Motorola BLUETOOTH WIRELESS HEADSET User Manual

Welcome.fm Page 1 Monday, January 14, 2002 1:40 PM

Welcome

Welcome to Motorola’s “connected” world of Bluetooth™ personal area wireless
networking.

You can place a call directly from your Bluetooth Wireless Headset by using your
Bluetooth capable phone and your phone’s voice activation feature. The headset
provides handsfree convenience and freedom from cables and wires. Bluetooth
technology makes all connections quickly and

All Motorola wireless products are designed and manufactured to meet Motorola’s
rigorous specifications and world-class quality standards. During development, our
testing team took the Motorola Bluetooth Wireless Headset through rigorous
durability tests including temperature, humidity, shock, dust, vibration, and drop
tests.

We are confident that you will find your Bluetooth Wireless Headset to be a
convenient and secure way to mak e clear, crisp phone calls. Thank you for choosing a
Motorola Bluetooth product!

without any cables

.

Welcome.fm Page 2 Monday, January 14, 2002 1:40 PM

Personal Communications Sector
600 North U.S. Highway 45
Libertyville, Illinois 60048

1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States)
1-800-461-4575 (Canada)

www.motorola.com
MOTOROLA, the Stylized M Logo and all other trademarks indicated as such herein

are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off. The BLUETOOTH
trademarks are owned by their proprietor and used by Motorola, Inc., under license.
TrueSync is a trademark of Starfish, Inc., a wholly owned subsidiary of Motorola, Inc.
All other product or service names are the property of their respective owners.

© 2001 Motorola, Inc. All rights reserved. Printed in the U.S.A.
Manual number: 9887570M01-O

BluetoothTOC.fm Page 3 Monday, January 14, 2002 1:41 PM

Contents

Safety and General Information
Introduction

What Is Bluetooth Wireless Technology? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

How Can I Use My Bluetooth Wireless Headset? . . . . . . . . . . . . . . . . . . . . . . . 7

What Is Included in This Kit? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Headset Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Using Y our Headset

Charging Your Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Wearing the Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Linking Your Headset and Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Controlling Headset Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Placing a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Ending a Call from the Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Transferring a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Disconnecting the Bluetooth Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Using Your Headset Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Resetting the Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Paired Link to Two Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

3

Safety.fm Page 4 Monday, January 14, 2002 1:42 PM

Safety and General Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ
THIS INFORMATION BEFORE USING YOUR PHONE.

Users are not permitted to make changes or modify the device in any way. Changes
or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21.

This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation. See 47 CFR Sec. 15.19(3).

Electromagnetic Interference/Compatibility

Note:

(EMI) if inadequately shielded, designed, or otherwise configured for
electromagnetic compatibility.

Facilities

To avoid electromagnetic interference and/or compatibility conflicts, turn off your
phone in any facility where posted notices instruct you to do so. Hospitals or health
care facilities may be using equipment that is sensitive to external RF energy.

4

Nearly every electronic device is susceptible to electromagnetic interference

Safety.fm Page 5 Monday, January 14, 2002 1:42 PM

Safety and General Information

Aircraft

When instructed to do so, turn off your phone when on board an aircraft. Any use of
a phone must be in accordance with applicable regulations per airline crew
instructions.

Medical Devices

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum
separation of 6 inches (15 centimeters) be maintained between a handheld wireless
phone and a pacemaker. These recommendations are consistent with the
independent research by, and recommendations of, Wireless Technology Research.

Persons with pacemakers should:

•ALWAYS keep the phone and Bluetooth phone module more than six inches (15
centimeters) from your pacemaker when the phone is turned ON.

•NOT carry the phone and Bluetooth phone module in the breast pocket.

• use the ear opposite the pacemaker to minimize the potential for interference.

• turn OFF the phone immediately if you have any reason to suspect that
interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of
such interference, you may want to consult with your hearing aid manufacturer to
discuss alternatives.

5

Safety.fm Page 6 Monday, January 14, 2002 1:42 PM

Safety and General Information

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device
to determine if it is adequately shielded from RF energy. Your physician may be able
to assist you in obtaining this information.

