Mitsubishi Electronics MXZ-2A20NA, MXZ-3A30NA, MXZ-4A36NA User Manual
Revision C:
• MXZ-4A36NA have been added.
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
OUTDOOR UNIT
SERVICE MANUAL
Inverter-controlled multi system type
Models
MXZ-2A20NA
MXZ-2A20NA -
1
MXZ-3A30NA
Please void OB444 REVISED EDITION-B.
HFC
utilized
R410A
No. OB444
REVISED EDITION-C
MXZ-3A30NA MXZ-4A36NA
MXZ-2A20NA
MXZ-2A20NA -
1
1
Indoor unit service manual
MSZ-A·NA Series (OB450)
CONTENTS
1. TECHNICAL CHANGES ····································2
2. PART NAMES AND FUNCTIONS······················6
3. INDOOR UNIT OPERATIONAL CHARACTERISTICS····7
4. SPECIFICATION···············································18
5. OUTLINES AND DIMENSIONS·······················21
6. WIRING DIAGRAM ··········································25
7. REFRIGERANT SYSTEM DIAGRAM··············30
8. DATA·································································36
9. ACTUA TOR CONTROL····································52
10. SERVICE FUNCTIONS·····································52
11. TROUBLESHOOTING ······································54
12. DISASSEMBLY INSTRUCTIONS·····················71
13. PARTS LIST······················································80
14. RoHS PARTS LIST···········································88
15. OPTIONAL PARTS ·········································100
NOTE:
• This service manual describes technical
data of the outdoor units.
• RoHS compliant products have <G> mark
on the spec name plate.
For servicing of RoHS compliant products,
refer to the RoHS Parts List.
9700058
The Slim Line.
From Mitsubishi Electric.
TM
33223
Revision A:
• RoHS PARTS LIST has been added.
Revision B:
• MXZ-2A20NA - and MXZ-3A30NA - have been added.
11
Revision C:
• MXZ-4A36NA has been added.
1
TECHNICAL CHANGES
MXZ-2A20NA
New model
MXZ-30TN2 ➔ MXZ-3A30NA
1. Combinations of connectable indoor units have been increased.
2. Capacity class of connectable indoor units have been made larger.
3. Compressor has been changed. (THV247FBA ➔ TNB220FMCH)
4. Outdoor fan motor has been changed. (RA6N60-AA ➔ RC0J60-AB)
5. Refrigerant has been changed. (R22 ➔ R410A)
6. Refrigerant system diagram has been changed.
• 1 of 2 high pressure switch has been removed.
• Accumulator has been removed.
• Receiver has been added.
7. Communication system has been changed.
8. Power supply way has been changed(change to supply to outdoor unit).
9. Evaporation temperature thermistor has been added.
10. Ambient temperature thermistor has been added.
MXZ-2A20NA ➔ MXZ-2A20NA -
1. Compressor has been changed. (SNB130FPDH1 ➔ SNB130FQBH1)
2. Gas pipe temperature thermistor has been removed.
3. Pre-heat control has been added.
4. Electronic control P.C. board has been changed.
5. Power board has been changed.
MXZ-3A30NA ➔ MXZ-3A30NA -
1. Ball valve has been changed to stop valve.
2. Gas pipe temperature thermistor has been removed.
3. Pre-heat control has been added.
4. Auto line correcting function has been added.
5. Noise filter P.C. board has been changed.
6. Electronic control P.C. board has been changed.
7. Weight has been changed. (158lb. ➔ 148lb.)
1
1
MXZ-4A36NA
New model
2
INFORMATION FOR THE AIR CONDITIONER WITH R410A REFRIGERANT
Refrigeration
oil
Refrigerant
New refrigerant
R410A
HFC-32: HFC-125 (50%:50%)
Pseudo-azeotropic refrigerant
Not included
A1/A1
72.6
-60.5
225.82
3.995
Non combustible
0
1730
From liquid phase in cylinder
Possible
Incompatible oil
Non
Non
Previous refrigerant
R22
R22 (100%)
Single refrigerant
Included
A1
86.5
-41.4
136.34
2.772
Non combustible
0.055
1700
Gas phase
Possible
Compatible oil
Light yellow
Non
Refrigerant
Composition (Ratio)
Refrigerant handling
Chlorine
Safety group (ASHRAE)
Molecular weight
Boiling point (-F)
Steam pressure [77-F](PSIG)
Saturated steam density [77-F](lb/ft
3
)
Combustibility
ODP w1
GWP w2
Refrigerant charge method
Additional charge on leakage
Kind
Color
Smell
w1:Ozone Depletion Potential : based on CFC-11
w2 :Global Warming Potential : based on CO
2
• This room air conditioner adopts HFC refrigerant (R410A) which never destroys the ozone layer.
• Pay particular attention to the following points, though the basic installation procedure is same as that for R22 air
conditioners.
1 As R410A has working pressure approximate 1.6 times as high as that of R22, some special tools and piping parts/
materials are required. Refer to the table below.
2 Take sufficient care not to allow water and other contaminations to enter the R410A refrigerant during storage and
installation, since it is more susceptible to contaminations than R22.
3 For refrigerant piping, use clean, pressure-proof parts/materials specifically designed for R410A. (Refer to 2. Refrigerant
piping.)
4 Composition change may occur in R410A since it is a mixed refrigerant. When charging, charge liquid refrigerant to prevent
composition change.
3
R410A tools Can R22 tools be used?
Gas leak detector
R410A has high pressures beyond the measurement range of existing
gauges.
Hose material has been changed to improve the pressure resistance.
Dedicated for HFC refrigerant.
1/4in. and 3/8in.
Description
Clamp bar hole has been enlarged to reinforce the spring strength in the tool.
Provided for flaring work (to be used with R22 flare tool).
Provided to prevent the back flow of oil. This adapter enables you to use
vacuum pumps.
It is difficult to measure R410A with a charging cylinder because the
refrigerant bubbles due to high pressure and high-speed vaporization.
No
No
No
Yes
Yes
New
New
New
Gauge manifold
Charge hose
Torque wrench
Flare tool
Flare gauge
Vacuum pump
adapter
Electronic scale for
refrigerant charging
No : Not Substitutable for R410A Yes : Substitutable for R410A
No 1/2in. and 5/8in.
1.Tools dedicated for the air conditioner with R410A refrigerant
New Specification Current Specification
The incompatible refrigeration oil easily separates from
refrigerant and is in the upper layer inside the suction muffler.
Raising position of the oil back hole enables to back the
refrigeration oil of the upper layer to flow back to the
compressor.
Since refrigerant and refrigeration oil are compatible,
refrigeration oil goes back to the compressor through the
lower position oil back hole.
Compressor
Suction muffler
Oil back hole
Refrigeration oil
Refrigerant
Compressor
Suction muffler
Oil back hole
Refrigeration oil /Refrigerant
Compressor
-22 -4 14 32 50 68
86
104 122 140
-73
0
73
145
218
290
363
435
508
580
(PSIG)
R410A
R22
Conversion chart of refrigerant temperature and pressure
Saturated liquid pressure
(-F)
The following tools are required for R410A refrigerant. Some R22 tools can be substituted for R410A tools.
