLL/CLKOUT Stop Mode Operation .......................................................................... 7-5

7-7 CPU and Peripherals in Low-Power Modes ............................................................... 7-16

8-1 SCM Register Map ....................................................................................................... 8-2

8-2 IPSBAR Field Description............................................................................................ 8-4

8-3 RAMBAR Field Description ........................................................................................ 8-5

8-4 CRSR Field Descriptions.............................................................................................. 8-6

8-5 CWCR Field Description.............................................................................................. 8-8

8-6 Core Watchdog Timer Delay........................................................................................ 8-8

8-7 MPARK Field Description ......................................................................................... 8-13

8-8 SACU Register Memory Map .................................................................................... 8-15

8-9 MPR[n] Field Descriptions......................................................................................... 8-16

8-10 PACR Field Descriptions............................................................................................ 8-17

8-11 PACR ACCESSCTRL Bit Encodings........................................................................ 8-17

8-12 Peripheral Access Control Registers (PACRs)........................................................... 8-17

8-13 Grouped PeripheralAccess Control Register (GPACR) Field Descriptions............... 8-19

8-14 GPACR ACCESS_CTRL Bit Encodings ................................................................... 8-19

8-15 GPACR Address Space .............................................................................................. 8-20

9-1 Clock Module Operation in Low-power Modes........................................................... 9-2

9-2 Signal Properties .......................................................................................................... 9-4

9-3 Clock Module Memory Map ........................................................................................ 9-5

9-4 SYNCR Field Descriptions........................................................................................... 9-6

9-5 SYNSR Field Descriptions ........................................................................................... 9-9

9-6 System Clock Modes ................................................................................................. 9-10

9-7 Clock Out and Clock In Relationships ....................................................................... 9-11

9-8 Charge Pump Current and MFD in Normal Mode Operation .................................... 9-13

9-9 Loss of Clock Summary ............................................................................................. 9-16

9-10 Stop Mode Operation.................................................................................................. 9-17

10-1 Interrupt Priority Within a Level ................................................................................ 10-3

xxxiv MCF5282 User’s Manual MOTOROLA

TABLES

Tabl e Number

Title

Page

Number

10-2 Interrupt Controller Base Addresses........................................................................... 10-5

10-3 Interrupt Controller Memory Map.............................................................................. 10-5

10-4 IPRHn Field Descriptions........................................................................................... 10-7

10-5 IPRLn Field Descriptions ........................................................................................... 10-7

10-6 IMRHn Field Descriptions.......................................................................................... 10-8

10-8 INTFRCHn Field Descriptions................................................................................... 10-9

10-7 IMRLn Field Descriptions .......................................................................................... 10-9

10-9 INTFRCLn Field Descriptions ................................................................................. 10-10

10-10 IRQn Field Descriptions ........................................................................................... 10-10

10-11 IACKLPRn Field Descriptions................................................................................. 10-11

10-12 ICRnx Field Descriptions ......................................................................................... 10-12

10-13 Interrupt Source Assignment for INTC0 .................................................................. 10-12

10-14 Interrupt Source Assignment for INTC1 .................................................................. 10-15

10-15 SWIACK and L1IACK-L7IACK Field Descriptions............................................... 10-16

11-1 Edge Port Module Operation in Low-power Modes .................................................. 11-2

11-2 Edge Port Module Memory Map ................................................................................ 11-3

11-3 EPPAR Field Descriptions.......................................................................................... 11-4

11-4 EPDD Field Descriptions............................................................................................ 11-5

11-5 EPIER Field Descriptions........................................................................................... 11-5

11-6 EPDR Field Descriptions............................................................................................ 11-6

11-7 EPPDR Field Descriptions.......................................................................................... 11-6

11-8 EPFR Field Descriptions ............................................................................................ 11-7

12-1 Chip Select Module Signals........................................................................................ 12-1

12-2 Byte Enables/Byte Write Enable Signal Settings ....................................................... 12-2

12-3 Accesses by Matches in CSARs and DACRs............................................................. 12-4

12-4 D[19:18] External Boot Chip Select Configuration ................................................... 12-5

12-5 Chip Select Registers .................................................................................................. 12-5

12-6 CSARn Field Description ........................................................................................... 12-7

12-7 CSMRn Field Descriptions......................................................................................... 12-7

12-8 CSCRn Field Descriptions.......................................................................................... 12-9

13-1 ColdFire Bus Signal Summary .................................................................................. 13-1

13-2 Accesses by Matches in CSCRs and DACRs............................................................. 13-4

13-3 Bus Cycle States ........................................................................................................ 13-5

13-4 Allowable Line Access Patterns ............................................................................... 13-11

14-1 MCF5282 Signal Description .................................................................................... 14-3

14-2 MCF5282 Alphabetical Signal Index ......................................................................... 14-8

14-3 MCF5282 Signals and Pin Numbers Sorted by Function......................................... 14-11

14-4 Pin Reset States at Reset (Single-Chip Mode).......................................................... 14-17

14-5 Default Signal Functions After System Reset (External Boot Mode) ...................... 14-17

14-6 Transfer Size Encoding............................................................................................. 14-20

14-7 Processor Status Encoding........................................................................................ 14-32

15-1 SDRAM Commands ................................................................................................... 15-3

15-2 Synchronous DRAM Signal Connections .................................................................. 15-4

MOTOROLA Table s xxxv

TABLES

Tabl e Number

Title

Page

Number

15-3 DRAM Controller Registers ....................................................................................... 15-4

15-4 DCR Field Descriptions.............................................................................................. 15-5

15-5 DACRn Field Descriptions......................................................................................... 15-6

15-6 DMRn Field Descriptions........................................................................................... 15-8

15-7 Generic Address Multiplexing Scheme ...................................................................... 15-9

15-8 MCF5282 to SDRAM Interface (8-Bit Port, 9-Column Address Lines).................. 15-10

15-9 MCF5282 to SDRAM Interface (8-Bit Port,10-Column Address Lines)................. 15-10

15-10 MCF5282 to SDRAM Interface (8-Bit Port,11-Column Address Lines)................ 15-10

15-11 MCF5282 to SDRAM Interface (8-Bit Port,12-Column Address Lines)................ 15-10

15-12 MCF5282 to SDRAM Interface (8-Bit Port,13-Column Address Lines)................. 15-10

15-13 MCF5282 to SDRAM Interface (16-Bit Port, 8-Column Address Lines)................ 15-11

15-14 MCF5282 to SDRAM Interface (16-Bit Port, 9-Column Address Lines)............... 15-11

15-15 MCF5282 to SDRAM Interface (16-Bit Port, 10-Column Address Lines)............. 15-11

15-16 MCF5282 to SDRAM Interface (16-Bit Port, 11-Column Address Lines).............. 15-11

15-17 MCF5282 to SDRAM Interface (16-Bit Port, 12-Column Address Lines).............. 15-11

15-18 MCF5282 to SDRAM Interface (16-Bit Port, 13-Column-Address Lines) ............ 15-12

15-19 MCF5282 to SDRAM Interface (32-Bit Port, 8-Column Address Lines)................ 15-12

15-20 MCF5282 to SDRAM Interface (32-Bit Port, 9-Column Address Lines)................ 15-12

15-21 MCF5282 to SDRAM Interface (32-Bit Port, 10-Column Address Lines).............. 15-12

15-22 MCF5282 to SDRAM Interface (32-Bit Port, 11-Column Address Lines).............. 15-12

15-23 MCF5282 to SDRAM Interface (32-Bit Port, 12-Column Address Lines).............. 15-13

15-24 SDRAM Hardware Connections ............................................................................. 15-13

15-25 SDRAM Example Specifications ............................................................................ 15-19

15-26 SDRAM Hardware Connections ............................................................................. 15-20

15-27 DCR Initialization Values......................................................................................... 15-20

15-28 DACR Initialization Values...................................................................................... 15-21

15-29 DMR0 Initialization Values...................................................................................... 15-22

15-30 Mode Register Initialization .................................................................................... 15-23

15-31 Mode Register Mapping to MCF5282 A[31:0] ........................................................ 15-24

16-1 DMAREQC Field Description.................................................................................... 16-3

16-2 Memory Map for DMA Controller Module Registers................................................ 16-5

16-3 DCRn Field Descriptions............................................................................................ 16-8

16-4 DSRn Field Descriptions ......................................................................................... 16-10

17-1 ECR[ETHER_EN] De-Assertion Effect on FEC ....................................................... 17-6

17-2 User Initialization (Before ECR[ETHER_EN]) ......................................................... 17-6

17-3 FEC User Initialization (Before ECR[ETHER_EN])................................................. 17-7

17-4 Microcontroller Initialization...................................................................................... 17-7

17-5 MII Mode.................................................................................................................... 17-8

17-6 7-Wire Mode Configuration ....................................................................................... 17-8

17-7 Destination Address to 6-Bit Hash ........................................................................... 17-14

17-8 PAUSE Frame Field Specification ........................................................................... 17-16

17-9 Module Memory Map............................................................................................... 17-20

17-10 FEC Register Memory Map...................................................................................... 17-20

xxxvi MCF5282 User’s Manual MOTOROLA

TABLES

Tabl e Number

Title

Page

Number

17-11 MIB Counters Memory Map .................................................................................... 17-22

17-12 EIR Field Descriptions.............................................................................................. 17-24

17-13 EIMR Field Descriptions .......................................................................................... 17-26

17-14 RDAR Field Descriptions......................................................................................... 17-27

17-15 TDAR Field Descriptions ......................................................................................... 17-28

17-16 ECR Field Descriptions ............................................................................................ 17-29

17-17 MMFR Field Descriptions ........................................................................................ 17-30

17-18 MSCR Field Descriptions......................................................................................... 17-31

17-19 Programming Examples for MSCR.......................................................................... 17-32

17-20 MIBC Field Descriptions.......................................................................................... 17-32

17-21 RCR Field Descriptions ............................................................................................ 17-33

17-22 TCR Field Descriptions ............................................................................................ 17-35

17-23 PALR Field Descriptions.......................................................................................... 17-36

17-24 PAUR Field Descriptions ......................................................................................... 17-37

17-25 OPD Field Descriptions ............................................................................................ 17-37

17-26 IAUR Field Descriptions .......................................................................................... 17-38

17-27 IALR Field Descriptions........................................................................................... 17-39

17-28 GAUR Field Descriptions......................................................................................... 17-39

17-29 GALR Field Descriptions ......................................................................................... 17-40

17-30 TFWR Field Descriptions......................................................................................... 17-41

17-31 FRBR Field Descriptions.......................................................................................... 17-41

17-32 FRSR Field Descriptions .......................................................................................... 17-42

17-33 ERDSR Field Descriptions ....................................................................................... 17-43

17-34 ETDSR Field Descriptions ....................................................................................... 17-44

17-35 EMRBR Field Descriptions ...................................................................................... 17-44

17-36 Receive Buffer Descriptor Field Definitions ............................................................ 17-48

17-37 Transmit Buffer Descriptor Field Definitions .......................................................... 17-50

18-1 Watchdog Module Operation in Low-power Modes .................................................. 18-1

18-2 Watchdog Timer Module Memory Map..................................................................... 18-3

18-3 WCR Field Descriptions............................................................................................. 18-4

18-4 WMR Field Descriptions ............................................................................................ 18-5

18-5 WCNTR Field Descriptions........................................................................................ 18-5

19-1 PIT Module Operation in Low-power Modes ............................................................ 19-2

19-2 Programmable Interrupt Timer Modules Memory Map ............................................. 19-3

19-3 PCSR Field Descriptions ............................................................................................ 19-4

19-4 PIT Interrupt Requests ................................................................................................ 19-8

20-1 Watchdog Module Operation in Low-power Modes .................................................. 20-3

20-2 Signal Properties ......................................................................................................... 20-3

20-3 GPT Modules Memory Map....................................................................................... 20-4

20-4 GPTIOS Field Descriptions ........................................................................................ 20-6

20-5 GPTCFORC Field Descriptions ................................................................................. 20-6

20-6 GPTOC3M Field Descriptions ................................................................................... 20-7

20-7 GPTOC3D Field Descriptions .................................................................................... 20-7

MOTOROLA Table s xxxvii

TABLES

Tabl e Number

Title

Page

Number

20-8 GPTCNT Field Descriptions ...................................................................................... 20-8

20-9 GPTSCR1 Field Descriptions..................................................................................... 20-8

20-10 GPTTOV Field Description........................................................................................ 20-9

20-11 GPTCL1 Field Descriptions ..................................................................................... 20-10

20-12 GPTLCTL2 Field Descriptions ................................................................................ 20-10

20-13 GPTIE Field Descriptions......................................................................................... 20-11

20-14 GPTSCR2 Field Descriptions................................................................................... 20-11

20-15 GPTFLG1 Field Descriptions................................................................................... 20-12

20-16 GPTFLG2 Field Descriptions................................................................................... 20-12

20-17 GPTCn Field Descriptions........................................................................................ 20-13

20-18 GPTPACTL Field Descriptions................................................................................ 20-13

20-19 GPTPAFLG Field Descriptions................................................................................ 20-15

20-20 GPTPACR Field Descriptions .................................................................................. 20-15

20-21 GPTPORT Field Descriptions .................................................................................. 20-16

20-22 GPTDDR Field Descriptions .................................................................................... 20-16

20-23 GPT Settings and Pin Functions ............................................................................... 20-20

20-24 GPT Interrupt Requests ............................................................................................ 20-21

21-1 DMA Timer Module Memory Map........................................................................... 21-3

21-2 DTMRn Field Descriptions ........................................................................................ 21-5

21-3 DTXMRn Field Descriptions...................................................................................... 21-6

21-4 DTERn Field Descriptions.......................................................................................... 21-7

22-1 QSPI Input and Output Signals and Functions ........................................................... 22-3

22-2 QSPI_CLK Frequency as Function of System Clock and Baud Rate ........................ 22-7

22-3 QSPI Registers............................................................................................................ 22-9

22-4 QMR Field Descriptions........................................................................................... 22-10

22-5 QDLYR Field Descriptions ...................................................................................... 22-12

22-6 QWR Field Descriptions........................................................................................... 22-12

22-7 QIR Field Descriptions ............................................................................................. 22-13

22-8 QCR0–QCR15 Field Descriptions............................................................................ 22-15

23-1 UART Module Memory Map ..................................................................................... 23-3

23-2 UMR1n Field Descriptions......................................................................................... 23-5

23-3 UMR2n Field Descriptions......................................................................................... 23-6

23-4 USRn Field Descriptions ............................................................................................ 23-7

23-5 UCSRn Field Descriptions.......................................................................................... 23-9

23-6 UCRn Field Descriptions.......................................................................................... 23-10

23-7 UIPCRn Field Descriptions ...................................................................................... 23-12

23-8 UACRn Field Descriptions....................................................................................... 23-13

23-9 UISRn/UIMRn Field Descriptions ........................................................................... 23-14

23-10 UIPn Field Descriptions............................................................................................ 23-15

23-11 UOP1/UOP0 Field Descriptions............................................................................... 23-16

23-12 UART Module Signals ............................................................................................. 23-18

23-13 UART Interrupts ....................................................................................................... 23-29

23-14 UART DMA Requests.............................................................................................. 23-30

xxxviii MCF5282 User’s Manual MOTOROLA

TABLES

Tabl e Number

Title

Page

Number

23-15 UART Module Initialization Sequence .................................................................... 23-30

24-1 I2C Interface Memory Map ....................................................................................... 24-6

24-2 I2ADR Field Descriptions .......................................................................................... 24-6

24-3 I2FDR Field Descriptions........................................................................................... 24-7

24-4 I2CR Field Descriptions ............................................................................................. 24-8

24-5 I2SR Field Descriptions.............................................................................................. 24-9

25-1 FlexCAN Memory Map.............................................................................................. 25-3

25-2 Common Extended/Standard Format Frames............................................................. 25-6

25-3 Message Buffer Codes for Receive Buffers ............................................................... 25-6

25-4 Message Buffer Codes for Transmit Buffers.............................................................. 25-6

25-5 Extended Format Frames ............................................................................................ 25-7

25-6 Standard Format Frames............................................................................................. 25-7

25-7 Examples of System Clock/CAN Bit-Rate/S-Clock................................................. 25-14

25-8 CANMCR Field Descriptions................................................................................... 25-21

25-9 CANCTRL0 Field Descriptions ............................................................................... 25-23

25-10 Transmit Pin Configuration ...................................................................................... 25-23

25-11 CANCTRL1 Field Descriptions ............................................................................... 25-24

25-12 PRESDIV Field Descriptions ................................................................................... 25-25

25-13 CANCTRL2 Field Descriptions ............................................................................... 25-25