FCC Notice to Users

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

6

Intro.fm Page 7 Monday, January 14, 2002 1:42 PM

Introduction

What Is Bluetooth Wireless Technology?

Bluetooth

Bluetooth devices communicate without wires, using built-in radio transceivers that
operate on a globally available radio frequency to ensure worldwide compatibility.
Your Bluetooth Wireless Headset can communicate with other Bluetooth devices
within a range of approximately 10 meters (33 feet).

wireless technology propels you into a new dimension in connectivity.

How Can I Use My Bluetooth Wireless Headset?

The Bluetooth Wireless Headset lets you connect with a Bluetooth device such as a

Motorola 270c wireless phone with attached Bluetooth module

• Use your phone hands-free.

• Handle incoming and outgoing calls with the headset multifunction control
button.

• Use voice activation to make calls.

Note:

your User’s Guide for more information.

Connecting your headset requires Bluetooth Headset Profile Support. Consult

7

Intro.fm Page 8 Monday, January 14, 2002 1:42 PM

Introduction

What Is Included in This Kit?

This package includes the following:

• Bluetooth headset

• Motorola charger

• Headset pouch with built-in belt clip

• Lanyard option for carrying the headset

8

Intro.fm Page 9 Monday, January 14, 2002 1:42 PM

Introduction

Headset Features

Headset Off

(boom closed)

2

1

1—Headset Indicator light
2—Volume Control
3—Microphone
4—Boom

Contains microphone and controls power (On/Off) status of headset.

Adjusts speaker (receive) volume up and down.

Picks up your voice input.

Headset On

(boom open)

3
4

5

9

Provides visual cue about headset status.

8

6

7

5—Earhook
6—Speaker
7—Charging Port
8—Lanyard Loop

headset around your neck and always keep it near.

9—Multifunction Button E Controls several headset functions.

Attaches headset to ear.

Plays the sound you receive on the call.

Receives the plug for your battery charger.

Lets you attach a lanyard to the headset, so you can wear the

9

Using.fm Page 10 Monday, January 14, 2002 1:43 PM

Using Your Headset

Charging Your Headset

When to Charge

First-Time Use

contained battery for two hours.

Recharging

repeated at 20-second intervals, the headset battery needs to be recharged.
Over extended periods of time, batteries gradually wear down and require longer

charging times. This is normal. The more you talk on the phone with the headset, the
less standby time your battery has.

The rechargeable batteries that power this product must be disposed of
properly and may need to be recycled. Contact your local recycling center
for proper disposal methods. Never dispose of batteries in a fire because

they may explode.

—Before you can use your headset, you need to charge its self-

—When you hear five rapid high tones through the headset speaker,

10

Using.fm Page 11 Monday, January 14, 2002 1:43 PM

Using Your Headset

How to Charge

Step

1

Plug the Motorola charger into the
headset, with the charger’s release
tab and the headset both facing up.

2

Plug the other end of the charger into an electrical outlet.
During charging, the headset indicator turns on and remains lit until charging

is complete. Your headset requires approximately two hours to receive a full
charge.

3

When charging is complete (indicator is off), remove the charger from the
electrical outlet, press the release tab, and detach the charger cord from the
headset.

Note:

headset while in your vehicle.
A fully charged headset battery provides approximately:

• talk time—2.5 hours

• standby time (boom open)—10 hours

• storage time (boom closed)—20 days

You can also use a Motorola Original Vehicle Power Adapter to charge the

11

Using.fm Page 12 Monday, January 14, 2002 1:43 PM

Using Your Headset

Wearing the Headset

Placing the Headset on Your Ear

When packaged, the headset is configured for wear on the right ear.

Step

1

Open the boom, then open the
earhook (90˚ from the headset).

2

Loop the earhook over your ear.

3

Press the headset to your ear.

4

Point the boom toward your mouth.

12

Using.fm Page 13 Monday, January 14, 2002 1:43 PM

Using Your Headset

Changing for Wear on the Left Ear

When packaged, the headset is configured for wear on the right ear.
To change it for wear on your left ear:

Step

1

Open the boom, then open the
earhook (90˚ from the headset).

2

Gently lift and pull the top of the
earhook up and off the upper hinge
pin. Then pull it away to remove it.

