IP8830 IP Phone
User Guide
for Broadworks
Please read this guide carefully before operating your set.
Retain this guide for future reference.
LGN8830-1002SBUG-01.00 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
Regulatory and Safety Notices
1. Radio Frequency Emissions:
FCC Compliance statement:
This device complies with Part 15 rules. Operation is subject to the following two conditions;
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesire d o peration.
This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a different circuit from that to which the receiver is connected
If problems persist, consult the dealer or an experienced radio/TV technician for help.
Canadian Compliance statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This device complies with Class B limits of Industry Canada. Operation is subject to the following two conditions;
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesire d o peration.
European Union Declarations of Conformity
LG-Nortel Co. Ltd. declares that the equipment specified in this document, which bears the “CE” mark, conforms to
the European Union Radio and Telecommunications Terminal Equipment Directive (R&TTE 1999/5/EC) including,
Electromagnetic Compatibility Directive (89/336/EEC) and
Low Voltage Directive (73/23/EEC)
The product fulfills the essential requirements of the harmonized standards shown above.
2. Product Safety Instructions
This product complies with and conforms to the following international Product Safety standards as applicable:
Safety of Information Technology Equipment, IEC 6095-1, including
Relevant national deviations as listed in Compliance with IEC for Electrical Equipment (IECEE)
Safety of Information Technology Equipment, CAN/CSA-C22.2 No. 60950-1/UL 60950-1
3. E-911 and use of the
Please note the use and operation of this phone as part of a multi-line telephone system (MLTS) may be subject to
state and/or federal E-911 MLTS laws that require the MLTS to provide a caller’s telephone number, extension, and
physical location to applicable state and/or local emergency services when a caller initiates a 911 call. The MLTS
may not provide a caller’s telephone number, extension, or physical location information to emerg ency services when
a caller dials 911, and compliance with state and/or federal E-911 MLTS laws is the sole responsib ility of the
purchaser of this phone.
4. Privacy:
IP8830 Phone implements security and encryption technologies however, privacy of communications may not be
ensured when using this telephone.
:
:
IP8830 Phone with Multi-Line Telephone Systems:
Copyright© 2008 LG-Nortel Co. Ltd. All Rights Reserved
This material is copyrighted by LG-Nortel Co Ltd. Any unauthorized reproduction, use or disclosure of this material, or any part
thereof, is strictly prohibited and is a violation of Copyright Laws. LG-Nortel reserves the right to make changes in specifications at
any time without notice. The information furnished by LG Nortel in this material is believed to be accurate and reliable, but is not
warranted to be true in all cases.
LG-Nortel is a trademark of LG-Nortel Co. Ltd.
All other brand and product names are trademarks or registered trademarks of their respective companies.
IP8830 Broadworks IP Phone
User Guide
Care & Precautions:
Before connecting or using your new phone, take a moment to consider safety and reliability. Use common sense
when locating, connecting and using your
• Locate on a dry level surface. Keep the phone away from the edges of the surface to avoid the potential of a
fall.
• Locate cables to avoid potential for damage. For example, do not locate under rugs or carpet as damage may
result from foot traffic or heavy objects. Also, do not locate cables between the desktop and walls where they
may be crushed, damaging the insulation.
• Check the cables regularly and, if damage is noted, disconnect your phone. Contact your local repres entative
for a replacement.
• Should liquid spill on the phone, disconnect the unit from power and the network.
• Do not use during lightning storms. Lightning presents a potential shock hazard.
• Clean the
• Always use caution when connecting to AC power. Use only with a properly grounded standard AC power
outlet.
IP8830 Phone with a soft dry cloth; do not use liquid cleaners.
What is new in this release?
Issue 1.00 2008.12 first release
IP8830 Phone.
ii Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
Table of Contents
1. IP8830 IP Phone Overview....................................................................................1
2. Installing your IP8830 Phone................................................................................3
3. Using Features of IP8830 Phone..........................................................................4
3.1. Receiving a Call............................................................................................................................ 4
3.2. Placing a Call................................................................................................................................ 4
3.3. Putting a Call on Hold................................................................................................................... 4
3.4. Announcing a Call Transfer.......................................................................................................... 5
3.5. Using Blind Call Transfer.............................................................................................................. 5
3.6. Call Forward................................................................................................................................. 5
3.7. 3-Party Conference.......................................................................................................................6
3.8. Call Waiting...................................................................................................................................6
3.9. Redial............................................................................................................................................ 7
3.10. Speed Dial Buttons....................................................................................................................... 7
3.11. Speed Number Dialing.................................................................................................................. 7
3.12. DND (Do-Not-Disturb)................................................................................................................... 7
3.13. Muting a Call................................................................................................................................. 8
3.14. Accessing Your Voice Mail........................................................................................................... 8
3.15. DSS/BLF Coverage...................................................................................................................... 8
3.16. Hotline/Warm-Line........................................................................................................................ 9
4. Advanced Services and the IP8830 Phone LCD Menu.....................................10
4.1. Using the Cal l Logs Menu........................................................................................................... 10
4.2. Using the Phone Book Menu...................................................................................................... 10
4.3. Private Hold................................................................................................................................12
4.4. Barge-in...................................................................................................................................... 12
5. Setting Your Preferences....................................................................................13
5.1. LCD Contrast.............................................................................................................................. 13
5.2. Ring Setting................................................................................................................................13
5.2.1. Setting the Ring Type......................................................................................................... 13
5.2.2. Setting Line Ring Type and Delay...................................................................................... 14
5.3. Ringer Off.................................................................................................................................... 15
5.4. Enabling Automatic Headset Operation..................................................................................... 15
5.5. Setting Flexible Buttons..............................................................................................................16
5.6. Time Configuration..................................................................................................................... 17
5.6.1. SNTP Server Address ........................................................................................................ 17
5.6.2. Time Zone........................................................................................................................... 17
5.6.3. DST Auto Adjustment......................................................................................................... 18
5.6.4. Time Format........................................................................................................................ 18
5.6.5. Date Format........................................................................................................................ 18
5.7. Lock Outgoing Call..................................................................................................................... 19
iii Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
5.8. Enabling Speed Number Dialing ................................................................................................ 20
5.9. Key Tone..................................................................................................................................... 20
5.10. Bluetooth Headset...................................................................................................................... 20
5.10.1. Pairing a Bluetooth headset................................................................................................ 21
5.10.2. Connect or Disconnect a Paired Headset .......................................................................... 21
5.10.3. Deleting a Headset from the Paired List............................................................................. 22
5.10.4. Bluetooth Module Information............................................................................................. 22
5.11. Language Setting........................................................................................................................ 23
Appendix A Dial Pad Character Set ........................................................................... 24
Appendix B Time Zones..............................................................................................25
Appendix C IP8830 Icons............................................................................................26
iv Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
1. IP8830 IP Phone Overview
Your new LG-Nortel IP8830 Phone is an Internet Protocol (IP) phone employing Session Initiation
Protocol (SIP), the well-known open standard for establishing, managing and terminating a
communication session. IP8830 Phone interoperates with call servers, proxies and gateways to
exchange SIP signaling messages for call control. Real-time Transport Protocol (RTP) packets deliver
voice between the end-points over a managed IP network.
