Morphy Richards 480003 Instruction manual

DF480003 MUK Rev1

Health Fryer

Please read and keep these instructions for future use

GUARANTEE

YEAR

* Register online for your 2 year guarantee. See the back of this instruction book for details (UK and Ireland customers only).

www.facebook.com/morphyrichardsuk

@loveyourmorphy

www.morphyrichards.co.uk/blog

For competitions, product hints and tips and more join us at

DF480003 MUK Rev1.qxp_Layout 1 08/09/2017 14:53 Page 1

The use of any electrical appliance requires the following common sense safety rules.

Please read these instructions carefully before using the product.

•This appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved.

• Keep the appliance and its cord out of the reach of children aged less

than 8 years.

• Children shall not play with the appliance.

• Cleaning and user maintenance shall not be made by children unless

they are older than 8 and supervised.

•This appliance is intended to be used in household and similar

applications such as: farm houses, by clients in hotels, motels and other residential type environments, bed and breakfast type environments. It is not suitable for use in staff kitchen areas in shops, offices and other working environments.

• If the supply cable is damaged, it must be replaced with a special

cable assembly available from the manufacturer or its service agent in order to avoid a hazard.

• For care and cleaning refer to page 8.

•This appliance is not intended to be operated by means of an external

timer or separate remote control system.

Health And Safety

DF480003 MUK Rev1.qxp_Layout 1 08/09/2017 14:53 Page 2

n addition, we offer the following safety advice.

ocation

• P

lace the appliance on a horizontal, flat and stable heat resistant surface, away from a heating source and where it cannot be splashed by water.

• Allow adequate air space above and on all sides

or air circulation.

• Do not use outdoors or near water.

Mains cable

• The mains cable should reach from the socket to

the base unit without straining the connections.

• Do not let the cable hang over the edge of the

table or the counter and keep it away from any hot surface.

• Do not let the cable run across an open space

e.g. between a lower socket and table.

Personal safety

• WARNING: Never attempt to move your Health

Fryer until it is completely cool. This can take up to three hours.

• Be careful not to touch those surfaces of the

Health Fryer which become hot when in use.

• WARNING: To protect against the risk of electric

shock, do not immerse the control unit in water or other liquid.

• Unplug from the electrical outlet when not in use

and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the appliance.

• WARNING: Misuse can cause personal injury.

• Never leave the Health Fryer unattended when

connected to the electricity supply.

• Never lean over the Health Fryer when it is in use.

ther safety considerations

• The use of attachments or tools not

recommended or sold by Morphy Richards may c

ause fire, electric shock or injury.

• Do not operate any appliance with a damaged

ord or plug or after the appliance malfunctions

or has been damaged in any manner.

• Do not use the Health Fryer for anything other

han its intended purpose.

Electrical requirements

Check that the voltage on the rating plate of your appliance corresponds with your house electricity supply which must be A.C. (Alternating Current).

WARNING : The plug removed from the mains lead, if severed, must be destroyed, as a plug with a bared flexible cord is hazardous if engaged into a live socket outlet.

Should the fuse in the 13 amp plug require changing, a 13 amp BS1362 fuse must be fitted.

WARNING: This appliance must be earthed.

Health And Safety (Continued)

PLEASE BE AWARE OF HOT SURFACES

HANDLE WITH CARE

Treating scalds

• Run cold water over the affected area immediately.

• Do not stop to remove clothing.

• Seek medical advice quickly.

DF480003 MUK Rev1.qxp_Layout 1 08/09/2017 14:53 Page 3

Health And Safety ......................................................... 2

Introduction .................................................................. 4

Product Overview ........................................................ 5

Before First Use ........................................................... 6

Using your Health Fryer ............................................... 6

Hints And Tips ............................................................. 8

Care And Cleaning ....................................................... 8

Cooking Guide ............................................................. 9

Troubleshooting ........................................................... 10

Recipes ......................................................................... 12

Notes ............................................................................ 21

Guarantee ..................................................................... 24

Contents

Thank you for your recent purchase of this M

orphy Richards Health Fryer.

Please read the instructions thoroughly before use.

emember to visit www.morphyrichards.co.uk to register your

product’s two year guarantee.

Introduction

DF480003 MUK Rev1.qxp_Layout 1 08/09/2017 14:53 Page 4

Features

(1) Temperature Control

(2) Main Body

(3) Timer Control

(4) Drawer

(5) Basket Release Button Cover

(6) Basket Release Button

(7) Frying Basket Handle

(8) Mains Power Cord Socket

(9) Air outlet and filter

(10) Frying basket

Product Overview

REVERSE

DF480003 MUK Rev1.qxp_Layout 1 08/09/2017 14:53 Page 5

Using Your Health Fryer

Remove the Drawer (4) from the Main Body (2). Pull the Drawer

(4) fully out from your Health

Fryer.