4
2.Refrigerant piping
Wall thickness
(inch)
Outside diameter
(inch)
1/4
3/8
1/2
5/8
0.0315
0.0315
0.0315
0.0394
Heat resisting foam plastic
Specific gravity 0.045 Thickness 0.315 inch
Insulation material
Electronic scale for refrigerant charging
Outdoor unit
Refrigerant gas
cylinder
operating valve
Refrigerant gas cylinder
for R410A with siphon
Refrigerant (liquid)
Service port
Gauge manifold
valve (for R410A)
Union
Liquid pipe
Gas pipe
Stop valve
Indoor unit
Charge hose (for R410A)
1 Specifications
Use the copper or copper-alloy seamless pipes for refrigerant that meet the following specifications.
2 Flaring work and flare nut
Flaring work for R410A pipe differs from that for R22 pipe.
For details of flaring work, refer to installation manual “FLARING WORK”.
Pipe diameter
(inch)
1/4
3/8
1/2
5/8
17 [11/16]
26 [1-1/32]
29 [1-5/32]
Dimension of flare nut
(mm) [inch]
R410A
22 [7/8]
R22
17 [11/16]
22 [7/8]
24 [15/16]
27 [1-1/16]
3.Refrigeration oil
Apply the special refrigeration oil (accessories: packed with indoor unit) to the flare and the union seat surfaces.
4.Air purge
• Do not discharge the refrigerant into the atmosphere.
Take care not to discharge refrigerant into the atmosphere during installation, reinstallation, or repairs to the refrigerant
circuit.
• Use the vacuum pump for air purging for the purpose of environmental protection.
5.Additional charge
For additional charging, charge the refrigerant from liquid phase of the gas cylinder.
If the refrigerant is charged from the gas phase, composition change may occur in the refrigerant inside the cylinder and the
outdoor unit. In this case, ability of the refrigeration cycle decreases or normal operation can be impossible. However,
charging the liquid refrigerant all at once may cause the compressor to be locked. Thus, charge the refrigerant slowly.
5
MXZ-3A30NA
Air inlet
Drain outlet
(Back and side)
Air outlet
Air inlet
Drain outlet
(Back and side)
Air outlet
MXZ-3A30NA - MXZ-4A36NA
1
Air inlet
(Back and side)
Air outlet
Drain outlet
6
1
09
12
15
09+09
09+12
09+15
12+12
95
95
95
97
97
97
97
3.34
4.53
7.05
7.80
9.64
9.64
9.64
3.69
5.01
7.79
8.62
10.66
10.66
10.66
–
–
–
9,000
11,500
12,500
10,000
9,000
(5,400 ~ 9,000)
12,000
(5,400 ~ 12,000)
15,000
(5,400 ~ 15,000)
18,000
(7,800 ~ 18,000)
20,000
(7,800 ~ 20,000)
20,000
(7,800 ~ 20,000)
20,000
(7,800 ~ 20,000)
730
(490 ~ 730)
990
( 490 ~ 990)
1,540
(490 ~ 1,540)
1,740
(630 ~ 1,740)
2,150
(630 ~ 2,150)
2,150
(630 ~ 2,150)
2,150
(630 ~ 2,150)
9,000
12,000
15,000
9,000
8,500
7,500
10,000
Indoor units
combination
Unit A Unit B
Cooling capacity (BTU/h)
Total
Power consumption
(W)
Current
(A)
Power
factor
(%)
208V 230V
MXZ-2A20NA MXZ-2A20NA -
09
12
15
09+09
09+12
09+15
12+12
95
95
95
97
97
97
97
4.30
5.40
7.87
8.16
7.98
7.98
7.98
4.76
5.97
8.70
9.02
8.82
8.82
8.82
–
–
–
10,900
12,500
13,750
11,000
10,900
(5,200 ~ 15,400)
13,600
(5,200 ~ 16,400)
18,000
(5,200 ~ 21,100)
21,800
(8,500 ~ 21,800)
22,000
(8,500 ~ 22,000)
22,000
(8,500 ~ 22,000)
22,000
(8,500 ~ 22,000)
940
(480 ~ 1,430)
1,180
(480 ~1,460)
1,720
(480 ~ 2,100)
1,820
(520 ~ 1,820)
1,780
(520 ~ 1,780)
1,780
(520 ~ 1,780)
1,780
(520 ~ 1,780)
10,900
13,600
18,000
10,900
9,500
8,250
11,000
Indoor units
combination
Heating capacity (BTU/h)
Total
Power consumption
(W)
Current
(A)
Power
factor
(%)
208V 230V
Unit A Unit B
3
The following charts show indoor unit performance when operating individually or in combination. For authorized system
configurations of the indoor units, please refer to the Mr. Slim brochure.
INDOOR UNIT OPERATIONAL CHARACTERISTICS
7
1
09
12
15
17
24
09+09
09+12
09+15
09+17
09+24
12+12
12+15
12+17
15+15
15+17
17+17
09+09+09
09+09+12
09+09+15
09+09+17
95
95
95
95
95
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
3.66
4.58
6.04
6.77
10.07
8.07
8.96
11.21
12.10
14.34
11.21
12.55
12.55
12.55
12.55
12.55
12.82
14.57
14.57
14.57
4.05
5.06
6.68
7.49
11.13
8.92
9.91
12.39
13.38
15.86
12.39
13.88
13.88
13.88
13.88
13.88
14.18
16.11
16.11
16.11
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
9,000
11,400
12,900
13,800
9,000
(7,200 ~ 9,000)
12,000
(7,200 ~ 12,000)
15,000
(7,200 ~ 15,000)
16,200
(7,200 ~ 16,200)
22,000
(7,200 ~ 22,000)
18,000
(12,000 ~ 18,000)
21,000
(12,000 ~ 21,000)
24,000
(12,000 ~ 24,000)
25,200
(12,000 ~ 25,200)
28,000
(12,000 ~ 28,000)
24,000
(12,000 ~ 24,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
27,000
(12,600 ~ 27,000)
28,400
(12,600 ~ 28,400)
28,400
(12,600 ~ 28,400)
28,400
(12,600 ~ 28,400)
–
–
–
–
–
9,000
12,000
15,000
16,200
20,400
12,000
14,500
15,200
13,000
13,800
13,000
9,000
8,500
7,750
7,300
9,000
12,000
15,000
16,200
22,000
9,000
9,000
9,000
9,000
7,600
12,000
11,500
10,800
13,000
12,200
13,000
9,000
8,500
7,750
7,300
Indoor units
combination
Unit A Unit B Unit C
Cooling capacity (BTU/h)
Total
Power consumption
(W)
Current
(A)
Power
factor
(%)
208V 230V
MXZ-3A30NA MXZ-3A30NA -
800
(650 ~ 800)
1,000
(650 ~ 1,000)
1,320
(650 ~ 1,320)
1,480
(650 ~ 1,480)
2,220
(650 ~ 2,200)
1,800
(920 ~ 1,800)
2,000
(920 ~ 2,000)
2,500
(920 ~ 2,500)
2,700
(920 ~ 2,700)
3,200
(920 ~ 3,200)
2,500
(920 ~ 2,500)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,860
(1,000 ~ 2,850)
3,250
(1,000 ~ 3,250)
3,250
(1,000 ~ 3,250)
3,250
(1,000 ~ 3,250)
8
