Mister Cappuccino Espresso
coffee maker with heated milk frother
Please read and keep these instructions
GGeettttiinngg tthhee bbeesstt ffrroomm yyoouurr nneeww ccooffffeeee mmaakkeerr......
WARNING : pressure cap
Unplug your coffee machine. The pressure cap must be slowly removed before unlocking the
filter holder.
SSaaffeettyy ffiirrsstt
Caution must be used when handling hot water, coffee or steam.
RRuunn wwaatteerr tthhrroouugghh yyoouurr mmaacchhiinnee bbeeffoorree ffiirrsstt uussee
It is important to run water through your coffee maker in order to rinse the machine. You can also
run water through to warm your coffee machine.
DDeessccaallee aass aapppprroopprriiaattee ffoorr tthhee hhaarrddnneessss ooff tthhee wwaatteerr iinn yyoouurr aarreeaa
It is important to descale as the performance of your coffee
maker may be impaired by limescale and other impurities in the water supply.
CCMM4477000099 RReevv 22
For replacement parts, help with using your Morphy Richards, problems
and lots more, contact us by phone or through our website.
UUKK HHeellpplliinnee:: 00887700 006600 22661100
RReeppllaacceemmeenntt ppaarrttss:: 00887700 116677 66664411
IIrreellaanndd 11880000 440099111199
47009 rev2 24/4/06 15:12 Page 1
22 UUKK HHeellpplliinnee 00887700 006600 22661100 RReeppllaacceemmeenntt PPaarrttss 00887700 115577 66664411 IIrreellaanndd HHeellpplliinnee 11880000 440099111199
IIMMPPOORRTTAANNTT SSAAFFEETTYY
IINNSSTTRRUUCCTTIIOONNSS
The use of any electrical
appliance requires the following
common sense safety rules.
Primarily there is danger of
injury or death and secondly
the danger of damage to the
appliance. These are indicated
in the text by the following two
conventions:
IMPORTANT: Damage to the
appliance! In addition we offer
the following safety advice.
LLooccaattiioonn
• Remove all the packaging and
retain for future reference.
• Ensure the coffee maker is
used on a firm, flat surface.
• Do not use the coffee maker
outdoors or in a bathroom.
• Do not place the coffee maker
on a highly polished wooden
surface as damage may occur
to the surface.
• Do not place the coffee maker
on or near hot surfaces such
as a hot plate or radiant rings
or near a naked flame.
• WARNING: Do not place the
coffee maker onto a metal tray
or metal surface whilst in use.
MMaaiinnss lleeaadd
• Do not let the mains lead hang
over the edge of the worktop
where a child could reach it.
• Do not let the lead run across
an open space e.g. between a
low socket and table.
• Do not let the lead run across a
cooker or other hot area which
might damage the cable.
• The mains lead should reach
from the socket to the base
unit without straining the
connections.
PPeerrssoonnaall ssaaffeettyy
• Ensure the lid of the glass jug
is securely in place before
pouring.
• Take care to pour hot coffee
slowly and carefully without
tipping the glass jug too fast.
• Do not fill above the capacity
mark of the water level gauge
marked on the jug.
• Do not use the glass jug in a
microwave.
• Milk should not be reheated,
only heat it when required.
• When heating milk, please use
stainless steel jug provided.
• Do not fill milk jug above the
MAX mark.
• Do not touch metal parts until
the unit has cooled.
CChhiillddrreenn
• Children do not understand the
dangers associated with
operating electrical appliances.
Never allow children to use this
appliance.
PPrroodduucctt ssaaffeettyy
• Never use warm or hot water
to fill the water tank.
• Do not overfill the water tank.
• Scalding may occur if the
pressure cap is removed during
the brewing cycles, therefore
never open or remove the
pressure cap whilst the
machine is switched on.
Pressure cap must be removed
slowly before unlocking the
filter holder. This procedure
must be followed even when
the machine is switched off
and cooled.
• The glass jug and the filter
holder get hot while the
machine is in use. Always use
with care.
• Make sure the mains lead does
not touch the hot parts of the
machine.
• Do not wind the mains lead
around the hot appliance or
store the appliance until it has
fully cooled down.
• Do not remove the filter holder
when the appliance is
producing hot water or coffee.
Turn the machine off and
release the steam first by
slowly removing the pressure
cap.
TTrreeaattiinngg ssccaallddss
• Run cold water over the
affected area immediately. Do
not stop to remove clothing,
get medical help quickly.