25-14 TIMER Field Descriptions........................................................................................ 25-26

25-15 Mask examples for Normal/Extended Messages...................................................... 25-26

25-16 RXGMASK, RX14MASK, and RX15MASK Field Descriptions ........................... 25-28

25-17 ESTAT Field Descriptions........................................................................................ 25-29

25-18 IMASK Field Descriptions ....................................................................................... 25-31

25-19 IFLAG Field Descriptions ........................................................................................ 25-31

25-20 RXECTR Field Descriptions .................................................................................... 25-32

25-21 TXECTR Field Descriptions .................................................................................... 25-32

26-1 MCF5282 Ports External Signals ............................................................................... 26-4

26-2 MCF5282 Ports Module Memory Map ...................................................................... 26-6

26-3 PORTn (8-bit, 7-bit, 6-bit, and 4-bit) Field Descriptions ........................................... 26-9

26-4 DDRn (8-bit, 6-bit, and 4-bit) Field Descriptions .................................................... 26-10

26-5 PORTnP/SETn (8-bit, 6-bit, and 4-bit) Field Descriptions ...................................... 26-12

26-6 CLRn (8-bit,7-bit, 6-bit, and 4-bit) Field Descriptions............................................. 26-13

26-7 PBCDPAR Field Descriptions.................................................................................. 26-14

26-8 Reset Values for PBCDPAR Bits ............................................................................. 26-14

26-9 PEPAR Field Descriptions........................................................................................ 26-15

26-10 Reset Values for PEPAR Bits and Fields ................................................................. 26-16

26-11 PFPAR Field Descriptions........................................................................................ 26-17

26-12 PJPAR Field Descriptions ........................................................................................ 26-18

26-13 PSDPAR Field Descriptions..................................................................................... 26-19

26-14 PASPAR Field Descriptions..................................................................................... 26-20

26-15 PEHLPAR Field Descriptions .................................................................................. 26-21

26-16 PQSPAR Field Description ...................................................................................... 26-21

MOTOROLA Table s xxxix

TABLES

Tabl e Number

Title

Page

Number

26-17 PTCPAR Field Descriptions..................................................................................... 26-22

26-18 PTDPAR Field Descriptions..................................................................................... 26-23

26-19 PUAPAR Field Descriptions .................................................................................... 26-24

27-1 Multiplexed Analog Input Channels........................................................................... 27-7

27-2 QADC Memory Map .................................................................................................. 27-8

27-3 QADCMCR Field Descriptions.................................................................................. 27-9

27-4 QACR0 Field Descriptions....................................................................................... 27-12

27-5 Prescaler fSYS Divide-by Values............................................................................. 27-13

27-6 QACR1 Field Descriptions....................................................................................... 27-14

27-7 Queue 1 Operating Modes ........................................................................................ 27-15

27-8 QACR2 Field Descriptions....................................................................................... 27-18

27-9 Queue 2 Operating Modes ........................................................................................ 27-18

27-10 QASR0 Field Descriptions ....................................................................................... 27-23

27-11 CCW Pause Bit Response......................................................................................... 27-24

27-12 Queue Status ............................................................................................................. 27-24

27-13 QASR1 Field Descriptions ....................................................................................... 27-26

27-14 CCW Field Descriptions........................................................................................... 27-27

27-15 Input Sample Times .................................................................................................. 27-28

27-16 Non-Multiplexed Channel Assignments and Signal Designations........................... 27-28

27-17 Multiplexed Channel Assignments and Signal Designations ................................... 27-29

27-18 RJURR Field Descriptions........................................................................................ 27-30

27-19 LJSRR Field Descriptions ........................................................................................ 27-30

27-20 LJURR Field Descriptions........................................................................................ 27-31

27-21 Analog Input Channels ............................................................................................. 27-34

27-22 Trigger Events........................................................................................................... 27-40

27-23 Status Bits ................................................................................................................. 27-40

27-24 External Circuit Settling Time to 1/2 LSB ............................................................... 27-74

27-25 Error Resulting from Input Leakage (IOff) .............................................................. 27-75

27-26 QADC Status Flags and Interrupt Sources ............................................................... 27-76

28-1 Reset Controller Signal Properties............................................................................. 28-2

28-2 Reset Controller Memory Map ................................................................................... 28-3

28-3 RCR Field Descriptions .............................................................................................. 28-3

28-4 RSR Field Descriptions .............................................................................................. 28-5

28-5 Reset Source Summary............................................................................................... 28-6

29-1 Debug Module Signals................................................................................................ 29-2

29-2 Processor Status Encoding.......................................................................................... 29-3

29-3 BDM/Breakpoint Registers......................................................................................... 29-7

29-4 Rev. A Shared BDM/Breakpoint Hardware ............................................................... 29-7

29-5 AATR Field Descriptions ........................................................................................... 29-8

29-6 ABLR Field Description........................................................................................... 29-10

29-7 ABHR Field Description .......................................................................................... 29-10

29-8 CSR Field Descriptions ............................................................................................ 29-11

29-9 DBR Field Descriptions............................................................................................ 29-13

xl MCF5282 User’s Manual MOTOROLA

TABLES

Tabl e Number

Title

Page

Number

29-10 DBMR Field Descriptions ........................................................................................ 29-13

29-11 Access Size and Operand Data Location.................................................................. 29-13

29-12 PBR Field Descriptions ............................................................................................ 29-14

29-13 PBMR Field Descriptions......................................................................................... 29-14

29-14 TDR Field Descriptions ............................................................................................ 29-15

29-15 Receive BDM Packet Field Description................................................................... 29-19

29-16 Transmit BDM Packet Field Description ................................................................. 29-19

29-17 BDM Command Summary ....................................................................................... 29-20

29-18 BDM Field Descriptions........................................................................................... 29-21

29-19 Control Register Map................................................................................................ 29-32

29-20 Definition of DRc Encoding—Read......................................................................... 29-36

29-21 DDATA[3:0]/CSR[BSTAT] Breakpoint Response.................................................. 29-37

29-22 PST/DDATA Specification for User-Mode Instructions.......................................... 29-40

29-23 PST/DDATA Specification for MAC Instructions................................................... 29-43

29-24 PST/DDATA Specification for Supervisor-Mode Instructions................................ 29-44

30-1 Signal Properties ........................................................................................................ 30-3

30-2 Write-Once Bits Read/Write Accessibility................................................................. 30-4

30-3 Chip Configuration Module Memory Map................................................................. 30-4

30-4 CCR Field Descriptions .............................................................................................. 30-5

30-5 RCON Field Descriptions........................................................................................... 30-6

30-6 RCSC Chip Select Configuration ............................................................................... 30-7

30-7 BOOTPS Port Size Configuration .............................................................................. 30-7

30-8 CIR Field Description................................................................................................. 30-8

30-9 Reset Configuration Pin States During Reset ............................................................. 30-9

30-10 Configuration During Reset....................................................................................... 30-9

30-11 Chip Configuration Mode Selection ......................................................................... 30-11

30-12 Output Pad Driver Strength Selection ...................................................................... 30-11

30-13 Clock Mode Selection............................................................................................... 30-12

31-1 Signal Properties ......................................................................................................... 31-3

31-2 Pin Function Selected ................................................................................................. 31-3

31-3 Signal State to the Disable Module............................................................................. 31-4

31-4 IDCODE Register Field Descriptions......................................................................... 31-6

31-5 JTAG Instructions....................................................................................................... 31-8

32-1 MCF5282 Signal Description by Pin Number............................................................ 32-3

32-2 Orderable Part Numbers ............................................................................................. 32-7

33-1 Absolute Maximum Ratings, ..................................................................................... 33-1

33-2 Thermal Characteristics .............................................................................................. 33-3

33-3 DC Electrical Specifications....................................................................................... 33-4

33-4 PLL Electrical Specifications ..................................................................................... 33-6

33-5 QADC Absolute Maximum Ratings........................................................................... 33-7

33-6 QADC Electrical Specifications (Operating) ............................................................ 33-7

33-7 QADC Conversion Specifications (Operating) .......................................................... 33-9

33-8 SGFM Flash Program and Erase Characteristics........................................................ 33-9

MOTOROLA Table s xli

TABLES

Tabl e Number

Title

Page

Number

33-9 SGFM Flash Module Life Characteristics ................................................................ 33-10

33-10 Processor Bus Input Timing Specifications.............................................................. 33-10

33-11 External Bus Output Timing Specifications ............................................................. 33-11

33-12 SDRAM Timing ....................................................................................................... 33-16

33-13 GPIO Timing, ........................................................................................................... 33-17

33-13 (VDD = 2.7 to 3.6 V, VSS = 0 V, V

= 5 V) ........................................................ 33-17

DDH

33-14 Reset and Configuration Override Timing ............................................................... 33-18

33-15 I2C Input Timing Specifications between SCL and SDA......................................... 33-19

33-16 I2C Output Timing Specifications between SCL and SDA..................................... 33-20

33-17 MII Receive Signal Timing ...................................................................................... 33-21

33-18 MII Transmit Signal Timing..................................................................................... 33-22

33-19 MII Async Inputs Signal Timing .............................................................................. 33-22

33-20 MII Serial Management Channel Timing................................................................. 33-23

33-21 Timer Module AC Timing Specifications ................................................................ 33-24

33-22 QSPI Modules AC Timing Specifications................................................................ 33-24

33-23 JTAG and Boundary Scan Timing............................................................................ 33-25

33-24 Debug AC Timing Specification .............................................................................. 33-27

A-1 CPU Space Register Memory Map.............................................................................. A-1

A-2 Module Memory Map Overview ................................................................................. A-2

A-3 Register Memory Map ................................................................................................. A-3

xlii MCF5282 User’s Manual MOTOROLA

About This Book

The primary objective of this user’s manual is to define the functionality of the MCF5282 processors for use by software and hardware developers.

The information in this book, except for changes to the Flash functionality, also applies to the MCF5281.

The information in this book is subject to change without notice, as described in the disclaimers on the title page. As with any technical documentation, it is the reader’s responsibility to be sure he is using the most recent version of the documentation.

To locate any published errata or updates for this document, refer to the world-wide web at http://www.motorola.com/coldfire.

Audience

This manual is intended for system software and hardware developers and applications programmers who want to develop products with the MCF5282. It is assumed that the reader understands operating systems, microprocessor system design, basic principles of software and hardware, and basic details of the ColdFire

architecture.

Organization

Following is a summary and brief description of the major sections of this manual:

• Chapter 1, “Overview,” includes general descriptions of the modules and features incorporated in the MCF5282, focussing in particular on new features.

• Chapter 2, “ColdFire Core,” provides an overview of the microprocessor core of the MCF5282. The chapter describes the organization of the Version 2 (V2) ColdFire processor core and an overview of the program-visible registers (the programming model) as they are implemented on the MCF5282.

• Chapter 3, “Enhanced Multiply-Accumulate Unit (EMAC),” describes the MCF5282 multiply/accumulate unit, which executes integer multiply, multiply-accumulate, and miscellaneous register instructions. The EMAC is integrated into the operand execution pipeline (OEP).

MOTOROLA About This Book xliii

Organization

• Chapter 4, “Cache,” describes the MCF5282 cache implementation, including organization, configuration, and coherency. It describes cache operations and how the cache interacts with other memory structures.

• Chapter 5, “Static RAM (SRAM),” describes the MCF5282 on-chip static RAM (SRAM) implementation. It covers general operations, configuration, and initialization. It also provides information and examples of how to minimize power consumption when using the SRAM.

• Chapter 6, “ColdFire Flash Module (CFM)” describe the functionality of the MCF5282 Flash memory.

• Chapter 7, “Power Management,” describes the low power operation of the MCF5282 and peripheral behavior in low power modes.

• Chapter 8, “System Control Module (SCM),” describes the functionality of the SCM, which provides the programming model for the System Access Control Unit (SACU), the system bus arbiter, a 32-bit Core Watchdog Timer (CWT), and the system control registers and logic.

• Chapter 9, “Clock Module,” describes the MCF5282’s different clocking methods. It also describes clock module operation in low power modes.

• Chapter 10, “Interrupt Controller Modules,” describes operation of the interrupt controller portion of the SCM. Includes descriptions of the registers in the interrupt controller memory map and the interrupt priority scheme.

• Chapter 11, “Edge Port Module (EPORT),” describes EPORT module functionality, including operation in low power mode.

• Chapter 12, “Chip Select Module,” describes the MCF5282 chip-select implementation, including the operation and programming model, which includes the chip-select address, mask, and control registers.

• Chapter 13, “External Interface Module (EIM),” describes data-transfer operations, error conditions, bus arbitration, and reset operations.

• Chapter 14, “Signal Descriptions,” describes MCF5282 signals. It includes an alphabetical listing of signals that characterizes each signal as an input or output, defines its state at reset, and identifies whether a pull-up resistor should be used.

• Chapter 15, “Synchronous DRAM Controller Module,” describes the configuration and operation of the SDRAM controller. It begins with a general description and brief glossary, and includes a description of signals involved in DRAM operations. The remainder of the chapter describes the programming model and signal timing, as well as the command set required for synchronous operations.

• Chapter 16, “DMA Controller Module,” describes the MCF5282 Direct Memory Access (DMA) controller module. It provides an overview of the module and describes in detail its signals and registers. The latter sections of this chapter describe operations, features, and supported data transfer modes in detail.

xliv MCF5282 User’s Manual MOTOROLA

Organization

• Chapter 17, “Fast Ethernet Controller (FEC),” provides a feature-set overview, a functional block diagram, and transceiver connection information for both MII (Media Independent Interface) and 7-wire serial interfaces. It also provides describes operation and the programming model.

• Chapter 18, “Watchdog Timer Module,” describes Watchdog timer functionality, including operation in low power mode.

• Chapter 19, “Programmable Interrupt Timer Modules (PIT0–PIT3),” describes the functionality of the four PIT timers, including operation in low power mode.

• Chapter 20, “General Purpose Timer Modules (GPTA and GPTB),” describes the functionality of the two general purpose timers, including operation in low power mode.

• Chapter 21, “DMA Timers (DTIM0–DTIM3),” describes the configuration and operation of the four DMA timer modules (DTIM0, DTIM1, DTIM2, and DTIM3). These 32-bit timers provide input capture and reference compare capabilities with optional signaling of events using interrupts or triggers. This chapter also provides programming examples.

• Chapter 22, “Queued Serial Peripheral Interface (QSPI) Module,” provides a feature-set overview and a description of operation, including details of the QSPI’s internal storage organization. The chapter concludes with the programming model and a timing diagram.

• Chapter 23, “UART Modules,” describes the use of the universal asynchronous receiver/transmitters (UARTs) implemented on the MCF5282 and includes programming examples.

• Chapter 24, “I2C Interface,” describes the MCF5282 I protocol, clock synchronization, and I

C programming model registers. It also

C module, including I2C

provides extensive programming examples.

• Chapter 25, “FlexCAN,” describes the MCF5282 implementation of the controller area network (CAN) protocol. This chapter describes FlexCAN module operation and provides a programming model.

• Chapter 26, “General Purpose I/O Module,” describes the operation and programming model of the general purpose I/O (GPIO) ports on the MCF5282.

• Chapter 30, “Chip Configuration Module (CCM),” describes CCM functionality, detailing the two modes of chip operation: master mode and single-chip mode. This chapter provides a description of signals used by the CCM and a programming model.

• Chapter 27, “Queued Analog-to-Digital Converter (QADC),” describes the use of the QADC module implemented on the MCF5282.

• Chapter 28, “Reset Controller Module,” describes the operation of the reset controller module, detailing the different types of reset that can occur.

MOTOROLA About This Book xlv

Suggested Reading

This section lists additional reading that provides background for the information in this manual as well as general information about the ColdFire architecture.

General Information

The following documentation provides useful information about the ColdFire architecture and computer architecture in general:

• ColdFire Programmers Reference Manual, R1.0 (MCF5200PRM/AD)

• Using Microprocessors and Microcomputers: The Motorola Family, William C. Wray, Ross Bannatyne, Joseph D. Greenfield

• Computer Architecture: A Quantitative Approach, Second Edition, by John L. Hennessy and David A. Patterson.

• Computer Organization and Design: The Hardware/Software Interface, Second Edition, David A . Patterson and John L. Hennessy.

ColdFire Documentation

The ColdFire documentation is available from the sources listed on the back cover of this manual. Document order numbers are included in parentheses for ease in ordering.