Features available to IP8830 Phone through SIP call servers are similar to those of a conventional
business telephone. In addition to the features described in this guide, your call server may provide
additional features, often using dialed feature codes. Refer to your system administrator for further
information.
The IP8830 Phone has fixed feature buttons, soft feature keys, flexible buttons that are configurable, and
dial pad buttons as shown in the figure below.
The twenty-four (24) flexible buttons access lines and features based on the IP Phone configuration.
Flexible buttons assigned for line access, called line buttons, represent a telephone line or a SIP user. A
line may be private, calls to a private line signal at all appearances of the line but an active or held call is
only visible and accessible by the original end-points. A shared line appears at multiple phones and all
calls are visible and accessible by all end-points with the line. Each line button employs LEDs to indicate
status as shown below.
Incoming call Orange* LED flashes at 60 ipm, fast flash
Line in use at this phone Orange* LED On
Call held at this phone Orange* LED flashes at 30 ipm, slow flash
1 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
Shared line in use at Red LED On
another phone
Shared line call held at Red LED slow flash
another phone
Line not registered w/server Red/Orange LED flashes color, red to orange at 30 ipm
* When the LCD displays information for a line, such as when an incoming call first rings, the LED
color is orange otherwise, the LED color will be green.
Flexible buttons not assigned for line access may access features such as Speed dial, Redial and others.
Refer to section 5.5
The figure below shows other major components of IP8830 Phone. These components include:
• Handset
• Speaker and microphone
• Message Wait Indicator (Message LED)
• LCD (240 by 56 pixel), displays 4-lines
• Flexible button labels
and your system administrator for further information.
The top line of the LCD indicates a number of icons indicating the connection, status and options for the
IP8830 phone. A list of the icons and there meaning are provided in Appendix C
2 Dec. ‘08
.
IP8830 Broadworks IP Phone
User Guide
2. Installing your IP8830 Phone
The figure below shows the cable connections for your IP Phone. The LAN and desktop PC connections
employ standard category 5 LAN cables terminated with RJ-45 connectors. The IP Phone supports PoE
(Power over Ethernet) in accordance with the IEEE-802.1af industry standard. When connected to a PoE
complaint LAN port, the IP Phone derives power from the port. If the LAN port does not support PoE, use
the AC/DC adaptor, available separately, for connection to power. The handset connects to the base with
the supplied standard handset coiled cord. Use the chart below to make connections to the IP Phone.
1 LAN Connect the IP Phone LAN port to the LAN wall jack with the provided LAN cable.
2 PC Connect the IP Phone PC port to your desktop PC with an RJ-45 terminated
UTP-5 cable.
3 Power If the LAN port supports PoE (IEEE 802.3af compliant), the AC/DC adapter is not
required. If not supported, connect the IP Phone power port to the DC out of
Power Adapter. Connect the Power Adapter AC plug to an AC wall jack.
4 Headset Connect Headset RJ-11 jack to the IP Phone headset jack.
5 Handset Connect the Handset coiled cord to the IP Phone base and handset.
3 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
3. Using Features of IP8830 Phone
3.1. Receiving a Call
When you receive a call, your phone rings, the LCD displays the incoming call information and the
associated line button flashes.
To answer a ringing call:
o Lift the handset. You may press the speakerphone button, line button or the Answer softkey to
activate the speakerphone. To use a headset, press the headset button.
To end the call:
o Hang up the handset. If using the speakerphone, press the speakerphone button. If using the
headset, press the headset button.
To refuse a ringing call:
o Press Refuse softkey, the IP Phone stops ringing and the call server routes the call.
3.2. Placing a Call
You place calls with the handset on-hook or off-hook. Similar to your mobile phone, IP8830 Phone uses
a technique called ‘store and forward dialing’. After you dial a digit, the IP Phone waits about 6 seconds
for additional digits. If you do not dial additional digits, the IP Phone sends the digits you dialed to the call
server for processing. To send the digits immediately, press the # button to indicate dialing is complete,
and then the IP Phone sends the number to the call server.
To place a call:
o Lift the handset. You may press the speakerphone button or line button to activate the
speakerphone. To use a headset, press the headset button.
o Dial the destination number. After a short delay, the IP Phone sends the number, or dial # to send
the dialed digits immediately.
o When the called party answers, begin speaking, the LCD displays the elapsed call time.
To end the call,
o Hang up the handset. If using the speakerphone, press the speakerphone button. If using the
headset, press the headset button.
3.3. Putting a Call on Hold
You can place a call in a waiting state where the held party cannot hear you and you cannot hear the held
party. The held party receives MOH (Music-On-Hold), if configured in the call server.
While a call is on hold, you can answer or place other calls and can toggle between held calls on the
same line. With Call Hold Ringback enabled, the IP Phone rings as a reminder of calls on hold when you
return the IP Phone to idle. Refer to your system administrator or Installer Guide for further information.
To place a call on hold:
4 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
o Press the Hold button or the Hold softkey. The call status changes to hold and you receive dial
tone. You may then select another line to answer or place a call. Note, if you select an idle line and
take no action for about 15 seconds, the line is disconnected.
To retrieve a held call on a different line:
o Press the slow flashing line button.
o Select the desired call from the displayed call list using Previous-Next softkeys
o Select the OK softkey to resume a connection with the call.
To toggle between two calls on the same line:
o Press the Hold button or the Resume softkey, the active call status changes to hold and the held
call connects.
3.4. Announcing a Call Transfer
Using Announcing a Call Transfer, you send an active call to another extension after announcing the call
transfer to the receiving party.
To transfer an active call:
o Press the Transfer button or the Transfer softkey. The active call status changes to hold and you
receive dial tone.
o Dial the number you wish to receive the transfer.
o Await answer and announce the transfer.
o Hang-up the handset to complete the transfer.
To cancel a transfer, for example the second party does not answer or is busy:
o Press the EndCall softkey.
3.5. Using Blind Call Transfer
You can transfer an active call to another extension without talking to the party receiving the call. The call
transfers to the new party without verifying that the new party is there or willing to receive the call.