OOtthheerr ssaaffeettyy
ccoonnssiiddeerraattiioonnss
• Disconnect the coffee maker
from the mains supply when
filling, cleaning or not in use.
• When unplugging, turn any
control to ‘off’, then remove
plug from the wall outlet.
• Keep the outside of the coffee
maker area clean and dry at all
times.
• Do not touch hot surfaces.
Always use handles or knobs.
• Do not immerse the coffee
maker itself in water and
always ensure the electrical
connections are kept dry.
• Do not operate any appliance
with a damaged cord or plug or
after the appliance
malfunctions or has been
damaged in any manner. Ring
the helpline number for advice
on examination and repair.
• The use of attachments or
tools not recommended or sold
by Morphy Richards may
cause fire, electric shock or
injury.
• Do not use the coffee maker
for anything other than its
intended purpose.
47009 rev2 24/4/06 15:12 Page 2
33wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm
EELLEECCTTRRIICCAALL
RREEQQUUIIRREEMMEENNTTSS
Check that the voltage on the
rating plate of your appliance
corresponds with your house
electricity supply which must
be A.C. (Alternating current).
If the socket outlets in your
home are not suitable for the
plug supplied with this
appliance the plug should be
removed and the appropriate
one fitted.
WARNING : The plug
removed from the mains
lead, if severed, must be
destroyed as a plug with a
bared flexible cord is
hazardous if engaged into a
live socket outlet.
Should the fuse in the 13 amp
plug require changing a 13
amp BS1362 fuse must be
fitted.
WARNING: This appliance
must be earthed.
WWAARRNNIINNGG::
PPRREESSSSUURREE CCAAPP
Unplug the machine and
allow to cool. Slowly remove
the pressure cap before
unlocking the filter holder.
⁄⁄
¤¤
‹‹
››
fifi
flfl
‡‡
··
‚‚
„„
ÂÂ
‰‰
ÊÊ
ÁÁ
ËË
ÈÈ
ÍÍ
ÎÎ
ÏÏ
FFEEAATTUURREESS
⁄⁄
Pressure cap
¤¤
Water tank
‹‹
Strength selector
››
Filter
fifi
Filter retaining clip
flfl
Filter holder
‡‡
Drip tray metal plate
··
Drip tray
‚‚
Hot water outlet
„„
On/off/switch with power and
ready indicators
‰‰
Milk frother hot plate on/off
switch with indicator
ÂÂ
Glass coffee jug with lid
ÊÊ
Jug lid
ÁÁ
Measuring spoon/tamper
ËË
Milk frother jug
ÈÈ
Milk frother attachment
ÍÍ
Milk frother on/off button
ÎÎ
Steam exhaust tube
ÏÏ
Milk frother hot plate
47009 rev2 24/4/06 15:12 Page 3
44 UUKK HHeellpplliinnee 00887700 006600 22661144 RReeppllaacceemmeenntt PPaarrttss 00887700 115577 66664455 IIrreellaanndd HHeellpplliinnee 11880000 440099111199
OOPPEERRAATTIINNGG TTHHEE
AAPPPPLLIIAANNCCEE
BBeeffoorree uussee
Take your coffee maker out of the
box and remove the packaging.
Before using the appliance for the
first time, clean thoroughly by
operating two or three times with the
maximum volume of fresh water (6
cups) but without using coffee.
Wash the detachable parts of the
machine in warm soapy water.
MMaakkiinngg eesspprreessssoo
ccooffffeeee
1 Unscrew the pressure cap by turning
it anti-clockwise.
2 To fill the water tank use your glass
jug to measure the volume of water
required. The jug is marked with the
water levels for 2 cups (minimum), 4
cups and 6 cups (maximum).
Always switch the machine off and
remove the plug from the socket
before filling the water tank. Care
should be taken to ensure that the
correct quantity of water is placed in
the tank, as the machine always
uses all the water.
3 Close the pressure cap tightly by
turning it clockwise.
4 Place the washable metal filter into
the filter holder and add the desired
quantity of coffee to the filter using
the measuring spoon provided.
Special marks on the inside of the
filter show the correct levels for 2, 4
and 6 cups of coffee lightly
compress the coffee down. Remove
excess coffee from the edge of the
filter.
5 Position the filter holder underneath
the water outlet,,push it upwards
and turn it to the right into the locked
position to fix it onto your coffee
machine.
AA
Note: Push firmly to the right to lock
into position.