• User’s manuals—These books provide details about individual ColdFire implementations and are intended to be used in conjunction with The ColdFire Programmers Reference Manual. These include the following:

xlvi MCF5282 User’s Manual MOTOROLA

Conventions

— ColdFire MCF5102 User’s Manual (MCF5102UM/AD)

— ColdFire MCF5202 User’s Manual (MCF5202UM/AD)

— ColdFire MCF5204 User’s Manual (MCF5204UM/AD)

— ColdFire MCF5206 User’s Manual (MCF5206EUM/AD)

— ColdFire MCF5206E User’s Manual (MCF5206EUM/AD)

— ColdFire MCF5307 User’s Manual (MCF5307UM/AD)

— ColdFire MCF5407 User’s Manual (MCF5407UM/AD)

Additional literature on ColdFire implementations is being released as new processors become available. For a current list of ColdFire documentation, refer to the World Wide Web at http://www.motorola.com/ColdFire/.

Conventions

This document uses the following notational conventions:

MNEMONICS In text, instruction mnemonics are shown in uppercase.

mnemonics In code and tables, instruction mnemonics are shown in lowercase.

italics Italics indicate variable command parameters.

Book titles in text are set in italics.

0x0 Prefix to denote hexadecimal number

0b0 Prefix to denote binary number

REG[FIELD] Abbreviations for registers are shown in uppercase. Specific bits,

fields, or ranges appear in brackets. For example, RAMBAR[BA] identifies the base address field in the RAM base address register.

nibble A 4-bit data unit

byte An 8-bit data unit

word A 16-bit data unit

longword A 32-bit data unit

x In some contexts, such as signal encodings, x indicates a don’t care.

n Used to express an undefined numerical value

~ NOT logical operator

& AND logical operator

| OR logical operator

The only exceptions to this appear in the discussion of serial communication modules that support variable-length data transmission units. To simplify the discussion these units are referred to as words regardless of length.

MOTOROLA About This Book xlvii

Acronyms and Abbreviations

Table i lists acronyms and abbreviations used in this document.

Table i. Acronyms and Abbreviated Terms

Term Meaning

ADC Analog-to-digital conversion

ALU Arithmetic logic unit

BDM Background debug mode

BIST Built-in self test

BSDL Boundary-scan description language

CODEC Code/decode

DAC Digital-to-analog conversion

DMA Direct memory access

DSP Digital signal processing

EA Effective address

FIFO First-in, first-out

GPIO General-purpose I/O

C Inter-integrated circuit

IEEE Institute for Electrical and Electronics Engineers

IFP Instruction fetch pipeline

IPL Interrupt priority level

JEDEC Joint Electron Device Engineering Council

JTAG Joint Test Action Group

LIFO Last-in, first-out

LRU Least recently used

LSB Least-significant byte

lsb Least-significant bit

MAC Multiply accumulate unit, also Media access controller

MBAR Memory base address register

MSB Most-significant byte

msb Most-significant bit

Mux Multiplex

NOP No operation

OEP Operand execution pipeline

PC Program counter

PCLK Processor clock

PLIC Physical layer interface controller

PLL Phase-locked loop

xlviii MCF5282 User’s Manual MOTOROLA

Table i. Acronyms and Abbreviated Terms (Continued)

Term Meaning

POR Power-on reset

PQFP Plastic quad flat pack

PWM Pulse width modulation

QSPI Queued serial peripheral interface

RISC Reduced instruction set computing

Rx Receive

SIM System integration module

SOF Start of frame

TAP Test access port

TTL Transistor transistor logic

Tx Transmit

UART Universal asynchronous/synchronous receiver transmitter

USB Universal serial bus

Terminology Conventions

Table ii shows terminology conventions used throughout this document.

Table ii. Notational Conventions

Instruction Operand Syntax

Opcode Wildcard

cc Logical condition (example: NE for not equal)

An Any address register n (example: A3 is address register 3)

Ay,Ax Source and destination address registers, respectively

Dn Any data register n (example: D5 is data register 5)

Dy,Dx Source and destination data registers, respectively

Rc Any control register (example VBR is the vector base register)

Rm MAC registers (ACC, MAC, MASK)

Rn Any address or data register

Rw Destination register w (used for MAC instructions only)

Ry,Rx Any source and destination registers, respectively

Xi Index register i (can be an address or data register: Ai, Di)

MOTOROLA About This Book xlix

Terminology Conventions

Table ii. Notational Conventions (Continued)

Instruction Operand Syntax

ACC MAC accumulator register

CCR Condition code register (lower byte of SR)

MACSR MAC status register

MASK MAC mask register

PC Program counter

SR Status register

Port Name

DDATA Debug data port

PST Processor status port

Miscellaneous Operands

#<data> Immediate data following the 16-bit operation word of the instruction

<ea> Effective address

<ea>y,<ea>x Source and destination effective addresses, respectively

<label> Assembly language program label

<list> List of registers for MOVEM instruction (example: D3–D0)

<shift> Shift operation: shift left (<<), shift right (>>)

<size> Operand data size: byte (B), word (W), longword (L)

bc Both instruction and data caches

dc Data cache

ic Instruction cache

# <vector> Identifies the 4-bit vector number for trap instructions

<> identifies an indirect data address referencing memory

<xxx> identifies an absolute address referencing memory

dn Signal displacement value, n bits wide (example: d16 is a 16-bit displacement)

SF Scale factor (x1, x2, x4 for indexed addressing mode, <<1n>> for MAC operations)

Operations

+ Arithmetic addition or postincrement indicator

– Arithmetic subtraction or predecrement indicator

x Arithmetic multiplication

l MCF5282 User’s Manual MOTOROLA

Terminology Conventions

Table ii. Notational Conventions (Continued)

Instruction Operand Syntax

/ Arithmetic division

~ Invert; operand is logically complemented

& Logical AND

| Logical OR

^ Logical exclusive OR

<< Shift left (example: D0 << 3 is shift D0 left 3 bits)

>> Shift right (example: D0 >> 3 is shift D0 right 3 bits)

→ Source operand is moved to destination operand

←→ Two operands are exchanged

sign-extended All bits of the upper portion are made equal to the high-order bit of the lower portion

If <condition>

then <operations>

else <operations>

{} Optional operation

() Identifies an indirect address

Address Calculated effective address (pointer)

Bit Bit selection (example: Bit 3 of D0)

lsb Least significant bit (example: lsb of D0)

LSB Least significant byte

LSW Least significant word

msb Most significant bit

MSB Most significant byte

MSW Most significant word

C Carry

N Negative

Test the condition. If true, the operations after ‘then’ are performed. If the condition is false and the optional ‘else’ clause is present, the operations after ‘else’ are performed. If the condition is false and else is omitted, the instruction performs no operation. Refer to the Bcc instruction description as an example.

Displacement value, n-bits wide (example: d16 is a 16-bit displacement)

Condition Code Register Bit Names

Subfields and Qualifiers

V Overflow

X Extend

ZZero

MOTOROLA About This Book li

Revision History

Table iii provides a revision history for this document.

Table iii. Revision History

Revision

Number

0 11/2002 Preliminary release.

0.1 1/2003 Changed title from “MCF5282 ColdFire

Date of

Release

Substantive Changes Section/Page

Manual” to “MCF5282 ColdFire

Added “This product incorporates SuperFlash® technology licensed from SST.”

Changed equation in footnote to f 2(MFD + 2) ≤ 80 MHz, f

Multiplied all PLL frequencies in table by 2. Table 9-4/9-6

Changed DTMRx to DTIMx. Figure 10-13/10-12

Changed bit numbers from 63–32 to 31–0. Figure 10-1/10-7

Changed bit numbers from 63–32 to 31–0. Figure 10-3/10-8

Changed bit numbers from 63–32 to 31–0. Figure 10-5/10-9

Added Section 14.2.4, “Chip Configuration Signals.” 14.2.4/14-22

Added Table 14-3. Table 14-3/14-11

Added “Unlike the MCF5272, the MCF5282 does not have an independent SDRAM clock signal. For the MCF5282, the timing of the SDRAM controller is controlled by the CLKOUT signal.”

≤ 66 MHz.

sys

Integrated Microprocessor User’s

Microcontroller User’s Manual.”

= f

× 2(MFD + 2)/2 exp RFD; f

sys

ref

Title page

1.1/1-1

Table 9-4/9-6

15.2/15-3

Added Section 15.2.3.2, “SDRAM Byte Strobe Connections.” 15.2.3.2/15-13

Added “Note: Because the MCF5282 has 24 external address lines, the maximum SDRAM address size is 128 Mbits.”

Changed reset value to 0010_0000_0000_0000. Figure 30-4/30-8

Changed “PSTCLK” references to “CLKOUT.” Chapter 29

Changed “TEA

Changed “RAS0” and “RAS1” to “SDRAM_CS0” and “SDRAM_CS1.” Figure 32-1/32-2

Added Table 32-1. Table 32-1/32-3

Changed max input high voltage to 5.25 V. Table 33-3/33-4

Changed “System Integration Module” to “System Control Module.” Appendix A

1 4/2003 Replaced Figure 6-1 with a more accurate block diagram. Figure 6-1/6-3

Enhanced discussion of Flash blocks. 6.2/6-2

Added “Note:

” to “TA.” Figure 29-41/29-46

Enabling Flash security will disable BDM

15.2.3.1/15-9

6.3.4.3/6-10

communications.”

Added “Note:

When Flash security is enabled, the chip will boot in

6.3.4.3/6-10

single chip mode regardless of the external reset configuration.”

lii MCF5282 User’s Manual MOTOROLA

Table iii. Revision History

Revision History

Revision

Number

Date of

Release

Substantive Changes Section/Page

Changed text in Step 1 to read “If f

÷ 2 is greater than 12.8 MHz,

SYS

6.4.3.1/6-18

PRDIV8 = 1; otherwise PRDIV8 = 0.”

Changed equation in Step 2 to the following: 6.4.3.1/6-18

DIV[5:0] =

2 x 200kHz x (1 + (PRDIV8 x 7))

SYS

Changed equation in Step 3 to the following: 6.4.3.1/6-18

CLK

2 x (DIV[5:0] + 1) x (1 + (PRDIV8 x 7))

SYS

Changed equations in example to reflect revisions above. 6.4.3.1/6-18

Changed text to read “So, for f

= 66 MHz, writing 0x54 to CFMCLKD

SYS

6.4.3.1/6-18 will set FCLK to 196.43 kHz which is a valid frequency for the timing of program and erase functions.”

Changed text to read “Consider the follwoing example for f

= 66 MHz.” 6.4.3.1/6-18

SYS

Added “Page erase verify” category. Table 6-12/6-16

Added “Page erase verify” category and description. Table 6-13/6-20

Added “Access error” row. Table 6-14/6-25

Moved information in Section 8.4.6, “DMA Request Control Register,” to Section 16.2, “DMA Request Control (DMAREQC).”

Chapter 8 and

16.2/16-3

Changed offset for the copy of RAMBAR to “0x008.” Figure 8-2/8-5

Changed CWTIC to CWTIF. Table 8-5/8-8

Changed text to read “Setting MPARK[PRK_LAST] causes the arbitration

8.5.2.1/8-11 pointer to be parked on the highest priority master.”

Changed “÷ MFD (2–9)” to “÷ MFD (4–18).” Figure 9-2/9-4

Changed equation in “Normal PLL Clock Mode” row to the following:

= f

sys

ref

× 2(MFD + 2)/2

RFD

Table 9-7/9-11

Eliminated Section 12.4.1.4, “Code Example.” Chapter 12

In “Reset: CSCR0” row, changed “D7, D6, D5” to “—, D19, D18.” Figure 12-4/12-8

Replaced “SCKE

Changed text to read “The transmit FIFO uses addresses from the start of the

” with “SCKE.” Table 14-1/14-3

17.5.4.20/17-42 FIFO to the location four bytes before the address programmed into the FRSR.”

Added the following footnote: “The receive buffer pointer, which contains the

Table 17-36/17-48 address of the associated data buffer, must always be evenly divisible by 16. The buffer must reside in memory external to the FEC. This value is never modified by the Ethernet controller.”

Added the following footnote: “The transmit buffer pointer, which contains

Table 17-37/17-50 the address of the associated data buffer, must always be evenly divisible by

4. The buffer must reside in memory external to the FEC. This value is never modified by the Ethernet controller.”

MOTOROLA About This Book liii

Revision History

Table iii. Revision History

Revision

Number

Date of

Release

Substantive Changes Section/Page

Changed value in “Divide by” block to 8192. Figure 18-1/18-2

Multiplied all system clock divisor values in PRE field description by 2. Table 19-3/19-4

Changed equation in text to the following:

19.6.3/19-7

Timeout period = PRE[3:0] × (PM[15:0] + 1) × system clock ÷ 2

In “UISR Field” row, changed bit 6 to a reserved bit. Figure 23-12/23-14

Changed bit 6 to a reserved bit. Table 23-9/23-14

Changed equation in PRES_DIV field description to the following: Table 25-12/25-25

SYS

------------------------------------------= 2PRESDIV + 1()

30.6.2/30-10

Added “Note:

S-clock

When Flash security is enabled, the chip will boot in

single chip mode regardless of the external reset configuration.”

Changed equation in QPR field description to the following: Table 27-4/27-12

QCLK

Multiplied all f

divisor values in this table by 2. Table 27-5/27-13

SYS

Added “Note: Enabling Flash security will disable BDM communications.” 29.1/29-1

SYS

2(QPR[6:0] + 1)

Replaced “SCKE

Replaced “PEL2” with “PEL6, ” “PNQ6” with “PNQ7,” “PNQ5” with

” with “SCKE.” Figure 32-1/32-2

Table 32-1/32-3 “PNQ6,” “PEL5” with “PEL1,” “PNQ4” with “PNQ5,” “PNQ3” with “PNQ4,” “PNQ2” with “PNQ3,” “PNQ1” with “PNQ2,” “PNQ0” with “PNQ1,” “PQS0” with “PQS1,” “PQS1” with “PQS0,” “PJ6” with “PJ7,”

” with “SDRAM_CS0,” “RAS1” with “SDRAM_CS1,” and “SCKE”

“RAS0 with “SCKE.”

Changed value for “ESD Target for Human Body Model” to “2000” and

Table 33-1/33-1 “ESD Target for Machine Model” to “200.”

Changed value in “Maximum number of guaranteed program/erase cycles

Table 33-9/33-10

before failure” row to “10,000.”

Changed the max value in specs B6a–B6c to “0.5t

Changed the min value in spec B7a to “0.5t

CYC

in Figure 33-2, Figure 33-3, and Figure 33-4.

+ 10.” Table 33-11/33-11

CYC

+ 2” and reflected the change

Table 33-11/33-11 Figure 33-2/33-13 Figure 33-3/33-14 Figure 33-4/33-15

Changed the min value in spec D8 to “2” and the max value to”'—”. Table 33-12/33-16

Changed the max value in spec G1a to “12.” Table 33-13/33-17

Added the following footnote: “Because of long delays associated with the

Table 33-13/33-17 PQA/PQB pads, signals on the PQA/PQB pins will be updated on the following edge of the clock.”

Added timing diagrams and tables to Section 33.12, “Fast Ethernet AC

33.12/33-20

Timing Specifications.”

Changed the max value in spec 1 to “1/4.” Table 33-23/33-25

liv MCF5282 User’s Manual MOTOROLA

Table iii. Revision History

Revision History

Revision

Number

2 1/2004 Added MCF5281 device to manual. The MCF5281 implements half the Flash

Date of

Release

Substantive Changes Section/Page

Changed the min value in spec 2 to “4.” Table 33-23/33-25

Changed the min value in spec 3 to “25.” Table 33-23/33-25

Changed the min value in spec 6 to “25.” Table 33-23/33-25

Changed the max value in spec 7 to “30.” Table 33-23/33-25

Changed the max value in spec 8 to “30.” Table 33-23/33-25

Changed the max value in spec 11 to “25.” Table 33-23/33-25

Changed the min value in spec D1 to “5.” Table 33-24/33-27

Changed the min value in spec D2 to “2.” Table 33-24/33-27

Changed offset for the copy of RAMBAR to “0x008.” Table A-3/A-3

of the MCF5282.

Changed the description of real time debug support. It has only one user-visible hardware breakpoint register.

Change the I field description to read: “Interrupt level mask. Defines the current interrupt level. Interrupt requests are inhibited for all priority levels less than or equal to the current level, except the edge-sensitive level 7 request, which cannot be masked.”

Throughout Manual

1.1/1-1

Table 2-2/2-6

Replaced the description of PRI1 and PRI2. Table 5-1/5-2

Added note to the SPV bit description, “The BDE bit in the second RAMBAR register must also be set to allow dual port access to the SRAM. For more information, see Section 8.4.2, ‘Memory Base Address Register (RAMBAR).’”