To transfer an active call without announcing the transfer:
o Press the BlindXfr softkey. The active call status changes to hold and you receive dial tone.
o Dial the number you wish to receive the transfer.
o Hang-up the handset to complete the transfer.
To cancel a transfer, for example you mis-dial the receiving number:
o Press the EndCall softkey.
3.6. Call Forward
Call forward directs incoming calls to ring at another location that you designate. You can select one of
four (4) conditions that will forward your calls:
- Call Forward Busy – redirects incoming calls if the line is busy.
5 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
- Call Forward No Answer – redirects incoming calls that are not answered in the configured no
answer time.
- Call Forward Busy or No Answer – redirects incoming calls if the line is busy or not answered
after the no answer time expires.
- Call Forward All Calls – immediately redirects all incoming calls.
To set up Call Forward:
o Press the CallFwd softkey.
o Use the Previous-Next softkeys to select the desired Call Forward condition.
o Press the OK softkey.
o Input the destination where you want your calls sent.
o Press the OK softkey. The display shows “(x) Fwd to ext” indicating the forward condition and
destination for the calls.
(B) = Busy, (N) = No-answer, (BN) = Busy or No-answer, (U) = Unconditional
To disable Call Forward:
o Press the CallFwd softkey. The message “Fwd to xxxx” disappears from the LCD.
3.7. 3-Party Conference
The IP Phone has a 3-Party Conference feature that lets you converse with two other parties
simultaneously.
To set-up a conference:
o Place first call as normal.
o Press the Conferen softkey. The call status changes to hold and you receive dial tone.
o Dial the number you want to join the conference.
o When the party answers, press the Join softkey to establish the conference.
To end your conference and disconnect all parties:
o Hang up the handset.
To cancel a conference, for example the second party does not answer or is busy:
o Press the EndCall softkey.
3.8. Call Waiting
With Call Waiting configured, while you are in a call the IP Phone alerts you of an incoming call. The line
button flashes and you receive a beep tone over the active conversation to indicate the new call. In
addition, during the ring signal, the LCD displays the incoming caller id so you know who is calling before
you interrupt the current call.
To answer an incoming call while on a call:
o Press the Answer softkey. The active call changes to the hold state and the new call connec ts.
6 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
3.9. Redial
Your IP Phone saves the last number you dialed and allows you to redial the number with the touch of a
button. The number is stored in memory but is lost if power to the IP Phone is interrupted.
To redial a call:
o Press the Redial softkey. The IP Phone activates the speakerphone and places the call.
o Lift the handset for privacy or press the headset button to use the headset.
3.10. Speed Dial Buttons
Flexible buttons not assigned as a line are available for configuration as feature buttons including Speed
dial. Pressing a Speed dial button selects your line and sends the stored number to the call server for
processing. Refer to your system administrator for further information.
To place a call using Speed dial:
o Press the desired Speed dial flexible button. The IP Phone activates the speakerphone and places
the call on your line. You may select a different line button on your IP Phone prior to selecting the
Speed dial button.
o Lift the handset for privacy or press the headset button to use the headset
3.11. Speed Number Dialing
Your IP8830 Phone incorporates a Phone Book with up to 100 records. Refer to section 4.2 for
information on use of the Phone Book. Each record includes a name, contact information and a Speed
number (00 to 99). When you dial a Speed number, the IP Phone initiates a call to the contact. Speed
number dialing must be enabled. Refer to your system administrator for further information.
To place a call using a Speed number:
o Dial the Speed number (00-99) for the desired contact. After a short delay, the IP Phone sends the
contact information from the Phone Book. You may dial # to set up the call immediately. If the
Phone Book has no record of the Speed number, the IP Phone sends the digits dialed to the call
server for processing.
3.12. DND (Do-Not-Disturb)
When the DND (Do Not Disturb) feature is enabled and activated, the IP Phone will not notify you of an
incoming call. The IP Phone does not ring, allowing you to work without interruption from an incoming
call. The call server configuration determines routing of the incoming call while your phone is in DND.
Refer to your system administrator for further information.
To activate DND:
o While the IP Phone is idle, press the DND button. When active, the DND button LED illuminates
red, and “Do not disturb” displays in the LCD.
To deactivate DND:
o Press the illuminated DND button again.
7 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
3.13. Muting a Call
Mute toggles the microphone of the Handset, Speakerphone and Headset Off and On. When Mute is
active, the connected party will not receive audio from the microphone.
To mute the microphone:
o Press the Mute button. The Mute button LED illuminates red indicating mute is active.
To turn the microphone back on:
o Press the illuminated Mute button again.
3.14. Accessing Your Voice Mail
When you have a message waiting, the Message LED flashes to indicate you have new messages in
your mailbox. The IP Phone delivers the message waiting indication for your primary line, line button 1.
To access your voice mailbox:
o Press the Message button. The display indicates the number of messages waiting.
o Press Dial softkey. The IP Phone activates the speakerphone and places a call to your voice
mailbox. To listen to your messages, follow the instructions for your voice mail system.
3.15. DSS/BLF Coverage
The IP8830 Phone has a DSS line type that addresses the special needs associated with an Attendant or
Secretarial answering position. The specific needs for these users are:
• Direct Station Selection (DSS) - one-touch calling and transfers to extensions
• Busy Lamp Field (BLF) - visual status indication of covered lines.
• Coverage - the ability to pick up calls ringing at those extensions.
The DSS line in the IP Phone uses the shared line assignment in the call server. Operation of the
DSS/BLF Coverage button however is distinctly different then a shared line. For more information on
assigning DSS lines, consult your system administrator.
To call an idle covered extension:
o Lift the handset. You may press the speakerphone button or the headset button.
o Press the DSS line button. You may press the DSS line button prior to lifting the handset, which
activates the speakerphone and places the call.
To transfer an active call:
o Press the DSS line button. The IP Phone places the active call on hold, and calls the extension.
o Await answer and announce the transfer.
o To complete the transfer, hang up the handset.
To cancel a transfer, for example the second party does not answer or is busy:
o Press the EndCall softkey.
8 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
To answer a call for a covered extension:
o Lift the handset. You may press the speakerphone button or press the headset button.
o Press the flashing DSS/BLF Coverage button. You may press the DSS line button prior to lifting
the handset, which activates the speakerphone and answers the call.
The LED indications of the DSS line button are:
• Solid red line in use remotely
• Fast blinking red Call appearance ringing for covered line
• Slow blinking red Remote call hold
3.16. Hotline/Warm-Line
With Hotline/Warm-Line operation configured, the IP Phone automatically calls the defined destination
when you take the handset off-hook or press the speaker button. The call initiates immediately, Hotline,
or after a delay of up to 10 seconds, Warm-Line. The later permits you the time to access another feature
or line as needed. Note that with Hotline configured, Speed dial, redial and other automated dialing
features will not operate.