6 Your machine is fitted with a strength
selector which allows you to make
LIGHT to STRONG coffee. Set the
strength selector mid way between
LIGHT and STRONG for MEDIUM
strength coffee.
7 Place your glass jug with the lid on
the drip tray and directly under the
spout of the filter holder, ensuring
that the jug handle is pointing
outwards from the unit.
8 Plug the espresso coffee maker in at
hte wall socket and push the coffee
on/off switch to ‘ON’ position. The
orange light will glow to show th
ecoffee maker is working.
9 The coffee will start to flow from the
filter holder spout after about 2 or 3
minutes. Wait until all the water from
the water tank has flowed into your
glass jug and the green light glows.
10 When the filtering process is
complete switched off the coffee
maker, remove the glass jug from
your coffee maker and pour the
coffee into your cups.
WARNING: The coffee maker and
hot plates are hot and remain hot
for some time after switching off.
11 Unplug machine and allow to cool.
Slowly remove the pressure cap.
12 To remove the used coffee grounds,
remove the filter holder by turning
the handle to the left until you find
that the filter holder drops down. Flip
the filter retaining clip so that it
retains the filter. Turn the filter upside
down and knock out the grounds.
Flip the retaining clip back along the
handle before the next use.
Note: Due to the amount of steam
lost through the process, the coffee
produced will be less than the water
put in. This is accounted for in the
amount to put in.
AA
47009 rev2 24/4/06 15:12 Page 4
55
www.morphyrichards.com
MMaakkiinngg aa ccaappppuucccciinnoo
Prepare your machine as described
in the section ‘Making a coffee’. Use
your glass jug for measuring the
correct amount of water needed.
FFrrootthhiinngg mmiillkk
It is advised to start heating your
milk at the same time as heating
your coffee or several minutes before
making coffee to ensure milk is hot.
1 Fill the stainless steel milk jug
provided with the required amount of
milk. Do not exceed the maximum
level or add less than the minimum
level.
2 Place the jug on the hot plate and
switch on.
BB
NOTE: You can turn on the hot plate
at the same time as the coffee on/off
switch. It will take approximately 5-7
minutes for the milk to heat up to its
optimum frothing temperature.
3 Lift the milk jug up to the milk frother
blade CC. Raise the milk jug ensuring
that the cowl is just under the
surface of the milk - this will give the
maximum froth. Maintain the milk jug
in this position between 30-60
seconds.
WARNING: Take care as the milk
will be hot.
4 Place the milk jug back on the hot
plate to reheat the milk and preserve
the quality of the froth.
NOTE: The jug can stay on the hot
plate until the coffee has finished
brewing but be careful not to burn
your milk/froth.
5 Pour the coffee into cups and gently
pour or preferably spoon the milk
onto the coffee, then sprinkle a little
chocolate powder for the perfect
cappuccino.
6 Turn off the milk frother hot plate by
pressing the on/off switch.
WARNING: the stainless steel jug
and the hotplate will remain hot
for sometime after switching off.
CClleeaanniinngg
The milk frother blade can be wiped
clean still attached to the machine or
it can be removed for easy cleaning
by unscrewing the blade and shaft.
Wash carefully in hot soapy water.
For quick cleaning just after use, fill
up the milk jug with hot water and
run the frother for 30-50 seconds;
repeat the process twice.
If the milk has been left for a long
time the cowl and blade can be
removed and soaked in hot soapy
water for 2-5 minutes before rinsing
clean.
1 Remove the cowl directly after use
and rinse in warm cold water. DDIt is
recommended that you clean the
blade immediately after use, as dried
milk can be difficult to remove.
The frother blade can be wiped clean
still attached to the machine.
2 If further cleaning is required the
propeller and shaft can be removed.
To replace, insert the stem of the
milk frother blade into the mounting
hole on the unit and screw into
place.
EE
NOTE: If the blade is removed,
ensure that it is fully tightened in
place otherwise the frother will not
operate properly.
3 There may be some splash back of
milk on the underside of the frothing
unit. Switch the unit off then simply
wipe this area clean with a damp
cloth.
WARNING: THE FROTHER ONLY
OPERATES CORRECTLY WHEN
THE COWLING IS CORRECTLY
ASSEMBLED.