Replaced Figure 6-2, “CFM 512K Array Memory Map” and renamed it “CFM Array Memory Map”

Change value for page erase verify command to 0x06. Table 6-12/6-16

Change value for page erase verify command to 0x06. Table 6-13/6-20

Add the following note to the BDE bit description: “The SPV bit in the CPU’s RAMBAR must also be set to allow dual port access to the SRAM. For more information, see Section 5.3.1, ‘SRAM Base Address Register (RAMBAR).’”

Remove ÷ 2 from CLKGEN block. Figure 9-1/9-3

Add this text to the end of the first paragraph: “If a specific interrupt request is completely unused, the ICRnx value can remain in its reset (and disabled) state.”

Added the following note: “The wakeup mask level taken from LPICR[6:4] is adjusted by hardware to allow a level 7 IRQ to generate a wakeup. That is, the wakeup mask value used by the interrupt controller must be in the range of 0–6.”

Changed CSCRn to reflect that AA is set at reset. Figure 12-4/12-8

Table 5-1/5-2

Figure 6-2/6-4

Table 8-3/8-5

10.3.6/10-11

10.5/10-17

Removed final paragraph. The paragraph incorrectly states that the MCF5282 does not have a bus monitor.

MOTOROLA About This Book lv

13.5/13-14

Revision History

Table iii. Revision History

Revision

Number

Date of

Release

Substantive Changes Section/Page

Changed pull-up indications in the ‘Internal Pull-Up’ column. Table 14-3/14-11

Change encodings for bits 31–9 to:

Table 17-13/17-26

0 The corresponding interrupt source is masked. 1 The corresponding interrupt source is not masked.

Change PIT1–PIT4 to PIT0–PIT3 throughout chapter. When a timer is

Chapter 19 referenced individually, PIT1 should be PIT0, PIT2 should be PIT1, PIT3 should be PIT2, and PIT4 should be PIT3. Other chapters in the user’s manual use the correct nomenclature: PIT0–PIT3.

Change timeout period equation to the equation below. 19.6.3/19-7

Timeout period

PRE[3:0] (PM[15:0] 1)+2××

-----------------------------------------------------------------------------= system clock

Change UISR bits 5–3 to reserved bits Figure 23-11/23-13

Change ‘I2CR = 0xA’ to ‘I2CR = 0xA0.’ 24.6.1/24-10

Changed ‘When interfacing to 16-bit ports, the port C and D pins and PJ[5:4] (BS

[1:0]) can be configured as general-purpose input/output (I/O)’

30.2.1/30-2

Added additional device number order information to Table 32-2 for

Table 32-2/32-7

MCF5280 and MCF5281 at 66- and 80-MHz, and MCF5282 at 80 MHz.

Delete references to ‘T

Replace V

row with the row below, in which the maximum value has been

= TL to TH’. Chapter 33

Table 33-1/33-1

changed to 6.0 V.

Replace I

row with the row below, in which the maximum value in

DDA

Table 33-6/33-7

normal operation has been changed to 5.0 mA.

Replaced Figure 33-5, “SDRAM Read Cycle” Figure 33-5/33-16

lvi MCF5282 User’s Manual MOTOROLA

Chapter 1 Overview

This chapter provides an overview of the MCF5282 microprocessor features, including the major functional components.

1.1 MCF5282 Key Features

A block diagram of the MCF5282 is shown in Figure 1-1. The main features are as follows:

• Static Version 2 ColdFire variable-length RISC processor

— Static operation

— On-chip 32-bit address and data path

— Processor core and bus frequency up to 80 MHz

— Sixteen general-purpose 32-bit data and address registers

— ColdFire ISA_A with extensions to support the user stack pointer register, and

four new instructions for improved bit processing

— Enhanced Multiply-Accumulate (EMAC) unit with four 48-bit accumulators to

support 32-bit signal processing algorithms

— Illegal instruction decode that allows for 68K emulation support

• System debug support

— Real-time trace for determining dynamic execution path

— Background debug mode (BDM) for in-circuit debugging

— Real time debug support, with one user-visible hardware breakpoint register (PC

and address with optional data) that can be configured into a 1- or 2-level trigger

• On-chip memories

— 2-Kbyte cache, configurable as instruction-only, data-only, or split I-/D-cache

— 64-Kbyte dual-ported SRAM on CPU internal bus, accessible by core and

non-core bus masters (e.g., DMA, FEC) with standby power supply support

— 512 Kbytes of interleaved Flash memory supporting 2-1-1-1 accesses

(256 Kbytes on the MCF5281)

– This product incorporates SuperFlash® technology licensed from SST.

MOTOROLA Chapter 1. Overview 1-1

MCF5282 Key Features

• Power management

— Fully-static operation with processor sleep and whole chip stop modes

— Very rapid response to interrupts from the low-power sleep mode (wake-up

feature)

— Clock enable/disable for each peripheral when not used

• Fast Ethernet Controller (FEC)

— 10BaseT capability, half- or full-duplex

— 100BaseT capability, half- or limited-throughput full-duplex

— On-chip transmit and receive FIFOs

— Built-in dedicated DMA controller

— Memory-based flexible descriptor rings

— Media-independent interface (MII) to transceiver (PHY)

• FlexCAN 2.0B Module

— Includes all existing features of the Motorola TOUCAN module

— Full implementation of the CAN protocol specification version 2.0B

– Standard data and remote frames (up to 109 bits long) – Extended data and remote frames (up to 127 bits long) – 0–8 bytes data length – Programmable bit rate up to 1 Mbit/sec

— Up to 16 message buffers (MBs)

– Configurable as receive (Rx) or transmit (Tx)

– Support standard and extended messages — Unused message buffer (MB) space can be used as general-purpose RAM space — Listen-only mode capability — Content-related addressing — No read/write semaphores — Three programmable mask registers

– Global (for MBs 0-13)

– Special for MB14

– Special for MB15 — Programmable transmit-first scheme: lowest ID or lowest buffer number — “Time stamp” based on 16-bit free-running timer — Global network time, synchronized by a specific message — Programmable I/O modes — Maskable interrupts

1-2 MCF5282 User’s Manual MOTOROLA

MCF5282 Key Features

• Three universal asynchronous/synchronous receiver transmitters (UARTs)

— 16-bit divider for clock generation

— Interrupt control logic

— Maskable interrupts

— DMA support

— Data formats can be 5, 6, 7, or 8 bits with even, odd, or no parity

— Up to 2 stop bits in 1/16 increments

— Error-detection capabilities

— Modem support includes request-to-send (URTS

) and clear-to-send (UCTS)

lines for two UARTs

— Transmit and receive FIFO buffers

C module

•I

— Interchip bus interface for EEPROMs, LCD controllers, A/D converters, and

keypads

— Fully compatible with industry-standard I

C bus

— Master or slave modes support multiple masters

— Automatic interrupt generation with programmable level

• Queued serial peripheral interface (QSPI)

— Full-duplex, three-wire synchronous transfers

— Up to four chip selects available

— Master mode operation only

— Programmable master bit rates

— Up to 16 pre-programmed transfers

• Queued analog-to-digital converter (QADC)

— 8 direct, or up to 18 multiplexed, analog input channels

— 10-bit resolution +/- 2 counts accuracy — Minimum 7 µS conversion time

— Internal sample and hold

— Programmable input sample time for various source impedances

— Two conversion command queues with a total of 64 entries

— Sub-queues possible using pause mechanism

— Queue complete and pause software interrupts available on both queues

— Queue pointers indicate current location for each queue

MOTOROLA Chapter 1. Overview 1-3

MCF5282 Key Features

— Automated queue modes initiated by:

– External edge trigger and gated trigger

– Periodic/interval timer, within QADC module [Queue 1 and 2]

– Software command

— Single-scan or continuous-scan of queues

— Output data readable in three formats:

– Right-justified unsigned

– Left-justified signed

– Left-justified unsigned

— Unused analog channels can be used as digital I/O

— Low pin-count configuration implemented

• Four 32-bit DMA timers

— 15-ns resolution at 66 MHz

— Programmable sources for clock input, including an external clock option

— Programmable prescaler

— Input-capture capability with programmable trigger edge on input pin

— Output-compare with programmable mode for the output pin

— Free run and restart modes

— Maskable interrupts on input capture or reference-compare

— DMA trigger capability on input capture or reference-compare

• Two 4-channel general purpose timers

— Four 16-bit input capture/output compare channels per timer

— 16-bit architecture

— Programmable prescaler

— Pulse widths variable from microseconds to seconds

— Single 16-bit pulse accumulator

— Toggle-on-overflow feature for pulse-width modulator (PWM) generation

— One dual-mode pulse accumulation channel per timer

• Four periodic interrupt timers (PITs)

— 16-bit counter

— Selectable as free running or count down

• Software watchdog timer

— 16-bit counter

— Low-power mode support

1-4 MCF5282 User’s Manual MOTOROLA

MCF5282 Key Features

• Phase locked loop (PLL)

— Crystal or external oscillator reference

— 2- to 10-MHz reference frequency for normal PLL mode

— 33- to 66-MHz oscillator reference frequency for 1:1 mode

— Low-power modes supported

— Separate clock output pin

• Two interrupt controllers

— Support for up to 63 interrupt sources per interrupt controller (a total of 126),

organized as follows:

– 56 fully-programmable interrupt sources

– 7 fixed-level interrupt sources

— Seven external interrupt signals

— Unique vector number for each interrupt source

— Ability to mask any individual interrupt source or all interrupt sources (global

mask-all)

— Support for hardware and software interrupt acknowledge (IACK) cycles

— Combinatorial path to provide wake-up from low-power modes

• DMA controller

— Four fully programmable channels

— Dual-address transfer support with 8-, 16- and 32-bit data capability along with

support for 16-byte (4 x 32-bit) burst transfers

— Source/destination address pointers that can increment or remain constant

— 24-bit byte transfer counter per channel

— Auto-alignment transfers supported for efficient block movement

— Bursting and cycle steal support

— Software-programmable connections between the 11 DMA requesters in the

UARTs (3), 32-bit timers (4) plus external logic (4) and the four DMA channels

• External bus interface

— Glueless connections to external memory devices (e.g., SRAM, Flash, ROM,

etc.)

— SDRAM controller supports 8-, 16-, and 32-bit wide memory devices

— Glueless interface to SRAM devices with or without byte strobe inputs

— Programmable wait state generator

— 32-bit bidirectional data bus

— 24-bit address bus

MOTOROLA Chapter 1. Overview 1-5

MCF5282 Key Features

— Up to seven chip selects available

— Byte/write enables (byte strobes)

— Ability to boot from internal Flash memory or external memories that are 8, 16,

or 32 bits wide

•Reset

— Separate reset in and reset out signals

— Seven sources of reset:

– Power-on reset (POR)

– External

– Software

– Watchdog

– Loss of clock

– Loss of lock

– Low-voltage detection (LVD)

— Status flag indication of source of last reset

• Chip integration module (CIM)

— System configuration during reset

— Support for single chip, master, and test modes

— Selects one of four clock modes

— Sets boot device and its data port width

— Configures output pad drive strength

— Unique part identification number and part revision number

• General purpose I/O interface

— Up to 142 bits of general purpose I/O

— Coherent 32-bit control

— Bit manipulation supported via set/clear functions

— Unused peripheral pins may be used as extra GPIO

• JTAG support for system-level board testing

1-6 MCF5282 User’s Manual MOTOROLA

Chip

Configuration

Reset

Controller

External Interface

Module

Power

Management

Ports

Module

JTAG

Port

Debug Module

ColdFire V2 Core

Flash

Module

64K

SRAM

MCF5282 Key Features

Tes t

Controller

Chip

Selects

Edgeport

DRAM

Controller

Clock Module

(PLL)

Interrupt

Controller 0

Interrupt

Controller 1

UART0

Serial

I/O

UART1

Serial

I/O

UART2

Serial

I/O

DIV

D-Cache/I-Cache

Control

System

Module (SCM)

DMA Timer

Modules

(DTIM0–

DTIM3)

2-Kbyte

EMAC

Module

I2C

Internal Bus

Arbiter

Watchdog

Timer

DMA

Controller

FEC

MOTOROLA Chapter 1. Overview 1-7

General Purpose Timer A

General Purpose Timer B

QSPI FlexCANQADC

Figure 1-1. MCF5282 Block Diagram

PIT Timers (PIT0–

PIT3)

MCF5282 Key Features

1.1.1 Version 2 ColdFire Core

The processor core is comprised of two separate pipelines that are decoupled by an instruction buffer. The two-stage instruction fetch pipeline (IFP) is responsible for instruction-address generation and instruction fetch. The instruction buffer is a first-in-first-out (FIFO) buffer that holds prefetched instructions awaiting execution in the operand execution pipeline (OEP). The OEP includes two pipeline stages. The first stage decodes instructions and selects operands (DSOC); the second stage (AGEX) performs instruction execution and calculates operand effective addresses, if needed.

The V2 core implements the ColdFire instruction set architecture revision A with added support for a separate user stack pointer register and four new instructions to assist in bit processing. Additionally, the MCF5282 core includes the enhanced multiply-accumulate unit (EMAC) for improved signal processing capabilities. The EMAC implements a 4-stage execution pipeline, optimized for 32 x 32 bit operations, with support for four 48-bit accumulators. Supported operands include 16- and 32-bit signed and unsigned integers, signed fractional operands, and a complete set of instructions to process these data types. The EMAC provides superb support for execution of DSP operations within the context of a single processor at a minimal hardware cost.

1.1.1.1 Cache

The 2-Kbyte cache can be configured into one of three possible organizations: a 2-Kbyte instruction cache, a 2-Kbyte data cache or a split 1-Kbyte instruction/1-Kbyte data cache. The configuration is software-programmable by control bits within the privileged cache configuration register (CACR). In all configurations, the cache is a direct-mapped single-cycle memory, organized as 128 lines, each containing 16 bytes of data. The memories consist of a 128-entry tag array (containing addresses and control bits) and a 2-Kbyte data array, organized as 512 x 32 bits. The tag and data arrays are accessed in parallel using the following address bits:

Table 1-1. Cache Configuration

Configuration Tag Address Data Array Address

2 Kbyte I-Cache [10:4] [10:2]

2 Kbyte D-Cache [10:4] [10:2]

Split I-/D-Cache 0 Instruction Fetches Operand Accesses

If the desired address is mapped into the cache memory, the output of the data array is driven onto the ColdFire core's local data bus, completing the access in a single cycle. If the data is not mapped into the tag memory, a cache miss occurs and the processor core initiates a 16-byte line-sized fetch. The cache module includes a 16-byte line fill buffer used

0, [9:4] 1, [9:4]

0, [9:2] 1, [9:2]

1-8 MCF5282 User’s Manual MOTOROLA

MCF5282 Key Features

as temporary storage during miss processing. For all data cache configurations, the memory operates in write-through mode and all operand writes generate an external bus cycle.

1.1.1.2 SRAM

The SRAM module provides a general-purpose 64-Kbyte memory block that the ColdFire core can access in a single cycle. The location of the memory block can be set to any 64-Kbyte boundary within the 4-Gbyte address space. The memory is ideal for storing critical code or data structures, for use as the system stack, or for storing FEC data buffers. Because the SRAM module is physically connected to the processor's high-speed local bus, it can quickly service core-initiated accesses or memory-referencing commands from the debug module.

The SRAM module is also accessible by non-core bus masters, for example the DMA and/or the FEC. The dual-ported nature of the SRAM makes it ideal for implementing applications with double-buffer schemes, where the processor and a DMA device operate in alternate regions of the SRAM to maximize system performance. As an example, system performance can be increased significantly if Ethernet packets are moved from the FEC into the SRAM (rather than external memory) prior to any processing.

1.1.1.3 Flash

This product incorporates SuperFlash® technology licensed from SST. The ColdFire Flash Module (CFM) is a non-volatile memory (NVM) module for integration with the processor core. The CFM is constructed with eight banks of 32K x 16-bit Flash arrays to generate 512 Kbytes of 32-bit Flash memory

NOTE

The CFM on the MCF5281 is constructed with four banks of 32K x 16-bit Flash arrays to generate 256 Kbytes of 32-bit Flash memory.

These arrays serve as electrically erasable and programmable, non-volatile program and data memory. The Flash memory is ideal for program and data storage for single-chip applications allowing for field reprogramming without requiring an external programming voltage source. The CFM interfaces to the V2 ColdFire core through an optimized read-only memory controller which supports interleaved accesses from the 2-cycle Flash arrays. A “backdoor” mapping of the Flash memory is used for all program, erase, and verify operations. It also provides a read datapath for non-core masters (for example, DMA).