Operation of this feature is automatic.
9 Dec. ‘08
IP8830 Broadworks IP Phone
08:30
N
08:30
N
08:30
N
User Guide
4. Advanced Services and the IP8830 Phone LCD Menu
This section describes how to view and use the advanced services available through the LCD menu. The
IP8830 Phone has three context sensitive softkeys, pressing the softkey selects the function or value
shown in the LCD just above the softkey. The left (return) and right navigation buttons navigate through
menus.
The menu items and order of display may be different on your phone based on the service subscription.
Not all features may be available to you based on the call server configuration.
4.1. Using the Call Logs Menu
The IP8830 Phone has access to a log of all calls placed or received by the phone, including incoming
calls that were not answered (missed calls). The LCD displays the call logs that you can use to place a
call to the logged party. You access the call logs with the Up navigation button or using a flexible button
assigned for the Call Log function. Refer to your system administrator for further information.
To access the Call Logs menu:
o While in an idle state, press the Up navigation or Call Log
flexible button. The Call Log menu displays with several
choices (missed, outgoing and incoming).
o Use the Previous-Next softkeys to select the desired log
and press the OK softkey, or dial the digit in front of the desired selection.
o The log will display information on the calls along with the
received caller id.
To place a call using the Call Logs:
o Dial the digit preceding the desired log item or use the Previous-Next softkeys to highlight the
desired log item and press the Dial softkey.
Call Log
>1.Missed Calls
Previous
Missed Calls
>1.John,4913 11/07 12:55
Previous
ext
ext
OK
Dial
4.2. Using the Phone Book Menu
The IP8830 Phone has an internal Phone Book with up to 100 entries. Each record includes the contact
name, contact information and Speed number. You can add, delete, edit, dial and search entries from the
Phone Book Menu. You access the Phone Book Menu with the Down navigation button or a flexible
button assigned for the Phone Book function. Refer to your system administrator for further information.
To access the Phone Book menu:
o Press the Down navigation or Phone Book flexible button,
the LCD displays the first Phone Book record.
Phone Book (Page 1)
>(01)Tom,1234
Previous
ext
Dial
To call a contact from the Phone Book:
o Access the Phone Book as described above.
o Use the Previous-Next softkeys to display the desired record or dial the digit preceding the desired
record.
o Press the Dial softkey.
10 Dec. ‘08
IP8830 Broadworks IP Phone
08:30
08:30
N
08:30
08:30
N
User Guide
To add a record to the Phone Book:
o Access the Phone Book as described above.
o Press the right navigation button to display the Add softkey.
o Select the Add softkey.
o Enter the name, contact information, ring type and speed
number, for the record, selecting the OK softkey for each
entry. Use the Mode softkey to enter characters. Refer to
Appendix A Dial Pad Character Set
, which shows the
relationship between the dial pad digits and characters.
To edit a record:
o Access the Phone Book as described above.
o Use the Previous-Next softkeys to display the desired
record or dial the digit preceding the desired record.
o Press the right navigation button to display the Edit softkey.
o Select the Edit softkey.
o Edit the name, contact information, ring type and speed
number, for the record, selecting the OK softkey for each
entry. Use the Mode softkey to enter characters. Refer to
Appendix A Dial Pad Character Set
, which shows the
relationship between the dial pad digits and characters.
To delete a record:
o Access the Phone Book as described above.
o Use the Previous-Next softkeys to display the desired
record or dial the digit preceding the desired record.
o Press the right navigation button to locate the Delete
softkey.
o Select the Delete softkey and confirm by selecting the Yes
softkey. Caution this action deletes the record from the
Phone Book.
Phone Book (Page 1)
>(01)Tom,1234
Edit
Phone Book : Number
9876
Å
Phone Book (Page 1)
>(01)Tom,1234
Previous
Phone Book (Page 1)
>[15]Tommy,9876
Edit
Phone Book : Number
9844
Å
Phone Book (Page 1)
>(15)Tommy,9844
Edit
Data will be lost.
Are you sure?
Add
Mode
ext
Add
Mode
Add
Delete
OK
Dial
Delete
OK
Delete
o
08:30
08:30
11 Dec. ‘08
IP8830 Broadworks IP Phone
08:30
d
08:30
N
d
08:30
N
08:30
N
User Guide
To delete all records:
o Access the Phone Book as described above.
o Press the right navigation button to locate the Del.All
softkey.
o Select Del.All softkey and confirm the deletion by selecting
the Yes softkey. Caution this action deletes all records
from the Phone Book.
To search for a record in the Phone Book:
o Access the Phone Book as described above.
o Press the right navigation button to locate the Find softkey.
o Select the Find softkey.
o Enter the search criteria (name or contact information).
Use the Mode softkey to enter characters. Refer to
Appendix A Dial Pad Character Set
, which shows the
relationship between the dial pad digits and characters.
o Select the OK softkey to view the search results.
4.3. Private Hold
Phone Book (Page 1)
>[01]Tom,1234
Fin
Data will be lost.
Are you sure?
Yes
Phone Book (Page 1)
>[01]Tom,1234
Fin
Search for:
Sam
Å
Phone Book (Page 1)
>(14)Sam,9543
Previous
Mode
ext
Del.All
o
Del.All
OK
Dial
08:30
08:30
Your Call Server may provide “private hold”. If available, a call on a shared line can be placed on hold
and others cannot access held the call.
To place an active shared line call on private hold:
o Press the right navigation button to display the PrivHold
selection.
o Press the PrivHold softkey.
To Richard
4012
PrivHold
EndCall
08:30
4.4. Barge-in
Your Call Server may provide barge-in operation. If available, other users with the shared line
appearance may be able to enter an active call directly.
To enter a call using Barge-in:
o Press the shared line appearance button. A list of call selections (held calls, active calls subject to
Barge-in and “Make a new call”) for the line displays.
o Use the Previous-Next softkeys to highlight the Barge-in
selection.
o Press the OK softkey.
>2.Barge in call 2
3.Make a new call
Previous
ext
OK
12 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
5. Setting Your Preferences
In the LCD Menu, you can set various preferences for the IP Phone. Settings you can adjust include:
- LCD contrast
- Ring Setting
- Ringer off
- Headset auto mode
- Flexible button settings
- Time Configuration
- Outgoing Call Lock
- Speed Number Dialing
- Key Tone
- Bluetooth
- Language
The following paragraphs provide detailed instructions for each of the preferences as well a s descriptive
information for each.
5.1. LCD Contrast
The contrast of the LCD is adjustable for best viewing angle.