Indoor units
combination
09
12
15
17
24
09+09
09+12
09+15
09+17
09+24
12+12
12+15
12+17
15+15
15+17
17+17
09+09+09
09+09+12
09+09+15
09+09+17
Heating capacity (BTU/h)
Unit A Unit B Unit C
10,900
13,600
18,000
20,100
23,200
10,900
10,900
10,100
9,300
7,300
13,500
12,000
11,200
13,500
12,700
13,500
9,500
8,600
7,800
7,350
–
–
–
–
–
10,900
13,600
16,900
17,700
19,700
13,500
15,000
15,800
13,500
14,300
13,500
9,500
8,600
7,800
7,350
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
9,500
11,400
13,000
13,900
Total
10,900
(8,600 ~ 15,400)
13,600
(8,600 ~ 16,400)
18,000
(8,600 ~ 21,100)
20,100
(8,600 ~ 21,500)
23,200
(8,600 ~ 27,800)
21,800
(11,000 ~ 31,000)
24,500
(11,000 ~ 33,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
28,500
(11,400 ~ 36,000)
28,600
(11,400 ~ 36,000)
28,600
(11,400 ~ 36,000)
28,600
(11,400 ~ 36,000)
Power consumption
(W)
1,100
(780 ~1,520)
1,380
(780 ~ 1,600)
1,940
(780 ~ 2,280)
2,240
(780 ~ 2,300)
2,520
(780 ~ 3,000)
1,700
(740 ~2,560)
1,980
(740 ~ 2,800)
2,200
(740 ~ 2,920)
2,200
(740 ~ 2,920)
1,980
(740 ~ 2,740)
2,200
(740 ~ 2,920)
2,160
(740 ~ 2,860)
2,140
(740 ~ 2,860)
2,120
(740 ~ 2,800)
2,110
(740 ~ 2,800)
2,100
(740 ~ 2,800)
2,180
(740 ~ 2,880)
2,180
(740 ~ 2,880)
2,180
(740 ~ 2,880)
2,180
(740 ~ 2,880)
Current
(A)
208V 230V
5.57
6.98
9.82
11.34
12.75
8.43
9.81
10.90
10.90
9.81
10.90
10.71
10.61
10.51
10.46
10.41
10.80
10.80
10.80
10.80
5.03
6.32
8.88
10.25
11.53
7.62
8.87
9.86
9.86
8.87
9.86
9.68
9.59
9.50
9.46
9.41
9.77
9.77
9.77
9.77
Power
factor
(%)
95
95
95
95
95
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
9
09
12
15
17
24
09+09
09+12
09+15
09+17
09+24
12+12
12+15
12+17
15+15
15+17
17+17
09+09+09
09+09+12
09+09+15
09+09+17
09+09+24
09+12+12
95
95
95
95
95
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
4.05
5.06
6.68
7.49
11.13
8.92
9.91
12.39
13.38
15.86
12.39
13.88
13.88
13.88
13.88
13.88
14.18
16.21
17.35
17.35
17.35
17.35
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
9,000
12,000
14,500
15,700
18,300
11,700
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
9,000
(7,200 ~ 9,000)
12,000
(7,200 ~ 12,000)
15,000
(7,200 ~ 15,000)
16,200
(7,200 ~ 16,200)
22,000
(7,200 ~ 22,000)
18,000
(12,000 ~ 18,000)
21,000
(12,000 ~ 21,000)
24,000
(12,000 ~ 24,000)
25,200
(12,000 ~ 25,200)
28,000
(12,000 ~ 28,000)
24,000
(12,000 ~ 24,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
27,000
(12,600 ~ 27,000)
30,000
(12,600 ~ 30,000)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
–
–
–
–
–
9,000
12,000
15,000
16,200
20,400
12,000
14,500
15,200
13,000
13,800
13,000
9,000
9,000
8,800
8,200
6,900
11,700
9,000
12,000
15,000
16,200
22,000
9,000
9,000
9,000
9,000
7,600
12,000
11,500
10,800
13,000
12,200
13,000
9,000
9,000
8,800
8,200
6,900
8,700
Indoor units
combination
Unit A Unit B Unit C Unit D
Cooling capacity (BTU/h)
Total
Power consumption
(W)
Current
(A)
Power
factor
(%)
208V
MXZ-4A36NA 208V
800
(650 ~ 800)
1,000
(650 ~ 1,000)
1,320
(650 ~ 1,320)
1,480
(650 ~ 1,480)
2,200
(650 ~ 2,200)
1,800
(920 ~ 1,800)
2,000
(920 ~ 2,000)
2,500
(920 ~ 2,500)
2,700
(920 ~ 2,700)
3,200
(920 ~ 3,200)
2,500
(920 ~ 2,500)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,860
(1,000 ~ 2,850)
3,270
(1,000 ~ 3,270)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
10
Indoor units
combination
09+12+15
09+12+17
09+15+15
09+15+17
09+17+17
12+12+12
12+12+15
12+12+17
12+15+15
09+09+09+09
09+09+09+12
09+09+09+15
09+09+12+12
Cooling capacity (BTU/h)
Unit A Unit B Unit C Unit D
8,000
7,600
7,500
7,100
6,700
10,700
9,900
9,400
9,100
9,000
8,300
7,700
7,700
10,700
10,100
12,300
11,700
12,700
10,700
9,900
9,400
11,500
9,000
8,300
7,700
7,700
13,400
14,400
12,300
13,300
12,700
10,700
12,300
13,300
11,500
9,000
8,300
7,700
10,300
–
–
–
–
–
–
–
–
–
9,000
11,100
12,900
10,300
Total
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
36,000
(12,600 ~ 36,400)
36,000
(12,600 ~ 36,400)
36,000
(12,600 ~ 36,400)
36,000
(12,600 ~ 36,400)
Power consumption
(W)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,820
(1,000 ~ 3,900)
3,820
(1,000 ~ 3,900)
3,820
(1,000 ~ 3,900)
3,820
(1,000 ~ 3,900)
Current
(A)
208V
17.35
17.35
17.35
17.35
17.35
17.35
17.35
17.35
17.35
18.55
18.55
18.55
18.55
Power
factor
(%)
97
97
97
97
97
97
97
97
97
99
99
99
99
11
09
12
15
17
24
09+09
09+12
09+15
09+17
09+24
12+12
12+15
12+17
15+15
15+17
17+17
09+09+09
09+09+12
09+09+15
09+09+17
09+09+24
09+12+12
09+12+15
95
95
95
95
95
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
5.57
6.98
9.82
11.34
12.75
8.43
9.81
10.90
10.90
9.81
10.90
10.71
10.61
10.51
10.46
10.41
13.38
13.38
13.38
13.38
13.38
13.38
13.38
Indoor units
combination
Unit A Unit B Unit DUnit C
Heating capacity (BTU/h)
Total
Power consumption
(W)
Current
(A)
Power
factor
(%)
208V
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
10,800
12,400
14,600
15,600
16,800
11,500
13,700
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
10,900
(8,600 ~ 15,400)
13,600
(8,600 ~ 16,400)
18,000
(8,600 ~ 21,100)
20,100
(8,600 ~ 21,500)
23,200
(8,600 ~ 27,800)
21,800
(11,000 ~ 31,000)
24,500
(11,000 ~ 33,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
–
–
–
–
–
10,900
13,600
16,900
17,700
19,700
13,500
15,000
15,800
13,500
14,300
13,500
10,800
10,000
8,900
8,400
7,800
11,500
10,400
1,100