1.1.1.4 Debug Module

The ColdFire processor core debug interface is provided to support system debugging in conjunction with low-cost debug and emulator development tools. Through a standard

MOTOROLA Chapter 1. Overview 1-9

MCF5282 Key Features

debug interface, users can access real-time trace and debug information. This allows the processor and system to be debugged at full speed without the need for costly in-circuit emulators. The debug interface is a superset of the BDM interface provided on Motorola’s 683xx family of parts.

The on-chip breakpoint resources include a total of 6 programmable registers—a set of address registers (with two 32-bit registers), a set of data registers (with a 32-bit data register plus a 32-bit data mask register), and one 32-bit PC register plus a 32-bit PC mask register. These registers can be accessed through the dedicated debug serial communication channel or from the processor’s supervisor mode programming model. The breakpoint registers can be configured to generate triggers by combining the address, data, and PC conditions in a variety of single or dual-level definitions. The trigger event can be programmed to generate a processor halt or initiate a debug interrupt exception.

To support program trace, the Version 2 debug module provides processor status (PST[3:0]) and debug data (DDATA[3:0]) ports. These buses and the CLKOUT output provide execution status, captured operand data, and branch target addresses defining the dynamic execution path of the processor at the CPU’s clock rate.

1.1.2 System Control Module

This section details the functionality of the System Control Module (SCM) which provides the programming model for the System Access Control Unit (SACU), the system bus arbiter, a 32-bit Core Watchdog Timer (CWT), and the system control registers and logic. Specifically, the system control includes the internal peripheral system base address register (IPSBAR), the processor’s dual-port RAM base address register (RAMBAR), and system control registers that include low-power and core watchdog timer control.

1.1.3 External Interface Module (EIM)

The external interface module handles the transfer of information between the internal core and memory, peripherals, or other processing elements in the external address space.

Programmable chip-select outputs provide signals to enable external memory and peripheral circuits, providing all handshaking and timing signals for automatic wait-state insertion and data bus sizing.

Base memory address and block size are programmable, with some restrictions. For example, the starting address must be on a boundary that is a multiple of the block size. Each chip select can be configured to provide read and write enable signals suitable for use with most popular static RAMs and peripherals. Data bus width (8-bit, 16-bit, or 32-bit) is programmable on all chip selects, and further decoding is available for protection from user mode access or read-only access.

1-10 MCF5282 User’s Manual MOTOROLA

MCF5282 Key Features

1.1.4 Chip Select

Programmable chip select outputs provide a glueless connection to external memory and peripheral circuits, providing all handshaking and timing signals for automatic wait-state insertion and data bus sizing.

1.1.5 Power Management

The MCF5282 incorporates several low-power modes of operation which are entered under program control and exited by several external trigger events. An integrated Power-On Reset (POR) circuit monitors the input supply and forces an MCU reset as the supply voltage rises. The Low Voltage Detect (LVD) section monitors the supply voltage and is configurable to force a reset or interrupt condition if it falls below the LVD trip point. The RAM standby switch provides power to RAM when the supply voltage is higher than the standby voltage. If the supply voltage to chip falls below the standby battery voltage, the RAM is switched over to the standby supply.

1.1.6 General Input/Output Ports

All of the pins associated with the external bus interface may be used for several different functions. Their primary function is to provide an external memory interface to access off-chip resources. When not used for this function, all of the pins may be used as general-purpose digital I/O pins. In some cases, the pin function is set by the operating mode, and the alternate pin functions are not supported.

The digital I/O pins on the MCF5282 are grouped into 8-bit ports. Some ports do not use all eight bits. Each port has registers that configure, monitor, and control the port pins.

1.1.7 Interrupt Controllers (INTC0/INTC1)

There are two interrupt controllers on the MCF5282, each of which can support up to 63 interrupt sources for a total of 126. Each interrupt controller is organized as 7 levels with 9 interrupt sources per level. Each interrupt source has a unique interrupt vector, and 56 of the 63 sources of a given controller provide a programmable level [1-7] and priority within the level.

1.1.8 SDRAM Controller

The SDRAM controller provides all required signals for glueless interfacing to a variety of JEDEC-compliant SDRAM devices. SRAS/SCAS address multiplexing is software configurable for different page sizes. To maintain refresh capability without conflicting with concurrent accesses on the address and data buses, SRAS SDRAM_CS

[1:0], and SCKE are dedicated SDRAM signals.

, SCAS, DRAMW,

MOTOROLA Chapter 1. Overview 1-11

MCF5282 Key Features

1.1.9 Test Access Port

The MCF5282 supports circuit board test strategies based on the Test Technology Committee of IEEE and the Joint Test Action Group (JTAG). The test logic includes a test access port (TAP) consisting of a 16-state controller, an instruction register, and three test registers (a 1-bit bypass register, a 256-bit boundary-scan register, and a 32-bit ID register). The boundary scan register links the device’s pins into one shift register. Test logic, implemented using static logic design, is independent of the device system logic.

The MCF5282 implementation supports the following:

• Perform boundary-scan operations to test circuit board electrical continuity

• Sample

MCF5282 system pins during operation and transparently shift out the result

in the boundary scan register

• Bypass the MCF5282 for a given circuit board test by effectively reducing the boundary-scan register to a single bit

• Disable the output drive to pins during circuit-board testing

• Drive output pins to stable levels

1.1.10 UART Modules

The MCF5282 contains three full-duplex UARTs that function independently. The three UARTs can be clocked by the system clock, eliminating the need for an external crystal.

Each UART has the following features:

• Each can be clocked by the system clock, eliminating a need for an external UART clock

• Full-duplex asynchronous/synchronous receiver/transmitter channel

• Quadruple-buffered receiver

• Double-buffered transmitter

• Independently programmable receiver and transmitter clock sources

• Programmable data format: — 5–8 data bits plus parity — Odd, even, no parity, or force parity — One, one-and-a-half, or two stop bits

• Each channel programmable to normal (full-duplex), automatic echo, local loop-back, or remote loop-back mode

• Automatic wake-up mode for multidrop applications

• Four maskable interrupt conditions

• All three UARTs have DMA request capability

1-12 MCF5282 User’s Manual MOTOROLA

MCF5282 Key Features

• Parity, framing, and overrun error detection

• False-start bit detection

• Line-break detection and generation

• Detection of breaks originating in the middle of a character

• Start/end break interrupt/status

1.1.11 DMA Timers (DTIM0-DTIM3)

There are four independent, DMA-transfer-generating 32-bit timers (DTIM0, DTIM1, DTIM2, DTIM3) on the MCF5282. Each timer module incorporates a 32-bit timer with a separate register set for configuration and control. The timers can be configured to operate from the system clock or from an external clock source using one of the DTINx signals. If the system clock is selected, it can be divided by 16 or 1. The selected clock is further divided by a user-programmable 8-bit prescaler which clocks the actual timer counter register (TCRn). Each of these timers can be configured for input capture or reference compare mode. By configuring the internal registers, each timer may be configured to assert an external signal, generate an interrupt on a particular event, or cause a DMA transfer.

1.1.12 General-Purpose Timers (GPTA/GPTB)

The two general-purpose timers (GPTA and GPTB) are 4-channel timer modules. Each timer consists of a 16-bit programmable counter driven by a 7-stage programmable prescaler. Each of the four channels for each timer can be configured for input capture or output compare. Additionally, one of the channels, channel 3, can be configured as a pulse accumulator.

A timer overflow function allows software to extend the timing capability of the system beyond the 16-bit range of the counter. The input capture and output compare functions allow simultaneous input waveform measurements and output waveform generation. The input capture function can capture the time of a selected transition edge. The output compare function can generate output waveforms and timer software delays. The 16-bit pulse accumulator can operate as a simple event counter or a gated time accumulator.

1.1.13 Periodic Interrupt Timers (PIT0-PIT3)

The four periodic interrupt timers (PIT0, PIT1, PIT2, PIT3) are 16-bit timers that provide precise interrupts at regular intervals with minimal processor intervention. Each timer can either count down from the value written in its PIT modulus register, or it can be a free-running down-counter.

MOTOROLA Chapter 1. Overview 1-13

MCF5282 Key Features

1.1.14 Software Watchdog Timer

The watchdog timer is a 16-bit timer that facilitates recovery from runaway code. The watchdog counter is a free-running down-counter that generates a reset on underflow. To prevent a reset, software must periodically restart the countdown.

1.1.15 Phase Locked Loop (PLL)

The clock module contains a crystal oscillator (OSC), phase-locked loop (PLL), reduced frequency divider (RFD), status/control registers, and control logic. To improve noise immunity, the PLL and OSC have their own power supply inputs, VDDPLL and VSSPLL. All other circuits are powered by the normal supply pins, VDD and VSS.

1.1.16 DMA Controller

The Direct Memory Access (DMA) controller module provides an efficient way to move blocks of data with minimal processor interaction. The DMA module provides four channels (DMA0–DMA3) that allow byte, word, longword or 16-byte burst line transfers. These transfers are triggered by software, explicitly setting a DCRn[START] bit or the occurrence of a hardware event from one of the on-chip peripheral devices, such as a capture event or an output reference event in a DMA timer (DTIMn) for each channel. The DMA controller supports dual-address mode to on-chip devices.

1.1.17 Reset

The reset controller is provided to determine the cause of reset, assert the appropriate reset signals to the system, and keep track of what caused the last reset. The power management registers for the internal low-voltage detect (LVD) circuit are implemented in the reset module. There are seven sources of reset:

• External

• Power-on reset (POR)

• Watchdog timer

• Phase-locked loop (PLL) loss of lock

• PLL loss of clock

• Software

• Low-voltage detection (LVD) reset

External reset on the RSTO are also software-readable status flags indicating the cause of the last reset, and LVD control and status bits for setup and use of LVD reset or interrupt.

pin is software-assertable independent of chip reset state. There

1-14 MCF5282 User’s Manual MOTOROLA

MCF5282-Specific Features

1.2 MCF5282-Specific Features

1.2.1 Fast Ethernet Controller (FEC)

The MCF5282’s integrated Fast Ethernet Controller (FEC) performs the full set of IEEE

802.3/Ethernet CSMA/CD media access control and channel interface functions. The FEC supports connection and functionality for the 10/100 Mbps 802.3 media independent interface (MII). It requires an external transceiver (PHY) to complete the interface to the media.

1.2.2 FlexCAN

The FlexCAN module is a communication controller implementing the CAN protocol. The CAN protocol can be used as an industrial control serial data bus, meeting the specific requirements of real-time processing, reliable operation in a harsh EMI environment, cost-effectiveness, and required bandwidth. FlexCAN contains 16 message buffers.

1.2.3 I2C Bus

The I2C bus is a two-wire, bidirectional serial bus that provides a simple, efficient method of data exchange, minimizing the interconnection between devices. This bus is suitable for applications requiring occasional communications over a short distance between many devices.

1.2.4 Queued Serial Peripheral Interface (QSPI)

The queued serial peripheral interface module provides a synchronous serial peripheral interface with queued transfer capability. It allows up to 16 transfers to be queued at once, eliminating CPU intervention between transfers.

1.2.5 Queued Analog-to-Digital Converter (QADC)

The QADC is a 10-bit, unipolar, successive approximation converter. A maximum of 8 analog input channels can be supported using internal multiplexing. A maximum of 18 input channels can be supported in the internal/external multiplexed mode.

The QADC consists of an analog front-end and a digital control subsystem. The analog section includes input pins, an analog multiplexer, and sample and hold analog circuits. The analog conversion is performed by the digital-to-analog converter (DAC) resistor-capacitor array and a high-gain comparator.

The digital control section contains queue control logic to sequence the conversion process and interrupt generation logic. Also included are the periodic/interval timer, control and

MOTOROLA Chapter 1. Overview 1-15

MCF5282-Specific Features

status registers, the 64-entry conversion command word (CCW) table, and the 64-entry result table.

1-16 MCF5282 User’s Manual MOTOROLA

Chapter 2 ColdFire Core

This section describes the organization of the Version 2 (V2) ColdFire® processor core and an overview of the program-visible registers. For detailed information on instructions, see the ColdFire Family Programmer’s Reference Manual.

2.1 Processor Pipelines

Figure 2-1 is a block diagram showing the processor pipelines of a V2 ColdFire core.

Instruction

IAG

Address

Generation

Instruction Fetch Pipeline

Operand Execution Pipeline

DSOC

AGEX

Instruction

Fetch Cycle

FIFO

Instruction Buffer

Decode & Select,

Operand Fetch

Address

Generation,

Execute

Address [31:0]

read_data[31:0]

write_data[31:0]

Figure 2-1. ColdFire Processor Core Pipelines

MOTOROLA Chapter 2. ColdFire Core 2-1

Processor Register Description

The processor core is comprised of two separate pipelines that are decoupled by an instruction buffer.

The Instruction Fetch Pipeline (IFP) is a two-stage pipeline for prefetching instructions. The prefetched instruction stream is then gated into the two-stage Operand Execution Pipeline (OEP), which decodes the instruction, fetches the required operands and then executes the required function. Since the IFP and OEP pipelines are decoupled by an instruction buffer which serves as a FIFO queue, the IFP is able to prefetch instructions in advance of their actual use by the OEP thereby minimizing time stalled waiting for instructions.

The Instruction Fetch Pipeline consists of two stages with an instruction buffer stage:

• Instruction Address Generation (IAG Cycle)

• Instruction Fetch Cycle (IC Cycle)

• Instruction Buffer (IB Cycle)

When the instruction buffer is empty, opcodes are loaded directly from the IC cycle into the Operand Execution Pipeline. If the buffer is not empty, the IFP stores the contents of the fetch cycle in the FIFO queue until it is required by the OEP. In the Version 2 implementation, the instruction buffer contains three 32-bit longwords of storage.

The Operand Execution Pipeline is implemented in a two-stage pipeline featuring a traditional RISC datapath with a dual-read-ported register file (RGF) feeding an arithmetic/logic unit. In this design, the pipeline stages have multiple functions:

• Decode & Select/Operand Cycle (DSOC Cycle)

• Address Generation/Execute Cycle (AGEX Cycle)

2.2 Processor Register Description

The following paragraphs describe the processor registers in the user and supervisor programming models. The appropriate programming model is selected based on the privilege level (user mode or supervisor mode) of the processor as defined by the S bit of the status register (SR).

2.2.1 User Programming Model

Figure 2-2 illustrates the user programming model. The model is the same as the M68000 family microprocessors, consisting of the following registers:

• 16 general-purpose 32-bit registers (D0–D7, A0–A7)

• 32-bit program counter (PC)

• 8-bit condition code register (CCR)

2-2 MCF5282 User’s Manual MOTOROLA

Processor Register Description

2.2.1.1 Data Registers (D0–D7)

Registers D0–D7 are used as data registers for bit (1-bit), byte (8-bit), word (16-bit) and longword (32-bit) operations; they can also be used as index registers.

2.2.1.2 Address Registers (A0–A6)

These registers can be used as software stack pointers, index registers, or base address registers; they can also be used for word and longword operations.

2.2.1.3 Stack Pointer (A7)

Certain ColdFire implementations, including the MCF5282, support two unique stack pointer (A7) registers—the supervisor stack pointer (SSP) and the user stack pointer (USP). This support provides the required isolation between operating modes of the processor. The SSP is described in Section 2.2.3.2, “Supervisor/User Stack Pointers (A7 and OTHER_A7).”

A subroutine call saves the PC on the stack and the return restores it from the stack. Both the PC and the SR are saved on the supervisor stack during the processing of exceptions and interrupts. The return from exception (RTE) instruction restores the SR and PC values from the supervisor stack.

2.2.1.4 Program Counter (PC)

The PC contains the address of the currently executing instruction. During instruction execution and exception processing, the processor automatically increments the contents of the PC or places a new value in the PC, as appropriate. For some addressing modes, the PC is used as a base address for PC-relative operand addressing.

MOTOROLA Chapter 2. ColdFire Core 2-3

Processor Register Description

15 031

15 7 0

Figure 2-2. User Programming Model

2.2.1.5 Condition Code Register (CCR)

D1 D2 D3 D4 D5 D6 D7

A0 A1 A2 A3 A4 A5 A6

CCR

DATA REGISTERS

ADDRESS REGISTERS

USERSTACK POINTER

PROGRAM COUNTER

CONDITION CODE REGISTER

The CCR is the LSB of the processor status register (SR). Bits 4–0 act as indicator flags for results generated by processor operations. Bit 4, the extend bit (X bit), is also used as an input operand during multiprecision arithmetic computations.

43210

XNZVC

Figure 2-3. Condition Code Register (CCR)

Table 2-1. CCR Field Descriptions

Bits Name Description

4 X Extend condition code bit.

3 N Negative condition code bit. Set if the most significant bit of the result is set;

otherwise cleared.