DO NOT OPERATE THE FROTHER
DRY OR NOT SUBMERSED IN
LIQUID FOR LONG PERIODS OF
TIME
BB
CC
DD
EE
wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm
47009 rev2 24/4/06 15:12 Page 5
66 UUKK HHeellpplliinnee 00887700 006600 22661144 RReeppllaacceemmeenntt PPaarrttss 00887700 115577 66664455 IIrreellaanndd HHeellpplliinnee 11880000 440099111199
RREECCIIPPIIEESS
Cappuccino
1/3 espresso
1/3 hot milk
1/3 hot frothed milk
Chocolate powder for sprinkling
1 Prepare coffee as per ‘making a
perfect espresso coffee’ instructions.
2 Fill the stainless steel milk jug with
the required amount of milk, place on
the hotplate and switch on. The milk
will take approx.5-7 minutes to reach
the appropriate temperature.
3 Froth milk by lifting the milk jug up to
the milk frothing blade ensuring that
the blade is just under the surface of
the milk and press the milk frothing
button. The milk will take approx. 3060 seconds to froth.
4 Pour the coffee and hot milk into a
cappuccino cup, spoon over frothed
milk.
5 Sprinkle with chocolate powder to
serve.
Cafe Latte
1/2 espresso
1/2 hot frothed milk
1 Prepare coffee as per ‘making a
perfect espresso coffee’ instructions.
2 Fill the stainless steel milk jug with
the required amount of milk, place on
the hotplate and switch on. The milk
will take approx. 5-7 minutes to
reach the appropriate temperature.
3 Froth milk by lifting the milk jug up to
the milk frothing blade ensuring that
the blade is just under the surface of
the milk and press the milk frothing
button. The milk will take approx. 3060 seconds to froth.
4 Pour the coffee into a tall glass and
top with the frothed milk.
Moccacino
1/3 espresso
1/3 hot frothed milk
1/3 hot chocolate
1 Prepare coffee as per ‘making a
perfect espresso coffee’ instructions.
2 Fill the stainless steel milk jug with
the required amount of milk, place on
the hotplate and switch on. The milk
will take approx. 5-7 minutes to
reach the appropriate temperature.
3 Froth milk by lifting the milk jug up to
the milk frothing blade ensuring that
the blade is just under the surface of
the milk and press the milk frothing
button. The milk will take approx. 3060 seconds to froth.
4 Prepare the hot chocolate according
to the instructions.
5 Pour the coffee, hot milk and hot
chocolate into a tall glass and serve.
Irish coffee
Makes 2 servings
40ml of double cream
2 tsp sugar
4 shots of Irish whisky
350ml hot strong coffee
1 Whip double cream until thick then
chill.
2 Warm 2 Irish coffee glasses with hot
water and place in each a teaspoon
of sugar and 2 shots of Irish whisky.
3 Divide coffee among the glasses.
4 Slowly dribble the chilled cream over
the back of the spoon.
5 Do not stir.
Amaretto coffee
250ml hot strong coffee
2 tablespoons of double or whipped
cream
2 shots of Amaretto
Sugar to taste
1 Stir the coffee and alcohol together
either with a couple of tablespoons
of double-cream, or top with a dollop
of whipped cream.
2 Sprinkle with grated chocolate and
serve.
47009 rev2 24/4/06 15:12 Page 6
77wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm
HHIINNTTSS AANNDD TTIIPPSS
CCLLEEAANNIINNGG AANNDD
MMAAIINNTTEENNAANNCCEE
RReeffiilllliinngg
1 Switch off the coffee maker, and
allow 5 minutes to cool.
2 Remove the pressure cap slowly and
refill with cold water.
DDeessccaalliinngg
• If you live in a harder water area, we
recommend that your coffee makers
is descaled at regular intervals, eg.
every 2 - 3 months. In areas of
moderately hard water you should
descale every 6 months.
• If the water filters through more
slowly than usual, it is a sign that
descaling is necessary.
• We recommend you to use
proprietary liquid descaler which is
especially made for coffee makers
and plastic kettles. Follow the
instructions on the bottle or sachet,
and them operate the coffee maker
with just water 3 times before
making coffee.
• Do not use kettle descaler unless the
packet specially states it is suitable
for coffee makers.
CClleeaanniinngg ccaarree
Unplug the coffee maker, slowly
remove the pressure cap and allow
to cool.
Do not immerse the coffee maker in
liquid.
Rinse the water tank occasionally
with cold water. Do not use a cloth
as any residue or lint may be left
behind to clog the coffee maker.