(780 ~1,520)
1,380
(780 ~ 1,600)
1,940
(780 ~ 2,280)
2,240
(780 ~ 2,300)
2,520
(780 ~ 3,000)
1,700
(740 ~2,560)
1,980
(740 ~ 2,800)
2,200
(740 ~ 2,920)
2,200
(740 ~ 2,920)
1,980
(740 ~ 2,740)
2,200
(740 ~ 2,920)
2,160
(740 ~ 2,860)
2,140
(740 ~ 2,860)
2,120
(740 ~ 2,800)
2,110
(740 ~ 2,800)
2,100
(740 ~ 2,800)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
10,900
13,600
18,000
20,100
23,200
10,900
10,900
10,100
9,300
7,300
13,500
12,000
11,200
13,500
12,700
13,500
10,800
10,000
8,900
8,400
7,800
9,400
8,300
12
Indoor units
combination
09+12+17
09+15+15
09+15+17
09+17+17
12+12+12
12+12+15
12+12+17
12+15+15
09+09+09+09
09+09+09+12
09+09+09+15
09+09+12+12
Heating capacity (BTU/h)
Unit A Unit B Unit DUnit C
7,900
7,600
7,200
7,000
10,800
9,700
9,300
9,000
9,000
8,300
7,700
7,700
9,900
12,400
11,900
12,700
10,800
9,700
9,300
11,700
9,000
8,300
7,700
7,700
14,600
12,400
13,300
12,700
10,800
13,000
13,800
11,700
9,000
8,300
7,700
10,300
–
–
–
–
–
–
–
–
9,000
11,100
12,900
10,300
Total
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
36,000
(11,400 ~ 41,200)
36,000
(11,400 ~ 41,200)
36,000
(11,400 ~ 41,200)
36,000
(11,400 ~ 41,200)
Power consumption
(W)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
3,100
(740 ~ 4,000)
3,100
(740 ~ 4,000)
3,100
(740 ~ 4,000)
3,100
(740 ~ 4,000)
Current
(A)
208V
13.38
13.38
13.38
13.38
13.38
13.38
13.38
13.38
15.05
15.05
15.05
15.05
Power
factor
(%)
97
97
97
97
97
97
97
97
99
99
99
99
13
09
12
15
17
24
09+09
09+12
09+15
09+17
09+24
12+12
12+15
12+17
15+15
15+17
17+17
09+09+09
09+09+12
09+09+15
09+09+17
09+09+24
09+12+12
95
95
95
95
95
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
3.66
4.58
6.04
6.77
10.07
8.07
8.96
11.21
12.10
14.34
11.21
12.55
12.55
12.55
12.55
12.55
12.82
14.66
15.69
15.69
15.69
15.69
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
9,000
12,000
14,500
15,700
18,300
11,700
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
9,000
(7,200 ~ 9,000)
12,000
(7,200 ~ 12,000)
15,000
(7,200 ~ 15,000)
16,200
(7,200 ~ 16,200)
22,000
(7,200 ~ 22,000)
18,000
(12,000 ~ 18,000)
21,000
(12,000 ~ 21,000)
24,000
(12,000 ~ 24,000)
25,200
(12,000 ~ 25,200)
28,000
(12,000 ~ 28,000)
24,000
(12,000 ~ 24,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
26,000
(12,000 ~ 26,000)
27,000
(12,600 ~ 27,000)
30,000
(12,600 ~ 30,000)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
–
–
–
–
–
9,000
12,000
15,000
16,200
20,400
12,000
14,500
15,200
13,000
13,800
13,000
9,000
9,000
8,800
8,200
6,900
11,700
9,000
12,000
15,000
16,200
22,000
9,000
9,000
9,000
9,000
7,600
12,000
11,500
10,800
13,000
12,200
13,000
9,000
9,000
8,800
8,200
6,900
8,700
Indoor units
combination
Unit A Unit B Unit C Unit D
Cooling capacity (BTU/h)
Total
Power consumption
(W)
Current
(A)
Power
factor
(%)
230V
MXZ-4A36NA 230V
800
(650 ~ 800)
1,000
(650 ~ 1,000)
1,320
(650 ~ 1,320)
1,480
(650 ~ 1,480)
2,200
(650 ~ 2,200)
1,800
(920 ~ 1,800)
2,000
(920 ~ 2,000)
2,500
(920 ~ 2,500)
2,700
(920 ~ 2,700)
3,200
(920 ~ 3,200)
2,500
(920 ~ 2,500)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,800
(920 ~ 2,800)
2,860
(1,000 ~ 2,850)
3,270
(1,000 ~ 3,270)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
14
Indoor units
combination
09+12+15
09+12+17
09+15+15
09+15+17
09+17+17
12+12+12
12+12+15
12+12+17
12+15+15
09+09+09+09
09+09+09+12
09+09+09+15
09+09+12+12
Cooling capacity (BTU/h)
Unit A Unit B Unit C Unit D
8,000
7,600
7,500
7,100
6,700
10,700
9,900
9,400
9,100
9,000
8,300
7,700
7,700
10,700
10,100
12,300
11,700
12,700
10,700
9,900
9,400
11,500
9,000
8,300
7,700
7,700
13,400
14,400
12,300
13,300
12,700
10,700
12,300
13,300
11,500
9,000
8,300
7,700
10,300
–
–
–
–
–
–
–
–
–
9,000
11,100
12,900
10,300
Total
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
32,100
(12,600 ~ 32,100)
36,000
(12,600 ~ 36,400)
36,000
(12,600 ~ 36,400)
36,000
(12,600 ~ 36,400)
36,000
(12,600 ~ 36,400)
Power consumption
(W)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,500
(1,000 ~ 3,500)
3,820
(1,000 ~ 3,900)
3,820
(1,000 ~ 3,900)
3,820
(1,000 ~ 3,900)
3,820
(1,000 ~ 3,900)
Current
(A)
230V
15.69
15.69
15.69
15.69
15.69
15.69
15.69
15.69
15.69
16.78
16.78
16.78
16.78
Power
factor
(%)
97
97
97
97
97
97
97
97
97
99
99
99
99
15
09
12
15
17
24
09+09
09+12
09+15
09+17
09+24
12+12
12+15
12+17
15+15
15+17
17+17
09+09+09
09+09+12
09+09+15
09+09+17
09+09+24
09+12+12
09+12+15
95
95
95
95
95
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
97
5.03
6.32
8.88
10.25
11.53
7.62
8.87
9.86
9.86
8.87
9.86
9.68
9.59
9.50
9.46
9.41
12.10
12.10
12.10
12.10
12.10
12.10
12.10
Indoor units
combination
Unit A Unit B Unit DUnit C
Heating capacity (BTU/h)
Total
Power consumption
(W)
Current
(A)
Power
factor
(%)
230V
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
10,800
12,400
14,600
15,600
16,800
11,500
13,700
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
10,900
(8,600 ~ 15,400)
13,600
(8,600 ~ 16,400)
18,000
(8,600 ~ 21,100)
20,100
(8,600 ~ 21,500)
23,200
(8,600 ~ 27,800)
21,800
(11,000 ~ 31,000)
24,500
(11,000 ~ 33,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
27,000
(11,000 ~ 35,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
–
–
–
–
–
10,900
13,600
16,900
17,700
19,700
13,500
15,000
15,800
13,500
14,300
13,500
10,800
10,000
8,900