2 Z Zero condition code bit. Set if the result equals zero; otherwise cleared.

1 V Overflow condition code bit. Set if an arithmetic overflow occurs implying that the

result cannot be represented in the operand size; otherwise cleared.

0 C Carry condition code bit. Set if a carry out of the operand msb occurs for an

addition, or if a borrow occurs in a subtraction; otherwise cleared Set to the value of the C bit for arithmetic operations; otherwise not affected.

2-4 MCF5282 User’s Manual MOTOROLA

Processor Register Description

2.2.2 EMAC Programming Model

The registers in the EMAC portion of the user programming model, are described in Section Chapter 5, “Enhanced Multiply-Accumulate Unit (EMAC),” and include the following registers:

• Four 48-bit accumulator registers partitioned as follows:

— Four 32-bit accumulators (ACC0–ACC3) — Eight 8-bit accumulator extension bytes (two per accumulator). These are

grouped into two 32-bit values for load and store operations (ACCEXT01 and ACCEXT23).

Accumulators and extension bytes can be loaded, copied, and stored, and results from EMAC arithmetic operations generally affect the entire 48-bit destination.

• Eight 8-bit accumulator extensions (two per accumulator), packaged as two 32-bit values for load and store operations (ACCext01 and ACCext23)

• One 16-bit mask register (MASK)

• One 32-bit status register (MACSR) including four indicator bits signaling product or accumulation overflow (one for each accumulator: PAV0–PAV3)

These registers are shown in Figure 2-4.

31 0

MACSR MAC status register ACC0 MAC accumulator 0 ACC1 MAC accumulator 1 ACC2 MAC accumulator 2 ACC3 MAC accumulator 3 ACCext01 Extensions for ACC0 and ACC1 ACCext23 Extensions for ACC2 and ACC3 MASK MAC mask register

Figure 2-4. EMAC Register Set

2.2.3 Supervisor Programming Model

Only system control software is intended to use the supervisor programming model to implement restricted operating system functions, I/O control, and memory management. All accesses that affect the control features of ColdFire processors are in the supervisor programming model, which consists of registers available in user mode as well as the following control registers:

• 16-bit status register (SR)

• 32-bit supervisor stack pointer (SSP)

• 32-bit vector base register (VBR)

• 32-bit cache control register (CACR)

MOTOROLA Chapter 2. ColdFire Core 2-5

Processor Register Description

• Two 32-bit access control registers (ACR0, ACR1)

• Two 32-bit memory base address registers (RAMBAR, FLASHBAR)

15 7 0

(CCR)

OTHER_A7

VBR

CACR

ACR0

ACR1

FLASHBAR

RAMBAR

STATUS

SUPERVISOR A7 STACK POINTER

VECTOR BASE REGISTER

CACHE CONTROL

ACCESS CONTROL

FLASH BASE ADDRESS REGISTER

RAM BASE ADDRESS REGISTER

Figure 2-5. Supervisor Programming Model

The following paragraphs describe the supervisor programming model registers.

2.2.3.1 Status Register (SR)

The SR stores the processor status and includes the CCR, the interrupt priority mask, and other control bits. In supervisor mode, software can access the entire SR. In user mode, only the lower 8 bits are accessible (CCR). The control bits indicate the following states for the processor: trace mode (T bit), supervisor or user mode (S bit), and master or interrupt state (M bit). All defined bits in the SR have read/write access when in supervisor mode.

System Byte Condition Code Register (CCR)

151413121110 876543210

T0SM0 I 000XNZVC

Figure 2-6. Status Register

Table 2-2. SR Field Descriptions

Bits Name Description

15 T Trace enable. When set, the processor performs a trace exception after

14 — Reserved, should be cleared.

13 S Supervisor/user state. Denotes whether the processor is in supervisor

2-6 MCF5282 User’s Manual MOTOROLA

every instruction.

mode (S = 1) or user mode (S = 0).

Processor Register Description

Table 2-2. SR Field Descriptions (continued)

Bits Name Description

12 M Master/interrupt state. This bit is cleared by an interrupt exception, and

can be set by software during execution of the RTE or move to SR instructions.

11 — Reserved, should be cleared.

10–8 I Interrupt level mask. Defines the current interrupt level. Interrupt

requests are inhibited for all priority levels less than or equal to the current level, except the edge-sensitive level 7 request, which cannot be masked.

7–5 — Reserved, should be cleared.

4–0 CCR Refer to Table 2-1.

2.2.3.2 Supervisor/User Stack Pointers (A7 and OTHER_A7)

The MCF5282 architecture supports two independent stack pointer (A7) registers—the supervisor stack pointer (SSP) and the user stack pointer (USP). The hardware implementation of these two programmable-visible 32-bit registers does not identify one as the SSP and the other as the USP. Instead, the hardware uses one 32-bit register as the active A7 and the other as OTHER_A7. Thus, the register contents are a function of the processor operation mode, as shown in the following:

if SR[S] = 1

then A7 = Supervisor Stack Pointer

OTHER_A7 = User Stack Pointer

else A7 = User Stack Pointer

OTHER_A7 = Supervisor Stack Pointer

The BDM programming model supports direct reads and writes to A7 and OTHER_A7. It is the responsibility of the external development system to determine, based on the setting of SR[S], the mapping of A7 and OTHER_A7 to the two program-visible definitions (SSP and USP). This functionality is enabled by setting the enable user stack pointer bit, CACR[EUSP]. If this bit is cleared, only the stack pointer (A7), defined for previous ColdFire versions, is available. EUSP is zero at reset.

If EUSP is set, the appropriate stack pointer register (SSP or USP) is accessed as a function of the processor’s operating mode. To support dual stack pointers, the following two privileged M68000 instructions are added to the ColdFire instruction set architecture to load/store the USP :

move.l Ay, USP; move to USP

move.l USP, Ax; move from USP

These instructions are described in the ColdFire Family Programmer’s Reference Manual.

MOTOROLA Chapter 2. ColdFire Core 2-7

Programming Model

2.2.3.3 Vector Base Register (VBR)

The VBR contains the base address of the exception vector table in memory. To access the vector table, the displacement of an exception vector is added to the value in VBR. The lower 20 bits of the VBR are not implemented by ColdFire processors; they are assumed to be zero, forcing the table to be aligned on a 1 MByte boundary.

2.2.3.4 Cache Control Register (CACR)

The CACR controls operation of the instruction/data cache memories. It includes bits for enabling, freezing, and invalidating cache contents. It also includes bits for defining the default cache mode and write-protect fields. The CACR is described in Section 4.4.2.1, “Cache Control Register (CACR).”

2.2.3.5 Access Control Registers (ACR0, ACR1)

The access control registers, ACR0 and ACR1, define attributes for two user-defined memory regions. These attributes include the definition of cache mode, write protect, and buffer write enables. The ACRs are described in Section 4.4.2.2, “Access Control Registers (ACR0, ACR1).”

2.2.3.6 Memory Base Address Registers (RAMBAR, FLASHBAR)

Memory base address registers are used to specify the base address of the internal SRAM and Flash modules and indicate the types of references mapped to each. Each base address register includes a base address, write-protect bit, address space mask bits, and an enable bit. For the MCF5282, FLASHBAR determines the base address of the on-chip Flash, and RAMBAR determines the base address of the on-chip RAM. For more information, refer to Section 5.3.1, “SRAM Base Address Register (RAMBAR)” and Section 6.3.2, “Flash Base Address Register (FLASHBAR).”

2.3 Programming Model

Table 2-3 lists register names, the CPU space location, and whether the register is written from the processor using the MOVEC instruction.

Table 2-3. ColdFire CPU Registers

Name CPU Space (Rc)

Memory Management Control Registers

CACR 0x002 Yes Cache control register

Written with

MOVEC

ACR0, ACR1 0x004-0x005 Yes Access control registers 0 and 1

2-8 MCF5282 User’s Manual MOTOROLA

Processor General-Purpose Registers

Additions to the Instruction Set Architecture

Table 2-3. ColdFire CPU Registers (continued)

Name CPU Space (Rc)

D0-D7 0x(0,1)80-0x(0,1)87 No Data registers 0-7 (0 = load, 1 = store)

A0-A7 0x(0,1)88-0x(0,1)8F No Address registers 0-7 (0 = load, 1 = store)

Processor Miscellaneous Registers

OTHER_A7 0x800 No Other stack pointer

VBR 0x801 Yes Vector base register

MACSR 0x804 No MAC status register

MASK 0x805 No MAC address mask register

ACC0-ACC3 0x806, 0x809,

0x80A, 0x80B

ACCext01 0x807 No MAC accumulator 0, 1 extension bytes

ACCext23 0x808 No MAC accumulator 2, 3 extension bytes

SR 0x80E No Status register

PC 0x80F Yes Program counter

Written with

MOVEC

A7 is user stack pointer

No MAC accumulators 0-3

Local Memory Registers

FLASHBAR 0xC04 Yes Flash base address register

RAMBAR 0xC05 Yes SRAM base address register

2.4 Additions to the Instruction Set Architecture

The original ColdFire instruction set architecture (ISA) was derived from the M68000-family opcodes based on extensive analysis of embedded application code. After the initial ColdFire compilers were created, developers identified ISA additions that would enhance both code density and overall performance. Additionally, as users implemented ColdFire-based designs into a wide range of embedded systems, they identified frequently used instruction sequences that could be improved by the creation of new instructions. This observation was especially prevalent in development environments that made use of substantial amounts of assembly language code.

Table 2-4 summarizes the new instructions added to Revision A+ ISA. For more details see Section 2.14, “ColdFire Instruction Set Architecture Enhancements.”

MOTOROLA Chapter 2. ColdFire Core 2-9

Exception Processing Overview

Table 2-4. ISA Revision A+ New Instructions

Instruction Description

BITREV The contents of the destination data register are bit-reversed; that

is, new Dx[31] = old Dx[0], new Dx[30] = old Dx[1], ..., new Dx[0] = old Dx[31].

BYTEREV The contents of the destination data register are byte-reversed;

that is, new Dx[31:24] = old Dx[7:0], ..., new Dx[7:0] = old Dx[31:24].

FF1 The data register, Dx, is scanned, beginning from the

most-significant bit (Dx[31]) and ending with the least-significant bit (Dx[0]), searching for the first set bit. The data register is then loaded with the offset count from bit 31 where the first set bit appears.

STLDSR Pushes the contents of the Status Register onto the stack and

then reloads the Status Register with the immediate data value.

2.5 Exception Processing Overview

Exception processing for ColdFire processors is streamlined for performance. The ColdFire processors differ from the M68000 family in that they include:

• A simplified exception vector table

• Reduced relocation capabilities using the vector base register

• A single exception stack frame format

• Use of a single self-aligning system stack

All ColdFire processors use an instruction restart exception model, but certain microarchitectures (V2 and V3) require more software support to recover from certain access errors. See Section 2.7.1, “Access Error Exception” for details.

Exception processing includes all actions from the detection of the fault condition to the initiation of fetch for the first handler instruction. Exception processing is comprised of four major steps

First, the processor makes an internal copy of the SR and then enters supervisor mode by asserting the S bit and disabling trace mode by negating the T bit. The occurrence of an interrupt exception also forces the M bit to be cleared and the interrupt priority mask to be set to the level of the current interrupt request.

Second, the processor determines the exception vector number. For all faults except interrupts, the processor performs this calculation based on the exception type. For interrupts, the processor performs an interrupt-acknowledge (IACK) bus cycle to obtain the vector number from the interrupt controller. The IACK cycle is mapped to a special acknowledge address space with the interrupt level encoded in the address.

2-10 MCF5282 User’s Manual MOTOROLA

Exception Processing Overview

Third, the processor saves the current context by creating an exception stack frame on the supervisor system stack. As a result, the exception stack frame is created at a 0-modulo-4 address on the top of the current system stack. Additionally, the processor uses a simplified fixed-length stack frame for all exceptions. The exception type determines whether the program counter placed in the exception stack frame defines the location of the faulting instruction (fault) or the address of the next instruction to be executed (next).

Fourth, the processor calculates the address of the first instruction of the exception handler. By definition, the exception vector table is aligned on a 1 Mbyte boundary. This instruction address is generated by fetching an exception vector from the table located at the address defined in the vector base register. The index into the exception table is calculated as (4 x vector number). Once the exception vector has been fetched, the contents of the vector determine the address of the first instruction of the desired handler. After the instruction fetch for the first opcode of the handler has been initiated, exception processing terminates and normal instruction processing continues in the handler.

All ColdFire processors support a 1024-byte vector table aligned on any 1 Mbyte address boundary (see Table 2-5). The table contains 256 exception vectors; the first 64 are defined by Motorola and the remaining 192 are user-defined interrupt vectors.

Table 2-5. Exception Vector Assignments

Vec to r

Number(S)

0 0x000 — Initial stack pointer

1 0x004 — Initial program counter

2 0x008 Fault Access error

3 0x00C Fault Address error

4 0x010 Fault Illegal instruction

5 0x014 Fault Divide by zero

6–7 0x018–0x01C — Reserved

8 0x020 Fault Privilege violation

9 0x024 Next Trace

10 0x028 Fault Unimplemented line-a opcode

11 0x02C Fault Unimplemented line-f opcode

12 0x030 Next Debug interrupt

13 0x034 — Reserved

14 0x038 Fault Format error

15–23 0x03C–0x05C — Reserved

24 0x060 Next Spurious interrupt

25–31 0x064-0x07C — Reserved

32–47 0x080–0x0BC Next Trap # 0-15 instructions

48–63 0x0C0–0x0FC — Reserved

Vec to r

Offset (Hex)

Stacked

Program

Counter

Assignment

MOTOROLA Chapter 2. ColdFire Core 2-11

Exception Stack Frame Definition

Table 2-5. Exception Vector Assignments (continued)

Vec to r

Number(S)

64–255 0x100–0x3FC Next User-defined interrupts

“Fault” refers to the PC of the instruction that caused the exception; “Next” refers to the PC

of the next instruction that follows the instruction that caused the fault.

Vec to r

Offset (Hex)

Stacked

Program

Counter

Assignment

All ColdFire processors inhibit interrupt sampling during the first instruction of all exception handlers. This allows any handler to effectively disable interrupts, if necessary, by raising the interrupt mask level contained in the status register. In addition, the V2 core includes a new instruction (STLDSR) that stores the current interrupt mask level and loads a value into the SR. This instruction is specifically intended for use as the first instruction of an interrupt service routine which services multiple interrupt requests with different interrupt levels. For more details see Section 2.14, “ColdFire Instruction Set Architecture Enhancements.”

2.6 Exception Stack Frame Definition

The exception stack frame is shown in Figure 2-7. The first longword of the exception stack frame contains the 16-bit format/vector word (F/V) and the 16-bit status register, and the second longword contains the 32-bit program counter address.

SSP

FORMAT FS[3:2] VECTOR[7:0] FS[1:0 ] STATUS REGISTER

+ 0X4

PROGRAM COUNTER[31:0]

Figure 2-7. Exception Stack Frame Form

The 16-bit format/vector word contains 3 unique fields:

• A 4-bit format field at the top of the system stack is always written with a value of 4, 5, 6, or 7 by the processor indicating a two-longword frame format. See Table 2-6.

Table 2-6. Format Field Encodings

Original SSP @ Time

of Exception, Bits 1:0

00 Original SSP - 8 4

01 Original SSP - 9 5

10 Original SSP - 10 6

11 Original SSP - 11 7

SSP @ 1st Instruction

of Handler

Format Field

2-12 MCF5282 User’s Manual MOTOROLA

Processor Exceptions

• There is a 4-bit fault status field, FS[3:0], at the top of the system stack. This field is defined for access and address errors only and written as zeros for all other types of exceptions. See Table 2-7.

Table 2-7. Fault Status Encodings

FS[3:0] Definition

00xx Reserved

0100 Error on instruction fetch

0101 Reserved

011x Reserved

1000 Error on operand write

1001 Attempted write to write-protected space

101x Reserved

1100 Error on operand read

1101 Reserved

111x Rese rved

• The 8-bit vector number, vector[7:0], defines the exception type and is calculated by the processor for all internal faults and represents the value supplied by the interrupt controller in the case of an interrupt. Refer to Table 2-5.

2.7 Processor Exceptions

2.7.1 Access Error Exception

The exact processor response to an access error depends on the type of memory reference being performed. For an instruction fetch, the processor postpones the error reporting until the faulted reference is needed by an instruction for execution. Therefore, faults that occur during instruction prefetches that are then followed by a change of instruction flow do not generate an exception. When the processor attempts to execute an instruction with a faulted opword and/or extension words, the access error is signaled and the instruction aborted. For this type of exception, the programming model has not been altered by the instruction generating the access error.