Wash the milk frother blade,mailk
frother attachment, milk frother jug
drip tray metal plate, drip tray, glass
jug, filter and filter holder, in warm
soapy water. Rinse and dry all parts
thoroughly. Refit filter, filer holder,
milk frother blade, milk frother
attachment
Wipe all external surfaces with a
damp cloth and dry thoroughly.
Never use harsh or abrasive
cleaners.
MILK FROTHER PARTS
(EXCLUDING MILK FROTHER JUG)
ARE DISHWASHER SAFE
HHeellpplliinnee
If you have any difficulty with your
appliance, do not hesitate to call. We
are more likely to be able to help
than the store from where you
bought it.
Please have the following
information ready to enable our staff
to deal with your enquiry quickly:
• Name of the product
• Model number as shown on the
underside of the appliance.
• Serial number as shown on
underside of the appliance.
For electrical products sold within
the European Community.
At the electrical products useful life it
should not be disposed of with
household waste.
Please recycle where facilities exist.
Check with your Local Authority or
retailer for recycling advice in your
country.
UK
Helpline
0870 060 2604
Replacement Parts
0870 167 6635
Ireland Helpline 1800 409119
47009 rev2 24/4/06 15:12 Page 7
88 wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm
YYOOUURR TTWWOO YYEEAARR
GGUUAARRAANNTTEEEE
It is important to retain the retailers
receipt as proof of purchase. Staple
your receipt to this back cover for
future reference. Please quote the
following information if the product
develops a fault. These numbers can
be found on the base of the product.
Model no. Serial no.
All Morphy Richards products are
individually tested before leaving the
factory. In the unlikely event of any
appliance proving to be faulty within
28 days of purchase it should be
returned to the place of purchase for
it to be replaced.
If the fault develops after 28 days
and within 24 months of original
purchase, you should contact the
Helpline number quoting Model
number and Serial number on the
product, or write to Morphy Richards
at the address shown.
You will be asked to return the
product (in secure, adequate
packaging) to the address below
along with a copy of proof of
purchase.
Subject to the exclusions set out
below (see Exclusions) the faulty
appliance will then be repaired or
replaced and dispatched usually
within 7 working days of receipt.
If for any reason this item is replaced
during the 2 year guarantee period,
the guarantee on the new item will
be calculated from original purchase
date. Therefore it is vital to retain
your original till receipt or invoice to
indicate the date of initial purchase.
To qualify for the 2 year guarantee
the appliance must have been used
according to the manufacturers
instructions. For example coffee
makers should have been regularly
descaled.
EEXXCCLLUUSSIIOONNSS
Morphy Richards shall not be liable to
replace or repair the goods under the
terms of the guarantee where:
1 The fault has been caused or is
attributable to accidental use,
misuse, negligent use or used
contrary to the manufacturers
recommendations or where the fault
has been caused by power surges or
damage caused in transit.
2 The appliance has been used on a
voltage supply other than that
stamped on the products.
3 Repairs have been attempted by
persons other than our service staff
(or authorised dealer).
4 Where the appliance has been used
for hire purposes or non domestic
use.
5 Morphy Richards are not liable to
carry out any type of servicing work,
under the guarantee.
6 Plastic filters for all Morphy Richards
kettles and coffee makers are not
covered by the guarantee.
• This guarantee does not confer any
rights other than those expressly set
out above and does not cover any
claims for consequential loss or
damage. This guarantee is offered as
an additional benefit and does not
affect your statutory rights as a
consumer.
• This guarantee is valid in the UK and
Ireland only.
For electrical products sold
within the European
Community. At the end of the
electrical products useful life it
should not be disposed of
with household waste.
Please recycle where facilities
exist. Check with your Local
Authority or retailer for
recycling advice in your
country.
Morphy Richards products are intended for household use only.
Morphy Richards has a policy of continuous improvement in product quality and
design. The company, therefore reserves the right to change the specification of its
models at any time.
The After Sales Division
Morphy Richards Ltd
Mexborough, South Yorkshire,
England, S64 8AJ
Helpline (office hours)
UK 0870 060 2610
Republic of Ireland 1800 409119
CCMM4477000099 RReevv22 44//0066
FFoorr ddeettaaiillss ooff ootthheerr pprroodduuccttss iinn tthhee MMoorrpphhyy RRiicchhaarrddss rraannggee pplleeaassee sseeee oouurr wweebbssiittee .. .. ..
47009 rev2 24/4/06 15:12 Page 8
Loading...