To adjust the LCD contrast:
o Press the Setting (
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 1, or move the cursor to 1.LCD Contrast using the Previous-Next softkeys and press the OK
softkey.
o Press the Down softkey to decrease the contrast, or press
the Up softkey to increase the contrast.
o Move to another parameter with the navigation buttons and
continue the session or press the Setting (
exit the configuration session.
) button.
) button to
LCD Contrast
■■■■□□□
Down
Up
5.2. Ring Setting
Ring settings determine the ring type (tone) for the phone. In addition, the ring type for each line can be
set with immediate or delayed audible notification. Note the ring type set for a contact in the Phone Book
has priority over the phone or line settings, see section 4.2
.
5.2.1. Setting the Ring Type
The IP Phone uses one of fourteen distinctive ring types for incoming call notification. Nine are stored in
the memory of your IP Phone and the remaining five (5) must be downloaded prior to use. By assigning
different ring signals to closely located phones, you can identify the ringing phone. The ring type
assigned for the IP Phone is the “Default Ring Type” for incoming calls to the phone and is set to “ringer
off” or one of the fourteen tones.
13 Dec. ‘08
IP8830 Broadworks IP Phone
y
y
User Guide
To set the ring type for the phone:
o Press the Setting (
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 2, or move the cursor to 2.Ring Setting using the Previous-Next softkeys and press the OK
softkey.
o Dial 1, or move the cursor to 1.Default Ring Type using
the Previous-Next softkeys and press the OK softkey. An
asterisk, », displays in front of the current setting.
o Select the ring type using the Next softkey. Press the Play
softkey to hear the selected tone.
o Press the OK softkey to save the selected the ring type.
o Move to another parameter with the navigation buttons and
continue the session or press the Setting (
the configuration session.
5.2.2. Setting Line Ring Type and Delay
) button.
) button to exit
Ring Setting
>1.Default Ring Type
Previous
Default Ring Type
*Type1
Pla
Next
Next
OK
OK
You can assign each line with a different ring type (tone) to distinguish which line is ringing. Selections
for the type include one of up to fourteen tones, “Ringer Off” or “Set to Default”, see section 5.2.1
. Of the
fourteen tones, five are permanently stored in the memory of the phone and the remaining five must be
downloaded before use. In addition, for each line the ring signal can be immediate or delayed. The delay
is set in 1 second increments from 0 (no delay) to 10 seconds.
To set the ring type for a line:
o Press the Setting (
) button.
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 2, or move the cursor to 2.Ring Setting using the Previous-Next softkeys and press the OK
softkey.
o Dial the Line number plus one (2 for Line 1, 3 for Line 2,
etc.), or move the cursor to Line
n
Configuration using the
Previous-Next softkeys and press the OK softkey. The
value of
n
is the Line button number.
o Dial 1, or move the cursor to 1.Ring Type using the
Previous-Next softkeys and press the OK softkey. Note
the line number displays in parenthesis after “Ring Type”.
o Select the ring type using the Next softkey. Press the Play
Ring Setting
>2.Line 1 Configuration
Previous
Line 1 Configuration
>1.Ring Type
Previous
Next
Next OK
OK
08:30
softkey to hear the selected tone. An asterisk, », displays
in front of the current setting.
o Press the OK softkey to save your entry.
o Move to another parameter with the navigation buttons and
continue the session or press the Setting (
) button to exit the configuration session.
Ring Type (1)
*Set to Default
Pla
Next OK
To set delayed ring for a line:
o Press the Setting (
14 Dec. ‘08
) button.
IP8830 Broadworks IP Phone
Y
User Guide
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 2, or move the cursor to 2.Ring Setting using the Previous-Next softkeys and press the OK
softkey.
o Dial the Line number plus one (2 for Line 1, 3 for Line 2,
etc.), or move the cursor to Line
Previous-Next softkeys and press the OK softkey. The
value of
n
is the Line button number.
n
Configuration using the
Ring Setting
>2.Line 1 Configuration
Previous
Next
o Dial 2, or move the cursor to 2.Delayed Ring using the
Previous-Next softkeys and press the OK softkey. . Note
the line number is shown in parenthesis after “Delayed Ring
Timer”.
Line 1 Configuration
>2.Delayed Ring Timer
Previous
Next
o Using the dial pad enter the desired delay up to 10 seconds
in one-second increments, zero is no delay. The
backspace softkey will delete the previous character and
the Clear softkey deletes the entire entry.
Delayed Ring Timer (1)
0
Å
Clear
o Press the OK softkey to save your entry.
o Move to another parameter with the navigation buttons and continue the session or press the
Setting (
) button to exit the configuration session.
08:30
OK
OK
OK
5.3. Ringer Off
The IP Phone can be programmed not to ring when an incoming call is received.
To set the Ringer Off parameter:
o Press the Setting (
) button.
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 3, or move the cursor to 3.Ringer Off using the
Previous-Next softkeys and press the OK softkey.
o Press the Yes softkey to enable Ringer Off, or press the No
softkey to disable Ringer Off.
Ringer Off
Current value is ‘No’.
es
No
o Move to another parameter with the navigation buttons and continue the session or press the
Setting (
) button to exit the configuration session.
5.4. Enabling Automatic Headset Operation
Your IP8830 Phone supports use of a headset with a standard RJ-11 jack. In the Headset Auto Mode,
pressing a line button automatically connects audio to the headset. Also, redial, Speed dial, Speed
number dialing and click-to-call place calls with audio through the headset.
To enable Headset Auto Mode:
o Press the Setting (
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 4, or move the cursor to 4.Headset Auto Mode using the Previous-Next softkeys and press
the OK softkey.
) button.
15 Dec. ‘08
IP8830 Broadworks IP Phone
Y
User Guide
o Press the Yes softkey to enable the Headset Auto Mode or
press the No softkey to disable the Headset Auto Mode.
o Move to another parameter with the navigation buttons and
continue the session or press the Setting (
) button to
exit the configuration session.
5.5. Setting Flexible Buttons
Your IP8830 Phone has twenty-four (24) flexible buttons. Normally, the first two (2) buttons are for your
line. The flexible buttons not assigned as line buttons can access various functions. The table below
indicates the available functions with a brief description of each.