8,400
7,800
11,500
10,400
1,100
(780 ~1,520)
1,380
(780 ~ 1,600)
1,940
(780 ~ 2,280)
2,240
(780 ~ 2,300)
2,520
(780 ~ 3,000)
1,700
(740 ~2,560)
1,980
(740 ~ 2,800)
2,200
(740 ~ 2,920)
2,200
(740 ~ 2,920)
1,980
(740 ~ 2,740)
2,200
(740 ~ 2,920)
2,160
(740 ~ 2,860)
2,140
(740 ~ 2,860)
2,120
(740 ~ 2,800)
2,110
(740 ~ 2,800)
2,100
(740 ~ 2,800)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
10,900
13,600
18,000
20,100
23,200
10,900
10,900
10,100
9,300
7,300
13,500
12,000
11,200
13,500
12,700
13,500
10,800
10,000
8,900
8,400
7,800
9,400
8,300
16
Indoor units
combination
09+12+17
09+15+15
09+15+17
09+17+17
12+12+12
12+12+15
12+12+17
12+15+15
09+09+09+09
09+09+09+12
09+09+09+15
09+09+12+12
Heating capacity (BTU/h)
Unit A Unit B Unit DUnit C
7,900
7,600
7,200
7,000
10,800
9,700
9,300
9,000
9,000
8,300
7,700
7,700
9,900
12,400
11,900
12,700
10,800
9,700
9,300
11,700
9,000
8,300
7,700
7,700
14,600
12,400
13,300
12,700
10,800
13,000
13,800
11,700
9,000
8,300
7,700
10,300
–
–
–
–
–
–
–
–
9,000
11,100
12,900
10,300
Total
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
32,400
(11,400 ~ 36,000)
36,000
(11,400 ~ 43,000)
36,000
(11,400 ~ 43,000)
36,000
(11,400 ~ 43,000)
36,000
(11,400 ~ 43,000)
Power consumption
(W)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
2,700
(740 ~ 2,880)
3,100
(740 ~ 4,350)
3,100
(740 ~ 4,350)
3,100
(740 ~ 4,350)
3,100
(740 ~ 4,350)
Current
(A)
230V
12.10
12.10
12.10
12.10
12.10
12.10
12.10
12.10
13.61
13.61
13.61
13.61
Power
factor
(%)
97
97
97
97
97
97
97
97
99
99
99
99
17
4
1
1
1
Item Model
Capacity
Power
consumption
EER [SEER]
HSPF IV (V)
COP
External finish
Power supply
Max. fuse size (time delay)
Min. circuit ampacity
Fan motor
Compressor
Refrigerant control
Sound level
Defrost method
Dimensions
Weight
Remote controller
Control voltage (by built-in transformer)
Refrigerant piping
Valve size
Connection method
Refrigerant charge (R410A)
Refrigeration oil (Model)
Model
Winding resistance (at 68˚F) "
W
D
H
Liquid
Gas
Indoor
Outdoor
Btu/h
Btu/h
Btu/h
W
W
W
V, phase, Hz
A
A
F.L.A
R.L.A
L.R.A
dB(A)
in.
in.
in.
lb.
in.
in.
lb.
oz.
20,000/ (7,800 ~ 20,000)
22,000/ (8,500 ~ 22,000)
14,500
2,150/ (630 ~ 2,150)
1,780/ (520 ~ 1,780)
1,500 (1,500)
9.3 [15
]
9.0 (7.0)
3.63
Munsell 5Y 8/1
208/230, 1, 60
20
15
0.96
U-V 0.45 V-W 0.45 W-U 0.45
U-V 0.98 V-W 0.98 W-U 0.98
10.1
15
LEV
49/51
Reverse cycle
33-1/16
13
27-15/16
130
Wireless type
12-24V DC
Not supplied (optional parts)
1/4
A,B:3/8
Flared
Flared
5lb. 15oz.
❈1 ❈3
❈1
❈1
❈2
❈1
❈1
❈2
Cooling
Heating 47
Heating 17
Cooling
Heating 47
Heating 17
Cooling
Heating
Heating
MXZ-2A20NA MXZ-2A20NA -
SNB130FPDH1
SNB130FQBH1
20.3 (NEO22)
23.7 (NEO22)
MXZ-2A20NA
MXZ-2A20NA -
MXZ-2A20NA
MXZ-2A20NA -
1
MXZ-2A20NA
MXZ-2A20NA -
Cooling
Heating
Mode
❈1: "A" Cooling steady state at rated compressor speed
❈3: "B-2" Cooling steady state at rated compressor speed
"B-1" Cooling steady state at minimum compressor speed
Low ambient cooling steady state at minimum compressor speed
Intermediate cooling steady state at intermediate compressor speed
w
❈1: Standard rating-heating at rated compressor speed
❈2: Low temperature heating at rated compressor speed
Max. temperature heating at minimum compressor speed
High temperature heating at minimum compressor speed
Frost accumulation at rated compressor speed
Frost accumulation at intermediate compressor speed
w
Test
Indoor air condition Outdoor air condition
Dry bulb
Wet bulb
Dry bulb
Wet bulb
80
80
80
80
80
70
70
70
70
70
70
67
67
67
67
67
60
60
60
60
60
60
95
82
82
67
87
47
17
62
47
35
35
(75)
(65)
(65)
(53.5)
(69)
43
15
56.5
43
33
33
w
At intermediate compressor speed
=("Cooling rated compressor speed" - "minimum compressor speed") / 3 + "minimum compressor speed".
Unit: ˚F
SPECIFICATION
NOTE : Test conditions are based on ARI 210/240.
❈1 : Rating conditions(cooling) — Indoor : 80˚FDB, 67˚FWB, Outdoor : 95˚FDB, (75˚FWB)
❈2 : (heating) — Indoor : 70˚FDB, 60˚FWB, Outdoor : 17˚FDB, 15˚FWB
❈3 : (cooling) — Indoor : 80˚FDB, 67˚FWB, Outdoor : 82˚FDB, 65˚FWB
(heating) — Indoor : 70˚FDB, 60˚FWB, Outdoor : 47˚FDB, 43˚FWB
18
Item Model
❈1
❈1
❈1
❈2
❈1
❈2
Btu/h
Btu/h
Btu/h
Capacity
Power
consumption
❈1 ❈3
EER [SEER]
HSPF IV (V)
COP
Cooling
Heating 47
Heating 17
Cooling
Heating 47
Heating 17
Cooling
Heating
Heating
External finish
Power supply
V, phase, Hz
Max. fuse size (time delay)
Min. circuit ampacity
Fan motor
F.L.A
Model
Compressor
Winding resistance (at 68˚F) "
R.L.A
L.R.A
Refrigerant control
Sound level
dB(A)
Defrost method
W
Dimensions
D
H
Weight
Remote controller
Control voltage (by built-in transformer)
Refrigerant piping
Valve size
Connection method
Liquid
Gas
Indoor
Outdoor
Refrigerant charge (R410A)
Refrigeration oil (Model)
W
W
W
A
A
in.
in.
in.
MXZ-3A30NA
lb.
MXZ-3A30NA -
in.
in.
lb.
oz.
MXZ-3A30NA MXZ-3A30NA -
28,400/ (12,600 ~ 28,400)
28,600/ (11,400 ~ 36,000)
18,800
3,250/ (1,000 ~ 3,250)
2,180/ (740 ~ 2,880)
2,120
8.7 [16.0
]
10.0 (7.5)
3.84
Munsell 3.0Y 7.8/1.1
208/230, 1, 60
20
15
0.93
TNB220FMCH
U-V 0.61 V-W 0.61 W-U 0.61
11
15
LEV
49/49
Reverse cycle
35-7/16
12-19/32
35-7/16
158
1
148
Wireless type
12-24V DC
Not supplied (optional parts)
1/4
A:1/2 B,C:3/8
Flared
Flared
7lb. 11oz.
29.4 (NEO22)
1
NOTE : Test conditions are based on ARI 210/240.