If the access error occurs on an operand read, the processor immediately aborts the current instruction’s execution and initiates exception processing. In this situation, any address register updates attributable to the auto-addressing modes, (for example, (An)+,-(An)), have already been performed, so the programming model contains the updated An value. In addition, if an access error occurs during the execution of a MOVEM instruction loading from memory, any registers already updated before the fault occurs contain the operands from memory.

MOTOROLA Chapter 2. ColdFire Core 2-13

Processor Exceptions

The V2 ColdFire processor uses an imprecise reporting mechanism for access errors on operand writes. Because the actual write cycle may be decoupled from the processor’s issuing of the operation, the signaling of an access error appears to be decoupled from the instruction that generated the write. Accordingly, the PC contained in the exception stack frame merely represents the location in the program when the access error was signaled. All programming model updates associated with the write instruction are completed. The NOP instruction can collect access errors for writes. This instruction delays its execution until all previous operations, including all pending write operations, are complete. If any previous write terminates with an access error, it is guaranteed to be reported on the NOP instruction.

2.7.2 Address Error Exception

Any attempted execution transferring control to an odd instruction address (that is, if bit 0 of the target address is set) results in an address error exception.

Any attempted use of a word-sized index register (Xn.w) or a scale factor of 8 on an indexed effective addressing mode generates an address error as does an attempted execution of a full-format indexed addressing mode.

2.7.3 Illegal Instruction Exception

Any attempted execution of an illegal 16-bit opcode (except for line-A and line-F opcodes) generates an illegal instruction exception (vector 4). Additionally, any attempted execution of any non-MAC line-A and most line-F opcode generates their unique exception types, vector numbers 10 and 11, respectively. The V2 core does not provide illegal instruction detection on the extension words on any instruction, including MOVEC.

2.7.4 Divide-By-Zero

Attempting to divide by zero causes an exception (vector 5, offset = 0x014).

2.7.5 Privilege Violation

The attempted execution of a supervisor mode instruction while in user mode generates a privilege violation exception. See the ColdFire Programmer’s Reference Manual for lists of supervisor- and user-mode instructions.

2.7.6 Trace Exception

To aid in program development, all ColdFire processors provide an instruction-by-instruction tracing capability. While in trace mode, indicated by the assertion of the T-bit in the status register (SR[15] = 1), the completion of an instruction execution (for all but the STOP instruction) signals a trace exception. This functionality allows a debugger to monitor program execution.

2-14 MCF5282 User’s Manual MOTOROLA

Processor Exceptions

The STOP instruction has the following effects:

1. The instruction before the STOP executes and then generates a trace exception. In the exception stack frame, the PC points to the STOP opcode.

2. When the trace handler is exited, the STOP instruction is executed, loading the SR with the immediate operand from the instruction.

3. The processor then generates a trace exception. The PC in the exception stack frame points to the instruction after the STOP, and the SR reflects the value loaded in the previous step.

If the processor is not in trace mode and executes a STOP instruction where the immediate operand sets SR[T], hardware loads the SR and generates a trace exception. The PC in the exception stack frame points to the instruction after the STOP, and the SR reflects the value loaded in step 2.

Because ColdFire processors do not support any hardware stacking of multiple exceptions, it is the responsibility of the operating system to check for trace mode after processing other exception types. As an example, consider the execution of a TRAP instruction while in trace mode. The processor will initiate the TRAP exception and then pass control to the corresponding handler. If the system requires that a trace exception be processed, it is the responsibility of the TRAP exception handler to check for this condition (SR[15] in the exception stack frame asserted) and pass control to the trace handler before returning from the original exception.

2.7.7 Unimplemented Line-A Opcode

A line-A opcode is defined when bits 15-12 of the opword are 0b1010. This exception is generated by the attempted execution of an undefined line-A opcode.

2.7.8 Unimplemented Line-F Opcode

A line-F opcode is defined when bits 15-12 of the opword are 0b1111. This exception is generated by attempted execution of an undefined line-F opcode.

2.7.9 Debug Interrupt

This special type of program interrupt is discussed in detail in Chapter 29, “Debug Support.” This exception is generated in response to a hardware breakpoint register trigger. The processor does not generate an IACK cycle but rather calculates the vector number internally (vector number 12).

MOTOROLA Chapter 2. ColdFire Core 2-15

Processor Exceptions

2.7.10 RTE and Format Error Exception

When an RTE instruction is executed, the processor first examines the 4-bit format field to validate the frame type. For a ColdFire core, any attempted RTE execution where the format is not equal to {4,5,6,7} generates a format error. The exception stack frame for the format error is created without disturbing the original RTE frame and the stacked PC pointing to the RTE instruction.

The selection of the format value provides some limited debug support for porting code from M68000 applications. On M68000 family processors, the SR was located at the top of the stack. On those processors, bit 30 of the longword addressed by the system stack pointer is typically zero. Thus, if an RTE is attempted using this “old” format, it generates a format error on a ColdFire processor.

If the format field defines a valid type, the processor: (1) reloads the SR operand, (2) fetches the second longword operand, (3) adjusts the stack pointer by adding the format value to the auto-incremented address after the fetch of the first longword, and then (4) transfers control to the instruction address defined by the second longword operand within the stack frame.

2.7.11 TRAP Instruction Exception

The TRAP #n instruction always forces an exception as part of its execution and is useful for implementing system calls.

2.7.12 Interrupt Exception

Interrupt exception processing includes interrupt recognition and the fetch of the appropriate vector from the interrupt controller using an IACK cycle. See Chapter 10, “Interrupt Controller Modules” for details on the interrupt controller.

2.7.13 Fault-on-Fault Halt

If a ColdFire processor encounters any type of fault during the exception processing of another fault, the processor immediately halts execution with the catastrophic “fault-on-fault” condition. A reset is required to force the processor to exit this halted state.

2.7.14 Reset Exception

Asserting the reset input signal to the processor causes a reset exception. The reset exception has the highest priority of any exception; it provides for system initialization and recovery from catastrophic failure. Reset also aborts any processing in progress when the reset input is recognized. Processing cannot be recovered.

2-16 MCF5282 User’s Manual MOTOROLA

Processor Exceptions

The reset exception places the processor in the supervisor mode by setting the S-bit and disables tracing by clearing the T bit in the SR. This exception also clears the M-bit and sets the processor’s interrupt priority mask in the SR to the highest level (level 7). Next, the VBR is initialized to zero (0x00000000). The control registers specifying the operation of any memories (e.g., cache and/or RAM modules) connected directly to the processor are disabled.

NOTE

Other implementation-specific supervisor registers are also affected. Refer to each of the modules in this user’s manual for details on these registers.

Once the processor is granted the bus, it then performs two longword read bus cycles. The first longword at address 0 is loaded into the stack pointer and the second longword at address 4 is loaded into the program counter. After the initial instruction is fetched from memory, program execution begins at the address in the PC. If an access error or address error occurs before the first instruction is executed, the processor enters the fault-on-fault halted state.

ColdFire processors load hardware configuration information into the D0 and D1 general-purpose registers after system reset. The hardware configuration information is loaded immediately after the reset-in signal is negated. This allows an emulator to read out the contents of these registers via BDM to determine the hardware configuration.

Information loaded into D0 defines the processor hardware configuration as shown in Figure 2-8.

31 24 23 20 19 16

Field PF VER REV

Reset 1100_1111_0010_0000

R/W R

15 14 13 12 11 10 8 7 4 3 0

Field MAC DIV EMAC FPU MMU — ISA DEBUG

Reset 0110_0000_1000_0000

R/W R

Figure 2-8. D0 Hardware Configuration Info

MOTOROLA Chapter 2. ColdFire Core 2-17

Processor Exceptions

Table 2-8. D0 Hardware Configuration Info Field Description

Bits Name Description

31–24 PF Processor family. This field is fixed to a hex value of 0xCF indicating a ColdFire core is present.

23–20 VER ColdFire core version number. This field is fixed to a hex value of 0x2 indicating a Version 2 ColdFire

core.

19–16 REV Processor revision number.

15 MAC MAC execute engine status. Indicates if optional MAC unit is present.

0 MAC execute engine not present in core. (This is the value used for MCF5282.) 1 MAC execute engine is present in core.

14 DIV Divide execute engine status. Indicates if optional hardware divide unit is present.

0 Divide execute engine not present in core. 1 Divide execute engine is present in core. (This is the value used for MCF5282.)

13 EMAC EMAC execute engine status. Indicates if optional enhanced MAC unit is present.

0 EMAC execute engine not present in core. 1 EMAC execute engine is present in core. (This is the value used for MCF5282.)

12 FPU FPU execute engine status. Indicates if optional FPU unit is present.

0 FPU execute engine not present in core. (This is the value used for MCF5282) 1 FPU execute engine is present in core.

11 MMU Virtual memory management unit status. Indicates if optional MMU unit is present.

0 MMU execute engine not present in core. (This is the value used for MCF5282) 1 MMU execute engine is present in core.

10–8 — Reserved.

7–4 ISA Instruction set architecture (ISA) revision number.

0000 ISA_A 0001 ISA_B 0010 ISA_C 1000 ISA_A+ (ISA_A with the addition of the BYTEREV, BITREV, FF1, and STLDSR instructions.

This is the value used for MCF5282.)

0x3-0xF Reserved.

3–0 DEBUG Debug module revision number.

0000 DEBUG_A (This is the value used for MCF5282) 0001 DEBUG_B 0010 DEBUG_C 0011 DEBUG_D 0100 DEBUG_E 0x5-0xF Reserved.

Information loaded into D1 defines the local memory hardware configuration as shown in Figure 2-9.

2-18 MCF5282 User’s Manual MOTOROLA

Processor Exceptions

31 30 29 28 27 24 23 20 19 16

Field CL ICA ICSIZ RAM0SIZ ROM0SIZ

Reset 0001_0011_1011_0000

R/W R

15 14 13 12 11 8 7 4 3 0

Field BUSW DCA DCSIZ RAM1SIZ ROM1SIZ

Reset 0001_0000_1000_0000

R/W R

Figure 2-9. D1 Hardware Configuration Info

Table 2-9. D1 Local Memory Hardware Configuration

Information Field Description

Bits Name Description

31–30 CL Cache line size. This field is fixed to a hex value of 0x0 indicating a 16-byte cache line size.

29–28 ICA Instruction cache associativity.

00 Four-way. 01 Direct mapped. (This is the value used for MCF5282)

27–24 ICSIZ Instruction cache size.

0000 No instruction cache. 0001 512B instruction cache. 0010 1KB instruction cache. 0011 2KB instruction cache. (This is the value used for MCF5282) 0100 4KB instruction cache. 0101 8KB instruction cache. 0110 16KB instruction cache. 0111 32KB instruction cache. 1000 64KB instruction cache. 0x9–0xF Reserved.

MOTOROLA Chapter 2. ColdFire Core 2-19

Processor Exceptions

Table 2-9. D1 Local Memory Hardware Configuration

Information Field Description (continued)

Bits Name Description

23–20 RAM0SIZ RAM bank 0 size. The first RAM bank can be used for either SRAM or Flash. The first encodings

shown are used to indicate the size of a RAM bank, and the second set of encodings indicate the size for a Flash bank. On the MCF5282, RAM0 is associated with the on-chip Flash, so these bits use the Flash encodings.

RAM size encodings: 0x0–0x3 No RAM. 0100 4KB RAM. 0101 8KB RAM. 0110 16KB RAM. 0111 32KB RAM. 1000 64KB RAM. 1001 128KB RAM. 0xA–0xF Reserved.

Flash size encodings: 0x0–0x7 No Flash. 1000 64KB Flash. 1001 128KB Flash. 1010 256KB Flash. 1011 512KB Flash. (This is the value used for MCF5282) 0xC–0xF Reserved.

19–16 ROM0SIZ ROM bank 0 size.

0x0–0x3 No ROM. (This is the value used for MCF5282) 0100 4KB ROM. 0101 8KB ROM. 0110 16KB ROM. 0111 32KB ROM. 1000 64KB ROM. 1001 128KB ROM. 0xA–0xF Reserved.

15–14 BUSW Encoded bus data width.

00 32-bit data bus (only configuration currently in use).

13–12 DCA Data cache associativity.

00 Four-way. 01 Direct mapped. (This is the value used for MCF5282)

11–8 DCSIZ Data cache size.

0000 No data cache. (This is the value used for MCF5282) 0001 512B data cache. 0010 1KB data cache. 0011 2KB data cache. 0100 4KB data cache. 0101 8KB data cache. 0110 16KB data cache. 0111 32KB data cache. 1000 64KB data cache. 0x9–0xF Reserved.

2-20 MCF5282 User’s Manual MOTOROLA

Table 2-9. D1 Local Memory Hardware Configuration

Information Field Description (continued)

Bits Name Description

7–4 RAM1SIZ RAM bank 1size.

0x0–0x3 No RAM. 0100 4KB RAM. 0101 8KB RAM. 0110 16KB RAM. 0111 32KB RAM. 1000 64KB RAM. (This is the value used for MCF5282) 1001 128KB RAM. 0xA–0xF Reserved.

3–0 ROM1SIZ ROM bank 1size.

0x0–0x3 No ROM. (This is the value used for MCF5282) 0100 4KB ROM. 0101 8KB ROM. 0110 16KB ROM. 0111 32KB ROM. 1000 64KB ROM. 1001 128KB ROM. 0xA–0xF Reserved.

Instruction Execution Timing

2.8 Instruction Execution Timing

This section presents V2 processor instruction execution times in terms of processor core clock cycles. The number of operand references for each instruction is enclosed in parentheses following the number of processor clock cycles. Each timing entry is presented as C(R/W) where:

•C is the number of processor clock cycles, including all applicable operand fetches and writes, and all internal core cycles required to complete the instruction execution.

• R/W is the number of operand reads (R) and writes (W) required by the instruction. An operation performing a read-modify-write function is denoted as (1/1).

This section includes the assumptions concerning the timing values and the execution time details.

2.8.1 Timing Assumptions

For the timing data presented in this section, the following assumptions apply:

1. The operand execution pipeline (OEP) is loaded with the opword and all required extension words at the beginning of each instruction execution. This implies that the OEP does not wait for the instruction fetch pipeline (IFP) to supply opwords and/or extension words.

MOTOROLA Chapter 2. ColdFire Core 2-21

Instruction Execution Timing

2. The OEP does not experience any sequence-related pipeline stalls. For V2 ColdFire processors, the most common example of this type of stall involves consecutive store operations, excluding the MOVEM instruction. For all STORE operations (except MOVEM), certain hardware resources within the processor are marked as “busy” for two processor clock cycles after the final DSOC cycle of the store instruction. If a subsequent STORE instruction is encountered within this 2-cycle window, it will be stalled until the resource again becomes available. Thus, the maximum pipeline stall involving consecutive STORE operations is 2 cycles. The MOVEM instruction uses a different set of resources and this stall does not apply.

3. The OEP completes all memory accesses without any stall conditions caused by the memory itself. Thus, the timing details provided in this section assume that an infinite zero-wait state memory is attached to the processor core.

4. All operand data accesses are aligned on the same byte boundary as the operand size: that is, 16 bit operands aligned on 0-modulo-2 addresses and 32 bit operands aligned on 0-modulo-4 addresses.

If the operand alignment fails these guidelines, it is misaligned. The processor core decomposes the misaligned operand reference into a series of aligned accesses as shown in Table 2-10.

Table 2-10. Misaligned Operand References

Address[1:0] Size

X1 Word Byte, Byte 2(1/0) if read

X1 Long Byte, Word, Byte 3(2/0) if read

10 Long Word, Word 2(1/0) if read

Kbus

Operations

Additional

C(R/W)

1(0/1) if write

2(0/2) if write

1(0/1) if write

2.8.2 MOVE Instruction Execution Times

The execution times for the MOVE.{B,W} instructions are shown in Table 2-11, while Table 2-12 provides the timing for MOVE.L.

For all tables in this section, the execution time of any instruction using the PC-relative effective addressing modes is the same for the comparable An-relative mode.

The nomenclature “xxx.wl” refers to both forms of absolute addressing, xxx.w and xxx.l.