Feature Description
0 No Function Unassigned
1 Speed Dial Function Dials the assigned number
2 Phone Book Function Views the personal phone book
3 Call Log Function Views the call log list
4 Mute Function Toggles the Mute feature on and off
5 Headset Function Toggles the Headset on and off
6 Redial Function Dials the last number dialed by the user.
7 Return Call Function Dials the number of the last answered call
8 Set Call Forwarding Sets the call forwarding configuration
9 Conference Function 1. Initiates a conference call
2. Joins calls in a conference
10 Transfer Function Initiates a call transfer
11 Hold Fu nction Places an active call on hold
12 Do not distur b Toggles the DND on and off
13 Set Ringer Off Toggles the ringer on and off
14 Message F unction Views the number of new and old messages stored
in the Voice Mail server, and dials the Voice Mail
server by pressing the Dial softkey
Headset Auto Mode
Current value is ‘No’.
es
No
To assign a function to a flexible button not used as a line:
o Press the Setting (
) button.
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 5, or move the cursor to 5.Flexible Key Setting using
the Previous-Next softkeys and press the OK softkey.
Press Flexible Button
o Select the desired flexible button. An asterisk, », displays
in front of the current setting.
o Select a function using the Previous-Next softkey and
press the OK softkey. Refer to the flexible button functions
chart above.
16 Dec. ‘08
[05] Select Function
*No Function
Previous
Next
OK
IP8830 Broadworks IP Phone
User Guide
o If the selected function is Speed dial, enter the speed
number and press the OK softkey to save the entry. To
enter alphanumeric characters select the Mode softkey.
Refer to Appendix A
for the character mapping of dial pad
digits.
o Move to another parameter with the navigation buttons and continue the session or press the
Setting (
) button to exit the configuration session.
5.6. Time Configuration
Within the Time Configuration menu, the IP Address or name of the desired Simple Network Time
Protocol (SNTP) server and the local time zone are defined. In addition, Daylight Savings Time (DST) is
enabled. Consult with your administrator before changing the SNTP server.
5.6.1. SNTP Server Address
SNTP (Simple Network Time Protocol) is a standard protocol that permits a network device to obtain the
network’s current time. For operation with SNTP, the IP8830 IP Phone requires an SNTP server IP
address or name.
To assign the SNTP server address:
o Press the Setting (
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 6, or move the cursor to 6.Time Configuration using the Previous-Next softkeys and press
the OK softkey.
o Dial 1, or move the cursor to 1.SNTP Server Address using the Previous-Next softkeys and
press the OK softkey.
o Input the SNTP server address using the dial pad and press
the OK softkey to save the entry. To enter alphanumeric
characters select the Mode softkey. Refer to Appendix A
for the character mapping of dial pad digits.
o Move to another parameter with the navigation buttons and continue the session or press the
Setting (
) button to exit the configuration session.
) button.
[05] Enter number
12345
Å
SNTP Server Address
clock.via.net
Å
Mode OK
Mode
OK
5.6.2. Time Zone
For proper operation of the clock, the IP Phone requires the local time zone. For available time zones,
see Appendix B Time Zones.
To enter the Time Zone:
o Press the Setting (
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 6, or move the cursor to 6.Time Configuration using the Previous-Next softkeys and press
the OK softkey.
17 Dec. ‘08
) button.
IP8830 Broadworks IP Phone
Y
User Guide
o Dial 2, or move the cursor to 2.Time Zone using the
Previous-Next softkeys and press the OK softkey. An
asterisk, », displays in front of the current selection.
o Select the nearest region from the display using the
Previous-Next softkeys and press the OK softkey to save the entry.
o Move to another parameter with the navigation buttons and continue the session or press the
Setting (
) button to exit the configuration session.
5.6.3. DST Auto Adjustment
The IP8830 Phone automatically adjusts for DST (Daylight Savings Time) when enabled.
To enable/disable automatic daylight savings time:
o Press the Setting (
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 6, or move the cursor to 6.Time Configuration using the Previous-Next softkeys and press
the OK softkey.
o Dial 3, or move the cursor to 3.DST Auto Adjustment using the Previous-Next softkeys and
press the OK softkey.
o Press the Yes softkey to enable DST Auto Adjustment, or
press the No softkey to disable DST Auto Adjustment.
o Move to another parameter with the navigation buttons and
continue the session or press the Setting (
exit the configuration session.
) button.
) button to
Time Zone
*(GMT-08:00) PACIFIC STANDARD
Previous
DST Au to Adjust m ent
Current value is ‘Yes’.
es
Next
OK
No
5.6.4. Time Format
The format of the LCD time display can be set for 12-hour format or 24-hour format. In addition, the LCD
time display can be disabled.
To set the display format for time:
o Press the Setting (
) button.
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 6, or move the cursor to 6.Time Configuration using the Previous-Next softkeys and press
the OK softkey.
o Dial 4, or move the cursor to 4.Time Format using the Previous-Next softkeys and press the OK
softkey.
o An asterisk, », displays in front of the current setting.
Press the Previous-Next softkeys to select the Time
Format and press the OK softkey to save your entry.
o Move to another parameter with the navigation buttons and
continue the session or press the Setting (
) button to exit the configuration session.
Time Format
*24 HR (16:30)
Previous
Next
OK
5.6.5. Date Format
The format of the LCD date displays in the one of the formats below:
18 Dec. ‘08
IP8830 Broadworks IP Phone
(
K
Y
User Guide
- MM/DD (01/22)
- DD/MM (22/01)
- DD Month (22 Jan)
- Month DD (Jan 22)
- Disabled, no date display
To set the date display format:
o Press the Setting (
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 6, or move the cursor to 6.Time Configuration using the Previous-Next softkeys and press
the OK softkey.
o Dial 5, or move the cursor to 5.Date Format using the Previous-Next softkeys and press the OK
softkey.
o Press the Previous-Next softkeys to select the display
format and press the OK softkey to save your entry. An
asterisk, », displays in front of the current setting.
o Move to another parameter with the navigation buttons and
continue the session or press the Setting (
) button.
Date Format
*DD Mon
01 Jan)
Previous
Next
) button to exit the configuration session.
08:30
OK
5.7. Lock Outgoing Call
The IP Phone can be configured to allow outgoing calls only if a password is entered. When enabled, the
LCD screen will display the password request and the lock icon as shown, and the password must be
entered prior to placing an outgoing call.
Enter Password:
****
Å
To activate this feature, the LCD password must be set, consult your system administrator to set the LCD
password.
To enable/disable the Lock Outgoing Call feature:
o Press the Setting ( ) button.
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 8, or move cursor to 8.Lock Outgoing Call using the Previous-Next softkeys and press the
OK softkey.
o Press the Yes softkey to enable Lock Outgoing Call, or
press the No softkey to disable Lock Outgoing Call.
o Move to another parameter with the navigation buttons and
continue the session or press the Setting (
exit the configuration session.