❈1 : Rating conditions(cooling) — Indoor : 80˚FDB, 67˚FWB, Outdoor : 95˚FDB, (75˚FWB)
❈2 : (heating) — Indoor : 70˚FDB, 60˚FWB, Outdoor : 17˚FDB, 15˚FWB
❈3 : (cooling) — Indoor : 80˚FDB, 67˚FWB, Outdoor : 82˚FDB, 65˚FWB
Mode
Cooling
❈1: "A" Cooling steady state at rated compressor speed
❈3: "B-2" Cooling steady state at rated compressor speed
"B-1" Cooling steady state at minimum compressor speed
Low ambient cooling steady state at minimum compressor speed
Intermediate cooling steady state at intermediate compressor speed
Heating
❈1: Standard rating-heating at rated compressor speed
❈2: Low temperature heating at rated compressor speed
Max. temperature heating at minimum compressor speed
High temperature heating at minimum compressor speed
Frost accumulation at rated compressor speed
Frost accumulation at intermediate compressor speed
w
At intermediate compressor speed
(heating) — Indoor : 70˚FDB, 60˚FWB, Outdoor : 47˚FDB, 43˚FWB
Test
w
w
Indoor air condition Outdoor air condition
Dry bulb
80
80
80
80
80
70
70
70
70
70
70
Wet bulb
67
67
67
67
67
60
60
60
60
60
60
=("Cooling rated compressor speed" - "minimum compressor speed") / 3 + "minimum compressor speed".
19
Dry bulb
95
82
82
67
87
47
17
62
47
35
35
Unit: ˚F
Wet bulb
(75)
(65)
(65)
(53.5)
(69)
43
15
56.5
43
33
33
Item
208V
208V
36,000/ (11,400 ~ 41,200)
3,100/ (740 ~ 4,000)
230V
230V
36,000/ (11,400 ~ 43,000)
3,100/ (740 ~ 4,350)
Model
Capacity
Power
consumption
EER [SEER]
HSPF IV (V)
COP
External finish
Power supply
Max. fuse size (time delay)
Min. circuit ampacity
Fan motor
Compressor
Refrigerant control
Sound level
Defrost method
Dimensions
Weight
Remote controller
Control voltage (by built-in transformer)
Refrigerant piping
Valve size
Connection method
Refrigerant charge (R410A)
Refrigeration oil (Model)
Model
Winding resistance (at 68˚F) "
W
D
H
Liquid
Gas
Indoor
Outdoor
Btu/h
Btu/h
Btu/h
W
W
W
V, phase, Hz
A
A
F.L.A
R.L.A
L.R.A
dB(A)
in.
in.
in.
lb.
in.
in.
lb.
oz.
36,000/ (12,600 ~ 36,400)
24,600
3,820/ (1,000 ~ 3,900)
3,340
9.4 [16.0
]
9.5 (7.0)
3.40
Munsell 3.0Y 7.8/1.1
208/230, 1, 60
20
19
0.93
TNB220FMCH
U-V 0.61 V-W 0.61 W-U 0.61
14.4
15
LEV
54/57
Reverse cycle
35-7/16
12-19/32
35-7/16
150
Wireless type
12-24V DC
Not supplied (optional parts)
1/4
A:1/2 B,C,D:3/8
Flared
Flared
8lb. 13oz.
29.4 (NEO22)
❈1 ❈3
❈1
❈1
❈2
❈1
❈1
❈2
Cooling
Heating 47
Heating 17
Cooling
Heating 47
Heating 17
Cooling
Heating
Heating
MXZ-4A36NA
Cooling
Heating
Mode
❈1: "A" Cooling steady state at rated compressor speed
❈3: "B-2" Cooling steady state at rated compressor speed
"B-1" Cooling steady state at minimum compressor speed
Low ambient cooling steady state at minimum compressor speed
Intermediate cooling steady state at intermediate compressor speed
w
❈1: Standard rating-heating at rated compressor speed
❈2: Low temperature heating at rated compressor speed
Max. temperature heating at minimum compressor speed
High temperature heating at minimum compressor speed
Frost accumulation at rated compressor speed
Frost accumulation at intermediate compressor speed
w
Test
Indoor air condition Outdoor air condition
Dry bulb
Wet bulb
Dry bulb
Wet bulb
80
80
80
80
80
70
70
70
70
70
70
67
67
67
67
67
60
60
60
60
60
60
95
82
82
67
87
47
17
62
47
35
35
(75)
(65)
(65)
(53.5)
(69)
43
15
56.5
43
33
33
w
At intermediate compressor speed
=("Cooling rated compressor speed" - "minimum compressor speed") / 3 + "minimum compressor speed".
Unit: ˚F
NOTE : Test conditions are based on ARI 210/240.
❈1 : Rating conditions(cooling) — Indoor : 80˚FDB, 67˚FWB, Outdoor : 95˚FDB, (75˚FWB)
❈2 : (heating) — Indoor : 70˚FDB, 60˚FWB, Outdoor : 17˚FDB, 15˚FWB
❈3 : (cooling) — Indoor : 80˚FDB, 67˚FWB, Outdoor : 82˚FDB, 65˚FWB
(heating) — Indoor : 70˚FDB, 60˚FWB, Outdoor : 47˚FDB, 43˚FWB
20
5
OUTLINES AND DIMENSIONS
MXZ-2A20NA MXZ-2A20NA -
6-9/16" 6-21/32"
2-1/2"
1-7/32"21/32"
Air in
Drain hole 3-
14-3/16"
19-11/16"
11-11/32"9-3/16"
1-25/32"
1-1/2"1-7/32"
11/16" 11/16"14-3/16"
4-13/32"
(Base bolt M10)
1-3/16"33-1/16"
5-5/16"
Air in
Air out
[1-5/16"
15/16"
11-3/4" 2-5/8"
29/32"
1
15-19/32"
✕13/16" Oval hole
Indoor and outdoor
connect wiring
3-
[7/8" hole
1-3/16"12-3/4"
1-3/16"
27-15/16"
8-5/8"
More than 3.94 in.
1"
Liquid pipe
[1/4"flared (both A&B unit)
REQUIRED SPACE
Open as a rule
More than 19.69 in.
if the front and both sides are
open
Open as a rule
More than 19.69 in.
if the back, both sides
and top are open
1/2"1-3/16" 13"
Gas pipe
[3/8"flared (both A&B unit)
B unit connection
A unit connection
Unit: inch
More than 3.94 in.
More than 7.87 in.
if there are obstacles to both
sides
More than 13.78 in.
21
Grounding terminal
Conduit
cover
Lock nut
Connector
MXZ-3A30NA
3-15/32"
29/32"
1-1/4"
3-25/32"
29-9/16"
2-11/16"
15"
9-27/32"
1-3/16"
35-7/16"
1-5/16"
(7-7/8")
(5/8")
(1-1/16")
13-31/32"
(5/8")
15-1/4"
1-9/16"
12-19/32" 13/32"
7-7/8" 19-11/16"
35-7/16"
18-1/8"
12-1/2"
1-31/32"
29/32"
9-27/32"
10-5/8"
1-3/8"
1-3/8"
2-29/32"
Indoor and outdoor
connect wiring
4-[7/8" hole
Gas pipe
[1/2" flared (A unit)
[3/8" flared (B,C unit)
[1/4" flared
Liquid pipe
C unit connection
B unit connection
A unit connection
Air in
Drain hole 3-[1-5/16"
Air out
Air in
(Base bolt M10)
2-U-shape notched holes
(Base bolt M10)
2-15/32"✕1-13/32" Oval hole
More than 3.94 in.
Open as a rule
More than 19.69 in.
if the front and both sides are
open
More than 3.94 in.
More than 7.87 in.
if there are
obstacles to both
sides
Open as a rule
More than 19.69 in.
if the back, both sides
and top are open
More than 13.78 in.