3

Flip the headset over.

4

Hook the bottom of the earhook onto the lower hinge pin, then lift and pull
the top of the earhook over the upper hinge pin.

13

Using.fm Page 14 Monday, January 14, 2002 1:43 PM

Using Your Headset

Storing Your Headset in its Holster

Your headset comes with a holster where you can store it when you are not using it.
To fit your headset into its holster:

Step

Slip the headset down into the
holster, with the lanyard tab pointing
up and the earhook facing the inside
of the holster.

14

Using.fm Page 15 Monday, January 14, 2002 1:43 PM

Using Your Headset

Linking Your Headset and Phone

Note:

You establish a Bluetooth link between your headset and phone with a paired link.
When you set up a paired link, the phone remembers the headset’s ID. Once your
headset and phone are paired, your headset automatically connects to your phone
any time you open the boom.

You must link your headset and phone before you can make a call.

Paired Link

With the headset and phone in close proximity:

Step Result

1

With the headset’s boom closed, press
and hold the Multifunction Button E
for two seconds.

The headset indicator turns on.

2

Open the headset boom. The indicator remains lit.

15

Using.fm Page 16 Monday, January 14, 2002 1:43 PM

Using Your Headset

Step Result

3

Perform a

device discovery

from the

When the scan is complete, the
phone. For Motorola phones, perform
device discovery by selecting these
options:

Settings

Bluetooth Link

>
>

Scan All

Connection

>

Hands Free

>

For details on device discovery for
another phone, refer to the user’s
guide for the phone.

4

Press the
bond to the headset.

5

When
appears, enter the passkey

Enter Bluetooth Passkey

soft k ey on the phone to

YES

0000

, then

phone displays:

Bond with Motorola headset

It may take several seconds to

establish a connection.

The device ID is now stored in the

phone’s memory.
press

headset with the phone.

OK

on the phone to pair the

16

Pairing is successful when the

headset indicator flashes 10 times

rapidly.

Using.fm Page 17 Monday, January 14, 2002 1:43 PM

Using Your Headset

Step Result

6

Press the

7

Press the
the Bluetooth menu

Link

END

soft key on the phone.

key on the phone to exit

The audio gateway is established
between your phone and headset.

The phone returns to idle.
You can now place and receive calls.

(See “Placing a Call” on page 18
and “Receiving a Call” on page 20.)

Controlling Headset Volume

Increasing and Decreasing Volume

To increase speaker volume, press the top of the volume button repeatedly until you
reach the desired volume level.

To decrease speaker volume, press the bottom of the volume button repeatedly until
you reach the desired volume level.

Note:

not matter whether you wear the headset on the right or left ear. Pressing the top of
the volume key always increases the volume, and pressing the bottom always
decreases the volume.

Because the headset is equipped with Volume Orientation Technology, it does

17

Using.fm Page 18 Monday, January 14, 2002 1:43 PM

Using Your Headset

Placing a Call

You can place a call with your headset in these three ways:

• using voice activation

• dialing a number from the phone

• redialing a number with the headset’s Multifunction Button

In all three cases, you must first link your headset and phone as described in
“Linking Your Headset and Phone” on page 15.

E

Using Voice Activation with Motorola Phones

Note:

Bluetooth Link menu.

Step Result

1

To use voice activation, you must turn on

Press the Multifunction Button E.A tone sounds to prompt you to

Voice Dial

speak the name of the person you

wish to call (as entered in the

phone’s phonebook.)

in your phone’s

2

Say the voice tag name. Your phone finds the entry, pauses

18

two seconds, then places the call.

Using.fm Page 19 Monday, January 14, 2002 1:43 PM

Using Your Headset

Notes:

•Voice tags must be stored in the phone. Consult your phone’s User Guide for
more information.

• If the voice tag name is not recognized, you will hear a high/low tone in the
headset.

Dialing a Number from the Phone Keypad

Step

1

Using the phone’s keypad, dial the phone number.

2

To send the call:

•

Press the standard key for sending calls from your phone.

or

•

Momentarily press the headset’s Multifunction Button E.