2-22 MCF5282 User’s Manual MOTOROLA

Instruction Execution Timing

Table 2-11. Move Byte and Word Execution Times

Destination

Source

Rx (Ax) (Ax)+ -(Ax) (d16,Ax) (d8,Ax,Xi) (xxx).wl

Dn 1(0/0) 1(0/1) 1(0/1) 1(0/1) 1(0/1) 2(0/1) 1(0/1)

An 1(0/0) 1(0/1) 1(0/1) 1(0/1) 1(0/1) 2(0/1) 1(0/1)

(An) 3(1/0) 3(1/1) 3(1/1) 3(1/1) 3(1/1) 4(1/1) 3(1/1)

(An)+ 3(1/0) 3(1/1) 3(1/1) 3(1/1) 3(1/1) 4(1/1) 3(1/1)

-(An) 3(1/0) 3(1/1) 3(1/1) 3(1/1) 3(1/1) 4(1/1) 3(1/1)

,An) 3(1/0) 3(1/1) 3(1/1) 3(1/1) 3(1/1) — —

(d8,An,Xi) 4(1/0) 4(1/1) 4(1/1) 4(1/1) — — —

(xxx).w 3(1/0) 3(1/1) 3(1/1) 3(1/1) — — —

(xxx).l 3(1/0) 3(1/1) 3(1/1) 3(1/1) — — —

(d16,PC) 3(1/0) 3(1/1) 3(1/1) 3(1/1) 3(1/1) — —

(d8,PC,Xi) 4(1/0) 4(1/1) 4(1/1) 4(1/1) — — —

#<xxx> 1(0/0) 3(0/1) 3(0/1) 3(0/1) — — —

Table 2-12. Move Long Execution Times

Destination

Source

Rx (Ax) (Ax)+ -(Ax) (d

Dn 1(0/0) 1(0/1) 1(0/1) 1(0/1) 1(0/1) 2(0/1) 1(0/1)

An 1(0/0) 1(0/1) 1(0/1) 1(0/1) 1(0/1) 2(0/1) 1(0/1)

(An) 2(1/0) 2(1/1) 2(1/1) 2(1/1) 2(1/1) 3(1/1) 2(1/1)

(An)+ 2(1/0) 2(1/1) 2(1/1) 2(1/1) 2(1/1) 3(1/1) 2(1/1)

-(An) 2(1/0) 2(1/1) 2(1/1) 2(1/1) 2(1/1) 3(1/1) 2(1/1)

,An) 2(1/0) 2(1/1) 2(1/1) 2(1/1) 2(1/1) — —

,An,Xi) 3(1/0) 3(1/1) 3(1/1) 3(1/1) — — —

(xxx).w 2(1/0) 2(1/1) 2(1/1) 2(1/1) — — —

(xxx).l 2(1/0) 2(1/1) 2(1/1) 2(1/1) — — —

(d16,PC) 2(1/0) 2(1/1) 2(1/1) 2(1/1) 2(1/1) — —

(d8,PC,Xi) 3(1/0) 3(1/1) 3(1/1) 3(1/1) — — —

#<xxx> 1(0/0) 2(0/1) 2(0/1) 2(0/1) — — —

,Ax) (d8,Ax,Xi) (xxx).wl

MOTOROLA Chapter 2. ColdFire Core 2-23

Standard One Operand Instruction Execution Times

2.9 Standard One Operand Instruction Execution Times

Table 2-13. One Operand Instruction Execution Times

Effective Address

Opcode <EA>

Rn (An) (An)+ -(An) (d16,An) (d8,An,Xn*SF) xxx.wl #xxx

bitrevDx1(0/0)———— — ——

byterevDx1(0/0)———— — ——

clr.b <ea> 1(0/0) 1(0/1) 1(0/1) 1(0/1) 1(0/1) 2(0/1) 1(0/1) —

clr.w <ea> 1(0/0) 1(0/1) 1(0/1) 1(0/1) 1(0/1) 2(0/1) 1(0/1) —

clr.l <ea> 1(0/0) 1(0/1) 1(0/1) 1(0/1) 1(0/1) 2(0/1) 1(0/1) —

ext.wDx1(0/0)———— — ——

ext.lDx1(0/0)———— — ——

extb.lDx1(0/0)———— — ——

ff1Dx1(0/0)———— — ——

neg.lDx1(0/0)———— — ——

negx.l Dx 1(0/0) ———— — ——

not.lDx1(0/0)———— — ——

sccDx1(0/0)———— — ——

stldsr#imm————— — —5(0/1)

swapDx1(0/0)———— — ——

tst.b <ea> 1(0/0) 3(1/0) 3(1/0) 3(1/0) 3(1/0) 4(1/0) 3(1/0) 1(0/0)

tst.w <ea> 1(0/0) 3(1/0) 3(1/0) 3(1/0) 3(1/0) 4(1/0) 3(1/0) 1(0/0)

tst.l <ea> 1(0/0) 2(1/0) 2(1/0) 2(1/0) 2(1/0) 3(1/0) 2(1/0) 1(0/0)

2.10 Standard Two Operand Instruction Execution Times

Table 2-14. Two Operand Instruction Execution Times

Effective Address

Opcode <EA>

Rn (An) (An)+ -(An)

(d16,An) (d16,PC)

(d8,An,Xn*SF) (d8,PC,Xn*SF)

xxx.wl #xxx

add.l <ea>,Rx 1(0/0) 3(1/0) 3(1/0) 3(1/0) 3(1/0) 4(1/0) 3(1/0) 1(0/0)

add.l Dy,<ea> — 3(1/1) 3(1/1) 3(1/1) 3(1/1) 4(1/1) 3(1/1) —

addi.l #imm,Dx 1(0/0) — — — — — — —

addq.l #imm,<ea> 1(0/0) 3(1/1) 3(1/1) 3(1/1) 3(1/1) 4(1/1) 3(1/1) —

addx.l Dy,Dx 1(0/0) — — — — — — —

2-24 MCF5282 User’s Manual MOTOROLA

Standard Two Operand Instruction Execution Times

Table 2-14. Two Operand Instruction Execution Times (continued)

Effective Address

Opcode <EA>

Rn (An) (An)+ -(An)

and.l <ea>,Rx 1(0/0) 3(1/0) 3(1/0) 3(1/0) 3(1/0) 4(1/0) 3(1/0) 1(0/0)

and.l Dy,<ea> — 3(1/1) 3(1/1) 3(1/1) 3(1/1) 4(1/1) 3(1/1) —

andi.l #imm,Dx 1(0/0) — — — — — — —

asl.l <ea>,Dx 1(0/0) — — — — — — 1(0/0)

asr.l <ea>,Dx 1(0/0) — — — — — — 1(0/0)

bchg Dy,<ea> 2(0/0) 4(1/1) 4(1/1) 4(1/1) 4(1/1) 5(1/1) 4(1/1) —

bchg #imm,<ea> 2(0/0) 4(1/1) 4(1/1) 4(1/1) 4(1/1) — — —

bclr Dy,<ea> 2(0/0) 4(1/1) 4(1/1) 4(1/1) 4(1/1) 5(1/1) 4(1/1) —

bclr #imm,<ea> 2(0/0) 4(1/1) 4(1/1) 4(1/1) 4(1/1) — — —

bset Dy,<ea> 2(0/0) 4(1/1) 41/1) 4(1/1) 4(1/1) 5(1/1) 4(1/1) —

bset #imm,<ea> 2(0/0) 4(1/1) 4(1/1) 4(1/1) 4(1/1) — — —

btst Dy,<ea> 2(0/0) 3(1/1) 3(1/1) 3(1/1) 3(1/1) 4(1/1) 3(1/1) —

btst #imm,<ea> 1(0/0) 3(1/1) 3(1/1) 3(1/1) 3(1/1) — — 1(0/0)

cmp.l <ea>,Rx 1(0/0) 3(1/0) 3(1/0) 3(1/0) 3(1/0) 4(1/0) 3(1/0) 1(0/0)

cmpi.l #imm,Dx 1(0/0) — — — — — — —

divs.w

divu.w

divs.l

divu.l

<ea>,Dx 20(0/0) 23(1/0) 23(1/0) 23(1/0) 23(1/0) 24(1/0) 23(1/0) 20(0/0)

<ea>,Dx ≤35(0/0) ≤38(1/0) ≤38(1/0) ≤38(1/0) ≤38(1/0) — — —

eor.l Dy,<ea> 1(0/0) 3(1/1) 3(1/1) 3(1/1) 3(1/1) 4(1/1) 3(1/1) —

eori.l #imm,Dx 1(0/0) — — — — — — —

lea <ea>,Ax — 1(0/0) — — 1(0/0) 2(0/0) 1(0/0) —

lsl.l <ea>,Dx 1(0/0) — — — — — — 1(0/0)

lsr.l <ea>,Dx 1(0/0) — — — — — — 1(0/0)

moveq #imm,Dx — — — — — — — 1(0/0)

muls.w <ea>y, Dx 4(0/0) 6(1/0) 6(1/0) 6(1/0) 6(1/0) 7(1/0) 6(1/0) 4(1/0)

mulu.w <ea>y, Dx 4(0/0) 6(1/0) 6(1/0) 6(1/0) 6(1/0) 7(1/0) 6(1/0) 4(1/0)

muls.l <ea>y, Dx 4(0/0) 6(1/0) 6(1/0) 6(1/0) 6(1/0) — — —

mulu.l <ea>y, Dx 4(0/0) 6(1/0) 6(1/0) 6(1/0) 6(1/0) — — —

or.l <ea>,Rx 1(0/0) 3(1/0) 3(1/0) 3(1/0) 3(1/0) 4(1/0) 3(1/0) 1(0/0)

or.l Dy,<ea> — 3(1/1) 3(1/1) 3(1/1) 3(1/1) 4(1/1) 3(1/1) —

ori.l #imm,Dx 1(0/0) — — — — — — —

rems.l

remu.l

<ea>,Dx ≤35(0/0) ≤38(1/0) ≤38(1/0) ≤38(1/0) ≤38(1/0) — — —

sub.l <ea>,Rx 1(0/0) 3(1/0) 3(1/0) 3(1/0) 3(1/0) 4(1/0) 3(1/0) 1(0/0)

sub.l Dy,<ea> — 3(1/1) 3(1/1) 3(1/1) 3(1/1) 4(1/1) 3(1/1) —

(d16,An) (d16,PC)

(d8,An,Xn*SF) (d8,PC,Xn*SF)

xxx.wl #xxx

MOTOROLA Chapter 2. ColdFire Core 2-25

Miscellaneous Instruction Execution Times

Table 2-14. Two Operand Instruction Execution Times (continued)

Effective Address

Opcode <EA>

Rn (An) (An)+ -(An)

(d16,An) (d16,PC)

(d8,An,Xn*SF) (d8,PC,Xn*SF)

xxx.wl #xxx

subi.l #imm,Dx 1(0/0) — — — — — — —

subq.l #imm,<ea> 1(0/0) 3(1/1) 3(1/1) 3(1/1) 3(1/1) 4(1/1) 3(1/1) —

subx.l Dy,Dx 1(0/0) — — — — — — —

For divide and remainder instructions the times listed represent the worst-case timing. Depending on the operand values, the actual execution time may be less.

2.11 Miscellaneous Instruction Execution Times

Table 2-15. Miscellaneous Instruction Execution Times

Opcode <EA>

Effective Address

Rn (An) (An)+ -(An) (d16,An) (d8,An,Xn*SF) xxx.wl #xxx

link.wAy,#imm2(0/1)———— — ——

move.w CCR,Dx 1(0/0) ———— — ——

move.w<ea>,CCR1(0/0)———— — —1(0/0)

move.wSR,Dx1(0/0)———— — ——

move.w<ea>,SR7(0/0)———— — —7(0/0)

movecRy,Rc9(0/1)———— — ——

movem.l <ea>,&list — 1+n(n/0) — — 1+n(n/0) — — —

movem.l &list,<ea> — 1+n(0/n) — — 1+n(0/n) — — —

nop 3(0/0)———— — ——

pea <ea> — 2(0/1) — — 2(0/1)

3(0/1)

2(0/1) —

pulse 1(0/0)———— — ——

stop#imm————— — —3(0/0)

trap#imm————— — —15(1/2)

trapf 1(0/0)———— — ——

trapf.w 1(0/0)———— — ——

trapf.l 1(0/0)———— — ——

unlkAx2(1/0)———— — ——

wddata <ea> — 3(1/0) 3(1/0) 3(1/0) 3(1/0) 4(1/0) 3(1/0) 3(1/0)

wdebug <ea> — 5(2/0) — — 5(2/0) — — —

n is the number of registers moved by the MOVEM opcode.

If a MOVE.W #imm,SR instruction is executed and imm[13] = 1, the execution time is 1(0/0).

The execution time for STOP is the time required until the processor begins sampling continuously for interrupts.

PEA execution times are the same for (d16,PC).

PEA execution times are the same for (d8,PC,Xn*SF).

2-26 MCF5282 User’s Manual MOTOROLA

EMAC Instruction Execution Times

2.12 EMAC Instruction Execution Times

Table 2-16. EMAC Instruction Execution Times

Effective Address

Opcode <EA>

Rn (An) (An)+ -(An) (d16,An)

muls.w <ea>y, Dx 4(0/0) 6(1/0) 6(1/0) 6(1/0) 6(1/0) 7(1/0) 6(1/0) 4(1/0)

mulu.w <ea>y, Dx 4(0/0) 6(1/0) 6(1/0) 6(1/0) 6(1/0) 7(1/0) 6(1/0) 4(1/0)

muls.l <ea>y, Dx 4(0/0) 6(1/0) 6(1/0) 6(1/0) 6(1/0) — — —

mulu.l <ea>y, Dx 4(0/0) 6(1/0) 6(1/0) 6(1/0) 6(1/0) — — —

mac.w Ry, Rx, Raccx 1(0/0) — — — — — — —

mac.l Ry, Rx, Raccx 1(0/0) — — — — — — —

msac.w Ry, Rx, Raccx 1(0/0) — — — — — — —

msac.l Ry, Rx, Raccx 1(0/0) — — — — — — —

mac.w Ry, Rx, <ea>, Rw,

Raccx

mac.l Ry, Rx, <ea>, Rw,

Raccx

msac.w Ry, Rx, <ea>, Rw — 2(1/0) 2(1/0) 2(1/0) 2(1/0)

msac.l Ry, Rx, <ea>, Rw,

Raccx

— 2(1/0) 2(1/0) 2(1/0) 2(1/0)

(d8,An,X

n*SF)

———

xxx.wl #xxx

mov.l <ea>y, Raccx 1(0/0) — — — — — — 1(0/0)

mov.l Raccy,Raccx 1(0/0) — — — — — — —

mov.l <ea>y, MACSR 5(0/0) — — — — — — 5(0/0)

mov.l <ea>y, Rmask 4(0/0) — — — — — — 4(0/0)

mov.l <ea>y,Raccext01 1(0/0) — — — — — — 1(0/0)

mov.l <ea>y,Raccext23 1(0/0) — — — — — — 1(0/0)

mov.l Raccx,<ea>x 1(0/0)

mov.l MACSR,<ea>x 1(0/0) — — — — — — —

mov.l Rmask, <ea>x 1(0/0) — — — — — — —

mov.l Raccext01,<ea.x 1(0/0) — — — — — — —

mov.l Raccext23,<ea>x 1(0/0) — — — — — — —

Effective address of (d16,PC) not supported

Storing an accumulator requires one additional processor clock cycle when saturation is enabled, or fractional rounding is performed (MACSR[7:4] = 1---, -11-, --11)

————— ——

MOTOROLA Chapter 2. ColdFire Core 2-27

Branch Instruction Execution Times

NOTE

The execution times for moving the contents of the Racc, Raccext[01,23], MACSR, or Rmask into a destination location <ea>x shown in this table represent the best-case scenario when the store instruction is executed and there are no load or M{S}AC instructions in the EMAC execution pipeline. In general, these store operations require only a single cycle for execution, but if preceded immediately by a load, MAC, or MSAC instruction, the depth of the EMAC pipeline is exposed and the execution time is four cycles.

2.13 Branch Instruction Execution Times

Table 2-17. General Branch Instruction Execution Times

Effective Address

Opcode <EA>

Rn (An) (An)+ -(An)

(d16,An) (d16,PC)

(d8,An,Xi*SF)

(d8,PC,Xi*SF)

xxx.wl #xxx

bsr ————3(0/1)— ——

jmp <ea> — 3(0/0) — — 3(0/0) 4(0/0) 3(0/0) —

jsr <ea> — 3(0/1) — — 3(0/1) 4(0/1) 3(0/1) —

rte — — 10(2/0) — — — — —

rts — — 5(1/0) — — — — —

Table 2-18. BRA, Bcc Instruction Execution Times

Opcode

bra 2(0/0) — 2(0/0) —

bcc 3(0/0) 1(0/0) 2(0/0) 3(0/0)

Forward

Taken

Forward

Not Taken

Backward

Taken

Backward Not Taken

2.14 ColdFire Instruction Set Architecture Enhancements

This section describes the new opcodes implemented as part of the Revision A+ enhancements to the basic ColdFire ISA.

2-28 MCF5282 User’s Manual MOTOROLA