Conduit cover
Lock nut
Connector
Unit: inch
REQUIRED SPACE
22
MXZ-3A30NA -
A
B
C
;
;
;
;
;
;
;
;
;
;
;
;
;
;
;
;;
;;
;
;;
;;
;
;
;;
;
;
;
;;
;;
;;
;
;;
;;
;
;
;
;
;
;
;
;
;
;;;;
;
;;
;
;
;
;
;
;;
;
;
;;
;
;
;;
;
;
;
;
;
;
;
;
;
;
;
;
;;
;
;
;
;
;
;;
;
;
;
;;
;
;
;;
;;
;;
;
;
;
;
;
;
;
;
;
;;
;
;
;;
;
;
;
;;
;
;;
;;
;
;
;
;;
;;
;
;
;
;
;;
;;
;
;
;;
;
;
;;;
;
;;;
;
;;
;
;
;
;
;
;
;
;;
;
;;
;
;
;
;
;
;
;;
;
;;
;
;
;
;
;
;
;
;
;;
;
;
;
;
;
;;
;
;;
;;
;;
;
;;
;;
;
;;
;
;;;;
;;
;
;
;;
;
;
;
;
;
;
;;
;
;
;
;
;
;
;
;
;;
;
;
;;
;
;
;
;
;
;
;
;
;;
;
;;
;;
;;
;
;;
;;
;;
;
;;
;;
;
;
;
;;
;;
;
;
;;
;
;
;
;
;
;;
;
;
;;
;
;
;
;
;
;
;
;
;
;;
;
;;
;
;;
;
;
;;
;;
;
;;
;
;
;;
;
;
;
;;
;;
;
;
;
;;
;
;
;
;
;
;
;;
;
;
;
;
;
;;
;
;
;;
;
;
;
;
;
;;
;
;
;
;
;
;
;
;
;
;;
;
;;
;
;
;
;
;
;
;
;
;
;
;
;;
;
;;
;
;
;
;
;
;;
;;
;
;
;
;;
;
;;
;
;
;
;
;;
;
;
;
;
;
;
;;
;
;;
;
;
;
;
;
;
;;
;
;
;
;
;
;;
;
;
;
;
;
;;
;;
;
;
;
;;
;;
;
;;
;
;
;;
;
;;
;
;
;;
;
;
;;;
;
;;;
;
;
;;
;
;
;;
;
;
;;
;
;;
;
;
;
;
;
;
;
;;;;
;
;
;
;
;
;;;;;;
;
;
;
;
;
;;
;
;
;
;
;
;
;;
;
;
;
;
;
;;
;
;
;
;;
;
;
;
;
;
;
;
;
;
;;
;
;;
;
;
;
;
;
;
;
;
;
;;
;
;
;
;
;
;
;;
;
;
;
;
;
;;
;
;
;
;
;
;
;
;
;
;;
;
;;
;
;
;
;
;
;
;
;;
;;
;
;
;
;;
;
;
;
;
;
;
;
;
;
;
;
;
;
;
;
;
;;
;
;
;;
;
;;
;
;
;;
;
;
;
;
;
;;
;
;
;
;
;
;
;
;;
;
;
;
;;
;
;
;
;;;
;
;;
;;;;
;
;
;
;
;
;
;;
;;;
;
;;
;
;
;
;;
;;
;
;
;
;
;
;;;
;
;
;
;
;;;
;
;
;
;
;
;
;
;
;;
;;
;
;;
;
;;;;;;
;
;;
;
;;
;
;
;;
;
;;
;;
;
;
;;;
;;
;;
;
;;
;;
;
;
;
;
;;;;
;;
;
;;;
;;
;
;
;;
;
;
;
;;
;
;;
;;
;;
;
;
;
;
;
;
;
;
;;
;;
;
;
;;
;
;;
;;
;
;
;;
;
;
;
;;
;
;;
;;
;
;
;
;
;;
;;
;;
;
;
;;
;;;
;
;
;;
;;;
;
;
;;
;;
;
;
;;
;;;;;
;
;;;
;
;
;;
;
;;;
;
;
;;
;;
;
;;
;
;;
;;
;
;
;
;
;
;
;
;;;;;;
;
;
;
;;;;
;
;
;
;;;
;;
;;;;
;;;
;;;;
;
;;
;;;;
;;;
;
;
;
;
;
;;;
;;
;
;;;
;
;
;;
;;
;
;;
;;
;;;;;
;;
;;;
;
;
;;
;;
;;
;
;;
;;
;
;
;;;
;;
;
;
;
;;
;;
;
;
;;;
;;
;
;
;;
;;
;;
;
;;;;
;
;
;
;;
;
;
;;
;;
;
;;
;
;
;
;;
;;;;;
;
;;;;
;;
;
;;;
;
;
;;
;;;;;
;;
;;;;;
;;
;;;;;
;;
;
;;
;
;
;
;;
;;;
;
;
;;
;;
;
;;
;
;;
;;
;;;
;
;
;
;
;;
;
;;
;;
;
;
;;
;;
;
;;;;
;;;
;;;;
;;
;;
;;
;;
;;
;
;
;
;
;;;;
;;
;
;
;;
;;;
;
;
;
;;
;
;;;
;
;;
;
;;
;;
;
;
;
;
;
;
;
;
;;;;
;;
;
;
;;
;;;
;
;
;
;
;;
;;
;
;;;
;
;
;;
;;
;;
;
;;
;;
;;
;
;
;;
;
;;;;;
;;
;;;;
;;
;
;
;
;
;
;
;
;
;;
;
;
;;
;
;;;
;;
;
;;
;;;;
;;;
;;
;
;;;
;
;;;
;
;;;
;
;
;;;;;;
;
;
;
;;
;;;;;
;;
;
;;
;
;
;;
;
;
;
15/16"
7/16"
5/8"
5/8"
1-1/16"
1-9/16"
14"
15-1/4"
10-5/8"
9-27/32"
1-3/8"
19-11/16" 7-7/8"7-7/8"
2-29/32"
1-3/8"
(Bolt pitch)
Air in
Air out
Air in
2-(15/32"o1-13/32") Oval hole
2-U Shaped notched hole
(Base bolt M10)
3-[7/8"Punched hole
(Connect wiring hole)
35-7/16"
(Connect wiring hole)
2-[7/8"Knockout
Handle
Handle
8-27/32"
1-25/32"
19-1/8"
12-1/2"
18-1/8"
29/32"
13/32"12-19/32"1-3/16"
3-15/32"
Gas pipe
[3/8 (B,C unit)
[1/2 (A unit)
More than 3-15/16"
More than 19-11/16"
More than 7-7/8"
More than13-25/32"
More than 3-15/16"
More than 19-11/16"
More than 13-25/32"
More than 13-25/32"
More than 3-15/16"
SERVICE SPACE
More than 3-15/16"
More than 19-11/16"
5-3/16"
Liquid pipe
[1/4 flared
35-7/16"
1-3/16"
4-3/4"
(Base bolt M10)
Drain hole 3-[1-5/16"
Note : Leave front and both sides
clearance fully.
Note : Leave front and overhead
clearance fully.
Note : Leave front, overhead and
both sides clearance fully.