Clear O
) button to
Lock Outgoing Call
Current value is ‘Yes’.
es No
19 Dec. ‘08
IP8830 Broadworks IP Phone
Y
Y
User Guide
5.8. Enabling Speed Number Dialing
The IP8830 Phone includes a Phone Book that supports up to 100 entries. Each Phone Book record
includes a two-digit Speed number, see Speed Number Dialing
number (00~99) sends the contact number or user id from the associated Phone Book record.
To enable/disable Speed number operation:
o Press the Setting (
) button.
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 9, or move cursor to 9.Speed Number using the Previous-Next softkeys and press the OK
softkey.
o Press the Yes softkey to enable Speed number, or press
the No softkey to disable Speed number.
o Move to another parameter with the navigation buttons and
continue the session or press the Setting (
) button to
exit the configuration session.
5.9. Key Tone
. When enabled, dialing the Speed
Speed Number
Current value is ‘Yes’
es
No
When you press a button on the IP8820 phone, the phone will generate a beep tone to indicate that the
button has been pressed. This key tone is optional and can be enabled or disabled using the key tone
setting.
To enable/disable the Key Tone:
o Press the Settings (
) button. .
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys and press the
OK softkey.
o Dial 10, or move the cursor to 10.Key Tone using the Previous-Next softkeys and press the OK
softkey.
o Press the Yes softkey to enable the Key Tone, or press the
No softkey to disable the Key Tone.
o Move to another parameter with the navigation buttons and
continue the session or press the Settings (
) button to
Key Tone
Current value is ‘Yes’
es
No
exit the configuration session.
5.10. Bluetooth Headset
Your IP8830 phone can be equipped with an optional Bluetooth module; you can use a Bluetooth headset
with your phone. The
for installing the module are provided with the module or can be found in the IP8800 Installer Guide.
When paired and connected to a compatible Bluetooth headset, such as the IP-8502, the headset can
control the On/Off hook status of the phone and audio is delivered from the IP8830 to the headset using
wireless Bluetooth technology. In order to use a Bluetooth headset, the headset must be paired with and
activated in the IP8830. The following sections provide instructions for setting up your IP Phone for use
with a Bluetooth headset. Note the Bluetooth menus discussed below are only available and displayed
when a Bluetooth module is installed on your IP Phone.
icon appears in the upper line of the LCD if the module is installed. Instructions
20 Dec. ‘08
IP8830 Broadworks IP Phone
A
User Guide
5.10.1. Pairing a Bluetooth headset
A Bluetooth headset must be paired with the IP8830 Bluetooth module before it can be connected
(activated). Up to five (5) headsets may be paired with the IP Phone at one time. Note that only one may
be active at a time.
To pair and connect a new headset with the IP Phone:
o Press the Settings (
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys, and press the
OK softkey.
o Dial 11, or move the cursor to 11.Bluetooth using the Previous-Next softkeys, and press the OK
softkey.
o Dial 1, or move the cursor to 1.Headset Management
using the Previous-Next softkeys, and press the OK
softkey. This will display a list of paired headsets.
o If no headsets are paired with the IP Phone, press the
Search softkey, the IP Phone will search for nearby
Bluetooth headsets. If one or more Bluetooth headsets are
already paired with the IP Phone, press the right navigation
button and select the Add softkey to add another headset.
o Select a Bluetooth headset from the list of headsets using
the Next softkey, and select the Pair softkey.
o When the “Enter PIN Code” message displays, input the
PIN associated with the headset and press OK softkey. If a
valid PIN is entered, the headset is automatically activated
for use with your IP8830 phone.
o Move to another parameter with the navigation buttons and continue the session or press the
Settings (
) button to exit the configuration session.
) button.
Paired Headset List
*Wireless Headset (00:1A:34:56:78:AB)
dd
No Paired Headset
Search
Searched Headset List
Wireless Headset(00:1A:34:5678:AB)
Search
Enter PIN Code
Å
Next
Next
Clear
Delete
08:30
Pair
OK
5.10.2. Connect or Disconnect a Paired Headset
When one or more headsets are paired with the IP8830 phone, the headset must be connected
(activated) prior to use. When it is desired to change the active headset, the presently active headset
must be disconnected (deactivated) prior to connecting the new headset. The following procedure
describes the steps required to connect or disconnect a headset that is already paired to the IP Phone.
To connect a paired headset or disconnect an active headset:
o Press the Settings (
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys, and press the
OK softkey.
o Dial 11, or move the cursor to 11.Bluetooth using the Previous-Next softkeys, and press the OK
softkey.
21 Dec. ‘08
) button.
IP8830 Broadworks IP Phone
A
A
08:30
User Guide
o Dial 1, or move the cursor to 1.Headset Management
using the Previous-Next softkeys, and press the OK
softkey. This displays a list of previously paired headsets.
o Select a Bluetooth headset from the list of paired headsets
using the Next softkeys. An asterisk, », displays in front of the current headset selection.
o Use the right navigation button to locate and select the
Connect softkey to activate the headset or press the
Disconn to deactivate the headset. The LCD will display
the connected or disconnected message for about 3
seconds.
o Move to another parameter with the navigation buttons and
continue the session or press the Settings (
) button to
exit the configuration session.
5.10.3. Deleting a Headset from the Paired List
A Bluetooth headset can be removed from the Paired list. This is useful when five headsets are already
paired and a new headset must be paired with your IP8830.
To remove a headset from the Paired list:
Paired Headset List
*Wireless Headset (00:1A:34:56:78:AB)
dd
Paired Headset List
*Wireless Headset (00:1A:14:78:34:1D)
Connect
Headset is connected
Next
Delete
o Press the Settings (
) button.
o Dial 3, or move the cursor to 3.Phone Settings using the Previous-Next softkeys, and press the
OK softkey.
o Dial 11, or move the cursor to 11.Bluetooth using the Previous-Next softkeys, and press the OK
softkey.
o Dial 1, or move the cursor to 1.Headset Management using the Previous-Next softkeys, and
press the OK softkey. This will display a list of previously paired headsets.
o Select a Bluetooth headset from the list of headsets found
using the Next softkeys.
o Press the Delete softkey to remove the headset from the
Paired list
Paired Headset List
*Wireless Headset (00:1A:34:56:78:AB)
dd
Next
Delete
o Move to another parameter with the navigation buttons and continue the session or press the
Settings (
) button to exit the configuration session.
5.10.4. Bluetooth Module Information
To assure the operation of the Bluetooth module, the address information for the module can be viewed
from the Bluetooth menu item.
To remove a headset from the Paired list:
o Press the Settings (
o Dial 3, or move cursor to 3.Phone Settings using the Previous-Next softkeys, and press the OK
softkey.
o Dial 11, or move cursor to 11.Bluetooth using the Previous-Next softkeys, and press the OK
softkey.
o Dial 2, or move cursor to 2.Local Device Info using the
Previous-Next softkeys, and press the OK softkey.
o Move to another parameter with the navigation buttons and
) button.