19

Using.fm Page 20 Monday, January 14, 2002 1:43 PM

Using Your Headset

Redialing a Number with the Headset (Motorola Phones)

Note:

(voice dialing) in your phone’s Bluetooth Link menu.

To redial a number with the headset, you must turn OFF voice activation

Step

1

Press the headset’s Multifunction Button E once to recall the last number
dialed.

2

Press the Multifunction Button E again to send the call.

Ending a Call from the Headset

To end a call, press the headset’s Multifunction Button E. A tone indicates that the
call has ended.

Receiving a Call

With the Headset On and Linked

When you receive an incoming call with the headset on (the boom is open) and
linked, a ring tone sounds in your headset. To link your phone, see “Linking Your
Headset and Phone” on page 15.

Answer the call by pressing the headset’s Multifunction Button

20

E.

Using.fm Page 21 Monday, January 14, 2002 1:43 PM

Using Your Headset

With the Headset Off (Paired Link Only)

When you receive a call with the headset off, open the headset’s boom. The Auto­Answer feature enables you to answer the call through the headset.

Transferring a Call

Headset to Phone

The transfer must be initiated by the phone. (See the user’s guide for your phone.)

Phone to Headset

Open the boom to activate the Auto-Transfer feature.
If the boom is already open and the call is on the phone, press the headset’s

Multifunction Button E.

Disconnecting the Bluetooth Link

To terminate the Bluetooth connection between the headset and phone, turn the
headset off by closing the boom.

If you terminate the Bluetooth connection during an active call, the call is held at the
phone for 30 seconds to let you transfer the call back to the phone. If you do not
transfer the call, it is terminated at the end of the 30 seconds.

21

Using.fm Page 22 Monday, January 14, 2002 1:43 PM

Using Your Headset

Using Your Headset Indicators

Headset Indicator

With charger plugged in:

Headset Indicator Headset

ON charging in progress
OFF charging complete

With no charger attached:

Headset Indicator Headset

OFF power off
ON (steady) pairing mode
10 rapid flashes pairing successful
flashes at a 3-second interval

(.1 seconds ON, 2.9 seconds OFF)
flashes at a 2-second interval

(.5 seconds ON, 1.5 seconds OFF)

standby (not on a call)

connected (on a call)

22

Using.fm Page 23 Monday, January 14, 2002 1:43 PM

Using Your Headset

Audio Tones

Audio Tone Headset Status

single high tone when button released volume up or down
five rapid high tones, repeated every 20

seconds
no audio indications; deteriorating

audio quality
series of 4 tones, low to hight audio link open
ring tone incoming call
single high tone pairing confirmation
single low tone initiate voice activation
dual high/low tone voice tag not recognized
single high tone end call
series of 4 tones, high to low audio link closed
no tone power ON/OFF

low battery

out of range

23

Using.fm Page 24 Monday, January 14, 2002 1:43 PM

Using Your Headset

Resetting the Headset

If the phone and headset fail to communicate, you may need to reset the headset.

Step

1

Plug the headset into the charger (see “How to Charge” on page 11).

2

Wait 5 seconds.

3

Detach the headset from the charger.

Note: Resetting the headset does not affect paired links or device data.

Paired Link to Two Devices

Your headset can store pairing information for two different Bluetooth devices:

• In Mode 1, the headset connects to the last device it was paired to in Mode 1.

• In Mode 2, the headset connects to the last device it was paired to in Mode 2.

24

Using.fm Page 25 Monday, January 14, 2002 1:43 PM

Using Your Headset

To toggle between Modes 1 and 2:

Step Result

1

With the headset’s boom closed,
hold the Multifunction Button E
for two seconds.

2

With the boom still closed, press

The headset indicator light turns on.

The indicator flashes once for Mode 1,

either volume button

3

Open the boom and verify the
LED flash.

4

Pair with a device as described in
“Paired Link” on page 15.

twice for Mode 2.
The indicator flashes once for Mode 1,

twice for Mode 2.

25

Using.fm Page 26 Monday, January 14, 2002 1:43 PM

Imported to Canada by

Motorola Canada Limited

Mississauga, Ontario L4Z 2H4

Importé au Canada par

Motorola Canada Limitée

Mississauga (Ontario) L4Z 2H4