1.Installation space
2.Service space
C unit connection
B unit connection
A unit connection
Conduit cover
Lock nut
Connector
1 Unit: inch
23
MXZ-4A36NA
A
B
C
D
15/16"
7/16"
5/8"
5/8"
1-1/16"
1-9/16"
14"
15-1/4"
10-5/8"
9-27/32"
1-3/8"
19-11/16" 7-7/8"7-7/8"
2-29/32"
1-3/8"
(Bolt pitch)
Air in
Air out
Air in
2-(15/32"o1-13/32") Oval hole
2-U Shaped notched hole
(Base bolt M10)
3-[7/8"Punched hole
(Connect wiring hole)
35-7/16"
(Connect wiring hole)
2-[7/8"Knockout
Handle
Handle
12-13/32"
1-25/32"
19-1/8"
12-1/2"
18-1/8"
29/32"
13/32"12-19/32"1-3/16"
3-15/32"
Gas pipe
[3/8 (B,C,D unit)
[1/2 (A unit)
More than 3-15/16"
More than 19-11/16"
More than 7-7/8"
More than13-25/32"
More than 3-15/16"
More than 19-11/16"
More than 13-25/32"
More than 13-25/32"
More than 3-15/16"
SERVICE SPACE
More than 3-15/16"
More than 19-11/16"
5-3/16"
Liquid pipe
[1/4 flared
35-7/16"
1-3/16"
4-3/4"
(Base bolt M10)
Drain hole 3-[1-5/16"
Note : Leave front and both sides
clearance fully.
Note : Leave front and overhead
clearance fully.
Note : Leave front, overhead and
both sides clearance fully.
1.Installation space
2.Service space
C unit connection
D unit connection
B unit connection
A unit connection
Unit: inch
24
Lock nut
Conduit cover
Connector
6
MXZ-2A20NA
WIRING DIAGRAM
25
MXZ-2A20NA -
1
26
MXZ-3A30NA
27
MXZ-3A30NA -
1
28
MXZ-4A36NA
V
BOARD
POWER
PFC
FILTERNOISE
P.C.BOARD
L
MC
CT1
X64
CT61
W
U
BLK
U
CB3
CB2
CB1
R
RED
1
2
BLK
3
GROUND
S
YLW
4
3
WHT
TAB4
F64
TAB1
BLK
TB1
L1
SUPPLY
POWER
WHT
IPM
BLK
12
CN903
R64B
R64A
N/F
TAB2
BLU
L2
60Hz
208/230V
1phase
V
12
NR64
N
CN5
BLK
F65
321
RED
CT2
1432
BLK
12
CN902
N/F
CN61
BLU
W
RS3
RS1
CN2
567
SSR61
BLK
INDOOR
TO
12-24V
No.D
UNIT
RT64
BLK
BLK
21
CN3
LD9
RS4
LD1
LD2
RS2
12
CN4
CN901
12345
CN912
BLU
21
BLU
BLK
LDE2
BLK
LDE1
CN631
123
BRN
BLK
BLU
TB5
S2S3S1
60Hz
208/230V
1PH.
No.C
INDOOR
UNIT
TO
CONNECTING
BLK
CN801
WHT
123
RED
BLK
12
BLK
BLK
BLK
5432176
BLK
BLK
BLK
BLK
BLK
12345
BLK
21S4
CN621
123
GRY
TB4
S1S3S2
60Hz
208/230V
1PH.
12-24V
CONNECTING
WHT
BLK
12312345
CN932
HC930
F931
F801
T801
CN701
CN702
P.C.BOARDCONTROLELECTRONIC
CN781
CN611
321
RED
ORN
BLK
TB3
S1
S2
S3
208/230V
12-24V
No.B
INDOOR
UNIT
TO
CONNECTING
RED
R930A
54
60Hz
1PH.
MF
YLW
R930B
CN601
BLU
BLK
BLK
BLU BLU
S3
No.A
INDOOR
TO
UNIT
BLU
(GRN)
(WHT) (RED) (BLU)
123
12-24V
GRY
PNK
ORN
CN931
WHT
YLW
ORN
BLU
CN796
BRN
RED
143256
GRY
21
GRY
CN663
GRY
81 234567
GRY
BLK
CN661
BLK
GRY
GRY
RED
21
RED
CN681
WHT
YLW
ORN
BLU
CN794
BRN
RED
1 43256
WHT
652 341
YLW
ORN
BLU
CN793
BRN
RED
WHT
652341
YLW
ORN
BLU
CN792
BRN
RED
WHT
652341
YLW
ORN
BLU
CN791
BRN
RED
TB2
S1
S2
60Hz
208/230V
1PH.
CONNECTING
F
LEV
RT68 RT65
RT61
HPS
D
LEV
C
LEV
B
LEV
A
LEV
RT62
unit
for
electric
indoor
side
the
diagram
to
indoor
wiring
refer
the
wiring
electric
NOTES:
servicing.
1.About
COIL
BLOCK
SOLENOID
NAME
RELAY
VALVE
TRANSFORMER
TERMINAL
REVERSING
X64
21S4
T801
TB1~5
SYMBOL
NAME
TEMP.THERMISTOR
THERMISTOR
TEMP.THERMISTOR
TEMP.THERMISTOR
AMBIENT
FIN
DISCHARGE
DEFROST
RT61
RT64
RT65
RT62
SYMBOL
CONTROLLER
FILTER
MOTOR
NAME
VARISTOR
FAN
FACTOR
NOISE
POWER
MF
N/F
PFC
NR64
SYMBOL
MODULE
MODULE
SWITCHHPS
NAMESYMBOL
POWER
POWER
REACTOR
PRESSURE
INTELLIGENT
INTELLIGENT
HIGH
L
IPM
HC930
CAPACITOR
TRANSFORMER
TRANSFORMER
CURRENT
CURRENT
CT61
F64 FUSE(T2AL250V)
CT1,2
SYMBOL NAME
CB1~3 SMOOTHING
only
block
indicate.
conductors
copper
2.Use
:connector
wiring).
below
:Terminal
field
(For
3.Symbols
RELAYRS1~4 RESISTOR
EXCHANGER
THERMISTOR
COIL
HEAT
TEMPERATURE
OUTDOOR
RT68
SSR61 SOLENOID
RESISTOR
RESISTOR
R64A,B
R930A,B
VALVE
VALVE
COMPRESSORMC
EXPANSION
EXPANSION
F
A~D
LEV
LEV
FUSE(T3.15AL250V)
F931 FUSE(T3.15AL250V)
F65 FUSE(T6.3AL250V)
F801
29
7
REFRIGERANT SYSTEM DIAGRAM
MXZ-2A20NA MXZ-2A20NA -
R.V. coil
OFF
ON
Indoor unit
B
Indoor unit
A
Indoor unit
Indoor unit
Refrigerant flow in cooling
Refrigerant flow in heating
Unit B gas pipe
temperature thermistor
Unit A gas pipe
temperature thermistor
O.D.0.16✕I.D.0.11✕ 3.93
A
O.D.0.16✕I.D.0.11✕ 3.93
B
Strainer
#100
Strainer
#100
W
Capillary tube
Capillary tube
Oil separator
W
LEV A
LEV B
Ball valve with
service port
Ball valve
Service
port
Muffler
1
Compressor
Discharge
temperature
thermistor RT62
Capillary tube
O.D.0.98✕I.D.0.02✕39.37
4-way valve
Strainer
#100
Service
port
Power
receiver
LEV E
Outdoor heat
exchanger
temperature
thermistor
RT68
HEX-OUT
Strainer
#100
FAN-OUT
Capillary tube
O.D.0.14✕I.D.0.09✕19.68
Distributor
Unit:mm
Ambient
temperature
thermistor
RT65
Defrost
thermistor
RT61
W Except MXZ-2A20NA - .
1
30
Loading...