Ensuring the lead is inserted into the back of the Main Body (2), plug the Health Fryer into the mains.

emove all packaging materials.

emove all stickers and labels from the appliance

(

excluding the rating label).

lean all parts to remove any dust or

anufacturing residues.

horoughly wash all removable par ts by hand

ith hot water, washing-up liquid and a non-abrasive sponge. Do not submerge the Main Body

(2) in water. Wipe with a damp cloth.

• PLEASE NOTE: All parts are NOT dishwasher

safe.

Wipe the inside and outside of the appliance with a moist cloth.

Dry all parts of your Health Fryer thoroughly. W

hen replacing the drawer, ensure it is aligned

orrectly.

se the appliance on a horizontal, flat and stable

eat resistant surface, away from a heating

source and where it cannot be splashed by water.

Before First Use

Remove the Frying Basket (10) from the Drawer (4) by lifting the Basket Release Button Cover (5) and pressing the Basket Release Button (6). Use the Frying Basket Handle (7) to pull the basket fully out from the Drawer (4).

PLEASE NOTE: Only raise the Basket Release Button Cover

(5) when using the Basket

Release Button (6). At all other times, have the Basket Release Button Cover (5) lowered.

The power light will illuminate. Before cooking, preheat the Health Fryer for 3 minutes at the temperature that you will be cooking at.

DF480003 MUK Rev1.qxp_Layout 1 08/09/2017 14:53 Page 6

Using Your Health Fryer (Continued)

Turn the Timer Control

(3)

to set the cooking

time. Your food is now cooking.

Place the food into

the Frying Basket (10) and repeat Step 3. Only place food in the Frying Basket (10). Do not put oil or food into the Drawer (4).

When the time is up on the timer, the Health Fryer will ring and automatically turn off.

If the food is not cooked to your desired requirements, repeat.

Tip: Check your food at two minute intervals to ensure food is not overcooked.

Either remove the entire Basket

(10)

(see Step 2), or carefully use plastic or wooden utensils to

remove your food.

Turn the Temperature Control

(1)

to set the

temperature you require.

Place the Frying Basket (10) into the Drawer and re-insert the Drawer

(4)

into the Main Body (2)

until it clicks into place. Ensure the Drawer

(4)

is fully closed. A safety switch will prevent it working if not closed properly.

DF480003 MUK Rev1.qxp_Layout 1 08/09/2017 14:53 Page 7

• T

ake into account the food to be cooked before you select your frying temperature. As a general g

uide pre-cooked food needs a higher cooking

temperature than raw food.

• C

ook your food thoroughly. Remember that your food may begin to turn golden brown before it is cooked through.

• Select your cooking utensils with care. Do not

use utensils that may melt. Do not use metal utensils as they may damage the pan coatings.

• Your Health Fryer has a maximum capacity for

food. This is dependant on food type (see the ‘Cooking guide’ for more information). As a guide do not fill the basket more than half full.

• Smaller ingredients usually require a shorter

frying time than larger ingredients.

• A larger amount of ingredients requires only a

slightly longer frying time, a smaller amount of ingredients requires only a slightly shorter frying time.

• Do not leave the Drawer out for too long.

The temperature will drop.

• The optimal amount for preparing crispy fries

is 500 grams.

• Use pre-made dough to prepare filled snacks

quickly and easily. Pre-made dough also requires a shorter frying time than home-made dough.

• You can also use the Health Fryer to reheat

ingredients. To do this, set the temperature to 150°C for up to 10 minutes. Check that food is hot before eating.

lean the appliance after each use, but remove

he mains plug from the wall and allow the

appliance to cool down - removing the Drawer

(4)

rom the Health Fryer allows it to cool down

quicker.

emove the power cord when cleaning the Health

ryer. The cord can then be stored with the Health

Fryer itself.

Wipe the outside of the appliance with a moist cloth.

Remove the Drawer

(4)

and

Frying Basket (10) a

nd wash them by hand in hot soapy water, using a non-abrasive sponge.

• If any food residue is stuck to the Drawer

(4)

and

Frying Basket (10), half

fill the Drawer with hot

soapy water. Place the

Frying Basket (10)

in the Drawer and let them soak for approximately 10 minutes. Do not place inside the main unit.

• The Drawer

(4)

and

Frying Basket (10)

have a coating. Do not use metal kitchen utensils or abrasive cleaning materials to clean them, as this may damage the coating.

Clean the inside of the appliance with a moist cloth.

Dry all parts of your Health Fryer thoroughly and replace the Drawer

(4), Frying Basket (10)

. When replacing the Drawer, ensure it is aligned correctly.

Hints And Tips Care and Cleaning

DF480003 MUK Rev1.qxp_Layout 1 08/09/2017 14:53 Page 8