08:30
TI-IPP
00:1A:34:56:78:AB
22 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
continue the session or press the Settings ( ) button to exit the configuration session.
5.11. Language Setting
The IP Phone firmware includes an xml file, which, among other things, determines the languages
available to the phone. The Language setting determines the display of text in the LCD. When the xml
file contains more than one (1) language, you may select the language shown in the display. Note the
Language menu number ‘12’ is used when the IP Phone is equipped with a Bluetooth module. When a
Bluetooth module is not connected, the Language menu number is ‘11’.
To select an available language:
o Press the Settings (
o Dial 3, or move cursor to 3.Phone Settings using the Previous-Next softkeys, and press the OK
softkey.
o Dial 12, or move cursor to 12.Language using the Previous-Next softkeys, and press the OK
softkey.
o Select a Language from the list using the Previous-Next
softkeys, and press the OK softkey. An asterisk, »,
displays in front of the current selection.
o Move to another parameter with the navigation buttons and
continue the session or press the Settings (
) button.
Language
*English
Previous
Next
) button to exit the configuration session.
OK
23 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
Appendix A Dial Pad Character Set
The IP8830 Phone dial pad inputs digits or alphanumeric characters. The table below maps each dial
pad digit to characters available. Three modes are available, dial pad digits, upper case letters and lower
case letters as shown in the table.
Dial Pad Mode
Digit
1 @ : / @ : /
2 A B C a b c
3 D E F d e f
4 G H I g h i
5 J K L j k l
Upper Case
‘[A]’
Lower Case
‘[a]’
6 M N O m n o
7 P Q R S p q r s
8 T U V t u v
9 W X Y Z w x y z
0 . , ? ! . , ? !
* . * . *
# Space (‘ ‘) Space (‘ ‘)
24 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
Appendix B Time Zones
Country No Country No
GMT-12:00 International Date Line, West 60 GMT+01:00 Oslo, Norway 30
GMT-11:00 Midway/Samoa 61 GMT+01:00 Paris, France 31
GMT-10:00 Hawaii 1 GMT+01:00 Rome, Italy 32
GMT-09:00 Alaska 62 GMT+01:00 Stockholm, Sweden 33
GMT-08:00 Los Angeles, California 2 GMT+01:00 Vienna, Austria 34
GMT-08:00 Pacific Standard 3 GMT+02:00 Athens, Greece 35
GMT-07:00 Mountain Standard 4 GMT+02:00 Harare, Z imbabwe 36
GMT-06:00 Central Standard 5 GMT+02:00 Helsinki, Finland 37
GMT-06:00 Mexico City, Mexico 6 GMT+02:00 Istanbul, T urkey 38
GMT-06:00 Saskatc., Canada 7 GMT+02:00 Jerusalem, Israel 39
GMT-05:00 Bogotá, Colombia 8 GMT+03:00 Kuwait 40
GMT-05:00 Eastern Standard 9 GMT+03:00 Moscow, Russia 41
GMT-05:00 Lima, Peru 10 GMT+03:00 Nairobi, Kenya 42
GMT-05:00 New York, NY 11 GMT+03:00 Riyadh, Saudi Arabia 43
GMT-04:00 Atlantic Standard 12 GMT+03:30 Tehran, Iran 44
GMT-04:00 Caracas, Venezuela 13 GMT+04:00 Abu Dhabi, UAE 45
GMT-04:00 La Paz, Bolivia 14 GMT+04:00 Tbilisi, Georgia 46
GMT-03:30 New Found land 15 GMT+04:30 Kabul, Afghanistan 47
GMT-03:00 Brasilia, Brazil 16 GMT+05:00 Islamabad, Pakistan 64
GMT-03:00 Buenos Aires, Argentina 17 GMT+05:30 New Delhi, India 48
GMT-03:00 Georgetown, Guyana 18 GMT+06:00 Dhaka, Bangladesh 65
GMT-02:00 Inuuk, Greenland 63 GMT+06:30 Yangon, Myanmar 66
GMT-01:00 Azores, Portugal 19 GMT+07:00 Bangkok, Thailand 49
GMT-01:00 Cape Verde 20 GMT +07:00 Jakarta, Indonesia 50
GMT 00:00 Casablanca, Morocco 21 GMT+08:00 Beijing, China 51
GMT 00:00 Lisbon, Portugal 22 GMT+09:00 Seoul, Korea 52
GMT 00:00 London, England 23 GMT+09:00 Tokyo, Japan 53
GMT+01:00 Amsterdam, Netherlands 24 GMT+ 09:30 Darwin, Australia 54
GMT+01:00 Berlin, Germany 25 GMT+10:00 Guam Standard 55
GMT+01:00 Bern, Switzerland 26 GMT+11:00 Solomon Islands 67
GMT+01:00 Brussels, Belgium 27 GMT+12:00 Marshall Islands 56
GMT+01:00 Central European 28 GMT+12:00 Auckland, Wellington 57
GMT+01:00 Copenhagen, Denmark 59 GMT+13:00 Nuku’alofa 58
GMT+01:00 Madrid, Spain 29
25 Dec. ‘08
IP8830 Broadworks IP Phone
User Guide
Appendix C IP8830 Icons
Your IP8830 displays various icons in the upper line of the LCD to assist you in understanding the status
of the phone. Below is a list of icons and their meaning.
LAN or Network connection icon indicates the status of the LAN connection to the IP8830. If the
icon is blinking, the LAN connection is faulty. This icon displays as the first icon on the left.
PC Port icon, when displayed, indicates a device, generally a PC, is connected to the PC port of
the IP8830.
Only one of the following Bluetooth icons may display based on status.
Bluetooth module icon indicates the optional Bluetooth module is installed with no paired
headsets. When blinking, the IP8830 is searching or attempting to pair with a headset.
Bluetooth paired icon, indicates one or more (maximum 5) headsets are paired with the module
but none are active. When blinking the IP8830 is attempting to pair or connect a headset
Bluetooth connected icon, indicates a headset is connected to IP8830. When blinking rapidly, the
IP8830 is searching or attempting to pair or disconnect a headset. When blinking slowly, the
Bluetooth headset is in use.
Forward icon indicates calls to the extension are forwarded.
Message icon indicates one or more messages waiting in Voice Mail.
DND icon indicates the IP Phone is in DND and will not notify you of incoming calls.
Hold icon indicates the extension has calls on hold.
Locked icon indicates the IP Phone is locked and a password is required to place calls.
26 Dec. ‘08
LGN8820-1002SBUG-01.00 Dec. ’08
Loading...
